Kenwood DNR935WBT, DNR935WBTM User Manual

CONNECTED MONITOR WITH DVD RECEIVER

DNR935WBT
DNR935WBTM

Quick Start Guide

You can update the system by connecting a USB device containing an
update le.
For updating the system, visit <http://www.kenwood.com/cs/ce/>.

B5K-0037-00 (MN/M2N/XN)© 2014 JVC KENWOOD Corporation

Contents About The Quick Start Guide

About The Quick Start Guide ............................... 2

Precautions ................................................................. 3

Features of Connected systems .......................... 5

First Step .......................................................................6

Functions of the Buttons on the Front Panel

Common Operation .................................................9

Login ............................................................................10

Operation on the Home Screen ........................ 11

How to Play Music ...................................................12

How to Play Movie .................................................. 13

How to Listen to the Radio ..................................14

How to Make a Phone Call ...................................14

Installation ................................................................. 16

iPod/ iPhone/ Android setup .............................23

About This Unit ........................................................26

This Quick Star t Guide describes basic functions of
this unit.
For functions not described in this Guide, refer to the
Instruction Manual on the following website:

http://manual.kenwood.com/edition/im388/

... 8

To refer to the Instruction Manual, a PC loaded with
Microsoft® Windows XP/Vista/7/8 or Mac OS X® 10.4 or
later is required in addition to Adobe® Reader™ 7.1 or
Adobe® Acrobat® 7.1 or later.
The Instruction Manual is subject to change for
modification of specifications and so forth. Be sure to
download the latest edition of the Instruction Manual
for reference.

✎ NOTE

• The panels shown in this guide are examples used
to provide clear explanations of the operations. For
this reason, they may be different from the actual
panels.

• In operation procedures, bracket shape indicates
the key or button you should control.
< >: indicates the name of panel buttons.
[ ]: indicates the name of touch keys

2 ñ English

Precautions

2WARNING

Ñ To prevent injury or re, take the following

precautions:

• To prevent a short circuit, never put or leave any
metallic objects (such as coins or metal tools)
inside the unit.

• Do not watch or fix your eyes on the unit’s
display when you are driving for any extended
period.

• If you experience problems during installation,
consult your Kenwood dealer.

Ñ Precautions on using this unit

• When you purchase optional accessories, check
with your Kenwood dealer to make sure that they
work with your model and in your area.

• You can select language to display menus, audio
file tags, etc. See Language setup (P.104) in
the Instruction Manual.

• The Radio Data System or Radio Broadcast Data
System feature won’t work where the service is
not suppor ted by any broadcasting station.

Ñ Protecting the monitor

To protect the monitor from damage, do not
operate the monitor using a ballpoint pen or
similar tool with the sharp tip.

Ñ Lens fogging

When you turn on the car heater in cold weather,
dew or condensation may form on the lens in the
disc player of the unit. Called lens fogging, this
condensation on the lens may not allow discs to
play. In such a situation, remove the disc and wait
for the condensation to evaporate. If the unit still
does not operate normally after a while, consult
your Kenwood dealer.

Ñ Precautions on handling discs

• Do not touch the recording sur face of the disc.

• Do not stick tape etc. on the disc, or use a disc
with tape stuck on it.

• Do not use disc type accessories.

• Clean from the center of the disc and move
outward.

• When removing discs from this unit, pull them
out horizontally.

• If the disc center hole or outside rim has burrs,
use the disc only after removing the burrs with a
ballpoint pen etc.

• Discs that are not round cannot be used.

• 8-cm (3 inch) discs cannot be used.

• Discs with coloring on the recording sur face or
discs that are dir ty cannot be used.

• This unit can only play the CDs with

.
This unit may not correctly play discs which do
not have the mark .

• You cannot play a disc that has not been
finalized. (For the finalization process see your
writing software, and your recorder instruction
manual.)

Ñ Erase the personal information

Before giving or selling this unit to others, be sure
to delete the information (mail, search logs, etc.)
stored in this unit by yourself and confirm that the
data has been deleted.
We shall not be liable for any damage caused by
leakage of undeleted data.

1. Press the <HOME> button.

2. Press the <MENU> button.

3. Touch [Setting].

4. Touch [Backup & Reset].

5. Touch [Factory data reset].

6. Enter owner password. Touch [Rest].

7. Touch [ERASE].

English ñ 3

Ñ About the front panel

When removing the produc t from the box or
installing it, the front panel may be positioned
at the angle shown in (Fig. 1). This is due to the
characteristics of mechanism the product is
equipped with.
When the product is first powered on works
properly, the front panel will automatically move
into the position (initial set ting angle) shown in
(Fig. 2).

Ñ How To Reset Your Unit

If the unit or the connected unit fails to operate
properly, reset the unit.

1 Press the <Reset> button.

The unit returns to factor y settings.

(F ig. 1)

(Fig. 2)

Ñ Cleaning The Unit

If the faceplate of this unit is stained, wipe it with a
dry sof t cloth such as a silicon cloth. If the faceplate
is stained badly, wipe the stain off with a cloth
moistened with neutral cleaner, then wipe it again
with a clean sof t dry cloth.

! CAUTION

• Applying spray cleaner directly to the unit may
affect its mechanical parts. Wiping the faceplate
with a hard cloth or using a volatile liquid such as
thinner or alcohol may scratch the surface or erase
screened print.

✎ NOTE

• Disconnect the USB device before pressing the
<Reset> button. Pressing the <Reset> button with
the USB device connected can damage the data
stored in the USB device. For how to disconnect the
USB device, see How t o Play Music (P.12).

• When the unit is turned on after resetting, the Initial
SETUP screen appears. See Firs t Step (P.6).

4 ñ English

Features of Connected systems

By connecting this unit to Internet, you can use various services.

Ñ Cooperation with Route Collector site

• By uploading music files to Dropbox and creating a play list on Route Collector site, you can
listen to music anywhere through streaming without music files on this unit.

• Speech to Text (STT ) and Text to Speech (T TS).

Ñ Use of internet service

• Streaming ser vice such as Aupeo!.

• Internet service such as email, and social networking service such as Facebook and Twitter.

• Information (RSS, etc.) ser vice.

Ñ 4G, 3G, LTE or EDGE

Ñ Wi-Fi access point

• Connect to Internet using the tethering
function of your smartphone or an Internet
device.

Ñ Wi- Fi (11n /g/b)

Ñ About the account

• To use internet services via this system, you
need to create an account in the Route
Collector site.

• In addition to the owner account, you can
register up to four user accounts.

• You can use a guest account as well.

• By switching among accounts, you can secure
the privacy when using the mail feature or
social media.

Ñ Wi-Fi hotspot

• This unit becomes the Wi-Fi access point
and you can enjoy music and video in a
smartphone Wi-Fi connected by Kenwood
Wireless Link.

