Jabra BT 125 User Manual

© 2006 Jabra, GN Mobile A/S (GN Netcom A/S). All rights reserved. Jabra® is a registered trademark of GN Mobile A/S (GN Netcom A/S). All other trademarks included herein are the property of their respective owners. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by GN Mobile A/S (GN Netcom A/S) is under license. (Design and specifications subject to change without notice)

www.jabra.com

Bluetooth® headset

User manual

www.jabra.com

Fig. 1 Fig. 5

Fig. 3

1 2

Fig. 2

1 2

Fig. 4

1 2 3

English

Français

Español

Português

1. Thank you. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

2. About your Jabra BT125 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

3. What your new headset can do . . . . . . . . . . . . . . . . . . . . . .4

4. Getting started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

5. Charge your headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

6. Turning your headset on and off . . . . . . . . . . . . . . . . . . . . .5

7. Pair it with your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

8. Wear it how you like it . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

9. How to. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

10. What the lights mean. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

11. Troubleshooting & FAQ. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

12. Need more help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

13. Taking care of your headset. . . . . . . . . . . . . . . . . . . . . . . . . .8

14. Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

15. Certification and safety approvals. . . . . . . . . . . . . . . . . . . .9

16. Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1. Thank you

Thank you for purchasing the Jabra BT125 Bluetooth® headset. We hope you enjoy it!

This instruction manual will get you started and ready to make the most of your headset.

Remember, driving comes first, not the call!

Using a mobile phone while driving can distract you and increase the likelihood of an accident. If driving conditions demand it (such as bad weather, high traffic density, presence of children in the car, difficult road conditions), pull off the road and park before making or answering calls. Also, try to keep conversations short and do not make notes or read documents.

Always drive safely and follow local laws.

2. About your Jabra BT125

Volume down

Volume up

Adjustable earhook

Indicator light (LED) and answer/end button

Charging socket

RELEASE YOUR JABRA

Jabra BT125 Bluetooth headset

3. What your new headset can do

Your Jabra BT125 lets you do all this (dependent on your phone

supporting the function):

• Answer calls

• End calls

• Reject calls*

• Voice dialing*

• Last number redialing*

• Call waiting*

• Place call on hold*

* Phone dependent

Specifications

• Talk time up to 8 hours/standby time up to 170 hours

• Rechargeable battery with charging option from AC power supply, PC via USB cable or car charger (PC USB cable and car charger sold separately)

• Weight

• Operating range up to 33 feet (10 meters)

• Headset and hands-free Bluetooth profiles

• Bluetooth specification (see glossary page 10) version 2.0

/2 oz (14g)

4. Getting started

The Jabra BT125 is easy to operate. The answer/end button on the headset performs different functions depending on how long you press it.

Instruction: Duration of press

Tap Press briefly Press Approx: 1 second Press and hold Approx: 5 seconds

5. Charge your headset

Make sure that your Jabra BT125 headset is fully charged for 2 hours before you start using it. Use the AC power supply to charge from a power socket. Connect your headset as shown in fig. 2. When the light indicator (LED) is solid blue, your headset is charging. When the solid blue LED light turns off, it is fully charged. (Follow step 1-2 in fig. 2).

6. Turning your headset on and off

• To turn on your headset press the answer/end button until you see a burst of blue flashes on the indicator light (LED)

• To turn off your headset press and hold the answer/end button until you see a burst of blue flashes on the indicator light (LED)

7. Pair it with your phone

Before you use your Jabra BT125, you need to pair it with your mobile phone. (Follow step 1-4 in fig. 3).

1. Put the headset in pairing mode

• Make sure the headset is off .

• Press and hold the answer/end button until a solid blue light comes on.

2. Set your Bluetooth phone to ‘discover ’ the Jabra BT125

Follow your phone’s instruction guide. This usually involves going to a

‘setup,’ ‘connect’ or ‘Bluetooth’ menu on your phone and selecting the option to ‘discover’ or ‘add’ a Bluetooth device.* (See example from a

typical mobile phone in fig. 3).

3. Your phone will find the Jabra BT125

Your phone then asks if you want to pair with it. Accept by pressing ‘Yes’ or

‘OK’ on the phone and confirm with the passkey or PIN = 00 00 (4 zeros). Your phone will confirm when pairing is complete. In case of unsuccessful pairing, repeat steps 1 to 3.

8. Wear it how you like it

The Jabra BT125 is ready to wear on your right ear. If you prefer the left, gently pull out the earhook, rotate the ear hook 180°, and insert. (See fig. 4). The earhook can be adjusted to fit your ear better – adjust the back edge of the earhook for a more secure fit.

For optimal performance, wear the Jabra BT125 and your mobile phone on the same side of your body or within line of sight. In general, you will get better performance when there are no obstructions between your headset and your mobile phone. (See fig. 5).

RELEASE YOUR JABRA

Jabra BT125 Bluetooth headset

9. How to...

Answer a call

• Tap the answer/end button on your headset to answer a call.

End a call

• Tap the answer/end button to end an active call.

Make a call

• When you make a call from your mobile phone, the call will (subject to phone settings) automatically transfer to your headset. If your phone does not support this function, tap on the answer/end button on the Jabra BT125 to receive the call in the headset.

Reject a call*

• Press the answer/end button when the phone rings to reject an incoming call. Depending on your phone settings, the person who called you will either be forwarded to your voice mail or hear a busy signal.

Activate voice dialing*

• Tap the answer/end button. For best results, record the voice-dialing tag through your headset if your phone allows you to do so. Please consult your phone’s user manual for more information about using this feature.

Redial last number*

• Press the answer/end button.

Adjust sound and volume

• Press the volume up or down (+ or -) to adjust the volume.

