Kodak EasyShare M1073 IS
digital camera
Extended user guide
www.kodak.com
For interactive tutorials: www.kodak.com/go/howto
For help with your camera: www.kodak.com/go/m1073support
Eastman Kodak Company
Rochester, NY 14650
© Eastman Kodak Company, 2008
All screen images are simulated.
Kodak, EasyShare, and Perfect Touch are trademarks of Eastman Kodak Company.
P/N 4F8184_en
Front view
Product features
1
2
3
4
5
6
7
8
1 Shutter button
2
Flash button
3
On/Off button 7 Speaker
4Flash 8Lens
www.kodak.com/go/support
5 Self-timer/video light
6 Microphone
i
Product features
Back view
16
optional memory card
(sold separately)
15
14
1
2
3
4
13
5
6
7
8
9
10
11
12
1LCD
2 Review button
3 Ready/Battery charging light
4 Menu button 12 Share button
5
Delete button
6 Zoom button (Wide/Telephoto) 14 SD/SDHC memory card slot
7 Mode dial 15 Dock connector
8 DC-In (5V) , for optional AC adapter 16 Tripod socket
ii www.kodak.com/go/support
9OK/
10 Strap post
11 USB port
13 Battery compartment
Table of contents 1
1 Setting up your camera .........................................................................1
Attaching the strap ....................................................................................... 1
Loading the battery....................................................................................... 1
Charging the battery ..................................................................................... 2
Turning on the camera ..................................................................................3
Setting the language, date/time..................................................................... 3
Storing pictures on an SD/SDHC card ............................................................. 4
2 Taking pictures/videos ...........................................................................5
Taking a picture ............................................................................................ 5
Taking a video .............................................................................................. 6
Using optical zoom .......................................................................................7
Using the flash.............................................................................................. 8
Using different picture-taking modes ............................................................. 9
Using camera Help ...................................................................................... 11
Taking panoramic pictures........................................................................... 12
Understanding the picture-taking icons........................................................13
3 Working with pictures/videos ..............................................................14
Reviewing pictures/videos ........................................................................... 14
Using sound tags ........................................................................................ 16
Deleting pictures/videos .............................................................................. 17
Using the menu button in Review ................................................................ 18
Using Kodak Perfect Touch technology ........................................................18
Cropping pictures........................................................................................ 19
Editing videos ............................................................................................. 19
Running a slide show ..................................................................................21
Viewing pictures/videos in different ways..................................................... 23
Selecting multiple pictures/videos ................................................................ 25
Copying pictures/videos............................................................................... 25
Understanding the review icons...................................................................26
www.kodak.com/go/support iii
Table of contents
4 Doing more with your camera .............................................................27
Using the menu button to change settings................................................... 27
Customizing your camera ............................................................................ 31
Using the self-timer..................................................................................... 34
Using burst .................................................................................................35
Using exposure compensation to adjust picture brightness ........................... 35
Using the framing grid to compose a picture................................................ 35
5 Transferring, printing, tagging ............................................................36
Installing the software................................................................................. 36
Transferring pictures with the USB cable ...................................................... 37
Printing pictures.......................................................................................... 38
Dock compatibility for your camera.............................................................. 40
Tagging your pictures..................................................................................41
6 Troubleshooting ..................................................................................45
Camera problems........................................................................................ 45
Camera/computer communications.............................................................. 47
LCD screen messages .................................................................................. 48
7 Getting help ........................................................................................51
8 Appendix .............................................................................................53
Camera specifications ................................................................................. 53
Care and maintenance ................................................................................ 55
Upgrading your software and firmware........................................................ 55
Storage capacities ....................................................................................... 56
Important safety instructions ....................................................................... 56
Battery life .................................................................................................. 57
Limited Warranty ........................................................................................ 58
Regulatory compliance ................................................................................ 60
iv www.kodak.com/go/support
1 Setting up your camera
Attaching the strap
Loading the battery
To extend battery life, see page 57.
Kodak Li-Ion rechargeable
digital camera battery
KLIC-7001
www.kodak.com/go/support 1
Setting up your camera
Charging the battery
Kodak USB AC adapter
USB AC adapter
Battery
Charging
light
(included)
Kodak EasyShare cameras
or printer docks
(may be sold separately)
For dock compatibility, see
page 40.
Kodak 5V AC adapter,
Kodak Li-Ion universal
battery chargers
(sold separately)
USB cable
Battery Charging light
First, turn
OFF the
camera.
Charge until
the Battery
Charging
light turns
off (up to 3
hours).
e
g
r
a
2
.
h
7
C
/
r
6
.
e
3
Pow
L
R
A
E
S
G
R
R
E
A
V
I
H
N
C
U
Y
n
R
o
E
I
T
i
L
BAT
Your computer
Learn more about USB charging www.kodak.com/go/USBcharging
Purchase battery charging accessories www.kodak.com/go/accessories
2 www.kodak.com/go/support
Connect the USB cable to the computer’s USB port, not a Hub.
Make sure the computer is turned on and not in sleep mode.
Turning on the camera
Setting the language, date/time
Setting up your camera
Language:
1
2
1
OK
Date/Time:
At the prompt, press OK.
2
OK
to change.
to accept.
to change.
for previous/next field.
to accept.
NOTE: To change the date/time and language in the future, use the Menu button (page 27).
www.kodak.com/go/support
3
Setting up your camera
Storing pictures on an SD/SDHC card
Your camera has internal memory. You can purchase an SD or SDHC memory card to
conveniently store more pictures and videos. We recommend Kodak SD or SDHC
cards. (Write-once SD cards are not supported.)
1
Turn off the camera.
2
Insert or remove the
optional card.
3
Turn on the camera.
CAUTION:
A card can only be inserted one way; forcing it may cause
damage. If you insert or remove a card while the camera is
accessing it, the card, pictures, or camera may be damaged.
See page 56 for storage capacities.
Purchase accessories www.kodak.com/go/m1073accessories
4 www.kodak.com/go/support
2 Taking pictures/videos
Taking a picture
1
On/Off button
3
Press the Shutter button
halfway to focus and set
exposure.
When the framing marks
turn green, press the
Shutter button completely
down.
2
Framing marks
Reviewing the picture just taken
After you take a picture or video, the LCD displays a quickview for approximately
10 seconds. (To exit the quickview sooner, press the Shutter button halfway.)
The picture is saved
unless you press the
Delete button.
To review pictures/videos anytime, see page 14.
www.kodak.com/go/support 5
Delete button
Press
to play a video.
to adjust the volume
during playback
Taking pictures/videos
Using the framing marks
Framing marks indicate the camera focus area. The camera attempts to focus on
foreground subjects, even if the subjects are not centered in the scene.
Framing marks
1 Press the Shutter button halfway.
When the framing marks turn green, focus is
accomplished.
2 If the camera is not focusing on the desired subject
(or if the framing marks disappear), release the
Shutter button and recompose the scene.
3 Press the Shutter button completely down to
take the picture.
NOTE: Framing marks do not appear in all modes. When you use AF Zone and set Center Zone, the framing
marks are fixed at Center Wide. Multiple framing marks may appear when faces are detected (see
page 29).
Taking a video
1
3
On/Off button
Press the Shutter button
completely down and
release.
To stop recording, press
and release the Shutter
button again.
2
6 www.kodak.com/go/support
Using optical zoom
Use optical zoom to get up to 3X closer to your subject.
1 Use the LCD to frame your subject.
2 Press Telephoto (T) to zoom in. Press Wide Angle
(W) to zoom out.
The zoom indicator shows zoom status.
3 Take the picture or video.
NOTE: For focus distances, see page 53.
■ Always use the auto focus framing marks,
page 6.
Optical
zoom
range
Digital
zoom
range
■ If you are not using zoom (1X, wide angle), you
can be as close as 4 in. (10 cm) to your subject.
Taking pictures/videos
■ As you zoom, you need to move further from
WTD
your subject.
Using the digital zoom
Use digital zoom in any Still mode or during video recording to get up to 5X
magnification beyond optical zoom for a combined zoom of 15X.
1 Press Telephoto (T) to the maximum optical zoom limit. Release the button, then
press it again.
2 Take the picture.
NOTE: You may notice decreased image quality when using digital zoom. The slider on the zoom indicator
turns red when the picture quality reaches the limit for an acceptable 4 x 6-in. (10 x 15 cm) print.
www.kodak.com/go/support
7
Taking pictures/videos
Using the flash
Use the flash when you take pictures at night, indoors, or outdoors in heavy shadows.
Press the
through flash modes (see Flash modes below).
