Hp MEDICAL ARCHIVE SOLUTION User Guide

HP Medical Archive Solutions

User Guide

January 2007 (Third Edition)

Part Number T4434-96001

Confidential computer software. Valid license from HP required for possession, usr or copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor’s standard commercial license.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Bycast® and StorageGRID™ are trademarks of Bycast Inc. Their related marks, images, and symbols are the exclusive properties of Bycast Inc.

Microsoft, Windows, Windows XP and Windows NT are U.S. registered trademarks of Microsoft Corporation.

Adobe and Acrobat are trademarks of Adobe Systems Incorporated.

Linux is a U.S. registered trademark of Linus Torvalds.

UNIX is a registered trademark of The Open Group.

This product includes software developed by the OpenSSL Project for use in the Open SSL Toolkit. (http://www.openssl.org/)

HP Medical Archive Solutions

January 2007 (Third Edition) Part Number T4434-96001

Contents

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Currency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x

References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Document Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Using this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv

1 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . 1

Architecture Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Role of the Network Management System (NMS) . . . . . . . . . . 3

Network and Element Terminology . . . . . . . . . . . . . . . . . . . . . 3

Capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Accessing the NMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Security Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Enable Pop-ups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Log Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Managing User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Account Management Configuration . . . . . . . . . . . . . . . . . . . . 10

Editing Your Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2 Interface Components . . . . . . . . . . . . . . . . . . 13

Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Refresh Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

System Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Account Management Button . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Logout Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Version Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Navigation Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Tree Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

HP Medical Archive iii

HPMA User Guide

3 Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Content Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Tabs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Property Information (Overview) . . . . . . . . . . . . . . . . . . . . . . . 19

Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Navigating Locations and Nodes . . . . . . . . . . . . . . . . . . . . . . . 23

Location and Node Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

System Status Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

System Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Indicators and Propagation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Alarm Levels and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Alarms Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Main Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

History Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Alarm Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Tracing the Source of an Alarm . . . . . . . . . . . . . . . . . . . . . . . . . 36

Resolving Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

4 Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Introduction to Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Accessing Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Immediate Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Quick Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Custom Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Report Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Text Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Chart View Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Printing Charts and Reports . . . . . . . . . . . . . . . . . . . . . . . . . . 48

5 Services and Components . . . . . . . . . . . . . . . 51

Overview of Services and Components . . . . . . . . . . . . . . . . . . 52

Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Service Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Interpreting Attribute Description Tables . . . . . . . . . . . . . . . . 56

iv HP Medical Archive

ADC—Administrative Domain Controller . . . . . . . . . . . . . . . 59

ADC Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

ADC Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

AMS—Audit Management System . . . . . . . . . . . . . . . . . . . . . 65

AMS Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

AMS Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

CLB—Connection Load Balancer . . . . . . . . . . . . . . . . . . . . . . 71

CLB Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

CLB Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

CMN—Configuration Management Node . . . . . . . . . . . . . . . 80

CMN Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

CMN Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

CMS—Content Management System . . . . . . . . . . . . . . . . . . . 100

CMS Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

CMS Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

FSG—File System Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

FSG Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

FSG Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

LDR—Local Distribution Router . . . . . . . . . . . . . . . . . . . . . . . 123

LDR Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

LDR Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

NMS—Network Management System . . . . . . . . . . . . . . . . . . . 148

NMS Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

NMS Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

SSM—Server Status Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . 155

SSM Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

SSM Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

6 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 169

Introduction to Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 170

Alarm Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Configuration—Notification Page . . . . . . . . . . . . . . . . . . . . . . . 171

Active Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

Changing Alarm Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Service and Component Configuration . . . . . . . . . . . . . . . . . . 176

Configuration—Main Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

ADC Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

ADC Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

AMS Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

AMS Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

HP Medical Archive v

HPMA User Guide

7 Troubleshooting Alarms . . . . . . . . . . . . . . . . . 193

CLB Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

CLB Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

CMN Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

CMS Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

CMS Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

FSG Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

FSG Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

LDR Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

LDR Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

NMS Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

NMS Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

SSM Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

SSM Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Alarm Reference Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

8 Introduction to Server Manager . . . . . . . . . . 221

Overview of Server Manager . . . . . . . . . . . . . . . . . . . . . . . . . . 222

Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222

Capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

Architecture Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

The Core Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223

Automatic Startup and Shutdown . . . . . . . . . . . . . . . . . . . . . . . 224

9 Server Manager Operation . . . . . . . . . . . . . . . 225

Display Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226

Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226

Service List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

Control Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

Server Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

Prompt Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Using the Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Display Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Keyboard Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

vi HP Medical Archive

Command Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

Monitoring Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

Starting Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

Stopping Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231

Restarting the Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231

Shutting Down the Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

HP Medical Archive vii

HPMA User Guide

viii HP Medical Archive

Preface

Purpose

This guide is intended to familiarize you with operating the HP Medical Archive grid software. There are two software components covered by this document:

• Network Management System (NMS): the grid monitoring and

reporting interface

• Server Manager: used on all servers in the HP Medical Archive

Network Management System (NMS)

Once familiar with the NMS functionality, you can routinely refer to this guide for information about system attributes, appropriate alarm responses, and configuring components and alarm notifications. The various grid service components, their configuration, and alarms are documented. An alarm troubleshooting table is included for reference.

Currency

Server Manager

This guide covers the application interface, service monitoring functionality, an d applicat ion features. The objectives of this document are to enable you to use the Server Manager to:

• Monitor service operation

• Stop and start services on a node

• Restart a server

• Shutdown a server

Content of this guide is current with release 6.0 of the HP Medical Archive software.

HP Medical Archive ix T4434-96001

HPMA User Guide

Server Manager

This release uses the Server Manager software version 2.0. This version of the application does not report its version number.

Network Management System (NMS)

The content is current with the NMS software release version 3.2. To find the version number of your NMS software:

1. Within any page of the NMS interface (after login), click the HP

logo in the top left corner to open a dialog showing the version information.

2. Use your operating system’s window close button to close the

About dialog.

If you have an earlier version of NMS, contact HP technical support.

Intended Audience

The content of this guide is intended for storage grid administra tors, P ACS adminis trators, and technical s upport staff responsible for maintaining the HP Medical Archive system.

You are assumed to have a general understanding of the grid’s components and functionality. A fairly high level of computer literacy is assumed, including knowledge of file systems, tree-structured hierarchies, and network connectivity. You should also be familiar with using and navigating an Internet web browser.

x HP Medical Archive

T4434-96001

References

This document assumes familiarity with many terms related to computer operations and network administration. There is also a w ide use of acronyms. A glossary is included at the back of this guide (page 321).

Document Structure

PDF editions include bookmarks and hyperlinks to assist navigating the document.

Y ou may print copies of the PDF editions for internal use but all copies must be treated as proprietary and confidential; not for general distribution.

Preface

Using this Guide

This guide is comprised of nine chapters covering both general information and reference tables.

Readers new to the HP Medical Archive system should read the first four chapters to gain an understanding of how the NMS works to help you monitor the grid. The first two chapters introduce the basic functionality and interface layout of the NMS. The next two chapters explain NMS functionality for understanding alarm monitoring and notifications, and for obtaining reports.

The remaining chapters provide references to look up specific information. Chapters 5 and 6 provide reference information on services and components. Chapter 7 is the final chapter on the NMS; a reference of alarms with troubleshooting tips.

The last two chapters deal with the Server Manager application used on the HP Medical Archive cabinet console(s).

Chapters

Below is a brief overview of the content of each chapter. Chapter 1: “Getting Started”—Introducing the HP Medical Archive

architecture and the role of the Network Management System within

HP Medical Archive xi T4434-96001

HPMA User Guide

it. This also describes the procedures to access the NMS and manage user accounts.

Chapter 2: “Interface Components”—Describing the interface components, their use, and navigation.

Chapter 3: “Alarms”—Providing a conceptual overview of NMS alarms, their types and levels, and explaining how to display, trace, and respond to alarms. Use of the alarm history is also discussed.

Chapter 4: “Reports”—Explaining the report options and formats, how to generate and print reports, and customizing the report view for the data needed.

Chapter 5: “Services and Components”—Providing a detailed reference of services, their components, and attributes.

Chapter 6: “ Configuration”—Describing procedures for customizing the alarm notification settings, and other elements of system configuration.

Conventions

Chapter 7: “Troubleshooting Alarms”—Providing a detailed table for administrators to locate the appropriate response to an alarm, and better understand the alarms and attributes.