Ñ Notes

• TTS (by Nuance)

• STT (by Nuance)
To use the following services, you need
to register the corresponding free or
paid accounts.

• Aupeo!

• Facebook

• Twi tte r

• Dropbox

English ñ 5

First Step

Power on the unit and perform some setup steps
before using.

1 Press the <8HOME> button.

The unit is turned on.

⿠To turn o the unit:

Press the <8HOME> button for 1 second.

✎ NOTE

• “Initial setup” also appears when the unit is reset.

2 Touch the corresponding key and set the

item.

Language Setup

Select the language used for the GUI and input
methods. Default is “English (United States)”.

1) Touch [Language Setup].

2) Select a language from the list.

Wi Setup

Configure settings for connection to Wi-Fi.

1) Touch [Wifi Setup].

2) Slide Wi-Fi to ON.

3) Select the Wi-Fi access point to register from
the list.

4) Enter the Password.

5) Touch [Connect].

After set ting, press the < 6 > button.

Date Setup

Set the date and time.

1) Touch [Date Setup].

2) Touch [Selec t time zone].

3) Select a time zone.

After set ting, press the < 6 > button.

Account Setup

Set the information about the user of this unit.

1) Touch [Account Setup].

See Types of ac counts, Create User Account and
Set Owner Account.

⿠Types of accounts

Administrator

As Administrator, you can create an owner account
and perform initial setup.

You can log in to the system if you have not created
an owner account.

Guest

An account for guests such as your friends.

The guest can operate this unit, but cannot use the
functions related to mail, social media, and Route
Collector site.

Owner

The account for the person who manages this unit.

The owner can use the func tions related to mail,
social media, and Route Collector site.

You can register users such as your family.

User

The account for the user of this unit.

The user can use the functions related to mail, social
media, and Route Collector site.

You can register up to 4 user accounts.

6 ñ English

⿠Create User Account

✎ Preparation

• To register yourself in the Route Collector site as a
user, you need a mail address.

• You can register yourself via the Web.
http://www.route-collector.com/

• This step may be skipped if you have already
registered yourself in the Route Collector site.

1) Touch [Create Account].

2) Enter account information.
You cannot register an account which has
already been used. Register another account
name.

3) Touch [OK].
The account is temporarily registered in the
Route Collector site.

4) Activate the account.
A confirmation mail is sent to the registered mail
address. Open the indicated URL to complete
account registration.

⿠Set Owner Account

1) Touch [Set Owner Account].

2) Enter account information.
Enter the information registered in the Route
Collector site.

3) Touch [OK].

3 Touch [ Nex t].
4 Touch the corresponding key and set the

item.

Color

Set the screen and button illumination color. You
can select whether to perform color scan and adjust
scanning color.

After set ting, touch [

Camera

Set the parameters for the camera.

After set ting, touch [

].

].

5 Touch [Finish].

✎ NOTE

• For details on operations of each setting, refer to the
Instruction Manual.

6 Touch [Administrator] or [Owner].

Language

Select the language used for the control screen and
setting items. Default is “American English (en)”.

After set ting, touch [Enter].

Angle

Adjust the position of the monitor. Default is “0”.

After set ting, touch [

].

English ñ 7

Ñ How to prepare the remote control

Insert two “AAA”/“R03”-size batteries with the and

poles aligned properly, following the illustration

inside the case.

! CAUTION

• Put the remote controller in a place where it will
not move during braking or other operations. A
dangerous situation could result, if the remote
controller falls down and gets wedged under the
pedals while driving.

• Do not leave the battery near re or under direct
sunlight. A re, explosion or excessive heat
generation may result.

• Do not recharge, short, break up or heat the
batter y or place it in an open re. Such actions
may cause the battery to leak uid. If spilled uid
comes in contact with your eyes or on clothing,
immediately rinse with water and consult a
physician.

• Place the battery out of reach of children. In the
unlikely event that a child swallows the battery,
immediately consult a physician.

Functions of the Buttons on the Front Panel

1

2

8

3

4

5
6

7

No. Name/ Motion

G (Eject)

1

• Ejects the disc.

• When the panel is opened, pressing
closes the panel and pressing for 1
second ejects the disc forcibly.

• Pressing for 1 second turns the screen
off. (The function of the [G] button can
be changed to camera view function.
(Instruction Manual P.103))

R, S (VOLUME)

2

• Adjusts volume.

8 ñ English

No. Name/ Motion

HOME

3

• Displays the Home screen (P.11).

• Pressing for 1 second turns the power off.

• When the power off, turns the power on.

MENU

4

• Displays the option menu screen.

• Pressing for 1 second switches AV out
sources.

No. Name/ Motion

6 (Back)

5

• Return to the previously viewed screen.

• Pressing for 1 second displays the Hands
Free screen (Instruction Manual
P.94).

Gesture control sensor

6

• A sensor which detects motions of your
hand. (P.10)

Reset

7

• If the unit or the connected unit fails
to operate properly, the unit returns
to factor y settings when this button is
pressed (Instruction Manual P.129).

Disc insert slot

8

• A slot to inser t a disc media.

Common Operation

Ñ General

There are some functions which can be operated
from most screens.

Ñ List screen

There are some common function keys in the list
screens of most sources.

(Scroll)

etc.

Touch to scroll through tex ts on the display.

Touch keys with various functions are displayed
here.
Displayed keys differ depending on the current
audio source, status, etc.
For examples, see Lis t screen (P.22) in the
Instruction Manual.

Ñ Flick scrolling

You can scroll the list screen by icking the screen
up/down or right/left.

(Mixed Media Search)

Touch to display the Mixed Media Search screen.

(Quic k menu)

Touch to display the quick menu. The content of the
menu are as follows.

: Displays the SETUP Menu screen.
: Displays the Audio Control Menu screen.
: Displays the control screen of current source.

Icon feature differs depending on the source.

(RETURN)

Returns to previous screen.

English ñ 9

Ñ Gesture Control

Without touching the unit, you can control it by a
motion of your hand.

Gesture control sensor

X (Right) *

Displays Current Source Control screen.

W (Left) *

Switches to APPS source.

Y (Up) *

Displays the Home screen.

Z (Down) *

Switches to Facebook in SNS Application.

(Approach)

Displays the Movie control screen when playing a
DVD or a video file.

✎ NOTE

• * You can change operations that work by the

motion of your hand in Gesture Registration.

(Instruction Manual P.10 4).

• Gesture Control works
correctly when you
move your hand in
the detection range
of the sensor that can
be adjusted as shown in the
figure. Selec t Gesture Settings >
Sensibility and adjust it to your
convenient range. (Instruction
Manual P.10 4).

