JABRA BOOST
WECHAT EDITION
User Manual
jabra.cn/boost
© 2015 GN Netcom A/S. All rights reserved. Jabra® is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth® word
mark and logos are owned by the Bluetooth SIG, Inc. and any use
of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).
MADE IN CHINA
MODEL: OTE15
Declaration of Conformity can be found on
www.jabra.com/CP/US/declarations-of-conformity
CONTENTS
1. WELCOME .......................................... 4
2. HEADSET OVERVIEW ......................... 5
3. HOW TO WEAR ................................. 6
3.1 CHANGE EARGELS
3.2 ATTACHING THE EARHOOK
4. HOW TO CHARGE THE BATTERY ....... 8
4.1 BATTERY STATUS
4.2 POWER NAP
5. HOW TO CONNECT ...........................10
6. HOW TO USE .................................... 11
6.1 CALLS
6.2 RESET THE HEADSET
7. W ECH AT ............................................14
7.1 GETTING STARTED USING WECHAT
8. SUPPORT ..........................................15
8.1 FAQ
8.2 HOW TO CARE FOR YOUR HEADSET
9. TECHNICAL SPECIFICATIONS ...........16
ENGLISH
JABRA BOOST WECHAT EDITION
3
1. WELCOME
Thank you for using the Jabra Boost WeChat
Edition. We hope you will enjoy it!
JABRA BOOST WECHAT EDITION FEATURES
Play and respond to unread WeChat text/voice
messages using the headset (Android phones
only)
Long talk time - Up to 9 hours*
Power Nap for extended standby time - Up to
365 days
Voice guidance
Battery and pairing status display
HD voice compatible*
Wireless freedom - Up to 30m/98ft*
New comfort EarGels
*phone/network dependent
ENGLISH
JABRA BOOST WECHAT EDITION
4
2. HEADSET OVERVIEW
Multi-function button
(WeChat and calls)
Battery
indicator
Micro-USB Port
ENGLISH
On/O
switch
Bluetooth
indicator
USB cable
Small
EarHook
Large
EarHook
EarGel Left looped
JABRA BOOST WECHAT EDITION
Volume up/down
buttons
Microphone
Right looped
EarGel
EarGel
5
3. HOW TO WEAR
The headset can be worn on the left or right ear,
with or without the EarHook. Different EarGels
and EarHooks are available in the pack.
jabra
L
R
jabra
ENGLISH
JABRA BOOST WECHAT EDITION
6
3.1 CHANGE EARGELS
Choose between 3 ergo-designed EarGels for
optimal fit and comfort (standard, left looped, or
right looped).
3.2 ATTACHING THE EARHOOK
Select between two different EarHook sizes (small
or large). The EarHook can be attached to the
headset for a more secure fit, and can be worn
with the Standard EarGel (suitable for left or right
ear).
ENGLISH
JABRA BOOST WECHAT EDITION
7
4. HOW TO CHARGE THE
BATTERY
Fully charge the headset before first use, and enjoy
up to 9 hours talk time. It takes approx. 2 hours to
charge.
To charge the headset simply connect it to the PC
using the supplied USB cable.
Battery LED
4.1 BATTERY STATUS
Charge the headset by connecting it to a PC using
the supplied USB cable.
BATTERY STATUS
More than 30 minutes talk time remaining
- Less than 30 minutes talk time remaining
- Headset charging (connected via USB to PC)
ENGLISH
JABRA BOOST WECHAT EDITION
8
4.2 POWER NAP
To extend standby time the headset will
automatically enter Power Nap mode when the
headset is out of range of your connected mobile
device for more than 60 minutes. Power Nap
provides up to 365 days of battery readiness/
standby time.
To exit Power Nap (or answer an incoming call)
simply tap the Multi-function button on the
headset. Your mobile device must be switched on,
within range, and have Bluetooth enabled.
ENGLISH
JABRA BOOST WECHAT EDITION
9
5. HOW TO CONNECT
CONNECT TO A BLUETOOTH® DEVICE
1. Turn the headset on (set the On/Off switch to
the On position).
2. Press and hold (3 secs) the Volume up and
Volume down button until the Bluetooth
indicator flashes blue and the voice-guided
instructions are announced in the headset.
