Kenwood DNX4210BT-OP, DNX4210DAB-OP Easy Setup Manual
KENWOOD NAVIGATION SYSTEMS
DNX4210BT -OP & DNX4210DAB-OP
Volume
1
Easy Set-up
Guide
KENWOOD
Easy Set-up Guide
Bluetooth Hands-free Phone Set-up & FAQ .......................................................................... 1
How to Pair an iPhone ............................................................................................................................ 2
How to Pair a Blackberry 9300 ............................................................................................................... 3
How to Pair a Samsung Galaxy SII ........................................................................................................ 4
Additional hints, if phonebook does not download .................................................................... 5
How to Pair a Phone (General Information for other Makes/Models) .................................................... 6
Amount of Downloadable Contacts ........................................................................................................ 7
No Direct Dial .......................................................................................................................................... 7
New Phones cannot be Paired ............................................................................................................... 7
How to Check How Many Phones are Authorised to Pair? .................................................................... 7
How to Delete a Phone? ......................................................................................................................... 7
Software Updates .................................................................................................................. 8
Where to Download Software Updates .................................................................................................. 8
How to Check what Software Version you are Running ......................................................................... 8
How to Update your Software Version ................................................................................................... 9
Mapping Updates ................................................................................................................ 10
Check Mapping Data Version ............................................................................................................... 10
How to Download a Map Update .......................................................................................................... 11
How to Activate TMC (Traffic Information) ........................................................................... 14
Speed Camera POI’s ........................................................................................................... 15
How to Upload Speed Camera POI’s ................................................................................................... 15
iPod/iPhone ......................................................................................................................... 19
iPod/iPhone Compatibility ..................................................................................................................... 19
How to Connect Up an iPhone 5 ............................................................................................. 19
Video Playback Will Not Work via an iPhone 5 ....................................................................... 19
No iPod/iPhone Loading .......................................................................................................... 19
iPod/iPhone Music Playback Not Working .............................................................................. 19
DAB - Digital Radio (DNX4210DAB only) ............................................................................ 20
Initial DAB Reception Tuning ................................................................................................................ 20
Presetting DAB Stations ....................................................................................................................... 21
Priority Function .................................................................................................................................... 21
General FAQ’s ..................................................................................................................... 22
How to Dim the Display ........................................................................................................................ 22
What to do with a Blank Screen ........................................................................................................... 22
Unable to Enter a Postcode for Wales or Scotland but English Postcodes are OK ............................. 22
My iPod Icon has Disappeared from the Top Menu, Instead I have Video 1 and Video 2 Icons ......... 22
Chapter
1
Bluetooth Hands-free Phone Set-up & F AQ
In this chapter we explain how to pair an iPhone, Blackberry 9300, Samsung Galaxy SII and
non-specific make/model of phone. You should always consult your phone’s instruction manual
for detailed information on phone settings for Bluetooth. Also ensure that your phone is running
the latest software version available.
iPhone’s
Blackberry 9300
Samsung Galaxy SII
1
General Information for Other Phone’s
How
You ca
Navigat
After pa
please b
NOTE: During initial pairing it is normal for the phone to connect/disconnect several times.
to Pair an iPhone
n initiate pairing from either the iPhone (Method 1) or the Kenwood
ion System DNX4210BT-OP or DNX4210DAB-OP (Method 2).
iring the initial download of your phonebook may take up to 5 minutes,
e patient.
METHOD 1
Pairing From the iPhone:
Method 1 - Make the iPhone discoverable:
1. Select “SETTINGS” on the iPhone
2. Select “BLUETOOTH”
3. Ensure that the Bluetooth is “ON”
The phone will search for available devices.
4. Select “ DNX4210BT” or “DNX4210DAB” from the list
5. Enter the default pin code “0000” when prompted. The iPhone will connect after 30 seconds to 1
minute.
6. Select “PAIR” when prompted on the iPhone
METHOD 2
Pairing From the Kenwood Navigation System:
Method 2 - Make the iPhone discoverable:
1. Select “SETTINGS” on the iPhone
2. Select “BLUETOOTH”
3. Ensure that the Bluetooth is “ON”
On the Kenwood Navigation System:
4. Select [TEL] either on screen icon or hard key
6. Select [REGISTER NEW DEVICE]
The Kenwood Navigation System will search
for available devices.
7. Select the “iPhone” from the list
8. Enter the default pin code “0000” when
9. Select “PAIR” when prompted on the
5. Select [BT SET-UP]
prompted. The phone will connect after 30
seconds to 1 minutes
iPhone
2
How to Pair a Blac kberry 9300
You can initiate pairing from either the Blackberry 9300 (Method 1) or the
Kenwood Navigation System DNX4210BT-OP or DNX4210DAB-OP (Method 2).
