Karcher HD 10-25 S VEX User Manual

www.karcher.com
5.961-066 A 2006919 10/03
HD 10/25 S VEX
2
English
Português
Pºcc®å¼
Lietuviškai
Latviski
Eesti keeles
5
13
21
29
37
45
53
4
HD 10/25 S VEX
English Operating Instructions HD 1 0/ 25 S VEX
5
Unit components
Please fold out illustration page at the front
1 Hand-held spray gun 2 Lever of hand-held spr ay gun 3 High-pressure hose 4 Handgun support 5 Detergent metering valve 6 Cap for de tergent reservoir 7 Detergent reservoir 8 Detergent suction-hose with filter
9 Fastening screw for hoo d 10 Unit switch 11 Hood 12 Pressure gauge 13 High-pressure outlet 14 Nozzle rest 15 Water connection 16 Fine filter 17 Oil level display 18 Oil reservoir 19 Indicator light 20 Hose rest 21 Detergent reservoir ven t 22 Accessori es box 23 Cable holder 24 Handle 25 Nozzle 26 Marking of the nozzle 27 Spray lance 28 Pressure/flow cont rol 29 Safety catch of hand-held spray gun
For your safety
Before you use the cleaner for the first time, read these operatin g in st ru ct i ons and take special note of the accom p anying booklet "Safety Instructio ns for High-Pressure Clean­ers" No. 5.951-949.
Use of the cleaner
Use this unit exclusiv el y f or – cleaning with high-pr ess ure jet and deter-
gent (e.g. cleaning of machines, vehicles, buildings, tools),
– cleaning with high-pressure jet without de-
tergent (e.g. cleaning f ac ades, terraces, gardening equipmen t).
For stubborn dirt we recommend the dirt blaster as an optiona l accessory.
Safety features
Relief valve with pressure switch
On reducing the flow ra te with t he pr essure and flow control, the re l ief va l ve opens and part of t he wa ter runs ba ck t o th e suct io n si de of the pump.
If the lever of the hand-he ld spr ay gun is re­leased, the pressure switch switches the pump off. If the lever is retracted, the pressure switch switches the pump on again.
The overflow valve and pressure switch have been set and sealed at th e f actory.
Adjustments are m ade only by Customer Service.
Operating Instructions HD 10/25 S VEX English
6
Preparing the unit for use
Unpack the unit
– When unpacking the uni t, check the con-
tents of the packaging . If there has been any damage in transit info rm t he dealer.
– Do not dispose of the packa gi ng with the
household rubbish, ha nd i t in at th e appro­priate collection point for recycling.
Check the oil level
Read the oil level displayed while unit is at
a standstill. The oil level must be above the two indic ators.
Activate the oil reservoir vent
Unscrew the fastening sc rew of the hood
and remove the hood.
Cut off the tip on the cover to the oi l reser-
voir.
Fasten the unit cover.
Mount the accessories
Mount nozzle on the spr ay lance (see
markings on the top of the setting ring).
Fit the spray lance to the hand-held spray
gun with pressure and flow control.
Lock cable clincher into bore lateral to the
handle.
Tighten the high-pressu re hos e according-
ly.
Switching on the unit
Electrical connection
Caution!
The voltage specified on the mo del rat­ing plate must correspond to the voltage sup­plied.
Caution!
The maximum tolerable mains impedance at the el ect rical contact point (see Technical Data) must not be exceeded.
Caution!
Use an extension cable with a sufficient cable cross-section (see Technical Sp ecifica­tions) and unwind it fully from the cable drum.
For connected load s see model rating plate/ Technical Specifications.
Caution!
It is essential that the unit is connected to the power supply by means of a plug. An in­separable connec tion to the power supply is prohibited. The plug is us ed to disconnect from the mains.
Water connection/Suction feed operation
Connection to water main
Caution!
