JVC KDDV-4200, KDDV-4202, KDDV-4201, KDDV-4204, KDDV-4205 Service manual

SERVICE MANUAL

DVD/CD RECEIVER

MA24820062

KD-DV4200J,KD-DV4201E,KD-DV4201EU,

KD-DV4202E,KD-DV4202EU,KD-DV4203UI,

KD-DV4204UI,KD-DV4205U,KD-DV4205UN,

KD-DV4205UT,KD-DV4205A,KD-DV4206U,

KD-DV4206UN,KD-DV4206UT,KD-DV4206A,

KD-DV4207EE

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

TABLE OF CONTENTS

1 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-25

5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-31

COPYRIGHT © 2006 Victor Company of Japan, Limited

No.MA248

2006/2

SPECIFICATION

KD-DV4200

AUDIO AMPLIFIER SECTION

Power Output 17 W RMS × 4 Channels at 4 Ω and 1% THD+N
Signal to Noise Ratio 80 dBA (reference: 1 W into 4 Ω)
Load Impedance 4 Ω (4 Ω to 8 Ω allowance)

Tone Control Range Bass ±10 dB at 100Hz

Treble ±10 dB at 10kHz

Audio Output Level Digital (DIGITAL OUT: Optical) Signal wave length : 660 nm

Output level : -21 dBm to -15 dBm

Line-Out Level/Impedance 2.0 V/20 k

Output Impedance 1 k

Color System NTSC

Video Output (composite) 1 Vp-p/75 Ω

Other Terminals CD changer

TUNER SECTION

Frequency Range FM 87.5 MHz to 107.9 MHz (with channel interval set to 100 kHz or 200 kHz)

AM 530 kHz to 1 710 kHz (with channel interval set to 10 kHz)

FM Tuner Usable Sensitivity 11.3 dBf (1.0

50 dB Quieting Sensitivity 16.3 dBf (1.8

Alternate Channel Selectivity (400 kHz) 65 dB

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 35 dB

AM Tuner Sensitivity 20

Selectivity 35 dB

DVD/CD PLAYER SECTION

Signal Detection System Non-contact optical pickup (semiconductor laser)

Number of Channels 2 channels (stereo)

Frequency Response DVD, fs=48 kHz 16 Hz to 22 000 Hz

DVD, fs=96 kHz 16 Hz to 44 000 Hz

VCD, CD, MP3, WMA 16 Hz to 20 000 Hz

Dynamic Range 96 dB

Signal-to-Noise Ratio 98 dB

Wow and Flutter Less than measurable limit

MP3 (MPEG Audio Layer 3) Bit Rate 32 kbps - 320 kbps

Sampling frequency MPEG-1 : 48 kHz, 44.1 kHz, 32 kHz

WMA (Windows Media® Audio) Bit Rate 32 kbps -192 kbps

Sampling frequency 48 kHz, 44.1 kHz, 32 kHz

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)

Grounding System Negative ground

Allowable Operating Temperature 0°C to +40°C (32°F to 104°F)

Dimensions (W

Mass (approx.) 1.7 kg (3.7 lbs) (excluding accessories)

× H × D) Installation Size (approx.) 182 mm × 52 mm × 158 mm

Panel Size (approx.) 188 mm

87.5 MHz to 108.0 MHz (with channel interval set to 50 kHz)

531 kHz to 1 602 kHz (with channel interval set to 9 kHz)

MPEG-2 : 24 kHz, 22.05 kHz, 16 kHz

GENERAL

(7-3/16"

(7-7/16"

Ω load (full scale)

Ω

µV/75 Ω)
µV/75 Ω)

µV

× 2-1/16" × 6-1/4")

× 58 mm × 11 mm

× 2-5/16" × 7/16")

1-2 (No.MA248)

KD-DV4201/KD-DV4202

AUDIO AMPLIFIER SECTION

Maximum Power Output Front/Rear 45 W per channel

Continuous Power Output
(RMS)

Load Impedance 4

Tone Control Range Bass/Treble ±10 dB at 100 Hz/±10 dB at 10 kHz

Frequency Response 40 Hz to 20 000 Hz

Signal-to-Noise Ratio 70 dB

Audio Output Level Digital (DIGITAL OUT: Optical) Signal wave length : 660 nm

Color System PAL

Video Output (composite) 1 Vp-p/75

Other Terminals CD changer, Steering wheel remote input

Frequency Range FM 87.5 MHz to 108.0 MHz

FM Tuner Usable Sensitivity 11.3 dBf (1.0

MW Tuner Sensitivity/Selectivity 20

LW Tuner Sensitivity 50

Signal Detection System Non-contact optical pickup (semiconductor laser)

Number of Channels 2 channels (stereo)

Frequency Response DVD, fs=48 kHz 16 Hz to 22 000 Hz

Dynamic Range 96 dB

Signal-to-Noise Ratio 98 dB

Wow and Flutter Less than measurable limit

MP3 Bit Rate 32 kbps - 320 kbps

WMA Bit Rate 32 kbps - 192 kbps

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)

Grounding System Negative ground

Allowable Operating Temperature 0

Dimensions (W

Mass (approx.) 1.6 kg (excluding accessories)

× H × D) Installation Size (approx.) 182 mm × 52 mm × 158 mm

Front/Rear 17 W per channel into 4

monic distortion

Ω (4 Ω to 8 Ω allowance)

Output level : -21 dBm to -15 dBm

Line-Out Level/Impedance 2.0 V/20 k

Output Impedance 1 k

Ω load (full scale)

Ω

Ω

TUNER SECTION

AM (MW) 522 kHz to 1 620 kHz

(LW) 144 kHz to 279 kHz

µV/75 Ω)

50 dB Quieting Sensitivity 16.3 dBf (1.8

Alternate Channel Selectivity (400 kHz) 65 dB

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 30 dB

µV/75 Ω)

µV/35 dB
µV

DVD/CD PLAYER SECTION

DVD, fs=96 kHz 16 Hz to 44 000 Hz

VCD/CD/MP3/WMA 16 Hz to 20 000 Hz

Sampling Frequency 48 kHz, 44.1 kHz, 32 kHz

Sampling Frequency MPEG-1 : 48 kHz, 44.1 kHz, 33 kHz

MPEG-2 : 24 kHz, 22.05 kHz, 16 kHz

GENERAL

°C to +40°C

Panel Size (approx.) 188 mm

× 58 mm × 11 mm

Ω, 40 Hz to 20 000 Hz at no more than 0.8% total har-

(No.MA248)1-3

KD-DV4203/KD-DV4204/KD-DV4205/KD-DV4206

AUDIO AMPLIFIER SECTION

Maximum Power Output Front/Rear 50 W per channel

Continuous Power Output
(RMS)

Load Impedance 4

Tone Control Range Bass/Treble ±10 dB at 100 Hz/±10 dB at 10 kHz

Frequency Response 40 Hz to 20 000 Hz

Signal-to-Noise Ratio 70 dB

Audio Output Level Digital (DIGITAL OUT: Optical) Signal wave length : 660 nm

Color System PAL/NTSC

Video Output (composite) 1 Vp-p/75

Other Terminal CD changer

Frequency Range FM 87.5 MHz to 108.0 MHz

FM Tuner Usable Sensitivity 11.3 dBf (1.0

AM Tuner Sensitivity/Selectivity 20

Signal Detection System Non-contact optical pickup (semiconductor laser)

Number of Channels 2 channels (stereo)

Frequency Response DVD, fs=48 kHz 16 Hz to 22 000 Hz

Dynamic Range 96 dB

Signal-to-Noise Ratio 98 dB

Wow and Flutter Less than measurable limit

MP3 Bit Rate 32 kbps - 320 kbps

WMA Bit Rate 32 kbps - 192 kbps

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)

Grounding System Negative ground

Allowable Operating Temperature 0

Dimensions (W

Mass (approx.) 1.6 kg (excluding accessories)

× H × D) Installation Size (approx.) 182 mm × 52 mm × 158 mm

Front/Rear 19 W per channel into 4

total harmonic distortion

Ω (4 Ω to 8 Ω allowance)

Output level : -21 dBm to -15 dBm

Line-Out Level/Impedance 2.0 V/20 k

Output Impedance 1 k

Ω load (full scale)

Ω

Ω

TUNER SECTION

AM 531 kHz to 1 602 kHz

µV/75 Ω)

50 dB Quieting Sensitivity 16.3 dBf (1.8

Alternate Channel Selectivity (400 kHz) 65 dB

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 30 dB

µV/75 Ω)

µV/35 dB

DVD/CD PLAYER SECTION

DVD, fs=96 kHz 16 Hz to 44 000 Hz

VCD/CD/MP3/WMA 16 Hz to 20 000 Hz

Sampling Frequency 48 kHz, 44.1 kHz, 32 kHz

Sampling Frequency MPEG-1 : 48 kHz, 44.1 kHz, 33 kHz

MPEG-2 : 24 kHz, 22.05 kHz, 16 kHz

GENERAL

°C to +40°C

Panel Size (approx.) 188 mm

× 58 mm × 11 mm

Ω, 40 Hz to 20 000 Hz at no more than 0.8%

1-4 (No.MA248)

KD-DV4207

AUDIO AMPLIFIER SECTION

Maximum Power Output Front/Rear 50 W per channel

Continuous Power Output
(RMS)

Load Impedance 4

Tone Control Range Bass/Treble ±10 dB at 100 Hz/±10 dB at 10 kHz

Frequency Response 40 Hz to 20 000 Hz

Signal-to-Noise Ratio 70 dB

Audio Output Level Digital (DIGITAL OUT: Optical) Signal wave length : 660 nm

Color System PAL

Video Output (composite) 1 Vp-p/75

Other Terminals CD changer

Frequency Range FM1 /FM2 87.5 MHz to 108.0 MHz

FM Tuner Usable Sensitivity 11.3 dBf (1.0

MW Tuner Sensitivity/Selectivity 20

LW Tuner Sensitivity 50

Signal Detection System Non-contact optical pickup (semiconductor laser)

Number of Channels 2 channels (stereo)

Frequency Response DVD, fs=48 kHz 16 Hz to 22 000 Hz

Dynamic Range 96 dB

Signal-to-Noise Ratio 98 dB

Wow and Flutter Less than measurable limit

MP3 Bit Rate 32 kbps - 320 kbps

WMA Bit Rate 32 kbps - 192 kbps

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)

Grounding System Negative ground

Allowable Operating Temperature 0

Dimensions (W

Mass (approx.) 1.6 kg (excluding accessories)

× H × D) Installation Size (approx.) 182 mm × 52 mm × 158 mm

Front/Rear 19 W per channel into 4

total harmonic distortion

Ω (4 Ω to 8 Ω allowance)

Output level : -21 dBm to -15 dBm

Line-Out Level/Impedance 2.0 V/20 k

Output Impedance 1 k

Ω load (full scale)

Ω

Ω

TUNER SECTION

FM3 65.00 MHz to 74.00 MHz

AM (MW) 522 kHz to 1 620 kHz

(LW) 144 kHz to 279 kHz

µV/75 Ω)

50 dB Quieting Sensitivity 16.3 dBf (1.8

Alternate Channel Selectivity (400 kHz) 65 dB

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 30 dB

µV/75 Ω)

µV/35 dB
µV

DVD/CD PLAYER SECTION

DVD, fs=96 kHz 16 Hz to 44 000 Hz

VCD/CD/MP3/WMA 16 Hz to 20 000 Hz

Sampling Frequency 48 kHz, 44.1 kHz, 32 kHz

Sampling Frequency MPEG-1 : 48 kHz, 44.1 kHz, 33 kHz

MPEG-2 : 24 kHz, 22.05 kHz, 16 kHz

GENERAL

°C to +40°C

Panel Size (approx.) 188 mm

× 58 mm × 11 mm

Ω, 40 Hz to 20 000 Hz at no more than 0.8%

(No.MA248)1-5

• "DVD Logo" is a trademark of DVD Format/Logo Licensing Corporation registered in the US, Japan and other countries.

• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/
or other countries.

• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

• "DTS" and "DTS 2.0 + Digital Out" are registered trademarks of Digital Theater Systems, Inc.

• iPod is a trademark of Apple Computer, inc., registered in the U.S. and other countries.

• "SIRIUS" and the SIRIUS dog logo are registered trademarks of SIRIUS Satellite Radio Inc.

• XM and its corresponding logos are registered trademarks of XM Satellite Radio Inc.

• "SAT Radio," the SAT Radio logo and all related marks are trademarks of SIRIUS Satellite Radio Inc., and XM Satellite Radio, Inc.

• Design and specifi cations are subject to change without notice.

1-6 (No.MA248)

1.1 Safety Precautions

SECTION 1

PRECAUTIONS

!

!

Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.

Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.

(No.MA248)1-7

1.2 Preventing static electricity

Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.

1.2.1 Grounding to prevent damage by static electricity

Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as DVD players.
Be careful to use proper grounding in the area where repairs are being performed.

(1) Ground the workbench

Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.

(2) Ground yourself

Use an anti-static wrist strap to release any static electricity built up in your body.

(caption)
Anti-static wrist strap

1M

Conductive material
(conductive sheet) or iron plate

(3) Handling the optical pickup

• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)

• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.

1.3 Handling the traverse unit (optical pickup)

(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the

replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a

time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) It is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.

1.4 Attention when traverse unit is decomposed

*Please refer to "Disassembly method" in the text for the DVD pickup unit.

• Apply solder to the short land before the flexible wire is disconnected from the connector on the DVD pickup unit.
(If the flexible wire is disconnected without applying solder, the DVD pickup may be destroyed by static electricity.)

• In the assembly, be sure to remove solder from the short land after connecting the flexible wire.

Flexible wire

1-8 (No.MA248)

CN101

Short-circuit points

Mechanism control board

1.5 Important for laser products

!

1.CLASS 1 LASER PRODUCT

2.DANGER : Invisible laser radiation when open and inter

lock failed or defeated. Avoid direct exposure to beam.

3.CAUTION : There are no serviceable parts inside the

Laser Unit. Do not disassemble the Laser Unit. Replace

the complete Laser Unit if it malfunctions.

4.CAUTION : The CD,MD and DVD player uses invisible

laser radiation and is equipped with safety switches which

prevent emission of radiation when the drawer is open and

the safety interlocks have failed or are defeated. It is

dangerous to defeat the safety switches.

5.CAUTION : If safety switches malfunction, the laser is able

to function.

6.CAUTION : Use of controls, adjustments or performance of

procedures other than those specified here in may result in

hazardous radiation exposure.

Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.

REPRODUCTION AND POSITION OF LABELS

WARNING LABEL

CAUTION : Visible and Invisible

CLASS 1
LASER PRODUCT

laser radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE TO
BEAM. (e)

ADVARSEL : Synlig og usynlig
laserstråling når maskinen er
åben eller interlocken fejeler.
Undgå direkte eksponering til
stråling. (d)

VARNING : Synlig och
osynling laserstrålning när
den öppnas och spärren är
urkopplad. Betrakta ej
strålen. (s)

VARO : Avattaessa ja suojalukitus
ohitettuna tai viallisena olet alttiina
näkyvälle ja näkymättömälle
lasersäteilylle. Vältä säteen
kohdistumista suoraan itseesi. (f)

(No.MA248)1-9

SECTION 2

SPECIFIC SERVICE INSTRUCTIONS

This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

1-10 (No.MA248)

SECTION 3

DISASSEMBLY

3.1 Main body section

3.1.1 Removing the front panel assembly
(See Fig.1)

Push the detach button in the lower left part of the front panel as­sembly and remove the front panel assembly.

3.1.2 Removing the bottom cover
(See Fig.1)

Reference:

Remove the front panel assembly as required.
(1) Release the two joints a, two joints b and joint c.
(2) Remove the bottom cover from the main body.

Caution:

Do not damage the main board when releasing the joints using

a screwdriver or a similar tool.

Front panel assembly

Detach button

Fig.1

b

Bottom cover

a

3.1.3 Removing the front chassis assembly
(See Fig.3)

• Remove the front panel assembly and bottom cover.

(1) From the both sides of the main body, remove the two

screws A attaching the front chassis assembly.

(2) Release the two joints d and two joints e.

a

b

c

Fig.2

d

A

d

Front chassis assembly

Fig.3

A

e

e

(No.MA248)1-11

3.1.4 Removing the side heat sink
(See Fig.4)

Reference:

Remove the front panel and front chassis assemblies as re-

quired.
From the left side of the main body, remove the two screws B and
three screws C attaching the side heat sink.

B

3.1.5 Removing the rear bracket

(See Fig.5)

• Remove the bottom cover.

(1) From the back side of the main body, remove the screws

D, screw E, tow screws F, three screws G and screw H at­taching the rear bracket.

(2) Remove the rear bracket.

Reference:

The quantity of screws D differs by each model.

D

G

G

C

Fig.4

Cable holder

G

E

(For KD-DV4201 and KD-DV4202)

F

G

Side heat sink

Rear bracket

D

Rear bracket

D
G

H

D
G

1-12 (No.MA248)

E

F

Fig.5

D

H

3.1.6 Removing the main board
(See Figs.5 and 6)

• Remove the front panel assembly, bottom cover, front chassis

assembly and side heat sink.

Reference:

Remove the rear bracket as required.

(1) From the back side of the main body, remove the three

screws G attaching the main board. (See Fig.5.)

(2) From the bottom side of the main body, remove the three

screws J attaching the main board. (See Fig.6.)

(3) Disconnect the connector CN961

the DVD mechanism assembly and take out the main
board from the main body. (See Fig.6.)

3.1.7 Removing the DVD mechanism assembly
(See Fig.7)

• Remove the front panel assembly, bottom cover, front chassis

assembly, side heat sink and main board.
(1) From the inside of the top chassis, remove the three

screws K attaching the DVD mechanism assembly.

(2) Take out the DVD mechanism assembly from the top chas-

sis.

on the main board from

CN961

J

DVD mechanism assembly

K

J

J

Main board

Fig.6

K

K

Fig.7

Top chassis

(No.MA248)1-13

3.1.8 Removing the main sub board
(See Figs.8 to 10)

• Remove the front panel assembly, bottom cover, front chassis

assembly, side heat sink, main board and DVD mechanism as­sembly.
(1) From the top side of the DVD mechanism assembly, re-

move the two screws M attaching the dust cover. (See
Fig.8.)

(2) Remove the dust cover from the DVD mechanism assem-

bly. (See Fig.8.)

Reference:

When attaching the dust cover, align the joints f in the
holes of the dust cover before attaching the screws M.
(See Fig.8.)

(3) Release the lock of the connector CN962

board and disconnect the card wire. (See Fig.9.)
(4) Bend the joint g in the direction of the arrow. (See Fig.9.)
(5) Remove the two screws N attaching the main sub board

and remove the main sub board from the DVD mechanism

assembly. (See Fig.9.)

Reference:

• When attaching the main sub board, align the joints h in the

holes of the main sub board before attaching the screws N.
(See Fig.9.)

• When the resolution of DVD mechanism assembly is done

sequentially, remove the two screws P attaching the support
bracket. (See Fig.10.)

• Remove the card wire from the connector CN401

quired. (See Fig.10.)

on the main sub

as re-

DVD mechanism assembly

Dust cover

Fig.8

DVD mechanism assembly

CN962

h

M

Lock

f

M

f

g

N

P

h

Main sub board

Fig.9

Support bracket

CN401

Fig.10

1-14 (No.MA248)

3.1.9 Removing the switch board
(See Figs. 11 to 13)

• Remove the front panel assembly.

(1) From the back side of the front panel assembly, remove the

four screws Q attaching the rear cover. (See Fig.11.)

(2) Release the joints j attaching the rear cover to the front

panel assembly. (See Fig.12.)

(3) Release the joint k and take out the switch board while lift-

ing the switch board from the front panel assembly little by
little. (See Fig.13.)

Reference:

Remove the volume knob from the front side of the front panel
assembly at the same time.

Note:

Do not lose the compression springs when removing the
switch board. (See Fig.13.)

Q

Q

Rear cover

Q

Fig.11

Joints j

Joints j Joints j

Fig.12

Switch board

Joint

Fig.13

Joints j

Front panel assembly

k

(No.MA248)1-15

3.2 DVD mechanism assembly

3.2.1 Removing the mechanism control board
(See Fig.1)

Caution:

Before disconnecting the flexible wire extending from the DVD
pickup, solder the short-circuit point on the flexible wire using
a grounding soldering iron. If you do not follow this instruction,
the DVD pickup may be damaged.
(1) Turn over the body, and solder the short-circuit points on

the flexible wire extending from the DVD pickup.

(2) Disconnect the flexible wire from connector CN101

mechanism control board.

(3) Disconnect the card wire from connector CN201

mechanism control board.

(4) Disconnect the flexible wire from connector CN202

mechanism control board.

(5) Unsolder two soldered points a on the mechanism control

board and remove the wire extending from the feed motor.
(6) Remove the screw A attaching the lug wire.
(7) Remove the two screws B and screw C attaching the

mechanism control board.

Caution:

• As the flexible wire to be connected to CN101

attach it to the mechanism control board using a double
tape.

• After reassembling, unsolder the short-circuit points.

on the

on the

on the

, make sure to

Flexible wire

Double tape

CN101

B

Short-circuit points

A

Lug wire

B

CN201

Feed motor

a

C

CN202

Mechanism control board

Fig.1

1-16 (No.MA248)

3.2.2 Removing the top cover
(See Fig.2)

(1) Remove the two screws D attaching the top cover on the

back of the body.

(2) Remove the top cover upward.

Reference:

When reassembling, set part b of the top cover under the
bending part c of the chassis frame.

3.2.3 Removing the mechanism section
(See Fig.2 to 4)

• Remove the top cover.

(1) From the bottom of the body, remove the screw E attaching

the lug wire. (See Fig.2.)

(2) Remove the two screws F attaching the right and left stop-

pers on the front side. (See Fig.2.)

(3) Remove the two floating springs on the bottom of the body.

(See Fig.3.)

(4) Move the mechanism section upward and remove from the

chassis frame.
The three damper springs come off from the dampers.
(See Fig.4.)

Caution:

• When reassembling, reattach the damper spring to the
damper respectively and insert the three shafts on the bot­tom of the mechanism to the dampers.

• Before inserting the shaft to the dampers, apply IPA to the
hole of damper.

Floating spring

Fig.3

Mechanism section

Stopper

F

Top cover

Stopper

F

D

D

b

c

E

Lug wire

Damper SP.(F)

(Silver)

Damper (F)
(Black)

Damper SP.(F)

(Silver)

Damper (F)
(Black)

Fig.4

Damper SP.(R)

(Red)

Damper (R)
(Purple)

Chassis frame

Fig.2

(No.MA248)1-17

3.2.4 Removing the clamper unit
(See Fig.5 to 7)

• Remove the top cover and the mechanism section.

(1) Remove the clamper2 spring on the bottom of the mecha-

nism section. (See Figs.5.and 6.)

(2) Release the part d of the clamper spring from the bending

part of the chassis base assembly. (See Fig.7.)

(3) Move the clamper unit in the direction of the arrow and turn.

Release the two joints e and f, then remove the clamper
unit upward. (See Fig.6.)

3.2.5 Reattaching the clamper unit
(See Fig.5 to 9)

(1) Attach the clamper spring to the clamper unit. (See Fig.8.)
(2) Move the clamper unit to set the side joints e and f to each

boss of the chassis base assembly. Make sure that part g
is inserted to the notch of the chassis base assembly. (See
Figs.5 and 9.)

(3) Move the part d of the clamper spring to the outside of the

bending part of the chassis base assembly. (See Fig.7.)

(4) Attach the clamper2 spring to the chassis base assembly.

(See Figs.5 and 6.)

Caution:

When reattaching, temporarily hook the end of the clamper
spring as shown in the figure to make the work easy. (See
Fig.8.)

Clamper unit

Clamper2 spring

Chassis base assembly

Fig.6

Clamper spring

Clamper spring

f

Clamper2 spring

Chassis base assembly

g

d

Chassis base assembly

Fig.7

e

Fig.5

1-18 (No.MA248)

Clamper unit

Clamper unit

Clamper spring

Fig.8

Fig.9

g

Notch

(No.MA248)1-19

3.2.6 Removing the front unit
(See Fig.10 to 12)

• Remove the top cover and the mechanism section.

(1) Disconnect the flexible wire from connector CN202 on the

mechanism control board at the bottom of the body. (See
Fig.10.)

(2) Remove the screw G attaching the front unit on the top of

the body. (See Fig.11.)

(3) Move the front unit toward the front to release joint h, and

release two joints i and j on the right side of the chassis
base assembly. Then remove the front unit upward. (See
Figs.11 and 12.)

(4) Remove the two screws H attaching the switch board. (See

Fig.12.)

Reference:

You can remove the switch board only without removing the
front unit.

Caution:

When reassembling, attach the flexible wire extending from
the switch board using the double tape. (See Figs.10 and 12.)

Mechanism control board

G

Front unit

h

Fig.11

CN202

Double tape

Fig.10

Flexible wire

Double tape

j

i

H

Switch board

Front unit

G

1-20 (No.MA248)

h

Fig.12

3.2.7 Removing the loading arm assembly

(See Fig.13 , 14)

• Remove the top cover, the mechanism section and the front

unit.
(1) From the top of the body, move the loading arm assembly

from the front side upward, and release the bosses from
the right and left joints k and m of the chassis base assem­bly.

(2) Release the boss from notch n of the connect arm on the

right side of the body, and release the boss from notch p of
the slide cam assembly on the left side.

m

Loading arm assembly

Side cam
assembly

p

m

k

Fig.13

Loading arm assembly

k

n

n

Connect arm

Fig.14

(No.MA248)1-21

3.2.8 Removing the rod (L)(R)/roller assembly
(See Fig.15 and 16)

• Remove the top cover, the mechanism section, the front unit

and the loading arm assembly.
(1) Release the rod (L) and (R) from the joints q at the bottom

of the loading arm assembly (See Fig.15.)

(2) Remove the roller assembly from the loading arm assem-

bly. (See Fig.16.)

(3) Remove the two collars and washer from the roller assem-

bly. (See Fig.16.)

Caution:

After attaching the loading arm assembly to the roller assem­bly, attach the rod (L) and (R). Attach the rods to the right and
left collars of the roller. (See Fig.15.)
When reattaching the rod (L) and (R) to the loading arm as­sembly, engage each joint as shown in Fig.15. As joints q of
the rod (L), let the rod through q before reattaching it.

Collar

Collar

Rod(R) Rod(L)

q

q

q

Collar

Rod(L)

Rod(R)

q

Loading arm assembly

Fig.15

Roller assembly

Loading arm assembly

q

Rod(L)

q

Collar

Washer

Rod(R)

1-22 (No.MA248)

Fig.16

3.2.9 Removing the DVD pickup assembly

(See Fig.17 to 19)

• Remove the mechanism control board.

(1) From the bottom of the body, turn the feed gear in the di-

rection of the arrow to move the DVD pickup outwards.
(See Fig.17.)

(2) Remove the screw J attaching the thrust spring. (See

Fig.17.)

(3) Remove the DVD pickup assembly upward on the L.S.gear

side and release from sub shaft at joint r. Move the lead
screw of the DVD pickup assembly in the direction of the
arrow to release from joint s. (See Fig.18.)

Caution:

• When releasing the lead screw at joint s, the L.S.collar
comes off at the end of the lead screw. When reas­sembling, reattach the L.S.collar to the lead screw and
engage joint s. (See Fig.18.)

• When reattaching the L.S.collar, reattach it to the point
s of the lead screw, and to the rod (M). Make sure that
the L.S.collar is set on the rod (M) spring. (See Fig.18.)

(4) Remove the screw K attaching the rack spring/ rack plate

on the DVD pickup. (See Fig.19.)

(5) Pull out the lead screw. (See Fig.19.)

Caution:

Perform adjustment after replacing the pickup.

