HP Elite x2 G4 QuickSpecs

QuickSpecs
HP Elite x2 G4
Overview
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 1
Left
1.
Audio-out/Audio-in Combo Jack
6.
Glass Clickpad
2.
Speakers
7.
Optional Collaboration Keyboard
3.
Volume Up/Volume Down
8.
IR Cam LED
4.
Nano Security Lock Slot (Lock sold separately)
9.
Hybrid Webcam and IR Camera
5.
Magnetic Pen Attach Area
10.
Webcam LED
QuickSpecs
HP Elite x2 G4
Overview
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 2
Right
1.
Charging LED
7.
Optional Fingerprint Sensor (select models)
2.
USB Type-C™ charging port
8.
Power Button
3.
USB Type-C™ with Thunderbolt™
9.
Privacy Camera Shutter
4.
USB Type-C™ with Thunderbolt™
10.
Rear-Facing Webcam
5.
Nano SIM Card Slot (Available on configurations with WWAN only)1
11.
World-Facing Microphone
6.
Kickstand
1. All units have a SIM card slot and icon but units that do not support WWAN are shipped with a non-removable SIM slot plug.
QuickSpecs
HP Elite x2 G4
Overview
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 3
HP Rechargeable Active Pen G3
1.
Tip
5.
USB-C Charging Port (System AC adapter may be used to charge the pen)
2.
Erase
6.
Bluetooth Pairing / Application Launch
3.
Select
7.
Spare Pen Tips (3 elastomer tips, 4 POM tips. POM tips are recommended for use with anti-glare panels)
4.
Diamond-Cut Ring
8.
Pen Tip Removal Tool
1. Sold separately or as an optional accessory
QuickSpecs
HP Elite x2 G4
Overview
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 4
Designed for full PC performance and pure tablet freedom in an exquisite, fully-optimized detachable design featuring
authentic materials and thoughtful finishes
8th Generation Intel® Core™ (U-series) processors, some with vPro™ support
1
Up to 14 hours and 15 minutes of battery life
2
Windows 10 versions or FreeDOS
Choice of displays:
13" diagonal WUXGA+ 1000 nits Ultraslim bent 72% CG with HP Sure View Gen3 (1920 x 1280)* 13" diagonal 3kx2k 450 nits Ultraslim bent 72% CG (3000 x 2000)
12.3" diagonal WUXGA+ 400 nits Ultraslim 72% CG (1920 x 1280) 13" diagonal WUXGA+ 650 nits Ultraslim 72% CG with HP Sure View Gen2 (1920 x 1280)*
Supports fast charging (50% in 30 minutes) with no impact on battery recharge cycles
3
Weight starting at 830 g (1.83 lbs) for tablet
Height starting at 8.8 mm (.35 inches) for tablet
Supports up to gigabit speed LTE for a range of wireless broadband options for connectivity on the go
Front and back-facing webcams
Audio by Bang & Olufsen
Three microphone array featuring a rear-facing microphone with HP Advanced Noise Reduction to improve inbound
ambient noise cancellation
Enterprise grade security with HP Sure Sense
6
, HP SureStart Gen5, HP Privacy Camera, HP Sure View Gen35, HP Sure Run Gen2, HP Sure Recover Gen2, HP Sure Click, self-encrypting storage drives, a built-in IR camera and an optional Fingerprint Sensor7 (select models)
Passed 19 MIL-STD 810G tests
4
Standard commercial 1 year limited warranty with extended service available with optional HP Care Packs
1. vPro™ support not available on all configurations
2. Windows 10 MM14 battery life will vary depending on various factors including product model, configuration, loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery will naturally decrease with time and usage.
3. Recharges your battery up to 50% within 30 minutes when the system is off or in standby mode. Power adapter with a minimum capacity of 65 watts is required. After charging has reached 50% capacity, charging will return to normal. Charging time may vary +/-10% due to System tolerance.
4. MIL-STD-810G testing is not intended to demonstrate fitness of U.S. Department of Defense (DoD) contract requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Accidental damage requires an optional HP Accidental Damage Protection Care Pack.
5. HP Sure View Gen3 integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in landscape orientation.
6. HP Sure Sense requires Windows 10. See product specifications for availability. On HP Elite x2 G4 units with WWAN shipping to China, HP Sure Sense is only available via Softpaq download.
7. HP Fingerprint Sensor is an optional feature and requires configuration at purchase. *Touch-enabled display and Sure View privacy panel will lower actual brightness
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 5
HP Elite x2 G4
Preinstalled
Windows 10 Pro 641 Windows 10 Pro 64 (National Academic only)2 Windows 10 Home 641 Windows 10 Home Single Language 641 Windows 10 Pro (Windows 10 Enterprise available with a Volume Licensing Agreement)1 FreeDOS
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.
2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10 Anniversary Update. Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.
Intel® Core™ i7-8665U vPro™ with Intel® UHD graphics 620 (1.9 GHz base frequency, up to 4.8 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores)
3,4,5,7
Intel® Core™ i7-8565U with Intel® UHD Graphics 620 (1.8 GHz base frequency, up to 4.6 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores)
3,4,5,6
Intel® Core™ i5-8365U vPro™ with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 4.1 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4 cores)
3,4,5,7
Intel® Core™ i5-8265U with Intel® UHD Graphics 620 Graphics (1.6 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4 cores)
3,4,5,6
Processor Family 8th Generation Intel® Core™ i7 processor (i7-8665U, i7-8565U models)
5
8th Generation Intel® Core™ i5 processor (i5-8365U, i5-8265U models)5
3. Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
4. Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
5. Intel® Turbo Boost performance varies depending on hardware, software and overall system configuration. See
http://www.intel.com/technology/turboboost for more information.
