NetworX™ Series
NX-148E-CF Commercial Fire
LCD Keypad
User manual
UP & DOWN
light is “on”
when AC power is
is detachable and can
when the system is
when armed, “off”
when disarmed,
previous alarm.
CF
Model NX-148E-
SCROLL KEYS
POWER
present, flashes to
indicate a low
battery condition.
KEYS
5 FUNCTION
The door (not shown)
be removed or
COMMERCIAL FIRE SYSTEM LCD KEYPAD
replaced when
desired.
FIRE light is “on” to
indicate fire alarm,
flashes to indicate a
trouble condition with
your fire system.
ready to arm, flashes if
READY light is “on”
ready to “force arm”.
ARMED light is “on”
flashes to indicate a
PROGRAMMABLE
EMERGENCY
ACTIVATION KEYS
NUMERIC CODE
Activation keys that are programmed to work with your system.
The appropriate stickers should be applied on the keypad door for the Emergency
ENTRY KEYS
Installing/Service Company
For Service Call
Central Station
This system is is not partitioned.
EMERGENCY ACTIVATION KEYS
(check if enabled)
Fire Auxiliary Emergency Police
PROGRAMMED FUNCTIONS
Abort Delay (s) Group Bypass (s)
Battery Test Quick Arm (s)
Cancel Alarm Re Exit
Chime Siren Test
Forced Arming (s)
(s) These features should not be enabled on UL listed systems.
NOTE: Some of the features described above may or may not be available for
your system. Check with your installation company to find out how your
system is programmed.
To Arm or Disarm or Silence Alarm: Enter your user code.
To Quick Arm and Stay: Press “Stay” key.
To Quick Arm and Exit: Press “Exit” key.
Door Chime: Press “Chime” key to activate.
Reset Smoke Detector and Panel Reset: Press
NX-148E-CF
7
1
TABLE OF CONTENTS
GLOSSARY OF TERMS...........................................................................4
UNDERSTANDING THE LIGHTS............................................................. 6
KEYPAD FUNCTIONS.............................................................................. 7
Arming Your System In The “Away” Mode........................................... 7
Making Your System Ready To Arm.................................................... 7
Arming Your System In The “Stay” Mode ............................................ 8
Using The Quick Arm...........................................................................9
Disarming Your System ....................................................................... 9
Cancel / Abort Feature.......................................................................10
Bypassing Zones................................................................................10
Group Bypass .................................................................................... 11
Unbypassing ...................................................................................... 11
Emergency Activation Keys ............................................................... 11
Function Menu ................................................................................... 12
View Zone Status...............................................................................13
Setting The Keypad Tone .................................................................. 13
View Alarm Memory...........................................................................13
Test Function ..................................................................................... 13
Display Test Function.........................................................................14
Light Control For X-10 Devices..........................................................14
Change Languages............................................................................ 14
Changing User Codes........................................................................ 15
Assigning User Code Authority Levels............................................... 15
Reset Function...................................................................................16
Reading The Event Log ..................................................................... 17
Adjusting The View / Brightness Of The LCD....................................17
Setting The System Clock.................................................................. 18
Using The Door Chime Feature.........................................................18
PARTITIONED SYSTEMS OPERATION................................................ 19
Lights In Partitioning Master Mode.....................................................19
Displays In The Partitioning Master Mode ......................................... 19
KEYPAD CONTROL TONES (BEEPS) .................................................. 22
SERVICE DISPLAY................................................................................23
APPENDIX A - EVENT LOG...................................................................25
EMERGENCY EVACUATION PLANS....................................................27
NX-148E-CF 3
THIS MANUAL IS FURNISHED TO HELP YOU UNDERSTAND YOUR SECURITY
SYSTEM AND BECOME PROFICIENT IN ITS OPERATION. ALL USERS OF YOUR
SECURITY SYSTEM SHOULD READ AND FOLLOW THE INSTRUCTIONS AND
PRECAUTIONS IN THIS BOOKLET. FAILURE TO DO SO COULD RESULT IN THE
SECURITY SYSTEM NOT WORKING PROPERLY. THIS BOOKLET SHOULD BE KEPT
IN AN ACCESSIBLE LOCATION FOR THE LIFE OF THE SECURITY SYSTEM. IF YOU
DO NOT UNDERSTAND ANY PART OF THIS MANUAL, YOU SHOULD NOTIFY YOUR
INSTALLING COMPANY. READ THE ENTIRE MANUAL AND, IF POSSIBLE, PRA CTICE
ON THE KEYPAD CONTROL WHILE YOUR PROFESSIONAL INSTALLER IS ON SITE.
The SECURITY CONTROL can be turned on (ARMED) and off (DISARMED) by entering a 4
or 6 digit code into the Keypad Control, which is similar to a telephone keypad. If your
Security Control has been so programmed, you may be able to turn on (ARM) your System
by simply pressing the [STAY] or [EXIT] key. The system must always be Disarmed using a 4
or 6 digit code. The LCD keypad includes 9 lights and a 32-character liquid crystal display
and a built-in electronic sounder. These provide specific information relating to the status of
the security system which is described in the booklet. Understanding what the lights and
sounds mean will help you to easily operate your sy stem.
