HP ProBook 650 G5 Notebook PC
Overview
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 1
Left
1.
Webcam (select models)
6.
Smart Card Reader (select models)
2.
Internal microphones (2)
7.
Optical Drive (select models)
3.
Camera Privacy Shutter
8.
Security lock slot (Lock sold separately)
4.
Webcam LED (select models)
9.
Power button
5.
Clickpad
QuickSpecs
HP ProBook 650 G5 Notebook PC
Overview
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 2
Right
1.
Power connector
7.
USB 3.1 Gen 1 port
2.
MicroSD card slot
8.
USB 3.1 Gen 1 charging port
3.
Docking connector
9.
USB Type-C™ charging port (PD+DP 1.2, Gen1)
4.
VGA port (or Serial port)
10.
Audio combo jack
5.
Ethernet port
11.
HDD LED indicator
6.
HDMI port (Cable not included)
12.
Fingerprint reader (Select models)
QuickSpecs
HP ProBook 650 G5 Notebook PC
Overview
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 3
• Windows 10 versions and FreeDOS
• Precision-crafted slim design with fingerprint resistant modern, fresh and comfortable natural silver finish
• Choice of 8th Generation Intel® Core™ processors, with integrated graphics or optional AMD Radeon™ 540X 64 bit
Discrete Graphics
• HP Advanced keyboard, spill resistant with optional backlit design
• Large Clickpad with gestures support
• Enhanced security features including TPM2.0, HP Privacy Camera, Optional HP Sure View Gen3, Optional Smart Card
Reader, Optional Touch FingerPrint Reader3 (select models), HP Sure Sense2 and HP Sure Start Gen5.
• LED-backlit display 39.6 cm (15.6"") diagonal HD, FHD, Touch FHD or FHD with HP Sure View Gen3.
• Optional WWAN
• HDMI port for connecting to high-resolution displays
• Optional HD webcam with dual-microphone array for video conferencing
• Optional integrated ODD and Serial Port support
• Flexible wireless connectivity options, including 802.11 AX WLAN module and CAT9 WWAN module
• Battery hours up to 15 hours with fast charging technology
• Dual storage combines SSD fast boot up and app access with cost effective HDD mass storage
• Passed MIL-STD 810G test
1
• Compliance with FCC (Class B)
1. MIL-STD-810G testing is not intended to demonstrate fitness of U.S. Department of Defense (DoD) contract requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Accidental damage requires an optional HP Accidental Damage Protection Care Pack.
2. HP Sure Sense requires Windows 10. See product specifications for availability.
3. HP Fingerprint Sensor is an optional feature and requires configuration at purchase.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 4
HP ProBook 650 G5 Notebook PC
Preinstalled
Windows® 10 Pro 641 Windows® 10 Pro 64 (National Academic License)2 Windows® 10 Home 641 Windows® 10 Home Single Language 641 Windows® 10 Enterprise 64 (Web Support)1 FreeDOS
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.
2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10 Anniversary Update. Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.
Intel® Core™ i7-8665U vPro™ with Intel® UHD graphics 620 (1.9 GHz base frequency, up to 4.8 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores)
3,4,5
Intel® Core™ i7-8565U with Intel® UHD graphics 620 (1.8 GHz base frequency, up to 4.6 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores)
3,4,5
Intel® Core™ i5-8365U vPro™ with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 4.1 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4 cores)
3,4,5
Intel® Core™ i5-8265U with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4 cores)
3,4,5
Intel® Core™ i3-8145U with Intel® UHD Graphics 620 (2.1 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 4 MB cache, 2 cores)
3,4,5
Processor Family
8th Generation Intel® Core™ i7 processor (i7-8665U, i7-8565U models)5 8th Generation Intel® Core™ i5 processor (i5-8365U, i5-8265U models)5 8th Generation Intel® Core™ i3 processor (i3-8145U model)5
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 5
3. Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
4. Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
5. In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on http://www.support.hp.com.
Chipset is integrated with processor
Integrated
Intel® UHD Graphics 620
6
Discrete
AMD Radeon™ 540X (2 GB GDDR5 dedicated)
7
Supports
Support HD decode, DX12, HDMI 1.4
6. HD content required to view HD images.
7. AMD Dynamic Switchable Graphics technology requires an Intel processor, plus an AMD Radeon™ discrete graphics configuration and is not available on FreeDOS and Linux OS. With AMD Dynamic Switchable Graphics technology, full enablement of all discrete graphics video and display features may not be supported on all systems (e.g. OpenGL applications will run on the integrated GPU or the APU as the case may be).
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 6
Non-Touch HD
39.6 cm (15.6") diagonal HD SVA eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC (1366 x 768)
6,8
39.6 cm (15.6") diagonal HD SVA eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC, for HD camera (1366 x 768)
6,8
39.6 cm (15.6") diagonal HD SVA eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC, for WWAN (1366 x 768)
6,8
39.6 cm (15.6") diagonal HD SVA eDP anti-glare LED-backlit, 220 cd/m², 45% NTSC, for HD camera and WWAN (1366 x 768)
6,8
Non-Touch FHD
39.6 cm (15.6") diagonal FHD IPS eDP anti-glare LED-backlit, 250 cd/m², 45% NTSC (1920 x 1080)
6,8
39.6 cm (15.6") diagonal FHD IPS eDP anti-glare LED-backlit, 250 cd/m², 45% NTSC, for HD camera (1920 x 1080)
6,8
39.6 cm (15.6") diagonal FHD IPS eDP anti-glare LED-backlit, 250 cd/m², 45% NTSC, for WWAN (1920 x 1080)
6,8
39.6 cm (15.6") diagonal FHD IPS eDP anti-glare LED-backlit, 250 cd/m², 45% NTSC, for HD camera and WWAN (1920 x 1080)
6,8
Touch FHD
39.6 cm (15.6") diagonal FHD IPS eDP LED-backlit touch screen, 250 cd/m², 45% NTSC, for HD camera and WWAN (1920 x
1080)
6,8
Non-Touch FHD Privacy Panel
HP Sure View Gen3 Integrated Privacy Screen 39.6 cm (15.6") diagonal FHD IPS eDP anti-glare LED-backlit, 1000 cd/m², 72% NTSC, for HD camera and WWAN (1920 x 1080)*
6. HD content required to view HD images.
8. Resolutions are dependent upon monitor capability, and resolution and color depth settings. *Touch-enabled display and Sure View privacy panel will lower actual brightness
Docking station model
Total number of supported displays (incl. the notebook display)
Max. resolutions supported
Dock Connectors
Technical limitations
HP UltraSlim Docking Station
3
Dual 2.5K @ 60Hz
2xDP, 1xVGA
Dual 2.5k only with both displays into DP
HP Thunderbolt Dock G2
3
Single 4K@60Hz (3840 x 2160)
2xDP, 1xVGA, 1xTB,1xUSB-C alt-mode
System will perform at USB 3.0 Gen1 speeds when connected to the dock (5Gbits) Thunderbolt port will function as a USB 2.0 port with data and power out (15W) only.
HP USB-C Dock G4
3
Dual 2K @ 60Hz Single 4K @ 60Hz (3840 x 1440)
1xHDMI, 2xDP
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 7
HP USB-C Universal Dock
3
Dual 4K @ 60Hz Single 5K @ 60Hz
2xDP
HP USB-C Travel Dock
2
Single 2K @ 60Hz
1xHDMI, 1xVGA
Single external display Only HDMI or VGA at the time
HP USB-C Mini Dock
2
Single 4K @ 30Hz
1xHDMI, 1xVGA
Single external display Only HDMI or VGA at the time
Primary Storage
500 GB 7200 rpm SATA9 500 GB 7200 rpm SATA FIPS 140-2 SED9 1 TB 7200 rpm SATA9
Primary M.2 Storage
128 GB SATA-3 SS TLC9
256 GB PCIe® NVMe™ SS Value9
256 GB PCIe® Gen3x4 NVMe™ SS TLC9 256 GB SATA-3 TLC FIPS9 256 GB SATA-3 SS TLC (Opal 2)
9
256 GB Intel® PCIe® NVMe™ QLC M.2 SSD with 16 GB Intel® Optane™ memory H10(Available Q4 2019)
9,10,11
512 GB PCIe® NVMe™ Value9 512 GB PCIe® Gen3x4 NVMe™ SS TLC9
512 GB PCIe® Gen3x4 NVMe™ SS TLC (Opal 2)9 512 GB SATA- 3 SS TLC (FIPS)
9
512 GB Intel® PCIe® NVMe™ QLC M.2 SSD with 32 GB Intel® Optane™ memory H10
9,10,11
1 TB PCIe® Gen3x4 NVMe™ SS TLC
9
Cache Memory
16 GB PCIe® NVMe™ Intel® Optane™ Memory for storage acceleration9
9. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is reserved for system recovery software.
