Integra DPS-8.3 User Manual

SACD & DVD AUDIO/VIDEO PLAYER

DPS-8.3

Table of Contents

Getting Started

Instruction Manual

Connecting

Setting Up the Player

Basic Playback

Advanced Playback

Thank you for purchasing the Integra SACD & DVD AUDIO/VIDEO PLAYER. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new SACD & DVD AUDIO/VIDEO PLAYER. Please retain this manual for future reference.

Function Setup

Toubleshooting

Others

Table of Contents

Getting Started

Important Safeguards .................................... 3

Precautions ....................................................4

Notes on Discs ............................................... 6

Features/Supplied Accessories...................... 8

Before You Start ............................................. 9

Index to Parts and Controls ......................... 10

Connecting

Connecting to a TV ...................................... 15

• Using the supplied audio/video connection cable

• Making component video connections

• Making S-video connections

Connecting to an Amplifier (To Enjoy the Sound

Advantage of the DVD Player) ................ 17

• Making a digital connection with the amplifier

• Making discrete 5.1 channel ANALOG OUTPUT connections

• Making discrete 2 channel ANALOG OUTPUT connections

Operating Components not Reached by the

Remote Controller Signals (IR IN/OUT) .. 19

Connecting the Power/

Turning on the DVD Player ..................... 20

Various Functions

Advanced Playback

Still Frame/Slow Play ...................................29

Locating a Specific Title/Folder/Chapter/Track/

Location .................................................. 30

Repeat Play .................................................32

Random Play ............................................... 33

Playing in a Favorite Order .......................... 34

Selecting the Camera Angle ........................ 38

Selecting the Audio/Subtitle Language ........39

Continuing Playback from a Specified Location

(Last Memory) ......................................... 40

Memorizing Settings for Often Viewed DVDs

(Condition Memory) ................................ 41

Turning Off the Video Signal Output ............ 42

Listening through Headphones ....................43

Viewing Disc Information ............................. 44

Setting Up the Player

Setting Up the Player ...................................21

• Various sound formats and sound effects ............. 24

Basic Playback

Getting Started Using Your DVD Player.......25

Others

Programming the Commands of Other Remote

Control Units into the Remote

Controller ................................................ 65

Controllers .............................................. 68

Troubleshooting ........................................... 71

Specifications ............................................... 74

Advanced

Features

Function Setup

Adjusting Audio and Video Settings ............. 46

Using the Setup Screen Menus ............................... 46

Changing to the Setup Screen “Expert” Menu Mode 47 Adjusting the Dynamic Range of the Audio

Soundtrack ........................................................ 48

Setting the Audio 1 Options ..................................... 48

Setting the Audio 2 Options ..................................... 50

Setting the TV Screen Size...................................... 52

Setting the Video 1 Options ..................................... 53

Adjusting the Video Quality...................................... 54

Setting the Video 2 Options ..................................... 56

Setting the Language Options ................................. 57

Language Code List................................................. 60

Setting the Parental Lock Level ............................... 61

Country Code List .................................................... 63

Other Settings .......................................................... 63

Memorizing Settings (Function Memory) ................. 64

Recalling Memorized Settings ................................. 64

Resetting the Player to System Settings ................. 64

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Important Safeguards

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

AVIS

RISQUE DE CHOC ELECTRIQUE

OUVRIR

NE PAS

1. Read Instructions – All the safety and operating instructions should be read before the appliance is operated.

2. Retain Instructions – The safety and operating instructions should be retained for future reference.

3. Heed Warnings – All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions – All operating and use instructions should be followed.

5. Cleaning – Unplug the appliance from the wall outlet before cleaning. The appliance should be cleaned only as recommended by the manufacturer.

6. Attachments – Do not use attachments not recommended by the appliance manufacturer as they may cause hazards.

7. Water and Moisture – Do not use the appliance near water –for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

8. Accessories – Do not place the appliance on an unstable cart, stand, tripod, bracket, or table. The appliance may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the appliance. Any mounting of the appliance should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

9. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

10. Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the appliance and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the appliance on a bed, sofa, rug, or other similar surface. The appliance should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided. There should be free space of at least 5 cm (2 in.) and an opening behind the appliance.

11. Power Sources – The appliance should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company.

12. Grounding or Polarization – The appliance may be equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

PORTABLE CART WARNING

S3125A

13. Power-Cord Protection – Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

14. Lightning – For added protection for the appliance during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the appliance due to lightning and power-line surges.

15. Overloading – Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

16. Object and Liquid Entry – Never push objects of any kind into the appliance through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the appliance.

17. Servicing – Do not attempt to service the appliance yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

18. Damage Requiring Service – Unplug the appliance form the wall outlet and refer servicing to qualified service personnel under the following conditions:

A. When the power-supply cord or plug is damaged, B. If liquid has been spilled, or objects have fallen into the

appliance, C. If the appliance has been exposed to rain or water, D. If the appliance does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions as an improper

adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to

restore the appliance to its normal operation, E. If the appliance has been dropped or damaged in any way,

and F. When the appliance exhibits a distinct change in

performance – this indicates a need for service.

19. Replacement Parts – When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

20. Safety Check – Upon completion of any service or repairs to the appliance, ask the service technician to perform safety checks to determine that the appliance is in proper operation condition.

21. Wall or Ceiling Mounting – The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

22. Heat – The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.

23. Liquid Hazards – The appliance should not be exposed to dripping or splashing and no objects filled with liquids, such as vases should be placed on the appliance.

Precautions

This unit contains a semiconductor laser system and is classified as a “CLASS 1 LASER PRODUCT”. So, to use this model properly, read this Instruction Manual carefully. In case of any trouble, please contact the store where you purchased the unit. To prevent being exposed to the laser beam, do not try to open the enclosure.

DANGER:

VISIBLE LASER AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED OR DEFEATED. DO NOT STARE INTO BEAM.

CAUTION:

THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

For U.S. model

The laser is covered by a housing which prevents exposure during operation or maintenance. However, this product is classified as a Laser Product by CDRH (Center for Devices and Radiological Health) which is a department of the Food and Drug Administration. According to their regulations 21 CFR section 1002.30, all manufactures who sell Laser Products must maintain records of written communications between the manufacturer, dealers and customers concerning radiation safety. If you have any complaints about instructions or explanations affecting the use of this product, please feel free to write to the address on the back page of this manual. When you write us, please include the model number and serial number of your unit.

In compliance with Federal Regulations, the certification, identification and the period of manufacture are indicated on the rear panel.

FCC INFORMATION FOR USER

CAUTION:

The user changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

1. This unit is a CLASS 1 LASER PRODUCT and employs a laser inside the cabinet.

2. To prevent the laser from being exposed, do not remove the cover. Refer servicing to qualified personnel.

For Canadian model

NOTE: This class B digital apparatus complies with Canadian

ICES-003.

For models having a power cord with a polarized plug:

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Modèle pour les Canadien

REMARQUE: Cet appareil numérique de la classe B est

conforme à la norme NMB-003 du Canada.

