User’s Guide

KODAK DP2000 Digital Projector

with KODAK Image Manager Software

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide r easonable pr otecti on against harmfu l interfer ence when the equipment i s operated in a commer ci al environment. This equipment generates, uses, and can r adia te radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause har mf ul interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Canada

This Class A digital apparatus c om plies with Canadian ICES-003.

Cet appareil numérique de la classe A est c on for me à la norme NMB-003 du Can ad a.

Safety Certifications

UL, CUL, TÜV, NOM

EN 55022 Warning

This is a Class A product. In a dome stic environment it may cause radio interference, in wh i ch case the user may be required to take adequate measures. The typical use is in a conference room, meeting room or auditorium.

Declaration of Conf ormity

Manufacturer: Eastman Kodak Company Rochester, New York 14650 USA

We declare under our sole responsibilit y that the KODAK DP2000 Digit al Projector conforms to the followin g di recti ves and norms:

Directive 89/336/EEC, Amended by 93 /68/EEC EMI: EN 55022 (1992) Class A EMC: EN 50082-1 (1992)

IEC 801-2, IEC 801-3, IEC 801- 4 Directive 73/23/EEC, Amended by 93/ 68/EEC Safety: EN 60950: 1992 + A1 + A2 + A3: 1995

July, 1999

Australian Certification C-tick mark

Table of Contents

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Safety Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Important Operating Considerations . . . . . . . . . . . . . . . . . . 2

Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Image Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Unpacking the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Projector Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Usage Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

If You Need Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Setting u p the Pr ojector . . . . . . . . . . . . . . . . . . . . . . 11

Positioning the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Starting the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Turning Off the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Using the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Basic Image Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Adjusting the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

The Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using the Keypad and Remote Control . . . . . . . . . . . . . . . 23

Using the On-Screen Menus . . . . . . . . . . . . . . . . . . . . . . . . 25

Kodak Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Maintenance & Troubleshooting . . . . . . . . . . . . . . . 37

Cleaning the Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Replacing the Projection Lamp . . . . . . . . . . . . . . . . . . . . . . 38

Replacing the Batteries in the Remote Control . . . . . . . . . 41

Using the Kensington Lock . . . . . . . . . . . . . . . . . . . . . . . . . 41

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

User’s Guide KODAK DP2000 Digital Projector

Appendix A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Appendix B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Portable and Laptop Activation Chart . . . . . . . . . . . . . . . . 49

Appendix C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Using Video Mirroring with a PowerBook Computer . . . . 59

Appendix D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Projected Image Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Please read and follow all safety instructions provided before using your new projector. Failure to comply with safety instructions may result in fire, electrical shock, or personal injury and may damage or impair protection provided by equipment. Please save all safety

instructions.

Safety Definitions

• Warning: Statements identify conditions or practices that could

result in permanent personal injury.

• Caution: Statements identify conditions or practices that could

result in damage to your equipment.

Safety Symbols

Attention: For information ab out use of a feature , please ref er to this User’s Guide.

Warning: Hot surface. Do not touch.

Safety Instructions

An arrow pointing to the lamp door on the projector.

User’s Guide KODAK DP2000 Digital Projector

Safety Terms

• Warning: Don’t look directly into the lens when the projector is

turned on.

•Warning: To replace the la mp, turn the pow er off and

unplug the power cord. To avoid burns, wait 30 minutes before opening the lamp door. Follow all instructions provided in this User’s Guide.

•Warning: Please use the power cord provided. Connect

the power cord to a receptacle with a protective safety (earth) ground termina l.

• Warning: Refer all service to q ualified service personnel. Servic -

ing your own projector will void the warranty. See “If You Need Assistance” on page 8 for the customer service contact information.

• Caution: Don’t block ventilation openings.

• Caution: Don’t set liquids on the projector. Spilled liquids may

damage your projector.

• Caution: Don’t place the projector on a hot surface or in direct

sunlight.

• Caution: Do not drop the projector. Transport the projector in a

Kodak-approved case.

Important Operating Considerations

Do not place the projector on a tablecloth or other soft covering that may block the vents. In the unlikely event of the bulb rupturing, thoroughly clean the area behi nd the proj ect or and di scard any edible items placed in that area.

Do not place obje cts in this area behind the projector

Battery Use

Read and follow a ll warnings and instructions supplied by the battery manufacturer .

Keep batteries away from children. Store batteries in their original packaging. When inserting batteries, verify that the (+) and (-) terminals are

aligned co rrectly. Replace all batteries of a set at the same time. Do not mix new batteries with used ones. Do not use batteries of different chemistries, capacities, brands or

sizes together. Leakage could result. Do not disassemble, recharge, or short-circuit batteries. Do not subject batteries to high temperature or fire. Discard used batteries according to all applicable local and national

regulations. Utilize established community battery recycling programs where they are availab le. Consul t battery man ufacturers for additional information for disposing of batteries.

Safety Instructions

In the unlikely event of contact with b attery electrolyte, customers in the U.S. can contact the Kodak I nformation Center (KIC) at 1-800-242-2424. U.S. customers can also contact KIC for information regarding electrolyte removal from KODAK product components.

Customers outside the U.S. can contact their local Kodak Customer Service representative.

The KODAK DP2000 Digital Projector is specifically designed for the mobile presenter. It packs XGA 1024 x 768 graphics with

16.7 million colors into a small, 4.8 pound package. It generates

crisp, clear images using Digital Light Processing™ (DLP) technology. The DP2000 is easy to connect, easy to use, easy to transport, and easy to maintain.

Included with the DP2000 is Kodak’s exclusive Image Manager feature. W ith thi s feature you can sel ect the ima ge display s etting bes t suited for your specific presentation material and projection environment.

Image Resolution

The XGA resolution of the DP2000’s projected image is 1024 x 768. The projector cannot compress screen resolutions above 1024 x 768. If your computer’s screen resolution is higher than 1024 x 768, reset it to a lower resolution before you connect the projector.

The DP2000 automatically expands 640 x 480 and 800 x 600 images to 1024 x 768. You can display these images at their native resolutions by tu rning of f t he Auto Resize featu re. See “A uto Resi ze” on page 28 for more information.

Introduction

Compatibility

The projector is compatible with a wide variety of computers and video devices, including:

• IBM-compatible computers, including laptops, up to 1024 x 768 resolution.

• APPLE MACINTOSH and POWERBOOK computers up to 1024 x 768 resolution.

• Most standard VCRs, DVD players, camcorders and laser disc players.

User’s Guide KODAK DP2000 Digital Projector

Unpacking the Projector

The projector comes with the items shown here. Check to make sure that all are included. Contact your dealer of KODAK products immediately if anything is missing.

1. Digital projector and lens cap 6. VESA computer cable

2. Soft carry case 7. Audio cable adapter

3. Remote control 8. Audio cable

4. Power cords (U.S., U.K, Euro) 9. Composite video cable

5. User’s Guide, Quick Start Guide, and Online User Guide CD

10.

11.

USB mouse cable PS/2 mouse cable

Projector Features

speaker

keypad

zoom ring

Introduction

Hand grip

KENSINGTON Lock

focus ring

Usage Guidelines

• Do not look direc tly into the projection lens when the la mp is turned on. The bright ligh t may harm your eyes.

• Do not block the grills on the projector. Restricting the air flow can cause it to overheat and turn off. If this happens, you must wait a minute before attempting to turn it back on.

• Handle the projector as you would any product with glass components. Be especially careful not to drop it.

• Avoid leaving the projector in direct sunlight or extreme cold for extended perio ds of time. If this happens, allow it to reach room temperature before use.

