FOREWORD

Thank you for purchasing an INFINITI vehicle.

This user’s manual is for the navigation system only. This manual contains operating instructions for the INFINITI Navigation System offered in your INFINITI vehicle.

Please read this manual carefully to ensure safe operation of the navigation system.

. Because of possible specification

changes and optional equipment, sections of this manual may not apply to your vehicle.

. All information, specifications and il-

lustrations in this manual are those in effect at the time of printing. INFINITI reserves the right to change specifications or design at any time without notice.

. Do not remove this manual from the

vehicle when selling this vehicle. The next user of this navigation system may need the manual.

1 Introduction

How to use this manual................... 1-2

For safe operation............................ 1-2

Safety information ........................... 1-3

Laser product .................................. 1-4

2. Getting started

Control buttons and functions.. ........ 2-2

Opening/closing the Liquid Crystal

Display (LCD) (G35 Coupe only)........ 2-9

Start-up screen ................ .............. 2-12

Navigation system status screen

(M45/M35 only) ............................ 2-13

Menu screen types and how to

operate.......................................... 2-14

Functions disabled while driving .... 2-23

Operating maps .................. ........... 2-24

Storing your home location/

address ........................ ................. 2-31

Setting a destination ..................... 2-39

Setting the voice guidance............. 2-46

Voice recognition

(M45/M35 only) ............................ 2-52

3 Map settings

Map types ....................................... 3-2

Switching the map view ................... 3-4

Moving a map ...................... ........... 3-7

Changing the scale of a map ......... 3-12

Other settings for the map

screen ........................................ ... 3-15

Map icons ..................................... 3-22

4 Setting a destination

Destination screen ........................... 4-2

Setting a street address/

residence as the destination ............ 4-4

Setting a stored location as the

destination .................................... 4-21

Setting a facility as the

destination .................................... 4-32

Operations after setting a

destination .................................... 4-50

5 Route guidance

Procedures after setting a

destination ...................................... 5-2

About route guidance ...................... 5-7

Route setting ................................. 5-10

Setting conditions for the route

calculation..................................... 5-11

Change/edit route ......................... 5-15

Confirming a route......................... 5-26

Route guidance settings................. 5-30

Deleting/reactivating a route.......... 5-36

6 Storing a location/route

Storing a location ............................ 6-2

Storing a route .............................. 6-12

Storing a tracked route .................. 6-14

Editing the address book ............... 6-15

Deleting a stored item ................... 6-31

Customizing nearby places ............ 6-36

9 Voice recognition

7 Viewing technical information

Information screen

(G35 Coupe, M45/M35 only)............ 7-2

Viewing information about current

vehicle location ............................... 7-4

Viewing GPS current location

information...................................... 7-5

Viewing navigation system version

information...................................... 7-6

8 Other settings

Settings screen (FX45/35, QX56) ..... 8-2

Settings screen

(G35 Coupe, M45/M35) ................. 8-13

Map color settings .................... ..... 8-25

Adjusting the current vehicle

location ......................................... 8-26

Reset all navigation settings to

default........................................... 8-28

INFINITI Voice Recognition................ 9-2

10 General system information

Features of this navigation

system .......................................... 10-2

Current vehicle location ................. 10-4

Route calculation ........................... 10-9

Route guidance ............................ 10-11

Map DVD-ROM ............................. 10-16

How to handle the display ........... 10-22

11 Troubleshooting guide

Customer assistance...................... 11-2

Basic operations............................ 11-3

Vehicle icon................................... 11-4

Map DVD-ROM ............................... 11-6

Route calculation and visual

guidance ...... ................................. 11-7

Voice guidance .............................. 11-9

Voice recognition

(M45/M35 only) .......................... 11-10

MEMO

1 Introduction

How to use this manual ................................... 1-2

For safe operation ........................................... 1-2

Reference symbols....................................... 1-2

Safety information ........................................... 1-3

Laser product .................................................. 1-4

1. Introduction

HOW TO USE THIS MANUAL

This manual uses special words, symbols and icons, organized by function.

Please refer to the following items and familiarize yourself with them.

FOR SAFE OPERATION

WARNING:

This is used to indicate the presence of a hazard that could cause death or serious personal injury. To avoid or reduce the risk, the procedures must be followed precisely.

CAUTION!

This is used to indicate the presence of a hazard that could cause minor or moderate personal injury or damage to your vehicle. To avoid or reduce the risk, the procedures must be followed carefully.

NOTE:

This indicates an item to help you understand and maximize the performance of your vehicle. If ignored, it may lead to a malfunction or poor performance.

