XM5365
Reliability. Security. Productivity.
XM5365
This is a Class A device according to international elect romagnetic emissions standards (i.e. FCC Rules, EN 55022/EN 55032, etc.). Class A products are
intended for use in non-residential/non-domestic environments. Use of a Class A product in residential/domestic environments may cause interference to
radio communications and require corrective measures.
18KDO8139
Lexmark XM5365
Put output at up to 65 ppm* in more places with the Lexmark XM5365, the multifunction product with features and performance to
satisfy even large workgroups. Robust paper handling technology is designed to make printing more reliable, while long-life imaging
components increase uptime and thoughtful engineering enhancesserviceability.
Ready when you are
} Long-life fuser and imaging components extend uptime.
} Unison™ Toner replacement cartridges deliver up to 45,000
pages** of high-quality printing.
} Steel frame and durable design stands up to heavy use and
harsh environments.
Full-spectrum security
Get more done
} Powerful 1.2-GHz quad-core processor and up to 6 GB of
memory drives printing at up to 65 ppm* and scanning at up
to 150 sides per minute.
} Robust paper handling includes reliable feeding of a wide
range of media types and sizes and up to 3300 sheets
of input.
} Lexmark’s full-spectrum security architecture helps keep
your information safe—in the document, on the device and
over the network.
} Keypoint Intelligence - Buyers Lab honored Lexmark
with a prestigious BLI PaceSetter award for Document
Imaging Security***.
} Connect via Ethernet, USB, or simple mobile printing options.
Interact with ease
} Intuitive 7-inch class/17.8-cm color touch screen offers
smooth, tablet-like interaction with customizable
convenience and productivity apps.
} Front access to the paper path and power button means
you’ll virtually never have to access the back of the device,
allowing placement in or on cabinets.
} Innovative serviceability features, starting with single-
door access to parts and supplies, help you resolve
problems quickly.
Built for planet earth
} Energy management features reduce power consumption in
active use or sleep mode.
} Standard two-sided printing saves paper.
} Device is rated EPEAT® Gold and ENERGY STAR® certied.
} Recycle cartridges through the award-winning Lexmark
Cartridge Collection Program (LCCP).
*Print and copy speeds measured in accordance with ISO/IEC 24734 and ISO/IEC 24735 respec tively (ESAT). For more information se e: www.lexmark.com/ISOspeeds.
**Average yield based on approximately 5% print coverage.
***Award based on North America and/or Western Europe data
lexmark.com
18KDO8139
2
Lexmark XM5365
1
2
3
4
5
6
1 Multifunction product with 7-inch
(17.8 cm) class e-Task color touch
screen
29.1 x 22 x 22.8 inches
739.1 x 558.8 x 578.4 mm
2 100-sheet multipurpose feeder
Dimensions included as part of base model
3 550-sheet tray
Dimensions included as part of base model
4 550-sheet tray
4.3 x 16.85 x 20.1 inches
110 x 428 x 510 mm
5 2100-sheet tray
13.8 x 16.85 x 20.1 inches
350 x 428 x 510 mm
6 Caster base
5 x 20.5 x 27.3 inches
126 x 521 x 693 mm
7
10
8
11
9
12
7 250-sheet tray
3.2 x 16.85 x 20.1 inches
80 x 428 x 510 mm
8 550-sheet lockable tray
4.3 x 16.85 x 20.1 inches
110 x 428 x 510 mm
9 250-sheet lockable tray
3.2 x 16.85 x 20.1 inches
80 x 428 x 510 mm
10 Swivel cabinet
10.4 x 18.7 x 23.6 inches
263 x 476 x 600 mm
11 Adjustable printer stand
23 x 23.5 x 23.5
584.2 x 596.9 x 596.9
