This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe place for future reference.
Power Supply
Please connect the designated DC adaptor to an AC outlet
of the correct voltage.
Do not connect it to an AC outlet of voltage other than that
for which your instrument is intended.
Unplug the DC power adaptor when not using the instrument, or during electrical storms.
Connections
Before connecting the instrument to other devices, turn off
the power to all units. This will help prevent malfunction and
/ or damage to other devices.
Location
Do not expose the instrument to the following conditions to
avoid deformation, discoloration, or more serious damage:
Direct sunlight
Extreme temperature or humidity
Excessive dusty or dirty location
Strong vibrations or shocks
Close to magnetic fields
Unauthorized changes or modification to this system can
void the user's authority to operate this equipment.
CAUTION
The normal function of the product may be disturbed
by Strong Electro Magnetic Interference. If so, simply
reset the product to resume normal operation by
following the owner's manual. In case the function
could not resume, please use the product in other
location.
Interference with other electrical devices
Radios and televisions placed nearby may experience
reception interference. Operate this unit at a suitable
distance from radios and televisions.
Cleaning
Clean only with a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metallic, or other objects into the instrument. If this happens, remove the electric plug from the
outlet. Then have the instrument inspected by qualified
service personnel.
Disconnect all cables before moving the instrument.
02
Contents
Panel & Display Description
Front Panel............................................................................4
Display all parameters and values
related to the current operation.
3. POWER SWITCH
Turn the Power on or off.
4. [SHIFT] button
Holding down it to access
secondary functions of other
buttons.
6. [DEMO] button
Switch to Demo Mode.
7. [SONG] button
Switch to Song Mode
8. [STYLE] button
Switch to Style Mode.
9. [VOICE] button
Switch to Voice Mode.
10. [PIANO] button
Turn the Piano Mode on or off.
11. [SMART LEARNING] button
Turn the Smart Learning
function on or off.
17. [FADE] button
Turn the Fade In/Out function
on or off.
18. [CHORD] button
Enter the Chord Mode.
28. DATA DIAL
Adjust the parameter value.
29. [-]/[+] and NUMERIC buttons
Set parameters value or select
the number.
36. PITCH BEND
Roll the wheel upward or down ward to raise or lower the pitch.
3
12 13
14
15 16
04
5
7
6
17
In Song Mode
12. [ ] button
Start or Stop playing the song.
13. [ ] button
Pause or continue playing the song.
14. [ ] button
Set the beginning and the end for a
loop section of a selected song.
15. [ ] button
Rewind the song.
16. [ ] button
Fast forward the song.
When the [SHIFT] button is released
5. [TEMPO -]/[TEMPO +] button
Adjust the current tempo value.
19. [BANK] button
Switch between memory banks.
20. [STORE] button
Register the current panel settings.
21~26. [M1]~[M6] buttons
Recall the registered panel settings.
In O.T.S. mode, only M1~M4 are available.
27. [O.T.S.] button
Turn the One Touch Setting function
on or off.
30. [METRONOME] button
Turn the metronome on or off.
31. [MIXER] button
Enter the Mixer menu.
32. [DUAL] button
Turn the dual function on or off.
33. [LOWER] button
Turn the lower function on or off.
34. [HARMONY] button
Turn the Harmony effect on or off.
35. [FUNCTION] button
Enter the function menu.
18
19
20
2224
21
9
8
23
10
25
11
27
26
30 31 32 33 34 35
In Style Mode
12. [START/STOP] button
Start or stop playing the style.
13. [SYNC START] button
Turn the Sync Start function on or off.
14. [INTRO/ENDING] button
Play the Intro or Ending pattern.
15. [FILL A] button
Play the fill-in pattern A.
16. [FILL B] button
Play the fill-in pattern B.
When the [SHIFT] button is pressed
5. [ACCOMP -]/[ACCOMP +] button
Adjust the accompaniment volume value.
19. [RECORD] button
Enter the Record Mode.
20. [ACCOMP] button
Select the accompaniment track to record.
21~25. [MELODY 1]~[MELODY 5] button
Select the melody 1~5 track to record.
26. [TOUCH] button
Set an appropriate touch sensitivity level.
27. [PERFORM.] button
Turn the Performance Assistant function
on or off.
30. [OCTAVE] button
Enter the Octave menu.
31. [TRANSPOSE] button
Enter the Transpose menu.
32. [DICT.] button
Turn the chord dictionary function on or off.
33. [ALBUM] button
Turn the Album function on or off.
34. [DSP] button
Turn the DSP function on or off.
35. [SUSTAIN] button
Turn the sustain function on or off.
Rear Panel
Panel & Display Description
3738
37. DC 12V Jack
Connect the DC 12V power adapter.
38. MIC Jack
Connect a microphone.
LCD
1
ACCOMP
MELODY 1
MELODY 2
MELODY 3
MELODY 4
MELODY 5
3940
39. AUX IN Jack
Connect an external audio source,
4142
41. SUSTAIN Jack
Connect a sustain pedal.
such as MP3 or CD player.
42. USB Terminal
40. PHONES/OUTPUT Jack
Connect to a PC.
Connect a pair of headphones or an
audio equipment.
HAR MONY
4
PERFORM.
PERFORM. H
SUSTAIN
10
TOUCH
12
15
ALBUM
SMART LEARNING
16
17
18
2
3
5
6
7
89
13
11
14
1. ACCOMP/MELODY 1-5
2. SERIES NUMBER
3. VOICE/STYLE/DEMO/SONG
4. CHARACTER
5. RECORD
6. TREBLE CLEF/BASS CLEF
7. USB CABLE
8. MEASURE
9. BEAT
10. TEMPO
11. CHORD
12. MEMORY NUMBER/ONE TOUCH SETTING
13. A.B.C/FULL RANGE/FADE/
ACCOMPANIMENT SECTION
14. NOTE INDICATION/LESSON
15. DUAL/LOWER/HARMONY/DSP
16. PERFORMANCE ASSISTANT/
PERFORMANCE ASSISTANT HIGH
17. SUSTAIN/TOUCH/ALBUM
18. SMART LEARNING
05
Setup
This section contains information about setting up your instrument
and preparing to play. Please go through this section carefully before
turning the power on.
Power Supply
You can power the instrument either by batteries or by power adaptor.
Follow the instructions described below.
Using Batteries
The instrument needs 6 pieces of AA (NO.5) or equivalent alkaline
batteries for power supply.
1. Open the battery compartment cover located on the bottom of the
instrument.
2. Insert the batteries; carefully follow the polarity markings on the
cabinet.
3. Replace the compartment cover, making sure that it locks firmly in
place.
Open
Note:
1. Do not mix used and new batteries.
2. Always use same types of batteries.
3. Always remove the batteries from the instrument when it is not
being used for an extended period of time.
Using Power Adapter
1. Set the POWER switch to OFF, and then turn down the volume
before connecting to power supply.
2. Connect the adaptor to the DC jack of the instrument.
3. Plug the adaptor into an AC outlet. This will automatically cut off
the battery power supply.
Note:
1. In standby mode, the instrument will automatically shutdown in 30
minutes if it is not used. (Please refer to “Auto Power Off” for
details).
2. For your safety, please unplug the instrument when it is not in use
or during a thunderstorm.
Setting a Music Stand
A music stand is supplied with the keyboard. You can easily attach it
to the instrument by inserting it into the slots at the front of the panel.
VOLUME
MINMAX
PERFORM.ACCOMP
PERFORM.ACCOMP
PERFORM.H
MELODY 1
PERFORM.H
MELODY 1
SUSTAIN
MELODY 2
MELODY 2
MELODY 3
TOUCH
MELODY 3
ALBUM
ALBUM
MELODY 4
MELODY 4
SMART LEARNING
SMART LEARNING
MELODY 5
MELODY 5
SMART
SONG VOICESTYLEDEMOPIANO
SONG VOICESTYLEDEMOPIANO
SMART
LEARNING
LEARNING
TEMPO
TEMPO
ACCOMP
ACCOMP
Using Sustain Pedal
Plug an optional pedal into this jack and use it to switch sustain on
and off. When you step on the pedal, all notes you play on the
instrument will have a longer sustain.
