Page 1
Kodak EasyShare M1093 IS
digital camera
Extended user guide
www.kodak.com
For interactive tutorials:
www.kodak.com/go/howto
For help with your camera:
www.kodak.com/go/m1093support
Page 2
Eastman Kodak Company
Rochester, New York 14650
© Eastman Kodak Company, 2008
All screen images are simulated.
Kodak, EasyShare, and Perfect Touch are trademarks of Eastman Kodak Company.
4F8128_en
Page 3
Front view
Product features
1
2
3
4
5
8
7
6
1 Shutter button 5 Lens/Cover
2 Mode button 6 Self-timer light/AF assist light
3Flash button 7Flash
4 Power button, Battery Charging light 8 Microphone
www.kodak.com/go/support
i
Page 4
Product features
Back view
1
2
3
4
13
12
6
7
8
9
11
10
optional
1LCD 8 USB/AV Out
2 Telephoto/Wide Angle button 9 Delete, Share buttons
3 Speaker 10 Slot for optional SD or SDHC card
4 DC-In (5V) 11 Battery compartment
5 Review, Menu buttons 12 Tripod socket
6 Strap post 13 Dock connector
7Joystick
OK button
Display
Self-timer/Burst
5
ii www.kodak.com/go/support
Page 5
Table of contents 1
1 Setting up your camera .........................................................................1
Attaching the strap .......................................................................................1
Loading the KLIC-7004 battery......................................................................1
Charging the battery .....................................................................................2
Turning on the camera ..................................................................................2
Setting the language and date/time...............................................................4
Storing pictures on an SD or SDHC card.........................................................4
2 Taking pictures/videos ...........................................................................5
Taking a picture ............................................................................................5
Using the framing marks to take pictures.......................................................6
Using the optical zoom..................................................................................6
Using the flash..............................................................................................7
Using different modes ...................................................................................8
Taking a video ............................................................................................10
Using the self-timer.....................................................................................11
Understanding the picture-taking icons........................................................12
3 Working with pictures/videos ..............................................................13
Reviewing pictures/videos ...........................................................................13
Deleting pictures/videos ..............................................................................14
Understanding the review icons...................................................................15
Using the menu button in review.................................................................16
Cropping pictures........................................................................................17
Adding sound tags......................................................................................17
Using Kodak Perfect Touch technology ........................................................18
Editing videos .............................................................................................19
Running a slide show..................................................................................22
Viewing pictures/videos in different ways.....................................................25
Selecting multiple pictures/videos ................................................................26
Copying pictures/videos...............................................................................26
www.kodak.com/go/support iii
Page 6
Table of contents
4 Doing more with your camera .............................................................27
Using the menu button to change settings...................................................27
Using the Setup menu.................................................................................32
Taking panoramic pictures...........................................................................35
Using the histogram to view picture brightness............................................36
Using the framing grid to compose a picture................................................36
5 Transferring, printing, tagging ............................................................37
Installing the software.................................................................................37
Transferring pictures/videos.........................................................................38
Printing pictures..........................................................................................39
Tagging your pictures..................................................................................41
6 Troubleshooting ..................................................................................45
7 Getting help ........................................................................................49
Getting help from your camera....................................................................49
Getting help on the Web.............................................................................50
Getting help on the telephone.....................................................................51
8 Appendix .............................................................................................52
Camera specifications .................................................................................52
Care and maintenance ................................................................................54
Upgrading your software and firmware........................................................55
Storage capacities.......................................................................................55
Important safety instructions .......................................................................55
Battery replacement, battery life..................................................................56
Limited warranty .........................................................................................57
Regulatory compliance ................................................................................59
iv www.kodak.com/go/support
Page 7
1 Setting up your camera
IMPORTANT:
For package contents, see your product package.
Attaching the strap
Loading the KLIC-7004 battery
For information on replacing batteries and extending battery life, see page 56.
www.kodak.com/go/support 1
Page 8
Setting up your camera
Charging the battery
1
Turn OFF the camera.
2
Connect the cable.
Battery Charging light:
• Blinking: charging
• Steady: finished charging
Learn other charging options See page 3
Learn more about batteries See page 56
Turning on the camera
Press the Power button to
turn on the camera in Smart
Capture mode.
2 www.kodak.com/go/support
Page 9
Setting up your camera
Other charging options
First, turn OFF the camera. Charge until the Battery Charging light stays on.
Kodak 5V AC adapter
(May be sold separately.)
Kodak EasyShare camera or
printer dock; EasyShare
HDTV dock
(May be sold separately.)
For dock compatibility, see
page 40.
Kodak USB cable and a USB
computer port
Ensure that the USB cable is
connected to a powered USB
port and the computer is turned
on (not in sleep mode).
Purchase accessories www.kodak.com/go/m1093accessories
Learn more about USB charging www.kodak.com/go/USBcharging
www.kodak.com/go/support
3
Page 10
Setting up your camera
Setting the language and date/time
Language:
to change.
to accept.
OK
Date/Time:
At the prompt, press OK.
to change.
OK (press)
NOTE: To change language in the future, see page 33. To change date & time, see page 33.
for previous/next field.
to accept.
OK
Storing pictures on an SD or SDHC card
Your camera has internal memory. You can purchase an SD or SDHC card to
conveniently store more pictures/videos.
CAUTION:
A card can only be inserted one way; forcing it may cause
damage. Inserting or removing a card while the camera is on may
damage the pictures, the card, or the camera.
Turn off the camera.
1
Insert or remove the
2
optional
optional card.
3
Turn on the camera.
Purchase accessories www.kodak.com/go/m1093accessories
4 www.kodak.com/go/support
Page 11
2 Taking pictures/videos
Taking a picture
1 Press the Power button to turn on the camera.
2 Compose the picture.
3 Press the Shutter button halfway to focus and
set exposure. When the framing marks turn green,
press the Shutter button completely down.
NOTE: You can repeatedly press to turn on/off status icons,
histogram, and framing grid.
Framing marks
Reviewing the picture/video just taken
After you take a picture/video, the LCD displays a quickview for approximately 5
seconds. (To exit the quickview sooner, press the Shutter button halfway.)
Play/pause a video
Adjust volume
Delete
To review pictures/videos anytime, see page 13.
www.kodak.com/go/support 5
Page 12
Taking pictures/videos
Using the framing marks to take pictures
Framing marks indicate the camera focus area. In Smart Capture mode (and in SCN
modes designed for pictures of people), the camera attempts to focus on faces.
1 Press the Shutter button halfway.
If the camera is not focusing on the desired subject,
release the Shutter button and recompose the scene.
2 Press the Shutter button completely down to
take the picture.
Framing marks
NOTE: Multiple framing marks may appear when faces are detected. (The primary face gets a yellow
framing mark. To change focus from the selected face to another face, press .) Framing
marks do not appear in all modes.
Using the optical zoom
1 Use the LCD to frame your subject.
2 To zoom in, press Telephoto (T).
To zoom out, press Wide Angle (W).
3 Take the picture or video.
NOTE: For focus distances, see Specifications starting on page 52.
Using digital zoom
Use digital zoom in any picture-taking mode to get up to 5X magnification beyond
optical zoom. Press Telephoto (T) until the slider is at the end of the optical zoom
range. Release Telephoto (T), then press it again.
NOTE: Digital zoom is not available in Smart Capture mode. You may notice decreased image quality when
using digital zoom. The slider pauses and turns red when the picture quality reaches the limit for an
acceptable 4 x 6-in. (10 x 15 cm) print. You cannot use digital zoom while taking a video.
6 www.kodak.com/go/support
Page 13
Taking pictures/videos
Using the flash
Press the flash button repeatedly to scroll through flash modes.
The current flash mode is shown in the LCD status area.
Flash modes Flash fires
Auto When the lighting conditions require it.
Fill Every time you take a picture, regardless of the lighting
conditions. Use when the subject is in shadow or is
“backlit” (when the light is behind the subject). In low
light, hold the camera steady or use a tripod.
NOTE: (Not available in Smart Capture mode.)
Red Eye
Your camera can correct
red-eye using 2
methods. To choose a
red eye setting, see Red
Eye Reduction, page 32.
Preflash A preflash fires, shrinking the eye pupil, before the
picture is taken.
Digital
Correction
A preflash does not fire; the camera corrects red eye.
Off Never
Your camera saves the flash setting, even after you turn off the camera.
www.kodak.com/go/support
7
Page 14
Taking pictures/videos
Using different modes
Choose the mode that best suits your subjects and surroundings.
Mode
Use this mode For
General picture taking—it offers excellent image quality and ease of
use.
■ Faces are detected.
■ The scene is analyzed for other content and for lighting.
Smart
Capture
Video
■ Kodak Perfect Touch technology is applied, for better pictures.
