Bluetooth® Headset
User Manual
www.jabra.com
Fig. 1 Fig. 4
4
1
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Français
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3
5
Fig. 2
1 2 3
Fig. 3
Español
2
Fig. 5
Português
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
English
Thank you. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Getting started
1. Charge your headset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Turn on your headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Pair it with your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. Wear it how you like it . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. How to… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6. What the lights mean
7. Using a Jabra Bluetooth adaptor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8. Troubleshooting & FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9. Need more help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10. Taking care of your headset
11. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12. Certification and safety approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13. Glossary
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4
4
5
5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6
7
7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8
9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
1
2
3
Thank you
Thank you for purchasing the Jabra BT160 Bluetooth® Headset. We hope
you enjoy it!
This instruction manual will get you started and ready to make the most of
your headset.
!
Remember, driving comes first, not the call!
Using a mobile phone while driving can distract you and increase the
likelihood of an accident. If driving conditions demand it (such as bad weather,
high traffic density, presence of children in the car, difficult road conditions),
pull off the road and park before making or answering calls. Also, try to keep
conversations short and do not make notes or read documents.
Always drive safely and follow local laws.
What your headset can do
Your Jabra BT160 lets you do all this:
Answer calls
•
End calls
•
Reject calls (phone dependent)
•
Specifications:
Talk time/standby time up to 8 hours talk time (subject to phone),
•
110 hours standby
Rechargeable battery with charging option from AC power supply or car
•
charger (not included)
Weight 0.56 oz (16 g)
•
Operating range up to 33 feet / 10 m
•
Headset and hands-free Bluetooth profiles
•
Bluetooth1 specification (see glossary) version 1.2
•
Voice dialing (phone dependent)
•
Last number redialing
•
About your Jabra BT160
1 LED light
Blue indicates mode
(pairing, active or standby)
and battery charging
Red indicates low battery level
2 Volume up (
3 Charging socket
4 Answer/end button
Press and hold to turn headset on
Press and hold to turn headset off
Tap to answer or end a call
Press this, and press volume up (
headset in pairing mode
5 Earhook – gently flip and rotate 180° to fit left ear. (See fig. 2)
6 Plastic cover plate
+
), volume down (
–
)
3
5
+
) button at same time, to put
4
1
Changing the design
6
2
To insert your preferred design in your Jabra BT160:
1 Gently remove the plastic cover plates and current design.
2 Gently press out your preferred design from the sheets enclosed.
3 Add you preferred design and gently clip the plastic cover plate back
into place.
See illustrations below for further guidance.
4
5
Getting started
The Jabra BT160 is easy to operate. The answer/end button on the headset
performs different functions depending on how long you press it.
Instruction: Duration of press:
Tap Press briefly
Press Approx: 1 second
Press and hold Approx: 5 seconds
Charge your headset
1
Make sure that your Jabra BT160 headset is fully charged for two hours
before you start using it. Use the AC adapter to charge from a power socket.
Connect your headset as shown in fig. 3. When the LED is solid blue, your
headset is charging. When the solid blue LED turns off, it is fully charged.
Turn on your headset
2
Press the answer/end button to turn on your headset
•
Press and hold the answer/end button to turn off your headset
•
Pair it with your phone
3
Before you use your Jabra BT160, you need to pair it with your mobile phone.
1. Put the headset in pairing2 mode
Make sure that the headset is on.
Press the answer/end button and press the volume up (
the same time, until a solid blue light comes on.
2. Set your Bluetooth phone to ‘discover’ the Jabra BT160
Follow your phone’s instruction guide. This usually involves going to a
‘setup,’ ‘connect’ or ‘Bluetooth’ menu on your phone and selecting the
option to ‘discover’ or ‘add’ a Bluetooth device.* (See example from a
typical mobile phone in fig. 4
3. Your phone will find the Jabra BT160
Your phone then asks if you want to pair with it. Accept by pressing ‘Yes’
or ‘OK’ on the phone and confirm with the passkey or PIN
.
(4 zeros)
Your phone will confirm when pairing is complete. In case of
unsuccessful pairing, repeat steps 1 to 3.
)
+
) button at
3
= 0000
Wear it how you like it
The Jabra BT160 is ready to wear on your right ear. If you prefer the left,
gently flip and rotate the earhook 180°. (See fig. 2
For optimal performance, wear the Jabra BT160 and your mobile phone
on the same side of your body or within line of sight. In general, you will
get better performance when there are no obstructions between your
headset and your mobile phone.
