Wireless Access Point

802.11g

Manual

Table of Contents

Chapter 1 Introduction..............................................................................

1

1.1 Package Contents ..........................................................................................

2

1.2 Features..........................................................................................................

2

1.3 Specifications ................................................................................................

2

1.4 Physical Description......................................................................................

3

Chapter 2 Wireless LAN Access Point Connection ................................

5

Chapter 3 Wireless LAN Access Point Configuration............................

6

3.1 Getting Started...............................................................................................

6

3.2 Configuring the Access Point......................................................................

11

3.2.1

Client Mode configuration.................................................................................

12

3.2.2

AP Mode configuration......................................................................................

15

3.2.3

Repeater Mode configuration ............................................................................

17

3.2.4

P2P Mode configuration ....................................................................................

20

3.2.5

PMP Mode configuration .................................................................................

21

3.2.6

WEP Setting..................................................................................................

23

3.2.7

WPA Setting .................................................................................................

25

3.2.8

Advanced Setting..........................................................................................

26

3.2.9

Access Filter .................................................................................................

27

3.2.10

Status Setup ..................................................................................................

29

3.2.11

Admin Setup .................................................................................................

30

3.2.10

LAN Setup ....................................................................................................

32

Charpter 4 Troubleshooting ...................................................................

33

Chapter 1 Introduction

This product is an access point for IEEE 802.11g/b 2.4GHz wireless network. You can use this access point to build up a wireless LAN.

The product supports WPA-PSK, WEP, ESSID and MAC address filter functions to consolidate the wireless network security. With ESSID authentication, WPA-PSK, 64/128 bit WEP encryption and MAC address filtering you can prevent unauthorized wireless stations from accessing your wireless network.

The product’s dipole antenna is detachable by connecting to a RP-SMA connector. Users can install a high gain antenna to the connector for better network link quality so that you can build wireless network with more flexibility.

This product provides easy to use user interface and allows users to configuring from web browser. With the versatile of features, this product is the best choice for you to integrate your wireless and wired network seamlessly.

1.1 Package Contents

The Access Point includes the following items:

One Access Point

One Power Adapter

One User’s Manual

1.2 Features

Complies with the IEEE 802.11g/b 2.4GHz specification.

High data rate 54, 48, 36, 24, 18, 12, 11, 5.5, 2 and 1Mbps network speed.

Seamlessly integrate wireless and wired Ethernet LAN networks. Auto rate fallback in case of obstacles or interferences.

Provide 64/128-bit WEP Data Encryption function to protect the wireless data transmissions.

Supports Web-based configuration.

1.3 Specifications

Standards: IEEE 802.11g/b (Wireless), IEEE 802.3 (Wired) Data Rate: 54/48/36/24/18/12/11/5.5/2/1Mbps auto fallback Security: 64/128-bit WEP Data Encryption

Frequency Band: 2.400~2.4835GHz (Industrial Scientific Medical Band)

Antenna: External detachable dipole antenna (with RP-SMA connector)

Connectors: 10/100Mbps RJ-45 x 1

Power: 12VDC, 1A

Transmit Power: 16dBm (Typical)

LEDs: Power, LAN Link/Activity, Wireless Activity

Dimension: 30(H) x 127(W) x 87(D) mm

Temperature:

Operating: 32~131°F (0~55°C)

Storage: -4~158°F(-20~70°C)

Humidity: 10-90% (Noncondensing)

1.4 Physical Description

Front Panel

On the Access Point’s front panel there are LED lights that inform you of the Access Point’s current status. Below is an explanation of each LED.

LED

Color

Status

Description

Power

Green

Lit

Power is supplied.





Off

No Power.

Wireless

Green

Flash

Antenna is transmitting or receiving data.

Activity











Off

Antenna is not transmitting or receiving data.

LAN

Green

On

A valid link is established.

Link/Activity











Flash

It is transmitting or receiving data.





Off

No link is established.

Back Panel

Access Point’s connection ports are located on the back panel. Below is the description of each connection port.

1Antenna Connector

This round connection is standard Reverse SMA connector where any antennas with Reverse SMA connector can connect to the Access Point.

2DC Adapter Port

Insert the power jack of the power adapter into this port.

3LAN Port

The Access Point’s LAN port is where you connect to your LAN’s network devices.

4Reset

The Reset button allows you to do one of two things.

1)If problems occur with your Access Point, press the reset button with a pencil tip (for less than 5 seconds) and the Access Point will re-boot itself, keeping your original configurations.

2)If problems persist or you experience extreme problems or you forgot your password, press the reset button for longer than 5 seconds and the Access Point will reset itself to the factory default

settings (warning: your original configurations will be replaced with the factory default settings).