DVD Pickup assembly

DVD Pickup assembly

Feed gear

J

Thrust spring

Fig.17

s

L.S.collar

Rod(M)

Lead screw

Sub shaft

L.S.collar

r

L.S.gear

Fig.18

K

Rack spring

Lead screw

Rack plate

DVD Pickup

Fig.19

(No.MA248)1-23

3.2.10 Removing the spindle motor

r

(See Fig.20)

• Remove the mechanism control board.
Remove the two screws L attaching the spindle motor on the
bottom of the body.

Caution:

Perform adjustment when reattaching the spindle motor.

3.2.11 Removing the feed motor assembly

(See Fig.21 and 22)

• Remove the mechanism control board.
(1) Remove the feed TRI. spring on the bottom of the body.

(See Fig.21.)

(2) Remove the two screws M attaching the feed motor as-

sembly. (See Fig.21.)

(3) Remove the slit washer from the motor H. assembly and

pull out the worm wheel. (See Fig.22.)
Remove the two screws N attaching the feed motor. (See
Fig.22.)

Spindle motor

Feed TRI. spring

L

Fig.20

M

Feed motor assembly

1-24 (No.MA248)

Fig.21

Slit washer

Worm wheel

Feed moto

N

Motor H. assembly

Fig.22

SECTION 4

ADJUSTMENT

4.1 Test instruments required for adjustment

(1) Digital oscilloscope (100MHz)
(2) Jitter meter
(3) Digital tester
(4) Electric voltmeter
(5) Tracking offset meter
(6) Test Disc : VT501 or VT502
(7) Extension studs : STDV001-3P
(8) Extension cable : EXTDV002-30P

4.3 Connection method

Connection procedure

(1) Attach the front chassis assembly to the main board.
(2) Connect the front panel assembly to the main board.
(3) Attach the heat sink and rear bracket to the main board.
(4) Attach the extension studs to the DVD mechanism assembly.
(5) Connect the DVD mechanism assembly and the main board with a extension cable.

4.2 Standard measuring conditions

Power supply voltage DC14.4V(11 to 16V)

Load impedance 4Ω(2 Speakers connection)
Line Output 20KΩ

Caution:

Be sure to attach the heat sink and rear bracket onto the power
amplifier IC and regulator IC respectively, before supply the
power. If voltage is applied without attaching these parts, the
power amplifier IC and regulator IC will be destroyed by heat.

Extension cable
EXTDV002-30P

Heat sink

Rear bracket

Main board

Extension stud
STDV001-3P

Extension studs
STDV001-3P

(No.MA248)1-25

After replacing the pickup, set the unit in the service mode to display a jitter value on the LCD. Confirm that the jitter value measured
with a jitter meter is within 12% of the jitter value displayed on the LCD. If it is within 12%, then adjustment is not necessary. Please
note that a jitter value displayed on the LCD is hex data. Refer to the corresponding decimal notation value using the Jitter Conversion
Table and confirm it with the measured value.
Fix the screws "a", "b" and "c" with screw lock paint.

If the measured jitter value is outside the 12% tolerance range, perform the following adjustments.

c

b

a

Jitter value adjustment procedure (Pickup horizontal level adjustment relative to the DVD recording surface)
(For the adjustment tool use a 3 mm wrench and not a screwdriver, this procedure will make the adjustment easier.

3 mm wrench

(1) Set the unit to the service mode and display a jitter value (hex data) on the LCD.
(2) Turn each of the screws a, b and c, by a half-turn per step, in the direction that reduces the jitter value in order to minimize it.

(Do not turn a screw more than a half turn at a time, but adjust the screw in the cycle of same level turn by pair of b+c→ pair of

a+b.)

(3) After completing the adjustment, secure the screws with screw lock paint.

1-26 (No.MA248)

4.4 Jitter value conversion table

Load the test DVD and set the unit to the service mode. A jitter value converted to the hex value is displayed on the LCD.
Refer to the corresponding decimal notation value shown in the following Jitter Conversion Table.
The adjustment is OK if the jitter value measured with a jitter meter is within 12% of the jitter value displayed on the LCD.
If the measured jitter value is outside the 12% tolerance range, adjust it to minimize the difference between the measured
value and the displayed value.

Indicated

on the LCD

EF56
EF22
EEEE
EEBA
EE86
EE52
EE1E
EDEA
EDB6
ED82
ED4E
ED1A
ECE6
ECB2
EC7E
EC4A
EC16
EBE2
EBAE
EB7A
EB46
EB12
EADE
EAAA
EA76
EA42
EA0E
E9DA
E9A6
E972
E93E
E90A
E8D6
E8A2
E86E
E83A
E806
E7D2

Jitter value

(%)

4.7

4.8

4.9

5.0

5.1

5.2

5.3

5.4

5.5

5.6

5.7

5.8

5.9

6.0

6.1

6.2

6.3

6.4

6.5

6.6

6.7

6.8

6.9

7.0

7.1

7.2

7.3

7.4

7.5

7.6

7.7

7.8

7.9

8.0

8.1

8.2

8.3

8.4

Indicated

on the LCD

E79E
E76A
E736
E702
E6CE
E69A
E666
E632
E5FE
E5CA
E596
E562
E52E
E4FA
E4C6
E492
E45E
E42A
E3F6
E3C2
E38E
E35A
E326
E2F2
E2BE
E28A
E256
E222
E1EE
E1BA
E186
E152
E11E
E0EA
E0B6
E082
E04E
E01A

Jitter value

(%)

8.5

8.6

8.7

8.8

8.9

9.0

9.1

9.2

9.3

9.4

9.5

9.6

9.7

9.8

9.9

10.0

10.1

10.2

10.3

10.4

10.5

10.6

10.7

10.8

10.9

11.0

11.1

11.2

11.3

11.4

11.5

11.6

11.7

11.8

11.9

12.0

12.1

12.2

Indicated

on the LCD

DFE6
DFB2
DF7E
DF4A
DF16
DEE2
DEAE
DE7A
DE46
DE12
DDDE
DDAA
DD76
DD42
DD0E
DCDA
DCA6
DC72
DC3E
DC0A
DBD6
DBA2
DB6E
DB3A
DB06
DAD2
DA9E
DA6A
DA36
DA02
D9CE
D99A
D966
D932
D8FE
D8CA
D896
D862

Jitter value

(%)

12.3

12.4

12.5

12.6

12.7

12.8

12.9

13.0

13.1

13.2

13.3

13.4

13.5

13.6

13.7

13.8

13.9

14.0

14.1

14.2

14.3

14.4

14.5

14.6

14.7

14.8

14.9

15.0

15.1

15.2

15.3

15.4

15.5

15.6

15.7

15.8

15.9

16.0

Calculation

Indicated on the LCD

E9A6 7.5

Jitter (%)

(No.MA248)1-27

4.5 Operation procedure

Keep this state more than 2 seconds while
continuing pressing the [SEL] button, [SOURCE]
button and [STANDBY/ON ATTENUATOR]
button sequentially.

The unit enters the service mode.

"INIT ALL" is Initialize all data to the factory setting

indicated on the LCD.

Press the [SEL] key

:The system control EEPROM is
initialized entirely.

"VERSION" is Microcomputer version display

indicated on the LCD.

Press the [SEL] key

S-XXX-YY System control CPU

version/ROM correction version

DVD-XXXX DVD version
*Exchanging it operate each indication with the
[DISC UP] button and [DISC DOWN] button.

"AREA/RGN" is Destination area/region display

indicated on the LCD.

Press the [SEL] key

STS-X XX System control destination
DVD-X XX DVD unit destination
DVDRGN X DVD unit region
*Exchanging it operate each indication with the
[DISC UP] button and [DISC DOWN] button.

"VIDEO" is Setting of NTSC or PAL

indicated on the LCD.

Press the [SEL] key

"NTSC" or "PAL" are indicated on the LCD.
*Exchanging it operate each indication with the
[DISC UP] button and [DISC DOWN] button.

Note:
There is the model that is not equipped with
this mode by a version.

"CLR ERR" is Clear loading/ejection error history
indicated on the LCD.

Press the [SEL] key

:The error history stored in the EEPROM is
cleared.

"CD ERROR" is Read loading and ejection error history
indicated on the LCD.

Press the [SEL] key

: The error history saved in the system control

is read and displayed.

TOT-xxxx : Total error count.

Total error count
(A figure between 0 and 9999 is

displayed. 10000 or more is also
displayed as 9999.)

Enyyzzzz: Latest three error code.

Detailed error code
Error code

Counter

0nyyzzzz: First five error code

Detailed error code
Error code
Counter

*Exchanging it operate each indication with the

Error code (1 byte)

[DISC UP] button and [DISC DOWN] button.

First byte [01] Eject error

A B

[02] Loading error

1-28 (No.MA248)

A B

"DVD-TEMP" is
indicated on the LCD.

Detailed error code (2 bytes)

First byte Higher 4 bits Route NO. (Process of error occurrence)

Lower 4 bits Error type

. . . .

Refer to charts 1.1 and 1.2.

. . . .

*Displayed with loading/ejection error only.

[1] Time out
[2] Switch status error
[3] Swinging error

Second byte bit7

. . . .

Disc type (0: 12 cm. 1: 8 cm)
bit6,5
bit4
bit3
bit2
bit1 SW 1 status
bit0 RESET SW status

. . . .

. . . .

. . . .

. . . .

. . . .

. . . .

Fixed at 0
SW 1 status
SW 2 status
SW 3 status

(Example) When a switch status error occurs during loading route 3 and

the switch status is L/L/H/H/H (00111B = 07H), the error code
and detailed error code become: [09 3207].

Route No.(EJECT route No.)

-

1(2)

1(2)

2(2)

2(2)

2(2)

2(2)

3(1)

3(1)

SW1/2/3/4 [Rest SW] Loading Eject Reload

1,1,1,1 [0] No Disc No Disc

0,1,1,1 [0] Disc insert Disc push in

0,0,1,1 [0] Eject

0,0,0,1 [0] Reload start

0,0,1,1 [0]

0,1,1,1 [0]

1,1,1,1 [0]

1,1,1,0 [0]

1,1,1,0

[1]

detection

completion

Load completion Eject start Load completion

Chart 1.1 12cm Disc switch status transition

Route No.(EJECT route No.)

-

1(2)

1(2)

2(2)

2(2)

3(1)

3(1)

SW1/2/3/4 [Rest SW] Loading

1,1,1,1 [0] No Disc No Disc Disc push in

0,1,1,1 [0] Disc insert Eject

0,0,1,1 [0] Reload start

0,1,1,1 [0]

1,1,1,1 [0]

1,1,1,0 [0]

1,1,1,0 [1] Load completion Eject start Load completion

*

detection completion

Eject Reload

*Transition in the center loading (Similar to 12cm in the side loading)

Chart 1.2 8cm Disc switch status transition

Press the [SEL] key

Thermistor's temperature data readout
: Data in the temperature sensor in the DVD unit
is read every 5 seconds and displayed in hex numbers.

"SYS-TEMP" is
indicated on the LCD.

"CHK MODE" is
indicated on the LCD.

"RUNNING" is
indicated on the LCD.

"MEMCHECK" is
indicated on the LCD.

"INIT" is
indicated on the LCD.

Press the [SEL] key

Press the [SEL] key

Press the [SEL] key

Press the [SEL] key

Press the [SEL] key

Thermistor's temperature data readout
: Data in the temperature sensor in the system control
is read every 5 seconds and displayed in hex numbers.

DVD unit check mode
(See section "DVD unit check mode" for details.)

Running mode: For use in running tests.

Memory check
: The remaining data capacity of the disc is
displayed on the LCD.

Initialize user set data
: The system control EEPROM is initialized except
for the loading/ejection error history.

(No.MA248)1-29

4.6 DVD unit check mode

Change LCD indication with a [FF ] button and a [REW ] button.

Check item list

No. A/D key DVD unit operation Indication contents

1 [1] Start at normal speed NORMPLAY

2 [2] Tracking off on the outermost position of CD EF-BAL

3 [3] Tracking off on the innermost position of CD EF-BAL

4 [4] CD_LD lights and laser current is displayed CDLD ON

5 [5] DVD_LD lights and laser current is displayed DVDLD ON

6 [6] DVD x1 jitter measuring mode DVDx1JIT

7 [DISP] Indication of EEPROM contents ROM DATA

8 [SOURCE] Initialization of EEPROM contents ROMCLEAR

9 [SEL] Indication of temperature TEMP

10 [MODE] Search & jitter measurement to an appointed DVD JIT

11 [BAND] Setting of MONITOR terminal MONITOR

12 [DISC UP

13 [DISC DW

Example of
LCD indication

(After start, it is measured JITTER on the CUR Laser current value
internal position) JIT Jitter value

(for use in mechanism measurement) CUR Laser current value

position of DVD PLC (Position measured with

]

DVDx1 double speed start PLAY
(After start, it is measured JITTER on the CUR Laser current value

internal position) JIT Jitter value

]

Disc stopped & LD-OFF STOP

* * * *

* * * *

OUTTROFF For EF phase error

INNTROFF For EF phase error

CUR Laser current value

* * * *

JIT Jitter value

* * * *

CUR Laser current value

* * * *

JIT Jitter value

* * * *

* * * *

JIT Jitter value

* * * *

ADDR EEPROM address
DATA EEPROM contents

TEMP Temperature

* * * *

* * * *

* * * *

* * * *

JIT VT-501 jitter value)

* * * *

M1

* * * *

M2

* * * *

* * * *
* * * *

Note In the case of the jitter measurement: Begin a service mode after insert a disc.

1-30 (No.MA248)

.
.

Press key [1] of No.1 before an item in which the No.2 or 3 key is pressed.

.

Press key [1] of No.1 or key [12] of No.12 before an item in which the No.10 key is pressed and confirm
the indication of jitter value on the LCD.

.

No.6 starts only a DVD1 layer disc. Even other discs start DVD1 layer.

.

When No.1 and No.12 are pushed after jitter indication, a focus jump is executed. (only DVD2 layer)

.

Stop a disc before OPEN, CLOSE by all means.(OPEN and CLOSE are not executed in a disc turn.)

.

The check mode can be exited either by pressing the [POWER] key or by resetting the unit.

5.1 Feed section

SECTION 5

TROUBLESHOOTING

Is 4V present at both
sides of the feed motor?

Is the voltage output at
pin 17 and pin 18 of IC201?

Is the voltage input at pin
22 of IC201?

Is the voltage output at
pin 82 of IC301?

Is the power supply
present at pin 6
of IC301?

Check the connections
of D3.3V power supply.

5.2 Focus section

NO

NO

NO

NO

NO

YES

YES

YES

YES

YES

Check the feed motor.

Check the connections
between the feed motor
and IC201.

Is the power supply
present at pin 19
and pin 28 of IC201?

Check the connections
of M8V power supply.

Check the connections
between IC201 and
IC301.

Check IC301.

NO

YES

Is the power supply
present at pin 10
of IC201?

Check the connections
of M5V power supply.

YES

Check IC201.

NO

Is the voltage input at pin
3 of IC201?

NO

Is the voltage output at
pin 148 of IC301?

NO

Is the power supply
present at pin 6
of IC301?

NO

Check the connections
of D3.3V power supply.

YES

YES

YES

Is the power supply
present at pin 19
and pin 28 of IC201?

Check the connections
of M8V power supply.

Check the connections
between IC201 and
IC301.

Check IC301.

NO

YES

Is the power supply
present at pin 10
of IC201?

Check the connections
of M5V power supply.

YES

Check IC201.

NO

(No.MA248)1-31

5.3 Spindle section

Is the disk rotated?

NO

Is the voltage output at
pin 20,pin22 and pin 22
of IC251?

NO

Is the voltage input at pin
17 of IC251?

NO

Is the voltage output at
pin 76 of IC301?

NO

Is the power supply
present at pin 6
of IC301?

NO

YES

Does the RF signal appear
at pin 111 of IC301?

YES

Check the spindle motor
and its wiring.

YES

Is the power supply
present at pin 14
of IC251?

Check the connections
of D5V power supply.

Check the connections

YES

between IC201 and
IC301.

YES

Check IC301.

NO

YES

Is the RF waveform at
pin 111 of IC301 distorted?

Check the circuits in
the vicinity of IC301
or the pickup.

YES

Is the power supply
present at pin 15
and pin 25 of IC501?

Check the connections
of M8V power supply.

NO

NONO

YES

Proceed to the Tracking
section.

YES

Check IC501.

Check the connections
of D3.3V power supply.

5.4 Tracking section

Is the voltage input at pin
6 of IC201?

NO

Is the voltage output at
pin 147 of IC301?

NO

Is the power supply
present at pin 6
of IC301?

NO

Check the connections
of D3.3V power supply.

YES

Is the power supply
present at pin 19
and pin 28 of IC201?

Check the connections
of M8V power supply.

Check the connections

YES

between IC201 and
IC301.

YES

Check IC301.

NO

YES

Is the power supply
present at pin 10
of IC201?

Check the connections
of M5V power supply.

YES

Check IC201.

NO

1-32 (No.MA248)

5.5 Signal processing section

Is the sound output from
both channels (L, R)?

NO

No sound from either
channel.

NO

Compare the L-ch and
R-ch to locate the
defective point.

5.6 Maintenance of laser pickup

(1) Cleaning the pick up lens

Before you replace the pick up, please try to clean the lens
with a alcohol soaked cotton swab.

(2) Life of the laser diode

When the life of the laser diode has expired, the following
symptoms will appear.

• The level of RF output (EFM output: amplitude of eye
pattern) will be low.

YES

Normal

YES

Is 9V present at pin 32
of IC161?

Is 9V present at pin 10
of IC901?

Check IC901 and its
peripheral circuits.

NO

NO

Is the audio signal
(including sampling

YES

output components)
output to pins 1 and 7 of
IC411 during playback?

NO

Check IC411 and its
peripheral circuits.

Check the connections

YES

between pin 32 of IC161
and pin 10 of IC901.

5.7 Replacement of laser pickup

Turn off the power switch and disconnect the
power cord.

Replace the pickup with a normal one. (Refer
to "Removing the pickup unit" on the previous page.)

Is the audio signal output

YES

at pin 15 and pin 18 of
IC161 during playback?

Check IC161 and its
peripheral circuits.

Check the power
amplifier IC301.

NO

YES

Is RF output

1.3 0.4Vp-p?

NO

Replace it.

YES

OK

(3) Semi-fixed resistor on the APC PC board

The semi-fixed resistor on the APC printed circuit board
which is attached to the pickup is used to adjust the laser
power.Since this adjustment should be performed to match
the characteristics of the whole optical block, do not touch
the semi-fixed resistor.
If the laser power is lower than the specified value, the la­ser diode is almost worn out, and the laser pickup should
be replaced. If the semi-fixed resistor is adjusted while the
pickup is functioning normally, the laser pickup may be
damaged due to excessive current.

Plug the power cord in and turn the power on.
At this time, check that the laser emits for about
seconds and the objective lens moves up and down.
Note: Do not observe the laser beam directly.

Play a disc.

Check the eye-pattern at

RF test point or

ARF test point.

Finish.

(No.MA248)1-33

5.8 16PIN CORD DIAGRAM (for KD-DV4200)

GN

8

7

6

5

4

3

2

1

GN/BK

VI/BK

BL/WH

VI

NC

RD

BK

WH

WH/BK

GY/BK

GY

NC

YG

NC

YL

9

10

11

12

13

14

15

16

BK

RD

BL

WH

Black

Red

Blue

White

GN

VI

GY

YL

YG

Green

Violet

Gray

Yellow

Yellow Green

1 BK

16 YL

2 RD

9 WH

10 WH/BK

12 GY

11 GY/BK

8 GN

7 GN/BK

5 VI

6 VI/BK

3 BL/WH

14 YG

GND

MEMORY

ACC

FL+

FL-

FR+

FR-

RL+

RL-

RR+

RR-

REMOTE

PARKING

GND

PARKING
BRAKE

1-34 (No.MA248)

RR

FR

FL

RL

REMOTE

Rear Right

Front Right

Front Left

Rear Left

Remote

ACC

GND

MEMORY

PARKING

ACC Line

Ground

Memory Backup Battery+

Parking Brake

5.9 16 PIN CORD DIAGRAM (for KD-DV4201,KD-DV4201,KD-DV4202,KD-DV4207)

8

7

6

5

4

3
2

1

16 YL

GN

GN/BK

VI/BK

VI

NC

BL/WH

RD

BK

7 RD

1 BK

3 BL/WH

13 BR

8 GN

7 GN/BK

5 VI

6 VI/BK

9 WH

10 WH/BK

12 GY

11 GY/BK

14 YG

WH

WH/BK

GY/BK

GY

BR

YG

NC

YL

9

10

11

12

13

14

15

16

ACC

MEMORY

GND

REMOTE

TEL

RL+

RL-

RR+

RR-

FL+

FL-

FR+

FR-

PARKING

BK

RD

BL

WH

BR

Black

Red

Blue

White

Brown

GN

VI

GY

YL

YG

TEL MUTING

Green

Violet

Gray

Yellow

Yellow Green

RD

1

3
5

7

RD 7

YL 4

NC

NC

BL/WH

RD

8

5

2

7

8

1

2

5

6

3

4

BR

YL

NC

BK

2

4

6

8

PARKING
BRAKE

RR

FR

FL

RL

REMOTE

Rear Right

Front Right

Front Left

Rear Left

Remote

ACC

TEL

GND

MEMORY

PARKING

ACC Line

Telephone Muting

Ground

Memory Backup Battery+

Parking Brake

VI/BK

GY/BK

WH/BK

GN/BK

2

4

6

8

VI

1
3

GY

5

WH

GN

7

(No.MA248)1-35

5.10 16PIN CORD DIAGRAM (for KD-DV4203,KD-DV4204,KD-DV4205,KD-DV4206)

GN

8

7

6

5

4

3

2

1

GN/BK

VI/BK

BL/WH

VI

BL

RD

BK

WH

WH/BK

GY/BK

GY

NC

YG

NC

YL

10

11

12

13

14

15

16

9

BK

RD

BL

WH

Black

Red

Blue

White

GN

VI

GY

YL

YG

Green

Violet

Gray

Yellow

Yellow Green

1 BK

16 YL

2 RD

9 WH

10 WH/BK

12 GY

11 GY/BK

8 GN

7 GN/BK

5 VI

6 VI/BK

3 BL/WH

4 BL

14 YG

GND

MEMORY

ACC

FL+

FL-

FR+

FR-

RL+

RL-

RR+

RR-

REMOTE

ANT

PARKING

REMOTE OUT

POWER ANTENNA

GND

PARKING
BRAKE

1-36 (No.MA248)

RR

FR

FL

RL

REMOTE

Rear Right

Front Right

Front Left

Rear Left

Remote

ACC

GND

MEMORY

PARKING

ANT

ACC Line

Ground

Memory Backup Battery+

Parking Brake

Auto Antenna

(No.MA248)1-37

Victor Company of Japan, Limited
Mobile Entertainment Business Group Mobile Entertainment Category 10-1,1chome,Ohwatari-machi,Maebashi-city,Gumma-ken, 371-8543,Japan

(No.MA248)

Printed in Japan

VPT

PARTS LIST

KD-DV4200J,KD-DV4201E,KD-DV4201EU

KD-DV4202E,KD-DV4202EU,KD-DV4203UI

KD-DV4204UI,KD-DV4205U,KD-DV4205UN

KD-DV4205UT,KD-DV4205A,KD-DV4206U

KD-DV4206UN,KD-DV4206UT,KD-DV4206A

KD-DV4207EE

* All printed circuit boards and its assemblies are not available as service parts.

MA248

- Contents -

Exploded view of general assembly and parts list (Block No.M1)
DVD mechanism assembly and parts list (Block No.MJ)
Electrical parts list (Block No.01~09)
Packing materials and accessories parts list (Block No.M3)

3- 2
3- 6
3- 9
3-26

3-1

Exploded view of general assembly and parts list

Block No.

8

11

M

M

1

M

26

12

36

35

27

34

21

23

22

29

18

Switch
board

12

8

3

B

20

19

38

38

60

1

59

13

38

37

3-2

33

25

24

39

30

31

28

32

47

42

Main sub board

40

41

48

14

4

5

15

6

66

65

64

DV4205UT
DV4206UT

52

50

2

51

57

58

A

B

61

D

D

62

10

53

A

52

10

56

55

54

E

10

13

17

5

C

9

Main board

9

4

49

E

DV4201E,EU
DV4202E,EU

44

43

5

45

16

46

6

63

DV4201E,EU
DV4202E,EU
DV4203UI

7

DV4204UI

6

7

DV4205U,UN,UT,A
DV4206U,UN,UT,A
DV4207EE

3-3

General Assembly

Block No. [M][1][M][M]



Symbol No. Part No. Part Name Description Local

1 LV10774-008A TOP CHASSIS
2 LV40848-044A SPACER(P)
3 LV34061-001A SIDE HEAT SINK
4 QYSDST2003ZA TAP SCREW M2 x 3mm(x2)
5 QYSDST2606ZA TAP SCREW M2.6 x 6mm(x2)
6 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x3)
7 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x2)
8 GE40235-001A SCREW (x2)
9 GE40235-004A SCREW (x3)
10 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x3)
11 LV41200-005A SCREW (x3)
12 QYSDST2004ZA TAP SCREW M2 x 4mm(x2)
13 LV34460-001A INSULATOR
14 GE40255-001A SUPPORT BRACKET
15 GE20180-001A DUST COVER
16 GE40218-034A SHEET
17 GE40278-001A SHEET
18 GE10138-001A FRONT CHASSIS
19 GE31569-002A LOCK LEVER
20 GE40269-001A TORSION SPRING
21 GE31978-001A RLS KNOB
22 GE40202-011A COMP.SPRING
23 GE40294-002A BLIND
24 GE10144-001A FRONT PANEL DV4200J
24 GE10144-002A FRONT PANEL DV4201E,DV4201EU
24 GE10144-003A FRONT PANEL DV4202E,DV4202EU

24 GE10144-008A FRONT PANEL

24 GE10144-009A FRONT PANEL

24 GE10144-007A FRONT PANEL DV4207EE
25 GE31985-011A FINDER ASSY DV4200J
25 GE31985-012A FINDER ASSY DV4201E,DV4201EU
25 GE31985-013A FINDER ASSY DV4202E,DV4202EU
25 GE31985-014A FINDER ASSY DV4203UI
25 GE31985-015A FINDER ASSY DV4204UI
25 GE31985-016A FINDER ASSY DV4205U,DV4205UN,DV4205UT,DV4205A
25 GE31985-017A FINDER ASSY DV4206U,DV4206UN,DV4206UT,DV4206A
25 GE31985-018A FINDER ASSY DV4207EE
26 GE31968-002A POWER BUTTON

27 GE31993-005A SRC BUTTON

27 GE31993-003A SRC BUTTON

28 GE32000-002A DISP BUTTON

28 GE32000-003A DISP BUTTON

29 GE20191-002A PRESET BUTTON

29 GE20191-003A PRESET BUTTON

30 GE31991-002A EJECT BUTTON

30 GE31991-006A EJECT BUTTON

31 GE31990-002A DETACH BUTTON DV4200J

31 GE31990-003A DETACH BUTTON

31 GE31990-004A DETACH BUTTON

32 GE40202-017A COMP.SPRING

33 GE40315-002A VOL KNOB ASSY

33 GE40315-001A VOL KNOB ASSY

34 GE31989-001A NAVI BASE
35 GE40127-002A COMP.SPRING

36 GE40316-008A NAVI BTN ASSY

36 GE40316-007A NAVI BTN ASSY

37 GE10146-001A REAR COVER
38 VKZ4777-010 MINI SCREW (x4)
39 GE31995-001A LCD CASE
40 GE31998-001A LENS CASE

DV4203UI,DV4206U,DV4206UN,DV4206UT,
DV4206A

DV4204UI,DV4205U,DV4205UN,DV4205UT,
DV4205A

DV4200J,DV4201E,DV4201EU,DV4204UI,D
V4205U,DV4205UN,DV4205UT,DV4205A

DV4202E,DV4202EU,DV4203UI,DV4206U,D
V4206UN,DV4206UT,DV4206A,DV4207EE
DV4200J,DV4201E,DV4201EU,DV4204UI,D
V4205U,DV4205UN,DV4205UT,DV4205A
DV4202E,DV4202EU,DV4203UI,DV4206U,D
V4206UN,DV4206UT,DV4206A,DV4207EE
DV4200J,DV4201E,DV4201EU,DV4204UI,D
V4205U,DV4205UN,DV4205UT,DV4205A
DV4202E,DV4202EU,DV4203UI,DV4206U,D
V4206UN,DV4206UT,DV4206A,DV4207EE
DV4200J,DV4201E,DV4201EU,DV4204UI,D
V4205U,DV4205UN,DV4205UT,DV4205A
DV4202E,DV4202EU,DV4203UI,DV4206U,D
V4206UN,DV4206UT,DV4206A,DV4207EE

