JVC KD-G322 User Manual

CD RECEIVER

RECEPTEUR CD

KD-G162/KD-G161

KD-G162

KD-G161

For canceling the display demonstration, see page 5. Pour annuler la démonstration des affichages, référez-vous à la page 5.

ENGLISH

FRANÇAIS

KD-G162

KD-G161

For installation and connections, refer to the separate manual. Pour l’installation et les raccordements, se référer au manuel séparé.

INSTRUCTIONS

MANUEL D’INSTRUCTIONS

GET0334-003A

[EX/EU]

Thank you for purchasing a JVC product.

Please read all instructions carefully before operation, to ensure your complete understanding and to

obtain the best possible performance from the unit.

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

ENGLISH

2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel.

3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.

Warning:

If you need to operate the unit while driving, be sure to look ahead carefully or you may be involved in a traffic accident.

How to reset your unit

• Your preset adjustments will also be erased.

How to forcibly eject a disc

• If this does not work, reset your unit.

• Be careful not to drop the disc when it ejects.

How to detach/attach the control

panel

Detaching...

Attaching...

Note: Only for [EX] model users in UK and European countries For security reasons, a numbered ID card is provided with this unit, and the same ID number is imprinted on the unit’s chassis. Keep the card in a safe place, as it will help the

authorities to identify your unit if stolen.

How to read this manual

• Button operations are mainly explained with the illustrations in the table below.

•

is used to indicate an indicator is

displayed for the correspnding operation.

• Some related tips and notes are explained in “More about this unit” (see pages 14 and 15).

Press briefly.

Press repeatedly.

Press and hold until your desired response begins.

Press and hold both buttons at the same time.

Press either one.

CONTENTS

Control panel — KD-G162 and KD-G161 ........ 4

Getting started ................................. 5

Basic operations .................................................... 5

Radio operations .............................. 6

FM RDS operations ............................ 7

Searching for your favorite FM RDS programme ... 7

Disc operations ................................. 9

Playing a disc in the unit ...................................... 9

Sound adjustments ........................... 10

General settings — PSM ................... 11

Maintenance .................................... 13

More about this unit ......................... 14

Troubleshooting ............................... 16

Specifications ................................... 17

ENGLISH

How to use the M MODE button

If you press M MODE, the unit goes into functions mode, then the number buttons work as different function buttons.

Ex.: When number button 2 works as

MO (monaural) button.

Time countdown indicator

To use these buttons for their original functions again after pressing M MODE, wait

for 5 seconds without pressing any of these buttons until the functions mode is cleared or press M MODE again.

Caution on volume setting:

Discs produce very little noise compared with other sources. Lower the volume before playing a disc to avoid damaging the speakers by the sudden increase of the output level.

For safety...

• Do not raise the volume level too much, as this will block outside sounds, making driving dangerous.

• Stop the car before performing any complicated operations.

Temperature inside the car...

If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.

Control panel — KD-G612/KD-G611/KD-G511

Control panel — KD-G162 and KD-G161

Parts identification

ENGLISH

1 (standby/on/attenuator) button 2 SOURCE button 3 BAND button 4 Loading slot 5 Display window 6 0 (eject) button 7 TP/PTY (traffic programme/programme

type) button

¢/4 buttons

9 Control dial p SEL (select) button q DISP (display) button w EQ (equalizer) button e MO (monaural) button r SSM (Strong-station Sequential Memory)

button

t Number buttons y RPT (repeat) button u RND (random) button

Display window

i M MODE button o

(control panel release) button

Display window

; DISC indicator a RND s RPT (repeat) indicator d LOUD (loudness) indicator f EQ (equalizer) indicator g Sound mode (C-EQ: custom equalizer)

indicators—JAZZ, CLASSIC, HIP HOP, POPS, ROCK, USER

h Source display / Volume level indicator /

Time countdown indicator

j Main display k RDS indicators—TP, PTY, AF, REG l Tuner reception indicators—ST (stereo),

MO (monaural)

(disc random) indicator

Getting started

Basic operations

~ Turn on the power.

Basic settings

• See also “General settings — PSM” on pages 11 and 12.

ENGLISH

* You cannot select “DISC” as the

playback source if there is no disc in the unit.

