B30
USE & CARE GUIDE
GOURMET SINGLE-CUP BREWING SYSTEM
MINI – MODEL B30
Please read and save these instructions
Pour les directives en Francais, veullez vous reporter a la page 7
Dimensions: 11"H x 7"W x 10"D
(279mm H x 178mm W x 254mm D)
Weight: 6.5 Lbs. (2.95Kgs)
Electrical:120VAC, 700W 60Hz
Approvals: cULus Approved for Commercial and Household Use Only
Press here to open
and insert a K-Cup
Flashes to
alert you
to place a
cup on the
drip tray
Flashes to
indicate
when to
press for
brew
Lights RED,
indicates
heating
Press here
to turn on
the brewer
Drip Plate
Drip Tray
Cup Sensors
When using electrical appliances, basic safe-
ty precaution should be followed, including
the following:
1. Read all instructions before using.
2. Do not touch hot surfaces. Use handles
and knobs when available.
3. This appliance must be properly installed
and located in accordance with these
instructions before it is used.
4. The use of accessory attachments not
recommended by the appliance manufac-
turer may result in fire, electrical shock or
injury to persons.
5. Do not place on or near a hot gas or elec-
tric burner, or in a heated oven.
6. Do not use outdoors.
7. To protect against fire, electric shock and
injury to persons do not immerse cord,
plugs, or the appliance in water or other
liquid.
8. Use only water in this appliance! Do not
put any other liquids or foods in the Water
Reservoir.
9. Unplug the coffee brewer when not in use
and before cleaning. Allow to cool before
attaching or removing parts and before
cleaning the appliance.
10. Do not operate any appliance with a dam-
aged cord or plug or after the appliance
malfunctions or is damaged in any man-
ner. Contact your Keurig Customer Service
to arrange for replacement or repair.
11. Do not let the cord hang over the edge of
the table or counter, or touch hot surfaces.
12. To disconnect, turn the Power Button on
the right-front of the Brewer off and then
remove the plug from the wall outlet.
13. Close supervision is necessary when any
appliance is used by or near children.
14. Do not push the PRESS TO OPEN button
while brewing is in progress.
15. This appliance is equipped with a power
cord having a grounding wire with a
grounding plug. The appliance must be
grounded using a 3-hole properly grounded
outlet. In the event of an electrical short
circuit, grounding reduces the risk of
electrical shock.
16. If the outlet is a standard 2-prong wall
outlet, it is your personal responsibility
and obligation to have it replaced with a
properly grounded 3-prong wall outlet.
17. Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord or use an adapter.
18. Consult a qualified electrician if the
grounding instructions are not completely
understood, or if doubt exists as to
whether the appliance is properly grounded.
19. Do not use the appliance for other than
its
intended use.
SAVE THESE INSTRUCTIONS
CAUTION: There are two sharp needles
that puncture the K-Cup
®
portion pack,
one above the K-Cup
®
Holder and the
other in the bottom of the K-Cup
®
Holder.
To avoid risk of injury, do not put your
fingers in the K-Cup
®
chamber.
WARNING: This product contains chemi-
cals, including lead, known to the State of
California to cause cancer, birth defects or
other reproductive harm.
CAUTION: There is extremely hot water in
the K-Cup
®
Holder during the brew process.
To avoid risk of injury, do not open the
K-Cup
®
chamber during the brew process.
THIS PRODUCT IS FOR COMMERCIAL
AND HOUSEHOLD USE
To reduce the risk of injury, do not drape cord
over the counter top or table top where it can
be pulled on by children or tripped over unin-
tentionally.
Record your Brewer Serial Number here. _________
The Serial Number is located on the Serial Number
label found on the bottom of the brewer box.
1
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT REMOVE THE BOT-
TOM COVER. NO USER SERVICEABLE PARTS
ARE INSIDE. REPAIR SHOULD BE DONE BY
AUTHORIZED SERVICE PERSONNEL ONLY.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
DO NOT OPEN
SET-UP & OPERATION
Plug Brewer into its own grounded outlet.
If the electric circuit is overloaded with other
appliances, your Brewer may not function
properly. If possible, the Brewer should be
operated on its own circuit, separate from
other appliances.
CAUTION: There are two sharp needles
that puncture the K-Cup
®
portion pack,
one above the K-Cup
®
Holder and the
other in the bottom of the K-Cup
®
Holder.
To avoid risk of injury, do not put your
fingers in the K-Cup
®
Chamber.
Select a K-Cup
®
portion pack. Do not remove
the foil lid or puncture the K-Cup
®
portion pack.
Make sure the brew-
er is plugged in.
Press the Power
Button found on the
front of the Brewer.
Depress the large
“PRESS TO OPEN”
button on top of the
brewer.
Place a K-Cup
®
portion pack in the
K-Cup
®
Holder.
Do not remove
the foil lid.
Lower the Handle
completely and
firmly to close the
Lid and puncture the
K-Cup
®
portion pack.
The Hot Water Tank
cover will open auto-
matically.
Fill the Hot Water
Tank with filtered or
bottled water up to
the FILL LEVEL
indicator.
Close the Hot Water
Tank cover. The
“PLACE CUP” light
will be flashing
Place a 10 oz coffee
cup in the dispense
area on the drip tray.
Press the flashing
BREW button. The
HEATING light will be
illuminated.
When the water
reaches temperature,
the HEATING light
will go off and the
coffee/tea/hot cocoa
will start to dispense.
Your cup of gourmet coffee, tea or hot cocoa
will be ready in less than 3 minutes. Enjoy!
2
SECTION 1
2
3
4
5
6
7
1
NOTE: Do not use a clear, glass mug.
Cup sensor will not "read" the glass mug
and the "Place Mug" light will flash.
