HP EliteDesk 705 QuickSpecs

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Overview

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 1

HP EliteDesk 705 G4 Desktop Mini Business PC

1.

USB Type-C™ (charge support up to 5V/3A)

5.

Universal Audio Jack with CTIA headset support

2.

USB 3.1 Gen 1 Type A

6.

Hard Drive activity light

3.

USB 3.1 Gen 1 Type A (charge support up to 5V/1.5A)

7.

Dual-state power button

4.

Headset Connector

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Overview

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 2

HP EliteDesk 705 G4 Desktop Mini Business PC

1.

DisplayPort™ 1.2

7.

WLAN External Antenna Punchout

2.

USB 3.1 Gen 1 Type A

8.

Standard lock slot (10 mm)

3.

Configurable Option card slot (Choice of DisplayPort™ 1.2,

HDMI™ 2.0, VGA, USB Type-C™ with alt mode display, Discrete
Graphics Option Card with DisplayPort™ 1.4) (Availability

depends on model)

9.

10.

11.

Cover Release Thumbscrew
WLAN Internal Antenna
Padlock Loop

4.

USB 3.1 Gen 1 Type A
allows for wake from S4 with keyboard/mouse when
connected and enabled in BIOS

5.

RJ-45 Network Adapter

6.

Power connector

Not Shown

Slots

(1) Internal M.2 2230 connector for WLAN
(1) Internal M.2 SSD storage (2230 or 2280 connector)

Bays

(1) 2.5- inch SATA drive Bay

Mounting

Support for

- VESA 100 mounting system on bottom of PC chassis

- VESA Sleeve

- Quick Release Bracket

- B300/B500 Mounting bracket

- 100mm VESA Plate Integrated

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Overview

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 3

HP EliteDesk 705 G4 Microtower

1.

5.25-inch Half-Height Drive Bay (behind bezel)

6.

Universal Audio Jack with CTIA headset support

2.

Slim optical drive (optional)

7.

USB 2.0 port (charge support up to 5V/1.5A)

3.

SD 4 Card Reader (optional)

8.

USB 2.0 port

4.

Dual-state power button

9.

USB 3.1 Gen 1 ports (2)

5.

Hard Drive activity light

10.

USB Type-C™ port (charge support up to 5V/3A)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Overview

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 4

HP EliteDesk 705 G4 Microtower

1.

Audio-out jack for powered audio devices

6.

USB 2.0 ports with wake from S4 (2)

2.

Dual-Mode DisplayPort™ 1.2 (2)

7.

Standard lock slot

3.

Optional port (DisplayPort™ 1.2, HDMI, VGA or USB Type-C™) (USB­C™ option has alt mode DisplayPort™ 1.2 or 15W output) - shown

here with VGA port installed

8.

RJ-45 Network Adapter

9.

Optional serial port - shown here installed

4.

USB 3.1 Gen1 ports (2)

10.

Power connector

5.

USB 2.0 ports (2)

11.

Audio-in

Not shown

Slots

Bays

(1) PCI Express x16 graphics connectors

(2) 2.5" internal storage drive bay

(3) PCI Express x1

(1) 3.5” internal storage drive bay (convertible to 2.5”)

(1) internal M.2 SSD storage (2230 or 2280 connector)
(1) internal M.2 WLAN (2230 connector)

(1) 9.5mm slim optical drive bay
(1) 5.25" external half-height drive bay

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 5

HP EliteDesk 705 G4 Small Form Factor Business PC

1.

9.5mm slim optical drive (optional)

6.

USB 2.0 port (charge support up to 5V/1.5A)

2.

SD 4 card reader (optional)

7.

Universal Audio Jack with CTIA headset support

3.

USB Type-C™ (charge support up to 5V/3A)

8.

Hard Drive activity light

4.

USB 3.1 Gen 1 ports (2)

9.

Dual-state power button

5.

USB 2.0 port

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 6

HP EliteDesk 705 G4 Small Form Factor Business PC

1.

Audio-in connector

7.

RJ-45 Network Adapter

2.

Audio-out connector for powered audio devices

8.

USB 2.0 ports with wake from S4 (2)

3.

Dual-Mode DisplayPort™ 1.2 (2)

9.

USB 3.1 Gen 1 (2

4.

Serial Port - shown here not installed

10.

USB 2.0 (2)

5.

Standard lock slot

11.

Power connector

6.

Optional port (DisplayPort™ 1.2, HDMI, VGA or USB Type­C™) (USB-C™ option has alt mode DisplayPort™ 1.2 or
15W output) - shown here with HDMI port installed

Not shown

Slots

Bays

(1) PCI Express x16 graphics connectors

(1) 3.5” internal storage drive bay (convertible to two 2.5”1)

(1) PCI Express x1

(1) 9.5mm slim optical drive bay

(1) internal M.2 SSD storage (2230 or 2280 connector)
(1) internal M.2 WLAN (2230 connector)

1. SFF can be configured with either (1) 3.5” or (2) 2.5” internal storage drive (2.5-inch drive needs adapter that can only be purchased when
configuring the PC from factory with a 2.5” drive)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 7

AT A GLANCE

• Choice of three form factors: Microtower, Small Form Factor and Desktop Mini

• Latest AMD® Ryzen™ PRO and Athlon PRO Processor with Radeon™ Vega Graphics

1

• 7th generation of AMD® Pro A-Series APU

•

DDR4 Synchronous Dynamic Random Access Memory (SDRAM) (Transfer rates up to 2933 MT/s)

1

• Processor support up to 65W on DM; up to 95W on MT/SFF

• Integrated AMD® Radeon™ Vega Graphics (AMD® Radeon™ on 7th gen) and optional Radeon™ RX discrete graphics

• Support for up to three monitors via two standard DisplayPort™ 1.2 connectors with multi-stream

2

and an optional third

video port connector which provides the following choices: HDMI, VGA, DisplayPort™ 1.2, or USB Type-C™ with
DisplayPort™ 1.2 for all platforms; USB Type-C™ with DisplayPort™ 1.2 for 705 G4 DM 35W (see Ports section for port

availability by platform)

• Selection of discrete graphic cards to configure systems to up to 7 displays (MT, SFF and DM 35W)

• AMD® Radeon™ discrete graphics enabling viewing immersive VR

• MT and SFF models can be configured with dual data drives in a RAID (limited configurations)

• Industry-standard AMD® DASH manageability

• HP Sure Click

• HP Sure Start Gen4

• HP Sure Run

• HP Sure Recover

• HP BIOSphere Gen4

• HP Client Security Manager Gen4

• High efficiency energy saving power supply options

• ENERGY STAR® certified. EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See

http://www.epeat.net for registration status by country4. Search keyword generator on HP’s 3rd party option store for

solar generator accessories at http://www.hp.com/go/options.

