User Guide
ideapad D330-10IGM
Read the safety notices and important tips in the
included manuals befo
re using your computer.
Notes
• Before using the product, be sure to read Lenovo Safety and General Information
Guide first.
• The latest electronic compliance and environmental information are available
from the Le
novo compliance information Web sites.
- To view compliance information go to:
http://www.lenovo.com/compliance.
- To download environmental information go to:
http://www.lenovo.com/ecodeclaration.
• Some instructions in this guide may assume that you are using Windows® 10. If you
are using another Windows operating system, some operations may be slightly
different. If you are using other operating systems, some operations may not apply
to you.
• The features described in this guide are common to most models. Some
features may not be available on your computer or your computer may include
features that are not described in this user guide.
• The illustrations in this manual may diff
er from the actual product. The
screenshots of operating system are for reference only. Please refer to the actual
product.
Regulatory Notice
• For details, refer to Guides & Manuals at http://support.lenovo.com.
First Edition (May 2018)
© Copyright Lenovo 2018.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General
Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set
forth in Contract No. GS-35F-05925.
Contents
Chapter 1. Getting to know your computer ......................................... 1
Top view ..................................................................................................................... 1
Left-side view ............................................................................................................ 3
Right-side view .......................................................................................................... 5
Bottom view ............................................................................................................... 6
Rear View ................................................................................................................. 10
Keyboard dock top view (Optional) ..................................................................... 11
Keyboard dock left-side view (Optional) ............................................................ 14
Keyboard dock right-side view (Optional) ......................................................... 14
To use the Lenovo Active Pen
To use the Lenovo Active Pen2
Chapter 2. Starting to use Windows 10 ............................................. 22
Configuring the operating system for the first time .......................................... 22
Operating system interfaces .................................................................................. 22
Putting the computer to sleep or shutting it down ............................................ 25
Touch screen operation .......................................................................................... 27
Connecting to a wireless network ........................................................................ 30
Get help from Windows ......................................................................................... 31
Chapter 3. Recovery system ...............................................................32
Chapter 4. Troubleshooting ................................................................35
Frequently asked questions ................................................................................... 35
Troubleshooting ...................................................................................................... 36
Trademarks ..........................................................................................39
(on select models)............................................... 18
(on select models)............................................. 20
i
Chapter 1. Getting to know your computer
d
e
a
c b c b
Top view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Note: The dashed areas indicate parts that are not visible externally.
a Front camera
b Wireless LAN
antennas
c Wireless WAN
antennas (on
Use the camera for video communication.
Connect to a wireless LAN adapter to send and receive
wireless radio signals.
Connect to a wireless WAN adapter to send and receive
wireless radio signals.
select models)
Note: The GPS antenna is included here.
d Multi-touch
Functions as the visual display as well as touchpad input.
screen
Note: For details, see “Touch screen operation” on page 27.
e Speaker
Provides audio output.
1
Chapter 1. Getting to know your computer
Screen orientation
You can rotate the display panel to your preferred orientation.
The orientation of the display automatically changes (alte
portrait and landscape modes) depending on how you hold it.
rnating between
2
Chapter 1. Getting to know your computer
Notes:
Left-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
a
a Combo audio
jack
• The combo audio jack does not support conventional microphones.
• The recording function may not be supported if third-party headphones or headsets are
connected, due to different industry standards.
Connects to headsets.
3
Chapter 1. Getting to know your computer
Connecting USB devices
You can connect a USB device to your computer by inserting its USB plug
(Type A) into the USB port on your computer.
The first time you plug a USB device into a particular USB port on your
computer, Windows automatically installs a driver for that device. After the
driver has been installed, you can disconnect and reconnect the device
without performing any additional steps.
Note: Typically, Windows detects a new device after it has been connected, and then installs
the driver automatically. However, some devices may require you to install the driver
before connecting. Check the documentation provided by the device’s manufacturer
before connecting the device.
Before disconnecting a USB storage device, make sure your computer has
finished transferring data to that device. Click the Safely Remove Hardware
and Eject Media icon in the Windows notification area to remove the device
before disconnecting.
Note: If your USB device uses a power cord, connect the device to a power source before
connecting it. Otherwise, the device may not be recognized.
4
Chapter 1. Getting to know your computer
a b c d
Right-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
a Power button
b Volume up/down
button
c Type-C port
d AC power
adapter jack
Press this button to turn on/off the computer.
Increases/decreases the volume level.
Type-C port supports:
• USB 3.1
•DP
• PD (on select models)
Connects to the AC power adapter.
5
Chapter 1. Getting to know your computer
a abc
Notes:
Notes:
Bottom view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
a Tablet-keyboard
dock latch
Note: For details, see “Combination of tablet and keyboard dock” on page 15.
b Keyboard dock
Attaches the tablet to the dock keeping the tablet secured
in place.
Connects the tablet to the keyboard dock.
connector
c Nano-SIM-card
and microSD
Accept micro SD card (not supplied) and Nano SIM card
(not supplied).
card tray
• Select models may not have the Nano SIM card slot, please refer to the actual product.
• For details, see “Using the Nano-SIM-card and microSD card tray” on page 6.
Using the Nano-SIM-card and microSD card tray
Your computer supports the following types of cards:
• Micro Secure Digital (SD) card
• Nano Subscriber Identity Module (SIM) card
• The card tray may have two slots for different types of cards. Insert only one card in one
slot at a time.
• Select models may not have the Nano SIM card slot, please refer to the actual product.
• This card reader does not support SDIO dev
• The illustrations are for reference only, please refer to the actual product.
ices (e.g., SDIO Bluetooth and so on.).
(on select models)
6
Chapter 1. Getting to know your computer
Inserting card(s)
1 Turn off the tablet, and disconnect the AC adapter and any cable(s) from
the tablet.
2 Insert a prying pin (n
firmly and push it straight in until the card tray pops out.
ot supplied) into
the tiny hole on the card tray. Press
7
Chapter 1. Getting to know your computer
3 Gently pull the card tray out of the card reader.
4 Put card(s) in the corresponding slot on the card tray.
5 Reinsert the card tray.
8
Chapter 1. Getting to know your computer
Notes:
Removing card(s)
1 Turn off the tablet, and disconnect the AC adapter and any cable(s) from
the tablet.
into
2 Insert a prying pin
the tiny hole on the card tray. Press firmly and
push it straight in until the card tray pops out.
3 Gent
ly pull the card tray out of the card reader.
4 Remove card(s) from the card tray, then reinsert the card tray.
• Do not insert or remove cards while the computer is turned on. Doing so may damage the
card reader.
• Before removing the memory card, disable it by using the Windows safely remove
hardware and eject media utility to avoid data corruption.
9
Chapter 1. Getting to know your computer
Rear View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
a Rear camera (on
select models)
10
Use the camera for video communication or taking photos.
