Intel BXNUC10I7FNH User Manual

Intel® NUC 10 Performance

Unleash yoUr inner creator.

Experience the new size of powerful.

create.

BETTER

3x

FASTER
WIRELESS
SPEEDS

2

consUme.
repeat.

Featuring the power of 10th generation Intel® Core™

processors, the Intel® NUC 10 Performance has the

power to create content as well as consume it. Record

and mix music, add animation effects to your video

edits, or over-binge your favorite shows in stunning

ultra high-def 4K. Whatever it is, this Mini PC brings

full-size PC performance at a size small enough to fit

in the palm of your hand.

Available with a choice of hard drive configurations to

meet your speed and storage needs, the NUC 10

OVERALL

PERFORMANCE

FE ATURES

• 10th generation Intel® Core™ processors

• HDMI* 2.0

• Thunderbolt™ 3

• Support for three 4K60 displays

• Four USB 3.1 ports

• Intel® WiFi 6

• Bluetooth*

• Intel® Gigabit LAN

• SDXC slot with UHS-II support

• 3-year limited warranty

4

1

8x

USAGES

• Home theater

• Home oce productivity

• Casual gaming

AVAILABLE SKUs

Intel® NUC Mini PC

Intel® NUC Kit

MORE
BANDWIDTH WITH
THUNDERBOLT 3

3

Performance has the ports to connect every last

peripheral and keep your data moving at top speed.

And with triple display support, you can multitask

across multiple screens and give your brilliance room

to spread out.

Intel® NUC 10 Performance:
A Workhorse for a Range of Needs

intel® nUc 10 perfromance mini pcs and kits

Built with 10th generation Intel® Core™ i7 processors

Kits Mini PCs

NUC10i7FNH NUC10i7FNK NUC10i7FNHA NUC10i7FNHJA NUC10i7FNKPA NUC10i7FNHC NUC10i7FNKP

Processor

Graphics

Memory

Storage

Other Features
& Technology

Geo-Specic

Power Cord

Operating
System

What’s Needed

Dual-channel DDR4 SODIMM slots

M.2 22x42/80 slot,

2.5" 7mm SATA drive bay

Intel® WiFi 6 and Bluetooth* v5, Intel® Gigabit LAN, SDXC Card Slot, Consumer Infrared Sensor, Kensington Lock Ready, 3-Year Limited Warranty

US, EU, UK, AU, CN

or No Cord Option

Not Included Windows® 10 Home Not Included

Memory, Storage, Operating System

See page 6 for details

M.2 22x42/80 slot

HDMI* 2.0a, Thunderbolt™ 3, Front USB 3.1 Gen2 Type-C Port (fast charging), 2 USB 3.1 Gen2 Ports,

US, EU US

10th Generation Intel® Core™ i7-10710U Processor

1.1 GHz – 4.7 GHz Turbo, 6 core, 12 thread, 12 MB Cache, 25W

Intel® UHD Graphics, 300 MHz – 1.15 GHz

16 GB Dual-channel

DDR4-2666

256 GB NVMe SSD,

1 TB SATA3 HDD

— — — Operating System

16 GB Intel®

Optane™ Memory,

1 TB SATA3 HDD

US, EU, UK, AU,

or No Cord Option

256 GB NVMe SSD

8 GB Dual-channel DDR4-2666

256 GB NVMe SSD,

1 TB SATA3 HDD

EU CN

256 GB NVMe SSD

intel® nUc 10 perfromance mini pcs and kits

Built with 10th generation Intel® Core™ i5 processors

Kits Mini PCs

NUC10i5FNH NUC10i5FNK NUC10i5FNHJ NUC10i5FNHJA NUC10i5FNHCA NUC10i5FNKPA NUC10i5FNHF NUC10i5FNKP

Processor

Graphics

Memory

Storage

Other Features
& Technology

Geo-Specic

Power Cord

Operating
System

What’s Needed

10th Generation Intel® Core™ i5-10210U Processor

1.6 GHz – 4.2 GHz Turbo, 4 core, 8 thread, 6 MB Cache, 25W

Intel® UHD Graphics, 300 MHz – 1.1 GHz

Dual-channel DDR4 SODIMM slots 8 GB Dual-channel DDR4-2666

M.2 22x42/80 slot,

2.5" 7mm

SATA drive bay

US, EU, UK, AU, CN

or No Cord Option

Not Included Not Included Windows® 10 Home Not Included

Memory, Storage, Operating System

See page 6 for details

M.2 22x42/80 slot

Intel® WiFi 6 and Bluetooth* v5, Intel® Gigabit LAN, SDXC Card Slot, Consumer Infrared Sensor, Kensington Lock Ready, 3-Year Limited Warranty

US, EU, UK, AU,

or No Cord Option

HDMI* 2.0a, Thunderbolt™ 3, Front USB 3.1 Gen2 Type-C Port (fast charging), 2 USB 3.1 Gen2 Ports,