• CCC, CECP and SEPA Certified

• PC chassis and all internal components and modules are manufactured with low halogen content

3

• Arsenic-free

• Dust filter available (MT, SFF and DM 35W)

• Lengthy purchase lifecycles and image stability

• Protected by HP Services, including limited warranties up to 3-3-3 (terms and conditions vary by country; certain

restrictions and exclusions apply); Care Packs available with up to 5 years Next Business Day Onsite Hardware Support

• Integrated Conexant Audio Codec

• Compliance with CE (Class B) / FCC (Class B) / UL (UL609501) / CSA (CSA C22.2 No.60950-1-07) / ICES-003 / CCC / VCCI (Class

B) / KCC (Class B)

1. Multicore is designed to improve performance of certain software products. Not all customers or software applications will
necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware
and software configurations. AMD’s numbering is not a measurement of clock speed.

2. DisplayPort™ multi-stream monitors ‘daisy-chained’ together.

3. External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be low halogen.

4. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit www.epeat.net for more information

NOTE: See important legal disclosures for all listed specs in their respective features sections.

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 8

PRODUCT NAME

HP EliteDesk 705 G4 Microtower Business PC
HP EliteDesk 705 G4 Small Form Factor Business PC
HP EliteDesk 705 G4 Desktop Mini Business PC

OPERATING SYSTEM

Preinstalled

Windows® 10 Pro 641
Windows® 10 Pro 64 (National Academic License)2
Windows® 10 Home 641
Windows® 10 Home Single Language 641
FreeDos

Web-supported only

Windows® 7 64 bit
Windows 10 Enterprise 64

1. Not all features are available in all editions or versions of Window. Systems may require upgraded and/or separately purchased hardware,
drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always
enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.

2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10 Anniversary Update.
Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.

NOTE: Your product does not support Windows 8 or Windows 7. In accordance with Microsoft’s support policy, HP does not support the
Windows® 8 or Windows 7 operating system on products configured with Intel® and AMD® 7th generation and forward processors or provide
any Windows® 8 or Windows 7 drivers on http://www.support.hp.com

CHIPSET

DM

SFF

MT

AMD® B350 FCH

X

X

X

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 9

PROCESSORS

AMD® Ryzen™ with AMD®Radeon™ Vega Graphics APU and CPU*

DM

SFF

MT

AMD Ryzen™ 7 PRO 2700X CPU* (4.1 GHz Max Boost, 3.6 GHz base frequency, 20 MB, 95W,
Eight-Core)

X X

AMD Ryzen™ 7 PRO 2700 CPU* (4.1 GHz Max Boost, 3.2 GHz base frequency, 20 MB, 65W,
Eight-Core)

X X

AMD Ryzen™ 5 PRO 2600 CPU* (3.9 GHz Max Boost, 3.4 GHz base frequency, 19 MB, 65W,
Six-Core)

X X

AMD® Ryzen™ 5 PRO 2400G APU with AMD®Radeon™ Vega Graphics (3.9 GHz Max boost,

3.6 GHz base frequency, 6MB, 65W, Quad Core)

X X X

AMD® Ryzen™ 5 PRO 2400GE APU with AMD®Radeon™ Vega Graphics (3.8 GHz Max boost,

3.2 GHz base frequency, 6MB, 35W, Quad Core)

X

AMD® Ryzen™ 3 PRO 2200G APU with AMD®Radeon™ Vega Graphics (3.7 GHz Max boost,

3.5 GHz base frequency, 6MB, 65W, Quad Core)

X X X

AMD® Ryzen™ 3 PRO 2200GE APU AMD®Radeon™ Vega Graphics (3.6 GHz Max boost, 3.2
GHz base frequency, 6MB, 35W, Quad Core)

X

AMD® Athlon™ PRO 200GE APU with AMD®Radeon™ Vega Graphics (3.2 GHz Max boost,

3.2 GHz base frequency, 5MB, 35W, Dual Core)

X

7th Generation of AMD® Pro A-Series APU1

DM

SFF

MT

AMD® PRO A10-9700E APU with AMD® Radeon™ Graphics (3.5 GHz Max boost, 3.0 GHz
base frequency, 2MB, 35W, Quad Core)

X

AMD® PRO A10-9700 APU with AMD® Radeon™ Graphics (3.8 GHz Max boost, 3.5 GHz base
frequency, 2MB, 65W, Quad Core)

X X

AMD® PRO A8-9600 APU with AMD® Radeon™ Graphics (3.4 GHz Max boost, 3.1 GHz base
frequency, 2MB, 65W, Quad Core)

X X

AMD® PRO A6-9500 APU with AMD® Radeon™ Graphics (3.8 GHz Max boost, 3.5 GHz base
frequency, 1MB, 65W, Dual core)

X X

AMD® PRO A6-9500E APU with AMD® Radeon™ Graphics (3.4 GHz Max boost, 3.2 GHz base
frequency, 1MB, 35W, Dual core)

X

6th Generation of AMD® Pro A-Series APU1

DM

SFF

MT

AMD® PRO A12-8870E APU with AMD® Radeon™ Graphics (3.8 GHz Max boost, 2.9 GHz
base frequency, 2MB, 35W, Quad Core)

X

AMD® PRO A12-8870 APU with AMD® Radeon™ Graphics (4.2 GHz Max boost, 3.7 GHz base
frequency, 2MB, 65W, Quad Core)

X

AMD® PRO A10-8770E APU with AMD® Radeon™ Graphics (3.5 GHz Max boost, 2.8 GHz
base frequency, 2MB, 35W, Quad Core)

X

AMD® PRO A10-8770 APU with AMD® Radeon™ Graphics (3.8 GHz Max boost, 3.5 GHz base
frequency, 2MB, 65W, Quad Core)

X

AMD® PRO A6-8570E APU with AMD® Radeon™ Graphics (3.4 GHz Max boost, 3.0 GHz base
frequency, 1MB, 35W, Dual Core)

X

AMD® PRO A6-8570 APU with AMD® Radeon™ Graphics (3.8 GHz Max boost, 3.5 GHz base
frequency, 1MB, 65W, Dual Core)

X

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 10

1. Multi-core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit
from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software
configurations. AMD’s numbering is not a measurement of clock speed.

*. AMD® Ryzen PRO CPU requires discrete graphic card attached.

