HYUNDAI Santa Fe 2021 Reference Guide
Car Infotainment System | Quick Reference Guide
Santa Fe
To access the online manual for Car Infotainment
System, scan the QR code.
Be sure to read this User’s Manual before using the product to ensure safety and usability.
Reading the manual on web with the QR code
You can access the online user’s manual of the system by scanning the QR code with your
smartphone.
Warning
Ý
Park the vehicle at a safe place and scan the QR code. To ensure your safety, the system does
not provide QR codes while driving.
Scan the QR code by using any of the following methods:
1
On the All Menus screen, press User's Manual.
•
On the All Menus screen, press Setup > General > System Info > User's Manual on
•
Web (QR Code).
Or scan the QR code in the Quick Reference Guide.
•
Scan the QR code after installing
2
the QR code reader App from App
Store (
(
Press the URL for User's Manual
3
on Web from the smartphone
display.
The online user's manual of the system
appears in the Internet browser App on
the smartphone.
A
Depending on how you scan the QR code, the online manual may open without pressing
the URL.
A
With a camera App of your iPhone or Android smartphone, the QR code can also be
scanned. Depending on the Android smartphone model, the QR code scanning may not
be supported for the provided App. For more details, see the smartphone’s manual.
A
When you scan the QR code on each function menu, you can see the usage of the
function running (except for several functions).
-
Run the desired function on the system and then press User's Manual on Web (QR
Code) from the menus on the screen.
A
Without scanning the QR code, you can directly enter the URL address to see User’s
Manual on Web. (http://webmanual.hyundai.com/STD_GEN5_WIDE/AVNT/USA/English/
index.html)
) or Google Play Store
).
1
Safety Warnings
Be sure to keep the following instructions. Otherwise, it may cause serious injury or accident.
Driving
Ý
Obey all trac laws while driving.
Relying solely on the navigation system may cause violation of trac rules and regulations, resulting in an
•
accident.
In order to check the vehicle speed, see the speedometer rst, not the speed on the
navigation system.
The speed on the navigation system may dier from actual vehicle speed.
•
While driving, refrain from watching the screen.
An accident may occur by negligence in keeping your eyes forward.
•
To manipulate the screen or buttons requiring multiple steps, be sure to stop your vehicle.
•
To use your mobile phone, rst stop your vehicle.
When you use your mobile phone while driving, it may disperse your attention, resulting in an accident.
•
When making a call while driving, use the Bluetooth Hands-free function and if possible, minimize the call
•
time.
Make sure that the volume of the phone is suciently low so that the external sound is
audible.
When you drive with no external sound present may cause a trac accident.
•
When you drive for a long time with a loud audio volume, it may aect your hearing.
•
For emergency services (e.g. hospital, re station), do not rely solely on the navigation
system.
Some emergency services may not be included in the navigation map. Check relevant information in advance
•
to stay prepared for an emergency.
System handling
Ý
Do NOT arbitrarily disassemble or modify the system.
It may cause an accident, re, or electric shock.
•
Exercise caution to make sure that no liquid or foreign materials enter the system.
It may cause smoke generation, re ignition, or system failure.
•
When the screen is not displayed, the volume is muted, or other system failures occur,
immediately stop using the system.
Otherwise, it may cause re, electric shock, or fatal system failure.
•
A
If you experience any problems with the system, contact your place of purchase or dealer.
2
Safety Precautions
Be sure to keep the following instructions. Otherwise, it may cause minor injury or system
damage.
Operation
Use the system with the vehicle started.
When you use the system for a long time with the vehicle stopped, it may cause battery discharge.
•
Do NOT arbitrarily install an unauthorized aftermarket product in your vehicle.
Using unapproved products may cause an error while using the system.
•
System errors caused by installing unapproved products are not covered under the warranty.
•
System handling
Do NOT apply excessive force to the system.
When you apply excessive pressure to the screen, the LCD panel or touch panel may get damaged.