KEEP IN MIND, THE LEVEL OF SECURITY YOU WILL OBTAIN WITH THIS SYSTEM
RELATES SPECIFICALLY WITH TWO MAJOR FACTORS:
1. The quantity, quality, and placement of security devices attached to this system.
2. The knowledge you have of the security system and how that knowledge is utilized
YOU SHOULD BE AWARE OF THE FOLLOWING FACTS WHEN PREPARING A
SAFETY/SECURITY PLAN FOR YOUR HOME/BUSINESS.
PLEASE READ THE FOLLOWING INFORMATION AND INSTRUCTIONS CAREFULLY
BEFORE OPERATING YOUR SECURITY CONTROL SYSTEM. IF YOU DO NOT
UNDERSTAND ANY PORTION OF THIS MANUA L, OR IF YOU HA VE ANY QUESTIONS
ABOUT YOUR SYSTEM, CONTACT THE INSTALLING COMPANY.
in a weekly test of the complete system.
1. Your security sy stem is an electronic device and is subject to failure or malfunct ion.
Do not rely on it as your single source of security.
2. Your system should be tested weekly.
3. Your system will not work without power.
4. Warning devices will need to be loud enough, wired correctly, and properly placed
to provide notification of an alarm event.
5. Smoke and heat detectors may not detect heat and smoke in all situations.
6. Use qualified security professionals to install and maintain your security system.
7. It may be possible to arm the security system without the backup battery connected.
Your periodic test should be done with A.C. Power removed to verify the battery is
connected and adequately charged.
8. Care should be taken to plug in and restrain the A.C. Transformer after testing.
4
NX-148E-CF
GLOSSARY OF TERMS
Abort Delay: An option that allows a delay in reporting to the central
Authority Level: The level of access an individual has when using an alarm
Central Station: Location where alarm data is sent during an alarm report.
Chime Feature: An option that allows the keypad to sound a ding-dong
Codes: Can be either User Codes (relating to a person) or
Duress Code: An option that allows a special code to be sent to the
Forced Arming: An option that allows the system to be turned on (ARMED)
Function Code: A Function Code is either a four (4) or six (6) digit code that
Group Bypass: An option that allows the user to bypass multiple zones
Instant/Delay: An option that allows an instant alarm condition for
Master Code: A master arm/disarm code that can program other user
Partitioned System: A system divided into multiple areas in which its own user
Perimeter: The outer edge of the protected area.
Quick Arm: An option that allows you to turn on (ARM) the security
User Code: A 4- or 6-digit entry used to arm or disarm the system.
station.
panel.
whenever an entry/exit door is opened.
Function Codes (a toggle switch to turn specific functions
on/off). NOTE: A system may have either 4-digit codes
or 6-digit codes, but not a mixture of the two.
central station that indicates the alarm system is being
operated under duress.
with one or more zones open. A system that is ready to be
“force armed” will flash the ready light. NOTE: Those
zones that are not ready will not create an alarm.
has been programmed by the installer to operate a device.
with a single operation.
Entry/Exit doors, or grants a delay to allow someone to
enter/exit the building without an alarm or before entering a
user code to disarm.
codes.
or users control each area.
system by pressing either the [STAY] or [EXIT] key on the
keypad control (for ARMING only) as programmed by the
installing company.
NX148E-CF
5
UNDERSTANDING THE LIGHTS
Armed Light The armed light is “on” when the system is armed. The armed
Bypass Light The bypass light is “on” when any zone in this keypad’s
Cancel Light The cancel light will flash during an abort delay time. Entering
Chime Light The chime light is “on” when the chime feature is “on”; “off”
Exit Light The exit light is “on” during the exit delay. Please note that the
Fire Light A steady fire light means a fire zone has been faulted. A
Power Light The power light is on if the primary power is on. The power
Ready Light The ready light is “on” when the system is ready to arm and
Stay Light The stay light is illuminated when all
Instant Message The LCD display will read “Instant“ when the entry/exit door(s)
light is “off” when it is disarmed. The armed light will flash
when there has been an alarm during the previous arm cycle.
partition is bypassed. If the bypass light is “off”, no zones are
bypassed.
a code followed by the [CANCEL] key during or after an
alarm report to the central station will cause the cancel light
to come on. It will stay on until the central station has
received the cancel report. NOTE: The cancel feature must
be enabled. (See "Cancel/Abort Feature" on page 10.)
otherwise.
light will flash during the last 10 seconds of the exit d elay as a
warning that the time is running out. (The user may want to
disarm the system if the exit light is flashing in order to
prevent an alarm. The user may then re-arm the system and
exit before the delay expires.)
rapidly flashing fire light means that a fire zone is in a trouble
condition.
light will flash if the system has a low battery condition.
“flashes” if ready to force arm. The ready light is “off” when
the system is not ready to arm because of a zone(s) being
faulted.
interior zones are
bypassed.
have no delay. (See “Arming System in Stay Mode”, page 8.)