10. Intel® Optane™ memory system acceleration does not replace or increase the DRAM in your system. Requires 8th Gen or higher Intel® Core™ processor, BIOS version with Intel® Optane™ supported, Windows 10 64-bit, and an Intel® Rapid
Storage Technology (Intel® RST) driver.
11. Intel® Optane™ memory H10 only for Intel® PCIe® NVMe™ QLC M.2 SSD.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 8
Maximum Memory
64 GB DDR4-2400 SDRAM12
Memory
4 GB Total System Memory (4 GB x 1)12 8 GB Total System Memory (4 GB x 2)12 8 GB Total System Memory (8 GB x 1)
12
12 GB Total System Memory (8 GB + 4 GB)12 16 GB Total System Memory (16 GB x 1)12 16 GB Total System Memory (8 GB x 2)12 32 GB Total System Memory (16 GB x2)
12
48 GB Total System Memory (32 GB + 16 GB) (available Q4 2019)12 64 GB Total System Memory (32 GB x2) (available Q4 2019)
12
Memory Slots
2 SODIMM Both slots are customer accessible / upgradeable DDR4 SODIMMS, System runs at: 2400 Supports Dual Channel Memory
12. Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 9
WLAN
Intel® Dual Band Wireless-AC 9560 802.11 ac (2x2) Wi-Fi® and Bluetooth® 5 Combo, vPro™13 Intel® Dual Band Wireless-AC 9560 802.11 ac (2x2) Wi-Fi® and Bluetooth® 5 Combo, non-vPro™13 Intel® Wi-Fi 6** AX200 + Bluetooth® 5 (802.11ax 2x2, vPro, supporting gigabit file transfer speeds)13 Intel® Wi-Fi 6** AX200 + Bluetooth® 5 (802.11ax 2x2, non-vPro, supporting gigabit file transfer speeds)13
WWAN
LTE CAT6: Fibocom Intel® XMM™ 7262 LTE-Advanced, LTE/HSPA+ w/GPS14 LTE CAT9: Fibocom Intel® XMM™ 7360 LTE-Advanced, LTE/HSPA+ w/GPS14
NFC NXP NPC300 Near Field Communication Module 15
WPAN Bluetooth® BT 5.0 supported via all supported WLAN modules
Ethernet
Intel® Ethernet Connection I219-LM 10/100/1000 (vPro™)16 Intel® Ethernet Connection I219-V 10/100/1000 (Non-vPro™)16
13. Wireless access point and Internet service required and sold separately. Availability of public wireless access points limited.
14. WWAN module requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.
15. Sold separately or as an optional feature.
16. The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required. **Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax devices. Only available in countries where 802.11ax is supported.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 10
Audio
2 Integrated stereo speakers Integrated dual array microphone
Webcam 720p HD HP Privacy Camera
6,15,17
Optical Drive
DVD-ROM (Defeatured Combo)18 DVD Writer SATA Drive17
6. HD content required to view HD images.
15. Sold separately or as an optional feature.
17. Internet access required.
18. DVD-Writer does not support DVD RAM. Don’t copy copyright protected materials.
Keyboard
HP Advanced Keyboard with Numeric Keypad
Pointing Device
ClickPad, Spill-resistant with drain ClickPad, Spill-resistant with drain, DuraKeys & Backlit Dual Point, Spill-resistant with drain, DuraKeys & Backlit Dual Point Spill-resistant with drain, DuraKeys & Backlit Privacy
Function Keys
ESC: system information F1 - Display Switching F2 - Blank or Privacy F3 - Brightness Down F4 - Brightness Up F5 - Speaker Mute F6 - Volume Down F7 – Volume Up F8 - Mic Mute F9 - Backlight Toggle (for backlit keyboard) or Blank F10 – Blank F11 – Wi-fi Toggle
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 11
F12 – Sleep
Clickpad requirements:
On/off control by driver Taps enabled as default
Gestures:
(Win 10): Disabled by default: 3 Finger Flick 2 Finger Rotate Momentum Motion 1 Finger Vertical Scroll
Win 10:
Support PTP with Miniport driver Settings enabled by default by MSFT: 2 Finger Scrolling 2 Finger Zoom (Pinch) OSD (enable/disable) 3 finger tap – Cortana 3 finger flick –App switch 4 finger tap – Action Center
Preinstalled Software
BIOS
HP BIOSphere Gen519 HP Drive Lock & Automatic Drive Lock20 BIOS Update via Network Master Boot Record Security Power On Authentication Secure Erase21 Absolute Persistence Module22 Pre-boot Authentication
Software
HP Native Miracast Support23 HP Connection Optimizer HP Image Assistant
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 12
HP Hotkey Support HP JumpStart HP Support Assistant24 HP Noise Cancellation Software Buy Office (sold separately)
Manageability Features
HP Driver Packs25 HP System Software Manager (SSM) HP BIOS Config Utility (BCU) HP Client Catalog HP Manageability Integration Kit Gen3
26
HP Cloud Recovery
27
Client Security Software
HP Client Security Manager Gen528 HP Fingerprint Sensor
29
(select models) HP Power On Authentication Windows Defender30
Security Management
Pre-boot Authentication TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)31 M2 SSD, SATA 1 port disablement (via BIOS) Serial, USB enable/disable (via BIOS) Power-on password (via BIOS) Setup password (via BIOS) Support for chassis padlocks and cable lock devices HP Sure Click32 HP Sure Start Gen5
33
HP Sure Sense
34
Security TPM
Model: Infineon SLB9670 Version: 7.85 Revision: TPM 2.0 FIPS 140-2 Compliant: Yes
Smartcard Reader
Model number: Alcor AU9560 FIPS 201 Compliant: Yes
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 13
IPv6 Compliance:
Yes
MD5 Hash: Please follow the instructions below to access MD5 Hash.
Log-on to http://hp.com/support, enter your product name, select software and drivers, select OS, select driver. After
selecting the driver, click on “Associated files” and then click on “Download”. When opening the file, under “Purpose” you should see the appropriate “SOFTPAQ MD5:” Field
Is the BIOS on this notebook ISO/IEC 19678:2015 (formerly NIST 800-147) compliant?:
Yes UEFI version: 2.6
19. HP BIOSphere Gen5 is available on select HP Pro and Elite PCs. See product specifications for details. Features may vary depending on the platform and configurations.
20. HP Drive Lock & Automatic Drive Lock is not supported on NVMe drives
21. For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88 "Clear" sanitation method. HP Secure Erase does not support platforms with Intel® Optane™.
22. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:
http://www.absolute.com/company/legal/agreements/ computrace-agreement. Data Delete is an optional service provided by
Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.
23. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming.
24. HP Support Assistant requires Windows and Internet access.
25. HP Driver Packs not preinstalled, however available for download at http://www.hp.com/go/clientmanagement.
26. HP Manageability Integration Kit can be downloaded from http://www.hp.com/go/clientmanagement.
27. HP Cloud Recovery is available for HP Elite and Pro desktops and laptops PCs with Intel® or AMD processors and requires an open, wired network connection. Note: You must back up important files, data, photos, videos, etc. before use to avoid loss of data. Detail please refer to: https://support.hp.com/us-en/document/c05115630
28. HP Client Security Manager Gen5 requires Windows and is available on the select HP Pro and Elite PCs. See product specifications for details.