You can choose the best picture size and aspect ratio for your
needs—just press the Menu button and choose Picture Size.
■ 3:2 (the best choice when making 4 x 6 prints)
■ 16:9 (wide screen)
■ 4:3 (the default setting)
Capturing video with sound. (See page 10.)
1 Press the Mode button.
2 Press to highlight a mode, then press OK.
Program
Scene
Advanced picture taking—allows more access to manual settings than
Smart Capture.
Point-and-shoot simplicity when taking pictures in practically any
situation. (See page 9.)
8 www.kodak.com/go/support
Page 15
Taking pictures/videos
Using Scene (SCN) modes
Choose a Scene mode—for great pictures in practically any situation!
1 Press the Mode button.
2 Press to highlight SCN, then press OK.
3 Press to view scene mode descriptions.
If the mode description turns off before you finish reading it, press OK.
4 Press OK to choose a Scene mode.
SCN mode For
Portrait Full-frame portraits of people.
Panorama L-R,
R-L
Blur Reduction Reducing blur caused by camera shake or subject motion.
Sport Subjects that are in motion.
Landscape Distant scenes.
Close-up Close range. Use available light instead of flash, if possible.
Night Portrait Reduces red eye of people in night scenes or low-light conditions.
Night Landscape Distant scenery at night. Flash does not fire.
Snow Bright snow scenes.
Beach Bright beach scenes.
Text Documents. Place the camera on a steady surface or tripod.
Fireworks Fireworks. Place the camera on a steady surface or tripod.
Flower Close-ups of flowers or other small subjects in bright light.
Manner/
Museum
See page 35.
Quiet occasions, like a wedding or lecture. Flash and sound are
disabled. Place the camera on a steady surface or tripod.
www.kodak.com/go/support
9
Page 16
Taking pictures/videos
SCN mode For
SelfPortrait
High ISO People indoors, in low-light scenes.
Children Action pictures of children in bright light.
Backlight Subjects that are in shadow or “backlit” (when light is behind the
Panning Shot Shooting a fast-moving subject. The background gives the sense
Candle Light Subjects illuminated by candle light.
Sunset Subjects at dusk.
Close-ups of yourself. Assures proper focus and minimizes red
eye.
subject).
of movement, while the subject appears still.
Taking a video
Mode
1 Press the Mode button.
2 Press to highlight Video, then press OK.
3 Press the Shutter button completely down,
then release it. To stop recording, press and release
the Shutter button again.
To review and work with videos, see page 13.
10 www.kodak.com/go/support
Page 17
Taking pictures/videos
Using the self-timer
Use the self-timer when you want to be included in a picture, or to ensure a steady
Shutter button press. Place the camera on a tripod or flat surface.
1 In any picture-taking mode, press until the
desired self-timer icon appears for:
10 seconds—A picture is taken after a 10-second
delay (so you have time to get into the scene).
2 seconds—A picture is taken after a 2-second
delay (for a steady, shutter release on a tripod).
2 shot—The first picture is taken after a 10-second
delay. A second picture is taken 8 seconds later.
2 Compose the scene. Press the Shutter button
halfway, then completely down.
The camera takes the picture/pictures after the delay.
NOTE: In Panoramic modes (page 35), only the 2- and 10-second options are available.
Use the same procedure to take a 2- or 10-second self-timer video, but press the
Shutter button completely down.
Using burst
Use burst to take up to 3 pictures in quick succession. (Burst is not available in
Panorama mode.)
1 In any picture-taking mode, repeatedly press
until the Burst icon appears at the top of the LCD.
2 Press the Shutter button halfway to focus and set
exposure. Press the Shutter button completely
down and hold it to take pictures.
www.kodak.com/go/support
11
Page 18
Taking pictures/videos
Understanding the picture-taking icons
Self timer
Picture size
Flash mode
Focus mode
Capture mode
Tag nam e
Histogram
Framing grid
Long time exposure
Date stamp
Pictures/time remaining
Image storage location
Zoom indicator
AF control
White Balance
Exposure metering
AF zone
Battery level
ISO
Exposure compensation
12 www.kodak.com/go/support
Page 19
3 Working with pictures/videos
Reviewing pictures/videos
1 Press the Review button.
2 Press for previous/next picture/video.
■ To exit, press the Review button.
Magnifying a picture
1 Press T to magnify 1X–8X.
2 Press to view other parts of a
picture.
■ Press OK to return to 1X.
Playing a video
Press to play a video. Press OK to
pause/unpause. During playback:
■ Press to adjust the volume.
■ Press to play at 2X speed; press again for 4X.
Playback speed
4X
Reverse
www.kodak.com/go/support 13
1X2X 2X
Forward
■ Press to reverse at 2X speed; press again for 4X.
4X
■ Press and hold for 4 seconds to jump to a
bookmark (see page 21).
Page 20
Working with pictures/videos
Deleting pictures/videos
1 Press the Review button.
2 Press for previous/next picture/video.
3 Press the Delete button.
4 Follow the screen prompts.
NOTE: To delete protected pictures/videos, remove protection before deleting. (See Protecting
pictures/videos from deletion.)
Using the undo delete feature
If you accidentally delete a picture/video, you may be able to use Undo Delete to
retrieve it. This feature is only available immediately after you delete a picture/video.
Protecting pictures/videos from deletion
1 Press the Review button.
2 Press for previous/next picture/video.
3 Press the Menu button.
4 Press to highlight Protect, then press OK.
The picture/video is protected and cannot be deleted. The Protect icon appears
with the protected picture/video.
■ Press the Menu button to exit the menu.
CAUTION:
Formatting internal memory or an SD or SDHC card deletes all (including
protected) pictures/videos. (Formatting internal memory also deletes
email addresses and tag names. To restore them, see EasyShare software
Help.)
14 www.kodak.com/go/support
Page 21
Understanding the review icons
Pictures
Email tag
Protected
Favorite tag
Review
Selected
Working with pictures/videos
Print tag/number of prints
Perfect Touch tech.
Picture/Video number
Image storage location
Relative picture number
Scroll arrows
Videos
Email tag
Protected
Favorite tag
Review
Scroll arrows
www.kodak.com/go/support
Battery level
Tag nam e
Video length
Picture/Video number
Image storage location
Relative video number
Battery level
Tag n ame
15
Page 22
Working with pictures/videos
Viewing picture/video information
1 Press the Review button.
2 Repeatedly press to turn on/off status icons, histogram, and picture/video
info.
■ Press the Review button to exit Review.
Using the menu button in review
The Menu button lets you:
■ Edit your pictures/videos
■ Control how your camera takes pictures/videos
■ Customize other camera behaviors
IMPORTANT:
Your camera offers an on-board Help system. To get the most from your
camera, see page 49.
1 Press the Review button, then the Menu button.
2 Press to highlight a tab:
■ Review to view pictures/videos
■ Edit to edit pictures/videos
■ Setup for other camera settings (page 32)
3 Press to highlight a setting, then press OK.
4 Highlight an option, then press OK.
16 www.kodak.com/go/support
Page 23
Working with pictures/videos
Cropping pictures
You can crop a picture so that only the desired portion of the picture remains.
1 Press the Review button, then to find a
picture to crop.
3 Press Telephoto (T) to zoom in, or to move the crop box. Press OK.
4 Follow the screen prompts.
The picture is cropped. (The original is saved.) Cropped pictures cannot be cropped
again on the camera.
■ Press the Menu button to exit the menu.
Cropped picture
2 Press the Menu button, then to highlight the
Edit tab. Highlight Crop, then press OK.
Adding sound tags
You can add a recorded voice or sound tag (up to 1 minute long) to a picture.
NOTE:
Only one sound tag can be added to each picture (not to videos).
Recording a sound tag
1 Press the Review button, then to find a picture.
2 Press the Menu button, then to highlight the Edit tab.
3 Press to highlight Sound Tag. Press OK.
4 Highlight Record, then press OK.
5 Follow the screen prompts.
The sound tag is applied to your picture.
■ Press the Menu button to exit the menu.
www.kodak.com/go/support
17
Page 24
Working with pictures/videos
Playing a sound tag
1 Press the Review button, then to find a sound-tagged picture.
2 Press to play the sound tag.
3 Press to adjust the volume.
4 Press OK to stop playback.
Using Kodak Perfect Touch technology
Kodak Perfect Touch technology helps ensure better, brighter pictures. Perfect Touch
technology is automatically applied to pictures taken in Smart Capture mode. (You
cannot apply Perfect Touch technology to videos, panoramic pictures, or pictures to
which Perfect Touch technology is already applied.)
1 Press the Review button.
2 Press for previous/next picture.
3 Press the Menu button, then to highlight the Edit tab. Highlight Perfect
Touch tech, then press OK.
The enhancement is previewed. Press to view other parts of the picture.
