OWNER’S MANUAL

Network 3D Blu-ray Disc™ / DVD Player

Please read this manual carefully before operating your set and retain it for future reference.

BP740 / BP740N

P/NO : MFL68164531_1.0

www.lg.com

Getting Started2

Safety Information

Getting Started

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK DO NOT REMOVE COVER (OR BACK) NO

USER-SERVICEABLE PARTS INSIDE REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

enclosure that may be of sucient magnitude to constitute a risk of electric shock to persons.

instructions in the literature accompanying the product.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

WARNING: Do not install this equipment in a conned space such as a book case or similar unit.

CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings shall be never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product shall not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing)

Use of controls, adjustments or the performance of procedures other than those specied herein may result in hazardous radiation exposure.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon a dedicated circuit;

That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specication page of this owner’s manual to be certain. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or re. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service center. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. To disconnect power from the mains, pull out the mains cord plug. When installing the product, ensure that the plug is easily accessible.

Getting Started 3

This device is equipped with a portable battery or accumulator.

Safety way to remove the battery or the battery from the equipment: Remove the

old battery or battery pack, follow the steps in reverse order than the assembly. To prevent contamination of the environment and bring on possible threat to human and animal health, the old battery or the battery put it in the appropriate container at designated collection points. Do not dispose of batteries or battery together with other waste. It is recommended that you use local, free reimbursement systems batteries and accumulators. The battery shall not be exposed to excessive heat such as sunshine, re or the like.

CAUTION: The apparatus shall not be exposed to water (dripping or splashing) and no objects lled with liquids, such as vases, shall be placed on the apparatus.

Disposal of your old appliance

1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC.

2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health.

4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product.

Disposal of waste batteries/accumulators

1. When this crossed-out wheeled bin symbol is attached to batteries/ accumulators of Your product it means they are covered by European Directive 2006/66/EC.

2. This symbol may be combined with chemical symbols for mercury(Hg), cadmium(Cd) or lead(Pb) if the battery Contains more that 0.0005% of mercury, 0.002% of cadmium or

0.004% of lead.

3. All batteries/accumulators should be disposed separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.

4. The correct disposal of Your old batteries/ accumulators will help to prevent potential negative consequences for the environment, animal and human health.

5. For more detailed information about disposal of Your old batteries/ accumulators, please contact Your city office, waste disposal service or the shop where You purchased the product.

Getting Started

Getting Started4

For Wireless product European Union Notice

LG Electronics hereby declares that this/

are in compliance with the essential requirements

Getting Started

and other relevant provisions of Directive 1999/5/ EC, 2004/108/EC, 2006/95/EC, 2009/125/EC and 2011/65/EU.

Please contact to the following address for obtaining a copy of the DoC (Declaration of Conformity).

Contact oce for compliance of this product:

LG Electronics Inc. EU Representative, Krijgsman 1, 1186 DM Amstelveen, The Netherlands

yPlease note that this is NOT a Customer Service

contact point. For Customer Service Information, see Warranty Card or contact the dealer that you purchased this product.

Indoor use only.

RF Radiation Exposure Statement

This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body.

these product(s) is/

Notes on Copyrights

yBecause AACS (Advanced Access Content

System) is approved as content protection system for Blu-ray Disc format, similar to use of CSS (Content Scramble System) for DVD format, certain restrictions are imposed on playback, analog signal output, etc., of AACS protected contents. The operation of this product and restrictions on this product may vary depending on your time of purchase as those restrictions may be adopted and/or changed by AACS after the production of this product.

yFurthermore, BD-ROM Mark and BD+ are

additionally used as content protection systems for Blu-ray Disc format, which imposes certain restrictions including playback restrictions for BD-ROM Mark and/or BD+ protected contents. To obtain additional information on AACS, BDROM Mark, BD+, or this product, please contact an authorized Customer Service Center.

yMany BD-ROM/DVD discs are encoded with

copy protection. Because of this, you should only connect your player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected discs.

yThis product incorporates copyright protection

technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering or disassembly is prohibited.

yUnder the U.S. Copyright laws and Copyright

laws of other countries, unauthorized recording, use, display, distribution, or revision of television programs, videotapes, BD-ROM discs, DVDs, CDs and other materials may subject you to civil and/ or criminal liability.

Important Notice for TV color system

The color system of this player diers according to currently playing discs.

For example, when the player plays the disc recorded in the NTSC color system, the image is output as an NTSC signal.

Only the multi system color TV can receive all signals output from the player.

yIf you have a PAL color system TV, you will see

just distorted images when using discs or video contents recorded in NTSC.

yThe multi system color TV changes the color

system automatically according to input signals. In case that the color system is not changed automatically, turn it o and then on to see normal images on screen.

yEven if the disc recorded in NTSC color system

are well displayed on your TV, these may not be recorded correctly on your recorder.

Getting Started 5

Caution

yWatching a 3D content for a long period

time may cause dizziness or tiredness.

yIt is not recommended to watch a movie

in 3D mode for inrm, child and pregnant woman.

yIf you are experiencing headache, tiredness

or dizziness while viewing contents in 3D, it is strongly recommended to stop the playback and rest until you feel normal.

Getting Started

Table of Contents6

Table of Contents

1 Getting Started

2 Safety Information 8 Introduction 8 – Playable Discs and symbols used in

this manual

9 – About the “7” Symbol Display 9 – Regional Code 9 – System Select 10 Remote Control 11 – Magic remote control functions 12 Front Panel 12 Rear Panel

2 Connecting

13 Connecting to Your TV 14 – What is SIMPLINK? 14 – Resolution Setting 15 Connecting to an Amplifier 15 – Connecting to an Amplifier via HDMI

Output

16 – Connecting to an Amplifier via Digital

Audio Output 17 Connecting to your Home Network 17 – Wired network connection 18 – Wired Network Setup 19 – Wireless network connection 19 – Wireless network setup

3 System Setting

22 Initial Setup 23 Settings 23 – Adjust the Setup Settings 23 – [NETWORK] Menu 25 – [DISPLAY] Menu 27 – [LANGUAGE] Menu 27 – [AUDIO] Menu 29 – [LOCK] Menu 30 – [OTHERS] Menu

4 Operating

32 Home Menu Display 32 – Using [HOME] menu 32 – Using the SmartShare 33 Playing the Linked Devices 33 – Playing a Disc 33 – Playing Blu-ray 3D disc 34 – Playing a file on disc/USB device 35 – Playing a file on Android device 36 – Playing a file on a network server 37 Using Home Network Server for PC 37 – About SmartShare PC Software

(DLNA)

37 – Downloading SmartShare PC

Software (DLNA)

37 – Installing SmartShare PC Software

(DLNA) 38 – Sharing files and folders 38 – System requirements 39 General Playback 39 – Basic operations for video and audio

content 39 – Basic operations for photo content 40 – Resume playback 40 – Last Scene Memory 41 On-Screen Display 41 – To control video playback 42 – To control photo view 43 Advanced Playback 43 – Repeat playback 43 – Repeating a specific portion 43 – Playing from selected time 44 – Selecting a subtitle language 44 – Hearing a different audio 44 – Watching from a different angle 44 – Changing the TV Aspect Ratio 45 – Changing subtitle Code Page 45 – Changing the Picture Mode 46 – Viewing content information 46 – Changing content list view 47 – Selecting a subtitle file 47 – Listening to music during slide show 48 – Playing content to 3D 49 Advanced Features 49 – Wi-Fi Direct™ 50 – Enjoying Miracast™

Table of Contents 7

50 – Enjoying BD-Live™ 51 – Enjoying web browsing 52 – LG AV Remote 52 – Private Sound Mode 52 – Using an USB keyboard or mouse 53 Using the Premium 53 Using the LG Smart World 54 – Signing in 54 – Searching online content 55 Using the My Apps Menu

5 Troubleshooting

56 Troubleshooting 56 – General 57 – Network 58 – Picture 58 – Customer support 58 – Open source software notice

6 Appendix

59 About Magic Remote Control 60 Network Software Update 60 – Network update notification 60 – Software update 62 Additional Information 62 – File requirement 63 – AVCHD (Advanced Video Codec High

Definition) 64 – About DLNA 64 – Certain system requirements 64 – Compatibility notes 65 Audio Output Specifications 67 Area Code List 68 Language Code List 69 Trademarks and Licenses 71 Specifications 72 Maintenance 72 – Handling the unit 72 – Notes on discs

73 Important Information Relating to

Network Services

Some of the content in this manual may dier from your player depending on the software of the player or your service provider.

Getting Started8

Introduction

Playable Discs and symbols used in this manual

Getting Started

Media/Term Logo Symbol Description

yDiscs such as movies that can be purchased or

rented.

y“Blu-ray 3D” discs and “Blu-ray 3D ONLY” discs.

yBD-R/RE discs that are recorded in BDAV format.

yBD-R/RE discs that contain Movie, Music or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

yDiscs such as movies that can be purchased or

rented.

yMovie mode and nalized only

ySupports the dual layer disc also

Finalized AVCHD format

yDVD±R/RW discs that contain Movie, Music or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

Blu-ray

DVD-ROM

DVD-R

DVD-RW

DVD+R

DVD+RW

y u i

DVD-RW (VR)

Audio CD

CD-R/RW

Note –

Caution –

y u i

VR mode and nalized only

Audio CD

yCD-R/RW discs that contain Movie, Music or

Photo les.

yISO 9660+JOLIET, UDF and UDF Bridge format

Indicates special notes and operating features.

Indicates cautions for preventing possible damages from abuse.

Note

yDepending on the conditions of the

recording equipment or the CD-R/RW (or DVD±R/RW) disc itself, some CD-R/RW (or DVD±R/RW) discs cannot be played on the unit.

yDepending on the recording software & the

nalization, some recorded discs (CD-R/RW, DVD±R/RW, BD-R/RE) may not be playable.

yBD-R/RE, DVD±R/RW and CD-R/RW discs

recorded using a personal computer or a DVD or CD Recorder may not play if the disc is damaged or dirty, or if there is dirt or condensation on the player’s lens.

yIf you record a disc using a personal

computer, even if it is recorded in a compatible format, there are cases in which it may not play because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

yThis player requires discs and recordings to

meet certain technical standards in order to achieve optimal playback quality.

yPre-recorded DVDs are automatically set to

these standards. There are many dierent types of recordable disc formats (including CD-R containing MP3 or WMA les) and these require certain pre-existing conditions to ensure compatible playback.

yCustomers should note that permission

is required in order to download MP3 / WMA les and music from the Internet. Our company has no right to grant such permission. Permission should always be sought from the copyright owner.

yYou have to set the disc format option

to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live System, you cannot use it on LG player. (Mastered/Live File System : Disc format system for windows Vista)

Getting Started 9

About the “7” Symbol Display

“7” may appear on your TV display during operation and indicates that the function explained in this owner’s manual is not available on that specic media.

Regional Code

This unit has a regional code printed on the rear of the unit. This unit can play only BD-ROM or DVD discs labelled same as the rear of the unit or “ALL”.

System Select

Open the disc tray using the R (OPEN/CLOSE) button and then, press and hold red (R) colored button for more than ve seconds to change the color system (PAL /NTSC /AUTO).

Getting Started

Getting Started10

Remote Control

Getting Started

Remote Control Indicator:

(RF & Bluetooth transmitter) Blinks when operating.

(POWER): Switches the

b 1

unit ON or OFF.

BACK (1): Exits the menu

or returns to the previous screen.

HOME (b): Displays the

Home screen.

Direction buttons (

): Selects an option in

a/d

the menu. If you press the navigation button while moving the pointer on the screen, the pointer disappears, and the Magic remote control works as a regular remote control. To display the pointer again, shake the Magic remote control from side to side.

w/s/

Wheel (a): Selects menus

or options and conrms your input; Scrolls the screen to search a menu on the web browser.

(Play/Pause): Starts

g N

playback./Pauses playback.

Z (Stop): Stops playback.

c/v

backward or forward. (Press and hold

C/V

next track or le.

exits On-Screen Display.

use a virtual numbered keypad. (Press and hold m (INFO/MENU))

Colored (R, G, Y, B) buttons:

Use to navigate BD-ROM menus. They are also used as shortcut buttons for specic menus.

: Searches

C/V

(INFO/MENU): Displays or

: If necessary, you can

)

: Moves previous/

Getting Started 11

WHEEL

Magic remote control functions

The Magic remote control operates by pairing with your unit. Once you purchased the unit, please register the Magic remote control as follows;

To register the Magic remote control

To use the Magic remote control, register it with your unit rst.