How to…
5
Answer a call
Tap the answer/end button on your headset to answer a call
•
End a call
Tap the answer/end button to end an active call
•
Reject a call (Dependent on your phone supporting this feature)
Press the answer/end button when the phone rings to reject an
•
incoming call. Depending on your phone settings, the person who
called you will either be forwarded to your voice mail or hear a busy
signal
Make a call
When you make a call from your mobile phone, the call will (subject to
•
phone settings) automatically transfer to your headset
Activate voice dialing (Dependent on your phone supporting this
feature)
Tap the answer/end button. For best results, record the voice-dialing
•
tag through your headset. Please consult your phone’s user manual for
more information about using this feature
Redial last number (Dependent on your phone supporting this feature)
Press the answer/end button
•
Adjust sound and volume
Press the volume up or down (
•
(See fig. 5)
+
or –) to adjust the volume
)
(See fig. 1)
6
7
What the lights mean
6
Troubleshooting & FAQ
8
What you see What this means about your headset
Flashing blue light Flashing every second: active on a call
Flashing blue light Flashing every three seconds: in standby mode
Flashing red light Running low on battery
Solid blue light Charging
Solid blue light off Fully charged
Solid blue light In pairing mode – (See section 3
Using a Jabra Bluetooth adaptor
7
If you want to use the Jabra BT160 with a non Bluetooth mobile phone, the
Jabra A210 adaptor is the answer.
It gives you a cordless connection with the following headset features:
answer/end call and voice dial function (if supported by the phone).
Rejecting a call and last number redial might not be supported through the
headset jack in the mobile phone.
To pair the Jabra BT160 with the Jabra A210
The pairing process is a little different:
Put your Jabra BT160 in pairing mode
•
Put the Jabra A210 adaptor in pairing mode
•
Place them close together. You do not need a dedicated pin code to pair
•
the two Jabra products. Consult the Jabra A210 user manual for more
information
Making/answering a call when using the Jabra A210
When you make a call from your mobile phone, the call will
•
automatically transfer to the headset (if it is turned on)
To answer a call: either tap the answer/end button on your headset or
•
press the answer button on your mobile phone
)
4
I hear crackling noises
For the best audio quality, always wear your headset on the same side
of the body as your mobile phone.
I cannot hear anything in my headset
• Increase the volume on the headset
• Ensure that the headset is paired with the phone
• Make sure that the phone is connected to the headset – if it does not
connect either from the phone’s Bluetooth menu or by tapping the
answer/end button, follow the pairing procedure (See section 3
I have trouble pairing BT160 with my phone
1. You may have deleted your headset pairing in your mobile phone.
Follow the pairing instructions in section 3
2. You can pair your BT160 with up to four different phones or bluetooth
devices. If your BT160 is connected to another phone or other
bluetooth device, disconnect the BT160 from the previously used
phone using the phone set up menu.
3. There is also the possibility that the BT160 is searching for a device to
connect to. Wait
4. Check the phone screen to ensure that the BT160 is not awaiting a
response from your mobile phone set up menu.
I cannot use Reject call, Call on hold, Redial or Voice dialling
These functions are dependent on your phone supporting them. Please
check your phone’s manual for further details.
Will the Jabra BT160 work with other Bluetooth equipment?
The Jabra BT160 is designed to work with Bluetooth mobile phones.
It can also work with other Bluetooth devices that are compliant with
Bluetooth version 1.1 or 1.2 and support a headset and/or hands-free
profile.
30 seconds and try again.
)
Need more help?
Web: www.jabra.com (for the latest support info and online
•
E-mail: Tech Support: techsupp@jabra.com
•
User Manuals)
Information: info@jabra.com
8
9
Taking care of your headset
10
1. Always store the Jabra BT160 with power off and safely protected.
2. Avoid storage at high temperatures (above 60°C / 134°F) – such as in
a hot vehicle or in direct sunlight. (Storage at high temperatures can
degrade performance and reduce battery life).
3. Do not expose the headset or any of its supplied parts to rain or other
liquids.