DV4201E,DV4201EU,DV4204UI,DV4205U,D
V4205UN,DV4205UT,DV4205A

DV4202E,DV4202EU,DV4203UI,DV4206U,D
V4206UN,DV4206UT,DV4206A,DV4207EE

DV4200J,DV4201E,DV4201EU,DV4204UI,D
V4205U,DV4205UN,DV4205UT,DV4205A
DV4202E,DV4202EU,DV4203UI,DV4206U,D
V4206UN,DV4206UT,DV4206A,DV4207EE

DV4200J,DV4201E,DV4201EU,DV4204UI,D
V4205U,DV4205UN,DV4205UT,DV4205A
DV4202E,DV4202EU,DV4203UI,DV4206U,D
V4206UN,DV4206UT,DV4206A,DV4207EE

3-4



Symbol No. Part No. Part Name Description Local

41 GE31999-001A LCD LENS
42 GE40300-001A LIGHTING SHEET
43 LV34058-002A BOTTOM COVER
44 GE32174-001A INSULATOR
45 GE32047-001A NAME PLATE DV4200J
45 GE32067-001A NAME PLATE DV4201E,DV4201EU
45 GE32070-001A NAME PLATE DV4202E,DV4202EU
45 GE32058-001A NAME PLATE DV4203UI
45 GE32061-001A NAME PLATE DV4204UI
45 GE32050-001A NAME PLATE DV4205U,DV4205UN,DV4205UT,DV4205A
45 GE32054-001A NAME PLATE DV4206U,DV4206UN,DV4206UT,DV4206A
45 GE32073-001A NAME PLATE DV4207EE
46 GE31683-017A LABEL (DVD) DV4200J
46 GE31683-018A LABEL (DVD) DV4201E,DV4201EU,DV4202E,DV4202EU
46 GE31683-022A LABEL (DVD) DV4203UI,DV4204UI

46 GE31683-019A LABEL (DVD)

46 GE31683-020A LABEL (DVD) DV4205A,DV4206A
46 GE31683-024A LABEL (DVD) DV4207EE
47 QLD0386-001 LCD MODULE
48 QNZ0827-001 RUBBER CONN
49 QUQP05-4510BB-E FFC WIRE 45pin 10cm
50 GE31994-001A REAR BRACKET
51 GE40324-001A FAN BRACKET
52 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x2)
53 QYSDST2606ZA TAP SCREW M2.6 x 6mm
54 GE40235-004A SCREW
55 QYSDSF2606ZA TAP SCREW M2.6 x 6mm
56 QYSDSF2606ZA TAP SCREW M2.6 x 6mm
57 LV43349-002A POWER IC BKT
58 LV43373-002A REGULATOR BKT
59 VMA4652-001SS EARTH PLATE
60 GE30854-001A LED HOLDER
61 QAR0353-001 COOLING FAN



62 QMFZ039-150-T FUSE 15A

63 LV41843-002A LASER CAUTION

64 QYSDST2604ZA TAP SCREW M2.6 x 4mm DV4201E,DV4201EU,DV4202E,DV4202EU
65 QAM0820-001 STEERING CABLE DV4201E,DV4201EU,DV4202E,DV4202EU
66 GE31574-032A UT LABEL DV4205UT
66 GE31574-033A UT LABEL DV4206UT

DV4205U,DV4205UN,DV4205UT,DV4206U,
DV4206UN,DV4206UT

DV4201E,DV4201EU,DV4202E,DV4202EU,
DV4203UI,DV4204UI,DV4205U,DV4205UN,
DV4205UT,DV4205A,DV4206U,DV4206UN,D
V4206UT,DV4206A,DV4207EE

3-5

DVD mechanism assembly and parts list

Grease

34

30

=

JVS-1003

=

MOBIL-1

=

JVG-31N

=

JC-803B

=

1401C

= FG-87HS

29

93

FMU-JD5-1D

97

94

95

92

96

15

91

90

18

14

87

Block No.

18

A

J

M

M

M

62

17

13

32

16

53

10

56

36

55

57

21

88

INSIDE

OUTSIDE

24

59

58

37

22

38

B

19

43

c

65

J

71

26

E

73

72

83

G

H

D

K

F

3

7420

70

28

27

B

29

31

34

35

33

C

23

3

48

47

F

44

50

54

H

G

49

60

61

7

75

AFTER SET PICK UP SA.
APPLY GREASE

52

K

51

63

45

46

BACK SIDE

6

89

c

64

40

43

39

41

42

25

76

79

80

86

67

10

11

9

INSIDE

68

98

86

66

a

85

E

81

84

86

J

1

a

82

1

77

5

A

78

69

b

4

2

16

12

10

5

D

8

12

8

17

3-6

The parts without symbol number are not service.

DVD mechanism



Symbol No. Part No. Part Name Description Local

1 VKZ4539-056 MINI SCREW (x2)
2 QYSPSFT2040ZA TAP SCREW M2 x 4mm
3 LV43481-001A COOLING RUBBER (x2)
4 LV10674-001A CHASSIS FRAME
5 LV30225-0J6A SPACER (x2)
6 VKZ4539-056 MINI SCREW
7 VYSA1R4-056 SPACER
8 LV35272-001A DAMPER(F) (x2)
9 LV35273-001A DAMPER(R)
10 QYSDST2005ZA SCREW M2 x 5mm(x3)
11 LV43039-001A DAMPER SP.(R)
12 LV43849-001A DAMPER SP(F2) (x2)
13 LV43041-001A FLOATING SPRING (x2)
14 LV10675-001A TOP COVER
15 LV30225-0J5A SPACER
16 VKZ4539-056 MINI SCREW (x2)
17 LV33669-001A STOPPER (x2)
18 VKZ4539-056 MINI SCREW (x2)
19 LV21297-004A CHAS. BASE ASSY
20 LV33608-002A GEAR HOLDER
21 VKZ4539-056 MINI SCREW
22 LV43561-002A ABSORBER
23 LV30225-0J5A SPACER
24 LV36831-001A SLIDE CAM ASSY2
25 LV33610-002A FLOATING ARM
26 LV33611-001A CONNECT ARM
27 LV33678-003A LOADING A. ASSY
28 LV43049-001A LOADING SHAFT
29 LV43052-003A ROLLER (x2)
30 LV33612-001A LOADING GEAR
31 QYWFM124013 WASHER 4mm/1.2mm x 0.13mm
32 LV43053-002A ROD(L)
33 LV43054-003A ROD(R)
34 LV43001-001A COLLAR (x2)
35 LV21285-003A PROTECTOR
36 LV43055-001A PROTECTOR SP.
37 QAR0373-001 MOTOR
38 LV43002-002A WORM GEAR
39 QYSPSPT2025MA SCREW M2 x 2.5mm(x2)
40 LV33679-001A MOTOR H. ASSY
41 LV33614-003A WORM WHEEL
42 QYWDL1230250 SLIT WASHER 3mm/1.2mm x 0.25mm
43 VKZ4539-056 MINI SCREW (x2)
44 LV33615-001A GEAR 2
45 LV43057-004A IDLER ARM ASSY
46 QYWDL1635252 SLIT WASHER 3.5mm/1.6mm x 0.25mm
47 LV21286-001A CONTROL CAM
48 QYWDL1230196 SLIT WASHER 3mm/1.2mm x 0.19mm
49 LV33616-002A LOAD.LOCK LEVER
50 LV43060-001A CAM SPRING
51 LV43005-001A GEAR 4
52 LV43006-002A GEAR 5
53 LV33617-002A GEAR 6
54 LV33618-002A LOADING G. ARM
55 QYWDL1635252 SLIT WASHER 3.5mm/1.6mm x 0.25mm
56 LV43007-002A GEAR 7
57 LV33619-002A GEAR 8
58 LV42132-001A E RING
59 QYWFM215013 WASHER 5mm/2.1mm x 0.13mm
60 LV33620-001A GEAR 9
61 LV43008-001A GEAR10
62 LV43061-001A LOAD SPRING
63 LV33621-001A FEED GEAR
64 LV33622-002A TRIGGER ARM
65 LV43062-001A FEED TRI.SPRING
66 QAR0240-002 SPINDLE MOTOR
67 LV21287-002A SPINDLE BASE
68 LV44169-001A SPECIAL SCREW (x2)
69 VKZ4539-056 MINI SCREW (x2)
70 QAL0742-001 DVD PICK UP
71 LV34583-002A CD RACK PLATE
72 LV34579-001A CD RACK SPRING
73 LV43903-002A MINI TAP SCREW
74 LV43037-001A LEAD SCREW

Block No. [M][J][M][M]

3-7



Symbol No. Part No. Part Name Description Local

75 LV43010-001A L.S.GEAR
76 LV43063-001A L.S.COLLAR
77 LV43011-001A THRUST SPRING
78 QYSPSFT2040ZA TAP SCREW M2 x 4mm
79 LV33624-001A HOLDER(M)
80 VKZ4539-056 MINI SCREW (x2)
81 LV22130-001A HOLDER(S) 2
82 VKZ4539-056 MINI SCREW (x2)
83 LV43064-001A ROD(M)
84 LV43065-001A ROD(S)
85 LV43066-001A SUB SHAFT
86 VKZ4730-002 SPECIAL SCREW (x3)
87 LV21298-007A CLAMPER UNIT
88 LV43070-001A CLAMPER SPRING
89 LV43355-001A CLAMPER2 SPRING
90 LV30225-0J6A SPACER
91 LV22185-001A FRONT UNIT (C)
92 VKZ4539-056 MINI SCREW
93 LVB30012-002A SW FPC
94 NSW0187-001 SWITCH
95 NSW0187-001 SWITCH
96 NSW0187-001 SWITCH
97 VKZ4539-055 MINI SCREW (x2)
98 LV44232-001A GRAPHITE SHEET

3-8

Electrical parts list

Main board(KD-DV4200J)

Block No. [0][1]



Symbol No.

IC161 NJW1192V-X IC
IC301 LA4743K POWER IC
IC401 SN74AHCT1G08V-X IC
IC402 TOTX177L OPTICAL JACK
IC411 MM1510XN-X IC
IC721 UPD784218AGC343 IC
IC722 BR24L16F-W-X IC
IC723 S-80833CNNB-G-W IC
IC801 SN74AHC126NS-X IC
IC901 R2S25400DS-E REGULATOR IC
IC921 BA33BC0FP-X IC
IC922 BD9781HFP-W DC CONVERTOR
IC961 SN74LVC32APW-X IC
IC962 SN74HCT32APW-X IC

Q2 RT1N141C-X DIGI TRANSISTOR
Q303 RT1N141C-X DIGI TRANSISTOR
Q344 KTD1304-X TRANSISTOR
Q354 KTD1304-X TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR
Q783 RT1P141C-X DIGI TRANSISTOR
Q821 RT1N141C-X DIGI TRANSISTOR
Q822 RT1P141C-X DIGI TRANSISTOR
Q823 2SC4485/ST/-T TRANSISTOR
Q885 RT1N141C-X DIGI TRANSISTOR
Q903 2SA1530A/R/-X TRANSISTOR
Q904 RT1N141C-X DIGI TRANSISTOR
Q976 RT1N441C-X TRANSISTOR
Q977 2SA1530A/R/-X TRANSISTOR

D1 1SS355W-X DIODE C.M
D2 1SS355W-X DIODE C.M
D302 1SS355W-X DIODE C.M
D344 1SS355W-X DIODE C.M
D354 1SS355W-X DIODE C.M
D401 CRS03-W SB DIODE
D411 UDZW12B-X Z DIODE
D731 1SS355W-X DIODE C.M
D781 1SS355W-X DIODE C.M
D782 1SS355W-X DIODE C.M
D783 UDZW11B-X Z DIODE
D801 CRS03-W SB DIODE
D821 UDZW12B-X Z DIODE
D885 1SS355W-X DIODE C.M
D901 1N5401-F64 DIODE
D903 1SS355W-X DIODE C.M
D906 UDZW5.1B-X SI DIODE
D921 1A3G-T1 SI DIODE
D922 RB051L-40-X SB DIODE
D923 CRS03-W SB DIODE
D924 CRS03-W SB DIODE
D925 CRS03-W SB DIODE
D981 CRS03-W SB DIODE
D982 CRS03-W SB DIODE

C2 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C4 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C6 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C7 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C8 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C83 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C93 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C161 QTE1A57-107Z E CAPACITOR 100uF 10V
C162 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C164 QTE1C57-106Z E CAPACITOR 10uF 16V
C169 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C171 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C172 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C173 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C174 NCS31HJ-471X C CAPACITOR 470pF 50V J

Part No. Part Name Description Local



Symbol No.

C175 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C176 NCB31HK-472X C CAPACITOR 4700pF 50V K
C177 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C178 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C179 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C180 QTE1H57-475Z E CAPACITOR 4.7uF 50V
C181 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C182 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C183 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C184 NCS31HJ-471X C CAPACITOR 470pF 50V J
C185 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C186 NCB31HK-472X C CAPACITOR 4700pF 50V K
C187 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C188 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C189 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C190 QTE1H57-475Z E CAPACITOR 4.7uF 50V
C302 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C311 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C312 QTE1C57-476Z E CAPACITOR 47uF 16V
C313 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C314 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C315 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C316 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C328 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C329 NCS31HJ-101X C CAPACITOR 100pF 50V J
C330 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C331 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C338 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C339 NCS31HJ-101X C CAPACITOR 100pF 50V J
C340 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C346 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C348 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C349 NCS31HJ-101X C CAPACITOR 100pF 50V J
C350 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C356 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C358 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C359 NCS31HJ-101X C CAPACITOR 100pF 50V J
C360 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C401 NCS31HJ-220X C CAPACITOR 22pF 50V J
C402 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C404 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C405 NCS31HJ-220X C CAPACITOR 22pF 50V J
C406 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C411 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C412 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C413 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C414 QERF0JM-337Z E CAPACITOR 330uF 6.3V M
C415 NCS31HJ-101X C CAPACITOR 100pF 50V J
C416 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C701 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C702 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C721 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C722 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C723 NCS31HJ-471X C CAPACITOR 470pF 50V J
C724 NCS31HJ-471X C CAPACITOR 470pF 50V J
C725 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C726 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C727 NDC31HJ-270X C CAPACITOR 27pF 50V J
C728 NDC31HJ-270X C CAPACITOR 27pF 50V J
C729 NDC31HJ-220X C CAPACITOR 22pF 50V J
C730 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C731 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C732 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C733 NCS31HJ-471X C CAPACITOR 470pF 50V J
C781 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C783 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C801 NCS31HJ-220X C CAPACITOR 22pF 50V J
C802 NCS31HJ-220X C CAPACITOR 22pF 50V J
C803 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C804 NCS31HJ-220X C CAPACITOR 22pF 50V J
C821 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C822 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C823 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C885 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C889 NCB31CK-104X C CAPACITOR 0.1uF 16V K

Part No. Part Name Description Local

3-9



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C901 QEZ0722-338 E CAPACITOR 3300uF
C902 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C903 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C904 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C905 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C906 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C907 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C909 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C911 NCB31HK-102X C CAPACITOR 1000pF 50V K
C912 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C913 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C921 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C922 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C925 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C926 QEXF1AM-476Z E CAPACITOR 47uF 10V M
C927 QEZ0595-477Z E CAPACITOR 470uF
C928 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C929 NCB31HK-472X C CAPACITOR 4700pF 50V K
C930 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C962 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C963 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C966 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C967 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C968 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C969 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C981 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C999 NCS31HJ-101X C CAPACITOR 100pF 50V J

Ω

R1 NRSA63J-0R0X MG RESISTOR 0
R2 NRSA63J-122X MG RESISTOR 1.2k
R3 NRSA63J-122X MG RESISTOR 1.2k
R4 NRSA63J-102X MG RESISTOR 1k
R5 NRSA63J-0R0X MG RESISTOR 0
R6 NRSA63J-0R0X MG RESISTOR 0
R7 NRSA63J-473X MG RESISTOR 47k
R8 NRSA63J-101X MG RESISTOR 100
R9 NRSA63J-473X MG RESISTOR 47k
R10 NRSA63J-472X MG RESISTOR 4.7k
R11 NRSA63J-472X MG RESISTOR 4.7k
R12 NRS181J-4R7X MG RESISTOR 4.7
R13 NRS181J-6R8X MG RESISTOR 6.8
R14 NRSA63J-123X MG RESISTOR 12k
R15 NRSA63J-202X MG RESISTOR 2k
R19 NRSA63J-473X MG RESISTOR 47k
R81 NRSA63J-223X MG RESISTOR 22k
R82 NRSA63J-472X MG RESISTOR 4.7k
R91 NRSA63J-223X MG RESISTOR 22k
R92 NRSA63J-472X MG RESISTOR 4.7k
R171 NRSA63J-393X MG RESISTOR 39k
R172 NRSA63J-472X MG RESISTOR 4.7k
R173 NRSA63J-222X MG RESISTOR 2.2k
R181 NRSA63J-393X MG RESISTOR 39k
R182 NRSA63J-472X MG RESISTOR 4.7k
R183 NRSA63J-222X MG RESISTOR 2.2k
R302 NRSA63J-0R0X MG RESISTOR 0
R304 NRSA63J-473X MG RESISTOR 47k
R305 NRSA63J-102X MG RESISTOR 1k
R306 NRS181J-0R0X MG RESISTOR 0
R307 NRSA63J-472X MG RESISTOR 4.7k
R327 NRSA63J-0R0X MG RESISTOR 0
R329 NRSA63J-273X MG RESISTOR 27k
R330 NRSA63J-0R0X MG RESISTOR 0
R337 NRSA63J-0R0X MG RESISTOR 0
R339 NRSA63J-273X MG RESISTOR 27k
R340 NRSA63J-0R0X MG RESISTOR 0
R343 NRSA63J-473X MG RESISTOR 47k
R344 NRSA63J-222X MG RESISTOR 2.2k
R345 NRSA63J-102X MG RESISTOR 1k
R346 NRSA63J-101X MG RESISTOR 100
R347 NRSA63J-0R0X MG RESISTOR 0
R349 NRSA63J-273X MG RESISTOR 27k
R350 NRSA63J-0R0X MG RESISTOR 0
R353 NRSA63J-473X MG RESISTOR 47k
R354 NRSA63J-222X MG RESISTOR 2.2k
R355 NRSA63J-102X MG RESISTOR 1k
R356 NRSA63J-101X MG RESISTOR 100
R357 NRSA63J-0R0X MG RESISTOR 0
R359 NRSA63J-273X MG RESISTOR 27k

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/8W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J

R360 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R401 NRSA63J-471X MG RESISTOR 470
R402 NRSA63J-100X MG RESISTOR 10
R403 NRSA63J-471X MG RESISTOR 470
R404 NRSA63J-1R0X MG RESISTOR 1
R412 NRSA63D-682X MG RESISTOR 6.8k
R413 NRSA63J-100X MG RESISTOR 10
R414 NRSA63J-102X MG RESISTOR 1k
R415 NRSA63J-750X MG RESISTOR 75
R416 NRSA63J-0R0X MG RESISTOR 0
R417 NRSA63D-181X MG RESISTOR 180
R704 NRSA63J-271X MG RESISTOR 270
R705 NRSA63J-271X MG RESISTOR 270
R706 NRSA63J-103X MG RESISTOR 10k
R707 NRSA63J-103X MG RESISTOR 10k
R713 NRSA63J-103X MG RESISTOR 10k
R714 NRSA63J-104X MG RESISTOR 100k
R715 NRSA63J-271X MG RESISTOR 270
R716 NRSA63J-271X MG RESISTOR 270
R717 NRSA63J-221X MG RESISTOR 220
R718 NRSA63J-103X MG RESISTOR 10k
R719 NRSA63J-102X MG RESISTOR 1k
R720 NRSA63J-102X MG RESISTOR 1k
R721 NRSA63J-222X MG RESISTOR 2.2k
R722 NRSA63J-222X MG RESISTOR 2.2k
R725 NRSA63J-473X MG RESISTOR 47k
R726 NRSA63J-103X MG RESISTOR 10k
R727 NRSA63J-562X MG RESISTOR 5.6k
R728 NRSA63J-472X MG RESISTOR 4.7k
R729 NRSA63J-0R0X MG RESISTOR 0
R733 NRSA63J-103X MG RESISTOR 10k
R735 NRSA63J-0R0X MG RESISTOR 0
R736 NRSA63J-222X MG RESISTOR 2.2k
R737 NRSA63J-222X MG RESISTOR 2.2k
R738 NRSA63J-472X MG RESISTOR 4.7k
R739 NRSA63J-472X MG RESISTOR 4.7k
R743 NRSA63J-473X MG RESISTOR 47k
R744 NRSA63J-821X MG RESISTOR 820
R745 NRSA63J-106X MG RESISTOR 10M
R746 NRSA63J-473X MG RESISTOR 47k
R749 NRSA63J-473X MG RESISTOR 47k
R750 NRSA63J-473X MG RESISTOR 47k
R751 NRSA63J-333X MG RESISTOR 33k
R755 NRSA63J-103X MG RESISTOR 10k
R756 NRSA63J-222X MG RESISTOR 2.2k
R757 NRSA63J-473X MG RESISTOR 47k
R758 NRSA63J-224X MG RESISTOR 220k
R759 NRSA63J-224X MG RESISTOR 220k
R760 NRSA63J-472X MG RESISTOR 4.7k
R761 NRSA63J-472X MG RESISTOR 4.7k
R762 NRSA63J-472X MG RESISTOR 4.7k
R763 NRSA63J-103X MG RESISTOR 10k
R765 NRSA63J-103X MG RESISTOR 10k
R766 NRSA63J-473X MG RESISTOR 47k
R767 NRSA63J-103X MG RESISTOR 10k
R768 NRSA63J-0R0X MG RESISTOR 0
R771 NRSA63J-392X MG RESISTOR 3.9k
R774 NRSA63J-472X MG RESISTOR 4.7k
R775 NRSA63J-472X MG RESISTOR 4.7k
R776 NRSA63J-472X MG RESISTOR 4.7k
R777 NRSA63J-102X MG RESISTOR 1k
R779 NRSA63J-222X MG RESISTOR 2.2k
R781 NRSA63J-471X MG RESISTOR 470
R801 NRSA63J-101X MG RESISTOR 100
R802 NRSA63J-473X MG RESISTOR 47k
R803 NRSA63J-223X MG RESISTOR 22k
R804 NRSA63J-104X MG RESISTOR 100k
R805 NRSA63J-103X MG RESISTOR 10k
R806 NRSA63J-104X MG RESISTOR 100k
R807 NRSA63J-331X MG RESISTOR 330
R808 NRSA63J-223X MG RESISTOR 22k
R809 NRSA63J-101X MG RESISTOR 100
R810 NRSA63J-473X MG RESISTOR 47k
R821 NRSA63J-100X MG RESISTOR 10
R822 NRSA63J-471X MG RESISTOR 470
R823 NRSA63J-223X MG RESISTOR 22k
R843 NRSA63J-473X MG RESISTOR 47k
R844 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω
Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω
Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1/16W D

1/16W J

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

1/16W J

1/16W J

1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

1/16W J

1/16W J

1/16W J

3-10



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R846 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R847 NRSA63J-392X MG RESISTOR 3.9k
R848 NRSA63J-221X MG RESISTOR 220
R885 NRSA63J-473X MG RESISTOR 47k
R886 NRSA63J-472X MG RESISTOR 4.7k
R887 NRSA63J-103X MG RESISTOR 10k
R901 QRE142J-102X C RESISTOR 1k
R902 NRSA63J-912X MG RESISTOR 9.1k
R903 NRSA63J-472X MG RESISTOR 4.7k
R909 NRSA63J-473X MG RESISTOR 47k
R910 NRSA63J-222X MG RESISTOR 2.2k
R914 NRS181J-221X MG RESISTOR 220
R923 NRSA63J-393X MG RESISTOR 39k
R924 NRSA63J-103X MG RESISTOR 10k
R925 NRSA63J-154X MG RESISTOR 150k
R926 NRSA63J-394X MG RESISTOR 390k
R927 NRSA63J-473X MG RESISTOR 47k
R962 NRSA63J-101X MG RESISTOR 100
R973 NRSA63J-103X MG RESISTOR 10k
R974 NRSA63J-103X MG RESISTOR 10k
R975 NRSA63J-103X MG RESISTOR 10k
R976 NRSA63J-563X MG RESISTOR 56k
R977 NRSA63J-183X MG RESISTOR 18k
R981 NRS181J-222X MG RESISTOR 2.2k
R982 NRS181J-222X MG RESISTOR 2.2k
RA723 NRZ0065-103X NET RESISTOR 10k
RA962 NRZ0065-222X NET RESISTOR 2.2k

L1 NQL334J-4R7X COIL 4.7uH J
L2 NQL093K-R22X COIL 0.22uH K
L401 NQR0007-002X FERRITE BEADS
L411 NQL114K-470X INDUCTOR 47uH K
L721 NQL38DK-330X COIL 33uH K
L722 QQL244J-470Z COIL 47uH J
L901 QQR1378-002 COIL
L902 NQL56CK-220X COIL 22uH K
L924 NQL56CK-220X COIL 22uH K
L925 NQL71EM-330X COIL 33uH M
L927 NQLB7GM-100X COIL 10uH M

CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN821 QGA2001C1-02 CONNECTOR W-B (1-2)
CN901 QNZ0607-001 CAR CONNECTOR
CN961 QGB2027M3-30S CONNECTOR B-B (1-30)
CN962 QGF0534F3-45X CONNECTOR FFC/FPC (1-45)
CN963 QGB2027L9-30X CONNECTOR B-B (1-30)
J1 QNB0190-001 CAR ANT JACK
J331 QNN0770-001 3P PIN JACK
J801 QNZ0095-001 CONNECTOR
K401 NQR0007-002X FERRITE BEADS
K402 NQR0007-002X FERRITE BEADS
K411 NQR0201-004X FERRITE BEADS
S723 QSW1049-001Z TACT SW
TH721 NAD0028-103X N THERMISTOR 10k
TU1 QAU0443-002 TUNER PACK
X721 QAX0617-001Z CRYSTAL 12.500MHz
X722 QAX0401-001 CRYSTAL 32.768KHz

Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/4W J

Ω
Ω

Ω

1/16W J

Ω

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

Ω

1/16W J

1/16W J

1/16W J
1/16W J

1/16W J

1/16W J
1/16W J

1/8W J
1/8W J

Switch board(KD-DV4200J)

Block No. [0][2]



Symbol No.

IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER

Q670 2SA1365/F/-X TRANSISTOR
Q671 RT1N141C-X DIGI TRANSISTOR

D630 SML-310LT/MN/-X LED
D631 SML310BA1T/HJ-X LED
D632 SML310BA1T/HJ-X LED
D633 SML310BA1T/HJ-X LED
D635 SML-310VT/JK/-X LED

Part No. Part Name Description Local

D637 SML-310VT/JK/-X LED
D638 SML-310VT/JK/-X LED
D639 SML-310VT/JK/-X LED
D640 SML-310VT/JK/-X LED
D641 SML-310VT/JK/-X LED
D642 SML-310VT/JK/-X LED
D643 SML-310VT/JK/-X LED
D644 SML-310VT/JK/-X LED
D645 SML-310VT/JK/-X LED
D646 SML-310VT/JK/-X LED
D647 SML-310VT/JK/-X LED
D648 SML-310VT/JK/-X LED
D649 SML-310VT/JK/-X LED
D650 SML-310VT/JK/-X LED
D651 SML-310VT/JK/-X LED
D652 SML-310VT/JK/-X LED
D653 NSPW310BS/B2RST LED
D654 NSPW310BS/B2RST LED
D661 1SS355W-X DIODE C.M
D662 UDZW5.1B-X SI DIODE
D681 UDZW6.2B-X SI DIODE

C661 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C662 NCS31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C664 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C681 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C682 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C686 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C687 NCB31HK-223X C CAPACITOR 0.022uF 50V K

Ω

R601 NRSA63J-821X MG RESISTOR 820
R602 NRSA63J-821X MG RESISTOR 820
R603 NRSA63J-122X MG RESISTOR 1.2k
R604 NRSA63J-182X MG RESISTOR 1.8k
R605 NRSA63J-272X MG RESISTOR 2.7k
R606 NRSA63J-821X MG RESISTOR 820
R607 NRSA63J-821X MG RESISTOR 820
R608 NRSA63J-122X MG RESISTOR 1.2k
R609 NRSA63J-182X MG RESISTOR 1.8k
R610 NRSA63J-272X MG RESISTOR 2.7k
R611 NRSA63J-821X MG RESISTOR 820
R612 NRSA63J-821X MG RESISTOR 820
R613 NRSA63J-122X MG RESISTOR 1.2k
R614 NRSA63J-182X MG RESISTOR 1.8k
R615 NRSA63J-272X MG RESISTOR 2.7k
R625 NRSA63J-471X MG RESISTOR 470
R627 NRSA63J-471X MG RESISTOR 470
R630 NRSA63J-821X MG RESISTOR 820
R631 NRSA63J-471X MG RESISTOR 470
R633 NRSA63J-331X MG RESISTOR 330
R635 NRSA63J-471X MG RESISTOR 470
R637 NRSA63J-331X MG RESISTOR 330
R639 NRSA63J-331X MG RESISTOR 330
R641 NRSA63J-471X MG RESISTOR 470
R643 NRSA63J-471X MG RESISTOR 470
R645 NRSA63J-471X MG RESISTOR 470
R649 NRS181J-391X MG RESISTOR 390
R650 NRS181J-391X MG RESISTOR 390
R661 NRSA63J-222X MG RESISTOR 2.2k
R662 NRSA63J-222X MG RESISTOR 2.2k
R663 NRSA63J-184X MG RESISTOR 180k
R664 NRSA63J-103X MG RESISTOR 10k
R665 NRSA63J-513X MG RESISTOR 51k
R666 NRSA63J-103X MG RESISTOR 10k
R667 NRSA63J-103X MG RESISTOR 10k
R668 NRSA63J-103X MG RESISTOR 10k
R670 NRS181J-471X MG RESISTOR 470
R671 NRSA63J-473X MG RESISTOR 47k
R672 NRS181J-102X MG RESISTOR 1k
R681 NRSA63J-471X MG RESISTOR 470
R682 NRSA63J-103X MG RESISTOR 10k
R686 NRSA63J-101X MG RESISTOR 100
R687 NRSA63J-473X MG RESISTOR 47k
R688 NRSA63J-473X MG RESISTOR 47k

CJ601 QGZ1601K1-15S CONNECTOR (1-15)
JS686 QSW0976-001 ROTARY ENCODER

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1/16W J

3-11



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW

Main board
(KD-DV4201E,DV4201EU,DV4202E,
DV4202EU)

Block No. [0][3]



Symbol No.

IC71 LC72725NM-X IC
IC161 NJW1192V-X IC
IC301 LA4743K POWER IC
IC401 SN74AHCT1G08V-X IC
IC402 TOTX177L OPTICAL JACK
IC411 MM1510XN-X IC
IC721 UPD784217AGC351 IC
IC722 BR24L32F-W-X IC
IC723 S-80833CNNB-G-W IC
IC801 SN74AHC126NS-X IC
IC901 R2S25400DS-E REGULATOR IC
IC921 BA33BC0FP-X IC
IC922 BD9781HFP-W DC CONVERTOR
IC961 SN74LVC32APW-X IC
IC962 SN74HCT32APW-X IC

Q2 RT1N141C-X DIGI TRANSISTOR
Q303 RT1N141C-X DIGI TRANSISTOR
Q344 KTD1304-X TRANSISTOR
Q354 KTD1304-X TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR
Q783 RT1P141C-X DIGI TRANSISTOR
Q821 RT1N141C-X DIGI TRANSISTOR
Q822 RT1P141C-X DIGI TRANSISTOR
Q823 2SC4485/ST/-T TRANSISTOR
Q885 RT1N141C-X DIGI TRANSISTOR
Q891 RT1N141C-X DIGI TRANSISTOR
Q903 2SA1530A/R/-X TRANSISTOR
Q904 RT1N141C-X DIGI TRANSISTOR
Q976 RT1N441C-X TRANSISTOR
Q977 2SA1530A/R/-X TRANSISTOR

D1 1SS355W-X DIODE C.M
D2 1SS355W-X DIODE C.M
D302 1SS355W-X DIODE C.M
D344 1SS355W-X DIODE C.M
D354 1SS355W-X DIODE C.M
D401 CRS03-W SB DIODE
D411 UDZW12B-X Z DIODE
D731 1SS355W-X DIODE C.M
D781 1SS355W-X DIODE C.M
D782 1SS355W-X DIODE C.M
D783 UDZW11B-X Z DIODE
D801 CRS03-W SB DIODE
D821 UDZW12B-X Z DIODE
D831 UDZW6.2B-X DIODE

Part No. Part Name Description Local

D885 1SS355W-X DIODE C.M
D891 MC2836-X DIODE
D901 1N5401-F64 DIODE
D903 1SS355W-X DIODE C.M
D906 UDZW5.1B-X SI DIODE
D921 1A3G-T1 SI DIODE
D922 RB051L-40-X SB DIODE
D923 CRS03-W SB DIODE
D924 CRS03-W SB DIODE
D925 CRS03-W SB DIODE
D981 CRS03-W SB DIODE
D982 CRS03-W SB DIODE

C2 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C4 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C6 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C7 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C8 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C71 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C72 NCB31HK-331X C CAPACITOR 330pF 50V K
C73 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C74 NCS31HJ-561X C CAPACITOR 560pF 50V J
C75 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C76 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C77 NCS31HJ-470X C CAPACITOR 47pF 50V J
C78 NCS31HJ-820X C CAPACITOR 82pF 50V J
C83 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C93 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C161 QTE1A57-107Z E CAPACITOR 100uF 10V
C162 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C164 QTE1C57-106Z E CAPACITOR 10uF 16V
C169 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C171 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C172 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C173 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C174 NCS31HJ-471X C CAPACITOR 470pF 50V J
C175 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C176 NCB31HK-472X C CAPACITOR 4700pF 50V K
C177 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C178 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C179 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C180 QTE1H57-475Z E CAPACITOR 4.7uF 50V
C181 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C182 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C183 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C184 NCS31HJ-471X C CAPACITOR 470pF 50V J
C185 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C186 NCB31HK-472X C CAPACITOR 4700pF 50V K
C187 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C188 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C189 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C190 QTE1H57-475Z E CAPACITOR 4.7uF 50V
C302 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C311 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C312 QTE1C57-476Z E CAPACITOR 47uF 16V
C313 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C314 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C315 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C316 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C328 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C329 NCS31HJ-101X C CAPACITOR 100pF 50V J
C330 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C331 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C338 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C339 NCS31HJ-101X C CAPACITOR 100pF 50V J
C340 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C346 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C348 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C349 NCS31HJ-101X C CAPACITOR 100pF 50V J
C350 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C356 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C358 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C359 NCS31HJ-101X C CAPACITOR 100pF 50V J
C360 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C401 NCS31HJ-220X C CAPACITOR 22pF 50V J
C402 NCB31HK-103X C CAPACITOR 0.01uF 50V K

3-12



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C404 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C405 NCS31HJ-220X C CAPACITOR 22pF 50V J
C406 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C411 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C412 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C413 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C414 QERF0JM-337Z E CAPACITOR 330uF 6.3V M
C415 NCS31HJ-101X C CAPACITOR 100pF 50V J
C416 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C701 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C702 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C721 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C722 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C723 NCS31HJ-471X C CAPACITOR 470pF 50V J
C724 NCS31HJ-471X C CAPACITOR 470pF 50V J
C725 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C726 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C727 NDC31HJ-270X C CAPACITOR 27pF 50V J
C728 NDC31HJ-270X C CAPACITOR 27pF 50V J
C729 NDC31HJ-220X C CAPACITOR 22pF 50V J
C730 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C731 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C732 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C733 NCS31HJ-471X C CAPACITOR 470pF 50V J
C781 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C783 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C801 NCS31HJ-220X C CAPACITOR 22pF 50V J
C802 NCS31HJ-220X C CAPACITOR 22pF 50V J
C803 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C804 NCS31HJ-220X C CAPACITOR 22pF 50V J
C821 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C822 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C823 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C831 NCS31HJ-101X C CAPACITOR 100pF 50V J
C885 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C889 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C892 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C901 QEZ0722-338 E CAPACITOR 3300uF
C902 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C903 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C904 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C905 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C906 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C907 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C909 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C911 NCB31HK-102X C CAPACITOR 1000pF 50V K
C912 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C913 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C921 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C922 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C925 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C926 QEXF1AM-476Z E CAPACITOR 47uF 10V M
C927 QEZ0595-477Z E CAPACITOR 470uF
C928 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C929 NCB31HK-472X C CAPACITOR 4700pF 50V K
C930 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C962 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C963 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C966 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C967 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C968 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C969 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C981 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C999 NCS31HJ-101X C CAPACITOR 100pF 50V J

Ω

R1 NRSA63J-0R0X MG RESISTOR 0
R2 NRSA63J-122X MG RESISTOR 1.2k
R3 NRSA63J-122X MG RESISTOR 1.2k
R4 NRSA63J-102X MG RESISTOR 1k
R5 NRSA63J-0R0X MG RESISTOR 0
R6 NRSA63J-0R0X MG RESISTOR 0
R7 NRSA63J-473X MG RESISTOR 47k
R8 NRSA63J-101X MG RESISTOR 100
R9 NRSA63J-473X MG RESISTOR 47k
R10 NRSA63J-472X MG RESISTOR 4.7k
R11 NRSA63J-472X MG RESISTOR 4.7k
R12 NRS181J-4R7X MG RESISTOR 4.7

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/8W J

1/16W J
1/16W J

1/16W J
1/16W J

R13 NRS181J-6R8X MG RESISTOR 6.8Ω 1/8W J
R14 NRSA63J-123X MG RESISTOR 12k
R15 NRSA63J-202X MG RESISTOR 2k
R19 NRSA63J-473X MG RESISTOR 47k
R71 NRSA63J-101X MG RESISTOR 100
R72 NRSA63J-202X MG RESISTOR 2k
R73 NRSA63J-103X MG RESISTOR 10k
R81 NRSA63J-223X MG RESISTOR 22k
R82 NRSA63J-103X MG RESISTOR 10k
R91 NRSA63J-223X MG RESISTOR 22k
R92 NRSA63J-103X MG RESISTOR 10k
R171 NRSA63J-393X MG RESISTOR 39k
R172 NRSA63J-472X MG RESISTOR 4.7k
R173 NRSA63J-222X MG RESISTOR 2.2k
R181 NRSA63J-393X MG RESISTOR 39k
R182 NRSA63J-472X MG RESISTOR 4.7k
R183 NRSA63J-222X MG RESISTOR 2.2k
R302 NRSA63J-0R0X MG RESISTOR 0
R304 NRSA63J-473X MG RESISTOR 47k
R305 NRSA63J-102X MG RESISTOR 1k
R306 NRS181J-0R0X MG RESISTOR 0
R307 NRSA63J-472X MG RESISTOR 4.7k
R327 NRSA63J-0R0X MG RESISTOR 0
R329 NRSA63J-273X MG RESISTOR 27k
R330 NRSA63J-0R0X MG RESISTOR 0
R337 NRSA63J-0R0X MG RESISTOR 0
R339 NRSA63J-273X MG RESISTOR 27k
R340 NRSA63J-0R0X MG RESISTOR 0
R343 NRSA63J-473X MG RESISTOR 47k
R344 NRSA63J-222X MG RESISTOR 2.2k
R345 NRSA63J-102X MG RESISTOR 1k
R346 NRSA63J-101X MG RESISTOR 100
R347 NRSA63J-0R0X MG RESISTOR 0
R349 NRSA63J-273X MG RESISTOR 27k
R350 NRSA63J-0R0X MG RESISTOR 0
R353 NRSA63J-473X MG RESISTOR 47k
R354 NRSA63J-222X MG RESISTOR 2.2k
R355 NRSA63J-102X MG RESISTOR 1k
R356 NRSA63J-101X MG RESISTOR 100
R357 NRSA63J-0R0X MG RESISTOR 0
R359 NRSA63J-273X MG RESISTOR 27k
R360 NRSA63J-0R0X MG RESISTOR 0
R401 NRSA63J-471X MG RESISTOR 470
R402 NRSA63J-100X MG RESISTOR 10
R403 NRSA63J-471X MG RESISTOR 470
R404 NRSA63J-1R0X MG RESISTOR 1
R412 NRSA63D-682X MG RESISTOR 6.8k
R413 NRSA63J-100X MG RESISTOR 10
R414 NRSA63J-102X MG RESISTOR 1k
R415 NRSA63J-750X MG RESISTOR 75
R416 NRSA63J-0R0X MG RESISTOR 0
R417 NRSA63D-181X MG RESISTOR 180
R704 NRSA63J-271X MG RESISTOR 270
R705 NRSA63J-271X MG RESISTOR 270
R706 NRSA63J-103X MG RESISTOR 10k
R707 NRSA63J-103X MG RESISTOR 10k
R713 NRSA63J-103X MG RESISTOR 10k
R714 NRSA63J-104X MG RESISTOR 100k
R715 NRSA63J-271X MG RESISTOR 270
R716 NRSA63J-271X MG RESISTOR 270
R717 NRSA63J-221X MG RESISTOR 220
R718 NRSA63J-103X MG RESISTOR 10k
R719 NRSA63J-102X MG RESISTOR 1k
R720 NRSA63J-102X MG RESISTOR 1k
R721 NRSA63J-222X MG RESISTOR 2.2k
R722 NRSA63J-222X MG RESISTOR 2.2k
R725 NRSA63J-473X MG RESISTOR 47k
R726 NRSA63J-103X MG RESISTOR 10k
R727 NRSA63J-562X MG RESISTOR 5.6k
R728 NRSA63J-472X MG RESISTOR 4.7k
R729 NRSA63J-0R0X MG RESISTOR 0
R733 NRSA63J-103X MG RESISTOR 10k
R735 NRSA63J-0R0X MG RESISTOR 0
R736 NRSA63J-222X MG RESISTOR 2.2k
R737 NRSA63J-222X MG RESISTOR 2.2k
R738 NRSA63J-472X MG RESISTOR 4.7k
R739 NRSA63J-472X MG RESISTOR 4.7k
R743 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω
Ω

Ω

1/16W J

1/16W J

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W D

1/16W D
1/16W J
1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

3-13



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R744 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R745 NRSA63J-106X MG RESISTOR 10M
R746 NRSA63J-473X MG RESISTOR 47k
R747 NRSA63J-473X MG RESISTOR 47k
R750 NRSA63J-473X MG RESISTOR 47k
R751 NRSA63J-333X MG RESISTOR 33k
R752 NRSA63J-223X MG RESISTOR 22k
R753 NRSA63J-222X MG RESISTOR 2.2k
R754 NRSA63J-222X MG RESISTOR 2.2k
R755 NRSA63J-103X MG RESISTOR 10k
R756 NRSA63J-222X MG RESISTOR 2.2k
R757 NRSA63J-473X MG RESISTOR 47k
R758 NRSA63J-224X MG RESISTOR 220k
R759 NRSA63J-224X MG RESISTOR 220k
R760 NRSA63J-472X MG RESISTOR 4.7k
R761 NRSA63J-472X MG RESISTOR 4.7k
R762 NRSA63J-472X MG RESISTOR 4.7k
R763 NRSA63J-103X MG RESISTOR 10k
R765 NRSA63J-103X MG RESISTOR 10k
R766 NRSA63J-473X MG RESISTOR 47k
R767 NRSA63J-103X MG RESISTOR 10k
R768 NRSA63J-0R0X MG RESISTOR 0
R771 NRSA63J-392X MG RESISTOR 3.9k
R774 NRSA63J-472X MG RESISTOR 4.7k
R775 NRSA63J-472X MG RESISTOR 4.7k
R776 NRSA63J-472X MG RESISTOR 4.7k
R777 NRSA63J-102X MG RESISTOR 1k
R779 NRSA63J-222X MG RESISTOR 2.2k
R781 NRSA63J-471X MG RESISTOR 470
R801 NRSA63J-101X MG RESISTOR 100
R802 NRSA63J-473X MG RESISTOR 47k
R803 NRSA63J-223X MG RESISTOR 22k
R804 NRSA63J-104X MG RESISTOR 100k
R805 NRSA63J-103X MG RESISTOR 10k
R806 NRSA63J-104X MG RESISTOR 100k
R807 NRSA63J-331X MG RESISTOR 330
R808 NRSA63J-223X MG RESISTOR 22k
R809 NRSA63J-101X MG RESISTOR 100
R810 NRSA63J-473X MG RESISTOR 47k
R821 NRSA63J-100X MG RESISTOR 10
R822 NRSA63J-471X MG RESISTOR 470
R823 NRSA63J-223X MG RESISTOR 22k
R832 NRSA63J-271X MG RESISTOR 270
R841 NRSA63J-473X MG RESISTOR 47k
R844 NRSA63J-473X MG RESISTOR 47k
R845 NRSA63J-222X MG RESISTOR 2.2k
R846 NRSA63J-392X MG RESISTOR 3.9k
R847 NRSA63J-392X MG RESISTOR 3.9k
R848 NRSA63J-221X MG RESISTOR 220
R885 NRSA63J-473X MG RESISTOR 47k
R886 NRSA63J-472X MG RESISTOR 4.7k
R887 NRSA63J-103X MG RESISTOR 10k
R891 NRSA63J-473X MG RESISTOR 47k
R892 NRSA63J-102X MG RESISTOR 1k
R901 QRE142J-102X C RESISTOR 1k
R902 NRSA63J-912X MG RESISTOR 9.1k
R903 NRSA63J-472X MG RESISTOR 4.7k
R909 NRSA63J-473X MG RESISTOR 47k
R910 NRSA63J-222X MG RESISTOR 2.2k
R914 NRS181J-221X MG RESISTOR 220
R923 NRSA63J-393X MG RESISTOR 39k
R924 NRSA63J-103X MG RESISTOR 10k
R925 NRSA63J-154X MG RESISTOR 150k
R926 NRSA63J-394X MG RESISTOR 390k
R927 NRSA63J-473X MG RESISTOR 47k
R962 NRSA63J-101X MG RESISTOR 100
R973 NRSA63J-103X MG RESISTOR 10k
R974 NRSA63J-103X MG RESISTOR 10k
R975 NRSA63J-103X MG RESISTOR 10k
R976 NRSA63J-563X MG RESISTOR 56k
R977 NRSA63J-183X MG RESISTOR 18k
R981 NRS181J-222X MG RESISTOR 2.2k
R982 NRS181J-222X MG RESISTOR 2.2k
RA723 NRZ0065-103X NET RESISTOR 10k
RA962 NRZ0065-222X NET RESISTOR 2.2k

L1 NQL334J-4R7X COIL 4.7uH J
L2 NQL093K-R22X COIL 0.22uH K

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω
Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω
Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω
Ω

Ω

1/16W J

Ω

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

1/16W J

1/16W J

1/16W J

1/16W J
1/16W J
1/16W J

1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J

1/8W J
1/8W J

L401 NQR0007-002X FERRITE BEADS
L411 NQL114K-470X INDUCTOR 47uH K
L721 NQL38DK-330X COIL 33uH K
L722 QQL244J-470Z COIL 47uH J
L901 QQR1378-002 COIL
L902 NQL56CK-220X COIL 22uH K
L924 NQL56CK-220X COIL 22uH K
L925 NQL71EM-330X COIL 33uH M
L927 NQLB7GM-100X COIL 10uH M

CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN821 QGA2001C1-02 CONNECTOR W-B (1-2)
CN831 QGA2006F1-02 CONNECTOR W-B (1-2)
CN901 QNZ0607-001 CAR CONNECTOR
CN961 QGB2027M3-30S CONNECTOR B-B (1-30)
CN962 QGF0534F3-45X CONNECTOR FFC/FPC (1-45)
CN963 QGB2027L9-30X CONNECTOR B-B (1-30)
J1 QNB0190-001 CAR ANT JACK
J331 QNN0770-001 3P PIN JACK
J801 QNZ0095-001 CONNECTOR
K401 NQR0007-002X FERRITE BEADS
K402 NQR0007-002X FERRITE BEADS
K411 NQR0201-004X FERRITE BEADS
K831 NQR0007-002X FERRITE BEADS
S723 QSW1049-001Z TACT SW
TH721 NAD0028-103X N THERMISTOR 10k
TU1 QAU0443-002 TUNER PACK
X71 QAX0263-001Z CRYSTAL 4.332MHz
X721 QAX0617-001Z CRYSTAL 12.500MHz
X722 QAX0401-001 CRYSTAL 32.768KHz

Ω

Switch board
(KD-DV4201E,DV4201EU,DV4202E,
DV4202EU)

Block No. [0][4]



Symbol No.

IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER

Q670 2SA1365/F/-X TRANSISTOR
Q671 RT1N141C-X DIGI TRANSISTOR

D630 SML-310LT/MN/-X LED
D631 SML310BA1T/HJ-X LED
D632 SML310BA1T/HJ-X LED
D633 SML310BA1T/HJ-X LED
D635 SML-310VT/JK/-X LED
D637 SML-310VT/JK/-X LED
D638 SML-310VT/JK/-X LED
D639 SML-310VT/JK/-X LED
D640 SML-310VT/JK/-X LED
D641 SML-310VT/JK/-X LED
D642 SML-310VT/JK/-X LED
D643 SML-310VT/JK/-X LED
D644 SML-310VT/JK/-X LED
D645 SML-310VT/JK/-X LED
D646 SML-310VT/JK/-X LED
D647 SML-310VT/JK/-X LED
D648 SML-310VT/JK/-X LED
D649 SML-310VT/JK/-X LED
D650 SML-310VT/JK/-X LED
D651 SML-310VT/JK/-X LED
D652 SML-310VT/JK/-X LED
D653 NSPW310BS/B2RST LED
D654 NSPW310BS/B2RST LED
D661 1SS355W-X DIODE C.M
D662 UDZW5.1B-X SI DIODE
D681 UDZW6.2B-X SI DIODE

Part No. Part Name Description Local

3-14



Symbol No.

C661 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C662 NCS31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C664 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C681 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C682 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C686 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C687 NCB31HK-223X C CAPACITOR 0.022uF 50V K

R601 NRSA63J-821X MG RESISTOR 820
R602 NRSA63J-821X MG RESISTOR 820
R603 NRSA63J-122X MG RESISTOR 1.2k
R604 NRSA63J-182X MG RESISTOR 1.8k
R605 NRSA63J-272X MG RESISTOR 2.7k
R606 NRSA63J-821X MG RESISTOR 820
R607 NRSA63J-821X MG RESISTOR 820
R608 NRSA63J-122X MG RESISTOR 1.2k
R609 NRSA63J-182X MG RESISTOR 1.8k
R610 NRSA63J-272X MG RESISTOR 2.7k
R611 NRSA63J-821X MG RESISTOR 820
R612 NRSA63J-821X MG RESISTOR 820
R613 NRSA63J-122X MG RESISTOR 1.2k
R614 NRSA63J-182X MG RESISTOR 1.8k
R615 NRSA63J-272X MG RESISTOR 2.7k
R625 NRSA63J-471X MG RESISTOR 470
R627 NRSA63J-471X MG RESISTOR 470
R630 NRSA63J-821X MG RESISTOR 820
R631 NRSA63J-471X MG RESISTOR 470
R633 NRSA63J-331X MG RESISTOR 330
R635 NRSA63J-471X MG RESISTOR 470
R637 NRSA63J-331X MG RESISTOR 330
R639 NRSA63J-331X MG RESISTOR 330
R641 NRSA63J-471X MG RESISTOR 470
R643 NRSA63J-471X MG RESISTOR 470
R645 NRSA63J-471X MG RESISTOR 470
R649 NRS181J-391X MG RESISTOR 390
R650 NRS181J-391X MG RESISTOR 390
R661 NRSA63J-222X MG RESISTOR 2.2k
R662 NRSA63J-222X MG RESISTOR 2.2k
R663 NRSA63J-184X MG RESISTOR 180k
R664 NRSA63J-103X MG RESISTOR 10k
R665 NRSA63J-513X MG RESISTOR 51k
R666 NRSA63J-103X MG RESISTOR 10k
R667 NRSA63J-103X MG RESISTOR 10k
R668 NRSA63J-103X MG RESISTOR 10k
R670 NRS181J-471X MG RESISTOR 470
R671 NRSA63J-473X MG RESISTOR 47k
R672 NRS181J-102X MG RESISTOR 1k
R681 NRSA63J-471X MG RESISTOR 470
R682 NRSA63J-103X MG RESISTOR 10k
R686 NRSA63J-101X MG RESISTOR 100
R687 NRSA63J-473X MG RESISTOR 47k
R688 NRSA63J-473X MG RESISTOR 47k

CJ601 QGZ1601K1-15S CONNECTOR (1-15)
JS686 QSW0976-001 ROTARY ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW

Part No. Part Name Description Local

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1/16W J

Main board
(KD-DV4203UI,DV4204UI,DV4205U,
DV4205UN,DV4205UT,DV4205A,
DV4206U,DV4206UN,DV4206UT,
DV4206A)

Block No. [0][5]



Symbol No.

