Anti-DDoS

User Guide

Issue 01

Date 2018-08-15

HUAWEI TECHNOLOGIES CO., LTD.

No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other trademarks and trade names mentioned in this document are the property of their respective holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specied in the contract, all statements, information, and recommendations in this document are provided "AS IS" without warranties, guarantees or representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every eort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute a warranty of any kind, express or implied.

Anti-DDoS User Guide Contents

1 Introduction.............................................................................................................................. 1

1.1 Functions.................................................................................................................................................................................... 1

1.2 Application Scenarios............................................................................................................................................................. 2

1.3 Accessing and Using Anti-DDoS.........................................................................................................................................2

1.3.1 How to Access Anti-DDoS.................................................................................................................................................2

1.3.2 How to Use Anti-DDoS...................................................................................................................................................... 3

1.3.3 Related Services.................................................................................................................................................................... 3

1.3.4 User Permissions.................................................................................................................................................................. 4

2 Operation Guide...................................................................................................................... 5

2.1 Enabling Anti-DDoS................................................................................................................................................................5

2.2 Enabling Alarm Notication................................................................................................................................................ 7

2.3 Adjusting Security Settings.................................................................................................................................................. 8

2.4 Viewing a Monitoring Report........................................................................................................................................... 11

2.5 Viewing an Interception Report....................................................................................................................................... 12

3 FAQs.......................................................................................................................................... 14

3.1 What Is Anti-DDoS?............................................................................................................................................................. 14

3.2 What Services Can Anti-DDoS Protect?........................................................................................................................ 14

3.3 How Do I Use Anti-DDoS?................................................................................................................................................. 14

3.4 What Kinds of Attacks Does Anti-DDoS Defend Against?......................................................................................14

3.5 Will I Be Promptly

Notied When an Attack Is Detected?..................................................................................... 15

A Change History...................................................................................................................... 16

Anti-DDoS User Guide 1 Introduction

1 Introduction

1.1 Functions

The Anti-DDoS trac cleaning service (Anti-DDoS for short) defends elastic IP addresses (EIPs) against network- and application-layer distributed denial of service (DDoS) attacks and sends alarms immediately when detecting an attack. In addition, Anti-DDoS improves the utilization of bandwidth and ensures the stable running of users' services.

Anti-DDoS monitors the service trac in real time. It then cleans attack trac according to user-congured defense policies so that services run as normal. In addition, monitoring reports are generated, presenting users with clear network security evaluations.

Anti-DDoS helps users cope with trac attacks with ease. It can precisely identify connection exhaustion and slow-connection attacks and can help users defend against the following attacks:

● Web server attacks

Such as SYN connection attacks

● Game attacks

Such as User Datagram Protocol (UDP) Protocol (TCP), and fragment attacks

● HTTPS server attacks

Such as SSL DoS and DDoS attacks

ood, HTTP ood, Challenge Collapsar (CC), and slow-

trac from the Internet to EIPs to detect attack

ood, SYN ood, Transmission Control

● DNS server attacks

Such as attacks targeted at vulnerabilities in the Domain Name Server (DNS) protocol stack, DNS reection attacks, DNS ood attacks, and DNS cachemiss attacks

Anti-DDoS also provides the following functions:

● Providing monitoring records for each EIP, including the current defense status, current defense abnormalities.

congurations, and the last 24 hours' trac and

Anti-DDoS User Guide 1 Introduction

● Providing attack statistics reports on all protected EIPs, covering the trac cleaning frequency, cleaned trac amount, top 10 attacked EIPs, and number of blocked attacks.

1.2 Application Scenarios

Anti-DDoS defends only EIPs against DDoS attacks.

Anti-DDoS devices are deployed at egresses of data centers. Figure 1-1 shows the network topology.

The detection center detects network access security policies. If an attack is detected, data is diverted to cleaning devices for real-time defense. Abnormal

Figure 1-1 Network topology

trac is cleaned, and normal trac is forwarded.

trac according to user-congured

1.3 Accessing and Using Anti-DDoS

1.3.1 How to Access Anti-DDoS

Anti-DDoS provides a web-based service management platform. You can access Anti-DDoS using the management console or HTTPS-based application programming interfaces (APIs).

● Management console

Anti-DDoS User Guide 1 Introduction

If you have registered an account, you can log in to the management console directly. On the home page, choose Security > Anti-DDoS to access the AntiDDoS service.

● HTTPS-compliant APIs

You can access Anti-DDoS using APIs. For details, see the

Reference

Anti-DDoS API

1.3.2 How to Use Anti-DDoS

Description:

● Anti-DDoS defends IP addresses against DDoS attacks after you enable it.