6. In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on
http://www.support.hp.com.
7. For full Intel® vPro™ functionality, Windows, a vPro supported processor, vPro enabled chipset, vPro enabled WLAN card and discrete TPM 2.0 are required. See http://Intel.com/vpro.
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 6
Integrated with processor
Integrated
Intel® UHD graphics 620
Supports
Support HD decode, DX12, HDMI 1.4b
8
8. HD content required to view HD images.
Touch
33.02 cm (13") diagonal 3kx2k IPS BrightView WLED-backlit Ultraslim bent touch screen with Corning® Gorilla® Glass 5 450 nits, 72% NTSC (3000x2000)
8,9,10
33.02 (13") diagonal WUXGA+ IPS eDP WLED-backlit ultra slim bent touch screen with Corning® Gorilla® Glass 5 and HP Sure View integrated privacy screen Gen3, 1000 nits, 72% NTSC (1920 x 1280)
8,9,10,11,*
33.02 (13") diagonal WUXGA+ IPS eDP WLED-backlit ultra slim touch screen with Corning® Gorilla® Glass 5 and HP Sure View integrated privacy screen Gen2, 650 nits, 72% NTSC (1920 x 1280)
8,9,10,12,*
31.24 cm (12.3") diagonal WUXGA+ IPS BrightView WLED-backlit Ultraslim touch screen with Corning® Gorilla® Glass 5, 400 nits, 72% NTSC (1920x1280)
8,9,10
8. HD content required to view HD images.
9. Sold separately or as an optional feature.
10. Resolutions are dependent upon monitor capability, and resolution and color depth settings.
11. HP Sure View Gen3 integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in landscape orientation.
12. HP Sure View Gen2 integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in landscape orientation. *Touch-enabled display and Sure View privacy panel will lower actual brightness
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 7
Docking station
model
Total number
of supported
displays (incl.
the notebook)
display)
Max.
resolutions
supported
Dock Connectors
Technical limitations
HP Thunderbolt Dock G2
3
Dual 4K @ 60Hz
2xDP, 1xVGA, 1xTB,
1xUSB-C alt-mode
Dual 4k (4096 x 2160) only with:
• 1 DP + TB port or
• USB-C alt mode + TB port
Dual 4K (3840 x 2160) with any of the DP, TB
or USB-C alt mode video ports
HP Elite USB-C Dock G4
3
Dual 2K @ 60Hz
Single 4K @
60Hz (3840 x
1440)
1xHDMI, 2xDP
HP USB-C Universal Dock
3
Dual 4K @ 60Hz
Single 5K @
60Hz
2xDP
HP USB-C Travel Dock
2
Single 2K @
60Hz
1xHDMI, 1xVGA
Single external display
Only HDMI or VGA at the time
HP USB-C Mini Dock
2
Single 4K @
30Hz
1xHDMI, 1xVGA
Single external display
Only HDMI or VGA at the time
Primary M.2 Storage
2 TB PCIe® Gen3x4 NVMe™ SS TLC13 1 TB PCIe® Gen3x4 NVMe™ SS TLC13 512 GB Intel® PCIe® NVMe™ QLC M.2 SSD with 32 GB Intel® Optane™ memory H10
13,14,15
512 GB PCIe® Gen3x4 NVMe™ SS TLC Opal 213 512 GB PCIe® Gen3x4 NVMe™ SS TLC13 512 GB PCIe® NVMe™ SS Value13
256 GB SATA-3 SED TLC Opal 213 256 GB PCIe® Gen3x4 NVMe™ SS TLC
13
256 GB PCIe® NVMe™ SS Value13 256 GB Intel® PCIe® NVMe™ QLC M.2 SSD with 16 GB Intel® Optane™ memory H10
13,14,15
128 GB SATA-3 SS TLC13
13. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is reserved for system recovery software.
14. Intel® Optane™ memory system acceleration does not replace or increase the DRAM in your system. Requires 8th Gen or higher Intel® Core™ processor, BIOS version with Intel® Optane™ supported, Windows 10 64-bit, and an Intel® Rapid Storage Technology (Intel® RST) driver.
15. Intel® Optane™ memory H10 only for Intel® PCIe® NVMe™ QLC M.2 SSD.
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 8
Maximum Memory
16 GB LPDDR3-2133 SDRAM15
Memory
16 GB LPDDR3-2133 SDRAM (2 X 8 GB)
16
8 GB LPDDR3-2133 SDRAM (2 x 4 GB)
16
Memory Slots
Memory soldered down Supports Dual Channel Memory
16. Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
WLAN
Intel® Wi-Fi 6 AX200 + BT5 (802.11ax 2x2, vPro*, supporting gigabit file transfer speeds)
17,18
Intel® Wi-Fi 6 AX200 + BT5 (802.11ax 2x2, non-vPro, supporting gigabit file transfer speeds)
17,18
WWAN
Intel® XMM™ 7360 LTE-Advanced Cat 9
19
Intel® XMM™ 7560 LTE-Advanced Pro Cat 16
20
Miracast
Native Miracast Support
21
Standalone GPS
HP Graff GNSS Module
22
HP Connection Optimizer
Support HP Connection Optimizer
17. Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other
802.11ax devices. Only available in countries where 802.11ax is supported. Wi-Fi® supporting gigabit speeds is achievable when transferring files between two devices connected to the same router. Requires a wireless router, sold separately, that supports 160 MHz channels.
18. Dynamic Regulatory Solution will auto-change AC WLAN to abgn by passive scan when entering Indonesia.
19. WWAN module is optional, must be configured at the factory and requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.