Sur les modèles dont la fiche est polarisee:

ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES,

INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

1. Regional Restriction Codes (Region Number)

Regional restriction codes are built into DVD Players and DVDVideo media for each sales region. If the regional code of the DVD Player does not match one of the regional codes on the DVD-Video, playback is not possible. The regional number can be found on the rear panel of the DVD

Player. (e.g. 2 for Region 2)

2. About This Manual

This manual explains the basic procedures for operating the DVD Player. Some DVD-Video and DVD-Audio discs do not support the full potential of the DVD technology. Your DVD Player may therefore not respond to all operating commands. Refer to instruction notes on discs.

A “ ” mark may appear on the TV screen during operation. It means that the operation is not permitted by the DVD Player or the disc.

3. Recording Copyright

Recording of copyrighted material for other than personal use is illegal without permission of the copyright holder.

4. Power

WARNING

BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY.

The voltage of the available power supply differs according to country or region. Be sure that the power supply voltage of the area where the unit will be used meets the required voltage (e.g., AC 100-240 V, 50/60 Hz) written on the rear panel.

5. Do not touch the unit with wet hands

Do not handle the unit or power cord when your hands are wet or damp. If water or any other liquid enters the case, take the unit to an authorized service center for inspection.

6. Location of the unit

• Place the unit in a well-ventilated location. Take special care to provide plenty of ventilation on all sides of the unit especially when it is placed in an audio rack. If ventilation is blocked, the unit may overheat and malfunction.

• Do not expose the unit to direct sunlight or heating units as the unit’s internal temperature may rise and shorten the life of the pickup.

• Avoid damp and dusty places and places directly affected by vibrations from the speakers. In particular, avoid placing the unit on or above one of the speakers.

• Be sure the unit is placed in a horizontal position. Never place it on its side or on a slanted surface as it may malfunction.

• When you place the unit near a TV, radio, or VCR, the playback picture may become poor and the sound may be distorted. In this case, place the unit away from the TV, radio, or VCR.

7. Care

From time to time you should wipe the front and rear panels and the cabinet with a soft cloth. For heavier dirt, dampen a soft cloth in a weak solution of mild detergent and water, wring it out dry, and wipe off the dirt. Following this, dry immediately with a clean cloth. Do not use rough material, thinners, alcohol or other chemical solvents or cloths since these could damage the finish or remove the panel lettering.

8. Notes on Handling

• When shipping the unit, use the original shipping carton and packing materials. For maximum protection, repack the unit as it was originally packed at the factory.

• Do not use volatile liquids, such as insect spray, near the unit. Do not leave rubber or plastic products in contact with the unit for a long time. They will leave marks on the finish.

• The top and rear panels of the unit

a long period of use. This is not a malfunction.

• When the unit is not in use, be sure to remove the disc and turn off the power.

• If you do not use the unit for a long period, the unit may not function properly in the future. Turn on and use the unit occasionally.

may become warm after

9. To Obtain a Clear Picture

The unit is a high technology, precision device. If the optical pick-up lens and disc drive parts are dirty or worn down, the picture quality becomes poor. To obtain a clear picture, we recommend regular inspection and maintenance (cleaning or parts replacement) every 1,000 hours of use depending on the operating environment. For details, contact your nearest dealer.

10. Notes on Moisture Condensation

Moisture condensation damages the unit. Please read the following carefully.

• What is moisture condensation?

Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of water form on the outside of the glass. In the same way, moisture may condense on the optical pick-up lens inside the unit, one of the most crucial internal parts of the unit.

• Moisture condensation occurs in the following cases.

– When you bring the unit directly from a cold place to a

warm place.

– When you use the unit in a room where you just turned on

the heater, or a place where the cold wind from the air conditioner directly hits the unit.

– In summer, when you use the unit in a hot and humid place

just after you move the unit from an air conditioned room.

– When you use the unit in a humid place.

• Do not use the unit when moisture condensation may occur.

If you use the unit in such a situation, it may damage discs and internal parts. Remove the disc, connect the power cord of the unit to the wall outlet, turn on the unit, and leave it for two or three hours. After a few hours, the unit will have warmed up and evaporated any moisture. Keep the unit connected to the wall outlet and moisture condensation will seldom occur.

Getting Started

Notes on Discs

This section shows you how to handle, clean, and store discs.

Playable Discs

This DVD Player can playback the following discs.

Disc mark

DVD videos

DVD Audio

VIDEO CDs

Audio CDs

The Structure of the Disc Content

DVD-Video

Normally, the contents of DVD-Video are divided into titles, and the titles are subdivided into chapters.

DVD-Audio

The contents of DVD-Audio are divided into groups, and the groups are subdivided into tracks.

Video CD/CD

Video CD and CD are divided into tracks.

Title 1

Chapter 1

Track 1 Track 2

Chapter 2

Group 1

Chapter 1

Track 1

Title 2 Chapter 2

Group 2

Track 2 Track 3

Chapter 3

*1This unit can play DVD-R discs recorded as DVD video

format.

This unit can play DVD-RW discs recorded as DVD video format. DVD-RW discs that were recorded with only onegeneration copy permission cannot be played.

*3This unit can play CD-R and CD-RW discs recorded in CD

Audio or Video CD format, or with MP3 audio files.

Playback of certain discs may not be possible. This may be caused by a number of possibilities, including but not limited to: whether or not the disc was not finalized, the type of disc used, the type of recording; damaged or dirt on either the disc or the player’s pick up lens. * For details, refer to the operating instructions supplied with

your CD recorder.

• You cannot playback discs other than those listed above.

• You cannot play discs such as CD-ROM etc., even if the

marks in the above table are labeled on those discs.

• This DVD Player uses the PAL/AUTO (Australian model only) color system, and cannot playback DVD videos recorded in any other color system (SECAM, etc.).

• Avoid using heart-shaped or octagonal discs. Playing irregularly shaped discs may damage the internal mechanism of the DVD Player.

Track 1 Track 2

Track 3

Track 4 Track 5

About VIDEO CDs

This DVD Player supports VIDEO CDs equipped with the PBC (Version 2.0) function. (PBC is the abbreviation of Playback Control.) You can enjoy two playback variations depending on the type of disc.

• VIDEO CD not equipped with PBC function (Version 1.1)

Sound and movies can be played on this DVD Player in the same way as an audio CD.

• VIDEO CD equipped with PBC function (Version 2.0)

In addition to operation of the VIDEO CD not equipped with the PBC function, you can enjoy playback with interactive software and search function using the menu displayed on the TV screen (Menu Playback). Some of the functions described in this Instruction Manual may not work with some discs.

• Do not use discs that have residue from adhesive tape, rental discs that have peeling labels, or discs that have custom labels or stickers. Otherwise, you may not be able to eject the discs or the DVD Player may become inoperative.

MP3 compatibility information

Handling Discs

• The CD-ROM must be ISO 9660 compatible.