● Enable alarm notication, which sends notications by SMS or email when an IP address is under a DDoS attack.

● Adjust security settings based on service needs during defense.

● View monitoring and interception reports after the defense is enabled to check network security situations.

● You can disable Anti-DDoS defense as required.

1.3.3 Related Services

CTS

Cloud Trace Service (CTS) provides you with a history of Anti-DDoS operations. After enabling CTS, you can view all generated traces to review and audit performed Anti-DDoS operations. For details, see the

Guide

● Anti-DDoS operations that can be recorded by CTS

Table 1-1 Anti-DDoS operations that can be recorded by CTS

Operation

Enabling Anti-DDoS openAntiddos

Disabling Anti-DDoS deleteAntiddos

Adjusting Anti-DDoS security settings updateAntiddos

● Using CTS to view Anti-DDoS audit logs

a. Log in to the management console.

b. Select Cloud Trace Service under Management & Deployment.

c. In the left navigation pane, choose Trace List.

d. You can use lters to query traces. The following four lters are available:

Cloud Trace Service User

Trace Name

▪ Trace Source, Resource Type, and Search By

○ Select query conditions from the drop-down list, for example,

choose Anti-DDoS > anti-ddos > Trace name > openAntiddos to query all Anti-DDoS enabling operations.

Anti-DDoS User Guide 1 Introduction

○ Trace name: This option allows you to select a trace name, such

as openAntiddos.

○ Resource ID: This option allows you to select or manually enter

the ID of the instance for which you want to view audit logs.

○ Resource name: This option allows you to select or manually

enter the name of the instance for which you want to view audit logs.

IAM

SMN

▪ Operator: Select a

level).

specic operator (at user level rather than tenant

▪ Trace Status: Available options include All trace statuses, normal,

warning, and incident. You can only select one of them.

▪ Start time and end time: You can specify the time period to query

traces.

e. Click

f. In the row containing the desired record, click View Trace.

Identity and Access Management (IAM) provides the permission management function for Anti-DDoS. Only users who have Anti-DDoS Administrator permissions can use Anti-DDoS. To apply for Anti-DDoS Administrator permissions, contact a user with Security Administrator permissions. For details, see the

and Access Management User Guide

The Simple Message Notication (SMN) service provides the notication function. When alarm notication is enabled in Anti-DDoS, you will receive alarm messages by SMS or email if your IP address is under a DDoS attack.

on the left of the record to be queried to extend its details.

Identity

For details about SMN, see the

Simple Message Notication User Guide

1.3.4 User Permissions

The public cloud system provides two types of permissions by default: user management and resource management.

● User management refers to the management of users, user groups, and user group rights.

● Resource management refers to the control operations that can be performed by users on cloud service resources.

Anti-DDoS User Guide 2 Operation Guide

2 Operation Guide

2.1 Enabling Anti-DDoS

Scenarios

Prerequisites

Procedure

Step 1 Log in to the management console.

Step 2 Click

Step 3 Under Security, choose Anti-DDoS. The Security Console is displayed.

Step 4 Choose Instances. On the displayed page, locate the row that contains the

The Anti-DDoS service then protects your IP addresses against DDoS attacks.

● You have obtained an account and its password to log in to the management console.

● You have not enabled Anti-DDoS for your IP addresses.

in the upper left corner and select the desired region or project.

unprotected IP address, and click Enable Anti-DDoS in the Operation column, as shown in Figure 2-1.

Figure 2-1 Instance IP Address

Step 5 In the displayed Enable Anti-DDoS dialog box, set required parameters and click

OK.

Anti-DDoS User Guide 2 Operation Guide

Figure 2-2 Enabling Anti-DDoS

Table 2-1 Parameters for enabling Anti-DDoS

Parameter

Trac

Cleaning Threshold

Description

Anti-DDoS scrubs trac when detecting that the incoming trac of an IP address exceeds the threshold.

If service trac triggers scrubbing, only attack trac is intercepted. If service trac does not trigger scrubbing, no trac is intercepted.

Set this parameter based on the actual service access You are advised to set a value close to, but not exceeding, the purchased bandwidth.

trac.

Anti-DDoS User Guide 2 Operation Guide

Parameter Description

CC Defense ● Disable: disables the defense.

● Enable: enables the defense.

NOTE

CC defense is available only for clients supporting the full HTTP protocol stack because This is because CC defense works in redirection or redirection+verication code mode. If your client does not support the full HTTP protocol stack, you are advised to disable CC defense.

● HTTP Request Rate: This option is available only when CC defense is enabled.

