Thank you for purchasing a JVC product.

Please read all instructions carefully before operation, to ensure your complete understanding and

to obtain the best possible performance from the unit.

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel.

3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical instruments.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.

Warning:

If you need to operate the unit while driving, be sure to look around carefully or you may be

Battery

Products

Information for Users on Disposal of Old Equipment and Batteries

[European Union only]

These symbols indicate that the product and the battery with this symbol should not be disposed as general household waste at its end-of-life. If you wish to dispose of this product and the battery, please do so in accordance with applicable national legislation or other rules in your country and municipality. By disposing of this product correctly, you will help to conserve natural resources and will help prevent potential negative effects on the environment and human health.

Notice:

The sign Pb below the symbol for batteries indicates that this battery contains lead.

involved in a traffic accident.

For safety...

• Do not raise the volume level too much, as this will block outside sounds, making driving dangerous.

• Stop the car before performing any complicated operations.

Temperature inside the car...

If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.

This unit is equipped with the steering wheel remote control function. Before operating, connect a JVC's OE remote adapter (not supplied) which matches your car to the steering wheel remote input terminal on the rear of the unit.

• For details, refer also to the instructions supplied with the remote adapter.

2 ENGLISH

EN02-11_KD-R511_003A_1.indd 2EN02-11_KD-R511_003A_1.indd 2 10/27/09 5:26:01 PM10/27/09 5:26:01 PM

How to read this manual

The following icons/symbols are used to indicate:

Press and hold the button(s)

[Hold]

until the desired operation begins.

Turn the control dial.

Turn the control dial to make a selection, then press to confirm.

( <XXXX> Menu setting item

Reference page number

XX)

Continued on the next page

How to attach/detach the control panel

How to reset your unit

Your preset adjustments will also be erased.

CONTENTS

3 How to read this manual 3 How to attach/detach the control

panel

3 How to reset your unit 3 How to forcibly eject a disc

Canceling the display demonstration

4 Setting the clock 5 Basic operations 6 Listening to the radio 9 Listening to a disc 10 Listening to the USB device 11 Listening to the other external

components

12 Using the remote controller 13 Selecting a preset sound mode 14 Menu operations 20 Maintenance 21 More about this unit 23 Troubleshooting 26 Specifications

How to forcibly eject a disc

[Hold]

• You can forcibly eject the loaded disc even if the disc is locked. To lock/unlock the disc,

• Be careful not to drop the disc when it ejects.

• If this does not work, reset your unit.

3ENGLISH

EN02-11_KD-R511_003A_f.indd 3EN02-11_KD-R511_003A_f.indd 3 12/10/09 4:58:48 PM12/10/09 4:58:48 PM

Canceling the display demonstration

1 Turn on the power.

[Hold]

(Initial setting)

Setting the clock

1 Turn on the power.

3 Select <CLOCK>.

[Hold]

(Initial setting)

4 Select <DEMO OFF>.

6 Finish the procedure.

6 Adjust the minute.

7 Select <24H/12H>.

4 Select <CLOCK SET>.

8 Select <24 HOUR> or

<12 HOUR>.

5 Adjust the hour.

9 Finish the procedure.

4 ENGLISH

EN02-11_KD-R511_003A_1.indd 4EN02-11_KD-R511_003A_1.indd 4 10/27/09 5:26:02 PM10/27/09 5:26:02 PM

Basic operations

Ejects the disc

Detaches the panel

When you press or hold the following button(s)...

Loading slot USB (Universal Serial Bus) input jack

Control dial

Display window

Remote sensor You can control this unit with an optionally purchased remote control, RM-RK50 (

Button General operation

• Turns on.

• Selects the available sources (if the power is turned on). If the source is ready, playback also starts.

• Turns off if pressed and held.

• Adjusts the volume level.

• Selects items.

• Mutes the sound while listening to a source. If the source is “CD” or “USB,” playback pauses. Press the control dial again to cancel muting or resume playback.

• Confirms selection.

• Selects the sound mode.

• Enters tone level adjustment directly ( 13) if pressed and held.

• Enters <COLOR> setting directly ( 18).

•

Enters <COLOR SETUP> setting directly ( 19) if pressed and held.

• Activates/deactivates TA Standby Reception.

• Enters PTY Searching mode if pressed and held.

• Returns to the previous menu.

Power off : Checks the current clock time. Power on : Changes the display information.

Auxiliary input jack

12).

5ENGLISH

EN02-11_KD-R511_003A_f.indd 5EN02-11_KD-R511_003A_f.indd 5 12/10/09 4:59:58 PM12/10/09 4:59:58 PM

Listening to the radio

]

“FM” or “AM”

“ST” lights up when receiving an FM stereo broadcast with sufficient signal strength.

Manual search

“M” flashes, then press

[Hold]

the button repeatedly.

When an FM stereo broadcast is hard to receive

[Hold]

]

<TUNER> ] <MONO> ] <MONO ON> Reception improves, but stereo effect will be lost.

To restore the stereo effect, repeat the same procedure to select <MONO OFF>.

Automatic presetting (FM)—

SSM (Strong-station Sequential Memory)

You can preset up to 18 stations for FM.

While listening to a station...

[Hold]

]

<TUNER> ] <SSM> ] <SSM 01 – 06> / <SSM 07 – 12> / <SSM 13 – 18> “SSM” flashes and local stations with the strongest signals are searched and stored automatically.

To preset another 6 stations, repeat the above procedure by selecting one of the other 6 SSM setting ranges.