4 Press OK. Follow the screen prompts to replace the original picture or to save the
enhanced picture as a new one.
■ Press the Menu button to exit the menu.
18 www.kodak.com/go/support
Page 25
Working with pictures/videos
Editing videos
You can do incredible things with your videos!
Making a picture from a video
You can choose a single frame from a video, then make a picture suitable for a
4 x 6-inch (10 x 15 cm) print.
1 Press the Review button, then to find a
video.
2 Press the Menu button, then to highlight the
Video
Trimming a video
You can remove an unwanted start or end from a video, saving only the desired
portion.
Video
Tri mme d vide o
Edit tab. Highlight Make Picture, then press OK.
3 Follow the screen prompts.
A picture is created. (The original video is saved.)
■ Press the Menu button to exit the menu.
1 Press the Review button, then to find a video.
2 Press the Menu button, then to highlight the
Edit tab. Highlight Trim, then press OK.
3 Follow the screen prompts.
The video is trimmed. (You can save it as a new video
or replace the original.)
■ Press the Menu button to exit the menu.
www.kodak.com/go/support
19
Page 26
Working with pictures/videos
Making a video action print
From a video, you can make a 4-, 9-, or 16-up picture, suitable for a 4 x 6-inch
(10 x 15 cm) print.
1 Press the Review button, then to find a video.
2 Press the Menu button, then to highlight the
Edit tab. Highlight Action Print, then press OK.
Video
4-, 9-, or
16-up picture
Manual: Choose the first and last frames; the camera chooses 2, 7, or 14 spaced
frames.
Full Manual: Choose 4, 9, or 16 frames.
Use Bookmarks: The camera uses bookmarked frames.
A 4-, 9-, or 16-up picture is created. If you have less than 4 or 9 bookmarks, equally spaced
video frames are used.
■ Press the Menu button to exit the menu.
3 Highlight an option, then press OK.
Auto: The camera includes the first and last frames,
then 2, 7, or 14 equally spaced frames.
20 www.kodak.com/go/support
Page 27
Working with pictures/videos
Using video bookmarks
You can set bookmarks at interesting places in your video, then jump from one
bookmark to another.
Setting bookmarks
1 Press the Review button, then to find a video.
2 Press the Menu button, then to highlight the
Edit tab. Highlight Bookmark, then press OK.
3 While the video plays, press to add
bookmarks. When finished adding up to 9
bookmarks, press .
■ Press the Menu button to exit the menu.
Using bookmarks
1 Press the Review button, then to find a video.
2 Press to play the video. To jump to the first
bookmark, press and hold for 4 seconds
while the video is playing.
■ After you jump to a bookmark, press to
jump to other bookmarks.
■ To view all bookmarked video frames, press the
Zoom wide angle (W) button. To return to
normal view, press the telephoto (T) button.
www.kodak.com/go/support
21
Page 28
Working with pictures/videos
Running a slide show
Use Slide Show to display your pictures/videos on the LCD.
NOTE: If you have a Kodak EasyShare HDTV dock, see its Getting Started Guide.
1 Press the Review button.
2 Press the Menu button, then to highlight the Review tab. Highlight Slide
Show, then press OK.
3 Press to highlight Begin Show, then press OK.
Each picture/video is displayed once. To interrupt the Slide Show, press OK.
Changing the slide show display interval
You can set the display interval for each picture from 3–60 seconds.
1 On the Slide Show menu, press to highlight Display Interval, then press OK.
2 Select a display interval.
To scroll through the seconds quickly, press and hold .
3 Press OK.
The display interval setting remains until you change it.
Running a continuous slide show loop
When you turn on Loop, the slide show is continuously repeated.
1 On the Slide Show menu, press to highlight Loop, then press OK.
2 Press to highlight On, then press OK.
3 Press to highlight Begin Show, then press OK.
The slide show repeats until you press OK or until the battery is exhausted.
22 www.kodak.com/go/support
Page 29
Working with pictures/videos
Choosing a slide show transition
Choose how the slide show transitions from one picture to another.
1 On the Slide Show menu, press to highlight Transition, then press OK.
2 Press to select a transition, then press OK.
Running a multimedia slide show
Multimedia Slide Show is similar to Slide Show, but also offers music and visual
effects. First, select 2-20 pictures (see page 26). Then:
1 Press the Review button.
2 Press the Menu button, then to highlight the Review tab. Highlight
Multimedia Slide Show, then press OK.
3 Press to highlight a choice from the menu below, then press OK.
■ Begin Show
■ Music
■ Effect
■ Play Order
Each picture is displayed once. To interrupt the slide show, press OK. After the
slide show plays, you may save or modify it.
NOTE: If you have a Kodak EasyShare HDTV dock, see its Getting Started Guide.
www.kodak.com/go/support
23
Page 30
Working with pictures/videos
Displaying pictures/videos on a television
For a true HDTV experience on your television, dock your camera on the Kodak
EasyShare HDTV dock.
To connect the camera directly to a non-HDTV television, use an A/V cable (may be
sold separately). You can display pictures/videos on a television, computer monitor, or
any device equipped with a video input.
Purchase accessories www.kodak.com/go/m1093accessories
NOTE: Ensure that the Video Out setting (NTSC or PAL) is correct (see page 33). The slide show stops if you
connect or disconnect the cable while the slide show is running. (Image quality on a television
screen may not be as good as on a computer monitor or when printed.)
24 www.kodak.com/go/support
Page 31
Working with pictures/videos
Viewing pictures/videos in different ways
Viewing as thumbnails (multi-up)
1 Press the Review button.
2 Press the Wide Angle (W) button to change from single-picture view to
thumbnails.
3 Press the Telephoto (T) button to return to single-picture view.
■ To select multiple pictures/videos, see page 26.
■ Press the Review button to exit Review.
Searching pictures by date, Favorites, or other tag
If you have many pictures on your camera or card, you can sort them so that only
some are visible at a time. You can sort by the date a picture was taken or—if you’ve
tagged pictures with a Favorites tag or a tag that you created—you can sort by tags.
1 Press the Review button, then the Menu button.
2 Press to highlight Search, then press OK.
3 Press to highlight Date, Favorite, or Tag, then to select a folder.
4 Press to select a folder.
5 To see the results of your search, highlight Exit then press OK. Press Save, then
press OK.
Pictures are displayed as thumbnails. Press to view them. Press the
Telephoto (T) button to view the picture full-screen.
■ Press the Review button to exit Review.
■ For more about tags, see page 41.
■ To select multiple pictures/videos, see page 26.
www.kodak.com/go/support
25
Page 32
Working with pictures/videos
Selecting multiple pictures/videos
Use the multi-select feature when you have two or more pictures/videos to print,
transfer, delete, etc. Multi-select is used most effectively in Multi-Up mode, page 25.
1 Press the Review button, then to find a
picture/video.
2 Press OK to select pictures/videos.
A check mark appears on the picture. You can now
Selected
pictures
print, transfer, delete, etc. the selected pictures. You
can press OK a second time to remove a check mark.
Copying pictures/videos
You can copy pictures/videos from a card to internal memory or from internal memory
to a card.
Copy pictures/videos:
1 Press the Review button.
2 Press the Menu button, then to highlight the Review tab.
3 Press to highlight Copy, then press OK. Highlight a choice, then press OK.
NOTE: Pictures/videos are copied, not moved. To remove pictures/videos from the original location after
copying, delete them (see page 14). Tags that you applied for print, email, and favorites are not
copied. Protection settings are not copied. To apply protection to a picture/video, see page 14.
26 www.kodak.com/go/support
Page 33
4 Doing more with your camera
IMPORTANT:
Your camera offers an on-board Help system. To get the most from your
camera, see page 49.
Using the menu button to change settings
You can change settings to get the best results from your camera.
NOTE: Some modes offer limited settings. Some settings remain until you change them; others, until you
change modes or turn off the camera.
1 Press the Menu button.
2 Press to highlight a tab:
■ Capture for the most common picture-taking settings
■ Capture + for other picture-taking settings
■ Video for video-taking settings
■ Setup for other camera settings
3 Press to highlight a setting, then press OK.
4 Highlight an option, then press OK.
Using the capture tab
Press Menu, , ,
and OK to access settings
Exposure Compensation
Make a picture lighter or
darker. (Available only in
Program and Panorama
modes).
0.0, -0.3, -0.7, -1.0, -1.3, -1.7, -2.0, +0.3, +0.7, 1.0, 1.3,
1.7, 2.0
Capture Options
www.kodak.com/go/support 27
Page 34
Doing more with your camera
Press Menu, , ,
and OK to access settings
Picture Size (Smart
Capture mode)
Choose a picture resolution.
Picture Size (all other
modes)
Choose a picture resolution.
Long Time Exposure
Choose how long the shutter
stays open.