The doors can be changed from instant to delay (toggled) by
pressing the [STAY] key when the system is armed.
6
NX-148E-CF
KEYPAD FUNCTIONS
ARMING YOUR SYSTEM IN THE “AWAY” MODE
AWAY is utilized when the user is going away from the premise and wants the
interior protected. Listed below are the steps to arm in the AWAY Mode:
Step 1 Close all protected doors and windows.
Ready light will be on or
flashing when all protected
zones and sensors are
secure. NOTE: If any zones
are bypassed, a sensor in
that zone can be violated without affecting the ready light.
The security system will not
arm if the ready light is off.
Refer to "Making Your
System Ready to Arm".
If the power light is off, you have no AC power. Restore power if
possible. If not, contact the installing company.
Step 2 Enter your 4 or 6 digit user code to arm the system.
The armed and exit lights will illuminate.
You may now leave the building.
IMPORTANT!
The exit light will flash rapidly for the last 10 seconds of the exit delay as a
warning to the user that the exit time is about to expire. The user may wish
to disarm and rearm the system if more time is needed.
MAKING YOUR SYSTEM READY TO ARM
If the ready light is not on or if it is flashing, a zone is not secure. To identify this
zone, use the scroll keys • – to the right of the display to browse through the
zones that are not normal. If you wish to bypass or unbypass one of these zones,
press the [BYPASS] key while that zone is being displayed. When finished
viewing the zones, press the # key to return to the code entry screen.
System Ready
Type Code to Arm
System Not Ready
For help, press º
System Armed
All Zones Secure
NX148E-CF
7
ARMING YOUR SYSTEM IN THE “STAY” MODE
STAY is utilized when the user is inside the premise and wants protection around
the perimeter. The steps to arm in the STAY Mode are as follows:
Step 1 Close all protected doors and windows.
Ready light must be on or flashing (force armed) when all protected
zones and sensors are secure. NOTE: If any zones are bypassed,
a sensor in that zone can be violated without affecting the ready
light.
The security system will not arm if the ready light is not on or flashing.
If the power light is off, you have no AC power. Restore power if
possible. If not, contact the installing company for service.
Step 2 Enter your 4 or 6 digit user code. (Optional, if programmed.)
If “Auto Bypass” is enabled, all interior zones will be bypassed if you
do not leave through a designated entry/exit door. If Auto Bypass is
enabled, omit Step 3.
When “Auto Instant” is enabled, if you do not leave through a
designated entry/exit door, the display will read “Instant”, indicating
that the entry/exit doors no longer have an entry delay. If “Auto
Instant” is enabled, omit Step 4.
Step 3 Press the [STAY] key.
The stay light will illuminate indicating that all interior zones are
bypassed. (All interior devices will bypass automatically, giving the
user freedom of movement within the interior area.)
The bypass light will illuminate if any zone(s) are bypassed. If any
zone (s) have been bypassed previously by the user, the light(s)
corresponding to the bypassed zone(s) will illuminate, alerting the
user that a zone(s) may be unprotected and can be faulted without an
alarm.
Step 4 To toggle from a “delayed entry” mode to an “Instant” mode, press the
[STAY] key again.
The LCD display will read
“Instant” meaning the entry/exit
doors do NOT have an entry
delay.
System Ready
Type code to arm
System Armed
Instant
8
NX-148E-CF
USING THE QUICK ARM
The Quick Arm feature may be used if it is enabled. Quick Arm will allow the user
to arm the security system in the AWAY mode by pressing the [EXIT] key. The
system can be quick armed in the STAY mode by pressing the [STAY] key. This
feature is used for ARMING ONLY, and will not disarm the security system. This is
ideal for a maid or baby sitter code, etc.
CHANGING MODES WHILE YOUR SYSTEM IS ARMED
Step 1 Pressing the [STAY] key will turn on/off (toggle) a delay on Entry/Exit
doors. The “Instant” message will toggle on the LCD display.
Step 2 (Optional, if programmed.) Press the [BYPASS] key at this time to turn
on/off (toggle) all designated interior zones. If all interior zones are not
bypassed, the stay light will extinguish.
Step 3 (Optional, if programmed.) When armed, pressing the [EXIT] key will
start the Exit delay, enabling you to leave the building.
IMPORTANT!
An alarm will be created if the “Instant” message is ON at this time and you reenter the building. You may re-initiate an entry/exit delay by pressing the [STAY]
key again. The “Instant” message will disappear.
DISARMING YOUR SYSTEM
When you enter the protected area through one of the designated Entry/Exit doors,
the keypad control will sound a continuous tone for the duration of the entry delay
time, or until you enter a valid code.
Step 1 Enter a valid user code.
Step 2 The red armed light will go off and
the tone will stop. The security
system is now DISARMED. If a valid code is not entered before the end
of the entry delay, an alarm will occur. NOTE: If the red armed light is
flashing during the entry delay, the alarm system has been activ ated
in your absence. Leave the building immediately and call your alarm
company and/or the police from a safe location.