• Transport the projector in a Kodak-approved hard or soft case.

connector panel

power cord connector

User’s Guide KODAK DP2000 Digital Projector

If You Need Assistance

The first place to look for help is in “Maintenance & Troubleshooting” on page 37. But you can also get help online, by fax, or by phone.

Online Services

Contact Kodak via:

World Wide Web http://www.kodak.com

America Online (keyword) KODAK CompuServe GO KODAK Kodak Internet List Server photo-cd@info.kodak.com; or

Faxed Information

Kodak offers automated support by fax:

(click on Service and Support)

ftp.kodak.com

U.S. and Canada 1-800-508-1531 Europe 44-0-131-458-6962 U.K. 44-0-131-458-6962

Customer Support

If you have questions concerning the operation of your KODAK projector , you can spea k directly t o a customer su pport represent ative. Have the projector se rial number ready, and be at your computer with your projector when you call.

In the U.S. and Canada call toll free, 1-888-375-6325, between the hours of 9:00 a.m. and 8:00 p.m. (Eastern Standard Time) Monday through Friday.

The International Toll Line is +44 (0) 131 458 6714. In Europe ca ll

Austria/Osterreich 0179 567 357 Germany/Deutschland 069 5007 0035 Spain/Espana 91 749 76 53 Belgium/Belgique 02 713 14 45 Ireland/Eire 01 407 3054

Introduction

Sweden/Sverige 08 587 704 21 Denmark/ Danmark 3 848 71 30 Italy/Italia 02 696 334 52 Switzerland/Schweiz/Suisse 01 838 53 51 Finland/Soumi 0800 1 17056 Netherlands/Nederland 020 346 9372 UK (National Line) 0870 2430270 France 01 55 1740 77 Norway/Norge 23 16 21 33 1 Int. Fax Line +44 (0) 131 458 6962

User’s Guide KODAK DP2000 Digital Projector

Warranty

This product is backed by a limited two-year warranty. The details of the warranty are printed at the back of this manual. A longer term warranty can be purchased from your dealer of KODAK products.

Setting up the Projector

This section describes how to:

• determine where to position the projector

• connect the projector to a computer or a video player

• turn on and turn off the projector

If you are experienced in setting up presentation systems, use the Quick Start card that came with the KODAK DP2000 Digital Projector. Otherwise, follow the procedures described here.

Positioning the Projector

Note: If you want to p roject from be hind a transl ucent screen, set up

the projector behind your screen. See “Rear Projection” on page 31 to reverse the image.

1. Make sure your projector is on a flat surface. It must be within 10 feet (3 m) of your power sourc e and wi th in 6 f eet (1.8 m) of your computer.

2. Position the projector the desired distance from the screen.

• The distance from the lens of the projector to the screen and

the zoom setting det er m ine the size of the projected image as shown here. For more information about image sizes at minimum and maximum zoom settin gs, see “Projec ted Image Size” on page 61.

(

)

7. 8

(

2. 5

(

)

5 ft.

1.5 m

)

12 ft.

3.7 m

)

20 ft. 6 m

)

3. Make sure the projector and your computer are turned off.

User’s Guide KODAK DP2000 Digital Projector

Connecting the Projector

,FRQVRQWKHSURMHFWRUZLOODLG\RXZKHQFRQQHFWLQJWKHSURMHFWRUWRD FRPSXWHURUYLGHRSOD\HU

&DXWLRQ 7XUQRIIWKHFRPSXWHUPRQLWRUDQGSURMHFWRUZKHQ HYHU

\RXFRQQHFWWKHFRPSRQHQWV

power connection

DLP

A TEXAS INSTRUMENTS TECHNOLOGY

Includes

Image Manager

audio in VESA computer input KENSINGTON lock

mouseS-video composite video

Connecting to a Computer

When you connect the projector to a computer, make sure that the distance between it and the projector is 6 feet or less.

Always use the power cord and VESA cable that shipped with the projector. A surge-protected power strip is recommended.

Many laptop computers do not automatically turn on their external video port when a secondary display device such as a projector is connected. Refer to your computer manual for the command that activates the external video port. Activation commands for some laptop computers are listed in Appendix C.

Note: If you are connecting an older Macintosh computer that does

not have a 15-pin connector, use the optional Mac adaptor.

Setting up the Projector

To connect to a computer:

1. Plug one end of the VESA computer cable into the video connector on your computer.

2. Plug the other end of the VESA computer cable in the connector on the projector

audio cable

VESA cable

Do you want to play your computer’s audio on the projector?

1. Plug either end of the audio cable into the audio connector on your computer.

2. Plug the other end of the audio cable into the connector on the projector.

User’s Guide KODAK DP2000 Digital Projector

Do you want to control the computer’s mouse from the projector’s remote control or keypad?

If your computer has a PS/2 connector, use the PS/2 mouse cable.

1. Plug the 6-pin end of the PS/2 mouse cable into the mouse connector on your computer.

2. Plug the 8-pin end of the PS /2 mo use cable into the connector on the cable hub.

If your computer has a USB connector and is running a USB compatible operatin g system, use the USB m ouse cable.

1. Plug the end of the USB mouse cable into the mouse connector on your computer.

2. Plug the end of the USB mouse cable into the connector on the projector.

Note: A USB mouse is hot-pluggable, meaning that you do not

need to restart your computer after connecting the mouse to use the mouse. A PS-2 mouse is not hot-pluggable.

Now you’re ready to start the projector and computer. Skip to “Starting the Projector” on page 17.

Connecting to a Video Player

If your video player uses a round, one-prong composite video

connector, you’ll only need the audio cable, audio adapter, and composite video cable that shipped with the projector.

If your video player uses a round, four-prong S-video connector, you’ll need an S-video cable in addition to the audio cable and audio adapter. The S-video cable is sold separat ely.

Note: Your video player may have a "Video Out" connector for a

coaxial cable connection. Do not use this to connect to the projector.

To connect to a video player:

1. Plug the composite video cable yellow connector into the

“video-out” connector on your video player. This connector may be labeled “To Monitor.”

• If you’re using an S-vi deo cable, connect it to the “S-video out” connector on the video player.

2. Plug the other yellow connector into the composite video connector on the back of the projector.

• If you’re using S-video, plug the other end of the cable into

the “S-video” connector on the projector.

Setting up the Projector

Connecting with composite video cable

audio adaptor

composite video cable

audio cable

User’s Guide KODAK DP2000 Digital Projector

Connecting with S-video cable

audio

adapter

audio cable

S-video

cable

3. Plug the plug the audio adapter white connector into the left

“audio out” port on your video player. Plug the adapter red connector into the right “audio out” port on the video player.

4. Plug the other end of the audio adapter into the audio cable.

5. Plug the audio cable into the "audio in" connector on the projector.

The projecto r is compatible with these major broadcast video standards: NTSC, NTSC 4.43, PAL, P AL-M, PAL-N, and SECAM. It automatically adjusts to optimize its performance for the incoming video. See “Video Standard” on page 30 for details.

Starting the Projector

Note: We recommend using a surge protector power strip.

1. Remove the lens cap.

2. Plug the power cord into the si de of the pro jector, a nd then pl ug it

into your electrical outlet. The fans start to run and the lamp LED on top of the projector

lights orange until the so ftware has initialized. T hen the LED lights green.

3. Turn on the lamp by pressing the button on the keypad.

The KODAK startup screen appears.

4. If you connected the pro jecto r to a vi deo pla yer, turn on the video

player .

