Jabra JXO Bluetooth Headset User Manual

www.jabra.com

Bluetooth® Headset

User Manual

www.jabra.com

© 2006 Jabra, GN Mobile A/S (GN Netcom A/S). All rights reserved. Jabra®
is a registered trademark of GN Mobile A/S (GN Netcom A/S). All other
trademarks included herein are the property of their respective owners.
The Bluetooth® word mark and logos are owned by the Bluetooth SIG,
Inc. and any use of such marks by GN Mobile A/S (GN Netcom A/S) is
under license.
(Design and specifications subject to change without notice)

Fig. 1

Fig. 3

Fig. 2

Fig. 5

Fig. 6

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Fig. 4

1

English

English

Thank you. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

1. Charge your headset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

2. Turn your headset on and off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

3. Pair it with your phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

4. Wear it how you like it . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

5. How to . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

6. What the lights mean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

7. Using a Jabra Bluetooth adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

8. Troubleshooting & FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

9. Need more help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

10. Taking care of your headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

11. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

12. Certification and safety approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

13. Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2

English

3

English

!

Thank you

Thank you for purchasing the Jabra JX10 Bluetooth® Headset. We hope you enjoy it!
This instruction manual will get you started and ready to make the most of your headset.

Remember, driving comes first, not the call!

Using a mobile phone while driving can distract you and increase the likelihood of an
accident. If driving conditions demand it (such as bad weather, high traffic density,
presence of children in the car, difficult road conditions), pull off the road and park
before making or answering calls. Also, try to keep conversations short and do not make
notes or read documents.

Always drive safely and follow local laws.

About your Jabra JX10

1. LED light

• Blue indicates mode (pairing, active or standby)

• Red/green indicates battery level (low, charging, or charged)

2. Volume up (+), volume down (-)

3. Charging socket

4. Pairing button – press until the

LED light turns solid blue to put
the headset in pairing mode

5. Answer/end button

• Press to turn headset on

(blue flash burst indicates success)

• Press and hold to turn headset off

(blue flash burst indicates success)

• Tap to answer or end a call

1

What your headset can do

Your Jabra JX10 lets you do all this

• Answer calls

• End calls

• Reject calls*

• Voice dialing*

• Last number redialing*

• Call waiting*

• Place a call on hold*
*Phone dependent

Specifications

• Up to 6 hours talk time/standby time up to 200 hours

• Rechargeable battery with charging option from AC power supply, PC via USB

cable, desktop charger or car charger (not included)

• Less than / ounce (10 grams)

• Operating range up to 33 feet (10 meters)

• Headset and hands-free Bluetooth profiles

• Bluetooth specification (see glossary) version 1.2

Getting started

The Jabra JX10 is easy to operate. The answer/end button on the headset performs
different functions depending on how long you press it.

Charge your headset

Make sure that your Jabra JX10 headset is fully charged for two hours before you start
using it. Use the AC power supply to charge from a power socket, or charge directly from
your PC with the USB cable provided. Connect your headset as shown in fig. 2. When the
LED is solid red, your headset is charging. When the LED is green, it is fully charged.

Charge from your desktop holder

Connect your USB cable/AC power supply to the desktop holder. Place your JX10 in the
cradle as shown in fig. 3

Instruction: Duration of press:

Tap Press briefly
Press Approx: 1 second
Press and hold Approx: 5 seconds

4

English

5

English

5

4

2

3

How to…

Answer a call

• Tap the answer/end button on your headset to answer a call.

End a call

• Tap the answer/end button to end an active call.

Make a call

• When you make a call from your mobile phone, the call will (subject to phone

settings) automatically transfer to your headset. If your phone does not allow
this feature, tap on the Jabra JX10’s answer/end button to transfer the call to the
headset.

Reject a call*

• Press the answer/end button when the phone rings to reject an incoming call.

Depending on your phone settings, the person who called you will either be
forwarded to your voice mail or hear a busy signal.

Activate voice dialing*

• Tap the answer/end button. For best results, record the voice-dialing tag through

your headset. Please consult your phone’s user manual for more information about
using this feature.

Redial last number*

• Press the answer/end button.