The current flash mode appears in the LCD screen.
button repeatedly to scroll
Flash-to-subject distance
Zoom position Flash distance
Wide angle 0.6–3.0 m (2–9.8 ft) @ ISO 250
Telephoto 0.6–2.0 m (2–6.6 ft) @ ISO 400
Flash modes Flash fires
Auto
When the lighting conditions require it.
Flash
Off Never.
Fill Every time you take a picture, regardless of the lighting conditions. Use when
the subject is in shadow or is “backlit” (when the light is behind the subject).
In low light, hold the camera steady or use a tripod.
Redeye
If Red -eye Pre -fl ash i s tu rne d of f:
■ The flash fires once and the
camera automatically
corrects red-eye in the
If Red-eye Pre-flash is turned on:
■ The flash fires once so the eyes
become accustomed to the flash, then
fires again when the picture is taken.
picture.
To turn the Red-eye Pre-flash feature on/off, see page 30.
8 www.kodak.com/go/support
Taking pictures/videos
Using different picture-taking modes
Mode dial
Choose the mode that best suits your
subjects and surroundings.
Use this mode For
Auto General picture taking—offers an excellent balance of image quality
and ease of use.
SCN
ISO
Landscape Far-away scenes. The camera uses infinity auto-focus. Auto-focus
framing marks are not available in Landscape.
Close-up Close range. Use available light instead of flash if possible.
Scene Point-and-shoot simplicity when taking pictures under special
conditions. (See page 10.)
High ISO People in low-light scenes indoors using a higher ISO.
Video Capturing video with sound. (See page 6.)
www.kodak.com/go/support
9
Taking pictures/videos
Scene modes
Choose a Scene mode—for great pictures in practically any situation!
1 Turn the Mode dial to Scene .
2 Press to display Scene mode descriptions.
If the mode description turns off before you finish reading it, press OK.
3 Press OK to choose a Scene mode.
Use this
For
SCN mode
Portrait Full-frame portraits of people.
Panorama
Left-Right
Panorama
Right-Left
Sport Subjects in motion.
Night
Portrait
Night
Landscape
Snow Bright snow scenes.
Beach Bright beach scenes.
Text/
Stitching up to 3 captured images from left to right into one image.
Stitching up to 3 captured images from right to left into one image.
Reducing red eye of people in night scenes or low-light conditions. Place the
camera on a flat, steady surface or use a tripod.
Distant scenery at night. Flash does not fire. Place the camera on a flat, steady
surface or use a tripod.
Documents. Focus is set to Auto Focus (see page 30).
Document
Fireworks Bright, colorful light displays. Flash does not fire. Place the camera on a flat,
steady surface or use a tripod.
Flower Close-ups of flowers or other small subjects in bright light. Focus is set to Auto
Focus (see page 30).
Manner/
Museum
Quiet occasions, like a wedding or lecture. Flash and sound are disabled.
10 www.kodak.com/go/support
Taking pictures/videos
Use this
For
SCN mode
SelfPortrait
Children Action pictures of children in bright light.
Backlight Subjects that are in shadow or “backlit” (when light is behind the subject).
Candle light Capturing subjects in low light.
Sunset Capturing the deep hues seen at sunset.
Close-ups of yourself. Assures proper focus and minimizes red eye.
Using camera Help
To better understand each menu option, use camera Help. Select an option you want
to learn more about, then press the Zoom telephoto (T) button.
T Tur n o n He lp
www.kodak.com/go/support
Scroll up/down
OK Turn off Help
11
Taking pictures/videos
Taking panoramic pictures
Use panorama to “stitch” up to 3 pictures into a panoramic scene.
NOTE: For best results, use a tripod. Individual pictures are not saved, even if panorama capture is
cancelled before stitching occurs. (Picture size is set to 5.0 MP for each picture. Exposure
Compensation, White Balance, AF Zone, and Color Mode are set with the first picture. The flash is
set to Off.)
1 Turn the Mode dial to SCN.
2 Press on the 4-way button to highlight Panorama Left-Right or Panorama
Right-Left (depending on the direction you want to pan), then press the OK
button.
3 Take the first picture.
After a quickview, the LCD displays the liveview and an “overlay” from the first picture.
4 Compose the second picture. Make the overlay from the first picture cover the
same portion in the new picture. (You can press the Delete button to re-take a
picture.)
5 If you are taking only 2 pictures, press the OK button to stitch them together.
After you take 3 pictures, the pictures are automatically stitched together. The LCD
displays a quickview for approximately 10 seconds.
Take 2 or 3
pictures.
Get 1 panoramic
picture.
1
2
3
12 www.kodak.com/go/support
Taking pictures/videos
Understanding the picture-taking icons
Picture size
Self-timer/Burst
Flash
Camera
mode
Tagged
Framing
marks
Framing
grid
In capture mode—shutter pressed halfway
Date stamp
Pictures/time remaining
Storage location
Zoom:
Focus zone
Exposure metering
White balance
Long time exposure
Blur reduction
ISO speed
Battery level
Exposure compensation
Wide, Telephoto,
Digital
Camera
mode
www.kodak.com/go/support
Auto Exposure/
Auto Focus warning
Battery level
Exposure compensation
13
3 Working with pictures/videos
Reviewing pictures/videos
Press the Review button to view and work with your pictures/videos. Press Review
again to exit. (To display pictures/videos on a television, see page 24.)
1 Press the Review button.
2 Press to view previous/next picture/video.
To save battery power, use an optional Kodak
OK
Review
NOTE: Pictures taken at 3:2 and 16:9 picture sizes have a black bar at the top and bottom. A video’s
duration is displayed at the top of the LCD.
EasyShare dock or Kodak 5-volt AC adapter. (See
page 2.)
Magnifying pictures
1 Press the Review button.
2 Press W/T to magnify 2X–8X.
3 Press to view other parts of the
picture.
14 www.kodak.com/go/support
4 Press OK to return to 1X.
NOTE: If you press W (wide zoom) while at 1X, the view changes
from single-picture to multi-up thumbnail pictures. (See
page 23.)
Playing a video
Review
Playback speed
2X
4X
1X
OK
Working with pictures/videos
1 Press the Review button.
2 Press to find previous/next video.
3 Press to play. Press OK to pause/unpause.
4 Press during pause to view previous/next
video frame.
5 Press during playback to adjust the
volume.
4X2X
Reverse
Forward
7 Press during playback to reverse at 2X, 4X.
Viewing picture/video information
1 Press the Review button.
2 Repeatedly press to turn on/off status icons
and picture/video info.
6 Press during playback to play at 2X, 4X.
www.kodak.com/go/support
15
Working with pictures/videos
Using sound tags
You can add a unique sound/message (up to 1 minute long) to your picture.
NOTE:
Only one tag can be added to each picture (not to videos).
Recording a sound tag
Playing a sound tag
1 Press the Review button, then to find a
picture.
2 Press the Menu button, then to
highlight Sound Tag. Press the OK button.
3 Choose Record, then press OK.
4 Follow the screen prompts.
The sound tag is applied to your picture.
■ Press the Menu button to exit the menu.
1 Press the Review button, then to find a
tagged picture.
OK
2 Press to play the sound tag.
3 Press to adjust the volume.
Review
4 Press OK to stop playback.
16 www.kodak.com/go/support
Working with pictures/videos
Deleting pictures/videos
1 Press the Review button.
2 Press for previous/next picture/video.
3 Press the Delete button.
4 Follow the screen prompts.
Using the undo delete feature
If you accidentally delete a picture, use Undo Delete to retrieve it. This feature is
available only immediately after you delete a picture in Review mode and when the
Undo Delete option appears.
1 Press to highlight Undo Delete.
2 Press OK.
The deleted picture (overlaid with the Delete menu) appears.
3 Select Exit to exit the Delete menu.
Protecting pictures/videos from deletion
1 Press the Review button.
2 Press for previous/next picture/video.
3 Press the Menu button.
4 Press to highlight Protect, then press OK.
The Protect icon appears with the protected picture/video.
■ Press the Menu button to exit the menu.
CAUTION:
Formatting a card deletes all (including protected) pictures/videos.
Formatting internal memory deletes all pictures/videos, email addresses,
album names, and favorites.
www.kodak.com/go/support
17
Working with pictures/videos
Using the menu button in Review
1 Press the Review button, then the Menu button.
2 Press to find:
■ Review to view pictures/videos
■ Edit to edit pictures/videos
■ Setup for other camera settings (page 31)
3 Press to highlight a setting, then press the OK button.
4 Choose an option, then press the OK button.
Using Kodak Perfect Touch technology
Kodak Perfect Touch technology helps ensure better, brighter pictures.
1 Press the Review button, then for previous/next picture.
2 Press the Menu button, then press to find Edit.
3 Press to highlight Perfect Touch tech., then press OK.
The enhancement is previewed in a split screen. Press to view other parts of the
picture.
