Kodak ESP Office 6150 Extended User Guide
KODAK ESP Office 6100 Series
All-in-One Printer
User Guide
Eastman Kodak Company
Rochester, NY 14650
© Eastman Kodak Company, 2009
Kodak, EasyShare, and Perfect Touch are trademarks of Eastman Kodak Company.
Specifications subject to change without notice.
P/N XXXXXX
September 2009
Table of contents
1 Printer Overview
Components.......................................................................................................................................................................1
Control panel.....................................................................................................................................................................2
Home Center Software ..................................................................................................................................................3
2 Configuring Your Printer
Configuring printer settings ..........................................................................................................................................4
Connecting to a wireless network ...............................................................................................................................5
Before you connect ...................................................................................................................................................5
Connecting to a wireless network using the WiFi Setup Wizard..................................................................5
Setting up an IP address...........................................................................................................................................9
Verifying the network configuration...................................................................................................................10
Printing the network configuration .....................................................................................................................10
Installing your printer on additional computers on the network.................................................................10
Connecting to another KODAK All-in-One Printer ......................................................................................... 11
Adding a network connection to a USB-connected computer .......................................................................... 12
Changing from USB to wireless connection ..................................................................................................... 12
Changing from USB to Ethernet connection..................................................................................................... 13
3 Handling Paper
Paper types...................................................................................................................................................................... 15
Paper sizes....................................................................................................................................................................... 15
Envelope sizes................................................................................................................................................................. 16
Loading paper .................................................................................................................................................................16
Loading plain paper................................................................................................................................................. 16
Loading legal-size paper ........................................................................................................................................ 18
Loading photo paper .............................................................................................................................................. 21
Loading envelopes...................................................................................................................................................23
Loading originals ........................................................................................................................................................... 25
Using the scanner glass ........................................................................................................................................ 25
Using the Automatic Document Feeder (ADF).............................................................................................. 26
4 Printing
Printing documents ...................................................................................................................................................... 27
Printing two-sided documents............................................................................................................................ 27
Printing pictures ............................................................................................................................................................ 29
Printing from a wireless device ................................................................................................................................. 29
5 Copying
Loading originals for copying.....................................................................................................................................30
Copying a document....................................................................................................................................................30
Using the default settings to copy a document .............................................................................................. 30
Adjusting the settings and copying a document............................................................................................ 30
Changing the number of copies of a document...............................................................................................32
Enlarging or reducing a document ......................................................................................................................32
www.kodak.com/go/aiosupport i
Table of contents
Darkening or lightening a copy ............................................................................................................................32
Copying a photograph..................................................................................................................................................33
Using the default settings to copy a photograph ............................................................................................33
Adjusting the settings and copying a photograph ..........................................................................................33
Changing the number of copies of a photograph........................................................................................... 34
Enlarging or reducing a photograph ...................................................................................................................35
Darkening or lightening a copy of a photograph.............................................................................................35
6 Scanning
Before you begin scanning ..........................................................................................................................................36
Changing the scan settings for scanning from the control panel ...............................................................36
Loading originals for scanning....................................................................................................................................37
Scanning from the computer ......................................................................................................................................37
Scanning multiple pictures simultaneously......................................................................................................38
Scanning from the control panel................................................................................................................................39
7 Faxing
Before you begin faxing...............................................................................................................................................40
Connecting the printer for faxing .......................................................................................................................40
Setting fax options ................................................................................................................................................. 42
Working with the phonebook..............................................................................................................................46
Preparing a fax for transmission............................................................................................................................... 49
Printing a fax cover page ...................................................................................................................................... 49
Loading originals..................................................................................................................................................... 49
Changing resolution and brightness.................................................................................................................. 49
Sending a fax.................................................................................................................................................................. 50
Using the Phonebook to send a fax ................................................................................................................... 50
Using Quick Dial to send a fax ............................................................................................................................ 50