Adjust sound and volume

• Press the volume up or down (+ or -) to adjust the volume. (See fig. 1 )

Call waiting and placing a call on hold*

This lets you place a call on hold during a conversation and answer a waiting call.

• Press the answer/end button once to put the active call on hold and answer the

waiting call.

• Press the answer/end button to switch between the two calls.

• Tap the answer/end button to end the active conversation.

* Functions marked with * are dependent on your phone supporting these

features. Check your phone’s user manual for further information.

Turning your headset on and off

• Press the answer/end button to turn on your headset. The blue light (LED)

shows a burst of flashes and thereafter continues to flash every 3 seconds.

• To turn off your headset, press and hold the answer/end button until you see a burst

of flashes.

Pair it with your phone

Before you use your Jabra JX10, you need to pair it with your mobile phone.

1. Put the headset in pairing mode

• Make sure the headset is on.

•

Press the pairing button marked until the blue light (LED) turns solid blue.

2. Set your Bluetooth phone to ‘discover’ the Jabra JX10

Follow your phone’s instruction guide. This usually involves going to a ‘setup,’

‘connect’ or ‘Bluetooth’ menu on your phone and selecting the option to ‘discover’ or
‘add’ a Bluetooth device. * (See example from a typical mobile phone in fig. 6).

3. Your phone will find the Jabra JX10

Your phone then asks if you want to pair with it. Accept by pressing ‘Yes’
or ‘OK’ on the phone and confirm with the

passkey or PIN = 0000 (4 zeros).

Your phone will confirm when pairing is complete. In case of unsuccessful pairing,
repeat steps 1 to 3.

Wear it how you like it

The Jabra JX10 is ready to wear on your right ear. If you prefer the left, gently remove the
earhook and rotate to fit the left ear. (See fig. 4)

For optimal performance, wear the Jabra JX10 and your mobile phone on the same

side of your body or within line of sight. In general, you will get better performance
when there are no obstructions between your headset and your mobile phone.

6

English

7

English

10

9

6

7

What the lights mean

Using a Jabra Bluetooth adapter

If you want to use the Jabra JX10 with a non-Bluetooth mobile phone, the Jabra A210
adapter is the answer.

The Jabra A210

gives you a cordless connection with the following headset features:
answer/end call, voice dial function (if supported by the phone). Rejecting a call, last
number redial and putting a call on hold might not be supported through the headset
jack in the mobile phone.

To pair the Jabra JX10 with the Jabra A210

The pairing process is a little different:

• Put your Jabra JX10 in pairing mode.

• Put the Jabra A210 adapter in pairing mode.

• Place them close together. You do not need a dedicated pin code to pair the two

Jabra products. Consult the Jabra A210 user manual for more information.

Making/answering a call when using the Jabra A210

• When you make a call from your mobile phone, the call will automatically transfer

to the headset (if it is turned on).

• To answer a call: either

tap the answer/end button on your headset or press the

answer button on your mobile phone.

What this means

Flashing every second: active on a call
Flashing every three seconds: in standby mode
Running low on battery
Charging
Fully charged
In pairing mode – see section 3

What you see

Flashing blue light
Flashing blue light
Flashing red light
Solid red light
Solid green light
Solid blue light

8

Troubleshooting & FAQ

I hear crackling noises
For the best audio quality, always wear your headset on the same side of the body as

your mobile phone.

I cannot hear anything in my headset

• Increase the volume on the headset.

• Ensure that the headset is paired with the phone.

• Make sure that the phone is connected to the headset – if it does not connect
either from the phone’s Bluetooth menu or by tapping the answer/end button,
follow the pairing procedure (see section 3).

I have pairing problems even though my phone indicates otherwise

You may have deleted your headset pairing connection in your mobile phone.

Follow the pairing instructions in section 3.

Will the Jabra JX10 work with other Bluetooth equipment?

The Jabra JX10 is designed to work with Bluetooth mobile phones. It can also work

with other Bluetooth devices that are compliant with Bluetooth version 1.1 or 1.2
and support a headset and/or hands-free profile.

Please note:

If the JX10 is completely discharged when you begin charging, it may take a couple

of minutes before the charging indicator light (LED) turns on.

Need more help?