Type code to
Disarm
NX148E-CF
9
Proc
edure #1
CANCEL / ABORT FEATURE (Optional, if programmed)
The cancel light will flash during an abort delay time. If a code is entered followed
by the [CANCEL] key while this light is flashing, all abortable reports will stop the
communication process. NOTE: The abort feature must be enabled. Entering a
code followed by the [CANCEL] key during or after an alarm report to the central
station will cause the cancel light to come on. It will stay on until the central station
has received the cancel report. NOTE: The cancel feature must be enabled.
BYPASSING ZONES
If you wish to bypass one or more zones, this must be done while the system is in
the disarmed state. If the zone is not known, refer to Procedure #2.
If you know the number of the zone to bypass, use the
following:
Step 1 Press the [BYPASS] key.
Step 2 When the LCD prompts for a code (optional, if programmed), enter your
user code.
Step 3 The bypass light flashes.
Step 4 Enter the zone you wish to bypass. (Example: Press 6 for zone 6 or
1 1 2 for zone 112.)
Step 5 Press the [BYPASS] key again. The zone is now bypassed.
Step 6 Repeat steps 4 and 5 for any other zone(s) that need to be bypassed.
Step 7 Press the [BYPASS] key again OR press # to exit the Bypass Mode.
The bypass light will stop flashing upon exiting the Bypass Mode.
Pressing the • – scroll keys will display all bypassed zones. Press
the # key to exit this viewing mode.
10
NX-148E-CF
If you do not know the number of the zone you wish to bypass,
Procedure #2
use the following steps:
Step 1 Press r • The description for zone 1 will be displayed.
Step 2 Use the • – scroll keys to browse through the custom descriptions
for the zones in this system.
Step 3 To bypass or unbypass a specific zone, press the [BYPASS] key while
that zone is displayed.
Step 4 When finished, press the # key to return to the code entry screen.
GROUP BYPASS
By pressing the [BYPASS] key, followed by the 0 key, then the [BYPASS] key
again, all zones that are designated as group bypass zones will be bypassed.
Press the [BYPASS] key again to exit group bypassing.
UNBYPASSING
To manually unbypass zones, perform the bypassing procedure on a zone that is
already bypassed. NOTE: All zones will automatically be unbypassed each time
the system is disarmed.
EMERGENCY ACTIVATION KEYS
NOTE: You must press and hold these keys for 2 seconds to activate these
functions. Your system may not be programmed for these activations.
Fire Key - If programmed, you can activate the Fire alarm by pressing the
Emergency Activation [Fire] key for two seconds. If your system is connected to a
monitoring center, an emergency report could be sent to that center. This key
should only be pressed in an emergency situation requiring response by fire
department personnel.
NX148E-CF
11
Auxiliary Key - If programmed, you can activate the auxiliary alarm by pressing
the Emergency Activation [Auxiliary] key for two seconds. If your system is
connected to a monitoring center, an emergency report could be sent to that
center. This key should only be pressed in an emergency situation requiring
response by emergency personnel.
Police (Panic/Hold-Up) Key - If programmed, when the Emergency Activation
[Police] key is pressed for two seconds, a local audible alarm will sound. If your
system is connected to a monitoring center, an emergency report could be
transmitted to that center. These keys should only be pressed in an emergency
situation requiring immediate response by law enforcement personnel. NOTE:
Some Panic/Hold-Up alarms are programmed to be silent at the protected site
while reporting an alarm to the monitoring center. Check with your installing
company to determine how your security system will respond to the Panic/Hold-Up
activation.
FUNCTION MENU
The functions listed below are found in the Function Menu.
Step 1 Press r The display will now begin scrolling though a list of functions
and the corresponding numbers associated with those functions.
Step 2 Press the number listed on the display in order to access that particular
function. Hint: If you already know the function numbers simply press [r] followed
by the function number.
The following list of menu selections will scroll automatically. NOTE: Some of the
functions are not listed because they are installer level functions. Each time the
[r] key is pressed the next menu item will be displayed. Press # to exit to this
menu.
Select an Option
Press for Help
This is a sample of the display. The list
below reflects the available functions.
ù=Zone Review
0=Set Tone 45=Display Test 7=Detector Reset EXIT=Silent Exit
1=Master Mode 46=Light
2=Service Check
3=Alarm Memory 5=User PIN 97=Set Date/Time
44=Test 6=User Authority CHIME=Walk Test
Control
49=Español
90=Log Review
91=View Settings
12
NX-148E-CF
VIEW ZONE STATUS
Step 1 Press r • . The LCD Screen will display the zone status.
Step 2 Use the • – scroll keys to browse through the descriptions. The LCD
Screen will display the list of all zones in sequential order by zone number.
Step 3 Press [#] to exit this function.
SETTING THE KEYPAD TONE
Step 1 Press r 0 . Keypad is now in the “Adjust Tone” mode.
Step 2 Press • to adjust the keypad
sounder to higher tones.
Step 3 Press – to adjust the keypad
sounder to lower tones.
Step 4 When the desired tone is reached, press # to set this tone and ex it from
the “Adjust Tone” mode.