6 ENGLISH

EN02-11_KD-R511_003A_1.indd 6EN02-11_KD-R511_003A_1.indd 6 10/28/09 10:06:46 AM10/28/09 10:06:46 AM

Manual presetting (FM/AM)

You can preset up to 18 stations for FM and 6 stations for AM.

Ex.: Storing FM station of 92.50 MHz into preset number “04.”

]

“92.50MHz”

“PRESET MODE” flashes.

[Hold]

]

Selects preset number “04.”

“P04” flashes and “MEMORY” appears.

Selecting a preset station

Changing the display information

Frequency = Clock = (back to the beginning)

The following features are available only for FM Radio Data System stations.

Searching for your favourite FM Radio Data System programme—

You can tune in to a station broadcasting your favourite programme by searching for a PTY code.

The last selected PTY code appears.

PTY Search

[Hold]

]

Select one of your favourite

programme types or a PTY code, and start searching.

If there is a station broadcasting a programme of the same PTY code as you have selected, that station is tuned in.

PTY codes: NEWS, AFFAIRS, INFO, SPORT, EDUCATE, DRAMA, CULTURE, SCIENCE, VARIED, POP M (music), ROCK M (music), EASY M (music), LIGHT M (music), CLASSICS, OTHER M (music), WEATHER, FINANCE, CHILDREN, SOCIAL, RELIGION, PHONE IN, TRAVEL, LEISURE, JAZZ, COUNTRY, NATION M (music), OLDIES, FOLK M (music), DOCUMENT

7ENGLISH

EN02-11_KD-R511_003A_1.indd 7EN02-11_KD-R511_003A_1.indd 7 10/28/09 10:06:46 AM10/28/09 10:06:46 AM

Standby receptions

TA Standby Reception

TA Standby Reception allows the unit to switch temporarily to Traffic Announcement (TA) from any source other than AM.

• The volume changes to the preset TA volume level if the current level is lower than the preset level. (<TA VOLUME>,

To activate TA Standby Reception

If the TP indicator lights up, TA Standby Reception is activated. If the TP indicator flashes, TA Standby Reception is not yet activated.

• To activate the reception, tune in to another station providing Radio Data System signals required for TA Standby Reception.

• To deactivate the reception, press again.

15)

T/P BACK

Tracing the same programme—

Network-Tracking Reception

When driving in an area where FM reception is not sufficient enough, this unit automatically tunes in to another FM Radio Data System station of the same network, possibly broadcasting the same programme with stronger signals.

Programme A broadcasting on different frequency areas (01 – 05)

To change the Network-Tracking Reception setting, see <AF-REG> ( 15).

PTY Standby Reception

PTY Standby Reception allows the unit to switch temporarily to your favourite PTY programme from any source other than AM.

To activate and select your favourite PTY code for PTY Standby Reception, see

<PTY-STANDBY> ( If the PTY indicator lights up, PTY Standby Reception is activated. If the PTY indicator flashes, PTY Standby Reception is not yet activated.

• To activate the reception, tune in to another station providing these signals.

• To deactivate the reception, select <PTY OFF> ( 15) for the PTY code. The PTY indicator goes off.

8 ENGLISH

15)

Automatic station selection—

Programme Search

Usually when you select a preset number, the station preset in that number is tuned in. If the signals from the FM Radio Data System preset station are not sufficient for good reception, this unit, using the AF data, tunes in to another frequency possibly broadcasting the same programme as the original preset station is broadcasting. (<P-SEARCH>,

Changing the display information

Station name (PS) = Station Frequency = Programme type (PTY) = Clock = (back to

the beginning)

15)

EN02-11_KD-R511_003A_3.indd 8EN02-11_KD-R511_003A_3.indd 8 11/24/09 5:15:18 PM11/24/09 5:15:18 PM

Listening to a disc

]

Turn on the power.

All tracks will be played repeatedly until you change the source or eject the disc.

Caution on volume setting:

Discs produce very little noise compared with other sources. Lower the volume before playing a disc to avoid damaging the speakers by the sudden increase of the output level.

Stopping playback and ejecting the disc

“NO DISC” appears. Press /

SOURCE

to listen to

another playback source.

Prohibiting disc ejection

[Hold]

To cancel the prohibition, repeat the same procedure.

Selects folder of the MP3/WMA

Selecting a track/folder

For MP3/WMA discs, select the desired folder, then the desired track by repeating the control dial procedures.

• To return to the previous menu, press

T/P BACK

Selecting the playback modes

You can use only one of the following playback modes at a time.

[Hold]

]

“REPEAT” j “RANDOM”

REPEAT

Selects track

Fast-forwards or

[Hold]

EN02-11_KD-R511_003A_1.indd 9EN02-11_KD-R511_003A_1.indd 9 10/27/09 5:26:04 PM10/27/09 5:26:04 PM

reverses the track

TRACK RPT : Repeats current track FOLDER RPT : Repeats current folder

RANDOM FOLDER RND : Randomly plays all tracks

of current folder, then tracks of next folders

ALL RND : Randomly plays all tracks

To cancel repeat play or random play, select “RPT OFF” or “RND OFF.”

9ENGLISH

Changing the display information

Disc title/Album name/performer (folder name)* = Track title (file name)* = Current track number with the elapsed playing time = Current track number with the clock time = (back

to the beginning) * If the current disc is an audio CD, “NO NAME” appears.