06
Connecting a pair of Headphones
1. A standard pair of stereo headphones can be connected to the
PHONES/OUTPUT jack for private practice or late-night playing.
2. The internal stereo speaker system is automatically shut off
when a pair of head phones is plugged into this jack.
Note:
To avoid the risk of hearing loss, do not listen with headphones at
high volume level for a long period of time.
Connecting an Audio Equipment
The rear-panel PHONES/OUTPUT jack delivers the output of the
instrument to an external audio equipment such as a keyboard
amplifier, a stereo sound system, a mixing console, or a tape
recorder.
Use an audio cable to connect the PHONES/OUTPUT jack of the
instrument to the AUX IN jack of the external audio equipment.
Note:
To avoid damaging the speakers, please set the volume level to
minimum before connecting the power and other devices.
Connections
Connecting an MP3/CD Player
The rear-panel AUX IN jack receives audio signals from an external
audio source such as an MP3 or a CD player.
Use an audio cable to connect the AUX IN jack of the instrument to
the AUX OUT jack of the MP3/CD player. The input signal is mixed
with the instrument signal, allowing you to play along.
Connecting a Computer
Use a standard USB cable to connect the USB jack of the instrument to the USB port of a computer. You can save the piano
performance to the computer or use the speaker system to play
back MIDI songs on the computer.
Note:
1. Do not set the USB device to be input and output simultaneously
when setting the software on computer. Otherwise, the sound will
be overlapped when playing the keyboard.
2. We recommend you to use a USB2.0 interface when connecting
the instrument to a computer.
Connecting a Microphone
By connecting a microphone, you can enjoy singing along with your
keyboard performance or with Song playback (KARAOKE).
1. Before turning the power on, set the master volume to minimum.
2. Connect a microphone to the MIC jack.
3. Turn the power on. Adjust the master volume while singing into
the microphone.
Note:
1. You can set the vocal effects in the Function Menu.
2. The [VOLUME] knob cannot adjust the volume level of the
microphone and the AUX IN, you need to adjust it on the external
equipment.
07
Power Switch and Master Volume
Power Switch
Before you switch your instrument on, please turn down the volume
of instrument and the connected audio equipment first.
1. Make sure the instrument is properly connected to power supply.
2. Press POWER SWITCH, the LCD screen is lit, and displays
“Loading!” , it indicates the instrument is powered on.
Note:
If the LCD display does not light up after you turned on the
keyboard, please check the power supply.
Master Volume
Rotate the [VOLUME] knob clockwise, the master volume will
increase and vice verse. It can be adjusted as required.
VOLUME
Note:
If the keyboard keeps silent, check if the volume is set to minimum
or if headphones are plugged into the PHONES/OUTPUT jack.
Playing Demo Songs
This instrument features several wonderful demos. (Please refer to
Demo List.)
1. Press the [DEMO] button, the LCD will display the current demo
number and name, meanwhile, all the demo songs will loop playing.
2. Use the data dial or the [+/Yes]/ [-/No] button to select a demo song.
3. Press the [START/STOP] button to stop playing and exit the demo
mode.
Or you can press the [DEMO] button to quit demo playing.
MIN MAX
DEMO
08
The keyboard has a variety of remarkably realistic built-in voices.
Please refer to Voice List.
1. Press the [VOICE] button.
Enter the Voice Mode. The LCD displays the current default voice
name and number.
2. Select a Voice.
Use the data dial or the [+/Yes]/ [-/No] button to select the voice you
want to play. You can also use the numeric buttons to select a voice.
3. Play the Voice.
Play the keyboard and enjoy the beautiful voice.
Playing Voices
VOICE
The instrument features a variety of styles. Try selecting different styles
(Please refer to the Style List) and playing with the auto accompaniment.
1. Press the [STYLE] button.
Enter the Style Mode. The LCD displays the current default style
name and number.
2. Select a Style.
Use the data dial or the [+/Yes]/ [-/No] button to select the style you
want to play. You can also use the numeric buttons to select a style.
3. Play the Style.
Press the [START/STOP] button to start a rhythm playing.
Playing Styles
STYLE
09
Playing Songs
This instrument has featured a variety of preset songs, and each song
can be practiced in Smart Learning mode.
1. Press the [SONG] button.
Enter the song mode. It will play all songs circularly.
2. Select a song.
Use the data dial or the [+/YES]/ [-/NO] button to select the song
you want to play.
3. Press the [START/STOP] button.
It will stop the song playback. Press it again, it will play current song
repeatedly.
4. When song playback is stopped, press the [STYLE] or [VOICE]
button, to exit the song mode.
SONG
Record
You can record your performance and save it to a user song.
1. Holding down [SHIFT] button, and then press the [RECORD] button
to enter the user song menu. You can use the data dial or the
[+/YES]/[-/NO] button to select a user song to which your recording
will be saved.
2. Holding down [SHIFT] button, and then press the [RECORD] button.
Enter the record standby mode, and you can select voice, style or
other parameters to prepare for recording.
3. Press the [START/STOP] button or play the keyboard to start
recording.
4. When recording is in process, holding down [SHIFT] button and
then press the [RECORD] button, it will stop recording and enter the
Song mode, and the current recorded song will play automatically in
circle.
Note:
To play back a user song in song mode, press the [SONG] button then
use the data dial, [+/YES] or [-/NO] button to select a user songs. If
there is no data in the selected user song, it will display “NoFile!” and
stop playing.
SHIFT
START/
STOP
BANK
ECORD
R
10
The instrument features a variety of exceptionally realistic voices.
Please refer to the Voice List.
Playing a Voice
1. Press the [VOICE] button. Enter the VOICE mode. LCD shows “VOICE
R1” and the current voice name and voice number.
2. Select a voice.
Use the data dial, the [+/YES]/ [-/NO] button to select the voice you
want to play. You can also use the numeric buttons to select a voice.
3. Play the voice.
Play the keyboard and enjoy the beautiful voice.
Note:
When the DUAL and LOWER function is on, you can press [VOICE]
button repeatedly to choose the voice source. The corresponding LCD
indicator will highlight between R1, R2, and L.
Playing two voices simultaneously-DUAL
The dual function allows two different voices to be layered together,
creating a much richer sound. Turn the function on, you can select a
second voice for the dual voice “VOICE R2”.
1. In idle mode, press the [DUAL] button to turn dual function on. The LCD
displays the current voice name and number, and the indicator “VOICE
R 2” and “DUAL”.
2. You can use the data dial or [+/YES]/ [-/NO] button to select the dual
voice you want to play. You can also use the numeric buttons to select
a voice.
3. Play the keyboard, and then you will hear two different voices layered
together, just like two different instruments playing at the same time.
4. Press the [DUAL] button again to turn the dual function off.
Playing Voices
VOICE
DUAL
ICT.
D
Note:
When the keyboard is split, only the right hand area will have the dual
voice.
Playing Different Voices with Both handsLOWER
The lower function splits the keyboard into right and left areas, each with
a different voice. The left section voice is lower voice. You can set the
split point to any key as you like.
1. In idle mode, press the [LOWER] button to turn the lower function on.
The LCD displays the left hand voice name and number, and the
indicator “VOICE L” and “LOWER”.
2. You can use the data dial or the [+/YES]/[-/NO] button to select the
lower voice you want to play. You can also use the numeric buttons to
select a voice.
3. Play the keyboard with both hands, and you will hear two different
voices.
4. Press the [LOWER] button again to turn lower function off.
Split Point
The Point on the keyboard that separates voice L and voice R1/R2 is
called the “split point”. The default split point is at F#3 (19) , however you
can assign it to any other key. Refer to the Function Menu.
Split Point:F#3
LOWER
A
LBUM
Lower Voice
11
Playing Voices
Touch
The touch response feature allows you to dynamically and expressively control the level of the voice with your playing strength just as on an
acoustic instrument. The piano has 3 touch types to choose.