20. Gigabit class Category 16 4G LTE module is optional and must be configured at the factory. Module designed for up to 1 Gbps download speeds as carriers deploy 5 carrier aggregation and 100Mhz channel bandwidth, requires activation and separately purchased service contract. Backwards compatible to HSPA 3G technologies. Check with service provider for coverage and availability in your area. Connection, upload and download speeds will vary due to network, location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.
21. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming.
22. Standalone GPS is an optional feature and requires factory configuration. GPS and WWAN are mutually exclusive. * For full Intel® vPro™ functionality, Windows, a vPro supported processor, vPro enabled chipset, vPro enabled WLAN card and discrete TPM 2.0 are required. See http://Intel.com/vpro.
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 9
Audio
Audio by Bang & Olufsen 2 Premium stereo speakers (74 dB) Maximum System Acoustic level: 35 dBA. SSD Random Seeks Sound Pressure level is 19 dBA (fan off). Integrated 3 Multi Array Microphone including world-facing 3
rd
mic for noise suppression Audio Solution Codec Realtek
ALC3292 + Discrete amp NXP9892
Camera
User facing FHD + IR camera – Front
8
Integrated 8MP – Back
Webcam
IR Webcam LED Indicator
8. HD content required to view HD images.
Keyboard
HP Elite x2 G4 Collaboration Keyboard
Pointing Device
Touchpad with multi-touch gesture enabled
Function Keys
Esc Key F1 - Display Switching F2 - Privacy F3 - Brightness Down F4 - Brightness Up F5 - Audio Mute F6 - Volume Down F7 - Volume Up F8 - Mic Mute F9 - Backlit Toggle F10 - numlk F11 - Wireless F12 - Calendar Share/Present Call Answer Call End Delete FN Key Lock
Hidden Function Keys
Fn+R - Break Fn+S - Sys Rq Fn+C - Scroll Lock Fn+E - Insert Fn+W - Pause
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 10
Clickpad Requirements:
Microsoft Precision Touchpad Default Gestures Support FW PTP with Filter Driver
Preinstalled Software
BIOS
HP BIOSphere Gen5
23
HP Drive Lock & Automatic Drive Lock
24
BIOS Update via Network Master Boot Record Security Power On Authentication Secure Erase
25
Absolute Persistence Module
26
Pre-boot Authentication
Software
HP Native Miracast Support
27
HP Connection Optimizer HP Image Assistant HP Hotkey Support HP JumpStart HP Support Assistant
28
HP Noise Cancellation Software Buy Office (Sold separately)
Manageability Features
HP Driver Packs
29
HP System Software Manager (SSM) HP BIOS Config Utility (BCU) HP Client Catalog HP Manageability Integration Kit Gen3
30
HP Cloud Recovery31
Client Security Software
HP Client Security Suite Manager
32
HP Fingerprint Sensor (select models)
33
HP Power On Authentication Windows Defender34
Security Management
Pre-boot Authentication TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)
35
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 11
SATA 0,1 port disablement (via BIOS) Serial, USB enable/disable (via BIOS) Power-on password (via BIOS) Setup password (via BIOS) Support for chassis padlocks and cable lock devices HP Sure Click
36
HP Sure Start Gen5
37
HP Sure Run Gen2
38
HP Sure Recover Gen2
39
HP Sure Sense40
Security
TPM
Model: Infineon SLB9670
Version: 7.85
Revision: TPM 2.0
FIPS 140-2 Compliant: Yes
Is the BIOS on this notebook ISO/IEC 19678:2015 (formerly NIST 800-147) compliant?:
Yes
UEFI version: 2.6
23. HP BIOSphere Gen5 is available on select HP Pro and Elite PCs. See product specifications for details. Features may vary depending on the platform and configurations.
24. HP Drive Lock & Automatic Drive Lock is not supported on NVMe drives
25. HP Secure Erase for the methods outlined in the National Institute of Standards and Technology Special Publication 800-88 "Clear" sanitation method. HP Secure Erase does not support platforms with Intel® Optane™.
26. Absolute agent is shipped turned off and will be activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:
http://www.absolute.com/company/legal/agreements/ computrace-agreement. Data Delete is an optional service provided by
Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.
27. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming.
28. HP Support Assistant requires Windows and Internet access.
29. HP Driver Packs not preinstalled, however available for download at http://www.hp.com/go/clientmanagement.
30. HP Manageability Integration Kit can be downloaded from http://www.hp.com/go/clientmanagement.
31. HP Cloud Recovery is available for HP Elite and Pro desktops and laptops PCs with Intel® or AMD processors and requires an open, wired network connection. Note: You must back up important files, data, photos, videos, etc. before use to avoid loss of data. Detail please refer to: https://support.hp.com/us-en/document/c05115630
32. HP Client Security Manager Gen5 requires Windows and is available on the select HP Pro and Elite PCs. See product specifications for details.
33. HP Fingerprint Sensor is an optional feature and requires configuration at purchase.
34. Windows Defender Opt in and internet connection required for updates.
35. Firmware TPM is version 2.0. Hardware TPM is v1.2, which is a subset of the TPM 2.0 specification version v0.89 as implemented by Intel Platform Trust Technology (PTT).re TPM is version 2.0. Hardware TPM is v1.2, which is a subset of the TPM
2.0 specification version v0.89 as implemented by Intel Platform Trust Technology (PTT).
36. HP Sure Click is available on select HP platforms and supports Microsoft Internet Explorer, Google Chrome™, and Chromium™. Supported attachments include Microsoft Office (Word, Excel, PowerPoint) and PDF files in read only mode, when Microsoft Office
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 12
or Adobe Acrobat are installed.
37. HP Sure Start Gen5 is available on select HP PCs with Intel processors. See product specifications for availability.
38. HP Sure Run Gen2: See product specifications for availability.
39. HP Sure Recover Gen2: See product specifications for availability. Requires an open, wired network connection. Not available on platforms with multiple internal storage drives. You must back up important files, data, photos, videos, etc. before using HP Sure Recover to avoid loss of data. HP Sure Recover (Gen1) does not support platforms with Intel® Optane™.