12 Spacer to add additional height
4.3 x 16.85 x 20.1 inches
110 x 428 x 510 mm
Standard
Optional
P/N Hardware
25B1200 Lexmark XM5365
P/N Cartridges and supplies
25 B3 074 Black Lexmark toner cartridge
58D0Z00 Imaging Unit
25A0013 3 staple cartridges
P/N Paper handling
50G0800 250-sheet tray
50G0820 250-sheet lockable tray
50G0802 550-sheet-tray
50G0822 550-sheet lockable tray
50G0804 2100-sheet tray
P/N Memory options
57X9801 User ash
27X0500 USB hard disk drive
P/N Connectivity
14F0100 RS-232C serial interface card
14F0000 Parallel 1284-B interface card
27X0142 MarkNet N8230 ber ethernet 100BASE-
FX(LC ), 1000BASE-SX(LC)
27X6510 MarkNet N8370 802.11a/b/g/n/ac 2.4/5GHz
wireless
1021231 10-Foot Parallel Printer Cable
1021294 2-Meter USB Printer Cable
P/N Furniture and accessories
50G0855 Caster base
50G0854 Spacer
3073173 Swivel cabinet
40C2300 Adjustable printer stand
P/N User replaceable parts
41X2352 Roller kit
41X2351 ADF maintenance kit
41X1108 Media pick roller (input tray)
41X1119 Tray separator (input tray)
41X 1076 Transfer roller
41X0358 ADF media pick roller
41X0360 ADF Separation Roller and cover
41X1123 Multipurpose feeder pick roller
For fusers and fuser mainten ance kits, contact your
service provider.
For application solutions see https://www.lexmark.
com/epg
Note 1: Support s up to 3 optional 550-sheet trays; OR one optional 550-sheet tray and one optional 2100 -sheet tray. For maximum paper input capacit y, install 1 optional
550-sheet tray and one option al 2100-sheet tray. When a 2100-s heet tray is installed, it must be the bottom tray, and a caster base isrequired.
Note 2: All measurements are shown as height x width x depth. For more information about supported congurations, refer to the Printer, Option and Stand Compatibility Guide
athttp://www.lexmark.com/publications/furniture_safety/
© 2018 Lexmark. All rights reserved.
Lexmark, the Lexmark logo and Unison are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. AirPrint® and the AirPrint Logo® are
trademarks of Apple, Inc. ENERGY STAR® is a U.S. registered mark. Google Cloud Print™ is a trademark of Google, Inc. MOPRIA®, the Mopria® Logo™ and the Mopria® Alliance
logos are trademark s, ser vice marks, and cer tication marks of Mopria Alliance, Inc. in the United States and other countries. All other trademarks are the proper ty of th eir
respective owners. All other trademarks are the property of their respective owners.
This product includes sof tware developed by the OpenSSL Project for use in the Open SSL Toolkit (ht tp://www.openssl.org/).
lexmark.com
18KDO8139
3
Product specications Lexmark XM5365
Printing
Display
Print Speed: Up to
Time to First Page: As fast as
Print Resolution
Memory / Processor
Hard Disk
Recommended Monthly Page Volume
Maximum Monthly Duty Cycle: Up to
6
2
3
Copying
Copy Speed: Up to
Time to First Copy: As fast as
6
Scanning
Scanner Type / ADF Scan
A4/Ltr Duplex Scan Speed: Up to
A4/Ltr Simplex Scan Speed: Up to
ADF Paper Input Capacity: Up to
Faxing
Modem Speed
Supplies
Laser Cartridge Yields (up to)
Imaging Unit Estimated Yield: Up to
Cartridge(s) Shipping with Product
7
1
1
Paper Handling
Included Paper Handling
Optional Paper Handling
Paper Input Capacity: Up to
Paper Output Capacity: Up to
Media Types Supported
Media Sizes Supported
General Information
Standard Ports
Optional Network Ports / Optional Local Ports
Noise Level: Operating
Specied Operating Environment
Limited Warranty - See Statement of Limited
Warranty
Size (in. - H x W x D) / Weight (lb.)