1. Holding down [SHIFT] button and then press [TOUCH] button to
enter the touch menu. LCD displays the current touch level.
The default number is 2.
2. Select a touch level.
When the LCD displays touch setting, using [+/YES]/ [-/NO] or data
dial or holding down [SHIFT] button, and then pressing [TOUCH]
button can change touch level. Pressing [+/YES] and [-/NO] buttons
simultaneously will set touch value to default setting: 2(normal).
3. Turn the touch function off.
If the value is set to OFF, there will be no touch response to
keyboard.
Sustain
1. Holding down [SHIFT] button and then press the [SUSTAIN] button
to start sustain function.
All notes will sustain even after releasing the keys.
2. To stop the sustain function, holding down [SHIFT] button and then
press the [TOUCH] button again
SHIFT
SHIFT
M6
OUCH
T
FUNCTION
SUSTAIN
SSUUSSTTAAIINN
Note:
To have a better sustain effect, we recommend you using a sustain
pedal. (Refer to pedal function for more details.)
Pitch Bend
With the pitch bend wheel, you can easily imitate the guitar, violin,
saxophone or the pitch bend effect of other instruments, and make
your performance more vivid. Simply roll the pitch bend wheel to bend
notes up or down while playing the keyboard.
Transpose
Transpose function allows the overall pitch of the instrument to be
transposed up or down by one octave in semitone steps.
1. Holding down [SHIFT] button, and then press [TRANSPOSE]
button to enter transpose menu. LCD displays the current
transpose: xxx Transpos.
2. Use [+/YES]/ [-/NO] or data dial to adjust the transpose value over
the range: ±12 semitones.
3. Press [+/YES] and [-/NO] simultaneously to set the transpose
value to its default setting: 000 Transpos.
Note:
1. For example, set the transpose to -05 or 007, and then you can play
the G scale using C scale keys.
2. Transpose setting applies to the accompaniment and keyboard
voice.
SHIFT
MIXER
T
RANSPOSE
12
Playing Voices
Octave
The octave function will raise or lower the pitch of the keyboard voice by
an octave.
1. Holding down [SHIFT] button and then press the [OCTAVE] button to
select octave function menu. The LCD displays “xxx Octave”.
2. Use [+/YES]/ [-/NO] button or data dial to change octave value,
adjustable range is: -1~ +1.
3. Press the [+/YES] and [-/NO] buttons simultaneously to restore
default setting: 000.
Note:
1. After adjusting the octave, notes in the highest and lowest keyboard
range may not sound normally.
2. You can set the octave value respectively for voice R1/R2/L.
Piano mode
This function is to set the voice of the whole keyboard to piano instantly.
1. Press [PIANO] button to enter or exit piano mode.
2. In piano mode, the accompaniment control is the same as in the
other modes, however, the accompaniment only plays the rhythm
part.
Note:
In piano mode, the A.B.C. is automatically turned off.
SHIFT
PIANO
METRONOME
CTAVE
O
Metronome
The metronome provides a steady beat to help you practise at a preset
tempo.
1. Press [METRONOME] button to start the metronome.
2. To stop the metronome, press the [METRONOME] button again.
(You can set its time signature in the function menu.)
Note:
1. If you turn on the metronome during style playback, the metronome
sound will start from the next beat and its time signature will match
the current style.
2. In recording mode, you can turn on the metronome, but the metronome
sound will not be recorded.
METRONOME
CTAVE
O
13
Auto Accompaniment
The auto accompaniment feature puts a full backing band at your
fingertips. To use it, all you have to do is to play the chords with your
left hand in the selected accompaniment style, and then the
accompaniment will automatically play along, instantly following the
chords you play. With auto accompaniment, even a solo performer
can enjoy playing with the backing of an entire band or orchestra. The
instrument features a variety of styles, try selecting different styles
(refer to Style List) and enjoy the auto accompaniment feature.
Play Auto Accompaniment
(rhythm track only)
1. Press [STYLE] button.
Enter the style mode. The “STYLE” icon on LCD will light up. The
LCD displays the name and number of the current style.
2. Select a style.
Use the data dial or the [+/YES]/ [-/NO] button to select a style you
want to play. Or you can use the numeric buttons to select a style.
3. Start playing a style.
Press the [START/STOP] button to start the rhythm tracks of the
auto accompaniment. Also you can press [SYNC START] and then
play any key to start the rhythm tracks of the auto accompaniment.
4. If you are ready to stop playing style, press the [START/STOP]
again.
STYLE
START/
STOP
SYNC
START
Play Auto Accompaniment(all tracks)
1. Turn the auto accompaniment on.
In style mode, you can press the [CHORD] button to enter the “auto
bass chord” (A.B.C.) mode. The keyboard is split into two sections.
Left hand section is chord section. The “A.B.C.” icon will light up.
Now pressing any key in chord section (Sync Start status) you will
hear the fantastic accompaniment.
Press [CHORD] button again to enter “full range” mode.
The “FULL RANGE” icon will light up. You can play chords over the
entire keyboard in multi-fingering.
2. Start the auto accompaniment.
You can press [SYNC START] button and then play a chord in
chord section to start auto accompaniment of all tracks.
When you change a chord, the accompaniment automatically
changes.
You can also press [START/STOP] button to start auto
accompaniment of rhythm track, then play a chord in chord section.
It will start auto accompaniment of all tracks.
Note:
The instrument can save several user styles. To use your styles, you
need to convert the styles with our application software and then save
them to instrument.
START/
STOP
SYNC
START
CHORD
INTRO/
ENDING
FILL AFILL B
14
Accompaniment Sections
There are various types of Auto Accompaniment sections that allow you
to vary the arrangement of the accompaniment to match the song you are
playing. They are: Intro, Main (A, B), Fill (A, B), and Ending. By switching
among them during your performance you can easily produce the
dynamic elements of a professional sounding arrangement in your
performance.
1. The intro is an opening section of the song.
When the intro pattern finished, the system will automatically shift to
the main section.
2. MAIN Section
The main is an important section of the song. And it plays an
accompaniment pattern and repeat infinitely until another section's
button is pressed.
3. FILL IN Section
Auto fill in function automatically adds a fill to your performance.
When the fill-in is finished,accompaniment shifts to the Main section
(A,B).
4.ENDING Section
Ending is used for the ending of the song. When the ending is finished,
accompaniment automatically stops. The length of the ending differs
depending on the selected style.
Note:
1. If you keep pressing the [FILL A]/[FILL B] button during style playback,
the fill-in pattern will repeat playing until the button is released.
Playback will then shift to the related MAIN section.
2. When style stops, press the [FILL A]/[FILL B] button to select a MAIN
section. “A or B” will highlight on LCD.
Auto Accompaniment
START/
STOP
STYLE
SYNC
START
INTRO/
ENDING
CHORD
FILL AFILL B
Playing Different Accompaniment Sections
1. Press the [STYLE] button. Then use the numeric buttons, data dial or
[+/YES]/ [-/NO] button to select a style.
2. Press [CHORD] button to enter A.B.C. (auto bass chord) mode.
3. Press [SYNC START] button.
4. Press the [FILL A] button, select the Main A section.
5. Press the [INTRO/ENDING] button. Now the “A” starts flashing on
LCD, and the style is ready to play.
6. It will start the accompaniment as soon as you start playing in Chord
section. When the playback of the intro is finished, it automatically
leads into Main A section.
7. Press the [FILL B] button. A fill-in plays, automatically followed by
the Main B section.
8. Press the [INTRO/ENDING] button again, and it will enter the Ending
Section. When the ending is finished, the auto accompaniment
automatically stops.
Fade
1. Fade In
Starting the style with fade in produces a smooth beginning, the
volume increases from low to high. Press the [FADE] button when
Style playback is stopped. The “ FADE” icon will be lighting up, and
then flashing with style playing.