Cleaning Drip Tray & External Parts
Regular cleaning of the Brewer’s external com-
ponents is recommended using a damp lint-free
cloth only.
1. Never immerse the base unit in water or
other liquids. The Housing and other exter-
nal components may be cleaned with a
damp, non-abrasive, lint free cloth.
2. The Drip Tray can accumulate liquids. The
Drip Tray and Drip Tray Plate should be peri-
odically inspected and cleaned with a damp
soapy non-abrasive lint free cloth. The Drip
Tray and Drip Tray Plate should not be put
into the dishwasher. To remove the Drip Tray
Assembly, simply slide it toward you, keep-
ing it level at all times to avoid spilling.
Cleaning the K-Cup
®
Portion Pack
Holder Assembly
1. Cleaning the Parts
The K-Cup
®
Holder Assembly is dishwasher
safe. To remove from the Brewer, open the
brewer by pressing the button. Grasp the
top of the K-Cup
®
Holder with one hand
while pushing up on the bottom of the
K-Cup
®
Holder from underneath with the
other until it releases. After cleaning, align
the K-Cup
®
Holder with the opening using
the two front ribs as a guide and snap into
place from the top.
2. Cleaning the Funnel
The Funnel can be removed from the
K-Cup
®
Holder by pulling on it until it
snaps off. The Funnel is dishwasher safe.
To replace it just snap it back onto the
K-Cup
®
Holder Assembly.
3. Cleaning the Exit Needle
The Exit Needle is located on the inside bot-
tom of the K-Cup
®
Holder. Should a clog
arise due to coffee grinds, it can be cleaned
using a paper clip or similar tool. Remove
K-Cup
®
Holder and then remove the funnel,
insert the paper clip into the Needle to
loosen the clog and push it out. The K-Cup
®
Holder is dishwasher safe. NOTE: The
Entrance needle does not require cleaning.
CAUTION: There are sharp needles that
puncture the K-Cup
®
above the K-Cup
®
Holder and in the bottom of the K-Cup
®
Holder. To avoid risk of injury, do not put your
fingers in the K-Cup
®
Chamber.
When finished cleaning, reassemble the K-Cup
holder and funnel and replace in the brewer.
Close the brewer, the water fill lid will pop open.
Cleaning the Hot Water Tank
To access the Hot Water Tank, press the PRESS
TO OPEN button and then lower the handle
completely, the water fill lid will pop open.
Inspect the Hot Water Tank area and clean with
a damp lint free cloth as necessary. Close the
water fill lid when finished.
3
SECTION 2
Insert paper clip
here to clean out
the exit needle
K-Cup Holder
CLEANING & MAINTENANCE
IMPORTANT: Make sure the brewer is unplugged before cleaning
Funnel
K-Cup Holder
Assembly
K-Cup Holder
NOTE: Over time, discoloration, spotting or
staining may appear in the Hot Water Tank. This
is normal and will vary depending on the miner-
al content of the bottled or filtered water used
in the brewer and will not affect the operation
of the brewer.
Emptying the Hot Water Tank
1. Ensure that the water fill lid is closed.
2. Place a cup on the drip plate then press and
hold the brew button until all the water has
been dispensed. Note, there will be a delay of
4 - 5 seconds until water starts to dispense.
Storage
Empty the Hot Water Tank before storing and
take care to ensure that you store your Brewer
in a safe and
frost free environment. It is
suggested to store your brewer in the upright
position. If you store the Brewer in a cold
environment, you run the risk of condensation
freezing inside the Brewer and causing damage.
When you prepare to use it after storage, we
recommend wiping the Hot Water Tank with a
damp lint-free cloth and running three cleansing
brews without a K-Cup
®
.
If your Brewer has been in an environment
below freezing, please be sure to let it warm to
room temperature for 2 hours before using.
De-Scaling Your Brewer
Mineral content in bottled or filtered water
varies. Depending on the mineral content of the
water, calcium deposits or scale may build up in
your Brewer. Scale is non-toxic but left unat-
tended, it can hinder Brewer performance. De-
scaling your Brewer helps maintain the heating
element, and other internal parts of the Brewer
that come in contact with water.
The Brewer should be de-scaled every 3-6
months to ensure optimal performance or when
there are white deposits in the Hot Water Tank.
It is possible for calcium deposits to build up
faster, making it necessary to de-scale more
often.
Step 1: Make sure you have at least 8 ounces
of undiluted white vinegar on hand. You will also
need a 10 oz ceramic cup (do not use a paper
cup) and access to a sink.
Step 2: Fill Hot Water Tank with 8 ounces of
undiluted white vinegar up to the FILL LEVEL
mark, place a ceramic cup on the drip tray.
Step 3: Close the lid, and perform a brew into
the ceramic cup without adding a K-Cup
®
.
Step 4: Pour the contents of the ceramic cup
into the Hot Water Tank, careful the liquid will
be hot, close the lid. Start a brew but power off
the brewer just after it starts to dispense and
then allow it to sit for at least 30 minutes.
Step 5: After the prescribed period of time,
perform a brew without adding a K-Cup
®
. Empty
the contents of the ceramic cup into the sink ,
be careful as contents may be hot.
Step 6: Fill the Hot Water Tank with 8 ounces of
bottled water, close the water fill lid, place a
cup on the drip tray and perform a brew.
Step 7: Repeat Step 6 three times using bottled
water (with no K-Cup in place) to cleanse the
brewer plumbing and get rid of any residual
taste from the vinegar.
The brewer is now ready for normal use again.
Service
Beyond these recommended cleaning and
maintenance procedures this brewer is not user
serviceable, for service please refer to the
Warranty section in this guide.
4
Loading...