29. HP Fingerprint Sensor is an optional feature and requires configuration at purchase.
30. Windows Defender Opt in and internet connection required for updates.
31. Firmware TPM is version 2.0. Hardware TPM is v1.2, which is a subset of the TPM 2.0 specification version v0.89 as implemented by Intel Platform Trust Technology (PTT).re TPM is version 2.0. Hardware TPM is v1.2, which is a subset of the TPM
2.0 specification version v0.89 as implemented by Intel Platform Trust Technology (PTT).
32. HP Sure Click is available on most HP PCs and supports Microsoft® Internet Explorer and Chromium™. Supported attachments include Microsoft Office (Word, Excel, PowerPoint) and PDF files in read only mode, when Microsoft Office or Adobe Acrobat are installed.
33. HP Sure Start Gen5 is available on select HP PCs with Intel processors. See product specifications for availability.
34. HP Sure Sense requires Windows 10. See product specifications for availability.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 14
Power Supply
HP Smart 45 W right angle 4.5 mm AC Adapter35 HP Smart 45 W right angle 4.5 mm AC Adapter - Argentina35 HP Smart 45 W right angle 4.5 mm AC Adapter 2-prong (Japan only)
35
HP Smart 45 W USB Type-C™ adapter35 HP Smart 65 W right angle 4.5 mm AC Adapter35 HP Smart 65 W EM External AC power adapter35 HP Smart 65 W USB Type-C™ adapter35
Primary Battery
HP Long Life 3-cell, 48 Wh Li-ion36 HP Fast Charge Technology - 90% in 90minutes
Battery Life
Up to 15 hours37
Power Cord
2-wire plug (C7), 1.0m, Conventional 3-wire plug (C5), 1.0m, Conventional 3-wire plug (C5), 1.8m, Conventional Duckhead power cord, 1.0m, Premium Duckhead power cord, 1.8m, Premium
35. Availability may vary by country.
36. Battery is internal and not replaceable by customer. Serviceable by warranty.
37. Windows 10 MM14 battery life will vary depending on various factors including product model, configuration, loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See http://www.bapco.com for additional details.
Weight
Starting at 4.8 lb (non-touch); Starting at 5.29 lb (touch)38 Starting at 2.18 kg (non-touch); Starting at 2.4 kg (touch)38
Dimensions (W x D x H)
14.85 x 10.12 x 0.95 in (non-touch); 14.85 x 10.12 x 0.99 in (touch)
37.7 x 25.7 x 2.39 cm (non-touch); 37.7 x 25.7 x 2.49 cm (touch)
38. Weight will vary by configuration.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 15
Ports
2 USB 3.1 Gen 1 (1 charging) 1 USB 3.1 Type-C™ Gen1 (Power delivery, DisplayPort™ 1.2) 1 HDMI 1.4
39
1 RJ-45 1 VGA or Serial Port 1 headphone/microphone combo 1 AC power
Expansion Slots 1 docking connector
1 microSD (multi-format digital media reader)
39. HDMI cable sold separately.
HP Services offers 3-year and 1-year limited warranties and 90 day software support options depending on country and the SKU selected by the customer. Batteries have a default one year limited warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the platform. On-site service and extended coverage is also available with HP Care Pack Services, optional extended service contracts that go beyond the standard limited warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc.40
40. HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit
http://www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or
indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 16
ENERGY STAR® certified EPEAT® 2019 Silver
41
Low halogen42 TCO 5.0 Certified
41. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
42. External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.
Stand-Alone Power Requirements (AC Power)
Nominal Operating Voltage
19.5 V Average Operating Power
Win 10
Integrated Graphics
11 W
Discrete Graphics
16 W
Max Operating Power
Discrete < 65W UMA < 45W
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing optical)
Non-operating
41° to 95° F (5° to 35° C) (writing optical)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
Shock
Operating
40 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude (unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 40,000 ft (-15.24 to 12,192 m)
Planned Industry Standard Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR®
Select models43
EPEAT® 2019
Yes, Silver in U.S.44
ICES
Yes
Australia / NZ A-Tick Compliance
Yes
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 17
CCC
Yes
Japan VCCI Compliance
Yes
KC
Yes
BSMI
Yes
CE Marking Compliance
Yes
BNCI or BELUS
Yes
CIT
Yes
GOST
Yes
Saudi Arabian Compliance (ICCP)
Yes
SABS
Yes
43. Configurations of the HP ProBook 650 G5 that are ENERGY STAR® qualified are identified as HP ProBook 650 G5 ENERGY STAR on HP websites and on http://www.energystar.gov.
44. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 18
Environmental Data
Eco-Label Certifications & declarations
This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• US Federal Energy Management Program (FEMP)
• EPEAT® 2019 Silver registered in the United States. Based on EPEAT®
registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. See http://www.epeat.net for registration status in your country.
• TCO Certified Edge
• China Energy Conservation Program (CECP)
• China State Environmental Protection Administration (SEPA)
• Taiwan Green Mark
• Korea Eco-label
• Japan PC Green label*
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption (in accordance with US ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Sort idle)
4.75
4.84
4.86
Normal Operation (Long idle)
2.47
2.54
2.47
Sleep
0.78
0.83
0.79
Off
0.28
0.31
0.28
Note:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S. Environmental Protection Agency (EPA) ENERGY
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 19
STAR® specifications for computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short idle)
16
16
16
Normal Operation (Long idle)
8 8 8
Sleep
2 2 3
Off
1 1 1
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.
Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
2.5
15
Fixed Disk – Random writes
2.9
23
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 20
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable features and/or components contained in the product may include:
• 3 USB ports
• 1 PC card slot (type I/II)
• 1 ExpressCard/54 slot
• 1 IEEE 1394 Port
• 2 SODIMM memory slots
• Optional expansion base docking station
• 1 multi-bay II storage port
• Interchangeable HDD
Spare parts are available throughout the warranty period and or for up to “5” years after the end of production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight Cadmium greater than 20ppm by weight
Battery description: CR2032 (coin cell) / SS03050 Battery type: Lithium / Li-Ion/Li-Ion Polymer Battery description: 6-cell high capacity Lithium-Ion battery (optional 8 cell available) Battery type:
Additional Information
• This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680.1 (EPEAT) standard at
the Silver level, see http://www.epeat.net
• Plastics parts weighing over 25 grams used in the product are marked
per ISO11469 and ISO1043.
• This product contains 5.69% post-consumer recycled plastic (by wt.)
according to IEEE 1680.1-2018 standard, criterion 4.2.1.1.
• This product is 96.4% recycle-able when properly disposed of at end of
life.
Packaging Materials
External:
PAPER/Corrugated
345
Internal:
PLASTIC/EPE (Expanded Polyethylene)
60
PLASTIC/Polyethylene low density - LDPE
5
PLASTIC/Polypropylene - PP
15
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 21
http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_spe cifications.html):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame
retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Bis(2-Ethylhexyl) phthalate (DEHP)
• Benzyl butyl phthalate (BBP)
• Dibutyl phthalate (DBP)
• Diisobutyl phthalate (DIBP)
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to
be frequently handled or carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail
packaging has been voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in
packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated
materials.
• Reduce size and weight of packages to improve transportation fuel
efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 22
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to:
http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
HP, Inc. Corporate Environmental Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp­information/environment/ecolabels.html
ISO 14001 certificates:
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755 842
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 23
Panel LCD 15.6 inch diagonal FHD (1920 x 1080) Anti-Glare WLED UWVA 72 percent cg 1000 nits eDP 1.4+PSR2 flat Privacy NWBZ
Outline Dimensions (W x H x D)
349.52 x 204.79 mm (max)
Active Area
344.16 x 193.59 mm (typ.)
Weight
350 g (max)
Diagonal Size
15.6 inch
Thickness
2.6 mm (max)
Interface
eDP 1.4 + PSR2 (4 lane)
Surface Treatment
Anti-Glare
Touch Enabled
No
Contrast Ratio
2000:1 (typ.)