VIEW ALARM MEMORY
Step 1 Press r 3 to display the zone(s) on the keypad that created the last
alarm.
Step 2 The LCD Screen will display the zone
description for those zones.
Step 3 Press [#] to exit the alarm memory.
TEST FUNCTION (Optional, if programmed)
If programmed, this function will perform a battery test, communicator test, and/or
a siren test. No alarms will be sent, and no reports will be sent unless a
communicator test is performed, in which case a test signal will be sent.
Step 1 Press r 4 4 . The test will be performed as programmed.
Step 2 If the siren test is performed, enter a user code to silence the siren.
Raise tone º
Lower tone º
Alarm Memory 1
ZONE 1
NX148E-CF
13
DISPLAY TEST FUNCTION
This function will perform a test of the LCD display. No alarms or reports will be
sent.
Step 1 Press r 4 5 . The test will be performed and all of the display
pixels and LED indicators will flash until another key is pressed.
Step 2 Press any key to end the test.
LIGHT CONTROL FOR X-10 DEVICES (Optional, if programmed)
This menu allows you to control up to ten X-10 devices from each keypad.
Step 1 Press r 4 6 . The LCD screen will prompt you to “Select Light
Number 0 - 9”.
Step 2 Enter the number of the X-10 device you want to control. The LCD screen
will show the light number on the left. On the right side of the display it will
prompt you to turn the light (X-10 device) “On” or “Off”.
Step 3 Press the • to turn the X-10 device “On” or press the – to turn the
X-10 device “Off”.
Step 4 The LCD screen will again prompt you to “Select Light Number 0 - 9”.
Step 5 Repeat Steps 2 and 3 until complete.
Step 6 Press # to exit from the X-10 menu.
CHANGE LANGUAGES
This function allows you to switch between the two languages programmed in your
keypad. NOTE
: You must exit any other function mode before attempting to
change languages.
Step 1 Press r 4 9 . The LCD keypad is now toggled to the second
language.
Step 2 Repeat Step 1 to revert to the first language.
14
NX-148E-CF
CHANGING USER CODES
Step 1 Press r 5 . The LCD Screen will prompt for a code.
Step 2 Enter [master code]. The LCD Screen will prompt for a user number.
NOTE: For partitioned systems, if you are changing the code of
another person, you must have access to all partitions, or at least
all of the partitions to which the other person has access.
Step 3 Enter the 2-digit user number. Always use leading zeros when
necessary, i.e. "04" for user number 4.
The LCD keypad will display the current code for this user. Stars (r)
represent blanks. NOTE: To delete
a user code, press [r]-[r]-[r]-[r]
for a 4-digit code or [r]-[r]-[r]-[r]-[r]-[r] for a 6-digit code.
Step 4 Enter the new user code for that individual. If you are changing the
current code, you may use the up and down scroll keys to select the digit
to change and enter the correct number. If it rejects the code because of
duplication or such, the sounder will beep 3 times.
Step 5 If another user code needs to be programmed, return to step 3 and enter
the user code.
Step 6 Press # while the LCD screen is prompting for a new user to exit
Code Programming,
ASSIGNING USER CODE AUTHORITY LEVELS
Assign authority levels to users by following the steps below. Assign user codes
before assigning authority levels.
NOTE: You must have authority to the partition you wish to add or remove
from another person’s authority.
Step 1 Press r 6 . The LCD Screen will now prompt for a code.
Step 2 Enter [master code]. The LCD Screen will prompt for a user number.
Step 3 Enter the 2-digit user number. Always use leading zeros when
necessary, i.e. "04" for user number 4. The LCD will now prompt you for
the attributes in the following chart.
NX148E-CF
15
PROMPT
Outputs used? » DO NOT CHANGE THIS SEGMENT!
Open / Close Rprt?
Bypass enable?
Arm / Disarm?
Master code?
Sched arm only?
Arm only?
Reserved
Output 4 ?
Output 3 ?
Output 2 ?
Output 1?
(These are for use by a professional installer only.)
0=No 1=Yes
Your keypress will apply to the user code you entered in
Step 3.
If these messages appear on the LCD screen, press the [r]
key until you return to the prompt for the user code or until
you exit this adjust mode.
Step 4 NOTE: The LCD will now display all of the partitions to which this user
has access. If you wish to remove a partition, press the partition number
on the keypad, and the display will mark that partition with a (-) hyphen
indicating access has been removed. If you wish to re-establish user
access to the partition, press the partition number again.
Step 5 Press [r] to save the data. The LCD will then prompt you for the next
user code.
Step 6 If another user code needs to be programmed, return to Step 3. If not,
press [#] to exit this feature without saving the data.
RESET FUNCTION
This function is used to reset Smoke Detectors, Zone Troubles, and Zone
Tampers.
Step 1 Disarm the system if it is not already disarmed.
Step 2 Press r 7 . Resets have now been performed.
Step 3 If the keypad begins beeping, the reset did not execute properly. Enter
your code to silence the keypad. Wait a few minutes and repeat step 2
to attempt another reset. If the keypad still beeps after repeated
attempts, please contact your installer.