Color Mode
Choose color tones.
Unavailable in Video mode.
Capture Options
10.0 MP (4:3)
8.9 MP (3:2)
7.5 MP (16:9)
5.0 MP (4:3)
4.5 MP (3:2)
3.8 MP (16:9)
3.1 MP (4:3)
2.8 MP (3:2)
2.4 MP (16:9)
10.0 MP (4:3)
8.9 MP (3:2)
7.5 MP (16:9)
5.0 MP (4:3)
3.1 MP (4:3)
2.2 MP (3:2)
2.1 MP (16:9)
1.2 MP (4:3)
None
0.5, 1.0, 2.0, 4.0, or 8.0 seconds
High Color
Natural Color
Low Color
Black & White
Sepia—for a reddish-brown, antique look.
NOTE: EasyShare software also lets you change a color picture to
black-and-white or sepia.
28 www.kodak.com/go/support
Page 35
Doing more with your camera
Press Menu, , ,
and OK to access settings
AF Control
Choose an auto-focus setting.
Focus Mode
Select a large or concentrated
area of focus.
Using the capture + tab
Press Menu, , ,
and OK to access settings
White Balance
Choose your lighting
condition.
Available in Smart Capture
mode.
Capture Options
Continuous AF—because the camera is always focusing,
there is no need to press the Shutter button halfway down to
focus.
Single AF—uses TTL-AF (through-the-lens auto focus) when
the Shutter button is pressed halfway down.
Auto—for general picture-taking.
Macro—for sharpness and detail in pictures at close range.
Use available light instead of flash, if possible. The camera
automatically sets the focus distance depending on the zoom
position.
Infinity—for distant subjects; auto-focus framing marks are
unavailable.
Capture + Options
Auto—automatically corrects white balance. Ideal for general
picture taking.
Daylight—for pictures in natural lighting.
Tungsten—corrects the orange cast of household light bulbs.
Ideal for indoor pictures under tungsten or halogen lighting
without flash.
Fluorescent—corrects the green cast of fluorescent lighting.
Ideal for indoor pictures under fluorescent lighting without
flash.
Open Shade—for pictures in shade in natural lighting.
www.kodak.com/go/support
29
Page 36
Doing more with your camera
Press Menu, , ,
and OK to access settings
Face Detect Capture
Choose if faces get focus
priority.
Exposure Metering
Evaluate light levels at specific
areas of a scene.
AF Zone
Select a large or concentrated
area of focus.
ISO Speed
Control the sensitivity of the
camera sensor.
Sharpness
Control picture sharpness.
Capture + Options
On—In P mode (and in SCN modes designed for pictures of
people), the camera attempts to focus on faces.
Off
NOTE: Not available in Smart Capture mode (because face detection
is always on). To change focus from the selected face to
another face, press .
Multi-Pattern—evaluates lighting conditions throughout
the image to give an optimum picture exposure. Ideal for
general picture taking.
Center-Weight—evaluates the lighting conditions of the
subject centered in the lens. Ideal for backlit subjects.
Center-Spot—similar to Center-weight, except the metering
is concentrated on a smaller area of the subject centered in the
lens. Ideal when you need an exact exposure of a specific area
in the picture.
Multi-Zone—evaluates 5 zones to give an even picture
focus. Ideal for general picture taking.
Center-Zone—evaluates the small area centered in the lens.
Ideal when you need precise focus.
Auto
ISO 64, 100, 200, 400, 800, 1600, 3200, 6400 (ISO 6400
available for picture sizes of 3.1 MP or less.)
High
Normal
Low
30 www.kodak.com/go/support
Page 37
Using the video tab
Doing more with your camera
Press Menu, , ,
and OK to access settings
Video Size
Choose a video resolution.
AF Control
Choose an auto-focus setting.
Focus Mode
Select a large or concentrated
area of focus.
Video Blur Reduction
Improve video stability.
Video Options
1280 x 720 (HD720p) HQ—HDTV format; uses the least
compression, gives the highest video quality.
1280 x 720 (HD720p)—HDTV format; uses compression to
save space.
640 x 480 HQ—medium quality and file size.
640 x 480—medium quality and file size; uses compression
to save space.
320 x 240—lowest quality; smallest file size.
Continuous AF—camera is always focusing.
Single AF—camera focuses once, when the Shutter button is
pressed.
Auto—for general video-taking.
Macro—for sharpness and detail at close range. The camera
automatically sets the focus distance depending on the zoom
position.
Infinity—for distant subjects.
On
Off
www.kodak.com/go/support
31
Page 38
Doing more with your camera
Using the Setup menu
Use Setup to customize your camera.
Press Menu, to highlight
Setup, then to access settings
LCD Brightness
Choose LCD brightness.
LCD Dimmer
Choose inactivity time until LCD dims.
Image Storage
Choose a storage location for
pictures/videos.
Set Tag
Create tag names and assign them to
pictures/videos. See page 41.
Date Stamp
Imprint the date on pictures.
Not available on panoramic pictures.
Red Eye Reduction
Choose how you want to reduce redeye.
Image Stabilizer (Still)
Improve picture-taking stability.
Setup Options
Power Save
High Power
30 seconds
20 seconds
10 seconds
Off (no dimming)
Auto—the camera uses the card if one is in the
camera. If not, the camera uses internal memory.
Internal Memory—the camera always uses
internal memory, even if a card is installed.
Add Tag—create a tag.
Delete Tag—delete a tag.
Clear All—selected tags are cancelled.
Choose a date option, or turn off the feature.
Preflash—red eye preflash fires before the
picture is taken.
Digital Correction—red eye preflash does not
fire; the camera corrects red eye.
On
Off
32 www.kodak.com/go/support
Page 39
Doing more with your camera
Press Menu, to highlight
Setup, then to access settings
Orientation Sensor
Orient pictures/videos so that they are
displayed with the correct side up.
Camera Sounds
Choose sound effects.
Sound Volume Off
Date & Time Set date and time.
Digital Zoom
Turn digital zoom on or off.
Not available in Smart Capture mode.
Auto Power Off
Choose inactivity time until camera turns
off.
Video Out
Choose the regional setting that lets you
connect the camera to a television or other
external device.
Language Choose your language.
Reset Camera
Reset settings to their default.
On, Off
Theme—applies the same sound effect set to all
functions.
Individual—choose a sound for each function.
High
Medium
Low
On
Off
10 minutes
5 minutes
3 minutes
1 minute
NTSC—used in North America and Japan; most
common format.
PAL—used in Europe and China.
Setup Options
www.kodak.com/go/support
33
Page 40
Doing more with your camera
Press Menu, to highlight
Setup, then to access settings
Format
CAUTION:
Formatting deletes all
pictures/videos, including those
that are protected. Removing a
card during formatting may
damage the card.
About
View camera information.
Setup Options
Memory Card—deletes everything on the card;
formats the card.
Cancel—exits without making a change.
Internal Memory—deletes everything in
internal memory including email addresses, and
tag names; formats the internal memory.
34 www.kodak.com/go/support
Page 41
Doing more with your camera
Taking panoramic pictures
Use panorama to “stitch” up to 3 pictures into a panoramic scene.
NOTE: For best results, use a tripod. Only the panoramic picture is saved; individual pictures are not.
(Exposure and white balance are set with the first picture. The flash is set to Off.)
1 Press the Mode button.
2 Press to highlight SCN, then press OK.
3 Press to highlight Panorama Left-Right or Panorama Right-Left
(depending on the direction you want to pan), then press OK.
4 Take the first picture.
After a quickview, the LCD displays the liveview and an “overlay” from the first picture.
5 Compose the second picture. Make the overlay from the first picture cover the
same portion in the new picture. (You can press the Delete button to re-take a
picture.)
6 If you are taking only 2 pictures, press OK to stitch them together.
After you take 3 pictures, the pictures are automatically stitched together.
Take 2 or 3
pictures.
Get 1
panoramic picture.
NOTE: To use the self-timer 10-second or 2-second setting, see page 11.
www.kodak.com/go/support
35
Page 42
Doing more with your camera
Using the histogram to view picture brightness
Use the histogram to evaluate the distribution of light before or after you take a
picture. Optimal exposure is achieved when the peak is in the middle of the
histogram. The flash may affect a picture’s light and shadow.
To turn on the histogram in Capture mode or in Review, press until the
histogram appears.
Dark picture Balanced picture Bright picture
Using the framing grid to compose a picture
The framing grid divides the LCD into thirds—vertically and horizontally. This is
helpful if, for example, you want to balance a picture between water, earth, and sky.
Press until the grid appears.
36 www.kodak.com/go/support
Page 43
5 Transferring, printing, tagging
CAUTION:
Before connecting any cables, install the software that was
included with your camera. Failure to do so may cause the
software to load incorrectly.
