Kodak DV-2500H User Manual

DVD PLAYER

DV-2500H

INSTRUCTION MANUALINSTRUCTION MANUAL

INSTRUCTION MANUAL

INSTRUCTION MANUAL

INSTRUCTION MANUAL

INSTRUCTION MANUAL

ENGLISH

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`a

1

IMPORTANT SAFETY PRECAUTIONS .... 2

FEATURES............................................. 5

ABOUT DISCS ....................................... 6

BEFORE OPERATION............................. 8

PREPARATIONS BEFORE OPERATION. 10

Front Panel..................................................... 10

Rear Panel ...................................................... 11

VFD................................................................. 12

Names and Layout of Remote Controls ......... 13

CONNECTIONS ................................... 14

BASIC OPERATIONS............................ 15

Play Discs ....................................................... 15

System Setting................................................ 16

V-Mode .......................................................... 16

USB/CARD ...................................................... 16

Display............................................................ 17

Fast Play......................................................... 18

Slow Play........................................................ 18

Pause/ Step..................................................... 18

Select Audio Language................................... 19

Select Channels .............................................. 19

Select 3D Audio.............................................. 19

MICROPHONE CONTROL.................... 20

Microphone Set up ......................................... 20

PLAYING A DESIRED SCENE............... 21

To skip scenes in a disc................................... 21

Directly moving to a desired title (DVD/VCD) . 21

Playing a disc containing MP3 (or CD) files.... 22

Repeat Play .................................................... 22

Repeating a defined period from A to B ........ 23

Select a Subtitle Language ............................. 23

Searching.........................................................24

PLAY DISCS IN VARIOUS WAYS.......... 25

Select Angle.................................................... 25

Zoom Play....................................................... 25

Book Mark...................................................... 26

Program Play (DVD)........................................ 27

Program Play (VCD)........................................ 28

Digest Play (VCD) ........................................... 29

Playing DivX disc on CD-R (W) ....................... 29

Kodak Picture CD mode.................................. 30

FUNCTION SETTING ........................... 32

Menu Setting...................................................32

Language........................................................ 34

Video.............................................................. 36

Audio ............................................................. 37

Parental...........................................................39

OTHERS............................................... 40

Troubleshooting ............................................. 40

Technical Specifications.................................. 41

TABLE OF CONTENTS

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`1

2

IMPORTANT SAFETY PRECAUTIONS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER­SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and servicing
instructions in the literature accompanying the
appliance.

WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN

OR MOISTURE.

CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

IMPORTANT FOR LASER PRODUCTS

• LASER : This Digital Video Disc Player employs a Laser System. To ensure proper use of this

product please read this owner’s manual carefully and retain for future reference. Should
the unit require maintenance, contact an authorized service location - see service
procedure.

Use of control adjustments or the performance of procedures other than those specified
may result in hazardous radiation exposure.

To prevent direct exposure to the laser beam, do not try to open the enclosure. Visible
laser radiation when open and interlocks defeated.
DO NOT STARE INTO THE BEAM.

• DANGER : Visible laser radiation when open and interlock failed or

defeated. Avoid direct exposure to beam.

• CAUTION : Do not open the top cover. There are no user serviceable parts

inside the Unit; leave all servicing to qualified service personnel.

CLASS 1
LASER PRODUCT

CAUTION: Any changes or modification in construction of this device which are not

expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

ATTENTION: KEEPING THE STATUS OF STOP MORE THAN 5 MINUTES ENTERS SCREEN SAVE MODE. WHEN

THE SCREEN SAVE MODE IS KEPT MORE THAN AN HOUR, THE SET ENTERS STAND-BY MODE.

MACROVISION
This product incorporates copyright protection technology that is protected by U.S patents and

other intellectual property rights. Use of this copyright protection technology must be
authorized by Macrovision, and is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`2

3

IMPORTANT SAFETY PRECAUTIONS

This set has been designed and manufactured to assure
personal safety. Improper use can result in electric shock or
fire hazard. The safeguards incorporated in this unit will
protect you if you observe the following procedures for
installation, use and servicing. This unit is fully
transistorized and does not contain any parts that can be
repaired by the user.

1 READ INSTRUCTIONS

All the safety and operating instructions should be read
before the unit is operated.

2 RETAIN INSTRUCTIONS

The safety and operating instructions should be retained
for future reference.

3 HEED WARNINGS

All warnings on the unit and in the operating
instructions should be adhered to.

4 FOLLOW INSTRUCTIONS

All operating and use instructions should be followed.

5 CLEANING

Unplug this unit from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.

6 ATTACHMENTS/ACCESSORIES

Do not use attachments unless recommended by the
unit’s manufacturer as they may cause hazards.

Caution : Apparatus shall not be exposed to dripping
or splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.

7 WATER AND MOISTURE

Do not use this unit near water- for example, near a
bath tub, wash bowl, kitchen sink or laundry tub, in a
wet basement, or near a swimming pool.

8 PLACEMENT

Do not place this unit on an unstable cart, stand,
tripod, bracket, or table. The unit may fall, causing
serious injury to a child or adult as well as serious
damage to the unit. Use
this unit only with a cart,
stand , tripod, bracket, or
table recommended by the
manufacturer.

8A

A unit and cart combination

should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the video
product and cart combination to overturn.

9 VENTILATION

Slots and openings in the case are provided for
ventilation to ensure reliable operation of the unit and
to protect it from overheating. These openings must not
be blocked or covered. These openings must not be
blocked by placing the unit on a bed, sofa, rug, or other
similar surface. This unit should never be placed near or
over a radiator or heat radiator. This unit should not be
placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.

10 POWER SOURCES

This unit should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult

your video dealer or local power company. For units
intended to operate from battery power, or other
sources, refer to the operating instructions.

11 GROUNDING OR POLARIZATION

This unit is equipped with a polarized alternating ­current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way.

This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the
plug still fails to fit, contact your electrician to replace
your obsolete outlet.To prevent electric shock, do not
use this polarized plug with an extension cord,
receptacle, or other outlet unless the blades can be fully
inserted without blade exposure. If you need an
extension cord, use a polarized cord.

12 POWER-CORD PROTECTION

Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs and the point where they exit from the
unit.

