Insignia NS-DVB2G, NS-DVB4G User Manual
User Guide | Guía del Usuario
Music/Video Player | Music/Video Player
NS-DV2G/DV4G / NS-DVB2G/DVB4G
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Insignia NS-DV2G/NS-DV4G/
NS-DVB2G/NS-DVB4G
Video MP3 Player
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Controls and connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Setting up your video MP3 player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Charging the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing the included software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using your video MP3 player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Turning your player on and off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Navigating the on-s
Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Locking the buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Getting more music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Tr ansferring music files to your player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Playing music files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Viewing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Watching videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Deleting all files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Disconnecting the player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Listening to FM radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Connecting to Bluetooth headphones (NS-DVB2G and NS-DVB4G models only) . . . . . . . . . . . . . . . . . . . 24
Changing settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Maintaining your video MP3 player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Care and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Upd
ating the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Buying a new battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Tr oubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Getting help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Learn more . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
creen menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your NS-DV2G, NS-DV4G, NS-DVB2G,
or NS-DVB4G represents the state of the art in digital media players and is designed for reliable and
trouble-free performance. You can use your video MP3 player to play digital video and music files, play
audiobooks from Audible.com, and listen to FM radio, and you can c
arry it with you anywhere.
Safety information
•Read, keep, and follow all instructions. Heed all warnings.
•Only use attachments and accessories for Insignia products or Universal accessories.
•Turn down the volume before turning on your video MP3 player and avoid using it at a high volume.
Permanent hearing loss may occur if earphones or headphones are us ed at high volu
volume also extends battery life.
www.insignia-products.com
me. Reduced
1
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
• Do not use headphones or earphones while driving, cycling, or operating any motorized vehicle. This
may create a traffic hazard and may be illegal in your area.
•To reduce the chance of electrical shock, do not use or operate this device near moist environments.
• Unplug the player during lightning storms or when unused for long periods of time.
•Risk of explosion, damage, or ba ttery leakage if the battery is replaced incorrectly or repl
incorrect type. Dispose of us ed batteries according to local regulations.
•Clean only with a dry cloth.
• Do not disassemble the player to access internal components (except for the battery) under any
circumstances.
aced by an
Features
•Plays MP3, OGG, WMA, secure WMA, and Audible audio file formats.
•Plays WMV and MPEG-4 video file formats.
•Displays JPEG photos.
•Backlit LCD supports several languages and displays album art and song information.
•Digital FM radio tuner allows you to access local radio station
your favorite radio stations.
•Five preset equalizer settings to optimize playback for normal, rock, jazz, classical, and pop music. You
can also set a custom equalizer setting for a total of six to choose from.
• Sophisticated music library sorting lets you browse the music in your player by a
genre, and playlist.
• A-B Repeat lets you select any start and end points during playback, so you can repeatedly play that
segment. This feature is especially helpful while learning languages and words to songs.
•High-speed mini USB 2.0 port for fast and easy file transfers.
•S
upports Microsoft WMDRM 10 technology.
•Fully compatible with the Best Buy Digital Music Store, and other Microsoft PlaysforSure music services
like Napster, and Yahoo.
•Easy-to-use menus.
•Mechanical wheel controls with middle select, and Menu and Power buttons.
•Two audio jacks for Dua l headphones and line-in jack for CD quality 16-bit/48kHz stereo recording.
•Support for external memory (MicroSD Card).
•Upgrade
•Easily replaceable and rechargeable lithium ion battery for up to 20 hours of music playback time and a 3
hour recharge time.
able firmware to keep your video MP3 player up to date.
s. The radio also memorizes up to 20 of
rtist, album, song title,
Package contents
•Insignia video MP3 player
•Rechargeable lithiu m ion battery
•Earbuds
• Mini USB 2.0 cable
•Quick Start Guide
•CD (contains Best Buy Digital Music Store software and this online us er guide)
•Audible and music offer cards
•Carrying case
System requirements
To transfer music from your computer to your video MP3 player, your computer must have the following
minimum system requirements:
• Windows 98 or later; Mac OS8.6 (requires software update) or later
•One available USB port
• CD Rom Drive
2
www.insignia-products.com
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Controls and connections
Front
Item Icon Function
A Rewind/Skip Back/Previ ous—
• Press to restart the current track.
• Press repeatedly to skip to previous tracks.
• Press and hold to rewind.
• In FM radio mode, press to chan ge frequencies.