Installing the software
1 Close all open software applications before starting the installation.
NOTE:
If running Windows OS and installing EasyShare software from the Kodak
Web site, do not close the WinZip application. If prompted, allow EasyShare
software to access the Internet.
2 Place the Kodak EasyShare software CD into the CD-ROM drive.
3 Load the software:
Windows OS
menu and type d:\setup.exe where d is the drive letter that contains the CD.
Mac OS X
4 Follow the on-screen instructions to install the software.
NOTE: When prompted, register your camera and software. Registering lets you sign up for information
that keeps your system up-to-date. To register later, visit
5 If prompted, restart the computer.
For software help, click the Help button in EasyShare software.
—if the install window does not appear, choose Run from the Start
—double-click the CD icon on the desktop, then click the Install icon.
www.kodak.com/go/register.
www.kodak.com/go/support 37
Page 44
Transferring, printing, tagging
Transferring pictures/videos
Using the USB cable
If you do not have an EasyShare dock, use a Kodak USB cable, model U-8.
Connect, then
turn on the
camera.
Using other options
You can also use these Kodak products to transfer your pictures/videos:
■ Kodak EasyShare camera dock, Kodak EasyShare printer dock (see page 40)
■ Kodak card readers
Purchase accessories www.kodak.com/go/m1093accessories
Learn more about connecting www.kodak.com/go/howto
38 www.kodak.com/go/support
Page 45
Transferring, printing, tagging
Printing pictures
Direct printing with an EasyShare all-in-one printer
Your camera is compatible with PictBridge technology, so you can print directly to
PictBridge enabled printers. You need a camera with fully charged battery, a
PictBridge enabled printer, and a USB cable.
Connecting the camera to an EasyShare all-in-one printer
1 Turn off the camera and printer.
2 Connect the appropriate USB cable from the camera to the printer.
Printing from an EasyShare all-in-one printer
1 Turn on the printer. Turn on the camera.
The PictBridge logo is displayed, followed by the current picture and menu. (If no
pictures are found, a message is displayed.) If the menu turns off, press any button to
redisplay it.
2 Highlight a printing option, then press OK.
Current Picture—Press to choose a picture. Choose the number of copies.
Tagged Pictures—If your printer is capable, print pictures that you tagged for
printing and choose a print size.
Index Print—Print thumbnails of all pictures. (This option requires one or more
sheets of paper.) If the printer is capable, choose a print size.
All Pictures—Print all pictures in internal memory, on a card, or in Favorites.
Choose the number of copies.
Image Storage—Access Auto or Internal Memory.
NOTE: During direct printing, pictures are not permanently transferred or saved to the printer. To transfer
pictures to your computer, see page 37.
Purchase cables, accessories www.kodak.com/go/m1093accessories
View dock compatibility www.kodak.com/go/dockcompatibility
www.kodak.com/go/support
39
Page 46
Transferring, printing, tagging
Disconnecting the camera from an EasyShare all-in-one printer
1 Turn off the camera and printer.
2 Disconnect the USB cable from the camera and the printer.
Using a printer that is not PictBridge enabled
After you transfer pictures from the camera to your computer, you can print them from
EasyShare software. For details, see Help in EasyShare software.
Ordering prints online
Kodak EasyShare
services offered in EasyShare software. You can easily:
■ Upload your pictures.
■ Edit, enhance, and add borders to your pictures.
■ Store pictures, and share them with family and friends.
■ Have prints, photo greeting cards, frames, and albums delivered to your door.
Gallery (www.kodakgallery.com) is one of the many online print
Printing from an optional SD or SDHC card
■ Automatically print tagged pictures when you insert your card into a printer with
an SD/SDHC card slot. See your printer user’s guide for details.
■ Make prints at an SD/SDHC card-capable Kodak picture maker/picture kiosk.
(Contact a location prior to visiting. Visit www.kodak.com/go/picturemaker.)
■ Take the card to your local photo retailer for professional printing.
Printing with an EasyShare print dock
Dock your camera to the Kodak EasyShare printer dock and print directly—with or
without a computer. To see which EasyShare camera and printer docks are compatible
with your camera, visit www.kodak.com/go/dockcompatibility.
40 www.kodak.com/go/support
Page 47
Transferring, printing, tagging
Tagging your pictures
You can tag your pictures so they are easy to:
■ Print
■ Email
■ Organize with a favorite tag
■ Organize with a tag name that you create
Tagging pictures for printing
1 Press the Share button. Press to locate a picture.
2 Press to highlight Print, then press OK.
3 Press to select the number of copies.
Optional: You can apply a print quantity to other pictures. Press for
previous/next. Keep the print quantity as is, or press to change it. Repeat
this step until the desired print quantity is applied to the pictures.
4 Press OK.
The Print icon appears in the status area.
■ Press the Share button to exit the menu.
Printing tagged pictures
When you transfer the tagged pictures to your computer, the EasyShare software print
screen opens. For details on printing, see Help in EasyShare software.
www.kodak.com/go/support
41
Page 48
Transferring, printing, tagging
Tagging pictures/videos for emailing
First, create a new email address: highlight Add Email, press OK, then use the
on-camera keyboard.
1 Press the Share button. Press to locate a picture, then press OK.
2 Press to highlight Email, then press OK.
3 Press to locate an email address, then press OK.
To tag other pictures/videos with the same address, scroll through them. When the
picture you want is displayed, press OK.
To send the pictures/videos to more than one address, repeat step 3.
■ To remove a selection, highlight a checked address and press OK. To remove
all email selections, highlight Clear All, then press OK.
■ To exit the menu, highlight Exit, then press OK.
The Email icon appears in the status area.
When you transfer the tagged pictures/videos to your computer, EasyShare software
prompts you to send the pictures/videos. For details, see Help in EasyShare software.
42 www.kodak.com/go/support
Page 49
Transferring, printing, tagging
Assigning the favorite tag to pictures/videos
To make your favorite pictures/videos easier to locate, you can assign the favorite tag.
1 Press the Review button, then locate a picture/video.
2 Highlight Favorite, then press OK.
To view favorites on your camera, see page 25.
The favorite tag appears with the picture. When you transfer the tagged pictures/videos
to your computer, EasyShare software opens and categorizes your pictures/videos with
the appropriate tag.
Assigning other tags to pictures/videos
First, create a new tag name: highlight Add Tag, press OK, then use the on-camera
keyboard.
1 Press the Review button, then locate a picture/video.
2 Press the Menu button.
3 Highlight Tag, then press OK.
4 Highlight a tag name, then press OK.
To assign the tag to other pictures, press to locate a picture, then press OK.
The tag name appears with the picture. A plus (+) means the picture has more than one
tag assigned.
To remove a selection, highlight a tag name and press OK. To remove all tag
selections, highlight Clear All, then press OK.
When you transfer the tagged pictures/videos to your computer, EasyShare software
opens and categorizes your pictures/videos with the appropriate tag.
www.kodak.com/go/support
43
Page 50
Transferring, printing, tagging
Assigning a tag to pictures/videos you take next
Use the Set Tag feature to assign a tag name to the next pictures/videos you take.
First, create a new tag name: highlight Add Tag, press OK, then use the on-camera
keyboard.
1 Press the Menu button.
2 Highlight the Setup tab.
3 Highlight Set Tag, then press OK.
4 Highlight a tag name, then press OK.
5 Press the Menu button to exit the menu.
The selected tag is displayed on the LCD.
When you transfer the tagged pictures/videos to your computer, EasyShare software
opens and categorizes your pictures/videos with the appropriate tag.
44 www.kodak.com/go/support
Page 51
6 Troubleshooting
IMPORTANT:
Your camera offers an on-board Help system. To get the most from your
camera, see page 49.
Camera problems
Status Solution
Camera does not
turn on
Camera does not turn
off
Camera buttons and
controls do not
function
In Review, a blue or
black screen is
displayed instead of
a picture
Pictures remaining
number does not
decrease after taking a
Flash does not fire ■ Check the flash setting, and change as needed (see page 7).
■ Make sure the battery is charged and installed correctly (see
page 1).
■ Turn the camera off, then on again.
■ Tra ns fer
■ Take another picture.
■ Continue taking pictures. The camera is operating normally.
(The camera estimates the number of pictures remaining after each
picture is taken, based on picture size and content.)
all
pictures to the computer (see page 37).
NOTE: The flash does not fire in all modes.
Memory card is almost
or entirely full
The battery does not
charge using USB
charging
■ Transfer the pictures to the computer (see page 37).
■ Delete pictures from the card or insert a new card.
■ See page 2 or visit www.kodak.com/go/USBcharging.
■ Insert a new battery (see page 1).
www.kodak.com/go/support 45
Page 52
Troubleshooting
Status Solution
Battery life is short ■ Make sure the correct battery type is installed (see page 56).