13 LIGHTNING

For added protection for this unit during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and

PORTABLE CART WARNING

(symbol provided by RETAC)

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`3

4

disconnect the antenna or cable system. This will
prevent damage to the unit due to lightning and power
line surges.

14 DISC TRAY

Keep your fingers well clear of the disc as it is closing. It
may cause serious personal injury.

15 OVERLOADING

Do not overload wall outlets or extension cords as this
can result in a risk of fire or electric shock.

16 OBJECT AND LIQUID ENTRY

Never press objects of any kind into this unit through
openings as they may touch dangerous voltage points
or “short-out” parts that could result in a fire or electric
shock. Never spill liquid of any kind on the unit.

17 BURDEN

Do not place a heavy object on or step on the product.
The object may fall, causing serious personal injury and
serious damage to the product.

18 DISC

Do not use a cracked, deformed or repaired disc. These
discs are easily broken and may cause serious personal
injury and product malfunction.

19 SERVICING

Do not attempt to service this unit yourself as opening
or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.

20 DAMAGE REQUIRING SERVICE

Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions.

A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into

the unit.
C. If the unit has been exposed to rain or water.
D. If the unit does not operate normally by following the

operating instructions. Adjust only those controls

that are covered by the operating instructions.

Improper adjustment of other controls may result in

damage and will often require extensive work by a

qualified technician to restore the unit to its normal

operation.

E. If the product has been dropped or the cabinet has

been damaged.

F. When the unit exhibits a distinct change in

performance-this indicates a need for service.

21 REPLACEMENT PARTS

When replacement parts are required, have the service
technician verify that the replacements he uses have the
same safety characteristics as the original parts. Use of
replacements specified by the unit manufacturer can
prevent fire, electric shock, or other hazards.

22 SAFETY CHECK

Upon completion of any service or repairs to this unit,
ask the service technician to perform safety checks
recommended by the manufacturer to determine that
the unit is in safe operating condition.

23 WALL OR CEILING MOUNTING

The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.

24 HEAT

The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.

IMPORTANT SAFETY PRECAUTIONS

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`4

5

FEATURES

HDMI

Audio/Video Digital output
support 1080I ( Interlace), 720P (Progressive) and 480P/576P Video out.

OUTSTANDING SOUND QUALITY

Dolby Digital system developed by Dolby Laboratories and DTS
developed by DTS Inc., features high quality surround sound which can be played
in DVD or CD disc at home, to reproduce high quality sound effects.

HIGH DEFINITION

The unit adopts MPEG2 coding format and brings the high horizontal resolution.

UNIQUE FUNCTIONS

Multi-angle and multi-language bring unique trick functions.
Parent lock makes it easy to control the content of discs.

SCREEN

Ordinary screen and wide screen (16:9) are available.

COMPATIBILITY

The unit can play DVD-video discs, and is compatible with CD, CD-G, CD-R, CD-RW,
PIC-CD, MP3, DVD-R, DVD-RW, DVD+RW.

ZOOM

It can enlarge pictures.

MULTI-FUNCTIONS

Fast forward, fast reverse, forward and reverse slow, frame play, repeat play and
program play.

TIME SEARCH

It can search a specific part on a disc, especially good for watching movies.

RESUME PLAY

It can memorize the position where the disc is stopped and resume playback.

VIDEO OUTPUT

Standard video, S-video output, RGB, HDMI Video mode.

AUDIO OUTPUT

HDMI/ Analog audio output, coaxial and optical digital audio output, can be
connected with the appropriate amplifier to enjoy high-quality sound effects.

KARAOKE

Dual-Microphone input, KARAOKE channel selection.

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`5

6

ABOUT DISCS

PRINCIPLES FOR WRITING

PLAYABLE DISCS

This manual mainly introduces how to use buttons on the remote control.
You may operate the unit if the buttons on the unit have the same or similar names
as or to those on the remote control.

TITLE

The images or music of a DVD are divided into some units, among which title is the
biggest one.
When playing a DVD, the movie is the title.
When playing a CD, the combined tracks make up the title.

STRUCTURE OF DVD STRUCTURE OF CD

DISC

TITLE

CHAPTER

DISC

TRACK

DVD-video Region number 2 or Region number ALL
DVD-R/+R DVD video
DVD-RW/+RW DVD video
DVD-ROM DVD video
CD-G Playback audio/ graphic files
CD-DA Digital audio files
CD-R/ CD-RW Digital audio/ MP3/ JPEG format files
CD-DA/JPEG/MP3 Total disc capacity : over 4M, Each file : under 1M
CD-ROM Digital audio/ MP3/ JPEG format files

NONE PLAYABLE DISCS

DVD-video Different region number
DVD-ROM Files for PC application / Data files
CD-ROM Files for PC application / Data files
CD-MP3 Files under windows format
DVD-RAM All format

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`6

7

ABOUT DISCS

CHAPTER

It is smaller than title among the units of a DVD. A title is made up of several
chapters , and each chapter has a number for search. But some discs may not
have numbered chapters.

TRACK

In a CD, each track has a number to enable search functions.

REGION MANAGEMENT INFORMATION

This unit is designed and manufactured to respond to the Region Management
information that is recorded on a DVD disc. The region number of this player is
“2”. If the region number described on the DVD discs does not correspond to the
Region number of this player, the player will not play this disc. This player will
play DVD discs made for “ALL” regions. Therefore, this player will play DVD discs
marked with labels containing the region number “2” or “ALL”.

(Region 2) (Region ALL)

2

SCENE

The menu pictures, motion and motionless pictures of a CD can be divided into some
parts, these parts are scenes. Each scene has a number for search.

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`7

8

BEFORE OPERATION

SECURITY

• Before operation, check if the voltage of the unit is in line with the local voltage.

• Hold the plug to disconnect it from the mains outlet. Do not pull the power cord.

• When the plug of the unit is connected to the mains outlet, the unit will be still
connected to AC even if the power is turned off.

• Disconnect the plug as soon as liquid or objects enter the unit. The unit can not be
used until being checked by experts.

• Do not open the cabinet as laser rays employed by the unit may damage eyes. Any
servicing should be done by qualified service personnel.

PLACEMENT

• Put the unit where ventilation is good enough to prevent overheating.