16
NX-148E-CF
READING THE EVENT LOG
The control panel has an event log that can be retrieved using a master code.
This log contains a listing of the events along with date, time, and partition where
the event occurred.
Step 1 To view the log, press r 9 0 . The LCD screen will prompt you
for a code.
Step 2 Enter your master code. The LCD screen will now show the most
recent event.
Step 3 To view the events from most recent to the oldest, press the – down
scroll key.
Step 4 To view the events from the oldest to the newest, press the • up scroll
key. The display contains the following information.
Event
Date
(Month/Day)
This screen shows an opening of Partition 3 on September 25
user 75. The [r] shows that this event is not programmed to be reported to the
central monitoring station. Refer to Appendix A on page 25 for a list of possible log
messages.
Open 75
º ³ User or Zone ID
9/25 17:57 P3*
º » Indicates partition
ü Time shown in and r indicates an
24 hour format event not reported
th
at 5:27 p.m. by
ADJUSTING THE VIEW / BRIGHTNESS OF THE LCD
Step 1 Enter r 9 1 . The LCD Screen will prompt for a code.
Step 2 Enter [master code]. The LCD will now prompt you to raise or lower the
view.
Step 3 Using the scroll keys to the right of the LCD, you can raise or lower the
viewing angle of the text.
Step 4 To advance to the Brightness option, pres s [r]. The LCD will prompt you
to brighten or dim the LCD lighting. Use the scroll keys again to adjust to
desired brightness.
Step 5 When completed, exit by pressing [r].
NX148E-CF
17
SETTING THE SYSTEM CLOCK
Step 1 Enter r 9 7 . The LCD Screen will prompt for a code.
Step 2 Enter [master code]. The time and date will be displayed with the
current hour flashing.
Step 3 Use the • – scroll keys to select the proper hour.
Step 4 Press the r key to move to the minutes, day of week, date, month,
and year.
Step 5 Repeat Steps 3 and 4 until the entire time and date are set.
USING THE DOOR CHIME FEATURE
The door chime is turned on or off by pressing the [CHIME] key. If the chime is on,
the chime light will be illuminated. If the chime is off, the chime light will be off.
Each press of the [CHIME] key will toggle the chime feature on/off and produce a
momentary ding-dong sound.
18
NX-148E-CF
PARTITIONED SYSTEMS OPERATION
This system is “ is not “ partitioned.
If your system is multi-partitioned and the keypad resides in one partition, your
keypad will provide the status of the zones in your partitioning by using the screen
messages described earlier in this manual. The Master Mode of operation allo ws
you to temporarily access any partition (providing your code is authorized) within
the system and to perform functions in other partitions. Read this entire manual to
help you understand the different screen messages that will be displayed from
your keypad.
NOTE: r 1 will temporarily access the Master Mode. The keypad will
revert back to its assigned partition 60 seconds after a keypress, or 10 seconds
without a keypress. Press [#] to exit this mode.
LIGHTS IN PARTITIONING MASTER MODE
ARMED will illuminate if ALL
READY will illuminate if ALL
if all areas are Ready or Force armable.
FIRE will illuminate if ANY one area has a Fire condition. The fire light will
flash if ANY area has a Fire Trouble condition.
POWER will illuminate if the primary power is connected to the NX-8 control
panel. It will flash if the system has a low standby battery condition.
STAY will illuminate if ANY area has the stay light on.
CHIME will illuminate if ANY partition is in the "Chime" mode.
EXIT will illuminate if ANY area is timing an ex it delay. It will flash if ANY area
is in the last 10 seconds of an exit delay.
BYPASS will illuminate if ANY area has a zone bypassed.
CANCEL will flash if ANY partition is in an abort delay time. If a code is
entered followed by the [CANCEL] key during or after an alarm report, the
cancel light will illuminate and remain constant until the central station has
received the cancel report.
SOUNDER will sound if ANY area has the sounder on. This includes Entry
delay, Exit delay, Chime, and Alarm.
DISPLAYS IN THE PARTITIONING MASTER MODE
ARMED and READY STATUS
The LCD screen will display the Armed and Ready status of ALL eight (8)
partitions if any or all of the areas is armed or not ready.
partitions are armed.
partitions are "Ready". The ready light will flash
NX148E-CF
19
Ready 12345678
Armed 1234-678
System Ready
Type code to arm
ARMING AND DISARMING MULTIPLE PARTITIONS
To arm/disarm multiple partitions, enter a code that has arm/disarm authority for
ALL of the partitions to be armed/disarmed. The following display will appear on
the LCD screen.
12-45-78 Disarm º
--3 67- Arm º
LCD DISPLAY FOR AREA
TOP LINE OVER BOTTOM LINE
Blank
Blank
Dash (-)
Dash (-)
Flashing Area #
Dash (-)
Dash (-)
Flashing Area #
Area #
Dash (-)
Dash (-)
Area #
To disarm all of these areas, press the • up scroll key.
To arm all of these areas, press the – down scroll key.
To toggle a single area between the armed and disarmed conditions, press
[r][Area number]. For example: If Area 4 is armed, [r] [4] will disarm Area 4.