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 11

GRAPHICS

System Integrated Graphics

DM

SFF

MT

AMD® Radeon™ R5 Graphics

X X X

AMD® Radeon™ R7 Graphics

X X X

AMD Radeon™ Vega 8 Graphics

X X X

AMD Radeon™ Vega 11 Graphics

X X X

Optional Discrete Graphics Solutions

DM

SFF

MT

AMD® Radeon™ RX 550 4GB FH PCIe x16

X X

AMD® Radeon™ RX 560X 4GB GDDR5

X

AMD® Radeon™ RX 580 4GB FH PCIe x16

X

AMD® Radeon™ RX 580 8GB FH GDDR5

X

AMD® Radeon™ R7 430 2GB VGA+DP Graphics Card

X X

AMD® Radeon™ R7 430 2GB GDDR5 64bit DP+VGA

X X

AMD® Radeon™ R7 430 2GB GDDR5 64bit 2DP

X X

AMD® Radeon™ R7 430 2GB 2DP Graphics Card

X X

AMD® Radeon™ 520 1GB VGA + DP Graphics Card

X

NVIDIA GeForce GTX 1060 3GB GFX

X

NVIDIA GeForce GT 730 2GB DP DVI PCIe x8 GFX

X X

NVIDIA® GeForce® RTX 2060 6GB DP+HDMI+DVI-D

X

NOTE: As of 2019, AMD Radeon™ RX 560 is renamed to AMD Radeon™ RX 560X

STORAGE

3.5 inch SATA Hard Disk Drives (HDD)

DM

SFF

MT

HDD 1TB 7200RPM SATA-3 3.5in

X

X

HDD 2TB 7200RPM SATA-3 3.5in

X

X

HDD 500GB 7200RPM 3.5in

X

X

HP 1TB 7200rpm 3.5 SATA 6.0Gb/s NCQ Smart IV Hard Drive (16MB)

X

X

HP 500GB 7200rpm 3.5 SATA 6.0Gb/s Smart IV Hard Drive

X

X

2.5 inch SATA Hard Disk Drives (HDD)

DM

SFF

MT

500 GB 5400RPM 2.5in SATA SSHD

X X X

1 TB 5400RPM 2.5in SATA SSHD

X X X

2 TB 5400RPM 2.5in SATA SSHD

X

2.5 inch Solid State Drives (SSD)

DM

SFF

MT

HDD 500GB 7200RPM 2.5in

X X X

HDD 1TB 7200RPM 2.5in

X X X

HDD 2TB 5400RPM 2.5in

X X

HDD 500GB 7200RPM 2.5in Self Encrypted Drive OPAL2*

X X X

HDD 500GB 7200RPM 2.5in Federal Information Processing Standard*

X X X

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 12

NOTE: Storage Drivelock does not work with Self Encrypting or Optane based storage.

2.5 inch SATA Solid State Hybrid Drives (SSHD)

DM

SFF

MT

HDD 500GB 5400RPM 2.5in SSHD

X X X

HDD 1TB 5400RPM 2.5in SSHD

X X X

HDD 2TB 5400RPM 2.5in SSHD

2.5 inch Solid State Drives (SSD)

DM

SFF

MT

SSD 128GB 2.5in SATA Three Layer Cell

X X X

SSD 256GB 2.5in SATA Three Layer Cell

X X X

SSD 512GB 2.5in SATA Three Layer Cell

X X X

SSD 256GB 2.5in SATA Self Encrypted OPAL2 TLC*

X X X

SSD 512GB 2.5in SATA Self Encrypted OPAL2 TLC*

X X X

SSD 256GB 2.5in Federal Information Processing Standard*

X X X

SSD 512GB 2.5in Federal Information Processing Standard*

X X X

NOTE: Storage Drivelock does not work with Self Encrypting or Optane based storage.

M.2 PCIe NMVe Solid State Drives (SSD)

DM

SFF

MT

SSD 128GB M.2 2280 PCIe NVMe

X X

SSD 256GB M.2 2280 PCIe NVMe

X X X

SSD 512GB M.2 2280 PCIe NVMe

X X X

SSD 128GB M.2 2280 PCIe-3x2 NVMe Three Layer Cell

X X

SSD 256GB M.2 2280 PCIe NVMe Three Layer Cell

X X X

SSD 512GB M.2 2280 PCIe NVMe Three Layer Cell

X X X

SSD 1TB M.2 2280 PCIe NVMe Three Layer Cell

X X X

SSD 256GB M.2 2280 PCIe NVMe Self Encrypted OPAL2 Three Layer Cell*

X X X

SSD 512GB M.2 2280 PCIe NVMe Self Encrypted OPAL2 Three Layer Cell*

X X

HP 9.5mm Slim DVD-ROM Drive

X X

HP 9.5mm Slim SuperMulti DVD Writer Drive

X X

HP 9.5mm Slim Blu-Ray Writer Drive

X

X

NOTE: Storage Drivelock does not work with Self Encrypting or Optane based storage.

Media Card Reader

DM

SFF

MT

SD 4.0 with 5-in-1 Interface (Supports SD, SDXC, SDHC, UHS-I, UHS-II)

X

X

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows

10) of system disk is reserved for the system recovery software.

MEMORY

Max Memory Configuration

DM

SFF

MT

DDR4-2666 (Transfer rates up to 2666 MT/s), 32 GB, 2 SODIMM

1

X

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 13

DDR4-2666 (Transfer rates up to 2666 MT/s), 64 GB, 4 DIMM

X X

Memory Configuration

DM

SFF

MT

4GB (1x4GB) 2666 DDR4 1.2v DIMM

X X

8GB (2x4GB) 2666 DDR4 1.2v DIMM

X X

8GB (1x8GB) 2666 DDR4 1.2v DIMM

X X

16GB (2x8GB) 2666 DDR4 1.2v DIMM

X X

16GB (1x16GB) 2666 DDR4 1.2v DIMM

X X

32GB (2x16GB) 2666 DDR4 1.2v DIMM

X X

32GB (4x8GB) 2666 DDR4 1.2v DIMM

X X

64GB (4x16GB) 2666 DDR4 1.2v DIMM

X X

DM

SFF

MT

4 GB (1 x 4 GB) 2666 DDR4 SODIMM1

X

8 GB (2 x 4 GB) 2666 DDR4 SODIMM1

X

8 GB (1 x 8 GB) 2666 DDR4 SODIMM1

X

16 GB (2 x 8 GB) 2666 DDR4 SODIMM1

X

16 GB (1 x 16 GB) 2666 DDR4 SODIMM1

X

32 GB (2 x 16 GB) 2666 DDR4 SODIMM1`

X

1. Transfer rates up to 2133 MT/s: for processors with AMD Pro A-Series APU; Transfer rates up to 2666MT/s: for processors with AMD

Ryzen™ with AMD Radeon™.