REFERENCE SYMBOLS

INFO:

This indicates information that is necessary for efficient use of your vehicle or accessories.

Reference page: This indicates the title and page that you should refer to.

<>: This indicates a button on the control panel.

[]: This indicates a key/item displayed on the screen.

Voice Command (M45/M35 only): This indicates an operation by voice command.

1-2

1. Introduction

SAFETY INFORMATION

This system is primarily designed to help you reach your destination, and it also performs other functions as outlined in this manual. However, you, the driver, must use the system safely and properly. Information concerning road conditions, traffic signs and the availability of services may not always be up-to-date. The system is not a substitute for safe, proper and legal driving.

Before using the navigation system, please read the following safety information. Always use the system as outlined in this manual.

WARNING:

. When the driver wants to operate the

navigation system or use the INFINITI controller (M45/M35 and FX45/35), first park the vehicle in a safe location and set the parking brake. Operating the system while driving can distract the driver and may result in a serious accident.

. Do not rely on route guidance alone. Always

be sure that all driving maneuvers are legal and safe in order to avoid accidents.

. Do not disassemble or modify this system.

If you do, it may result in accidents, fire or electrical shock.

. Do not use this system if you notice any

malfunctions such as a frozen screen or the lack of sound. Continued use of the system may result in accidents, fire or electrical shock.

. If you notice any foreign objects in the

system hardware, spill liquid on the system or notice smoke or a smell coming from it, stop using the system immediately and contact an INFINITI dealer. Ignoring such conditions may lead to accidents, fire or electrical shock.

CAUTION!

. Do not keep the navigation system running

with the engine stopped. Doing so may discharge the vehicle battery. When you use the navigation system, always keep the engine running.

. Some states/provinces may have laws

limiting the use of video screens while driving. Use this system only where it is legal to do so.

1-3

1. Introduction

LASER PRODUCT

This navigation system is certified as a Class 1 laser product.

The navigation system complies with DHHS Rules 21 CFR Chapter 1, Subchapter J.

WARNING:

. Do not disassemble or modify this system.

There are no user serviceable parts in this navigation system.

. If maintenance, adjustments and opera-

tions other than those specified in this manual are attempted, injury due to laser radiation and exposure could occur.

1-4

MEMO

1. Introduction

1-5

2 Getting started

Control buttons and functions...........................2-2

G35 Coupe.................................................. 2-2

QX56.......................................................... 2-4

FX45/35 ..................................................... 2-5

M45/M35 ................................................... 2-6

INFINITI controller

(M45/M35, FX45/35 and G35 Coupe)............ 2-7

Steering switch (M45/M35) ..........................2-8

Opening/closing the Liquid Crystal Display (LCD)

(G35 Coupe only)............................................. 2-9

How to open the LCD ...................................2-9

How to close the LCD ................................. 2-10

Start-up screen.............................................. 2-12

Navigation system status screen

(M45/M35 only) ............................................ 2-13

Menu screen types and how to operate........... 2-14

Menu screens and their purposes

(G35 Coupe, QX56) .................................... 2-14

Menu screens and their purposes

(M45/M35, FX45/35) ................................. 2-15

Using controls to adjust values, levels, etc.

(G35 Coupe, QX56) .................................... 2-17

Using controls to adjust values, levels, etc.

(M45/M35, FX45/35) ................................. 2-18

Map menu screen ...................................... 2-19

Start menu (M45/M35 only) ....................... 2-22

Functions disabled while driving ..................... 2-23

Operating maps............................................. 2-24

How to view map screen ............................ 2-24

Map screen types ...................................... 2-26

Switching map view................................... 2-27

Moving around within a map...................... 2-29

Changing the scale of a map ...................... 2-30

Storing your home location/address................ 2-31

How to store your home............................. 2-31

Character (letter and number) input

screen ...................................................... 2-34

Phone number input screen ........................ 2-36

List screen ................................................ 2-38

Setting a destination...................................... 2-39

Searching for a destination......................... 2-39

Starting route guidance.............................. 2-42

Deleting a route ........................................ 2-44

Setting the voice guidance ............................. 2-46

Turning voice guidance on/off..................... 2-46

Adjusting voice guidance volume ................ 2-48

Voice recognition (M45/M35 only)................... 2-52

INFINITI Voice Recognition........................... 2-52

Before starting ..........................................2-52

Command list............................................ 2-52

Voice command examples .......................... 2-54

2. Getting started

CONTROL BUTTONS AND FUNCTIONS

G35 Coupe

<VOICE>: Push to repeat voice guidance for a

guide point.