• The range of the detection is
affected by the angle of the
panel or conditions near the unit.

• Unintentional operation may
occur if your hand crosses the
detection range.

• Gesture Control may not work correctly if the cluster
panel hides the sensor or there is an objec t in the
detection range.

• The response of the remote control may become
worse when Gesture Control is turned on.

MIN

6

MAX

Side view

Login

1 Press the <HOME> button to turn the

power on.

2 Select the login user.
3 Enter the password.

(Password)

Enter the registered password.

If you selec ted Administrator or Guest, this screen is
not displayed.

[Auto Login?]

Checking this checkbox allows you to log in to the
system automatically from the next time.

[Login]

Log in to the system.

✎ NOTE

• If you forgot your password, create your new
password on the Route Collector site.
http://www.route-collector.com/

10 ñ English

Operation on the Home Screen

1 Press the <HOME> button to display the

Home screen.

2 Flick the screen left or right to select

the Service panel, Media panel, Source
launcher panel, or Network contents
panel.

1 Service panel

Network widget: Displays the SNS, or RSS.

2 Media panel

Now playing: Displays the title of the song being
played or the name of the station you are listening
to, and allows you to perform simple operations.

Media widget: Displays the Photo frame that shows
photos.

3 Source launcher panel

Allows you select a source.

4 Network contents panel

Allows you to select a network-related application.

Ñ Source launcher panel

(Shortcut icon)

You can register sources you use frequently so that
you can start them quickly.

(All source list)

Displays all sources.

⿠All source list

(All source list)

You can scroll the list screen by flicking the screen
up/d own.

(Home)

Returns to the Source launcher panel.

⿠Moving or deleting of an icon on the
Source launcher panel

1) Touch and hold the icon.

2) Drag the icon to the desired position or
Recycle Bin.

English ñ 11

⿠Adding of a shortcut icon to Source

launcher panel

1) Touch [ ] in Source launcher panel.

2) Touching the icon continuously to display
the Source launcher panel screen.

3) Drag the icon to an empt y space.

How to Play Music

You can play audio les from music CD, disc media,
USB storage device and iPod.

✎ NOTE

• For details on playable file format, media format,
iPod model, etc., refer to the Instruction Manual.

(P.130 )

• To connect with iPod/iPhone/Android the set ting
is necessar y. Refer to

(P.23).

iPod/ i Phone/ Andr oid setup

1 Connect the media you want to play as

shown below.

Disc

1) Press the <G> button to open the front

panel.

2) Inser t the disc into the slot.
The panel closes automatically and playback
starts.

⿠To eject the disc:

1) Press the <G> button.

iPod, USB device

1) Connect the device with each cable.
Playback starts.

⿠To disconnect the device:

1) Touch [G] on the screen and disconnect the
device from the cable.

✎ NOTE

• It applies when you set the iPod/iPhone connection
with cable.

2 Control the music you are listening to on

the source control screen.

The following symbols indicate the keys on the
screen.
The functions of the keys are the same despite the
difference of the source you are listening to.

Touch [ ]

Z

⿠Basic operations from this screen

L

Plays or pauses.

I

Stops playing.

G

Disconnects the device.

E F

Searches the previous/next content.

E F or move the cursor in the center
bar

Fast forwards or Fast backwards (Disc media,
CD, USB device only):

12 ñ English

Repeats current content.

1

2

3

3

Plays all contents in random order.

✎ NOTE

• For other operations, refer to the Instruction Manual.

• If desired key is not displayed in the multi-function
bar, touch the [

] to switch the menu.

3 Search the track/le you want to listen to.

⿠List search

1) Touch center of the screen.
The content list of the media being played
is displayed.
If the information of the current track only
is displayed, touch [
displa y.

] to switch the list

How to Play Movie

You can play DVD video, Video CD ( VCD), movie les
from disc media, iPod and USB storage device.

✎ NOTE

• For details on playable file format, device format,
etc., refer to the Instruction Manual.

1 Connect the media you want to play.

For the method of connecting, see H ow to Play
Music (P.12).

2 Control the movie by touching the

screen.

Each area on the screen has a separate function.

⿠Rened search

1) Touch [ ].

2) Touch the desired refinement method.
The list is refined by the item you selected.

3) Touch the desired item.

✎ NOTE

• For details on searching operations, refer to Search
Operation (P.62) in the Instruction Manual.

No. Name/Motion

Displays the movie control screen.

1

Displays the Source Control screen.

2

• Searches the next /previous content or file.

3

• Scrolling from center of display to left
or right per forms fast backward or fast
forward.
To stop fast backward/for ward, touch center
of the display.*

• *1 For iPod/USB, this function may be unavailable
depending on the playing file format.

1

✎ NOTE

• For operations on the source control screen, see

How to Play M usic (P.12).
However, searching by category/link/album ar twork
is not available.

English ñ 13

How to Listen to the Radio

1 Press the <HOME> button twice to the

Source launcher panel.

2 Touch [ ] in the Source launcher panel.
3 Touch [TUNER].

The unit switches to the Radio tuner source.

4 Operate on the source control screen.

⿠Station search

1) Touch [ ].
Sub function menu appears.

2) Touch [AM] or [FM] to select the band.)

3) To uch [ 4] or [¢] to tune in the desired
station.

⿠Auto memory

1) Touch [ ].
Sub function menu appears.

2) Touch [AM] or [FM] to select the band.

3) Touch [

4) To uc h [AME].

5) Tou ch [ 4] or [¢] in the sub func tion
menu.
Auto memory starts.

⿠Recalling the preset station

1) Touch [P#].
You can also display the preset list by
touching the frequency display in the center.

✎ NOTE

• For other operations, see Radio Basic Operation
(P.82) in the Instruction Manual.

].

How to Make a Phone Call

You can use your Bluetooth cell-phone when paired
to this unit.

1 Register your cell-phone to the unit.

Follow as the procedures shown below. For
detailed operation, see Regi stering the
Bluetooth Unit (P.91) in the Instruc tion
Manual.

1) Press the <HOME> button t wice to the
Source launcher panel.

2) Touch [

3) Touch [STANDBY].

4) Press and hold the < 6 > button.

5) Touch [

6) Touch [Search].
Searched Device List screen appears.

7) Select your cell-phone from the displayed list
in the Searched Device List screen.

8) Enter PIN code form the cell-phone.
Registering is completed.
The PIN code is set to “0000” as default.

] in the Source launcher panel.

].

14 ñ English

2 Connect your cell-phone to the unit.

1) Touch the device name you want to connect
in the Bluetooth SETUP screen.

2) Touch [ON] of [ TEL(HFP)] in the BT
Connection Settings screen.
The selected device is connected to the unit.