• Files should be MPEG1 Audio Layer 3 format, 44.1 or

48kHz, fixed bit-rate. Incompatible files will not play and

“UNPLAYABLE MP3 FORMAT” will be displayed.

• Not compatible with variable bit-rate (VBR) files.

• This system only plays tracks that are named with the file extension “.mp3” or “.MP3”.

• This system is not compatible with multi-session discs. If

you try to play a multi-session disc, only the first session will be played.

• Use CD-R or CD-RW media for recording your MP3 files. The disc must be finalized in order to play.

• Audio encoded at 128Kbps should sound close to regular audio CD quality. Although this system will play lower bitrate MP3 tracks, the sound quality becomes noticeably worse at lower bit-rates.

• Only the first 8 characters of folder and track names (excluding the “.mp3” extension) are displayed.

• This system can recognize a maximum of 250 folders and 250 tracks. Discs containing more than 250 folders or tracks will not play.

Notes on Copyright

It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, and rent copyrighted material without permission. DVD videos are copy protected, and any recordings made from these discs will be distorted. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

• Do not touch the playback side of the disc.

Playback side

• Do not attach paper or tape to discs.

Cleaning Discs

• Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the center outwards with a soft cloth. Always keep the disc clean.

• If you cannot wipe off the dust with a soft cloth, wipe the disc lightly with a slightly moistened soft cloth and finish with a dry cloth.

• Do not use any type of solvent such as thinner, benzine, commercially available cleaners or antistatic spray for vinyl LPs. It may damage the disc.

Storing Discs

• Do not store discs in a place subject to direct sunlight or near heat sources.

• Do not store discs in places subject to moisture and dust such as a bathroom or near a humidifier.

• Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause warping.

Features/Supplied Accessories

Features

THX*1 Ultra Certified DTS*2/Dolby Digital*3/MPEG2/PCM Digital Audio Outputs Advanced 192-kHz/24-Bit D/A Converters Vector Linear Shaping Circuitry RCA 6ch Multi-channel outputs 108-MHz/12-bit Video D/A Conversion Progressive Component Video Outputs Plays DVD-Audio and Video Discs, DVD-Rs,

DVD-RWs, MP3 CDs, CD-Rs, CD-RWs, Video CDs, SACDs and Audio CDs

Pre-programmed and Learning Remote Control

Supplied Accessories

Make sure your box contains everything listed below. If any pieces are missing, contact your nearest Integra dealer. The number of accessories is indicated in brackets.

Remote controller (RC-499DV) [1] Batteries (size AA/UM-3) [2]

*1Manufactured under licence from Lucasfilm Ltd. Lucasfilm and

THX are trademarks of Lucasfilm Ltd.

*2“DTS” and “DTS Digital Surround” are trademarks of Digital

Theater Systems, Inc.

*3Manufactured under license from Dolby Laboratories.

“Dolby”, “Pro Logic” and the double-D symbol Ÿ are trademarks of Dolby Laboratories.

THX Ultra

Before any home theatre component can be THX Ultra certified, it must pass a rigorous series of quality and performance tests. Only then can product feature the THX Ultra logo, which is your guarantee that the Home Theatre products you purchase will give you superb performance for many years to come.

S-video cable [1]

Cable which sends S-video images.

z cable [1]

Cable used for system connections to an Integra/ Onkyo component with an z jack.

(The components will not function as a system with only z connections. Be sure to connect the audio connection cables correctly as well.)

Power cord [1]

Shape may vary depending on the area which it was purchased.

Audio/video connection cable [1]

The cable with the yellow plug is for video. The cable with the red and white plugs are for audio.

Before You Start

Inserting the Batteries

1 Open the battery compartment cover.

2 Insert the two R6 (size AA) batteries.

Be sure to match the + and – ends of the batteries with the diagram inside the battery compartment.

Notes

• Do not mix new batteries with old batteries or different kinds of

batteries.

• To avoid corrosion, remove the batteries if the remote controller is

not to be used for a long time.

• Remove dead batteries immediately to avoid damage from

corrosion. If the remote controller does not operate smoothly, replace both batteries at the same time.

• The life of the batteries supplied is about six months but this will

vary depending on usage.

Using the Remote Controller

Point the remote controller toward the remote control sensor.

Remote control sensor

30˚

3 Close the battery compartment cover.

About 5 m

Notes

• Place the unit away from strong light such as direct sunlight or

inverted fluorescent light which can prevent proper operation of the remote controller.

• Using another remote controller of the same type in the same room

or using the unit near equipment which uses infrared rays may cause operational interference.

• Do not put any object such as a book on the remote controller. The

buttons of the remote controller may be pressed by mistake and drain the batteries.

• Make sure the audio rack doors do not have colored glass. Placing

the unit behind such doors may prevent proper remote controller operation.

• If there is any obstacle between the remote controller and the

remote control sensor, the remote controller will not operate.

Index to Parts and Controls

Setup

MenuTop Menu

Return

Push to Enter

Cursor

Display

Clear

Random

Last Memory

Repeat

PlayStop

Pause

Open /Close

Standby/On

Standby

O f f

Video Circuit

Off

Dimmer

Power

Phones Level

Phones

SACD

DVD

12453

7890-=~ !

#@$% ^&* )_(

DPS-8.3

For operational instructions, see the page indicated in brackets [ ].

■ Front panel

1 Power switch and Standby indicator [20]

Turns on the main power supply for the DPS-8.3. The DPS-8.3 enters standby state and the Standby indicator lights up. Pressing the switch again to the off position (— Off) shuts down the main power supply into the DPS-8.3.

• Before turning on the power, make sure all cables are properly connected.

2 Standby/On button [20, 21, 25, 28, 46, 64]

When Standby/On button is pressed to On while the Power switch is set to On, the DPS-8.3 turns on and the Standby indicator turns off. The indicator around 0 button lights up. Pressing the button again returns the DPS-8.3 to the standby state. This state turns off the display, disables control functions.

3 Video Circuit Off button and indicator [42]

Press to switch the video signal off.

4 Last Memory button [40]

You can resume DVD or Video CD playback from the point you last watched even if the disc is removed from the player. Press Last Memory during playback to set a Last Memory point. When you want to resume playback of that disc, press Last Memory in the stop mode and playback starts from the memorized point. Last Memory locations can be stored for up to 5 DVDs and 1 Video CD.

5 Clear button [31-36, 39-41, 59]

Works in conjunction with a number of player functions. Use to cancel repeat and random playback, and to edit programs.

6 Disc indicator [25]

When playing a disc, the appropriate disc type indicator lights up.

7 Disc tray [25]

When loading a disc, place discs in the disc tray with the label side facing up.

8 Top Menu button [26, 30]

Press to call up the top menu programmed on the DVD. Depending on the DVD, the top menu may be identical to the DVD menu.

9 Cursor (2/3/5/∞) button/Enter button [21, 46]

Use 2/3/5/∞ to move through the options on menu screens and to change settings. Use Enter to implement settings selected with the cursor buttons or to set items highlighted in a menu.