Using the numeric keypad to send a fax ............................................................................................................51
Using the Redial button to send a fax .................................................................................................................51
Receiving a fax.................................................................................................................................................................51
Receiving a fax automatically................................................................................................................................51
Receiving a fax manually .......................................................................................................................................52
8 Maintaining Your Printer
General care and cleaning...........................................................................................................................................53
Cleaning the scanner glass and document backing ...................................................................................... 54
Replacing ink cartridges...............................................................................................................................................56
Replacing the printhead ...............................................................................................................................................59
Updating the software and printer firmware..........................................................................................................63
Updating if your printer is connected to a computer with WINDOWS OS .............................................63
Updating if your printer is connected to a computer with MAC OS......................................................... 64
Monitoring and adjusting printer performance .................................................................................................... 64
Checking ink levels................................................................................................................................................. 64
Resetting factory defaults .................................................................................................................................... 64
ii www.kodak.com/go/aiosupport
Table of contents
9 Troubleshooting
Basic troubleshooting .................................................................................................................................................. 65
Getting help on the Web............................................................................................................................................. 67
Status lights.................................................................................................................................................................... 68
Power status light...................................................................................................................................................68
Wi-Fi status light .................................................................................................................................................... 68
10 Product and Safety Specifications
Features and Specifications ....................................................................................................................................... 69
Print performance...................................................................................................................................................69
Photo printing features.......................................................................................................................................... 69
Copy document features ...................................................................................................................................... 70
Copy photo features ..............................................................................................................................................70
Scanning features ................................................................................................................................................... 70
Input paper tray........................................................................................................................................................ 71
Output paper tray.................................................................................................................................................... 71
Ink cartridges ............................................................................................................................................................ 71
Connectivity.............................................................................................................................................................. 71
Software support .................................................................................................................................................... 72
Physical specifications .......................................................................................................................................... 72
Warranty................................................................................................................................................................... 72
System requirements..............................................................................................................................................73
Safety information ........................................................................................................................................................ 76
Regulatory compliance................................................................................................................................................ 77
FCC statement ........................................................................................................................................................ 77
Canadian statements............................................................................................................................................. 78
German compliance statement .......................................................................................................................... 78
REACH Article 33 declarations........................................................................................................................... 78
Waste electrical and electronic equipment labeling..................................................................................... 78
ENERGY STAR® Qualified .......................................................................................................................................... 79
Warranty Information.................................................................................................................................................. 79
Declaration of Conformity........................................................................................................................................... 81
www.kodak.com/go/aiosupport iii
1
11
15
1
18
13
16
19
12
17
14
2
7 83 4 5 6
9
10
Printer Overview
Components
This printer lets you print, copy, scan, and fax pictures and documents. In addition,
this printer supports networking, letting you access the printer over a wireless
(Wi-Fi) network.
1 Control panel 11 Printer access door
2 Automatic document feeder (ADF) 12 Printhead with ink cartridges installed
3 ADF paper-edge guides 13 Output tray extender with paper stop
4 Line in phone port 14 Output tray
5 Ext out phone port 15 Scanner glass
6 USB port 16 Scanner lid
7 Ethernet port 17 Front paper-edge guide
8 Power cord port 18 Paper tray
9 Cleanout area 19 Left paper-edge guide
10 Duplexer (pulled out)
www.kodak.com/go/aiosupport 1
Printer Overview
1 32 4 5126 9 117 8 10 14 15 16 17 1813
Control panel
Feature Description
1 LCD Displays pictures, messages, and menus
2 Copy button Displays the Copy Options menu
3 Fax button Lets you enter a phone number for sending a fax, or choose the Fax Options menu
4 Scan button Displays the Scan Options menu
5 Navigation buttons Used to navigate menus, scroll through pictures
6 Back button Displays the next higher screen in the menu structure
7 OK button Selects a menu item, accepts a setting, and continues with current operation
8 Home button Displays the Main Menu
9 Redial button Dials the last dialed phone number
10 Auto Answer button Turns the fax auto answer feature on or off; when on, the fax answers all incoming
calls
11 Phonebook button Displays the phone book of fax numbers entered on this printer; lets you enter or
edit phone numbers
2 www.kodak.com/go/aiosupport
KODAK ESP Office 6100 Series All-in-One Printer
Feature Description
12 Numeric keypad Used to dial phone number or a Quick Dial number for faxing; to enter information
and Quick Dial settings into the fax phonebook; to specify a quantity for making
copies; and to enter an encryption string or passphrase for access to a wireless
network
13 Cancel button Stops the current operation and goes to the Main Menu, highlighting the function
that you used last
14 Start Color button Starts the selected operation in color
15 Start Black button Starts the selected operation in black and white
16 On/Off button Turns the printer on or off
17 Wi-Fi connectivity LED When lit, signals that the printer is connected to a wireless (Wi-Fi) network;
blinks quickly when searching for networks; blinks slowly when attempting to join
an already configured network
18 Attention light Blinks when an error occurs
Home Center Software
KODAK Home Center Software is installed as part of the software installation on
your computer. The Home Center icon is added to your desktop and, depending on
your configuration, to the Start menu. Use this icon to start Home Center Software.