When registration of your cell-phone is
completed, the phone book of the cell­phone is automatically downloaded to this
unit.

3) Touch [

].

✎ NOTE

• Touch [Audio(A2DP)] if you want to connect the
device as an audio player.

3 Make or receive a phone call.

See the table below for each operation method.

Call using the phonebook

1) Touch [

2) Select the name from the list.

3) Select the number from the list.

4) Touch [

Call using the preset number

1) Touch [Preset #] to start calling the
corresponding phone number.

Call by voice

You can make a voice call using the voice
recognition function of the cell-phone.

1) Touch [

2) Pronounce the name registered in the cell­phone.

].

].

].

✎ NOTE

• For detailed operation, see Us ing Hands-Fr ee
Feature (P.94) in the Instruction Manual.

Call by entering a phone number

1) Touch [

2) Enter a phone number with number keys.

3) Touch [

Call using call records

1) Touch [
Calls), or [

2) Select the phone number from the list.

3) Touch [

].

].

] (Incoming Calls), [ ] (Outgoing

] (Missed Calls).

].

English ñ 15

Installation

Ñ Before Installation

Before installation of this unit, please note the
following precautions.

! WARNINGS

• If you connect the ignition wire (red) and the
batter y wire (yellow) to the car chassis (ground),
you may cause a short circuit, that in turn may
start a re. Always connect those wires to the
power source running through the fuse box.

• Do not cut out the fuse from the ignition wire
(red) and the battery wire (yellow). The power
supply must be connec ted to the wires via the
fuse.

! CAUTION

• Install this unit in th e console of your vehicle.
Do not touch the metal part of this unit during
and shortly after the use of the unit. Metal part
such as the heat sink and enclosure become hot.

✎ NOTES

• Mounting and wiring this product requires skills and
experience. For best safety, leave the mounting and
wiring work to professionals.

• Make sure to ground the unit to a negative 12V DC
power supply.

• Do not install the unit in a spot exposed to direct
sunlight or excessive heat or humidit y. Also avoid
places with too much dust or the possibility of water
splashing.

• Do not use your own screws. Use only the screws
provided. If you use the wrong screws, you could
damage the unit.

• If the power is not turned ON (“PROTECT” is
displayed), the speaker wire may have a short­circuit or touched the chassis of the vehicle and
the protection function may have been activated.
Therefore, the speaker wire should be checked.

• If your car’s ignition does not have an ACC position,
connect the ignition wires to a power source that
can be turned on and off with the ignition key. If you
connect the ignition wire to a power source with a
constant voltage supply, such as with battery wires,
the batter y may be drained.

• If the console has a lid, make sure to install the unit
so that the faceplate will not hit the lid when closing
and opening.

• If the fuse blows, first make sure the wires aren’t

touching to cause a short circuit, then replace the
old fuse with one with the same rating.

• Insulate unconnected wires with vinyl tape or other
similar material. To prevent a short circuit, do not
remove the caps on the ends of the unconnected
wires or the terminals.

• Connect the speaker wires correctly to the terminals
to which they correspond. The unit may be
damaged or fail to work if you share the ¤ wires or
ground them to any metal part in the car.

• When only two speakers are being connected to
the system, connect the connectors either to both
the front output terminals or to both the rear output
terminals (do not mix front and rear). For example,
if you connec t the ¢ connector of the left speaker
to a front output terminal, do not connect the ¤
connector to a rear output terminal.

• After the unit is installed, check whether the brake
lamps, blinkers, wipers, etc. on the car are working
properly.

• Mount the unit so that the mounting angle is 30°
or less.

• This unit has the cooling fan (P.18) to decrease
the internal temperature. Do not mount the unit in a
place where the cooling fan of the unit are blocked.
Blocking these openings will inhibit the cooling of
the internal temperature and result in malfunction.

• Do not press hard on the panel surface when installing
the unit to the vehicle. Other wise scars, damage, or
failure may result.

• Reception may drop if there are metal objects near
the Bluetooth antenna and WI-FI receiver.

Bluetooth antenna area

M4 x 8mmMAX

iPod/
AV-IN2

REMO

TE

POWER

5V=500mA

FUSE 10A

WiFi

Recever

WI-FI receiver

• Install the WI-FI receiver besides the place enclosed
by the metal.

• Gesture control may not work correctly if the unit is
installed deeply inside the cluster panel.

16 ñ English

Ñ Supplied accessories

First of all, make sure that all accessories are
supplied with the unit.

1 ...1 4 ...1

2 ...1 5 ...1

(2 m)

3 ...6 6 ...1

(M5x6m m)

✎ NOTE

• Make sure that the unit is installed securely in place.
If the unit is unstable, it may malfunction (eg, the
sound may skip).

Ñ Microphone unit

1) Check the installation position of the

microphone (accessory 4).

2) Clean the installation surface.

(3 m)

3) Install the microphone.

4) Wire the microphone cable up to the unit with it
secured at several positions using tape or other
desired method.

4

Ñ Unit

1) To prevent a short circuit, remove the key from

the ignition and disconnec t the ¤ terminal of
the battery.

2) Make the proper input and output wire
connections for each unit.

3) Connect the speaker wires of the wiring harness.

4) Connect the wiring harness wires in the
following order;
ground, battery, ignition.

5) Connec t the wiring harness connector to the
unit.

6) Install the unit in your car.

7) Reconnect the ¤ terminal of the bat tery.

8) Press the <Reset> button. (P. 4)

9) Perform the Initial Setup.
See Firs t Step (P.6).

3

Car Bracket

3

Fix a cable with a commercial item of tape.

Remove the separator of the microphone, and stick
the microphone to the place shown above.

Adjust the direction of the microphone to the
driver.

✎ NOTE

• Install the microphone as far as possible from the
cell-phone.

English ñ 17

Ñ Connecting wires to terminals

HDMI/MHL

Connect to the terminal that is grounded

when either the telephone rings or during

To use the Mute feature, you need to hook

up this wire to your telephone by using a

commercial telephone accessory.

When using the optional power amplifier,

connect to its power control terminal.

conversation.

If no connections are made,
do not let the cable come out from the tab.

MIC

AV-IN/OUT

AV-OUT
AUDIO

SW FRONT REAR

R L

Brown (Mute control wire)

Blue/White
(Power control wire)

Pin Color and functions

A1 Orange/White Dimmer
A2 Yellow Battery
A4 Red Ignition (ACC)
A5 Blue Antenna control
A6 Black Earth (Ground) Connection
A8/A 7 White
A10/ A9 Gray
B2/B1 Green
B6/B5 P urple

*Speaker Impedance: 4-8 Ω

M4 x 8mmMAX

iPod/

AV-IN2

REMO

IN

cessory 1

Ac

MUTE

P. CONT

¢

/ White/Black

¢

/ Gray/Blac k

¢

/ Green/B lack

¢

/ Purple/ Black ¤Rear Right

POWER

FUSE 10A

Connect to vehicle's harness.

t to vehicle's harness.