16 GB Intel® Optane™ Memory

1 TB SATA3 HDD

Not Included

Operating System,

Power Cord

256 GB NVMe SSD,

1 TB SATA3 HDD

US, EU, UK, AU,

or No Cord Option

4 GB Dual-channel

DDR4-2666

16 GB Intel®

256 GB NVMe SSD

US EU, UK CN

— Operating System

Optane™ Memory,

1 TB SATA3 HDD

8 GB Dual-channel

DDR4-2666

256 GB NVMe SSD

intel® nUc 10 perfromance mini pcs and kits

Built with 10th generation Intel® Core™ i3 processors

Kits Mini PCs

NUC10i3FNH NUC10i3FNK NUC10i3FNHJA NUC10i3FNHFA NUC10i3FNHF

Processor

Graphics

Memory

Storage

Other Features
& Technology

Geo-Specic

Power Cord

Operating
System

What’s Needed

Dual-channel DDR4 SODIMM slots 8 GB Dual-channel DDR4-2666 4 GB Dual-channel DDR4-2666

M.2 22x42/80 slot,

2.5" 7mm SATA drive bay

Intel® WiFi 6 and Bluetooth* v5, Intel® Gigabit LAN, SDXC Card Slot, Consumer Infrared Sensor, Kensington Lock Ready, 3-Year Limited Warranty

US, EU, UK, AU, CN

or No Cord Option

Memory, Storage, Operating System

See page 6 for details

10th Generation Intel® Core™ i3-10110U Processor

2.1 GHz – 4.1 GHz Turbo, 2 core, 4 thread, 4 MB Cache, 25W

Intel® UHD Graphics, 300 MHz – 1.0 GHz

M.2 22x42/80 slot

HDMI* 2.0a, Thunderbolt™ 3, Front USB 3.1 Gen2 Type-C Port (fast charging), 2 USB 3.1 Gen2 Ports,

EU, UK, AU,

or No Cord Option

Not Included Windows® 10 Home Not Included

US

16 GB Intel® Optane™ Memory,

1 TB SATA3 HDD

EU, UK, AU,

or No Cord Option

— Operating System

CN

intel® nUc 10 perfromance mini pcs and kits

Additional Technical Specications

Processors

NUC10i7FN

• Intel® Core™ i7-10710U (1.1 GHz – 4.7 GHz Turbo,
6 core, 12 thread, 12 MB Cache, 25W)

NUC10i5FN

• Intel® Core™ i5-10210U (1.6 GHz – 4.2 GHz Turbo,
4 core, 8 thread, 6 MB Cache, 25W)

NUC10i3FN

• Intel® Core™ i3-10110U (2.1 GHz – 4.1 GHz Turbo,
2 core, 4 thread, 4 MB Cache, 25W)

Storage Capabilities

NUC10i7FNK, NUC10i5FNK, & NUC10i3FNK

• M.2 22x42/80 key M slot for PCIe* x4 Gen3
NVMe/AHCI or SATA3 SSD

• Full-size SDXC UHS-II slot

NUC10i7FNH, NUC10i5FNH, & NUC10i3FNH

• M.2 22x42/80 key M slot for PCIe x4 Gen3
NVMe/AHCI or SATA3 SSD

• SATA3 SSD, 2.5" 7mm SATA3 bay and port

• Full-size SDXC UHS-II slot

System Memory

• Two DDR4 SODIMM sockets (Dual channel
DDR4-2666 SODIMMs, 1.2V, 64 GB max)

Connectivity

• HDMI* 2.0a port

• Thunderbolt™ 3 port

• Intel® WiFi 6 AX200 2x2

• Bluetooth* v5

• Front: USB 3.1 Gen2 Type- C port with
5V/9V fast phone charging profile

• Front: USB 3.1 Gen2 Type-A port

• Back: Two USB 3.1 Gen2 ports

• Intel® i219-V 10/100/1000 Mbps Ethernet

System BIOS

• 256 Mb Flash EEPROM with Intel® Platform
Innovation Framework for EFI Plug and Play

• Advanced configuration and power interface
V5.0b, SMBIOS2.5

• Intel® BIOS

• Intel® Express BIOS update support

Hardware Management Features

• Voltage and temperature sensing

• ACPI-compliant power management control

Expansion Capabilities

• 2x internal USB 2.0 headers

Audio

• Up to 7.1 multichannel digital audio
via HDMI* or Thunderbolt 3

• 3.5 mm stereo headset jack

• Beam-forming, far-field, quad-mic array

Chassis Size

Tall “H” Chassis

• 4.60" x 4.40" x 2.00"

• 117 mm x 112 mm x 51 mm

Slim “K” Chassis

• 4.60” x 4.40” x 1.50”

• 117 mm x 112 mm x 38 mm

Power Requirements

• 19V

DC 120W (NUC10i7FN models only),

or 90W power supply, with geo-specific
AC cords

Environment Operating Temperature

• 0° C to +35 C

Storage Temperature

• -20° C to +40° C

Safety Regulations and Standards

• IEC/EN/UL 60950-1

• IEC/EN/UL 62368-1

EMC/RF Regulations and Standards

• FCC P art 15B/15C/15E

• CISPR/EN 55032/55024

• ICES-003

• VCCI 32

• BSMI CNS 13438

• KN 32/35

• AS/NZS CISPR 32

• EN 300 328

• EN 301 893

• EN 300 440

• EN 301 489-1/3/17

• EN 62311

• AS/NZS 4268

• AS/NZS 2772.2

• ARPANSA

Environmental Regulations

• EU RoHS

• China RoHS

• Taiwan BSMI RoHS

• REACH

The Power of Small