1. Turn on the unit and wait for about 10 seconds

and then press and hold Wheel (a) button while pointing the remote control at the unit.

2. The remote control is automatically registered

and a registration completion message appears on the screen.

Note

If you failed to register the Magic remote control, turn o the unit and try again.

Battery Installation

How to use Magic remote control

y Shake the remote control slightly to make the

pointer appear on the screen.

y Shake the Magic remote control slightly to the

right and left to make the pointer appear on the center of screen.

y The magic pointer disappears when the remote

control is not moved for ve seconds.

How to use Magic remote tip

y When you press the wheel, it also functions as

Selection button.

y You can scroll through menus using the wheel.

y Use your wrist to move the pointer more easily.

Note

yIf the Magic remote control’s connection is

unstable or has any problems, cancel the registration and try it again. (page 59)

yDepending on the content, the pointing of

the magic remote control does not work. For controlling, please use the direction keys on the remote.

Getting Started

Open the battery cover at the bottom of the Remote Control, and insert two (1.5 V AA ) alkaline batteries with 4 and 5 matched correctly.

Caution

Do not mix old and new batteries, as this may damage the remote control.

Getting Started12

Front Panel

Getting Started

Disc Tray

Display Window

Remote Sensor

(OPEN / CLOSE)

d R

Rear Panel

AC power cord

DIGITAL AUDIO OUT (OPTICAL)

e T

(STOP)

f I g 1/!

USB Port

LAN port

HDMI OUT

(PLAY / PAUSE)

(POWER)

Connecting 13

Connecting to Your TV

If you have a HDMI TV or monitor, you can connect it to this player using a HDMI cable (Type A, High Speed HDMI™ Cable). Connect the HDMI jack on the player to the HDMI jack on a HDMI compatible TV or monitor.

Rear of the unit

HDMI cable

Set the TV’s source to HDMI (Refer to TV’s Owner’s manual).

Note

Please refer to the manuals of your TV, Stereo System or other devices as necessary to make the best connections.

Additional Information for HDMI

yWhen you connect a HDMI or DVI compatible

device make sure of the following:

-Try switching o the HDMI/DVI device and this player. Next, switch on the HDMI/DVI device and leave it for around 30 seconds, then switch on this player.

-The connected device’s video input is set correctly for this unit.

-The connected device is compatible with 720x576p, 1280x720p, 1920x1080i or 1920x1080p video input.

yNot all HDCP-compatible HDMI or DVI devices

will work with this player.

-The picture will not be displayed properly with non-HDCP device.

Note

yIf a connected HDMI device does not accept

the audio output of the player, the HDMI device’s audio sound may be distorted or may not output.

yWhen you use HDMI connection, you can

change the resolution for the HDMI output. (Refer to “Resolution Setting” on page 14)

ySelect the type of video output from the

HDMI OUT jack using [HDMI Color Setting] option on the [Settings] menu (see page

26).

yChanging the resolution when the

connection has already been established may result in malfunctions. To solve the problem, turn o the player and then turn it on again.

yWhen the HDMI connection with HDCP

is not veried, TV screen is changed to black screen. In this case, check the HDMI connection, or disconnect the HDMI cable.

yIf there are noises or lines on the screen,

please check the HDMI cable (length is generally limited to 4.5 m).

Connecting

Connecting14

What is SIMPLINK?

Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection.

Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power O, etc.

Refer to the TV owner’s manual for the details of

Connecting

SIMPLINK function.

LG TV’s with SIMPLINK function has the logo as shown above.

Note

Depending on the disc type or playing status, some SIMPLINK operation may dier from your purpose or not work.

Resolution Setting

The player provides several output resolutions for HDMI OUT jack. You can change the resolution using [Settings] menu.

1. Press HOME (b).

2. Use Wheel (a). The [Settings] menu appears.

3. Use

4. Use press Wheel (a) to move to the third level.

to select the [Settings] and press

a/d

to select [DISPLAY] option then press

w/s

to move to the second level.

to select the [Resolution] option then

w/s

Note

yIf your TV does not accept the resolution

you have set on the player, you can set resolution to 576p as follows:

1. Press R to open the disc tray.

2. Press I (STOP) for more than 5 seconds.

yIf you select a resolution manually and then

connect the HDMI jack to TV and your TV does not accept it, the resolution setting is set to [Auto].

yIf you select a resolution that your TV

does not accept, the warning message will appear. After resolution change, if you cannot see the screen, please wait 20 seconds and the resolution will automatically revert back to the previous resolution.

yThe 1080p video output frame rate may

be automatically set to either 24 Hz or 50 Hz depending both on the capability and preference of the connected TV and based on the native video frame rate of the content on the BD-ROM disc.

5. Use press Wheel (a) to confirm your selection.

to select the desired resolution then

w/s

Connecting 15

Connecting to an Amplifier

Make one of the following connections, depending on the capabilities of your existing equipment.

yHDMI Audio connection (page 15)

yDigital Audio connection (page 16)

Since many factors aect the type of audio output, see “Audio Output Specications” for details (page

65).

About Digital Multi-channel sound

A digital multi-channel connection provides the best sound quality. For this, you need a multichannel Audio/Video Receiver that supports one or more of the audio formats supported by your player. Check the logos on the front of the Audio/ Video receiver and the manual. (PCM Stereo, PCM Multi-Ch, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and/or DTS-HD)

Connecting to an Amplifier via HDMI Output

Connect the player’s HDMI OUT jack to the corresponding in jack on your amplier using a HDMI cable.

Rear of the unit

Connecting

HDMI cable

Receiver/Amplier

HDMI cable

Connect the amplier’s HDMI output jack to HDMI input jack on your TV using a HDMI cable if your amplier has HDMI output jack. (Refer to amplier’s owner’s manual)

You will need to activate the player’s digital output. (See “[AUDIO] Menu” on page 27.)

Connecting16

Connecting to an Amplifier via Digital Audio Output

Connect the player’s OPTICAL AUDIO OUT jack to the corresponding in jack on your amplier using an optional digital audio cable.

Rear of the unit

Connecting

Optical cable

Receiver/Amplier

You will need to activate the player’s digital output. (See “[AUDIO] Menu” on page 27.)

Connecting 17

Connecting to your Home Network

This player can be connected to a local area network (LAN) via the LAN port on the rear panel or the internal wireless module. By connecting the unit to a broadband home network, you have access to services such as software updates, BD-Live interactivity and on-line content services.

Wired network connection

Using a wired network provides the best performance, because the attached devices connect directly to the network and are not subject to radio frequency interference.

Please refer to the documentation for your network device for further instructions.

Connect the player’s LAN port to the corresponding port on your Modem or Router using a commercially available LAN or Ethernet cable.

Note

yWhen plugging or unplugging the LAN

cable, hold the plug portion of the cable. When unplugging, do not pull on the LAN cable but unplug while pressing down on the lock.

yDo not connect a modular phone cable to

the LAN port.

ySince there are various connection

congurations, please follow the specications of your telecommunication carrier or internet service provider.

yIf you want to access content from DLNA

servers, this player must be connected to the same local area network with them via a router.

yTo set your PC as a DLNA server, install the

SmartShare PC Software on your PC. (page

37)

Broadband service

Router

DLNA certied servers

Rear of the unit

Connecting

Connecting18

Wired Network Setup

If there is a DHCP server on the local area network (LAN) via wired connection, this player will automatically be allocated an IP address. After making the physical connection, a small number of home networks may require the player’s network setting to be adjusted. Adjust the [NETWORK] setting as follow.

Connecting

Preparation

Before setting the wired network, you need to connect the broadband internet to your home network.

1. Select [Connection Setting] option in the [Settings] menu then press Wheel (a).

2. Read the preparations for the network settings and then press Wheel (a) while [Start] is highlighted.

Advanced Setting

If you want to set the network settings manually, use [Network Setting] menu and press Wheel (a).

1. Use

2. Use

to select [Advanced Setting] on the

w/s

to select [Wired] and press Wheel

w/s

(a).

w/s/a/d

between [Dynamic] and [Static].

Normally, select [Dynamic] to allocate an IP address automatically.

Note

If there is no DHCP server on the network and you want to set the IP address manually, select [Static] then set [IP Address], [Subnet Mask], [Gateway] and [DNS Server].

to select the IP mode

Network will automatically be connected to the unit.

3. Select [Next] and press Wheel (a) to apply network settings.

Network connection status is displayed on the screen.

4. Press Wheel (a) while [OK] is highlighted to finish the wired network settings.

Connecting 19

Wireless network connection

Another connection option is to use an Access Point or a wireless router. The network conguration and connection method may vary depending on the equipment in use and the network environment.

Wireless

Communication

DLNA certied servers

Access Point or Wireless Router

Broadband service

Refer to the setup instructions supplied with your access point or wireless router for detailed connection steps and network settings.

For best performance, a direct wired connection from this player to your home network’s router or cable/DSL modem is always the best option. If you do chose to use the wireless option, note that performance can sometimes be aected by other electronic devices in the home.

Wireless network setup

For the wireless network connection, the player needs to be set up for network communication. This adjustment can be done from the [Settings] menu. Adjust the [NETWORK] setting as follow. Setting up the access point or the wireless router is required before connecting the player to the network.

Preparation

Before setting the wireless network, you need to:

-connect the broadband internet to the wireless home network.

-set the access point or wireless router.

-note the SSID and security code of the network.

1. Select [Connection Setting] option in the [Settings] menu then press Wheel (a).

2. Read the preparations for the network settings and then press Wheel (a) while [Start] is highlighted.

If wired network is not connected to the unit, all available networks are displayed on the screen.

3. Use network and press Wheel (a).

If you have security on your access point, you need to input the security code as necessary.

If you use other characters than the english alphabet or digits for the SSID name of your access point or wireless router, it may be displayed dierently.

to select a desired SSID of wireless

w/s

Note

Connecting

Connecting20

Note

Connecting

yWEP security mode generally have 4 keys

available on an access point setting. If your access point or wireless router use WEP security, enter the security code of the key “No.1” to connect on your home network.

yAn Access Point is a device that allows you

to connect to your home network wirelessly.

4. Use

w/s/a/d

between [Dynamic] and [Static]. Normally, select [Dynamic] to allocate an IP address automatically.

Note

If there is no DHCP server on the network and you want to set the IP address manually, select [Static] then set [IP Address], [Subnet Mask], [Gateway] and [DNS Server].

5. Select [Next] and press Wheel (a) to apply network settings.

Network connection status is displayed on the screen.

6. Select [OK] and press Wheel (a) to complete the network connection.

to select the IP mode

Advanced Setting

If you want to set the network settings manually, use [Network Setting] menu and press Wheel (a).

1. Use

2. Follow the instructions of each connection

to select [Advanced Setting] on the

w/s

to select [Wireless] and press Wheel

w/s

(a).

[AP List] - Scans all available access points or

wireless routers within range and display them as a list.

[Network name (SSID)] – Your access point may not be broadcasting its network name (SSID). Check your access point settings through your computer and either set your access point to broadcast SSID, or manually enter the network name in [Network name(SSID)].

[PBC] – If your access point or wireless router that supports the PBC (Push Button Configuration) method, select this option and press the Push Button on your access point within 120 counts. You do not need to know the network name (SSID) and security code of your access point.

[PIN] – If your access point supports the PIN Code configuration method based on WPS(WiFi Protected Setup), select this option and note the code number on the screen. And then, enter the PIN number on a setting menu of your access point to connect. Refer to the documentation for your network device.

method on the screen.

Note

To use PBC and PIN network connection, security mode of your access point must be set to OPEN or AES.