On a computer with WINDOWS Operating System (OS), you can use Home Center
Software to:
• browse, crop, enhance, and edit pictures
• print, scan, and fax
• upgrade your printer with the latest software and firmware
•configure your printer
• order supplies
• access the KODAK Tips and Projects Center
• access this Extended User Guide
On a computer with MAC OS, you can use Home Center Software to scan, order
supplies, configure your printer, or check for printer software updates.
www.kodak.com/go/aiosupport 3
2
Configuring Your Printer
This section explains how to configure or change your printer settings and your
wireless network settings.
Configuring printer settings
NOTE: When you first power on the printer, the printer automatically steps you
through the process of selecting the
To set or change basic printer settings:
1. Press Home.
2. Press to select Printer Settings, then press OK.
3. Press to select one of the following settings:
• Date and Time*
–Press OK, then press to select Ye a r , Month, Day, Hour, or Minute.
Press or to change the values; press OK when you are done.
• Button Sounds
–Press to select On or Off.
• Ti m e t o Lo w Po we r
–Press to change the time to energy-saving low power (select from 1 to 4
hours in 0.5 hour increments). After the time to low power, the printer goes
into a low-power mode.
• Language
–Press OK, press to select a language, then press OK.
• Country/Region
–Press OK, press to select a country or region, then press OK.
• Reset All Settings (see Resetting factory defaults, page 64)
NOTE: Resetting factory defaults does not change the date and time, language, or
country/region.
Language and Country/Region.
4. Press Back to go back to the Main Menu.
* You can also synchronize the printer's date and time to your computer from Home
Center Settings
4 www.kodak.com/go/aiosupport
under Tools in Home Center Software.
Connecting to a wireless network
To connect your printer to an 802.11 wireless (Wi-Fi) network, refer to the following
information.
Before you connect
You need:
• A computer equipped with a network interface card or wireless networking
support.
• A working 802.11 wireless network. Kodak recommends that you use a wireless
access point/router that uses Dynamic Host Configuration Protocol (DHCP).
• Your network name (SSID - Service Set Identifier). You can obtain your SSID
from the wireless access point, most commonly a router, using the router’s
embedded Web server. See the manufacturer’s documentation provided with
your wireless system for more information.
• Your Wired Equivalent Privacy (WEP) key or Wi-Fi Protected Access
(WPA/WPA2) passphrase.
•To be sure to temporarily disable your firewall until the printer is successfully
installed and communicating.
KODAK ESP Office 6100 Series All-in-One Printer
Connecting to a wireless network using the WiFi Setup Wizard
You can use the WiFi Setup Wizard on the printer to connect to your wireless
network. Read the following procedures and use the one that is appropriate for your
network setup.
Connecting to a listed network
See Before you connect to determine what is needed to connect your printer to the
network.
To connect to a listed network using the WiFi Setup Wizard:
1. Press Home.
2. Press to select Network Settings, then press OK.
3. With WiFi Setup Wizard selected, press OK.
NOTE: The Wi-Fi radio is turned on automatically when you select WiFi Setup
Wizard.
The printer searches for available wireless networks within range, then displays
the list in order of signal strength. For example:
www.kodak.com/go/aiosupport 5
Configuring Your Printer
NOTE: If there are more networks than can be shown on the LCD, a (page down)
symbol appears in the bottom right of the display. If you don’t see your
network in the list or want to change your network, select
Wireless Networks
, then press OK.