• In Menu mode, press to go to the previous menu.
BPower—
• Press and hold to turn on th e player.
• Press and hold again to turn off.
• Press briefly to return the screen to full bright ness.
C Up—Press to scroll up through li s t s or change radio frequency pre sets.
DMenu—
• Press to open the on-screen men u f or selecting songs and changin g
settings.
• Press and hold to go back to t he previous menu setting.
E Fast Fo rward/Skip/Next —
• Press to skip to the next track.
• Press and hold to fast forward.
• In menus, press to open the next submenu or setting.
• In FM radio mode, press to chan ge frequencies.
F Down—Press to scroll down through lists or change radio frequency presets.
G Play/Pause/Select—
• Press to play or pause playback.
• In menus, press to select.
• In FM radio mode, press to memorize presets or to record.
Scroll wheel—Volume in Now Playing mode and Up/Down in Menu mode.
www.insignia-products.com
3
Right side
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Item Icon Function
A Earphone jack—Connect earph ones or headphones to thi s jack.
Top
Bottom
B Mini USB 2.0 port—Connect the USB cable to this port and yo ur computer to
charge the player manage cont ent with your computer.
Item Function
A MicroSD Card slot—Insert a MicroSD card into this slot to increase the memory
capacity of your player.
B HOLD switch—Slide to disable all buttons. See Manually changing the USB
mode on page 27.
Item Function
A Earphone/Line in jack—Connect earphones or headphones to this jack to listen
to sound from the player or connect a device to this jack to record from the
device.
B RESET button—Insert a pointed obj ect to restart the player.
4
www.insignia-products.com
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Back
Item Function
A Battery cover—Remove the battery cover to insert or chang e the battery.
Display
Item Function
A Mode Icon—Displays whether a track is playing or paused.
B Current time—Displays the current t ime.
C Repeat/Shuffle icon —Indicates the current Repeat set ting.
D Battery icon—Indicates the battery's p ower level.
E Track number/Total Number—Lists the track number currently playing and the
number of tracks in the queue.
F Artist name—Displays the artist name of the current track.
G Album name—Displays the album name of the current track.
H Album Art—Shows the album art for the track, if available.
I Track name—Displays the track title of the current track.
J Progress bar—Displays the progress of the song.
K Play time—Displays the elapsed time of the current track.
L Total time—Displays the length of the current track.
M Next tr ack—Displays the next track.
www.insignia-products.com
5
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Setting up your video MP3 player
Installing the battery
1 Slide off the battery cover on the back of the video MP3 player.
2 Press the battery into the battery compartment, then slide it into place. The battery should fit snugly.
3 Slide the battery cover until it snaps into place.
Note
A plastic sheet has been placed over the screen to protect it in shipping. Remove the sheet before
continuing.
6
www.insignia-products.com
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Charging the battery
Charge the battery whenever you aren't using the player to make sure it's always fully charged. The battery
charges in about 3 hours. A fully charged battery provides up to 20 hou rs of continuous music playback,
depending on the brightness and display time of the backlight, and the volume levels. You do not need to
fully charge the battery before beginning to use your player.
To charge the battery:
1 Turn on your computer.
2 Connect the supplied mini USB 2.0 cable to the mini USB jack on the player and a standard USB jack on
your computer. When the cable is connected correctly, the player begins recharging its battery using the
USB connection, and the message “OK to disconnect” appears on the player.
As the battery cha rges, the blue battery icon shows an animation of being filled from right to left, to
illustrate that the battery is cha
After the player is fully charged, the battery icon turns green, indicating a full charge.
rging.
Connecting headphones
Yo u can use any headphones with a standard 3.5mm stereo audio plug.
Note
To use Bluetooth headphones instead of standard wired headphones, see Connecting to Bluetooth
headphones (NS-DVB2G and NS-DVB4G models only) on page 24. Bluetooth is available on the
NS-DVB2G and NS-DVB4G models only.
To connect headphones:
Plug headphones or the provided earphones into the earphone/headphone jacks on the player.
•
Note
To use the FM radio, you must have the provided earphones connected, because they act as the FM
antenna. You can use any headphones with unshielded wires.
Installing the included software
The instructions in this guide require installation of both the Best Buy Digital Music Store Media Manager
Software and the ArcSoft Media Converter.
Note
Attention Apple Users (OS 8.6 and higher):
•Do not install the software.