IC161 NJW1192V-X IC
IC301 TB2904HQ IC
IC401 SN74AHCT1G08V-X IC
IC402 TOTX177L OPTICAL JACK
IC411 MM1510XN-X IC
IC721 UPD784218AGC343 IC
IC722 BR24L16F-W-X IC
IC723 S-80833CNNB-G-W IC
IC801 SN74AHC126NS-X IC
IC901 R2S25400DS-E REGULATOR IC
IC921 BA33BC0FP-X IC
IC922 BD9781HFP-W DC CONVERTOR
IC961 SN74LVC32APW-X IC
IC962 SN74HCT32APW-X IC

Q2 RT1N141C-X DIGI TRANSISTOR
Q301 RT1N441C-X TRANSISTOR
Q302 RT1P441C-X TRANSISTOR
Q303 RT1N141C-X DIGI TRANSISTOR
Q344 KTD1304-X TRANSISTOR
Q354 KTD1304-X TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR
Q783 RT1P141C-X DIGI TRANSISTOR
Q821 RT1N141C-X DIGI TRANSISTOR
Q822 RT1P141C-X DIGI TRANSISTOR
Q823 2SC4485/ST/-T TRANSISTOR
Q885 RT1N141C-X DIGI TRANSISTOR
Q903 2SA1530A/R/-X TRANSISTOR
Q904 RT1N141C-X DIGI TRANSISTOR
Q976 RT1N441C-X TRANSISTOR
Q977 2SA1530A/R/-X TRANSISTOR

D1 1SS355W-X DIODE C.M
D2 1SS355W-X DIODE C.M
D301 UDZW11B-X Z DIODE
D302 1SS355W-X DIODE C.M
D305 CRS03-W SB DIODE
D308 CRS03-W SB DIODE
D344 1SS355W-X DIODE C.M
D354 1SS355W-X DIODE C.M
D401 CRS03-W SB DIODE
D411 UDZW12B-X Z DIODE
D731 1SS355W-X DIODE C.M
D781 1SS355W-X DIODE C.M
D782 1SS355W-X DIODE C.M
D783 UDZW11B-X Z DIODE
D801 CRS03-W SB DIODE
D821 UDZW12B-X Z DIODE
D851 CRS03-W SB DIODE
D852 CRS03-W SB DIODE
D885 1SS355W-X DIODE C.M
D901 1N5401-F64 DIODE
D903 1SS355W-X DIODE C.M
D906 UDZW5.1B-X SI DIODE
D921 1A3G-T1 SI DIODE
D922 RB051L-40-X SB DIODE
D923 CRS03-W SB DIODE
D924 CRS03-W SB DIODE
D925 CRS03-W SB DIODE
D981 CRS03-W SB DIODE
D982 CRS03-W SB DIODE

C2 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C4 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C6 NCB31EK-473X C CAPACITOR 0.047uF 25V K

Part No. Part Name Description Local

3-15



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C7 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C8 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C83 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C93 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C161 QTE1A57-107Z E CAPACITOR 100uF 10V
C162 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C164 QTE1C57-106Z E CAPACITOR 10uF 16V
C169 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C171 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C172 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C173 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C174 NCS31HJ-471X C CAPACITOR 470pF 50V J
C175 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C176 NCB31HK-472X C CAPACITOR 4700pF 50V K
C177 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C178 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C179 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C180 QTE1H57-475Z E CAPACITOR 4.7uF 50V
C181 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C182 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C183 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C184 NCS31HJ-471X C CAPACITOR 470pF 50V J
C185 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C186 NCB31HK-472X C CAPACITOR 4700pF 50V K
C187 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C188 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C189 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C190 QTE1H57-475Z E CAPACITOR 4.7uF 50V
C301 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C302 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C311 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C312 QTE1C57-476Z E CAPACITOR 47uF 16V
C313 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C314 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C315 QEKJ1HM-475Z E CAPACITOR 4.7uF 50V M
C316 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C328 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C329 NCS31HJ-101X C CAPACITOR 100pF 50V J
C331 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C338 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C339 NCS31HJ-101X C CAPACITOR 100pF 50V J
C346 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C348 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C349 NCS31HJ-101X C CAPACITOR 100pF 50V J
C356 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C358 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C359 NCS31HJ-101X C CAPACITOR 100pF 50V J
C401 NCS31HJ-220X C CAPACITOR 22pF 50V J
C402 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C404 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C405 NCS31HJ-220X C CAPACITOR 22pF 50V J
C406 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C411 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C412 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C413 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C414 QERF0JM-337Z E CAPACITOR 330uF 6.3V M
C415 NCS31HJ-101X C CAPACITOR 100pF 50V J
C416 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C701 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C702 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C721 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C722 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C723 NCS31HJ-471X C CAPACITOR 470pF 50V J
C724 NCS31HJ-471X C CAPACITOR 470pF 50V J
C725 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C726 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C727 NDC31HJ-270X C CAPACITOR 27pF 50V J
C728 NDC31HJ-270X C CAPACITOR 27pF 50V J
C729 NDC31HJ-220X C CAPACITOR 22pF 50V J
C730 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C731 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C732 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C733 NCS31HJ-471X C CAPACITOR 470pF 50V J
C781 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C783 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C801 NCS31HJ-220X C CAPACITOR 22pF 50V J

C802 NCS31HJ-220X C CAPACITOR 22pF 50V J
C803 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C804 NCS31HJ-220X C CAPACITOR 22pF 50V J
C821 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C822 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C823 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C851 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C885 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C889 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C901 QEZ0722-338 E CAPACITOR 3300uF
C902 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C903 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C904 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C905 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C906 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C907 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C909 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C911 NCB31HK-102X C CAPACITOR 1000pF 50V K
C912 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C913 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C921 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C922 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C925 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C926 QEXF1AM-476Z E CAPACITOR 47uF 10V M
C927 QEZ0595-477Z E CAPACITOR 470uF
C928 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C929 NCB31HK-472X C CAPACITOR 4700pF 50V K
C930 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C962 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C963 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C966 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C967 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C968 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C969 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C981 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C999 NCS31HJ-101X C CAPACITOR 100pF 50V J

Ω

R1 NRSA63J-0R0X MG RESISTOR 0
R2 NRSA63J-122X MG RESISTOR 1.2k
R3 NRSA63J-122X MG RESISTOR 1.2k
R4 NRSA63J-102X MG RESISTOR 1k
R5 NRSA63J-0R0X MG RESISTOR 0
R6 NRSA63J-0R0X MG RESISTOR 0
R7 NRSA63J-473X MG RESISTOR 47k
R8 NRSA63J-101X MG RESISTOR 100
R9 NRSA63J-473X MG RESISTOR 47k
R10 NRSA63J-472X MG RESISTOR 4.7k
R11 NRSA63J-472X MG RESISTOR 4.7k
R12 NRS181J-4R7X MG RESISTOR 4.7
R13 NRS181J-6R8X MG RESISTOR 6.8
R14 NRSA63J-123X MG RESISTOR 12k
R15 NRSA63J-202X MG RESISTOR 2k
R19 NRSA63J-473X MG RESISTOR 47k
R81 NRSA63J-123X MG RESISTOR 12k
R82 NRSA63J-472X MG RESISTOR 4.7k
R91 NRSA63J-123X MG RESISTOR 12k
R92 NRSA63J-472X MG RESISTOR 4.7k
R171 NRSA63J-393X MG RESISTOR 39k
R172 NRSA63J-472X MG RESISTOR 4.7k
R173 NRSA63J-222X MG RESISTOR 2.2k
R181 NRSA63J-393X MG RESISTOR 39k
R182 NRSA63J-472X MG RESISTOR 4.7k
R183 NRSA63J-222X MG RESISTOR 2.2k
R302 NRSA63J-0R0X MG RESISTOR 0
R304 NRSA63J-473X MG RESISTOR 47k
R305 NRSA63J-103X MG RESISTOR 10k
R306 NRS181J-0R0X MG RESISTOR 0
R307 NRSA63J-472X MG RESISTOR 4.7k
R327 NRSA63J-0R0X MG RESISTOR 0
R329 NRSA63J-102X MG RESISTOR 1k
R330 NRSA63J-102X MG RESISTOR 1k
R337 NRSA63J-0R0X MG RESISTOR 0
R339 NRSA63J-102X MG RESISTOR 1k
R340 NRSA63J-102X MG RESISTOR 1k
R343 NRSA63J-473X MG RESISTOR 47k
R344 NRSA63J-222X MG RESISTOR 2.2k
R345 NRSA63J-102X MG RESISTOR 1k
R346 NRSA63J-101X MG RESISTOR 100

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/8W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

3-16



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R347 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R349 NRSA63J-102X MG RESISTOR 1k
R350 NRSA63J-102X MG RESISTOR 1k
R353 NRSA63J-473X MG RESISTOR 47k
R354 NRSA63J-222X MG RESISTOR 2.2k
R355 NRSA63J-102X MG RESISTOR 1k
R356 NRSA63J-101X MG RESISTOR 100
R357 NRSA63J-0R0X MG RESISTOR 0
R359 NRSA63J-102X MG RESISTOR 1k
R360 NRSA63J-102X MG RESISTOR 1k
R401 NRSA63J-471X MG RESISTOR 470
R402 NRSA63J-100X MG RESISTOR 10
R403 NRSA63J-471X MG RESISTOR 470
R404 NRSA63J-1R0X MG RESISTOR 1
R412 NRSA63D-682X MG RESISTOR 6.8k
R413 NRSA63J-100X MG RESISTOR 10
R414 NRSA63J-102X MG RESISTOR 1k
R415 NRSA63J-750X MG RESISTOR 75
R416 NRSA63J-0R0X MG RESISTOR 0
R417 NRSA63D-181X MG RESISTOR 180
R704 NRSA63J-271X MG RESISTOR 270
R705 NRSA63J-271X MG RESISTOR 270
R706 NRSA63J-103X MG RESISTOR 10k
R707 NRSA63J-103X MG RESISTOR 10k
R713 NRSA63J-103X MG RESISTOR 10k
R714 NRSA63J-104X MG RESISTOR 100k
R715 NRSA63J-271X MG RESISTOR 270
R716 NRSA63J-271X MG RESISTOR 270
R717 NRSA63J-221X MG RESISTOR 220
R718 NRSA63J-103X MG RESISTOR 10k
R719 NRSA63J-102X MG RESISTOR 1k
R720 NRSA63J-102X MG RESISTOR 1k
R721 NRSA63J-222X MG RESISTOR 2.2k
R722 NRSA63J-222X MG RESISTOR 2.2k
R725 NRSA63J-473X MG RESISTOR 47k
R726 NRSA63J-103X MG RESISTOR 10k
R727 NRSA63J-562X MG RESISTOR 5.6k
R728 NRSA63J-472X MG RESISTOR 4.7k
R729 NRSA63J-0R0X MG RESISTOR 0
R733 NRSA63J-103X MG RESISTOR 10k
R735 NRSA63J-0R0X MG RESISTOR 0
R736 NRSA63J-222X MG RESISTOR 2.2k
R737 NRSA63J-222X MG RESISTOR 2.2k
R738 NRSA63J-472X MG RESISTOR 4.7k
R739 NRSA63J-472X MG RESISTOR 4.7k
R743 NRSA63J-473X MG RESISTOR 47k
R744 NRSA63J-821X MG RESISTOR 820
R745 NRSA63J-106X MG RESISTOR 10M
R746 NRSA63J-473X MG RESISTOR 47k

R747 NRSA63J-473X MG RESISTOR 47k

R748 NRSA63J-473X MG RESISTOR 47k

R749 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1/16W J

1/16W D

1/16W J

1/16W J
1/16W J

1/16W J
1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

1/16W J

DV42
05A,D
V4206
A

DV42
03UI,
DV42
04UI
DV42
03UI,
DV42
04UI,
DV42
05U,D
V4205
UN,D
V4205
UT,DV
4206U
,DV42
06UN,
DV42
06UT

R750 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R751 NRSA63J-333X MG RESISTOR 33k
R755 NRSA63J-103X MG RESISTOR 10k
R756 NRSA63J-222X MG RESISTOR 2.2k
R757 NRSA63J-473X MG RESISTOR 47k
R758 NRSA63J-224X MG RESISTOR 220k
R759 NRSA63J-224X MG RESISTOR 220k
R760 NRSA63J-472X MG RESISTOR 4.7k
R761 NRSA63J-472X MG RESISTOR 4.7k
R762 NRSA63J-472X MG RESISTOR 4.7k
R763 NRSA63J-103X MG RESISTOR 10k
R765 NRSA63J-103X MG RESISTOR 10k
R766 NRSA63J-473X MG RESISTOR 47k
R767 NRSA63J-103X MG RESISTOR 10k
R768 NRSA63J-0R0X MG RESISTOR 0
R771 NRSA63J-392X MG RESISTOR 3.9k
R774 NRSA63J-472X MG RESISTOR 4.7k
R775 NRSA63J-472X MG RESISTOR 4.7k
R776 NRSA63J-472X MG RESISTOR 4.7k
R777 NRSA63J-102X MG RESISTOR 1k
R779 NRSA63J-222X MG RESISTOR 2.2k
R781 NRSA63J-471X MG RESISTOR 470
R801 NRSA63J-101X MG RESISTOR 100
R802 NRSA63J-473X MG RESISTOR 47k
R803 NRSA63J-223X MG RESISTOR 22k
R804 NRSA63J-104X MG RESISTOR 100k
R805 NRSA63J-103X MG RESISTOR 10k
R806 NRSA63J-104X MG RESISTOR 100k
R807 NRSA63J-331X MG RESISTOR 330
R808 NRSA63J-223X MG RESISTOR 22k
R809 NRSA63J-101X MG RESISTOR 100
R810 NRSA63J-473X MG RESISTOR 47k
R821 NRSA63J-100X MG RESISTOR 10
R822 NRSA63J-471X MG RESISTOR 470
R823 NRSA63J-223X MG RESISTOR 22k

R841 NRSA63J-473X MG RESISTOR 47k

R843 NRSA63J-473X MG RESISTOR 47k

R844 NRSA63J-473X MG RESISTOR 47k
R846 NRSA63J-392X MG RESISTOR 3.9k
R847 NRSA63J-392X MG RESISTOR 3.9k
R848 NRSA63J-221X MG RESISTOR 220
R851 NRSA63J-472X MG RESISTOR 4.7k
R885 NRSA63J-473X MG RESISTOR 47k
R886 NRSA63J-472X MG RESISTOR 4.7k
R887 NRSA63J-103X MG RESISTOR 10k
R901 QRE142J-102X C RESISTOR 1k
R902 NRSA63J-912X MG RESISTOR 9.1k
R903 NRSA63J-472X MG RESISTOR 4.7k
R909 NRSA63J-473X MG RESISTOR 47k
R910 NRSA63J-222X MG RESISTOR 2.2k
R914 NRS181J-221X MG RESISTOR 220
R923 NRSA63J-393X MG RESISTOR 39k

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω
Ω
Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω
Ω
Ω

Ω

1/16W J

Ω

Ω
Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

Ω

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/4W J

Ω
Ω

Ω

1/16W J

Ω

Ω

Ω

1/16W J

1/16W J

1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

1/16W J
1/16W J
1/16W J
1/16W J

1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J

1/16W J
1/16W J

1/16W J

1/16W J

1/16W J

1/16W J
1/16W J

1/16W J

1/8W J

DV42
05U,D
V4205
UN,D
V4205
UT,DV
4205A
,DV42
06U,D
V4206
UN,D
V4206
UT,DV
4206A

DV42
03UI,
DV42
04UI,
DV42
05U,D
V4205
UN,D
V4205
UT,DV
4206U
,DV42
06UN,
DV42
06UT

DV42
05A,D
V4206
A

3-17



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R924 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R925 NRSA63J-154X MG RESISTOR 150k
R926 NRSA63J-394X MG RESISTOR 390k
R927 NRSA63J-473X MG RESISTOR 47k
R962 NRSA63J-101X MG RESISTOR 100
R973 NRSA63J-103X MG RESISTOR 10k
R974 NRSA63J-103X MG RESISTOR 10k
R975 NRSA63J-103X MG RESISTOR 10k
R976 NRSA63J-563X MG RESISTOR 56k
R977 NRSA63J-183X MG RESISTOR 18k
R981 NRS181J-222X MG RESISTOR 2.2k
R982 NRS181J-222X MG RESISTOR 2.2k
RA723 NRZ0065-103X NET RESISTOR 10k
RA962 NRZ0065-222X NET RESISTOR 2.2k

L1 NQL334J-4R7X COIL 4.7uH J
L2 NQL093K-R22X COIL 0.22uH K
L401 NQR0007-002X FERRITE BEADS
L411 NQL114K-470X INDUCTOR 47uH K
L721 NQL38DK-330X COIL 33uH K
L722 QQL244J-470Z COIL 47uH J
L901 QQR1378-002 COIL
L902 NQL56CK-220X COIL 22uH K
L924 NQL56CK-220X COIL 22uH K
L925 NQL71EM-330X COIL 33uH M
L927 NQLB7GM-100X COIL 10uH M

CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN821 QGA2001C1-02 CONNECTOR W-B (1-2)
CN901 QNZ0607-001 CAR CONNECTOR
CN961 QGB2027M3-30S CONNECTOR B-B (1-30)
CN962 QGF0534F3-45X CONNECTOR FFC/FPC (1-45)
CN963 QGB2027L9-30X CONNECTOR B-B (1-30)
J1 QNB0190-001 CAR ANT JACK
J331 QNN0770-001 3P PIN JACK
J801 QNZ0095-001 CONNECTOR
K401 NQR0007-002X FERRITE BEADS
K402 NQR0007-002X FERRITE BEADS
K411 NQR0201-004X FERRITE BEADS
S723 QSW1049-001Z TACT SW
TH721 NAD0028-103X N THERMISTOR 10k
TU1 QAU0443-002 TUNER PACK
X721 QAX0617-001Z CRYSTAL 12.500MHz
X722 QAX0401-001 CRYSTAL 32.768KHz

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/8W J

Ω

1/16W J

Ω

Ω

Switch board
(KD-DV4203UI,DV4204UI,DV4205U,
DV4205UN,DV4205UT,DV4205A,
DV4206U,DV4206UN,DV4206UT,
DV4206A)

Block No. [0][6]



Symbol No.

IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER

Q670 2SA1365/F/-X TRANSISTOR
Q671 RT1N141C-X DIGI TRANSISTOR

D630 SML-310LT/MN/-X LED
D631 SML310BA1T/HJ-X LED
D632 SML310BA1T/HJ-X LED
D633 SML310BA1T/HJ-X LED
D635 SML-310VT/JK/-X LED
D637 SML-310VT/JK/-X LED
D638 SML-310VT/JK/-X LED
D639 SML-310VT/JK/-X LED

Part No. Part Name Description Local

D640 SML-310VT/JK/-X LED
D641 SML-310VT/JK/-X LED
D642 SML-310VT/JK/-X LED
D643 SML-310VT/JK/-X LED
D644 SML-310VT/JK/-X LED
D645 SML-310VT/JK/-X LED
D646 SML-310VT/JK/-X LED
D647 SML-310VT/JK/-X LED
D648 SML-310VT/JK/-X LED
D649 SML-310VT/JK/-X LED
D650 SML-310VT/JK/-X LED
D651 SML-310VT/JK/-X LED
D652 SML-310VT/JK/-X LED
D653 NSPW310BS/B2RST LED
D654 NSPW310BS/B2RST LED
D661 1SS355W-X DIODE C.M
D662 UDZW5.1B-X SI DIODE
D681 UDZW6.2B-X SI DIODE

C661 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C662 NCS31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C664 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C681 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C682 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C686 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C687 NCB31HK-223X C CAPACITOR 0.022uF 50V K

Ω

R601 NRSA63J-821X MG RESISTOR 820
R602 NRSA63J-821X MG RESISTOR 820
R603 NRSA63J-122X MG RESISTOR 1.2k
R604 NRSA63J-182X MG RESISTOR 1.8k
R605 NRSA63J-272X MG RESISTOR 2.7k
R606 NRSA63J-821X MG RESISTOR 820
R607 NRSA63J-821X MG RESISTOR 820
R608 NRSA63J-122X MG RESISTOR 1.2k
R609 NRSA63J-182X MG RESISTOR 1.8k
R610 NRSA63J-272X MG RESISTOR 2.7k
R611 NRSA63J-821X MG RESISTOR 820
R612 NRSA63J-821X MG RESISTOR 820
R613 NRSA63J-122X MG RESISTOR 1.2k
R614 NRSA63J-182X MG RESISTOR 1.8k
R615 NRSA63J-272X MG RESISTOR 2.7k
R625 NRSA63J-471X MG RESISTOR 470
R627 NRSA63J-471X MG RESISTOR 470
R630 NRSA63J-821X MG RESISTOR 820
R631 NRSA63J-471X MG RESISTOR 470
R633 NRSA63J-331X MG RESISTOR 330
R635 NRSA63J-471X MG RESISTOR 470
R637 NRSA63J-331X MG RESISTOR 330
R639 NRSA63J-331X MG RESISTOR 330
R641 NRSA63J-471X MG RESISTOR 470
R643 NRSA63J-471X MG RESISTOR 470
R645 NRSA63J-471X MG RESISTOR 470
R649 NRS181J-391X MG RESISTOR 390
R650 NRS181J-391X MG RESISTOR 390
R661 NRSA63J-222X MG RESISTOR 2.2k
R662 NRSA63J-222X MG RESISTOR 2.2k
R663 NRSA63J-184X MG RESISTOR 180k
R664 NRSA63J-103X MG RESISTOR 10k
R665 NRSA63J-513X MG RESISTOR 51k
R666 NRSA63J-103X MG RESISTOR 10k
R667 NRSA63J-103X MG RESISTOR 10k
R668 NRSA63J-103X MG RESISTOR 10k
R670 NRS181J-471X MG RESISTOR 470
R671 NRSA63J-473X MG RESISTOR 47k
R672 NRS181J-102X MG RESISTOR 1k
R681 NRSA63J-471X MG RESISTOR 470
R682 NRSA63J-103X MG RESISTOR 10k
R686 NRSA63J-101X MG RESISTOR 100
R687 NRSA63J-473X MG RESISTOR 47k
R688 NRSA63J-473X MG RESISTOR 47k

CJ601 QGZ1601K1-15S CONNECTOR (1-15)
JS686 QSW0976-001 ROTARY ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1/16W J

3-18

SCHEMATIC DIAGRAMS

DVD/CD RECEIVER

KD-DV4200J,KD-DV4201E,KD-DV4201EU
KD-DV4202E,KD-DV4202EU,KD-DV4203UI
KD-DV4204UI,KD-DV4205U,KD-DV4205UN
KD-DV4205UT,KD-DV4205A,KD-DV4206U
KD-DV4206UN,KD-DV4206UT,KD-DV4206A

KD-DV4207EE

CD-ROM No.SML200602

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

Contents

Block diagram
Standard schematic diagrams
Printed circuit boards

COPYRIGHT 2006 Victor Company of Japan, Limited.

2-1
2-2
2-11 to 12

No.MA248SCH

2006/2

Safety precaution

!

!

Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.

Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.

< MEMO >

Block diagram

J1

CN961

CN701

J801

FOCUS

&

TRACKING

COIL

PICK UP

LOAD&FEED
MOTOR

SPINDLE
MOTOR

SW1 to SW3

DVD section

CN101

DVD LD

CD LD

F+,F­T+,T-

FLM+

M

M

FLM-

H1+,H1­H2+,H2-

CN201

H3+,H3­SM1 to Sm3

CN202

SW2, SW3

SW1

SP MOTOR

SDRAM

IC398

FLASH ROM

TRVSW

A,B,C,D,E,F
RF+,RF­LPC1,LPC2
CD/DVD,HAGUP

LPCO1
DVDLDCUR

Q101
Q102

LPCO2
CDLDCUR

Q103
Q104

IC201

DRIVER

IC251

DRIVER

MA0 to MA11
MDQ0 to MDQ15
DQM0,DQM1
BA0,BA1,MCK
NWE,NCSM

IC399

SW4

NCAS,NRAS

EXADT0 to EXADT15
EXADR16 to EZADR20
EXDAT0 to EXDAT15
NEXOE,NEXCE
NEXWE,/FL_RST

/DRVMUTE
TRDRV
FODRV
TRSDRV
DRVCONT
LM
VHALF

SPDRV
/SPMUTE
FG

IC301
DV2.1

AOUT3
BCK
LRCLK
PCMCLK
DACPDN
DACOCS
DCLK
DDATA

IC401

D/A

AOUTL+
AOUTL­AOUTR+
AOUTR-

IC411

AMP

LRMUTE
UCS,SCS
SCLK
U2SDT,S2UDT
DAC4OUT(COMPOSITE)
TX

EPDI
EPDO
EPSK
EPCS

IC481

EPROM

CPURST

IC304

RESET

L-CH
R-CH

SW1,SW4

CN403

ANT

CN962

CN963

CHANGER

SW4,SW5

2-1

LCD & Key switch section

D630 to D633

D635

D637 to D654

LIGHTING

DISPLAY

LCD DISPLAY

Q670,Q671

DIMMER

CONT

DIMOUT

LCD1

ENCODER

S1 to S52
COM1 to COM3

JS686

ENC1
ENC2

LCD DRIVER

LCDDA
LCDCL
LCDCE

IC661

IC681

REMOCON

REMOCON

KEY0
KEY1
KEY2

S601 to S618
KEY MATRIX

CJ601

ANT

Main amplifier section

J1

TU1

FM/AM TUNER

SW_FLAG, FSU
SSTOP, SDA, SCL
Q_OUT, AFS

Tu.L
Tu.R

USED FOR
KD-DV4201
KD-DV4202
KD-DV4207

IC71
RDS

RL, RR

FL, FR

RDSDA
RDSSCKMPX

VMUTE

COMPOSITE

MUTE

IC411

VIDEO

AMP

Q344,Q354

LINE OUT

MUTING

MUTE

Q303,Q781

MUTE

CONTROL

MUTE

IC301

POWER

AMP

VIDEO-OUT

REAR L
REAR R

FRONT L+
FRONT L­FRONT R+
FRONT R­REAR L+
REAR L­REAR R+
REAR R-

VIDEO OUT

J331

LINE OUT

CN901

SPEAKER
&
BATTERY

CN963

ANGER

CJ601

CN961

J801

KEY0 to KEY2
DIMOUT
LCDCL
LCDDA
LCDCE

CN701

ENC1,ENC2
REMOCON

SCK
SI/SO

IC801

JVC BUS

BUSSO
BUSSCK
BUSINT
I/O,SI/SO

DVDL
DVDR

CHL
CHR

IC161

E.VOLUME

LRMUTE
UCS,SCS
SCLK
U2SDT
S2UDT
CPURST

IC961

IC962
LEVEL
CONV.