4 Press OK. Follow the screen prompts to replace the original picture or to save the
enhanced picture as a new one.
NOTE: You cannot enhance previously enhanced pictures.
■ Press the Menu button to exit the menu.
18 www.kodak.com/go/support
Working with pictures/videos
Cropping pictures
You can crop a picture so that only the desired portion of the picture remains.
1 Press the Review button, then to find a
picture.
2 Press the Menu button. Press to find Edit.
Cropped picture
3 Press to highlight Crop, then press OK.
4 Press Telephoto (T) to zoom in, or to move the crop box. Press OK.
5 Follow the screen prompts.
The picture is cropped. The original is saved. (Cropped pictures cannot be cropped
again.)
■ Press the Menu button to exit the menu.
Editing videos
Making a picture from a video
You can choose a single frame from a video, then make a picture suitable for printing.
1 Press the Review button, then to find a video.
Video
www.kodak.com/go/support
2 Press the Menu button. Press to find Edit.
3 Press to highlight Make Picture, then
press OK.
4 Press OK to play.
5 Press to select a video frame.
6 Follow the screen prompts to save the picture.
A picture is created. (The original video is saved.)
■ Press the Menu button to exit the menu.
19
Working with pictures/videos
Trimming a video
You can delete an unwanted portion from the beginning or end of a video.
1 Press the Review button, then to find a
video.
2 Press the Menu button. Press to find Edit.
3 Press to highlight Trim, then press OK.
Video
Trimmed video
4 Follow the screen prompts. (Use fast-forward and
fast-reverse, if needed.)
The video is trimmed. (You can save it as a new video
or replace the original.)
■ Press the Menu button to exit the menu.
Making a video action print
From a video, you can make a 4-, 9-, or 16-up picture, suitable for a 4 x 6-inch
(10 x 15 cm) print.
1 Press the Review button, then to find a
video.
2 Press the Menu button. Press to find Edit.
Video
4-, 9-, or
16-up picture
3 Press to highlight Video Action Print, then
press OK.
4 Choose an option, then press OK.
Auto options: The camera includes the first and last frames, then 2, 7, or 14
equally spaced frames.
Manual options: You choose the first and last frames; the camera chooses 2, 7,
or 14 equally spaced frames.
■ Press the Menu button to exit the menu.
20 www.kodak.com/go/support
Working with pictures/videos
Running a slide show
Use Slide Show to display your pictures/videos on the camera or on a television (see
page 24). During a slide show, you can adjust the volume on a sound tag you
recorded (see page 16).
Starting the slide show
1 Press the Review button, then the Menu button.
2 Press to highlight Slide Show, then press the OK button.
3 Press to highlight Begin Show, then press the OK button.
The slide show begins. Each picture/video is displayed once.
To interrupt the Slide Show, press the OK button.
Changing the slide show display interval
The default interval setting displays each picture for 5 seconds. You can set the display
interval from 3–60 seconds.
1 On the Slide Show menu, press to highlight Interval, then press the OK
button.
2 Select a display interval.
To scroll through the seconds quickly, press and hold .
3 Press the OK button.
The interval setting remains until you change it.
www.kodak.com/go/support
21
Working with pictures/videos
Running a continuous slide show loop
When you turn on Loop, the slide show is continuously repeated.
1 On the Slide Show menu, press to highlight Loop, then press the OK
button.
2 Press to highlight On, then press the OK button.
3 Press to highlight Begin Show, then press the OK button.
The slide show repeats until you press the OK button or until battery power is
exhausted. The Loop feature remains until you change it.
Running a multimedia slide show
Multimedia Slide Show is similar to Slide Show, but also offers music and visual
effects. First, select 2-20 pictures (see page 25). Then:
1 Press the Review button.
2 Press the Menu button, then to highlight Multimedia Slide Show. Press the
OK button.
3 Press to highlight a choice from the menu below, then press the OK
button.
■ Begin Show
■ Music
■ Effect
■ Play Order
Each picture/video is displayed once. To interrupt the slide show, press the OK
button. After the slide show plays, you may save or modify it.
22 www.kodak.com/go/support
Working with pictures/videos
Viewing pictures/videos in different ways
Viewing as thumbnails (multi-up)
1 Press the Review button.
2 Press the Zoom Wide Angle (W) button to change
from single-picture view to multi-up thumbnails.
3 Press Telephoto (T) to return to single-picture view.
■ To select multiple pictures/videos, see page 25.
■ Press the Review button to exit Review.
Searching pictures by date, Favorites, or other tag
If you have many pictures on your camera or card, you can sort them so that only
some are visible at a time. You can sort by the date a picture was taken or—if you’ve
tagged pictures with a Favorites tag or a tag that you created—you can sort by tag.
1 Press the Review button, then the Menu button.
2 Press to highlight Search, then press the OK button.
3 Press to highlight Date, Favorite, or Tag, then to select a folder.
4 Press to select a folder. Choose another tab, highlight Exit and press the OK
button.
5 To see the results of your search, highlight Exit and Save, then press the OK
button.
Pictures are displayed in multi-up view. Press to view them. Press the
Telephoto (T) button to view the picture full-screen. Press the Wide Angle (W) button to
return to multi-up view.
■ Press the Review button to exit Review.
■ For more about tags, see page 41.
■ To select multiple pictures/videos, see page 25.
www.kodak.com/go/support
23
Working with pictures/videos
Viewing on a television using an A/V cable
You can display pictures/videos/slide shows on a television, computer monitor, or any
device equipped with a video input. To connect the camera to a television, use an A/V
(audio/video) cable (may be sold separately), then see page 14 or page 21.
NOTE: Ensure that the Video Out setting (NTSC or PAL) is correct (see page 32). The slide show stops if you
connect/disconnect a cable while the slide show is running. (Image quality on a television screen
may not be as good as on a computer monitor or when printed.)
CAUTION:
Turn off the camera
before
connecting/disconnecting the A/V cable.
Failure to do so may cause damage to the camera, pictures, or
memory card.
1
Turn off the camera.
Connect the A/V cable.
2
Turn on the camera.
3
View pictures/videos/slide shows on a television.
4
Purchase accessories www.kodak.com/go/m1073accessories
24 www.kodak.com/go/support
Working with pictures/videos
Selecting multiple pictures/videos
Use the multi-select feature when you have two or more pictures/videos to print,
delete, etc. (Multi-select is used most effectively in Multi-Up mode, page 23.)
1 Press the Review button, then to find a
picture/video.
2 Press the OK button to select pictures/videos.
A check mark appears on the picture. You can now
Selected
pictures
print, transfer, or delete the selected pictures. You can
press OK a second time to remove a check mark.
Copying pictures/videos
You can copy pictures/videos from a card to internal memory or from internal memory
to a card.
NOTE: Before you copy, make sure that a card is inserted in the camera.
Copy pictures/videos:
1 Press the Review button, then the Menu button.
2 Press to highlight Copy, then press OK.
3 Press to highlight an option.
4 Press OK.
NOTE: Pictures/videos are copied, not moved. To remove pictures/videos from the original location after
copying, delete them (see page 17).
Tags that you applied for print, email, and favorites are not copied. Protection settings are not
copied. To apply protection to a picture/video, see page 17.
www.kodak.com/go/support
25
Working with pictures/videos
Understanding the review icons
Pictures
Favorite tag
Email tag
Kodak Perfect Touch
tech.
Review mode
Tagged picture
Scroll arrows
Videos
Protect
Print tag/number of prints
Picture number
Image storage location
Battery level
Video length
Video number
Video number
Review mode
Scroll arrows
Image storage location
Play time
Volume control indicator
Battery level
26 www.kodak.com/go/support
4 Doing more with your camera
Using the menu button to change settings
You can change settings to get the best results from your camera.
NOTE: Some settings remain until you change them; others, until you change modes or turn off the camera.
Some modes offer limited settings.
1 Press the Menu button.
2 Press to choose a tab:
■ Capture for the most common picture-taking settings
■ Capture plus for other picture-taking settings
■ Setup for other camera settings
3 Press to highlight a setting, then press the OK button.
4 Choose an option, then press the OK button.
NOTE: For Review and Review plus options, see page 18.
www.kodak.com/go/support 27
Doing more with your camera
Using the capture tab
Press Menu, , ,
and OK to access settings
Picture Size
Choose a picture resolution.
For recommended print sizes,
visit:
www.kodak.com/go/printsizes
Long Time Exposure
Choose how long the shutter
stays open.
Options
10.2 MP (4:3)—Highest resolution; largest file size.
9.0 MP (3:2)—for printing on EasyShare printer docks and
photo printers.