If Area 4 is disarmed, [r] [4] will arm it.
Press [STAY] during the exit delay to bypass all interior zones in the exit delay .
To control the individual areas, refer to the following section.
This display is reflecting all 8 areas are
Ready, and Area 5 is disarmed. NOTE: If a
number is flashing on the Armed line, that
area is armed Instant. If a number is flashing
on the Ready line, that area is ready to be
Force Armed.
If ALL areas are disarmed and ready to arm,
this display will appear on the LCD screen.
The numbers on the top line represent the
disarmed areas to which this code has
access. The numbers on the bottom line
represent the areas that are armed. Refer to
the following table for possible conditions.
CONDITION
Area Not used or Authorized
Area Not Ready
Area Ready to Force Arm
Area Armed Instant
Area Disarmed & Ready to Arm
Area is Armed
20
NX-148E-CF
OPERATING INDIVIDUAL AREAS IN THE MULTI-PARTITION MODE
Enter a code that is a valid arm/disarm code for the area you wish to operate. The
following display will appear on the LCD screen.
12-4—78 Disarm º
--3-56-- Arm º
To toggle between the armed and disarmed states of an individual area, press [r]
[Area number].
To operate an individual area, enter the number of the partition you wish to
operate. The LCD keypad will now operate as a single area keypad. All keys and
functions entered will affect this individual partition only. The lights and display
represent the status of that partition only. The word "System" will be replaced with
the word "Area #". The following is an example of this feature. To exit this screen,
press [#].
Area 5 Ready
Type code to arm
SILENCING ALARMS IN THE MULTI-PARTITION MODE
If the keypad is sounding an alarm or the siren is running, it can be silenced by
entering a code with the authority for the area(s) that are in alarm. NOTE: The
[EXIT], [BYPASS], and [STAY] keys will only work if an individual partition is
selected.
Only the areas authorized by this code will
appear.
Area 5 is selected and Area 5 is ready to
arm. To exit the individual partition mode,
enter [#]-[#].
NX148E-CF
21
KEYPAD CONTROL TONES (BEEPS)
A sounder is built into the keypad and may sound for any of the following
reasons:
Beeps for all keypresses.
Sounds a continuous tone during the Entry delay time.
Pulses when a day zone is violated while the system is disarmed.
Pulses when a FIRE zone has a trouble condition.
Pulses when the armed status changes and the AC power is off.
Beeps 3 times for trying to arm with the “READY” light off, if “FORCE
ARMING” has not been selected.
Beeps 1 second for the ‘CHIME” feature.
Beeps 1 second at the end of the exit delay.
Beeps to indicate telephone line fault if selected.
Beeps during an exit delay; beeps rapidly for the last 10 seconds of
an exit delay; and beeps 1 second at the end of the exit delay.
Pulses when one or more of the following conditions are detected:
Zone or Box Tamper, Low Battery, AC Power Fail, or Expander
trouble.
Beeps 3 times every minute indicating a low battery or missing
transmitter is detected (if wireless device is in system). Entering code
will suppress the sounder for 12 hours.
Entering a valid code will silence the keypad sounder when it is pulsing. The
arm/disarm state of your system will not change when entering a code to silence a
pulsing keypad sounder. Please contact your installer if a trouble condition exists .
22
NX-148E-CF
SERVICE DISPLAY
The following message will be displayed periodically if the security system requires
service. Call your service provider promptly if this message is observed.
Service Required
Type r2 for help
If you see this display, press r 2 . One or more of the following fault
messages will be displayed. Use the scroll keys • – to browse through
them. To exit the service messages, press [#]-[#].
Control
Box tamper
Control
Fail to Comm.
Control
Ground fault
Control
Loss of time
Control
Low Battery
Control
Over-current
Control
Phone trouble
Control
Power trouble
Control
Siren trouble
(Optional) The Box Tamper circuit has
activated.
The control attempted to communicate
a message to the Central Station, but
was unsuccessful.
A short to ground has been detected on
a control circuit.
Your system has lost total power and
needs the clock reset.
The standby battery is low.
A short circuit of a control’s power
supply has occurred.
The phone line connected to the control
is not operating properly.
The main power to your system is not
on.
Open circuit has occurred on the bell or
siren circuit.
Expansion
Aux. comm. fail
NX148E-CF
An auxiliary reporting device has failed
to communicate.
23
Expansion
Box tamper
Expansion
Low Battery
Expansion
Over-current
Expansion
Power trouble
Expansion
Siren trouble
Expansion
RF Jammed
Expansion
Trouble
Zone
Lost, Press r
Zone
Low Batt, Press r
A box containing an expansion device
has been opened.
An expansion power supply has a low
battery.
A short circuit of an expansion devices’
power supply has occurred.
The main power to an expansion pow er
supply is not on.
An expansion device has detected
some form of trouble on the bell or
siren circuit.
A radio receiver is being jammed.
(Not applicable to all controls.)
An expansion device or keypad is not
reporting to the control panel.