• The video image should appear on the projection screen. If a computer source is active, press the button on the keypad (page 23) or the button on the remote to display

your video image. You can select a default source to determine which source the projector examines first during power-up for active video; see “Default Source” on page 31.

• Use the

5. If you connected the projector to a computer, turn on the computer. Make sure the computer external video port is activated . See “Port able and La ptop Acti vation Ch art” on pa ge 49. Note: With some computers, the order in which you power up

the equipment is very important. Most computers should be turned on last, after all other peripherals have been turned on. Refer to your computer documentation to determine the correct orde r.

• The computer image should appear on the projection screen.

If a video source is active, press the button on the keypad (page 23) or the button on the remote to display

your computer’s image.

• If necessary, make adjustments to the image using the

projector’s on-screen menus. To open the menus, press the

button on the keypad or remote, then sel ect the Display or Image sub-menu. For more information about the menus, see “Using the On-Screen Menus” on page 25.

Setting up the Projector

buttons to adjust the volume.

User’s Guide KODAK DP2000 Digital Projector

Turning Off the Projector

T o compl etely turn of f t he proje ctor, unplug it. If you want to turn the projector back on imme diately, you must allow about a mi nute f or t he

lamp to cool. The lamp won’t light if it’s too hot. Note: Lamp life will be extended if you turn the lamp off, then wait

1 minute while the lamp cools before unplugging the projector. The Lamp LED will light green when the lamp has cooled. See page 24 for details on the Lamp LED.

If you want to tu rn off the display for a shor t p eriod of time, press the

button on the keypad o r remote. Th is blanks the s creen f or fi ftee n

minutes, but keeps the pro jector runni ng. (You can change the amount of time the projector stays in standby mode; see “Standby Time” on page 31 for details.) After 15 minutes, the lamp goes out (the projector keeps running). To exit standby mode, press the button again. (It may take several seconds for the pr ojection lamp to reach full power and project the image again.)

Using the Projector

This section describes how to use and make adjustments to the projector. It also provides a reference to the keypad and remote control buttons and the options available from the on-screen menus.

Basic Image Ad jus tm e nt

1. Make sure you have turned on your equipment in the right order (page 17).

2. If the image doesn’t display completely, zoom the image

(page 20), adjust the height of the projector (page 20) or center the image by adjusting its horizontal or vertical position (page 29). Be sure the projector is at a 90 degree angle to the screen.

3. If the image is out of focus, rotate the focus lens (page 20).

4. If the image appears to shimmer or if it has blurry vertical bars after you have adjusted the focus, turn Auto Image (page 28) off and then back on to reset the automatic sync and tracking. If that doesn’t clear up the image, turn Auto Image off and adjust the sync (page 29) and/or the tracking (page 29) manually.

5. If the colors don’t loo k ri ght , check the KODAK Image Manager settings. See “Kodak Menu” on page 35

Or Adjust the brightness (page 26) and the tint (page 27).

User’s Guide KODAK DP2000 Digital Projector

Adjusting the Projector

To focus the image, rotate the focus ring until the image is clear. To zoom the image, rotate the zoom ri ng. This adj usts the image size without affecting focus.

zoom ring

focus ring

The projector is equipped with a self-locking, quick-release elevator foot and button.

To raise the projector:

1. Press and hold the elevator button.

2. Raise the projector to the height you want, then release the button to lock the elevator foot into position.

Elevator foot

Elevator button

The Remote Control

The projector ships with a remote that has four function buttons, a disk mouse and two mouse buttons, one on the top of the remote and one on the bottom.

Point the remote control at the projection screen or at the front or rear of the projector. The range for optimum operation is about 25 feet (7.6 m). If you point the remote at the projection screen, the distance to the screen and back to the projector must not be more than 25 feet (7.6 m). For best results, point the remote directly at the projector.

Using the Projector

disk mouse

simulates the right mouse button

simulates the left mouse button

Note: If the remote is inactive for several minutes, it “sleeps” to

conserve battery li fe . Pre ss any button except the dis k mou se to re-activate the remote.

User’s Guide KODAK DP2000 Digital Projector

Press anywhere on the edge of the disk mouse to move the cursor on the screen. You can move the cursor at any angle by pressing the corresponding edge of the disk. The mouse button on the top of the

remote simulates your computer’s right mouse button; the button on the bottom simulates your computer’s left mouse button. See “Using the Keypad and Remote Contr ol” starti ng on page 23 for a desc ription of the four function buttons.

If you are creating presentations in MICROSOF T you can use the remote’s mouse buttons to navigate through your presentation while in Slide Show mode. To configure POWERPOINT for this, choose Options from the Tools menu, click the View Tab, de-select the “Pop up Menu on Rig ht Mouse Click” op tion in the Slide Show section, then cli ck OK. Then, when you’re i n POWERPOINT’s Slide Show mode, a left click advances to the next slide and a right click returns to the previous slide (other POWERPOINT modes are not affected).

POWERPOINT®,

Using the Projector

Using the Keypad and Remote Control

While the menus are displayed, the volume, source, and standby buttons on

the keypad act as menu n avigation button s. See “Us ing the On-Screen Menus” on page 25 for details.

The Keypad Buttons.

lamp LED

source button - toggles back and forth between video and computer sources

volume decreases volume

The Remote Control Buttons

lamp on/off

menu button displays a menu of projector options on the screen

volume increases volume

standby - turns off the image without turning off the projector

standby

computer

disk mouse

simulates the right mouse button

video

User’s Guide KODAK DP2000 Digital Projector

Lamp on/off (keypad only)

Press the button to turn the lamp on or off. The Lamp LED indicates the state of the lamp. A gr een La mp LED indi cat es that you can turn the lamp on, or the lamp is currently on. An orange LED indicates the software is initializing or the lamp is cooling. Do not

press the button when the LED is orange.

Press to open the on-screen menus (the keypad lights green). Press again to close the menus. When you close the menus, the

projector saves any changes you made. For more information about

the on-screen menus, see “Using the On-Screen Menus” on page 25.

Source (keypad only) or Computer and Video (remote control only)

When you have more than one source (computer and video) connected to the projector, select between them by pressing the

button on the keypad or the or button on the remote.

Standby

When you press , the display and audio turn off and a blank screen is displayed for 15 minutes. You can change the amount of time the projector stays in standby mode; see “Standby Time” on page31 for details.

• If you press again within 15 minutes, the proj ector retu rns

to normal operations immediately.

• If you don’t press

minutes.

• If you press again after 15 minutes, wait until the lamp

LED is green.

again, the lamp turns off after 15

Volume (keypad only)

• To increase the volume, press

• To decrease the volume, pr ess .

Volume adjustments are saved for each source that you have connected.

Using the On-Screen Menus

The projector has seven drop-down menus that allow you to make image adjustments and change a variety of settings. Most of these

adjustments aren’t available directly from the keypad. Note: Some menu items may be grayed out at certain times. This

indicates that the item is not applicable to your setup (for example, video standards do not apply to computer sources) or the item is not enabled until another selection is made (for example, Manual Tracking is not available until Auto Image is turned off).

To open the on-screen menus, press the button on the keypad or remote. This changes the volume, source, and standby buttons on the keypad to menu navigation buttons. Press the corresponding buttons to move the cursor up, down, left, or right, or use the disk mouse on the remote. To select a menu, move the curs or left and right to highlight the menu you want. The drop-down menu appears.