■ Wipe the contacts with a clean, dry cloth before inserting a
battery in the camera.
■ Insert a new or charged battery (see page 1).
You cannot take a
■ Turn the camera off, then on again.
■ Depress the Shutter button all the way (see page 5).
■ Insert a new or charged battery (see page 1).
■ Memory is full. Transfer pictures to the computer (see page 37),
delete pictures (see page 14), or insert another card.
Error message appears
on LCD
■ Turn the camera off, then on again.
■ Remove the memory card.
■ Turn off the camera. Remove the battery. Wipe the contacts with
a clean, dry cloth.
■ Insert a new or charged battery.
■ If the problem still exists, get help (see page 49).
Memory card not
recognized or camera
freezes with card
Cannot find the
■ Card may be corrupted. Format the card in the camera (see
page 34).
■ Use another memory card. Only SD or SDHC cards are supported.
■ To view pictures on a card or in internal memory, see page 13.
desired picture/video
Computer/connectivity problems
Status Solution
Pictures do not
■ See Help in EasyShare software.
transfer to computer
Slide Show does not
run on an external
video device
■ Adjust the camera Video Out setting to NTSC or PAL (see
page 33).
■ Make sure the external device settings are correct. (See the
devi ce’s user ’s guide) .
46 www.kodak.com/go/support
Page 53
Troubleshooting
Status Solution
Computer does not
communicate with
the camera
■ Make sure the battery is charged and installed correctly (see
page 1).
■ Turn on the camera.
■ Make sure the USB cable model U-8 is connected to the camera
and the computer (see page 38). (If using an EasyShare dock,
check all cable connections. Make sure the camera is seated on
the dock.)
■ Make sure EasyShare software is installed (see page 37).
Picture quality problems
Status Solution
Picture is not clear ■ To automatically set exposure and focus, press the Shutter button
Picture is too dark ■ Reposition the camera for more available light.
halfway. When the framing marks turn green, press the Shutter
button completely down to take the picture.
■ Clean the lens (see page 54).
■ Make sure the camera is not in Macro mode if you are more than
27.6 in. (70 cm) from your subject.
■ Place the camera on a flat, steady surface or use a tripod (especially
in high-zoom settings or in low light).
■ Use Fill flash (see page 7) or change your position so light is not
behind the subject.
■ Move so that the distance between you and the subject is within the
effective flash range. (See camera specifications starting on
page 52.)
■ To automatically set exposure and focus, press the Shutter button
halfway. When the framing marks turn green, press the Shutter
button completely down to take the picture.
www.kodak.com/go/support
47
Page 54
Troubleshooting
Status Solution
Picture is too light ■ Reposition the camera to reduce the amount of available light.
■ Turn the flash off (see page 7).
■ Move so that the distance between you and the subject is within the
effective flash range. (See camera specifications starting on
page 52.)
■ To automatically set exposure and focus, press the Shutter button
halfway. When the framing marks turn green, press the Shutter
button completely down to take the picture.
■ In Program and Panorama modes, adjust the Exposure
Compensation (see page 27).
Direct printing (PictBridge enabled printer) problems
Status Solution
Cannot find the
desired picture
The Direct printing
menu interface turns
off
Cannot print pictures ■ Make sure there is a connection between the camera and the
Camera or printer
display an error
message
■ Use the Direct printing menu to change the image storage location.
■ Press any camera button to redisplay the menu.
printer (see page 39).
■ Make sure the printer and the camera have power.
■ Follow the prompts to resolve the issue.
48 www.kodak.com/go/support
Page 55
7 Getting help
Getting help from your camera
You want the most from your camera. You want to understand:
■ What it can do for you
■ And how to take the best possible pictures and videos
Great news!
Your camera offers a built-in Help system. It describes every setting for every menu
choice. If you learn nothing else about your camera, learn how to use on-camera Help.
Because the more you know your camera, the more confident you become!
Turning on camera Help
Press the Menu button, then
1
highlight a menu choice.
T
2
Press the Telephoto (T) button.
Menu
Scroll through a Help topic
OK
Turn off Help
www.kodak.com/go/support 49
Page 56
Getting help
Getting help on the Web
Camera
Email, write, or phone Kodak www.kodak.com/go/contact
Get support for your product (FAQs, troubleshooting
information, arrange for repairs, etc.)
Purchase camera accessories (camera docks, printer
docks, lenses, cards, etc.)
Download the latest camera firmware and software www.kodak.com/go/m1093downloads
See online demonstrations of your camera www.kodak.com/go/howto
Software
Get information on EasyShare software www.kodak.com/go/easysharesw
Get help with the Windows operating system and
working with digital pictures
Other
Get support for cameras, software, accessories, more www.kodak.com/go/support
Get information on Kodak EasyShare printer docks www.kodak.com/go/printerdocks
Get information on Kodak inkjet products www.kodak.com/go/inkjet
Optimize your printer for truer, more vibrant colors www.kodak.com/go/onetouch
Register your camera www.kodak.com/go/register
www.kodak.com/go/m1093support
www.kodak.com/go/m1093accessories
(or see Help in EasyShare software)
www.kodak.com/go/pcbasics
50 www.kodak.com/go/support
Page 57
Getting help
Getting help on the telephone
NOTE: If you have questions concerning this product, you may speak with Kodak customer support.
Australia 1800 267 588 Netherlands 020 346 9372
Austria 0179 567 357 New Zealand 0800 880 120
Belgium 02 713 14 45 Norway 23 16 21 33
Brazil 0800 891 42 13 Philippines 1 800 1 888 9600
Canada 1 800 465 6325 Poland 00800 4411625
China 800 820 6027 Portugal 021 415 4125
Czech Republic 00 800 56325000 Russia 8 495 929 9166
Denmark 3 848 71 30 Singapore 800 6363 036
Finland 0800 1 17056 Slovakia 00 800 56325000
France 01 55 1740 77 Spain 91 749 76 53
Germany 069 5007 0035 Sweden 08 587 704 21
Greece 00800 44140775 Switzerland 044 838 53 51
Hong Kong 800 901 514 Taiwan 0800 096 868
Hungary 06 80 456 325 Thailand 001 800 631 0017
India 91 80 41374555
(toll free 000800 440 1227)
Ireland 01 407 3054 United Kingdom 0870 243 0270
Italy 02 696 33452 United States 1 800 235 6325
Japan 03 5540 9002 International Toll Line +44 131 458 6714
Korea 080 708 5600 International Toll Fax +44 131 458 6962
Turkey 00800 448827073
www.kodak.com/go/support
51
Page 58
8 Appendix
Camera specifications
CCD—1/2.3 in.
Effective pixels—3672 x 2748
Image stabilization—CCD shift
Taking lens—3X optical zoom; f/3.1 (@ wide)–f/5.7; 35 mm equivalent: 35–105
mm
Lens protection—Built-in
Digital zoom—5X continuous
Shutter speed—8–1/1448 seconds
LCD—3 in. (7.6 cm) LCD; 230K pixels; 30 fps
Focus system—TTL-AF (through-the-lens auto focus); Auto: Multi-Zone,
Center-Zone. Working range:
23.6 in. (60 cm)–infinity @ wide, normal
23.6 in. (60 cm)–infinity @ telephoto, normal
2.6–27.6 in. (7–70 cm) @ wide, Macro mode
15.7–27.6 in. (40–70 cm) @ telephoto, Macro mode
32.8 ft (10 m)–infinity @ wide, Landscape mode
32.8 ft (10 m)–infinity @ telephoto, Landscape mode
ISO speed—Auto (in Smart Capture): 64–1600; Manual: 64, 100, 200, 400, 800,
1600, 3200, 6400 (ISO 6400 available for picture sizes of 3.1 MP or less.)
Image storage—Optional SD/SDHC Card (The SD logo is a trademark of the
SD Card Association.)
Internal storage capacity—32 MB internal memory (21 MB available for image
storage. 1 MB equals one million bytes.)