• Never put the unit in direct sunlight or near heat sources.

• Put the unit horizontally, never put any heavy object on the unit.

• To protect the pickup, do not put the unit where there is dust. If there is dust on
the pickup, use a cleaning disc to clean it. Paying particular attention to the
operating instructions of the cleaning disc.

CONDENSATION

Moisture will appear on the pickup lens in the following cases:

• The unit is suddenly moved from a cold place to a warm place.

• The unit is put in a room with a heater, or in cold air from an air-conditioner.

• Using the unit in a humid place. In these cases, the unit can not work. Unload the
disc and leave the unit on for about one hour to evaporate the moisture.

CLEANING

• Use a soft cloth with a little neutral detergent to wipe the cabinet, panel and
controls.

Never use abrasive paper, polishing powder, solvent like alcohol or gasoline.

HANDLING DISC

CLEANING DISC

• To keep the disc clean, do not touch the playsides of the disc.

• Do not attach paper or tape to the disc.

• Keep the disc away from direct sunlight or heat sources.

• Store the disc in a disc case after playback.

• Before playback, wipe the disc outward from the centre with clean cloth.

• Do not use any type of solvent such as thinner, benzine, commercially available
cleaners or antistatic spray.

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`8

9

BEFORE OPERATION

CHECK ACCESSORIES

USE REMOTE CONTROL

Check if you have all the accessories after the carton is opened.

1 Open the battery compartment.
2 Insert two AAA batteries, make sure to match "+" and "-" of the batteries to

the marks in the battery compartment.
3 Close the battery compartment.
4 Point the remote control at the remote sensor.

Remote control

AAA batteries

Video/Audio cord

Instruction manual

1. Batteries can last for about 6 months generally. Change the batteries if that does not
work.

2. If the remote control is not used for a long time, remove the batteries to prevent
battery leakage.

- U

M

-

4

+

N

Note:

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`9

10

PREPARATIONS BEFORE OPERATION

FRONT PANEL

! STANDBY/ON button

To switch the unit On or Off when connected to AC power outlet

@ OPEN/CLOSE button

To open or close the disc tray.

# PLAY button

To play the loaded disc. Press this button to go to the preferred item when the menu is
displayed on the TV screen.

$ STOP
% PREV button

To skip back from the current chapter or track.

^ NEXT button

To skip forward to the next chapter or track.

& Microphone Jack 1& 2
* Microphone volume adjustment knob.
( Microphone Echo adjustment knob.
) REMOTE SENSOR

Receives a light signal from the remote control.

1 DISPLAY

Displays operation status.

2 USB port

@! # $ % ^

* ()1 2

&

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`10

11

PREPARATIONS BEFORE OPERATION

REAR PANEL

! S-VIDEO OUTPUT

Connects to TV or monitor equipped with S-VIDEO input. In order to achieve a sharper
and cleaner picture than when connected via VIDEO OUT (composite video).

@ VIDEO OUT

Connects composite video signal to input AV or PHONO sockets of TV or monitor to
achieve high fidelity colour reproduction.

# AUDIO OUT (L/R TRACK)

Two phono sockets for analogue 2 Channel audio in order to a TV or stereo amplifier.

$ HDMI

Audio/Video High definition multimedia digital output terminal.

% DIGITAL AUDIO COAXIAL OUT

Connects digital audio under play mode into an AV amplifier or a receiver equipped with
digital audio decoder for you to enjoy the theatre-quality sound in your home.

^ DIGITAL AUDIO OPTICAL OUT

Connects digital audio under play mode into an AV amplifier or a receiver equipped with
digital audio decoder for you to enjoy the theatre-quality sound in your home.

& EURO AV JACK

If VIDEO OUT phono is not utilized, the SCART socket can be used to connect to a TV set,
monitor or VCR.

* POWER SUPPLY SOCKET WIRE

Creates POWER between wall outlet and the unit.

#

$ % ^ &

! @

*

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`11

12

PREPARATIONS BEFORE OPERATION

VFD

! Recognized DISC TYPE indicator

: DVD

@ Recognized DISC TYPE indicator

: VCD

# PLAY indicator
$ PAUSE indicator
% DISC LOAD/PLAY indicator

This indicator is lit up after
recognizing the disc.

^ DVD/CD/MP3 indicator

Indicates the title, chapter or track
number.

& DVD/CD/MP3 indicator

Indicates the hour.

* DVD/CD/MP3 indicator

Indicates the minutes.

( DVD/CD/MP3 indicator

Indicates the seconds.

) REPEAT MODE indicator

: In case you want to play a

chapter, track, title or disc
repeatedly.

1 DVD AUDIO STREAM indicator

: dts digital out

2 Recognized DISC TYPE indicator

: MP3

3 PBC indicator

This indicator is lit up in selecting PBC
ON while this indicator disappears in
selecting PBC OFF.

4 NUMBER/ CHARACTER indicator

Chapter, track number, and time are
displayed in loading DVD/CD disc,
while track number and time are
displayed in loading MP3.

: Tray is opened

: Tray is closed

: Disc is loaded

: There is no disc in tray

: Disc has some error

5 DVD AUDIO STREAM indicator

Indicates the audio type of the
disc under playing is DOLBY
DIGITAL.

2

4

53

! #@ % ^

& ) 1* (

$

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`12

13

PREPARATIONS BEFORE OPERATION

NAMES AND LAYOUT OF REMOTE CONTROLS

POWER BUTTON

DISPLAY BUTTON

ANGLE

BUTTON

SETUP

BUTTON

TITLE/PBC BUTTON

UP/DOWN/LEFT/
RIGHT DIRECTION
BUTTON

SEARCH BUTTON

MARK BUTTON

PAUSE BUTTON
STEP BUTTON

AUDIO BUTTON

REPEAT BUTTON

CHANNEL BUTTON

VOLUME “+/-” BUTTON

ONE CHAPTER/TRACK
BACKWARD BUTTON

FAST BACKWARD
SEARCH BUTTON

SUBTITLE BUTTON

A-B REPEAT BUTTON

OPEN/CLOSE BUTTON

NUMBER BUTTON

MENU BUTTON

RETURN BUTTON

STOP BUTTON

SYSTEM BUTTON

INTRO BUTTON

ZOOM BUTTON

PROGRAM BUTTON

ONE CHAPTER/TRACK

FORWARD BUTTON

PLAY/ENTER BUTTON

MUTE BUTTON

3D SURROUND BUTTON

FAST FORWARD

SEARCH BUTTON

SLOW BUTTON

Select one of USB/Disc

* After setting the mode by using SETUP menu (for example, NTSC select in NTSC/PAL/AUTO

setup), the setting is kept though you switch the unit off and turn it on.

