QuickSpecs
HP ProBook 430 G8 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 1
HP ProBook 430 G8 Notebook PC
Left
1.
Internal Microphones (2)
6.
Clickpad
2.
Webcam LED (Optional)
7.
Micro SD Card Reader
3.
HD and IR Camera (Optional)
8.
Audio Combo Jack
4.
Camera Shutter (Only available with webcam)
9.
SuperSpeed USB Type-A 5Gbps signaling rate port
5.
IR Camera LED (Optional)
10.
Nano Security Lock Slot (Lock sold separately)
QuickSpecs
HP ProBook 430 G8 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 2
Right
1.
Power Button Key
4.
SuperSpeed USB Type-A 5Gbps signaling rate charging port
2.
Power Connector
5.
HDMI Port (Cable not included)
3.
SuperSpeed USB Type-C® 10Gbps signaling rate
(USB Power Delivery, DisplayPort™ 1.4)
6.
Touch Fingerprint Sensor (select models)
QuickSpecs
HP ProBook 430 G8 Notebook PC
Overview
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 3
At a Glance
• A new compact design with lift-anywhere edge
• Choice of 11th generation Intel® Core™ i7, i5 and i3 processors
• Preinstalled with Windows 10 versions or FreeDOS
• Fast and upgradeable dual channel DDR4 SODIMM memory up to 32 GB
• Choice of 33.8 cm (13.3") diagonal HD, Ultra Wide Viewing Angle FHD, Touch or Non-Touch screen, and Privacy Panel
option
• Features redesigned quiet and responsive HP Keyboard with the HP Programmable key and backlit options
• Choice of solid state drives up to 1 TB
• Multi-layered security with HP SureStart Gen6, HP Privacy Camera, HP Sure View Gen3
1
, HP Sure Sense, HP Sure Click and
Touch Fingerprint reader2
• Supports wireless options for connectivity on the go including gigabit-speed Wi-Fi® 6
• Supports fast charging (50% in 30 minutes) with no impact on battery recharge cycles
3
• Designed to support HP docking options
• Passed MIL-STD 810H tests
4
• Battery life up to 12 hours and 45 minutes
1. HP Sure View integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in
landscape orientation.
2. Sold separately or as an optional feature
3.HP notebooks up to 50% within 30 minutes when the system is off or in standby mode. Power adapter with a
minimum capacity of 65 watts is required. After charging has reached 50% capacity, charging will return to normal. Charging
time may vary +/-10% due to System tolerance.
4. MIL STD 810H testing is not intended to demonstrate fitness for U.S. Department of Defense contract requirements or for
military use. Test results are not a guarantee of future performance under these test conditions. Accidental damage requires an
optional HP Accidental Damage Protection Care Pack.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 4
PRODUCT NAME
HP ProBook 430 G8 Notebook PC
OPERATING SYSTEMS
Preinstalled
Windows 10 Pro 64 – HP recommends Windows 10 Pro for business1
Windows 10 Pro 64 (National Academic only)
2
Windows 10 Home 64
1
Windows 10 Home Single Language 64
1
Windows 10 Pro (Windows 10 Enterprise available with a Volume Licensing Agreement)
1
FreeDOS
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately
purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is
automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for
updates. See http://www.windows.com.
2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10
Anniversary Update. Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.
Supported Versions
HP tested Windows 10, version 1809 on this platform. For testing information on newer versions of Windows 10, please see
https://support.hp.com/document/c05195282
PROCESSORS
Intel® Core™ i7-1185G7 (3.0 GHz base frequency, up to 4.8 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache,
4 cores)
3,4 5,6
Intel® Core™ i7-1165G7 (2.8 GHz base frequency, up to 4.7 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache,
4 cores)
3,4 5,6
Intel® Core™ i5-1145G7 (2.6 GHz base frequency, up to 4.4 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache,
4 cores)
3,4 5,6
Intel® Core™ i5-1135G7 (2.4 GHz base frequency, up to 4.2 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache,
4 cores)
3,4 5,6
Intel® Core™ i3-1125G4 with Intel® UHD Graphics (2.0 GHz base frequency, up to 3.7 GHz with Intel® Turbo Boost Technology,
8 MB L3 cache, 4 cores)
3,4 5,6
Intel® Core™ i3-1115G4 with Intel® UHD Graphics (3.0 GHz base frequency, up to 4.1 GHz with Intel® Turbo Boost Technology,
6 MB L3 cache, 2 cores)
3,4 5,6
Intel® Pentium® Gold 7505 with Intel® UHD Graphics (2.0 GHz base frequency, up to 3.5 GHz with Intel® Turbo Boost
Technology, 4 MB L3 cache, 2 cores)
3,4 5,6
Intel® Celeron® 6305 with Intel® UHD Graphics (1.8 GHz base frequency, 4 MB L3 cache, 2 cores)
3,4 5,6
Processors Family
11th Generation Intel® Core™ i7 processor (i7-1165G7)
7
11th Generation Intel® Core™ i5 processor (i5-1135G7)
7
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 5
11th Generation Intel® Core™ i3 processor (i3-1115G4)
7
3. Multicore is designed to improve performance of certain software products. Not all customers or software applications will
necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application
workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement
of higher performance.
4. Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
5. Intel® Turbo Boost performance varies depending on hardware, software and overall system configuration. See
http://www.intel.com/technology/turboboost for more information.
6. Max Boost clock frequency performance varies depending on hardware, software and overall system configuration.
7. In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on
products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7
drivers on http://www.support.hp.com.
CHIPSET
Chipset is integrated with processor
GRAPHICS
Integrated
Intel® Iris® Xe Graphics (Core i5 and Core i7)
35
Intel® UHD Graphics (Core i3)
8
Supports
Support HD decode, DX12, HDMI 1.4b
8. HD content required to view HD images.
35. Intel® Iris® Xe Graphics capabilities require system to be configured with Intel® Core™ i5 or i7 processors and dual channel
memory. Intel® Iris® Xe Graphics with Intel® Core™ i5 or 7 processors and single channel memory will only function as UHD
graphics.