Rescan for
4. Press to select your network, then press OK.
5. If your network requires a password, “Enter Security String” and a keyboard
appear on the LCD. Press
, , or to select the letters and numbers of
your password, using the correct uppercase and lowercase letters. Press OK
after each character. When your security string is entered, select
OK.
press
DONE, then
• To erase a character, select BKSP (backspace), then press OK.
• To change from uppercase to lowercase, select abc/123, then press OK.
• To change from lowercase to uppercase, select ABC/123, then press OK.
• To enter punctuation or symbols, select !@#, then press OK.
6. When the confirmation message appears, press OK.
7. If you haven’t yet installed the KODAK All-in-One Printer Software that came
with your printer, insert the software CD and follow the on-screen instructions
to install the software.
The printer with a wireless connection is listed as the name of the printer plus a
number (for example, KodakESP6100+1133).
6 www.kodak.com/go/aiosupport
Connecting to an unlisted network
To connect to an unlisted network using the WiFi Setup Wizard:
1. Press Home.
2. Press to select Network Settings, then press OK.
3. With WiFi Setup Wizard selected, press OK.
NOTE: The Wi-Fi radio is turned on automatically when you select WiFi Setup
Wizard.
4. If your network is configured to not broadcast its SSID (network name) and does
not appear in the list, select
5. Use the keyboard on the LCD to enter the network name.
Press , , or to select the letters and numbers of your network name,
using the correct uppercase and lowercase letters. Press OK after each
character. When you have finished entering the network name, select
then press
• To erase a character, select BKSP (backspace), then press OK.
• To change from uppercase to lowercase, select abc/123, then press OK.
• To change from lowercase to uppercase, select ABC/123, then press OK.
• To enter punctuation or symbols, select !@#, then press OK.
6. Select WEP or WPA/WPA2 as required for your network's security setup, then
OK.
press
7. Use the keyboard on the LCD to enter the required security information
(password or passphrase), pressing
security information is entered, select
8. When the confirmation message appears, press OK.
9. If you haven’t yet installed the KODAK All-in-One Printer Software that came
with your printer, insert the software CD and follow the on-screen instructions
to install the software.
The printer with a wireless connection is listed as the name of the printer plus a
number (for example, KodakESP6100+1133).
KODAK ESP Office 6100 Series All-in-One Printer
Unlisted Network, then press OK.
DONE,
OK.
OK after each character. When your
DONE, then press OK.
www.kodak.com/go/aiosupport 7
Configuring Your Printer
Using WPS to connect to a Wi-Fi network
If your router supports Wi-Fi Protected Setup (WPS), you can use WPS Connect.
WPS lets you configure your printer for a wireless network by pressing buttons or
entering a PIN.
To connect to a network using WPS:
1. Press Home.
2. Press to select Network Settings, then press OK.
3. With WiFi Setup Wizard selected, press OK.
NOTE: The Wi-Fi radio is turned on automatically when you select Wi-Fi Setup
Wizard.
4. Press to select WPS Connect, then press OK.
5. Select one of two methods of connecting:
IMPORTANT: Before you press OK on the printer, make sure you know where the router's
push button is, or where to enter the generated PIN.
If necessary, consult your Internet service provider or router device
manufacturer’s documentation for more information.
• To use push buttons:
a. With Push Button Configuration selected, press OK.
b.You will have two minutes to push the WPS button on your router (this may
either be a physical button on the router or a virtual button in the router’s
software).
•To enter a PIN:
a. Press to select Generate WPS PIN, then press OK.
b.Go to your router’s software and locate the PIN button.
c. Enter the PIN you received on the LCD into the PIN screen for your router.
6. When the confirmation message appears, press OK.
7. If you haven’t yet installed the KODAK All-in-One Printer Software that came
with your printer, insert the software CD and follow the on-screen instructions
to install the software.
The printer with a wireless connection is listed as the name of the printer plus a
number (for example, KodakESP6100+1133).