Pay attention to the regulation s of th e water supply company; according to DIN 1988, the unit may not be connected direct to the public drinking water supply. A short-term connection via a non- re tu rn valve (Order no. 6.412-578 ) is all ow e d.
For connected loads see Technical Specifica­tions.
Connect a supply hose (not supplied) to the
water outlet on the unit and to the water in­let (e.g. w ater tap) .
Open water inlet.
English Operating Instructions HD 1 0/ 25 S VEX
7
!
Suctioning water from an open container
Screw suction hose with f ilt er
(Order no. 4.440-238) to the w ater outlet.
Vent the unit before using.To evacuate air from the unit, unscrew the
nozzle and leave the unit runni ng until wa­ter exits with no air bubbles.
Switch off the unit and screw th e no zzl e
back on.
Operating the unit
Danger!
Observe the relative safety regulations when using the unit at filling st at i ons or other high-risk areas.
Caution!
Only clean engines in places which have appropriate oil separators (protection of the environment).
Caution!
Only wash animals with the low­pressure fan jet (see "Sel ecti ng the type of spray").
Operating with high pre ssure
The unit is equipped with a pressure switch. The motor only starts up when the lever is re­tracted.
Set the unit switch to "I". The indicator light
will go green.
Unlock the hand-held spray gun and retract
the lever of the gun.
Adjust operating pressu re and flo w ra te
(+/–) by rotating the pressure/flow control (infinitely variable).
At the lowest flow rate the waste heat from
the motor will heat the water t o approx. 15 °C.
Selecting the type of spray
The handgun must be cl osed. Rotate the housing of the nozzle until the
desired symbol corresponds with the mark­ing.
Select pencil jet or fan jet by con ta ct less
changeover: rotate the spray lance, whi ch is pointing down at an angle of approx. 45°, to the left or right.
Explanation of the symbol s
High-pressure pencil jet (0°),
for particularly stubborn accumu­lation of grime. High-pressure fan jet (25°), for dirt accumulation over a la rge surface.
Low-pressure fan jet (CHEM) for operation with detergent or for cleaning at low pressu re.
Operating Instructions HD 10/25 S VEX English
8
!
Operating with detergent
Caution!
Unsuitable deterge nt s can harm the cleaner and the object which is to be cleaned. Use only dete r gents which are released by Kärcher. Proportions o f dete rg ent t o be used and accompanying instructions should be not­ed carefully. Use detergents sparingly out of consideration for the environment.
Kärcher cleaning agen ts guarantee trouble­free operation. Please seek advice or ask for our catalogue of informa tion sheets on clean­ing agents.
Fill detergent rese rvoir.Set nozzle to .Set the detergent metering valve to the
desired concentration.
Concentr ation of detergent when flow at maximun:
Position of metering valve
Recommended cleaning methods
Spray dete rgent with low pres sur e jet spar-
ingly over the dry surface to be cleaned and let it take effect but not dry out .
Spray off (rinse off) the loosened dirt using
the high-pressure spr ay.
When you have finished the operation, set
detergent metering valve to "0" and switch the unit on for about 1 minute and rinse it clear of detergent.
1357
0.5%2.5%5.0%7.0 %
Interrupting the operation
Release lever of the handgun, th e unit
switches off. Retract le ver again and the unit switches on agai n.
Availabi li t y t ime
Within the availability time, the unit starts when the hand-held spr ay gun is opened. The indicator light will go green.
If the spray gun remain s cl osed for 30 minutes, the availability time ends. The indicator light will flash green.
Reset availability time
Switch off the unit switch.Wait a moment.Switch the unit back on again.
Customer Service ca n change the unit to permanent operat ion.
Switching the unit off
Set unit switch to "0" and pull out power
plug.
Close water inlet.Retract lever until the unit is without pr es-
sure.
Push safety catch of the hand-held spray
gun forward to lock the lev er of the gun from being actuated inadvertently.
Danger!