7.6 MP (16:9)—HDTV format in high resolution.
5.0 MP (4:3)—medium file size.
3.1 MP (4:3)—medium file size.
2.2 MP (3:2)—for printing on EasyShare printer docks and
photo printers (at a lower resolution than 7.2 MP).
2.1 MP (16:9)—HDTV format.
1.2 MP (4:3)—Email, Internet, or to conserve space.
None, 0.5, 1.0, 2.0, 4.0 seconds
Color Mode
Choose color tones.
Unavailable in Video mode.
Date Stamp
Imprint the date on pictures.
Unavailable for panoramic
pictures.
High Color
Natural Color
Low Color
Black & White
Sepia—pictures have a reddish-brown, antique look.
NOTE: EasyShare software also lets you change a color picture to
black-and-white or sepia.
Unavailable in Video mode.
On
Off
28 www.kodak.com/go/support
Using the capture plus tab
Doing more with your camera
Press Menu, , ,
and OK to access settings
White Balance
Choose your lighting
condition.
Face Detection Capture
Choose if faces get focus
priority.
Options
Auto—automatically corrects white balance. Ideal for general
picture taking.
Daylight—for pictures in natural lighting.
Tungsten—corrects the orange cast of household light bulbs.
Ideal for indoor pictures under tungsten or halogen lighting
without flash.
Fluorescent—corrects the green cast of fluorescent lighting.
Ideal for indoor pictures under fluorescent lighting without
flash.
Open Shade—for pictures in shade in natural lighting.
On—In Auto mode (and in SCN modes designed for pictures
of people), the camera attempts to focus on faces.
Off
Exposure Metering
Evaluate light levels at specific
areas of a scene.
Multi-Pattern—evaluates lighting conditions throughout
the image to give an optimum picture exposure. Ideal for
general picture taking.
Center-Weight—evaluates the lighting conditions of the
subject centered in the lens. Ideal for backlit subjects.
Spot—similar to Center-weighted, except the metering is
concentrated on a smaller area of the subject centered on the
LCD. If used with Selectable AF zones, the exposure spot
follows the focus zone. Ideal when you need an exact exposure
of a specific area in the picture.
www.kodak.com/go/support
29
Doing more with your camera
Press Menu, , ,
and OK to access settings
AF Zone
Select a large or concentrated
area of focus.
ISO Speed
Control the camera’s
sensitivity to light.
Options
Multi-zone—evaluates 5 zones to give an even picture focus.
Ideal for general picture taking.
Center-zone—evaluates the small area centered on the LCD.
Ideal when precise focus of a specific area in the picture is
needed.
NOTE: For the best pictures, the camera is set to Multi-zone when in
Landscape mode.
Choose a lower ISO setting in brightly lit scenes; use a higher
ISO for low-light scenes. Choose Auto (default), 80, 100, 200,
400, 800, 1600.
NOTE: ISO returns to Auto when the camera is set to Portrait or SCN
mode.
Unavailable in Video mode.
Sharpness
Control picture sharpness.
Red-eye Pre-flash
Choose whether a pre-flash
fires when the flash is in Red
Eye mode.
Maintain Settings
Choose which settings are
saved, even after the camera is
turned off.
Available only in Auto mode.
High
Normal
Low
On—red eye flash fires before the picture is taken.
Off—red eye flash does not fire.
Exit
Flash
White Balance
ISO Speed
Color Mode
Sharpness
Exposure Metering
AF Zone
30 www.kodak.com/go/support
Doing more with your camera
Press Menu, , ,
and OK to access settings
Video Size
Available only in Video mode.
640 x 480
320 x 240
Options
Customizing your camera
Use Setup to customize your camera settings.
1 In any mode, press the Menu button.
2 Press to highlight Setup, then press OK.
3 Press to highlight a setting, then press OK.
4 Choose an option, then press OK.
5 Press the Menu button to exit.
NOTE: Press the T (Telephoto Zoom) button for information about camera settings and options. These
settings remain until you change them.
Press Menu, to highlight Setup,
Options
then to access settings
LCD Brightness Power Save
High Power
Image Storage
Choose a storage location for
pictures/videos.
Set Tag
Create tag names and assign them to
pictures/videos. See page 41.
Auto—the camera uses the card if one is in the
camera. If not, the camera uses internal
memory.
Internal Memory—the camera always uses
internal memory, even if a card is installed.
Exit
Add Tag—create a tag.
Delete tag—delete a tag.
Clear All—selected tag settings are cancelled.
www.kodak.com/go/support
31
Doing more with your camera
Press Menu, to highlight Setup,
then to access settings
Image Stabilizer
Improves stability, reducing the effects of
camera shake.
Continuous
Single
Off
Available only in Still mode.
Orientation Sensor
Orient pictures so that they are displayed
On
Off
with the correct side up.
Camera Sounds
Choose sound effects.
Themes—applies the same sound effect set to
all functions.
Individual—choose a sound effect for each
function.
Sound Volume Off
High
Options
Medium
Low
Date & Time See page 3.
Auto Power Off
Choose inactivity time until camera turns off.
10 minutes
5 minutes
3 minutes
1 minute
Video Out
Choose the regional setting that lets you
NTSC—used in North America and Japan.
PAL—used in Europe and China.
connect the camera to a television or other
external device.
Language See page 3.
32 www.kodak.com/go/support
Doing more with your camera
Press Menu, to highlight Setup,
then to access settings
Format
CAUTION:
Formatting deletes all
pictures/videos, including
those that are protected.
Removing a card during
formatting may damage
the card.
About
View camera information.
Options
Memory Card—deletes everything on the
card; formats the card.
Cancel—exits this setting.
Internal Memory—deletes everything in
internal memory including email addresses,
album names, and favorites; formats the
internal memory.
www.kodak.com/go/support
33
Doing more with your camera
Using the self-timer
1 Choose the desired self-timer mode, then compose the scene.
2 Press the Shutter button halfway, then completely down.
The camera takes the picture/pictures after the delay.
In this mode A picture is taken after...
A 10-second delay (so you have time to get into the scene).
10
A 2-second delay (for a steady, auto-shutter release on a tripod).
2
A 10-second delay. A second picture is taken 8 seconds later.
2x
Press
appears in the LCD status area.
NOTE: In Panoramic modes (page 12), only the 2- and 10-second self-timer options are available.
Use the same procedure to take a video, but:
■ Turn the Mode dial to Video .
■ Press the Shutter button completely down.
NOTE: Only the 2- and 10-second options are available in video mode. The video stops when no storage
space remains.
until the desired self-timer icon
34 www.kodak.com/go/support
Doing more with your camera
Using burst
Use burst to take up to 4 pictures in rapid succession.
1 In most Still modes, press the button repeatedly
until appears on the LCD.
2 Press the Shutter button halfway to focus and set
exposure.
3 Press the Shutter button completely down and
hold it to take pictures.
Press
appears in the LCD status area.
NOTE: During quickview, you can delete all pictures in the burst series. To delete selectively, do so in
until the Burst icon
The camera stops taking pictures when you release the
Shutter button, when the pictures are taken, or when
there is no more storage space.
Review (see page 17). Burst is not available when shutter speeds are longer than 0.5 seconds.
Using exposure compensation to adjust picture
brightness
Before you take a picture, you can adjust exposure compensation to make pictures
darker or lighter. (Available only in some modes.)
■ Press to decrease exposure compensation.
■ Press to increase exposure compensation.
The exposure compensation level is shown on the LCD and the image gets darker or lighter.
Using the framing grid to compose a picture
The framing grid divides the LCD into thirds—vertically and horizontally. This is
helpful if, for example, you want to balance a picture between water, earth, and sky.
www.kodak.com/go/support
To turn on/off the framing grid, press button
repeatedly.
35
5 Transferring, printing, tagging
Installing the software
CAUTION:
Install EasyShare software
computer. Failure to do so may cause the software to load
incorrectly.
1 Close all software applications that are open on your computer (including
anti-virus software).
2 Place the EasyShare software CD into the CD-ROM drive.
3 Load the software:
Windows OS—if the install window does not appear, choose Run from the Start
menu and type d:\setup.exe where d is the drive letter that contains the CD.
Mac OS X—double-click the CD icon on the desktop, then click the Install icon.
NOTE: You may need to download some Mac OS software versions. Visit
www.kodak.com/go/easysharesw
4 Follow the on-screen instructions to install the software.
before
.
connecting the camera to the
NOTE: When prompted, take few minutes to electronically register your camera and software. To register
later, visit
5 If prompted, restart the computer. If you turned off anti-virus software, turn it back
on. See the anti-virus software manual for details.
For information on the software applications included on the EasyShare software CD,
click the Help button in EasyShare software.
www.kodak.com/go/support 36
www.kodak.com/go/register
.
Transferring, printing, tagging
Transferring pictures with the USB cable
1
Turn off the camera.