NETWORKING/COMMUNICATIONS

Ethernet (RJ-45)

DM

SFF

MT

Realtek® RTL8111EPH (standard)

X X X

Wireless1

DM

SFF

MT

Intel® 3168 802.11 AC 1x1 with Bluetooth® 4.0 (Brazil)

X X

Intel® 7265 802.11AC 2x2 with Bluetooth® M.2 Combo Card non-vPro™ (Brazil)

X X

Intel® 9260 802.11 AC 2x2 +Bluetooth® 5 PCIe non-vPro™

X X X

Realtek® 802.11 AC 1x1 with Bluetooth® 4.2 LE M.2 PCIe

X X X

Realtek® 802.11 AC 2x2 with Bluetooth® 4.2 LE M.2 PCIe

X X

Intel® 8260 802.11AC 2x2 DualBand PCIe x1 Combo Card

X

Intel® 8260 802.11AC 2x2 DualBand M.2 Combo Card

X

1. Wireless access point and Internet service required and not included. Availability of public wireless access points limited. The specifications for the 802.11ac
WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to
communicate with other 802.11ac WLAN devices

KEYBOARDS AND POINTING DEVICES

Keyboards

DM

SFF

MT

HP Conferencing USB Keyboard

X X X

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 14

HP Wireless Collaboration Keyboard

X X X

HP USB and PS/2 Washable Keyboard

X X X

HP USB Smart Card (CCID) Keyboard

X X X

HP USB Business Slim Keyboard

X X X

HP USB Keyboard

X X X

HP PS/2 Business Slim Keyboard

X X

HP Wireless Business Slim Keyboard and Mouse

X X X

Mouse

DM

SFF

MT

HP PS/2 Mouse

X X

HP USB Optical Mouse

X X X

HP USB Premium Mouse

X X X

HP 1000dpi Laser Mouse USB

X X X

HP USB and PS/2 Washable Mouse

X X X

Antimicrobial USB Mouse1

X X X

HP Hardened USB Mouse1

X X X

1. Not available in all regions

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 15

SECURITY

DM

SFF

MT

Trusted Platform Module (TPM) 2.0 (Infineon SLB9670). Common Criteria EAL4+
Certified. FIPS 140-2 Level 2 Certified

X X X

PORTS

I/O Ports – Standard

DM

SFF

MT

USB 2.0

N/A

2 including 1 fast charging

(front);

4 including 2 wake from S4

(rear)

2 including 1 fast charging

(front);

4 including 2 wake from S4

(rear)

USB 3.1 Gen 1

2 front; 4 rear

2 front; 2 rear

2 front; 2 rear

USB 3.0 Type-C™ (15W)

1 front; 1 rear (option)

1 front; 1 rear (option)

1 front; 1 rear (option)

Video

2 DisplayPort™ 1.2 (rear),

1 Configurable video port (rear)

(Choice of DisplayPort™ 1.4,

HDMI™ 2.0, VGA, or USB Type-

C™ with alt mode display)

For models with discrete

graphics:

1 DisplayPort™ 1.4 (rear)

2 DisplayPort™ 1.2 (rear),

1 Configurable video port

(rear) (Choice of DisplayPort™

1.2, HDMI™ 2.0, VGA, or USB

Type-C™ with alt mode

display port or 15W output)

2 DisplayPort™ 1.2 (rear),
1 Configurable video port

(rear) (Choice of DisplayPort™

1.2, HDMI™ 2.0, VGA, USB

Type-C™ with alt mode display

port or 15W output)

Audio

1 Headset (front),

1 Universal Audio Jack with

CTIA headset support (front)

1 Headset (front);

1 Audio-out (rear),

1 Audio-in (rear)

1 Headset (front);

1 Audio-out (rear),

1 Audio-in (rear)

Network Interface

RJ45

RJ45

RJ45

I/O Ports – Optional

DM

SFF

MT

Serial (RS-232)

1 (rear)(option)

1 (rear) (option)

1 (rear) (option)

Serial (RS-232) and PS/2
combination

N/A

1 (rear) (option)

1 (rear) (option)

I/O Ports – Internal Ports

DM

SFF

MT

Internal SATA storage
connector(s)

N/A 3 4

Internal SATA storage
connector(s)

N/A 3 4

Internal SATA storage
connector (Data and Power)

1

N/A

N/A

NOTE: For Desktop Mini with M.2 Storage config, there will be no SATA drive bracket. If you plan to use or upgrade the storage with any 2.5" SATA
drive, please select a DM SATA Drive Bracket (available as both factory configured and after market option).

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 16

Slots

DM

SFF

MT

M.2 PCIe

(1) M.2 PCIe x1 2230 (for WLAN)

(1) M.2 PCIe x2 2280/2230

Combo (for storage)

(1) M.2 PCIe x1 2230 (for WLAN)

(1) M.2 PCIe x2 2280/2230

Combo (for storage)

(1) M.2 PCIe x1 2230 (for

WLAN)

(1) M.2 PCIe x2 2280/2230

Combo (for storage)

PCI Express x1 (v3.0)

N/A 1 3

PCI Express x16 (v3.0)

N/A

1

1

Bays

DM

SFF

MT

5.25" Half Height ODD

N/A

N/A

1

9.5mm Slim ODD

N/A

1

1

Secure Digital (SD) Reader

N/A

1

1

2.5” internal storage drive

1 (optional)

23

2

3.5” internal storage drive

N/A

1

1

NOTE: SFF can be configured with either (1) 3.5” or (2) 2.5” internal storage drive (2.5-inch drive needs adapter that can only be purchased
when configuring the PC from factory with a 2.5" drive.)
NOTE: The MT can support a single graphics card up to 75W. When configured with dual graphics cards support is limited to 35W for each.

