HP EliteDesk 705 G5 Small Form Factor PC (9PJ68EA)
Overview
Expandable performance in a compact form factor
Powered for the enterprise, the high-performance HP EliteDesk 705
SFF delivers impressive value with powerful performance,
expandability, manageability and resilient security for the modern
workplace.
Fast, reliable performance
Enjoy the powerful performance of an AMD
Ryzen™ PRO Processor[3], robust storage,
and fast memory.
Enhanced security and manageability
Get a PC reinforced by HP Sure Start for
AMD[2], HP Sure Run[5], HP Manageability
Integration Kit[6], Microsoft System Center
Conguration Manager, and HP Sure Sense.
[7] Make device management easy with AMD
DASH and support for KVM (BIOS only).
Expansion that extends your
investment
Congure the space-saving design of the
expandable HP EliteDesk 705 SFF with two
bays and two slots, plus, two additional M.2
slots for storage, one M.2 slot for WLAN/BT,
and 11 USB ports.
Reliability for the long haul
This feature-rich PC is designed for a long
life-cycle with up to 18-months of platform
stability. It passed 120,000 hours of testing
in the HP Total Test Process[8] and is
designed to undergo MIL-STD 810G testing.
[9]
Features
Let nothing stand in your way
Power through your day with Windows 10 Pro and
the powerful security, collaboration and connectivity
features from HP.
[4]
Protect critical security processes
Keep your critical applications and processes running
even if malware tries to shut them down with the
self-healing protection of HP Sure Run.
Recovery simplied
Advanced malware attacks can destroy your OS and
disrupt your business. HP Sure Recover Gen2 ensures
fast, secure, and automated recovery of your OS with
only a network connection, so you can minimize
downtime and get back to business fast.
[10]
Browse condently
Help protect your PC from websites and read only
Microsoft Office and PDF attachments with embedded
malware, ransomware, or viruses with hardware-
enforced security from HP Sure Click.
[11]
[2] HP Sure Start for AMD is available on select HP PCs with AMD processors. See product specifications for
availability.
[3] Multi-core is designed to improve performance of certain software products. Not all customers or software
applications will necessarily benefit from use of this technology. Performance and clock frequency will vary
depending on application workload and your hardware and software configurations. AMD’s numbering is not a
measurement of clock speed.
[5] See product specifications for availability.
[6] HP Manageability Integration Kit can be downloaded from
http://www8.hp.com/us/en/ads/clientmanagement/overview.html.
[7] HP Sure Sense requires Windows 10. See product specifications for availability.
[8] HP Total Test Process testing is not a guarantee of future performance under these test conditions.
Accidental damage requires an optional HP Accidental Damage Protection Care Pack.
[9] MIL-STD testing is pending and is not intended to demonstrate fitness for U.S. Department of Defense
contract requirements or for military use. Test results are not a guarantee of future performance under these
test conditions. Damage under the MIL STD test conditions or any accidental damage requires an optional HP
Accidental Damage Protection Care Pack.
[4] Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or
separately purchased hardware, drivers and/or software to take full advantage of Windows functionality.
Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional
requirements may apply over time for updates. See http://www.windows.com.
[10] Not available on platforms with multiple internal storage drives. You must back up important files, data,
photos, videos, etc. before using HP Sure Recover to avoid loss of data.
[11] HP Sure Click supports Microsoft® Internet Explorer and Chromium™. Supported attachments include
Microsoft Office (Word, Excel, PowerPoint) and PDF files in read only mode, when Microsoft Office or Adobe
Acrobat are installed.
Specications
Form factor Small form factor
Operating system Windows 10 Pro 64
Processor family AMD Ryzen™ 5 PRO processor
Processor
AMD Ryzen™ 5 PRO 3400G (3.7 GHz base clock, up to 4.2 GHz max boost
clock, 4 MB L3 cache, 4 cores)
[6,7]
Chipset AMD PRO 560
Memory 16 GB DDR4-2666 SDRAM (1 X 16 GB)
Memory Slots 4 DIMM
Internal Storage 512 GB PCIe® NVMe™ TLC M.2 SSD
Internal drive bays One 3.5" HDD convertible to two 2.5" HDD
External drive bays 1 slim ODD
Optical drive HP 9.5 mm Slim DVD-Writer
Graphics Integrated
Graphics (integrated) AMD Radeon™ Vega 11 Graphics
Audio
Conexant CX20632 codec, universal audio jack for headset front port,
audio line in and out rear ports (3.5 mm), multi-streaming capable
Minimum dimensions (W x D x H) 9.5 x 27 x 29.6 cm
Weight
4.53 kg
(Exact weight depends on configuration.)