8 www.kodak.com/go/aiosupport
Setting up an IP address
IMPORTANT: You should only need to set up an IP address for your printer if you are
All IP address entries have the following format: 000.000.000.000. Within each
three-digit grouping, the number must be right-justified. If an address or subnet
mask has only one or two characters between the periods, include one or two
leading zeros in front of that number. For example:
KODAK ESP Office 6100 Series All-in-One Printer
having a problem with connecting. Typically, it is not necessary to set up an
IP address. This procedure is for advanced users who know how to obtain
the IP address for the printer.
The address as it may appear
in your documentation
149.89.138.149 149.089.138.149
149.2.40.149 149.002.040.149
How to enter the address
in the printer menu
For information about obtaining the printer IP address, go to
www.kodak.com/go/inkjetnetworking.
To set up your IP address on the printer:
1. Press Home.
2. Press to select Network Settings, then press OK.
3. Press to select Advanced IP Address Setup, then press OK.
4. Press OK again to continue.
5. Select one of the following, then press OK:
• Dynamic (DHCP)
• Automatic (Private)
• Manual (Static)
6. If you selected Manual (Static), you are prompted to enter an IP address, a
Subnet Mask, a Gateway Address, and a DNS Server address. Press
OK after
each entry. Use the navigation buttons to enter each digit of the numbers.
Consult your Internet service provider or network administrator for more
information.
www.kodak.com/go/aiosupport 9
Configuring Your Printer
Verifying the network configuration
To verify that you are connected to your wireless network:
1. Press Home.
2. Press to select Network Settings, then press OK.
3. Press to select View Network Configuration, then press OK.
The wireless network settings appear on the LCD.
If the printer is connected to your network, you will see the network name and
the word CONNECTED.
4. To scroll through the information, press .
5. When you are done, press OK.
Printing the network configuration
To print the current network configuration:
1. Load plain paper into the printer. (See Loading plain paper, page 16.)
2. Press Home.
3. Press to select Network Settings, then press OK.
4. Press to select Print Network Configuration, then press OK.
The printer prints a summary of the network configuration.
Installing your printer on additional computers on the network
To add your printer to another computer(s) on your network, install the KODAK
All-in-One Printer Software that came with your printer on each computer. Follow
the on-screen instructions.
10 www.kodak.com/go/aiosupport
Connecting to another KODAK All-in-One Printer
If you are connecting to a newer model printer (for example, you already have an
7 printer and now you are adding an ESP Office 6150 printer), you must install
ESP
the software for the newer model.
If you are connecting to another ESP Office 6150 printer or to an older model:
On a computer with WINDOWS OS:
1. Select Start > All Programs > Kodak > Kodak Printer Network Setup Utility.
2. If your wireless all-in-one printer (example: KodakESP6100+1133) is not listed:
• Select No, my printer is not listed, then click Next.
• From the drop-down list, select your printer.
• Select Network - Wireless / WiFi, then click Next.
When your printer is detected, driver installation begins.
3. If your wireless all-in-one printer (example: KodakESP6100+1133) is listed:
• Highlight the all-in-one printer that is connected to your network.
• Select Yes, my printer is listed, then click Next.
When your printer is detected, driver installation begins.
4. When driver installation is complete, click Done.
KODAK ESP Office 6100 Series All-in-One Printer
On a computer with MAC OS:
1. From the dock, open System Preferences.
2. Click Print & Fax.
3. Click the + sign to add the printer.
4. Select the printer from the list of available printers, then click Add.
www.kodak.com/go/aiosupport 11
Configuring Your Printer
Adding a network connection to a USB-connected computer
You can change the way you connect to your printer at any time.
Changing from USB to wireless connection
To change the printer connection type from USB to a wireless (Wi-Fi) network:
If your printer is connected to a computer with WINDOWS OS:
1. On the printer control panel, press Home.
2. Press to select Network Settings, then press OK.
3. Press to select View Network Co nfiguration, press OK, then confirm you have
an IP address.
4. If you have not already done so, connect your printer to your wireless network.
Connecting to a wireless network, page 5.