V-MODE BUTTON

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`13

14

CONNECTIONS

CONNECTED TO A TV AND AN AUDIO AMPLIFIER

Turn off all equipment before operation.
The unit has many kinds of output modes like A/V output, S-VIDEO output and digital
signal output (COAXIAL, OPTICAL). You may select as you need.

#

!

TV

Amplifier

$

Connects either!, @, #+, $+, #+, $+, #+, $+,

#

+ or $+.

2 Speakers

Manufactured under license from Dolby Laboratories."Dolby" and the double-D
symbol are trademarks of Dolby Laboratories. Confidential Unpublished works.

©1992-1997 Dolby Laboratories, Inc. All rights reserved.
"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, Inc.

@

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`14

15

BASIC OPERATIONS

PLAY DISCS

Press "POWER" button on the TV and audio
system, Press "TV/VIDEO" button on the TV, select
VIDEO mode (TV).

Select S-Video mode if using an S-VIDEO
connection.

1

Select the correct audio input on the amplifier.

• Each amplifier is different from another, please
refer to the manual for the amplifier. (e.g.,
connect the audio output of the DVD player to
the DVD audio input of an amplifier.)

2

Press "STAND BY/ON" button on the front panel or " " button on the
remote control to turn the unit on.

3

Press "OPEN/CLOSE " button to open the disc tray and insert the disc
with its label upward. Press "OPEN/CLOSE " button again to close
the disc tray. The unit begins to read the disc. The TV screen shows the
DVD menu and title menu.

• When playing a DVD, DVD menus and titles are displayed on TV
screen.

• In the case of CD, the disc plays in order of its track number.

4

Stop playback.
Press .

5

Press to remove the disc.

6

TV/VIDEO

DVD/LD

The Step2 can be
cancelled if you
do not
connect it to the
amplifier.

N

Note:

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`15

16

BASIC OPERATIONS

SYSTEM SETTING

• When you press the [SYSTEM] button, the TV screen shows
the information as : “Press [SYSTEM] button again.” Press
the [SYSTEM] button again, the video out system changes
as follows.

According to the system of the TV to be connected, set the system of the unit to make it
match the TV.
In STOP mode, press SYSTEM button on the remote control, then choose TV TYPE.

SYSTEM

NTSC

PAL

AUTO

V-MODE (WHEN SELECTING CVBS/RGB/HDMI)

V-MODE

• In case of connecting the component, press the V-MODE on
the remote control to select CVBS / RGB / HDMI. In case of
selecting HDMI, S-VIDEO signal is not output.

When you press the [V-MODE] button, the TV screen shows
the information as : “Press [V-MODE] button again.” Press
the [V-MODE] button again to change the video mode.

When you connect the Composite, picture is not displayed, press the
V-MODE on the remote control to select Composite video.

USB/DISC

Choose one between USB and disc (You can select one only
that is inserted in).

• After inserting USB, press USB/CARD button on the remote
control to select one between USB and disc.

• When you press USB/CARD button, the TV screen shows :
DISC and USB

Move the cursor in the position of desired item by pressing

[œ √…†]

button

and press PLAY button.

USB/CARD

DV- 2500H English for agon 2006.10.25 11:6 PM ˘`16

17

BASIC OPERATIONS

DISPLAY

Press the “DISPLAY” button when playing a disc, the TV screen shows the
information as :

DISPLAY

DVD

VCD 2.0 00:00:41 00:50:28
PBC On

VCD

DVD Video 00:00:35 01:55:28
Title 1/7 Chapter 1/16
Audio 1/2 6Ch Eng
Subtitle Off
Angle 1/1 Bitrate 6.632Mbps

Remain TimeRunning Time

Remain TimeRunning Time

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `17

18

BASIC OPERATIONS

FAST PLAY

When playing disc, you may play it forward fast or reverse it fast to find what you need.

Press to play forward fast. Each
time you press the button, the speed of
picture changes like the right sides.

1

Press to reverse the disc fast.
Each time you press the button, the
speed of picture changes like the
right sides.

2

Press PLAY to play
normally when
playing fast.

The marked FAST
PLAY speed on
owner’s manual
and real fast play
speed can be
different
depending on
which disc you
play.

Press PLAY to
play normally .

Press PLAY to
play normally .

SLOW PLAY

Enjoy slow motions by the following steps.
Press "SLOW" button to play slowly.

SLOW

PAUSE/ STEP

Press PAUSE on the remote control to make the playback pause.
Pressing STEP again moves the picture forward frame by frame.

N

Note:

N

Note:

N

Note:

N

Note:

X2
X4
X8
X16

1

2

3

4

X2
X4
X8
X16

1

2

3

4

1/2 ➝ 1/4 ➝ 1/6 ➝ 1/8

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `18

19

BASIC OPERATIONS

SELECT AUDIO LANGUAGE

You can choose the language according to your choice when playing multi­language DVD.

Press “AUDIO” button, select different languages.

SELECT CHANNELS (VCD only)

You may select the right channel or left channel or stereo from a multi-channel.
Press "CHANNEL" button, the screen show alternately and select the desired

audio channel:

1. Different disc has different languages

2. You can press "AUDIO" button to choose the language you want when you play
multi-language DVD discs.

CHANNEL

AUDIO

L-Mono R-Mono

STEREO

Mix-Mono

You can use channel function when you play the disc, you can choose mono
audio output ( left or right channel ), stereo or mix-mono

*Attention:

Please select the AUDIO language in SETUP menu to keep the setting!

N

Note:

N

Note:

1/2 6Ch Eng

This function outputs 3D effects on the stereo audio analog output where 3D
effects are broken down.

Press [3D] button.

