KODAK LUMA 150

PORTABLE WIRELESS PROJECTOR

User Manual

3.9"H | 3.9"W | 0.87"D (9.9 cm | 9.9 cm | 2.2 cm)

Please read all directions before using the product and retain this guide for reference.

CONTENTS

1

INTRODUCTION

3

2

SPECIFICATIONS

3

3

BOX CONTENTS

3

4

SAFETY PRECAUTIONS

3-4

5

PRODUCT OVERVIEW

4

6

CHARGING THE PROJECTOR

5

7

USING THE PROJECTOR TO CHARGE DEVICES

5

8

USING THE AUDIO OUT JACK

5

9

POWERING THE PROJECTOR ON/OFF

6

10

CONTROLLING PHOTO PLAYBACK

6

11

CONTROLLING VIDEO PLAYBACK

6

12

SCREEN MIRRORING

7-8

13

WIRELESS SETTINGS AND SOFTWARE UPDATES

8-9

14

ADJUSTING FOCUS

9

15

ADJUSTING VOLUME

10

16

CONNECT YOUR DEVICE

10

17

VIEWING DISTANCE AND SCREEN SIZE

11

18

USING THE PROJECTOR

11

19

CUSTOMER SERVICE

11

20

WARRANTY

12-13

2

1. INTRODUCTION

Thank you for purchasing the KODAK LUMA 150 PORTABLE WIRELESS PROJECTOR . This User Guide is intended to provide you with guidelines to ensure that operation of this product is safe and does not pose risk to the user. Any use that does not conform to the guidelines described in this User Guide may void the limited warranty.

Please read all directions before using the product and retain this guide for reference. This product is intended for household use only.

This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions. See warranty for details.

2. SPECIFICATIONS

Rated Input: 5V, 2.4A

Rated Output: 5V, 1.0A

ANSI Lumens: 50

Native Resolution: 854 x 480

3. BOX CONTENTS

KODAK LUMA 150

HDMI®-to-HDMI® Cable

Power Cable/Power Adapter

User Guide

4.SAFETY PRECAUTIONS

Do not attempt to disassemble this device for any reason.

Do not store the projector in areas where it will be exposed to high temperatures, humidity, or direct sunlight. Exposure to any or all of these could permanently damage the projector.

Never handle the projector with damp or wet hands. This could damage the projector or create the risk of electric shock.

Keep the projector out of the reach of children.

Never point the projector at someone else’s face or look directly into the projector light. The light is bright and could cause damage.

Do not use products such as alcohol, gasoline, diluent, or any other organic solvent when cleaning or attempting to clean this product.

Do not use this device in an environment where it will be exposed to heavy dust or humidity/moisture.

Never drop or shake the projector, as this could cause it to malfunction or permanently damage the inside parts.

Do not use the projector while bathing or in a shower.

Do not place or store the projector where it can fall or be pulled into a tub or sink.

3

Kodak Luma 150 User Manual

Do not place, drop, or submerge the projector in water or any other liquid.

If the projector somehow falls into water despite you taking all of the above precautions, please do not reach into the water to retrieve it. Unplug it immediately and then retrieve it.

Take care that objects do not fall and liquids are not spilled onto the projector.

5.PRODUCT OVERVIEW

1.

Lens

1.

Power

2.

Speaker

2.

Focus Wheel

3.

Back

3.

Air Inlet

4.

Confirm / Play / Pause

4.

Tripod Dock

5.

Right / FF / Volume +

5.

Rating Label

6.

Left / REW / Volume -

6.

Non-slip Mat

7.

Volume Switch

7.

MicroSD Slot

8.

Power Indicator

8.

Speaker

9.Audio Output (3.5mm)

10.USB Input / Power Out

11.HDMI Input

12.Micro USB Input (5V/2.4A)

13.Reset

4

6. CHARGING THE PROJECTOR

Before using the projector, connect it to the charger, plug the USB end of the charging cable into a wall charger or similar power source and allow it to fully charge. This process should take about three hours.

Always use the original charger that was provided to ensure proper charging, and make sure the power rating of the adapter for the charging cable is ≤ 2.4A.

The four indicator lights will show the approximate battery capacity, with each light representing approximately 25% battery life. One indicator light lit means the battery is at less than 25% and should be charged soon. Two lights means the battery percentage is between 25% and 49%, and so on. Four lights lit means that battery is fully charged.

7. USING THE PROJECTOR TO CHARGE DEVICES

When the projector is powered on, you can connect the charging cable of your device to the USB port of the projector, and it will operate as a mobile power bank to charge your electronic devices. The power output is 5V/1A.

8. USING THE AUDIO OUT JACK

While the projector does include built-in speakers for regular use, you can also connect either headphones or a portable speaker to the 3.5mm AUDIO OUT jack as shown in the below image.

5