2
Connect the USB cable (U-8).
Turn on the camera.
3
Kodak EasyShare software opens on your computer
and prompts you through the transfer process.
Using other options
You can also use these Kodak products to transfer your pictures/videos:
■ Kodak EasyShare camera dock, Kodak EasyShare printer dock (see page 40)
■ Kodak card readers
Purchase accessories www.kodak.com/go/m1073accessories
Learn more about connecting www.kodak.com/go/howto
www.kodak.com/go/support
37
Transferring, printing, tagging
Printing pictures
Printing with a Kodak EasyShare printer or dock
Kodak EasyShare all-in-one printer—Connect your camera to a Kodak
EasyShare all-in-one printer and print directly—with or without a computer.
Kodak EasyShare printer dock—Dock your camera to the Kodak EasyShare
printer dock and print directly—with or without a computer.
Direct printing with an EasyShare all-in-one printer
Your camera is compatible with PictBridge technology, so you can print directly to
PictBridge enabled printers. You need: a camera with fully charged battery, a
PictBridge enabled printer, and a USB cable.
Connecting the camera to an EasyShare all-in-one printer
1 Turn off the camera and printer.
2 Connect the appropriate USB cable from the camera to the printer. See your printer
user guide for details.
Purchase cables and other
accessories
Dock compatibility www.kodak.com/go/dockcompatibility
www.kodak.com/go/m1073accessories
38 www.kodak.com/go/support
Transferring, printing, tagging
Printing from an EasyShare all-in-one printer
1 Turn on the printer. Turn on the camera.
The PictBridge logo is displayed, followed by the current picture and menu. (If no
pictures are found, a message is displayed.) If the menu interface turns off, press any
button to redisplay it.
2 Highlight a printing option, then press OK.
Current Picture—Press to choose a picture. Choose the number of copies.
Tagged Pictures—If your printer is capable, print pictures that you tagged for
printing and choose a print size.
Index Print—Print thumbnails of all pictures. (This option requires one or more
sheets of paper.) If the printer is capable, choose a print size.
All Pictures—Print all pictures in internal memory, on a card, or in Favorites.
Choose the number of copies.
Image Storage—Access Internal/Card or Favorites.
NOTE: During direct printing, pictures are not permanently transferred or saved to the printer. To transfer
pictures to your computer, see page 37. In Favorites mode, the current favorite picture is displayed.
Disconnecting the camera from an EasyShare all-in-one printer
1 Turn off the camera and printer.
2 Disconnect the USB cable from the camera and the printer.
Using a printer that is not PictBridge enabled
For details on printing pictures from your computer, click the Help button in EasyShare
software.
www.kodak.com/go/support
39
Transferring, printing, tagging
Ordering prints online
Kodak
Gallery (www.kodakgallery.com) is one of the many online print services
offered in the Kodak EasyShare software. You can easily:
■ Upload your pictures.
■ Edit, enhance, and add borders to your pictures.
■ Store pictures, and share them with family and friends.
■ Order high-quality prints, photo greeting cards, frames, and albums—and have
them delivered to your door.
Printing from an optional SD card
■ Automatically print tagged pictures when you insert your card into a printer with
an SD card slot. See your printer user’s guide for details.
■ Make prints at an SD-capable Kodak picture maker/picture kiosk. (Contact a
location before visiting. Visit www.kodak.com/go/picturemaker.)
■ Take the card to your local photo retailer for professional printing.
Dock compatibility for your camera
To see which Kodak EasyShare docks are compatible with your camera, visit
www.kodak.com/go/dockcompatibility.
Purchase camera docks,
printer docks, and other
accessories
40 www.kodak.com/go/support
www.kodak.com/go/m1073accessories
Transferring, printing, tagging
Tagging your pictures
You can tag your pictures so they are easy to:
■ Print
■ Email
■ Organize with a favorite tag
■ Organize with a tag name that you create
Tagging pictures for printing
1 Press the Share button. Press to locate a picture.
2 Press to highlight Print, then press OK.
3 Press to select the number of copies*
Optional: You can apply a print quantity to other pictures. Press for
previous/next. Keep the print quantity as is, or press to change it. Repeat
this step until the desired print quantity is applied to the pictures.
4 Press OK.
The Print icon appears in the status area.
■ Press the Share button to exit the menu.
* To tag all pictures in the storage location, highlight Print All, press OK, then choose
the number of copies. To cancel printing for all pictures in the storage location,
highlight Cancel Prints, then press OK.
Printing tagged pictures
When you transfer the tagged pictures to your computer, the EasyShare software print
screen opens. For details on printing, see Help in EasyShare software.
www.kodak.com/go/support
41
Transferring, printing, tagging
Tagging pictures/videos for emailing
First, create a new email address: highlight Add Email, press OK, then use the
on-camera keyboard.
1 Press the Share button. Press to locate a picture, then press OK.
2 Press the menu button, highlight Email, then press OK.
3 Press to locate an email address, then press OK.
To tag other pictures/videos with the same address, scroll through them. When the
picture you want is displayed, press OK.
To send the pictures/videos to more than one address, repeat step 3.
■ To remove a selection, highlight a checked address and press OK. To remove
all email selections, highlight Clear All, then press OK.
■ To exit the menu, highlight Exit, then press OK.
The Email icon appears in the status area.
When you transfer the tagged pictures/videos to your computer, EasyShare software
prompts you to send the pictures/videos. For details, see Help in EasyShare software.
42 www.kodak.com/go/support
Transferring, printing, tagging
Assigning the favorite tag to pictures/videos
To make your favorite pictures/videos easier to locate, you can assign the favorite tag.
1 Press the Share button, then locate a picture/video.
2 Highlight Favorite, then press OK.
■ To assign the tag to other pictures, press to locate a picture, then press
OK. To remove a selection, highlight a tag name and press OK. To remove all
tag selections, highlight Clear All, then press OK.
■ To view favorites on your camera, see page 14.
The favorite tag appears with the picture. A plus (+) means the picture has more than
one tag assigned. When you transfer the tagged pictures/videos to your computer,
EasyShare software opens and categorizes your pictures/videos with the appropriate
tag.
Assigning other tags to pictures/videos
First, create a new tag name: highlight Add Tag, press OK, then use the on-camera
keyboard.
1 Press the Review button, then locate a picture/video.
2 Press the Menu button.
3 Highlight Tag, then press OK.
4 Highlight a tag name, then press OK.
To assign the tag to other pictures, press to locate a picture, then press OK.
The tag name appears with the picture. A plus (+) means the picture has more than one
tag assigned.
To remove a selection, highlight a tag name and press OK. To remove all tag
selections, highlight Clear All, then press OK.
When you transfer the tagged pictures/videos to your computer, EasyShare software
opens and categorizes your pictures/videos with the appropriate tag.
www.kodak.com/go/support
43
Transferring, printing, tagging
Assigning a tag to pictures/videos you take next
Use the Set Tag feature to assign a tag name to the next pictures/videos you take.
First, create a new tag name: highlight Add Tag, press OK, then use the on-camera
keyboard.
1 Press the Menu button.
2 Highlight the Setup tab.
3 Highlight Set Tag, then press OK.
4 Highlight a tag name, then press OK.
5 Press the Menu button to exit the menu.
The selected tag is displayed on the LCD.
When you transfer the tagged pictures/videos to your computer, EasyShare software
opens and categorizes your pictures/videos with the appropriate tag.
44 www.kodak.com/go/support
6 Troubleshooting
For step-by-step product support, visit www.kodak.com/go/m1073support, and select
Interactive Troubleshooting & Repairs.
Camera problems
If... Try one or more of the following
Camera does not
turn on.
Camera does not
turn off.
Camera buttons
and controls do
not function
Battery does not
charge using USB
charging.
Pictures remaining
number does not
decrease after
taking a picture.
Short battery life
with Kodak Li-Ion
rechargeable
■ Remove the battery, then reinsert correctly (see page 1).
■ Install new battery.
■ Charge rechargeable battery (see page 2).
■ See page 2 or visit www.kodak.com/go/usbcharging.
■ The camera is operating normally. Continue taking pictures.
■ Limit the following activities that quickly deplete battery power:
reviewing pictures/videos on the LCD; excessive use of the flash.
digital camera
battery KLIC-7001.
www.kodak.com/go/support 45
Troubleshooting
If... Try one or more of the following
Stored pictures are
corrupted.
In Review mode,
you do not see a
picture (or the
expected picture)
on the LCD screen.
In Review mode, a
blue or black
screen is displayed
instead of a
picture.
Picture is too light.
■ Retake pictures. Do not remove card while the camera is accessing it.
Keep rechargeable batteries charged.