Connec

¤

Front Lef t

¤

Front Right

¤

Rear Lef t

18 ñ English

Ñ System connection

Accessory 4:
Bluetooth Microphone

FM/AM antenna input

cessory 5

Ac

HDMI/MHL

MIC

AV-IN/OUT

AV-OUT
AUDIO

SW FRONT REAR

R L

AV-OUT Output

- Audio Output

AV-OUT Output

- Visual Output

AV-IN1 input

- Yellow (Visual input)

- Red (Audio Right input)

- White (Audio Left input)

Rear view camera input

M4 x 8mmMAX

Cooling fan

WI-FI receiver

- Reception may drop if there
are metal objects near the

WiFi

Bluetooth antenna and WI-FI
receiver.

- Install the WI-FI receiver
besides the place enclosed by
the metal.

Connect to the vehicle’s
parking brake detection
switch harness.

iPod/

AV-IN2

REMO

IN

Accessory 2

POWER

Fuse
(10A)

Receiver

5V=500mA

FUSE 10A

Light Green (Parking sensor wire)

PRK SW

For best safety, be sure to connect
the parking sensor.

Purple/White (Reverse sensor wire)

REVERSE

Connect to vehicle’s reverse lamp harness
when using the optional rear view camera.

CAMERA

FRONT VIEW

Green/Red

Green/White

Front view camera input

To CMOS-3xx series (Optional
Accessory) camera control
terminal

English ñ 19

Ñ 3 way speaker system setup

Region code 3 area

Connect the speaker wires

HDMI/MHL

MIC

AV-IN/OUT

AV-OUT
AUDIO

R L

Subwoofer Preout

- Red (Audio Right Output)

- White (Audio Left Output)

Mid Range Preout

- Red (Audio Right Output)

- White (Audio Left Output)

Tweeter Preout

- Red (Audio Right Output)

- White (Audio Left Output)

When connecting to an external amplifier, connect
its ground wire to the car's chassis to avoid damaging
the unit.

M4 x 8mmMAX

SW FRONT REAR

Preout

RCA Cable
(sold separately)

Power amplifier
(optional accessory)

Speaker

Input

iPod/

AV-IN2

Join the wires

REMO

IN

POWER

FUSE 10A

1
2
3

Accessory 1

Speaker impedance: 4-8 Ω

Green/Black

Green

Purple/Black

Purple

White/Black

White

Gray/Black

Gray

+

+

+

+

To tweeter left
speaker

To tweeter right
speaker

To mid range left
speaker

To mid range right
speaker

Pin Color

¢

A8/A 7 White

/ White/Black
A10/ A9 Gray ¢ / Gray/Blac k
B2/B1 Green ¢ / Green/B lack
B6/B5 P urple ¢ / Purple/ Black

¤

¤

¤

¤

NOTE

• For how to connect speaker wires to terminals
other than speaker terminals and Preout
terminals, see Connec ting wires to ter minals
(P.18) and System connection (P.19).

20 ñ English

✄

Cut the cable. Insulate the cut cable by
putting tape on the cable conductor.

Switching between speaker systems

Switch to the 3 way speaker system following the
procedure below.

!

• Be sure to set the speaker network correc tly.
Connecting 3 way speakers with the 2 way mode
selected can break the speakers.

1 Press the <HOME> button twice to the

Source launcher panel.

2 Touch [ ] in the Source launcher

panel.

3 Touch [STANDBY].
4 Press the <∞> button and <0> button

for 1 second at the same time.

Speaker system select screen appears.

5 Touc h [3wa y].

A confirmation screen appears.

6 Touc h [Ye s].

The 2 way speaker system is switched to the 3 way
speaker system.

✎ NOTE

• When the 3-way speaker system is selected,
the following functions are disabled. (See the
Instruction Manual.)

- Zo ne Control (P.120)

- DS P select (P.116)

- Fader of Co ntrolling G eneral Audio (P.116 )

• For speaker setup and crossover setup, see Set ting
Aud io (P.112 ) in the Instruction Manual.

English ñ 21

Ñ Optional accessory connection

AV-IN/OUT

MIC

AV-OUT

AUDIO

SW FRONT REAR

R L

POWER

FUSE 10A

REMO

TE

M4 x 8mmMAX

iPod/

AV-IN2

HDMI/MHL

55 4

iPod/

iPhone

1 2

3

5

3

2

1

4

HDMI/ MHL input
MHL maximum power supply current :
5 V

900 mA

When you connect the cable to HDMI/MHL
terminal, remove the fixture. After connecting the
cable, put the fixture again.

HDMI/ MHL con nector

Fixture

iPod input / AV-IN2 (CA-C3AV; Optional
Accessory) input
(iPod/ AV-IN2 switchable)

iPod/ USB terminal (0.8m)
iPod/ USB maximum power supply current :
5 V

1 A

USB device
(sold separately)

KCA-iP103 (0.8m)
(Optional Accessory)

3

B: Music

A: Video and Music (HDMI)

KCA-HD100 (1.8m)
(Optional Accessory)

1

3

KCA-iP103 (0.8m) (Charging)
(Optional Accessory)

3

D: Music

C: Video and Music (analog)

AV Output (1.8m)

2

3

USB terminal (0.8m)

KCA-iP102 (0.8m)

(Optional Accessory)

Rear Preout

- Red (Audio Right Output)

- White (Audio Left Output)

iPod/iPhone

(sold separately)

Lightning Digital AV

(sold separately)

(sold separately)

iPod

KCA-iP202

(Optional Accessory)

3

Adapter

Accessory 6 Steering remote harness

Connect to vehicle's steering remote harness.
Contact your Kenwood dealer for details.

Pin Color and functions

C6 G ray/Re d Ground
C7 Light green/Red Input 1
C8 Purple/Re d Input 2

22 ñ English

R L

When connecting to an external amplifier, connect
its ground wire to the car's chassis to avoid damaging
the unit.

C6 C7C8

Front Preout

- Red (Audio Right Output)

- White (Audio Left Output)

SW FRONT REAR

Subwoofer Preout

- Red (Audio Right Output)

- White (Audio Left Output)

Android smartphone
(sold separately)

KCA-MH100 (1.8m)
(Optional Accessory)

NOTE

• For the connec tion and the setti ng of iPod/iPhone re fer
to iPod/iPhone connection and setting (P.23).