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 17

SOFTWARE COMPONENTS AND APPLICATIONS WITH WINDOWS

BIOS

HP BIOSphere Gen417
HP DriveLock & Automatic DriveLock20
BIOS Update via Network
Master Boot Record Security
Power On Authentication
HP Secure Erase18
Absolute Persistence Module19
Pre-boot Authentication
HP Wireless Wakeup

Software
HP Native Miracast Support15
HP LAN-Wireless Protection
HP Velocity

HP Hotkey Support – CMIT
HP Recovery Manager
HP JumpStart
HP Support Assistant21
HP Noise Cancellation Software
Buy Office

Manageability Features
HP Driver Packs22
HP System Software Manager (SSM)
HP BIOS Config Utility (BCU)
HP Client Catalog
HP Manageability Integration Kit Gen223
Ivanti Management Suite

24

HP Cloud Recovery37

Client Security Software
HP Client Security Suite Gen425 including:
HP Security Manager26 (including Credential Manager, HP Password Manager, HP Spare Key)
HP Device Access Manager
HP Power On Authentication
Microsoft Defender27

Security Management
HP Secure Erase18
TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified) (FIPS 140-2 Level 2 Certified)32
SATA 0,1 port disablement (viaBIOS)
RAID configurations33
Serial, USB enable/disable (viaBIOS)
Power-on password (viaBIOS)
Setup password (viaBIOS)
Support for chassis padlocks and cable lock devices
Integrated hood sensor
HP Sure Start Gen430
HP Sure Run35
HP Sure Recover

36

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 18

15. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming

17. HP BIOSphere Gen4 requires Intel® or AMD® 8th Gen processors. Features may vary depending on the platform and configurations.

18. For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88 "Clear" sanitation method.

19. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be
purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery
Guarantee is a limited warranty. Certain conditions apply. For full details visit:

http://www.absolute.com/company/legal/agreements/computrace-agreement. Data Delete is an optional service provided by

Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a
Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.

20. Storage Drivelock does not work with Self Encrypting or Optane based storage.

21. HP Support Assistant requires Windows and Internet access.

22. HP Driver Packs not preinstalled, however available for download at http://www.hp.com/go/clientmanagement.

23. HP Manageability Integration Kit can be downloaded from http://www8.hp.com/us/en/ads/clientmanagement/overview.html

24. Ivanti Management Suite subscription required.

25. HP Client Security Suite Gen 4 requires Windows and Intel® or AMD® 8th generation processors.

26. HP Password Manager requires Internet Explorer or Chrome or FireFox. Some websites and applications may not be supported. User may
need to enable or allow the add-on / extension in the internet browser.

27. Windows Defender Opt in Windows 10 and internet connection required for updates.

30. HP Sure Start Gen4 is available on HP EliteDesk products equipped with Intel® 8th generation or AMD processors

32. Firmware TPM is version 2.0. Hardware TPM is v1.2, which is a subset of the TPM 2.0 specification version v0.89 as implemented by Intel
Platform Trust Technology (PTT).

33. RAID configuration is optional and does require a second hard drive. RAID 1 is pre-installed and functionality will require a second hard
drive.

35. HP Sure Run is available on HP Elite products equipped with 8th generation Intel® or AMD® processors.

36. HP Sure Recover is available on HP Elite PCs with 8th generation Intel® or AMD® processors and requires an open, wired network
connection. Not available on platforms with multiple internal storage drives, Intel® Optane™. You must back up important files, data,
photos, videos, etc. before use to avoid loss of data.

37. HP Cloud Recovery is available for HP Elite and Pro desktops and laptops PCs with Intel® or AMD processors and requires an open, wired
network connection. Note: You must back up important files, data, photos, videos, etc. before use to avoid loss of data. Detail please refer
to: https://support.hp.com/us-en/document/c05115630

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 19

ENVIRONMENTAL & INDUSTRY

Environmental Data HP EliteDesk 700 Desktop Mini G4 series

Eco-Label Certifications
& declarations

This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:

• IT ECO declaration

• US ENERGY STAR®

• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See

http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd party

option store for solar generator accessories at http://www.hp.com/go/options.

*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit

http://www.epeat.net for more information.

System Configuration

The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a “Typically Configured Desktop”.

Energy Consumption
(in accordance with US
ENERGY STAR® test
method)

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation (Short
idle)

10.789

10.858

10.739

Normal Operation (Long
idle)

10.488

10.538

10.458

Sleep

0.815

0.851

0.81

Off

0.756

0.809

0.74

NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable
U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model
family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is
for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a
Microsoft Windows® operating system.

Heat Dissipation*

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation (Short
idle)

36.7905

37.0258

36.62

Normal Operation (Long
idle)

35.7641

35.9346

35.6618

Sleep

2.7792

2.9019

2.7621

Off

2.578

2.7587

2.5234

NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.

Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)

Sound Power

(L

WAd

, bels)

Sound Pressure

(L

pAm

, decibels)

Typically Configured –
Idle

3.1

20

Fixed Disk – Random
writes

4.4

33

Longevity and Upgrading

This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:

Spare parts are available throughout the warranty period and or for up to “5” years after the end of

production.

Batteries

This battery(s) in this product comply with EU Directive 2006/66/EC

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 20

Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight

Battery size: CR2032 (coin cell)
Battery type: Lithium

Additional Information

• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive ­2011/65/EC.

• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.

• This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water

and Toxic Enforcement Act of 1986).

• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.

• This product contains 0% post-consumer recycled plastic (by wt.)

• This product is 95.1% recycle-able when properly disposed of at end of life.

Packaging Materials

External:

PAPER/Corrugated

Internal:

PLASTIC/EPE (Expanded Polyethylene)

PLASTIC/Polyethylene low density

Material Usage

This product does not contain any of the following substances in excess of regulatory limits (refer to
the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):

• Asbestos

• Certain Azo Colorants

• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics

• Cadmium

• Chlorinated Hydrocarbons

• Chlorinated Paraffins

• Formaldehyde

• Halogenated Diphenyl Methanes

• Lead carbonates and sulfates

• Lead and Lead compounds

• Mercuric Oxide Batteries

• Nickel – finishes must not be used on the external surface designed to be frequently handled or

carried by the user.

• Ozone Depleting Substances

• Polybrominated Biphenyls (PBBs)

• Polybrominated Biphenyl Ethers (PBBEs)

• Polybrominated Biphenyl Oxides (PBBOs)

• Polychlorinated Biphenyl (PCB)

• Polychlorinated Terphenyls (PCT)

• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been

voluntarily removed from most applications.

• Radioactive Substances

• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 21

Packaging Usage

HP follows these guidelines to decrease the environmental impact of product packaging:

• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging

materials.

• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.

• Design packaging materials for ease of disassembly.

• Maximize the use of post-consumer recycled content materials in packaging materials.

• Use readily recyclable packaging materials such as paper and corrugated materials.

• Reduce size and weight of packages to improve transportation fuel efficiency.

• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

End-of-life Management
and Recycling

HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP
sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly instructions)
is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions
may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who
integrate and re-sell HP equipment.
Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications

http://www8.hp.com/us/en/hp-information/environment/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K_
Certificate.pdf

and

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf

Environmental Data HP EliteDesk 700 Small Form Factor G4 series

Eco-Label Certifications
& declarations

This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:

• IT ECO declaration

• US ENERGY STAR®

• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See

http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd party

option store for solar generator accessories at http://www.hp.com/go/options.