0 Menu button [26, 31, 38, 39, 58]

Use to display or close the DVD menu or MP3 Navigator screen.

- Open/Close button [25, 28]

Press to open and close the disc tray.

= Pause button [27]

Press during playback to pause. Press again to resume playback.

~ Stop button [28]

Press to stop playback. Whenever a disc is loaded in the player, the indicator above the Stop button lights up.

! Play button [25]

Press to start or resume playback. Whenever a disc is loaded in the player, indicator above £ Play lights up.

@ Dimmer button [45]

Toggle to control the lightness of the display (4 steps).

# Repeat button [32]

Use to set the repeat mode.

$ Random button [33]

Press to play chapters/tracks in random order.

% Remote control sensor [9]

Point the remote control toward the remote sensor to operate the player.

^ Return button [26, 46, 59, 62]

Use to go one menu back (current settings are maintained). Use Return when you do not want to change the option setting in a menu.

& Setup button [21, 46, 64]

Press when the player is in either play or stop mode to open and close the Setup screen.

* Display button [44, 45, 55]

Press during playback to display statistical disc information. Press repeatedly to display different information.

( 4/¢ button [26, 27]

Press to go back or advance to previous chapters/tracks. Press and hold to perform fast-reverse/fast-forward playback scanning.

) Phones jack [43]

This is a standard stereo jack for connecting stereo headphones. The audio for the ANALOG OUTPUT CH 1 and CH 2 are sent to the headphone speakers.

_ Phones Level dial [43]

Use to control the phones level. Turn the dial clockwise to increase the phones level and counterclockwise to decrease it.

■ Display

12 3456

AUDIO

DVD

SACD V CD

PROGRESSIVE

1 Ÿ D indicator

Lights when Dolby Digital sound is selected and played back. (Only with DVDs recorded in Dolby Digital).

2 Inserted disc indicator [25] 3 TITLE/GROUP indicator 4 GUI (Graphical User Interface) indicator

Lights when an on-screen menu operation is being performed. Onscreen menu helps you set up the player.

5 CHP/TRACK indicator 6 Angle icon indicator [38] 7 REPEAT indicator [32] 8 REMAIN indicator

Lights up to indicate the remaining time of titles, chapters and tracks.

9 L, C, R, LS, RS and LFE indicator [50]

Indicates the compatible audio channels for DVD playback. L: Left front channel C: Center channel R: Right front channel LS: Left surround channel S: Surround channel (monoural) RS: Right surround channel LFE: LFE (Low Frequency Effect) channel

0 LAST indicator [40]

TITLE GROUP

GUI

CHP TRACK

TOTAL

REMAIN

LFECRL

R SL S

D.MIX COND

LAST

- COND indicator [41] = PROGRESSIVE indicator

Lights when progressive video signals are output.

~ £/8 indicator ! DTS indicator

Lights when DTS is selected and played back. (Only with DVDs recorded in DTS).

@ Multifunctional indicator

(e.g. operating status and error messages)

# TOTAL indicator

Lights up to indicate the total number of titles, tracks and track playback time.

$ D.MIX indicator

Indicates when DVD audio, Dolby Digital, DTS or MPEG etc. audio is downmixed (channel dowmixing) (e.g., when 5.1 channel sound is downmixed to 2 channels).

Index to Parts and Controls

MODEL NO.

DPS

8.3

SACD & DVD AUDIO/VIDEO PLAYER

REMOTE

CONTROL

COMPONENT

DIGITAL OUTPUT

OPTICAL COAXIAL

OUT

S VIDEO VIDEO

COMPONENT

VIDEO OUTPUT

ANALOG OUTPUT

SURR 11+2

CH 1 CH 2 FRONT SURR 1 CENTER SURR 2

SUB WOOFER

TRIG

GER

RS-232

AC INLET

■ Rear panel

Shapes of jacks vary depending on the area in which it was purchased.

1 VIDEO OUTPUT COMPONENT 1 jacks [16]

If your TV has component inputs, you can connect a component video cable to your TV and to your DVD Player for ideal video quality. The component Video Cable only carries the video signal; remember to connect the left and right audio cables. If you connect a TV that is compatible with a Progressive scan signal, you can enjoy both Interlaced and Progressive scan.

2 VIDEO OUTPUT S VIDEO jack [16]

If your TV or monitor has an S-video input, clear picture reproduction is possible by connecting the player to your TV or monitor via the S-Video jack. You can switch between [S1] and [S2] S-video output from the Setup menu.

3 VIDEO OUTPUT VIDEO jack [15]

Connect to the video input on a TV or monitor or AV amplifier or receiver with video input capability.

4 VIDEO OUTPUT COMPONENT 2 jacks

If your TV has component inputs, you can connect a BNC video cable to your TV and to your DVD Player for ideal video quality.

5 RS-232 port

This port is to be used in conjunction with an external controller to control the operation of the DPS-8.3 using an external device.

6 AC INLET [20]

Use to connect the power cord to the wall outlet.

7 ANALOG OUTPUT CH 1/CH 2 jacks [15-18]

Use to output two-channel audio (analog) to the audio stereo inputs on a TV or stereo amplifier.

8 ANALOG OUTPUT FRONT/SURR 1/CENTER/

SUBWOOFER jacks [18]

Use to output 5.1 channel audio (analog) to the 5.1 channel discrete inputs on an amplifier. If you are connecting to a receiver that has both digital and analog input jacks for DVD player connection, it may be beneficial to make both connections.

9 SURR 2 jacks [18]

Use when making connections to 7.1 channel analog inputs. (Make sure the SURR 1/1+2 selector switch is set to 1+2.)

0 SURR 1/1+2 selector switch [18]

When using 2 channel surround, select 1, when using 4 channel surround, select 1+2. Audio will be output 3dB lower when 1+2 is selected. The same audio is output from SURR 1 and from SURR 2.

- DIGITAL OUTPUT OPTICAL jack [17]

Use to output the digital audio signal recorded on discs. You can output the digital signal via the optical output jack to an AV amplifier or receiver.

= DIGITAL OUTPUT COAXIAL jack [17]

Use to output the digital audio signal recorded on discs. You can output the digital signal via the coaxial output jack to an AV amplifier or receiver.

~ IR IN/OUT jacks [19]

If the DPS-8.3 is located inside a rack or cabinet that will not allow infrared beams to reach the IR sensor, you will need to connect a remote sensor to IR IN jack to be able to use the remote controller. Then install the remote sensor in an unblocked location where you can easily point the remote controller. Using a mini-jack connector, connect IR emitter to the IR OUT jack on the DPS-8.3 and then place the IR emitter on the remote sensor of the component or facing it.

! 12V TRIGGER jack

When the DPS-8.3 is turned on, this terminal outputs at 12 V/100 mA.

@ z jack [17, 18]

Use to connect this player to another component bearing the z mark. This lets you control this unit as though it were a component in a system. (The components will not function as a system with only z connections. Be sure to connect the audio connection cables correctly as well).