Connecting 21

Notes on Network Connection

yMany network connection problems during

set up can often be xed by re-setting the router or modem. After connecting the player to the home network, quickly power o and/ or disconnect the power cable of the home network router or cable modem. Then power on and/or connect the power cable again.

yDepending on the internet service provider (ISP),

the number of devices that can receive internet service may be limited by the applicable terms of service. For details, contact your ISP.

yOur company is not responsible for any

malfunction of the player and/or the internet connection feature due to communication errors/malfunctions associated with your broadband internet connection, or other connected equipment.

yThe features of BD-ROM discs made available

through the Internet Connection feature are not created or provided by our company, and our company is not responsible for their functionality or continued availability. Some disc related material available by the Internet Connection may not be compatible with this player. If you have questions about such content, please contact the producer of the disc.

ySome internet contents may require a higher

bandwidth connection.

yEven if the player is properly connected and

congured, some internet contents may not operate properly because of internet congestion, the quality or bandwidth of your internet service, or problems at the provider of the content.

ySome internet connection operations may not

be possible due to certain restrictions set by the Internet service provider (ISP) supplying your broadband Internet connection.

yAny fees charged by an ISP including, without

limitation, connection charges are your responsibility.

yA 10 Base-T or 100 Base-TX LAN port is required

for wired connection to this player. If your internet service does not allow for such a connection, you will not be able to connect the player.

yYou must use a Router to use xDSL service.

yA DSL modem is required to use DSL service and

a cable modem is required to use cable modem service. Depending on the access method of and

subscriber agreement with your ISP, you may not be able to use the internet connection feature contained in this player or you may be limited to the number of devices you can connect at the same time. (If your ISP limits subscription to one device, this player may not be allowed to connect when a PC is already connected.)

yThe use of a “Router” may not be allowed or its

usage may be limited depending on the policies and restrictions of your ISP. For details, contact your ISP directly.

yThe wireless network operate at 2.4 GHz

radio frequencies that are also used by other household devices such as cordless telephone, Bluetooth® devices, microwave oven, and can be aected by interference from them.

yTurn o all unused network equipment in

your local home network. Some devices may generate network trac.

yFor the purpose of the better transmission,

placing the player from the access point as close as possible.

yIn some instances, placing the access point or

wireless router at least 0.45 m above the oor may improve the reception.

yMove closer to the access point if possible or re-

orient the player so there is nothing between it and the access point.

yThe reception quality over wireless depends on

many factors such as type of the access point, distance between the player and access point, and the location of the player.

ySet your access point or wireless router to

Infrastructure mode. Ad-hoc mode is not supported.

Connecting

System Setting22

Initial Setup

When you turn on the unit for the rst time, the initial setup wizard appears on the screen. Set the display language and network settings on the initial setup wizard.

1. Press 1 (POWER).

The initial setup wizard appears on the screen.

2. Use

w/s/a/d

and press Wheel (a).

3. Try the some features of your Magic remote

System Setting

control by following the guide on the screen.

4. Read and prepare the preparations for the network settings and then press Wheel (a) while [Start] is highlighted.

to select a display language

6. Use

w/s/a/d

between [Dynamic] and [Static]. Normally, select [Dynamic] to allocate an IP address automatically.

7. Select [Next] and press Wheel (a) to apply network settings.

Network connection status is displayed on the screen.

For details on network settings, refer to “Connecting to your Home Network” on page

17.

8. Check all the settings that you have set in the previous steps.

to select the IP mode

If wired network is connected, the network connection setting will automatically be finished.

5. All available networks are displayed on the screen. Use or desired SSID of wireless network and press Wheel (a).

If you have security on your access point, you need to input the security code as necessary.

to select [Wired Network]

w/s

Press Wheel (a) while [Finish] is highlighted to finish the initial setup settings. If there is any settings to be changed, use select 1 and press Wheel (a).

9. Displays private sound mode guide. Press Wheel (a).

w/s/a/d

System Setting 23

Settings

Adjust the Setup Settings

You can change the settings of the player in the [Settings] menu.

1. Press HOME (b).

2. Use Wheel (a). The [Settings] menu appears.

3. Use press Wheel (a) to the second level.

4. Use press Wheel (a) to move to the third level.

to select the [Settings] and press

a/d

to select the first setup option, and

s/w

to select a second setup option, and

s/w

[NETWORK] Menu

The [NETWORK] settings are needed to use the software update, BD-Live and on-line content services.

Connection Setting

If your home network environment is ready to connect the player, the player needs to be set the wired or wireless network connection for network communication. (See “Connecting to your Home Network” on page 17.)

Connection Status

If you want to check the network status on this player, select the [Connection Status] options and press Wheel (a) to check whether a connection to the network and the internet have been established.

BD-LIVE connection

You can restrict Internet access when BD-Live functions are used.

[Permitted]

Internet access is permitted for all BD-Live contents.

[Partially permitted]

Internet access is permitted only for BDLive contents which have content owner certicates. Internet access and AACS Online functions are prohibited for all BD-Live contents without a certicate.

[Prohibited]

Internet access is prohibited for all BD-Live contents.

System Setting

5. Use Wheel (a) to conrm your selection.

to select a desired setting, and press

s/w

System Setting24

Smart Service Setting

[Country Setting]

Select your area for displaying proper online content service.

[Initialize]

Depending on the region, [Initialize] function may not be available.

Device Name

You can make a network name using virtual keyboard. This player will be recognised by the name you are entering on your home network.

Wi-Fi Direct

System Setting

This player is a Wi-Fi Direct™ certied device. WiFi Direct is the technology that devices to connect each other without connecting to an Access point or a router. Press Wheel (a) to display the WiFi Direct menu. Refer to page 49 for the device connection.

Network Play

This function allows you to control the playback of media streamed from DLNA media server by a DLNA certied smartphone. Most DLNA certied smartphone has a function to control the playback media on your home network. Set this option to [On] for allowing your smartphone to control this unit. Refer to instructions of your DLNA certied smartphone or the application for more detailed information.

Note

yThis unit and the DLNA certied

smartphone must be connected to the same network.

yTo use the [Network Play] function using a

DLNA certied smartphone, press HOME (b) to display the home menu before connecting to this unit.

yWhile controlling the unit using the

[Network Play] function, the remote control may not work.

yAvailable le formats described on page

62 are not always supported on [Network Play] function.

System Setting 25

[DISPLAY] Menu

TV Aspect Ratio

Select a TV aspect ratio option according to your TV type.

[4:3 Letter Box]

Select when a standard 4:3 TV is connected. Displays theatrical images with masking bars above and below the picture.

[4:3 Pan Scan]

Select when a standard 4:3 TV is connected. Displays pictures cropped to ll your TV screen. Both sides of the picture are cut o.

[16:9 Original]

Select when a 16:9 wide TV is connected. The 4:3 picture is displayed with an original 4:3 aspect ratio, with black bars appearing at the left and right sides.

[16:9 Full]

Select when a 16:9 wide TV is connected. The 4:3 picture is adjusted horizontally (in a linear proportion) to ll the entire screen.

Note

You cannot select [4:3 Letter Box] and [4:3 Pan Scan] option when the resolution is set to higher than 720p.

Resolution

Sets the output resolution of the HDMI video signal. Refer to page 14 for details about the resolution setting.

[Auto]

If the HDMI OUT jack is connected to TVs providing display information (EDID), automatically selects the resolution best suited to the connected TV.

[576p]

Outputs 576 lines of progressive video.

[720p]

Outputs 720 lines of progressive video.

[1080i]

Outputs 1080 lines of interlaced video.

[1080p]

Outputs 1080 lines of progressive video.

Ultra HD Upscaling

This feature allows the unit to up-scale the original video resolution to Ultra HD resolution and output via HDMI connection.

[Auto]

If you connect a display capable of displaying Ultra HD resolution, this unit will output video signals in Ultra HD resolution automatically.

[O ]

The unit will turn o the Up-scaling feature.

System Setting

Note

yThis unit will output video signals in Ultra

HD resolution when it plays BD-ROM disc formatted in 24 Hz.

yThe playback pictures may be momentarily

interrupted when the resolutions switch.

System Setting26

1080p Display Mode

When the resolution is set to 1080p, select [24 Hz] for smooth presentation of lm material (1080p/24 Hz) with a HDMI-equipped display compatible with 1080p/24 Hz input.

Note

yWhen you select [24 Hz], you may

experience some picture disturbance when the video switches video and lm material. In this case, select [50 Hz].

yEven when [1080p Display Mode] is set to

[24 Hz], if your TV is not compatible with 1080p/24 Hz, the actual frame frequency of

System Setting

the video output will be 50 Hz to match the video source format.

HDMI Color Setting

Select the type of output from the HDMI OUT jack. For this setting, please refer to the manuals of your display device.

[YCbCr]

Select when connecting to a HDMI display device.

[RGB]

Select when connecting to a DVI display device.

3D Mode

Select the type of output mode for Blu-ray 3D disc playback. (This function is activated only when 3D TV is connected.)

[On]

Blu-ray 3D disc playback will output as 3D mode.

[O ]

Blu-ray 3D disc playback will output as 2D mode like a normal BD-ROM disc playback.

Home Menu Guide

This function allows you to display or delete the guide bubble on the Home Menu. Set this option to [On] for displaying guide.

System Setting 27

[LANGUAGE] Menu

Display Menu

Select a language for the [Settings] menu and onscreen display.

Disc Menu/Disc Audio/ Disc Subtitle

Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu.

[Original]

Refers to the original language in which the disc was recorded.

[Other]

Press Wheel (a) to select another language. Enter the corresponding 4-digit number according to the language code list on page

68.

[O] (Disc Subtitle only)

Turn o subtitle.

Note

Depending on the disc, your language setting may not work.

[AUDIO] Menu

Each disc has a variety of audio output options. Set the player’s Audio options according to the type of audio system you use.

Note

Since many factors aect the type of audio output, see “Audio Output Specications” on page 65 for details.

Digital Output

[Auto]

Select if you connect this unit’s DIGITAL AUDIO OUT and HDMI OUT jack to a device with LPCM, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and DTS-HD decoder.

[PCM]

Select if you connect this unit’s HDMI OUT jack to a device with digital decoder or DIGITAL AUDIO OUT jack to a device with two channel digital stereo decoder.

[DTS Re-Encode]

Select if you connect this unit’s HDMI OUT or DIGITAL AUDIO OUT jack to a device with DTS decoder.

Note

yWhen [Digital Output] option is set to

[Auto], the audio may output as bitstream. If the bitstream information is not detected from HDMI device with EDID, the audio may output as PCM.

yIf the [Digital Output] option is set to [DTS

Re-Encode], the DTS Re-Encode audio is outputted for BD-ROM discs with secondary audio and the original audio is outputted for the other discs (like [Auto]).

System Setting

System Setting28

Sampling Freq. (Digital Audio Output)

[48 kHz]

Select this if your A/V Receiver or Amplier is not capable of handling 192 kHz and 96 kHz signal. When this choice is made, this unit automatically converts any 192 kHz and 96 kHz signals to 48 kHz so your system can decode them.

[96 kHz]

Select this if your A/V Receiver or Amplier is not capable of handling 192 kHz signals. When

System Setting

this choice is made, this unit automatically converts any 192 kHz signals to 96 kHz so your system can decode them.

[192 kHz]

Select this if your A/V Receiver or Amplier is capable of handling 192 kHz signals.

Check the documentation for your A/V Receiver or Amplier to verify its capabilities.

DRC (Dynamic Range Control)

This function allows you to listen to a movie at a lower volume without losing clarity of sound.

[Auto]

The dynamic range of the Dolby TrueHD audio output is specied by itself. And the dynamic range of the Dolby Digital and Dolby Digital Plus are operated as same as the [On] mode.

[On]

Compress the dynamic range of the Dolby Digital, Dolby Digital Plus or Dolby TrueHD audio output.

[O ]

Turns o this function.

Note

The DRC setting can be changed only when a disc is not inserted or the unit is in complete stop mode.

System Setting 29

[LOCK] Menu

The [LOCK] settings aect only BD-ROM and DVD playback.

To access the any features in [LOCK] settings, you must enter the 4-digit security code you have created. If you have not entered a password yet, you are prompted to do so. Enter a 4-digit password twice, and press Wheel (a) to create a new password.

Password

You can create or change the password.

[None]

Enter a 4-digit password twice, and press

Wheel (a) to create a new password.

[Change]

Enter the current password and press Wheel (a). Enter a 4-digit password twice, and press Wheel (a) to create a new password.

If you forget your password

If you forget your password, you can clear it using the following steps:

1. Remove any disc that might be in the player.

2. Highlight [Password] option in the [Settings] menu.

3. Use colored buttons to enter “Red -> Green -> Yellow -> Green -> Yellow -> Blue”. The password is cleared.

DVD Rating

Blocks playback of rated DVD based on their content. (Not all discs are rated.)

[Rating 1-8]

Rating one (1) has the most restrictions and rating eight (8) is the least restrictive.

[Unlock]

If you select [Unlock], parental control is not active and the disc plays in full.