• Connect your player to your computer.
www.insignia-products.com
7
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
To install the software:
1 Insert the Insignia software CD into your computer's CD drive. The software installation program starts.
-ORIf the installation program doesn't start automatically, double-click My Computer on your desktop,
double-click the CD drive that contains the Insignia CD, then double-click the file Setup.exe. The
software installation program
2 Follow the on-screen instructions to finish the installation.
Tip
For iTunes Drag and Drop support, File & Folder (MSC) USB mode is automatically enabled when you
connect the player. Your Insignia MP3 player will only play iTunes MP3 files that you drag and drop from
iTunes. For information on changing USB modes, see Manually changing the USB mode on page 27.
starts.
Using your video MP3 player
Turning your player on and off
To turn your player on and off:
1 Press and hold (Power).
2 To t urn off your player, press and hold (Power) again.
Navigating the on-screen menus
Use the on-screen menu to play music and change settings.
To navigate the on-screen menu:
1 Press
2 Use the scroll wheel to highlight one of the following menu items:
• Now Playing—displays the track currently playing.
• Music Library—access your stored tracks.
• Audible Books—access your stored Audible files.
• Video—access your stored video files.
• Photo—access your stored photo files.
• FM Radio—access the bu
• Recording—record a file using the Line-in jack.
• Settings—access your video MP3 player settings.
3 Press
press (Previous).
Tip
(Menu). The main menu opens.
ilt-in FM radio.
(Next). The submenu of the item you selected opens. To navigate backwards from a submenu,
Press and hold the
(Menu) button to return to the menu you were last navigating.
Recording
Yo u can record sound on your video MP3 player either from an attached device such as a CD or MP3 player,
or from the built-in FM radio.
Recording from a device
To record from an attached device:
1 Connect your Video MP3 player to the device using a standard 3.5 mm stereo cable. One end of the
cable plugs into the line out jack on your device and the other end plugs into the line in jack on the Video
MP3 player.
2 (Optional) If you would like to change the recording quality or size then select Settings from the Main
menu, Record, then select Encoder. Choose either WMA or PCM (PCM provides the highest quality),
then select the quality level of the recording.
3 Press
4
Use the scroll wheel to select Recording, then press (Next) or (Play/Pause).
5 Press and hold
6 Press and hold
(Menu). The main menu opens.
(Play/Pause) to start recording, then release the button.
(Play/Pause) to stop recording, then release the button.
Tip
To record from a microphone, use an amplified microphone for best results.
8
www.insignia-products.com
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Recording a radio broadcast
To record an FM radio broadcast:
1 Press
2
Use the scroll wheel to select FM Radio, then press (Next) or (Play/Pause).
3 Tune to the broadcas t you want to record.
4 Press and hold
5 Press and hold
Note
Listening to a recording
To listen to a recording:
1 Press
2
Use the scroll wheel to select Music Library, then press (Next) or (Play/Pause).
3
Use the scroll wheel to select Recordings, then press (Next) or (Play/Pause).
Use the scroll wheel to select the select the recording to listen to, then press (Next) or
4
(Play/Pause). The play pop-up opens.
5
Use the scroll wheel to select Play, then press (Next) or (Play/Pause). The recording plays.
Changing the volume
(Menu). The main menu opens.
(Play/Pause) to start recording, then release the button.
(Play/Pause) to stop recording, then release the button.
All radio recordings use WMA 128kb/s for recording.
(Menu). The main menu opens.
To change the volume:
•Turn the wheel to the right or left to change the volume.
Locking the buttons
Yo u can prevent accidental button operation by locking the buttons.
To lock the buttons:
1 Slide the HOLD switch in the direction of the arrow. An image of the hold button in the HOLD position
appears on the screen.
2 To unlock the buttons, slide the HOLD switch away from the arrow.
Note
To use File & Folder (MSC) USB mode (UMS), see Manually changing the USB mode on page 27.
www.insignia-products.com
9
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Getting more music
Yo ur video MP3 player already contains some mus ic files, but you can get more music from your own music
CDs and from the Internet.
Getting music from CDs and the Internet to your video MP3 player involves two steps :
1 Rip a CD (create files of the music on the CD) or download music files from the Internet.
2 Select the files to copy and copy them to your player.
Getting more music on your computer
Getting music from CDs
To rip a CD:
1 Click Start, All Programs, Best Buy Digital Music Store, Best Buy Digital Music Store. Best Buy
Digital Music Store opens.