40. HP Sure Sense requires Windows 10. See product specifications for availability. On HP Elite x2 G4 units with WWAN shipping to China, HP Sure Sense is only available via Softpaq download.
Power Supply
HP Smart 65 W USB Type-C™ adapter
41
HP Smart 65 W USB Type-C™ slim adapter
41
Primary Battery
HP Long Life 2-cell, 47 Wh Li-ion polymer
42
Supports HP Fast Charging (Up to 50% in 30 mins)43
Battery life
Up to 14 hours and 15 minutes
44
Power Cord
Duckhead Duckhead Power Cord Length: AC = 1m
41. Availability may vary by country.
42. Battery is internal and not replaceable by customer. Serviceable by warranty.
43. Recharges the battery up to 50% within 30 minutes when the system is off or in standby mode. Power adapter with a minimum capacity of 65 watts is required. After charging has reached 50% capacity, charging will return to normal. Charging time may vary +/-10% due to System tolerance.
44. Windows 10 MM14 battery life will vary depending on various factors including product model, configuration, loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See http://www.bapco.com for additional details.
Weight
Tablet (Imperial)
Starting at 1.83 lbs45
Tablet (Metric)
Starting at 0.83 kg45
Collaboration Travel Keyboard (Imperial)
Starting at .81 lbs45
Collaboration Travel Keyboard (Metric)
Starting at .37 kg45
Tablet and Collaboration Travel Keyboard (Imperial)
Starting at 2.58 lb45
Tablet and Collaboration Travel Keyboard (Metric)
Starting at 1.17 kg45 Product Dimensions (w x d x h)
Dimensions tablet (imperial)
11.39 x 8.51 x 0.35 in
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 13
Dimensions tablet (metric)
28.93 x 21.58 x 0.88 cm
Dimensions tablet and Collaboration Travel Keyboard(imperial)
11.39 x 8.79 x 0.56 in
Dimensions tablet and Collaboration Travel Keyboard (metric)
28.93 x 22.32 x1.42 cm
45. Weight will vary by configuration.
Ports
2 USB 3.1 Type-C™ with Thunderbolt support 1 USB 3.1 Type-C™ Gen 1 (Power delivery, DisplayPort™ 1.2) 1 Headphone/Microphone Combo Nano Security Lock Slot (Lock sold separately)
Expansion Slots
1 Nano SIM
Sensors
Accelerometer Magnetometer Gyro E-compass ALS (ambient light sensor) Hall Sensor
HP Services offers 1-year or 3 year limited warranties and 90 day software limited warranty options depending on country. Batteries have a default one year limited warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the platform. Refer to http://www.hp.com/support/batterywarranty/ for additional battery information. On-site service and extended coverage is also available. HP Care Pack Services are optional extended service contracts that go beyond the standard limited warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc.46
46. HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit
http://www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or indicated
to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 14
Stand-Alone Power Requirements (AC Power)
Nominal Operating Voltage
19 V Average Operating Power
Win 10
Integrated Graphics
6.78W
Discrete Graphics
N/A
Max Operating Power
UMA < 65W
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing optical)
Non-operating
41° to 95° F (5° to 35° C) (writing optical)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
Shock
Operating
40 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude (unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 40,000 ft (-15.24 to 12,192 m)
Planned Industry Standard Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR®
Yes
47
EPEAT® 2019
Yes, Gold in U.S.
48
ICES
Yes
Australia / NZ A-Tick Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
KC
Yes
BSMI
Yes
CE Marking Compliance
Yes
BNCI or BELUS
Yes
CIT
Yes
GOST
Yes
Saudi Arabian Compliance (ICCP)
Yes
SABS
Yes
UKRSERTCOMPUTER
Yes
47. Configurations of the HP Elite x2 G4 that are ENERGY STAR® certified are identified as HP Elite x2 G4 ENERGY STAR® on HP websites and on http://www.energystar.gov.
48. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit http://www.epeat.net for more information.
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 15
Panel LCD 12.3 inch diagonal WUXGA+ (1920 x 1280) BrightView WLED UWVA 72% NTSC 400 nits eDP 1.4+PSR Ultraslim
Outline Dimensions (W x H x D)
265.56 x 185.06 mm (max)
Active Area
259.2 x 172.8 mm (typ.)
Weight
161 g (max)
Diagonal Size
12.3 inch
Thickness
1.96 mm (panel side) / 4.59 mm (max)
Interface
eDP 1.4a + PSR (2 lane)
Surface Treatment
Bright-View (BV)
Touch Enabled
Yes
Contrast Ratio
1200:1 (typ.)
Refresh Rate
60Hz
Brightness
400 nits
Pixel Resolution
1920 x 1280 (WUXGA+)
Format
RGB
Backlight
LED
Color Gamut Coverage
72% of NTSC
Color Depth
6bits
Viewing Angle
UWVA 85/85/85/85
13" diagonal 3kx2k IPS LED-backlit touch screen with Corning® Gorilla® Glass 4 Low Power Ultra Slim bent 450 nits 72% NTSC (3000 x 2000)
Outline Dimensions (W x H x D)
279.3 x 193.0 mm (max)
Active Area
274.5 x 183 mm (max)
Weight
160 g (max)
Diagonal Size
13.0”
Thickness
1.8 (panel side)/3.9 (PCBA side) mm(max)
Interface
eDP
Surface Treatment
Glare
Touch Enabled
Yes
Contrast Ratio
1800 (typ.)