<ROUTE>: Push to access guidance control func-

tions (guidance cancellation, route priority, waypoint setting on the route, etc.).

2-2

<SETTING>: Push to access the system settings.

<INFO>: Push to display the navigation informa-

tion, such as GPS and version information, etc.

INI0202

<MAP>: Push to display the current location

map screen.

<DEST>: Push to enter a destination. Various

methods for entering a destination are available.

“4. Setting a destination”

JOYSTICK and <ENTER>: Push to highlight an item on the

screen, select the highlighted item, move on the map, etc.

<BACK>: Push to return to the previous screen.

In a settings screen, this button can also be used to apply the setting.

<ZOOM IN>/<ZOOM OUT>: Push to switch to the zoom mode to

change the map scale.

<CANCEL>: Push to return to the map screen while

making a setting on the menu screen or cancel the route that has already been set.

< > (DAY/NIGHT): Push to switch between the day screen

and the night screen. Push and hold to turn the display on and off.

2. Getting started

2-3

2. Getting started

QX56

< > (ZOOM IN/ZOOM OUT): Push to switch to the zoom mode to

change the map scale.

<DEST>: Push to enter a destination. Various

methods for entering a destination are available.

“4. Setting a destination” .

<ROUTE>: Push to access guidance control func-

tions (guidance cancellation, route priority, waypoint setting on the route, etc.).

JOYSTICK and <ENTER>: Move to highlight an item on the

screen, and then push to select the highlighted item, move on the screen, etc.

INI0254

< > (DAY/NIGHT): Push to switch between the day screen

and the night screen. Push and hold to turn the display on and off.

<SETTING>: Push to access the system settings.

<TRIP>: Push to display the trip computer. Refer

to the Owner’s Manual of your vehicle.

<BACK>: Push to return to the previous screen.

In a settings screen, this button can also be used to apply the setting.

<GUIDE VOICE>: Push to repeat voice guidance for a

guide point.

<MAP>: Push to display the current location

map screen.

2-4

FX45/35

<DEST> : Push to enter a destination. Various

methods for entering a destination are available.

“4. Setting a destination”

<MAP> : Push to display the current location

map screen.

<ROUTE> : Push to access guidance control func-

tions (guidance cancellation, route priority, waypoint setting on the route, etc.).

<DAY/NIGHT> : Push to switch between the day screen

and the night screen. Push and hold to turn the display on and off.

INI0222

2. Getting started

<TRIP> : Push to display the trip computer. Refer

to the Owner’s Manual of your vehicle.

<SETTING> : Push to access the system settings.

<ZOOM IN>,<ZOOM OUT>: Push to switch to the zoom mode to

change the map scale.

INFINITI Controller: Push to highlight an item on the

screen, select the highlighted item, move on the map, etc.

2-5

2. Getting started

M45/M35

<DEST> : Push to enter a destination. Various

methods for entering a destination are available.

“4. Setting a destination”

<MAP> : Push to display the current location

map screen.

<ROUTE> : Push to access guidance control func-

tions (guidance cancellation, route priority, waypoint setting on the route, etc.).

<INFO> : Push to display the vehicle information

and the navigation information, such as GPS and version information, etc.

INI0115

<SETTING> : Push to access the system settings.

<STATUS>: Push to display the current status of

the air conditioner, radio, audio and navigation systems.

<ZOOM IN>, <ZOOM OUT>: Push to switch to the zoom mode to

change the map scale.

<DAY/NIGHT> : Push to switch between the day screen

and the night screen. Push and hold to toggle the display on and off.

INFINITI Controller: Push to highlight an item on the

screen, select the highlighted item, move on the map, etc.

2-6

INFINITI CONTROLLER (M45/M35, FX45/35 and G35 Coupe)

<ENTER>: Push to select the highlighted item on

the screen.

Main directional buttons: Use to move across the map, highlight

an item on the screen or adjust a setting (volume, brightness, etc.).

Additional directional buttons: Use to move across the map or high-

light an item on the character input screen.

Center dial: Turn to highlight an item on the screen

or adjust a setting.

INI0116

2. Getting started

<BACK> : Push to return to the previous screen.

In a settings screen, this button can also be used to apply the setting.

<VOICE>: Push to repeat voice guidance for a

guide point.

INFO:

If <BACK> needs to be pushed to apply the setting in a settings screen, this manual will explicitly include a step for this procedure. Otherwise, pushing <BACK> returns you to the previous screen.