10
2 Put a music CD in the CD drive, then close any dialog boxes that may open. Best Buy Digital Music Store
lists the tracks on the right side of the screen. If you are connected to the Internet, the list shows the track
names.
3 Click the check boxes
in front of the songs you want to copy.
www.insignia-products.com
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
4 Click Import CD. Best Buy Digital Music Store creates MP3 files from the music tracks on the CD and
lists them under the My Library folder.
For information on transferring your music files to your video MP3 player, see Transferring music files to
your player on page 13.
www.insignia-products.com
11
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Getting music from Digital Music Store
To buy and download music files from the Internet:
1 Click Start, All Programs, Best Buy Digital Music Store, Best Buy Digital Music Store. Best Buy
Digital Music Store opens.
2 In the Search box, type the name of the artist or album you want to download music for, then click Go.
Any matches that Digital Music Store finds are displayed on the screen.
3 Decide which tracks or albums you wa
nt to buy, then click BUY next to the music you want.
4 Follow the on-screen directions to finish the purchase. The music files are added to your Digital Music
Store music library.
Tip
Yo u can also use other digital music management programs to get music files from CDs and the
Internet. See the program's online help for more information.
Tip
For iTunes Drag and Drop support, File & Folder (MSC) USB mode is automatically enabled when you
connect the player. Your Insignia MP3 player will only play iTunes MP3 files that you drag and drop from
iTunes. For information on changing USB modes, see Manually changing the USB mode on page 27.
12
www.insignia-products.com
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Tran sferring music files to your player
Copying files using Best Buy Digital Music Store
To copy files from your computer to the video MP3 player using Best Buy Digital Music Store:
1 Connect the USB cable to a USB port on your computer and the mini USB port on your player. The
message “Searching for PC” appears on the player.
Yo ur computer detects the player, and adds the player as a new device (“Insignia Video Player”) in the My
Computer list of drives in Windows.
2 Click Start, All Programs, Best Buy Digital Music Store, Best Buy Digital Music Store. Bes
Digital Music Store opens.
3 Close any popup windows that open.
4 Click My Library in the list of content types. Your entire library of digital music appears in the right side of
the screen.
5 Click and drag the music files from your library list to the Insignia Video Player item in the Sources list.
t Buy
www.insignia-products.com
13
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
As the songs are copied to your player, the message “Syncing: Do not disconnect device” appears on the
player.
6 When you have finished transferring a ll of the files you want to copy to your Insignia Video Player, you
can click Insignia Video Player in the list of sources to view the updated list of tracks on your player.
14
When the transferring is complete, the message “OK to disconnect” appears
7 Unplug the USB cable from your computer and your player.
www.insignia-products.com
on the player.
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Tran sferring files using Windows Explorer
For Windows XP and Windows 2000 users, the player automatically connects in Media Manager (MTP)
mode to copy WMA and MP3 files to the Media folder, and any other file formats to the Data folder (you
cannot see the Data folder using the player's display).
Depending on which media manager software (such as BBDMS, Windows Media Player, and many others)
you use, the name of the su bfolders may be different th
For all other operating system users, the player automatically connects in File &Folder (MSC) mode to copy
folders and any format of files to the player's root folder. The player will still only play MP3, Vorbis, and WMA
files.
To copy m u sic files from your computer to your player using Windows Explorer:
1 Connect your player to the computer using the provided USB cable. The message “Searching for PC”
appears on the player.
an “Media” and “Data.”
2 On your compu
3 Open My Computer again to open another window, then open the Insignia Video Player drive. (When
your computer detected the player, it added the player as a new device called “Insignia Video Player” in
the My Computer list of drives in Windows.)
4 Double-click the device and the internal storage icon until you see a list of files and folders.
5 Click and drag the music files from your comp
• If your player is in Media Manager (MTP) mode, copy them to the Media folder on the player.
• If your player is in File & Folder (MSC) mode, copy them to the root folder on the player.
Tip
To s elect multiple files, press and hold Ctrl on your keyboard while clicking the files with your mouse.
To s elect an entire range of files, click the file at the top of the range, press and hold Shift on your
keyboard, then click the file at the bottom of the range.
When the transferring is complete, the message “OK to disconnect” appears on the player.
ter, click Start, My Computer, then double-click the folder where your music files are.
uter to the player:
www.insignia-products.com
15
6 Unplug the USB cable from your computer and your player.
Tip
Vor bis files will only be recognized in File and Folder (MSC) mode. See Manually changing the USB
mode on page 27.
