Janome MC 6500P User Manual
Bring Home Professional Speed, Control,
And Creative Freedom
Sewing and quilting are meant to be calming and relaxing. But when you
see what you can do with a true professional-level machine, your pulse is sure
to quicken. The Memory Craft 6500 Professional is the fastest home
machine we’ve ever made with the largest bed and arm space and more
unique features for serious sewing.
»
EASY ON-SCREEN
STITCH
MANIPULATION
Four modes give
you customizing
power over 135
stitches, including
block and script
monogramming,
and seven
buttonholes.
» WIND YOUR
BOBBINS WITHOUT
UNTHREADING
The Bobbin Winding
Motor functions
independently of the
sewing motor,so you
don’t have to rethread in the middle
of your work.
»
SEW AT UP TO 1000
STITCHES PER MINUTE
Long seams will flash by
with perfect Janome stitch
quality.Run straight
stitches at up to 1000 spm.
The MC6500P can also do
Zig-zag at up to 700 spm.
» DON’T REACH FOR THOSE SNIPS
Janome’s first-ever Automatic Thread Cutter is
the ultimate time and motion saver.It can even
be programmed into the end of your stitch
combinations.
»
BIGGER IS BETTER
At 9”x 5” (225mm x 120mm),
it has the largest arm and
bed space of any household
sewing machine. And,it
comes standard with a
generous extension table for
even more room.
Features
• BACKLIT LCD SCREEN
• MAXIMUM SEWING SPEED: 1000 SPM/STRAIGHT;700 SPM/ ZIG-ZAG
• SPEED CONTROL LEVER
• ARM AND BED SPACE:9” X 5” (225mm X 120mm)
• VISIBLE PRESSURE GAUGE
• JAM-PROOF,MAGNETIC, TOP-LOADING,FULL-ROTARY HOOK SYSTEM
• INDEPENDENT MOTOR FOR BOBBIN WINDING
• AUTOMATIC THREAD CUTTER, WITH MEMORY CAPABILITY
• SUPERIOR FEED SYSTEM (SFS)
• EXTERNAL FEED BALANCING DIAL
• FRONT ACCESS FEED DOG UP/DOWN CONTROL
• 135 UTILITY AND DECORATIVE STITCHES
• BLOCK AND SCRIPT MONOGRAM STITCHES
• 7 ONE-STEP,SENSOR BUTTONHOLES
• ADJUSTABLE STITCH WIDTH FROM 0 TO 7MM
• ADJUSTABLE STITCH LENGTH FROM 0 TO 5MM
• INDIVIDUAL STITCH EDITING
• COMBINATION STITCH EDITING
• ELONGATION
» 135 STITCHES ACROSS FOUR MODES
The MC6500P stitch collection ranges from utility to decorative,encompassing beautiful quilting and heirloom
stitches, such as the unique French Knot.The selections are divided into four quick-access modes: Direct,Quilt, Utility,
and Monogramming.The Quilt Mode alone has 69 patterns to choose from, including 4 hand-look stitches.
• TURN OVER MEMORY
• RECALL MEMORY BANK
• RESUMPTION SET/LAST-STITCH RECALL
• AUTO-LOCK,LOCK-A-MATIC, AND NEEDLE UP/DOWN QUICK COMMAND KEYS
• VERTICAL THREAD DELIVERY SYSTEM WITH DUAL THREAD GUIDE BAR
• BUILT-IN NEEDLE THREADER
• 71 NEEDLE DROP POSITIONS (INCLUDING 15 LEFT TO RIGHT NEEDLES POSITIONS)
• EXTRA-HIGH PRESSER FOOT LIFT
• TWIN NEEDLE GUARD
• KNEE LIFTER
• EXTENDED SEAM ALLOWANCE GUIDE
• BEEP INDICATOR SHUT-OFF
• 14 STANDARD FEET:ZIG-ZAG, OVEREDGE, ROLLED HEM, ZIPPER,SATIN STITCH,
BLIND HEM, CORDING,OVERCASTING, 1/4” SEAM, DARNING,BUTTONHOLE,
QUILTING GUIDE,EVEN FEED, CRAFT (OPEN TOE)
• LARGE EXTENSION TABLE
• 10 LANGUAGES AVAILABLE ON SCREEN
• ELECTRONIC FOOT CONTROL
• SEWING LIGHT
• SOFT DUST COVER
www.janome.com
Professional Power Comes Home
» CUSTOMIZE
YOUR
STITCHES
Don’t see the
exact stitch you want? Then alter a preset stitch to create your own! Stitches
can be elongated, flipped and combined
with other stitches, then saved into the
Recall Memory Bank. Adjust stitch width
from 0 to 7mm. Adjust length from 0 to
5mm. Center needle and left needle
straight stitches can be programmed in
increments of 1, 3,or 5 stitches.