DISPLAYS
Internal
Non-Touch
33.8 cm (13.3") diagonal HD SVA eDP anti-glare, narrow bezel, 250 nits, 45% NTSC (1366 x 768)
8,10
33.8 cm (13.3") diagonal HD SVA eDP anti-glare, narrow bezel, 250 nits, 45% NTSC for HD camera (1366 x 768)
8,10
33.8 cm (13.3") diagonal HD SVA eDP anti-glare, narrow bezel, 250 nits, 45% NTSC for HD+IR camera (1366 x 768)
8,10
33.8 cm (13.3") diagonal FHD UWVA eDP anti-glare, narrow bezel flat, 250 nits, 45% NTSC for HD camera (1920 x 1080)
8,10
33.8 cm (13.3") diagonal FHD UWVA eDP anti-glare, narrow bezel flat, 250 nits, 45% NTSC for HD+IR camera (1920 x 1080)
8,10
33.8 cm (13.3") diagonal FHD UWVA eDP+PSR anti-glare, low power narrow bezel flat, 400 nits, 72% NTSC for HD camera
(1920 x 1080)
8,10
33.8 cm (13.3") diagonal FHD UWVA eDP+PSR anti-glare, low power narrow bezel flat, 400 nits, 72% NTSC for HD+IR camera
(1920 x 1080)
8,10
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 6
33.8 cm (13.3") diagonal FHD UWVA eDP+PSR anti-glare, narrow bezel flat with HP Sure View Gen3 Integrated Privacy Screen,
1000 nits, 100% sRGB for HD camera (1920 x 1080)
8,10,11
33.8 cm (13.3") diagonal FHD UWVA eDP+PSR anti-glare narrow bezel flat with HP Sure View Gen3 Integrated Privacy Screen,
1000 nits, 100% sRGB for HD+IR camera (1920 x 1080)
8,10,11
Touch
33.8 cm (13.3") diagonal FHD UWVA eDP anti-glare, narrow bezel flat, touch-on-panel screen, 250 nits, 45% NTSC for HD
camera (1366 x 768)
8, 9, 10
HDMI
Supports resolutions up to 4K 30Hz
8. HD content required to view HD images.
9. Sold separately or as an optional feature.
10. Resolutions are dependent upon monitor capability, and resolution and color depth settings.
11. HP Sure View integrated privacy screen is an optional feature that must be configured at purchase and is designed to
function in landscape orientation.
NOTE: Actual brightness will be lower with touchscreen or Sure View.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 7
STORAGE AND DRIVES
Primary M.2 Storage
128 GB PCIe® NVMe™ M.2 TLC Solid State Drive 12
256 GB PCIe® NVMe™ M.2 Value Solid State Drive
12
512 GB PCIe® NVMe™ M.2 Value Solid State Drive
12
512 GB Intel® PCIe® NVMe™ QLC M.2 SSD with 32 GB Intel® Optane™ memory H10
12, 38,39
1 TB PCIe® NVMe™ M.2 TLC Solid State Drive 12
12. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows
10) is reserved for system recovery software.
38. Intel® Optane™ memory system acceleration does not replace or increase the DRAM in your system. Requires 8th Gen or
higher Intel® Core™ processor, BIOS version with Intel® Optane™ supported, Windows 10 64-bit, and an Intel® Rapid Storage
Technology (Intel® RST) driver.
39. Intel® Optane™ memory H10 only for Intel® PCIe® NVMe™ QLC M.2 SSD.
MEMORY
Maximum Memory
32 GB DDR4-3200 SDRAM 13
Memory
32 GB DDR4-3200 SDRAM (2 x 16 GB)
13
16 GB DDR4-3200 SDRAM (1 x 16 GB)
13
12 GB DDR4- 3200 SDRAM (4 GB and 8 GB (1 x 8 GB))
13
8 GB DDR4-3200 SDRAM (1 x 8 GB)
13
8 GB DDR4-3200 SDRAM (2 x 4 GB)
13
4 GB DDR4-3200 SDRAM (1 x 4 GB) 13
Memory Slots
2 SODIMM
Both slots are accessible/upgradeable by IT or self-maintainers only
DDR4 PC4 SODIMMS, system runs at 3200
Supports Dual Channel Memory
13. Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to
ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 8
NETWORKING/COMMUNICATIONS
WLAN
Realtek 802.11ac (2x2) WLAN and Bluetooth® 5 Combo
14
Intel® Dual Band Wireless-AC 9560 802.11a/b/g/n/ac (2x2) WLAN and Bluetooth® 5 Combo, non-vPro®
14
Intel® Dual Band Wi-Fi® 6 AX201 802.11a/b/g/n/ac/ax (2x2) WLAN and Bluetooth® 5 Combo, non-vPro® 15
Realtek RTL8852AE 802.11ax 2x2 Wi-Fi and Bluetooth® 5.115
14. Wireless access point and internet service required and sold separately. Availability of public wireless access points
limited. Wi-Fi 5 (802.11 ac) is backwards compatible with prior 802.11 specs.
15. Wireless access point and Internet service required and sold separately. Availability of public wireless access points
limited. The specifications for Wi-Fi® 6 (802.11ax WLAN) are draft specifications and are not final. If the final specifications
differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax WLAN
devices. Only available in countries where 802.11ax is supported.