• For the connec tion and the setti ng of Android
smartp hone refer to Android connection (P.23).

iPod/ iPhone/ Android setup

Ñ Android connection

To connect the Android device with this unit,
the cable (sold separately) and the prole which
your Android device supports are necessary as
follows:

⿠ To listen to music and watch video of APPS

source

– MHL device
– KCA- MH100
– Bluetooth profile: SPP
– Application link setup: HDMI/MHL + BT

(P. 24)

⿠ To listen to music of APPS source

– Bluetooth profile: A2DP
– Bluetooth profile: SPP
– Application link setup: Bluetooth ( P.24)

⿠ To listen to music of Bluetooth Audio source

– Bluetooth profile: A2DP
– Bluetooth profile: AVRCP

✎ NOTE

• When you select Pandora source the setting of
Application link setup (P. 24) is also necessary.

• In the APPS source, some functions can be
controlled from this unit and they depend on the
applications. Refer to Apps Operation (P.70) in
the Instruction Manual.

• Do not leave the cable or the adapter made by
other makers inside the car. It might lead the
malfunction caused by heat.

Ñ iPod/iPhone connection and setting

⿠Connectable iPod/iPhone

1

The following models can be connected to this
unit.

Made for Typ e

• iPhone 5s

• iPhone 5c

• iPhone 5

• iPhone 4S

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

• iPod touch (5th generation)

• iPod touch (4th generation)

• iPod touch (3rd generation)

• iPod touch (2nd generation)

• iPod touch (1st generation)

• iPod classic

• iPod with video

• iPod nano (7th generation)

• iPod nano (6th generation)

• iPod nano (5th generation)

• iPod nano (4th generation)

• iPod nano (3rd generation)

A B E
A B E
A B E
C D E
C D F
C D F
C D F
C D F
A B E
C C D F
C D F
C D F
C D F
D
C D
A B F
D
C D
C D
C D

⿠iPod/iPhone connection

To connect the iPod/iPhone with this unit, the
cable, adapter (both sold separately), and the
prole which your iPod/iPhone supports are
necessary as follows:

A To listen music and watch video with

Lightning connector device

– Lightning Digital AV Adapter
– KCA-HD100
– KCA- iP103
– Bluetooth profile: SPP
– iPod connection setup: HDMI + BT ( P.24)

B To listen music with Lightning connector

device

– KCA- iP103
– iPod connection setup: USB 1Wire (P.24)

C To listen music and watch video with 30-pin

connector device (analog)

– KCA-iP202
– iPod connection setup: USB+AV-IN (P. 24)

D To listen music with 30-pin connector device

– KCA- iP102
– iPod connection setup: USB 1Wire (P.24)

English ñ 23

E To listen to music via Bluetooth

– Bluetooth profile: A2DP
– Bluetooth profile: SPP
– iPod connection setup: Bluetooth (P.24 )

F To listen to music of Bluetooth Audio source

– Bluetooth profile: A2DP
– Bluetooth profile: AVRCP

✎ NOTE

• When you select Pandora source the setting of
Application link setup (P. 24) is also necessary.

• In the APPS source, some functions can be
controlled from this unit and they depend on the
applications. Refer to Apps Operation (P.70) in
the Instruction Manual.
For the setting refer to Application link setup
(P. 24).

• Do not leave the cable or the adapter made by
other makers inside the car. It might lead the
malfunction caused by heat.

⿠iPod/iPhone connection setup

When you rst selec t iPod as a source, the setting
screen of the iPod/iPhone connection will appear.

1 Press the <HOME> button twice to the

Source launcher panel.

USB 1Wire

B D : Select when connec ting with KCA-iP103 or
KCA -iP102.

HDMI + BT

A : Select when connec ting with KCA-HD100 and
Lightning Digital AV Adapter.

Bluetooth

E : Select when connec ting via Bluetooth only.

6 Touc h [Next].

Confirmation screen appears.

7 Touch [Done].

✎ NOTE

• When you select “HDMI + BT” or “Bluetooth” in step
5, Bluetooth device selection screen will appear.
Select the iPod/iPhone to be connected.

2 Touch [ ] in the Source launcher

panel.

3 Touch [iPod].

iPod connection setup screen appears.

4 Touc h [CHANGE ].
5 Set each item as follows.

USB + AV-IN

C : Select when connec ting with KCA-iP202.

24 ñ English

If a connectable Bluetooth device is not displayed,
touch [Search] and do the pairing of the devices.

• “iPod connection setup” also appears when the unit
is reset.

• The set ting of “iPod connection setup” is just for the
unit and regardless of the account.

Ñ Application link setup

When you rst selec t Apps as a source, the setting
screen for the connec tion with the device installed
the apps will appear.

1 Press the <HOME> button twice to the

Source launcher panel.

2 Touch [ ] in the Source launcher

panel.

3 Touch [APPS].

Application link setup screen appears.

4 Touc h [CHANGE ].
5 Select the device installed the apps.

6 Select the way to connect the device with

this unit.
⿠When selecting [iPod/iPhone]

For the setting items refer to iPod/iPhone
connection setup (P.24).

⿠When selecting [Android/Other]

8 Touch [Done].

✎ NOTE

• For the details of the necessary cable and adapter
to connect with iPod/iPhone and Android, refer to
iPod/iPhone connection and setting (P.23)
and Android connection (P.23).

• When you select “HDMI + BT”, “HDMI/MHL +
BT” or “Bluetooth” in step 6, Bluetooth device
selection screen will appear. Selec t the device to be
connected.

If a connectable Bluetooth device is not displayed,
touch [Search] and do the pairing of the devices.

• “Application link setup” also appears when the unit
is reset.

• The set ting of “Application link setup” is just for the
unit and regardless of the account.

HDMI/MHL + BT

Select when connec ting with KCA-MH100.

Bluetooth

Select when connec ting via Bluetooth only.

7 Touc h [Next].

Confirmation screen appears.

English ñ 25

About This Unit

Ñ Requirements Pandora®:

Requirements for listening to the Pandora® are as
follows:

• A smartphone with the latest Pandora application
installed.

• A Pandora account (if you do not have an account,
create one for free using the mobile app or on
www.pandora.com).

• An active internet connection.

iPhone or iPod touch

• Apple iPhone or iPod touch with iOS 3 or later
installed.

• Latest version of the Pandora application (search
App Store for Pandora and install).

Android™

• Latest version of the Pandora Android application
(search Google Play for Pandora and install).

BlackBerry®

• Visit www.pandora.com from the built in browser to
download the Pandora application.

• Bluetooth must be built in and the following profiles
must be supported.

- SPP (Serial Port Profile)

- A2DP (Advanced Audio Distribution Profile)

✎ NOTE

• The Pandora service is available only in the U.S,
Australia and New Zealand.

• Because Pandora® internet radio is a third-party
service, the specifications are subject to change
wihtout prior notice. Accordingly, compatibility
may be impaired or some or all of the services may
become unavailable.