Refresh Rate
60 Hz
Brightness*
1000 nits
Pixel Resolution
1920 x 1080 (FHD)
Format of LCD Pixel Arrangement
RGB
Backlight
LED
Color Gamut Coverage
72% of NTSC
Color Depth
8 bits
Viewing Angle
UWVA 85/85/85/85
*Touch-enabled display and Sure View privacy panel will lower actual brightness
Panel LCD 15.6 inch diagonal FHD (1920 x 1080) Anti-Glare WLED UWVA 45 percent cg 250 nits eDP 1.2 w/o PSR slim NWBZ
Outline Dimensions (W x H x D)
350.96 x 216.65 mm (max)
Active Area
344.16 x 193.59 mm (typ.)
Weight
370 g (max)
Diagonal Size
15.6 inch
Thickness
3.2 mm (max)
Interface
eDP 1.2 (2 lane)
Surface Treatment
Anti-Glare
Touch Enabled
No
Contrast Ratio
600:1 (typ.)
Refresh Rate
60 Hz
Brightness
250 nits
Pixel Resolution
1920 x 1080 (FHD)
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 24
Format of LCD Pixel Arrangement
RGB
Backlight
LED
Color Gamut Coverage
45% of NTSC
Color Depth
6 bits
Viewing Angle
UWVA 85/85/85/85
Panel LCD 15.6 inch diagonal FHD (1920 x 1080) Anti-Glare WLED UWVA 45 percent cg 250 nits eDP slim Touch on Panel NWBZ
Outline Dimensions (W x H x D)
350.96 x 216.75 mm (max)
Active Area
344.16 x 193.59 mm (typ.)
Weight
385 g (max)
Diagonal Size
15.6 inch
Thickness
3.2 mm (panel side) / 3.4 mm (PCBA Side) (max)
Interface
eDP 1.2
Surface Treatment
Anti-Glare On-cell
Touch Enabled
No
Contrast Ratio
600:1 (typ.)
Refresh Rate
60 Hz
Brightness
250 nits
Pixel Resolution
1920 x 1080 (FHD)
Format of LCD Pixel Arrangement
RGB
Backlight
LED
Color Gamut Coverage
45% of NTSC
Color Depth
6 bits
Viewing Angle
UWVA 85/85/85/85
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 25
15.6" diagonal HD SVA anti­glare LED-backlit non-touch; 220 cd/m2; 45% percent cg (1366 x 768)
Outline Dimensions (W x H x D)
360 x 224.3 (mm) max
Active Area
344.2 x 193.5 (mm)
Weight
370 g max
Diagonal Size
15.6 (inch)
Thickness
3.2 (mm) max
Interface
eDP 1.2
Surface Treatment
Anti-Glare (AG)
Touch Enabled
None
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
220 nits
Pixel Resolution
1366 x 768 (HD)
Format of LCD Pixel Arrangement
RGB
Backlight
LED
Color Gamut Coverage
45% of NTSC
Color Depth
6 bits + Hi FRC
Viewing Angle
SVA 45/45/25/35
NOTE: All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 26
HDD 500 GB 7200 RPM 7mm SATA
Drive Weight
0.21 lbs (95 g)
Rotation speed
7200 RPM
Cache Buffer
Up to 32 MB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
600 MB/s
Seek Time
Single Track: 2 ~ 1.5 ms; Average: 11 ~ 13 ms; Maximum: 18 ~ 22 ms
Logical Blocks
976,773,168
Operating Temperature
32° to 140°F (0° to 60°C) [ambient temp]
Security Features
ATA Security
Features
S.M.A.R.T., NCQ, Ultra DMA
HDD 500 GB 7200 RPM 7mm FIPS SATA Opal2
Drive Weight
0.21 lbs (95 g)
Rotation speed
7200 RPM
Cache Buffer
Up to 32 MB
Height
0.28 in (7 mm)
Width
2.75 in (69.85 mm)
Interface
ATA-8, SATA 3.0
Transfer Rate
600 MB/s
Seek Time
Single Track: 2 ~ 1.5 ms; Average: 11 ~ 13 ms; Maximum: 18 ~ 22 ms
Logical Blocks
976,773,168
Operating Temperature
32° to 140°F (0° to 60°C) [ambient temp]
Security Features
ATA Security; TCG Opal 2.x, FIPS
Features
S.M.A.R.T., NCQ, Ultra DMA
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 27
HDD 1 TB 7200 RPM 7mm SATA 2.5in
Drive Weight
90 g
Rotation speed
7200 RPM
Cache Buffer
128 MB
Height
7.2mm Max.
Width
69.85mm
Interface
ATA-8, SATA 3.0
Transfer Rate
600 MB/s
Seek Time
Single Track: 1.5 ms Average: 13 ms Maximum: 32 ms
Logical Blocks
1,953,525,168
Operating Temperature
0~60°C
Security Features
ATA Security
Features
S.M.A.R.T., NCQ, Ultra DMA, TRIM
SSD 128 GB 2280 M2 SATA-3 TLC
Drive Weight
0.02 lb (10 g)
Capacity
128 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ATA-8, SATA 3.0
Maximum Sequential Read
Up To 520 MB/s
Maximum Sequential Write
Up To 450 MB/s
Logical Blocks
250,069,680
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
DIPM; TRIM; DEVSLP
256 GB 2280 PCIe NVMe Value Solid State Drive
Drive Weight
0.02 lb (10 g)
Capacity
256 GB
NAND Type
MLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 1700 MB/s
Maximum Sequential Write
Up To 600 MB/s
Logical Blocks
703,282,608
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
TRIM; L1.2
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 28
SSD 256 GB 2280 M2 PCIe-3x4 SS NVMe TLC
Drive Weight
0.02 lb (10 g)
Capacity
256 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 2600 MB/s
Maximum Sequential Write
Up To 900 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
TRIM; L1.2
SSD 256 GB 2280 M2 SATA-3 Three Layer Cell Federal Information Processing Standard
Form Factor
M.2 2280
Capacity
256 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
0.02 lb (10 g)
Maximum Sequential Read
ATA-8, SATA 3.0
Maximum Sequential Write
Up To 530 MB/s
Logical Blocks
Up To 550 MB/s
Operating Temperature
500,118,192
SSD 256 GB 2280 M2 SATA-3 Self Encrypted OPAL2 Three Layer Cell
Form Factor
M.2 2280
Capacity
256 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
ATA-8, SATA 3.0
Maximum Sequential Read
Around 530 ~ 560 MB/s
Maximum Sequential Write
Around 500 ~ 530 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; TCG OPAL 2.0; DIPM; TRIM; DEVSLP
256 GB 2280 PCIe-3x2x2 NVMe+SSD 16 GB 3D Xpoint
Form Factor
M.2 2280
Capacity
256 GB
NAND Type
QLC
Height
0.09 in (2.3 mm)
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 29
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 1450 MB/s
Maximum Sequential Write
Up To 650 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
TRIM; L1.2, Optane Storage acceleration
SSD 512 GB 2280 PCIe NVMe Value
Form Factor
M.2 2280
Capacity
512 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Around 1500 ~ 1700 MB/s
Maximum Sequential Write
Around 860 ~ 1500 MB/s
Logical Blocks
1,000,215,215
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; TRIM; L1.2
SSD 512 GB 2280 M2 PCIe­3x4 SS NVMe TLC
Drive Weight
0.02 lb (10 g)
Capacity
512 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 2600 MB/s
Maximum Sequential Write
Up To 1400 MB/s
Logical Blocks
1,000,215,216
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
TRIM; L1.2
SSD 512 GB 2280 PCIe-3x4 NVMe Self Encrypted OPAL2 Three Layer Cell
Form Factor
M.2 2280
Capacity
512 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
0.02 lb (10 g)
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 30
Maximum Sequential Read
PCIe NVMe Gen3X4
Maximum Sequential Write
Around 3000 ~ 3400 MB/s
Logical Blocks
Around 1800 ~ 2500 MB/s
Operating Temperature
1,000,215,216
Features
32° to 158°F (0° to 70°C) [ambient temp]
SSD 512 GB 2280 M2 SATA-3 TLC FIPS
Drive Weight
0.02 lb (10 g)
Capacity
512 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
ACS-3, SATA 3.2
Maximum Sequential Read
Up To 530 MB/s
Maximum Sequential Write
Up To 400 MB/s
Logical Blocks
1,000,215,216
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
DIPM; TRIM; DEVSLP
SSD 512 GB 2280 PCIe-3x2x2 NVMe+SSD 32 GB 3D Xpoint
Form Factor
M.2 2280
Capacity
512 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 2400 MB/s
Maximum Sequential Write
Up To 1300 MB/s
Logical Blocks
1,000,215,215
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security, TRIM; L1.2
SSD 1 TB 2280 PCIe-3x4 NVMe TLC SS
Drive Weight
0.02 lb (10 g)
Capacity
1 TB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X4
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 31
Maximum Sequential Read
2900
Maximum Sequential Write
2000
Logical Blocks
2000409263
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
TRIM; L1.2
SSD 16 GB 2280 PCIe-3x2 NVMe 3D Xpoint
Drive Weight
M.2 2280
Capacity
16 GB
NAND Type
Xpoint
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
PCIe NVMe Gen3X2
Maximum Sequential Read
1400
Maximum Sequential Write
300
Logical Blocks
28,181,188
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
L1.2
NOTE: For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows
10) is reserved for system recovery software.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 32
DVD-ROM Drive
Access Times
Random
<140ms CD (typical)
< 160ms DVD (typical)
Weight
150g max.