•
To clean the screen or button panel, rst turn o the vehicle and then use a dry, soft
cloth to wipe it.
Do not wipe using a rough or hard cloth, chemical ber, organic solvent (e.g. alcohol, benzene, thinner), or air
•
freshener. The panel surface may become scratched or damaged due to a chemical reaction.
When you install an air freshener on the air conditioner vent, the surface may be
deformed due to leakage.
A
If you experience any problems with the system, contact your place of purchase or dealer.
3
Component names and functions
Control panel
a a
POWER button/VOLUME knob
Press the button to turn on or o the Radio/Media.
•
Press and hold the button to turn o the screen and sound.
•
Turn the knob left or right to adjust the system volume (except for navigation
•
sound)
b b
MAP button
Returns to the current location on the map.
•
When pressed while in guidance on the map screen, the voice guidance is repeated.
•
c c
NAV button
Moves to the navigation/route screen.
•
When you press and hold the button, the Places screen appears.
•
d d
Custom button
Runs the user-dened function.
•
Press and hold the button to display the Custom Button settings screen.
•
e e
SEEK/TRACK button
While listening to the radio, change the station.
•
While playing media, change the track/le. Press and hold to rewind or fast forward
•
(except for the Bluetooth audio mode).
A
The system shape and menu arrangement may dier depending on the vehicle model
and specications.
4
f f
RADIO button
Turns on the radio.
•
When you press the button repeatedly with the radio turned on, it toggles between
•
FM, AM and SiriusXM modes.
g g
MEDIA button
Run the media.
•
Press and hold to display the media selection window.
•
h h
SETUP button
Displays the Settings screen.
•
When you press and hold the button the SW Info/Update screen appears.
•
i i
System Reset button
Restarts the system.
•
j j
TUNE knob/FILE knob/ENTER button
Turn the knob to change the frequency and channel while listening to the radio.
•
Turn the knob while playing media to scan for music or le.
•
Press the button to select a channel, music, or le during a search.
•
Turn the knob on the map screen to zoom in or out the map (if activated).
•
When you press and hold the button, the TUNE Knob Function screen appears.
•
5
Steering wheel remote control
a a
Voice Recognition button
Press to start voice recognition and press and hold to end voice recognition.
•
Press and hold to start or end voice recognition of a connected smartphone via
•
phone projection.
(The button’s operation may vary depending on smartphone specications.)
b b
MODE button
Press the button repeatedly to change the system mode (radio, media, etc.).
•
Press and hold the button to display the settings for the Steering Wheel MODE
•
button.
c c
Volume lever/button
Volume adjustment.
•
Press the button to mute or unmute the volume (except for navigation sound).
•
Press the button to pause or resume playback.
•
d d
Move lever
While listening to the radio, switch between the stations on the preset list. Press
•
and hold to search for a station.
While playing media, change the track/le. Press and hold to rewind or fast forward
•
(except for the Bluetooth audio mode).
e e
Call button
Before connection of Bluetooth: Press to display the Bluetooth connection window.
•
After connection of Bluetooth: Press to display the recent calls list, press and hold to
•
redial the last number, and press for an incoming call to answer it.
On a Bluetooth call: Press to switch to Call Waiting and press and hold to switch
•
between the system and mobile phone.
f f
End Call button
During a Bluetooth call, press to end the call.
•
Press to ignore a call with the Bluetooth connected.
•
A
The system shape and menu arrangement may dier depending on the vehicle model
and specications.
6
Turning the system on or o
Turning on the system
Turn on the vehicle.
1
When a safety warning message appears, read it and press Conrm.
2
A
To change the display language, press Language.
Turning o the system
To turn o the system while driving, press and hold the Power button on
the panel.
The screen and sound will be turned o.
A
To use the system again, press the Power button.
A
When a specied period of time elapses after turning o the vehicle, the system
automatically shuts down. When you open the driver's door, the system immediately
shuts down.