You are advised to set this parameter to the maximum number of HTTP requests that can be processed by the deployed service. Anti-DDoS automatically scrubs the total number of detected requests exceeds this threshold. If the value is too large, CC defense will not be triggered promptly.

– If the actual HTTP request rate is smaller than the

congured value, the deployed service is able to process all HTTP requests, and Anti-DDoS does not need to be involved.

– If the actual HTTP request rate is greater than or equal

to the to analyze and check each request, which responses to normal requests.

congured value, Anti-DDoS triggers CC defense

trac if

aects

Step 6 Click OK to save the

----End

congurations and enable protection.

2.2 Enabling Alarm Notication

Scenarios

The alarm notication function sends you alarm notications (by SMS or email) if a DDoS attack is detected. If you do not enable this function, you have to log in to the management console to view alarms.

Prerequisites

You have obtained an account and its password to log in to the management console.

Procedure

Step 1 Log in to the management console.

Step 2 Click

in the upper left corner and select the region or project.

Anti-DDoS User Guide 2 Operation Guide

Step 3 Under Security, choose Anti-DDoS. The Security Console is displayed.

Step 4 In the upper right corner, click Congure Alarm Notication.

Figure 2-3 Conguring alarm notications

Table 2-2 Parameter description

Parameter Description Exampl

Anti-DDoS Indicates whether the alarm notication

function is enabled. There are two values:

● : enabled

● : disabled

If the function is in disabled state, click

Topic You can select an existing topic or click View

Topic to create a topic.

For details about topics, see the

Message Notication User Guide

Step 5 Click OK to enable alarm

----End

e Value

to set it to .

N/A

Simple

notication.

2.3 Adjusting Security Settings

Scenarios

You can adjust security settings after Anti-DDoS is enabled.

Anti-DDoS User Guide 2 Operation Guide

Prerequisites

You have obtained an account and its password to log in to the management console.

Procedure

Step 1 Log in to the management console.

Step 2 Click

Step 3 Under Security, choose Anti-DDoS. The Security Console is displayed.

Step 4 On the Anti-DDoS > Instances page, locate the target IP address and click

Advanced Settings in the Operation column, as shown in Figure 2-4.

Figure 2-4 Instance IP address list

Step 5 In the displayed Advanced Settings dialog box, set required parameters.

Figure 2-5 Page for setting protection parameters

in the upper left corner and select the desired region or project.

Anti-DDoS User Guide 2 Operation Guide

Table 2-3 Parameter description

Parameter Description

Trac

Cleaning Threshold

Anti-DDoS scrubs trac when detecting that the incoming trac of an IP address exceeds the threshold.

Set this parameter based on the actual service access trac. You are advised to set a value close to, but not exceeding, the purchased bandwidth.

NOTE

If your service trac is larger than the value of Trac Cleaning Threshold you set,

intercepted. If service trac does not trigger scrubbing, no trac is intercepted.

trac scrubbing is triggered. Only attack trac is

CC Defense CC defense is available only for clients supporting the full HTTP

protocol stack because CC defense works in redirection or redirection+verication code mode. If your client does not support the full HTTP protocol stack, you are advised to disable CC defense.

HTTP Request Threshold

This parameter is required only when CC Defense is set to Enable. The unit is qps (short for queries per second). QPS is a common measure of the amount of search trac an information retrieval system, such as a search engine or a database, receives during one second.

This parameter is used to defend against a large number of malicious requests targeting websites. Defense against CC attacks, which aim to exhaust server resources by sending specially crafted GET or POST requests, is triggered when the HTTP request rate on a site reaches the selected value. In EIP protection, the maximum recommended value is 5000. In ELB protection, the value can be larger

You are advised to set this parameter to the maximum number of HTTP requests that can be processed by the deployed service. Anti-DDoS will automatically scrub

trac if detecting that the total number of requests exceeds the congured HTTP request threshold. If the value is too large, CC defense will not be triggered promptly.

● If the actual HTTP request rate is smaller than the

congured value, the deployed service is able to process all HTTP requests, and Anti-DDoS does not need to be involved.

● If the actual HTTP request rate is greater than or equal to

congured value, Anti-DDoS triggers CC defense to

the analyze and check each request, which aects responses to normal requests.

Step 6 Click OK to save the settings.

----End

Anti-DDoS User Guide 2 Operation Guide

2.4 Viewing a Monitoring Report

Scenarios

This section describes how to view the monitoring report of an instance IP address, covering the current protection status, protection settings, and the anomalies within the last 24 hours.

Prerequisites

You have obtained an account and its password to log in to the management console.

Procedure

Step 1 Log in to the management console.

trac and

Step 2

Step 3 Under Security, choose Anti-DDoS. The Security Console is displayed.