AUDIO/MULTIMEDIA
Audio
2 Integrated stereo speakers
Integrated microphone (Dual Array)
Speaker Power
2W/4ohm Per speaker
Camera
720p HD Camera
8
720p HD Camera+IR Camera
8,9
8. HD content required to view HD images.
9. Sold separately or as an optional feature.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 9
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Keyboard
HP Premium Keyboard, spill resistant and optional Durakeys and backlit
Pointing Device
Clickpad with multi-touch gesture support
Function Keys
F1 - Display Switching
F2 - Blank or SureView On/Off
F3 - Brightness Down
F4 - Brightness Up
F5 - Audio Mute
F6 - Volume Down
F7 - Volume Up
F8 - Mic Mute
F9 - Blank or Backlit Toggle
F10 - Insert
F11 - Airplane Mode
F12 - Programmable Key
Print Screen
Power Button (with LED)
Hidden Function Keys
Fn+R - Break
Fn+S - Sys Rq
Fn+C - Scroll Lock
SOFTWARE AND SECURITY
Preinstalled Software
BIOS
HP BIOSphere Gen5
16
HP Drive Lock & Automatic Drive Lock
BIOS Update via Network
Power On Authentication
HP Secure Erase
18
Absolute Persistence Module
19
HP LAN-Wireless Protection
Pre-boot Authentication
Software
Xerox® DocuShare® 30 day free trial offer42
HP Connection Optimizer
17
HP Image Assistant
HP Hotkey Support
myHP
HP Noise Cancellation Software
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 10
HSA Fusion for Commercial
HSA Telemetry for Commercial
Touchpoint Customizer for Commercial
HP Notifications
HP Privacy Settings
HP System Information
HP Wireless Button Driver
HP Power Manager
HP Work Well
Buy Office (sold separately)
Manageability Features
HP Driver Packs (download)
20
HP Manageability Integration Kit Gen3 (download)
21
HP System Software Manager (SSM) (download)
HP BIOS Config Utility (BCU) (download)
HP Client Catalog (download)
HP Client Management Script Library (download)
Client Security Software
HP Client Security Manager Gen7
22
Windows Defender
23
Security Management
Pre-boot Authentication
USB enable/disable (via BIOS)
Power-on password (via BIOS)
Setup password (via BIOS)
HP Fingerprint Sensor
24
Support for chassis padlocks and cable lock devices
HP Sure Click
26
HP Sure Sense
27
HP Sure Start Gen6
28
HP Sure Admin
29
TPM 2.0 Embedded Security Chip (Common Criteria EAL4+ Certified) (FIPS 140-2 Level 2 Certified) 30
16. HP BIOSphere Gen5 is available on select HP Pro and Elite PCs. See product specifications for details.
Features may vary depending on the platform and configurations.
17. HP Connection Optimizer requires Windows 10.
18. HP Secure Erase For the methods outlined in the National Institute of Standards and Technology Special
Publication 800-88 "Clear" sanitation method. HP Secure Erase does not support platforms with Intel®
Optane™.
19. Absolute firmware module is shipped turned off and can only be activated with the purchase a license
subscription and full activation of the software agent. License subscriptions can be purchased for terms
ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. Certain
conditions apply. For full details visit: https://www.absolute.com/about/legal/agreements/absolute/
20. HP Driver Packs not preinstalled, however available for download at
http://www.hp.com/go/clientmanagement.
21. HP Manageability Integration Kit can be downloaded from http://www.hp.com/go/clientmanagement.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 11
22. HP Client Security Manager Gen6 requires Windows and is available on the select HP Pro and Elite PCs.
23. Windows Defender Opt in and internet connection required for updates.
24. HP Fingerprint sensor is an optional feature that must be configured at purchase.
25. Windows Defender Opt in and internet connection required for updates.
26. HP Sure Click requires Windows 10 Pro or Enterprise. See https://bit.ly/2PrLT6A_SureClick for complete details.
27. HP Sure Sense requires Windows 10. Pro or Enterprise
28. HP Sure Start Gen6 is available on select HP PCs.
29. HP Sure Admin requires Windows 10, HP BIOS, HP Manageability Integration Kit from
http://www.hp.com/go/clientmanagement and HP Sure Admin Local Access Authenticator smartphone app
from the Android or Apple store.
30. Firmware TPM is version 2.0.
42. Simply sign up and start using Xerox® DocuShare® Go. No credit card. No obligation. Data will become
unavailable unless a subscription is entered before the end of the 30-day free trial period. See visit
http://www.xerox.com/docusharego for details.
POWER
Power Supply
16
HP Smart 65 W External AC power adapter 32
HP Smart 65 W EM External AC power adapter
32
HP Smart 65 W USB Type-C® adapter
32
HP Smart 45 W External AC power adapter
32
HP Smart 45 W USB Type-C® adapter
32
Primary Battery
HP Long Life 3-cell, 45 Wh Polymer 33
Power Cord
3-wire plug - 1m
32
2-wire plug - 1m 32
Battery life
Up to 12 hours and 45 minutes (UMA graphics, Intel® 11th generation CPU and 3-cell 45 Wh battery)
Battery Weight
190 g
32. Availability may vary by country.
33. Battery is internal and not replaceable by customer. Serviceable by warranty.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 12
WEIGHTS & DIMENSIONS
Product Weight
34
Starting at 2.81 lb
Starting at 1.28kg (400nits panel only)
Product Dimensions (w x d x h)
Metal bottom cover:
12.08 x 8.2 x 0.62 in
30.69 x 20.84 x 1.59 cm
Plastic bottom cover:
12.08 x 8.2 x 0.69 in
30.69 x 20.84 x 1.77 cm
34. Weight will vary by configuration.
PORTS/SLOTS
Ports
1 SuperSpeed USB Type-C® 10Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4)
2 SuperSpeed USB Type-A 5Gbps signaling rate
35
(1 charging, 1 powered port)
1 HDMI 1.4b
36
1 Headphone/microphone combo jack
1 AC power
Expansion Slots
1 Micro SD Card Reader
Supports SD, SDHC, SDXC
36. HDMI cable sold separately.
SERVICE AND SUPPORT
HP Services offers 3-year and 1-year limited warranties and 90-day software limited warranty options depending on
country. Batteries have a default one-year limited warranty except for Long Life batteries which will have same 1-year or 3year limited warranty as the platform. Refer to http://www.hp.com/support/batterywarranty/ for additional battery
information. On-site service and extended coverage is also available. HP Care Pack Services are optional extended service
contracts that go beyond the standard limited warranties. To choose the right level of service for your HP product, use the
HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc.