• Some Pandora® functionality cannot be operated
from this unit.

• For issues using the Pandora® application, please
contact Pandora at [e-mail]

Ñ Copyrights

• The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks by
JVC KENWOOD Corporation is under license. Other
trademarks and trade names are those of their
respective owners.

• The “AAC” logo is a trademark of Dolby Laboratories.

• “Made for iPod” and “Made for iPhone” mean that an

electronic accessor y has been designed to connect
specifically to iPod or iPhone, respectively, and has
been certified by the developer to meet Apple
performance standards. Apple is not responsible for
the operation of this device or its compliance with
safety and regulatory standards. Please note that the
use of this accessory with iPod or iPhone may affect
wireless performance.

• iPhone, iPod, iPod classic, iPod nano, and iPod touch
are trademarks of Apple Inc., registered in the U.S.
and other countries.
Lightning is a trademark of Apple Inc.

•

• This item incorporates copy protection technology

• Manufactured under license from Dolby

• Adobe, Acrobat and Reader are either registered

• Android is a trademark of Google Inc.

• Twitter is a registered trademark of Twitter, Inc.

• Facebook® is a registered trademark of Facebook

• Nuance is a registered trademark of Nuance

• “aupeo” is a trade mark of Aupeo Ltd.

• Dropbox is a trademark of Dropbox Inc.

• The terms HDMI and HDMI High-Definition

• MHL and the MHL logo are a trademark or

• ABOUT DIVX VIDEO: DivX® is a digital video

is a trademark of DVD Format/Logo
Licensing Corporation registered in the U.S., Japan
and other countries.

that is protected by U.S. patents and other
intellectual property rights of Rovi Corporation.
Reverse engineering and disassembly are
prohibited.

Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.

trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other
countries.

Inc.

Communications, Inc.

Multimedia Interface, and the HDMI logo are
trademarks or registed trademarks of HDMI
Licensing LLC in the United States and other
countries.

registered trademark of MHL, LLC.

- Incorporates MHL 2

format created by DivX, LLC, a subsidiary of Rovi
Corporation. This is an official DivX Certified® device
that plays DivX video. Visit div x.com for more
information and soft ware tools to convert your files
into DivX videos.

26 ñ English

• ABOUT DIVX VIDEO -ON-DEMAND: This DivX
Certified® device must be registered in order to play
purchased DivX Video- on-Demand (VOD) movies.
To obtain your registration code, locate the DivX
VOD section in your device setup menu. Go to vod.
divx.com for more information on how to complete
your registration.

• DivX®, DivX Certified® and associated logos are
trademarks of Rovi Corporation or its subsidiaries
and are used under license.

• QR Code ® is registered trademarks of DENSO WAVE
INCORPORATED in JAPAN and other countries.

• AVC
THIS PRODUCT IS LICENSED UNDER THE AVC
PATENT PORTFOLIO LICENSE FOR THE PERSONAL
USE OF A CONSUMER OR OTHER USES IN WHICH IT
DOES NOT RECEIVE REMUNERATION TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE AVC STANDARD
(“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO
THAT WAS ENCODED BY A CONSUMER ENGAGED
IN A PERSONAL ACTIVITY AND/OR WAS OBTAINED
FROM A VIDEO PROVIDER LICENSED TO PROVIDE
AVC VIDEO. NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA,
L.L.C. SEE HT TP://WWW.MPEGLA.COM

• MPEG-4 Visual
THIS PRODUCT IS LICENSED UNDER THE MPEG­4 VISUAL PATENT PORTFOLIO LICENSE FOR
THE PERSONAL AND NON-COMMERCIAL USE
OF A CONSUMER FOR (i) ENCODING VIDEO IN
COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD
(“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG­4 VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL
ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED BY MPEG LA TO PROVIDE
MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION INCLUDING THAT RELATING TO
PROMOTIONAL, INTERNAL AND COMMERCIAL USES
AND LICENSING MAY BE OBTAINED FROM MPEG LA,
LLC. SEE HTTP://WWW.MPEGLA.COM.

• libFL AC
Copyright (C) 2000,2001,2002,2003,2004,2005,2006,2
007,2008,2009 Josh Coalson
Redistribution and use in source and binar y forms,
with or without modification, are permitted
provided that the following conditions are met:

- Redistributions of source code must retain the
above copyright notice, this list of conditions and

the following disclaimer.

- Redistributions in binary form must reproduce the
above copyright notice, this list of conditions and
the following disclaimer in the documentation and/
or other materials provided with the distribution.

- Neither the name of the Xiph.org Foundation
nor the names of its contributors may be used to
endorse or promote produc ts derived from this
software without specific prior written permission.
THIS SOFT WARE IS PROVIDED BY THE COPYRIGHT
HOLDERS AND ONTRIBUTORS ``AS IS’’ AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL
THE FOUNDATION OR CONTRIBUTORS BE LIABLE
FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT
OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE,
DATA , OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,
OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILIT Y OF
SUCH DAMAGE.

English ñ 27

Ñ KENWOOD Route Network Service “Route

Collector” User’s Agreement

This KENWOOD Route Network Service “Route
Collector ” User’s Agreement (“Agreement”) sets forth
the terms and conditions for use of the KENWOOD
Route Network Service “Route Collector” provided by
JVCKENWOOD Corporation (“Service”) to the users
who fulfill the requirements for “Conditions of Use” in
the paragraph 1 (“User(s)”), and the rules for handling
User’s information necessary for use this Service.

1. Conditions of Use

Users who desire to take advantage of this Service
must however first register themselves upon agreeing
to the terms of this Agreement. This Service may only
be used by Users for personal use, not for commercial
use.

The terms of this Agreement may be revised or
modified as necessar y at our option without prior
notice. In such event, Users shall hereby agree to the
application of any such revisions or modifications as a
condition to continued use of the Service.

Also, Users shall be solely responsible for managing
and using their registered user account names
and passwords. In no event can we accept any
responsibility for any problems or damages resulting
from the User’s management and usage of its user
account name and password management.

2. Period for the Service

Users may in principal continue to use the Service
as long as it is being provided by us. However, the
Service may be changed, suspended or cancelled at
our option without prior notice.

3. Disclaimer

The User shall undertake use of the Service at its own
individual responsibility, and accordingly we shall not
assume any responsibility for usage of the Service by
the User, including but not limited to the examples
as follows.

(1) We shall make no warranty as to completeness,

legality, moral correctness, recentness, and
appropriateness of the Ser vice and the User shall
assume full risk and individual responsibility for
using the Ser vice.

(2) We shall assume no responsibility for any loss or

damage that may be incurred by the User due to its
use of or inability to use the Service, regardless of
whether such loss or damage is direct or indirect,
foreseeable or unforeseeable, including but not

limited to special damages.