Every time you press [3D] button, the 3D
sound toggles between 3D on -> 3D off.

SELECT 3D AUDIO

3D

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `19

20

MICROPHONE CONTROL

MICROPHONE SET UP

Turn on Microphone Switch.

1

Connect the Microphone to the input socket on the front panel.

2

Insert the Karaoke disc (label side uppermost) and select track to
play.

3

Adjust the microphone level & echo on the front panel of DVD.

4

Select either the Left, Right, Mixed or Stereo mode, using channel
button on the remote control.

5

Adjust to a comfortable volume using the volume (+/-) button on
the remote control of the DVD player and the volume on the
Monitor/TV.

6

(not supplied)

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `20

21

PLAYING A DESIRED SCENE

TO SKIP SCENES IN A DISC

Press √√■to move to the next chapter (or track).

The current chapter (or track) moves to the next chapter (or track).

1

Press ■œœ to move to previous chapter (or track).

The current chapter (or track) moves to the previous chapter (or track) or
first scene of current chapter (or track).

2

DIRECTLY MOVING TO A DESIRED TITLE (DVD/VCD)

Press the [TITLE/PBC] or [MENU]
button.

A list of the titles on the disc is
displayed.

If using some disc, the menu screen
will appear only when the disc has PBC
function and PBC ON is activated.

1

Press the [PLAY] button after pressing the [œ √…†] or number
button to select the desired title.

The selected title now starts playing.

2

Some movie discs may contain multiple titles. If the disc has a movie title menu
recorded on it, the [TITLE/PBC] button can be used to select the movie title. Details of
operation may differ depending on the disc used.

PLAY MOVIE

PLAY MOVIE

SETUP
SCENE SELECTION
SPECIAL FEATURES

You can select
the desired title
directly by using
number button.

* In the case of PBC play, press RETURN to return to the sub-menu, press

it again to return to the home menu.

N

Note:

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `21

22

PLAYING A DESIRED SCENE

PLAYING A DISC CONTAINING MP3 (or CD) FILES

When a MP3 disc is loaded,
MP3 menu screen is displayed
automatically depending on
MP3 disc’s folder structure.

1

Use

[œ √…†]

button to
select the folder you want to
play, and press the [PLAY]
button.

2

Use [œ √…†] button to select a MP3 file and press the PLAY
button then play will start automatically. When you know the file
number, enter the MP3 file number using the numeric buttons on
the remote control and then press [PLAY] button.

3

Press √√■on the remote control to choose next file. Press■œœ for
previous file.

When you know the file number, enter MP3 file number using the
numeric buttons on the remote control and then press [PLAY]
button.

4

9268-2
AAFALLROAD12
ALL_NITE
AMEILEENDONA
AMFUNKYFLOW
AMPOPPIESDAI
AMPOPPI2
AMPOP

√√

00 : 00 : 26

17/76 /mp3/04 -- -- - - --.MP3

Filter

Repeat : Off
Mode : Normal

Music Playing

This button allows you to see the file lists under the folder.

REPEAT PLAY

When play a disc, this function can be used to repeatedly play a title, chapter,
track or disc.

Press "REPEAT" button, the screen shows orderly.

REPEAT

Repeat Chapter

Repeat Title

• DVD

• CD/ MP3

Repeat single

Repeat

folder

Repeat

Off

Repeat

Off

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `22

23

PLAYING A DESIRED SCENE

You may press A-B to enjoy some parts repeatedly when playing a disc.

1. Press “A-B” to set a starting point A.

2. Press “A-B” twice to an end point B.
Afterwards, the unit plays from A to B.

3. Press “A-B” three times to remove A-B repeat.

A-B

Rep

A -

Rep

A - B

Rep AB

Off

REPEATING A DEFINED PERIOD FROM A TO B

This function does
NOT apply to
MP3.

N

Note:

SELECT A SUBTITLE LANGUAGE

When play a multi-subtitle DVD, you may select one subtitle to show it on the
screen.

Keep pressing [SUBTITLE] button till the
user’s preferred language appears.

If a DVD disc includes subtitle information, every time
the user presses [SUBTITLE] button, ENGLISH, FRENCH, SPANISH
and others appear one by one.

1

Remove the subtitle.
Press SUBTITLE until the screen shows "Off".

2

SUBTITLE

1. For some discs,
subtitles cannot
be removed.

2. Subtitle
function is only
available for
some discs with
subtitle
recorders.

N

Note:

1/8 Eng

Total Subtitle

Current Subtitle

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `23

24

PLAYING A DESIRED SCENE

■ Using the SEARCH button you may play a disc at a desired Title, Chapter
or Time.

Press the [SEARCH] button to select SEARCH mode.
Press … or † button to select title, chapter or time item.
Enter title number, chapter number or time by using numeric buttons directly and

then press PLAY to confirm.

SEARCHING

SEARCHING D

SEARCHING D

VD WITH A TITLE/CHAPTER NUMBER OR A TIME

VD WITH A TITLE/CHAPTER NUMBER OR A TIME

• SEARCH
functionality
depends on
different DVD
disc's format.
Some DVD discs do
not allow SEARCH
function.

• SEARCH does NOT
function during
Program playback.

N

Note:

■ Using the SEARCH button you may play a disc at a desired Track or Time.

Press the [SEARCH] button to select SEARCH mode.
Press … or † button to select track or time item.
Enter track number or time by using numeric buttons directly and then press PLAY

to confirm.

SEARCHING CD WITH A DISC /TRA

SEARCHING CD WITH A DISC /TRA

CK TIME OR TRA

CK TIME OR TRA

CK NUMBER

CK NUMBER

Title - - -
Chapter - - -
Time - - : - - : - -

Search

Track - - -
Time - - : - - : - ­Disc Time - - : - - : - -

Search

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `24

25

PLAY DISCS IN VARIOUS WAYS

SELECT ANGLE

Some discs have images with different screen angles, you may select among
them. For example, when you watch a running train, you may select to watch it
from the front, the left window or the right window without stopping it.

Keep pressing [ANGLE] button till the
preferred angle appears.

ANGLE

Angle 2/4 (select ANGLE2)

Angle 3/4 (select ANGLE3)

Angle 4/4 (select ANGLE4)

Multi Angle
function is limited
to a DVD disc
supporting multi
angle information.