■ Transfer pictures to the computer (see page 37), then format the card
in the camera (see page 33).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
■ Check the image storage location setting (see page 31).
■ Transfer the picture to the computer (see page 37), then format the
card in the camera (see page 33).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
■ Decrease Exposure Compensation (see page 35).
Picture is not clear.
Picture is too dark.
■ Turn off the flash, then move back from the subject.
■ Clean the lens (see page 55).
■ Make sure your camera is not in Close-up mode.
■ Move so there is at least 2 ft (0.6 m) between the camera and the
subject.
■ Place the camera on a flat, steady surface or use a tripod.
■ Turn on the flash (see page 8).
■ Move so that the distance between you and the subject is within the
effective flash range (see page 54).
■ Use Fill flash (page 8) or change your position so light is not behind
the subject.
■ Increase Exposure Compensation (see page 35).
46 www.kodak.com/go/support
If... Try one or more of the following
Troubleshooting
Camera does not
recognize SD card.
Camera freezes up
when a card is
inserted or
removed.
Memory card full.
Memory card and
internal memory
full.
■ Purchase a certified SD/SDHC card. (MMC and write-once SD cards are
not supported.)
■ Reformat the card (see page 33).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
■ Insert a card into the slot, then push to seat (see page 4).
■ Turn the camera off, then back on.
■ Make sure the camera is turned off before inserting or removing a
card.
■ Insert a new card (see page 4), transfer pictures to the computer (see
page 37), or delete pictures (see page 17).
■ Transfer pictures to the computer (see page 37), then format the card
or internal memory (see page 33).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
Camera/computer communications
If... Try one or more of the following
The computer does
not communicate
with the camera.
www.kodak.com/go/support
■ Turn on the camera (see page 3).
■ Make sure the battery is fully charged (see page 2).
■ Connect the USB cable to camera and computer port (see page 37).
■ Install the software (see page 36).
■ Disconnect the USB cable. Close all software applications. Re-install
the software (see page 36).
■ Disconnect camera from the computer. Close all software applications,
reconnect camera.
47
Troubleshooting
If... Try one or more of the following
Cannot transfer
pictures.
(The Add New
Hardware Wizard
cannot locate
drivers.)
Slide show stops or
does not run on an
external video
■ Disconnect the USB cable. (If using camera dock or printer dock,
disconnect cable and remove camera from dock). Close all open
applications. Re-install the software (see page 36).
■ Disconnect the USB cable. Close all software applications. Re-install
the software (see page 36).
■ Reboot the computer.
■ Try another co mputer.
■ Adjust the camera Video Out setting NTSC or PAL (see page 32).
■ Make sure the external device settings are correct. (See the device’s
user’s guide.)
device.
LCD screen messages
If... Try one or more of the following
No images to
display
■ Change image storage location setting (see page 31).
Memory card
requires
formatting
■ Insert a new card (see page 4) or format the card (see page 33).
Caution: Formatting a card deletes all pictures and videos,
including protected files.
Memory card
cannot be read
(Please format
memory card or
insert another
card)
Only one USB
connection
■ Unplug the USB cable from the camera.
■ Remove the camera from the dock.
allowed.
Disconnect cable
or rem. (remove)
camera from dock.
48 www.kodak.com/go/support
If... Try one or more of the following
Troubleshooting
Internal memory
requires
formatting
Internal memory
cannot be read
(Please format
internal memory)
No memory card
(Files not copied)
Not enough space
to copy files (Files
not copied)
Memory card is
locked (Insert new
memory card)
Memory card is
unusable (Insert
new memory card)
■ Format the internal memory (see page 33).
Caution: Formatting deletes all pictures and videos, including
protected files. (Formatting internal memory also deletes email
addresses, album names, and Favorites. To restore them, see the
Kodak EasyShare software Help.)
■ Insert a certified SD or SDHC card (see page 4).
NOTE: MMC and write-once SD cards are not supported.
■ Delete pictures from the image storage location you are copying to
(see page 17), or insert a new card (see page 4).
Insert a new card (see page 4), move the switch on the card to unlock the
card, or change the image storage location to internal memory (see
page 31).
■ Insert a new card (see page 4) or format the card (see page 33).
NOTE: MMC and write-once SD cards are not supported.
Caution: Formatting a card deletes all pictures and videos,
including protected files.
Date and time
■ Reset the clock (see page 3).
have been reset
No address book
on camera
■ Create and copy address book from computer. See the Kodak
EasyShare software Help.
(Connect with
computer to
import address
book)
www.kodak.com/go/support
49
Troubleshooting
If... Try one or more of the following
No album names
on camera
(Connect with
computer to
import album
names)
High camera
temperature.
(Camera will be
turned off.)
Unrecognized file
format
Camera error
#XXXX.
■ Create and copy album names from computer. See the Kodak
EasyShare software Help.
■ Leave the camera off for 10 minutes, then turn it back on.
■ Transfer the picture to the computer (see page 37), or delete it (see
page 17).
■ Turn camera off, then back on. If the message reappears, visit
www.kodak.com/go/m1073support and select Interactive
Troubleshooting & Repairs.
50 www.kodak.com/go/support
7 Getting help
Camera
Email, write, or phone customer support www.kodak.com/go/contact
Get support for your product (FAQs,
troubleshooting information, arrange for repairs,
etc.)
Purchase camera accessories (camera docks,
printer docks, lenses, cards, etc.)
Download the latest camera firmware and
software
See online demonstrations of your camera www.kodak.com/go/howto
www.kodak.com/go/m1073support
www.kodak.com/go/m1073accessories
www.kodak.com/go/m1073downloads
Software
Get information on EasyShare software www.kodak.com/go/easysharesw (or click
the Help button in EasyShare software)
Get help with the Windows operating system and
working with digital pictures
www.kodak.com/go/pcbasics
Other
Get support for other cameras, software, accessories www.kodak.com/go/support
Get information on Kodak EasyShare printer docks www.kodak.com/go/printerdocks
Get information on Kodak inkjet products www.kodak.com/go/inkjet
Optimize your printer for truer, more vibrant colors www.kodak.com/go/onetouch
Register your camera www.kodak.com/go/register
www.kodak.com/go/support 51
Getting help
NOTE: If you have questions concerning this product, you may speak with Kodak customer support.
Australia 1800 267 588 Netherlands 020 346 9372
Austria 0179 567 357 New Zealand 0800 880 120
Belgium 02 713 14 45 Norway 23 16 21 33
Brazil 0800 891 42 13 Philippines 1 800 1 888 9600
Canada 1 800 465 6325
China 800 820 6027 Portugal 021 415 4125
Czech Republic 00 800 56325000
Denmark 3 848 71 30 Singapore 800 6363 036
Ireland 01 407 3054
Finland 0800 1 17056 Spain 91 749 76 53
France 01 55 1740 77 Sweden 08 587 704 21
Germany 069 5007 0035
Greece
Hong Kong 800 901 514
00800 44140775
Poland 00800 4411625
Russia 8 495 929 9166
Slovakia 00 800 56325000
Switzerland 044 838 53 51
Taiwan 0800 096 868
Thailand 001 800 631 0017
Hungary 06 80 456 325 Turkey 00800 448827073
India
91 80 41374555
United Kingdom 0870 243 0270
(toll free 000800 440 1227)
Italy 02 696 33452 United States 1 800 235 6325
Japan 03 5540 9002 International Toll Line +44 131 458 6714
Korea 080 708 5600 International Toll Fax +44 131 458 6962
52 www.kodak.com/go/support
8 Appendix
Camera specifications
For more specifications, visit www.kodak.com/go/m1073support.
CCD—1/2.33 in., 4:3 aspect ratio; 10.6 MP (total), 10.2 MP (effective)
Picture sizes—
10.2 MP (4:3): 3680 x 2760 pixels
9.0 MP (3:2): 3680 x 2452 pixels
7.6 MP (16:9): 3680 x 2070 pixels
5.0 MP (4:3): 2592 x 1944 pixels
3.1 MP (4:3): 2048 x 1536 pixels
2.2 MP (3:2): 1800 x 1200 pixels
2.1 MP (16:9): 1920 x 1080 pixels
1.2 MP (4:3): 1280 x 960 pixels
Color display—6.9 cm (2.7 in.); (960 x 240) pixels; 30 fps; field-of-view: 100%.