If an MP3/WMA file does not have Tag information or <TAG DISPLAY> is set to <TAG OFF> (

folder name and file name appear.

14),

Listening to the USB device

This unit can play MP3/WMA files stored in a USB device.

]

Turn on the power.

USB input jack

All tracks will be played repeatedly until you change the source or detach the USB device.

Caution on volume setting:

USB devices produce very little noise compared with other sources. Lower the volume before playing a USB to avoid damaging the speakers by sudden increase of the output level.

If you have turned off the power (without detaching the USB device)...

Pressing playback starts from where it has been stopped previously.

• If a different USB device is currently attached,

/ SOURCE

turns on the power and

playback starts from the beginning.

USB memory

Stop playing and detaching the USB device

Straightly pull it out from the unit. “NO USB” appears. Press another playback source.

You can operate the USB device in the same way you operate the files on a disc. (

/ SOURCE

to listen to

10 ENGLISH

EN02-11_KD-R511_003A_3.indd 10EN02-11_KD-R511_003A_3.indd 10 11/24/09 5:15:25 PM11/24/09 5:15:25 PM

Cautions:

• Avoid using the USB device if it might hinder your safety driving.

• Do not pull out and attach the USB device repeatedly while “READING” is shown on the display.

• Do not start the car engine if a USB device is connected.

• This unit may not be able to play the files depending on the type of USB device.

• Operation and power supply may not work as intended for some USB devices.

• You cannot connect a computer to the USB input terminal of the unit.

• Make sure all important data has been backed up to avoid losing the data.

• Do not leave a USB device in the car, expose to direct sunlight, or high temperature to avoid deformation or cause damages to the device.

• Some USB devices may not work immediately after attaching USB device or turn on the power.

• For more details about USB operations,

22, 23.

Listening to the other external components

You can connect an external component to the AUX (auxiliary) input jack on the control panel. Preparation: Make sure <AUX ON> is selected for the <SRC SELECT> = <AUX IN> setting. ( 17)

• For details, refer also to the instructions supplied with the adapter or external components.

]

“AUX IN”

Ÿ Turn on the connected

component and start playing the source.

]

Adjust the volume.

⁄ Adjust the sound as you

want. ( 13)

Connecting an external component to the AUX input jack

Portable audio player,

3.5 mm stereo mini plug (not supplied)

EN02-11_KD-R511_003A_1.indd 11EN02-11_KD-R511_003A_1.indd 11 10/27/09 5:26:04 PM10/27/09 5:26:04 PM

etc.

11ENGLISH

Using the remote controller

KD-R511 can be remotely controlled as instructed here (with an optionally purchased remote controller). We recommend that you use remote controller RM-RK50 with your unit.

Installing the lithium coin battery (CR2025)

• Turns the power on if pressed briefly.

• Turns the power off if pressed and held.

Caution:

• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

• Battery shall not be exposed to excessive heat such as sunshine, fire, or the like.

If the effectiveness of the remote controller decreases, replace the battery.

Before using the remote controller:

• Aim the remote controller directly at the remote sensor on the unit.

• DO NOT expose the remote sensor to bright light (direct sunlight or artificial lighting).

Remote sensor

12 ENGLISH

• Changes the preset stations.

• Changes the folder of the MP3/WMA.

Adjusts the volume level.

Selects the sound mode.

Selects the source.

• Searches for stations if pressed briefly.

• Fast-forwards or reverses the track if

• Changes the tracks if pressed briefly.

Warning (to prevent accidents and damage):

• Do not install any battery other than CR2025 or its equivalent.

• Do not leave the remote controller in a place (such as dashboards) exposed to direct sunlight for a long time.

• Store the battery in a place where children cannot reach.

• Do not recharge, short, disassemble, heat the battery, or dispose of it in a fire.

• Do not leave the battery with other metallic materials.

• Do not poke the battery with tweezers or similar tools.

• Wrap the battery with tape and insulate when throwing away or saving it.

When the power is on, pressing the button also mutes the sound or pauses. To cancel muting or resume playback, press the same button again.

pressed and held.

EN12-19_KD-R511_003A_3.indd 12EN12-19_KD-R511_003A_3.indd 12 12/1/09 9:38:24 AM12/1/09 9:38:24 AM

Selecting a preset sound mode

You can select a preset sound mode suitable for the music genre.

FLAT = NATURAL = DYNAMIC = VOCAL BOOST = BASS BOOST = USER = (back to

the beginning)

While listening, you can adjust the tone level of the selected sound mode.

[Hold]

Adjust the level (–06 to +06) of the selected tone (BASS / MID / TRE). The sound mode is automatically stored and changed to “USER.”

Tone

BASS 60 Hz

MIDDLE 0.5 kHz

TREBLE 10.0 kHz

Sound element

Frequency Level Q

–06 to +06 Q1.0

80 Hz 100 Hz 200 Hz

–06 to +06 Q0.75

1.0 kHz

1.5 kHz

2.5 kHz –06 to +06 Q FIX

12.5 kHz

15.0 kHz

17.5 kHz

Q1.25 Q1.5 Q2.0

Q1.0 Q1.25

Storing your own sound mode

You can store your own adjustments in memory.

[Hold]

]

<PRO EQ> ] <BASS> / <MIDDLE> /

Adjust the sound elements of the selected tone. ( table on the left)

Repeat steps 2 and 3 to adjust other

tones. The adjustments made will be stored automatically in “USER.”

The current sound mode changes to “USER” automatically.