Remote controller (Operation buttons)

RPT

A-B

RC-499DV

Display

DIS

Dimmer

DIM

VOL

Video Off

Muting

(

£ ¢

∞

Step/Slow

Pause

Speed

Surround

Random

Program

Clear

PGM

Cond M

C.M

CLR

Function M

Enter

RND


PIC

---

•

–

9 0

Audio SEL

TV / VCR

Step/Slow

Repeat

)

™

≠

1 Send/Learn indicator [65]

Lights when the remote controller is sending a command to the DVD Player or other preprogrammed component, and when learning the command of another remote control unit.

2 On/Standby buttons [20]

Press On to turn the DVD Player on and Standby to put the DVD Player in standby. (The Standby indicator lights up.)

3 0 button [25]

Press to open and close the disc tray.

4 DVD button [65]

Press to select the DVD mode. In this mode, the remote controller is set to control the DVD Player.

5 Angle button [38]

Press repeatedly to select a camera angle when a DVD-Video is recorded with multiple angle playback.

6 Audio button [39]

Press repeatedly to select an audio and/or language track recorded on a DVD-Audio/Video.

7 Top Menu button [26, 30]

Press to select the top menu on a DVD-Audio/Video. This menu may be the same as the DVD menu.

8 Return button [26]

Press to go back to a previous menu screen.

9 Display button [44]

Press during playback to display statistical disc information. Press repeatedly to display different information.

0 4 (skip back) button [27]

Press to return to previous titles, groups, chapters, or tracks.

- £ (play) button [28]

Press to start playback.

= 1 (fast reverse) button [27]

Press to scan rapidly backward through the contents on a disc.

~ 7 (stop) button [28]

Press to stop playback.

! Step/Slow e button [29]

Press to perform slow reverse playback of a DVD.

@ Speed button 2 [27]

Press repeatedly during playback or pause to switch the reverse playback speed.

# Random button [33]

Press to start random playback.

$ Repeat button [32]

Press to repeat playback.

% A-B button [32]

Press to repeat a specific section on a disc.

^ Picture button [54]

Press to display the pre-programmed setting menu.

& Number buttons [34]

Use to enter numeric values

Index to Parts and Controls

* Light button

Press to switch on/off the remote controller button lights.

( Subttl button [39]

Press repeatedly to select one of the subtitle languages recorded on a DVD-Video.

) Last M button [40]

Press to resume playback from the point you last watched.

_ Menu button [26]

Press to display the DVD menu.

+ 5/∞/2/3 and ENTER multi control [46]

Use to navigate menu screens and enter settings.

¡ Setup button [21]

Press to display the Setup screen menu.

™ Video Off button [42]

Press to turn off the video output circuitry for a more dedicated audio performance.

£ Dimmer button [45]

Press repeatedly to change the brightness of the front panel display in four grades (including turning the front panel display off). The dimmer setting is restored to normal brightness whenever the DVD Player is turned off.

¢ ¢ (skip forward) button [27]

Press to advance through titles, groups, chapters, or tracks.

∞ ¡ (fast forward) button [27]

Press to scan rapidly forward through the contents on a disc.

§ Step/Slow E button [29]

Press to perform slow forward playback of a DVD or Video CD.

¶ Pause button [27]

Press to pause.

• Speed button 3 [27]

Press repeatedly during playback or pause to switch the forward playback speed.

ª Clear button [32]

Press to clear entered values and settings.

º Program button [34]

Press to playback titles, chapters, or tracks in a specific order.

– Function M button [64]

You can store in memory settings. Press Function M to memorize and recall the settings.

≠ Cond M button [41]

You can store in memory the settings for DVDs. Press Cond M during DVD playback to memorize the settings.

Ÿ Search button [30]

Press to find the specific section on a disc where you want to start playback.

Remote controller buttons that can be used to control your Integra/Onkyo receiver

Press RCVR to set the remote controller to operate an Integra/Onkyo receiver. The following buttons can be used to operate an Integra/ Onkyo receiver. Refer to the manual supplied with your receiver for details on each function.

RC-499DV

8 0

Audio SEL

TV / VCR

Step/Slow

Display

DIS

Pause

Speed

Surround

1 On button

Press On to turn the receiver on.

2 Standby button

Press Standby to put the receiver in standby.

3 Input Selector

Press to select the input. These buttons can be used in either DVD or receiver mode.

4 RCVR button

Press to switch to receiver mode.

5 2/3/5/∞/ENTER button

Use to navigate menu screens and enter settings.

6 CH +/– buttons

Press to select the radio presets if the receiver has radio features.

7 VOL 5/∞ buttons

Press to adjust the volume. These buttons can be used in either DVD or receiver mode.

8 Return button

Press to return to the previous menu during the receiver setup screen.

9 Setup button

Press to display/turn off the receiver setup menu.

0 Audio SEL button

Press to switch audio inputs.

- Muting button

Press to mute/cancel mute function.

= Display button

Press to change the display.

~ Dimmer button

Press repeatedly to change the brightness of the front panel display.

! Surround Mode button

Press to switch listening modes (surround modes).

Dimmer

DIM

VOL

Video Off

Muting

Step/Slow

1 2

Connecting

Connecting to a TV

Before connecting

• Refer also to the instruction manual of the TV.

• When you connect the DVD Player to the TV, be sure to turn off the

power and unplug both units from the mains before making any connections.

• Connect the DVD Player to the TV directly. If you connect the DVD Player to a VCR, TV/VCR combination, or video selector, the playback picture may be distorted as DVD videos are copy protected.

Using the supplied audio/video connection cable

Using the supplied audio/video cable, make audio connections from the ANALOG OUTPUT CH 1 or CH 2 L and R jacks to the corresponding audio input jacks on the TV. In the same manner, make video connection from the VIDEO OUTPUT VIDEO jack to the corresponding video input jack on the TV. By making connections to a stereo system, you can improve the quality of the sound. Using an audio cable (not supplied), make audio connections from the ANALOG OUTPUT CH 1 or CH 2 L and R jacks to the corresponding jacks on the stereo component.

Note

Be sure to match the colors of the plugs on the cable with the corresponding jacks on the DVD Player and the TV: yellow for video, red for R (right) audio and white for L (left) audio. If the TV audio is monaural, leave the red plug disconnected.

• Connect the plugs securely.

Be sure to set the TV Aspect after connection using the Setup Navigator explained in “Setting Up the Player” starting on page 21 or the function setting menu explained in “Adjusting Audio and Video Settings” starting on page 46.

Stereo audio/video connection cable

To audio and video input

Video (Yellow)

L (White)

Incomplete

Insert completely

COMPONENT

VIDEO OUTPUT

CH 1 CH 2 FRONT SURR 1 CENTER SURR 2

ANALOG OUTPUT

S VIDEO VIDEO

SUB WOOFER

SURR

11+2

OPTICAL COAXIAL

Notes

• Connect the player’s video output directly to the television.