Taking lens—3X optical lens f/2.9–f/5.2; 32 mm–96 mm (35 mm equivalent)
Lens barrier—Automatic built-in
Digital zoom—5.0X continuous with 0.2X increments starting at 3X optical zoom;
combined zoom: 15X
Focus system—TTL-AF; selectable multi-zone AF, center-zone AF. Working range:
60 cm (23.6 in.)–infinity @ normal
0.10–0.7 m (3.9–28 in.) @ close-up/macro, wide
0.35–0.7 m (13.8–28 in.) @ close-up/macro, tele
www.kodak.com/go/support 53
Appendix
10 m (32.8 ft)–infinity @ Landscape
Exposure metering—Multi-pattern, Center-weight, Spot
Exposure compensation—+/-2.0 EV with 0.3 EV steps
Long Time Exposure—None, 0.5, 1.0, 2.0, 4.0 seconds
Shutter speed—Mechanical shutter with CCD; Auto: 4–1/2000 sec.
ISO speed—Auto: 80–400
Manual: 80, 100, 200, 400, 800, 1600 (selectable)
Electronic flash—Guide no. 4.5 (@ ISO 100); auto flash with pre-flash:
Wide, ISO 250: 0.6–3.0 m (2–9.8 ft.); Tele, ISO 400: 0.6–2.0 m (2–6.6 ft.)
Flash modes—Auto, Off, Fill, Red-eye
Capture modes—Auto, Landscape, Close-up, SCN, High ISO, Video
Video capture—VGA (640 x 480) @ 15 fps; QVGA (320 x 240) @ 30 fps
Image file format—Still: EXIF 2.21 (JPEG compression); file organization: DCF
(movie): MOV; CODEC Motion JPEG (video); G.711 (audio)
Image storage—Optional SD/SDHC Card . MMC and write-once SD cards
are not supported. (The SD logo is a trademark of the SD Card Association.)
Internal storage capacity—32 MB internal memory/17.5 MB available for image
storage (1 MB equals one million bytes)
Power—Kodak Li-Ion rechargeable digital camera battery KLIC-7001; optional
Kodak 5V AC adapter; optional Kodak USB AC adapter (for battery charging only)
Communication with computer—USB 2.0 Full Speed (PIMA 15740 protocol), via
USB cable model U-8, EasyShare camera dock or printer dock
PictBridge support—Yes
Self Timer—2 seconds, 10 seconds, or 2-shot
Burst—4 shots (1.0 fps)
White balance—Auto, Daylight, Tungsten, Fluorescent, Open Shade
54 www.kodak.com/go/support
Face Detect Capture—On, Off
Sharpness modes—High, Normal, Low
Auto power off—Selectable 1, 3, 5, 10 minutes
Microphone—Yes (for audio recording at Video mode)
Speaker—Yes
Color modes—Color (high, natural, low), Black & White, Sepia
Tripod mount—1/4 inch
Appendix
Operating temperature—32–104
°F (0–40°C)
Size—92 mm (3.6 in.) x 56.5 mm (2.2 in.) x 22.7 mm (0.9 in.) @ power off
Weight—117 g (4.1 oz.) without battery or card
Care and maintenance
■ If you suspect water has gotten inside the camera, remove the battery and card.
Allow all components to air-dry for at least 24 hours before using the camera.
■ Blow gently on the lens or LCD to remove dust and dirt. Wipe gently with a soft,
lint-free cloth or an untreated lens-cleaning tissue. Do not use cleaning solutions
unless designed specifically for camera lenses. Do not allow chemicals, such as
suntan lotion, to contact painted surfaces.
■ Service agreements may be available in your country. Contact a dealer of Kodak
products for more information.
■ For digital camera disposal or recycling information, contact your local authorities.
In the US, visit the Electronics Industry Alliance Web site at www.eiae.org or the
Kodak Web site at www.kodak.com/go/m1073support.
Upgrading your software and firmware
Download the latest versions of the software included on the Kodak EasyShare
software CD and the camera firmware (the software that runs on the camera). Visit
www.kodak.com/go/m1073downloads.
www.kodak.com/go/support
55
Appendix
Storage capacities
The LCD displays the approximate number of pictures (or minutes/seconds of video)
remaining. For average SD card capacities, visit www.kodak.com/go/SDcapacities.
Actual storage capacity varies depending on subject composition, card size, and other
factors. You may be able to store more or fewer pictures and videos. Favorites take up
additional space in internal memory.
Important safety instructions
CAUTION:
Do not disassemble this product; there are no user-serviceable parts
inside. Refer servicing to qualified service personnel. Kodak AC adapters
and battery chargers are intended for indoor use only. The use of controls,
adjustments, or procedures other than those specified herein may result
in exposure to shock and/or electrical or mechanical hazards. If the LCD
breaks, do not touch the glass or liquid. Contact Kodak customer support.
■ The use of an accessory that is not recommended by Kodak may cause fire, electric
shock, or injury. For approved accessories, visit www.kodak.com/go/accessories.
■ Use only a USB-certified computer equipped with a current-limiting motherboard.
Contact your computer manufacturer if you have questions.
■ If using this product in an airplane, observe all instructions of the airline.
■ When removing the battery, allow it to cool; it may be hot.
■ Read and follow all warnings and instructions supplied by the battery
manufacturer.
■ Use only batteries approved for this product to avoid risk of explosion.
■ Keep batteries out of the reach of children.
■ Do not allow batteries to touch metal objects, including coins. Otherwise, a battery
may short circuit, discharge energy, become hot, or leak.
■ Do not disassemble, install backward, or expose batteries to liquid, moisture, fire,
56 www.kodak.com/go/support
Appendix
or extreme temperature.
■ Remove the battery when the product is stored for an extended period of time. In
the unlikely event that battery fluid leaks inside the product, contact Kodak
customer support.
■ In the unlikely event that battery fluid leaks onto your skin, wash immediately with
water and contact your local health provider. For additional health-related
information, contact your local Kodak customer support.
■ Dispose of batteries according to local and national regulations. Visit
www.kodak.com/go/kes.
■ Do not charge non-rechargeable batteries.
For more information on batteries, visit www.kodak.com/go/batterytypes.
Battery life
Kodak Li-Ion rechargeable digital camera battery KLIC-7001: 200-250 pictures per
charge. Battery life per CIPA testing method. (Approximate number of pictures in Auto
mode, using internal memory.) Actual life may vary based on usage.
Extending battery life
■ Use power-saving features (see Customizing your camera, page 31).
■ Dirt on the battery contacts can affect battery life. Wipe the contacts with a clean,
dry cloth before loading batteries in the camera.
■ Battery performance is reduced at temperatures below 41° F (5° C). When using
your camera in cold weather, carry spare batteries and keep them warm. Do not
discard cold batteries that do not work; when they return to room temperature,
they may be usable.
www.kodak.com/go/support
57
Appendix
Limited Warranty
Kodak warrants Kodak consumer electronic products and accessories (“Products”),
excluding batteries, to be free from malfunctions and defects in both materials and
workmanship for one year from the date of purchase.
Retain the original dated sales receipt. Proof of the date of purchase will be required
with any request for warranty repair.
Limited warranty coverage
Warranty service is only available from within the country where the Products were
originally purchased. You may be required to ship Products, at your expense, to the
authorized service facility for the country where the Products were purchased.
Kodak will repair or replace Products if they fail to function properly during the
warranty period, subject to any conditions and/or limitations stated herein. Warranty
service will include all labor as well as any necessary adjustments and/or replacement
parts. If Kodak is unable to repair or replace a Product, Kodak will, at its option,
refund the purchase price paid for the Product provided the Product has been
returned to Kodak along with proof of the purchase price paid. Repair, replacement,
or refund of the purchase price are the sole remedies under the warranty.
If replacement parts are used in making repairs, those parts may be remanufactured,
or may contain remanufactured materials. If it is necessary to replace the entire
Product, it may be replaced with a remanufactured Product. Remanufactured
Products, parts, and materials are warranted for the remaining warranty term of the
original Product, or 90 days after the date of repair or replacement, whichever is
longer.
Limitations
This warranty does not cover circumstances beyond Kodak’s control. This warranty
does not apply when failure is due to shipping damage, accident, alteration,
modification, unauthorized service, misuse, abuse, use with incompatible accessories
or attachments (such as third party ink or ink tanks), failure to follow Kodak’s
operation, maintenance, or repacking instructions, failure to use items supplied by
Kodak (such as adapters and cables), or claims made after the duration of this
58 www.kodak.com/go/support
Appendix
warranty.
Kodak makes no other express or implied warranty for this product, and
disclaims the implied warranties of merchantability and fitness for a
particular purpose. In the event that the exclusion of any implied warranty is
ineffective under the law, the duration of the implied warranty will be one year from
the purchase date or such longer period as required by law.
The option of repair, replacement, or refund is Kodak’s only obligation. Kodak will not
be responsible for any special, consequential or incidental damages resulting from the
sale, purchase, or use of this product regardless of the cause. Liability for any special,
consequential or incidental damages (including but not limited to loss of revenue or
profit, downtime costs, loss of the use of the equipment, cost of substitute
equipment, facilities or services, or claims of your customers for such damages
resulting from the purchase, use, or failure of the Product), regardless of cause or for
breach of any written or implied warranty is expressly disclaimed.