Warning
Ý
Driving while distracted can result in a loss of vehicle control that may lead to an accident,
•
severe bodily injury, or death. The driver's primary responsibility is the safe and legal
operation of the vehicle, and the use of any vehicle systems, including the touch screen
and steering wheel controls, which take the driver's eyes, attention, and focus away from
the safe operation of the vehicle, or which are not permissible by law, should never be
used during the operation of the vehicle.
Some functions may not be active while driving to ensure safety. Those functions run only
•
when the vehicle is stationary. In order to use them, rst stop the vehicle.
When the screen is not displayed, the volume is muted, or other system failures occur,
•
immediately stop using the system. When you use the faulty system continuously, it may
cause re, electric shock, or fatal system failure.
Caution
The system can be turned on even when the ignition switch is in “ACC” or “ON.” However,
•
when you use the system without turning on the vehicle for a long time, it may cause
battery discharge. To use the system for a long time, be sure to turn on the vehicle.
When you use the system with the vehicle turned o, the battery warning message
•
appears. The warning message disappears as soon as you turn on the vehicle.
7
How to Update the Map and Software for
your Infotainment System
To ensure you are maximizing the full potential of your navigation system, we advise
updating the map and software annually. To update, visit the map update website and install
the Navigation Updater program onto your PC. Use the program to download and install the
latest map, points of interest, and software. Alternatively, you can visit your local dealership
to update.
Product specications
Common specications
Item Specications
External dimensions 297.5 x 158.8 x 239.45 mm
Weight 2.05 kg
Display
Item Specications
Display size AV body - 10.25 inch (243.65 x 91.37 mm)
Number of pixels AV body - 1,382,400 pixels
(resolution: 1920 x 720)
Drive system TFT (Thin Film Transistor) active matrix system
Viewing angle AV body - Left/right, Horizontal/vertical: 89°
Internal lighting LED
8
FCC Certication
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modications to this device not explicitly approved by manufacturer
could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with minimum 20 cm between the radiator
and your body. This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter unless authorized to do so by the FCC.
9
Car Infotainment System
User's Manual
This guide covers specications for all vehicle models, including optional specications, and
[
is based on the latest version of system software.
The design and specication of the system may change without prior notice for
[
performance improvement.
In order to improve the product performance, the functions and services in this manual are
[
subject to change without notice. In case of software update, the screens in this manual
may dier from actual ones on the product.
For more information about the functions and services updated for performance
[
improvement, access the online user's manual.
Functions and services in this manual may dier from those in the actual vehicle. For more
[
details, refer to the owner's manual or brochure of your vehicle.
Your system is not compatible with the system software and map data for regions outside
[
of the country of purchase.
1
Available materials for operation
Quick Reference Guide
Provided in the format of a booklet. It provides brief information of the system,
including basic controls and main functions.
User's Manual on Web
To view related information while using the system, press User's Manual on Web
(QR Code) from the menus on the screen. By scanning the QR code with your
smartphone, you can access the online user's manual.
2
Symbols in this User's Manual
Warning
Indicates very important information directly related to user safety. Failure to follow
instructions may cause serious injury.
Caution
Indicates important information directly related to user safety. Failure to follow
instructions may cause minor injury or vehicle damage or breakdown.
Note
Indicates helpful information for operation of the product.
If equipped
Indicates descriptions for optional features, which may not be available on your
specic vehicle depending on the model or trim level.
This guide covers specications for all vehicle models, including optional
specications. It may include descriptions for features that are not equipped in your
vehicle or are unavailable for your vehicle model.
3
HEV only
Displays only the functions that can be used in a hybrid vehicle.
PHEV only
Displays only the functions that can be used in a plug-in hybrid vehicle.
EV only
Displays only the functions that can be used in an electric vehicle.
4
Safety Warnings
Be sure to keep the following instructions. Otherwise, it may cause serious injury or accident.
Driving
Ý
Obey all trac laws while driving.
Relying solely on the navigation system may cause violation of trac rules and regulations, resulting in an
accident.