After pairing the initial download of your phonebook may take up to 5 minutes,
please be patient.
NOTE: During initial pairing you may need to do this several times.
METHOD 1
Pairing From the Blackberry 9300:
Method 1 - Make the iPhone discoverable:
1. Select Spanner Symbol on the Blackberry 9300
2. Select “BLUETOOTH”
3. Press the Blackberry Button (Touch key)
4. Select “ADD DEVICES”
5. Select “SEARCH”
The phone will list all available devices.
6. Select “ DNX4210BT” or “DNX4210DAB” from the list
7. When the phone prompts for a pin code - “0000” (Default pin code of the Kenwood Navigation
System)
8. You will get the message “ACCEPT CONNECTION REQUEST?” – Press “OK” or “YES”
METHOD 2
Pairing From the Kenwood Navigation System:
Method 2
On the Kenwood Navigation System:
1. Select [TEL] either on screen icon or hard key
3. Select [REGISTER NEW DEVICE]
The Kenwood Navigation System will search
for available devices.
4. Select the “Blackberry 9300” from the list
5. Enter the default pin code “0000” when
6. Then “ACCEPT CONNECTION
2. Select [BT SET-UP]
prompted
REQUEST” press “OK” or “YES”
3
How to Pair a Samsung Galaxy SII
NOTES: After initial pairing if the phonebook does not download please
see additional hints further below.
Also after pairing the initial download of your phonebook may take up to 5 minutes,
please be patient.
Step 1 – Turn on the Bluetooth and make the Samsung Galaxy SII visible by selecting the following:
1. Select “APPLICATIONS” on the Samsung Galaxy SII
2. Select “SETTINGS”
3. Select “WIRELESS AND NETWORK”
4. Select “ BLUETOOTH SETTINGS” (Turn on Bluetooth if not already)
5. Select “VISIBLE” (NOTE: The phone will only stay visible for 2 minutes)
(Images below show screen shots)
Step 2 – Connect the Samsung Galaxy SII to the Kenwood Navigation System
6. Select [TEL] either on screen icon in the
“TOP MENU” screen or hard key
7. Select [BT SETUP]
8. Select “REGISTER NEW DEVICE”
9. Select “GALAXY SII” from the list
4
Samsung Galaxy SII Continuation
10.
The phone will prompt for an
unlock code enter “0000”
11. After connection, press [TEL] to use
phone
Additional hints, if phonebook does not download
1. During the initial pairing process, your phone may flash a message in the notifications area (Top
Screen) “PHONEBOOK ACCESS REQUEST”.
If you get this message, drag the very top of the screen downwards and check the setting “ALLOW
PHONEBOOK ACCESS”.
2. Only contacts on the phone’s memory are transferred if your contacts are on your SIM card then
transfer them to the phone’s memory.
3. Select “CONTACTS”
4. Press the Options Button to
the left of the Home Button
5. Select “IMPORT/EXPORT”
6. Select “IMPORT FROM
SIM CARD”
7. Select “PHONE”
8. Select the contacts to be
transferred and then “IMPORT”
5
How to Pair a Phone (General Information for other Mak es/Models)
There are two methods used to register your phone, you can generally use either method, but some
phones will only work using one or the other methods below (So if the first method doesn’t work and you
have tried to pair several times using this method, then try the second method).
After pairing the initial download of your phonebook may take up to 5 minutes, please be patient.
METHOD 1
Pairing From the Phone:
Method 1 – (Exact method may vary depending on the phone make/model please consult the phone’s
instruction manual):
1. Ensure that the Bluetooth is switched on, on the phone
2. In the phone’s menu system, select “BLUETOOTH” or something similar
3. Then select “SEARCH FOR DEVICES” or something similar
4. The phone should find “DNX4210BT” or “DNX4210DAB”
5. Select this and enter the default pin code “0000”
6. Wait while your phone pairs with the Kenwood Navigation System
7. Confirm any additional commands shown on your phone’s display to allow Bluetooth connection
The phone will search for available devices.
8. Select “ DNX4210BT” or “DNX4210DAB” from the list
9. Enter the default pin code “0000” when prompted
The phone will connect after 30 seconds to 1 minute
METHOD 2
Pairing From the Kenwood Navigation System:
Method 2 – (Exact method may vary depending on the phone make/model please consult the phones
instruction manual):
1. Ensure that the Bluetooth is switched on, on the phone
On the Kenwood Navigation System:
2. Select [TEL] either on screen icon in the
“TOP MENU” screen or hard key
4. Select [REGISTER NEW DEVICE]
3. Select [BT SET-UP]
The Kenwood Navigation System will search for available
devices.
5. Select the your phone from the list
6. Enter the default pin code “0000” when prompted
The phone will connect after 30 seconds to 1 minute
6