IC722

EPROM

VOLDA
VOLCK

SW1
SW4

LRMUTE
UCS,SCS
SCLK
U2SDT
S2UDT
CPURST

EPDAI
EPDAO
EPCLK

IC721

CPU

EACH BLOCK

PON
ANT

IC901,IC921,IC922

REGULATOR

USED FOR
KD-DV4203, KD-DV4204
KD-DV4205, KD-DV4206

D851

AUTO ANT

USED FOR
KD-DV4201, KD-DV4202
KD-DV4207

TELMUTE
TELCONT

RESET

Q891,Q892

TEL MUTE

DOUTMUTE

IC723

RESET

S723

RESET

SW

ACC
REMOTE

AUTO ANTANT

TEL

TX

IC401

DIGITAL

OUT

USED FOR
KD-DV4201
KD-DV4202

FAN

HANDLEREM

IC402

DIGITAL
OUT

CN821

CN831

OE
REMOTE

FAN
MOTOR

M

2-2

Standard schematic diagrams

0

1

3

/

/

Main section (for KD-DV4200)

TU1
QAU0443-002

J1

QNB0190-001

0

B1

0.22u

L2

R2

1.2K

L1

4.7u

D2

D1

CN962

QGF0534F3-45X

CN963

QGB2027L9-30X

R401

QGB2027M3-30S

CN961

C909

100/16

SN74AHCT1G08V-X

470

TX

0.01

C403

100

R962

D925

IC401

R405

0

C401

22p

C402

0.01

K402

NQR0007-002X

D924

CRS03-W

C969

0.047
COMPOSITE

CRS03-W

C2

R403

470

10

R402

1

R404

K401

NQR0007-002X

L401

C404

100/6.3

D401

CRS03-W

NQR0007-002X

SCS

SN74LVC32APW-X

0.1/16

C966

D923

C961

CRS03-W

220/10

C968

0.047

DVDL

DVDR

SW1

SW4

IC921

BA33BC0FP-X

D921

1A3G-T1

C921

C922

220/10

100/10

KEY0

KEY2

KEY1

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

D701

D703

D702

2p

TOTX177L

C405

C925

220/10

LCDCE

0

C1

R1

1SS355W-X

0.1

1SS355W-X

SW_FLAG

47K

R19

IC402

220/10

0.047

C411

C412

22p

0.01

C406

S2UDT

LCDCL

270

R704

L924

QEXF1AM-476Z

ENC1

ENC2

270

R705

C963

220/10

NQL56CK-220X

C926

REMOCON

10K

R706

0

B922

C927

470/25

PDETACH

CPURST

R974

R975

C911

0.001

10K

R707

IC961

LCDDA

FSU

IC411

COMPOSITE

R973

10K

10K

10K

L927

NQLB7GM-100X

L925

NQL71EM-330X

0.1

C928

D704

D705

D706

D707

D709

D710

C701

C702

D711

MM1510XN-X

C413

180

6.8K

R417

R412

C967

0.1/16

C962

220/10

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

0.1

0.1

MA8062/M/-X

R9

47K

NQL114K-470X

1.5

BD9781HFP-W

R923

39K

390k

RB051L-40-X

D922

R926

R3

R10

L411

D906

RT1N141C-X

IC922

R5

1.2K

SSTOP

4.7K

R914

220

UDZW5.1B-X

0.1

C930

R6

0

SDA

R11

4.7K

C414

330/6.3

R414

SN74HCT32APW-X

R910

Q904

C929

4700P

150K

R925

10K

R924

R7

0.01

0

C4

SCL

R413

10

1K

IC962

Q903

2SA1530A/R/-X

R909

2.2K

R927

CN101

QGA2006C1-04

C155

470

R155

0.47

C83

4.7/50

C93

4.7/50

R8

R4

1K

47k

47/16

C5

R12

4.7

R415
75

R416
0

K411

NQR0201-004X

D411

UDZW12B-X

VIDEO-OUT

47K

47K

R928

47k

100

0.1

0.1

0.047

220/10

C6

C9

C7

C8

R13

6.8

Q_OUT

C74

560p

IC71

LC72725NM-X

UCS

SCLK

U2SDT

LRMUTE

RA962

NRZ0065-222X

LRMUTE

SDA

SCL

SCS

CPURST

Q2

RT1N141C-X

R725

47K

C721

0.047
C722

220/10

C723
470P

AFS

0.01

47/6.3

C75

R14

C73

330P

C72

0.01

C76

C77

QAX0263-001Z

0.01
C997

C999
100P

R81

22K

R91

22K

12K

47p

X71

R15

10/16

2K

R71

C71

C78

C415
100P

DOUTMUTE

C94

100

2K

R72

RDSSCK

82p

VMUTE

MUTE

PBRK

ANT

PON

TELMUTE
TELCONT

FAN

RDSDA

R92

10k

C416

0.01

R733

R717

R848

R738

R739

R758

R759

4.7K

C84

R82

R73

IC721

UPD784218AGC343

R726

R735

R727

R728

R729

R731

R736

R737

VPP

4.7K

4.7K

220k

220k

4.7K

R723

47K

47K

R724

10K

0

5.6k

4.7k

0

2.2k

10K

220
220

2.2K

2.2K

LEVEL

47K

47K

R141

R151

0.00470.0047

C141C151

DVDL

TU.L

DVDR

C102

22/16

LINE-L

C101

10/16

47k47k

R101R111

LINE-G

C111

10/16

LINE-R

C112

22/16

VOLDA

VOLCK

2.2k

2.2k

R722

R721

10k

10k

L721

R763

R765

SW4

SW1

VOL2

VOL1

47k

47k

47k

47k

47k

47k

R743

R747

R749

R750

R742

R748

470P

220/10

220/10

C724

C725

C726

C732

R199

220

0.22

UDZS5.1B-X

C194

D195

100/10

0.01

C161

C162

R103

10k

R113

10k

R112

10k 10k

820

R744

NQL38DK-330X

X721

QAX0617-001Z

8P

27P

C727

RDSDA

2.2K

R845

R745

R746

C728

39K

R198

R114

AFS

SSTOP

1K

1k

R720

R719

10M

47K

RESET

X722C729

27P

D194

RB160M-30-X

C163

C164

R104R102

10k10k

UCS

QAX0401-001

22P

2.2/50

10/16

TU.R

47k

R844

R718

R751

BUSINT

C171

C181

R105

10k

R115

10k

C109

0.022

47k

R843

10k

2.2k

R753

33k

MA111-X

D193

C172

2.2/50

C182

2.2/50

IC101

NJM4565V-X

47k

47k

R841

R842

REMOCON

R755

10k

VDD

GND

22k

R752

HANDLEREM

2SC3928A/QR/-X

C193

0.047

C192
22/16

C177

2.2/50

QTE1H55-225Z

C187

2.2/50

QTE1H55-225Z

R106

R116

C110
47/16

LCDCL

3.9K

5W_FLAG

3.9K

R847

R846

2.2k

R754

LCDDA

Q191

R195

12k

R164

47

R196

1k

R197

C175

0.1

R172

C176

C174

22/16

C173

4.7k

470p

R171

39k

R181
39k

C186

C184

C183

470p

22/16

4.7k

R182

0.1

C185

C1

2.2

C103

47/6.3

R107

10k

10k

C11
47/6

10k

10k

R117

C1

2.2

S723

QSW1049-001Z

2-3

CN701

QGZ1601J1-15

R198

C171

X722C729

R719

1

39K

10M

1k

SSTOP

C181

R105

10k

R115

10k

C109

0.022

47k

R843

10k

2.2k

R753

33k

MA111-X

D193

C172

2.2/50

C182

2.2/50

IC101

NJM4565V-X

47k

47k

R842

R841

R754

REMOCON

R755

10k

VDD

GND

22k

R752

HANDLEREM

2SC3928A/QR/-X

C193

0.047

C192

22/16

C177

2.2/50

QTE1H55-225Z

C187

2.2/50

QTE1H55-225Z

R106

R116

C110
47/16

LCDCL

3.9K

5W_FLAG

3.9K

R847

R846

2.2k

LCDDA

Q191

R195

D191

MA111-X

12k

180k

R164

C191
1/50

47

R196

22k

R194

1k

R197

C175

0.1

R172

0.0047

C176

C178

C174

C173C183

22/16

4.7k

470p

R171

39k

R181

39k

C188

C186

C184

0.0047

470p

22/16

4.7k

R182

0.1

C185

C104

2.2/50

C103

47/6.3

R107

10k

10k

C113
47/6.3

R117

10k

10k

C114

2.2/50

R715

270

270

R716

TD RD

IC723

S723

QSW1049-001Z

MA111-X

R193

2.2k

R173

0.1

0.1

2.2k

R183

NI

B101

Q161

RT1N141C-X

Q162

RT1N141C-X

SCK

R779

R778

R777

R776

R775

R774

R771

R770

R766

R768

R767

R784

NRZ0065-103X

R756

D192

47k

C180

4.7/50

C179

C190

4.7/50

C189

4.7/50 4.7/50

AUX.L

BR24L16F-W-X

C733

470P

R713

10k

2.2k

47K

1k

4.7k

4.7k

4.7k

3.9k

47K

47K

0

10K

0

RA723

S-80833CNNB-G-W

C730

2.2k
47/6.3

R191

R192

IC722

R785

NAD0028-103X

4.7K

R760

47k

47k

R174

30k

30k

R184

CD4066BPW-X

100k

100k

10K

TH721

4.7K

R761

RDSSCK

R175

30k

IC161

NJW1192V-X

30k

R185

R161

2.2k

IC162

R162

2.2k

Q_OUT

4.7K

R762

0.01

C731

C170

10/16

PDET

R714

R712

SCLK

S2UDT

U2SDT

LCDCE

FSU

LEVEL

KEY2

KEY1

KEY0

D731

47k

1SS355W-X

R757

BUSSCK

BUSSO

SI/SO

VIDEO-OUT

0

0

B104

B105

VOLDA

VOLCK

NI

B102

CHR

CHL

0.01

C169

470

R781

D782

1SS355W-X

Q783

RT1P141C-X

C783

D781

D783

100/16

UDZW11B-X

I/O

L722

QQL244J-470Z

D903

1SS355W-X

Q976

RT1N441C-X

C356

4.7/25

D354

1SS355W-X

D344

1SS355W-X

0

B103

B106

1SS355W-X

Q977

2SA1530A/R/-X

R976

56k

0

R307

R304

1SS355W-X

RT1P141C-X

47/6.3

R977

18k

4.7/25

D302

Q781

C781

R354

2.2k

R344

2.2k

C346

C910

0.001

R337

0

0

R357

R347

0

R327
0

RT1N141C-X

MUTE

R355

47k47k

R353

R343

R345

47K

R358

47K

R328

4.7K

47k

Q303

D851

R891
47K

TELMUTE

10/16

C903

R802

47K

C802

22P

1K

1K

47K

R338

47K

R348

Q891
RT1N141C-X

RT1N141C-X

22/16

C904

SI/SO

R805

C338

0.47

0.47

0.47

CRS03-W

100/10

C905

100k

R356

100

Q354
KTD1304-X

Q344

KTD1304-X

100

R346

IC301

LA4743K

R339

R340

27K

0

R360

R359

C358

C348

C328

0.47

R305

1K

CRS03-W

Q892

TELCONT

47/16

C906

ANT

BUSSO

10k

R804

R803

22K
R801

100

27K

R349

27K

R329

27K

D852

R892
1K

D891
MC2836-X

R893

3.3k

C891

0.1

IC901
R2S25400DS-E

220/10

0.01

C907

C908

I/O

SN74AHC126NS-X

0

100P

100P

R306

C317

0

C339

C359

100P

100P

R350

C329

C349

0

R330

0

R302
0

C314

22/16

C851

0.1

4.7K

R851

R885

47k

C892

0.1

PBRK

L902

NQL56CK-220X

PON

IC801

1/50

4.7/50

C315

D885

1SS355W-X

R886

4.7k

Q885

RT1N141C-X

C803

0.047

0.01

C313

C330

0.1

C303

C304

C305

R887
10k

C885

10/16

0.047
22/16

C913

C912

BUSINT

BUSSCK

100K

R806

R807

330

R808
22k

R809

100

R810

C804

47K

22P

C311

22/16

C316

D308

CRS03-W

D981
CRS03-W

D982
CRS03-W

C360

CRS03-W

C981

FAN

HANDLEREM

0.01

C340

0.1

0.1

C307

C308

C309

R981

0.1

CHR

C801

22P

R821

10

R823

22K

Q821

RT1N141C-X

C312

47/16

C350

0.1

C306

D305

R902

9.1K

R903

4.7K

SCK

C310

R832
270

C318

R982

2.2K2.2k

CHL

Q301

RT1N441C-X

1/50

C902

2.2/50

J801

QNZ0095-001

D801

470

R822

RT1P441C-X

0.01
C302

SI/SO

SCK

CRS03-W

2SC4485/ST/-T

C823

Q822

D821

NQR0007-002X

UDZW6.2B-X

C355

Q302

R901

1k

TEL

0.01

UDZW12B-X

C821 C822

10/16

K831

D831

100P

C345
100P

D301

UDZW11B-X

0.1

C889

Q823

C301

3300

RT1P141C-X

10/16

47/16

C901

D901

QGA2001C1-02

QGA2006F1-02

C831
100P

0.022

C331

QQR1378-002

0.022

C430

L901

1N5401-F64

CN831

J331

QNN0770-001

CN901

QNZ0607-001

!

CN821

D194

RB160M-30-X

RESET

114

0k

C163

C164

10/16

TU.R

R104

10k

47k

R844

R718

UCS

R751

QAX0401-001

22P

BUSINT

2.2/50

Parts are safety assurance parts.
When replacing those parts make
sure to use the specified one.

2-4

LCD & Key control section (for KD-DV4200)

LCD1

S601

R605

2.7K

QLD0386-001

R601

R602R603R604

1.2K

1.8K

S602

820

820

S605S604S603

KEY2

S606

S49

S50

S51

S52

S44

S45

S46

S47

S48

S43

COM3

COM2

COM1

S1S2S3S4S5

S6

S7

S8S9S10

S11

S12

S13

S14

S15

S16

S17

S18

S19

S20

S21

S22

S23

S24

S25

S26

S27

S28

S29

S30

S31

S32

S33

S34

S35

S36

S37

S38

S39

S40

S41

S42

R609

R610

2.7K

R615

2.7K 1.8K

S617S618

R614

R608

S616

D641

470

R635

D639

D640D631 D632

330

R636

D642

D643

330

R637

R606R607

8208201.8K 1.2K

S608

S609S610S611S612

R611

R612R613

820

8201.2K

KEY1

S607

R630

KEY0

S613S614S615 D630

D633

820

330

330

R632

470

R627

R628

470

R625

330

R626

470

R631

D635 D647

D637

D638

330

510

R633

R634

510

R638

330

R639

D644

D645

D646

510

R640

470

R641

D648

330

R642

470

R643

D649

D650

330

R644

470

R645

2-5

IC681

RPM7338-V4

JS686

QSW0976-001

470

R643

COM3

COM2

COM1

D649

D650

330

R644

C682

D681

0.012

UDZW6.2B-X

C681

4.7/6.3

10K

R682

R681

470

S44

S45

S46

S47

S48

R661

2.2K

R662

D651

D652

D653

R649

470

330

R645

R646

R670

470

Q670

D654

2SA1365/F/-X

R672

390

390

R650

Q671

RT1N141C-X

2.2K

R665

C663

0.022

R666

LCDCE

R667

LCDCL

R668

LCDDA

51K

D662

C662
680p

UDZW5.1B-X

R664

10K

47K

R671

R663

D661

180K

DIMOUT

C661

10/6.3

1SS355W-X

1K

S49
S50

S51

S52

COM1

COM2

COM3

INH

OSC

10K

CE

10K

CLK

10K

DATA

S2

S1

PT6523LQ-L

S3S4S5S6S7

S43

IC661

R687

47K

R688

47K

S37

S40

S41

S42

S38

S39

S9

S8

S11

S10

S12

100

R686

C687

C686

0.022

S35

S36

S13

S14

0.022

C664

0.1

S33

S34

S32

S31

S30

S29

S28
S27

S26
S25

S24

S23

S22

S21

S20

S19

S18

S17

S16

S15

QGZ1601K1-15S

CJ601

ACC5V

REMOCON

DIMOUT

LCDCL

LCDDA

LCDCE

ENC1
ENC2

KEY0

KEY1

KEY2

Vdd

2-6

0

1

3

/

/

Main section (for KD-DV4201,KD-DV4202)

CN962

QGF0534F3-45X

CN963

QGB2027L9-30X

R401

QGB2027M3-30S

CN961

C909

100/16

SN74AHCT1G08V-X

470

TX

0.01

C403

100

R962

D925

IC401

R405

0

C401

22p

C402

0.01

K402

NQR0007-002X

D924

CRS03-W

C969

0.047
COMPOSITE

CRS03-W

C94

100

2K

82p

VMUTE

MUTE

PBRK

ANT

PON

TELMUTE

TELCONT

FAN

R72

RDSDA

RDSSCK

C416

0.01

10K

R92

C84

10k

R73

UPD784217AGC351

R727

R728

R729

R731

R733

R717

R848

R736

R737

R738

R739

R758

R759

QGA2006C1-04

C155

0.47

10K

R82

IC721

R726

R735

2.2k

10K

220
220

2.2K

2.2K

VPP

4.7K

4.7K

220k

220k

CN101

470

R155

R151

R723

47K

47K

R724

10K

0

5.6k

4.7k

0

LEVEL

47K

47K

R141

0.00470.0047

C141C151

DVDL

TU.L

DVDR

C102

22/16

LINE-L

C101

10/16

47k

R101R111

LINE-G

47k

C111

10/16

LINE-R

C112

22/16

VOLDA

VOLCK

2.2k

2.2k

R722

R721

10k

10k

L721

R763

R765

SW4

SW1

VOL2

VOL1

47k

47k

47k

47k

47k

47k

R747

R748

R743

R749

R750

R742

470P

220/10

220/10

C724

C725

C726

C732

R199

220

UDZS5.1B-X

D195

0.01

100/10

C161

C162

R103

10k

R113

10k

R112

10k 10k

820

R744

NQL38DK-330X

X721

QAX0617-001Z

8P

27P

C727

0.22

C194

RDSDA

2.2K

D194

RB160M-30-X

39K

R198

C163

2.2/50

C164

10/16

TU.R

R104R102

10k10k

R114

47k

AFS

R844

SSTOP

1K

1k

R845

R720

R719

R718

10M

R745

UCS

47K

R746

RESET

X722C729

R751

QAX0401-001

22P

27P

C728

BUSINT

C171

C181

R105

10k

R115

10k

C109

0.022

47k

R843

10k

2.2k

R753

33k

MA111-X

D193

C172

2.2/50

C182

2.2/50

IC101

NJM4565V-X

47k

47k

R842

R841

R754

REMOCON

R755

10k

VDD

GND

22k

R752

HANDLEREM

2SC3928A/QR/-X

C193

0.047

C192

22/16

C177

2.2/50

QTE1H55-225Z

C187

2.2/50

QTE1H55-225Z

R106

R116

C110
47/16

LCDCL

3.9K

5W_FLAG

R846

2.2k

C173

C183

LCDDA

3.9K

R847

Q191

R195

12k

R164

47

R196

1k

R197

C175

0.1

R172

C174

C176

22/16

470p

R171

4.7k

39k

R181
39k

C186

C184
470p

22/16

4.7k

R182

0.1

C185

C1

2.2

C103

47/6.3

R107

10k

10k

C11
47/6

10k

10k

R117

C1

2.2

S723

QSW1049-001Z

TU1
QAU0443-002

J1

QNB0190-001

0

B1

0.22u

L2

R2

1.2K

L1

4.7u

C2

D2

D1

0.1

0

2p

TOTX177L

R403

470

10

R402

1

R404

K401

NQR0007-002X

L401

C404

100/6.3

D401

CRS03-W

D923

CRS03-W

C961

220/10

DVDL

DVDR

SW1

SW4

220/10

MA8062/M/-X

D703

C968

0.047

BA33BC0FP-X

C921

MA8062/M/-X

MA8062/M/-X

D702

IC921

D701

NQR0007-002X

0.1/16

C966

KEY2

C405

SCS

SN74LVC32APW-X

D921

1A3G-T1

C922

100/10

C925

220/10

KEY0

KEY1

LCDCE

C1

1SS355W-X

R1

1SS355W-X

SW_FLAG

FSU

47K

R19

IC402

22p

0.01

C406

IC961

C963

220/10

0

B922

L924

NQL56CK-220X

470/25

C926

QEXF1AM-476Z

ENC1

ENC2

LCDDA

LCDCL

PDETACH

REMOCON

10K

270

270

R704

R706

R705

0.047

C412

C927

S2UDT

10K

220/10

C411

R974

R975

C911

0.001

R707

IC411

COMPOSITE

CPURST

R973

10K

10K

10K

L927

NQLB7GM-100X

L925

NQL71EM-330X

D704

D705

D706

D707

D709

D710

C701

C702

D711

MM1510XN-X

C413

6.8K

R412

220/10

0.1

C928

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

0.1

0.1

MA8062/M/-X

180

R417

C967

0.1/16

C962

R9

NQL114K-470X

1.5

R923

RB051L-40-X

D922

R3

47K

L411

D906

RT1N141C-X

BD9781HFP-W

39K

390k

R926

1.2K

SSTOP

R10

4.7K

R914

220

UDZW12B-X

IC922

0.1

C930

R6

R5

0

SDA

R11

4.7K

C414

330/6.3

SN74HCT32APW-X

Q904

C929

4700P

150K

R925

10K

R924

R7

0

SCL

R414

1K

IC962

R910

47k

0.01

47/16

C4

C5

R413

10

K411

Q903

2SA1530A/R/-X

R909

2.2K

R927

47K

R12

4.7

R415
75

R416

0

NQR0201-004X

D411

VIDEO-OUT

47K

R928

47k

C93

4.7/50

UDZW12B-X

C83

4.7/50

R8

R4

100

1K

0.1

0.047

0.1

220/10

C6

C9

C7

C8

R13

6.8

Q_OUT

C74

560p

IC71

LC72725NM-X

UCS

SCLK

U2SDT

LRMUTE

RA962

NRZ0065-222X

LRMUTE

SDA

SCL

SCS

CPURST

Q2

RT1N141C-X

R725

47K

C721

0.047
C722

220/10

C723
470P

AFS

0.01

47/6.3

C75

R14

C73

330P

C72

0.01

C76

C77

QAX0263-001Z

0.01
C997

C999
100P

R81

22K

R91

22K

12K

R15

2K

R71

10/16

C71

47p

C78

X71

C415
100P

DOUTMUTE

2-7

CN701

QGZ1601J1-15

C171

6

C181

R105

10k

R115

10k

47k

R843

10k

2.2k

R753

33k

2.2/50

47k

R842

REMOCON

MA111-X

D193

C172

2.2/50

C182

QTE1H55-225Z

IC101

NJM4565V-X

47k

R841

5W_FLAG

R754

R755

10k

VDD

GND

22k

R752

HANDLEREM

2SC3928A/QR/-X

C193

0.047

C192

22/16

C177

2.2/50

QTE1H55-225Z

C187

2.2/50

R106

R116

C110
47/16

LCDCL

3.9K

R846

2.2k

LCDDA

Q191

R195

D191

MA111-X

MA111-X

R193

2.2k

R173

0.1

0.1

2.2k

R183

NI

Q161

RT1N141C-X

Q162

RT1N141C-X

SCK

R779

R778

R777

R776

R775

R774

R771

R770

R766

R768

R767

R784

NRZ0065-103X

R756

D192

47k

C180

4.7/50

C179

C190

4.7/50

C189

4.7/50 4.7/50

AUX.L

BR24L32F-W-X

C733

470P

R713

10k

2.2k

47K

1k

4.7k

4.7k

4.7k

3.9k

47K

47K

0

10K

0

RA723

S-80833CNNB-G-W

C730

2.2k
47/6.3

R191

R192

IC722

R785

NAD0028-103X

4.7K

R760

47k

47k

R174

30k

30k

R184

CD4066BPW-X

100k

100k

10K

TH721

4.7K

R761

RDSSCK

30k

R175

IC161

NJW1192V-X

30k

R185

R161

2.2k

IC162

R162

2.2k

FSU

Q_OUT

4.7K

R762

0.01

C731

C170

10/16

PDET

R714

R712

SCLK

S2UDT

U2SDT

LCDCE

LEVEL

KEY2

KEY1

KEY0

D731

47k

1SS355W-X

R757

12k

180k

R164

C191
1/50

47

R196

22k

R194

1k

R197

C175

0.1

R172

C174

0.0047

C176

C178

22/16

C173

470p

R171

4.7k

39k

R181

39k

C188

C186

C184

C183

0.0047

470p

22/16

4.7k

R182

0.1

C185

B101

C104

2.2/50

C103

47/6.3

R107

10k

10k

C113
47/6.3

10k

10k

R117

C114

2.2/50

3.9K

R715

R847

R716

S723

QSW1049-001Z

TD RD

270

270

IC723

BUSSCK

BUSSO

SI/SO

VIDEO-OUT

1SS355W-X

1SS355W-X

0

0

B104

B105

VOLDA

VOLCK

NI

B102

CHR

CHL

0.01

C169

470

R781

D782

1SS355W-X

Q783

RT1P141C-X

D781

C783

D783

100/16

UDZW11B-X

I/O

L722

QQL244J-470Z

D903

1SS355W-X

2SA1530A/R/-X

Q976

RT1N441C-X

R976
56k

4.7/25

D354

D344

0

B106

1SS355W-X

Q977

C356

0

B103

1SS355W-X

R307

R304

47/6.3

18k

R354

2.2k

R344

2.2k

C346

4.7/25

D302

Q781
RT1P141C-X

C781

C910

0.001

R977

R337

0

0

R357

R347

0

R327

0

RT1N141C-X

MUTE

R343

4.7K

R353

47k

R891
47K

R355

47k47k

R345

47K

R358

47K

R328

Q303

TELMUTE

10/16

C903

D851

Q891
RT1N141C-X

22/16

C904

R802

47K

C802

22P

47K

R338

47K

R348

1K

1K

C338

0.47

C358

0.47

C348

0.47

C328

0.47

CRS03-W

RT1N141C-X

TELCONT

47/16

100/10

C905

C906

SI/SO

10k

R805

R804

100k

R803

22K

R801

100

R305

CRS03-W

Q892

KTD1304-X

1K

BUSSO

Q354
KTD1304-X

Q344

R339

27K

R359

27K

R349

27K

R329

27K

D852

R892
1K

D891
MC2836-X

R893

3.3k

ANT

I/O

SN74AHC126NS-X

R356

100

R346

LA4743K

C851

C891

0.1

IC901
R2S25400DS-E

220/10

0.01

C907

C908

100

100P

C359

100P

C349

R302
0

22/16

PON

IC801

IC301

C314

0.1

C892

0.1

L902

R340

0

R360

0

100P

C339

100P

R350

C329

R330

R851

R885

47k

PBRK

NQL56CK-220X

R306
0

0

0

4.7/50

C315

4.7K

1SS355W-X

Q885

RT1N141C-X

J331

0.022

0.022

C430

C331

L901

QQR1378-002

1N5401-F64

CN821

CN831

CN901

QNN0770-001

QNZ0607-001

C355

100P

C345
100P

Q301

RT1N441C-X

Q302

RT1P441C-X

C317

C313

0.01

1/50

C330

0.1

C303

C304

C305

D885

R886

4.7k

R887
10k

C885

10/16

0.047
22/16

C912

C913

BUSINT

BUSSCK

100K

R806

R807
330

R808
22k

R809

100

C804

R810

C803

22P

47K

0.047

C311

22/16

C312

47/16

C350

C360

0.1

CRS03-W

CRS03-W

D308

C306

D305

D981

CRS03-W

D982
CRS03-W

9.1K

R902

FAN

4.7K

R903

HANDLEREM

SCK

C318

1/50

0.01

C316

C301

D301

47/16

0.01
C302

UDZW11B-X

C902

2.2/50

R901

C340

0.1

0.1

C307

C308

C309

R981

C981

0.1

CHR

C801

22P

R821

10

R823

22K

Q821

RT1N141C-X

1k

TEL

C310

C901

3300

0.1

C889

2SC4485/ST/-T

0.01

Q822

UDZW12B-X

C821 C822

10/16

K831

D831

Q823

10/16

RT1P141C-X

D901

QGA2001C1-02

QGA2006F1-02

C831
100P

R982

2.2K2.2k

CHL

J801

QNZ0095-001

SI/SO

SCK

D801

CRS03-W

470

R822

C823

D821

R832

NQR0007-002X

270

UDZW6.2B-X

D194
0M-30-X

C163

2.2/50

C164

10/16

TU.R

R104

10k

C109

0.022

47k

R844

R718

T

R751

BUSINT

Parts are safety assurance parts.
When replacing those parts make
sure to use the specified one.