Your rights
Some states or jurisdictions do not allow exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
Some states or jurisdictions do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you.
This warranty gives you specific rights, and you may have other rights which vary from
state to state or by jurisdiction.
Outside the United States and Canada
In countries other than the United States and Canada, the terms and conditions of
this warranty may be different. Unless a specific Kodak warranty is communicated to
the purchaser in writing by a Kodak company, no warranty or liability exists beyond
any minimum requirements imposed by law, even though defect, damage, or loss may
be by negligence or other act.
www.kodak.com/go/support
59
Appendix
Regulatory compliance
FCC compliance and advisory
Kodak EasyShare M1073 IS digital camera
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed or used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures: 1) reorient
or relocate the receiving antenna; 2) increase the separation between the equipment
and the receiver; 3) connect the equipment to an outlet on a circuit different from that
to which the receiver is connected; 4) consult the dealer or an experienced radio/TV
technician for additional suggestions.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Where shielded
interface cables have been provided with the product or specified additional
components or accessories elsewhere defined to be used with the installation of the
product, they must be used in order to ensure compliance with FCC regulation.
60 www.kodak.com/go/support
Appendix
FCC and Industry Canada
This device complies with Industry Canada RSS-210 and FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Canadian DOC statement
DOC Class B Compliance—This Class B digital apparatus complies with Canadian ICES-003.
Observation des normes-Classe B—Cet appareil numérique de la classe B est conforme à
la norme NMB-003 du Canada.
Australian C-Tick
N137
Waste Electrical and Electronic Equipment labeling
EU: It is the user’s responsibility to discard this equipment into an
approved, segregated collection scheme to enable its suitable
treatment/disposal and to improve human/environmental protection. For
more information, see your retailer, local authority or
www.kodak.com/go/recycle. (Product weight: 109 g.)
Korean Class B ITE
www.kodak.com/go/support
61
Appendix
VCCI Class B ITE
China RoHS
Russian GOST-R
Eastman Kodak Company
Rochester, NY 14650
AIO-40
62 www.kodak.com/go/support
Index 1
Numerics
4-way arrows, ii
A
A/V cable, 24
about picture, video, 15
about this camera, 33
accessories, 37
battery, 57
buying, 51
printer dock, 38
SD/SDHC card, 4
albums
set, 31
appendix, 53
auto, 9
flash, 8
flash/status, 8
OK, ii
ok, ii
on/off, i
review, ii, 14
share, ii
shutter, i
zoom, 7
C
cable
audio/video, 24
cable, USB, 37
camera sounds, 32
candle light, 11
caring for your camera, 55
charging the battery, 2
focus framing marks, 6
B
backlight, 11
battery
charging, 2
compartment, ii
extending life, 57
loading, 1
types, 54
beach, 10
burst, using, 35
button
delete, 5
drive, 35
www.kodak.com/go/support 63
children, 11
clock, setting, 3
color mode, 28
compatibility, dock, 40
copy pictures
card to memory, 25
memory to card, 25
to computer, 36
cropping pictures, 19
customer support, 51, 52
customizing camera settings, 31
D
date
setting, 3
Index
DC-in, ii
deleting
during quickview, 5
from internal memory, 17
from SD/SDHC card, 17
protecting pictures, videos, 17
digital zoom, using, 7
displaying slide show, 21
disposal, recycling, 55, 61
dock
compatibility, 40
connector, ii
printer, 38
doing more with your camera, 27
download pictures, 36
E
EasyShare software
installing, 36
emailing pictures, videos, 42
exposure
compensation, 35
long time, 28
metering, 29
external video device
viewing pictures/videos, slide
shows, 24
flash
settings, 8
flower, 10
focus
framing marks, 6
zone, 30
format, 33
framing grid, 35
G
grid, framing, 35
guidelines, battery, 57
H
help, 45
I
icons, mode dial, 9
image stabilizer, 32
image storage, 31
information
about pictures, videos, 15
installing
batteries, 1
SD/SDHC card, 4
software, 36
internal memory
storage capacity, 56
F
favorites
tagging, 43
filter pictures, videos, 23
fireworks, 10
firmware, upgrading, 55
64 www.kodak.com/go/support
ISO speed, 30
K
Kodak
EasyShare software, 36, 55
Perfect Touch technology, 18
Index
L
LCD, ii
brightness, 31
reviewing pictures, 14
reviewing videos, 14
lens
cleaning lens, 55
loading
batteries, 1
SD/SDHC card, 4
software, 36
long time exposure, 28
M
Macintosh computers, installing
software on, 36
maintenance, camera, 55
manner/museum, 10
memory
inserting card, 4
storage capacities, 56
menu settings, 27
portrait, 10
SCN, 9
self-portrait, 11
snow, 10
sports, 10
sunset, 11
text/document, 10
multimedia slide show, 22
multiple selections, 25
multi-up, 23
N
night landscape, 10
night portrait, 10
O
OK button, ii
ok button, ii
on/off button, i
online prints, ordering, 40
optical zoom, 7
orientation sensor, 32
mode dial, i, 9
modes
auto, 9
backlight, 11
beach, 10
candle light, 11
children, 11
fireworks, 10
flower, 10
manner/museum, 10
night landscape, 10
night portrait, 10
P
panoramic pictures, 12
Perfect Touch technology, 18
PictBridge enabled printer, 38
pictures
checking settings, 26
copying, 25
cropping, 19
deleting, 17
emailing tagged, 42
printing, 39
printing tagged, 41
www.kodak.com/go/support 65
Index
protecting, 17
reviewing, 14
storage capacity, 56
tagging, 41
taking, modes, 9
transfer, 36
portrait, 10
power, camera, 3
pre-tagging, 44
printer dock, 38
printing
from a card, 40
from computer, 39
order online, 40
PictBridge, 38
tagged pictures, 40
with EasyShare printer dock, 38
problem-solving, 45
protecting pictures, videos, 17
slide show, 21
reviewing videos
deleting, 17
LCD, 14
protecting, 17
slide show, 21
running slide show, 21
S
scene modes, 10
panorama, 12
SCN, 9
SD/SDHC card
inserting, 4
printing from, 40
storage capacities, 56
search pictures, videos, 23
select multiple pictures/videos, 25
self-portrait, 11
self-timer, 34
Q
quickview, using, 5
self-timer light, i
service and support telephone
numbers, 52
R
recycling, disposal, 55, 61
red-eye, flash, 8
regulatory information, 60
repair, 51
review button, ii, 14
reviewing pictures
as you take them, 5
deleting, 17
LCD, 14
protecting, 17
setting
about, 33
camera sounds, 32
color mode, 28
date and time, 3
exposure metering, 29
flash, 8
focus zone, 30
image stabilizer, 32
image storage, 31
ISO, 30
66 www.kodak.com/go/support
Index
LCD brightness, 31
long time exposure, 28
orientation sensor, 32
picture taking mode, 9
self-timer, 34
sharpness, 30
sound volume, 32
video out, 32
video size, 31
white balance, 29
setting, albums, 31
setup mode, using, 31
share button, ii
sharpness, 30
shutter
button, i
self-timer delay, 34
T
tagging
creating tags, 43
favorites, 43
for email, 42
for print, 41
pre-tagging, 44
telephone support, 52
television
viewing pictures/videos, slide
shows, 24
text/document, 10
time, setting, 3
timer, shutter delay, 34
tips
care & maintenance, 55
transferring pictures, videos, 36
slide show
continuous loop, 22
running, 21
snow, 10
software
installing, 36
upgrading, 55
sound volume, 32
sounds, 32
speakers, i
specifications, camera, 53
sports, 10
storage capacity, 56
strap post, ii
sunset, 11
support, technical, 51, 52
trash can, deleting, 5
tripod socket, ii
troubleshooting, 45
turning camera on and off, 3
U
undelete, 17
undo, 17
upgrading software, firmware, 55
USB cable, 37
V
VCCI compliance, 62
video
action print, 20
checking settings, 26
copying, 25
www.kodak.com/go/support 67
Index
deleting, 17
emailing tagged, 42
out, 24, 32
protecting, 17
reviewing, 14
size, 31
storage capacities, 56
viewing, 14
video light, i
videos
transfer, 36
viewing
by date, tag, 23
by multi-up, 23
viewing picture
after taking, 5, 14
viewing picture, video information, 15
volume, 32
W
warranty, 58
WEEE, 61
white balance, 29
Windows OS-based computers
installing software, 36
wrist strap, 1
Z
zoom
digital, 7
optical, 7
68 www.kodak.com/go/support
Loading...