A wireless or multiplexed zone device is
not reporting to the control. Press [r]
to identify the zone.
A wireless device has a low battery.
Press [r] to identify the zone.
Zone
Tamper, Press r
Zone
Trouble, Press r
24
A zone is tampered. Press [r] to
identify the tampered zone.
A zone is experiencing some form of
trouble (probably wiring). Press [r] to
identify the zone.
NX-148E-CF
APPENDIX A - EVENT LOG
NOTE: Your system may not have all of the features listed in this table.
DISPLAY DESCRIPTION
TXlobat
ZN Lost
Duress
Man Fire
Aux 2
Panic
KP Tamper
BoxTamp
AC Fail
OverCur
Srn Tamp
Tel Flt
Exp Trb
Log Full
Open
Close
Exit Err
Rec Close
Autotest
Start Prog
End Prog
Start Dnld
End Dnld
Transmitter
Low Battery
Zone Lost A wireless or multiplexed zone device is not
Duress The control has been armed or disarmed with a
Manual Fire Keypad “Fire” has been activated.
Auxiliary 2 Keypad “Medical” has been activated.
Panic Keypad “Panic” has been activated.
Keypad
Tamper
Box Tamper The box tamper circuit has been activated.
AC Fail AC failure has been detected.
Over Current A short circuit of a power supply has occurred.
Siren Tamper A siren or speaker tamper has been detected.
Telephone
Fault
Expansion
Trouble
Log Full The event log is full. Old events will be pushed
Open Reports user number, date, time and partition of
Close Reports user number, date, time and partition of
Exit Error Entry/Exit zone was faulted at the instant the
Recent Close An alarm occurred within 5 minutes after the
Auto Test Sending a communicator test at a specified
Start
Programming
End
Programming
Start Download
End Download Download session is ended.
The transmitter has a low battery.
reporting to the control.
Duress code.
The keypad tamper has been activated.
A telephone fault or tamper has been detected.
An expansion device or keypad is not reporting
to the control.
out as new ones enter the log.
opening.
closing.
exit delay expired.
control was armed.
interval.
Local programming is started.
Local programming is ended.
Download session is started.
NX148E-CF
25
DISPLAY DESCRIPTION
Cancel
Cancel System is disarmed and the Cancel button was
pressed within 5 minutes of an alarm.
Gnd Flt
Man Test
Ground Fault A short to ground has been detected.
Manual Test Bell and/or communicator test while system is in
disarmed condition.
Re-exit
Re-Exit The exit delay has been re-started without
disarming the system.
Output Trip
Output Trip A trip has occurred on an expander auxiliary
output.
Data Lost
Data Lost Communication of a signal has failed (log only
event).
Walk-test
End Test
Cross-Trip
Walk-Test A zone “Walk-Test” mode has been activated.
End Test Test has been ended.
Cross Trip The first zone of a cross zone has been tripped
(log only).
Expansion
Event
Partial Arm
Listen In
Service Start
Service End
Code Entry
First Open
Last Close
Sprnklr
Clock Set
RF Jammed
CleanMe
Expansion
Event
Partial Arm Reports a closing in the stay mode.
Listen In A listen in function has been activated.
Service Start Technician is on site.
Service End Technician is off site.
Code Entry A code has been entered.
First Open Reports when the first partition is disarmed.
Last Close Reports when the last partition is armed.
Sprinkler Instant sprinkler supervisory report
Clock Set Clock has been reset.
RF Jammed A wireless expansion module is jammed
CleanMe A smoke detector requires cleaning.
An expansion module created an undefined
event.
26
NX-148E-CF
EMERGENCY EVACUATION PLANS
An emergency evacuation plan should be established for an actual fire alarm
condition. For example, the following steps are recommended by the National Fire
Protection Association and can be used as a guide in establishing an evacuation
plan for your building.
Draw up a floor plan of your home. Show windows, doors, stairs, and rooftops that
can be used for escape. Indicate each occupant's escape routes. Always keep
these routes free from obstruction. Determine two means of escape from each
room. One will be the normal exit from the building. The other may be a window
that opens easily. An escape ladder may have to be located near the window if
there is a long drop to the ground below. Set a meeting place outdoors for a
headcount of the building occupants. Practice escape procedures. In a home,
sleep with bedroom door closed; this will increase your escape time. If you
suspect fire, test the door for heat. If you think it is safe, brace your shoulder
against the door and open it cautiously. Be ready to slam the door if smoke or
heat rush in. Practice escaping to the outdoors and meeting in an assigned spot.
Call the Fire Department from a neighbor's phone.
NOTE: After the installation of your Security System has been completed, notify
your local Fire and Police Departments to give them your name and address for
their records. Early warning fire detection is best achieved by the installation of
fire detection equipment in all rooms. This equipment should be installed in
accordance with the National Fire Protection Association's Standard 72. For
additional information write the National Fire Protection Association, Batterymarch
Park, Quincy, MA 02269.
NX148E-CF
27
SYSTEM NOTES
NX-148E-CF USERS MANUAL
NX148ECFUB03 REV B (MAY2003)
Loading...