See
5. On your computer, disable any firewall you have installed until you have
successfully completed the installation For more information on firewalls, go to
www.kodak.com/go/inkjetnetworking.
6. Select Start > All Programs > Kodak > Kodak Printer Network Setup Utility.
• If your wireless all-in-one printer (example: Kodak ESP Office 6100+1133) is
listed:
not
a. Select No, my printer is not listed, then click Next.
b.From the drop-down list, select your printer: ESP Office 6100 Series.
c. Select Network - Wireless/WiFi, then click Next.
When your printer is detected, driver installation begins.
• If your wireless all-in-one printer (example: Kodak ESP Office 6100+1133) is
listed:
a. Highlight the all-in-one printer that is connected to your network.
b. Select Yes, my printer is listed, then click Next.
When your printer is detected, driver installation begins.
7. When driver installation is complete, click Done.
The printer with a wireless connection is listed as the name of the printer plus a
number (for example, KODAK ESP Office 6100+1133 Series).
12 www.kodak.com/go/aiosupport
If your printer is connected to a computer with MAC OS:
1. Disconnect the printer from the computer.
2. On the printer control panel, press Home.
3. Press to select Network Settings, then press OK.
4. Press to select View Network Configuration, press OK, then confirm you have
an IP address. If you do not have an IP address, see Connecting to a wireless
network, page 5.
5. From the dock, open System Preferences.
6. Click Print & Fax.
7. Cl ick t he + sign to add the printer.
8. Select the printer from the list of available printers, then click Add.
The printer with a wireless connection is listed as the name of the printer plus a
number (for example, Kodak ESP Office 6100+1133).
Changing from USB to Ethernet connection
Before you connect, you need:
KODAK ESP Office 6100 Series All-in-One Printer
• A functional Ethernet network that includes a router, switch, or hub with an
Ethernet port.
• A Category 5 (or higher) Ethernet cable.
• To temporarily disable your firewall until the printer is successfully installed and
communicating.
To change from a USB connect an Ethernet network connection:
1. Unplug the USB cord from your printer and computer.
2. Connect the Ethernet cable to the Ethernet port on the back of the printer.
3. Connect the other end of the Ethernet cable to an available Ethernet port on
your router, switch, or hub.
www.kodak.com/go/aiosupport 13
Configuring Your Printer
If your printer is connected to a computer with WINDOWS OS:
1. Select Start > All Programs > Kodak > Kodak Printer Network Setup Utility.
2. Select No, my printer is not listed, then click Next.
3. Select ESP Office 6100 Series, from the printer drop-down menu.
4. Select Network - Ethernet cable, then click Next.
The Printer Setup Utility searches for your printer and connects automatically.
5. Click Done.
If your printer is connected to a computer with MAC OS:
1. Select Apple > System Preferences.
2. Under Hardware, select Print & Fax.
3. In the Print & Fax dialog box, click +.
4. Select your printer from the list, then click Add.
14 www.kodak.com/go/aiosupport
3
Handling Paper
Paper types
For the best photo printing results, use KODAK Photo Papers, which are optimized to
work with KODAK All-in-One Printers.
For the best document printing results, use KODAK Document Papers or a paper
with the COLORLOK Technology logo on the package. Use only paper that is
designed for inkjet printers.
When handling paper:
• Hold the paper by the edges; avoid placing your fingerprints on it.
• Do not touch the glossy side of photo paper.
• Store paper flat, away from direct sunlight and heat.
You can use:
• Plain paper — 20 to 24 lb / 75 to 90 gsm
• Photo paper — 6.5 to 12 mils (up to 290 gsm)
• Card stock — 110 lb / 200 gsm, max
• Envelopes — 20 to 24 lb / 75 to 90 gsm
• Transparencies — inkjet variety with white stripe
• Labels — all commercially available inkjet varieties on 8.5 x 11-in. or A4 sheets
Paper sizes
The printer accepts the following paper sizes:
• 4 x 6 in. / 101 x 152 mm
• 4 x 7 in. / 101 x 178 mm
• 4 x 12 in. / 101 x 305 mm
• 5 x 7 in. / 127 x 178 mm
• 7.25 x 8.5 in / 184 x 216 mm
• 8 x 10 in. / 203 x 254 mm
• 8.5 x 11 in. / 216 x 279 mm
• 8.5 x 14 in. / 216 x 356 mm
• A4 (8.27 x 11.69 in. / 210 x 297 mm)
• A5 (5.83 x 8.27 in. / 148 x 210 mm)
• A6 (4.13 x 5.83 in. / 105 x 148 mm)
• B5 (6.93 x 9.48 in. / 176 x 250 mm)
NOTE: Do not load paper smaller than 4 x 6 in. / 101 x 152 mm.