Refresh Rate
60Hz
Brightness
450 nits typical (Panel Only)
Pixel Resolution
3000 x 2000
Format
RGB stripe
Backlight
LED
Color Gamut Coverage
72% of NTSC
Color Depth
6 bits
Viewing Angle
85/85/85/85
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 16
13" diagonal WUXGA+ (1920 x 1280) BrightView WLED UWVA 72% NTSC 1000 nits eDP
1.4+PSR2 bent Privacy Gen3
Outline Dimensions (W x H x D)
277.748 x 193.2 mm (max)
Active Area
272.448 x 191.632 mm (typ.)
Weight
190 g (max)
Diagonal Size
13.0 inch
Thickness
3.9 mm (max)
Interface
eDP 1.4 + PSR2 (4 lane)
Surface Treatment
BrightView (BV)
Touch Enabled
Yes
Contrast Ratio
2000:1 (typ.)
Refresh Rate
60 Hz
Brightness
1000 nits
Pixel Resolution
1920 x 1280 (WUXGA+)
Format
RGB
Backlight
LED
Color Gamut Coverage
72% NTSC
Color Depth
8 bits
Viewing Angle
UWVA 85/85/85/85
13" diagonal WUXGA+ (1920 x 1280) BrightView WLED UWVA 72% NSTC 650 nits eDP 1.4a ultraslim Privacy Gen2
Outline Dimensions (W x H x D)
279.3 x 193.2 mm (max.)
Active Area
272.449 x 181.632 mm (max.)
Weight
220g (max.)
Diagonal Size
13.0"
Thickness
3.9 mm(max.)
Interface
eDP 1.4a
Surface Treatment
BrightView (BV)
Touch Enabled
Yes
Contrast Ratio
Sharing mode, 600:1 (typ.) Privacy mode, 150:1 (typ.)
Refresh Rate
120 Hz
Brightness
Sharing mode, 650 nits (typ.) Privacy mode, 320 nits (typ.)
Pixel Resolution
1920 x 1280 (WUXGA+)
Format
RGB
Backlight
LED
Color Gamut Coverage
Sharing mode, 72% NTSC Privacy mode, 60% NTSC
Color Depth
6 bits + Hi FRC
Viewing Angle
Sharing mode, CR >10, L/R/U/D, 85/85/85/85 (typ.) Privacy mode CR>2, L/R/U/D, 50/50/85/85 (typ.)
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 17
SSD 128 GB 2280 M2 SATA­3 TLC
Form Factor
M.2 2280
Capacity
128 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
ATA-8, SATA 3.0
Maximum Sequential Read
540 MB/s 560 MB/s
Maximum Sequential Write
500 MB/s 530 MB/s
Logical Blocks
250,069,680
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
DIPM; TRIM; DEVSLP
SSD 1 TB 2280 PCIe-3x4 NVMe Three Layer Cell single-sided
Form Factor
M.2 2280
Capacity
1 TB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 2800 MB/s
Maximum Sequential Write
Up To 1600 MB/s
Logical Blocks
2,000,409,264
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (Option); TRIM; L1.2
SSD 256 GB 2280 M2 PCIe-3x4 SS NVMe TLC
Form Factor
M.2 2280
Capacity
256 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
2580 MB/s 2600 MB/s
Maximum Sequential Write
900 MB/s 1000 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (Option); TRIM; L1.2
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 18
SSD 256 GB 2280 M2 SATA­3 Self Encrypted OPAL2 Three Layer Cell
Form Factor
M.2 2280
Capacity
256 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
ATA-8, SATA 3.0
Maximum Sequential Read
530 MB/s 560 MB/s
Maximum Sequential Write
500 MB/s 530 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; TCG OPAL 2.0; DIPM; TRIM; DEVSLP
SSD 2 TB 2280 PCIe-3x4 NVMe Three Layer Cell single-sided
Form Factor
M.2 2280
Capacity
2 TB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 3000 MB/s
Maximum Sequential Write
Up To 2100 MB/s
Logical Blocks
3,907,029,168
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; TCG OPAL 2.0; DIPM; TRIM; DEVSLP
SSD 512 GB 2280 M2 PCIe­3x4 SS NVMe TLC
Form Factor
M.2 2280
Capacity
512 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
2800 MB/s 2900 MB/s
Maximum Sequential Write
1000 MB/s 1800 MB/s
Logical Blocks
1,000,215,215
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (Option); TRIM; L1.2
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 19
SSD 512 GB 2280 PCIe-3x4 NVMe Self Encrypted OPAL2 Three Layer Cell
Form Factor
M.2 2280
Capacity
512 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
2800 MB/s 2900 MB/s
Maximum Sequential Write
1000 MB/s 1800 MB/s
Logical Blocks
1,000,215,215
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security (Option); TCG Opal 2.0; TRIM; L1.2
SSD 512 GB 2280 PCIe NVMe Value
Form Factor
M.2 2280
Capacity
512 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 1700 MB/s
Maximum Sequential Write
Up To 1500 MB/s
Logical Blocks
1,000,215,215
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security; TRIM; L1.2
SSD 256 GB 2280 PCIe NVMe Value
Form Factor
M.2 2280
Capacity
256 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 1700 MB/s
Maximum Sequential Write
Up to 1300 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security, TRIM; L1.2
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 20
512 GB 2280 PCIe-3x2x2 NVMe+SSD 32 GB 3D Xpoint
Form Factor
M.2 2280
Capacity
512 GB
NAND Type
TLC
Height
0.09 in (2.3 mm)
Width
0.87 in (22 mm)
Weight
0.02 lb (10 g)
Interface
PCIe NVMe Gen3X4
Maximum Sequential Read
Up To 2400 MB/s
Maximum Sequential Write
Up To 1300 MB/s
Logical Blocks
1,000,215,215
Operating Temperature
32° to 158°F (0° to 70°C) [ambient temp]
Features
ATA Security, TRIM; L1.2
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 21
Intel® 22260
802.11a/b/g/n/ac/ax (2x2) Wi-Fi 6* and Bluetooth® 5.1 Combo vPro