Chapter 8: “Introduction to Server Manager”—Describing the Server Manager application used on the console of each server in the grid.

Chapter 9: “Server Manager Operation”—Describing procedures for using the Server Manager to gracefully connect and disconnect grid nodes.

This guide adheres to conventions for terminology to avoid confusion or misunderstanding. There are also conventions for typography to enhance readability and usefulness of the text.

Terminology

There is some room for confusion between common computer network terminology for “server” and “node” as they are used in this document.

A server is usually thought of as a piece of computing hardware that provides data services to requesting network clients; a resource pro-

xii HP Medical Archive

T4434-96001

Preface

viding network, computational, and storage services. Within the context of the HP Medical Archive, a server is a piece of hardw are that hosts one or more grid services.

Nodes in a network are usually defined as an independent entity with a unique network identity, running on a resource. In this text, the use of the term “node” refers to the logical entity of a building block within the HP Medical Archive; it is a server combined with a predefined set of grid services that perform one or more tasks within the grid.

The term “node” also appears within the NMS interface. In that context, it generally refers to a single grid service, regardless of how many services may be hosted on the server. See “Network and Element Terminology” on page 3 for additional information.

Numerics

Numeric values are presented in decimal unless noted otherwise. Hexadecimal values in the text are noted using the prefix “0x”; for

example: 0x3B.

Fonts

T o assist y ou in easily picking out the elements of importance, changes from the standard font are used:

• Items upon which you act are shown in bold. These include:

• Sequences of selections from the navigation tree, tabs, and

page options, such as: CN1-A-1

• Buttons or keys to click or press, such as Apply or <Tab>.

• Radio buttons or check boxes to enable or disable, such as

Reset Validation Failure Counts.

• Field prompts, names of windows and dialogs, messages, and

other literal text in the interface is shown in sans-serif such as the LDR State pull-down menu, or the Sign In... window.

• Items within the narrative that require emphasis appear in italics.

X CMS X Reports X Chart.

Keyboard Input

Keyboard keys that use words or standard abbreviations are shown within angle brackets, such as <Ctrl> for the control key, <Tab>, <space>, and <Enter>. Where combinations are to be entered, they are

HP Medical Archive xiii T4434-96001

HPMA User Guide

noted as <Alt>+<F7>. Where key sequences are needed, they are noted without the plus “+”, for example: <space>Y<Enter>.

Instructions for keyboard entry come in three forms:

• “Enter” a command or value does not specify pressing <Enter> at

the end; pressing <Enter> at the end is assumed.

• “Type” a string or value explicitly includes any terminating

<Enter> or <Tab> keystroke. If one is not shown, do not assume

one.

• “Press” a key intends that only the specified key should be

pressed; do not also press the <Enter> key.

Color

Color plays a helpful role in identifying elements in the text. This guide is available in color in the PDF edition. The narrative does not assume that you are reading it in color.

Contacts

For general product and company information, refer to the HP web site at:

www.hp.com

If you cannot find the information that you need in this document, there are several other resour c es tha t you can use to get more detailed information.

• The HP website (http://www.hp.com)

• Your nearest HP authorized reseller (for the locations and tele-

phone numbers of these resellers refer to the HP website)

• HP technical support:

• In North America, call 1-800-652-6672.

• For other regions, refer to the HP website.

xiv HP Medical Archive

T4434-96001

Getting Started

NMS and the HP Medical Archive Architecture

Elements of the grid and capabilities of the Network Management System.

Chapter Contents

Architecture Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Network and Element Terminology. . . . . . . . . . . . . . . . . . . .3

Capabilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Software Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Accessing the NMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Log Out. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Managing User Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Account Management Configuration. . . . . . . . . . . . . . . . . .10

Editing Your Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

HP Medical Archive 1 T4434-96001

HPMA User Guide

Architecture Overview

The HP Medical Archive architecture provides a secure, reliable, and high performance solution for the storage and distribution of very high volumes of fixed content health care data within a data center and optionally a disaster recovery (DR) site.

The term “grid computing” is inspired by the success of the interconnection of the electric power and communication network infrastructure in the late 1800s and early 1900s.

The power grid manages the available power resources and balances loads to ensure continuous operation. How and where the power originates is transparent to the consumer. During peak hours, available resources are automatically balanced and power is rerouted to where it is needed most. As demand increases, additional generating resources come online, and they are transparently utilized. Similarly, when stations go offline or get decommissioned, there are no consumer service disruptions. The grid automatically balances the available resources to changing demand; loss of a subset of resources does not result in degraded service.

Grid computing is based on the principle that access to computational resources (storage, processing power, and data) can be enhanced with high levels of reliability and scalability, analogous to obtaining electric power from the power grid. Grid storage is the application of grid computing principles to storage architecture: directories, query, resource management, and fault management.

The HP Medical Archive system is composed of multiple nodes, which form a unified archive. Each node consists of software services operating on a server that manages a limited capacity storage resource.

Within a given facility, all nodes are interconnected using standard TCP/IP networking, and communicate with local imaging modalities, PACS, and workstations. Wi de Area Network (WAN) links extend the grid, enabling off-site replication of content for disaster recovery.

The HP Medical Archive deployment relies on open standards for interoperability with external hospital systems. Exchange of clinical data with external clinical systems, including PACS, viewing workstations, and modalities, takes place over standardized network file system protocols (NFS/CIFS) or (optionally) via established imaging protocols, including DICOM.

2 HP Medical Archive

T4434-96001

Role of the Network Management System (NMS)

The Network Management Syste m (NMS) performs two primary functions for HP Medical Archive deployments:

• It is a monitoring system that notifies administrators of problems

when the status of key hardware or software changes (including

via e-mail or mobile phone text message, if configured).

• It is a browser-based interface making the system easily available

to multiple users for:

• Reporting status information about the grid’s hardware and

software so you can monitor and resolve grid issues.

• Creating, viewing, and printing reports on current and historic

data about each grid component based on your selection of report criteria.

• Configuring grid components and customizing the notification

settings according to your criteria.

Getting Started

Network and Element Terminology

The Network Management System views the HP Medical Archive system as having tiers, or layers of detail. From the highest (big picture) to the lowest (most granular detail) the elements are:

• Locations

• Nodes

• Services

• Components

• Attributes

Locations

The location tier views the grid as being made up of geographically separate facilities or groups of nodes. The HP Medical Archive can be deployed as a Single Site (Site A) or Single Site + DR (Site A and Site B).

Nodes

Within the context of the HP Medical Archive system, a node is a server hosting a collection of one or more grid services. Physically, a server is a computer with associated storage and network resources. Logically, a node hosts services that the NMS can monitor and manage. (The NMS itself is a service that runs on one or more servers.)

HP Medical Archive 3 T4434-96001

HPMA User Guide

Services

A service is a software module providing a set of capabilities to the HP Medical Archive system. They are discussed in detail in Chapter 5.

Each service consists of components that deliver a particular capability. Each node of the grid has a predefined set of services that it hosts.

Services are typically identified by a three letter acronym.

Components

A component within a service delivers a particular capability. Each component has a set of configurable attributes that can be monitored automatically.

Services contain one or more components. Each component contains a set of attributes.

Capabilities

Components have names defined by the software.

Attributes

The most granular level of the system is an attribute. This is a single value or property of a component in a service. Attributes are the elements that are monitored for alarm states and may be included in reports.

Every component contains a set of attributes associated with the capability it enables.

For each service and component the NMS interface presents four tabs, one for each capability:

• Overview—property information about the service or component.

You can use this capability to trace alarms, generate immediate reports (page 43), and get an overall sense of a service or component’s performance.

• Alarms—showing the status of monitored attributes and reporting

alarm histories, enabling you to trace and troubleshoot current alarms and analyze alarm histories to prevent future problems.

• Reports—for generating reports on current and historical condi-

tions of attributes to monitor and improve system performance.

4 HP Medical Archive

T4434-96001

• Configuration—to set or change service settings or alarm monitor-

ing conditions. Consult the specific service descriptions in Chapter 5 for details of the

exact information and Chapter 6 for settings available.

Software Requirements

Accessing the NMS requires access to a web browser with grid access to a well-known address (defined by your system administrator).