1. Web: www.jabra.com (for the latest support info and online User Manuals)

2. E-mail: Tech Support: [e-mail]

Information: [e-mail]

3. Phone:

1 [phone] (toll-free in USA)

1 [phone] (Canada)

Taking care of your headset

• Always store the Jabra JX10 with the power off and safely protecte

d.

• Avoid storage at extreme temperatures (above 45°C/113°

F – including direct sunlight
– or below -10°C/14°F). This can shorten battery life and may affect operation. High
temperatures may also degrade performance. Low temperatures (down to -10C/14F)
will shorten battery life and may affect operation but should not permanently
damage the Jabra JX10.

• Do not expose the Jabra JX10 to rain or other liquids.

8

English

9

English

12

THE SOLE WARRANTIES, EXPRESS OR IMPLIED,GIVEN BY JABRA IN CONNECTION
WITH THE PRODUCT, AND JABRA DISCLAIMS ALL OTHER WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. JABRA SHALL NOT
BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH THE PRODUCT, EVEN IF JABRA HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.THE LIABILITY OF JABRA HEREUNDER FOR ALL
CLAIMS SHALL NOT EXCEED THE AMOUNT PAID BY PURCHASER TO JABRA FOR
THE PRODUCT GIVING RISE TO JABRA’S LIABILITY.

Certification and safety approvals

FCC

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.

Users are not permitted to make changes or modify the device in any way.
Changes or modifications not expressly approved by Jabra will void the user’s
authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

The user must place the base 8” (20cm) or more from any personnel in order to
comply with FCC RF exposure requirements.

11

Warranty

Jabra (GN Netcom) warrants this product against all defects in material and workmanship
Jabra limited product warranty. Jabra is a wholly owned trademark of GN
Mobile (GN Netcom A/S). Jabra warrants to Purchaser that for a period of one
(1) year after the date of purchase (the “Warranty Period”) of any Jabra Product
(“Product”) by Purchaser, the Product will substantially conform to Jabra’s
published specifications for the Product on the date of Purchaser’s purchase
of the Product, subject to the terms herein. Purchaser shall notify Jabra of
any nonconformance during the Warranty Period and obtain a written return
material authorization (“RMA”) and an RMA number for the nonconforming
Product from Jabra and return the nonconforming Product to Jabra, freight
prepaid, with a statement describing the nonconformity. Jabra’s exclusive
obligation with respect to nonconforming Product shall be, at Jabra’s option
and expense, to repair or replace such Product so that it substantially conforms
with its published specifications on the date of Purchaser’s purchase, or, if Jabra,
in Jabra’s sole discretion, determines that it is not possible to repair or replace
the Product, Jabra may, at Jabra’s option, refund to Purchaser the purchase price
paid for the Product.THE FOREGOING IS PURCHASER’S SOLE AND EXCLUSIVE
REMEDY FOR BREACH OF WARRANTY BY JABRA WITH RESPECT TO THE
PRODUCT. The warranty set forth above shall not apply to any Product which
has not been properly used or handled in accordance with the instructions
supplied by Jabra, lost or misplaced for any reason, or which has been modified,
repaired or altered, except by Jabra or at a Jabra authorized service facility, or
which has been subjected to faulty installation, misuse, abuse, or which the
Product defect is attributable to any failure or damage which is beyond the
reasonable control of Jabra. This warranty is available only to Purchaser, and
does not extend to any distributors, retailers, or other resellers of the Product.
This warranty applies only to new Jabra products purchased from authorized
retail sellers. This warranty does not apply to:“open box purchases”, resales by
private parties or any other third party purchases by unauthorized distributors.
Transfer of Jabra products through any unauthorized distributor renders our
manufacturer’s warranty null and void. BUYER BEWARE: any Jabra product sold
by a private party or unauthorized distributor and not by an authorized Jabra
retail seller is sold on an “as is” or “with all faults”basis with respect to Jabra.
As such, the entire risk as to the quality and performance of such products
will be with the buyer if the unauthorized distributor will not cover the costs
of repairing defects. Should such products prove defective following their
purchase, the buyer or unauthorized distributor, and not the manufacturer or
its authorized retail sellers, assumes the entire cost of all necessary servicing or
repair. Therefore, buyers are strongly encouraged to purchase Jabra products
only from Jabra authorized retail sellers. THE FOREGOING WARRANTIES ARE