2. Fade Out
Stopping the style with fade out produces a smooth ending, the volume
will decrease from high to low. Press the [FADE] button during Style
playback. The “FADE ” icon will be lighting up, and then flashing until
style stops.
3. Fade In/ Out Time
The default time is 10 seconds.
IN / OUT
FADE
15
Auto Accompaniment
Accompaniment Volume
The function will adjust the accompaniment volume, so as to keep an
appropriate balance between the accompaniment volume and the voice
volume.
1. Holding down [SHIFT] button, and then use the [ACCOMP +]/
[ACCOMP -] button to set accompaniment volume, adjustable range:
0~127, the LCD displays current accompaniment volume level.
2. Holding down [SHIFT] button and then press the [ACCOMP +]/
[ACCOMP -] for a while to quickly adjust the volume value.
3. When LCD displays the volume level, Holding down [SHIFT], then
press both the [ACCOMP +]/ [ACCOMP -] button simultaneously to
turn the accompaniment volume off. The LCD displays “OFF
Accomp”. Holding down [SHIFT] button and then press the
[ACCOMP +]/ [ACCOMP -] buttons again to turn the accompaniment
volume on.
Chord Fingering
How the chords are played or indicated with your left hand (in the auto
accompaniment section of the keyboard) is referred to as "fingering".
There are 2 types of fingerings as described below.
SHIFT
TEMPO
ACCOMP
Chord Basics
A chord, in music, is any harmonic set of three or more notes that is
heard as if sounding simultaneously. The most frequently encountered
chords are triads. A triad is a set of three notes that can be stacked in
thirds. When stacked in thirds, the triad's members, from lowest
pitched tone to highest, are called: the Root, the Third, and the Fifth.
Triad Type
There are following basic triad types:
Major Triad
Minor Triad
Augmented
Triad
Diminished
Triad
Chord Inversion
We define this chord its root is not in the bass (i.e., is not the lowest
note) as an inversion chord. When the root is in the bass, we call the
chord: root-position chord. If we put the Third and Fifth in the root
position, then it forms “Inversion”, we call this chord “Inversion Chord”.
See the following major triad and its inverted chord.
Chord Name
The chord name contains two parts content: Chord root and Chord type.
A root with a major third added above and a perfect fifth
will consist as a “Major Triad”.
A root with a minor third added above and a perfect fifth
will consist as a “Minor Triad”.
A root with a major third added above and an
augmented fifth will consist as an “Augmented Triad”.
A root with a minor third added above and a diminished
fifth will consist as a “Diminished Triad”.
Single Finger
Single finger type not only can detect single finger but also can detect
multi finger. And the single finger makes it easily to play chords through
only one, two or three keys. Including major, minor, seventh, and minor
seventh chord. Refer to relevant picture on the right for details.
16
Multi-finger
Multi-finger allows you to play chords in normal fingering. Try playing
the 32 chord types in C scale as listed on the right.
Note:
In full range mode, the entire keyboard will only recognize chords
played in normal fingering.
Tempo
Each style of the instrument has been set with a default or standard
tempo; however, this can be changed by using the [TEMPO +]/
[TEMPO -] button.
1. Use the [TEMPO +]/ [TEMPO -] button to change the tempo. While
the tempo value is flashing, use the data dial to quickly change the
tempo.
Auto Accompaniment
TEMPO
ACCOMP
2. Press the [TEMPO+] and [TEMPO-] buttons simultaneously to
restore the default tempo setting.
Note:
When style stops, changing the style will automatically reset the tempo.
However, changing the style during style playback will not result in
tempo change.
One Touch Setting
Sometimes it is not easy to get an appropriate voice to play a song, but
One Touch Setting Function can make it easy to get a perfect choice.
When One Touch Setting is switched on, you can instantly recall all
auto accompaniment related settings including voices selection and
digital effects simply with a single touch of a button.
1. Press the [O.T.S.] button to turns on the One Touch Setting for
current style. The LCD displays “O.T.S. ”.
2. Press one of the One Touch Setting buttons [M1]-[M4].Various panel
settings (such as voice, effect, etc.) that match the selected style
can be instantly recalled.
1. The O.T.S. is automatically turned off when you enter the song mode.
2. In O.T.S. mode, the memory is not selectable.
17
Harmony
The harmony function will automatically add harmony notes to the
notes played in the right-hand section, which gives you a rich and
harmonic expression.
HARMONY
Harmony Switch
1. Press [HARMONY] button. The LCD displays “OFF”, which
indicates the harmony effects is turned off..
2. When the LCD displays “OFF”, repeat the previous operation. The
LCD displays “Duet”, which indicates the harmony effect is on, and
the type is Duet.
3. To choose a different harmony type, please refer to the harmony
setting in function menu.
Play with harmony effect
Turn on the A.B.C. function, then play a chord in the left hand area. As
soon as you play in the right hand area, it will add harmony effect to
the notes.
Note:
The harmony types of 1+5, Octave 1~2, Echo 1~4, Tremolo 1~4 and
Trill 1~4 will always be available, but the rest are not selectable until
the A.B.C is turned on.
Performance Assistant
D
S
P
There are 2 voices you can select to perform in performance assistant
mode: Guitar and Piano.
What's the performance assistant?
Performance assistant is an easy-to-use function. With this function you
will find playing to be more interesting. Even if you are not a keyboard
player, the performance assistant will help you to play your familiar
instrument voice on the keyboard with ease. Performance assistant
provides many wonderful phrases. Just use several keys and you will
perform your own wonderful music.
Enter the Performance Assistant
1. Holding down [SHIFT] button, and then press [PERFORM] button to
enter the performance assistant mode. The default setting is Guitar
Mode and the LCD will display Guitar's voice name.
2. You can use the Data Dial, [+/YES] or [-/NO] button to shift between
the guitar voice and the piano voice.
3. The default time signature is the 4/4 and you can change it in function
menu. Please refer to Performance Beat setting in function menu.
4. Performance assistant supports the following time signature: 2/4, 3/4,
4/4, and 6/8 beat.
5. Use the [TEMPO+] or [TEMPO-] to change the tempo.
SHIFT
O.T.S.
ERFORM.
P
PPEERRFFOORRMM..
PPEERRFFOORRMM..
18
Guitar Mode
Performance Assistant
Guitar key map
The Guitar Mode makes you perform a guitar voice with keyboard just
like you're playing a real guitar. In this mode you can use some
perform skills like strum (5), broken chord (5), echoism (5) and also 2
endings.
Chord part
C2 to B3 is the chord part area. Play a chord in this area.
Sub Area 1
C4 to B4 (only white keys) is the sub area 1. Up to 5 types of broken
chord are provided in this area.
Sub Area 2
The 6 keys: C5 to A5 (only white keys) simulate the 6 strings of a real
guitar. Play a free solo in this area.
Rhythm Area
C6 to G6 (only white keys) is the rhythm area. Wonderful styles and
strums are provided in this area. Use A6 to B6 to play an ending.
Position Change
Press C7, the guitar voice will be shifted to a high position.
Repeatedly press the C7 key to change the guitar voice between a
high and a low position.
Note:
The keys above C7 will not respond in this mode.
Guitar key map
Chord part
Sub
Area 1
Sub
Area 2
Rhythm
Area
Position Change
PPEERRFFOORRMM..
Playing in Guitar Mode
Play a chord in the chord part.
A chord type will be displayed on the LCD and the guitar root note will
sound.
Play a broken chord in the sub area 1.
When the chord type is on display, press a white key in the sub area 1,
a wonderful broken chord phrase will start. Press other white keys to
play different phrases. Play a different chord with your left hand to
enjoy the subtle change in the phrases.
Play a free solo in the sub area 2.
When the chord type is on display, press a white key in the sub area 2
you can play guitar free solo, like you're playing a real one.
Play different chords with your left hand to bring more dynamics to your
performance. The last white key B5 is invalid.
Play a strum rhythm in the rhythm area.
When the chord type is on display, press a white key in the rhythm
area you can play the magic strum rhythm. Change the chord with
your left hand, and play your strums.