Max Data Transfer Rate
24X CD-ROM
8X DVD-ROM
5X DVD-RAM
UDMA Mode 5
Interface
Gen 1 SATA
Supported Media (read)
CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM
Max Media Capacity (read)
8.5 GB
Transport
Tray Loading
DVD Writer SATA Drive
Access Times
Random
<140ms CD (typical)
< 160ms DVD (typical)
Weight
150g max.
Max Data Transfer Rate
24X CD-ROM
8X DVD-ROM
24X CD-R
10X CD-RW
8X DVD+R
8X DVD+RW
8X DVD-R
6X DVD-RW
6X - DVD+R Dual Layer
6X - DVD-R Dual Layer
5X DVD-RAM
Transfer Mode
UDMA Mode 5
Interface
Gen 1 SATA
Supported Media (read)
CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM
Supported Media (write)
CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM, DVD+R DL, DVD-R DL
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 33
Max Media Capacity (read)
8.5 GB
Max Media Capacity (write)
8.5 GB
Transport
Tray Loading
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 34
Intel® Wi-Fi® 6** AX200 + BT5 vPro
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11ax IEEE 802.11d IEEE 802.11e IEEE 802.11h IEEE 802.11i IEEE 802.11k IEEE 802.11r IEEE 802.11v
Interoperability
Wi-Fi® certified
Frequency Band
•802.11b/g/n/ax
2.402 – 2.482 GHz
•802.11a/n/ac/ax
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
•802.11ax: MCS0 ~ MCS11, (1SS and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
Modulation
Direct Sequence Spread Spectrum OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM , 1024QAM
Security3
•IEEE and Wi-Fi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
•WPA2 certification
•IEEE 802.11i
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 35
•Cisco Certified Extensions, all versions through CCX4 and CCX Lite
•WAPI
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ac VHT160(5GHz): +11.5dBm minimum
• 802.11ax HT40(2.4GHz): +10dBm minimum
• 802.11ax VHT160(5GHz): +10dBm minimum
Power Consumption
•Transmit mode 2.0 W
•Receive mode 1.6 W
•Idle mode (PSP) 180 mW (WLAN Associated)
•Idle mode 50 mW (WLAN unassociated)
•Connected Standby 10 mW
•Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity4
•802.11b, 1Mbps: -93.5dBm maximum
•802.11b, 11Mbps: -84dBm maximum
• 802.11a/g, 6Mbps: -86dBm maximum
• 802.11a/g, 54Mbps: -72dBm maximum
• 802.11n, MCS07: -67dBm maximum
• 802.11n, MCS15: -64dBm maximum
• 802.11ac, MCS0: -84dBm maximum
• 802.11ac, MCS9: -59dBm maximum
•802.11ax, MCS11(HT40): -59dBm maximum
•802.11ax, MCS11(VHT160): -58.5dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications Form Factor
PCI-Express M.2 MiniCard
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 36
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8g
2. Type 126: 1.3g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0/5.1 Wireless Technology Bluetooth Specification
4.0/4.1/4.2/5.0/5.1 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy: 0~79 (1 MHz/CH) BLE: 0~39 (2 MHz/CH)
Signaling Data Rate
Legacy: 3 Mbps signaling data rate1 2.17 Mbps BLE: 1 Mbps signaling data rate1 0.2 Mbps
1. Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 9.5 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW
Bluetooth Software Supported
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management Certifications
ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 37
LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
1. Wireless access point and Internet service is required. Availability of public wireless access point is limited.
2. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
3. Check latest software/driver release for updates on supported security features.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation). **Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax devices. Only available in countries where 802.11ax is supported.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 38
Intel® Wi-Fi® 6** AX200 + BT5 non-vPro
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11ax IEEE 802.11d IEEE 802.11e IEEE 802.11h IEEE 802.11i IEEE 802.11k IEEE 802.11r IEEE 802.11v
Interoperability
Wi-Fi® certified
Frequency Band
•802.11b/g/n/ax
2.402 – 2.482 GHz
•802.11a/n/ac/ax
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
• 802.11ax: MCS0 ~ MCS11, (1SS and 2SS) (20MHz, 40MHz, 80MHz & 160MHz)
Modulation
Direct Sequence Spread Spectrum OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM , 1024QAM
Security3
•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES
•WPA2 certification
•IEEE 802.11i
•WAPI
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 39
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ac VHT160(5GHz): +11.5dBm minimum
• 802.11ax HT40(2.4GHz): +10dBm minimum
• 802.11ax VHT160(5GHz): +10dBm minimum
Power Consumption
•Transmit mode 2.0 W
•Receive mode 1.6 W
•Idle mode (PSP) 180 mW (WLAN Associated)
•Idle mode 50 mW (WLAN unassociated)
•Connected Standby 10 mW
•Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity4
•802.11b, 1Mbps: -93.5dBm maximum
•802.11b, 11Mbps: -84dBm maximum
• 802.11a/g, 6Mbps: -86dBm maximum
• 802.11a/g, 54Mbps: -72dBm maximum
• 802.11n, MCS07: -67dBm maximum
• 802.11n, MCS15: -64dBm maximum
• 802.11ac, MCS0: -84dBm maximum
• 802.11ac, MCS9: -59dBm maximum
•802.11ax, MCS11(HT40): -59dBm maximum
•802.11ax, MCS11(VHT160): -58.5dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8g
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 40
2. Type 126: 1.3g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0/5.1 Wireless Technology Bluetooth Specification
4.0/4.1/4.2/5.0/5.1 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy: 0~79 (1 MHz/CH) BLE: 0~39 (2 MHz/CH)
Signaling Data Rate
Legacy: 3 Mbps signaling data rate1 2.17 Mbps BLE: 1 Mbps signaling data rate1 0.2 Mbps
1. Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 9.5 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW
Bluetooth Software Supported
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management Certifications
ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 41
Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
1. Wireless access point and Internet service is required. Availability of public wireless access point is limited.
2. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
3. Check latest software/driver release for updates on supported security features.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation). **Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax devices. Only available in countries where 802.11ax is supported.