37
37. HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your
geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit
http://www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or
indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local
laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty
provided with your HP Product.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 13
ENVIRONMENTAL & INDUSTRY
Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following approvals and may
be labeled with one or more of these marks:
•IT ECO declaration
•US ENERGY STAR®
•EPEAT® 2019 Gold in U.S. Based on US EPEAT® registration according to IEEE 1680.1-2018
EPEAT®. EPEAT® status varies by country. Visit http://www.epeat.net for more information.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Notebook model is based on a “Typically Configured Notebook”.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
(Short idle)
4.14 W
4.164 W
4.056 W
Normal Operation
(Long idle)
2.112 W
2.184 W
2.076 W
Sleep
0.372 W
0.384 W
0.372 W
Off
0.192 W
0.228 W
0.192 W
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model
family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S.
Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model
family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is
for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a
Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
(Short idle)
14 BTU/hr
14 BTU/hr
14 BTU/hr
Normal Operation
(Long idle)
7 BTU/hr
7 BTU/hr
7 BTU/hr
Sleep
1 BTU/hr
1 BTU/hr
1 BTU/hr
Off
1 BTU/hr
1 BTU/hr
1 BTU/hr
Heat dissipation is calculated based on the measured watts, assuming the service level is attained
for one hour.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured –
Idle
2.6
14.4
Fixed Disk – Random
writes
2.6
14.4
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:
• 3 USB ports
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 14
• 1 PC card slot (type I/II)
• 1 ExpressCard/54 slot
• 1 IEEE 1394 Port
• 2 SODIMM memory slots
• Optional expansion base docking station
• 1 multi-bay II storage port
Spare parts are available throughout the warranty period and or for up to “5” years after the end of
production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: Not Applicable
Battery type: Not Applicable
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water
and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680.1 (EPEAT) standard at the <Gold> level, see
http://www.epeat.net
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
• This product contains 2.4% post-consumer recycled plastic (by wt.)
• This product is 96.2% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Paper
51 g
PAPER/Corrugated
230 g
Internal:
PLASTIC/Polyethylene Expanded - EPE
31 g
PLASTIC/Polyethylene low density - LDPE
9 g
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer
to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 15
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated materials.
• Reduce size and weight of packages to improve transportation fuel efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
End-of-life Management
and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest
HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly
instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These
instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
HP Inc. Corporate
Environmental
Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 16
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K
_Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 17
SYSTEM UNIT
Stand-Alone Power Requirements (AC Power)
Nominal Operating Voltage
19 V
Average Operating Power
4.62 W
Integrated graphics
Yes
Max Operating Power
UMA < 45W
Temperature
Operating
32° to 95° F (0° to 35° C)
Non-operating
-4° to 140° F (-20° to 60° C)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
Shock
Operating
40 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude (unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 40,000 ft (-15.24 to 12,192 m)
Planned Industry Standard Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR®
Select models
38
EPEAT®
EPEAT® 2019 Gold in U.S.
39
ICES
Yes
Australia /
Yes
NZ A – Tick Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
KC
Yes
BSMI
Yes
CE Marketing Compliance
Yes
BNCI or BELUS
Yes
CIT
Yes
GOST
Yes
Saudi Arabian Compliance (ICCP)
Yes
SABS
Yes
38.Configurations of the HP ProBook 430 G8 that are ENERGY STAR® certified are identified as HP ProBook 430 G8 ENERGY STAR on
HP websites and on http://www.energystar.gov.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 18
39. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. EPEAT® status varies by country. Visit
http://www.epeat.net for more information.
DISPLAYS
Note: All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may
vary either higher or lower.
Actual brightness will be lower with touchscreen or Sure View.
Panel LCD 13.3 inch FHD
(1920x1080) Anti-Glare
WLED UWVA 45% NTSC
250nits eDP 1.2 w/o PSR
slim NWBZ
Outline Dimensions (W x H x D)
300.56 x 187.77 mm (max) (w/ PCB & w/o bracket)
Active Area
293.76 x 165.24 mm (typ.)
Weight
260 g (max)
Diagonal Size
13.3 inch
Thickness
3.0 mm (max)
Interface
eDP 1.2 (2 lane)
Surface Treatment
Anti-Glare
Touch Enabled
No
Contrast Ratio
600:1 (typ.)
Refresh Rate
60 Hz
Brightness
250nits (typ.)
Pixel Resolution
1920 x 1080 (FHD)
Format
RGB
Backlight
LED
Color Gamut Coverage
NTSC 45%
Color Depth
6 bits
Viewing Angle
UWVA 85/85/85/85
Panel LCD 13.3 inch FHD
(1920x1080) Anti-Glare
WLED UWVA 45% NTSC
250nits eDP slim Touch on
Panel NWBZ
Outline Dimensions (W x H x D)
300.56 x 177.77 mm (max)
Active Area
293.76 x 165.24 mm (typ.)
Weight
260 g (max)
Diagonal Size
13.3 inch
Thickness
3.0 mm/ 5.0 mm (PCB) (max)
Interface
eDP 1.2
Surface Treatment
Anti-Glare On-cell
Touch Enabled
Yes
Contrast Ratio
600:1 (typ.)
Refresh Rate
60 Hz
Brightness
250 nits
Pixel Resolution
1920 x 1080 (FHD)
Format
RGB Stripe
Backlight
LED
Color Gamut Coverage
NTSC 45%
Color Depth
6 bits (Hi FRC supportive w/ condition to enable)
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 19
Viewing Angle
UWVA 85/85/85/85
Panel LCD 13.3 inch FHD
(1920x1080) Anti-Glare
WLED UWVA 72% NTSC
1000nits eDP 1.4+PSR2
flat Privacy NWBZ Gen3
Outline Dimensions (W x H x D)
299.06 x 186.54 mm (max)
Active Area
293.76 x 165.24 mm (typ.)