Blu-ray Disc Rating

Set an age limit of BD-ROM play. Use number buttons to input an age limit for BD-ROM viewing.

[255]

All BD-ROM can be played.

[0-254]

Prohibits play of BD-ROM with corresponding ratings recorded on them.

Note

The [Blu-ray Disc Rating] will be applied only for the Blu-ray disc that containing the Advanced Rating Control.

Area Code

Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 67.

System Setting

System Setting30

[OTHERS] Menu

Pointer

Sets the speed and size of the Magic remote control’s magic pointer.

[Speed]

Sets the moving speed of the magic pointer.

[Size]

Chooses the size of the magic pointer.

DivX® VOD

ABOUT DIVX VIDEO: DivX® is a digital video

format created by DivX, LLC, a subsidiary of Rovi

System Setting

Corporation. This is an ocial DivX Certied® device that has passed rigorous testing to verify that it plays DivX video. Visit divx.com for more information and software tools to convert your les into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod. divx.com for more information on how to complete your registration.

[Register]

Displays the registration code of your player.

[Deregister]

Deactivate your player and display the deactivation code.

Quick Start

This player can stay in standby mode with low power consumption, so that the player can instantly boot without delay when you turn on this unit. Set this option to [On] for activating [Quick Start] function.

Note

yIf [Quick Start] option is set to [On] and an

AC power is accidently re-connected to the player by power failure etc., the player automatically boots itself to be the standby status. Before operating the player, wait for a while until the player is in standby status.

yWhen [Quick Start] is set to [On], power

consumption will be higher than when [Quick Start] is set to [O ].

Auto Power Off

The screen saver appears when you leave the player in Stop mode for about 5 minutes. If you set this option to [On], the unit automatically turns o within 15 minutes since the Screen Saver is displayed. Set this option to [O] to leave the screen saver until the unit is operated by the user.

Note

All the downloaded videos from DivX(R) VOD with this player’s registration code can only be played on this unit.

Initialize

[Factory Set]

You can reset the player to its original factory settings.

[Blu-ray Storage Clear]

Initializes the BD-Live contents from the connected USB storage.

Note

If you reset the player to its original factory settings using [Factory Set] option, you have to set all the activation for the on-line services and network settings again.

Software

[Information]

Displays the current software version.

[Update]

You can update the software by connecting the unit directly to the software update server (see page 60).

System Setting 31

System Setting

Daylight Saving Time

When you use the BBC App, this function sets the time ahead one hour for daylight saving time (GMT+1).

[On]

Sets the time ahead one hour.

[O ]

Turns o this function.

Operating32

Home Menu Display

Using [HOME] menu

The home menu appears when you press HOME

Operating

(b). Use press Wheel (a).

w/s/a/d

Note

Depending on the region, the [LG Smart World], [My Apps], [d] and [c] may not be available.

[SmartShare] - Displays SmartShare menu.

[Premium] - Displays the Premium home

screen. (page 53)

[LG Smart World] - Displays LG Apps titles

provided to the unit. (page 53)

[My Apps] - Displays the [My Apps] screen.

(page 55)

[Settings] - Adjusts the system settings.

[d] - Searches for desired LG Apps and other

content.

[c] - Displays login menu.

to select a category and

Using the SmartShare

You can play video, photo and audio content on the unit by inserting a disc, connecting an USB device and Android device (MTP) or using home network (DLNA).

1. Press HOME (b) to display the home menu.

2. Select [SmartShare] and press Wheel (a).

Displays all linked devices.

Displays video, photo or audio content.

Displays the le or folder on linked device.

Operating 33

Playing the Linked Devices

Playing a Disc

erot

1. Press R (OPEN/CLOSE), and place a disc on the disc tray.

2. Press R (OPEN/CLOSE) to close the disc tray. For the most Audio CD, BD-ROM and DVD-ROM discs, playback starts automatically.

3. Press HOME (b) and then select [SmartShare].

4. Select disc icon.

Note

yPlayback functions described in this manual

are not always available in every les and media. Some functions can be restricted depending on many factors.

yDepending on the BD-ROM titles, a USB

device connection may be needed for the proper playback.

yUnnalized DVD-VR format discs may not

be played in this player.

ySome DVD-VR discs are made with CPRM

data by DVD RECORDER. This unit cannot support these kinds of discs.

Playing Blu-ray 3D disc

This player can play the Blu-ray 3D discs which contains separate views for the left and right eyes.

Preparation

In order to playback Blu-ray 3D title in stereoscopic 3D mode, you need to:

Check your TV is 3D capable and has HDMI

input(s).

y Wear 3D glasses to enjoy the 3D experience

if it is necessary.

Check whether the BD-ROM title is the Blu-

ray 3D disc or not.

Connect an HDMI cable (Type A, High

Speed HDMI™ Cable) between the player’s HDMI output and TV’s HDMI input.

1. Press HOME (b), and set the [3D Mode] option on the [Settings] menu to [On] (page 26).

2. Press R (OPEN/CLOSE), and place a disc on the disc tray.

3. Press R (OPEN/CLOSE) to close the disc tray. The playback starts automatically.

4. Refer to the owner’s manual of your 3D-ready TV for the further instruction.

You may need to adjust the display settings and focus on your TV’s setting for the improved 3D eect.

Caution

yWatching a 3D content for a long period

time may cause dizziness or tiredness.

yIt is not recommended to watch a movie

in 3D mode for inrm, child and pregnant woman.

yIf you are experiencing headache, tiredness

or dizziness while viewing contents in 3D, it is strongly recommended to stop the playback and rest until you feel normal.

Operating

Operating34

Playing a file on disc/USB device

yui

This player can play video, audio and photo les contained in the disc or USB device.

1. Insert a data disc on the tray or connect an USB device.

When you connect the USB device on the HOME menu, the player plays an audio le contained in

the USB storage device automatically. If the USB

Operating

storage device is containing various types of les, a menu for the le type selection will appear.

File loading may take few minutes depending on the number of content stored in the USB storage device. Press Wheel (a) while [Cancel] is selected to stop loading.

2. Press HOME (b).

3. Select [SmartShare] and press Wheel (a).

Notes on USB device

yThis player supports USB ash drive/external

HDD formatted in FAT32 and NTFS when accessing les (music, photo, movie). However, for BD-Live, use the USB ash drive / external HDD formatted in FAT32.

yThis unit can support up to 4 partitions of the

USB device.

yDo not extract the USB device during operation

(play, etc.).

yAn USB device which requires additional

program installation when you have connected it to a computer, is not supported.

yUSB device: USB device that supports USB1.1

and USB2.0.

yVideo, audio and photo les can be played. For

details of playing each le type, refer to the relevant pages.

yRegular back up is recommended to prevent

data loss.

yIf you use an USB extension cable, USB HUB or

USB Multi-reader, the USB device may not be recognized.

ySome USB device may not work with this unit.

ySome digital cameras and mobile phones are

not supported.

yUSB Port of the unit cannot be connected to PC.

The unit cannot be used as a storage device.

4. Select the desired linked device in the category.

5. Select [Movie], [Photo] or [Music].

6. Select a file using (Play/Pause) or Wheel (a) to play the file.

w/s/a/d

, and press N

Operating 35

Playing a file on Android device

yui

This player can play video, audio and photo les contained in the Android device.

1. Connect the Android device to the unit with USB cable. Make sure that MTP is activated on Android device.

2. Press HOME (b).

3. Select [MTP] and press Wheel (a).

File loading may take few minutes depending

on the number of content stored in the Android device.

4. Select [Movie], [Photo] or [Music].

Notes on Connecting Android device

yThis unit can support only the MTP (Media

Transfer Protocol) Android device.

yDo not extract the Android device during

operation (play, etc.).

yVideo, audio and photo les can be played. For

details of operations on each le, refer to relevant pages.

yRegular back up is recommended to prevent

data loss.

yIf you use an USB extension cable, USB HUB or

USB Multi-reader, the Android device may not be recognized.

ySome Android devices may not work with this

unit.

yWhen you use MTP, playing some music, photo,

movie, or subtitle les may not work depending on the Android device.

Operating

5. Select a file using (Play/Pause) or Wheel (a) to play the file.

w/s/a/d

, and press N

Operating36

Playing a file on a network server

yui

This player can play video, audio and photo les located in a DLNA server through your home network.

1. Check the network connection and settings (page 17).

2. Press HOME (b).

3. Select [SmartShare] and press Wheel (a).

4. Select a DLNA media server in the category.

5. Select [Movie], [Photo] or [Music].

Operating

6. Select a file using (Play/Pause) or Wheel (a) to play the file.

w/s/a/d

, and press N

Note

yThe le requirements are described on page

62.

yThe thumbnail of the unplayable les can

be displayed, but those cannot be played on this player.

yThe subtitle le name and video le name

have to be the same and located at the same folder.

yThe playback and operating quality may be

aected by your home network condition.

yYou may experience connection problems

depending on your server’s environment.

yTo set your PC as a DLNA server, install the

SmartShare PC Software on your PC. (page

37)

Operating 37

Using Home Network Server for PC

DLNA stands for Digital Living Network Alliance, which allows users to access video, photo and audio les stored in server and enjoy them on TV via home networking.

Before connecting to PC to play a le, SmartShare PC Software (DLNA) should be installed on your PC.

About SmartShare PC Software (DLNA)

SmartShare PC Software (DLNA) is for sharing video, audio and photo les stored on your computer to this unit as a DLNA-compatible digital media server.

Downloading SmartShare PC Software (DLNA)

1. Start up your computer, visit http://www.lg.com. If necessary, select your region.

2. Click support tab.

3. Fill your model name on the cover of owner’s manual in search bar.

4. Find and download the “SmartShare PC Software (DLNA)” le.

Installing SmartShare PC Software (DLNA)

1. Before installation, close all running programs including rewall and Anti-Virus programs.

2. Unzip and double-click “Setup.exe” to install SmartShare PC Software (DLNA). The installation is prepared and the installation wizard appears.

3. Follow the directions of the installation wizard displayed on the screen.

4. Click the [Exit] button to complete the installation.

Note

ySmartShare PC Software is not supported

with Mac OS.

yThe SmartShare PC Software (DLNA) is

a customized software edition only for sharing les and folders to this player.

yThis manual explains operations with the

English version of SmartShare PC Software (DLNA) as examples. Follow the explanation referring to the actual operations of your language version.

Operating

Operating38

Sharing files and folders

On your computer, you must share the folder containing video, audio and/or photo content to play them on this player.

This part explains the procedure for selecting the shared folders on your computer.

1. Double-click the “SmartShare” icon.

2. Click [Movie], [Photo] or [Music] icon on the center, and then click [Settings] on the top right corner of the SmartShare PC Software. The [Settings] menu appears on the screen.

3. Click [My Shared Contents] tab, and then click

icon. The [Add/Remove Shared Folders]

menu appears on the screen.

4. Click the folder containing the les you want to share and then click the [OK]. The checked folder is added to the [My Shared Contents] and then click the [OK] at the bottom of the

Operating

[Settings] menu.

5. Make sure that the SmartShare (DLNA) service turns on at the [Service] tab.

Note

yIf the shared folders or les are not displayed

on the player, click the [My Shared Contents] on the [Settings] menu, and then click icon.

yFor more information, click [HELP] on the

[Settings] menu.

System requirements

Minimum System

yCPU : Intel® 2.0 GHz or AMD Sempron™ 2000+

processors

yMemory : 1 GB of free RAM

yGraphics card : 64 MB video memory, minimum

resolution of 1024 x 768 pixels, and 16 bit color settings

yFree Disk Space : 200 MB

yWindows® XP (Service Pack 2 or higher), Windows

Vista®, Windows® 7, Windows® 8.0, Windows® 8.1

yWindows® Media Player® 11.0 or higher

yNetwork environment: 100 Mb Ethernet, WLAN

Recommended System

yCPU : Intel® Core™ Duo or AMD Athlon™ 64X2,

1.7 GHz or better

yMemory : 2 GB of free RAM

yGraphics card : 128 MB video memory, minimum

resolution of 1024 x 768 pixels, and 16 bit color settings

yFree Disk Space : 200 MB

yWindows® XP (Service Pack 2 or higher), Windows

Vista®, Windows® 7, Windows® 8.0, Windows® 8.1

yWindows® Media Player® 11.0 or higher

yNetwork environment: 100 Mb Ethernet, WLAN

Operating 39

General Playback

Basic operations for video and audio content

To stop playback

Press Z (STOP) during playback.