www.kodak.com/go/aiosupport 15
Handling Paper
Paper tray
Output tray
Envelope sizes
Loading paper
Loading plain paper
The printer accepts the following envelope sizes:
• C5 (6.38 x 9 in. / 162 x 229 mm)
• C6 (4.5 x 6.38 in. / 114 x 162 mm)
• DL (4.31 x 8.69 in. / 110 x 220 mm)
• US #7¾ (3.88 x 7.5 in. / 98 x 190 mm)
• US #9 (3.88 x 8.88 in. / 98 x 225 mm)
• US #10 (4.13 x 9.5 in. / 105 x 241 mm)
IMPORTANT: Do not load envelopes with cutout or clear windows.
The paper tray capacity is 200 sheets of plain paper.
To load plain paper:
1. Raise the output tray, and pull out the paper tray.
16 www.kodak.com/go/aiosupport
KODAK ESP Office 6100 Series All-in-One Printer
Left paper-
Front paper-edge guide
edge guide
2. Make sure the left paper-edge guide is to the far left.
3. Move the front paper-edge guide forward.
4. Fan and stack the paper, then insert it into the tray.
5. Move the paper forward until it stops.
6. Move both the left and front paper-edge guides until they touch the paper.
7. Push in the paper tray until it clicks into place, and lower the output tray.
www.kodak.com/go/aiosupport 17
Handling Paper
Paper stop
Output tray extender
Paper tray
Output tray
8. Pull out the output tray extender until it is fully extended.
9. Lift the paper stop.
Loading legal-size paper
The paper tray capacity is 200 sheets of legal-size (8.5 x 14 in. / 216 x 356 mm)
paper.
To load legal-size paper:
1. Raise the output tray, and pull out the paper tray.
18 www.kodak.com/go/aiosupport
KODAK ESP Office 6100 Series All-in-One Printer
Front paper-edge guide
Left paperedge guide
2. Make sure the left paper-edge guide is to the far left.
3. Move the front paper-edge guide forward until it is fully extended.
4. Fan and stack the paper, then insert it into the tray.
5. Move the paper forward until it stops.
6. Move both the left and front paper-edge guides until they touch the paper.
www.kodak.com/go/aiosupport 19
Handling Paper
Output tray extender
Paper stop
7. Push in the paper tray until it clicks into place, and lower the output tray.
8. Pull out the output tray extender until it is fully extended, but do not lift the
paper stop.
20 www.kodak.com/go/aiosupport
Loading photo paper
Paper tray
Output tray
Front paper-edge guide
Left paperedge guide
The paper tray capacity is 40 sheets of photo paper.
To load photo paper:
KODAK ESP Office 6100 Series All-in-One Printer
1. Raise the output tray, and pull out the paper tray.
2. Remove any paper from the tray.
3. Make sure the left paper-edge guide is to the far left.
4. Move the front paper-edge guide forward.
www.kodak.com/go/aiosupport 21
Handling Paper
5. Fan and stack the photo paper, then insert the paper (short side first) into the
tray with the
IMPORTANT: If the photo paper is loaded the wrong way, the ink on your pictures will be
logo side facing up and the glossy side down.
wet and the image quality will be affected.
6. Move the paper forward until it stops.
7. Move both the left and front paper-edge guides until they touch the paper.
8. Push in the paper tray until it clicks into place, and lower the output tray.
NOTE: If you are using 8 x 10 in. / 203 x 254 mm or larger photo paper, output tray
extender until it is fully extended, and lift the paper stop.
22 www.kodak.com/go/aiosupport
Loading...