At this time, the only supported browser is:

• Microsoft Internet Explorer v6.0 SP2 (and above)

• JavaScript and cookies must be enabled

To view the customized and dynamic graphics used by the NMS, you must also download and install:

• Adobe SVG Viewer plug-in

The plug-in is available from the Adobe web site:

www.adobe.com/svg/viewer/install/

Getting Started

This viewer supports Scalable Vector Graphic technology (SVG); a powerful tool used for high quality graphics that are dynamically created from real-time data.

Accessing the NMS

The Network Management System (NMS) can be accessed using a supported web browser (page 5).

Both the user name and password are case sensitive.

You require a user name and password to access the system. Each system user is assigned their user name and password when first introduced to the NMS. If you did not receive a user name and password, contact your system administrator. (See “Managing User Accounts” on page 8 for more information.) To connect to the NMS interface:

1. Launch the Internet Explorer browser.

2. Open the address: https://<IP_Address>:8443/NMS where

<IP_Address> is the address of the Admin Node.

HP Medical Archive 5 T4434-96001

HPMA User Guide

Security Certificate

Depending on your version of Windows and Internet Explorer, you may be prompted with a Security Alert dialog when you access the NMS URL.

If this appears, you can either:

• Click Yes to proceed with this session. The alert will appear again

the next time you access this URL.

• Click View Certificate and then Install the certificate using the

installation wizard so that you no longer receive the alert.

Log In

Once you have accessed the NMS via your browser, the HP Medical Archive log in... window appears.

Figure 1: NMS log in Window

To log into the NMS:

1. Click in the username field to place the cursor in the field.

2. Ty pe your username (case sensitive).

3. Press <Tab> to move the cursor to the password field.

4. Type your password (case sensitive). Keystrokes appear as aster-

isks (*) to protect your password.

6 HP Medical Archive

T4434-96001

5. Click the GO button to access the NMS interface.

If the username or password you entered could not be validated, the window shows an appropriate message in red (such as “Invalid user

name. Please enter a valid user name and password.”) below the

password field. Repeat the login process to correct your entry.

If you have forgotten your password, contact HP technical support to have your password reset.

Enable Pop-ups

To make any changes to passwords, you must ensure that Internet Explorer has the Pop-up Blocker turned off.:

Getting Started

Your grid map appears. See the next chapter for information on

using the interface.

Log Out

1. Select Tools

the Internet Explorer main menu to open the Pop-up Blocker

Settings dialog.

Note that the menu option is a toggle. If the blocker was already disabled, the menu option is to Turn on the Pop-up Blocker.

You are now able to use the NMS Account Management feature to change access passwords.

When you have finished your NMS session, be sure to log out to keep the system secure. The Logout arrow button is located under the

System Status icon at the top right corner of the screen.

X Pop-up Blocker X Turn off Pop-up Blocker from

HP Medical Archive 7 T4434-96001

HPMA User Guide

Figure 2: Location of the Logout Button

To log out:

1. Click on the Logout arrow button to log out.

The Network Management System log in... screen appears with the message “Logged out” displayed below the password field.

Figure 3: Successful Log Out Window

2. You may safely close the browser or continue using other

applications.

Failure to log out may permit other (unauthorized) users of the workstation to continue accessing your NMS session. Note that simply closing your browser is not sufficient to log out of the session.

Managing User Accounts

At the time of installation, default user and group accounts are configured for you. There is an account for system technical supp ort (Vendor) that has full permissions. The account for your use is the Admin user. These accounts cannot be deleted.

8 HP Medical Archive

T4434-96001

Getting Started

You may only alter the Password, First Name, and Last Name for your account.

To access the account management panel of the NMS:

1. Click on the Account Management button in the top

left of the Header frame (Figure 2 on page 8).

The Account Management tab appears in the Content frame. Using

the Admin account, only your own account and group appear.

Figure 4: Sample Account Management Tab

T o return to t he usual NMS content ta bs, select any item in the Navigation tree.

HP Medical Archive 9 T4434-96001

HPMA User Guide

Account Management Configuration

User accounts are configured to use a group account profile to control permissions within the NMS. Action buttons are used to make changes to account settings.

Table 1: Account Configuration Controls

Action Description

Edit the settings for the row. This enables the fields in the row to be edited. It also enables the Apply Changes button at the bottom of the page. Changes are not committed until the Apply Changes button is selected. The default HP Medical Archive accounts and groups cannot be deleted. Only the password, first, and last name can be edited.

Disabled for the Admin account.

Disabled for the HP Medical Archive default accounts.

The accounts and groups displayed indicate the profile of an account and the permissions that each profile supports.

Table 2: Account Management Attributes

Attribute Type / Units Description User Accounts

User Name Text The user name entered at login. Password Encrypted Masked password for the account; shown as a string of

asterisks. First Name Text User’s first name. Last Name Text User’s last na me. Language Enumerated

text

Status Enumerated

text

The default language to be used for this user.

The current status of the account:

Active—the user can log in and use the NMS Disabled—the user account is prevented from

logging in.

10 HP Medical Archive

T4434-96001

Getting Started

Table 2: Account Management Attributes (cont.)

Attribute Type / Units Description

Group Name Text Case sensitive reference to an entry defined in the

Group Accounts table. The profile governs the permitted activities for user accounts within this group.

Group Accounts

Group Name Text A case sensitive user defined profile name. This name

is referenced in the Group Name for a user account.

Group Description

NMS Check box Enables access to monitor the grid using the NMS. This

Configuration Check box Enables access to the Configuration tab Main page of

Accounts Check box Enables full access to the Account Management tab.

Text User-defined description; the intent of the user group

profile.

excludes access to some Configuration tab items.

the CMN service.

When deselected, the user can access the tab to:

• View only their own account settings

• Edit their password, first and last name

Editing Your Account

All users can access the settings for their own account. The action buttons for inserting a blank line and deleting a line are disabled. You can edit your entry to change the password, first, and last name.

1. Click the edit button on the line in the User Account table to

enable entry fields.

2. To change your password:

You may need to configure your browser to permit popups from this site.

HP Medical Archive 11 T4434-96001

a. Double-click the Password entry to select the complete field. b. Type a new password and press <Tab>. A popup window

appears to confirm the password:

HPMA User Guide

Figure 5: Password Confirmation Popup

c. Re-enter the password in the popup window. d. Click the Apply button in the popup window to confirm the

password and close the popup. If the password fails to match, a dialog appears advising you to re-enter the password (step 2a).

3. To change your real name: edit the First Name and Last Name

fields.

4. Click the Apply Changes button to commit the changes.

12 HP Medical Archive

T4434-96001

Interface Components

Navigating the NMS Interface

Chapter Contents

Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Header. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Refresh Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

System Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Logout Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Version Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Navigation Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Tree Structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Content Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Ta bs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Property Information (Overview). . . . . . . . . . . . . . . . . . . . .21

Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Navigating Locations and Nodes . . . . . . . . . . . . . . . . . . . . . . . .25

Location and Node Maps. . . . . . . . . . . . . . . . . . . . . . . . . . . .25

HP Medical Archive 15 T4434-96001

HPMA User Guide

Frames

The NMS interface is divided into three key sections or frames:

• Header

• Navigation Tree

• Content Frame

Every “page” of the NMS interface contains these three frames.

Header

Content Frame

Navigation Tree

Figure 7: NMS Interface—Frames

The Header frame of the NMS interface contains high-level grid status information. This frame is primarily used as a reference, providing a quick overview of the grid’s vital statistics as well as buttons to manage user accounts and log off of the NMS system.

The latest refresh date and time are shown on the far left along with the Account Management button. The right side contains the System Status icon and the Logout button. The Hewlett-Packard logo in the

16 HP Medical Archive

T4434-96001

Interface Components

top left serves as a button to access the HP Medical Archive Management Interface version information.

Refresh Time

Account Management Button

Refresh Time

Version Information (click logo)

Logout Button

Figure 8: NMS Interface—Header Frame

Information presented in the NMS interface is time-sensitive. Since the interface is delivered as HTML “pages”, the content shown is static. The “Updated” date and time indicates when the data shown was collected; the time at which the grid status “snapshot” was taken. The refresh information is very useful when addressing an alarm situation.