4
Black: 1200 Image Quality, 1200 x 1200 dpi, 2400 Image Quality, 600 x 600 dpi
150000 pages, based on 3 average letter/A4-size pages per print job and ~ 5% coverage
550-Sheet Input, 100-Sheet Multipurpose Feeder, 550-Sheet Output Bin, Integrated Duplex
250-Sheet Tray, 550-Sheet Tray, 2100-Sheet Tray, 250-Sheet Lockable Tray, 550-Sheet Lockable Tray
Standard: 650 pages 20 lb or 75 gsm bond / Maximum: 3300 pages 20 lb or 75 gsm bond
Standard: 550 pages 20 lb or 75 gsm bond / Maximum: 550 pages 20 lb or 75 gsm bond
Card Stock, Dual Web Labels, Envelopes, Integrated Labels, Paper Labels, Plain Paper, Transparencies, Refer to the Card Stock
10 Envelope, 7 3/4 Envelope, 9 Envelope, A4, A5, B5 Envelope, C5 Envelope, DL Envelope, Executive, Folio, JIS-B5, Legal, Letter,
One Internal Card Slot, USB 2.0 Specication Hi-Speed Certied (Type B), Gigabit Ethernet (10/100/1000), Front USB 2.0
Specication Hi-Speed Certied port (Type A), Two Rear USB 2.0 Specication Hi-Speed Certied ports (Type A)
Internal MarkNet N8350 802.11b/g/n Wireless, Marknet N8370 WiFi Option / Internal RS-232C serial, Internal 1284-B
Humidity: 8 to 80% Relative Humidity, Temperature: 10 to 32°C (50 to 90°F), Altitude: 0 - 2896 Meters (9,500 Feet)
Lexmark e-Task 7-inch (17.8 cm) color touch screen
Black: 65 ppm
Black: 4.2 seconds
Standard: 2048 MB / Maximum: 6144 MB / Quad Core, 1200 MHz
Option available
5000 - 75000 pages
300000 pages per month
Black: 65 cpm
Black: 4.2 seconds
Flatbed scanner with ADF / DADF (single pass Duplex)
Black: 144 / 150 sides per minute / Color: 144 / 150 sides per minute
Black: 72 / 75 sides per minute / Color: 72 / 75 sides per minute
200 pages 20 lb or 75 gsm bond
ITU T.30, V.34 Half-Duplex, 33.6 Kbps
45,000-page Extra High Yield Cartridge
11,000-page Starter Return Program Toner Cartridge
& Label Guide.
Statement, Universal, Ocio, A6
Bidirectional Parallel
Print: 57 dBA / Copy: 60 dBA / Scan: 56 dBA
1-Year Onsite Repair, Next Business Day
29.1 x 22.0 x 22.8 in. / 97.2 lb.
All information in this brochure is subject to change without notice. Lexmark is not liable for any errors or omissions.
This is a Class A device according to international electromagnetic emissions standards (i.e. FCC Rules, EN 55022/EN 55032, etc.).
Class A products are intended for use in non-residential/non-domestic environments. Use of a Class A product in residential/
domestic environments may cause interference to radio communications and require corrective measures.
1
Average standard page yield value declared in accordance with ISO/IEC 19752. 2”Recommended Monthly Page Volume” is a range of pages that helps customers evaluate
Lexmark’s product offerings ba sed on the average number of pages customers plan to print on the device each month. Lexmark recommends that the number of pages per
month be within the stated range for optimum device performance, based on factors including: supplies replacement inter vals, paper loading inter vals, speed, and typical
customer usage. 3”Maximum Monthly Dut y Cycle” is dened as the maximum number of pages a device could deliver in a month using a multishif t operation. This metric provides a
comparison of robustness in relation to othe r Lexmark printers and MFPs. 4Printers are sold subject to certain license/agreement condition s. See w ww.lexmark.com/printerlicense
for details. 5Actual Yield may vary based on other factor s such as device speed, paper size and fe ed orientation, toner coverage, tray source, percentage of black-only printing
and average print job complexity. 6Print and copy speeds me asured in accordance with ISO/IEC 24734 and ISO/IEC 24735 respectively (ESAT). For more information see: www.
lexmark.com/ISOspeeds. 7Product functions only with replacement cartridge s designed for use in a specic geographical region. See www.lexmark.com/regions for more details.
lexmark.com
18KDO8139