ZOOM PLAY

This function can be used to enjoy a motion or motionless picture.

Press "ZOOM" button when playing, the
screen shows orderly:

1

Press "UP/DOWN/LEFT/RIGHT“[

œ √…†

]

button to move the enlarged picture.

2

ZOOM

N

Note:

1 2 3 Off

1/4

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `25

26

PLAYING A DESIRED SCENE

If you erase a
book mark
function, press
“RETURN”
button.

BOOK MARK

Storing a marker in the memory

Press MARK during playback mode and press PLAY at the starting
point to be viewed (listened to) again.

Press … or † button to select another book mark item.

1

N

Note:

■ Storing a MARKER in the DVD memory is similar to marking your page in a
book. It allows you to quickly return to any point on the disc.

Recalling/ Clearing a marker

Press MARK during playback. Press …

or

† to select the marker to

be recalled/ cleared.

Press PLAY to recall a marker. Or press RETURN to clear a marker.
Play resumes from the point corresponding to the selected marker,
or the selected marker is cleared.

2

Bookmark 1 - - : - - : - ­Bookmark 2 - - : - - : - ­Bookmark 3 - - : - - : - -

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `26

27

PLAY DISCS IN VARIOUS WAYS

• Some DVD discs
do not allow
programming.

N

Note:

You may program the title and chapter on a disc and play them in the
programmed order.

• You can clear
all programmed
item by press
PLAY button on
the position of
“Clear All”.

• You can clear
from the latest
programmed
item by press
PLAY button on
the position of
“Clear”.

N

Note:

PROGRAM PLAY (DVD)

Press "PROGRAM" button, the screen shows:

1

Press … or † button to select the desired title number.
Press PLAY. Then chapter screen appears.

You can also select the desired chapter number by using … or
† button. Press PLAY.

2

Program

Title 1
Title 2
Title 3
Title 4
Title 5
Title 6

1
3
5
7
9
11
13
15

2
4
6
8
10
12
14
16

†

Play Clear

Clear all

Program

..
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5

1
3
5
7
9
11
13
15

2
4
6
8
10
12
14
16

†

Play Clear

Program

..
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5

1 T1C2
3
5
7
9
11
13
15

2 T2C2
4
6
8
10
12
14
16

†

Play Clear

Clear all

The selected title/chapter number will display at the right sides on
the screen.

After the programming is finished, press direction [œ √…† ]
button to select "Play", press "PLAY" button to start playing.

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `27

28

PLAY DISCS IN VARIOUS WAYS

You may program the track on a disc and play them in the programmed order.

PROGRAM PLAY (VCD)

Press "PROGRAM" button, the screen shows:

1

• Single track
disc can not
be
programmed.

N

Note:

• You can clear all programmed item by press PLAY button on the position of
“Clear All”.

• You can clear from the latest programmed item by press PLAY button on the
position of “Clear”.

N

Note:

Press … or † button to select the desired track number.
Press PLAY.

2

Program

Track 1
Track 2
Track 3
Track 4
Track 5
Track 6

1
3
5
7
9
11
13
15

2
4
6
8
10
12
14
16

†

Play Clear

Clear all

Program

Track 1
Track 2
Track 3
Track 4
Track 5
Track 6

1 T3
3 T1
5
7
9
11
13
15

2 T4
4
6
8
10
12
14
16

†

Play Clear

Clear all

The selected track number will display at the right sides on the
screen.

After the programming is finished, press direction [œ √…† ]
button to select "Play", press "PLAY" button to start playing.

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `28

29

Each time you press INTRO button when the unit is playing a disc,
digest playback mode changes as below.

1

2

When you select “Intro on”, the player will play 10 seconds each
track.

DIGEST PLAY (VCD)

Intro on

Intro off

INTRO

PLAY DISCS IN VARIOUS WAYS

PLAYING DivX DISC ON CD-R (W)

■ DivX refers to a new format of Audio/Video files available for playback
over the internet because of the popularity to download music from DivX
websites on to ones computer.

When a DivX disc is loaded, the DivX menu screen is displayed
automatically depending on DivX disc’s folder structure.

1

Move the cursor to DivX file you want to play and press play button.

2

On your disc, if there are many subtitles, press the [SUBTITLE] button for
selecting subtitle you want to display.

3

YOUR DVD PLAYER CAN PLAY;

- Picture DivX version: DivX 3.11, 4.x, 5.x, XviD, ISO-MPEG4,

DivX PRO( Excluding QPEL and GMC)

- Subtitle file extension : It can support Smi, Srt, Sub, TXT.

- Subtitle Support language: It can display ENGLISH and some languages.

• In order to recognize a DivX subtitle normally, the DivX subtitle language in
Language menu should be set to the corresponding national language. (refer
to “DivX subtitle” in page 34)

N

Note:

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `29

30

PLAY DISCS IN VARIOUS WAYS

About Kodak Picture CD

A Kodak Picture CD has the size and shape of a regular CD. You can order a
KODAK Picture CD simply by checking the box on the photo finishing
envelope when you drop off a roll of film (35mm or Advanced Photo System
(APS) color print film) at the time of processing in Kodak Express store
displaying "Kodak Picture CD" sign. When your order is returned, you receive
your prints, negatives, and your full roll of pictures safely stored on you
KODAK Picture CD. Each KODAK Picture CD brings you the tools to enhance,
share and manage your pictures on your computer.
Now, you can playback Kodak Picture CDs on our DVD players and view your
pictures on your TV in the comfort of your living room.

Kodak Picture CD mode

Playing back your Kodak Picture CD

The new feature enables the decoding of JPEG files from a Kodak Picture CD
disk.

When a Kodak Picture CD has been loaded in the player, an automatic slide
show will be launched.

Each picture in the Kodak Picture CD will be displayed consecutively in a
slide-show fashion and will be scaled to fit in the whole TV screen.

Press PAUSE button to display an image indefinitely.
Press SKIP (

■

œœ √√

■

) button to view the next or previous picture.

Press PLAY button to resume the slide show.