End the guitar performing.
Press the A6 or B6 to end your guitar performs. When the ending is
finished, the phrase stops automatically.
Chord part
Chord part
Chord part
Chord part
Sub
Area 1
Sub
Area 1
Sub
Area 1
Sub
Area 1
Sub
Area 2
Sub
Area 2
Sub
Area 2
Sub
Area 2
Rhythm
Area
Position Change
Rhythm
Area
Position Change
Rhythm
Area
Position Change
Rhythm
Area
Position Change
19
Performance Assistant
Play the echoism.
Play the black keys on Sub area 1, Sub area 2 and Rhythm area to play
different echoism patterns. There are 5 kinds of echoism to arrange on
the C#, D#, F#, G#, A# circularly.
Change the position
Press the C7, the PERFORM.H icon will be lightened on the LCD. It
means that the guitar position has been changed to the High position.
Play the white keys in sub area 1, Sub area 2 and Rhythm area, and
enjoy the vivid guitar performance.
Piano Mode
Piano Key Map
The piano mode allows you to play the piano voice just like playing the
acoustic one. In this mode you can use such piano phrases as piano
rhythm (5), broken chord (5) and also 3 endings.
The piano key map is similar to the guitar key map. Press A6 to C7
(white keys) will start an ending. All the black keys above C4 are
invalid.
Playing in Piano Mode
1. Select Piano Mode.
In performance assistant mode, use data dial, [+/YES] or [-/NO]
button to select Piano Mode.
2. Play a chord in chord part. Play different phrases in Sub area and
Rhythm area.
Chord part
Chord part
Piano Key Map
Chord part
Sub
Area 1
Sub
Area 1
Sub Area
Sub
Area 2
Sub
Area 2
Rhythm
Area
Position Change
Rhythm
Area
Position Change
Rhythm
Area
PPEERRFFOORRMM..
3. Press the A6, B6 or C7 to end your piano performance. When the
ending is finished, the phrase stops automatically.
Exit the Performance Assistant
When the phrase stops, press the [VOICE], [STYLE], [SONG], [DEMO],
[SHIFT] + [PERFORM] to exit the Performance Assistant mode.
20
DSP
The DSP simulates sounds in real environment. With the DSP effect,
you can add ambiance and depth to your performance in a variety of
ways. The DSP effect is set to ON and the icon on the LCD is lighten
when keyboard is power on.
Holding down [SHIFT] button and then press the [DSP] button to turn
the DSP effect on or off. Refer to Function Menu for the effect types
and the adjustable levels.
Note:
It may cause a break or a noise if you switch on/off the DSP when style
and song is playing. This is normal and need not panic.
SHIFT
HARMONY
D
S
P
Mixer
The Mixer allows you to adjust separately the volume of different
tracks.
1. Press the [MIXER] button to enter the mixer function menu, the
LCD
displays the current mixer track.
2. Repeatedly press the [MIXER] button to select the track you want.
Then use [+/YES]/ [-/NO] button or data dial to change parameters.
Content
Adjust the Percussion track volume.
Adjust the Rhythm track volume.
Adjust the Bass track volume.
Adjust the Chord 1 track volume.
Adjust the Chord 2 track volume.
Adjust the Chord 3 track volume.
Adjust the Phrase 1 track volume.
Adjust the Phrase 2 track volume.
Adjust the Upper 1 track volume.
Adjust the Upper 2 track volume.
Adjust the Lower track volume.
It will exit the mixer menu if there is no operation in 5 seconds.
MIXER
T
RANSPOSE
21
Pedal Function
You can assign other pedal functions to the sustain pedal. Please
refer to the Function Menu.
1. Sustain Pedal
This pedal function performs the same function as the damperpedal on an acoustic piano, letting you sustain the sound of
voices
even after releasing the keys.Step and press on the pedal to turn the sustain effect on.Release the pedal to turn the sustain effect off.
2. Soft Pedal
When the soft pedal is selected, press the pedal to make them
(the
notes you play) sound softer.
3. Style Start/Stop Pedal
When the style start/stop pedal is selected, press the pedal tostart/stop accompaniment.
4. Memory Pedal
When the memory pedal is selected, pressing this pedal at the
first
time will call up register memory: M1, and then you can call upregister memory M2, M3…by pressing this pedal step by step.
22
Function Menu
Press the [FUNCTION] button to enter function menu. The LCD
displays the current function menu option. Use [+/YES]/ [-/NO] button
or data dial to set parameter of the current menu.
It will exit the function menu if there is no operation in 5 seconds.
Tune
This function sets the pitch of entire keyboard by in a 2-cent increment.
1. Repeatedly press the [FUNCTION] button to select the tune menu.
The LCD displays “xxx Tune”.
Use [+/YES]/ [-/NO] button or data dial to change tune value. Its
range is from -50 to 50 cents.
2. Press [+/YES] and [-/NO] buttons simultaneously will set the tune
value to its default setting: 000.
The setting applies to both accompaniment and the voice.
Key Split
The Point on the keyboard that separates voice L and voice R1/R2 is
called the "split point". Left hand section controls the auto bass chord
accompaniment when the A.B.C. function is on, or it plays the lower
voices when the A.B.C. function is off.
1. Repeatedly press the [FUNCTION] button to select split point menu.
The LCD displays “xxx KeySplit”. Use [+/YES]/[-/NO] button or data
dial to change Split Point. The range of Split Point is: 1~61.
2. Press [+/YES] and [-/NO] buttons simultaneously will set the split
point value to its default setting: F#3 (19).
FUNCTION
SUSTAIN
FUNCTION
SUSTAIN
23
Function Menu
Beat Type
1. Repeatedly press the [FUNCTION] button to select beat type menu.
The LCD displays “xxx BeatType”. Use [+/YES]/ [-/NO] button or data
dial to change beat type. The range of beat type: 0, 2~9.
2. Press [+/YES] and [-/NO] buttons simultaneously will set the beat type
value to its default setting: 004.
Metronome Volume
1. Repeatedly press the [FUNCTION] button to select metronome
volume menu. The LCD displays “xxx MetroVol”. Use [+/YES]/[-/NO]
button or data dial to adjust metronome volume value.
The range of metronome value is: 0 ~ 127.
2. Press [+/YES] and [-/NO] buttons simultaneously will set the
metronome volume value to its default setting: 080.
Pedal Type
1. Repeatedly press the [FUNCTION] button to select pedal type menu.
The LCD displays “00x Pedal Sust”. Use [+/YES]/ [-/NO] button or data
dial to change pedal type.
2. Press [+/YES] and [-/NO] buttons simultaneously will set the pedal
type to its default setting: 001 PedalSustain.
The pedal types are as follows:
The EQ controls the gain setting of different frequency band. Different
gain setting will produce different sound effect. You can select one of
the 6 preset EQ settings in the EQ display.
1. Repeatedly press the [FUNCTION] button to select the EQ type
menu. The LCD displays “006 EQ Reset”. Use [+/YES]/ [-/NO] button
or data dial to change EQ type.
2. Press [+/YES] and [-/NO] buttons simultaneously will set the EQ type
to its default setting: 006 EQ .
No.
1
2
3
4
5
6
LCD
EQ Pop
EQ Rock
EQ Class
EQ Jazz
EQ Dance
EQ Reset
EQ Type
Pop
Rock
Classical
Jazz
Dance
Reset
Reverb Type
1. Repeatedly press the [FUNCTION] button to select reverb type
menu. The LCD displays “004 RevHall1”.Use [+/YES]/ [-/NO] button
or data dial to change reverb type.
2. Press [+/YES] and [-/NO] buttons simultaneously will set the reverb
Harmony Type
Duet
StandardTrio
Full Chord
Rock Duet
Country Duet
Country Trio
Block
4 Close 1
4 Close 2
4 Open
1+5
Octave 1
Octave 2
Arpeggio
Echo1
Echo2
Echo3
Echo4
Tremolo1
Tremolo2
Tremolo3
Tremolo4
Trill1
Trill2
Trill3
Trill4
FUNCTION
SUSTAIN
MIDI IN
1. Repeatedly press the [FUNCTION] button to select MIDI in menu.
The LCD displays “xxx Midi In”. Use [+/YES]/ [-/NO] button or data
dial to change MIDI in channel: 1~16, ALL.