52 www.kodak.com/go/support
Page 59
Appendix
Electronic Flash—Auto flash; Auto, Fill, Red Eye, Off; Guide No. 6.6; working
range: 0.6–3.0 m (2–9.8 ft) @ wide, ISO 400; 0.6–2.0 m (2–6.6 ft) @ telephoto, ISO
400
Image file format—
Still: EXIF 2.21 (JPEG compression); file organization DCF
Video: QuickTime (video: CODEC MPEG-4; audio: G.711)
Color modes—High Color, Natural Color, Low Color, Black & White, Sepia
Sharpness modes—High, Normal, Low
White Balance—Auto, Daylight, Tungsten, Fluorescent, Open Shade
Capture modes—Smart Capture, Program, Scene, Video
Picture size—
Smart Capture mode
10.0 MP (4:3): 3648 x 2736 pixels
8.9 MP (3:2): 3648 x 2432 pixels
7.5 MP (16:9): 3648 x 2064 pixels
5.0 MP (4:3): 2592 x 1944 pixels
4.5 MP (3:2): 2592 x 1728 pixels
3.8 MP (16:9): 2592 x 1456 pixels
3.1 MP (4:3): 2048 x 1536 pixels
2.8 MP (3:2): 2048 x 1360 pixels
2.4 MP (16:9): 2048 x 1152 pixels
Video capture—
1280 x 720 (HD720p) HQ @ 30 fps
1280 x 720 (HD720p) @ 30 fps
640 x 480 HQ @ 30 fps
640 x 480 @ 30 fps
320 x 240 @ 30 fps
Exposure metering—TTL-AE; Multi-
www.kodak.com/go/support
All other modes
10 MP (4:3): 3648 x 2736 pixels
8.9 MP (3:2): 3648 x 2432 pixels
7.5 MP (16:9): 3648 x 2064 pixels
5.0 MP (4:3): 2592 x 1944 pixels
3.1 MP (4:3): 2048 x 1536 pixels
2.2 MP (3:2): 1800 x 1200 pixels
2.1 MP (16:9): 1920 x 1080 pixels
1.2 MP (4:3): 1280 x 960 pixels
Pattern, Center-Weight, Center-Spot
53
Page 60
Appendix
Exposure compensation—+/-2.0 EV with 1/3 EV step
Burst mode—Maximum 3 pictures @ 1.5 fps; Auto Exposure, Auto Focus, Auto
White Balance executed for first shot only
Communication with computer—USB 2.0 high speed (PIMA 15740 protocol);
via USB cable model U-8; EasyShare camera dock, printer dock, or HDTV dock
Video output—NTSC or PAL
PictBridge support—Yes
Power—Kodak Li-Ion rechargeable digital camera battery KLIC-7004; 5V AC
adapter; EasyShare camera dock, printer dock, or HDTV dock
Size—3.7 x 2.3 x 0.8 in. (95.2 x 58.5 x 21.4 mm) @ power off
Weight—4.4 oz (126 g) without card or battery
Operating temperature—32–104
° F (0–40° C)
Tripod mount—1/4 inch
Care and maintenance
■ If you suspect water has gotten inside the camera, remove the battery and card.
Allow all components to air-dry for at least 24 hours before using the camera.
■ Blow gently on the lens or LCD to remove dust and dirt. Wipe gently with a soft,
lint-free cloth or an untreated lens-cleaning tissue. Do not use cleaning solutions
unless designed specifically for camera lenses. Do not allow chemicals, such as
suntan lotion, to contact painted surfaces.
■ Service agreements may be available in your country. Contact a dealer of Kodak
products for more information.
■ For digital camera disposal or recycling information, contact your local authorities.
In the US, visit the Electronics Industry Alliance Web site at www.eiae.org or
www.kodak.com/go/m1093support
54 www.kodak.com/go/support
Page 61
Appendix
Upgrading your software and firmware
Download the latest versions of the software included on the Kodak EasyShare
software CD and the camera firmware (the software that runs on the camera). Visit
www.kodak.com/go/m1093downloads.
Storage capacities
The LCD displays the approximate number of pictures (or minutes/seconds of video)
remaining. For average SD card capacities, visit www.kodak.com/go/SDcapacities.
Actual storage capacity varies depending on subject composition, card size, and other
factors. You may be able to store more or fewer pictures and videos. Favorites take up
additional space in internal memory.
Important safety instructions
CAUTION:
Do not disassemble this product; there are no user-serviceable parts
inside. Refer servicing to qualified service personnel. Kodak AC adapters
and battery chargers are intended for indoor use only. The use of controls,
adjustments, or procedures other than those specified herein may result
in exposure to shock and/or electrical or mechanical hazards. If the LCD
breaks, do not touch the glass or liquid. Contact Kodak customer support.
■ The use of an accessory that is not recommended by Kodak may cause fire, electric
shock, or injury. For approved accessories, visit www.kodak/go/accessories.
■ Use only a USB-certified computer equipped with a current-limiting motherboard.
Contact your computer manufacturer if you have questions.
■ If using this product in an airplane, observe all instructions of the airline.
■ When removing the battery, allow it to cool; it may be hot.
■ Follow all warnings and instructions supplied by the battery manufacturer.
■ Use only batteries approved for this product to avoid risk of explosion.
www.kodak.com/go/support
55
Page 62
Appendix
■ Keep batteries out of the reach of children.
■ Do not allow batteries to touch metal objects, including coins. Otherwise, a battery
may short circuit, discharge energy, become hot, or leak.
■ Do not disassemble, install backward, or expose batteries to liquid, moisture, fire,
or extreme temperature.
■ Remove the battery when the product is stored for an extended period of time. In
the unlikely event that battery fluid leaks inside the product, contact Kodak
customer support.
■ In the unlikely event that battery fluid leaks onto your skin, wash immediately with
water and contact your local health provider. For additional health-related
information, contact your local Kodak customer support.
■ Dispose of batteries according to local and national regulations. Visit
www.kodak.com/go/kes.
■ Do not charge non-rechargeable batteries.
For more information on batteries, visit www.kodak.com/go/batterytypes.
Battery replacement, battery life
Kodak Li-Ion rechargeable digital camera battery KLIC-7004: 220 pictures per charge.
Battery life per CIPA testing method. (Approx. number of pictures in Smart Capture
mode, using 128 MB SD card.) Actual life may vary based on usage.
Extending battery life
■ Use power-saving features (see Using the Setup menu, page 32).
■ Dirt on the battery contacts can affect battery life. Wipe the contacts with a clean,
dry cloth before loading the battery in the camera.
■ Battery performance is reduced at temperatures below 41° F (5° C). When using
your camera in cold weather, carry spare batteries and keep them warm. Do not
discard cold batteries that do not work; when they return to room temperature,
they may be usable.
56 www.kodak.com/go/support
Page 63
Appendix
Limited warranty
Kodak warrants Kodak consumer electronic products and accessories (“Products”),
excluding batteries, to be free from malfunctions and defects in both materials and
workmanship for one year from the date of purchase. Retain the original dated sales
receipt. Proof of the date of purchase will be required with any request for warranty
repair.
Limited warranty coverage
Warranty service is only available from within the country where the Products were
originally purchased. You may be required to ship Products, at your expense, to the
authorized service facility for the country where the Products were purchased. Kodak
will repair or replace Products if they fail to function properly during the warranty
period, subject to any conditions and/or limitations stated herein. Warranty service
will include all labor as well as any necessary adjustments and/or replacement parts. If
Kodak is unable to repair or replace a Product, Kodak will, at its option, refund the
purchase price paid for the Product provided the Product has been returned to Kodak
along with proof of the purchase price paid. Repair, replacement, or refund of the
purchase price are the sole remedies under the warranty. If replacement parts are
used in making repairs, those parts may be remanufactured, or may contain
remanufactured materials. If it is necessary to replace the entire Product, it may be
replaced with a remanufactured Product. Remanufactured Products, parts and
materials are warranted for the remaining warranty term of the original Product, or 90
days after the date of repair or replacement, whichever is longer.
Limitations
This warranty does not cover circumstances beyond Kodak's control. This warranty
does not apply when failure is due to shipping damage, accident, alteration,
modification, unauthorized service, misuse, abuse, use with incompatible accessories
or attachments (such as third party ink or ink tanks), failure to follow Kodak's
operation, maintenance or repacking instructions, failure to use items supplied by
Kodak (such as adapters and cables), or claims made after the duration of this
warranty.
www.kodak.com/go/support
57
Page 64
Appendix
Kodak makes no other express or implied warranty for this product, and disclaims the
implied warranties of merchantability and fitness for a particular purpose. In the event
that the exclusion of any implied warranty is ineffective under the law, the duration of
the implied warranty will be one year from the purchase date or such longer period as
required by law. The option of repair, replacement, or refund is Kodak's only
obligation. Kodak will not be responsible for any special, consequential or incidental
damages resulting from the sale, purchase, or use of this product regardless of the
cause. Liability for any special, consequential or incidental damages (including but not
limited to loss of revenue or profit, downtime costs, loss of the use of the equipment,
cost of substitute equipment, facilities or services, or claims of your customers for such
damages resulting from the purchase use or failure of the Product), regardless of
cause or for breach of any written or implied warranty is expressly disclaimed.
Your rights
Some states or jurisdictions do not allow exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
Some states or jurisdictions do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you. This warranty gives you specific
rights, and you may have other rights which vary from state to state or by jurisdiction.
Outside the United States and Canada
In countries other than the United States and Canada, the terms and conditions of
this warranty may be different. Unless a specific Kodak warranty is communicated to
the purchaser in writing by a Kodak company, no warranty or liability exists beyond
any minimum requirements imposed by law, even though defect, damage, or loss may
be by negligence or other act.