» SEVEN BUTTONHOLES
TO CHOOSE FROM
The MC6500P features
7 advanced Janome
buttonholes. Six are one-step, sensor
buttonholes – perfectly sized every time. The
seventh is an Automatic buttonhole,per fect for
bulky or other difficult fabrics that demand a
custom touch. Choose from square,rounded,
keyhole and more.
» TWO STYLES
OF LETTERING,
IN TWO SIZES
Select Block or Script
in 5mm or 7mm and enter up to 50
characters. Each alphabet includes capital
and lower case letters, and alternate letters
used in foreign alphabets.
The Memory Craft For Serious Sewing
The Memory Craft 6500 Professional is a step up from the usual home
sewing machine. It provides the speed and precision critical to advanced sewing.
In fact, everything about the MC6500P is designed to help you complete your
projects faster and with better results —
whatever type of sewing you’re interested in.
Quilting is a breeze with the knee lift, extra
large arm and bed space,and easy-access to
drop or raise the feed-dogs.Features like the
Visible Pressure Gauge and precise speed
control make garments come together with an
expert finish. Blazing stitch speed and
the awesome specialty stitches will
help you get more home dec done in
less time. If you’re serious about sewing,
this is your machine.
» JANOME STITCH QUALITY
From automatic buttonholes to the
French Knot, all your stitching will have
beautiful Janome quality.The
» BUILT FOR SPEED
With a straight stitch
speed of up to 1000
stitches per minute,
the MC6500P is the
fastest home sewing
machine we’ve ever
made, which means
you can finish what
you start quickly and
easily.
»
AUTOMATIC THREAD CUTTER
Now there’s no need to stop, lift the presser foot,and manually
cut your thread tails. A Quick Key directly above the needle
engages the Automatic Thread Cutter and accurately snips your
thread.You can also program the machine to clip your thread at
the end of a custom stitch sequence.
combination of a powerful motor and
precision gearing gives you accurate,
professional grade stitching at any
speed, on any fabric.
Exercise Your Freedom To Create
You have the speed. You have the control. You have the freedom to
create projects that turn out exactly the way you want.
» BRIGHT LCD SCREEN
»
QUICK-FLIP STITCH CHART
All 135 stitches are easy to find on a clever flip
chart that folds up from the back of the machine.
« PRESSURE REGULATOR WITH
VISIBLE PRESSURE GAUGE
Sometimes bulky layers of fabric
need more pressure from the
foot; sometimes sheer fabrics
need less.The MC6500P lets you
control how firmly the foot is
pressing on your fabric.The
Visible Pressure Gauge shows
you the exact position of your
ideal setting so you can get the
same results every time.
« HANDY SHORTCUTS AT YOUR
FINGERTIPS
Automatic Thread Cutter,Needle
Up/Down, Lock Stitch and Reverse
Quick Keys are all within easy
reach right above the sewing
area. Plus,the Automatic Thread
Cutter and Needle Up/Down keys
have indicator lights,so you never
have to guess if they’re turned on.
« EASY NEEDLE THREADER
Another great time-saving
feature to get you sewing
faster.Just push down the
lever,loop the thread
through, release,and you’re
ready to sew.
» MORE NEEDLE POSITIONS
Janome is known for precision stitch
quality,but the MC6500P takes it to
the next level. With 71 total needle
drop positions (including 15 left to
right needles positions), your
decorative stitches have the detail
and quality you expect and deserve.
» DUAL THREAD GUIDE BAR
Accommodates a variety of
spool types and sizes.
» KNEE LIFTER
It lifts the presser foot while leaving the needle in place so you can
keep your hands on your work. A favorite feature of quilters, it’s also
very useful for garment and home dec projects. And just in case you
accidentally bump the lift while you’re sewing,the MC6500P has a
built-in safety feature that stops the machine and gives you a warning,
so you don’t break a needle or ruin your project.
» INDEPENDENT BOBBIN WINDER
Now,when you need to wind
another bobbin, you don’t have to
stop and unthread the machine.
The MC6500P is the first Janome
with an Independent Bobbin
Winding Motor.Wind your bobbin
while you keep sewing.
» ERGONOMIC AND
INTUITIVE DESIGN
Easy-access, raised keys and
a bright, clear LCD screen
give you efficient
navigation through all the
machine’s operations.Press
a key and the screen
displays everything you
need to know about the
stitch or function. Giant
stitch diagrams pop up to
confirm your stitch
selection. For additional
information or options,
simply press the Help key.
9” x 5”(225mm x 120mm)
»
The largest arm and bed space of
any household sewing machine.
» EASY ACCESS FEED DOG CONTROL
For quilting or other free-motion sewing,you can quickly
drop the feed dogs.The lever is right on the front of the
machine.
»
TWIN NEEDLE GUARD
Automatically sets and prevents
decorative stitch widths from
being set too wide for Twin
Needle applications
»
TURN-OVER MEMORY