2-7

2. Getting started

STEERING SWITCH (M45/M35)

<ENTER>: Tilt to highlight an item on the screen

or adjust a setting. Push to select the highlighted item. If this button is pushed while a map is displayed, the map menu screen is displayed.

“MAP MENU SCREEN” (page 2-19)

INI0117

Push and hold to display the start menu.

“START MENU (M45/M35 only)”

(page 2-22) If this button is tilted up while the audio function is activated and the map or status screen is displayed, the audio system can be operated.

Push this button during a setting operation to return to the previous screen. In a settings screen, this button can also be used to apply the setting.

<TALK> : Push to start the voice re cognition

mode. Push and hold for 1 second to cancel voice commands when in the voice recognition mode. Push and hold when not in the voice recognition mode to display the phone screen.

Use to adjust the volume. These buttons have the same function as that of the volume knob. Refer to the Owner’s Manual of your vehicle.

<SOURCE>: Use to switch the audio mode (source).

Refer to the Owner’s Manual of your vehicle.

2-8

2. Getting started

OPENING/CLOSING THE LIQUID CRYSTAL DISPLAY (LCD) (G35 Coupe only)

When you use this system, make sure the engine is running.

NOTE:

If you use the system with the engine not running (ignition in the ON or ACC position) for long periods of time, this may drain the battery, making it difficult to start the engine.

HOW TO OPEN THE LCD

CAUTION!

. Do not place any objects on the instrument

panel. If you drop any objects onto the instrument panel or spill liquid on it, it may result in a system malfunction.

. To protect the liquid crystal display, close it

when it is not being used.

INI0203

The liquid crystal display closes when: . the ignition key is turned to the OFF

position. (It will open when the ignition key is turned to the ON or ACC position.)

. the button on the upper part of the

liquid crystal display is pressed with the ignition key in the ON or ACC position.

2-9

2. Getting started

INFO:

The liquid crystal display may not open if the power supply had been interrupted due to disconnecting the vehicle battery etc.

If it is difficult to see the screen due to sunlight, tilt the display forward or backward to adjust to the desired angle.

HOW TO CLOSE THE LCD

CAUTION!

. Be careful not to pinch your hands or

fingers when the liquid crystal display is closed.

. Do not open/close the liquid crystal display

manually. It may damage the equipment.

INI0204

The liquid crystal display closes when: . the ignition key is turned to the OFF

position.

. the button on the upper part of the

liquid crystal display is pressed with the ignition key in the ON or ACC position.

The voice guidance cannot be heard when the cover is closed.

2-10

NOTE:

If the liquid crystal display stays opened/ closed (or partly opened) and does not move when the button on the cover of the liquid crystal display is pressed, turn the ignition key off and turn it on again. Then try the open/close operation again. If the liquid crystal display still does not move, contact an INFINITI dealer.

Return the liquid crystal display to the original position before closing. Attempting to close the liquid crystal display while it is tilted may damage the mechanism.

If the side of the display is pushed, it may be difficult to store.

2. Getting started

2-11

2. Getting started

START-UP SCREEN

INV2729

1. The navigation system starts when the ignition switch is pushed to the ACC or ON position.

2-12

G35 Coupe, M45/M35

INV2730

2. As the start-up screen is displayed, read the precautions carefully, highlight [OK] and push <ENTER>.

FX45/35, QX56

INV2901

INFO:

If you do not push <ENTER> for more than 30 seconds, the status screen will be displayed. Push <DEST>, <MAP>, <ROUTE>, <INFO>, <SETTING>, <STATUS> or <TALK> to return to the start-up screen (M45/M35 only).

NAVIGATION SYSTEM STATUS SCREEN (M45/M35 only)

By pushing <STATUS> while the current location map screen is displayed, you can display the current status of the navigation system.

Each time <STATUS> is pushed, displayed information is switched in the order of audio, air conditioner, vehicle information and navigation route information.

INFO:

There are different status screens displayed depending on various factors, such as the currently active mode, whether a destination has been set or not, etc.

INV2799

When a route to the destination is set and the audio system is on, a screen similar to the one above appears.

Turning direction at the next intersection

Distance to the next intersection

Remaining time to the destination

Name of the next street

2. Getting started

INV2777

When a route to the destination is not set and the audio system is off, a screen similar to the one above appears.

2-13

2. Getting started

MENU SCREEN TYPES AND HOW TO OPERATE

MENU SCREENS AND THEIR PURPOSES (G35 Coupe, QX56)

Push <DEST>, <ROUTE>, <TRIP> (QX56), <INFO> (G35 Coupe) or <SETTING> to display the corresponding menu screen.