IMG_0248
IMG_0249
IMG_0250
IMG_0248
IMG_0248
IMG_0248

17/76 /JPG/2003_BAT (IMG_0248).JPG

Filter

Repeat : Off
Mode : Normal

W: 640 H:480

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `30

31

PLAY DISCS IN VARIOUS WAYS

Image rotation

Press ANGLE button to rotate a picture.
These operations are allowed only when a picture is being displayed normally
and will be cancelled automatically when a new picture is displayed.

Zoom

Press ZOOM button to execute zoom function and select the zoom enlarging
scale.

In zoom mode, Press [œ √…† ] button to move the picture,to adjust the
picture to be displayed on the screen. With zoom mode off, the next picture
will be scaled to normal fitting to the whole TV screen.

Press PLAY button to cancel the zoom and resuming to the slide show.

JPEG file format (limitations)

• JPEG file of CMYK color mode is not supported.

• The range of pixels should be not exceeding 3840 pixels x 3840 pixels, in
order to achieve the best performance.

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `31

32

32

FUNCTION SETTING

MENU SETTING

Various features of the player can be adjusted in the SETUP menu:

OSD Language : English
Subtitle : Off
DivX subtitle :

Western European
Audio : Auto
Disc Menu : Auto

TV Display : Normal LB
TV Type : PAL
Angle mark : Off
Captions : Off
Screen Saver : On
HD Resolution : Auto
HD JPEG mode : Off

Digital Output : LPCM
DownMix : LT/RT
Dual Mono : Stereo
Dynamic : Off

Parental Control : Adult

Set Password

Use Default Settings

OSD Language

English
Français
Español
Deutsch
Italiano
Nederlands
Portuguese

Digital Output

1

SETUP button

2

Play or √button

Language

Video

Audio

Parental

✓

TV Display

TV Type

NTSC
PAL
AUTO

✓

…

or

†

Parental Control

Enter Password

Normal LB
Normal PS
16:9 Wide

✓

Off
LPCM
Bitstream

✓

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `32

33

33

FUNCTION SETTING

BASIC NAVIGATION

To navigation through the setting on the screen, use the direction [œ √…† ] buttons to scroll
through the list of settings and use “PLAY” button to select the high lighted function.

SETUP MENU

Press the SETUP button to enter the On Screen Display and to exit at any time. In each of the
menus, selecting MAIN PAGE (SETUP menu) will immediately return you to the initial screen.

Subtitle

Audio

Disc Menu

DownMix

LT/RT
Stereo

Dual Mono

Stereo
L-Mono
R-Mono
Mix-Mono

Dynamic

Off
On

English
Français
Español
Deutsch
Italiano
Nederlands
Portuguese
Off

English
Français
Español
Deutsch
Italiano
Nederlands
Portuguese
Auto

English
Français
Español
Deutsch
Italiano
Nederlands
Portuguese
Auto

…

or

†

…

or

†

…

or

†

…

or

† …

or

† …

or

†

✓

DivX subtitle

Unicode (UTF-8)
Western European
Turkish
Central European
Cyrillic
Greek
Hebrew
Arabic
Baltic

…

or

†

✓

✓

✓

✓

✓

✓

HD Resolution

HD JPEG mode

Off
On

✓

Auto
480P/576P
720P
1080i
1024x768
1366x768

✓

Angle Mark Captions

Screen Saver

…

or

†

…

or

†

…

or

†

…

or

†

…

or

†

Set Password

Enter New Password

1. Kids Safe

2. G

3. PG

4. PG-13

5. PG-R

6. R

7. NC-17

8. Adult

Use Default Settings

Yes No

…

or

†

…

or

†

✓

†

Off
On

✓

Off
On

✓

Off
On

✓

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `33

34

FUNCTION SETTING

Language

OSD Language

When select a language, the screen show this language.

For example, if you select ENGLISH, the OSD is in English.

“OSD” means
“On Screen
Display”.

N

Note:

SUBTITLE

• Selecting Subtitle language.
Please set it as the preferred language. In case the subtitle language is set and
recorded in the DISC, it is automatically played in the set language in every
playing. For example, English is set and recorded as subtitle language in the
DISC, it is played in English.

DivX SUBTITLE

• Selecting DivX Subtitle language.
Please set it as the preferred language. In case the DivX subtitle language is set and
recorded in the DISC, it is automatically played in the set language in every
playing. For example, English is set and recorded as subtitle language in the
DISC, it is played in English.

The default is Western European.

Each DivX subtitle option supports related languages as follows.

• Unicode (UTF-8): supports English, French, Spanish, German, Italian, Dutch and
Portuguese. 7 kinds languages for DivX subtitle.

• Western European: supports Albanian, Breton, Catalan, Danish, Dutch, English,

Faroese, Finnish, French, Gaelic, German, Icelandic, Irish,
Italian, Norwegian, Portuguese, Spanish and Swedish.

• Turkish: supports Albanian, Danish, Dutch, English,Finnish, French, Gaelic,

German, Italian, Kurdish (Latin), Norwegian, Portuguese, Spanish,
Swedish and Turkish.

• Central European: supports Albanian, Croat, Czech, Dutch, English, German,

Hungarian, Irish, Polish, Romanian, Slovak, Slovene and
Sorbian.

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `34

35

AUDIO

• Selecting an audio language.
Set it as the preferred audio language. In case the audio language is set and
recorded in the DISC, it is automatically played in the set language in every
playing. For example, English is set and recorded as audio language in the
DISC, it is played in English.

DISC MENU

• Selecting Disc Menu language.
Please set it as the preferred DISC MENU language. In case the DISC MENU
language is set and recorded in the DISC, it is automatically played in the set
language in every playing. For example, English is set and recorded as a DISC
MENU language in the DISC, it is played in English.

• Cyrillic: supports Bulgarian, English, Macedonian, Moldavian, Russian,
Serbian and Ukrainian.

• Greek: supports English and modern Greek.

• Hebrew: supports English and modern Hebrew.

• Arabic: supports Arabic.

• Baltic: supports Baltic.

• Vietnam: supports Vietnamese.

FUNCTION SETTING

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `35

36

Video

TV TYPE

TV DISPLAY

You may select according to the colour system of the TV to be connected.

• Select "NTSC" for a NTSC TV.

• Select "PAL" for a PAL TV.

• Select "Auto" for a multi-system TV.