2-8

470

LCD & Key control section (for KD-DV4201,KD-DV4202)

LCD1

QLD0386-001

S49

S50

S51

S48

S52

S42

S43

S44

S45

S46

S47

S36

S37

S38

S39

S40

S41

S30

S31

S32

S33

S34

S35

S29

COM3

COM2

COM1

S1S2S3S4S5

S6

S7

S8S9S10

S11

S12

S13

S14

S15

S16

S17

S18

S19

S20

S21

S22

S23

S24

S25

S26

S27

S28

R605

2.7K

S601

R610

2.7K

R615

2.7K 1.8K

R601

R602R603R604

1.2K

1.8K

S602

R609

R608

R614

S616

S617S618

820

820

S606

S605S604S603

D648

330

R642

470

R643

D649

D650

330

R644

D641

470

R635

D639

D640D631 D632

330

R636

D642

D643

330

R637

R606R607

8208201.8K 1.2K

S608

S609S610S611S612

R612R613

8201.2K

S607

R611

820

S613S614S615 D630

R630

820

470

470

R631

330

R632

R627

330

R628

470

R625

D633

330

R626

D635 D647

D637

D638

330

510

R633

R634

510

R638

330

R639

D644

D645

D646

510

R640

470

R641

2-9

IC681

COM3

RPM7338-V4

JS686

QSW0976-001

COM2

COM1

D649

D650

330

R644

470

R645

D651

D652

330

R646

R649

D653

C682

D681

0.012

UDZW6.2B-X

C681

10K

R682

R661

2.2K

R662

2.2K

R670

470

R664

47K

R671

DIMOUT

R663

180K

10/6.3

C661

10K

D661

1SS355W-X

Q670

D654

2SA1365/F/-X

1K

R672

390

390

R650

Q671

RT1N141C-X

C662
680p

D662
UDZW5.1B-X

R665
51K

LCDCE

LCDCL

LCDDA

0.022

C663

R666

R667

R668

10K

10K

10K

S49
S50

S51

S52

COM1

COM2

COM3

INH

OSC

CE

CLK
DATA

4.7/6.3

S47

S48

S2

S1

470

R681

S44

S45

S46

PT6523LQ-L

S3S4S5S6S7

S43

IC661

R687

47K

R688

47K

S37

S40

S41

S42

S38

S39

S9

S8

S11

S10

S12

100

R686

C687

0.022

C686

S35

S36

S13

S14

0.022

QGZ1601K1-15S

C664

0.1

S33

S34

S32

S31

S30

S29

S28
S27

S26
S25

S24

S23

S22

S21

S20

S19

S18

S17

S16

S15

CJ601

ADD5V

REMOCON

DIMOUT

LCDCL

LCDDA

LCDCE

ENC1
ENC2

KEY0

KEY1

KEY2

VDD

2-10

0

C176

2

Main section (for KD-DV4203,KD-DV4204,KD-DV4205,KD-DV4206)

CN962

QGF0534F3-45X

CN963

QGB2027L9-30X

R401

CN961

QGB2027M3-30S

C909

100/16

SN74AHCT1G08V-X

470

TX

100

R962

D925

IC401

R405

0

22p

0.01

C403

K402

NQR0007-002X

CRS03-W

C969

0.047

C401

C402

0.01

D924

CRS03-W

COMPOSITE

R81

R91

C94

2K

100

2K

R72

RDSDA

RDSSCK

82p

DOUTMUTE

VMUTE

MUTE

PBRK

ANT

PON

TELMUTE

TELCONT

FAN

4.7K

C84

R92

10k

R73

C416

0.01

R727

R728

R729

R731

R733

R717

R848

R736

R737

R738

R739

R758

R759

CN101

QGA2006C1-04

C155

R155

0.47

4.7K

R82

IC721

UPD784218AGC343

R726

10K

R735

0

5.6k

4.7k

0

2.2k

10K

220
220

2.2K

2.2K

VPP

4.7K

4.7K

220k

220k

C171

C181

R105

10k

R115

10k

C109

0.022

47k

R843

10k

2.2k

R753

33k

MA111-X

D193

C172

2.2/50

C182

2.2/50

IC101

NJM4565V-X

47k

47k

R841

R842

REMOCON

R755

10k

VDD

GND

HANDLEREM

C193

0.047

C192

22/16

C177

QTE1H55-225Z

C187

QTE1H55-225Z

C110
47/16

3.9K

5W_FLAG

R846

2.2k

R754

22k

R752

Q191

2SC3928A/QR/-X

R196

C174
470p

22/16

2.2/50

C173

C184

C183

470p

22/16

2.2/50

R107

R106

10k

R117

R116

10k

LCDCL

LCDDA

3.9K

R847

47

R197

R171

39k

R181
39k

10k

10k

R195

12k

1k

C175

R172

4.7k

4.7k

R182

C185

C1

2.2

C103
47/6.3

C11
47/6

S723

QSW1049-001Z

R164

0.1

C186

0.1

C1

2.

D194

RB160M-30-X

R199

LEVEL

470

47K

47K

R141

R151

0.00470.0047

C141C151

LINE-L

LINE-G

LINE-R

VOLDA

VOLCK

2.2k

2.2k

R722

R723

47K

R721

47K

R724

10k

R763

VOL2

VOL1

SW1

47k

47k

47k

R749

R750

R743

470P

C724

220

39K

0.22

UDZS5.1B-X

C194

D195

R198

DVDL

TU.L

C163

2.2/50

100/10

0.01

C161

C162

C164

10/16

R103

10k

10k

R112

10k 10k

RDSDA

2.2K

R845

820

R745

R744

NQL38DK-330X

R746

X721

QAX0617-001Z

8P

27P

C728

C727

TU.R

R104R102

10k10k

R114

47k

R844

AFS

SSTOP

1K

1k

R719

R720

R718

10M

UCS

47K

RESET

X722C729

R751

QAX0401-001

22P

27P

BUSINT

DVDR

C102

22/16

C101

10/16

47k47k

R101R111

C111

10/16

R113

C112

22/16

10k

L721

R765

SW4

47k

47k

47k

R748

R747

R742

220/10

220/10

C726

C725

C732

TU1

QAU0443-002

J1

QNB0190-001

0

B1

0.22u

L2

R2

1.2K

L1

4.7u

D2

D1

C2

R403

470

10

R402

1

R404

K401

NQR0007-002X

L401

C404

100/6.3

D401

CRS03-W

NQR0007-002X

SCS

SN74LVC32APW-X

0.1/16

C966

D923

CRS03-W

C961

220/10

C968

0.047

DVDL

DVDR

SW1

SW4

IC921

BA33BC0FP-X

D921

1A3G-T1

C922

C921

100/10

220/10

KEY2

KEY1

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

D701

D702

D703

TOTX177L

220/10

KEY0

0

0.1

2p

C1

R1

1SS355W-X

1SS355W-X

SW_FLAG

R19

47K

IC402

220/10

0.047

C411

C412

22p

C406

C405

0.01

S2UDT

IC961

R974

R975

C963

220/10

C911

0.001

0

B922

L924

NQL56CK-220X

C927

470/25

C925

C926

QEXF1AM-476Z

ENC1

ENC2

LCDCL

LCDCE

LCDDA

PDETACH

REMOCON

10K

270

270

R707

10K

R704

R705

R706

FSU

IC411

COMPOSITE

CPURST

R973

10K

10K

10K

L927

NQLB7GM-100X

L925

NQL71EM-330X

D704

D705

D706

D707

D709

D710

C701

C702

D711

MM1510XN-X

C413

6.8K

R412

C962

220/10

0.1

C928

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

0.1

0.1

MA8062/M/-X

180

R417

C967

0.1/16

RB051L-40-X

D922

R9

47K

L411

NQL114K-470X

1.5

BD9781HFP-W

R923

39K

390k

R926

R3

1.2K

SSTOP

R10

4.7K

R914

220

D906

UDZW12B-X

RT1N141C-X

IC922

0.1

C930

R6

R5

0

SDA

R11

4.7K

C414

330/6.3

SN74HCT32APW-X

Q904

C929

4700P

150K

R925

R924

0

SCL

R414

1K

R910

10K

R7

47k

0.01

47/16

C5

C4

R413

10

K411

IC962

Q903

2SA1530A/R/-X

R909

2.2K

R927

47K

R12

4.7

R415
75

R416

0

NQR0201-004X

D411

VIDEO-OUT

47K

R928

C93

4.7/50

47k

4.7/50

C6

UDZS12B-X

C83

R8

R4

1K

0.1

0.047

0.1

220/10

C8

C7

C9

R13

6.8

Q_OUT

IC71

UCS

SCLK

U2SDT

LRMUTE

100

Q2

C74

560p

LC72725NM-X

RA962

NRZ0065-222X

0.047

220/10

LRMUTE

SDA

SCL

SCS

CPURST

RT1N141C-X

0.01

47/6.3

C75

R725

47K

C721

C722

C723
470P

AFS

C73

0.01

C76

0.01
C997

12K

12K

12K

R14

R15

330P

C72

47p

C77

X71

QAX0263-001Z

C999
100P

R71

10/16

C71

C78

C415
100P

2-11

CN701

QGZ1601J1-15

9

C194

C171

0

22

C181

R105

10k

R115

10k

C109

0.022

47k

R843

10k

2.2k

R753

33k

MA111-X

D193

C172

2.2/50

C182

2.2/50

IC101

NJM4565V-X

47k

47k

R841

R842

REMOCON

R755

10k

VDD

GND

HANDLEREM

C193

0.047

C192

22/16

C177

QTE1H55-225Z

C187

QTE1H55-225Z

C110
47/16

3.9K

5W_FLAG

R846

2.2k

R754

22k

R752

Q191

2SC3928A/QR/-X

R196

C174
470p

22/16

2.2/50

C173C183

C184
470p

22/16

2.2/50

R107

10k

R106

R117

R116

10k

LCDCL

LCDDA

3.9K

R847

47

R197

R171

39k

R181

39k

10k

10k

R195

12k

1k

C175

R172

4.7k

4.7k

R182

C185

C104

2.2/50

C103

47/6.3

C113
47/6.3

C114

2.2/50

S723

QSW1049-001Z

BUSSCK

BUSSO

SI/SO

VIDEO-OUT

0

0

B105

B104

VOLDA

VOLCK

NI

B102

CHR

CHL

0.01

C169

470

R781

D782

1SS355W-X

Q783

RT1P141C-X

C783

D781

D783

100/16

UDZW11B-X

I/O

L722

QQL244J-470Z

D903

1SS355W-X

Q976

RT1N441C-X

4.7/25

D354

1SS355W-X

D344

1SS355W-X

0

B106

1SS355W-X

Q977

2SA1530A/R/-X

R976

56k

C356

0

B103

1SS355W-X

R354

2.2k

R344

2.2k

C346

4.7/25

R307

R304

D302

Q781

RT1P141C-X

C781

47/6.3

C910

0.001

R977

18k

R337

0

0

R357

R347

0

R327

0

RT1N141C-X

MUTE

R355

47k47k

R353

R343

R345

47K

R358

47K

R328

4.7K

47k

Q303

D851

R891
47K

TELMUTE

10/16

C903

R802

47K

C802

22P

1K

1K

47K

R338

47K

R348

Q891
RT1N141C-X

RT1N141C-X

22/16

C904

SI/SO

R805

C338

0.47

0.47

0.47

CRS03-W

100/10

C905

100k

22K

C358

C348

C328

0.47

CRS03-W

Q892

TELCONT

47/16

C906

10k

R804

R803

R801

100

Q354
KTD1304-X

Q344

KTD1304-X

R305

10K

ANT

I/O

BUSSO

R356

100

R346

TB2904HQ

R339

1K

R359

1K

R349

1K

R329

1K

D852

R892
1K

D891
MC2836-X

R893

3.3k

C891

0.1

IC901
R2S25400DS-E

220/10

0.01

C907

C908

SN74AHC126NS-X

J331

0.022

C331

L901

QQR1378-002

D901

1N5401-F64

C831
100P

QNN0770-001

0.022

C430

CN901

QNZ0607-001

CN821

CN831

C355
100P

C345
100P

100

IC301

R340
1K

R360
1K

100P

100P

R306

C317

0

C313

4.7/50

C315

4.7K

1SS355W-X

RT1N141C-X

0.01

1/50

C330

0.1

C303

C304

C305

D885

R886

4.7k

R887
10k

Q885

C885

10/16

0.047
22/16

C913

C912

BUSINT

BUSSCK

R806

100K

R807

330

R808
22k

R809

100

C804

C803

R810

22P

0.047

47K

C339

C359

100P

100P

R350

C329

1K

C349

R330

1K

R302
0

C314

2.2/50

0.1

C851

R851

R885

47k

C892

0.1

PBRK

L902

NQL56CK-220X

PON

IC801

C311

4.7/25

C312

47/16

C350

C360

0.1

C306

R902

R903

SCK

0.1

C307

D305

D308

C308

CRS03-W

CRS03-W

D981
CRS03-W

C981

0.1

D982

CRS03-W

9.1K

R821

R823

22K

FAN

4.7K

HANDLEREM

Q301

RT1N441C-X

Q302

RT1P441C-X

C318

1/50

C316

0.01

C301

D301

47/16

0.01
C302

UDZW11B-X

C902

2.2/50

R901

C340

0.1

C309

R981

CHR

C801

22P

10

Q821

RT1N141C-X

1k

TEL

C310

C901

3300

0.1

C889

R982

2.2K2.2k

CHL

J801

QNZ0095-001

SI/SO

SCK

D801

CRS03-W

2SC4485/ST/-T

Q823

470

R822

C823

0.01

QGA2001C1-02

Q822

RT1P141C-X

D821

UDZW12B-X

C821 C822

10/16

10/16

K831

R832
270

NQR0007-002X

D831

UDZW6.2B-X

QGA2006F1-02

D191

MA111-X

R173

0.1

0.1

R183

NI

B101

RT1N141C-X

RT1N141C-X

270

270

SCK

R779

R778

R777

R776

R775

R774

R771

R770

R766

R768

R767

R784

NRZ0065-103X

R756

D192

MA111-X

47k

R193

2.2k

4.7/50

C179

C189

4.7/50

2.2k

Q161

Q162

BR24L16F-W-X

C733

470P

47K

10K

0

RA723

S-80833CNNB-G-W

C730

2.2k
47/6.3

C190

AUX.L

R713

2.2k

47K

1k

4.7k

4.7k

4.7k

3.9k

47K

0

C180

4.7/50

4.7/50

10k

R191

R192

IC722

R785

NAD0028-103X

4.7K

R760

47k

47k

R174

R184

CD4066BPW-X

100k

100k

TH721

4.7K

R761

R175

30k

30k

R185

IC162

R162

2.2k

Q_OUT

10K

4.7K

R762

RDSSCK

0.01

C731

30k

IC161

NJW1192V-X

30k

R161

2.2k

C170

10/16

PDET

R714

R712

SCLK

S2UDT

U2SDT

LCDCE

FSU

LEVEL

KEY2

KEY1

KEY0

D731

47k

1SS355W-X

R757

180k

R164

C191
1/50

22k

R194

0.1

C178

C176

0.0047

C188

C186

0.0047

0.1

R715

R716

TD RD

IC723

D194

RB160M-30-X

39K

.

R198

C163

2.2/50

C164

10/16

TU.R

R104

10k

103

R114

12

10k

47k

R844

AFS

SSTOP

RDSDA

1k

2.2K

1K

R719

R720

R845

R718

R745

10M

UCS

47K

R746

RESET

X722C729

R751

QAX0401-001

22P

27P

C728

BUSINT

Parts are safety assurance parts.
When replacing those parts make
sure to use the specified one.

2-12

LCD & Key control section (for KD-DV4203,KD-DV4204,KD-DV4205,KD-DV4206)

LCD1

QLD0386-001

S49

S50

S51

S48

S52

S42

S43

S44

S45

S46

S47

S36

S37

S38

S39

S40

S41

S30

S31

S32

S33

S34

S35

S24

S25

S26

S27

S28

S29

S18

S19

S20

S21

S22

S23

S12

S13

S14

S15

S16

S17

S6

S7

S8S9S10

S11

S1S2S3S4S5

COM1

COM2

COM3

R605

2.7K

S601

R610

2.7K

R615

2.7K 1.8K

R601

R602R603R604

1.2K

1.8K

S602

R608

R609

R614

S616

S617S618

820

820

S605S604S603

R606R607

8208201.8K 1.2K

S608

S609S610S611S612

R612R613

820

8201.2K

KEY2

S606

KEY1

S607

R611

KEY0

S613S614S615 D630

R630

D635 D647

330

R633

D637

D638

510

R634

470

R635

D633

820

330

470

R631

330

R632

470

R627

R628

470

R625

330

R626

D639

D640D631 D632

330

R636

330

R637

D643

D641

D642

510

R638

330

R639

D644

D645

D646

510

R640

470

R641

D648

330

R642

470

R643

D649

D650

330

R644

470

R645

2-13

IC681

RPM7338-V4

JS686

QSW0976-001

C682

D681

0.012

UDZW6.2B-X

C681

4.7/6.3

10K

R682

R681

470

S44

S45

S46

S47

S48

R661

2.2K

R662

D651

649

D652

650

D653

R649

330

470

R645

330

R646

R644

R670

470

Q670

D654

2SA1365/F/-X

R672

390

390

R650

Q671

RT1N141C-X

2.2K

R665

C663

0.022

LCDCE

R666

R667

LCDCL

LCDDA

R668

51K

D662

C662
680p

UDZW5.1B-X

R664

10K

47K

R671

R663

D661

180K

DIMOUT

C661

10/6.3

1SS355W-X

1K

S49
S50

S51

S52

COM1

COM2

COM3

INH

OSC

10K

CE

10K

CLK

10K

DATA

S2

S1

PT6523LQ-L

S3S4S5S6S7

S43

IC661

R687

47K

R688

47K

S37

S40

S41

S42

S38

S39

S9

S8

S11

S10

S12

100

R686

C687

0.022

0.022

QGZ1601K1-15S

C664

0.1

S33

S34

S32

S31

S30

S29

S28
S27

S26
S25

S24

S23

S22

S21

S20

S19

S18

S17

S16

S15

CJ601

ACC5V

REMOCON

ENC1
ENC2

DIMOUT

LCDCL

LCDDA

LCDCE

KEY0

KEY1

KEY2

VDD

C686

S35

S36

S13

S14

2-14

4

3

5

5

3

Main section (for KD-DV4207)

CN962

QGF0534F3-45X

CN963

QGB2027L9-30X

R401

CN961

QGB2027M3-30S

C909

100/16

SN74AHCT1G08V-X

470

TX

0.01

C403

NQR0007-002X

100

R962

D925

22p

CRS03-W

IC401

R405

0

K402

C401

C402

0.01

D924

CRS03-W

C969

0.047
COMPOSITE

R81

R91

C94

2K

100

2K

R72

RDSDA

RDSSCK

82p

DOUTMUTE

VMUTE

MUTE

PBRK

ANT

PON

TELMUTE

TELCONT

FAN

10K

R92

10k

R73

C416

0.01

R727

R729

R733

R717

R848

R736

R737

R738

R739

R758

R759

QGA2006C1-04

C155

0.47

10K

R82

C84

IC721

UPD784217AGC351

10K

R726

R735

0

5.6k

4.7k

R728

0

R731

2.2k

10K

220

220

2.2K

2.2K

VPP

4.7K

4.7K

220k

220k

CN101

R155

470

47K

R151

R723

47K

47K

R724

LEVEL

47K

R141

0.00470.0047

C141C151

DVDL

TU.L

DVDR

C102

22/16

LINE-L

C101
10/16

47k47k

R101R111

LINE-G

C111

10/16

LINE-R

C112

22/16

VOLDA

VOLCK

2.2k

2.2k

R722

R721

10k

10k

L721

R763

R765

SW4

SW1

VOL2

VOL1

47k

47k

47k

47k

47k

47k

R748

R747

R742

R749

R750

R743

470P

220/10

220/10

C724

C732

C725

C726

R199

220

UDZS5.1B-X

D195

100/10

0.01

C161

10k

10k

R113

10k

10k

820

R744

NQL38DK-330X

X721

8P

C727

0.22

C194

C162

R103

R112

RDSDA

2.2K

R845

R745

R746

QAX0617-001Z

27P

C728

R114

10k

AFS

1K

R720

47K

27P

RB160M-30-X

39K

R198

R104R102

10k

SSTOP

1k

R719

10M

UCS

RESET

X722C729

QAX0401-001

22P

D194

C163

2.2/50

C164

10/16

TU.R

47k

R844

R718

R751

BUSINT

C171

C181

R105

10k

R115

10k

C109

0.022

47k

R843

10k

2.2k

R753

33k

MA111-X

D193

C172

2.2/50

C182

2.2/50

QTE1H55-225Z

IC101

NJM4565V-X

47k

47k

R842

R841

R754

REMOCON

R755

10k

VDD

GND

22k

R752

HANDLEREM

2SC3928A/QR/-X

C193

0.047

C192

22/16

C177

2.2/50

QTE1H55-225Z

C187

2.2/50

R106

R116

C110
47/16

LCDCL

3.9K

3.9K

5W_FLAG

R846

R847

2.2k

LCDDA

Q191

R195

12k

R164

47

R196

1k

R197

0.1

C175

C174

R172

C176

C173

22/16

4.7k

470p

R171

39k

R181

39k

C186

C184

C183

470p

22/16

4.7k

R182

0.1

C185

C10

2.2/

C103

47/6.3

R107

10k

10k

C11

47/6.

R117

10k

10k

C11

2.2/

S723

QSW1049-001Z

TU1
QAU0453-001

J1

QNB0190-001

0

B1

0.22u

L2

R2

1.2K

L1

4.7u

D2

D1

C2

TOTX177L

R403

470

10

R402

1

R404

K401

NQR0007-002X

L401

C404

100/6.3

D401

CRS03-W

NQR0007-002X

SCS

SN74LVC32APW-X

0.1/16

C966

D923

CRS03-W

C961

220/10

C968

0.047

DVDL

DVDR

SW1

SW4

IC921

BA33BC0FP-X

D921

1A3G-T1

C921

C922

100/10

220/10

KEY0

KEY2

KEY1

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

D701

D702

D703

0

2p

C405

C925

220/10

LCDCE

0.1

C1

R1

1SS355W-X

1SS355W-X

SW_FLAG

R19

47K

IC402

220/10

0.047

C411

C412

22p

0.01

C406

S2UDT

LCDCL

270

R704

L924

QEXF1AM-476Z

ENC1

ENC2

10K

270

R706

R705

C963

220/10

0

B922

NQL56CK-220X

470/25

C926

PDETACH

REMOCON

CPURST

R973

R974

R975

C911

0.001

C927

R707

10K

IC961

LCDDA

FSU

IC411

MM1510XN-X

6.8K

R412

COMPOSITE

10K

10K

10K

L927

NQLB7GM-100X

L925

NQL71EM-330X

0.1

C928

D704

D705

D706

D707

D709

D710

C701

C702

D711

C413

180

R417

C967

0.1/16

C962

220/10

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

MA8062/M/-X

0.1

0.1

MA8062/M/-X

R9

47K

NQL114K-470X

1.5

BD9781HFP-W

R923

39K

390k

RB051L-40-X

D922

R926

R3

R10

L411

D906

RT1N141C-X

IC922

R5

1.2K

SSTOP

4.7K

R914

220

UDZW12B-X

R925

0.1

C930

R6

0

SDA

R11

4.7K

C414

330/6.3

R414

SN74HCT32APW-X

R910

Q904

C929

4700P

150K

10K

R924

0

SCL

1K

R7

47k

0.01

C4

R413

10

IC962

Q903

2SA1530A/R/-X

R909

2.2K

R927

47K

47/16

C5

K411

R12

4.7

R415
75

R416

0

NQR0201-004X

D411

VIDEO-OUT

47K

R928

C93

4.7/50

UDZW12B-X

47k

C83

4.7/50

R8

R4

1K

0.1

0.047

0.1

220/10

C8

C7

C6

C9

R13

6.8

Q_OUT

IC71

UCS

SCLK

U2SDT

LRMUTE

RA962

100

Q2

C74

560p

LC72725NM-X

NRZ0065-222X

R725

0.047

220/10

C723
470P

LRMUTE

SDA

SCL

SCS

CPURST

RT1N141C-X

AFS

0.01

47/6.3

C75

47K

C721

C722

R14

C73

330P

C72

0.01

C76

C77

QAX0263-001Z

0.01
C997

C999
100P

22K

22K

12K

R15

R71

10/16

C71

47p

C78

X71

C415
100P

2-15

CN701

QGZ1601J1-15

C171

C164

C163

C181

R105

10k

R115

10k

C109

0.022

47k

R843

10k

2.2k

R753

33k

MA111-X

D193

C172

2.2/50

C182

2.2/50

IC101

NJM4565V-X

47k

47k

R841

R842

REMOCON

R755

10k

VDD

GND

HANDLEREM

2SC3928A/QR/-X

C193

0.047

C192

22/16

C177

QTE1H55-225Z

C187

QTE1H55-225Z

C110
47/16

3.9K

5W_FLAG

R846

2.2k

R754

22k

R752

2.2/50

2.2/50

R106

R116

LCDCL

3.9K

R847

LCDDA

Q191

R195

D191

MA111-X

MA111-X

R193

R173

2.2k

0.1

0.1

2.2k

R183

NI

Q161

RT1N141C-X

Q162

RT1N141C-X

C733

SCK

R779

R778

R777

R776

R775

R774

R771

R770

R766

R768

R767

R784

RA723

NRZ0065-103X

R756

D192

47k

C180

4.7/50

4.7/50

C179

C190

4.7/50

C189

4.7/50

AUX.L

IC722

BR24L32F-W-X

470P

R713

10k

2.2k

47K

1k

4.7k

4.7k

4.7k

3.9k

47K

47K

0

10K

0

R760

S-80833CNNB-G-W

C730

2.2k
47/6.3

R191

47k

R192

R174

100k

R785

NAD0028-103X

4.7K

R761

47k

R175

30k

30k

R185

R184

IC162

CD4066BPW-X

R162

2.2k

100k

Q_OUT

10K

TH721

4.7K

4.7K

R762

RDSSCK

0.01

C731

30k

IC161

NJW1192V-X

30k

R161

2.2k

C170

10/16

PDET

R714

R712

SCLK

S2UDT

U2SDT

LCDCE

FSU

LEVEL

KEY2

KEY1

KEY0

D731

47k

1SS355W-X

R757

12k

180k

R164

C191

1/50

47

R196

22k

R194

1k

R197

0.1

C175

C174

R172

C176

C178

0.0047

C173C183

22/16

4.7k

470p

R171

39k

R181
39k

C188

C186

C184

0.0047

470p

22/16

4.7k

R182

0.1

C185

B101

C104

2.2/50

C103
47/6.3

R107

10k

10k

C113
47/6.3

R117

10k

10k

C114

2.2/50

R715

270

270

R716

TD RD

IC723

S723

QSW1049-001Z

BUSSCK

BUSSO

SI/SO

VIDEO-OUT

1SS355W-X

0

0

B105

B104

VOLDA

VOLCK

NI

B102

CHR

CHL

0.01

C169

470

R781

D782

1SS355W-X

Q783

RT1P141C-X

C783

D781

D783

100/16

UDZW11B-X

I/O

L722

QQL244J-470Z

D903

1SS355W-X

Q976

R976

RT1N441C-X

C356

4.7/25

D354

1SS355W-X

D344

0

0

B103

B106

1SS355W-X

1SS355W-X

Q977

2SA1530A/R/-X

56k

4.7/25

R307

R304

D302

47/6.3

R977

18k

R354

2.2k

R344

2.2k

C346

Q781
RT1P141C-X

C781

C910

0.001

R343

R337

0

0

R357

R347

0

R327

0

RT1N141C-X

MUTE

R353

4.7K

R355

47k

R891
47K

47k47k

R345

47K

R358

47K

R328

Q303

TELMUTE

10/16

C903

R802

47K

C802

22P

47K

R338R348

47K

D851

Q891
RT1N141C-X

22/16

C904

1K

1K

C338

0.47

0.47

0.47

CRS03-W

RT1N141C-X

100/10

C905

SI/SO

R805

100k

22K

C358

C348

C328

0.47

TELCONT

47/16

C906

10k

R804

R803

R801

100

R305

CRS03-W

Q892

KTD1304-X

10K

BUSSO

Q354
KTD1304-X

Q344

R339

1K

R359

1K

R349

1K

R329

1K

D852

R892
1K

D891
MC2836-X

R893

3.3k

IC901
R2S25400DS-E

0.01

C907

ANT

I/O

SN74AHC126NS-X

R356

100

R346

TB2904HQ

C891

0.1

220/10

C908

J331

0.022

C430

L901

1N5401-F64

CN821

CN831

CN901

QNN0770-001

QNZ0607-001

C355

100P

C345
100P

100

IC301

R340

1K

R360
1K

100P

100P

R306

C317

0

C339

C359

100P

100P

R350

C329

1K

C349

R330

1K

R302
0

C314

2.2/50

C851

0.1

4.7K

R851

R885

47k

C892

0.1

PBRK

L902

NQL56CK-220X

PON

IC801

1/50

C330

0.1

4.7/50

C315

D885

1SS355W-X

R886

4.7k

Q885

RT1N141C-X

C803

0.047

0.01

C313

C303

C304

C305

R887
10k

C885

10/16

0.047
22/16

C913

C912

BUSINT

BUSSCK

R806

100K

R807

330

R808
22k

R809

100

C804

R810

22P

47K

C311

4.7/25

C312

47/16

C350

C360

0.1

C306

R902

R903

SCK

0.1

C308

C307

D305

D308

CRS03-W

CRS03-W

D981
CRS03-W

C981

0.1

D982

CRS03-W

C801

R823

22K

FAN

HANDLEREM

22P

R821

9.1K

4.7K

Q301

RT1N441C-X

C318

1/50

C316

0.01

0.01
C302

C902

2.2/50

C340

0.1

C310

C309

R981

R982

2.2K2.2k

CHL

CHR

J801

QNZ0095-001

SI/SO

SCK

D801

CRS03-W

Q821

RT1N141C-X

R832
270

2SC4485/ST/-T

470

R822

C823

D821

NQR0007-002X

UDZW6.2B-X

10

Q302

RT1P441C-X

D301

R901

1k

TEL

0.01

Q822

UDZW12B-X

C821 C822

10/16

K831

D831

UDZW11B-X

0.1

C889

Q823

10/16

C301

3300

RT1P141C-X

0.022

C331

47/16

QQR1378-002

C901

D901

QGA2001C1-02

QGA2006F1-02

C831
100P

D194
0M-30-X

2.2/50

10/16

TU.R

104

0k

47k

R844

R718

R751

BUSINT

Parts are safety assurance parts.
When replacing those parts make
sure to use the specified one.