Warranty
11
Jabra limited product warranty. Jabra is a wholly owned trademark
of GN Mobile (GN Netcom A/S). Jabra warrants to Purchaser that for
a period of one (1) year after the date of purchase (the “Warranty
Period”) of any Jabra Product (“Product”) by Purchaser, the Product
will substantially conform to Jabra’s published specifications for
the Product on the date of Purchaser’s purchase of the Product
subject to the terms herein. Purchaser shall notify Jabra of any
nonconformance during the Warranty Period and obtain a written
return material authorization (“RMA”) and an RMA number for the
nonconforming Product from Jabra and return the nonconforming
Product to Jabra, freight prepaid, with a statement describing
the nonconformity. Jabra’s exclusive obligation with respect to
nonconforming Product shall be, at Jabra’s option and expense,
to repair or replace such Product so that it substantially conforms
with its published specifications on the date of Purchaser’s
purchase, or, if Jabra, in Jabra’s sole discretion, determines that
it is not possible to repair or replace the Product, Jabra may, at
Jabra’s option, refund to Purchaser the purchase price paid for the
Product.THE FOREGOING IS PURCHASER’S SOLE AND EXCLUSIVE
REMEDY FOR BREACH OF WARRANTY BY JABRA WITH RESPECT
TO THE PRODUCT. The warranty set forth above shall not apply
to any Product which has not been properly used or handled
in accordance with the instructions supplied by Jabra, lost or
misplaced for any reason, or which has been modified, repaired or
altered, except by Jabra or at a Jabra authorized service facility, or
which has been subjected to faulty installation, misuse, abuse, or
which the Product defect is attributable to any failure or damage
which is beyond the reasonable control of Jabra. This warranty is
available only to Purchaser, and does not extend to any distributors,
,
retailers, or other resellers of the Product. This warranty applies only
to new Jabra products purchased from authorized retail sellers.
This warranty does not apply to:“open box purchases”, resales by
private parties or any other third party purchases by unauthorized
distributors. Transfer of Jabra products through any unauthorized
distributor renders our manufacturer’s warranty null and void. BUYER
BEWARE: any Jabra product sold by a private party or unauthorized
distributor and not by an authorized Jabra retail seller is sold on
an “as is” or “with all faults”basis with respect to Jabra. As such, the
entire risk as to the quality and performance of such products will
be with the buyer if the unauthorized distributor will not cover the
costs of repairing defects. Should such products prove defective
following their purchase, the buyer or unauthorized distributor, and
not the manufacturer or its authorized retail sellers, assumes the
entire cost of all necessary servicing or repair. Therefore, buyers are
strongly encouraged to purchase Jabra products only from Jabra
authorized retail sellers. THE FOREGOING WARRANTIES ARE THE SOLE
WARRANTIES, EXPRESS OR IMPLIED,GIVEN BY JABRA IN CONNECTION
WITH THE PRODUCT, AND JABRA DISCLAIMS ALL OTHER
WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT
OF THIRD PARTY RIGHTS. JABRA SHALL NOT BE LIABLE FOR
ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH THE PRODUCT, EVEN IF JABRA HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.THE LIABILITY
OF JABRA HEREUNDER FOR ALL CLAIMS SHALL NOT EXCEED THE
AMOUNT PAID BY PURCHASER TO JABRA FOR THE PRODUCT GIVING
RISE TO JABRA’S LIABILITY.
Certification and safety approvals
12
FCC
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Users are not permitted to make changes or modify the device in
any way. Changes or modifications not expressly approved by Jabra
will void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits
10
11
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The user must place the base 8” (20cm) or more from any personnel
in order to comply with FCC RF exposure requirements.
Industry Canada
Operation is subject to the following two conditions: (1) This device
may not cause interference and (2) This device must accept any
interference, including interference that may cause undesired
operation of the device.
The term “IC:” before the certification/registration number only
signifies that registration was performed based on a Declaration of
Conformity indicating that Industry Canada technical specifications
were met. It does not imply that Industry Canada approved the
equipment.
Bluetooth
The Bluetooth
SIG, Inc. and any use of such marks by Jabra is under license. Other
trademarks and trade names are those of their respective owners.
® word mark and logos are owned by the Bluetooth
Glossary
13
1 Bluetooth: is a radio technology that connects devices, such as mobile
phones and headsets, without wires or cords over a short distance
(approx. 30 feet). Get more information at www.bluetooth.com
Bluetooth profiles are the different ways that Bluetooth devices
communicate with other devices. Bluetooth phones support either
the headset profile, the hands-free profile or both. In order to support
a certain profile, a phone manufacturer must implement certain
mandatory features within the phone’s software.
2 Pairing: creates a unique and encrypted link between two Bluetooth
devices and lets them communicate with each other. Bluetooth devices
will not work if the devices have not been paired.
3 Passkey or PIN: is a code that you enter on your mobile phone to pair
it with your Jabra BT160. This makes your phone and the Jabra BT160
recognize each other and automatically work together.
4 Standby mode: is when the Jabra BT160 is passively waiting for a call.
When you ‘end’ a call on your mobile phone, the headset goes into
standby mode.
Loading...