*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit

http://www.epeat.net for more information.

System Configuration

The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a “Typically Configured Desktop”.

Energy Consumption
(in accordance with US
ENERGY STAR® test
method)

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation (Short
idle)

22.49

22.24

22.35

Normal Operation (Long
idle)

21.1

21.25

20.87

Sleep

1.05

1.06

1.05

Off

1.08

1.09

1.08

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 22

NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable
U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model
family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is
for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a
Microsoft Windows® operating system.

Heat Dissipation*

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation (Short
idle)

76.6909

75.8384

76.2135

Normal Operation (Long
idle)

71.951

72.4625

71.1667

Sleep

3.5805

3.6146

3.5805

Off

3.6828

3.7169

3.6828

NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.

Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)

Sound Power

(L

WAd

, bels)

Sound Pressure

(L

pAm

, decibels)

Typically Configured –
Idle

3.9

28

Fixed Disk – Random
writes

4.4

33

Active Mode
*Pinnacle Ridge with
GT730 graphic card

3.7

28

Longevity and Upgrading

This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:

Spare parts are available throughout the warranty period and or for up to “5” years after the end of

production.

Batteries

This battery(s) in this product comply with EU Directive 2006/66/EC

Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight

Battery size: CR2032 (coin cell)
Battery type: Lithium

Additional Information

• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive ­2011/65/EC.

• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.

• This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water

and Toxic Enforcement Act of 1986).

• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.

• This product contains 0% post-consumer recycled plastic (by wt.)

• This product is 95.1% recycle-able when properly disposed of at end of life.

Packaging Materials

External:

PAPER/Corrugated

Internal:

PLASTIC/EPE (Expanded Polyethylene)

PLASTIC/Polyethylene low density

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 23

Material Usage

This product does not contain any of the following substances in excess of regulatory limits (refer to
the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):

• Asbestos

• Certain Azo Colorants

• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics

• Cadmium

• Chlorinated Hydrocarbons

• Chlorinated Paraffins

• Formaldehyde

• Halogenated Diphenyl Methanes

• Lead carbonates and sulfates

• Lead and Lead compounds

• Mercuric Oxide Batteries

• Nickel – finishes must not be used on the external surface designed to be frequently handled or

carried by the user.

• Ozone Depleting Substances

• Polybrominated Biphenyls (PBBs)

• Polybrominated Biphenyl Ethers (PBBEs)

• Polybrominated Biphenyl Oxides (PBBOs)

• Polychlorinated Biphenyl (PCB)

• Polychlorinated Terphenyls (PCT)

• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been

voluntarily removed from most applications.

• Radioactive Substances

• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

Packaging Usage

HP follows these guidelines to decrease the environmental impact of product packaging:

• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.

• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.

• Design packaging materials for ease of disassembly.

• Maximize the use of post-consumer recycled content materials in packaging materials.

• Use readily recyclable packaging materials such as paper and corrugated materials.

• Reduce size and weight of packages to improve transportation fuel efficiency.

• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

End-of-life Management
and Recycling

HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP
sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly instructions)
is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions
may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who
integrate and re-sell HP equipment.
Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications

http://www8.hp.com/us/en/hp-information/environment/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K_
Certificate.pdf

and

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 24

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 25

Environmental Data HP EliteDesk 700 MicroTower G4 series

Eco-Label Certifications
& declarations

This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:

• IT ECO declaration

• US ENERGY STAR®

• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See

http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd party

option store for solar generator accessories at http://www.hp.com/go/options.

*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit

http://www.epeat.net for more information.

System Configuration

The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a “Typically Configured Desktop”.

Energy Consumption
(in accordance with US
ENERGY STAR® test
method)

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation (Short
idle)

22.22

22.682

23.569

Normal Operation (Long
idle)

21.409

21.432

21.753

Sleep

1.3327

1.2579

1.2692

Off

0.9518

0.8825

0.9171

NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable
U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model
family does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is
for a typically configured PC featuring a hard disk drive, a high efficiency power supply, and a
Microsoft Windows® operating system.

Heat Dissipation*

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation (Short
idle)

75.7702

77.3456

80.3703

Normal Operation (Long
idle)

73.0047

73.0831

74.1777

Sleep

4.5445

4.2894

4.328

Off

3.2456

3.0093

3.1273

NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.

Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)

Sound Power

(L

WAd

, bels)

Sound Pressure

(L

pAm

, decibels)

Typically Configured –
Idle

3.9

28

Fixed Disk – Random
writes

4.4

33

Longevity and Upgrading

This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:

Spare parts are available throughout the warranty period and or for up to “5” years after the end of

production.

Batteries

This battery(s) in this product comply with EU Directive 2006/66/EC

Batteries used in the product do not contain:

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 26

Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight

Battery size: CR2032 (coin cell)
Battery type: Lithium

Additional Information

• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive ­2011/65/EC.

• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.

• This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water

and Toxic Enforcement Act of 1986).

• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.

• This product contains 0% post-consumer recycled plastic (by wt.)

• This product is 95.1% recycle-able when properly disposed of at end of life.

Packaging Materials

External:

PAPER/Corrugated

Internal:

PLASTIC/EPE (Expanded Polyethylene)

PLASTIC/Polyethylene low density

Material Usage

This product does not contain any of the following substances in excess of regulatory limits (refer to
the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):

• Asbestos

• Certain Azo Colorants

• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics

• Cadmium

• Chlorinated Hydrocarbons

• Chlorinated Paraffins

• Formaldehyde

• Halogenated Diphenyl Methanes

• Lead carbonates and sulfates

• Lead and Lead compounds

• Mercuric Oxide Batteries

• Nickel – finishes must not be used on the external surface designed to be frequently handled or

carried by the user.

• Ozone Depleting Substances

• Polybrominated Biphenyls (PBBs)

• Polybrominated Biphenyl Ethers (PBBEs)

• Polybrominated Biphenyl Oxides (PBBOs)

• Polychlorinated Biphenyl (PCB)

• Polychlorinated Terphenyls (PCT)

• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been

voluntarily removed from most applications.

• Radioactive Substances

• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 27

Packaging Usage

HP follows these guidelines to decrease the environmental impact of product packaging:

• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging

materials.

• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.

• Design packaging materials for ease of disassembly.

• Maximize the use of post-consumer recycled content materials in packaging materials.

• Use readily recyclable packaging materials such as paper and corrugated materials.

• Reduce size and weight of packages to improve transportation fuel efficiency.

• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

End-of-life Management
and Recycling

HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP
sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly instructions)
is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions
may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who
integrate and re-sell HP equipment.
Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications

http://www8.hp.com/us/en/hp-information/environment/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K_
Certificate.pdf

and

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Standard Features and Configurable Components (availability may vary by country)

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 28

SERVICE AND SUPPORT

On-site Warranty15: Three-year (3-3-3) limited warranty delivers three years of on-site, next business day16 service for parts
and labor and includes free support 24 x 717. Three-year onsite and labor are not available in all countries. Service offers terms
up to 5 years by choosing an optional HP Care Pack. To choose the right level of service for your HP product, visit HP Care Pack
Central: http://www.hp.com/go/cpc.18

15. Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be offered in your
region.

16. On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not available
in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.

17. Technical telephone support applies only to HP-configured and third-party HP qualified hardware and software. Toll-free calling and 24 x
7 support may not be available in some countries.

18. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware
purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable HP terms and
conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights according to
applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty
provided with your HP Product.

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Graphics

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 29

GRAPHICS

AMD® Radeon™ 5 Graphics (Integrated on AMD® PRO A6-9500E & PRO A6-9500 APUs)

AMD® Radeon™ R7 Graphics (Integrated on AMD® PRO A10-9700E & PRO A10-9700 APUs)
AMD Radeon™ Vega 8 Graphics (Integrated on AMD® Ryzen™ 3 PRO 2200GE & Ryzen™ 3 PRO 2200G APUs)
AMD Radeon™ Vega 11 Graphics (Integrated on AMD® Ryzen™ 5 PRO 2400GE & Ryzen™ 5 PRO 2400G APUs)

Multi Display Support

Maximum of 3 displays supported by the integrated graphics

DisplayPort

Two DisplayPort outputs are standard. One DisplayPort output is optional.
AMD® PRO APUs and AMD® Ryzen™ APUs support
DP1.2 features including DP++, Audio, MST, HBR2, HDCP1.4 and a maximum resolution of
5128x3880@30Hz or 3840x2160@60Hz.

VGA Port (Optional)

Maximum Resolution of 2048x1536 at 60Hz

HDMI (Optional)

AMD® PRO APUs support HDMI 2.0 features and AMD® Ryzen™ APUs support HDMI 2.0a features.

All support HDCP1.4, audio and a maximum resolution of 4096x2160@60Hz

USB-C (Optional)

Supports DisplayPort Alt Mode

Memory

512MB when less than 8GB of system memory is installed
1GB when 8GB or more of system memory is installed

Maximum Color Depth

up to 10 bits

Graphics/Video API Support

AMD® PRO APUs:
DirectX 12
OpenCL 1.2
OpenGL 4.1
Dedicated decoding of the H.264 format at up to 4K and 60Hz.
Encoding H.264 video supported at 1080p120, 1440p60, and 2160p60

AMD® Ryzen™ APUs:
DirectX 12
Vulkan 1.0
OpenCL 2.0
OpenGL 4.5
Hardware-based decode of HEVC/H.265 main10 profile videos at resolutions up to 3840x2160 at
60Hz with 10-bit color for HDR content.
Dedicated decoding of the H.264 format at up to 4K and 60Hz.
Decoding the VP9 format at resolutions up to 3840x2160 using a hybrid approach where the
video and shader engines collaborate to offload work from the CPU.
Encode HEVC/H.265 at 1080p240, 1440p120, and 2160p60.
Encoding H.264 video is also supported at 1080p120, 1440p60, and 2160p60

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Graphics

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 30

AMD® Radeon™ RX550 4GB FH PCIe x16

Engine Clock

1183MHz

Memory Clock

7 Gbps

Memory Size(width)

4 GB(128-bit)

Memory Type

GDDR5

Max. Resolution(HDMI)

4096x2160 @ 60Hz

Max. Resolution(DP)

5120x2880 @ 60Hz

Multi Display Support

3 displays

HDCP Compliance

Yes

Rear I/O connectors(bracket)

HDMI, DPx2

Cooling(active/passive)

Active fan-sink(Active cooling with dynamic speed)

Total power consumption(W)

<62W

PCB form-factor with bracket

ATX (Full height) PCB with ATX single slot bracket

AMD® Radeon™ RX 560X

Architecture

Discrete GPU
AMD® GPU drives the integrated panel and all of the graphics output ports

DisplayPort

Multimode capable; supports HDCP, HDR, Display Port Audio (6 streams max), DisplayPort HBR3
link rates and Multi-Stream Technology for a maximum of 5 displays (including the integrated
panel and all attached displays)

HDMI

Supports HDMI 2.0b features
Supports HDCP 2.2, HDR

Memory

4GByte, 128bit wide GDDR5

Maximum Color Depth

up to 12 bits/color

Graphics/Video API Support

DirectX 12
OpenCL 2.0
OpenGL 4.5
AMD® Unified Video Decoder (UVD)

Rear I/O connector

1 DP

Max. Resolution (VGA)

2048 x 1536@60Hz

Max. Resolution (HDMI)

4096 x 2160@60Hz

Max. Resolution (DP)

5120 x 2880@60Hz

AMD® Radeon™ RX580 4GB FH PCIe x16

Engine Clock

1266 MHz

Memory Clock

8gbs

Memory Size(width)

4 GB(256-bit)

Memory Type

128M x 32 GDDR5

Max. Resolution(HDMI)

4096x2160@60Hz

Max. Resolution(DP)

5120x3200@60Hz

Multi Display Support

4 displays

HDCP Compliance

Yes

Rear I/O connectors(bracket)

DP*3 + HDMI

Cooling(active/passive)

Active fan-sink (Active cooling with dynamic speed)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Graphics

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 31

Total power consumption(W)

<150W

PCB form-factor with bracket

ATX (Full height) PCB with ATX dual slot bracket

AMD® Radeon™ RX580 8GB GDDR5 Graphics Card

Engine Clock

1266 MHz

Memory Clock

4000 MHz

Memory Size(width)

8 GB (256-bit)

Memory Type

256M x 32 GDDR5

Max. Resolution(HDMI)

4096x2160@60Hz

Max. Resolution(DP)

5120x3200@60Hz

Multi Display Support

4 displays

HDCP Compliance

Yes

Rear I/O connectors(bracket)

HDMI + DPx3

Cooling(active/passive)

Active fan-sink (Active cooling with dynamic speed)

Total power consumption(W)

<150W

PCB form-factor with bracket

ATX (Full height) PCB with ATX dual slot bracket

AMD® Radeon™ R7 430 2GB VGA+DP Graphics Card

Engine Clock

780 MHz

Memory Clock

1100 MHz

Memory Size(width)