How to select a menu item

Example: <DEST> screen

1. Tilt the joystick up and down. An item is highlighted accordingly.

2. To select the preferred menu item, highlight the item and push <ENTER>.

INFO:

Some items in the menu contain further details, which are displayed on the right side of the screen when the menu item is highlighted. This allows you to preview details of the item. These details appear only on the menu screen displayed by pushing <DEST>.

INI0205

2-14

INI0150

2. Getting started

MENU SCREENS AND THEIR PURPOSES (M45/M35, FX45/35)

Push <DEST>, <ROUTE>, <PHONE>, <INFO>, <TRIP> or <SETTING> to display the corresponding menu screen.

How to select a menu item

Example: <DEST> screen

1. Turn the center dial clockwise or counterclockwise or push the up or down button of the main directional buttons. An item is highlighted accordingly.

2. To select the preferred menu item, highlight the item and push <ENTER>.

INFO:

Some items in the menu contain

further details, which are displayed on the right side of the screen when the menu item is highlighted. This allows you to preview details of the item. These details appear only on the menu screen displayed by pushing <DEST>.

2-15

2. Getting started

You can also select an item by tilting

the switch up and down. (M45/M35 only)

2-16

INV3001

3. Depending on the item you selected, a detailed menu screen, a character input screen or a setting screen, etc. is displayed. On the screen displayed, make adjustments, input information, etc. accordingly.

INV2734

4. Push <BACK> to return to the previous

screen without applying any changes. Push <MAP> to return to the current

location map screen without applying any changes.

INFO:

Depending on the menu selected, pushing <MAP> may not return you to the current location map screen.

INI0255

2. Getting started

USING CONTROLS TO ADJUST VALUES, LEVELS, ETC. (G35 Coupe, QX56)

Use the joystick to adjust the volume of the voice guidance and the display brightness.

How to adjust

1. Highlight the preferred setting item and

push <ENTER>. The color of the corresponding adjustment item changes.

2. Use the joystick, and the value or bar indicating levels increases or decreases accordingly.

3. Push <ENTER> or <BACK> to apply the setting.

2-17

2. Getting started

INI0223

USING CONTROLS TO ADJUST VALUES, LEVELS, ETC. (M45/M35, FX45/35)

There are two main methods you can use to control the navigation system: the center dial and the main directional buttons. Use these controls to adjust the volume of phone and voice guidance, the display brightness, etc.

How to adjust

1. Highlight the preferred setting item and push <ENTER>. The color of the corresponding adjustment item changes.

2. Use one of the controls, and the value or bar indicating levels increases or decreases accordingly.

3. Push <ENTER> or <BACK> to apply the setting.

INFO:

You can also adjust the volume of phone and voice guidance, the display brightness, etc. by tilting the switch up and down. (M45/M35 only)

2-18

MAP MENU SCREEN

Push <ENTER> while the current location map screen or a scrolled map screen is displayed to display the menu corresponding to that screen.

This menu allows you to quickly use helpful functions, such as setting a destination easily and searching for Points of Interest nearby.

To select a menu item, use the method described in “Menu screen types and how

INV2735

to operate”.

Current location map screen

If <ENTER> is pushed while the current location map screen is displayed, the following options are available.

. Store Location:

Allows you to store the current vehicle location in the Address Book. The stored location can be retrieved as necessary to set it as a destination (waypoint).

2. Getting started

“STORING A LOCATION” (page 6-2)

. Nearby:

Allows you to search for points of interest near the current vehicle location, such as restaurants and gas stations, etc.

“SETTING A NEARBY PLACE” (page 4-47)

. Map View:

Switches the map type. It is used to switch between Plan View and Bird-

view

. Heading:

Switches the orientation of the map. “North Up” or “Heading Up” are the available options.

. Landmark Icons:

Allows you to display certain points of interest near the current vehicle location on the map, such as restaurants and gas stations, etc.

and set the left screen display. “SWITCHING THE MAP VIEW” (page 3-4)

“SETTINGS OF HEADING/LONG RANGE MAP VIEW” (page 3-15)

“DISPLAYING LANDMARK ICONS” (page 3-22)

2-19

2. Getting started

. Store Tracking:

Allows you to store in the Address Book the route that you have travelled from the starting point to the current location.

“STORING A TRACKED ROUTE” (page 6-14)

2-20

+ 298 hidden pages

Infiniti NAVIGATION 2007 User Manual

Table of Contents