Weight
255 g (max)
Diagonal Size
13.3 inch
Thickness
3.0 mm (max)
Interface
eDP 1.4 + PSR (4 lane)
Surface Treatment
Anti-Glare (AG)
Touch Enabled
No
Contrast Ratio
2000:1 (typ.)
Refresh Rate
60 Hz
Brightness
1000 nits
Pixel Resolution
1920 x 1080 (FHD)
Format
RGB
Backlight
LED
Color Gamut Coverage
sRGB 100%
Color Depth
8 bits
Viewing Angle
UWVA 85/85/85/85
Panel LCD 13.3 inch FHD
(1920x1080) Anti-Glare
WLED UWVA 72% NTSC
400nits eDP 1.4+PSR2
ultraslim LP NWBZ
Outline Dimensions (W x H x D)
299.06 x 185.54 mm (max)
Active Area
293.76 x 165.24 mm (typ.)
Weight
170 g (max)
Diagonal Size
13.3 inch
Thickness
2.0 mm (max)
Interface
eDP 1.4 + PSR2 (2 lane)
Surface Treatment
Anti-Glare
Touch Enabled
No
Contrast Ratio
1200:1 (typ.)
Refresh Rate
60 Hz
Brightness
400 nits
Pixel Resolution
1920 x 1080 (FHD)
Format
RGB
Backlight
LED
Color Gamut Coverage
NTSC 72%
Color Depth
8 bits
Viewing Angle
UWVA 85/85/85/85
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 20
Panel LCD 13.3 inch HD
(1366x768) Anti-Glare
WLED SVA 45% NTSC
250nits eDP NWBZ
ultraslim
Outline Dimensions (W x H x D)
300.56 x 187.77 max. (w/ PCB & w/o bracket)
Active Area
293.83 x 165.20 typ
Weight
260g Max
Diagonal Size
13.3 inch
Thickness
3.0 mm max.
Interface
eDP 1.2 (1 lane)
Surface Treatment
Anti-Glare
Touch Enabled
No
Contrast Ratio
300:1 (typ)
Refresh Rate
60 Hz
Brightness
250 nits
Pixel Resolution
1366 x 768 (HD)
Format
RGB
Backlight
LED
Color Gamut Coverage
NTSC 45%
Color Depth
6 bits
Viewing Angle
SVA 45/45/15/35
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 21
STORAGE AND DRIVES*
*For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is
reserved for system recovery software.
SSD 128GB 2280 PCIe-3x2
Three Layer Cell
Form Factor
M.2 2280
Capacity
128 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe
Maximum Sequential Read
1400 ~ 2100 MB/s
Maximum Sequential Write
800 ~ 1200 MB/s
Logical Blocks
250,069,680
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; DIPM; TRIM; DEVSLP
SSD 1TB 2280 PCIe-3x4
NVMe Three Layer Cell
single-sided
Form Factor
M.2 2280
Capacity
1 TB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
3100 ~ 3500 MB/s
Maximum Sequential Write
2770 ~ 3037 MB/s
Logical Blocks
2,000,409,264
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; TRIM; L1.2
SSD 256GB 2280 PCIe NVMe
Value
Form Factor
M.2 2280
Capacity
256 GB
NAND Type
Value
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3
Maximum Sequential Read
2100 ~ 2200 MB/s
Maximum Sequential Write
900 ~ 1400 MB/s
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 22
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (optional); TRIM; L1.2
SSD 512GB 2280 PCIe NVMe
Value
Form Factor
M.2 2280
Capacity
512 GB
NAND Type
Value
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3
Maximum Sequential Read
2200 ~ 2300 MB/s
Maximum Sequential Write
1000 ~ 1600 MB/s
Logical Blocks
1,000,215,215
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (optional); TRIM; L1.2
SSD 512GB 2280 PCIe3x2x2 NVMe+SSD 32GB 3D
Xpoint
Form Factor
M.2 2280
Capacity
512 GB
NAND Type
QLC+3D XPoint
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X2X2
Maximum Sequential Read
Up to 2400 MB/s
Maximum Sequential Write
Up to 1300 MB/s
Logical Blocks
1,000,215,215
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; TRIM; L1.2
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 23
NETWORKING/COMMUNICATIONS
Intel Wi-Fi® 61 AX201 +
Bluetooth® 5 (802.11ax
2x2, non-vPro®,
supporting gigabit file
transfer speeds)5
non-vPro®
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11ax
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Features Wi-Fi®® 6 technology
Frequency Band
• 802.11b/g/n/ax
2.402 – 2.482 GHz
• 802.11a/n/ac/ax
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
• 802.11ax: MCS0 ~ MCS11, (1SS and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
Modulation
Direct Sequence Spread Spectrum
OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM, 1024QAM
Security
3
• IEEE compliant 64 / 128-bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• WPA3 certification
• IEEE 802.11i
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
2
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 24
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ac VHT160(5GHz): +11.5dBm minimum
• 802.11ax HT40(2.4GHz): +10dBm minimum
• 802.11ax VHT160(5GHz): +10dBm minimum
Power Consumption
• Transmit mode: 2.0 W
• Receive mode:1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode: 50 mW (WLAN unassociated)
• Connected Standby/Modern Standby: 10mW
• Radio disabled: 8 mW
Power Management
ACPI and PCI Express compliant power management 802.11 compliant
power saving mode
Receiver Sensitivity
3
• 802.11b, 1Mbps: -93.5dBm maximum
• 802.11b, 11Mbps: -84dBm maximum
• 802.11a/g, 6Mbps: -86dBm maximum
• 802.11a/g, 54Mbps: -72dBm maximum
• 802.11n, MCS07: -67dBm maximum
• 802.11n, MCS15: -64dBm maximum
• 802.11ac, MCS0: -84dBm maximum
• 802.11ac, MCS9: -59dBm maximum
• 802.11ax, MCS11(HT40): -59dBm maximum
• 802.11ax, MCS11(VHT160): -58.5dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard with CNVi Interface
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8 g
2. Type 126: 1.3 g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF
LED Off – Radio ON
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 25
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0/5.1 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0/5.1 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)
Signaling Data Rate
Legacy: 3 Mbps signaling data rate* 2.17 Mbps
BLE: 1 Mbps signaling data rate* 0.2 Mbps
* Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 9.5 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mWPeak (Rx) 230 mW
Selective Suspend 17 mW
Bluetooth Software
Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles
Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
1. Wireless access point and Internet service required and sold separately. Availability of public wireless access points
limited. The specifications for Wi-Fi® 6 (802.11ax WLAN) are draft specifications and are not final. If the final specifications
differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax WLAN
devices. Only available in countries where 802.11ax is supported.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 26
2. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
3. Check latest software/driver release for updates on supported security features.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%
for 802.11a/g (OFDM modulation).