(See fig. 1,

Call waiting and placing a call on hold*

This lets you place a call on hold during a conversation and answer a waiting call.

• Press the answer/end button once to place the active call on hold and answer the waiting call.

• Press the answer/end button to switch between the two calls.

• Tap the answer/end button to end the active conversation.

* Phone dependent

& 2).

10. What the lights mean

What you see

Flashing blue light Flashing blue light Flashing blue light Solid blue light Solid blue light

What this means about your headset

Flashing every second: active on a call Flashing every three seconds: in standby mode Flashing three times rapidly: running low on battery Charging In pairing mode – see section 7

11. Troubleshooting & FAQ

I hear crackling noises For the best audio quality, always wear your headset on the same side of

the body as your mobile phone.

I cannot hear anyt hing in my headset

• Increase the volume on the headset.

• Ensure that the headset is paired with the phone.

• Make sure that the phone is connected to the headset – if it does not connect either from the phone’s Bluetooth menu or by tapping the answer/end button, follow the pairing procedure (See sectio n 3).

I have pairing problems even t hough my phone indicates o therwise

You may have deleted your headset pairing connection in your mobile

phone. Follow the pairing instructions in section 3.

Will the Jabra BT125 work with other Bluetooth equipment?

The Jabra BT125 is designed to work with Bluetooth mobile phones. It can

also work with other Bluetooth devices that are compliant with Bluetooth version 1.1 or 1.2 and support a headset and/or hands-free profile.

I cannot use Reject call, call on ho ld, Redial or voice dialing

These functions are dependent on your phone supporting them. Please

check your phone’s manual for further details.

12. Need more help?

1. Web: www.jabra.com

(for the latest support info and online User Manuals)

2. E-mail: Tech Support: techsupp@jabra.com

Information: info@jabra.com

3. Phone:

1 (603) 579-5311 (Canada)

1 (800) 327-2230 (toll-free in USA)

RELEASE YOUR JABRA

Jabra BT125 Bluetooth headset

13. Taking care of your headset

• Always store the headset with the power off and safely protected.

• Avoid storage at extreme temperatures (above 45°C/113°F – including

direct sunlight – or below -10°C/14°F). This can shorten battery life and may affect operation. High temperatures may also degrade performance.

• Do not expose the headset to rain or other liquids.

14. Warranty

Jabra limited product warranty. Jabra is a wholly owned trademark of GN Mobile (GN Netcom A/S). Jabra warrants to Purchaser that for a period of one (1) year after the date of purchase (the “Warranty Period”) of any Jabra Product (“Product”) by Purchaser, the Product will substantially conform to Jabra’s published specifications for the Product on the date of Purchaser’s purchase of the Product, subject to the terms herein. Purchaser shall notify Jabra of any nonconformance during the Warranty Period and obtain a written return material authorization (“RMA”) and an RMA number for the nonconforming Product from Jabra and return the nonconforming Product to Jabra, freight prepaid, with a statement describing the nonconformity. Jabra’s exclusive obligation with respect to nonconforming Product shall be, at Jabra’s option and expense, to repair or replace such Product so that it substantially conforms with its published specifications on the date of Purchaser’s purchase, or, if Jabra, in Jabra’s sole discretion, determines that it is not possible to repair or replace the Product, Jabra may, at Jabra’s option, refund to Purchaser the purchase price paid for the Product.THE FOREGOING IS PURCHASER’S SOLE AND EXCLUSIVE REMEDY FOR BREACH OF WARRANTY BY JABRA WITH RESPECT TO THE PRODUCT. The warranty set forth above shall not apply to any Product which has not been properly used or handled in accordance with the instructions supplied by Jabra, lost or misplaced for any reason, or which has been modified, repaired or altered, except by Jabra or at a Jabra authorized service facility, or which has been subjected to faulty installation, misuse, abuse, or which the Product defect is attributable to any failure or damage which is beyond the reasonable control of Jabra. This warranty is available only to Purchaser, and does not extend to any distributors, retailers, or other resellers of the Product. This warranty applies only to new Jabra products purchased from authorized retail sellers. This warranty does not apply to: "open box purchases”, resales by private parties or any other third party purchases by unauthorized distributors. Transfer of Jabra products through any unauthorized distributor renders our manufacturer’s warranty null and void. BUYER BEWARE: any Jabra product sold by a private party or unauthorized distributor and not by an authorized Jabra retail seller is sold on an “as is” or “with all faults" basis with respect to Jabra. As such, the entire risk as to the quality and performance of such products will be with

the buyer if the unauthorized distributor will not cover the costs of repairing defects. Should such products prove defective following their purchase, the buyer or unauthorized distributor, and not the manufacturer or its authorized retail sellers, assumes the entire cost of all necessary servicing or repair. Therefore, buyers are strongly encouraged to purchase Jabra products only from Jabra authorized retail sellers. THE FOREGOING WARRANTIES ARE THE SOLE WARRANTIES, EXPRESS OR IMPLIED, GIVEN BY JABRA IN CONNECTION WITH THE PRODUCT, AND JABRA DISCLAIMS ALL OTHER WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. JABRA SHALL NOT BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE PRODUCT, EVEN IF JABRA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.THE LIABILITY OF JABRA HEREUNDER FOR ALL CLAIMS SHALL NOT EXCEED THE AMOUNT PAID BY PURCHASER TO JABRA FOR THE PRODUCT GIVING RISE TO JABRA’S LIABILITY.

15. Certi cation and safety approvals

FCC

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by Jabra (GN Netcom) will void the user’s authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

RELEASE YOUR JABRA

Jabra BT125 Bluetooth headset