To pause playback

Press N (Play/Pause) during playback. Press N (Play/Pause) to resume playback.

To scan forward or backward

Press and hold C or V to play fast forward or fast reverse during playback. On scanning you can change the various playback speeds by pressing

or V repeatedly.

To slow down the playing speed (Video)

While the playback is paused, press and hold V and press V repeatedly to play various speeds of slow motion.

To skip to the next/previous chapter/track/file

During playback, press C or V to go to the next chapter/track/le or to return to the beginning of the current chapter/track/le.

Press C twice briey to step back to the previous chapter/track/le.

In the le list menu of a server, there may have many types of content in a folder together. In this case, press C or V to go to the previous or next content with same type.

Basic operations for photo content

To play a slide show

Press N (Play/Pause) to start slide show.

To stop a slide show

Press Z (STOP) while slide show.

To pause a slide show

Press N (Play/Pause) while slide show. Press N (Play/Pause) to re-start the slide show.

To skip to the next/previous photo

While viewing a photo in full screen, press a or d to go to the previous or next photo.

Operating

Operating40

Resume playback

eroyt u

The unit records the point where you pressed the

(STOP) depending on the disc.

If “MZ (Resume Stop)” appears on the screen briey, press N (Play/Pause) to resume playback (from the scene point). If you press Z (STOP) twice or unload the disc, “Z(Complete Stop)” appears on the screen. The unit will clear the stopped point.

Note

yThe resume point may be cleared when a

button is pressed (for example; 1 (POWER),

(OPEN/CLOSE), etc).

yOn BD-ROM discs with BD-J, the resume

playback function does not work.

Operating

yIf you press Z (STOP) once during BD-ROM

interactive title playback, the unit will be in Complete Stop mode.

Last Scene Memory

This unit memorizes the last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the unit or switch o the unit. If you load a disc that has the scene memorized, the scene is automatically recalled.

Note

yLast Scene Memory function for a previous

disc is erased once a dierent disc is played.

yThis function may not work depending on

the disc.

yOn BD-ROM discs with BD-J, the last scene

memory function does not work.

yThis unit does not memorize settings of

a disc if you switch o the unit before commencing to play it.

Operating 41

On-Screen Display

You can display and adjust various information and settings about the content.

To control video playback

eroy

You can control playback and set options while watching videos.

During playback, press INFO/MENU (m).

a Progress bar - Displays the current position

and total playing time.

b [Disc Menu] - Accesses menu on a disc. c [Title/Popup] - Displays the DVD title menu

or BD-ROM’s pop-up menu, if available.

d [Option] - Displays playback information. e [Repeat] - Repeats a desired section or

sequence. (page 43)

f [3D] - Adjusts the 3D setting. (page 48)

Displaying content information onscreen

eroy

1. During playback, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

a Title – Current title number/total number of

titles

b Chapter – Current chapter number/total

number of chapters

c Time – Elapsed playing time/total playback

time

d Audio – Selected audio language or channel e Subtitle – Selected subtitle. f Angle – Selected angle/total number of

angles

g TV Aspect Ratio – Selected TV aspect ratio h Picture Mode – Selected picture mode

a/d

, and press

Operating

Operating42

Note

yIf no button is pressed for a few seconds,

the on-screen display disappears.

yA title number cannot be selected on some

discs.

yAvailable items may dier depending on

discs or titles.

yIf an interactive Blu-ray Disc is playing back,

some setting information is displayed on the screen but prohibited to be changed.

To control photo view

Controls playback and sets options while viewing pictures in full screen.

You can control playback and set options while viewing pictures in full screen.

While viewing pictures, press INFO/MENU (m).

Operating

a [Slideshow] - Starts or pause slide show. b [Music] - Select the background music for the

slide show.

c [Option] - Displays slide show options. d [Rotate] - Rotates the photo clockwise. e [Zoom] - Displays the [Zoom] menu.

Setting the slide show option

You can use various options during viewing a photo in full screen.

1. While viewing pictures, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

a [Speed] - Use

speed between photos in a slide show.

b [Eect] - Use

effect between photos in a slide show.

c [Music Select] – Select the background music

for the slide show (page 47).

a/d

to select a transition

a/d

, and press

a/d

to select a delaying

Operating 43

Advanced Playback

Repeat playback

erotu y

Blu-ray Disc / DVD / Video les

1. During playback, press INFO/MENU (m).

2. Select an [Repeat] using

Wheel (a)

A-B – Selected portion will be repeated continually.

Chapter – The current chapter will be played back

repeatedly.

Title – The current title will be played back repeatedly.

All – All the titles or les will be played back repeatedly.

O – Returns to normal playback.

Audio CDs/Audio les

During playback, select [Repeat] and press Wheel (a)

repeatedly to select a desired repeat mode.

– Selected portion will be repeated continually.

(Audio CD only)

Track – The current track or le will be played

back repeatedly.

All – All the tracks or les will be played back

repeatedly.

All – All the tracks or les will be played back

repeatedly in random order.

– The tracks or les will be played back in

random order.

Note

This function may not work on some disc or title.

a/d

, and press

Repeating a specific portion

eroty

This player can repeat a portion you have selected.

1. During playback, press INFO/MENU (m).

2. Select an [Repeat] using Wheel (a).

3. Select [A-B] and press Wheel (a).

4. Press Wheel (a) portion you wish to repeat.

5. Press Wheel (a) at the end of the portion. Your selected portion will be repeated continually.

Note

yYou cannot select a portion less than 3

seconds.

yThis function may not work on some disc or

title.

at the beginning of the

a/d

, and press

Playing from selected time

eroy

1. During playback, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

3. Select the [Time] option and then input the required start time in hours, minutes, and seconds from left to right.

For example, to nd a scene at 2 hours, 10 minutes, and 20 seconds, enter “21020”.

Press forward or backward.

4. Press Wheel (a) to start playback from selected time.

yThis function may not work on some disc or

titles.

yThis function may not work depending on

the le type and ability of the DLNA server.

to skip the playback 60 seconds

a/d

Note

a/d

, and press

Operating

Operating44

Selecting a subtitle language

eroy

1. During playback, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

3. Use

4. Press

By pressing Wheel (a), you can set various

subtitle options.

5. Press BACK (1) to exit the On-Screen display.

Some discs allow you to change subtitle selections only via the disc menu. If this is the case, choose the appropriate subtitle from the selections on the disc menu.

Hearing a different audio

Operating

to select the [Subtitle] option.

w/s

to select desired subtitle language.

a/d

Note

a/d

eroy

1. During playback, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

3. Use

4. Use audio track or audio channel.

5. Press BACK (1) to exit the On-Screen display.

ySome discs allow you to change audio

yImmediately after you have switched sound,

yOn BD-ROM disc, the multi audio format

to select the [Audio] option.

w/s

to select desired audio language,

a/d

Note

selections only via the disc menu. In this case, choose the appropriate audio from the selections on the disc menu.

there may be a temporary discrepancy between the display and actual sound.

(5.1CH or 7.1CH) is displayed with [MultiCH] in the on-screen display.

a/d

, and press

Watching from a different angle

If the disc contains scenes recorded at dierent camera angles, you can change to a dierent camera angle during playback.

1. During playback, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

3. Use

4. Use

5. Press BACK (1) to exit the On-Screen display.

Changing the TV Aspect Ratio

to select the [Angle] option.

w/s

to select desired angle.

a/d

, and press

eoy

You can change the TV aspect ratio setting during playback.

1. During playback, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

3. Use option.

4. Use

5. Press BACK (1) to exit the On-Screen display.

Even if you change the value of the [TV Aspect Ratio] option in On-Screen display, the [TV Aspect Ratio] option in the [Settings] menu is not changed.

to select the [TV Aspect Ratio]

w/s

to select desired option.

a/d

Note

a/d

, and press

Operating 45

Changing subtitle Code Page

If the subtitle is displayed in broken letter, you can change the subtitle code page to view the subtitle le properly.

1. During playback, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

3. Use

4. Use

5. Press BACK (1) to exit the On-Screen display.

to select the [Code Page] option.

w/s

to select desired code option.

a/d

, and press

Changing the Picture Mode

eroy

You can change the [Picture mode] option during playback.

1. During playback, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

3. Use

4. Use

5. Press BACK (1) to exit the On-Screen display.

to select the [Picture Mode] option.

w/s

to select desired option.

a/d

Setting the [User setting] option

1. During playback, press INFO/MENU (m).

2. Select an [Option] using Wheel (a).

3. Use

4. Use and press Wheel (a).

to select the [Picture Mode] option.

w/s

to select the [User setting] option,

a/d

, and press

Operating

5. Use

w/s/a/d

options.

Select [Default] option then press Wheel (a) to reset the all video adjustments.

6. Use

w/s/a/d

and press Wheel (a) to nish setting.

to adjust the [Picture Mode]

to select the [Close] option,

Operating46

Viewing content information

The player can display the content information.

1. Select a le using

2. Press INFO/MENU (m) to display the option menu.

The le information appears on the screen.

Note

The information displayed on the screen may not correct comparing actual content information.

Operating

w/s/a/d

Changing content list view

yui

On the [SmartShare] menu, you can change the

content list view.

Press red (R) colored button repeatedly.

Operating 47

Selecting a subtitle ﬁle

If the subtitle le name is dierent from the video le name, you need to select the subtitle le on the [Movie] menu before playing the movie.

1. Use

w/s/a/d

wish to play in the [Movie] menu.

2. Press Wheel (a).

Press Wheel (a) again to deselect the subtitle le. Selected subtitle le will be displayed when you play the video le.

Note

yIf you press Z (STOP) during playback, the

subtitle selection is cancelled.

yThis function is not available for playing le

on a server via home network.

to select the subtitle le you

Listening to music during slide show

You can display photo les while listening to audio les.

1. While viewing a photo in full screen, press INFO/ MENU (m) to display the option menu.

2. Select an [Option] using Wheel (a).

3. Use press Wheel (a) to display the [Music Select] menu.

4. Use (a).

Available device may differ depending on the location of the current photo file.

5. Use play.

to select [Music Select] option, and

w/s

to select a device, and press Wheel

w/s

Photo location Available Device

Disc, USB Disc, USB

MTP MTP

DLNA server DLNA server

to select a file or a folder you wish to

w/s

a/d

, and press

Operating

Select g and press Wheel (a) to display the upper directory.

Note

When selecting audio le from a server, folder selection is not available. Only le selection is available.

6. Use d to select [OK], and press Wheel (a) to complete music selection.

Operating48

Playing content to 3D

eroy

This function allows you to convert 2D content to 3D and to play 3D content in case of le encoded in 3D also. You can adjust 3D’s depth and distance on the [3D] option while playing back.

Converting 2D content to 3D

1. During playback, press INFO/MENU (m).

2. Select an [3D], and press Wheel (a).

3. Select 2D contents to 3D.

Playing ﬁle encoded in 3D

1. During playback, press INFO/MENU (m).

2. Select [3D], and press Wheel (a).

3. Select suitable mode (side by side, top and

Operating

bottom) which is same way as le encoded in 3D by using

3D Setting

1. During playback, press INFO/MENU (m).

2. Select an [3D], and press Wheel (a).

3. Select an [3D Setting], and press Wheel (a).

You can adjust 3D’s depth and distance.

Select [Initialize] option then press Wheel (a) to reset the all adjustments.

by using

w/s/a/d

to convert

Reverting

1. During playback, press INFO/MENU (m).

2. Select an [3D], and press Wheel (a).

3. Select

yWhen you have set to Ultra HD resolution,

if you select the [On] in [3D], the Ultra HD resolution is automatically changed to the original resolution.

yMovie les which is upper 30 fps (frame

rate) may not be converted to 3D.

yIf the subtitle is displayed abnormally, set

the TV’s 3D option to o and the unit’s 3D option to on.

Note

by using

w/s/a/d

to revert.

Operating 49

Advanced Features

Wi-Fi Direct™

Connecting to a Wi-Fi Direct™ certified device

yui

This player can play movie, music and photo les located in a Wi-Fi Direct™ certied device. The Wi-Fi Direct™ technology make the player to be directely connected to a Wi-Fi Direct™ certied device without connecting to a network device such as an access point.