5. Wi-Fi® supporting gigabit speeds is achievable when transferring files between two devices connected to the same router.
Requires a wireless router, sold separately, that supports 160MHz channels.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 27
Intel Jefferson Peak2
9560 802.11a/b/g/n/ac
(2x2) WiFi® and
Bluetooth® 5.0 Combo1
non-vPro®
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Wi-Fi®® CERTIFIED modules
Frequency Band
• 802.11b/g/n
2.402 – 2.482 GHz
• 802.11a/n/ac
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security
3
• IEEE and WiFi® compliant 64 / 128-bit WEP encryption for a/b/g mode
only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• WPA3 certification
• IEEE 802.11i
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
2
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 28
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ac VHT160(5GHz): +11.5dBm minimum
Power Consumption
• Transmit mode: 2.0 W
• Receive mode:1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode: 50 mW (WLAN unassociated)
• Connected Standby/Modern Standby: 10mW
• Radio disabled: 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
• 802.11b, 1Mbps: -93.5dBm maximum
• 802.11b, 11Mbps: -84dBm maximum
• 802.11a/g, 6Mbps: -86dBm maximum
• 802.11a/g, 54Mbps: -72dBm maximum
• 802.11n, MCS07: -67dBm maximum
• 802.11n, MCS15: -64dBm maximum
• 802.11ac, MCS0: -84dBm maximum
• 802.11ac, MCS9: -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard with CNVi Interface
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8 g
2. Type 126: 1.3 g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF
LED Off – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 29
Signaling Data Rate
Legacy: 3 Mbps signaling data rate* throughput up to 2.17 Mbps
BLE: 1 Mbps signaling data rate* throughput up to 0.2 Mbps
* Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mWPeak (Rx) 230 mW
Selective Suspend 17 mW
Bluetooth Software
Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles
Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
1. Wireless access point and internet service required and sold separately. Availability of public wireless access points
limited. Wi-Fi® 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi® 6 (802.11ax) are draft and are
not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to
communicate with other 802.11ax devices. Only available in countries where 802.11ax is supported. Wi-Fi®® supporting
gigabit speeds is achievable when transferring files between two devices connected to the same router. Requires a wireless
router, sold separately, that supports 160 MHz channels.
2. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
3. Check latest software/driver release for updates on supported security features.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%
for 802.11a/g (OFDM modulation).
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 30
Realtek RTL8822CE
802.11ac 2x2 Wi-Fi® +
Bluetooth® 5
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Wi-Fi®® CERTIFIED modules
Frequency Band
• 802.11b/g/n
2.402 – 2.482 GHz
• 802.11a/n/ac
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security
3
• IEEE and WiFi® compliant 64 / 128-bit WEP encryption for a/b/g mode
only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• WPA3 certification
• IEEE 802.11i
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power
2
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 31
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ac VHT160(5GHz): +11.5dBm minimum
Power Consumption
• Transmit mode: 2.0 W
• Receive mode:1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode: 50 mW (WLAN unassociated)
• Connected Standby/Modern Standby: 10mW
• Radio disabled: 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
4
• 802.11b, 1Mbps: -93.5dBm maximum
• 802.11b, 11Mbps: -84dBm maximum
• 802.11a/g, 6Mbps: -86dBm maximum
• 802.11a/g, 54Mbps: -72dBm maximum
• 802.11n, MCS07: -67dBm maximum
• 802.11n, MCS15: -64dBm maximum
• 802.11ac, MCS0: -84dBm maximum
• 802.11ac, MCS9: -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8 g
2. Type 126: 1.3 g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF
LED Off – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 32
Signaling Data Rate
Legacy: 3 Mbps signaling data rate* throughput up to2.17 Mbps
BLE: 1 Mbps signaling data rate* throughput up to 0.2 Mbps
* Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mWPeak (Rx) 230 mW
Selective Suspend 17 mW
Bluetooth Software
Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles
Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
1. Wireless access point and internet service required and sold separately. Availability of public wireless access points
limited. Wi-Fi® 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi® 6 (802.11ax) are draft and are
not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to
communicate with other 802.11ax devices. Only available in countries where 802.11ax is supported. Wi-Fi®® supporting
gigabit speeds is achievable when transferring files between two devices connected to the same router. Requires a wireless
router, sold separately, that supports 160 MHz channels.
2. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
3. Check latest software/driver release for updates on supported security features.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%
for 802.11a/g (OFDM modulation).