! For FM/AM tuner

⁄ Adjust the volume.

Volume level appears.

Volume level indicator

@ Adjust the sound as you want. (See

page 10.)

To drop the volume in a moment (ATT)

To restore the sound, press it again.

To turn off the power

1 Canceling the display

demonstrations

Select “DEMO,” then “DEMO OFF.”

2 Setting the clock

Select “CLOCK H” (hour), then adjust the hour. Select “CLOCK M” (minute), then adjust the minute. Select “24H/12H,” then “24H” (hour) or “12H” (hour).

3 Finish the procedure.

To check the current clock time while...

The power is turned off

Listening to...

An FM (non-RDS) or AM station:

Frequency Ô Clock

An FM RDS station:

Station name (PS) = Station Frequency = Programme type (PTY) = Clock = (back to

the beginning)

Listening to a disc...

Elapsed playing time with track number Ô Clock

Radio operations

ENGLISH

When an FM stereo broadcast is hard to receive

Lights up when receiving an FM stereo broadcast with sufficient signal strength.

Selected band appears.

! Start searching for a station.

When a station is received, searching stops. To stop searching, press the same button again.

To tune in to a station manually

In step ! above... 1

2 Select the desired station frequencies.

Lights up when monaural mode is activated.

Reception improves, but stereo effect will be lost.

To restore the stereo effect, repeat the same procedure. “MONO OFF” appears and the MO indicator goes off.

Storing stations in memory

You can preset six stations for each band.

FM station automatic presetting —

SSM (Strong-station Sequential Memory)

1 Select the FM band (FM1 – FM3) you

want to store into.

“SSM” flashes, then disappears when automatic presetting is over.

Local FM stations with the strongest signals are searched and stored automatically in the FM band.

Manual presetting

Ex.: Storing FM station of 92.5 MHz into preset

number 4 of the FM1 band.

Preset number flashes for a while.

Listening to a preset station

FM RDS operations

What you can do with RDS

RDS (Radio Data System) allows FM stations to send an additional signal along with their regular programme signals. By receiving the RDS data, this unit can do the

following:

•

Programme Type (PTY) Search (see the following)

• TA (Traffic Announcement) and PTY

Standby Receptions (see pages 8 and 12)

•

Tracing the same programme automatically —Network-Tracking Reception (see page 9)

• Programme Search (see page 12)

Searching for your favorite FM RDS programme

You can tune in to a station broadcasting your favorite programme by searching for a PTY code.

•

To store your favorite programme types, see page 8.

ENGLISH

2 Select the preset station (1 – 6) you

want.

~ The last selected PTY

code appears.

Ÿ Select one of your favorite

programme types.

Select one of the PTY codes (see

page 15).

To be continued...

! Start searching for your favorite

programme.

If there is a station broadcasting a programme

ENGLISH

Storing your favorite programme

You can store six favorite programme types.

Preset programme types in the number buttons (1 to 6):

1 Select a PTY code (see page 7). 2 Select the preset number (1 – 6) you

want to store into.

of the same PTY code as you have selected, that station is tuned in.

types

Using the standby receptions

TA Standby Reception

TA Standby Reception allows the unit to switch temporarily to Traffic Announcement (TA) from any source other than AM. The volume changes to the preset TA volume level if the current level is lower than the preset level (see page 12).

To activate TA Standby Reception

The TP (Traffic Programme)

indicator either lights up or flashes.

• If the TP indicator lights up, TA Standby Reception is activated.

• If the TP indicator flashes, TA Standby Reception is not yet activated. (This occurs when you are listening to an FM station without the RDS signals required for TA Standby Reception.)

To activate TA Standby Reception, tune in to

another station providing these signals. The TP indicator will stop flashing and remain lit.

To deactivate the TA Standby Reception

The TP indicator goes off.

Ex.: When “ROCK M” is selected

3 Repeat steps 1 and 2 to store other

PTY codes into other preset numbers.

4 Finish the procedure.

PTY Standby Reception

PTY Standby Reception allows the unit to switch temporarily to your favorite PTY programme from any source other than AM.

To activate and select your favorite PTY code for PTY Standby Reception, see page 12.

The PTY indicator either lights up or flashes.

• If the PTY indicator lights up, PTY Standby Reception is activated.