Playing music files
To play music:
1 Press
2
Use the scroll wheel to highlight Music Library, then press (Next). The music library opens.
(Menu). The main menu opens.
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
3 Highlight one of the following tabs across the top of the screen using the scroll wheel, then press
(Down) or (Play/Pause) to open that category:
• Artists—Lists all artists transferred to the player.
• Albums—Lists all albums transferred to the player. Even if you copied only one track from an album to
your player, that album name will appear in this list.
• Tra cks—Lists all track
• Genres—Lists all music genres transferred to the player.
• Playlists—Lists all playlists transferred to the player.
• Recordings—Lists all the recorded files on the player.
• Audible—Lists all Audible tracks.
Tip
To n avigate backwards from a submenu, press
4 Select the content to play by pressing
playing the music. Play and Play All start playing the music immediately. Add to Now Playing queues
the music behind the tracks that are currently playing. Select Play All to play all the tracks. The player
switches to the Now Playing view, which displays information on the track currently playing.
The album art a
(Next) again to see the list of songs selected for playback. Pressing (Next) toggles through the various
screens.
ppears on the left of the display. P ress (Next) to view full screen album art. Press
s arranged alphabetically by track title.
.
(Play/Pause). A pop-up menu shows the options you have for
16
www.insignia-products.com
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
5 If your selection does not begin to play, pre ss (Play/Pause).
Play/Pause
The track begins playing, and the play status icon ( ) appears in the upper left corner of the display.
•To pause playback, press
(Play/Pause). The pause status icon ( ) appears in the upper left corner
of the screen.
•To skip to the next track, press
(Skip/Fast Forward) (2). To skip to a previous track, press (Skip
Back/Rewind) (3) repeatedly.
Skip
back
Skip
•To fast forward the current track, press and hold
press and hold
•To restart the current track, press
Tip
If you are using a subscription music service, your player will play a short tone between tracks when
your content is about to expire and a message appears on the screen telling you how many days are left
before your content expires.
(Skip Back/Rewind).
(Skip Back/Rewind) once.
(Skip/Fast Forward). To rewind the current track,
www.insignia-products.com
17
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Repeating and shuffling playback
Yo u can set the player to repeat or shuffle tracks using the Repeat/Shuffle menu.
To shuffle the playback order:
1 In the Settings menu, select Audio, then press
2 In the Audio menu, select Repeat/Shuffle Playback, then press
3 Use the scroll wheel to select from the following modes, then s elect
(Next) or (Play/Pause).
(Next) or (Play/Pause).
(Next). The shuffle icon appears.
Yo u can select from the following modes:
• Repeat single track
•Shuffle tracks/No repeat
• Repeat all tracks
• Repeat all tracks with shuffle
Repeating segments of a track
Yo u can use A-B repeat to repea tedly play a segment of a track. You must first enable A-B repeat.
To enable A-B repeat:
1 Press
2 Use the scroll wheel to highlight Settings, then press
3 Use the scroll wheel to highlight Audio, then press
4 Use the scroll wheel to highlight A-B repeat, then press
5 Use the scroll wheel to highlight On or Off, then press
6. Press
(Menu). The main menu opens.
(Next) or (Play/Pause).
(Next) or (Play/Pause).
(Next) or (Play/Pause).
(Next) to select. The message “Use the down
button to activate A-B” appears, then the Audio Setting menu opens again.
(Menu) to return to the Now Playing screen.
To repeat an audio segment:
1 During playback, press
(Down) to mark the start of the playback loop. The Repeat icon on the display
shows an “A.”
2 Press (Down) a gain to mark the end of the playback loop. The Repeat icon on the display shows an
“AB” and the player repeats that audio segment indefinitely.
3 Press (Down) a gain to cancel the repeating loop.
Using the equalizer
Six equalizer settings are available, and five are preprogrammed: Normal, Rock, Jazz, Classic, and Pops.
The User setting lets you cus tomize the equalizer to your preference.
To select a pre-programmed equalizer setting:
1 In the Settings menu, select Audio, then press
2 In the Audio menu, select Equalizer, then press
(Next) or (Play/Pause).
(Next) or (Play/Pause).
3 Use the scroll wheel to select the equalizer setting you want.
4 Press
(Next) or (Play/Pause) to save your new settings.
To change the equalizer's custom setting:
1 In the Settings menu, select Audio, then press
2 In the Audio menu, select Equalizer, then press
(Next) or (Play/Pause).