• Since the player is compatible to analog copy protection there

may be cases when recordings from the deck may be distorted during playback.

• Progressive signals are not output from the players video or S1/S2 video output jack.

DIGITAL OUTPUT

R (Red)

: Signal flow

RS-232

AC INLET

TRIG

GER

OUT

REMOTE CONTROL

SACD & DVD AUDIO/VIDEO PLAYER

MODEL NO.

DPS

8.3

DO NOT connect

the mains lead at this time.

MODEL NO.

DPS

8.3

SACD & DVD AUDIO/VIDEO PLAYER

REMOTE

CONTROL

COMPONENT

DIGITAL OUTPUT

OPTICAL COAXIAL

OUT

S VIDEO VIDEO

COMPONENT

VIDEO OUTPUT

ANALOG OUTPUT

SURR

11+2

CH 1 CH 2 FRONT SURR 1 CENTER SURR 2

SUB WOOFER

TRIG

GER OU

RS-232

AC INLET

Connecting to a TV

Making component video connections

If the TV or monitor has component video inputs, making this type of video connection will produce the ideal picture quality for the presentation of DVD-Video. Using a component video cable (sold separately), connect the VIDEO OUTPUT COMPONENT jacks to the corresponding component video input jacks on the TV. Some TVs and monitors use BNC jacks for the component video input. When this is the case, make connections to the VIDEO OUTPUT COMPONENT BNC jacks using a component video cable that has BNC plugs. Actual labels for component video inputs may vary depending on the TV manufacturer. (e.g. Y, R-Y, B-Y or Y, C In some TVs or monitors, the color levels of the playback picture may be reduced slightly or the tint may change. In such a case, adjust the TV or monitor for optimum performance. By making connections to a stereo system, you can improve the quality of the sound. Using an audio cable (not supplied), make audio connections from the ANALOG OUTPUT CH 1 or CH 2 L and R jacks to the corresponding jacks on the stereo component.

B, CR)

Component video cable

To component video input

Stereo audio connection cable

To audio input

L (White)

R (Red)

Making S-video connections

If the TV or monitor has an S video input, make the S video connection. The S video connection will provide higher quality picture playback. By making connections to a stereo system, you can improve the quality of the sound. Using an audio cable (not supplied), make audio connections from the ANALOG OUTPUT CH 1 or CH 2 L and R jacks to the corresponding jacks on the stereo component.

Notes

• If you make the S video connection, leave the yellow plug disconnected.

• If the TV audio is monaural, leave the red plug disconnected.

: Signal flow

DO NOT connect the mains lead at this time.

S video connection cable

To S video input

R (Red)

L (White)

Stereo audio connection cable

To audio input

Connecting to an Amplifier (To Enjoy the Sound Advantage of the DVD Player)

Although you can reproduce the DVD Player’s sound from the TV speakers with the connections on pages 15 and 16, connecting with an amplifier provides you high quality dynamic sounds.

Before connecting

• Refer to the instruction manual of the amplifier.

• When you connect the DVD Player to the amplifier, be sure to turn off

the power and unplug both units from the mains before making any connections. Otherwise, the speakers may be damaged.

• Connect the plugs securely.

Incomplete

Insert completely

■ Making a digital connection with the amplifier

If your amplifier has a digital input jack, be sure to connect it to either DIGITAL OUTPUT OPTICAL or COAXIAL jack on the DVD player.

Note

DO NOT connect to the AC-3RF input (e.g. of a Dolby Digital receiver) which is reserved only for video disc players. To ensure proper delivery of sound, be sure to match the names of the jacks on the DVD Player and the component being connected to.

Notes

• The remote controller supplied with Integra/Onkyo amplifier can be used to operate the DVD player.

• The function of the upper and lower z connectors are the same. Connect to either one.

• Connecting z cable only does not make the system operational. You must also connect the audio cables as well.

•

When using the optical input jack, remove the protective cap and keep it safely. When the jack is not used, replace the protective cap.

Be sure to set the digital output setting after connection using the Setup Navigator explained in “Setting Up the Player” starting on page 21 or the function setting menu explained in “Adjusting Audio and Video Settings” starting on page 46.

Audio connection cables

To audio inputs

R (Red)

: Signal flow

COMPONENT

VIDEO OUTPUT

CH 1 CH 2 FRONT SURR 1 CENTER SURR 2

ANALOG OUTPUT

S VIDEO VIDEO

SUB WOOFER

SURR 11+2

OPTICAL COAXIAL

DIGITAL

OUTPUT

Note

If you listen to multichannel DVD-Audio through one of the digital outputs, it will be downmixed to stereo. Also, high sampling rate DVD-Audio (192kHz or 176.4kHz) will be downsampled to 96kHz,

88.2kHz, 48kHz, or 44.1 khz, depending on the disc. Multi channel and high sampling rate DVD-Audio is only available through the analog outputs. Some DVD-Audio and all SACD audio is output only through the analog outputs. In order to enjoy Dolby Digital/DTS 5.1 channel sound, a separate Dolby Digital decoder, and 5.1 channel (front right/left, center, surround right/left) + subwoofer are required.

L (White)

Optical fiber connection cable

To Digital optical jack

Coaxial cable

To coaxial inputs

z cable To z jack

RS-232

TRIG

GER

OUT

REMOTE CONTROL

SACD & DVD AUDIO/VIDEO PLAYER

MODEL NO.

An amplifier with a Dolby Digital/DTS/MPEG1/MPEG2 decoder

DPS

8.3

DO NOT connect

the mains lead at this time.

AC INLET

MODEL NO.

DPS

8.3

SACD & DVD AUDIO/VIDEO PLAYER

REMOTE

CONTROL

COMPONENT

DIGITAL OUTPUT

OPTICAL COAXIAL

OUT

S VIDEO VIDEO

COMPONENT

VIDEO OUTPUT

ANALOG OUTPUT

SURR

11+2

CH 1 CH 2 FRONT SURR 1 CENTER SURR 2

SUB WOOFER

TRIG

GER OU

RS-232

AC INLET

Connecting to an Amplifier (To Enjoy the Sound Advantage of the DVD Player)

Making discrete 5.1 channel ANALOG OUTPUT connections

The discrete ANALOG OUTPUT jacks are intended to deliver up to 5.1 channels of multi channel audio from DVD-Video and DVD-Audio sources. Connections can be made from the ANALOG OUTPUT FRONT, SURR 1 (surround), CENTER, and SUBWOOFER jacks to the corresponding input jacks on an AV component with multi channel discrete audio input jacks.

Notes

• To ensure proper delivery of sound, be sure to match the names of the jacks on the DVD Player and the component being connected to.

• When connecting to an amplifier with 5.1 channel analog sound inputs, connect this unit’s SURR 1 jacks to the amplifier surround inputs. (Make sure the SURR 1/1+2 selector switch is set to 1).