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 33
Realtek RTL8852AE
802.11ax1 2x2 Wi-Fi® +
Bluetooth®5.1 (802.11ax
2x2, supporting gigabit
data rate) 5
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11ax
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Wi-Fi® certified modules
Frequency Band
•802.11b/g/n/ax
2.402 – 2.482 GHz
•802.11a/n/ac/ax
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: max 300Mbps
• 802.11ac : max 866.7Mbps
• 802.11ax : max 1201Mbps
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM, 1024QAM
Security3
• IEEE and WiFi certified 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• WPA3 certification
• IEEE 802.11i
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b : +18.5dBm minimum
• 802.11g : +17.5dBm minimum
• 802.11a : +18.5dBm minimum
• 802.11n HT20(2.4GHz) : +15.5dBm minimum
• 802.11n HT40(2.4GHz) : +14.5dBm minimum
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 34
• 802.11n HT20(5GHz) : +15.5dBm minimum
• 802.11n HT40(5GHz) : +14.5dBm minimum
• 802.11ac VHT80(5GHz) : +11.5dBm minimum
• 802.11ax HE40(2.4GHz) : +10dBm minimum
• 802.11ax HE80(5GHz) : +10dBm minimum
Power Consumption
• Transmit mode :2.5 W
• Receive mode :2 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode :50 mW (WLAN unassociated)
• Connected Standby/Modern Standby: 10mW
• Radio disabled: 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity4
•802.11b, 1Mbps : -93.5dBm maximum
•802.11b, 11Mbps : -84dBm maximum
•802.11a/g, 6Mbps : -86dBm maximum
•802.11a/g, 54Mbps : -72dBm maximum
•802.11n, MCS07 : -67dBm maximum
•802.11n, MCS15 : -64dBm maximum
•802.11ac, MCS0 : -84dBm maximum
•802.11ac, MCS9 : -59dBm maximum
•802.11ax, MCS11(HE40): -57dBm maximum
•802.11ax, MCS11(HE80): -54dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8g
2. Type 126: 1.3g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF
LED Off – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0/5.1 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0/5.1 Compliant
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 35
Frequency Band
2402 to 2480 MHz
Number of Available
Channels
Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)
Data Rates and
Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx): 330 mW
Peak (Rx): 230 mW
Selective Suspend: 17 mW
Bluetooth Software
Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles
Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
BT5.1
ESR9/10 Compliance
LE Advertisement Extensions
Channel Selection Algo
Limited High Duty Cycle Non-Connectable Advertising
2Mbps LE
LE Long Range
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 36
1. Wireless access point and Internet service required and sold separately. Availability of public wireless access points
limited. The specifications for Wi-Fi® 6 (802.11ax WLAN) are draft specifications and are not final. If the final specifications
differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax WLAN
devices. Only available in countries where 802.11ax is supported.
2. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
3. Check latest software/driver release for updates on supported security features.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%
for 802.11a/g (OFDM modulation).
5. Wi-Fi® supporting gigabit speeds is achievable when transferring files between two devices connected to the same router.
Requires a wireless router, sold separately, that supports 160MHz channels.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 37
POWER
AC Adapter 45 Watt
nPFC Standard
USB Type-C® Straight
1.8m
Dimensions (H x W x D)
94.0mm x 40.0mm x 26.5mm
Weight
192.5g +/-10%
Input
Input Efficiency
Average Efficiency of 25%, 50%, 75%, 100%
load condition with 115Vac/230Vac Spec:
5V: 81.5%
9V: 86.7%
12V: 87.41%
15V: 87.8%
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
5V/15W
9V/27W
12V/36W
15V/45W
DC output
5V/9V/12V/15V
Hold-up time
5 ms at 115 Vac input
Connector
USB Type-C®
Environmental Design
Operating
temperature
32°F to 95°F (0° to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20° to 85°C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
AC Adapter 45 Watt Smart
nPFC Standard Barrel
4.5mm Right Angle 1.8m
Dimensions
95 x 45 x 26.8 mm
Weight
200 g +/- 10 g
Input
Input Efficiency
87.74 % at 115 Vac and 88.4 % at 230Vac
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.4 A at 90 Vac
Output
Output power
45 W
DC output
19.5 V
Hold-up time
5 ms at 115 Vac input
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 38
Output current limit
<8.0A
Connector
4.5mm Barrel Type
Environmental Design
Operating
temperature
32°F to 95°F (0°to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20°to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
AC Adapter 45 Watt Smart
nPFC Standard Barrel
4.5mm Right Angle 1.8m
2prong
Dimensions
95 x 45 x 26.8 mm
Weight
200 g +/- 10 g
Input
Input Efficiency
87.74 % at 115 Vac and 88.4 % at 230Vac
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.4 A at 90 VAC
Output
Output power
45 W
DC output
19.5 V
Hold-up time
5 ms at 115 Vac input
Output current limit
<8.0A
Connector
4.5mm Barrel Type
Environmental Design
Operating
temperature
32°F to 95°F (0°to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20°to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
Dimensions
90.0 x 51 x 28.5mm
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 39
AC Adapter 65 Watt nPFC
Standard USB type C®
Straight 1.8m
Weight
250 g +/- 10 g
Input
Input Efficiency
81.5% min at 115 Vac/ 230Vac @ 5V/3A
86.7% min at 115 Vac/ 230Vac @ 9V/3A
88% min at 115 Vac/ 230Vac @ 12V/5A
89% min at 115 Vac/ 230Vac @ 15V/4.33A
89% min at 115 Vac/ 230Vac @ 20V/3.25A
Input frequency range
47 ~ 63 Hz
Input AC current
1.6 A at 90 VAC and maximum load
Output
Output power
65 W
DC output
5V/9V/12V/15V/20V
Hold-up time
5 ms at 115 Vac input
Output current limit
8.0A Max.