Risk of scalding due to hot water. Re­sidual water contained in the switched off unit can heat up. When re m ovi ng the hose from the water i nle t, th e he ater wate r ca n spur t ou t and cause scal ds. Do not remove t he hose until the unit has cooled down.
Transporting the cleaner
To transport the cleaner over relatively long
stretches, take hold of it by the handle and pull it along behind you.
Empty the detergent reservoir before trans-
porting it horizontally.
English Operating Instructions HD 1 0/ 25 S VEX
9
!
Storing the cleaner
Place the handgun in the support.Reel in the high-pressure hose and hang it
over the hose rest. or Coil the connecting cable round the cable/
hose rest.
Frost protection
Caution!
Frost will destroy a unit that is not com­pletely e mpty of wat er! St or e the un it where i t will be free of frost.
If storage away from frost is not possible: Empty the detergent tank (s ee care and
maintenance/As and whe n re quired).
Drain off the water and rinse the unit
through with anti-freeze.
Leave the unit to dry for max. 1 minute.Use the standard glycol-based anti-freezes
for cars.
Follow the handli ng instruc t i ons of the anti-
freeze manufacturer.
Care and maintenance
Danger!
Before any care and maintenance work
on the unit draw out the mains plug.
Caution!
When changing the o il, dispose of any waste oil only at authorised collection points.
Safety inspection/Maintenance contract
You can arrange with your deal er to have a regular safety inspection carried out or to have a maintenance contract. Please seek advice.
Before each use
Check connecting cable for damage (risk of
getting an electric shock), have a damaged connectin g cable r eplaced wi thout d elay by authorised Customer Service personnel or an electrician.
Check high-pressure hose for damage
(danger of explosion), replace a damaged high-pressure hose w i th out delay.
Check unit (pump) for any leaks.
Three drops per minute ar e all ow able and can appear on the under side of the unit. Seek the help of Customer Service if leaks are more serious.
Every week
Check oil level in oil reservoir: if the oil is
milky (water in oil), seek the help of Cus­tomer Service immediately.
Clean the fine filter.
– Unpressurize uni t . – Unscrew the fastening screw of the hood
and remove the hood. – Unscrew the cover with filter. – Clean the filter with clean water or com-
pressed air. – Reassemble in th e r everse order.
Clean the filter at the suction hose for de-
tergent.
Annually or after 500 operating hours
Change the oil
– For oil quantity and type see Technical
Specifications. – Undo the fastenin g sc rew, remove the
hood, unscrew the front oil drain plug on
the motor housing. – Drain oil into a suitabl e container. – Screw in the oil drain pl ug. – Fill slowly with fresh oil; air bubbles have
to escape.
Operating Instructions HD 10/25 S VEX English
10
!
As and when required
Emptying and cleaning the detergent tank
– Pull out the screw cap and hose for the
detergent tank. – Place the unit on its rear. – Empty and clean the det ergent tank.
Troubleshooting
Danger!
Before any repair work is undertaken, switch the unit off and pull out the power plug. Have electrical compo nents checked and re­paired only by authorised C ustomer Service personnel. For faults which are not identified in this chap­ter, or when in doubt or wh en expressly in­structed to do so, cons ul t au t hor i sed Customer Service perso nnel.
Indicator light
The indica tor li ght sh ows the operat ing st atus (green) and faults (red).
To reset:
Switch off the unit switch.Wait a moment.Switch the unit back on again.
Operatin g status displ ay
Constant green light:
– Unit is operational.
1 x flashing green:
– Operational readi nes s expired after
30 minutes.
– The unit switched off after 30 minutes of
permanent operation (safety feature in the case of a burst high-pressure hose).
Fault disp lay
1 x flashing red:
– High-pressure side leaking. Check high-
pressure hose, hose connections and hand-held spray gun for leaks.
2 x flashing red:
– Motor too hot. Switch off the unit switch.
Leave unit to cool down. Switch the unit back on again.