System Status Indicator

Local time is shown, as determined from the browser settings. If you change the time zone settings of your computer , the change is effectiv e the next time you log into the NMS interface.

Refreshing the Display

To take a new “snapshot” of the grid status:

• Select the update icon or the date and time text

—or—

• Select the “refresh” button on your browser (for Microsoft Internet

Explorer, press <F5>).

After the page has finished reloading, the content is updated and the update time reflects the time you took the snapshot.

HP Medical Archive 17 T4434-96001

HPMA User Guide

The interface automatically triggers a refresh at intervals of about one minute. Configuration pages that allow input do not automatically refresh, allowing you to complete your data entry without interruption.

System Status Indicator

The System Status icon indicates the highest level of alarm within the grid. If there are no alarms in the system, the icon displays a normal status (green) as seen in Figure 8 on page 17.

Select the icon to see the Grid Map current alarm states that are not “normal”.

See “Alarm Levels and Indicators” on page 33 for a description of the range of alarm indicators. Chapter 3 covers alarms in detail.

Account Management Button

The Account Management button is used to access the Account Management tab allowing you to access user account settings.

The Admin user can view their own account settings and make changes to their password and the settings for their first and last names.

Only the Vendor maintenance user has Account permission to:

• View all accounts

• Reset forgotten passwords

See “Managing User Accounts” on page 8 for more details.

Logout Button

X Alarms X Main page listing all

The Logout arrow button is used to log off of the NMS, ending your session. Be sure to log off the system every time you finish a session to protect the grid from unauthorized access. See “Log Out” on page 7 for more specific information.

Version Information

Clicking on the HP logo at the top left corner of the Header frame opens a dialog with the interface version number, the software build

18 HP Medical Archive

T4434-96001

date, and copyright information. See “Currency” on page ix for an example.

Navigation Tree

The Navigation Tree on the left side of the NMS interface displays a tree structure of the grid: the sites, cabinets, nodes, services, and components. This frame provides quick access to any element of th e grid.

Naming Conventions

The names that appear in the Navigation Tree follow the following convention:

• Locations:

• Site A—The primary site for the HP Medical Archive.

• Site B—An optional Disaster Recovery (DR) site.

• Cabinets:

• A-1 through A-10—Cabinets at the primary site.

• B-1 through B-10—Cabinets at an optional DR site.

• Nodes—Named using the following elements:

• Two or three-letter code for the type of node (such as: AN for

• A sequence number within the cabinet

• The cabinet identifier (such as B-1, A-3, and so on)

• Services—Named by the software with a three letter acronym,

such as ADC for an Administrative Domain Controller service.

• Components—Named by the software

Interface Components

Admin Node, GN for Gateway Node, or CSN for Control/ Storage Node)

Example: GN1-A-1 is the primary Gateway Node in cabinet A-1.

Tree Structure

By clicking on the +/- sign to the left of a name, you reveal/h ide the list of related grid elements on that branch. This enables progressive disclosure of grid elements while keeping the number of items listed more manageable.

HP Medical Archive 19 T4434-96001

HPMA User Guide

T o view detailed information about an element o f the grid, click on the element’s name. The information is displayed in the Content frame of the NMS interface.

Status Indicators

The icon beside each location, cabinet, node, and service reflects the overall status of that part of the grid. (Components do not include a status indicator; they retain their normal icon and color .) If there are no alarms, the icon appears in the normal (green) state. If there is an alarm, the icon reflects the most severe alarm currently active on that branch of the tree (see Table 3 on page 33).

Content Frames

Tabs

After using the Navigation Tr ee to select a grid element, you can use the Content frame to view and report on the component’s status, alarms, and configuration.

The Content frame of the NMS interface displays information on tabs appropriate to the element:

• Overview

• Alarms

• Reports

• Configuration

Figure 9: NMS Interface—Tabs

20 HP Medical Archive

T4434-96001

Interface Components

Some tabs do not apply to some elements. Only applicable tabs appear . Select the tab to view its contents.

Page Selectors

Some tabs organize information into “pages”. If so, a page selector appears below the selected tab. Select the page name to access that view.

Figure 10: NMS Interface—Page Selectors

The currently selected page is shown in blue, alternate page options are in black.

Property Information (Overview)

The Overview tab provides a list of service and component attributes with their values and (if notification is active) their current status. It includes attribute information specific to the service or component; consult the specific service descriptions in Chapter 5 for details of the exact information available.

HP Medical Archive 21 T4434-96001

HPMA User Guide

Figure 11: Sample Overview Page

Text Color

The display of attribute values normally appears black, indicating the service is running normally (reporting to the NMS). If the text appears

blue, the service is in an unknown state (not reporting to the NMS) and

the attribute values shown are the last known values. In cases where a service is gracefully removed from the grid (offline) the last known attribute values appear in gray italics.

Immediate Reports

Beside attributes that support chart style reports (“Charts” on page 46) there is an icon indicating the format of the chart available. Selecting the icon delivers the page with the Immediate report (“Immediate Reports” on page 43) for that attribute over the past hour.

Active Alarms

If an alarm status icon (Table 3 on page 33) appears beside the attribute’s name on the Overview page, alarm monitoring for that attribute is active (see “Enabling (or Disabling) an Alarm” on page 205). The attribute status can be viewed in more detail on the Alarms tab by clicking the icon.

22 HP Medical Archive

T4434-96001

Alarms

Interface Components

The Alarms tab provides information to trace the source of an alarm and to review an alarm’s history. This tab offers two pages of information.

• The Main page displays a table of the attributes actively being

monitored, showing their current state. Each row represents a monitored attribute and the color represents the alarm state. The table includes the attribute code, the description, and the alarm time of faults.

• The History page provides query functionality for attribute alarm

histories. Reviewing the alarm history is useful for preventing grid issues and for proactive grid maintenance. The query mechanism operates in the same fashion as custom reports (page 45).

See Chapter 3 for a full description of the alarm capability.

Reports

Configuration

The Reports tab starts with a form to create a quick report or custom query about a selected attribute. There are two kinds of reports available, chart and text, selected using the appropriate page option.

• The Chart page produces graphical data for the selected attribute.

• The Text page produces tables of data.

Both are useful tools for analyzing the system and for troubleshooting alarms. See Chapter 4 for a full des cription.

The Configuration tab offers two pages for configuring the main properties of the service or component, and for setting the alarm monitoring features.

HP Medical Archive 23 T4434-96001

HPMA User Guide

Some configuration items are not accessible to the Admin account. These can only be changed using the Vendor account.

• The Main page form allows you to change the state, label, and

notes related to an attribute.

WARNING

Changing configuration settings requires careful and deliberate planning. Some configurable elements can affect the state of your live system. Only experienced administrators should alter the device and component configuration settings.

CAUTION

Changes to the configuration are rarely needed, and should only be undertaken after consultation with HP technical support.

• The Notification page is used to change the notification details for

an attribute, as well as activating and deactivating alarms. This page gives you the ability to customize alarm settings to your specific grid needs.

CAUTION

Alarm settings are enabled as part of your i nstalla tion. Changes to alarm settings should not be made for simple convenience; this may conceal underlying problems that should be resolved. If you find an alarm is persistent, discuss the situation with HP technical support before making changes.

Configuration of alarm notifications is discussed in “Alarm Configuration” on page 201 and changes to the main configuration of services and components is discussed in Chapter 6 for each service.

24 HP Medical Archive

T4434-96001

Navigating Locations and Nodes

Once you have logged on to the NMS, the first displayed content is a Scalable Vector Graphic (SVG) indicating two sites. Icons indicate the actual installation of Site A and Site B. As you navigate to a site, the map shows a set of cabinets (the possible maximum of eight); again, icons above the cabinets indicate the actual installation of y our grid. At the cabinet level, a fully installed cabinet is schematically illustrated with icons beside the nodes actually installed. For a given node, a schematic image appears with icons for each service installed. Samples are shown in the following subsections.

Location and Node Maps

The grid’s geographic locations (the primary site and optional DR site) are illustrated on the map with a status icon representing actual installation. The color of the icon gives you an immediate indication of the location’s alarm state.