Intel® 9560
802.11a/b/g/n/ac (2 x 2) Wi-Fi® and Bluetooth®
5.0 Combo1 vPro
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11d IEEE 802.11e IEEE 802.11h IEEE 802.11i IEEE 802.11k IEEE 802.11r IEEE 802.11v
Interoperability
Wi-Fi® certified
Frequency Band
•802.11b/g/n
2.402 – 2.482 GHz
•802.11a/n/ac
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 42
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
Modulation
Direct Sequence Spread Spectrum OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security3
•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES
•WPA2 certification
•IEEE 802.11i
•WAPI
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ac VHT160(5GHz): +11.5dBm minimum
Power Consumption
•Transmit mode 2.0 W
•Receive mode 1.6 W
•Idle mode (PSP) 180 mW (WLAN Associated)
•Idle mode 50 mW (WLAN unassociated)
•Connected Standby 10 mW
•Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity4
802.11b, 1Mbps: -93.5dBm maximum
802.11b, 11Mbps: -84dBm maximum
802.11a/g, 6Mbps: -86dBm maximum
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 43
802.11a/g, 54Mbps: -72dBm maximum
802.11n, MCS07: -67dBm maximum
802.11n, MCS15: -64dBm maximum
802.11ac, MCS0: -84dBm maximum
802.11ac, MCS9: -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard with CNVi Interface
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8g
2. Type 126: 1.3g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy: 0~79 (1 MHz/CH) BLE: 0~39 (2 MHz/CH)
Signaling Data Rate
Legacy: 3 Mbps signaling data rate1 2.17 Mbps BLE: 1 Mbps signaling data rate1 0.2 Mbps
1. Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 44
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW
Bluetooth Software Supported
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management Certifications
ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
1. Wireless access point and Internet service is required. Availability of public wireless access point is limited.
2. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
3. Check latest software/driver release for updates on supported security features.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 45
Intel® 9560
802.11a/b/g/n/ac (2 x 2) Wi-Fi® and Bluetooth®
5.0 Combo1 non-vPro
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11d IEEE 802.11e IEEE 802.11h IEEE 802.11i IEEE 802.11k IEEE 802.11r IEEE 802.11v
Interoperability
Wi-Fi® certified
Frequency Band
•802.11b/g/n
2.402 – 2.482 GHz
•802.11a/n/ac
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
Modulation
Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security3
•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES
•WPA2 certification
•IEEE 802.11i
•WAPI
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 46
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ac VHT160(5GHz): +11.5dBm minimum
Power Consumption
•Transmit mode: 2.0 W
•Receive mode: 1.6 W
•Idle mode (PSP) 180 mW (WLAN Associated)
•Idle mode: 50 mW (WLAN unassociated)
•Connected Standby/Modern Standby: 10mW
•Radio disabled: 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity4
802.11b, 1Mbps: -93.5dBm maximum
802.11b, 11Mbps: -84dBm maximum
802.11a/g, 6Mbps: -86dBm maximum
802.11a/g, 54Mbps: -72dBm maximum
802.11n, MCS07: -67dBm maximum
802.11n, MCS15: -64dBm maximum
802.11ac, MCS0: -84dBm maximum
802.11ac, MCS9: -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard with CNVi Interface
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8g
2. Type 126: 1.3g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 47
LED Activity
LED Amber – Radio OFF LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy: 0~79 (1 MHz/CH) BLE: 0~39 (2 MHz/CH)
Signaling Data Rate
Legacy: 3 Mbps signaling data rate1 2.17 Mbps BLE: 1 Mbps signaling data rate1 0.2 Mbps
1. Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW
Bluetooth Software Supported
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management Certifications
ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX)
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 48
Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
1. Wireless access point and Internet service is required. Availability of public wireless access point is limited.
2. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
3. Check latest software/driver release for updates on supported security features.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
Intel® XMM™ 7360 LTE-Advanced CAT9
1
Technology/Operating bands
FDD LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3), 1700/2100 (Band 4), 850 (Band 5), 2600 (Band 7), 900 (Band 8), 1400 (Band 11), 700 (Band 12 lower), 700 (Band 13 upper), 700 (Band 17 lower), 850 (Band 18 lower), 850 (Band 19 upper), 800 (Band 20), 1400 (Band 21), 850 (Band 26), 700 (Band 28), 700 (Band 29 RX only), 2300 (Band 30), 1700/2100 (Band 66). TDD LTE: 2600 (Band 38), 1900 (Band 39), 2400 (Band 40), 2500 (Band 41). HSPA+: 2100 (Band 1), 1900 (Band 2), 1700/2100 (Band 4), 850 (Band 5), 900 (Band 8) MHz
Wireless protocol standards
3GPP Release 11 LTE Specification CAT.9, DL 60MHz BW throughput up to 450Mbps; UL 20MHz throughput up to 50Mbps WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification
GPS
Standalone, A-GPS (MS-A, MS-B)
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz, Beidou 1561.098 MHz
Maximum data rates
LTE: 450 Mbps (Download), 50 Mbps (Upload) DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload)
Maximum output power
LTE: 23 dBm HSPA+: 23.5 dBm
Maximum power consumption
LTE: 1,200 mA (peak); 900 mA (average) HSPA+: 1,100 mA (peak); 800 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
5.8 g
Dimensions
42 x 30 x 2.3 mm
1. Mobile Broadband is an optional feature and requires configuration at time of purchase. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 49
Intel® XMM™ 7262 LTE­Advanced DL CAT6
Technology/Operating bands
FDD LTE: 2100 (Band 1), 1800 (Band 3), 850 (Band 5), 2600 (Band 7), 900 (Band 8), 800 (Band 20), 700 (Band 28), HSPA+: 2100 (Band 1), 850 (Band 5), 900 (Band 8)
Wireless protocol standards
3GPP Release 11 LTE Specification CAT.6, DL 40MHz BW throughput up to 300Mbps; UL 20MHz throughput up to 50Mbps WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification
GPS
Standalone, A-GPS (MS-A, MS-B and XTRA)
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz
Maximum data rates
LTE: 300 Mbps (Download), 50 Mbps (Upload) DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload)
Maximum output power
LTE: 23 dBm HSPA+: 23.5 dBm
Maximum power consumption
LTE: 1,200 mA (peak); 830 mA (average) HSPA+: 1,100 mA (peak); 680 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
6 g
Dimensions
42 x 30 x 2.3 mm
1. Mobile Broadband is an optional feature and requires configuration at time of purchase. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 50
Near Field Communications Controller (optional)
Dimensions (L x W x H)
Module 25 mm by 10 mm by 2.0 mm
Chipset
NPC100
System interface
I2C
NFC RF standards
ISO/IEC 14443 A ISO/IEC 14443 B ISO/IEC 15693 ISO/IEC 18092 ECMA-340 NFCIP-1 Target and Initiator ECMA-320 NFCIP-2
NFC Forum Support
Tag Type 1, Type 2, Type3 and Type 4, NFCIP-1 and NFCIP-2
Reader (PCD-VCD) Mode
1
ISO/IEC 14443 A ISO/IEC 14443 B ISO/IEC 15693 MIFARE 1K MIFARE 4K MIFARE DESFire FeliCa Jewel and Topaz cards
Card Emulation (PICC­VICC) Mode
1
ISO/IEC 14443 A ISO/IEC 14443 B and B’ MIFARE FeliCa
Frequency
13.56 MHz
NFC Modes Supported
Reader/Writer, Peer-to-Peer
Raw RF Data Rates
106, 212, 424, 848 kbps
Operating temperature
0°C to 70°C
Storage temperature
-20°C to 125°C
Humidity
10-90% operating 5-95% non-operating
Supply Operating voltage
4.35 to 5.25 Volts
I/O Voltage
1.8V or 3.3V
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 51
Intel® i219LM 10/100/1000 Integrated NIC
Connector
RJ-45
System Interface
PCI (Intel proprietary) + SMBus
Data rates supported
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-
30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s
IEEE Compliance
IEEE 802.1p QoS (Quality of Service) Support IEEE 802.1q VLAN support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) IEEE 802.3az EEE (Energy Efficient Ethernet)
Performance
TCP/IP/UDP Checksum Offload (configurable) Protocol Offload (ARP & NS) Large send offload and Giant send offload Receiving Side Scaling (Hash Mode Only) Jumbo Frame 9K