3. Wear the headset and follow the voice-guided
instructions to connect to your Bluetooth device.
jabra
NOTE: Fully charge the headset before first use, and enjoy up to
9 hours talk time. It takes approx. 2 hours to charge.
ENGLISH
JABRA BOOST WECHAT EDITION
10
6. HOW TO USE
Battery indicator
On/Off switch
Bluetooth indicator
Multi-function button
(WeChat and calls)
Volume up
Volume down
ENGLISH
JABRA BOOST WECHAT EDITION
11
6.1 CALLS
CALLS
On/off Slide the On/off switch
Answer/end call
Reject incoming
call
Activate Siri/
Google Now
voice commands
(phone/network
dependent)
Adjust speaker
volume
Mute/un-mute
microphone
Tap the Multi-function
button to answer an
incoming call or end a call
Double-tap the Multi-
function button
Press and hold (1 sec) the
Volume up or Volume down
button
When on a call, tap the
Volume up or Volume down
button
When on a call, tap both
the Volume up and Volume
down at the same time
ENGLISH
JABRA BOOST WECHAT EDITION
12
6.2 RESET THE HEADSET
Resetting the headset clears the list of connected
devices.
1. Turn the headset on (set the On/Off switch to
the On position).
2. Simulatenously press and hold (5 secs) the
Volume up and Multi-function button until the
Bluetooth indicator and the Battery indicator
flash, and then release the buttons.
ENGLISH
JABRA BOOST WECHAT EDITION
13
7. WECHAT
7.1 GETTING STARTED USING WECHAT
1. Install the WeChat app and the Jabra Social
Connect app on your Android phone. Install the
Jabra Social Connect app from www.jabra.cn/wx
WeChat Jabra Social Connect
2. You can now play and respond to unread WeChat
text or voice messages using your headset.
The headset is used for responding to unread
WeChat messages.
WECHAT MESSAGES
Play unread
message
Reply to message
Skip to unread
conversation with
another person
Tap the Multi-function
button
Press and hold the
Multi-function button to
begin recording a voice
message. Release the button
to send the message (up to
60 seconds)
Double-tap the
Multi-function button
ENGLISH
JABRA BOOST WECHAT EDITION
14
8. SUPPORT
8.1 FAQ
View the FAQ on Jabra.cn/boost.
8.2 HOW TO CARE FOR YOUR HEADSET
Always store the headset with the power off
and safely protected
Avoid storage at extreme temperatures (above
40°C/104°F or below 0°C/32°F). This can shorten
battery life and may affect headset operation
Do not expose the headset to rain or other
liquids
ENGLISH
JABRA BOOST WECHAT EDITION
15
9. TECHNICAL
SPECIFICATIONS
JABRA BOOST WECHAT
EDITION HEADSET
Weight: 8.5 g (0.30 oz)
Dimensions:
Microphones: Omni-directional microphone
Speaker: 11 mm dynamic speaker
Operating range:
Bluetooth version: 4.0
Paired devices:
Supported Bluetooth
profiles:
Talk time: Up to 9 hours
Standby time: Up to 9 days
SPECIFICATION
L 49.3 mm x W 14.5 mm x
H 9.5 mm
L 1.94 in x W 0.57 in x
H 0.37 in
Up to 30m/98ft (phone
dependent)
Up to 8, connected to 1 device
at a time
A2DP(v1.2), Hands Free Profile
(v1.6), Headset profile(v1.2)
ENGLISH
JABRA BOOST WECHAT EDITION
16
JABRA BOOST WECHAT
EDITION HEADSET
Power Nap standby time: Up to 365 days
Charging time: Approx. 2 hours
Operating temperature: -10°C to 55°C (14°F to 131°F)
Storage temperature: 0°C to 40°C (32°F to 104°F)
USB charging cable: 5V, >100 mA
Materials:
Pairing passkey or PIN: 0000
SPECIFICATION
Polycarbonate (PC),
Polycarbonate + acryl
butadien styren (PC + ABS),
silcone rubber, PP, TPE
ENGLISH
JABRA BOOST WECHAT EDITION
17
ENGLISH
www.jabra.com/boost
JABRA BOOST WECHAT EDITION
18
REV A