Interface Components

Figure 12: NMS Interface—Sample Grid Map of Locations

Clicking on an icon displays the next level (the individual location). At this level, there are eight cabinets illustrated, the maximum possible

in a single site deployment of the HP Medical Archive. (If a DR site is used, the maximum at either site is four cabinets, howe ver the illustration shows the maximum of eight.) Only installed cabinets have an icon above them.

HP Medical Archive 25 T4434-96001

HPMA User Guide

Figure 13: NMS Interface—Sample Site Map of Cabinets

Selecting a cabinet displays the map with node icons positioned where the hardware is physically located in a fully populated cabinet. The node icons appear beside the nodes that are installed in your grid. The icon reflects the alarm status of each node. The names are defined by the software as described in “Naming Conventions” on page 19.

Figure 14: NMS Interface—Sample Location Map of Nodes

Every grid node typically has multiple services that are individually monitored. Clicking on the node’s name displays a generic SVG map of a server with icons for the services it host s. Each service h as its own status icon appropriately colored to represent its alarm status.

26 HP Medical Archive

T4434-96001

Interface Components

Figure 15: NMS Interface—Sample Server Map of Services

As with locations, cabinets, and nodes, you can select a service to reveal status information in the Content frame. The service/component content is more detailed. The grid map, locations, and grid nodes content displays only the Overview tab with its illustrative map. The Content frame for services and components displays the four tabs: Overview, Alarms, Reports, and Configuration discussed in “Tabs” on page 20. Click a tab to display the related content and selection forms.

HP Medical Archive 27 T4434-96001

HPMA User Guide

28 HP Medical Archive

T4434-96001

Alarms

System Status and Notifications

Chapter Contents

System Status Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

System Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Notifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Indicators and Propagation . . . . . . . . . . . . . . . . . . . . . . . . . .32

Alarm Levels and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Alarms Ta b . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Main Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

History Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Alarm Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Tracing the Source of an Alarm. . . . . . . . . . . . . . . . . . . . . . .38

Resolving Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

HP Medical Archive 29 T4434-96001

HPMA User Guide

System Status Overview

The Network Management System provides useful day-to-day information on the status of your grid. When a component of your grid is not performing within expectations however, the NMS becomes a critical assessment tool. Alarm indicators draw immediate attention to grid issues.

The NMS uses color-coding and icons for easy identification of alarm locations and levels. When you first view the NMS interface, the System Statu s icon (in the upper right corner of the page) indicates the highest alarm level on the system. You can then use the NMS tree or maps to locate the specific grid problem, assess the cause, and take quick action toward a resolution.

System Monitoring

A primary role of the NMS is to monitor grid activity and issue alarms if any attributes reach or exceed user-defined thresholds. When a tested alarm level evaluates true, that level is set.

There are six levels of alarm for each attribute; each uniquely identified (by an ID number) and individually configured. As new services are added to the grid, new alarm attribute IDs are created for it, ensuring that each alarm is uniquely associated with a specific service or component attribute and alarm level.

Each monitored attribute of each service and component is tested against the configured thresholds using the algorithm shown in Figure 15.

The attribute value is tested against each enabled setting starting from the most critical and working toward normal. The “Unknown” setting is the last one tested.

30 HP Medical Archive

T4434-96001

Alarms

When an alarm condition is found to be true, that level is checked against the current alarm level for the attribute. If there is no change, then no further action is taken.

Figure 15: Alarm Monitoring Algorithm

Only if a new alarm level is detected is there a change in the alarm level reported. This automatically clears alarms when conditions return to the “Normal” level.

If an alarm level changes, the current alarm level is set and propagated up the network hierarchy as needed. If there is a notification e-mail address, then a brief text notification is sent. The notification is sent only at the time the alarm state enters the new level.

Notifications

Administrators can be notified if an alarm reaches a level of urgent concern. All alarms provide indicators for informational purposes that you can check on a routine basis. Urgent ones can also be configured to

HP Medical Archive 31 T4434-96001

HPMA User Guide

issue a text notification to the user-specified e-mail addresses (possibly routed to a pager or mobile phone) of system administration staff.

The NMS is pre-configured with a default set of alarms and notification settings. You can easily customize these settings to reflect your company’s network monitoring methodology.

For information on how to customize the alarm notification settings, see “Alarm Configuration” on page 201.

CAUTION

Indicators and Propagation

Alarms are generated at the attribute level of the grid. When an issue is detected, the alarm is propagated up through the grid hierarchy. The associated attribute, component, service, and node information on the NMS are all changed to reflect the alarm state. As a result, you can view the general alarm state at the grid level, then drill down through the service components to locate the specific details. (See Figure 16: “Sample Alarm Indicator Propagation” on page 34.)

Each individual service reflects the highest alarm state of its components. If more than one alarm exists on a node, the node always reflects the highest and most serious alarm level (see “Alarm Levels and Indicators” below). Locations (Site A and Site B) display the highest alarm level of the nodes on that branch.

Refer to Figure 16 on page 34 for an example. One node’s SSM indicates a minor alarm state while its LDR indicates an unknown state. That node icon displays the unknown alarm state (the higher alarm level). Another node in the same group shows a major alarm on the AMS service. The group location propagates the “unknown” alarm indicator. The color and icon of each service, node, and location reflects its highest alarm state along its branch of the Navigation Tree.

32 HP Medical Archive

T4434-96001

Alarm Levels and Indicators

NMS alarms are organized into a hierarchy of levels. The hierarchy reflects the seriousness of a grid issue. There are six alarm levels in the NMS interface. Each alarm level has an associated color and icon. The NMS alarms levels (from lowest to highest) are:

Table 3: Alarm Levels and Indicators

Icon Color Level Meaning

Green Normal All functions are working normally. Yellow Notice An unusual condition exists that does not affect

normal operation; most likely related to a component being in a standby state.

Alarms

Light Orange

Dark Orange

Red Critical A critical alert of an abnormal condition that has

Blue Unknown /

Minor Alert An abnormal condition exists that could affect opera-

tion in the future; should be investigated to prevent escalation.

Major Alert An abnormal condition exists that is currently affecting

operation; requires prompt attention to prevent escalation.

stopped normal operation; should be addressed immediately.

An unknown condition exists that has stopped normal

Offline

The “Unknown” alarm level is considered the most severe if it is enabled and detected, although it is the last level tested in the alarm monitoring algorithm (Figure 15 on page 31). Most attributes do not enable this level. It is typically used to indicate loss of connection between the NMS and a service.

Each alarm level has it s own icon and color. These icons and colors are used throughout the NMS interface to save you time when analyzing a critical grid situation. Alarm colors and icons accelerate alarm identification and resolution by making the alarm source quickly visible on the NMS interface. The System Sta tus icon in the Header frame immediately indicates the most serious alarm level of the grid. The icons on the Network Map indicate the status of each location or node. You can then follow the tree branch to the individual service to find the source of the alarm.

operation. Requires immediate attention.

HP Medical Archive 33 T4434-96001

HPMA User Guide

Nodes display the alarm icon of the highest alarm state among their hosted services (Figure 16). Note that each service retains its unique icon, but the color changes to reflect its current alarm state. Component icons and colors, however, remain unchanged regardless of the alarm state.

Figure 16: Sample Alarm Indicator Propagation

Alarms Tab

Under the Alarms tab of each service or component, colors highlight critical alarm information (Figure 17). By default, the table rows are green to indicate a normal status. If the status of an attribute changes, an alarm row for that attribute changes to the appropriate color (Table 3 on page 33).

34 HP Medical Archive

T4434-96001

Alarms

Figure 17: Sample Alarms Tab

Each row provides detailed information about the alarm (see Table 4 on page 36 for details). More detailed information about each attribute’s code, value, and definition can be found in Chapter 7, “Troubleshooting Alarms” on page 247.

Main Page

Once the alarm is resolved, the alarm returns to the green status to indicate that the attribute has returned to a normal state.

You can access and view alarm status at both the service and the component levels. There are two pages under the Alarms tab: Main and History. When the tab is selected, it defaults to the Main page, which provides details of the current status.

The Main page of the Alarms tab gives the current status of the selected service or component attributes. This page is an overview of each attribute’s current alarm level. You can use this page to get a quick, but detailed, sense of what may be causing a system alarm. The Main page can also be used to track the daily status of the system in order to prevent major alarms.