(3) We shall not be involved in nor assume

responsibility for any ac ts, problems, and other
issues between Users.

(4) Should any third parties suffer losses or damages

as a result of the User ’s use of the Ser vice, we shall
assume no responsibility therefor.

(5) Should the User suffer losses or damages from

misuse by any third par ties of the User’s registered
user account name or password for the Service, we
shall assume no responsibilit y therefor.

4. Prohibited Mat ters

Concerning the use of the Ser vice, the following or
similar acts by the User are prohibited. Further, should
we determine that the User has violated the terms of
this Agreement, we reserve the right to suspend use
of the Service by the User without prior notice, or take
other necessary measures as we may deem necessary.
In such case, we bear no obligation to disclose our
reasons therefor.

(1) Acts for commercial purposes or gain

(2) Use of the account name or password of his own or

any third parties for improper purposes

(3) Infringement or acts that may likely infringe on

the intellectual property rights of third parties
(including but not limited to copyrights, design
rights, patent, utility model rights, trademark, trade
secrets, and know-how)

(4) Infringement or acts that may likely infringe on the

proprietary rights, honor, trustworthiness, portrait
rights, privacy, publicity rights, and other rights or
profits

(5) Dissemination or distribution or acts that may likely

constitute dissemination or distribution of contents
that may be offensive to public orals and morals, or
defamator y to third parties

(6) Criminal acts, acts associated with criminal acts, or

acts that may likely be criminal

(7) Dissemination or distribution of junk mail, spam or

malicious programs such as the computer viruses

(8) Dissemination or distribution of false information

(9) Obstruction or acts that may likely constitute

obstruc tion of the operation of the Service

(10) Acts that cause or that may likely cause trouble,

disadvantages or damages to us or third parties

(11) Use of the Service for illegal purposes

(12) Other acts deemed inappropriate by us

28 ñ English

5. Compensation Claim

Should any complaints, lawsuits or similar claims be
asserted against us by other Users or third parties for
any reasons attributable to the User in connec tion
with the Ser vice, we reserve the right to claim from
the concerned User any damages, costs and expenses
which we may incur (including compensation,
attorney fees and legal costs).

6. Ownership of Intellectual Proper ty Rights

All intellectual proper ty rights (including but not
limited to copyrights, design rights, patent, utility
model rights, trademark, trade secrets, and know­how), the portrait rights, privacy, publicity rights
and other personal rights, and proprietary rights or
other property rights of the information, tex t, image,
program, layout, design, architecture, and others
related to the Ser vice are owned by us, or provided
to us under license from the rights holder except for
the rights of the thing which are made by User. The
unauthorized copying, alteration, or sublicensing of
such intellectual proper ty rights, in whole or in part,
without our consent may be prohibited by applicable
law.

Further, our trade names, trademarks, logo marks and
product names, some of which are registered, are
used as names and symbols for commercial purposes.
Also, trademarks, ser vice names, symbols and other
marks belonging to other parties, such as companies
and individuals, are also included in the Ser vice.

7. Use of Public Information

We may save and store all information (including but
not limited to tex t information, image information,
and others) that were released, posted, uploaded, or
saved by User via the Service. Furthermore, User shall
agree that we may use such information as described
previously in every possible condition toward smooth
operation and improvement of the Service.

8. Usage Fee

The Service shall be offered without charge to the
User. However, the environment that is necessary for
use this Service shall be prepared by User on his own
responsibility and liability including any miscellaneous
expenses such as provider, electricit y, packet
communication, and others.

9. User Information

In order to take advantage of the Service, the User
must first register user account name, password,

the User’s valid e-mail address and arbitrary
User’s information via the next page (collectively
“Information”). We shall properly manage and keep
Information as important data in conformity with
our “Privacy Policy” and shall only use Information for
issuing notices regarding completion of registration,
maintenance of Ser vice, suspension of Service, and
procedures for reissuance of passwords. We shall not
disclose Information for any purposes other than the
foregoing without the prior consent of the User.

10. Governing Law

The Agreement shall be governed by and construed
in accordance with the laws of Japan.

English ñ 29

Ñ About QAU0569 (USB Wi-Fi® Adapter)

The Wi-Fi Adapter is attached to this unit when
shipped from the factory. When the adapter is
removed, store it in a safe place.

Ñ The marking of products using lasers

DNR935WBTM:

CLASS 1
LASER PRODUCT

The label is at tached to the chassis/case and says
that the component uses laser beams that have been
classified as Class 1. It means that the unit is utilizing
laser beams that are of a weaker class. There is no
danger of haz ardous radiation outside the unit.

Ñ Eski Elektrik ve Elektronik Ekipmanların

İmha Edilmesi Hakkında Bilgi (ayrı atık
toplama sistemlerini kullanan ülkeleri için
uygulanabilir)

Sembollü (üzerinde çarpı işareti olan çöp

kutusu) ürünler ev atıkları olarak atılamaz.
Eski elek trik ve elek tronik ekipmanlar,
bu ürünleri ve ürün atıklarını
geri dönüştürebilecek bir tesiste
değerlendirilmelidir. Yaşadığınız bölgeye
en yakın geri dönüşüm tesisinin yerini
öğrenmek için yerel makamlara müracaat
edin. Uygun geri dönüşüm ve atık
imha yöntemi sağlığımız ve çevremiz
üzerindeki zararlı etkileri önlerken
kaynakların korunmasına da yardımcı
olacak tır.

Declaration of Conformity with regard to the
EMC Directive 2004/108/EC

Declaration of Conformity with regard to the
R&TTE Directive 1999/5/EC

Declaration of Conformity with regard to the
RoHS Dir ective 2011/65/EU

Manufacturer:

JVC KENWOOD Corporation
3-12, Moriyacho, Kanagawa-ku, Yokohama-shi,

Kanagawa 221-0022, JAPAN

EU Representative:

JVCKENWOOD NEDERLAND B.V.
Amsterdamseweg 37, 1422 AC UITHOORN, The
Netherlands

English

Hereby, JVC KENWOOD declares that this unit
DNR935WBTM is in compliance with the essential
requirements and other relevant provisions of

Directive 1999/5/EC.

Türkçe

Bu vesileyle JVC KENWOOD, DNR935WBTM ünitesinin,
1999/5/EC Direktifinin başlıca gereksinimleri ve diğer
ilgili hükümleri ile uyumlu olduğunu beyan eder.

For Turkey

Bu ürün 28300 sayılı Resmi Gazete’de yayımlanan Atik
Elektrikli ve Elektronik Eşyalarin Kontrolü Yönetmeliğe
uygun olarak üretilmiştir.

30 ñ English

English ñ 31