13ENGLISH

EN12-19_KD-R511_003A_1.indd 13EN12-19_KD-R511_003A_1.indd 13 10/28/09 10:07:44 AM10/28/09 10:07:44 AM

Menu operations

1 2 3

Category

DEMO

CLOCK

PRO EQ

DISPLAY

Takes effect only when CT (clock time) data is received.

* *2 Some characters or symbols will not be shown correctly (or will be blanked) on the display.

[Hold]

Menu item Selectable setting, [Initial: Underlined]

DEMO

Display demonstration

CLOCK SET Clock setting—[0:00]

24H/12H

Time display mode

CLOCK ADJ * Clock adjustment

BASS —

MIDDLE

TREBLE

DIMMER • DIMMER ON

SCROLL *

TAG DISPLAY • TAG ON

• DEMO ON

• DEMO OFF

• 24 HOUR

• 12 HOUR

• AUTO

• OFF

• DIMMER OFF

• SCROLL ONCE

• SCROLL AUTO

• SCROLL OFF Pressing regardless of the setting.

• TAG OFF

: Display demonstration will be activated

automatically if no operation is done for about 20 seconds.

: Cancels. ( 4)

: Adjust the hour, then the minute. (

: For settings,

: The built-in clock is automatically adjusted

using the CT (clock time) data in the Radio Data System signal.

: Cancels. : For settings,

: Dims the display and button illumination. : Cancels.

: Scrolls the displayed information once. : Repeats scrolling (at 5-second intervals). : Cancels.

DISP

for more than one second can scroll the display

: Shows the Tag information while playing MP3/

WMA tracks.

: Cancels.

Repeat step 2 if necessary.

• To return to the previous menu, press

T/P BACK

• To exit from the menu, press or

13.

DISP

14 ENGLISH

EN12-19_KD-R511_003A_f.indd 14EN12-19_KD-R511_003A_f.indd 14 12/15/09 5:00:37 PM12/15/09 5:00:37 PM

Category

Menu item Selectable setting, [Initial: Underlined]

SSM * Strong-station Sequential

• SSM 01 – 06

• SSM 07 – 12

• SSM 13 – 18

Memory

AF-REG *

• AF ON Alternative frequency/ regionalization reception

• AF-REG ON

• OFF

PTYSTANDBY *

TA VOLUME *

Traffic announcement

TUNER

volume

3, *4

• PTY OFF, PTY

codes

• VOLUME 00

– VOLUME 50 (or VOLUME 00 – VOLUME 30) * [ VOLUME 15 ]

P-SEARCH *

Programme

• SEARCH ON

• SEARCH OFF search

MONO *

• MONO ON Monaural mode

• MONO OFF

IF BAND

• AUTO Intermediate frequency band

• WIDE

Displayed only when the source is “FM.”

* *4 Only for FM Radio Data System stations. *5 Depends on the amplifier gain control.

: For settings,

: When the currently received signals become

weak, the unit switches to another station (the programme may differ from the one currently received). (The AF indicator lights up.)

: When the currently received signals become

weak, the unit switches to another station broadcasting the same programme. (The AF and REG indicators light up.)

: Cancels. : Activates PTY Standby Reception with one of

the PTY codes ( 7). —

: Activates Programme Search. (

: Cancels.

: Activate monaural mode to improve FM

reception, but stereo effect will be lost. ( 6)

: Restore the stereo effect.

: Increases the tuner selectivity to reduce

interference noises between adjacent stations. (Stereo effect may be lost.)

: Subject to interference noises from adjacent

stations, but sound quality will not be degraded and the stereo effect will remain.

15ENGLISH

EN12-19_KD-R511_003A_3.indd 15EN12-19_KD-R511_003A_3.indd 15 12/1/09 9:39:10 AM12/1/09 9:39:10 AM

Category

Menu item Selectable setting, [Initial: Underlined]

BUTTON ZONE COLOR 01 —

COLOR 29, USER

COLOR

DISP ZONE

Display zone

: For settings,

ALL ZONE

DAY COLOR • BUTTON ZONE

NIGHT COLOR

MENU COLOR

• DISP ZONE

• ON

: For settings,

: Changes the display and buttons (except for

EQ/BASS-TRE

COLOR SETUP

FADER *

BALANCE *

LOUD

Loudness

VOL ADJUST

Volume adjust

• OFF

R06 – F06

[00]

L06 – R06

[00]

• LOUD ON

• LOUD OFF

VOL ADJ –05 — VOL ADJ +05

[VOL ADJ 00]

list search and playback mode operations.

: Cancels.

: Adjust the front and rear speaker output

balance.

: Adjust the left and right speaker output

balance.

: Boost low and high frequencies to produce a

well-balanced sound at a low volume level.

: Cancels.

: Preset the volume adjustment level of

each source (except FM), compared to the FM volume level. The volume level will automatically increase or decrease when you

AUDIO

change the source.

• Before making an adjustment, select the source you want to adjust.

• “VOL ADJ FIX” appears on the display if “FM” is selected as the source.

L/O MODE

Line output mode

• SUB.W

• REAR

: Select if the REAR LINE OUT terminals are

used for connecting a subwoofer (through an external amplifier).

: Select if the REAR LINE OUT terminals are

used for connecting the speakers (through an external amplifier).

If you are using a two-speaker system, set the fader level to “00.”

* *7 This adjustment will not affect the subwoofer output.

18.

19.