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11ax IEEE 802.11d IEEE 802.11e IEEE 802.11h IEEE 802.11i IEEE 802.11k IEEE 802.11r IEEE 802.11v
Interoperability
Wi-Fi® certified
Frequency Band
•802.11b/g/n/ax
2.402 – 2.482 GHz
•802.11a/n/ac/ax
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
• 802.11ax: MCS0 ~ MCS11, (1SS and 2SS) (20MHz, 40MHz, 80MHz & 160MHz)
Modulation
Direct Sequence Spread Spectrum OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM, 1024QAM
Security
2
•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
•WPA2 certification
•IEEE 802.11i
•Cisco Certified Extensions, all versions through CCX4 and CCX Lite
•WAPI
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power1
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 22
802.11ac VHT160(5GHz): +11.5dBm minimum
• 802.11ax HT40(2.4GHz): +10dBm minimum
• 802.11ax VHT160(5GHz): +10dBm minimum
Power Consumption
•Transmit mode 2.0 W
•Receive mode 1.6 W
•Idle mode (PSP) 180 mW (WLAN Associated)
•Idle mode 50 mW (WLAN unassociated)
•Connected Standby 10mW
•Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
•802.11b, 1Mbps: -93.5dBm maximum
•802.11b, 11Mbps: -84dBm maximum
• 802.11a/g, 6Mbps: -86dBm maximum
• 802.11a/g, 54Mbps: -72dBm maximum
• 802.11n, MCS07: -67dBm maximum
• 802.11n, MCS15: -64dBm maximum
• 802.11ac, MCS0: -84dBm maximum
• 802.11ac, MCS9: -59dBm maximum
•802.11ax, MCS11(HT40): -59dBm maximum
•802.11ax, MCS11(VHT160): -58.5dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8 g
2. Type 126: 1.3 g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Amber Radio OFF; LED White Radio ON
1. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
2. Check latest software/driver release for updates on supported security features.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
*Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax devices. Only available in countries where 802.11ax is supported.
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 23
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0/5.1 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0/5.1 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy: 0~79 (1 MHz/CH) BLE: 0~39 (2 MHz/CH)
Signaling Data Rate
Legacy: 3 Mbps signaling data rate1 2.17 Mbps BLE: 1 Mbps signaling data rate1 0.2 Mbps
1. Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 9.5 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW
Bluetooth Software Supported
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management Certifications
ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
For full Intel® vPro™ functionality, Windows, a vPro supported processor, vPro enabled chipset, vPro enabled WLAN card and
discrete TPM 2.0 are required. See http://Intel.com/vpro.
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 24
Intel® 22260
802.11a/b/g/n/ac/ax (2 x 2) Wi-Fi 6* and Bluetooth® 5.1 Combo
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11ax IEEE 802.11d IEEE 802.11e IEEE 802.11h IEEE 802.11i IEEE 802.11k IEEE 802.11r IEEE 802.11v
Interoperability
Wi-Fi® certified
Frequency Band
•802.11b/g/n/ax
2.402 – 2.482 GHz
•802.11a/n/ac/ax
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
•802.11b: 1, 2, 5.5, 11 Mbps
•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
•802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
• 802.11ax: MCS0 ~ MCS11, (1SS and 2SS) (20MHz, 40MHz, 80MHz & 160MHz)
Modulation
Direct Sequence Spread Spectrum OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM, 1024QAM
Security
2
•IEEE and Wi-Fi compliant 64 / 128 bit WEP encryption for a/b/g mode only
•AES-CCMP: 128 bit in hardware
•802.1x authentication
•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
•WPA2 certification
•IEEE 802.11i
•Cisco Certified Extensions, all versions through CCX4 and CCX Lite
•WAPI
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power1
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 25
• 802.11ac VHT160(5GHz): +11.5dBm minimum
• 802.11ax HT40(2.4GHz): +10dBm minimum
• 802.11ax VHT160(5GHz): +10dBm minimum
Power Consumption
•Transmit mode 2.0 W
•Receive mode 1.6 W
•Idle mode (PSP)180 mW (WLAN Associated)
•Idle mode 50 mW (WLAN unassociated)
•Connected Standby 10mW
•Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
•802.11b, 1Mbps: -93.5dBm maximum
•802.11b, 11Mbps: -84dBm maximum
• 802.11a/g, 6Mbps: -86dBm maximum
• 802.11a/g, 54Mbps: -72dBm maximum
• 802.11n, MCS07: -67dBm maximum
• 802.11n, MCS15: -64dBm maximum
• 802.11ac, MCS0: -84dBm maximum
• 802.11ac, MCS9: -59dBm maximum
•802.11ax, MCS11(HT40): -59dBm maximum
•802.11ax, MCS11(VHT160): -58.5dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
Weight
1. Type 2230: 2.8g
2. Type 126: 1.3g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Amber Radio OFF; LED White Radio ON
1. The FCC has declared as of September 1, 2014 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
2. Check latest software/driver release for updates on supported security features.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
*Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax devices. Only available in countries where 802.11ax is supported.