HP Medical Archive 35 T4434-96001

HPMA User Guide

Figure 18: Sample Component Alarms Tab—Main Page

The alarm data is listed in a table with the following headings:

Table 4: Alarm Table Headings

Heading Definition

Severity Color icon indicating alarm level (see T able 3 on

page 33)

Attribute Code Code that identifies the attribute and issue

being monitored (see Chapter 7 for an alphabetical lookup table)

History Page

CId “Cell ID”, a secondary identifier used when a

monitored attribute is a cell in a table, such as the Status attribute of the SSM

X Volumes

component (VMST). The CId indicates the cor- responding row in the attribute table.

Node ID Unique number identifying the service within

the grid. This number is assigned at installation.

Description Brief details about the cause of the alarm; con-

sisting of the Primary Message and Secondary

Message in the alarm configuration.

Alarm Time Date and time stamp (in your local time zone)

of the last attribute report from the service or component.

Current Value Value of the attribute as last reported by the

service or component.

The History page enables you to perform queries on the history of an attribute. Alarm history provides perspective on whether an attribute

36 HP Medical Archive

T4434-96001

Alarms

has been triggering frequent alarms. These statistics allow you to address deeper grid issues and prevent future alarms.

Figure 19: Sample Alarm History Request Form

You can perform a quick or a custom query (the same selection mechanism as standard reports). Quick queries generate results for a predefined time range with the click of a single button. Custom queries provide data based on your specified time and date requirements. For more information on performing queries, see page 43.

The generated data displays in a table with the same headings shown on the Main page (see Table 4 on page 36). This data is listed sequentially based on the time of an alarm’s change in state. The most recent change is listed first.

Figure 20: Sample Alarm History Report

HP Medical Archive 37 T4434-96001

HPMA User Guide

To return to the history request form from an alarm history table, click the History page selector.

Analyzing Alarm Histories

Queries on the alarm history page provide valuable analytical information. You can query for data about a specific attribute or for all of the alarms that have occurred on a node over a specified period of time.

These queries are a powerful grid diagnostic tool, enabling you to identify alarm patterns and service issues. Regularly reviewing alarm patterns can resolve minor issues before they impact grid functionality. At the very least, reviewing the alarm history gives an overview of how the system is functioning and may help to prevent future alarms.

Alarm Handling

The NMS is a critical tool for responding to system alarms. When you receive an alarm notification, the NMS provides the data necessary to resolve the issue. This section provides step-by-step procedures for investigating, evaluating, and responding to alarms.

Tracing the Source of an Alarm

Tracing an alarm follows these main steps (each is expanded later in the text):

1. Trace through the network tree to the specific node generating the

alarm.

2. Use the information from the Alarms table to identify the compo-

nent and attribute causing the alarm.

3. Troubleshoot the alarm by using the lookup table in Chapter 7,

“Troubleshooting Alarms” on page 247.

1. Locate the Source of an Alarm

a. Log in to the NMS to display the Network Map. Use the icons

and color codes (Table 3 on page 33) to determine which

location has triggered the alarm.

38 HP Medical Archive

T4434-96001

Alarms

b. Select the Site that is displaying the alarm icon to view the

cabinet icons for that location. Use the icons and color codes to determine which cabinet has triggered the alarm.

c. Select the cabinet that is displaying the alarm icon to view the

node icons for that cabinet.

d. Select the node with the alarm icon to view the service icons

for that node. Use the color codes to determine which service has triggered the alarm.

e. Select the service with the alarm color to access the service’s

Overview page.

f. Select the Alarms

X Main page to view the summary table of

monitored attributes for the service and its components. Locate the row in the table highlighted in the alarm color. Note down the following information:

• Attribute Code—the four-letter identifier for the alarm type

• Description—the message explaining the alarm

2. Identify the Component and Attribute

a. Using the Description from step 1, determine if the alarm is

b. Select the Configuration

c. Find the rows with the Attribute Code noted in step 1. above.

d. Determine the specific condition for the alarm from the settings

3. Troubleshoot the Alarm

a. Look up the four-character Attribute Code from step 1 in the

b. Follow the suggested actions for the attribute.

Resolving Alarms

Most alarm conditions are temporary situations of grid load and resolve themselves over time. Always consult Chapter 7 for troubleshooting advice. For persistent alarms, contact HP technical support after following the suggested actions.

associated with a specific component. Select the component to view its Alarms

X Main page to find the alarm.

X Notification page to view the list of

monitored attributes for that service or component.

in that row.

“Alarm Reference Table” on page 248.

HP Medical Archive 39 T4434-96001

HPMA User Guide

Clearing Alarms

Alarm states are self-correcting when the attribute value for an alarm returns to normal. Once a grid issue has been resolved, the alarm details can be viewed under the Alarms You can perform queries to retrieve data for preventive analysis.

Alarms related to counted events, such as HTTP sessions failed, can often be reset using a check box on the component’s Configuration Main page. See Chapter 6.

X History page (see page 36).

40 HP Medical Archive

T4434-96001

Reports

Current and History Reporting

Create, view, and print reports on system attributes and status alarm histories.

Chapter Contents

Introduction to Reporting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Accessing Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Immediate Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Quick Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Custom Reports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Report Formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Text Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Chart View Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Printing Charts and Reports. . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

HP Medical Archive 41 T4434-96001

HPMA User Guide

Introduction to Reporting

Reports are a powerful system analysis and troubleshooting tool. The NMS can generate reports at both the service and the component level, although some individual attributes do not have reportable events. These reports provide an overview of how a system attribut e is functioning over a selected period of time. By viewing a report, you can quickly ascertain if the attribute has any issues.

Reports are also valuable to track the data flow on the grid. You can view how much data enters the grid each day, how many audit messages are being sent, and whether the data storage capacity is sufficient. You always know the state of resources on your grid.

The NMS provides a variety of report query options and displays. You generate reports with the simple click of a button or by requesting a custom report according to specific time spans. The generated report can be displayed in a graphical chart or a text table. You can then print the final report, or copy it for use in documents.

Report Types

The NMS provides three different way s to gener ate report s:

• Immediate—generated by the click of a button on the Overview

page.

• Quick—created through preset criteria selections on the Reports

page.

• Custom—a form on the Reports page enables you to specify your

requirements, providing feedback specifically customized to your needs.

Charts and Text Reports

Reports take one of two forms: chart or text. Charts present the data in a graphical view. Text reports are a simple text table with row entries for each event that an attribute reported. Both types are described in greater detail later in this chapter.

The format is determined by the page from which you select the report. Immediate reports are always charts, selected from the

Overview page. Quick and Custom reports are available from both the Reports

X Chart and Reports X Text pages.

42 HP Medical Archive

T4434-96001

Accessing Reports

Reports are accessed in one of two ways:

• Immediate reports are accessed by clicking the chart icon on the

Overview tab for the service or component.

• Quick and Customized reports are accessed from a form on the

Reports tab under either the Chart page or the Text page. Under the Reports tab, each service and component has select

attributes for which reports can be generated. Individual service details in Chapter 5 indicate whether attributes are reportable. In some cases, the attributes available under the chart and the text pages differ.

Immediate Reports

Immediate reports are available on the Overview page for reportable attributes, indicated by a chart butt on at the right side of the page.

Reports

Figure 21: Sample Immediate Report Buttons

The button graphic reflects the type of graph that is presented. The graph style is preconfigured to best present the attribute’s data.

Table 5: Immediate Report Buttons

Button Report Type Presentation

Level Bar graph

Bar Bar graph

State Line graph

When a button is selected, a chart report is generated and the NMS view changes to the Reports tab.

HP Medical Archive 43 T4434-96001

HPMA User Guide

Quick Reports

To generate an immediate report:

1. Navigate to the service or component you want to report on. The

item’s Overview page appears.

2. Scroll to the attribute you w ant to chart. If reports can be generated

for the attribute, the appropriate report button is available at the far right of the attribute’s row.

3. Click on the report button. The Reports page appears and the

requested chart is displayed.

The report displays the attribute’s data over the past hour, a preset time span. To view other time ranges, or to see a wider (zoom out) or narrow (zoom in) range of time use either the Quick Reports or the custom report form.

Quick reports are available on the Reports tab, from both the Chart and Text pages.