DISP

) illumination during menu,

16 ENGLISH

EN12-19_KD-R511_003A_3.indd 16EN12-19_KD-R511_003A_3.indd 16 11/24/09 5:16:21 PM11/24/09 5:16:21 PM

Category

Menu item Selectable setting, [Initial: Underlined]

SUB.W FREQ * Subwoofer cutoff frequency

• LOW

: Frequencies lower than 72 Hz are sent to the

subwoofer.

• MID

: Frequencies lower than 111 Hz are sent to

the subwoofer.

• HIGH

: Frequencies lower than 157 Hz are sent to

the subwoofer.

SUB.W LEVEL * Subwoofer level

SUB.W 00 — SUB.W 08

: Adjust the subwoofer output level.

[SUB.W 04]

BEEP

AUDIO

Keytouch tone

TEL MUTING

Telephone muting

AMP GAIN * Amplifier gain control

AM * AM station

AUX IN *

SRC SELECT

Auxiliary input

Displayed only when <L/O MODE> is set to <SUB.W>.

• BEEP ON

• BEEP OFF

• MUTING 1/

MUTING 2

• MUTING OFF

• LOW POWER

• HIGH POWER

• AM ON

• AM OFF

• AUX ON

• AUX OFF

: Activates the keypress tone. : Deactivates the keypress tone.

: Select either one which mutes the sounds

while using a mobile phone.

: Cancels.

: VOLUME 00 – VOLUME 30 (Select if the

maximum power of each speaker is less than 50 W to prevent damaging the speakers.)

: VOLUME 00 – VOLUME 50

: Enable “AM” in source selection. : Disable “AM” in source selection.

: Enable “AUX IN” in source selection. : Disable “AUX IN” in source selection.

*9 The volume level automatically changes to “VOLUME 30” if you change to <LOW POWER> with the

volume level set higher than “VOLUME 30.”

Displayed only when any source other than “AM” is selected.

Displayed only when any source other than “AUX IN“ is selected.

17ENGLISH

EN12-19_KD-R511_003A_f.indd 17EN12-19_KD-R511_003A_f.indd 17 12/10/09 5:01:02 PM12/10/09 5:01:02 PM

Selecting the variable buttons and display color illumination

You can select your preferred color for buttons illumination (except for display color separately.

EQ/BASS-TRE / DISP

) and

Button zone

[Hold]

]

<COLOR> ] <BUTTON ZONE> /

• Pressing

COLOR

in step 1 will enter zone selection menu (BUTTON ZONE / DISP ZONE / ALL ZONE) directly.

]

Select your preferred color from one

of the 29 preset colors or <USER> color.

All zone

Display zone

Repeat steps 2 and 3 to select a

different zone and your preferred color.

• If <ALL ZONE> is selected in step 2, the buttons and display illumination changed to the current/selected <BUTTON ZONE> color.

You can also change the <ALL ZONE>

color to one of your preferred color by performing step 3.

]

Exit from the setting.

18 ENGLISH

EN12-19_KD-R511_003A_3.indd 18EN12-19_KD-R511_003A_3.indd 18 11/24/09 5:27:08 PM11/24/09 5:27:08 PM

Creating your own day and night colors—USER

You can create your own colors for <DAY COLOR> and <NIGHT COLOR> to apply to button zone and display zone.

• <DAY COLOR> Displayed when <DIMMER> is set to <DIMMER OFF>.

• <NIGHT COLOR> Displayed when <DIMMER> is set to <DIMMER ON>.

Menu hierarchy Operation

• BUTTON DAY COLOR

COLOR SETUP

NIGHT COLOR

Ex.: Creating <USER> color for <BUTTON ZONE> in <DAY COLOR>.

ZONE

• DISP ZONE Press

• BUTTON

ZONE

• DISP ZONE

[Hold] [Hold]

]

]

• Pressing

COLOR

in step 1 will enter zone selection menu (BUTTON ZONE / DISP ZONE) directly.

]

Select a primary color. RED j GREEN j BLUE j (back to the beginning)

Follow example below.

T/P BACK

after step 5, then select DISP ZONE in

step 2. Press

T/P BACK

after step 5, then select NIGHT COLOR

in step 2.

]

Adjust the level of the selected primary color. 00 to 31

Repeat steps 3 and 4 to adjust other

primary colors.

]

Exit from the setting.

If “00” is selected for all the primary colors (as in step 4) for <DISP ZONE>, nothing appear on the display.

19ENGLISH

EN12-19_KD-R511_003A_1.indd 19EN12-19_KD-R511_003A_1.indd 19 11/5/09 4:06:16 PM11/5/09 4:06:16 PM

Maintenance

How to clean the connectors

Frequent detachment will deteriorate the connectors. To minimize this possibility, periodically wipe the connectors with a cotton swab or cloth moistened with alcohol, being careful not to damage the connectors.

Connectors

Moisture condensation

Moisture may condense on the lens inside the unit in the following cases:

• After starting the heater in the car.

• If it becomes very humid inside the car. Should this occur, the unit may malfunction. In this case, eject the disc and leave the unit turned on for a few hours until the moisture has evaporated.

How to handle discs

When removing a disc from its case, press down

the center holder of the case and lift the disc out, holding it by the edges.

• Always hold the disc by the edges. Do not touch its recording surface.

When storing a disc in its case, gently insert the disc around the center holder (with the printed surface facing up).

• Make sure to store discs in cases after use.

Center holder

To keep discs clean

A dirty disc may not play correctly. If a disc does become dirty, wipe it with a soft cloth in a straight line from center to edge.