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 26
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0/5.1 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0/5.1 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy: 0~79 (1 MHz/CH) BLE: 0~39 (2 MHz/CH)
Signaling Data Rate
Legacy: 3 Mbps signaling data rate1 2.17 Mbps BLE: 1 Mbps signaling data rate1 0.2 Mbps
1. Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 9.5 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW
Bluetooth Software Supported
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management Certifications
ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
Intel® XMM™ 7360 LTE­Advanced CAT9
1
Technology/Operating bands
FDD LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3), 1700/2100 (Band 4), 850 (Band 5), 2600 (Band 7), 900 (Band 8), 1400 (Band 11), 700 (Band 12 lower), 700 (Band 13 upper), 700 (Band 17 lower), 850 (Band 18 lower), 850 (Band 19 upper), 800 (Band 20), 1400 (Band 21), 850 (Band 26), 700 (Band 28), 700 (Band 29 RX only), 2300 (Band 30), 1700/2100 (Band 66).
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 27
TDD LTE: 2600 (Band 38), 1900 (Band 39), 2400 (Band 40), 2500 (Band
41). HSPA+: 2100 (Band 1), 1900 (Band 2), 1700/2100 (Band 4), 850 (Band 5), 900 (Band 8) MHz
Wireless protocol standards
3GPP Release 11 LTE Specification CAT.9, DL 60MHz BW throughput up to 450Mbps; UL 20MHz throughput up to 50Mbps WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification
GPS
Standalone, A-GPS (MS-A, MS-B)
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz, Beidou 1561.098 MHz
Maximum data rates
LTE: 450 Mbps (Download), 50 Mbps (Upload) DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload)
Maximum output power
LTE: 23 dBm HSPA+: 23.5 dBm
Maximum power consumption
LTE: 1,200 mA (peak); 900 mA (average) HSPA+: 1,100 mA (peak); 800 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
5.8 g
Dimensions (Length x Width x Thickness)
42 x 30 x 2.3 mm
1. Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.
Intel® XMM™ 7560 LTE­Advanced Pro DL CAT16
1
Technology/Operating bands
FDD LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3), 1700/2100 (Band 4), 850 (Band 5), 2600 (Band 7), 900 (Band 8), 700 (Band 12 lower), 700 (Band 13 upper), 700 (Band 14 upper), 700 (Band 17 lower), 850 (Band 18 lower), 850 (Band 19 upper), 800 (Band 20), 1900 (Band 25), 850 (Band 26), 700 (Band 28), 700 (Band 29 RX only), 2300 (Band 30), 1700/2100 (Band 66). TDD LTE: 2600 (Band 38), 1900 (Band 39), 2400 (Band 40), 2500 (Band
41), 3500 (Band 42), 5200 (Band 46 RX only) HSPA+: 2100 (Band 1), 1900 (Band 2), 1700/2100 (Band 4), 850 (Band 5), 900 (Band 8) MHz
Wireless protocol standards
3GPP Release 12 LTE Specification DL-CAT.16, DL 100MHz BW throughput up to 978Mbps; UL-CAT.7 20MHz throughput up to 75Mbps WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification
GPS
Standalone, A-GPS (MS-A, MS-B)
GPS bands
1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz, Beidou 1561.098 MHz
Maximum data rates
LTE: 978 Mbps (Download), 75 Mbps (Upload) DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload)
Maximum output power
LTE: 23 dBm in all band except B41 LTE B41 HPUE = 26dBm HSPA+: 23.5 dBm
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 28
Maximum power consumption
LTE: 1,200 mA (peak); 900 mA (average) HSPA+: 1,100 mA (peak); 800 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
6 g
Dimensions (Length x Width x Thickness)
42 x 30 x 2.3 mm
1. Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.
HP Graff GNSS Module
Technology
Standalone GPS, GLONASS
Dimensions (L x W x H)
42 x 30 x 2.3 mm
System interface
USB 2.0
GPS bands
GPS L1 1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz
Power Consumption
Active mode (continuous): 67 mA (peak); 26 mA (average)
Form Factor
M.2, 3042-S3 Key B
Weight
4.3 g
AC Adapter 65 Watt nPFC Slim USB type C Straight
1.8m
Dimensions (H x W x D)
88.0 x 53.5 x 21.0 mm
Weight
220 g +/- 10 g
Input
100 to 240 VAC
Input Efficiency
Average Efficiency of 25%, 50%, 75%, 100% load condition with 115Vac/230Vac Spec: 5V: 81.5% 9V: 86.7% 12V: 88.0% 15V: 89.0% 20V: 89.0%
Input frequency range
48 ~ 63 Hz
Input AC current
Max. 1.7 A at 90 VAC
Output
Output power
5V/15W 9V/27W 12V/60W 15V/65W 20V/65W
DC output
5V / 9V / 12V / 15V / 20V
Hold-up time
5 ms at 115 Vac input
Output current limit
<8.0A
Connector
USB Type-C
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 29
Environmental Design
Operating temperature
32°F to 95°F (0° to 35°C)
Non-operating (storage) temperature
-4°F to 185°F (-20° to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
20% to 95%
Storage Humidity
10% to 95%
EMI and Safety Certifications
CE Mark - full compliance with LVD and EMC directives Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. MTBF - over 200,000 hours at 25°C ambient condition.
AC Adapter 65 Watt nPFC USB type C Straight 1.8 m C6NS (Hades+)
Dimensions (H x W x D)
74 x 74 x 28.5 mm
Weight
245 g +/- 10 g
Input
100 to 240 VAC
Input Efficiency
81.5% min at 115 Vac/ 230Vac @ 5V/3A
86.7% min at 115 Vac/ 230Vac @ 9V/3A 88% min at 115 Vac/ 230Vac @ 10V/5A 88% min at 115 Vac/ 230Vac @ 12V/5A 89% min at 115 Vac/ 230Vac @ 15V/4.33A 89% min at 115 Vac/ 230Vac @ 20V/3.25A
Input frequency range
47 ~ 63 Hz
Input AC current
1.7 A at 90 VAC and maximum load
Output power
65W
DC output
5V/9V/10V/12V/15V/20V
Hold-up time
5ms at 115 Vac input
Output current limit
<8.0A
Connector
Non-Standard C6
Environmental Design
Operating temperature
32°F to 95°F (0° to 35°C)
Non-operating (storage) temperature
-4°F to 185°F (-20° to 85°C)
Altitude
0 to 16,400 ft (0 to 5000m)
Humidity
5% to 95%
Storage Humidity
5% to 95%
EMI and Safety Certifications
CE Mark - full compliance with LVD and EMC directives Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. MTBF - over 100,000 hours at 25°C ambient condition.