In order to check the vehicle speed, see the speedometer rst, not the speed on the
navigation system.
The speed on the navigation system may dier from actual vehicle speed.
While driving, refrain from watching the screen.
An accident may occur by negligence in keeping your eyes forward.
To manipulate the screen or buttons requiring multiple steps, be sure to stop your vehicle.
To use your mobile phone, rst stop your vehicle.
When you use your mobile phone while driving, it may disperse your attention, resulting in an accident.
If necessary, use handsfree (Bluetooth) calling when driving and minimize the call time.
Make sure that the volume of the phone is suciently low so that the external sound is
audible.
When you drive with no external sound present may cause a trac accident.
When you drive for a long time with a loud audio volume, it may aect your hearing.
For emergency services (e.g. hospital, re station), do not rely solely on the navigation
system.
Some emergency services may not be included in the navigation map. Check relevant information in advance
to stay prepared for an emergency.
System handling
Ý
Do NOT arbitrarily disassemble or modify the system.
It may cause an accident, re, or electric shock.
Exercise caution to make sure that no liquid or foreign materials enter the system.
It may cause smoke generation, re ignition, or system failure.
When the screen is not displayed, the volume is muted, or other system failures occur,
immediately stop using the system.
Otherwise, it may cause re, electric shock, or fatal system failure.
A
If you experience any problems with the system, contact your place of purchase or dealer.
5
Safety Precautions
Be sure to keep the following instructions. Otherwise, it may cause minor injury or system
damage.
Operation
Use the system with the vehicle started.
When you use the system for a long time with the vehicle stopped, it may cause battery discharge.
Do NOT arbitrarily install an unauthorized aftermarket product in your vehicle.
Using unapproved products may cause an error while using the system.
System errors caused by installing unapproved products are not covered under the warranty.
System handling
Do NOT apply excessive force to the system.
When you apply excessive pressure to the screen, the LCD panel or touch panel may get damaged.
To clean the screen or button panel, rst turn o the vehicle and then use a dry, soft
cloth to wipe it.
Do not wipe using a rough or hard cloth, chemical ber, organic solvent (e.g. alcohol, benzene, thinner), or air
freshener. The panel surface may become scratched or damaged due to a chemical reaction.
When you install an air freshener on the air conditioner vent, the surface may be
deformed due to leakage.
A
If you experience any problems with the system, contact your place of purchase or dealer.
6
HYUNDAI VEHICLE OWNER
PRIVACY POLICY
Your Hyundai vehicle may be equipped with technologies and services that use information
collected, generated, recorded or stored by the vehicle. Hyundai has created a Vehicle Owner
Privacy Policy to explain how these technologies and services collect use and share this
information.
You may read our Vehicle Owner Privacy Policy on the Hyundaiusa.com website at:
https://www.hyundaiusa.com/owner-privacy-policy.aspx
If you would like to receive a hard copy of our Vehicle Owner Privacy Policy, please contact
our Customer Connect Center at:
Hyundai Customer Care
P.O. Box 20850
Fountain Valley, CA 92728
800-633-5151
consumeraairs@hmausa.com
Hyundai's Customer Connect Center representatives are
available Monday through Friday, between the hours of 5:00 AM and 7:00 PM PST and
Saturday and Sunday between 6:30 AM and 3:00 PM PST (English).
For Customer Connect Center assistance in Spanish or Korean, representatives are available
Monday through Friday between 6:30 AM and 3:00 PM PST.