Normal PS

This is selected when the unit is
connected with a normal TV.
Wide-screen images are shown on the
screen, but with some parts cut
automatically.

1

1

Normal LB

This is selected when the unit is
connected with a normal TV.
Wide-screen images are shown on
screen, with black belts on the top and
bottom.

2

2

16:9 WIDE

This is selected when the unit is
connected with a wide-screen TV.

3

3

ANGLE MARK

This only works when there is an angle mark on the disc.

• Select "ON", the screen shows the mark when playing a DVD.

• Select "OFF", the mark is not shown.

FUNCTION SETTING

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `36

37

FUNCTION SETTING

HD JPEG MODE

Select HD JPEG mode to On or OFF.

HD Resolution

The HD Resolution menu enables you to select the desired HD Resolution used for
the video output. There are five Resolution mode.
The default is Auto.

SCREEN SAVER

Start the screen saver, the screen saver image appears when the unit stops
or the image is motionless for a few seconds. This saver can keep the
screen from being damaged.

CAPTIONS

The hidden subtitle is shown or turn off.

DIGITAL Output

• Bitstream

Select this when the DVD player is connected with a power amplifier through
optical or coaxial port. Please refer to the page 14. when a Dolby Digital DVD,
DTS DVD or MPEG DVD is played, select this, the coaxial or optical port will
output in the corresponding digital format (source code). The power amplifier
to be connected must have Dolby Digital, DTS and MPEG DVD is played, the
optical or coaxial port will output in PCM 2-channel format.

• LPCM

Select this when the DVD player is connected with a TV or a power amplifier
through audio cord.

• OFF

No signal is output from the coaxial, optical port.

Audio

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `37

38

FUNCTION SETTING

Down Mix

Select Down Mix mode to LT/RT or Stereo.

Dynamic

Set "Off" to view a program in the dynamic range as recorded in disc. To
hear loud sound softer and soft sound louder, set "On".
The default is Off.

Dual Mono

This is the output mode of the L and R signals of the set audio output. If it
is set to "MIX MONO", the function only works when the DVD being
played is 2.0-channel.

• STEREO

Choose this option, the audio output should be dummy stereo signal.

• L-MONO

• R-MONO

• MIX-MONO

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `38

39

FUNCTION SETTING

PARENTAL

PARENTAL CONTROL

The Parental Control feature allows you to prevent DVDs from being played
based on their ratings or to have certain discs played with alternative scenes.
You can set the Rating Level from ‘1. Kid Safe’ to ‘8. Adult’.

The content of a disc with lock function is evaluated by grades. You can select
an age grade as your need.

Example: Select “1. Kid Safe”, the scenes of violence inadvisable to children are

not played.

For adults, the screen suggests you enter the code after pressing “PLAY”
button, you can watch if the code is right.

The password is
set by yourself.

The password is
3308 when the
unit is turned on
initially or you
forget the
password.

N

Note:

N

Note:

SET PASSWORD

Select "SET PASSWORD" in Parental menu to setup password.
Press PLAY button, then Enter password screen appears.

Input a password according to the screen.

Use Default Settings

Each function setting returns to the factory initial status if you select “Yes”.

Use Default Settings

Yes No

Set Password

Enter New Password

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `39

40

OTHERS

TROUBLESHOOTING

If you experience the following problems while using the unit, this
troubleshooting guide can help you.

• NO SOUND

- Check if the unit is connected securely.

- Make sure you operate the TV or amplifier correctly.

• NO IMAGE, IMAGE ROLLS AND NO COLOUR

- Check if the unit is connected securely.

- Make sure you operate the TV correctly.

- Make sure you set the colour system correctly.

• BAD SOUND QUALITY

- Make sure the audio output mode is set correctly.

- Make sure the audio connection between the unit and amplifier is right.

• DISC CAN NOT BE PLAYED

- There is no disc in the unit.

- Insert the disc on the disc tray properly with the label side up.

- Clean the disc.

- Moisture has condensed in the unit.
Remove the disc and leave the unit on for about one hour.

• NO MICROPHONE SOUND

- Switch on the microphone.

- Turn the MIC LEVEL knob clockwise.

• MICROPHONE DISTORTION

- Keep the microphone far away from the speaker

- Turn down the volume

- Turn down the volume of microphone.

• REMOTE CONTROL DOES NOT WORK

- Remove barriers between the remote control and the unit.

- Replace the batteries with new ones.

- Point the remote control at the remote control sensor of the unit.

•

ATTENTION: KEEPING THE STATUS OF STOP MORE THAN 5 MINUTES ENTERS SCREEN SAVE MODE. WHEN

THE SCREEN SAVE MODE IS KEPT MORE THAN AN HOUR, THE SET ENTERS STAND-BY MODE.

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `40

41

OTHERS

Notes : Design and specifications in this instruction manual are subjected to change without prior notice to

improve quality and function.

TECHNICAL SPECIFICATIONS

Laser

Video

Frequency response

Signal/noise ratio

output level : 2.0 + 0/-0.2Vrms
(Load impedance : 1.0KΩ)

output level : 2.0 + 0/-0.2Vrms
(Load impedance : 1.0KΩ)

output level : 0.5 ± 0.1Vp-p
(Load impedance : 75Ω)

output level : 1.0 ± 0.1Vp-p
(Load impedance : 75Ω, imbalance, negative
polarity)

output level : brightness (Luma) 1.0 ± 0.1Vp-p
chromaticity (Color) 0.286 ± 20%
(Load impedance : 75Ω)

100-240V~, 50Hz/60Hz 12W

430 x 43 x 263 mm

2.9Kg / 2.2Kg

wavelength 650nm

PAL/AUTO/NTSC

20Hz ~ 20KHz (±1dB)

≥

90dB

≥

85dB ( 1KHz)

≥

80dB ( 1KHz)

Channel separation

Dynamic range

Output

Audio

Output

Video

Analog

Digital

Composite

S-video

Power

USB slot (only USB Flash disc)

Input Terminals

RGB

Body (W x H x D)

Packing

Dimensions

Weight (Gross/ Net)

492 x 100 x 372mm

0.5 Vp-p 75% white

DV- 2500H English for agon 2006.10.25 11:6 PM ˘ `41