Power consumption
Cable Disconnection: 25mW 100Mbps Full Run: 450mW 1000bp Full Run: 1000mW WoL Enable(S3/S4/S5): 50mW WoL Disable(S3/S4/S5): 25mW
Power Management
ACPI compliant – multiple power modes Situation-sensitive features reduce power consumption Advanced link down power saving for reducing link down power consumption
Management Interface
Auto MDI/MDIX Crossover cable detection
IT Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Virtual Cable Doctor for Ethernet cable status
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 52
Intel® i219v 10/100/1000 Integrated NIC
Connector
RJ-45
System Interface
PCI (Intel proprietary) + SMBus
Data rates supported
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-
30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s
IEEE Compliance
IEEE 802.1p QoS (Quality of Service) Support IEEE 802.1q VLAN support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) IEEE 802.3az EEE (Energy Efficient Ethernet)
Performance
TCP/IP/UDP Checksum Offload (configurable) Protocol Offload (ARP & NS) Large send offload and Giant send offload Receiving Side Scaling (Hash Mode Only) Jumbo Frame 9K
Power consumption
Cable Disconnection: 25mW 100Mbps Full Run: 450mW 1000bp Full Run: 1000Mw WoL Enable(S3/S4/S5): 50mW WoL Disable(S3/S4/S5): 25mW
Power Management
ACPI compliant – multiple power modes Situation-sensitive features reduce power consumption Advanced link down power saving for reducing link down power consumption
Management Interface
Auto MDI/MDIX Crossover cable detection
IT Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30) Comprehensive diagnostic and configuration software suite Virtual Cable Doctor for Ethernet cable status
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 53
Intel® I219-LM 1 Gigabit Network Connection LOM (vPro)
Connector
RJ-45
System Interface
PCI (Intel proprietary) + SMBus
Data rates supported
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-
30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s
IEEE Compliance
IEEE 802.1p QoS (Quality of Service) Support IEEE 802.1q VLAN support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) IEEE 802.3az EEE (Energy Efficient Ethernet)
Performance
TCP/IP/UDP Checksum Offload (configurable) Protocol Offload (ARP & NS) Large send offload and Giant send offload Receiving Side Scaling (Hash Mode Only) Jumbo Frame 9K
Power consumption
Cable Disconnetion: 25mW 100Mbps Full Run: 450mW 1000bp Full Run: 1000mW WoL Enable(S3/S4/S5): 50mW WoL Disable(S3/S4/S5): 25mW
Power Management
ACPI compliant – multiple power modes Situation-sensitive features reduce power consumption Advanced link down power saving for reducing link down power consumption
Management Interface
Auto MDI/MDIX Crossover cable detection
IT Manageability
Wake-on-LAN from modern standby or sleep state (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Virtual Cable Doctor for Ethernet cable status
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 54
Intel® I219-LM 1 Gigabit Network Connection LOM (non-vPro)
Connector
RJ-45
System Interface
PCI (Intel proprietary) + SMBus
Data rates supported
1. 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
2. 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
3. 1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 802.3 clauses 40)
4. Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10, 100 & 1000 Mbit/s
IEEE Compliance
IEEE 802.1p QoS (Quality of Service) Support IEEE 802.1q VLAN support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) IEEE 802.3az EEE (Energy Efficient Ethernet) IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BAE-T IEEE 802.3bz 2.5GBASE-T
Performance
TCP/IP/UDP Checksum Offload (configurable) Protocol Offload (ARP & NS) Large send offload and Giant send offload Receiving Side Scaling (Hash Mode Only) Jumbo Frame 9K
Power consumption
Cable Disconnetion: 25mW 100Mbps Full Run: 450mW 1000bps Full Run: 1000mW WoL Enable(S3/S4/S5): 50mW WoL Disable(S3/S4/S5): 25mW
Power Management
ACPI compliant – multiple power modes Situation-sensitive features reduce power consumption Advanced link down power saving for reducing link down power consumption
Management Interface
Auto MDI/MDIX Crossover cable detection
IT Manageability
Wake-on-LAN from modern standby or sleep state (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Virtual Cable Doctor for Ethernet cable status
Security & Manageability
Intel® non-vPro™ support with appropriate Intel® chipset components
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 55
AC Adapter 45 Watt nPFC Wall Mount USB type C Straight 1.8m C6NS
Dimensions
62.0x62.0x28.5mm
Weight
unit: 220g +/- 10g
Input
Input Efficiency
Average Efficiency of 25%, 50%, 75%, 100% load condition with 115Vac/230Vac Spec: 5V: 81.5% 9V: 86.7% 10V: 87.5% 12V: 87.8% 15V: 87.8% 20V: 87.8%
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
Average Efficiency of 25%, 50%, 75%, 100% load condition with 115Vac/230Vac Spec:
DC output
5V: 81.5%
Hold-up time
9V: 86.7%
Output current limit
10V: 87.5%
Connector
Non-Standard C6
Environmental Design
Operating temperature
32°Fto 95°F (0°to 35°C)
Non-operating (storage) temperature
-4°F to 185°F (-20°to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
5% to 95%
Storage Humidity
5% to 95%
EMI and Safety Certifications
Eg: *CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
AC Adapter 45 Watt Smart nPFC Standard Barrel 4.5mm Right Angle
1.8m
Dimensions
95.0x40.0x26.5mm
Weight
unit: 200g +/- 10g
Input
Input Efficiency
87.74 % at 115 Vac and 88.4 % at 230Vac
Input frequency range
47 ~ 63Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
45W
DC output
19.5V
Hold-up time
5ms at 115 Vac input
Output current limit
<8.0A
Connector
C6
Environmental Design
Operating temperature
32°F to 95°F (0°to 35°C)
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 56
Non-operating (storage) temperature
-4°F to 185°F (-20°to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Safety Certifications
Eg: *CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
AC Adapter 45 Watt Smart nPFC Standard Barrel 4.5mm Right Angle
1.8m Argentina
Dimensions
95.0 x 40.0 x 26.5 mm
Weight
unit: 200 g +/- 10 g
Input
Input Efficiency
87.74 % at 115 Vac and 88.4 % at 230Vac
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
45W
DC output
19.5V
Hold-up time
5ms at 115 Vac input
Output current limit
<8.0A
Connector
C6
Environmental Design
Operating temperature
32°F to 95°F (0°to 35°C)
Non-operating (storage) temperature
-4°F to 185°F (-20°to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Safety Certifications
CE Mark - full compliance with LVD and EMC directives Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. MTBF - over 200,000 hours at 25°C ambient condition.
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 57
AC Adapter 45 Watt Smart nPFC Standard Barrel 4.5mm Right Angle
1.8m 2prong
Dimensions
95.0x40.0x26.5mm
Weight
unit: 200g +/- 10g
Input
Input Efficiency
87.74 % at 115 Vac and 88.4 % at 230Vac
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
45W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<8.0A
Connector
C6
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Safety Certifications
Eg: *CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
AC Adapter 65 Watt nPFC USB type C Straight 1.8m C6NS
Dimensions
74x74x28.5mm
Weight
unit: 245g +/- 10g
Input
Input Efficiency
81.5% min at 115 Vac/ 230Vac @ 5V/3A
86.7% min at 115 Vac/ 230Vac @ 9V/3A 88% min at 115 Vac/ 230Vac @ 10V/5A 88% min at 115 Vac/ 230Vac @ 12V/5A 89% min at 115 Vac/ 230Vac @ 15V/4.33A 89% min at 115 Vac/ 230Vac @ 20V/3.25A
Input frequency range
47 ~ 63 Hz
Input AC current
1.7 A at 90 VAC and maximum load
Output
Output power
65W
DC output
5V/9V/10V/12V/15V/20V
Hold-up time
5ms at 115 Vac input
Output current limit
<8.0A
Connector
Non-Standard C6
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 185° F (-20° to 85° C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
5% to 95%
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 58
Storage Humidity
5% to 95%
Safety Certifications
Eg: *CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 100,000 hours at 25°C ambient condition.
