magicolor 1650EN
The compact A4 colour network printer
Colour printer 5/20 ppm
magicolor 1650EN
Network colour
for you and the team
If you are working in a small but busy team or office, why not ease your workload with a compact yet efficient
A4 colour printer that is stylish, affordable and easy to use. Konica Minolta’s small workgroup colour printer
magicolor 1650EN is all that and more – which makes it the perfect choice for your daily printing tasks.
With five colour or 20 black and white pages per minute, the
magicolor 1650EN is ideal to produce all the diverse documents
that small teams and offices typically deal with every day.
This compact printer is small enough to fit into any office and its
quiet operation makes it comfortable to work with. It is also fully
network compatible and ideal for small teams and workgroups.
The magicolor 1650EN comes in three flexible configurations:
The stadard model, magicolor 1650EN, offers network colour
and black and white printing. The magicolor 1650EN-d comes
with an automatic duplexer for double-sided printing, perfect
for printing presentations and brochures, and saving paper.
The magicolor 1650EN-dt combines double-sided printing with
additional paper trays for bigger print jobs and more volume.
magicolor 1650EN
standard
magicolor 1650EN-d
with duplex unit
magicolor 1650EN-dt
with duplex unit and
lower paper feeder
Configuration magicolor 1650EN magicolor 1650EN-d magicolor 1650EN-dt
Duplex
200 sheet paper
feeder
500 sheet lower
paper feeder
X X X
X X
X
Versatile printing power
Flexible media handling
Whatever your print requirements, the magicolor
1650EN gives you perfect results every time. With
a standard Emperon™ controller, it is PCL®6 and
PostScript®3 compatible, and at home in Windows,
Mac and Linux environments. Its powerful 256 MB
memory ensures fast processing of all print jobs;
Simitri®HD polymerised toner enhances the print
quality by delivering vivid colours and fine lines to
even the tiniest detail. A further benefit of Simitri®HD
toner is its increased resistance to UV light, producing
prints that are impressively long-lasting.
The magicolor 1650EN impresses with its versatile
media handling, being capable of processesing thin
and thick paper between 60 and 209 gsm, in A4
and A5 sizes. It can effortlessly print business cards,
envelopes, labels, photos, colourful presentations,
leaflets and more, saving you time and money.
And if the standard paper supply of 200 sheets leaves
you short, simply add extra capacity with a lower
paper feeder that gives you another 500 sheets.
Flexibility can also be increased with an optional
automatic duplex unit that makes double-sided
printing fast, convenient and completely automatic.
Clean Planet programme for the
environment
Konica Minolta takes the responsibility towards the
environment seriously, and strives to reduce the
impact of its products at each stage of the product
lifecycle. The Clean Planet programme gives you the
opportunity to recycle your used toner cartridges for
free. Cartridges are recycled efficiently, preserving
precious resources. Returning the cartridges is
quick, easy and completely free for you.
Big on ease of use
The magicolor 1650EN is ready to print as soon as
you take it out of its box. Operation is simple and
intuitive via the clearly structured LCD display; and
with the PageScope Web Connection tool you can
track consumable usage and manage the printer
configuration from your PC. Access to consumables
is straightforward with front loading toner cartridges.