• Do not use any solvents (for example, conventional record cleaner, spray, thinner, benzine, etc.) to clean discs.

To play new discs

New discs may have some rough spots around the inner and outer edges. If such a disc is used, this unit may reject the disc. To remove these rough spots, rub the edges with a pencil or ball-point pen, etc.

Do not use the following discs:

Single CD (8 cm disc) Warped disc

Sticker and sticker

residue

Unusual shape

Stick-on label

C-thru Disc

(semitransparent

disc)

Transparent or

semitransparent

parts on its recording

area

20 ENGLISH

EN20-27_KD-R511_003A_1.indd 20EN20-27_KD-R511_003A_1.indd 20 10/27/09 5:25:40 PM10/27/09 5:25:40 PM

More about this unit

Basic operations

General

• If you turn off the power while listening to a track, playback will start from where it had been stopped previously next time you turn on the power.

• If no operation is done for about 60 seconds after pressing be canceled.

button, the operation will

Tuner operations

Storing stations in memory

• During SSM search...

– All previously stored stations are erased and

the stations are stored anew.

– When SSM is over, the station stored in the

lowest preset number will be automatically tuned in.

• When storing a station manually, the previously preset station is erased when a new station is stored in the same preset number.

FM Radio Data System operations

• Network-Tracking Reception requires two types of Radio Data System signals—PI (Programme Identification) and AF (Alternative Frequency) to work correctly.

• If a Traffic Announcement is received by TA Standby Reception, the volume level automatically changes to the preset level (TA VOLUME) if the current level is lower than the preset level.

• When Alternative Frequency Reception is activated (with AF selected), Network-Tracking Reception is also activated automatically.

Disc/USB operations

Caution for DualDisc playback

• The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product may not be recommended.

General

• This unit has been designed to reproduce CDs/CD Texts, and CD-Rs (Recordable)/ CD-RWs (Rewritable) in audio CD (CD-DA), MP3 and WMA formats.

• If you change the source while listening to a disc, playback stops. Next time you select “CD” as the playback source, playback will start from where it had been stopped previously.

• When a disc is inserted upside down, “PLEASE” and “EJECT” appear alternately on the display. Press 0 to eject the disc.

• If the ejected disc is not removed within 15 seconds, it is automatically inserted into the loading slot again to protect it from dust. Playback starts automatically.

• MP3 and WMA “tracks” (words “file” and “track” are used interchangeably) are recorded in “folders.”

• While fast-forwarding or reversing on an MP3 or WMA disc, you can only hear intermittent sounds.

Playing a CD-R or CD-RW

• Use only “finalized” CD-Rs or CD-RWs.

• This unit can only play back files of the same type as those detected first if a disc includes both audio CD (CD-DA) files and MP3/WMA files.

• This unit can play back multi-session discs; however, unclosed sessions will be skipped while playing.

21ENGLISH

EN20-27_KD-R511_003A_1.indd 21EN20-27_KD-R511_003A_1.indd 21 10/27/09 5:25:40 PM10/27/09 5:25:40 PM

• Some CD-Rs or CD-RWs may not play back on this unit because of their disc characteristics, or for the following reasons:

– Discs are dirty or scratched. – Moisture condensation has occurred on the

lens inside the unit. – The pickup lens inside the unit is dirty. – The files on the CD-R/CD-RW are written

using the “Packet Write” method. – There are improper recording conditions

(missing data, etc.) or media conditions

(stained, scratched, warped, etc.).

• CD-RWs may require a longer readout time

since the reflectance of CD-RWs is lower than that of regular CDs.

• Do not use the following CD-Rs or CD-RWs: – Discs with stickers, labels, or a protective seal

stuck to the surface. – Discs on which labels can be directly printed

by an ink jet printer. Using these discs under high temperature

or high humidity may cause malfunctions or damage to the unit.

Playing an MP3/WMA disc

• This unit can play back MP3/WMA files with

the extension code <.mp3> or <.wma> (regardless of the letter case—upper/lower).

• This unit can show the names of albums,

artists (performer), and Tag (Version 1.0, 1.1,

2.2, 2.3, or 2.4) for MP3 files and for WMA files.

• This unit can display only one-byte characters.

No other characters can be correctly displayed.

• This unit can play back MP3/WMA files

meeting the conditions below: – Bit rate of MP3/WMA: 32 kbps — 320 kbps – Sampling frequency of MP3: 32 kHz, 44.1 kHz, 48 kHz (for MPEG-1) 16 kHz, 22.05 kHz, 24 kHz (for MPEG-2) – Sampling frequency of WMA:

22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz – Disc format: ISO 9660 Level 1/Level 2,

Romeo, Joliet, Windows extension

• The maximum number of characters for file/folder names (includes 4 extension characters—<.mp3> or <.wma>).

– ISO 9660 Level 1: up to 12 characters – ISO 9660 Level 2: up to 31 characters – Romeo: up to 64 characters – Joliet: up to 32 characters – Windows extension: up to 64 characters

• This unit can recognize a total of 512 files, 255 folders, and 8 hierarchical levels.

• This unit can play back files recorded in VBR (variable bit rate).

Files recorded in VBR have a discrepancy

in the elapsed time display, and do not show the actual elapsed time. In particular, this difference becomes noticeable after performing the search function.

• This unit cannot play back the following files:

– MP3 files encoded in MP3i and MP3 PRO

format.