AC Adapter 65 Watt Smart nPFC EM Barrel
4.5mm New EM
Dimensions
102x55x30mm
Weight
unit: 250g +/- 10g
Input
Input Efficiency
88.0 % at 115 Vac and 89.0 % at 230Vac
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.7 A at 90 Vac
Output
Output power
65W
DC output
19.5V
Hold-up time
5ms at 115 Vac input
Output current limit
<11.0A
Connector
C6
Environmental Design
Operating temperature
0° to 35° C
Non-operating (storage) temperature
-20° to 85° C
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Safety Certifications
Eg: *CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
AC Adapter 65 Watt Smart nPFC Standard Barrel 4.5mm Right Angle
1.8m
Dimensions
90.0x51x28.5mm
Weight
unit: 230g +/- 10g
Input
Input Efficiency
88.0 % at 115 Vac and 89.0 % at 230Vac
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.7 A at 90 Vac
Output
Output power
65W
DC output
19.5V
Hold-up time
5ms at 115 Vac input
Output current limit
<11.0A
Connector
C6
Environmental Design
Operating temperature
32°F to 95°F (0°to 35°C)
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 59
Non-operating (storage) temperature
-4°F to 185°F (-20°to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
Safety Certifications
Eg: *CE Mark - full compliance with LVD and EMC directives * Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. * MTBF - over 200,000 hours at 25°C ambient condition.
HP 3-cell Long Life Li-Ion (48 WHr)
Dimensions (H x W x L)
8.05. x185.15x95 mm
Weight
0.26 kg
Cells/Type
3cell Lithium-Ion Polymer cell / 606072
Energy
Voltage
11.4V
Amp-hour capacity
4.212Ah /4.0Ah
Watt-hour capacity
48Wh
Temperature
Operating (Charging)
32˚ to 113˚ F (0˚ to 45˚ C)
Operating (Discharging)
14˚ to 122˚ F (-10˚ to 60˚ C)
Warranty
3 years
Optional Travel Battery Available
No
QuickSpecs
HP ProBook 650 G5 Notebook PC
Technical Specifications
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 60
China
QuickSpecs
HP ProBook 650 G5 Notebook PC
Options and Accessories (sold separately and availability may vary by country)
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 61
Type
Description
Part #
Cases
HP Essential Top Load Case
H2W17AA#xxx
HP Essential Backpack (up to 15.6")
H1D24AA
HP Essential Messenger Case (up to 17.3")
H1D25AA
Docking
HP UltraSlim Docking Station
D9Y32AA#xxx
HP UltraSlim Docking Station TAA US
E5C22AV#ABA
HP Thunderbolt Dock 120W G2
2UK37AA
HP Thunderbolt Dock 120W G2 TAA
2UK37AA
HP TB Dock G2 w/ Combo Cable
3TR87AA
HP TB Dock 120W G2 w/ Audio
3YE87AA#xxx
HP USB-C Universal Dock
1MK33AA#xxx
HP USB-C/A Universal Dock G2
5TW13AA#XXX
HP USB-C Universal Dock w/4.5mm Adapter
2UF95AA
HP USB-C Universal Dock NF
3DV65AA
HP USB-C Dock G4
3FF69AA#xxx
HP USB-C Dock G5
5TW10AA#XXX
HP USB-C Mini Dock
1PM64AA#xxx
HP USB-C Travel Dock
T0K29AA#xxx
HP USB Travel Dock
T0K30AA#xxx
HP TB Dock Audio Module
3AQ21AA
HP TB Dock 120W G2 cable
3XB94AA
HP TB Dock G2 combo cable
3XB96AA
HP Adjustable Dual Display Stand
AW664AA#xxx
HP Display and Notebook Stand II
E8G00AA#xxx
HP USB-C Mini Dock
1PM64AA#xxx
Input/Output
HP Slim USB Keyboard and Mouse
T6T83AA#xxx
HP Slim Wireless Keyboard and Mouse
T6L04AA#xxx
HP USB Essential Keyboard and Mouse
H6L29AA
HP Ultra Mobile Wireless Mouse
H6F25AA#xxx
HP Comfort Grip Wireless Mouse
H2L63AA
HP 3-Button USB Laser Mouse
H4B81AA
HP USB Travel Mouse
G1K28AA
HP Slim Bluetooth Mouse
F3J92AA#xxx
QuickSpecs
HP ProBook 650 G5 Notebook PC
Options and Accessories (sold separately and availability may vary by country)
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 62
HP Essential USB Mouse
2TX37AA#xxx
HP Elite Presenter Mouse
2CE30AA#xxx
HP HDMI to DVI Adapter
F5A28AA
HP USB-C to DP
N9K78AA
HP USB-C to HDMI 2.0
1WC36AA#xxx
HP USB-C to USB-A Hub
Z6A00AA
HP UC Wireless Mono Headset
W3K08AA
HP UC Wireless Duo Headset
W3K09AA
HP Stereo 3.5mm Headset
T1A66AA
HP Stereo USB Headset
T1A67AA
HP TB Dock Audio Module
3AQ21AA
HP Thunderbolt 120W 1m cable
3AQ23AA
HP Thunderbolt 1m combo cable
3AQ25AA
Power
HP 45W Smart AC Adapter 4.5mm
H6Y88AA#xxx
HP 65W Smart AC Adapter
H6Y89AA#xxx
HP 65W Slim AC Adapter
H6Y82AA#xxx
HP 45W USB-C Power Adapter
1HE07AA#xxx
HP 65W USB-C Power Adapter
1HE08AA#xxx
HP 65W USB-C Slim Power Adapter (w/additional USB-A)
3PN48AA#xxx
3-cell Prismatic Battery
TBD
HP Power Bank
N9F71AA#xxx
HP USB-C Notebook Power Bank
2NA10AA
HP 65W USB-C Slim Power Adapter
3PN48AA
Storage
HP External USB Optical Drive
F2B56AA
HP 256GB TLC PCIe 3x4 NVMe M.2 SSD
1FU87AA
HP 512GB TLC PCIe 3x4 NVMe M.2 SSD
1FU88AA
HP 500GB 7200rpm HDD
F3B97AA
Security
HP Essential Combination Lock
T0Y16AA
HP Combination Lock
T0Y15AA
HP Keyed Cable lock
T0Y14AA
HP 15.6 Touchable Privacy Filter
3KP53AA
HP Docking Station Cable Lock
AU656AA#XXX
QuickSpecs
HP ProBook 650 G5 Notebook PC
Options and Accessories (sold separately and availability may vary by country)
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 63
HP Keyed Cable Lock 10mm
T1A62AA
UCC
HP Conferencing Keyboard
K8P74AA#xxx
HP Speaker Phone
K7V16AA
HP Wired Headset
K7V17AA
Memory
HP 4GB 2666MHz DDR4 Memory
4VN05AA
HP 8GB 2666MHz DDR4 Memory
4VN06AA
HP 16GB 2666MHz DDR4 Memory
4VN07AA
HP 4GB DDR4 3200 Memory
286H5AA
HP 8GB DDR4 3200 Memory
286H8AA
Displays
HP ProDisplay P223 21.5-inch Monitor
X7R61AA
HP ProDisplay P240va 23.8-inch Monitor
N3H14AA
HP EliteDisplay E243 23.8-inch Monitor
1FH47AA
QuickSpecs
HP ProBook 650 G5 Notebook PC
Summary of Changes
c06314750 — DA16450— Worldwide — Version 9 — April 19, 2021
Page 64
Date of change:
Version History:
Updated
Description of change:
June 10, 2019
V1 to V2
Added
HP Cloud Recovery
June 21, 2019
V2 to V3
Added
Environmental Tab
June 24, 2019
V3 to V4
Updated
Display Section
June 27, 2019
V4 to V5
Updated
Display Section
September 9, 2019
V5 to V6
Updated
Intel® Optane™ and disclaimer for 1000 nit Sure View panel
September 11, 2019
V6 to V7
Updated
Ports and Slots section
March 30, 2020
V7 to V8
Updated
Images section, USB-C port
April 19, 2021
V8 to V9
Added
Intel I219-LM(v-Pro)/I219-V (non-vPro)/Memory Modules
V9 to V10
Copyright © 2021 HP Development Company, L.P. The only warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Intel, Core and Intel vPro are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the United States and other
countries. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