7
Contents
01
02
System overview
Component names and functions 1-2
Turning the system on or o 1-5
Using the touch screen 1-7
Using the Home screen 1-10
Seeing the all menus screen 1-13
Using the split screen 1-14
Useful functions
Using the First Run Setup 2-2
Using the phone projection function 2-4
Using the driving assist display 2-9
Using the climate control system 2-13
Using the rear-seat climate control system 2-14
Using the Passenger Talk mode in the rear seat 2-16
Using the Quiet mode in the rear seat 2-17
Playing Sounds of Nature 2-18
Using the HD Radio Data 2-19
Seeing the driving information 2-22
Seeing notications 2-22
Using the Valet mode 2-23
8
03
Radio
Listening to the radio 3-2
Listening to HD Radio™ 3-10
Listening to SiriusXM™ radio 3-12
04
05
06
Media
Using media 4-2
Navigation
Navigation functions 5-2
Various ways to nd routes 5-10
Using the address book 5-23
Searching for gas stations 5-28
Searching for EV (Electric Vehicle) charging stations 5-29
Phone
Connecting a Bluetooth device 6-2
Making a call via Bluetooth 6-6
Accepting an incoming call over Bluetooth 6-14
Checking a new message over Bluetooth 6-17
9
07
Voice functions
Voice recognition 7-2
Using the Siri Eyes Free 7-21
Voice Memo 7-22
08
09
Blue Link
Blue Link service 8-2
Running the Blue Link 8-4
Using safety and security services 8-9
Contacting the Blue Link Center 8-10
Route guidance service 8-11
Settings
Conguring system settings 9-2
Conguring the vehicle settings (Type1) 9-3
Conguring the vehicle settings (Type2) 9-19
Conguring the device connections settings (Type1) 9-33
Conguring the device connections settings (Type2) 9-35
Conguring the advanced system settings (Type1) 9-38
Conguring the button settings (Type1) 9-42
10
Conguring the button settings (Type2) 9-43
Conguring the sound settings (Type1) 9-45
Conguring the sound settings (Type2) 9-49
Conguring the voice recognition settings (Type1) 9-53
Conguring the voice recognition settings (Type2) 9-54
Conguring the navigation settings (Type1) 9-54
Conguring the navigation settings (Type2) 9-60
Conguring the Blue Link settings (Type1) 9-65
Conguring the Blue Link settings (Type2) 9-66
Conguring the user prole settings (Type1) 9-67
Conguring the user prole settings (Type2) 9-68
Conguring the general system settings (Type1) 9-69
Conguring the general system settings (Type2) 9-74
Conguring the display settings (Type1) 9-79
Conguring the display settings (Type2) 9-84
Conguring the media settings (Type1) 9-88
How to Update the Map and Software for your
Infotainment System 9-89
10
Appendix
Solutions 10-2
System status indicator icons 10-9
FAQ 10-11
Product specications 10-13
Important information 10-17
Index 10-19
Trademarks 10-23
Open Source Information 10-24
11
01
System overview
Component names and functions
Turning the system on or o
Using the touch screen
Using the Home screen
Seeing the all menus screen
Using the split screen
Component names and functions
The following describes the part names and controls on the control panel and steering wheel.
Control panel
A
The shape may dier depending on the vehicle model and specications. For more
information, see "Quick Reference Guide" that is separately provided.
POWER button
(POWER/PWR)/
VOLUME knob
(VOLUME/VOL)
MAP button
NAV button
RADIO button
MEDIA button
SEEK/
TRACK button
Press the button to turn on or o the Radio/Media.
Press and hold the button to turn o the screen and
sound.
Turn the knob to adjust the system volume (except for
navigation sound).
Returns to the current location on the map.
When pressed while in guidance on the map screen, the
voice guidance is repeated.
Moves to the navigation/route screen.
When you press and hold the button, the Places screen
appears.
Turns on the radio.
When you press the button repeatedly with the radio
turned on, it toggles between FM, AM and SiriusXM
modes.
Run the media.
Press and hold to display the media selection window.
While listening to the radio, change the station.
While playing media, change the track/le. Press and hold
to rewind or fast forward (except for the Bluetooth audio
mode).
> See "Searching by keyword."
1-2
Custom button
(
)
Runs the user-dened function.
Press and hold the button to display the Custom Button
settings screen.
SETUP button
TUNE knob/
FILE knob/
ENTER button
(if equipped)
System Reset button
Displays the Settings screen.