There are six options specifying the time span for the report, ranging from the last 5 minutes to the last year. Quick reports can be generated with the selection of an attribute and then the push of a time span button.

Figure 22: Report Request Form—Quick Reports

To generate a quick report:

1. Navigate to the service or component you want to report on. The

item’s Overview page appears.

2. Select the Reports tab. The Charts page appears by default.

44 HP Medical Archive

T4434-96001

3. Optionally deselect the Vertical Scaling check box to force the Y-

4. Use the Attribute pull-down menu to select the attribute to report.

5. Select the Quick Query button for the desired duration of the

Although the Content frame may update fairly quickly, charts can take some time to tabulate and form the image. Allow several minutes for tabulation of long time ranges.

Custom Reports

Reports

axis to start at zero. This option is selected by default, allowing the

Y-axis to cover a range that best fits the data.

—or—

Optionally select the Text page to obtain a text format report.

report. The report appears after a few moments.

Custom reports present in the same way as quick reports but add the ability to customize the time span of the data (down to the second) to be displayed. Both Chart and Text pages support custom reports.

Figure 23: Report Request Form—Custom Reports

To generate a custom report:

1. Navigate to the service or component you want to report on. The

item’s Overview page appears.

2. Select the Reports tab. The Charts page appears by default.

3. Optionally deselect the Vertical Scaling check box to force the Y-

axis to start at zero. This option is selected by default, allowing the

Y-axis to cover a range that best fits the data.

—or—

Optionally select the Text page to obtain a text format report.

4. Use the Attribute pull-down menu to select the attribute to report.

HP Medical Archive 45 T4434-96001

HPMA User Guide

5. In the Custom Query panel, enter the Start Date and End Date for

your report, using values for your local time zone. Use the format YYYY/MM/DD HH:MM:SS for both entries. Leading zeros are required to match the format. For example, 2005/4/8 7:30:00 fails validation; the correct equivalent is 2005/04/08 07:30:00.

6. Select the Custom Query button to generate and display the

report. The report appears after a few moments.

CAUTION

Allow several minutes for charts to appear. Although the Content frame may update fairly quickly, charts can take several minutes to tabulate and form the image. Do not initiate another report request until the current one has completed.

To view other time ranges, or to see a wider (zoom out) or narrow (zoom in) range of time, modify the start and end dates in the custom report form.

Report Formats

Chart and text reports present essentially the same data in very different ways. You can use each report format to suit your specific reporting needs. Chart reports give a graphical presentation of data. T ext reports give th e basic data in a simple table with no customization options after the report has been created.

Charts

Chart reports present the data with the attribute values (vertical axis) over a specified time span (horizontal axis). The types of chart reports available are detailed below. If the numbers in the chart represent a volume portion (such as the percentage of memory being used), the area under bars is shaded. If the numbers represent exact values (such as the number of system restarts), the bars appear as a simple line with no shading.

Data for a given period may appear slightly different on charts that cover different time ranges. For example, the charted values shown in the last hour may differ when included in a chart of the last day. This is

46 HP Medical Archive

T4434-96001

Reports

an artifact of the data downsampling and “binning” that is performed prior to charting large volumes of data. These differences are normal.

If you require precise results, you can obtain the unprocessed values by using a text report. Note that text reports do not list any data during periods when the attribute was either unavailable or was unreported (indeterminate). Charts use white space or light purple shadi ng respectively to indicate these periods.

Interpreting Lines and Shading

Charts use color and shading to convey specific informat ion about th e graph.

Table 6: Chart Colors and Shading

Sample Meaning

Reported attribute values are plotted using dark green lines.

Light green shading around dark green lines indicates that the actual values in that time range vary and have been “binned” together for faster plotting. The range in light green indicates the maximum and minimum values within the “bin”. Light brown shading is used for bar graphs to indicate volumetric data.

Light purple shading indicates that the attribute value at that time was indeterminate; the attribute wa s not reporting.

Blank areas (white, no data plotted) indicate that the attribute was unavailable. The service or component was known to be offline, so no data exists for that time range.

HP Medical Archive 47 T4434-96001

HPMA User Guide

Level Graph

Level graphs are used to plot the values of an attribute that has a “unit” value (such as Local Clock Rate Error, in ppm). The changes in the value are plotted in “bins” at regular intervals over time.

Bar Graph

Bar (area) graphs are similar to level graphs but include a light brown shading below the line. These are used to plot the values of an attribute that has a “quantity” value (such as Service Load, a percentage). The changes in the value are plotted in “bins” at regular interv als over time.

48 HP Medical Archive

T4434-96001

Reports

State Graph

State graphs are similar to level grap hs but the trans itio n is discontinuous; that is, the value jumps from one state (value) to another. These are used to plot values that represent distinct states (such as a service State, that can be online, standby, or offline). The changes in the value appear as distinct horizontal lines at predefined levels on the chart.

Text Reports

Text reports present the data in a simple table with the date and time in the first column and the attribute values in the second column. They give the basic data in a simple format without any of the additional overview information provided in a chart report.

Figure 24: Sample Text Report

The Date column lists the local date and time of attribute reports. The Value column displays the attribute’s value for each report.

This detailed breakdown of data can result in very long tables. Text reports are therefore better suited to shorter, more specific time spans.

HP Medical Archive 49 T4434-96001

HPMA User Guide

Text reports support some attributes—such as changes to text attributes—that are not available in chart form.

Chart View Controls

When you generate a chart report, it may be useful to compare the results with another chart. The NMS provides the ability to view the data in a new window; to hold it while using the main interface to select other reports or views.

To see other time ranges of data, use the custom report form to select the desired range. Narrowing the time span “zooms” in on the data for detailed analysis.

Window

To capture the current view for comparison with other chart views, you can place the chart in a new window (kiosk). You may open as many of these kiosk views as you wish.

Opens a new window and displays the current view.

When you are done, use your operating system’s window close button to close these chart windows.

Printing Charts and Reports

Reports of any type can be printed—as can an y other page of the NMS interface—by using the print function of your browser.

Using Microsoft

1. Create the desired report (or other content page).

2. Right-click in the Content frame to access the context menu.

Note that where you right-click determines the context menu you get. Right-clicking in the title area of the Content frame yields the menu shown at left; over the chart yields the menu on the right.

Internet Explorer:

50 HP Medical Archive

T4434-96001

Reports

Figure 25: Browser Context Menus

3. Select either Print or Print Picture... from the context menu to

open the Print dialog.

4. Use the dialog to make appropriate selections for your needs.

Depending on the context menu used, the Options tab in the dialog

may offer you the selection to print Only the selected frame. This

is the recommended option. See “Print Options” below for a more

detailed discussion.

5. Select Print to send the page to your printer.

Print Options

When printing a chart frame, there are two possible outcomes:

• Printing from the frame context menu; printing only the selected

frame yields a page with:

• Content frame heading (service, component, and icon)

• The chart itself with its title

• Chart window button

• Printing from the image context menu drops the Content frame

heading and chart window button, yielding only the chart itself

along with its title.

• Printing from a new window ( ) using the image context menu

yields the Content frame heading (service, component and icon)

and the chart (with its title). Text reports print as normal web pages with: the Content frame title,

the table title, and the table data.

HP Medical Archive 51 T4434-96001

HPMA User Guide

52 HP Medical Archive

T4434-96001

Services and Components

Reference information on service and component attributes.

Chapter Contents

Overview of Services and Components . . . . . . . . . . . . . . . . . . .54

Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Service Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

Interpreting Attribute Description Tables . . . . . . . . . . . . . .58

ADC—Administrative Domain Controller . . . . . . . . . . . . . . . .61

AMS—Audit Management System. . . . . . . . . . . . . . . . . . . . . . .67

CLB—Connection Load Balancer . . . . . . . . . . . . . . . . . . . . . . . .73

CMN—Configuration Management Node . . . . . . . . . . . . . . . .82

CMS—Content Management System . . . . . . . . . . . . . . . . . . . .102

FSG—File System Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . .111

LDR—Local Distribution Router. . . . . . . . . . . . . . . . . . . . . . . . 125

NMS—Network Management System. . . . . . . . . . . . . . . . . . .150

SSM—Server Status Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . .157

HP Medical Archive 53 T4434-96001

HPMA User Guide

Overview of Services and Components

The NMS categorizes system information by the services a nd se rvice components found on each node. These services and components contain attributes that form the basis for the NMS alarm notification and report options.