2. Press [+/YES] and [-/NO] buttons simultaneously to restore MIDI in
channel to its default setting: ALL.
MIDI OUT
1. Repeatedly press the [FUNCTION] button to select MIDI out menu.
The LCD displays “xxx Midi Out”. Use [+/YES]/ [-/NO] button or data
dial to change MIDI out channel: 1~16.
2. Press [+/YES] and [-/NO] buttons simultaneously to restore MIDI out
channel to its default setting: 001.
Auto Power Off
This function sets the time period after which the instrument will shut
down if it is not used.
1. Repeatedly press the [FUNCTION] button to select auto power off
menu. The LCD displays “xxx Power Off”. Use [+/YES]/ [-/NO] button
or data dial to change auto power off time: 30 minutes, 60 minutes or
OFF.
FUNCTION
SUSTAIN
FUNCTION
SUSTAIN
2. Press [+/YES] and [-/NO] buttons simultaneously will set the default
setting is: 030 (30 minutes).
26
Performance Beat
This function is used to set the performance assistant beat type.
1. Repeatedly press [FUNCTION] button to select Perform Beat menu.
The LCD displays “xxx Perfm Bt”. Use [+/YES]/ [-/NO] or data dial to
change performance beat: 4-4, 3-4, 2-4, 6-8.
2. Press [+/YES] and [-/NO] buttons simultaneously will set
performance beat channel to its default setting: 4-4.
Vocal Effects
The vocal effect feature will give you a professional vocal experience
when singing with a microphone. The instrument has preset 7 vocal
effects: Delay, Tremolo, Pitch Shift, Low Fidelity, Overdrive, Reverb and
Compressor.
1. Turn the vocal effects on/off
Repeatedly press the [FUNCTION] button to select the vocal effect
menu. The LCD displays “001 V-VclOff”, indicating all vocal effects
are turned off.
2. Select a vocal effect
In the vocal effect menu, press the [+/YES]/ [-/NO] button to select a
vocal effect, such as “002 V-Delay”, which indicates the selected
vocal effect is Delay.
Note:
The selected vocal effect is not activated yet, you need to adjust its
level in the Vocal Effect Level menu.
Function Menu
Vocal Effect Level
You can adjust the effect level for each vocal effect in the vocal effect
level menu.
1. Repeatedly press the [FUNCTION] button to select the vocal effect
level menu. The LCD displays the current effect level, such as “015
vDel-Lev”, which indicates the current delay level is 15.
2. Press the [+/YES]/ [-/NO] button to adjust the effect level. “000”
means the current effect is turned off.
Restore Factory Setting
Pressing and holding [+/YES] and [-/NO] button together and then turn
the power on, the instrument will be restored to factory setting.
It will delete all the user data: user styles, user songs and registered
memory. The LCD will display “Loading!”. After the restore completed,
the instrument will start normally.
Vocal effects and the default levels are as follows:
The Registration Memory feature can make your performance more easy
and efficient. It allows you to save virtually all panel settings to a Registration Memory setting, and you can instantly recall custom panel settings by
pressing a single button.
Registering the Panel Setting
1. There are 8 memory banks, and each bank has 6 memories (M1-M6).
2. Holding down the [STORE] button , then press one of the registration
memory buttons: [M1] - [M6]. Notice that the new settings will replace
the previous memory data.
Note:
Press [STORE] and [M1] button then power on, the registration memory
will be reset to default.
Recalling the Registered Panel Settings
Press one of the registration memory buttons: [M1] - [M6]. For example,
press [M2], the panel settings stored in the memory 2 of bank 1 are
recalled.
Note:
Registration data cannot be recalled when the One Touch Setting function
is on.
1. Press the [BANK] button. The LCD will display the bank number.
2. There are 8 banks in all and each bank has 6 memories (M1-M6).
Repeatedly press the [BANK] button to select a bank.
3. You can save following parameters into M1-M6 registered memory:
Voice Parameter: including voice, dual, lower, DSP, mixer.
Accompaniment Parameter: including style, tempo, and accompani ment no/off.
Function Parameter: including velocity, part parameters in function
menu.
Song Album
The album function allows you to practise a song with a preset style, tempo
and voice. The instrument features a variety of song albums. Please refer to
the Album List.
1. Holding down [SHIFT] button and then press the [ALBUM] button to turn
the album function on or off.
SHIFT
BANK
ECORD
R
LOWER
A
LBUM
2. When the album function is on, LCD displays the name of album song and
the album indicator lights up. Now use the data dial, [+/YES] or [-/NO]
button to select an album song. The instrument will recall the accompani ment parameters to fit that song.
3. Press the [VOICE] or [STYLE] button to exit the album function.
28
ALBUM
With the easy-to-use song recording features, you can record your own
keyboard performances as a user song. Each user songs can be
recorded with 6 tracks (1 ACCOMP track, 5 MELODY tracks) each.
Record
Start Recording
Before you start recording, you need to select a user song to which the
recording song will be saved.
1. Holding down [SHIFT] button and then press the [RECORD] button to
enter user song selection mode. The LCD displays “RecSng01” and
sequence number.
Use the data dial, [+/YES] or [-/NO] button select the user song you
want.
2. Holding down [SHIFT] button and then press the [RECORD] button
again to enter recording standby mode. “REC” appears on LCD and
the beats start flashing. The instrument will automatically select an
empty track to record your performance.
The select track indicator will flash on the left of LCD.
3. In the recording standby mode, you can adjust parameters such as
the voice, style and tempo. When recording a new song, it will
automatically select “Melody 1” as the recorded track.
Holding down [SHIFT] button and then press “ACCOMP” (or
“MELODY1” to “MELODY 5”) to select a desired track.
The ACCOMP track and one of MELODY track can be recorded at
the same time, but it cannot record two MOLODY track
simultaneously.
4. Press [START/STOP] button or play the keyboard to start recording.
If you have selected the ACCOMP track, and have turned on the
A.B.C. function, recording will start as soon as you play a chord in the
left hand area.
ACCOMP
SHIFT
SHIFT
BANK
ECORD
R
BANK
ECORD
R
Select a Track
Track indicators on LCD usually show one of three states: Blinking, Light
on, Light off.
Blinking: It means the track is chosen for recording. If the track has
recorded data, the original data will be replaced.
Light on: the track has data and will play back the data during recording.
Light off: the track either has no data or is under recording and cannot
play back.
In recording standby mode, you can press the track buttons repeatedly
to shift between different states.
Note:
1. Record style with accompaniment track, and record melody with
melody track.
2. In recording standby mode, it will automatically select the empty track
next to the occupied track. For example, if “Melody 1” is occupied,
then “Melody 2” will be selected as the record track. When all 6 tracks
have been recorded, select the “melody 1” track to save recordings.
29
Record
Stop Recording
1. When recording is in process, holding down [SHIFT] button and
then press the [RECORD] button to stop recording.
2. When recording is in process, if the memory is full, the recording
will stop and save automatically, and the LCD displays “Rec_Full”.
3. If you are recording a style, recording will stop when the ending
section is finished.
Playback Recording
1. When recording is in process, holding down [SHIFT] button and then
press the [RECORD] button, it will stop recording and enter the song
mode, the LCD displays default name “RecSng” and number of user
song, the current recorded song will play automatically in circle.
2. Press the [SONG] button to enter the song mode and it will play all
songs circularly. Use the data dial, [+/YES] or [-/NO] button to select
a user songs.
If there is no data in the selected user song, it will display “NoFile!”
and stop playing.
3. When playback stops, you can select a user song, and then press
the [START/STOP] button to play the selected song in a loop.