– MP3 files encoded in an inappropriate

format. – MP3 files encoded with Layer 1/2. – WMA files encoded in lossless, professional,

and voice format. – WMA files which are not based upon

Windows Media® Audio. – WMA files copy-protected with DRM. – Files which have data such as AIFF, ATRAC3,

etc.

• The search function works but search speed is

not constant.

Playing MP3/WMA tracks from a USB device

• While playing from a USB device, the playback

order may differ from other players.

• This unit may be unable to play back some

USB devices or some files due to their characteristics or recording conditions.

• Depending on the shape of the USB devices

and connection ports, some USB devices may not be attached properly or the connection might be loose.

22 ENGLISH

EN20-27_KD-R511_003A_1.indd 22EN20-27_KD-R511_003A_1.indd 22 10/27/09 5:25:40 PM10/27/09 5:25:40 PM

• Connect one USB mass storage class device to the unit at a time. Do not use a USB hub.

• If the connected USB device does not have the correct files, “CANNOT PLAY” appears.

• This unit can show Tag (Version 1.0, 1.1, 2.2,

2.3, or 2.4) for MP3 files and for WMA files.

• This unit can play back MP3/WMA files meeting the conditions below:

– Bit rate of MP3/WMA: 32 kbps — 320 kbps – Sampling frequency of MP3: 32 kHz, 44.1 kHz, 48 kHz (for MPEG-1) 16 kHz, 22.05 kHz, 24 kHz (for MPEG-2) – Sampling frequency of WMA:

22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz

• This unit can play back MP3 files recorded in VBR (variable bit rate).

• The maximum number of characters for:

– Folder names : 32 characters – File names : 32 characters – MP3 Tag : 64 characters – WMA Tag : 32 characters

• This unit can recognize a total of 5 000 files, 255 folders (255 files per folder including folder without unsupported files), and of 8 hierarchies.

Troubleshooting

• This unit does not support SD card reader.

• This unit cannot recognize a USB device whose rating is other than 5 V and exceeds 500 mA.

• USB devices equipped with special functions such as data security functions cannot be used with the unit.

• Do not use a USB device with 2 or more partitions.

• This unit may not recognized a USB device connected through a USB card reader.

• This unit may not play back files in a USB device properly when using a USB extension cord.

• This unit cannot play back the following files: – MP3 files encoded in MP3i and MP3 PRO

format.

– MP3 files encoded in an inappropriate

format. – MP3 files encoded with Layer 1/2. – WMA files encoded in lossless, professional,

and voice format. – WMA files which are not based upon

Windows Media® Audio.

Symptom Remedy/Cause

Sound cannot be heard from the speakers.

“PROTECT” appears on the display and no operations can be done.

General

The unit does not work at all.

EN20-27_KD-R511_003A_1.indd 23EN20-27_KD-R511_003A_1.indd 23 10/28/09 10:08:43 AM10/28/09 10:08:43 AM

• Adjust the volume to the optimum level.

• Make sure the unit is not muted/paused ( 6).

• Check the cords and connections.

Check to be sure the terminals of the speaker leads are covered with insulating tape properly, then reset the unit ( If “PROTECT” does not disappear, consult your JVC IN-CAR ENTERTAINMENT dealer or a company supplying kits.

Reset the unit. (

3).

23ENGLISH

Symptom Remedy/Cause

“AUX IN” cannot be selected. Check the <SRC SELECT> = <AUX IN> setting.

( 17)

General

Nothing appear on the display.

SSM automatic presetting does not work.

Static noise while listening to the

FM/AM

radio.

“AM” cannot be selected.

Disc cannot be played back. Insert the disc correctly.

• CD-R/CD-RW cannot be played back.

• Tracks on the CD-R/CD-RW cannot be skipped.

Disc can neither be played back nor ejected.

Disc sound is sometimes

Disc playback

interrupted.

“NO DISC” appears on the display. Insert a playable disc into the loading slot.

“PLEASE” and “EJECT“ appear alternately on the display.

Disc cannot be played back. • Use a disc with MP3/WMA tracks recorded in a

Noise is generated. Skip to another track or change the disc. (Do not

A longer readout time is required

MP3/WMA playback

(“READING” keeps flashing on the display).

Tracks do not play back in the order you have intended them to play.

Check the <USER> color settings (

19).

Store stations manually.

Connect the aerial firmly.

Check the <SRC SELECT>

<AM> setting. ( 17)

• Insert a finalized CD-R/CD-RW.

• Finalize the CD-R/CD-RW with the component which you used for recording.

• Unlock the disc. (

• Eject the disc forcibly. ( 3)

• Stop playback while driving on rough roads.

• Change the disc.

• Check the cords and connections.

Press 0, then insert a disc correctly.

format compliant with ISO 9660 Level 1, Level 2, Romeo, or Joliet.

• Add the extension code <.mp3> or <.wma> to the file names.

add the extension code <.mp3> or <.wma> to non-MP3 or WMA tracks.)

Do not use too many hierarchical levels and folders.

The playback order is determined when the files are recorded.

24 ENGLISH

EN20-27_KD-R511_003A_1.indd 24EN20-27_KD-R511_003A_1.indd 24 10/27/09 5:25:41 PM10/27/09 5:25:41 PM

Symptom Remedy/Cause

The elapsed playing time is not correct.

“NO FILE” appears on the display.

“NOT SUPPORT” appears on the display and track skips.

MP3/WMA playback

The correct characters are not displayed (e.g. album name).

Noise is generated. The track played back is not an MP3/WMA track. Skip to

“READING” keeps flashing on the display.