• When connecting to an amplifier with 7.1 channel analog sound inputs, connect this unit’s SURR 2 jacks to the amplifier’s additional surround inputs. (Make sure the SURR 1/1+2 selector switch is set to 1+2. The same audio will be output from SURR 1 and from SURR 2).

Audio connection cables

To audio inputs

FRONT L

: Signal flow

Making discrete 2 channel ANALOG OUTPUT connections

Use a separately sold audio cord to connect ANALOG OUTPUT CH 1 or CH 2 L/R jacks for stereo sound.

Note

To ensure proper delivery of sound, be sure to match the names of the jacks on the DVD Player and the component being connected to. Do not connect the PHONO, or TUNER jacks of other components to this player.

FRONT R

SURROUND L

SURROUND R

CENTER

SUBWOOFER

z cable

An amplifier with 5.1 channel discrete input

To z jack

DO NOT connect the mains lead at this time.

z cable To z jack

Audio connection cables

To audio inputs

FRONT L

FRONT R

An amplifier with discrete 2 channel input

Operating Components not Reached by the Remote Controller Signals (IR IN/OUT)

In order to use the remote controller to control the DPS-8.3 from a remote location, you will need to prepare a multi-room kit (sold separately such as one of those given below:

• Integra’s Multi-Room System kit (IR Remote Controller Extension System).

• Multiroom A/V distribution and control system such as those from Niles® and Xantech®.

If the remote controller signal does not reach the DPS-8.3 remote sensor

If the DPS-8.3 is located inside a cabinet or other enclosure where the infrared rays from the remote controller cannot enter, then operation with the remote controller will not be possible. In such a case, it will be necessary to install a remote sensor at a location outside of the cabinet for the infrared rays from the controller to reach.

IR Receiver

IR IN

DPS-8.3

In the cabinet

Connecting block

Remote Controller

Make connection as shown below. Do not plug the equipment into the power source until the connection is completed.

from connecting block

Mini plug cable

DPS-8.3

OUT

If the remote controller signal does not reach other components

In this situation, you will need to use a commercially-available IR emitter. Connect the mini plug of the IR emitter to the IR OUT terminal on the DPS-8.3. Then place the IR emitter on the remote sensor of the component or facing it. When the IR emitter is connected, only the signal input to the IR IN terminal is output to the IR OUT terminal. The signal input from the remote sensor on the front of the DPS-8.3 will not be output to the IR OUT terminal.

: Signal flow

IR IN

IR OUT

other component

from connecting block

Connecting block

Mini plug cable

DPS-8.3

IR Emitter

Mini plug

IR Receiver

Remote Controller

Emitter

Mini plug cable

: Signal flow

Remote control sensor

OUT

DPS-8.3

IR Emitter

:Signal flow

Connecting the Power/Turning on the DVD Player

Before connecting

• The DPS-8.3 is shipped with the main power (Power) switch in the on position (_ On). When the power cord is plugged in for the first time, the DPS-8.3 will automatically enter the standby state and the Standby indicator will light (same condition after step 2 below).

• Make sure that all the connections on pages 15-18 are complete (the connection to a TV is required).

Power

Standby/On

Plug the supplied power cord into the AC INLET and then into the power outlet on the wall.

• Do not use a power cord other than the one supplied with the DPS-8.3. The power cord supplied is designed for use with the DPS-8.3 and should not be used with any other device.

• Never have the power cord disconnected from the DPS-8.3 while the other end is plugged into the wall outlet. Doing so may cause an electric shock. Always connect by plugging into the wall outlet last and disconnect by unplugging from the wall outlet first.

AC INLET

To the mains

Press Power to switch on the main power.

The DVD Player enters standby mode. The STANDBY indicator lights up.

• The buttons on the remote controller do not operate if the Power switch is set to Off.

• To switch off the main power, press Power again.

Press Standby/On on the DVD Player or On on the remote controller.

The DVD Player turns on and the Standby indicator turns off.

• To put the DVD Player in the standby mode, press Standby/On on the DVD Player, or Standby on the remote controller. Be sure to set the volume to minimum before putting the DVD Player in the standby mode for the next use to avoid sudden loud sound reproduction.

• While the Standby indicator lights up, the DVD Player can receive signals from the remote controller. However, if you press Power on the DVD Player to switch off the main power, the remote controller cannot be used to turn on the DVD Player.

• Setting the Standby button to standby does not shut off the power completely.

■ Setting the TV System (Australian model only)

The default setting of this player is AUTO, and unless you notice that the picture is distorted when playing some discs, you should leave it set to AUTO. If you experience picture distortion with some discs, set the TV system to match your country or region’s system. Doing this, however, may restrict the kinds of disc you can watch. The table below shows what kinds of disc are compatible with each setting (AUTO, PAL and NTSC).

Disc Output format

Type

DVD

Video CD

CD, No disc

1 Switch the player into standby. 2 Hold down ¢ then press Standby/On until the display

indicates the new setting to switch the TV system.

The TV system changes as follows: AUTO = NTSC NTSC = PAL PAL = AUTO Note that you have to switch the player into standby before each change.

About MOD. (Modulation) PAL

• SHRINK Most models of the newly developed countdown PAL TV system detect 50 Hz (PAL)/60 Hz (NTSC) and automatically switch vertical amplitude, resulting in a display without vertical shrinkage.

• If your PAL TV does not have a V-Hold control, you may not be able to view NTSC disc because the picture may roll. If the TV has a V-Hold control, adjust it until the picture stops rolling. On some TVs, the picture may shrink vertically, leaving black bands at the top and bottom of the screen. This is not a malfunction; it is caused by the NTSC = PAL conversion.

Format

NTSC

PAL

NTSC

PAL

Position of TV SYSTEM mode

NTSC PAL AUTO

NTSC MOD. PAL NTSC

PAL PAL

NTSC MOD. PAL NTSC

NTSC PAL PAL

NTSC PAL NTSC or PAL

Setting Up the Player

The Setup Navigator has been designed to simplify the process of getting the DVD player ready to perform. Designed as a series of on-screen multiple-choice questions, the Setup Navigator automatically sets the audio, video, and language settings according to how the questions are answered. Once this procedure is complete, it will be possible to begin using the DVD player to enjoy DVDs. The procedure on this page describes the operations necessary to function within the Setup Navigator screens. A detailed description of the contents of each question that appears on the screen can be found on the following pages.

Using the Setup Navigator

Audio SEL

TV / VCR

Step/Slow

Repeat

RPT

A-B

B PIC C.M

RC-499DV

Display

VOL

ENTER

Dimmer

DIS

Pause

Speed

Surround

Random

Program

RND

PGM


Cond M

2/3/5/∞

Video Off

Setup

Muting

DIM

Step/Slow

Clear

CLR

Function M

Press On (Standby/On on the front panel).

If there’s already a disc loaded and it starts to play, press 7 to stop it.

Press SETUP.

When Setup is pressed for the first time, the following screen appears. Though the Setup Navigator may be used more than once, this screen only appears the first time Setup is pressed.