2-16

LCD & Key control section (for KD-DV4207)

2

LCD1

S601

R605

2.7K

QLD0386-001

R601

R602R603R604

1.2K

1.8K

S602

R609

R610

2.7K

R608

820

820

S606

S605S604S603

R606R607

8208201.8K 1.2K

S608

S609S610S611S612

S607

R630

S49

S50

S51

S46

S47

S48

S52

820

S40

S41

S42

S43

S44

S45

S39

D641

D633

D635 D647

D637

D638

D639

D640D631 D632

D643

D642

D644

D645

D646

D648

COM3

COM2

COM1

D649

D650

D651

D65

S1S2S3S4S5

S6

S7

S8S9S10

S11

S12

S13

S14

S15

S16

S17

S18

S19

S20

S21

S22

S23

S24

S25

S26

S27

S28

S29

S30

S31

S32

S33

S34

S35

S36

S37

S38

R615

2.7K 1.8K

S617S618

R614

S616

R611

R612R613

8201.2K

820

S613S614S615 D630

470

470

R631

330

R632

R627

330

R628

470

R625

330

R626

R633

470

330

510

R634

R635

330

R636

330

R637

510

R638

330

R639

510

R640

470

R641

R642

470

R643

330

R644

470

330

R645

R646

330

IC681

S3

RPM7338-V4

JS686

QSW0976-001

C682

D681

0.012

UDZW6.2B-X

C681

10K

S49
S50

S51

S52

COM1

COM2

COM3

INH

OSC

CE

CLK
DATA

4.7/6.3

S47

S48

S2

S1

470

R681

S44

S45

S46

PT6523LQ-L

S3S4S5S6S7

R682

S1

S2

COM1

COM2

COM3

R661

2.2K

R662

D649

D647

D650

D648

330

R642

470

R643

330

R644

470

R645

D651

D652

330

R646

R649

D653

R670

470

Q670

D654

2SA1365/F/-X

R672

390

390

R650

Q671

RT1N141C-X

2.2K

R665
51K

LCDCE

LCDCL

LCDDA

0.022

C663

R666

R667

R668

10K

10K

10K

D662

C662
680p

UDZW5.1B-X

R664

10K

47K

R671

R663

D661

180K

DIMOUT

C661

10/6.3

1SS355W-X

1K

S43

IC661

R687

47K

R688

47K

S37

S40

S41

S42

S38

S39

S9

S8

S11

S10

S12

100

R686

C687

0.022

C686

S35

S36

S13

S14

0.022

C664

0.1

S33

S34

S32

S31

S30

S29

S28
S27

S26
S25

S24

S23

S22

S21

S20

S19

S18

S17

S16

S15

QGZ1601K1-15S

CJ601

REMOCON

DIMOUT

ADD5V

ENC1
ENC2

LCDCL

LCDDA

LCDCE

KEY0

KEY1

KEY2

VDD

R379

NI

01/16

MA9

DRVCONT

DVD servo control section (common)

IC398

SG32M90TFIR3

EXADT15

EXADT14

EXADT13

EXADT12

EXADT11

EXADT10

EXADT9

EXADT8

EXADR19

EXADR20

NEXWE

/FL_RST

NI

R398

R396

47k

EXADR18

EXADR17

EXADT7

EXADT6

EXADT5

EXADT4

EXADT3

EXADT2

EXADT1 EXADT0

TP23

TP21

TP20

0.1/16

TP8

TP7

TP36

TP35

TP37

SW3

L-END

TP14

TP15

TP16

TP17

TP18

TP19

VREFH

HAGUP

RF+

LPC2

RF-

LPC1

E

F

C

D

A

B

CD/DVD

K102

R101

0

T+

F-

T-

F+

TP9

TP11

TP12

TP10

SM3

SM2

SM1

H3-

H3+

VH

H1+

H1-

H2+

H2-

B201

NI

SW1

B202

NI

SW2

B203

NI

SW3

B204

NI

SW4

B205

NI

TRVSW

DGND

NQR0007-002X

10k

2SC4617/R/-X

R260

C269

Q107

D5V

R233

47

NI

100k

R129

M5V

R201

M8V

R231

2.7k
R235 R234

0

6.8k 390k

SBRK

SBRK

M8V

C252

MGND

C396

0.1/16

NI

NI

NI

R121

R124

C109

R122

R123

0

0

R119

R120

0

0

91

R126

R127

R128R130

10k

Q105Q106

2SK3019-X2SK3019-X

F-

F+T-T+

NI

NI

1

C208

C207

C201

C202

0.1/16

100/16

IC201

BA5835FM-X

C211

C212

100/16

0.1/16

NI

C209

R232

15k

Q231

DTC114EE-X

MGND

0.047

C254

10/10

0.1/16

0.1/16

C253

C265

0.1/16

C256

C266

BD6671FM-X

SPDRV

100/16

R259

R252

0

R257

10k

C255

C267

0.01

0.1/16

/SPMUTE

/SPMUTE

SPDRV

CN101

TP201

TP202

CN201

QGF1038F2-11X

C113

0.1/16

C104

TP1

QGF0501F8-30X

0.1/16

C103

TP3

TP2

TP51

TP52

TP31

TP41

CN202

QGF0523F2-05W

SW4SW5

NSW0184-001XNSW0183-001X

TP25

TP24

K101

NQR0007-002X

0.1/16

TP5

TP4

TP33

TP32

TP39

TP40

SW1

SWGND

TP22

C112

TP6

TP34

TP38

SW2

REST

P3.3V

K399

EXADR16

R399

0

EXDAT15

EXDAT7

EXDAT14

EXDAT6

EXDAT13

EXDAT5

EXDAT12

EXDAT4

EXDAT11

EXDAT3

EXDAT10

EXDAT2

EXDAT9

EXDAT1

EXDAT8

EXDAT0

NEXOE

R397

NI

NEXCE

DVDLDCUR

NI

C110

12

R105

R104

3k 3k

2SB1424/R/-W

91

Q102

2SC4617/R/-X

2.4k
C102

R103

0.1/16

C203 C204
270p 150p

R203

30k

R221

MGND

C221

0.022

H3-

H3+

0

R253

C257

IC251

10k

0.47

R251

NQR0502-001X

C399

0.1/16

C397

MDQ0

22/6.3

0.1/16
MDQ1

C392

MDQ2

MDQ3

MDQ4

0.1/16
MDQ5

C391

MDQ6

MDQ7

C398

DQM0

0.1/16

NWE

NCAS

NRAS

NCSM

BA0

BA1

MA10

MA0

MA1

MA2

C395

0.1/16

DGND

LPCO1

CDLDCUR

0

R110

C106

470

R108

47/10

2.2

R112

R106

R107

1k 1k

Q101

2.4k

R111

330

R109

TDRV

R205

27k

FDRV

R204

27k

R202

47k

15k

R219

R220

18k

C213

0.1/16

TRSDRV

R222

10k

R223

10k

0

H1+

H2-

H2+

H1-

0.001

0.001

0.001

C258

C259

R256

47

R254

10k

NI

NI

C261

C260

C264

20k

R255

C251

C263

0.01

0.1/16

R113

2SB1424/R/-W

2SC4617/R/-X

C111

0.1/16

VHALF2

SM1

SM2

SM3

NI

C262

K4S281632F-UC75

IC399

DQM1

MDQ7

MDQ8

C1

0.1/16

C2

0.1/16

0.1/16

C3

0.1/16

C4

0.1/16

C5

0.1/16

0.1/16

C6

C7

0.1/16

R304

R323

C481

NI

0.1/16

C380

0

0

330

330

NI

R387

IC304

100k

R309

0.1/16

BR93L66F-W-X

MDQ6

C21

0.1/16

100

0

100

R386

R353

R354

NI

TUBUYAKI

10k

R381

R370

NI

R324

C310

1000p

IC481

R320

SCS

SCLK

S2UDT

U2SDT

SACK

EPDO

EPDI

EPDI

MDQ15

MDQ14

MDQ13

C393

MDQ12

0.1/16

MDQ11

MDQ10

MDQ9

C394

MDQ8

NI

C384

DQM1

0.1/16

MCK

MA11

MA9

MA8

MA7

MA6

MA5

MA4

MA3

S5V

LPCO2

0

1

R125

R118

ADS5V

C108

470

R116

47/10

12

2.2

R114

R115

Q103

Q104

R207

0

R206

0

VH

NI

C105

47/10

330

R117

DGND

/DRVMUTE

TRDRV

FODRV

VHALF

NI

R210

0

R211

TRSDRV

1k1k

DRVCONT

R384R385

/FL_RST

1/16

C371

LM

FG

FG

EXADR20

NEXWE

EXADT0

EXADT4

EXADT8

EXADT12

EXADR16

EXADR18

EXADT14

EXADT10

EXADT6

EXADT2

NEXCE

EXADT1

EXADT5

EXADT9

EXADT13

EXADR17

EXADR19

EXADT15

EXADT11

EXADT7

EXADT3

NEXOE

MDQ9

MDQ5

MDQ10

MDQ4

MDQ11

MDQ3

MDQ12

MDQ2

MDQ13

MDQ1

MDQ14

MDQ0

MDQ15

DACPDN

DACOCS

DCLK

DDATA

P3.3V

C307

R321

0

R322

R372

R373

EPCS

EPSK

EPDI

EPDO

C8

0.1/16

DGND

NI

1k

R310

R388

NI10k

R389R390

S-80827CNNB-G-W

EJREQ

10k

R481

EPCS

EPSK

DACPDN

DACOCS

DCLK

DDATA

MCK

NWE

DQM0

C20

0.01

C222

NI

1k

R380

R371

FG

CPURST

PCMCLK

BCK

AOUT3

LRCLK

10k

R224

TRSDRV

NCSM

NRAS

NCAS

27

R303

C19

0.1/16

10k

R258

NININI

NI

C268

0.015

R378

R376

R377

22k

R308

NI

R374

CD/DVD

SPDRV

HAGUP

LM

/DRVMUTE

/SPMUTE

TRVSW

PCMCLK

BCK

AOUT3

LRCLK

330p

C403

47k

DCLK

R404

DDATA

2-17

NI

C303

47/6.3

TP321

D3.3V

D3.3V

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

0

NQR0022-005X

0

NQR0022-005X

NQR0022-005X

VGND

B601

NQR0022-005X

R604

NI

R602

NI

C603

NI

NI

NI

NI

NI

D3.3V

0

0

R355

R356

NI

D3.3V

FG1

FG2

NI

NINININI

K420

K421

K422

K423

K424

K434

K426

K430

K431

K432

K433

0.1/16

DGND

NQL044K-100X

0.1/16

DGND

R21

NI

R22

NI

CN402

QGF0522F3-06W

C22

NI

C23

NI

R23

NI

R24

NI

CN403

QGF0534F3-45X

TP417

C453

0.1/16

L451

C451

0.1/16

C452

TP416

TP420

TP422

TP425

TP426

TP427

TP428

TP429

TP430

TP431

TP432

TP433

TP434

TP435

TP436

TP437

TP438

TP439

TP440

TP441

TP442

TP444

TP446

TP448

TP452

TP453

TP455

TP457

TP322

TP323

TP324

NI

NI

NI

NI

NI

NI

C454

S3.3V

S5V

0

DGND

D5V

M5V

M8V

MGND

R300

P3.3V

MCK

NWE

DQM0

DQM1

C20

NI

0.01

C222

R381

R320

NI

1k

R380

R371

FG

CPURST

S2UDT

10k

R224

TRSDRV

NCSM

NRAS

NCAS

27

R303

C19

0.1/16

10k

R258

NININI

C268

0.015

R376

R377

22k

R308

NI

R374

HAGUP

CD/DVD

SPDRV

/DRVMUTE

/SPMUTE

TRVSW

MA8

MA9

BA0

BA1

MA11

C18

0.1/16

0.1/16

TP313

0.1/16

C308

C309

0.1/16

NI

NI

NI

NI

R382

R383

R378

R379

100

100

47k

NI

R329

R328

R349

R331

DRVCONT

LM

Q302

SW3

SW4

MA1

MA6

MA0

MA7

MA10

C17

C16

0.1/16

0.1/16

IC301

MN2DS0003AA-H

TP312

TP302

TP303

TP309

TP308

TP307

P3.3V

NI

100

100

47k

47k

47k

R327

R326

R348

R347

R346

R330

Q301

SW2

SW1

DTC144EE-XDTC144EE-X

MA3

MA4

MA2

MA5

C14

C15

0.1/16

0.1/16

C335

0.1/16

TP306

C331

0

R314

UCS

C330

0.033

0.1/16

0.1/16

C333

C332

0.1/16

C337

0.018

C338

C334

0

0.0056

0.1/16
R313

C359

DGND

EXDAT13

EXDAT2

EXDAT14

EXDAT1

EXDAT15

EXDAT0

C13

0.1/16

TP315

TP314

0.1/16

0.1/16

C320

C321

0.1/16

0.1/16

C348

C350

5p

5p

C358

150

150

R363

R364

RF+

RF-

EXDAT11

EXDAT5

EXDAT10

EXDAT6

EXDAT9

EXDAT4

EXDAT12

EXDAT3

C12

0.1/16

0.1/16

C349

0.1/16

0.1/16

0.1/16

0.1/16

0.1/16

C322

C323

C319

C347

C314

0

R312

EXDAT7

0.1/16

C11

EXDAT8

C10

0.1/16

TP325

C315

0.1/16

R392

100

C311

NQL093K-1R8X

L306

L307

NQL093K-1R8X

R305

NI

0.1/16

C9

L305

NQL093K-1R8X

0.1/16

C313

0.1/16

C339

R325

180

C342

NI

1/16

C341

R340

30k

R350

180

R359

180

R360

180

20k

R208

22k

R209

C356

1/16

C317

0.1/16

0.1/16

C316

VHALF

1/16

1/16

C324

C340

VREFH

VHALF

LPCO2

LPC2

LPCO1

LPC1

K301

NQR0502-001X

C302

C305

0.1/16
47/6.3

D1.2V

NI

9102k

R365R366

C368

C369

47/6.3

1k

1k

22k

22k

R306

R307

R319

R317

R369

NI

R367

K425

NQL093K-1R8X

K427

NI

K428

NI

K429

NI

R357

R351

1k

1M

R352

R362

0

NI

R344

VGND

K311

C318

0.1/16
NQR0129-002X

R342

NI

R341
NI

C312

1/16

NQL044K-100X
C206
560p

680p

C205

C336

0.1/16

1.6k

R333

150

R335

150

R334

150

R337

150

R336

R338

0

R339

0

R394

0

R393

0

C492

0.1/16
R493

22k

TH491

NAD0025-103X

5.1k

C491

0.1/16

TP491

NI

C343

NI

C344

NI

C345

NI

C346

R301

NI

C367

TP320

NI

R361

R358

0

C325

X351
NAX0730-001X

C326

R345

0

R315

0

R316

0

L303

R318

3.3k

R491R492

10k

IC303

0

NI

0

NINI

C361

C362

IC302

BA00HC5WF-X

1/16

R332

1k

C366

TP317

TP319

TP316

TP318

NQL093K-1R8X0.1/16

AOUT3

0

BCK

LRCLK

10p

10p

PCMCLK

NI

L302

FODRV

TRDRV

ADS5V

DVDLDCUR

CDLDCUR

B

A

D

C

F

E

S3.3V

NI

L301

C301

220/6.3

DGND

EJREQ

UCS

SCS

SACK

SCLK

U2SDT

S2UDT

CPURST

LRMUTE

A5V

A9V

L-CH

AGND

R-CH

R302

NI

C360

C365

C364

0.1/16

K401

K402

K403

K404

K405

K406

K407

K441

K442

K443

K444

R441

K445

R442

SW4

K451

SW1

K452

K601

NI

0

R606R605

C602

NI

0

L601 L602

C601

R603

R601

DACPDN

DACOCS

DCLK

DDATA

PCMCLK

BCK

AOUT3

LRCLK

LRMUTE

R538

R535

10

PCMCLK

BCK

AOUT3

LRCLK

330p

C403

47k

IC401

AK4385ET-X

DCLK

R404

DDATA

R401

C402

47/10

C401

0.1/16

R402

0

R403

C404

NI

C405

0.047

DGND

C531

4.7k

0.0033

R531 R534

4.7k 200

4.7

R431

4.7k 200

R435

4.7k 4.7k

R533

R433

22k22k

NJM4580V-X

470p

4.7k

R532

C532

IC411

R432

C432

470p

4.7k

R434

C431

0.0033

22k

R537

4.7k

R536

C533

200

470p

C522

47/10

C521

0.1/16

C421

0.1/16

C422

C433

R436

470p

C412

47/10

200

R437

R438

22k

47/10

C411

0.1/16

A5V

L-CH

R522 R521

AGND

R422

1k 1.2k 1.2k 1k

R421

R411

A9V

10

R-CH

2-18

Printed circuit boards

Main board

IC921

C922

C927

R929 R930
C931

R928

R926

R924

C929 C930
R925

C928

R735

R927

R747

R749

IC922

R750

R748

S723

D922

R743

R759

R758

R742

CN701

C926

R765

L925

R763

R739
R738

IC723

R923

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

(Main board)

L902

C909

C921

L927

D921

B922

C925

L924

R731

R973

R733

R737

R729

R974

R736

R734

C724

C730

R728

R727

R972
B962

B963

C966

IC721

L721

R760

R761

R762

R805
C803

C732

X71

R73

C73

C72

R71

R72

C71

R975

C722

X721

X722

R744

C726

C727

R745

R746

C728

C729

R755
R756

C731

R757
D731

D701
D702
D703
D704
D705
D706
D711
D707
D709
D710

C702

C701

R707

R704
R705
R706

C912

R754
R845

C907

C723

R753

IC961

C77C78

CN961

L722

R752

C74

R414

R785
TH721

C76

B923

C999

C911

C969

C413

C415

R412

C416

R417

IC411

B961

C721

R803

R804

IC71

R15

R14

C75

R801

L411

C412

R413

C411

C414

R771

R774

R775

R766

R767

R784

RA723

Q892

Q891

R891

C725

R751
R726
R725

R722
R721

R779

R846
R847
R768
R717
R848

R806
R807

R809

C804

C7

IC801

C802

R802

Q2

C9

R4

R8

C8

C6

forward side

IC901

D923

D925

D906

R914

C962

RA962

C963

D903

R714

R712

R713

R776

R777

R778

Q904

R173

C175

D192

R893

R171

R172

C174

R192

D891

R892

R720
R719
R716
R718
R715

IC722

R844
R842

C733

R843
R841

R808

R810

R12

R13

C84
R82

R81

C83

C93

C176

IC301

C305

C304

C306

C303

C313

R306

R902

Q191
R196
C193

C831

C162

R903

C173

R9

R901

CN831

R199

R3

D781

C302

R976
R977

C317

Q977

Q976

C315

C348

C906

C905

C328

R328

R348

R327

R347

R184

C179

R185

C180

IC161

C190

B103 B104

C189

C346

C192

D193
D195
C194
R198

R116

R117

R115

R105

R106 R107

Q781 Q783

C781

R1

R19

R2

R16

C783

R197

D194

C1

IC101

C356

R102

Q161
Q162

R330

C349

C329

C312

R349

C301

C314

C358

D302

C177

C187

C851
R851

C338

D852
D851
D981
C981

R338

D982

R358

R981
R982

R337

R357

R174
R175

D801

C892

D885

C889

Q885

B101

B105 B106

IC162

B102

C113

C103

R161

R162

IC401

R404

R401

C401

L401

C402

R103R104

K401

R402

D401

D354

D782

R781

D344

D783

B1
L2

D924

C913

B921

C968

C914
C915

R962

IC962

C902

C967

C904

C903

R910

Q903

R909

C172

C178

C161

C164

C182

C183

R181

R182

R191

C184

C186

C188

C185

R183

D191

R164

R193

R194

R195

C191

C171

D831

K831

C181

R832

C94
R92
R91

C5

R11

R5

R10

R6

C4
R7

R329

C109

R344

R887

R354

TU1

R350

L1

R302

C104

C339
C359

R886

R305

R885

C885

R339

C169

R340

C403

Q344

R304

Q354

R359

R405

D1

R360

C2

R307

C406

C309

C307

C308

C311

D308

D301
Q301

Q302Q303

C821

C822

Q821

Q822

R823

R822

C114

R112

C404

K402

C405

R403

R355 R356

R353

R346

R345

R343

J1

D2

R114

C310

C901

R415

C112

C102

R113

D821

C345

R416

C823

C355

C316

C824

R821

Q823

C331
C430

CN821

C111

D411

K411

C101

D305

C141

R111

C318

C801

C340

J801

C330

C360

C350

CN901

L901

D901

R101

C151

R155

C155

CN101

PP1

IC402

J331

2-19

(Main sub board)

C994

C995

R993

C991

CN962

CN963

C992

R991

R992

reversed side

(Main board)

CN901

D901

C318

C111

C101

Q823

CN821

IC402

C822

C901

IC301

C821

C404

C112

C102

C311

C114

C885

C301

C113

C103

C104

C187

C312

C177

C314

C358

C338

C356

C317

C315

C328

C348

C346

C906

C905

C179

C180

C190

C189

C192

J801

L901

CN101

PP1

R901

C173

C164

C191

C902

C904

C903

C183

IC901

C172

C161

CN961

C182

C963

C962

C411

C909

C921

D921

C413

C925

C414

C926

L722

VDD

C725

VPP

C722

X721

SCK

GND

RESET

RD

TD

X722

C730

C922

C927

S723

J331

J1

(Main sub board)

C181

C171

C5

C93

C7

C83

C732

X71

C912

CN701

C71

C75

CN831

C781

C783

TU1

2-20

Switch board

D635

S618

S601

D637

S614

IC681

R625
R626

JS686

D633

S612

D638

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

forward side reversed side

D650

R631

D649

R632

S615

D631

R630

D647

D632

D630

S617

S613

R649
R650

CJ601

Q670
Q671

D653D654

R670

R672

R646

C664

R671

R645

S616

D648

LCD1

R627

R628

S611

S609

D643

R603

S604

R601

R602

R640

S605

R635
R636

S602

D641

S610

D642

R605

R607

D644

R604

S603

D645

R639

D639

S608

R606

D646

D640

D654

D653

S607

S606

D652

D651

B661

C661

D662
D681

R661

R662

C662

R637
R638

R665

R664
R663
D661

R642

R643

R666

IC681

R644

IC661

R667

R682

R633
R634
R641

R668

R610

JS686

C663

R688
R681

C687

C682

R609

R686

C681

R608

C686

R611
R612
R613
R614
R615

R687

2-21

DVD servo board

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

Q103

R113

R105

R21

R112

R111

C111

forward side

C201

R201

C492

R492

TH491

R114

R115

R116

K102

C108

R106

Q101

C106

R104

C105

C102

R103

R125

R379

R312
R313

R378

C340

R253

R380

C260C261

C491

R354

R314

R353

C317

C264

R376

R255

R342
C318

R322

R340

R360

R350

R341

R321

R316

C339

R315

C313

R359

R344
R328

R327

C9
R362

R325

R326

L305

IC304

R386

R348

R346

C2

L306

R302

C380

R388

R330

R347

L307

C15

C21

R251

R233

R235

C253

C252

C254

C263

C262

C211

C213

R231

R232

R234

Q231

R377

R491

R493

R117

R118

Q104

R110

R363

C358

R364

C359

R109

Q102

R107

R108

C349
C330
C337
C338
C332
C334
C333
C331
C335

K399

C398

Q301

C18

C360

R310

L301

R361

R390

R303

C20

C397

R387

R300

R329

R305

R349

C305

K407

K402

R301

C301

R389

SW5

IC303

C361

K301

C366

R437

R438

C533

K445

IC411

C432

R434
R432

R422
C421

B204

C433

R436

C431

R433
R431

R435

SW4

C532

R535

R534
R532
R533

R522

R531

L451

C451

C521

C452

R442
R441

K452

K451

C454

R538
R537
R536

K430

K433

K444

C531

C453

K431

IC401

R345

K406

R331

K404

K405

K401

K403
K441

R355

R356

C302

K426

R357

R358

Q302

TP3

TP1

TP2

Q105
Q106
Q107

K427
K428
K429

K432

K425

TP439

TP20

reverse side

CN101

TP8

TP4

TP18

TP422

TP420

TP425

TP426

TP427

TP428

TP429

TP430

TP431

TP432

TP440

R22

C207

TP52

TP51

IC201

C209

K101

TP25

TP308

TP307

TP314

C208

C212

TP21

TP23

TP306

TP315

C22C23

R23

R24

C394

R481

R396

IC481

C481

EPDI

C384

IC398

C393

R323

R398

R309

R324

C310

R101

R397

C396

TP5

C103
C104

TP6

TP7

R374

TUBUYAKI

R258

C112

C113

R393
R394

TP24
R130

R335

R126

R334

R127

R337

R128

R336

R129

R338

TP16

R339

R120

R119

R121

R122

C109C110

R124
R123

TP10

TP11

TP12

TP14

TP22

TP15

TP17

R207
R206
R204
C204
R202

TDRV

R205

FDRV

C203
R203

C202

R223

R222

R221

C308

R382

TP303

R220

R219

C255

R210

R383

TP312

TP302

C256

R259

R257

R371

R211

R252

C309

LRMUTE

C319

R385

C371

C8

R304

R372
R373

R370

R381

R320

TP313

C350

C348

C314
C347

TP491

R384

C324

R333

R208

R209

C336

C205

C206

R318

SBRK

TP35

C266

C265

TP33

IC251

C267

TP31

SPDRV

/SPMUTE

R224

C222

C268

C323
C343
C320
C346
C345
C321

TP309

C322

C344

TP19

TP9

C221

T

R

S
D

R
V

C399

C7

R399

C316

C312

C341

C356

L302

TP34

TP37

C258

C257

C259

TP32

TP36

FG

R256

C251

R254

C391

IC399

C307

IC301

C392

C3C4C5

C6

C311

R351

L303

C325

TP40

TP41

X351

R352

C342

K311

TP38

C326

CN201

TP201 TP202

REST

C395

R308

B205

C1

DCLK DDATA

PCMCLK

C368

R366R365

CN403

C522

R401

K442

TP433

TP434

TP455

IC302

C402

TP452

AOUT3

TP437

BCK

TP438

TP323

TP442

C603

C269

C362

K420
K421

K422
K423
K424

TP448

TP453

TP457

TP444

R260

C369

TP417

R604

CN401

TP416

TP446

C367

R332

C17C19

C16

TP324

C13C14

TP322

TP321

C11C12

TP325

R392

K434

C315

C10

TP317

TP319

R367

R307
R306

R601

C601

R603

TP318

TP320

TP441

R319

R317

R369

K601

B601

L601

L602

C602

R602

TP39

R606R605

TP316

CN402

C365

TP435

C401

TP436

C364

R521

CN202

LRCLK

R421

B203

SW3

SWGND

L-END

C403

C404

R404

C405

R402

R403

C422

C412

K443

R411

C411

B201

B202

SW1

SW2

C303

Victor Company of Japan, Limited

Mobile Entertainment Business Group Mobile Entertainment Category 10-1,1chome,Ohwatari-machi,Maebashi-city,Gumma-ken,371-8543,Japan

(No.MA248SCH)

Printed in Japan

VPT