On Wi-Fi Direct™ certied device

1. Turn on the Wi-Fi Direct™ certied device and run its Wi-Fi Direct function.

2. Run DLNA application on the device.

On your player

3. Select [NETWORK] option in the [Settings] menu then press Wheel (a).

4. Select [Wi-Fi Direct] option, and press Wheel (a).

5. Select a Wi-Fi Direct™ device on the list using

, and press Wheel (a).

w/s

To select a server from the device list, files or folders must be shared by DLNA server from the connected Wi-Fi Direct™ device.

6. Select [Movie], [Photo] or [Music] using

7. Select a le using

, and press Wheel (a).

a/d

Wheel (a) to play the le.

Note

yFor the purpose of the better transmission,

placing the player from the Wi-Fi Direct™ certied server as close as possible.

yThis unit can connect only 1 device at a

time. Multiple connection is not available.

yIf you try to connect wireless network while

a device is connected by Wi-Fi Direct™ function , Wi-Fi Direct™ connection will be force disconnected.

yIf this player and a Wi-Fi Direct™ device

are connected to the different local area network, Wi-Fi Direct™ connection may not available.

yIf a Wi-Fi Direct™ certified device is not in

Wi-Fi direct standby mode, this player can not find the device.

yWhen you connect a Wi-Fi Direct™

certified device to your player, PIN network connection is not supported.

yThis player cannot connect to a Wi-Fi direct™

device which is in Group Owner mode.

w/s/a/d

, and press

w/s/

Operating

Wi-Fi Direct™ connection will be proceeded. follow the procedure on the screen.

If you want to rescan available Wi-Fi Direct™ device, select the [Refresh List] and press Wheel (a).

Operating50

Enjoying Miracast™

You can mirror Miracast certied device’s screen and sound onto TV screen through your player wirelessly.

On Miracast™ certied device

1. Turn on the Miracast certied device and run its [Miracast] function.

On your player

2. Press HOME (b).

3. Select [Miracast] and press Wheel (a).

4. Select a Miracast device on the list using

Operating

and press Wheel (a).

Miracast function will be proceeded automatically.

If you want to rescan available Miracast device, select [Refresh List] and press Wheel (a).

Note

yFor the purpose of the better mirroring,

place Miracast certied device from the player as close as possible.

yThis unit can connect only 1 device at a

time. Multiple connection is not available.

yWhile mirroring, Wireless network or Wi-Fi

Direct cannot be used simultaneously.

yIf a Miracast certified device is not in

[Miracast] standby mode, this player cannot find the device.

yDepending on your wireless network

condition, mirroring may be unstable.

yWhile mirroring, the screen may be cut o

depending on your TV’s setting. In this case, please adjust the display settings on your TV.

w/s

Enjoying BD-Live™

BD-ROM supporting BD-Live that has a network extension function allows you to enjoy more functions such as downloading new movie trailers by connecting this unit to the internet.

1. Check the network connection and settings (page 17).

2. Insert an USB storage device to the USB port on the front panel.

An USB storage device is needed to download bonus content.

3. Press HOME (b), and set the [BD-LIVE connection] option on the [Settings] menu (page 23).

Depending on a disc, the BD-Live function may not be operated if [BD-LIVE connection] option is set to [Partially Permitted].

4. Insert a BD-ROM with BD-Live.

The operations may dier depending on the disc. Refer to the manual supplied with the disc.

Caution

Do not extract the connected USB device while content is being downloaded or a Bluray disc is still in the disc tray. Doing so may damage the connected USB device and BDLive features may not operate properly with the damaged USB device anymore. If the connected USB device seems damaged from such an action, you can format the connected USB device from the PC and reuse it with this player.

Note

ySome BD-Live content may be restrictively

accessed in some territories by content provider’s own decision.

yIt may take up to several minutes to load

and start enjoying BD-Live content.

yFor BD-Live, use the USB ash drive /

external HDD formatted in FAT32 only.

Enjoying web browsing

Types URL manually on the screen or visits web sites added to Favorite.

1. Press HOME (b).

2. Select the [Internet] in the [My Apps] and press Wheel (a).

3. Enter search terms in the blank.

a Types in the web address or URL. b Selects when opening several web browsers. c Add the current page to favorites. d Moves to a previously visited website.

Operating 51

Note

yFor best service quality, subscribe to an

Internet service of 4.0 Mbps (1.5 Mbps or faster). Contact the ISP (Internet service provider) for any problems related to Internet speed.

yInternet only works with pre-installed

plugins.

yInternet only plays the following media

le formats: “.jpeg”, “.png”, “.gif”, “.wmv”, “.asf”, “.wma”, “.mp3”, “.mp4”.

yInternet is forcibly closed when memory is

insucient.

yFor the internet, fonts installed on the unit

are used and may not be displayed normally depending on the content played.

yInternet does not support le and font

download.

yInternet is made only for this unit. So it may

have dierent operation from PC browsers.

Operating

Operating52

LG AV Remote

You can control this player with your iPhone or Android phone via your home network. This player and your phone must be connected to your wireless network device such as access point. Visit “Apple iTunes” or “Google Android Market (Google Play Store)” for detailed information of “LG AV Remote”.

Private Sound Mode

By downloading “LG AV Remote” application on your smart phone or tablet, you can connect your headsets, and enjoy the sound from your player on your smart devices.

This feature transmits video signal to TV through HDMI and Audio signal to smart phone or tablet through Wi-Fi. For more detailed information, please refer to “LG AV Remote” application.

Operating

Using an USB keyboard or mouse

You can connect an USB keyboard and/or mouse to type text and navigate menus.

1. Connect an USB keyboard or mouse to the USB port on the front panel.

2. Use the keyboard to type text, or the mouse to navigate menus.

Note

The following keyboards and mice are recommended.

-Logitech Wireless Combo MK520

-Logitech Wireless Combo MK320

-Logitech Wireless Combo MK260

-Microsoft Wireless Desktop 5000

-Microsoft Wireless Desktop 3000

-Microsoft Wireless Desktop 2000

-Microsoft Wireless Desktop 800

Operating 53

Using the Premium

You can use various content services via Internet with the Premium feature.

1. Check the network connection and settings (page 17).

2. Press HOME (b).

3. Select the [Premium] using Wheel (a).

4. Select an online service using and press Wheel (a).

Note

yFor detailed information of each service,

contact to the content provider or visit support link of the service.

yThe content of Premium services and

service related information, including user interface, is subject to changes. Please refer to the web site of each service for most upto-date information.

yUsing Premium features with wireless

network connection may result in improper streaming speed by interference from household devices that are using radio frequencies.

yFor the rst time to access [Premium] or

[LG Smart world] feature, current country setting appears.

yIf you want to change the country setting,

go to [Settings] > [NETWORK] > [Smart Service Setting] > [Country Setting]. Select [Manual] and press Wheel (a) on [Country Setting] menu.

, and press

a/d

w/s/a/d

Using the LG Smart World

You can use the LG application services on this player via Internet. You can easily nd and download various applications from LG Smart World.

1. Check the network connection and settings (page 17).

2. Press HOME (b).

3. Select the [LG Smart World], and press Wheel (a).

4. Select a category using (a).

5. Use

w/s/a/d

press Wheel (a) to display the information.

6. Press Wheel (a) while [Install] icon is highlighted. The application will be installed to the player.

To install an application to the player, user needs to sign in. Refer to page 54 for more information of signning in.

7. Press red (R) colored button to display the [My Apps] screen.

8. Select the installed application and press Wheel (a) to excute it.

Note

yDepending on the region, the [LG Smart

World], [My Apps], [d] and [c] may not be available.

yTo install a paid application, you need to be

a paid member. Visit www.lgappstv.com for more information.

to select an application, and

, and press Wheel

a/d

Operating

Operating54

Signing in

To use the [LG Smart World] feature, you need to sign in with your account.

1. On the home menu, select [c] icon and press Wheel (a).

2. Fill the [ID] and [Password] field using the virtual keyboard.

If you do not have an account, press red (R) colored button to register.

Operating

3. Use

w/s/a/d

Wheel (a) to sign in with your account.

If you select the [Auto Sign In] check box, your ID and password are remembered and automatically signed in without entering them.

Note

To view the information of your account and applications, select [c] icon and press Wheel (a) on the home menu, and select [My Page] option.

to select [OK], and press

Searching online content

If you are having diculties nding specic content from online services, you can use the all-in-one search function by entering keywords in the search menu.

1. Press HOME (b).

2. Select the [d] icon on the home menu using

w/s/a/d

The search menu appears on the screen.

3. Press Wheel (a). The virtual keyboard appears automatically.

4. Use Wheel (a) to confirm your selection on the virtual keyboard.

5. When you finish entering the keyword, select [k] and press Wheel (a) to display search result.

6. Use and press Wheel (a) to move to the selected content directly.

yDepending on the region, the [LG Smart

World], [My Apps], [d] and [c] may not be available.

yThe search function does not search

content in every online services. It works only in certain online services.

, and press Wheel (a).

w/s/a/d

Note

to select letters then press

to select a desired content,

Using the My Apps Menu

You can move or delete an installed application in the [My Apps] menu.

1. Press HOME (b).

2. Select the [My Apps], and press Wheel (a).

3. On the [My Apps] menu, press red (R) colored button.

Move an application

1. Select an application, and press Wheel (a) to display the options.

2. Use (a).

3. Use to move to, and press Wheel (a).

to select [Move], and press Wheel

w/s

w/s/a/d

to select a position you want

Operating 55

Operating

Delete an application

1. Select an application, and press Wheel (a) to display the options.

2. Use (a).

3. Use to confirm.

Depending on the region, the [LG Smart World], [My Apps], [d] and [c] may not be available.

to select [Delete], and press Wheel

w/s

to select [OK], and press Wheel (a)

a/d

Note

Troubleshooting56

Troubleshooting

General

Symptom Cause & Solution

The Power does not turned on. yPlug the power cord into the wall outlet securely.

The unit does not start playback.

The connected USB storage device is not recognized.

The angle cannot be changed. yMulti-angles are not recorded on the DVD Video being played.

Troubleshooting

Cannot play movie, photo or music les.

The remote control does not work properly.

The unit is plugged in, but the power will not turn on or o.

The unit is not operating normally.

yInsert a playable disc. (Check the disc type, color system, and regional

code.)

yPlace the disc with the playback side down.

yPlace the disc on the disc tray correctly inside the guide.

yClean the disc.

yCancel the Rating function or change the rating level.

yTry using dierent USB cable, some USB cables may not support

enough current for normal USB operation.

yIf you use an USB extension cable or USB HUB, the USB devices may

not be recognized.

yAn USB device which requires additional program installation when

you have connected it to a computer is not supported.

yThis unit supports only USB Flash Drive and USB External HDD with

FAT32 or NTFS format.

yThe les are not recorded in a format that the unit can play.

yThe unit does not support the codec of the movie le.

yThe remote control is not pointed at the remote sensor of the unit.

yThe remote control is too far from the unit.

yThere is an obstacle in the path of the remote control and the unit.

yThe batteries in the remote control are exhausted.

You can reset the unit as follows.

yUnplug the power cord, wait at least ve seconds, and then plug it in

again.

Troubleshooting 57

Network

Symptom Cause & Solution

BD-Live feature does not work. yThe connected USB storage may not have enough space. Connect

Streaming video services (such as YouTube™, etc.) are often stopped or “buer” during playback.

Media servers are not displayed on the device list.

Cannot connect the player to the access point or wireless LAN router.

Access point is not displayed on the “Access point name” list.

the USB storage with at least 1GB free space.

yEnsure that the unit is correctly connected to the local area network

and can access the internet (see page 17).

yYour broadband speed may not fast enough to use the BD-Live

features. Contact your Internet Service Provider (ISP) and increase the broadband speed is recommended.

yThe [BD-LIVE connection] option in the [Settings] menu is set to

[Prohibited]. Set the option to [Permitted].

yYour broadband service speed may not be fast enough to stream

video services. Contact your Internet Service Provider (ISP) and increase the broadband speed is recommended.

yThe rewall or anti-virus software on your media server is running.

Turn o the rewall or anti-virus software running on your media server.

yThe player is not connected to the local area network that your media

server is connected.

yThe wireless communication may be interrupted from household

devices that are using radio frequencies. Move the player away from them.

yThe access point or wireless LAN router may not broadcast its SSID.

Set your access point to broadcast its SSID through your computer.

yYour network device such as access point may not set with available

frequency range and channel that this player can support. Try setting the frequency range and channel on the network device setting.