Using the Projector

:KHQWKHPHQXRSWLRQLVDFWLYH XVHWKHVHEXWWRQVWRQDYLJDWH WKURXJKWKHPHQXV

T o cha nge a menu set ting , use the up and down navi gatio n button s on the keypad or the disk mouse on the remote control to move the cursor up and down to t he item you want to change (the select ed i t em is highlighted red), then use the left and right navigation buttons to adjust a setting.

User’s Guide KODAK DP2000 Digital Projector

Some submenus, such as Bri ghtnes s, cons ist of a sli der ba r you us e to increase or decreas e a va lu e. Some s ubmenus, such as Standby Time, consist of options you scroll through to select the desired one. All changes are saved when you close the menus.

To access another menu, use the up and down navigation buttons or the disk mouse on the remote control to move back to the top of the current menu, then use the left and right navigation buttons to move to another menu.

Display Menu



Brightness

Adjusting the brightness changes the intensity of the image.

• Pre ss the left na vigation b utton to da rken the image.

• Press the right navigation button to lighten the image.

Contrast

Contrast controls the degree of difference between the lightest and darkest parts of the picture. Adjusting the contrast changes the amount of black and white in the image.

• Press the left navigation button on the keypad to decrease

the contrast.

• Press the right navigation button on the keypad to increase

the contrast, making the blacks appear blacker and the whites appear whiter.

Using the Projector

Tint

The tint ad justs the red-green color balance in the projected imag e. Changing the Ti nt setting has no effect on PAL or SECAM video sources.

• Press the left navigation button on the keypad to increase

the amount of green in the image.

• Press the right navigation button on the keypad to increase

the amount of red in the image.

Color

The color setting adjusts a video image from black and white to fully saturated color.

• Press the left mouse button t o de crease the amount of color

in the image.

• Press the right mouse button to increase the amount of

color in the image.

Blank Screen

Blank Screen determines what color is displayed when th ere is no active source and when the projector is in standby. Click the left or right navigation button to toggle between blue and black.

Reset All

Click the left or r ight navig ation butt on to rese t all t he options (except Language, Video Standard, Rear Projection, and Standby Time) in all the menus to their origina l settings.

Audio Menu

Volume

Note: Changing t he v olu me fr om th e menu is the same as changing

Volume adjustments you make are saved for each source.

it using the keypad.

• Press the left navigation button to decrease the volume.

• Press the right navigation button to increase the volume.

User’s Guide KODAK DP2000 Digital Projector

Image Menu



Auto Image

Note: Some screen savers interfere with the operation of Auto

Image. If you’re experiencing problems, try turning your screen saver off, then turning Auto Image off and back on.

The projector automatically adjusts tracking, signal synchronization and vertical and horizontal position for most computers (Auto Image does not apply to video sources). If you want to adjust these features manually, you must turn off Image in the I mage menu and clicking either the left or right navigation button to select “off”.

Auto Image first by highlighting Auto

Auto Resize

Auto Resize automati cally resizes the image by scaling it up. It only

affects computer images that are not the projector’s native resolution. When

Auto Resize is on, the projector ma kes the be st fit of the image to

the screen. If you turn

Auto Resize off (by highlighting it in the Image

menu and clicking the left or right navigation button to select “off”), the image may be either cropped or too small for the screen.

Using the Projector

Manual Sync

Note: The Manual Sync option is available only for computer

sources. The projector sets this option automatically for a video source.

The projector adjusts signal synchronization automatically for most computers. But if the projected computer image looks fuzzy or streaked, try turning

Auto Image off then back on again. If the image

still looks bad, try adjusting the signal synchronization manually:

1. Turn Auto Image off.

2. Highlight Manual sync, then press the left or right navigation

button repeatedly until the image is sharp and free of streaks.

Manual Tracking

The projector adju sts tra cking automat ically to match the vide o signal from your computer. However, if the display shows evenly spaced, fuzzy, vertical lines or if the projected image is too wide or too narrow for the scre en, tr y tu rni ng

Auto Image off then back on ag ain. I f

the image is still bad, try adjusting the tracking manually: Note: Manual Tracking option is available only for computer

sources. The projector sets this option automatically for a video source.

1. Turn Auto Image off.

2. Highlight Manual tracking, then press the left or right navigation

button repeatedly until the fuzzy vertical bars are gone.

Horizontal position

Note: The Horiz. Position option is available only for computer

sources. The projector sets this option automatically for a video source.

Follow these steps to manually adjust the horizontal position:

1. Turn Auto Image off.

2. Highlight Horizontal position, the n press th e left nav igator bu tton

to move the image right or press the right navigator button to move the image left.

Positioning adjustment s are saved when you unplug the projector.

User’s Guide KODAK DP2000 Digital Projector

Vertical position

Note: The Vert. Position option is available only for computer

sources. The projector sets this option automatically for a video source.

Follow these steps to manually adjust the vertical position.

1. Turn Auto Image off.

2. Highlight Vertical position, then press the left navigation button to move the image down or press the right navigation button to move the image up.

Positioning adjustment s are saved when you power off the projector.

Controls Menu

Video Standard

When V i deo stand ard is set to Auto, t he proj ec tor at tempts t o pick the video standard (NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, or SECAM) automatically based on the input signal it receives. (The video standard options may vary depending on your region of the world.) If the projector is unable to detect the correct standard, the

colors might not look right or the image might appear “torn.” If this happens, manually se lect a s tandar d by c licki ng either the left or ri ght navigation button and cycling through the standards.

Note: If you already know the video standard used in your

geographical area, it’s best to manually select it.

Using the Projector

Standby Time

This option lets you select how long the lamp stays on and how long the blank screen is displayed in standby mode before the projector turns off. Select among 1, 5, 10, and 15 minutes and 1 and 2 hours by clicking the left or right navigation button and cycling through the options.

Rear Projection

When you turn

Rear Projection on, the projector reverses the image so

you can project from behind a translucent screen. Highlight Rear Projection, then click the left or right navigation button to turn this feature on and off.

Default Source

Default Source toggles between Computer and Video. This determines which source the projector checks first for active video during power-up. Highlight Default Source and click the left or right navigation button to toggle between the options.

Auto Source Select

This setting toggl es betwee n On and Of f. When this feature is Of f, the projector default s to th e sourc e sele cted i n Defau lt Source . To display

another source, you mus t man ual ly select one by pressing the button on the keypad or the or button on the remote control.

When this feature is On, the projector automatically finds the active source, checking the default source first. Highlight Auto Source Select and click the left or right navigation button to turn this feature on and off.

User’s Guide KODAK DP2000 Digital Projector

Plug and Play

This setting toggles between On and Off. When it is On, most new computers will automatically recognize the projector, then set the monitor resolution and re fresh rate accordingly. You need to set the Plug and Play setting to Off for the projector to display properly on some older computers. The Plug and Play setting does not affect video images.

If the projector’s display constantly changes between the computer

image and the message, “Perfecting the image”, you may need to set Plug and Play to Off.

Display Messages

This setting toggles between On and Off. When this feature is On, status messages such as “No signal detected” or “Standby Active” appear in th e lower-right corner of th e screen. Click the left or right navigation button to turn this feature off and not see status messages.

Display Startup Screen

This setting toggles betwee n On and Off. When this fea ture is On, the KODAK startup screen appears when the projector starts up and remains until an active sour ce is detected . The startup scree n contains information on contacting Kodak. Click the left or right navigation button to turn this feature off and display a plain black or blue screen instead of the startup screen.

Language Menu

You can display the on-screen menus in English, French, German, and Spanish.

Move the cursor to the language you want, then click the left or right navigation button. The menus redraw immediately.