Keyboard HP USB Slim Business Keyboard
Pointing device HP USB wired optical mouse
Ports
1 headset connector; 1 SuperSpeed USB Type-C® 10Gbps signaling rate; 4
SuperSpeed USB 5Gbps signaling rate (1 fast charging)
Expansion slots
1 M.2 2230; 1 PCIe x1; 1 PCIe x16; 2 M.2 2230/2280
[8]
(1 M.2 slot for WLAN and 2 M.2 2230/2280 slots for storage.)
Ports
1 audio-in; 1 audio-out; 1 power connector; 1 RJ-45; 2 DisplayPort™ 1.2; 2
USB 2.0; 4 SuperSpeed USB 5Gbps signaling rate
Package dimensions (W x D x H) 39.9 x 23 x 49.9 cm
Package weight 7.33 kg
Network interface Intel® I210-T1 PCIe® GbE
Network interface type LAN
Power 180 W internal power supply, up to 92% efficiency, active PFC
Energy efficiency ENERGY STAR® certied
Management features
AMD DASH technology capable; HP BIOS Cong Utility (download); HP
Client Catalog (download); HP Cloud Recovery; HP Driver Packs
(download); HP Image Assistant Gen 4; HP Management Integration Kit for
Microsoft System Center Conguration Management Gen 3; HP System
Software Manager (download); Ivanti Management Suite
[23,24,25,37]
Sustainable impact specications Low halogen
Security management
DriveLock; Hood sensor; HP BIOSphere Gen5; HP Client Security Suite Gen
5; HP Power On Authentication; HP Sure Click; HP Sure Recover Gen2; HP
Sure Run Gen2; HP Sure Start for AMD; Master Boot Record Security;
Power-on password (via BIOS); Pre-boot Authentication; RAID
congurations; SATA port disablement (via BIOS); Serial enable/disable (via
BIOS); Setup password (via BIOS); Support for chassis padlocks and cable
lock devices; Trusted Platform Module TPM 2.0 Embedded Security Chip
shipped with Windows 10 (Common Criteria EAL4+ Certied)(FIPS 140-2
Level 2 Certied); USB enable/disable and boot control (via BIOS)
[26,27,28,29,30,31,32]
UPC number
(ABD) 194850177064; (ABZ) 194850256868; (UUW) 194850691232; (UUZ)
194850474606
Warranty
3 year (3-3-3) limited warranty and service offering includes 3 years of
parts, labor and on-site repair. Terms and conditions vary by country.
Certain restrictions and exclusions apply.
Additional specications
Additional storage 5-in-1 SD card reader
Datasheet photo 1 Publication photos/Picard_1.jpg
Datasheet photo 2 Publication photos/hp-carepack-updated.jpg
Datasheet photo 3 Publication photos/Picard_3.jpg
Datasheet photo 4 Publication photos/Picard_4.jpg
Datasheet photo 5 Publication photos/Picard_5.jpg
Datasheet publication number 4AA7-6364
ECC memory No
External I/O ports footnote
number
[9]
Graphic card footnote number [16,17,18]
I/O Port location Rear
I/O Port location Front
Legal tagline HP recommends Windows 10 Pro for business
MDA key selling point Windows 10 Pro or other operating systems available
Memory and storage 16 GB memory; 512 GB SSD storage
Memory layout (slots & size) 1 x 16 GB
Memory module type DIMM
Memory size 16
Memory size uom GB
Memory speed 2666
Memory speed uom MHz
Memory type DDR4
Number of memory slots 1
Operating humidity range 10 to 90% RH
Operating temperature range 10 to 35°C
Operating temperature range 50 to 95°F
Package dimensions (W x D x H) 15.71 x 9.06 x 19.65 in
Processor Brand AMD
Processor base frequency 3.7
Processor base frequency uom GHz
Processor cache 6 MB L3
Processor core 4
Processor family Ryzen™ 5 PRO