ACCOMP
MELODY1
MELODY2
MELODY3
MELODY4
MELODY5
ACCOMP
SHIFT
SHIFT
BANK
ECORD
R
BANK
ECORD
R
Note:
1. The saved user songs will not be lost after power off.
2. When the user song stops, press and hold a track button until its
indicator lights off, the selected track will be muted in song playback.
Delete User Song
1. Press and hold [RECORD] and [STORE] button together and turn
power on simultaneously, all user songs will be erased.
2. In the recording standby mode, holding down [SHIFT] button and
then press the [RECORD] button for two seconds, the LCD will
display “Delete?” Now you can press [ACCOMP] (or [MELODY 1] to
[MELODY 5]) button to select the track you want to delete.
The track selected will light up. If all tracks light up, the whole user
song will be erased after confirmation.
3. Press [+/YES] to confirm and the recorded data in this track will be
erased. Press [-/NO] to quit this step, and go back to the recording
standby mode.
BANK
ECORD
R
STORE
CCOMP
A
30
The instrument has a variety of songs, and each song can be practised in
the smart learning mode.
Listen to the songs
1. Press the [SONG] button to enter the song mode. The LCD shows
“SONG” and it will play all songs circularly.
2. Use the data dial, [+/YES] or [-/NO] button to select a song.
3. During song playback, press the [START/STOP] button to stop the
song, press it again to play the current song repeatedly.
4. When the song is stopped, press the [STYLE], [RECORD], [VOICE],
[DUAL] or [LOWER] button to exit the song mode.
Song Control
1. Introductory Beat
Before song start playing, it has the introductory beat; the measure
starts from negative value. It begins to play the melody when the
measure goes to 1.
START/
STOP
SYNC
START
SONG
INTRO/
ENDING
Song
FILL AFILL B
2. REW, FF and PAUSE
When the song is playing:
Press the [ ] button to fast forward the song.
Press the [ ] button to rewind the song (base on the measure).
Press the [ ] button to pause the playing song, press it again to
continue playing.
3. Song Repeat
When playing the song, press the [ ] to set the beginning for a loop
section of the current song, then press it again to set the loop end.
When in loop status, press [ ] again to quit the loop playing status.
31
Smart Learning System
This built-in smart learning mode provides a variety of ways to help you
learn a new song faster and better. It smartly tailors the lessons for you,
tracks your progress and grows with you through the practice.
Smart Learning
How to start the smart learning mode?
Press the [SMART LEARNING] button to enter the Smart Learning
mode. LCD will first display the current song name and number, then
display the lesson name before the lesson starts.
SMART
SMART
LEARNING
LEARNING
Song Number/ScoreLearning Info
Note:
1. Use the data dial, [+/YES] or [-/NO] button to conveniently select a
song.
2. In the process of learning, the LCD displays the highest score of
previous challenge learning.
What is period and phrase?
The fastest way to learning a new song is to divide the song into several
parts, and individually practice each part. While you have a good
command of each part, it may become very easy to learn the complete
song.
A musical phrase is a unit of musical meter that has a complete musical
sense of its own. Just like a complete sentence in an article.
In music, a period is a group of phrases consisting usually of at least
one phrase, a common combination is two or four phrases, but three,
five or more phrases still exist.
Refer to the relationship of song, period and phrase on the right picture.
How to practicing with smart learning?
In order to help you learn songs faster and easier, the instrument
presets 8 lessons for each song, which includes: step learning of pitch,
timing, left hand, right hand, period, phrase and so on, try learning a
new song in an enjoyable way. The contents of each lesson is shown in
the following list:
Content of Lesson
Learn right hand pitch of period/phrase.
Learn right hand pitch and timing of period/phrase.
Learn left hand pitch of period/phrase.
Learn left hand pitch and timing of period/phrase.
Learn both hands pitch of period/phrase.
Learn both hands pitch and timing of period/phrase.
Learn both hands pitch and timing of complete song.
High score challenge.
Phrase1-1Phrase1-2 Phrase2-1Phrase2-2
Period1
Song
Phrase1-1 Lesson1
Phrase1-2 Lesson1
Period1 Lesson1
Phrase1-1 Lesson2
Phrase1-2 Lesson2
Period1 Lesson2
Phrase1-1 Lesson6
Phrase1-2 Lesson6
Period1 Lesson6
Phrase2-1 Lesson1
Phrase2-2 Lesson1
Period2 Lesson1
Phrase2-1 Lesson6
Phrase2-2 Lesson6
Period2 Lesson6
Period1
Period/Phrase
Left / Right
Hand Info
32
Song Lesson7
Song Lesson8
Song Lesson8
(Challenge the highest)
Normally, you will start from lesson 1 to lesson 6 before going to learn
the whole song at lesson 7. During the lessons, the instrument will
smartly pick out those phrases that you are not so familiar in the
practice, and tailor the practice to fit your progress. In lesson 8 (High
score challenge), you can challenge the highest score, and the score
will be permanently recorded.
Prompt Message
LCD
Lesson 1
Play A
Try A
Go Ahead
Try Again
Play A-H
Try A-H
Complete
Test
Score85
Retry ?
Description
Prepare for the next lesson.
preview the phrase which you are going to learn
Prompt the phrase which you are learning.
You have passed the current period/ phrase, please prepare for the next period / phrase.
You haven’t passed the current period/ phrase, please try again.
preview the period you are going to learning
Prompt the period you are learning.
You are going to lesson 7 (Complete song learning).
You are going to lesson 8 (High score challenge).
Your score.
Prompt if you want to play again when you finish this challenge learning.
Smart Learning System
Lesson 1/3/5 (Pitch)
With lesson 1/3/5, you can learn how to currently play melody pitch and
accompaniment chords of songs. These three lessons are played in a
same method. We are going to introduce the lesson 1 as an example.
1. Press [SMART LEARNING] button, start the smart learning. Use
data dial or [+/YES]/ [-/NO] button to select a song you want to learn.
2. The LCD currently displays name and number of song and, then,
display the name of lesson “Lesson 1”. When the LCD displays “Play
A”, it will preview the phrase you are going to learn. Please listen
carefully and watch the notes on the staff.
3. When the LCD displays “Try A”, it prompts you to play the notes to
be shown on the staff.
Note:
When you press the correct note, the song will continue playing,
otherwise, it will stop and wait.
4. After you have finished this phrase the LCD will display your current
learning score “SCOREXX”. If you have got a score of 80 or more
points, congratulations, you have passed this lesson, and you can
enter the next phrase learning. The LCD displays “Go Ahead”. If you
have got a score less than 80 points, the LCD displays “Try Again”, it
means you have to repeat this phrase again.
Note:
If your score is less than 80 points for 3 times, the system will replay the
current phrase again to help you be familiar with it. Repeat the practice
until you can play the phrase with ease.
33
Smart Learning System
Lesson 2/4/6 (Pitch and Timing)
In lesson 2/4/6, you will further learn both the pitch and timing of a song.
That is to say, play songs with correct timing, pitch or chord.
These three lessons are played in a same method. We are going to
introduce lesson 2 as an example.
1. The system automatically enters the lesson 2 after you have passed
the lesson 1; The LCD displays “Lesson 2”.
2. In lesson 2 mode, the system will preview the period /phrase you
are to play, and then start the lesson 2 learning. The LCD displays
“Try A”.
3. The LCD currently displays your learning score: “SCOREXX”. If
your score is or more than 80 points, you can prepare for the next
lesson, the LCD will display “GoAhead”, otherwise, the LCD will
display “Try Again”, repeat practicing current phrase.
4. If your score is less than 80 points for 3 times, it will automatically
reduce the tempo by 10%. (For example, if the original tempo is
100, then it will go down to 90); you can practice with the new
tempo.
If your score reach 80 points, the tempo will automatically recover
10%, repeatedly practice period/phrase until you can play songs
smoothly at the original tempo.
Note:
The tempo will be reduced by 50% at most. You can press [TEMPO +]
and [TEMPO -] buttons simultaneously to reset to the default tempo.