Status Menu

This is a read -only win dow for i nformat ional pu rposes . To display the status window, select Show status from the menu, then click the left or right navigation button. To remove the window, click the left or right navigation button.

Using the Projector

User’s Guide KODAK DP2000 Digital Projector

Lamp hours used

Indicates how many hours the current lamp has been in use. The counter starts at zero hours and counts each hour the lamp is in use. Change the bulb when the brightness is no longer acceptable. See

“Replacing the Projection Lamp” on page 38 for details.

Computer resolution

Shows your computer’s resolution setting. To change this, go to your computer’s Control Panel and adjust the resoluti on in the Disp lay tab. See your computer user’s guide for details.

Horizontal refresh rate

The time period that one horizontal line is displayed.

Vertical refresh rate

The time period that one video frame is displayed.

Mute status

Indicates if the audio is muted.

Software version

Indicates the projector’s software version. This information is useful when contacting Technical Support.

Source

Indicates the active source, Computer or Video.

Kodak Menu

Kodak’s exclusive Image Manager feature allows you to select the image display setting bes t suited for your specific presentatio n material and projection environment.

Image Manager Settings

Photo-PC Se tting matches the higher contrast found on a standard PC monitor. This option is best for:

• images created on a PC

• images from a KODAK digital camera

• a starting point for composite or S-video inputs.

Using the Projector

Photo-Mac Setting matches the lower contrast found on a standard MACINTOSH monitor. It is generally used for images created on or for a MACINTOSH. This setti ng also works well with a PC i f you are using higher than normal contrast PC images.

Rich Colors results in an image with deep contrast and saturated vibrant colors. It is generally used under bright lighting conditions. This setting works well to enhance colors of certain graphics and it may be useful when images c reated for a MACINTOSH are displayed from a PC.

Spreadsheets results in an image with contrast between a PC and MACINTOSH monit or. It is generally used for text-rich tables, such as financial displays. This setting fa ctors in ambient light, subject matter, and personal preferences to deliver the right balance of contrast and brightness.

Graphics delive rs the maximum brightness and high contrast ne ede d to project graphics and text against solid colored backgrounds.

User’s Guide KODAK DP2000 Digital Projector

Using the Image Manager

1. Click the Kodak menu.

2. Select the setting best suited for your presentation material and environment.

The new contrast setti ng is immediately applied to the image.

3. Click OK to save the sett ing as your default Image Manager setting for the current and future presentations.

This section describes how to:

• clean the lens

• replace the projection lamp

• replace the batteries in the remote

• use the Kensington lock feature

• troubleshoot the projector

Cleaning the Lens

Follow these steps to clean the projection lens:

1. Apply a non-abrasive camera lens cleaner to a soft, dry cloth.

• Avoid using an excessive amount of cleaner.

• Abrasive cleaners, solvents or other harsh chemicals might scratch the lens.

2. Lightly wipe the cleaning cloth over the lens in a circular motion.

3. If you don’t intend to use the projector immediately, replace the lens cap.

Maintenance &

Troubleshooting

User’s Guide KODAK DP2000 Digital Projector

Replacing the Projection Lamp

&DXWLRQ 7RDYRLGEXUQVDOORZWKHSURMHFWRUWRFRROIRUDWOHDVW

PLQXWHVEHIRUH\RXRSHQWKHODPSPRGXOHGRRU1HYHU H[WUDFWWKHODPSPRGXOHZKLOHWKHODPSLVRSHUDWLQJ

The lamp hour counter in the Status menu counts th e number of hour s the lamp has been in use. Replace the lamp when the brightness is no longer acceptable. You can order new lamp modules fro m your dealer of KODAK products.

Follow these steps to replace the projection lamp:

1. Turn off the projector by unplugging the power cord.

2. Wait 30 minutes to allow the lamp to cool thoroughly.

3. Invert the projector on a flat surface, then insert a small screwdriver or other flat object into the tab on the lamp module door.

4. Pull the lamp door up and remove it.

&DXWLRQ 1HYHURSHUDWHWKHSURMHFWRUZLWKWKHODPSGRRURSHQRU

UHPRYHG7KLVGLVUXSWVWKHDLUIORZDQGFDXVHVWKH SURMHFWRUWRRYHUKHDW

Maintenance & Troubleshooting

5. Loosen the two non-removable screws on the outside of the

module.

6. Grasp the pull tab and lift out the lamp module.

Be careful when removing the lamp module so that it does not break.

7. Install the new lamp module, being sure to align the connectors

properly.

&DXWLRQ 'RQRWGURSWKHODPSPRGXOHRUWRXFKWKHJODVVEXOE

7KHJODVVPD\VKDWWHUDQGFDXVHLQMXU\

User’s Guide KODAK DP2000 Digital Projector

8. Gently push the module in until it is flush with the bottom

case of the projector.

9. Tighten the screws on the outside of the module.

 5HSODFHWKHODPSGRRUE\LQVHUWLQJWKHKRRNVRQWKHUHDURIWKH

ODPSGRRULQWRWKHSURMHFWRUDQGSUHVVLQJWKHODPSGRRULQWR SODFH

 3OXJLQWKHSRZHUFRUGWRWXUQWKHSURMHFWRUEDFNRQ

 7RUHVHWWKHODPSKRXUFRXQWHULQWKH6WDWXVZLQGRZSUHVVDQG

KROGWKH EXWWRQWKHQSUHVVWKH EXWWRQZKLOHVWLOO

KROGLQJGRZQWKH EXWWRQIRUVHFRQGV9HULI\WKDWWKH

FRXQWHUZDVUHVHWE\SUHVVLQJWKH EXWWRQDQGYLHZLQJWKH FRXQWHULQWKH6WDWXVZLQGRZ

Maintenance & Troubleshooting

Replacing the Batteries in the Remote Control

The life of the batteries depends on how often and how long you use the remote control. Symptoms of low battery charge include erra tic responses when using the remote control and a reduced range of operation.

Follow these steps to replace the batteries:

1. Turn the remote control face down in your hand.

2. Slide the battery cover off the end of the remote control.

3. Remove the old batteries and properly dispose of them.

4. Install two new AAA alkaline batteries. Make sure y ou install

each battery in the correct direction.

5. Slide the battery cover back on the remote control.

Using the Kensington Lock

The projector has a Kensington Security Standard connector for use with a Kensington MicroSaver Security System. Refer to the information that came with t he Kensin gton S ystem for i nstructi ons on how to use it to secure the projector.

DLP

A TEXAS INSTRUMENTS TECHNOLOGY

Includes

Image Manager

User’s Guide KODAK DP2000 Digital Projector

Troubleshooting

Problem: Nothing on projection screen

• Make sure that the power cord is properly c onnected to a

fully functional AC electrical outlet. Make sure that the power cord is also properly connected to the projector.

• If the projector is plugged into a power stri p, make su re the

power strip is turned on.

• Make sure you have removed the lens cap on the projecti on

lens at the front of the projector.

• Make sure the lamp is switched on.

• Check the projector’s lamp to ensure that it is securely

connected in the lamp module. See “Replacing the Projection Lamp” on page 38.

• Make sure that the cables do not have any bent pins.

Problem: Color or text not being projected

• You might need to adjust the brightness up or down until

the text is visible. Refer to “Brightness” on page 26 for more information.

Problem: The screen resolution is not right

• Make sure the computer’s video card is set for a resolution

of no greater than 1024 x 768.

Problem: Image isn’t centered on the screen

• Move the projector to reposition the image.