Troubleshooting

Troubleshooting58


Symptom Cause & Solution

There is no picture. ySelect the appropriate video input mode on the TV so the picture

Picture noise appears. yYou are playing a disc recorded in a color system that is dierent from

from the unit appears on the TV screen.

yConnect the video connection securely.

yCheck the [HDMI Color Setting] in the [Settings] menu is set to the

appropriate item that conforms to your video connection.

yYour TV may not support the resolution you have set on the player.

Change the resolution that your TV accepts.

yThe player’s HDMI OUT jack is connected to a DVI device that does

not support copyright protection.

your TV.

ySet the resolution which your TV accepts.

Blu-ray 3D disc playback does not output 3D views.

Customer support

Troubleshooting

You can update the player using the latest software to enhance the products operation and/or add new features. To obtain the latest software for this player (if updates have been made), please visit http://www.lg.com or contact LG Electronics customer care center.

yConnect the player to your TV with HDMI cable (Type A, High Speed

HDMI™ Cable).

yYour TV may not support “HDMI 3D mandatory format”.

yThe [3D Mode] option in the [Settings] menu is set to [O ].

Set the option to [On].

Open source software notice

To obtain the corresponding source code under GPL, LGPL and other open source licenses, please visit http://opensource.lge.com. All referred license terms, warranty disclaimers and copyright notices are available to download with the source code.

About Magic Remote Control

To re-register the Magic remote control

Press the HOME (b) and BACK (1) buttons at the same time for about 5 seconds. The Magic remote control will be unpaired with your unit.

Appendix 59

Note

y Press the BACK (1) button while pointing

the remote control at the unit for 5 seconds to reset and re-register it.

y Set the speed and size of the Magic pointer

that appears on the screen. Refer to the setting the Magic pointer (page 30).

y If the Magic pointer has not been used for

a certain period of time, it will disappear. When the Magic pointer disappears from the screen, shake the Magic remote control to the right and left. Then, it appears again.

y If you press the navigation button while

moving the Magic pointer on the screen, the Magic pointer disappears, and the Magic remote control works as a regular remote control.

Caution

y Use within an eective distance of 33 ft. (10

meters). Using the Remote Control from greater distances or when obstructions block the sight line may cause malfunctions.

y Electronic devices nearby may cause

communication interference. Devices such as microwave oven and wireless LAN use the same frequency range (2.4 GHz) as the Magic remote control, which may interfere with the remote control.

y The Magic remote control may be broken if

dropped or damaged in any other way.

y Do not drop or subject the Magic remote

control to heavy impacts.

Appendix

Appendix60

Network Software Update

Network update notification

From time to time, performance improvements and/or additional features or services may be made available to units that are connected to a broadband home network. If there is new software available and the unit is connected to a broadband home network, the player will inform you about the update as follows.

Option 1:

1. The update menu will appear on the screen when you turn on the player.

2. Use press Wheel (a).

to select a desired option and then

a/d

Software update

You can update the player using the latest software to enhance the products operation and/or add new features. You can update the software by connecting the unit directly to the software update server.

Note

yBefore updating the software in your player,

remove any disc and USB Device from the player.

yBefore updating the software in your player,

turn the player o and then turn it back on.

yDuring the software update procedure,

do not turn o the player or disconnect AC power, or do not press any button.

yIf you cancel the update, turn o the power

and turn it on for stable performance.

yThis unit cannot be updated to previous

software version.

1. Check the network connection and settings (page 17).

2. Select [Software] option in the [Settings] menu then press Wheel (a).

3. Select [Update] option, and press Wheel (a).

[OK] Starts the software update.

Appendix

[Cancel]

Exits the update menu and the home menu appears.

Option 2:

If the software update is available from the update server, the “Update” icon appears in the Home menu. Press blue (B) colored button to start the update procedure.

The player will check for the newest update.

Note

yPressing Wheel (a) while checking for the

update will end the process.

yIf there is no update available, the Message,

“No update is found.” appears. Press Wheel (a) to return to the [Home] menu.

4. If newer version exists, the message “A new update was found. The update takes a few minutes. Do you want to update?” appears.

5. Select [OK] to start update. (Selecting [Cancel] will end the update.)

6. The player starts downloading the newest update from the server. (Downloading will takes several minutes depending on your home network condition)

7. To update software the next time, the software update procedure has to be started from the beginning again.

Caution

Do not turn o the power during the software update.

Note

If the software includes the driver update, disc tray may open during the process.

8. When update is completed, the power will be turned off automatically in a few seconds.

9. Turn the power back on. The system now operates with the new version.

Note

The Software Update function may not work properly depending on your internet environment. In this case, you can obtain the latest software from the authorized LG Electronics Service Center then update your player. Refer to “Customer support” on page

58.

Appendix 61

Appendix

Appendix62

Additional Information

File requirement

Video files

File

Location

Disc,

USB

DLNA

File

Extension

“.avi”, “.divx”, “.mpg”, “.mpeg”, “.mkv”, “.mp4”, “.asf”, “.wmv”, “.m4v” (DRM free), “.vob”, “.3gp”, “.mov”, “.trp”, “.m2t”, “.mpe”, “.m1v”, “.m2v ”, “.wm”, ”.v ”, “.ts”, “.dat”

“.avi”, “.divx”, “.mpg”, “.mpeg”, “.mkv”, “.mp4”, “.asf”, “.wmv”, “.m4v” (DRM free), “.3gp”, “.mov”, “.mpe”, “.m1v”, “.m2v ”, ”.v ”, “.ts”, “.dat”

Codec Format

DIVX3.11, DIVX4, DIVX5, DIVX6, (standard playback only) XVID, MPEG1 SS, H.264/ MPEG-4 AVC, MPEG2 PS, MPEG2 TS, VC-1 SM (WMV3)

Audio

Format

Dolby Digital, DTS, MP3, WMA, AAC, AC3

Subtitle

SubRip (.srt / .txt), SAMI (.smi), SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt), VobSub (.sub), SubViewer 1.0 (.sub), SubViewer 2.0 (.sub/.txt), TMPlayer (.txt), DVD Subtitle System (.txt)

SubRip (.srt / .txt), SAMI (.smi), SubStation Alpha (.ssa/.txt), MicroDVD (.sub/. txt), SubViewer 1.0 (.sub), SubViewer 2.0 (.sub/.txt), TMPlayer (.txt), DVD Subtitle System (.txt)

Audio files

Appendix

Photo files

File

Location

Disc,

USB

DLNA

File

Location

Disc, USB,

DLNA

File

Extension

“mp3”, “.wma”, “.wav”, “.m4a” (DRM free), “.ac”, “.ogg”, “.ai”

“mp3”, “.wma”, “.wav”, “.m4a” (DRM free), “.ac”, “.ogg”

File

Extension

“.jpg”, “.jpeg”, “.png”, “.gif”, “.mpo”, “.jps”

Sampling Frequency Bitrate Note

within 32 - 48 kHz (WMA), within 16 - 48 kHz (MP3)

Recommended

Size

Less than 4,000 x 3,000 x 24 bit/pixel Less than 3,000 x 3,000 x 32 bit/pixel

within 32 - 192 kbps (WMA), within 32 - 320 kbps (MP3)

Progressive and lossless compression photo image les are not supported.

Some wav les are not supported on this player.

Note

Appendix 63

Note

yThe le name is limited to 180 characters.

yMaximum les/Folder: Less than 2000 (total

number of les and folders)

yDepending on the size and number of the

les, it may take several minutes to read the content on the media.

yFile compatibility may dier depending on

the server.

yBecause the compatibility on DLNA server

are tested on the DLNA server (SmartShare PC Software) environment, le requirements and playback functions may dier depending on media servers.

yThe le requirements on page 62 are

not always compatible. There may have some restrictions by le features and media server’s ability.

yPlaying video subtitle les are only

available on DLNA media server created by SmartShare PC Software downloaded from website.

yThe les from removable media such as USB

drive, DVD-drive etc. on your media server may not be shared properly.

yThe total playback time of audio le

indicated on the screen may not correct for VBR les.

yHD video les contained on the CD/DVD or

USB 1.0/1.1 may not played properly. Blu-ray Disc or USB 2.0 are recommended to play back HD video les.

yThis player supports H.264/MPEG-4 AVC

prole Main, High at Level 4.1. A le with higher level may not be supported.

yThis player does not support les that are

recorded with GMC

*1 GMC – Global Motion Compensation

*2 Qpel – Quarter pixel

or Qpel

Note

yA “avi” le which is encoded “WMV 9 codec”

is not supported.

yThis player supports UTF-8 les even it

contains Unicode subtitle content. This player can not support the pure Unicode subtitle les.

yDepending on the types of le or ways of

recording, it may not play back.

yA disc which was recorded by multi-session

on normal PC is not supported on this player.

yTo be playback a video le, video le name

and Subtitle le name must be the same.

yWhen you play a video le with a extension

such as “.ts”, “.m2ts”, “.mts”, “.tp”, “.Trp” or “.m2t”, your player may not support subtitle les.

yThe total playback time of audio le

indicated on the screen may not correct for VBR les.

yVideo / Audio codec compatibility may

dier depending on video le.

AVCHD (Advanced Video Codec High Definition)

yThis player can playback AVCHD format discs.

These discs are normally recorded and used in camcorders.

yThe AVCHD format is a high denition digital

video camera format.

yThe MPEG-4 AVC/H.264 format is capable of

compressing images at higher eciency than that of the conventional image compressing format.

yThis player can playback AVCHD discs using

“x.v.Color” format.

ySome AVCHD format discs may not play

depending on the recording condition.

yAVCHD format discs need to be nalized.

y“x.v.Color” oers a wider color range than normal

DVD camcorder discs.

Appendix

Appendix64

About DLNA

This Player is a DLNA Certied digital media player that can display and play video, photo and audio content from your DLNA-compatible digital media server (PC and Consumer Electronics).

The Digital Living Network Alliance (DLNA) is a cross-industry organization of consumer electronics, computing industry and mobile device companies. Digital Living provides consumers with easy sharing of digital media through your home network.

The DLNA certication logo makes it easy to nd products that comply with the DLNA Interoperability Guidelines. This unit complies with DLNA Interoperability Guidelines v1.5.

When a PC running DLNA server software or other DLNA compatible device is connected to this player, some setting changes of software or other devices may be required. Please refer to the operating instructions for the software or device for more information.

Certain system requirements

For high denition video playback:

yHigh denition display that has HDMI input jack.

yBD-ROM disc with high denition content.

yHDMI or HDCP capable DVI input on your display

device is required for some content (as specied by disc authors).

For Dolby® Digital Plus, Dolby TrueHD and DTS-HD

multi-channel audio playback:

Appendix

yAn amplier/receiver with a built-in (Dolby

Digital, Dolby Digital Plus, Dolby TrueHD, DTS or DTS-HD) decoder.

yMain, center, surround speakers and subwoofer

as necessary for chosen format.

Compatibility notes

yBecause BD-ROM is a new format, certain disc,

digital connection and other compatibility issues are possible. If you experience compatibility problems, please contact an authorized Customer Service Center.

yThis unit allows you to enjoy functions such

as picture-in-picture, secondary audio and Virtual packages, etc., with BD-ROM supporting BONUSVIEW (BD-ROM version 2 Prole 1 version

1.1). Secondary video and audio can be played from a disc compatible with the picture-inpicture function. For the playback method, refer to the instructions in the disc.

yViewing high-denition content and up-

converting standard DVD content may require a HDMI-capable input or HDCP-capable DVI input on your display device.

ySome BD-ROM and DVD discs may restrict the

use of some operation commands or features.

yDolby TrueHD, Dolby Digital Plus and DTS-HD are

supported with maximum 7.1 channels if you use HDMI connection for the audio output of the unit.

yYou can use an USB device to store some disc

related information, including downloaded online content. The disc you are using will control how long this information is retained.