Step 4 On the Anti-DDoS > Instances page, locate the IP addresses for which Anti-DDoS

Step 5 On the Monitoring Report page, view monitoring details about an instance IP

Click

has been enabled and click the IP address in the Instance IP Address or View

Monitoring Report in the Operation column.

Figure 2-6 Viewing a monitoring report

address.

● You can view information such as the current protection status, protection

● A 24-hour defense

● The attack event list within one day records DDoS attacks on the ECS within

in the upper left corner and select the region or project.

settings, and the

minute intervals. It includes the following information:

Trac (Kbps) displays the trac status of the selected ECS, including

–

the incoming attack trac and normal trac.

– Packet Rate (pps) displays the packet rate of the selected ECS, including

the attack packet rate and normal incoming packet rate.

one day, including cleaning events and black hole events.

trac and anomalies within the last 24 hours.

trac chart is generated from data points taken in ve-

NO TE

Anti-DDoS User Guide 2 Operation Guide

Figure 2-7 Monitoring report

On the Monitoring Report page, click to download the monitoring report about the instance IP address.

----End

2.5 Viewing an Interception Report

Scenarios

This topic describes how to view the protection statistics, including the trac cleaning frequency, cleaned trac amount, weekly top 10 attacked instance IP addresses, and total number of intercepted attacks of all instance IP addresses of a user.

Prerequisites

You have obtained an account and its password to log in to the management console.

Procedure

Step 1 Log in to the management console.

Step 2 Click

in the upper left corner and select the desired region or project.

Step 3 Under Security, choose Anti-DDoS. The Security Console is displayed.

Step 4 On the Anti-DDoS > Security Report page, view the protection statistics of all

instance IP addresses of a user, as shown in Figure 2-8.

You can set Report Date to view the security report within a (one week long). You can query statistics of the last four weeks, including the number of cleaning times, cleaned addresses, and total number of intercepted attacks.

trac volume, top 10 attacked public IP

specied time range

NO TE

Anti-DDoS User Guide 2 Operation Guide

Figure 2-8 Interception report

On the Statistics page, click to download monitoring reports to view protection statistics of a certain period of time.

----End

Anti-DDoS User Guide 3 FAQs

3 FAQs

3.1 What Is Anti-DDoS?

trac from the Internet to EIPs to detect attack

3.2 What Services Can Anti-DDoS Protect?

Anti-DDoS provides the by users.

trac cleaning function for public IP addresses purchased

3.3 How Do I Use Anti-DDoS?

The Anti-DDoS protection is automatically enabled for the elastic IP addresses you purchased. If the protection is not enabled for any IP address, enable it by following the instructions in Enabling Anti-DDoS.

3.4 What Kinds of Attacks Does Anti-DDoS Defend Against?

Anti-DDoS helps users cope with connection exhaustion and slow-connection attacks and can help users defend against the following attacks:

● Web server attacks

trac attacks with ease. It can precisely identify

Anti-DDoS User Guide 3 FAQs

Such as SYN ood, HTTP ood, Challenge Collapsar (CC), and slowconnection attacks

● Game attacks

Such as User Datagram Protocol (UDP) ood, SYN ood, Transmission Control Protocol (TCP), and fragment attacks

● HTTPS server attacks

Such as SSL DoS and DDoS attacks

● DNS server attacks

Such as attacks targeted at vulnerabilities in the Domain Name Server (DNS) protocol stack, DNS miss attacks

reection attacks, DNS ood attacks, and DNS cache-

3.5 Will I Be Promptly Notied When an Attack Is Detected?

You will be promptly alarm notication.

On the Anti-DDoS console page, click Congure Alarm Notication in the upper right corner to enable the alarm notication function. Then you will receive

notications (by SMS or email) if a DDoS attack is detected.

notied when an attack is detected after you have enabled

Anti-DDoS User Guide A Change History

A Change History

Released On Description

2018-08-15 This issue is the rst ocial release.

Huawei Anti-DDoS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

1 Introduction

1.1 Functions

1.2 Application Scenarios

1.3 Accessing and Using Anti-DDoS

1.3.1 How to Access Anti-DDoS

1.3.2 How to Use Anti-DDoS

1.3.3 Related Services

1.3.4 User Permissions

2 Operation Guide

2.1 Enabling Anti-DDoS

2.3 Adjusting Security Settings

2.4 Viewing a Monitoring Report

2.5 Viewing an Interception Report

3 FAQs

3.1 What Is Anti-DDoS?

3.2 What Services Can Anti-DDoS Protect?

3.3 How Do I Use Anti-DDoS?

3.4 What Kinds of Attacks Does Anti-DDoS Defend Against?

A Change History