• Reposition the image using the software. Refer to

“Horizontal position” on page 29 and “Vertical position” on page 30.

• Be sure the projector is at a 90 degree angle to the screen.

Maintenance & Troubleshooting

Problem: Only the start-up screen displays

• Verify that the cables are connected correctly. See page 12

through page 16 for connection procedures.

• Verify that the proper input source is selected. See “Source

(keypad only) or Computer and Video (remote control only)” on page 24.

• You might need to turn everything off and turn on the

equipment again in the proper order. Refer to your computer documentation to determine the correct order.

• Make sure your laptop external video port i s turned on. Se e

the “Portable and Laptop Activation Chart” on page 49 in this guide or your computer’s manual for details.

• Make sure your computer video board is installed and

configured correctly.

• Make sure your computer has a compatible video board.

The projector isn’t CGA, EGA or SXGA compatible.

If you’re using Windows 98:

1. Open "My Computer" icon, the Control Panel folder and then the

Display icon.

2. Click the Settings ta b.

3. Verify that the Desktop area is set to 1024 x 768 or less.

Problem: Image is too wide or narrow for screen

• Adjust the zoom or projector placement.

• Adjust the resolution of your video card if it’s greater than

1024 x 768.

Problem: Image is out of focus

• Turn the projection lens to focus the im age.

• Make sure the projection screen is at least 5 feet

(1.5 m) from the projector.

• Check the projection lens to see if it needs cleaning.

User’s Guide KODAK DP2000 Digital Projector

Problem: Image and menus are reversed left to right

• Rear projection mode is probably turned on. Turn Rear

Projection off in the Controls menu. The image should

immediately return to forward projection. See “Rear Projection” on page 31.

Problem: the projector displays vertical lines,

“bleeding” or spots

• Adjust the brightness. See “Brightness” on page 26.

• Check the projection lens to see if it needs cleaning.

Problem: no sound

• Ad just the vol ume.

• Verify the audio/input connections.

• Adjust the audio source.

Problem: Image is “noisy” or streaked

Try these steps in this order.

1. Deactivate the screen saver on your computer.

2. Turn

Auto Image off and then back on agai n. See “Auto Imag e” on

page 28.

3. Turn

Auto Image off and adjust the synchronization and tracking

manually to find an optimal setting. See “Manual Sync” on page 29 and “Manual Tracking” on page 29.

• The problem could be with your computer’s video card. If

possible, connect a different computer.

Maintenance & Troubleshooting

Problem: Projected colors don’t match the computer or video player’s colors

Just as there ar e diffe rences in th e displays of diffe rent monitors , there are often differences between the computer image and the projected image.

• Adjust the colors using the KODAK Image Manager. See

“Kodak Menu” on page 35.

• Adjust the brightness, tint and/or c ontrast from the Dis play

menu. See “Brightness” on page 26, “Tint ” on page 27 and “Contrast” on page 26.

Problem: Lamp seems to be getting dimmer

• The lamp begins to lose brightness when it has been in use

for a long time. Replace the lamp as described in

“Replacing the Projection Lamp” on page 38.

Problem: Lamp shuts off

• A minor power surge may cause the lamp to shut off.

Unplug the projector, wait at least a minute, then plug it back in.

• Make sure the vents are not blocked.

To contact KODAK support see “If You Need Assistance” on

page 8

Specifications

The projectors must be operated and stored within the temperature and humidity ranges specified.

Temperature

Operating 50 to 104° F (10 to 40° C)

Appendix A

Non-operating -4 to 158

° F (-20 to 70° C)

Humidity

Operating and non-operati ng 5% to 95% relative humidity,

non-condensing

Dimensions

8.9 x 10 x 2.8 inches (22.6 x 25.4 x 7.1 cm)

Weight

4.8 lbs (2.2 kg) unpacked

Altitude

Operating 0 to 10,000 feet (3,048 meters) Non-operating 0 to 40,000 feet (12,192 meters)

9/99 47

User’s Guide KODAK DP2000 Digital Projector

Optics

Focus Range 4.9 - 16 feet (1.5 - 5 m)

Lamp

Type 120-watt VIP lamp

Input Power Requirements

100-120VAC 6A; 50/60Hz 200 - 240VAC 3A; 50Hz

Audio Input

Input Impedance 10K ohm nominal, AC coupled Maximum Input Voltage (L

+ RIN)

< 4.5 V for

PEAK

THD ≤ 0.3%

or RIN < 2.0 Vrms for THD

≤ 0.3%

Sensitivity 100 mV at 1 KHz for 88 dB

SPL at 1 meter

Connector Type 3.5 mm (1/8 inch) stereo phone

mini

48 9/99

Appendix B

Portable and Laptop Activation Chart

Many laptop computers do not automatically turn on their external video port when a secondary display device such as a projector is connected. Activation commands for some laptop computers are listed in the following table. (If your computer is not listed or the

given command does not work, refer to the computer’s documentation for the appropriate command.) On many laptops, the activation function key is labeled with an icon, for example or the text CRT/LCD.

Note: Usually, pressing the key commands once activates the

external video port, pressing it again activates both the external and internal ports, and pressing it a third time activates the internal port. Refer to your computer documentation for details on your specific model.

Key command

Computer

de-activate

activate port

Acer Ctrl-Alt-Esc (for

setup)

AST* ** FN-D or Ctrl -D FN-D or Ctr l-D

Ctrl-FN-D Ctrl-FN-D

FN-F5 FN-F5

type from A:/IVGA/ CR T

FN-F12 FN-F12

Ctrl-Alt-Esc (for setup)

type from A:/IVGA/ CRT

port

User’s Guide KODAK DP2000 Digital Projector

Key command

Computer

Key command

activate port

de-activate

port

AMS FN-F2 FN-F2

AMT setup screen setup screen

AT&T FN-F3

FN-F6

Advanced Logic Research

Altima Shift-Ctrl-Alt-C

Ambra** FN-F12 FN-F12

Ctrl-Alt-V Ctrl-Alt-V

setup VGA/ Conf.Simulscan

FN-F3 FN-F6

Shift-Ctrl-Alt-L setup VGA/

Conf.Simulscan

FN-F5 FN-F5

F2/Choose Option/ F5

Amrel* ** setup menu setup menu

Shift-Ctrl-D Shift-Ctrl-D

Apple see Mac Portable and Mac PowerBook

Aspen automatic automatic

Award FN-F6 FN-F6

F2/Choose Option/ F5

Appendix B

Key command

Computer

Key command

activate port

de-activate

port

BCC* automatic reboot computer

Bondwell LCD or CRT

options after bootup

Chaplet** setup screen setup screen

FN-F6 FN-F6

FN-F4 FN-F4

Chembook FN-F6 FN-F6

Commax Ctrl-Alt-#6 Ctrl-Alt-#5

Compaq* ** Ctrl-Alt-< Ctrl-Alt->

reboot for LCD or CRT options to appear

FN-F4 FN-F4

automatic automatic

mode/? (for setup option)

Compuadd* **

Data General Ctrl-Alt-Command Ctrl-Alt-Command

automatic automatic

Alt-F for screen setup option

mode/? (for setup option)