Audio Output Specifications

Appendix 65

Jack/Setting

Source

Dolby Digital PCM 2ch DTS Dolby Digital

Dolby Digital Plus PCM 2ch DTS Dolby Digital

Dolby TrueHD PCM 2ch DTS 2ch Dolby Digital

DTS PCM 2ch DTS DTS

DTS-HD PCM 2ch DTS DTS

Linear PCM 2ch PCM 2ch DTS 2ch PCM 2ch

Linear PCM 5.1ch PCM 2ch DTS PCM 2ch

Linear PCM 7.1ch PCM 2ch DTS PCM 2ch

Jack/Setting

Source

Dolby Digital PCM 2ch DTS Dolby Digital

Dolby Digital Plus PCM 2ch DTS Dolby Digital Plus

Dolby TrueHD PCM 2ch

DTS PCM 2ch DTS DTS

DTS-HD PCM 2ch DTS DTS-HD

Linear PCM 2ch PCM 2ch

Linear PCM 5.1ch PCM 5.1ch DTS Linear PCM 5.1ch

Linear PCM 7.1ch PCM 7.1ch DTS Linear PCM 7.1ch

*1 The secondary and interactive audio may not

be included in the output bitstream if [Digital Output] option is set to [Auto]. (Except LPCM Codec : the output always include interactive and secondary audio.)

*2 This player automatically selects the HDMI audio

according to the decoding capability of the connected HDMI device even though [Digital Output] option is set to [Auto].

*3 If the [Digital Output] option is set to [DTS re-

encode], the audio output is limited to 48 kHz and 5.1Ch. If the [Digital Output] option is set to [DTS re-encode], the DTS Re-encode audio is outputted for BD-ROM discs, and the original audio is outputted for the other discs (like [Auto]).

OPTICAL (DIGITAL AUDIO OUT)

PCM

DTS Re-encode

HDMI OUT

DTS Re-encode

DTS 2ch

yIf the HDMI OUT jack is connected to your TV

with High Speed HDMI™ Cable and Dolby Digital Plus/Dolby TrueHD is outputted from HDMI OUT jack, DIGITAL AUDIO OUT jack is limited to “PCM 2ch” ( When the HDMI and DIGITAL AUDIO OUT are connected simultaneously).

Auto

*1 *

Dolby TrueHD

Linear PCM 2 ch

Appendix

Appendix66

yThe audio is outputted up to PCM 48 kHz/16 bit

for MP3/WMA le and PCM 44.1kHz/16 bit for Audio CD during playback.

yYou must select a digital audio output and

a maximum sampling frequency that your Amplier (or AV receiver) accepts using [Digital Output] and [Sampling Freq.] options on the [Settings] menu (page 27).

yWith digital audio connection (DIGITAL AUDIO

OUT or HDMI OUT), Disc Menu button sounds of BD-ROM may not be heard if the [Digital Output] option is set to [Auto].

yIf the audio format of the digital output does

not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

yMulti-channel Digital Surround Sound via digital

connection can only be obtained if your receiver is equipped with a Digital Multi-channel decoder.

Appendix

Appendix 67

Area Code List

Choose an area code from this list.

Area Code Area Code Area Code Area Code

Afghanistan AF

Argentina AR

Australia AU

Austria AT

Belgium BE

Bhutan BT

Bolivia BO

Brazil BR

Cambodia KH

Canada CA

Chile CL

China CN

Colombia CO

Congo CG

Costa Rica CR

Croatia HR

Czech Republic CZ

Denmark DK

Ecuador EC

Egypt EG

El Salvador SV

Ethiopia ET

Fiji FJ

Finland FI

France FR

Germany DE

Great Britain GB

Greece GR

Greenland GL

Hong Kong HK

Hungary HU

India IN

Indonesia ID

Israel IL

Italy IT

Jamaica JM

Japan JP

Kenya KE

Kuwait KW

Libya LY

Luxembourg LU

Malaysia MY

Maldives MV

Mexico MX

Monaco MC

Mongolia MN

Morocco MA

Nepal NP

Netherlands NL

Antilles AN

New Zealand NZ

Nigeria NG

Norway NO

Oman OM

Pakistan PK

Panama PA

Paraguay PY

Philippines PH

Poland PL

Portugal PT

Romania RO

Russian Federation RU

Saudi Arabia SA

Senegal SN

Singapore SG

Slovak Republic SK

Slovenia SI

South Africa ZA

South Korea KR

Spain ES

Sri Lanka LK

Sweden SE

Switzerland CH

Taiwan T W

Thailand TH

Turkey TR

Uganda UG

Ukraine UA

United States US

Uruguay UY

Uzbekistan UZ

Vietnam VN

Zimbabwe ZW

Appendix

Appendix68

Language Code List

Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu].

Language Code Language Code Language Code Language Code

Lithuanian 7684

Macedonian 7775

Malagasy 7771

Malay 7783

Malayalam 7776

Maori 7773

Marathi 7782

Moldavian 7779

Mongolian 7778

Nauru 7865

Nepali 7869

Norwegian 7879

Oriya 7982

Panjabi 8065

Pashto, Pushto 8083

Persian 7065

Polish 8076

Portuguese 8084

Quechua 8185

Rhaeto-Romance 8277

Rumanian 8279

Russian 8285

Samoan 8377

Sanskrit 8365

Scots Gaelic 7168

Serbian 8382

Serbo-Croatian 8372

Shona 8378

Appendix

Afar 6565

Afrikaans 6570

Albanian 8381

Amharic 6577

Arabic 6582

Armenian 7289

Assamese 6583

Aymara 6588

Azerbaijani 6590

Bashkir 6665

Basque 6985

Bengali; Bangla 6678

Bhutani 6890

Bihari 6672

Breton 6682

Bulgarian 6671

Burmese 7789

Byelorussian 6669

Chinese 9072

Croatian 7282

Czech 6783

Danish 6865

Dutch 7876

English 6978

Esperanto 6979

Estonian 6984

Faroese 7079

Fiji 7074

Finnish 7073

French 7082

Frisian 7089

Galician 7176

Georgian 7565

German 6869

Greek 6976

Greenlandic 7576

Guarani 7178

Gujarati 7185

Hausa 7265

Hebrew 7387

Hindi 7273

Hungarian 7285

Icelandic 7383

Indonesian 7378

Interlingua 7365

Irish 7165

Italian 7384

Japanese 7465

Kannada 7578

Kashmiri 7583

Kazakh 7575

Kirghiz 7589

Korean 7579

Kurdish 7585

Laotian 7679

Latin 7665

Latvian, Lettish 7686

Lingala 7678

Sindhi 8368

Singhalese 8373

Slovak 8375

Slovenian 8376

Spanish 6983

Sudanese 8385

Swahili 8387

Swedish 8386

Tagalog 8476

Tajik 8471

Tamil 8465

Telugu 8469

Thai 8472

Tonga 8479

Turkish 8482

Turkmen 8475

Twi 8487

Ukrainian 8575

Urdu 8582

Uzbek 8590

Vietnamese 8673

Volapük 8679

Welsh 6789

Wolof 8779

Xhosa 8872

Yiddish 7473

Yoruba 8979

Zulu 9085

Trademarks and Licenses

Blu-ray Disc™, Blu-ray™, Blu-ray 3D™, BD-Live™, BONUSVIEW™ and the logos are trademarks of the Blu-ray Disc Association.

Appendix 69

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS

“DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation.

Java is a trademark of Oracle and/or its aliates.

The terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

“x.v.Color” is a trademark of Sony Corporation.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

DLNA®, the DLNA Logo and DLNA CERTIFIED® are trademarks, service marks, or certication marks of the Digital Living Network Alliance.

The Wi-Fi CERTIFIED Logo is a certication mark of the Wi-Fi Alliance.

The Wi-Fi Protected Setup Mark is a trademark of the Wi-Fi Alliance.

Appendix

“AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.

DivX Certied® to play DivX® video up to HD 1080p, including premium content.

DivX®, DivX Certied® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license.

Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274

Appendix70

Cinavia Notice

This product uses Cinavia technology to limit the use of unauthorized copies of some commerciallyproduced lm and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted.

More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA.

This product incorporates proprietary technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2013 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited.

Appendix

Specifications

General

Power requirements Refer to main label on the rear panel.

Power consumption 16 W

Dimensions (W x H x D) Approx. 430 mm x 43.5 mm x 205 mm

Net Weight (Approx.) 1.58 kg

Operating temperature 5 °C - 35 °C

Operating humidity 5 % - 90 %

Outputs

HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)

DIGITAL AUDIO OUT (OPTICAL) 3 V (p-p), Optical jack x 1

System

Laser Semiconductor laser

Wavelength 405 nm / 650 nm

Signal system Standard PAL/NTSC color TV system

LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX

Wireless LAN (internal antenna)

Bus Power Supply (USB) 5 V 0 500 mA

Integrated IEEE 802.11n (5 GHz and 2.4 GHz bands) wireless networking access, compatible with 802.11a/b/g Wi-Fi networks.

Appendix 71

Motion Remote Control

Model M4-Media

Range of frequency 2.400 GHz - 2.4835 GHz

Channel 79 channels

Transmission Under 10 dBm

Reception sensitivity -86 dBm

Dimensions 42.4 mm x 47 mm x 186 mm

Weight 80 g ± 5 g (excluding battery)

Power source AA 1.5 V, 2 alkaline batteries

Operational temperature range 0 °C - 60 °C

yDesign and specications are subject to change without notice.

Appendix

Appendix72

Maintenance

Handling the unit

When shipping the unit

Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory.

Cleaning the unit

To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

Keeping the exterior surfaces clean

yDo not use volatile liquids such as insecticide

spray near the unit.

yWiping with strong pressure may damage the

surface.

yDo not leave rubber or plastic products in

contact with the unit for a long period of time.

Maintaining the unit

The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty

or worn, the picture quality could be diminished.

Appendix

For details, please contact your nearest authorized service center.

Notes on discs

Handling discs

Do not touch the playback side of the disc. Hold the disc by the edges so that ngerprints do not get on the surface. Never stick paper or tape on the disc.

Storing discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat and never leave it in a parked car exposed to direct sunlight.

Cleaning discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the center to out.

Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records.

Important Information Relating to Network Services

All information, data, documents, communications, downloads, les, text, images, photographs, graphics, videos, webcasts, publications, tools, resources, software, code, programs, applets, widgets, applications, products and other content (“Content”) and all services and oerings (“Services”) provided or made available by or through any third party (each a “Service Provider”) is the sole responsibility of the Service Provider from whom it originated.

The availability of and access to Content and Services furnished by the Service Provider through the LGE Device are subject to change at any time, without prior notice, including, but not limited to the suspension, removal or cessation of all or any part of the Content or Services.

Should you have any inquiry or problem related to the Content or Services, you may refer to the Service Provider’s website for the most up-todate information. LGE is neither responsible nor liable for customer service related to the Content and Services. Any question or request for service relating to the Content or Services should be made directly to the respective Content and Service Providers.

Please note that LGE is not responsible for any Content or Services provided by the Service Provider or any changes to, removal of, or cessation of such Content or Services and does not warrant or guaranty the availability of or access to such Content or Services.

Appendix 73

Appendix

LG BP740N User guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety Information

Getting Started

Introduction

Playable Discs and symbols used in this manual

About the “7” Symbol Display

Regional Code

System Select

Remote Control

Magic remote control functions

Front Panel

Rear Panel

Connecting to Your TV

Connecting

What is SIMPLINK?

Resolution Setting

Connecting to an Amplifier

Connecting to an Amplifier via HDMI Output

Connecting to an Amplifier via Digital Audio Output

Connecting to your Home Network

Wired network connection

Wired Network Setup

Wireless network connection

Wireless network setup

Initial Setup

System Setting

Settings

Adjust the Setup Settings

[NETWORK] Menu

[DISPLAY] Menu

[LANGUAGE] Menu

[AUDIO] Menu

[LOCK] Menu

[OTHERS] Menu

Home Menu Display

Using [HOME] menu

Operating

Using the SmartShare

Playing the Linked Devices

Playing a Disc

Playing Blu-ray 3D disc

Playing a file on disc/USB device

Playing a file on Android device

Playing a file on a network server

Using Home Network Server for PC

About SmartShare PC Software (DLNA)

Downloading SmartShare PC Software (DLNA)

Installing SmartShare PC Software (DLNA)

Sharing files and folders

System requirements

General Playback

Basic operations for video and audio content

Basic operations for photo content

Resume playback

Last Scene Memory

On-Screen Display

To control video playback

To control photo view

Advanced Playback

Repeat playback

Repeating a specific portion

Playing from selected time

Selecting a subtitle language

Hearing a different audio

Watching from a different angle

Changing the TV Aspect Ratio

Changing subtitle Code Page

Changing the Picture Mode

Viewing content information

Changing content list view

Listening to music during slide show

Playing content to 3D

Advanced Features

Wi-Fi Direct™

Enjoying Miracast™

Enjoying BD-Live™

Enjoying web browsing