Audio1

Setup Navigator

Setup using the Setup Navigator

Video1

Setup Navigator

Move

Language

Start

Auto Start Off

Select

General

SETUPENTER

Exit

Use the cursor buttons (5/∞) to make a selection.

• If you are going to use the Setup Navigator, it is not necessary to change the setting on the first screen. Please proceed to the next step.

• If you do not want to set up the player using the [Setup Navigator], use the cursor button (∞) to select [Auto Start Off] at this time. The Setup Navigator function may still be used at a later time in manual Setup screen menu operation (page 46).

■ When setting up for the first time

Some DVDs start playing automatically when loaded in the player. Because the Setup Navigator cannot be used if a disc is playing, it is recommended to set up the player using the Setup Navigator before loading a DVD for the first time. If a DVD has been loaded, be sure to press 7 before proceeding.

■ To change the answer to a prior question

Use the cursor button (2) to return to previous screens. Please note, however, that you cannot go forward using the cursor button (3), so it will be necessary to answer all the questions that occur after the screen that was returned to.

■ To exit the Setup Navigator

Press Setup while on any of the screens to exit the Setup Navigator. Please note that if the Setup Navigator is exited before all the questions are answered, no settings are changed.

Note

On-screen information (i) appears to clarify the functions and explain the options available.

Press ENTER.

The selection is entered and the next Setup Navigator screen appears.

Use steps 3 and 4 as a basis for entering selections on the all of the Setup Navigator screens described on the following pages.

Setting Up the Player

General

Language

Audio1

Video1

Exit

Move

Select

2channel jacks for L/R

Setup Navigator

Analog Jacks

Amp Connection

2 ChannelDolby Digital/DTS

5.1Channel Not Connected

SETUPENTER

General

Language

Audio1

Video1

Exit

Move

Select

Center speaker is connected to an amplifier

Setup Navigator

Center Speaker

Amp Connection

PresentDolby Digital/DTS

Not Present

SETUPENTER

General

Language

Audio1

Video1

Exit

Move

Select

Surround speakers are connected to an amplifier

Setup Navigator

Surround Speakers

Amp Connection

PresentDolby Digital/DTS

Not Present

SETUPENTER

General

Language

Audio1

Video1

Exit

Move

Select

Sub–woofer is connected to an amplifier

Setup Navigator

Sub–woofer

Amp Connection

PresentDolby Digital/DTS

Not Present

SETUPENTER

Using the Setup Navigator

■ Setting the OSD Language (On-Screen Display Language)

The [OSD Language] screen establishes the OSD language, or on-screen display language, which refers to the language that is used by the player in menus and on-screen messages. Additionally, the language that is established at this setting will also be used for the default audio and subtitle language.

Video1

OSD Language

Move

français Deutsch Italiano Español

Language

English

français Deutsch Italiano Español

Select

General

SETUPENTER

Exit

Audio1

Setup Navigator

Language

Select the On Screen Language

Settings: English

Notes

• The languages that can be selected may be different from those shown above.

• In addition to setting the [OSD Language], the audio and subtitle language are also set at this time. If you wish to change the audio or subtitle language to a different language, make changes in the Setup screen Language menu [Audio Language] and [Subtitle Language] as needed (pages 57, 58).

■ Setting the type of analog audio connections

The [Amp Connection] screen establishes the type of analog audio connection you made to your amplifier/receiver.

Settings: 2 Channel

5.1Channel Not Connected

If you select [5.1Channel] audio connection, confirm which speakers are connected to your amplifier.

■ Setting the TV screen size

The [TV Type] screen establishes the size, or more appropriately the width to height ration of your television or monitor. The width-to-height ratio of conventional TVs is 4:3, while the width-to-height ratio of wide screen and highdefinition TVs is 16:9. This width-to-height ratio is called the aspect ratio.

Audio1

Setup Navigator

TV Connection

Widescreen TV 16:9 aspect raito

Settings: Widescreen (16:9)

Note

There are two screen formats that can be used to display wide-screen format DVDs: letter box and pan & scan. When [Standard (4:3)] is selected in the Setup Navigator, the letter box screen format is automatically selected. To switch the preference to the pan & scan format, make changes in the Setup screen Video 1 menu [TV Screen] setting (page 52).

Video1

TV Type

Move

Standard (4:3)

Language

General

Widescreen(16:9)

Standard(4:3)

SETUPENTER

Select

Exit

Note

If you connected the audio output directly to your TV, choose [2 Channel].

■ Setting digital audio connections to an AV amplifier or decoder

The [Digital Jack] screen establishes whether digital connections have been made to an AV amplifier, receiver, or external decoder. As there are numerous options available, please refer to the instructions supplied with the component the player is connected to determine what digital audio formats can be decoded. If you have made no digital connections, select [Not Connected].

Audio1

Setup Navigator

Amp Connection

Compatible with Dolby Digital

Settings: Dolby Digital

Warning

• Do not set [Digital Jack] to [Dolby Digital/DTS] or [Dolby D/DTS/ MPEG] if the amplifier does not have a DTS decoder. If you do so, high volume sound may be output and damage your hearing as well as speakers.

• Select [PCM] when you connect the player to a 2 channel digital stereo amplifier. If you select other than [PCM], high volume sound may be output and damage your hearing as well as speakers.

Language

Video1

Digital Jack

Move

Dolby Digital

Dolby Digital/DTS Dolby Digital/MPEG Dolby D/DTS/MPEG PCM Not Connected

General

Select

SETUPENTER

Exit

■ Confirming the settings

The [Exit Setup Navigator] is the final screen in the Setup Navigator.

Video1

Move

Language

Save Changes

Delete Changes Start Again

Select

General

SETUPENTER

Exit

Audio1

Setup Navigator

Exit Setup Navigator

Changes are saved

Settings: Save Changes

Select to have the player make all of the necessary audio, video and language settings according to your responses in the Setup Navigator.

Delete Changes

Select to exit the Setup Navigator without changing any of the system settings.

Start Again

Select to return to the [OSD Language] screen of the Setup Navigator and do the settings again.

■ To change other player settings in the Setup screen menus

The procedure for changing the settings in the Setup screen menus is described on page 46.

■ Setting compatibility with 96 kHz output

The [96 kHz PCM Audio] screen establishes whether or not the AV component the player is connected to is capable of processing an audio signal with a sampling rate of 96 kHz. This screen only appears if connections have been made to an external AV component as determined in previous screens.

Audio1

Setup Navigator

Amp Connection

Digital jack not compatible with 96kHz

Settings: No

Language

Video1

96kHz PCM Audio

Move

General

Yes Don't Know

Select

SETUPENTER

Exit

Select if the connected AV component cannot process an audio signal with a sampling rate of 96 kHz.

Yes

Select if the connected AV component can process an audio signal with a sampling rate of 96 kHz.

Don’t Know

Select if you are uncertain whether the connected AV component can process an audio signal with a sampling rate of 96 kHz.