Alt-F for screen setup option

User’s Guide KODAK DP2000 Digital Projector

Key command

Computer

Key command

activate port

de-activate

port

Data General Walkabout

Datavue Ctrl-Shift-M Ctrl-Shift-M

DEC** FN-F5 FN-F5

Dell** Ctrl-Alt-< Ctrl-Alt->

2 CRT/X at DOS prompt

FN-F4 FN-F4

Ctrl-Alt-F10 Ctrl-Alt-F10

FN-F8 (CRT/LCD) FN-F8

FN-D FN-D

reboot

FN-F12 FN-F12

Digital* automatic reboot

FN-F2 FN-F2

Dolch dip switch to CRT dip switch to LCD

Epson dip switc h to CRT dip switch to LCD

Everex* setup screen option setup screen option

For-A Ctrl-Alt-Shift-C Ctrl-Shift-Alt-L

Fujitsu FN-F10

Appendix B

Key command

Computer

Key command

activate port

de-activate

port

Gateway FN-F3

FN-F1/FN-F1 again simultaneous

Grid* ** FN-F2, choose auto

or simultaneous

Ctrl-Alt-Tab Ctrl-Alt-Tab

Hitachi FN-F7 FN-F7

Honeywell FN-F10 FN-F10

Hyundai setup screen option setup screen option

IBM 970* automatic warm reboot

FN-F3 FN-F1

FN-F2

IBM ThinkPad**

reboot, enter setup menu

FN-F7, select choice from setup menu

FN-F1, select choice

FN-F5, select choice

FN-F2

User’s Guide KODAK DP2000 Digital Projector

Key command

Computer

activate port

PS/2 SC select choice (CRT, LCD, etc.)

Infotel FN-F12 FN-F12

Kaypro boot up, monitor

plugged in

Kris Tech FN-F8 FN-F8

Leading Edge FN-T FN-T

Mac Portable 100

Mac PowerBook

no video port: not compatible

de-activate

unplug monitor

port

140, 145, 150, 170

160, 165, 180, 520, 540, 5300

210, 230, 250, 270, 280, 2300

no video port: requires a 3rd-party interface

Control Panel folder, PowerBook Display fold er; Activate Video Mirroring

requires Apple Docking Station or Mini Dock

warm reboot

Appendix B

Key command

Computer

Key command

activate port

de-activate

port

Magitronic FN-F4 FN-F4

Mastersport FN-F2 FN-F1

Micro

Express*

Micron FN-F2 FN-F2

Microslate* automatic warm reboot

Mitsubishi SW2 On-Off-Off-

NCR setup screen option setup screen option

NEC* ** setup screen option setup screen option

automatic warm reboot

SW2 Off-On-On-

Off

CRT at the DOS prompt

FN-F3 FN-F3

Olivetti* automatic automatic

FN-O/* FN-O/*

Packard Bell* **FN-F0 FN-F0

Ctrl-Alt-< Ctrl-Alt- >

LCD at the DOS prompt

User’s Guide KODAK DP2000 Digital Projector

Key command

Computer

Key command

activate port

de-activate

port

Panasonic FN-F2 FN-F2

Prostar Ctrl-Alt-S at bootup Ctrl-Alt-S at bootup

Samsung* setup screen option setup screen option

Sanyo setup screen option setup screen option

Sharp dip switch to CRT dip swi tch to LCD

Sun SPARCDataview

Tandy** Ctrl-Alt-Insert Ctrl-Alt-Insert

Ctrl-Shift-M Ctrl-Shift-M

setup screen option setup screen option

Tangent FN-F5 FN-F5

Texas Instruments*

Top-Link* ** setup screen option setup screen option

Toshiba* ** Ctrl-Alt-End Ctrl-Alt-Home

setup screen option setup screen option

FN-F6 FN-F6

FN-End FN-Home

FN-F5 FN-F5

Appendix B

Key command

Computer

de-activate

activate port

port

setup screen option setup screen option

Twinhead* FN-F7 FN-F7

FN-F5 FN-F5

Automatic Automatic

WinBook Ctrl-Alt-F10 Ctrl-Alt-F10

Wyse software driven software driven

Zenith** FN-F10 FN-F10

FN-F2 FN-F2

FN-F1 FN-F1

Zeos** Ctrl-Shift-D

FN-F1

* These manufacturers have models that auto matically send video to the external CRT

port when some type of disp lay device is attached.

** These manufacturer s offer m or e than one key command dep e nding on the computer

model

Ctrl-Shift-D FN-F1

Appendix C

Using Video Mirroring with a PowerBook

Computer

When you turn video mirroring (called SimulScan in newer PowerBooks-see below) on, the projector displays the same

information that appears on your PowerBook’s built-in screen. When video mirroring is off, the projector acts like a separate display.

To turn on video mirroring for the first time:

1. Open the Monitor’s control panel; click on Monitor 2.

2. Set the number of colors you want.

3. Open the Control Stri p; click on the monitor icon.

4. Select “Turn Video Mirroring On.” Now you can turn video mirroring on and off from the Control Strip

without having to open the Monitor’s control panel again. When using video mirroring and high color graphics such as slide

shows, the projected image occasionally might turn black and white. If this happens, perform the following steps:

1. Turn off vid eo mirr ori ng.

2. Open the Monitor’s control panel.

3. Move the white menu bar to Monitor 2 to set the projector as the

primary monitor.

4. Restart the PowerBook.

User’s Guide KODAK DP2000 Digital Projector

Using SimulScan

Some newer PowerBooks display images on an external monitor or projector differently than previous ones. When using SimulScan, the projector displays the same information that appears on your PowerBook.

To select SimulScan:

1. Open the Control Panel, then double-click Monitors and Sound.

2. In the Resolution list, choose the SimulScan mode, then click OK.

3. If this changes your display settings, a dialog box appears. Click OK to confirm the change.

Projected Image Size

Use this chart and tables to help you determine projected image si zes

Appendix D

User’s Guide KODAK DP2000 Digital Projector

Table 1: Image Size, Width and Height for DP2000-maximum image size

Distance to

Screen

4.9 ft

1.5 m 8 ft

2.4 m 12 ft

3.7 m 16 ft

4.9 m 20 ft

6 m 30 ft

9 m

Diagonal Width Height

3.2 ft .9 m

5.2 ft

1.6 m

7.8 ft

2.4 m

10.4 ft

3.1 m

13.0 ft

3.9 m

19.5 ft

5.9 m

2.6 ft .8 m

4.2 f

1.3 m

6.3 ft

1.9 m

8.3 ft

2.5 m

10.4 ft

3.1 m

15.6 ft

4.8 m

1.9 ft 6 m

3.1 ft .9 m

4.7 ft

1.4 m

6.3 ft

1.9 m

7.8 ft

2.4 m

11.7 ft

3.6 m

Table 2: Image Size, Width and Height for DP2000-minimum image size

Distance to

Screen

4.9 ft

1.5 m

Diagonal Width Height

2.5 ft .8 m

2.0 ft .6 m

1.5 ft .4 m

8 ft

2.4 m 12 ft

3.7 m 16 ft

4.9 m 20 ft

6 m 30 ft

9 m

4.1 ft

1.25 m

6.2 ft

1.9 m

8.2 ft

2.5 m

10.3 ft

3.1 m

15.4 ft

4.7

3.3 ft 1 m

4.9 ft

1.5 m

6.6 ft

1.9 m

8.2 ft

2.5 m

12.3 ft

3.7 m

2.5 ft .7 m

3.7 ft

1.1 m

4.9 ft

1.5 m

6.2 ft

1.9 m

9.2 ft

2.8 m

Index

activation commands for laptops 49 adjusting

brightness 26 color 27 contrast 26 height 20 tint 27

volume 24, 27 altitude limits 47 assistance. See Technical Support Audio menu 27

Volume 27 Auto Source Select 31

Blank Screen 27 brightness, adjusting 26 buttons on keypad

Menu 24

Standby 24

Volume 24

cable hub 12 cables

A/V 15

composite video 15

hub connector 12

mouse 14 cleaning the projection lens 37 color

adjusting 27 colors

don’t match monitor colors 45

not displayed 42

compatibility

IBM-compatible 5 Macintosh 5

composite video cable

connecting 15 computers, compatible 5 connecting

laptop 14

mouse 14

power cord 17

video player 15–16 connector panel 12 contrast, adjusting 26 Controls menu 30

Auto Source Select 31

Default Source 31

Display Messages 32

Display Startup Screen 32

Plug and Play 32

Rear Projection 31

Standby Time 31

Video Standard 30 customer support numbers 9

Default Source 31 dimensions 47 Display menu options

Blank Screen 27

Brightness 26

Color 27

Contrast 26

Reset All 27

Tint 27

User’s Guide KODAK DP2000 Digital Projector

displaying

messages 32 on-screen menus 24 startup screen 32

focus range 48 fuzzy lines 29

help

customer support numbers 9 fax 8

humidity 47

IBM-compatible computers

compatibility 5


adjusting 19 centering 29

colors don’t match 45 fuzzy lines 29 has lines or spots 44 not centered 42 not displayed 42 out of focus 43 quality 42–45 resolution 5 reversed 31, 44 size 11, 61 streaked 44 too wide or too narrow 43

zooming 20 Image Manager 35 Image menu options 28

Auto Image 28

Auto Resize 28 Horiz. Position 29 Manual Sync 29 Manual Tracking 29 Vert. Position 30

Kensington lock 41 keypad

using 23

keypad buttons

menu 24 standby 24 volume 24

KODAK Image Manager 35

lamp

turns off unexpectedly 45 lamp hour counter 34 Language menu 33 language, selecting for menus 33 laptop activation sequence 49 lens

cleaning 37

Macintosh computers

compatibility 5 Menu button 25 menus. See on-screen menus monitor, colors don’t match 45 mouse, connecting 14

NTSC video 30

Index

on-screen menus

Audio menu 27 changing functions 25 changing language of 33 Controls menu 30 Display menu 26 displaying 25 Image menu 28 Language menu 33 Status menu 33

PAL video 27, 30 Plug and Play 32 power cord

connecting 17 power up sequence 17, 43 project from behind the screen 31

rear projection 31 relative humidity 47 remote control

operating the disk mouse 22

using 21, 23 re-positioning image on screen 29 resetting adjustments 27 resolution 5

safety guidelines 1 SECAM video 27, 30 security feature 41 service numbers 9 setting up 11 SimulScan with PowerBooks 60

specifications 47 Standby button 24 Standby Time 31 startup screen 32 Status menu 33 support numbers 9 S-video, connecting 15

temperature limits 47 test pattern 43 text not visible 42 tint, adjusting 27 turning off the projector 18 turning on the projector 17

USB mouse 14

vertical lines displayed 29, 44 video 27

mirroring PowerBook 59 video standards 30 volume

adjusting 24

warranty 10, 67 weight 47

zooming the image 20

WARRANTY TIME PERIOD

Kodak warrants the KODAK DIGITAL SCIENCE DP2000 Digital Projector (excluding lamps) to be free from malfunctions and defects in both materials and workmanship for two years from the date of purchase.

WARRANTY REPAIR COVERAGE

This warranty wi ll b e honored within the ge og raphical locati on that the product was purchased . If the equipment does not function properly during the w arranty period due to defects in either materials

or workmanship, Kodak will, at its option, either repair or replace the equipment without charge, subject to the conditions and lim it at ions stated herein. Such repair will include all labor as w el l as an y n e ce ssary adjustments and/or replacement parts.

If replacement parts are used in making repairs, th ese part s may be remanufactured, or may contain remanufactured materials. If it is necessary to replace the entire system, it may be replaced with a remanufactured system.

Kodak will also provide telephone assistance during the warranty period.

LIMIT ATIONS

WARRANTY SERVICE WILL NOT BE PROVIDED WITHOUT DATED PROOF OF PURCHASE. THIS WARRANTY BECOMES NULL AND VOID IF YOU FAIL TO PACK YOUR DIGITAL PROJECTOR

IN A MANNER CONSISTENT WITH THE ORIGINAL PRODUCT PACKAGING AND DAMAGE OCCURS DURING PRODUCT SHIPME NT.

THIS WARRANTY DOES NOT COVER: CIRCUMSTANCES BEYOND KODAK’S CONTROL; SERVICES OR PARTS TO CORRECT PROBLEMS RESULTING FROM THE USE OF ATTACHMENTS, ACCESSORIES, OR ALTERATIONS NOT MARKETED BY KODAK; SERVICE REQUIRED AS THE RESULT OF UNAUTHORIZED MODIFICATIONS OR SERVICE; MISUSE, ABUSE; FAILURE TO FOLLOW KODAK’S OPERATING, MAINTENANCE, OR REPACKAGING INSTRUCTIONS; OR FAILURE TO USE ITEMS SUPPLIED BY KODAK (SUCH AS ADAPTORS AND CABLES).

KODAK MAKES NO OTHER WARRANTIES, EXPRESS, IMPLIED, OR OF MERCHA NTABILITY OR FITNESS FOR A PARTICULAR PURPOSE FOR THIS EQUIPMENT OR SOFTWARE.

REPAIR OR REPLACEMENT WITHOUT CHARGE ARE KODAK’S ONLY OBLIGATION UNDER THIS WARRANTY. KODAK WILL NOT BE RESPONSIBLE FOR ANY SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES RESULTING FROM THE PURCHASE, USE, OR IMPROPER FUNCTIONING OF THIS EQUIPMENT REGARDLESS OF THE CAUSE. SUCH DAMAGE S FOR WHICH KODAK WILL NOT BE RESPONSIBLE INCLUDE, BU T ARE NOT LIMITED TO, LOSS OF REVENUE OR PROFIT, DOWNTIME COSTS, LOSS OF USE OF THE EQUIPMENT, COST OF ANY SUBSTITUTE EQUIPMENT, FACILITIES OR SERVICES, OR CLAIMS OF YOUR CUSTO MERS FOR SUCH DAMAGES.

Depending on your geographical location, some limitations and exclusions may not apply. Shipment of a unit from the customer to the kodak service center will be at the customer’s expense. This warranty is not tr an sfe rable from the original pu rcha se r of t he e quipment.

APPLICA TION SUPPORT

For application specific support, contact your reseller, systems integrator, software manufacturer, or dealer.

9/99 67

HOW TO OBTAIN SERVICE

Please refer to the Service and Support section of your User’s Guide for the support hotline designated to your location. When returning a digital projector for repair, the unit shall be packed in its original packing materials. A problem report

should also be enclosed wit h the eq uipment. If the original packagi ng h as b ee n dis carded or is not available, packing wil l be at the owner’s expense.

The repaired or replaced unit will be shipped from Kodak within five business days from the date of the digital projector receipt at the service center.

Unless a specific Kodak warranty is communicated to the purchaser in writing by a Kodak company , no other warranty or liability exists beyond the informat ion co nta ined above, even though defect, damage, or loss may be caused by negligence or other act.

To obtain warranty repair service contact your local Kodak representative. For assistance, refer to the Service and Support information in the KODAK Digital Project or User’s Guide.

Eastman Kodak Company 343 State Street Rochester, New York 14650

Kodak is a trademark of Eastman Kodak Company.

PN 010-0219 -00

Kodak DP2000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