• If the PTY indicator flashes, PTY Standby Reception is not yet activated. To activate PTY Standby Reception, tune in to another station providing these signals. The PTY indicator will stop flashing and remain lit.

To deactivate the PTY Standby Reception, select “OFF” for the PTY code (see page 12). The PTY indicator goes off.

Tracing the same programme—

Network-Tracking Reception

When driving in an area where FM reception is not sufficient enough, this unit automatically tunes in to another FM RDS station of the same network, possibly broadcasting the same programme with stronger signals (see the illustration on page 15).

When shipped from the factory, NetworkTracking Reception is activated.

To change the Network-Tracking Reception setting, see “AF-REG” on page 11.

Disc operations

To locate a particular track

To select a number from 01 – 06:

To select a number from 07 – 12:

Prohibiting disc ejection

You can lock a disc in the loading slot.

ENGLISH

Playing a disc in the unit

All tracks will be played repeatedly until you change the source or eject the disc.

To stop play and eject the disc

To fast-forward or reverse the track

To go to the next or previous tracks

To cancel the prohibition, repeat the same procedure.

Selecting the playback modes

You can use only one of the following playback modes at a time.

2 Select your desired playback mode.

7 Repeat play

Mode Plays repeatedly

TRK RPT : The current track. RPT OFF : Cancels.

7 Random play

Mode Plays at random

DISC RND : All tracks of the current disc.

RND OFF : Cancels.

Sound adjustments

You can select a preset sound mode suitable to the music genre (C-EQ: custom equalizer).

Adjusting the sound

You can adjust the sound characteristics to your preference.

ENGLISH

Preset values

Indication (For)

USER (Flat sound)

ROCK

(Rock or disco music)

CLASSIC

(Classical music)

POPS (Light music)

HIP HOP

(Funk or rap music)

JAZZ (Jazz music)

Ex.: When “ROCK” is selected

BAS TRE LOUD

(bass) (treble)

00 00 OFF

+03 +01 ON

+01 –02 OFF

+04 +01 OFF

+02 00 ON

+02 +03 OFF

(loudness)

Indication, [Range]

BAS*1 (bass), [–06 to +06]

Adjust the bass.

TRE*1 (treble), [–06 to +06]

Adjust the treble.

FAD*

(fader), [R06 to F06]

Adjust the front and rear speaker balance.

BAL (balance), [L06 to R06] Adjust the left and right speaker balance.

LOUD*1 (loudness), [LOUD ON or LOUD OFF]

Boost low and high frequencies to produce a well-balanced sound at low volume level.

VOL (volume), [00 to 30 or 50* Adjust the volume.

When you adjust the bass, treble, or loudness,

the adjustment you have made is stored for the currently selected sound mode (C-EQ) including “USER.”

If you are using a two-speaker system, set the

fader level to “00.”

Depending on the amplifier gain control

setting. (See page 12 for details.)

]

General settings — PSM

You can change PSM (Preferred Setting Mode) items listed in the table below.

3 Adjust the PSM item selected.

2 Select a PSM item.

4 Repeat steps 2 and 3 to adjust other

PSM items if necessary.

5 Finish the procedure.

Indications Selectable settings, [reference page]

DEMO

Display demonstration

CLOCK H

Hour adjustment

CLOCK M

Minute adjustment

DEMO ON : [Initial]; Display demonstration will be activated

automatically if no operation is done for about 20 seconds, [5].

DEMO OFF : Cancels.

0 – 23 (1 – 12), [5]

[Initial: 0 (0:00)]

00 – 59, [5]

[Initial: 00 (0:00)]

ENGLISH

24H/12H

Time display mode

CLK ADJ

Clock adjustment

AF-REG

Alternative frequency/ regionalization reception

12H O 24H, [5]

[Initial: 24H]

AUTO : [Initial]; The built-in clock is automatically adjusted

using the CT (clock time) data in the RDS signal.

OFF : Cancels.

When the received signals from the current FM RDS station become

weak...

AF : [Initial]; Switches to another station (the programme

may differ from the one currently received), [9].

• The AF indicator lights up. AF REG : Switches to another station broadcasting the same

programme.

• The AF and REG indicators light up. OFF : Cancels.

To be continued...

+ 23 hidden pages