“NO FILE” appears on the display.

“NOT SUPPORT” appears on the display and track skips.

Tracks/folders are not played back in the order you have intended.

• “CANNOT PLAY” flashes on

USB device playback

the display.

• “NO USB” appears on the display.

• The unit cannot detect the USB device.

While playing a track, sound is sometimes interrupted.

Correct characters are not displayed (e.g. album name).

Folder that is physically empty or folder that contains data but does not contain valid MP3/WMA track.

This sometimes occurs during playback. This is caused by how the tracks are recorded on the disc.

Selected folder is an empty folder *. Select another folder that contains MP3/WMA tracks.

Skip to the next track encoded in an appropriate format or to the next non-copy-protected WMA track.

This unit can only display letters (upper case), numbers, and a limited number of symbols.

another file. (Do not add the extension code <.mp3> or <.wma> to non-MP3 or WMA tracks.)

• Readout time varies depending on the USB device.

• Do not use too many hierarchy or folders.

• Turn off the power then on again.

• Reattach the USB device again.

Selected folder is an empty folder *. Select another folder that contains MP3/WMA tracks.

Skip to the next track encoded in an appropriate format or to the next non-copy-protected WMA track.

The playback order is determined by the write-in time stamp. The first track/folder written into the USB device will be the first track/folder for playback.

• Attach a USB device that contains tracks encoded in an appropriate format.

• Reattach the USB device again.

The MP3/WMA tracks have not been properly copied into the USB device. Copy MP3/WMA tracks again into the USB device, and try again.

This unit can only display letters (upper case), numbers, and a limited number of symbols.

25ENGLISH

EN20-27_KD-R511_003A_1.indd 25EN20-27_KD-R511_003A_1.indd 25 10/28/09 10:09:03 AM10/28/09 10:09:03 AM

Specifications

Maximum Power Output: Front/Rear: 50 W per channel

Continuous Power Output (RMS): Front/Rear: 20 W per channel into 4 Ω, 40 Hz to

20 000 Hz at no more than 1% total harmonic distortion.

Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)

Tone Control Range: Bass: ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz)

Q1.0, Q1.25, Q1.5, Q2.0

Middle: ±12 dB (0.5 kHz, 1.0 kHz, 1.5 kHz, 2.5 kHz)

Q0.75, Q1.0, Q1.25

Treble: ±12 dB (10.0 kHz, 12.5 kHz, 15.0 kHz,

17.5 kHz) Q (Fixed)

Frequency Response: 40 Hz to 20 000 Hz

AUDIO AMPLIFIER SECTION

Signal-to-Noise Ratio: 70 dB

Line-Out Level/Impedance: 2.5 V/20 kΩ load (full scale)

Subwoofer-Out Level/Impedance: 2.5 V/20 kΩ load (full scale)

Output Impedance: 1 kΩ

Other Terminal: AUX (auxiliary) input jack, USB input jack, Aerial input,

Steering wheel remote input

Frequency Range: FM: 87.5 MHz to 108.0 MHz

AM: MW: 522 kHz to 1 620 kHz

LW: 144 kHz to 279 kHz

FM Tuner: Usable Sensitivity: 9.3 dBf (0.8 μV/75 Ω)

50 dB Quieting Sensitivity:

Alternate Channel Selectivity (400 kHz):

TUNER SECTION

MW Tuner: Sensitivity: 20 μV

LW Tuner: Sensitivity: 50 μV

Frequency Response: 40 Hz to 15 000 Hz

Stereo Separation: 40 dB

Selectivity: 40 dB

16.3 dBf (1.8 μV/75 Ω)

65 dB

26 ENGLISH

EN20-27_KD-R511_003A_1.indd 26EN20-27_KD-R511_003A_1.indd 26 11/5/09 3:31:09 PM11/5/09 3:31:09 PM

Type: Compact disc player

Signal Detection System: Non-contact optical pickup

(semiconductor laser)

Number of Channels: 2 channels (stereo)

Frequency Response: 5 Hz to 20 000 Hz

Dynamic Range: 96 dB

Signal-to-Noise Ratio: 98 dB

CD PLAYER SECTION

Wow and Flutter: Less than measurable limit

MP3 Decoding Format: (MPEG1/2 Audio Layer 3) Max. Bit Rate: 320 kbps

WMA (Windows Media® Audio) Decoding Format: Max. Bit Rate: 320 kbps

USB Standard: USB 1.1, USB 2.0

Data Transfer Rate (Full Speed): Max. 12 Mbps

Compatible Device: Mass storage class

Compatible File System: FAT 32/16/12

USB SECTION

Playable Audio Format: MP3/WMA

Max. Current: DC 5 V 500 mA

Power Requirement: Operating Voltage: DC 14.4 V (11 V to 16 V allowance)

Grounding System: Negative ground

Allowable Operating Temperature: 0°C to +40°C

Dimensions (W × H × D):

GENERAL

(approx.)

Installation Size: 182 mm × 52 mm × 160 mm

Panel Size: 188 mm × 58 mm × 12 mm

Mass: 1.3 kg (excluding accessories)

Design and specifications are subject to change without notice.

JVC bears no responsibility for any loss of data in the USB mass storage class device while using this System.

Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

27ENGLISH

EN20-27_KD-R511_003A_1.indd 27EN20-27_KD-R511_003A_1.indd 27 10/27/09 5:25:41 PM10/27/09 5:25:41 PM

JVC KD-R511 Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