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 30
Battery MR 2 Cell WHr 47 Long Life -PL Fast Charge
Dimensions (H x W x L)
5.11 x 84.00 x 238.14 mm
Weight
0.190 kg
Cells/Type
4cell Lithium-Ion Polymer cell / 4473A9
Energy
Voltage
7.7 V
Amp-hour capacity
6.15 Ah
Watt-hour capacity
47 Wh
Temperature
Operating (Charging)
32˚ to 113˚ F (0˚ to 45˚ C)
Operating (Discharging)
14˚ to 122˚ F (-10˚ to 60˚ C)
Fuel Gauge LED
NA
Warranty
3-year
Optional Travel Battery Available
No
QuickSpecs
HP Elite x2 G4
Technical Specifications
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 31
Country of Origin
China
QuickSpecs
HP Elite x2 G4
Options and Accessories (sold separately and availability may vary by country)
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 32
Type
Description
Part Number
Docking
HP Thunderbolt Dock 120W G2
2UK37AA
HP Thunderbolt Dock w/Combo Cable G2
3TR87AA
HP Thunderbolt Dock w/Audio Module
3YE87AA
HP Audio Module
3AQ21AA
HP Thunderbolt Dock 120W Cable
3XB94AA
HP Thunderbolt Dock Combo Cable
3XB96AA
HP Thunderbolt Dock
1DT93AA
HP USB-C Dock G4
3FF69AA
HP USB-C Universal Dock
1MK33AA
HP USB-C Universal Dock Non Flash
3DV65AA
HP USB-C Mini Dock
1PM64AA
HP USB-C Dock G5
5TW10AA
HP USB-C/A Universal Dock G2
5TW13AA
Input/Output
HP Slim Wireless Keyboard and Mouse
T6L04AA
HP Slim USB Keyboard and Mouse
T6T83AA
HP Wireless (Link-5) Keyboard
T6U20AA
HP USB Essential Keyboard and Mouse
H6L29AA
HP Conferencing Keyboard
K8P74AA
HP Elite x2 G4 Collaboration Keyboard
7CS01AA
HP USB Collaboration Keyboard
Z9N38AA
HP Wireless Collaboration Keyboard
Z9N39AA
HP Comfort Grip Wireless Mouse
H2L63AA
HP X4000b Bluetooth Mouse
H3T50AA
HP 3-Button USB Laser Mouse
H4B81AA
HP USB Travel Mouse
G1K28AA
HP Ultra Mobile Wireless Mouse
H6F25AA
HP Slim Bluetooth Mouse
F3J92AA
HP Wireless Premium Mouse
1JR31AA
HP USB Premium Mouse
1JR32AA
HP Elite Presenter Mouse
2CE30AA
HP Rechargeable Active Pen G3
6SG43AA
HP USB-C to USB-A Hub
Z6A00AA
HP USB 3.0 PN
N2Z63AA
HP USB-C to HDMI
1WC36AA
HP USB-C to DP
N9K78AA
HP USB-C to VGA
N9K76AA
HP RJ45 Adapter PN
V7W66AA
Power
HP 65W USB-C Power Adapter
1HE08AA
HP 65W USB-C Slim Power Adapter
3PN48AA
HP USB-C Notebook Power Bank
2NA10AA
QuickSpecs
HP Elite x2 G4
Options and Accessories (sold separately and availability may vary by country)
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 33
Security
HP Nano Keyed Cable Lock
1AJ39AA
HP Nano Dual-Head Keyed Cable Lock
1AJ41AA
UCC
HP UC Speaker Phone
4VW02AA
HP Stereo 3.5mm Headset
T1A66AA
HP Stereo USB Headset
T1A67AA
HP UC Wireless Mono Headset
W3K08AA
HP UC Wireless Duo Headset
W3K09AA
QuickSpecs
HP Elite x2 G4
Change Log
Not all configuration components are available in all regions/countries.
c06383137 DA 16446 - Worldwide Version 13 December 14, 2020
Page 34
Date of change:
Version History:
Description of change:
August 1, 2019
From V1 to V2
Updated
Sure Sense disclaimer
August 7, 2019
From V2 to V3
Updated
Displays section
September 9, 2019
From V3 to V4
Added
Intel® Optane™ and disclaimer for 1000 nit Sure View panel
October 4, 2019
From V4 to V5
Updated
Ports, Battery and Weight Sections
November 6, 2019
From V5 to V6
Updated
Keyboard
November 13, 2019
From V6 to V7
Updated
Security Section
January 6, 2020
From V7 to V8
Updated
Collaboration Keyboard weight
February 21, 2020
From V8 to V9
Added
Two panels in display section
February 27, 2020
From V9 t oV10
Updated
Copyright and footnote for fingerprint sensor
March 4, 2020
From V10 to V11
Removed
Power Bank, Accessories Section
October 19, 2020
From V11 to V12
Updated
Display section
December 14, 2020
From V12 to V13
Updated
MIL Updated
Copyright © 2020 HP Development Company, L.P. The only warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Intel®, Core™, Optane, Thunderbolt and Intel vPro are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Bluetooth is a trademark owned by its proprietor and used by HP Inc. under license. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum. SDXC is a registered trademark of SD-3C in the United States, other countries or both. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency.
Loading...