Lesson 7 (Complete Song Learning)
1. Normally, you can start lesson 7 after finished lesson 1~6. Of
course, you can directly enter lesson 7 by pressing [ ] button.
The LCD displays “Complete” means you are preparing to learn
lesson 7.
2. In lesson 7 mode, the instrument will completely play back a song
for once, and then start pitch and timing practice. During the lesson,
it will smartly pick out those phrases that you are not so familiar in
the practice, and tailor the practice to fit your progress.
Repeatedly practice until you can play the song smoothly.
Lesson 8 (High Score Challenge)
When the above lessons are finished, it will automatically enter the
lesson 8 learning, the high score learning. The LCD displays “Test” and
your score from the last challenge.
Surely, if you want to directly challenge a song, you can press [ ]
button, and switch to lesson 8 quickly. After you finish this lesson, the
LCD will display your score and corresponding prompt sound. As the
list below:
Score
<60
60~69
70~79
80~89
90~100
Prompt Sound
Try Again
Ok
Good
Very Good
Excellent
34
If your score is higher than the instrument record, then congratulations!
This indicates that you have challenged successfully and your score will
be permanently recorded.
Select a Lesson
Besides the standard learning procedure, you can also press the
[ ] or [ ] button to freely select a lesson.
You can select a lesson from lesson 1 to lesson 8; the LCD will display
relevant information of lesson.
Pause the Lesson
Press the [ ] button to pause. Press the [ ] button again and the
lesson will resume from the current position.
Note:
The [ ] button cannot be used to pause lesson learning in lesson
1/3/5.
Stop/Start the Lesson
You can press the [start/stop] button to stop or start to learn. During the
learning process, press the [start/stop] button, it will stop and go back
the beginning of the current lesson.
Smart Learning System
Keeping Records of the Learning Progress
It smartly tracks your progress and save it, so the next time you enter
the function, you can pick up from where you leave.
Note:
It will not save your progress or records unless you exit the function as
instructed. That is to say, any sudden power off will result in lost of
records.
Practice with the Metronome
At the beginning of a lesson, the metronome provides a click sound,
giving you an accurate tempo guide when you practice, or letting you
easily start the lesson learning.
Note:
Since the piano songs do not have any accompaniment in lesson 6/7/8,
the system will automatically start metronome to help your lesson
learning.
35
Chord Dictionary
If you know the name of a chord but don't know how to play it, you
can use the Chord Dictionary function.
DICT 1 (Chord Learning Mode)
Holding down [SHIFT] button, and then press the [DICT.] button to
enter the DICT 1 mode, the LCD displays “Dict.1” and the A.B.C.
automatically turned on. In DICT 1 mode, the keys C4~B5 are used to
assign the Chord Type, the keys C6~B6 are used to assign the Chord
Root. When the Chord Type and Chord Root are confirmed, the LCD
will display the Chord and its keyboard position. For example, if you
want to play a CM7 Chord, press the C6 key to specify C as the chord
root. The root note you set will be shown on the LCD but the note
doesn't sound. Refer to the picture on the right for assigning the Chord
Root.
Press the E4 key to specify M7 as chord type. When the Chord Type
and Chord Root are confirmed, the LCD will display the chord and its
keyboard position. A prompt sound will be heard when you play it
correctly in the chord area.
DICT 2 (Chord Testing Mode)
Holding down [SHIFT] button, and then press the [DICT.] button to
enter the DICT 2 mode. In DICT 2 mode, you can have a chord test.
LCD will display a chord name in random order. If the chord fails to be
played in 3 seconds, its notes will appear on LCD. Once the chord is
played correctly, a new chord name will appear after a few seconds.
In DICT 2 mode, Holding down [SHIFT] button, and then press the
[DICT.] button again to turn off chord dictionary.
24 Chords will be displayed in the dictionary mode as follows:
Note
C6
C#6
D6
Eb6
E6
F6
F#6
G6
Ab6
A6
Bb6
B6
Chord Root
C
C#/Db
D
Eb/D#
E
F
F#/Gb
G
Ab/G#
A
Bb/A#
B
Note
C4
C#4
D4
Eb4
E4
F4
F#4
G4
Ab4
A4
Bb4
B4
Chord Root
M
M(9)
6
mM7
M7
M
M(9)
M6
M7(9)
M7
M7b5
7
Note
C5
C#5
D5
Eb5
E5
F5
F#5
G5
Ab5
A5
Bb5
B5
Chord Root
7(b9)
7(9)
7(#9)
7(b13)
7(13)
7(#11)
dim7
dim
7aug
aug
7sus4
sus4
SHIFT
SHIFT
M7
chord type
DUAL
D
ICT.
DUAL
D
C
root
ICT.
36
With the MIDI functions you can expand your musical possibilities.
This section will let you know what MIDI is, and what it can do, as well
as how you can use MIDI on your instrument.
What's MIDI?
1. MIDI (short for Musical Instrument Digital Interface) allows a wide
variety of electronic musical instruments, computers and other
related devices to connect and communicate with one another.
MIDI carries event messages that specify notation, pitch and
velocity, control signals for parameters such as volume, vibrato,
audio panning, and program change information to change the voice
selections.
2. The instrument can output the real-time playback information via
MIDI messages and control external MIDI devices. The instrument
can also accept incoming MIDI messages and generate sound
accordingly.
Note:
This instrument has a USB(DEVICE) terminal, which can be connected
to a PC as an MIDI input or MIDI output. This can not be connected with
another instrument, unless the instrument has a USB host terminal.
MIDI
Upload/Download Data from the Computer
1. Connect a standard USB cable between the rear-panel USB jack
on the instrument and the USB jack on your computer.
2. Power on the instrument first, and then open the PCSUITE software
on your computer. If the LCD displays “PCLink..” it indicates the
piano connects the PC successfully.
3. You can download MIDI files to the keyboard as user songs or
upload the user songs to PC.
4. You can upload user styles to the computer as a backup or
download them to the keyboard. You can upload memory files to the
computer as a backup or download them to the keyboard.
5. Please refer to software operation instructions for detail operating
methods.
37
Troubleshooting
Problem
The speakers produce a pop sound
whenever the power is turned ON or OFF.
No sound when the keyboard is played.
When using a mobile phone, noise is
produced.
The auto accompaniment does not play
back even Sync is in standby condition
and a key is pressed.
Certain notes sound at wrong pitch.
The Harmony function does not operate.
Possible Cause and Solution
This is normal and is no cause for alarm.
Make sure the master volume is set to an appropriate level. Check if headphones
are plugged into the PHONES/OUTPUT jack. The R1/R2/L voice volume (Mixer)
settings could be set too low. Make sure the voice volumes are set at appropriate
levels.
Using a mobile phone in close proximity to the instrument may produce
interference. To prevent this, turn off the mobile phone or use it further away
from the instrument.
You may be trying to start accompaniment by playing a key in the righthand
range of the keyboard. To start the accompaniment with Sync Start, make
sure to play a key in the left-hand range of the keyboard.
Make sure that the tuning value is set to 0. Press and hold the [+/YES] and
[-/NO] buttons at the same time, then turning the power on will set
INSTRUMENT to default.
Please make sure the Harmony function is on. And Harmony cannot be turned
on when a drum kit is selected for thevoice R1.
Notice:
If you notice any abnormality cannot handle, please connect the provider or specified repair station, and have the
instrument inspected by qualified service personnel.
38
Specifications
LCD Display
Multi-functional LCD
Keys
61 Keys with Touch Response
Polyphony
128
Voices
653
Songs
160 Preset Songs and 10 User Songs
Styles
240 Preset Songs and 10 User Styles
Demos
8
Album
310
Tempo
30 – 280
Panel Memory
48
DSP
With DSP function, your performance will have a broader
and fuller expression.
Accompaniment/Song Control
Start/Stop, Sync Start (Pause), Intro/Ending
(Repeat A/B), Fill A (REW), Fill B (FF),
Chord Mode, Fade.