Chapter 2 Wireless LAN Access

Point Connection

1.Locate an optimum location for the Wireless LAN Access Point.

The best location for your Access Point is usually at the center of your wireless network, with line of sight to all of your mobile stations.

2.Connect the Wireless LAN Access Point to your router, hub or switch.

Connect one end of standard UTP cable to the Access Point’s LAN Port and connect the other end of the cable to a switch, a router or a hub. The Access Point will then be connected to your existed wired LAN Network.

3.Connect the DC Power Adapter to the Wireless LAN Access Point’s Power Socket.

Only use the power adapter supplied with the Access Point. Using a different adapter may damage the product.

The Hardware Installation is completely also you can start to enjoy the wireless network environment.

Please follow below step to access the UI to configure the more function.

Chapter 3 Wireless LAN Access

Point Configuration

3.1 Getting Started

This Access Point provides web-based configuration tool allowing you to configure from wired or wireless stations. Follow the instructions below to get started configuration.

From Wired Station

1.Make sure your wired station is in the same subnet with the Access Point.

The default IP Address and Sub Mask of the Access Point is:

Default IP Address: 192.168.2.1 Default Subnet: 255.255.255.0

Configure your PC to be in the same subnet with the Access Point.

1a) Windows 95/98/Me

1.Click the Start button and select Settings, then click Control Panel. The Control Panel window will appear.

2.Double-click Network icon. The Network window will appear.

3.Check your list of Network Components. If TCP/IP is not installed, click the Add button to install it now. If TCP/IP is installed, go to step 6.

4.In the Network Component Type dialog box, select Protocol and click Add button.

5.In the Select Network Protocol dialog box, select Microsoft and TCP/IP and then click the OK button to start installing the TCP/IP protocol. You may need your Windows CD to complete the installation.

6.After installing TCP/IP, go back to the Network dialog box. Select TCP/IP from the list of Network Components and then click the Properties button.

7.Check each of the tabs and verify the following settings:

Bindings: Check Client for Microsoft Networks and File and printer sharing

for Microsoft Networks.

Gateway: All fields are blank.

DNS Configuration: Select Disable DNS.

WINS Configuration: Select Disable WINS Resolution.

IP Address: Select Specify an IP Address. Specify the IP Address and

Subnet Mask as following example.

1IP Address: 192.168.2.3 (any IP address within 192.168.2.2~192.168.2.254 is available, do not setup 192.168.2.1)

2Subnet Mask: 255.255.255.0

8.Reboot the PC. Your PC will now have the IP Address you specified.

1b) Windows 2000

1.Click the Start button and select Settings, then click Control Panel. The Control Panel window will appear.

2.Double-click Network and Dial-up Connections icon. In the Network and Dial-up Connection window, double-click Local Area Connection icon. The Local Area Connection window will appear.

3.In the Local Area Connection window, click the Properties button.

4.Check your list of Network Components. You should see Internet Protocol

[TCP/IP] on

your list. Select it and click the Properties button.

5.In the Internet Protocol (TCP/IP) Properties window, select Use the following IP address and specify the IP Address and Subnet mask as following.

IP Address: 192.168.2.3 (any IP address within

192.168.2.2~192.168.2.254 is available, do not setup 192.168.2.1) Subnet Mask: 255.255.255.0

6. Click OK to confirm the setting. Your PC will now have the IP Address you

specified.

1c) Windows NT

1.Click the Start button and select Settings, then click Control Panel. The Control Panel window will appear.

2.Double-click Network icon. The Network window will appear. Select the Protocol tab from the Network window.

3.Check if the TCP/IP Protocol is on your list of Network Protocols. If TCP/IP is not installed, click the Add button to install it now. If TCP/IP is installed, go to step 5.

4.In the Select Network Protocol window, select the TCP/IP Protocol and click the

Ok button to start installing the TCP/IP protocol. You may need your

Windows CD to

complete the installation.

5.After you install TCP/IP, go back to the Network window. Select TCP/IP from the list of Network Protocols and then click the Properties button.

6.Check each of the tabs and verify the following settings:

IP Address: Select Specify an IP address. Specify the IP Address and

Subnet Mask as following example.

3IP Address: 192.168.2.3 (any IP address within 192.168.2.2~192.168.2.254 is available, do not setup 192.168.2.1)

4Subnet Mask: 255.255.255.0

DNS: Let all fields are blank.

WINS: Let all fields are blank.

Routing: Let all fields are blank.

7.Click OK to confirm the setting. Your PC will now have the IP Address you specified.

2. Enter 192.168.2.1 from Web Browser to get into the Access Point’s configuration tool.

3.A screen will be popped up and request you to enter user name and password. The default user name and password is as follows.

User Name: Admin

Password: 1234

Enter the default user name and password, then press OK button directly.