This chapter provides a complete list of NMS services and components. Services are listed alphabetically.

Not all grids use every service and component listed here. Each grid uses only those services and components suited to the options purchased and the functionality required.

Services

Grid services are programs that run on the physical servers (nodes). Each delivers particular services to the grid as shown in Table 7. The NMS is used to access the critical information gathered by these services so that you can monitor the condition and performance of your grid.

By clicking on the service name in the NMS, you can view detailed data about the service and each of its component functions. The NMS provides basic functional statistics, alarm status, reporting functionality, and configuration options for each service and node.

Table 7: HP Medical Archive Services

Icon Tag Service Name Function Pg

LDR Local Distribution

Router

CLB Connection Load

Balancer

Data Plane

FSG File System Gateway Enabling storage and retrieval

Storing and routing data through the grid.

Enabling storage and retrieval through the DICOM protocol option.

through standard network file systems.

125

111

54 HP Medical Archive

T4434-96001

Table 7: HP Medical Archive Services (cont.)

Icon Tag Service Name Function Pg

Services and Components

Control Plane

Management Plane

CMS Content Management

System

ADC Administrative

Domain Controller

SSM Server Status Monitor Monitoring server activity and

NMS Network Management

System

CMN Configuration

Management Node

AMS Audit Management

System

Storing and managing metadata for the content.

Authenticating and managing IP address ranges and nodes, managing system timing, and reporting network topology.

hardware.

Notifying administrators of alarm conditions and providing the user interface for grid management.

Managing system configuration through the NMS interface. Access to changing settings in this service is restricted to the Vendor account.

Logging grid transactions for audit and reporting.

102

157

150

Within a grid, the same service can be installed and used on more than one node. The settings made to a service on one node do not affect the settings on the same service installed on a different node. System-wide configurations can be made by a service technician under the Vendor account using components of the Configuration Management Node (CMN).

Service Components

Each service is composed of one or more components that manage one piece of the service’s functionality. When using the NMS, you can select a service’s component to view the attributes that the component manages. The NMS also provides alarm status, reporting functionality, and configuration options for each component.

HP Medical Archive 55 T4434-96001

HPMA User Guide

Table 8 (below) lists all of the available service components, in alphabetic order by name. Note that the same symbol may be used by more than one component.

Table 8: Service Components

Icon Name

Audit CMN Configuration of the audit messages to be

Backup FSG View FSG backup settings and status.

Client Services FSG Status of file sharing services.

Parent Service

Data Provided

logged.

Connectivity All services

except SSM

Connectivity is a component of all services. The specific attributes listed in the NMS depend on the parent service. In general, this component manages information and statistics about network data transfer rates and volumes to and from the parent service, and the connection state to other services.

Content CMS Statistics on grid content ingest, replication,

and purging.

Database CMS, NMS Statistics on database type and transactions.

DICOM CLB, CMS Statistics on DICOM connections and

transactions.

LDR Connectivity settings and statistics for the

DICOM interface.

CMN Connectivity settings for the DICOM inter-

face to the grid.

DICOM Advanced

CMN Configuration settings for the DICOM con-

nection permissions and behaviors.

DICOM Indexes CMN List of the DICOM tags used by the grid for

content query and management.

56 HP Medical Archive

T4434-96001

Table 8: Service Components (cont.)

Parent

Icon Name

Service

Events AMS Statistics on the audit messages received and

SSM Server hardware and driver logs.

FSG Groups CMN Configuration of the FSG replication groups,

Grid Options CMN Report of grid identification information.

Grid Tasks CMN Management of grid-wide programmed

HTTP CLB, LDR Connectivity settings and statistics for the

Services and Components

Data Provided

committed.

and primary and secondary settings.

maintenance tasks.

HTTP interface.

CMN Connectivity settings for the HTTP interface

to the grid.

HTTP Advanced CMN Configuration settings for the HTTP connec-

tion permissions.

IP Ranges CMN IP ranges of permitted remote entity connec-

tions and their locations.

Network SSM Network reports on the network interfaces of

the server.

NMS Entities CMN Report of the grid configuration with

object IDs (OIDs).

RAID SSM Status of any attached RAID hardware and

drives.

Replication FSG, LDR View Replication settings and activity.

Services SSM Information on the state and resource usage

of services being monitored.

HP Medical Archive 57 T4434-96001

HPMA User Guide

Table 8: Service Components (cont.)

Parent

Icon Name

Service

Storage LDR, FSG Statistics on storage used and space available.

Synchronization CMS Statistics on message processing and informa-

Verification LDR View Verification settings and activity.

Volumes SSM Information on the state, mount point, and

Data Provided

tion synchronization between CMS services.

space available on storage volumes connected to the service.

The NMS interface provides you with detailed information and functionality for each service and component on your nodes. Whether you are inspecting the cause of an alarm or simply monitoring components on your grid, you can use the NMS to find information.

Interpreting Attribute Description Tables

This chapter provides attribute reference information in tables that follow a standard format. Given a (partial) sample display (Figure 26):

Figure 26: Partial Display Sample

58 HP Medical Archive

T4434-96001

The corresponding sample table (Table 9) illustrates the format. Below the sample table is an explanation of some column headings.

Table 9: Sample Service Attributes

Services and Components

Attribute Type/Units Description

State Enumerated

Text

Current state of the service: 20 = Online 10 = Standby 0=Offline

Status Enumerated

Text

The status of the service’s functionality: 0 = No Errors 10 = Errors

Node Information

User Label Text User-defined label for the service

appearing in the Navigation Tree, map views, and the title of the Content frame.

Notes Text Additional user-defined text pro-

viding description and annotations of the service or server.

Chart Text Alarm

ADCE

ADCA

N/A

The Type/Units column identifies the data type or units of measure. This is useful in interpreting alarm settings and the nature of reports that can be generated. If the type is “Enumerated text”, the enumerated values that the attribute can have are listed with the description of the attribute. Note that some attributes have enumerated values that can only occur under software control.

For units of “Duration” or “Bytes”, the values displayed in the NMS are scaled to a suitable unit. For example, durations scale to seconds, minutes, hours, or days; bytes scale to Kilobytes, Megabytes, or Gigabytes.

The scale of bytes displayed by the NMS uses the “natural” measure of powers of 10. For example 3 MBytes = 3 x 10

= 3,000,000 bytes. This is not the same as powers of 2 normally used for computing, where 3 MBytes = 3x220 = 3,145,728 bytes.

HP Medical Archive 59 T4434-96001

HPMA User Guide

The three columns on the right indicate if the attribute can be reported in chart form (Chart) and text form (Text), and the alarm attribute code (Alarm) used to monitor the attribute where available. In the PDF edition of this document, the alarm code is a hyperlink to the entry in Chapter 7, “Troubleshooting Alarms”.

60 HP Medical Archive

T4434-96001

Services and Components

ADC—Administrative Domain Controller

The Administrative Domain Controller (ADC) authenticates the grid nodes and their connections with each other. For two nodes to connect, the ADC must have certificates for both. The ADC maintains the certificates and synchronizes this information with the other ADCs in the grid.

In general, all system nodes maintain a connection to at leas t one ADC. This ensures that the nodes are always accessing the latest certificates (which may occasionally be updated or revoked). When nodes connect they cache other nodes’ certificates, enabling systems to continue functioning with known nodes even when an ADC is unavailable. New nodes can only establish connections via an ADC.

The connection of each node lets the ADC gath er topology information. This node information includes the CPU load, the amount of available disk space (if it has storage), the supported services, and the node’s group ID (location). The grid’s LDRs, CMSs, and CLBs ask the ADC for topology information through topology queries. The ADC responds to each query with the latest information received from the grid.

Group IDs are in the form of 10X00Y, where X and Y are pre-assigned based on the site and cabinet number. For example, cabinet B-3 would have a Group ID of 102003. These are used in placing replications under business rules, to permit the grid to disperse data in the most robust and efficient manner possible within the available topology.

ADC Attributes

The ADC supports the common set of service attributes. These common service attributes appear on the Overview tab for the service.

Table 10: ADC Service Attributes