58 www.kodak.com/go/support
Page 65
Appendix
Regulatory compliance
FCC compliance and advisory
Kodak EasyShare M1093 IS digital camera
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed or used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures: 1) reorient or relocate the
receiving antenna; 2) increase the separation between the equipment and the
receiver; 3) connect the equipment to an outlet on a circuit different from that to
which the receiver is connected; 4) consult the dealer or an experienced radio/TV
technician for additional suggestions. Any changes or modifications not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment. Where shielded interface cables have been provided with the
product or specified additional components or accessories elsewhere defined to be
used with the installation of the product, they must be used in order to ensure
compliance with FCC regulation.
Waste Electrical and Electronic Equipment labeling
In Europe: For human/environmental protection, it is your responsibility to dispose of this
equipment at a collection facility established for this purpose (separate from municipal
waste). For more information, contact your retailer, collection facility, or appropriate
local authorities; or visit www.kodak.com/go/recycle. (Product weight: 126 g.)
www.kodak.com/go/support
59
Page 66
Appendix
Australian C-Tick
N137
VCCI Class B ITE
Korean Class B ITE
Russian GOST-R
Eastman Kodak Company
Rochester, NY 14650
AIO-40
MPEG-4
Use of this product in any manner that complies with the MPEG-4 visual standard is
prohibited, except for use by a consumer engaging in personal and non-commercial
activities.
60 www.kodak.com/go/support
Page 67
Appendix
China RoHS
Canadian DOC statement
DOC Class B Compliance—This Class B digital apparatus complies with Canadian
ICES-003.
Observation des normes-Classe B—Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
FCC and Industry Canada
This device complies with Industry Canada RSS-210 and FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
www.kodak.com/go/support
61
Page 68
Index 1
A
A/V out, 24
about picture, video, 16
about this camera, 34
accessories, 38
battery, 56
buying, 50
SD/SDHC card, 4
AF assist light, i
auto, 8
enhancement, 18
focus control, 29, 30, 31
focus framing marks, 6
power off, 33
auto focus (AF)
zone, 30
B
backlight, 10
battery
charging, 2, 3
expected life, 56
loading, 1
types, 56
beach, 9
blur reduction, 9
bookmarks, 21
burst, using, 11
button
delete, 5
macro/landscape, ii
mode, i
OK, ii
power, i
review, ii
self-timer/burst, ii
Share, ii
shutter, i
telephoto/zoom, 6
C
cable
audio/video, 24
USB, 38
camera sounds, 33
Canadian compliance, 61
care and maintenance, 54
charging the battery, 2, 3
children, 10
clock, setting, 4
color mode, 28
compatibility, docks, 40
computer
connecting camera, 37
transfer to, 37
connector, USB / A/V, 24, 38
copy pictures
card to memory, 26
memory to card, 26
to computer via USB cable, 37
cropping pictures, 17
customer support, 51
customize camera, 32
62 www.kodak.com/go/support
Page 69
Index
D
date setting, 4
date stamp, 32
deleting
during quickview, 5
from internal memory, 14
from SD/SDHC card, 14
protecting pictures, videos, 14
digital zoom, 6
setting, 33
displaying slide show, 22
disposal, recycling, 54
dock
compatibility, 40
downloading pictures, 37
E
EasyShare software, 37
edit videos, 19
emailing pictures, videos, 42
expected battery life, 56
exposure
long time, 28, 31
metering, 30
external video device
viewing pictures, videos, 24
F
favorites tagging, 43
FCC compliance, 59
filter pictures, videos, 25
fireworks, 9
firmware, upgrading, 55
flash, using, 7
flower,9,10
focus framing marks, 6
focus mode, 29
format, 34
framing grid, 36
framing marks, 5
G
grid, framing, 36
guidelines, battery, 56
H
help
camera help, 49
Web links, 49
high ISO, 10
histogram, 36
I
icons, modes, 8
Image stabilizer, 31, 32
image storage, 32
information about pictures, videos, 16
installing
battery, 1
SD/SDHC card, 4
software, 37
ISO speed, 30
K
Kodak EasyShare software
installing, 37
upgrading, 55
Kodak Perfect Touch technology, 18
Kodak Web sites, 49
www.kodak.com/go/support 63
Page 70
Index
L
language, 33
LCD, ii
brightness, 32
dimmer, 32
reviewing pictures, 13
reviewing videos, 13
lens, i
cleaning lens, 54
light, self-timer/AF assist, i
loading
battery, 1
SD/SDHC card, 4
software, 37
long time exposure, 28, 31
M
Mac OS, installing software, 37
macro/landscape button, ii
magnify a picture, 13
maintenance, camera, 54
make picture from video, 19
manner/museum, 9
memory
inserting card, 4
menu settings, 27
microphone, i
mode button, i
modes, 8
auto, 8
backlight, 10
beach, 9
blur reduction, 9
children, 10
fireworks, 9
flower,9,10
high ISO, 10
manner/museum, 9
night landscape, 9
night portrait, 9
scene (SCN), 9
self-portrait, 10
snow, 9
sport, 9
text, 9
modes, capture
smart capture, 8
multimedia slide show, 23
multiple selections, 26
multi-up, 25
N
night landscape, 9
night portrait, 9
O
OK button, ii
online prints, ordering, 40
optical zoom, 6
orientation sensor, 33
P
panoramic pictures, 35
Perfect Touch technology, 18
PictBridge enabled printer, 39
picture size, 27, 28
pictures
copying, 26
cropping, 17
64 www.kodak.com/go/support
Page 71
Index
emailing tagged, 42
Kodak Perfect Touch, 18
printing, 40
printing tagged, 41
protecting, 14
review icons, 15
reviewing, 13
tagging, 41
taking, modes, 8
transfer via USB cable, 37
pictures/video
deleting, 14
playing a video, 13
power
camera, 2
power button, i
pre-tagging, 44
printing
from a card, 40
from computer, 40
optimizing printer, 49
order online, 40
PictBridge, 39
tagged pictures, 40
protecting pictures, videos, 14
Q
quickview, using, 5
R
recycling, disposal, 54
regulatory information, 59
repair, 50
review button, ii
reviewing pictures/video
as you take them, 5
deleting, 14
LCD, 13
protecting, 14
slide show, 22
running slide show, 22
S
safety, 55
scene modes (SCN), 9
SD/SDHC card
inserting, 4
printing from, 40
search pictures, videos, 25
select multiple pictures/videos, 26
self-portrait, 10
self-timer, 11
light, i
self-timer/burst button, ii
service and support telephone
numbers, 51
setting
AF zone, 30
auto power off, 33
auto-focus,29,30,31
camera sounds, 33
color mode, 28
date and time, 4
date stamp, 32
digital zoom, 33
exposure metering, 30
image storage, 32
ISO, 30
www.kodak.com/go/support 65
Page 72
Index
language, 33
LCD brightness, 32
LCD dimmer, 32
long time exposure, 28, 31
orientation sensor, 33
picture size, 27, 28
picture-taking mode, 8
self-timer, 11
sharpness, 30
sound volume, 33
video out, 33
video size, 31
white balance, 29
setting up the camera, 1
setup menu, 32
Share button, ii
sharpness, 30
shutter
button, i
problems, 46
self-timer delay, 11
slide show
continuous loop, 22, 23
running, 22
smart capture, 8
snow, 9
software
installing, 37
upgrading, 55
sound volume, 33
sounds, 33
specifications, camera, 52
sport, 9
strap, 1
support, technical, 51
T
tagging
creating tags, 43
favorites, 43
for email, 42
for print, 41
pre-tagging, 44
taking pictures, videos, 5
telephone support, 51
television, slide show, 24
text, 9
time, setting, 4
timer, shutter delay, 11
tips
battery guidelines, 56
care & maintenance, 54
transfer, via USB cable, 37
trash can, deleting, 5
trimming a video, 19
troubleshooting, 45
turning camera on and off, 2
U
undelete, undo, 14
upgrading software, firmware, 55
URLs, Kodak Web sites, 49
USB
transferring pictures, 37
USB, A/V out, ii
V
VCCI compliance, 60
video
66 www.kodak.com/go/support
Page 73
action print, 20
copying, 26
edit, 19
emailing tagged, 42
out, 33
playback, 13
protecting, 14
review icons, 15
size, 31
transfer to computer, 37
viewing, 13
video bookmarks, 21
viewing
by date, tag, 25
by multi-up, 25
picture, after taking, 5, 13
picture/video information, 16
volume, 33
W
warranty, 57
white balance, 29
Windows OS, installing software, 37
Index
Z
zoom
digital, 6
optical, 6
www.kodak.com/go/support 67
Loading...