Connector
USB Type C®
Environmental Design
Operating
temperature
32°F to 95°F (0°to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20°to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
AC Adapter 65 Watt Smart
nPFC EM Barrel 4.5mm
New EM
Dimensions (H x W x D)
102 x 55 x 30mm
Weight
250g +/-10%
Input
Input Efficiency
88.0 % at 115 Vac and 89.0 % at 230 Vac
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.7 A at 90 Vac
Output
Output power
65W
DC output
19.5V
Hold-up time
5 ms at 115 Vac input
Output current limit
<11.0A
Connector
4.5mm Barrel Type
Environmental Design
Operating
temperature
32°F to 95°F (0° to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20° to 85°C)
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 40
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
AC Adapter 65 Watt Smart
nPFC Standard Barrel
4.5mm Right Angle 1.8m
Dimensions (H x W x D)
90 x 51 x 28.5mm
Weight
230g +/-10%
Input
Input Efficiency
88.0 % at 115 Vac and 89.0 % at 230 Vac
Input frequency range
47 ~ 63 Hz
Input AC current
Max. 1.7 A at 90 Vac
Output
Output power
65W
DC output
19.5V
Hold-up time
5 ms at 115 Vac input
Output current limit
<11.0A
Connector
4.5mm Barrel Type
Environmental Design
Operating
temperature
32°F to 95°F (0° to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20° to 85°C)
Altitude
0 to 16,400 ft (0 to 5,000 m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
QuickSpecs
HP ProBook 430 G8 Notebook PC
Technical Specifications
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 41
Battery RH 3 Cell WHr 45
Long Life -PL Fast Charge
Dimensions (H x W x L)
6.2 x 68.7 x 249.6mm
Weight
190g
Cells/Type
3cell Lithium-Ion Polymer cell/ 545974
Voltage
11.4 V
Amp-hour capacity
3.950Ah
Watt-hour capacity
45 Wh
Operating (Charging)
32˚ to 113˚ F (0˚ to 45˚ C)
Operating (Discharging)
14˚ to 122˚ F (-10˚ to 60˚ C)
Optional Travel Battery
Available
No
Warranty
Based on system offering
Country of Origin
China
QuickSpecs
HP ProBook 430 G8 Notebook PC
Options and Accessories (sold separately and availability may vary by country)
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 42
Type
Description
Part Number
Cases
HP Business Backpack (up to 17.3")
2SC67AA
HP Business Slim Top Load (up to 14.1")
2SC65AA
HP Prelude Pro Recycle Backpack
1X644AA
HP Prelude Pro Recycle Top Load
1X645AA
HP Recycled Top Load
5KN29AA
HP Recycled Backpack
5KN28AA
Docking
HP USB-C® Mini Dock
1PM64AA
HP Thunderbolt Dock 120W G2
2UK37AA
HP TB Dock G2 w/ Combo Cable
3TR87AA
HP TB Dock 120W G2 w/Audio
3YE87AA
HP TB Dock 120W G2 Cable
3XB94AA
HP TB Dock G2 Combo Cable
3XB96AA
HP TB Dock G2 Audio Module
3AQ21AA
HP USB-C/A Universal Dock G2
5TW13AA
HP USB-C Dock G5
5TW10AA
Input/Output
HP USB Essential Keyboard and Mouse
H6L29AA
HP Wired Desktop 320MK Mouse & Keyboard
9SR36AA
HP Bluetooth Travel Mouse
6SP30AA
HP Comfort Grip Wireless Mouse
H2L63AA
HP Wired Desktop 320M Mouse
9VA80AA
HP USB Travel Mouse
G1K28AA
HP Elite USB-C Hub
4WX89AA
HP USB-C Travel Hub G2
7PJ38AA
HP USB-C to RJ45 Adapter
V7W66AA
HP USB-C to USB 3.0 Adapter
N2Z63AA
HP USB-C to HDMI 2.0 Adapter
1WC36AA
HP Stereo USB Headset
T1A67AA
HP Stereo 3.5mm Headset
T1A66AA
Power
HP 45W Smart AC Adapter 4.5mm
H6Y88AA
45W Smart Power Adapter 2 prong -4.5mm (Japan only)
L6F60AA
65W Smart Power Adapter (w/ 4.5mm to 7.5mm DC dongle)
H6Y89AA
HP 65W Slim AC Adapter
H6Y82AA
HP 65W USB-C Slim Power Adapter
3PN48AA
HP 45W LC USB-C Power Adapter
1MZ01AA
HP 65W USB-C LC Power Adapter
TBD
QuickSpecs
HP ProBook 430 G8 Notebook PC
Options and Accessories (sold separately and availability may vary by country)
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 43
HP Power Bank
N9F71AA
HP USB-C Notebook Power Bank
3TB55AA
Memory
HP 4GB DDR4 3200 Memory
HP 8GB DDR4 3200 Memory
HP 16GB DDR4 3200 Memory
286H5AA
286H8AA
286J1AA
Storage
HP External USB Optical Drive
F2B56AA
Security
HP Sure Key Cable Lock
6UW42AA
HP Nano Keyed Cable Lock
1AJ39AA
QuickSpecs
HP ProBook 430 G8 Notebook PC
Summary of Changes
Not all configuration components are available in all regions/countries.
c06907845 — DA16754 — Worldwide — Version 10 — April 29, 2021
Page 44
Date of change:
Version History:
Description of change:
December 14, 2020
V1 to V2
Update
USB Information
January 17, 2021
V2 to V3
Update
Environmental Data
January 21, 2021
V3 to V4
Added
WPA3 certification in Security, Networking section
January 26, 2021
V4 to V5
Added
New processors and USB Ports
February 2, 2021
V5 to V6
Update
Noise Emissions Data
February 25, 2021
V6 to V7
Update
Xerox DocuShare offer value
April 6, 2021
V7 to V8
Removed
Interchangeable HDD
April 20, 2021
V8 to V9
Updated
Memory Section Updated
April 29, 2021
V9 to V10
Added
Realtek WLAN/Updated TPM 2.0
Copyright © 2021 HP Development Company, L.P. The only warranties for HP products are set forth in the express limited
warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP
shall not be liable for technical or editorial errors or omissions contained herein.
Intel®, Core®, and Intel vPro® are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States
and other countries. Bluetooth is a trademark owned by its proprietor and used by HP Inc. under license. USB Type-C® and USB-C®
are trademarks of USB Implementers Forum. ENERGY STAR is a registered trademark of the U.S. Environmental Protection
Agency. Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the U.S. and/or other
countries.
Loading...