(Next) or (Play/Pause).
3 Use the scroll wheel to select the Custom setting.
4 Press
5 Press
6 Press
(Play/Pause) to move the cursor to the first equalizer setting dial.
(Up) or (Down) to adjust the setting. Repeat this step to adjust each remaining dial.
(Play/Pause) to save your new settings.
Playing Audible files
Yo u can listen to Audible audio books on your player.
18
To play Audible files:
1 Press
(Menu).
2 Use the scroll wheel to highlight Audible, then press
3 Use the scroll wheel to select the Audible file, then press
4 Press (Previous) or
(Next) to play the previous or next Audible file.
www.insignia-products.com
(Next) or (Play/Pause).
(Next) or (Play/Pause).
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
Moving between chapter in an Audible audio book
To move between chapters in Audible files:
1 Press
2 Press (Previous) or
3 Press
Tip
(Up) while playing an Audible file to turn on the chapter feature.
(Next) to move to the previous or next Audible chapter.
(Up) to turn off the chapter feature.
For more information about Audible, visit the Audible website at http://www.audible.com.
Viewing photos
Yo ur player can display JPG and JPEG photos. No other photo formats are supported. To display
non-JPG/JPEG photos, you must first convert them to JPG or JPEG using the MediaCoverter software
found on the enclosed CD. Using the included Media Converter significantly reduces the file size and allows
you to store may more photos on the player.
To view photos:
1 Press
2 Select Photo, then press
3 Use the scroll wheel to select the photo to display, then press
displays full screen.
•Press
•Press
•Press
Tran sferring photos to your player
The method you use to copy photos from your computer to your player depends on the USB mode your
player is set to. When you connect your player to your computer, the player automatically selects the mode
that is best suited to your operating system. The player shows the mode in the bottom left corner of the
display.
(Menu). The main menu opens.
(Next) or (Play/Pause). A list of available photos appears.
(Next) or (Play/Pause). The photo
(Previous) or (Next) to skip forward and backward.
(Play/Pause) to enter zoom mode, then press the direction buttons to pan the image.
(Up) to rotate the photo 90°.
Tip
Yo u can also use the ArcSoft Media Converter software to convert and transfer all images to your player.
To copy photos from your computer to your player using File & Folder (MSC) USB mode:
1 Connect your player to the computer using the provided USB cable. The message “Searching for PC”
appears on the player.
2 On your computer, click Start, My Computer, then double-click the folder where your photo files are.
3 Open My Computer again to open another window, then open the Insignia Video Player drive.
4 Click and drag the photo files from your computer to the player's root folder.
Tip
To select multiple files, press and hold Ctrl on your keyboard while clicking the files with your mouse. To
select an entire range of files, click the file at the top of the range, press and hold Shift on your
rd, then click the file at the bottom of the range.
keyboa
When transferring is complete, the message “OK to disconnect” appears on the player.
5 Unplug the USB cable from your computer and your player.
To copy photos from your computer to your player using Media Manager (MTP) USB mode:
1 Connect you
r player to the computer using the provided USB cable. The message “Searching for PC”
appears on the player.
2 On your computer, click Start, My Computer, then double-click the folder where your photo files are.
3 Open My Computer again to open another window, then open the Insignia Video Player drive.
4 Click and drag the photo files from their current location to the Media folder or the root folder on your
Insignia Video Player drive.
Tip
To select multiple files, press and hold Ctrl on your keyboard while clicking the files with your mouse. To
select an entire range of files, click the file at the top of the range, press and hold Shift on your
keyboard, then click the file at the bottom of the range.
When transferring is complete, the message “OK to disconnect” appears on the player.
www.insignia-products.com
19
Insignia NS-DV2G/NS-DV4G/ NS-DVB2G/NS-DVB4G Video MP3 Player
5 Unplug the USB cable from your computer and your player.
Tip
Yo u can also use the ArcSoft Media Converter software to convert and transfer all images to your player.
Deleting photos
To delete photos, see Deleting all files on page 21.
Watching videos
Converting and transferring videos to your player
To copy videos from your computer to your player using ArcSoft Media Converter:
1 Connect your player to the computer using the provided USB cable. The messa ge “Searching for PC”
appears on the player.
2 Open the ArcSoft Media Converter on your computer.
20
3 Click Add Media.
4 Click the file you want to convert, then click Open.
www.insignia-products.com
Loading...