3 x flashing red:
– Fault in the power sup pl y. C hec k t he
mains connection. Check supply fuses.
4 x flashing red:
– Current consum pt io n t oo high. Consult
Customer Service
Unit does not wor k
Availability time has run out. The indicator
light will flash green. Switch the unit off and then on again.
Check connecting cabl e fo r damage.Consult Customer Service if there is an
electrical fault.
Unit does not come up to pres­sure
Set nozzle to "high pressure".Clean/replace nozzle.Clean the fine filter, replace if requ i re d.Evacuate air from the cleane r (see Switch-
ing on the unit).
Check water inlet volume (see Technical
Specifications).
Check all supply lines to the pump for le aks
or obstructions .
Seek the hel p of Customer Se rvice if nec-
essary.
English Operating Instructions HD 1 0/ 25 S VEX
11
Pump is leaky
Three drop s per minute are allowable and
can appear on the undersid e of th e unit. Seek the hel p of Cust omer Serv ice i f lea ks are more serious.
Pump makes a knocking noise
Check all supply lines as well as the deter-
gent system for leaks.
Evacuate air from the cleaner (see Switch-
ing on the unit).
Clean the fi ne filter.Seek the help of Customer Ser vice if nec-
essary.
Detergent is not being drawn in
Set nozzle to "Chem".Check detergent suction hose with filter for
leaks or obstructions and clean it if neces­sary.
Clean/renew non-return valve in detergent
suction-hose connect i on.
Open detergent metering valve or check it
for leaks/remove obstru ctio n. Also cl ean the venting orifice in the hous i ng.
Seek the help of Customer Ser vice if nec-
essary.
Spare parts
You will find a list of spare parts at th e e nd o f these opera t i ng instructions.
Warranty
The warranty terms issued by our authorised marketing company are valid in every country. We remedy any fault in the unit free of charge within the warranty period providing the cause of the fault proves to be a ma te rial or m anu­facturing error.
The warranty only becomes operative when your dealer has compl et ed the reply card ac­companying the sale of the unit, has stamped and signed it and you have then sent the reply card to the marketing com pany in your coun­try.
Should you wish to call upon the guarantee, please appl y to you r dea ler or ne ares t auth or­ised Customer Service centre taking along also the accessorie s and bill of sale.
Operating Instructions HD 10/25 S VEX English
12
Technical Specifications
HD 10/25 S VEX
Mains connection
Voltage V 380 220 Type of current Hz 3~50 3~60 Connected load kW 7.7 7.5 Supply fuse (delayed-action, char. C) A 16 25 Max. tolerable mains impedance (0.145 + j0.090) Extension cable 10 m mm Extension cable 30 m mm
Water connectio n
Supply temperatur e max. °C 60 Supply volume min. l/h (l/min) 1200 (20) Supply hose – minimum length m 7.5 Supply hose – minimum diameter inches 3/4 Suction height from an open cont ainer 20 °C m 0.5 Supply pressure max. MPa (bar) 1 (10)
Performance data
Operating pressure MPa (bar) 3–19 (30–190) Max. operating overpressure (safety valve) MPa (bar) 20.9 (209) Flow rate Detergent intake Recoil force of the handgun N 62
Sound emission
Sound pressure level (EN 60704-1)
Guaranteed sound pressure level (2000/14/EC)
Vibrations of unit / total of vibrat ion (ISO 5349) Handheld gun m/s Spray lanc e m/s
Dimensions
Length mm 560 Width mm 500 Height mm 1090 Weight without accessories kg 62 Reservoir capacity, detergent l 6 Oil quantity, pump l 1.2 Oil type, pump SAE 90
2
2
l/h (l/min) l/h (l/min)
dB (A)
2.5 2.5 4–
500–1038 (8.3–17.3)
0–80 (0–1.3)
72
dB (A) 87
2 2
2.2
2.0
Loading...