When you press and hold the button the SW Info/Update
screen appears.
Turn the knob to change the frequency and channel while
listening to the radio.
Turn the knob while playing media to scan for music or
le.
Press the button to select a channel, music, or le during
a search.
Turn the knob on the map screen to zoom in or out the
map (if activated).
When you press and hold the button, the TUNE Knob
Function screen appears.
Restarts the system.
1-3
Steering wheel remote control
A
The shape may dier depending on the vehicle model and specications. For more
information, see "Quick Reference Guide" that is separately provided.
Voice Recognition
button (
MODE button
Volume lever/
button (+/-)
Mute button
(
Move lever/
button (
Call button
(
End Call button
(
)
)
/ )
)
)
Press to start voice recognition and press and hold to end
voice recognition.
Press and hold to start or end voice recognition of
a connected smartphone via phone projection.(The
button's operation may vary depending on smartphone
specications.)
Press the button repeatedly to change the system mode
(radio, media, etc.).
Press and hold the button to display the settings for the
Steering Wheel MODE button.
Volume adjustment.
Press the button to mute or unmute the volume (except
for navigation sound).
Press the button to pause or resume playback.
While listening to the radio, switch between the stations
on the preset list. Press and hold to search for a station.
While playing media, change the track/le. Press and hold
to rewind or fast forward (except for the Bluetooth audio
mode).
Before connection of Bluetooth: Press to display the
Bluetooth connection window.
After connection of Bluetooth: Press to display the recent
calls list, press and hold to redial the last number, and
press for an incoming call to answer it.
On a Bluetooth call: Press to switch to Call Waiting and
press and hold to switch between the system and mobile
phone.
During a Bluetooth call, press to end the call.
Press to ignore a call with the Bluetooth connected.
1-4
Turning the system on or o
The following explains how to turn on or o the system. Before using the system, be sure to
read the user's manual for safe and convenient manipulation.
Turning on the system
Turn on the vehicle.
1
When a safety warning message appears, read it and press Conrm.
2
A
To change the display language, press Language.
Option A
Option B
A
The screen may dier depending on the vehicle model and specications.
A
To set the user prole, note the following.
> See "Using the First Run Setup (if equipped)."
Turning o the system
To turn o the system while driving, press and hold the Power button on
the panel.
The screen and sound will be turned o.
A
To use the system again, press the Power button.
A
When a specied period of time elapses after turning o the vehicle, the system
automatically shuts down. When you open the driver's door, the system immediately
shuts down.
1-5
Warning
Ý
Driving while distracted can result in a loss of vehicle control that may lead to an accident,
severe bodily injury, or death. The driver's primary responsibility is the safe and legal
operation of the vehicle, and the use of any vehicle systems, including the touch screen
and steering wheel controls, which take the driver's eyes, attention, and focus away from
the safe operation of the vehicle, or which are not permissible by law, should never be
used during the operation of the vehicle.
Some functions may not be active while driving to ensure safety. Those functions run only
when the vehicle is stationary. In order to use them, rst stop the vehicle.
When the screen is not displayed, the volume is muted, or other system failures occur,
immediately stop using the system. When you use the faulty system continuously, it may
cause re, electric shock, or fatal system failure.
Caution
The system can be turned on even when the ignition switch is in "ACC" or "ON." However,
when you use the system without turning on the vehicle for a long time, it may cause
battery discharge. To use the system for a long time, be sure to turn on the vehicle.
When you use the system with the vehicle turned o, the battery warning message
appears. The warning message disappears as soon as you turn on the vehicle.
1-6
A
The screen may dier depending on the vehicle model and specications.
A
When you turn o and on the vehicle, the system is turned on with the mode and settings
used when the vehicle was turned o.
A
To prevent audio from playing loud when you turn on the vehicle, adjust the system
volume to an adequate level.
A
To automatically decrease the system volume, move to the All Menus screen and press
Setup > Sound > System Volumes > Start-up Volume Limit to set the function.
Loading...