Technical specifications
Print process
Print method
Desktop full colour A4 laser printer
Print speed
Up to 20 ppm monochrome
Up to 5 ppm colour
First page out
13 seconds monochrome
22 seconds colour
Warm-up time
Average 30 seconds
Max. resolution
PhotoART 9600
(600 dpi x 600 dpi x 4 bit)
Hardware and software
capabilities
Processor
400 MHz (Zoran Quatro 4230)
Memory
256 MB standard
Printer language
PCL 5c/e, PCL 6 (XL 2.1), HPGL/2,
PostScript 3
Printer management
®
PageScope
NetCare Device Manager
®
PageScope
Web Connection
®
PageScope
Network Setup
®
PageScope
EMS Plug-in
®
PageScope
Plug and Print
®
PageScope
NDPS Gateway
®
PageScope
Direct Print
Colour simulations
SWOP, Commercial Press,
Eurocolor, DIC, TOYO
Fonts
146 standard PostScript fonts
97 PCL scalable fonts
53 Symbol sets
10 standard line printer fonts
Interface support
10-Base-T/100-Base-TX Ethernet,
USB 2.0
Operating system
compatibility
Windows
2000, Server 2003 (32/64),
Server 2008, XP (32/64),
Vista (32/64)
Macintosh
OSX 10.2 or later,
OSX Server 10.2 or later,
OSX 10.5
Linux
Redhat v.9.0, SUSE v.8.2
Paper handling
Standard paper input magicolor
1650EN & magicolor 1650EN-d
200 sheet multi manual tray
Standard paper input magicolor
1650EN-dt
200 sheet multi manual tray
500 sheet lower paper feeder
Standard paper output
100 sheet face down output tray
Optional paper handling
500 sheet lower paper feeder
Printable area
Approx. 4 mm from all edges
Media sizes supported
A4, A5, letter, legal, envelope
C6, envelope DL, B5, custom size
92 – 216 mm x 184 – 356 mm
Duplexer sizes supported
A4
Paper weights
Plain paper (60 – 90 gsm)
Recycled paper (60 – 90 gsm)
Thick paper 1 (91–163 gsm)
Thick paper 2 (164 – 209 gsm)
Print media
Plain paper, recycled paper,
envelope, labels, postcard,
thick paper, letterhead
Physical
Dimensions (W x D x H in mm)
magicolor 1650EN:
396 mm x 380 mm x 275 mm
magicolor 1650EN-d:
396 mm x 435 mm x 337 mm
magicolor 1650EN-dt:
396 mm x 565 mm x 392 mm
Weight
magicolor 1650EN:
15.1 kg with consumables
magicolor 1650EN-d:
19.3 kg with consumables
magicolor 1650EN-dt:
22 kg with consumables
Electrical
Input voltage range
220 ~ 240 V (
Frequency
50 ~ 60 Hz (
Power consumption
470 W or less
(average colour printing)
510 W or less
(average monochrome printing)
200 W or less
(stand by)
22 W or less
(energy save mode)
+
10 %)
–
+
3 %)
–
Environmental
Temperature
10 ~ 35 °C
Humidity
15 ~ 85 % RH
Noise levels
49 dB or less operating colour
50 dB or less operating monochrome
29 dB or less stand by
Regulatory/Safety
conformity
Energy Star, Doc, CE Marking, GS,
EMC, WEEE, EcoMark
Consumables
Pre-installed
Toner:
Cyan, magenta and yellow toner yield
up to 500 pages
Black toner yield up to 1,000 pages
Imaging unit
(waste toner bottle included):
Black yield up to 45,000 pages
Cyan, magenta and yellow yield up
to 11,250 pages
Replacements
Toner:
Standard: Cyan, magenta and yellow
toner yield up to 1,500 pages
High capacity: Cyan, magenta, yellow
and black toner yield up to 2,500
pages
Imaging unit
(waste toner bottle included):
Black yield up to 45,000 pages
Cyan, magenta and yellow yield up
to 11,250 pages
Maintenance parts
Fuser unit
Yield up to 50,000 sheets
2nd transfer unit
Yield up to 50,000 sheets
Warranty period and
conditions
1 year on-site warranty
(within EU; local law applies)
Konica Minolta
Business Solutions (UK) Ltd
Old Bridge House • The Hythe
Staines • Middlesex TW18 3JQ
Tel: +44 (0)1784 44 22 55
Fax: +44 (0)1784 41 18 68
www.konicaminolta.co.uk/printer
n
All specifications relating to paper capacity refer to A4-size paper of 80 gsm quality.
n
All specifications relating to printing speeds refer to A4-size paper that is printed in multipage, simplex mode.
n
The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network and system configurations.
n
The stated life expectancy of each consumable is based on specific operating conditions such as page coverage for a particular page size (5 % coverage of A4). The actual consumables life will
vary depending on the use and other printing variables including page coverage, page size, media type, continuous or intermittent printing, ambient temperature and humidity.
n
Some of the product illustrations contain optional accessories.
n
Specifications and accessories are based on the information available at the time of printing, and are subject to change without notice.
n
Konica Minolta does not warrant that any prices or specifications mentioned will be error-free.
n
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks, of Microsoft Corporation in the United States and/or other countries.
© 2008 KONICA MINOLTA. All rights reserved. Specifications are subject to change without notice. The KONICA MINOLTA logo, magicolor, Emperon and Simitri HD, PhotoART-9600 are
trademarks of KONICA MINOLTA. All other brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
For further information please visit www.konicaminolta.co.uk/printer