2 GB(128-bit)

Memory Type

128M x 32 GDDR5

Max. Resolution(VGA)

2048x1536

Max. Resolution(DP)

4096x2160@60Hz

Multi Display Support

2 displays

HDCP Compliance

yes

Rear I/O connectors(bracket)

VGA+DP

Cooling(active/passive)

Active fan-sink (Active cooling with dynamic speed)

Total power consumption(W)

<50W

PCB form-factor with bracket

LP PCB with FH/LP bracket

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Graphics

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 32

AMD® Radeon™ R7 430 2GB GDDR5 DP+VGA Graphics Card

Engine Clock

780 MHz

Memory Clock

1100 MHz

Memory Size(width)

2 GB(64-bit)

Memory Type

256M x 32 GDDR5

Max. Resolution(VGA)

2048x1536

Max. Resolution(DP)

4096x2160@60Hz

Multi Display Support

2 displays

HDCP Compliance

yes

Rear I/O connectors(bracket)

DP+VGA

Cooling(active/passive)

Active fan-sink (Active cooling with dynamic speed)

Total power consumption(W)

<50W

PCB form-factor with bracket

LP PCB with FH/LP bracket

AMD® Radeon™ R7 430 2GB GDDR5 2DP Graphics Card

Engine Clock

780 MHz

Memory Clock

1100 MHz

Memory Size(width)

2 GB(64-bit)

Memory Type

256M x 32 GDDR5

Max. Resolution(DP)

4096x2160@60Hz

Multi Display Support

2 displays

HDCP Compliance

yes

Rear I/O connectors(bracket)

DPx2

Cooling(active/passive)

Active fan-sink (Active cooling with dynamic speed)

Total power consumption(W)

<50W

PCB form-factor with bracket

LP PCB with FH/LP bracket

AMD® Radeon™ R7 430 2GB 2DP Graphics Card

Engine Clock

780 MHz

Memory Clock

1100 MHz

Memory Size(width)

2 GB(128-bit)

Memory Type

128M x 32 GDDR5

Max. Resolution(DP)

4096x2160@60Hz

Multi Display Support

2 displays

HDCP Compliance

yes

Rear I/O connectors(bracket)

2DP

Cooling(active/passive)

Active fan-sink(Active cooling with dynamic speed)

Total power consumption(W)

<50W

PCB form-factor with bracket

LP PCB with FH/LP bracket

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Graphics

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 33

AMD® Radeon™ 520 1GB Graphics Card

Engine Clock

780 MHz

Memory Clock

1100 MHz

Memory Size(width)

1GB(32-bit)

Memory Type

256M x 32 GDDR5

Max. Resolution(VGA)

2048x1536

Max. Resolution(DP)

4096x2160@60Hz

Multi Display Support

2 displays

HDCP Compliance

Yes

Rear I/O connectors(bracket)

VGA+DP

Cooling(active/passive)

Active fan-sink (Active cooling with dynamic speed)

Total power consumption(W)

<50W

PCB form-factor with bracket

LP PCB with FH/LP bracket

NVIDIA® GeForce® GTX 1060 3 GB Graphics Card

Engine Clock

1506 MHz

Memory Clock

4004 MHz

Memory Size(width)

3 GB(192-bit)

Memory Type

128M x 32 GDDR5

Max. Resolution(DVI)

2560x1600@60Hz

Max. Resolution(HDMI)

4096x2160@60Hz

Max. Resolution(DP)

5120x3200@60Hz

Multi Display Support

4 displays

HDCP Compliance

Yes

Rear I/O connectors(bracket)

DVI-D+HDMI+DPx3

Cooling(active/passive)

Active fan-sink (Active cooling with dynamic speed)

Total power consumption(W)

<120W

PCB form-factor with bracket

ATX (Full height) PCB with ATX dual slot bracket

NVIDIA® GeForce® GT730 2GB DP DVI PCIe x8 GFX

Engine Clock

902 MHz

Memory Clock

1250 MHz

Memory Size(width)

2 GB (64-bit)

Memory Type

256Mx32 GDDR5

Max. Resolution(DVI)

2560 x 1600 x 30 bpp @ 60Hz (Dual Link)

Max. Resolution(DP)

4096 x 2160 x 24 bpp @ 60 Hz (DP1.2)

Multi Display Support

Up to 2 displays

HDCP Compliance

Yes

Rear I/O connectors(bracket)

DL DVI-I + DP

Cooling(active/passive)

Active fan-sink (Active cooling with dynamic speed)

Total power consumption(W)

35 W

PCB form-factor with bracket

2-pin fan connector for fan sink power/speed control

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Graphics

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 34

NVIDIA® GeForce® RTX 2060 6 GB Graphics Card

Engine Clock

1680 MHz

Memory Clock

7000 MHz

Memory Size(width)

6 GB(192-bit)

Memory Type

256M x 32 GDDR6

Max. Resolution(DVI)

2560x1600@60Hz

Max. Resolution(HDMI)

4096x2160@60Hz

Max. Resolution(DP)

7680x4320@60Hz

Multi Display Support

3 displays

HDCP Compliance

Yes

Rear I/O connectors(bracket)

DVI+HDMI+DP

Cooling(active/passive)

Active fan-sink (Active cooling with dynamic speed)

Total power consumption(W)

<170W

PCB form-factor with bracket

ATX (Full height) PCB with ATX dual slot bracket

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Storage

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 35

STORAGE

HP 500 GB 7.2K SATA 6.0Gb/s 2.5” Hard Disk Drive

Capacity

500 GB

Rotational Speed

7,200 rpm

Interface

SATA 6 Gb/s

Buffer Size

16 MB

Logical Blocks

976,773,168

Seek Time

12 ms (Average)

Height

0.267 in/6.8 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows

10) of system disk is reserved for the system recovery software.

HP 1 TB 7.2K SATA 6.0Gb/s 2.5” Hard Disk Drive

Capacity

1 TB

Rotational Speed

7,200 rpm

Interface

SATA 6 Gb/s

Buffer Size

32 MB

Logical Blocks

1,953,525,168

Seek Time

12 ms (Average)

Height

0.374 in/9.5 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows

10) of system disk is reserved for the system recovery software.

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Storage

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 36

HP 500 GB SATA 6G 2.5” 8GB Solid State Hybrid Drive (SSHD)

Capacity

500 GB

Rotational Speed

5,400 rpm

Drive Type

Solid State Hybrid Drive (SSHD) technology with NAND Flash

Interface

SATA 6 Gb/s

Buffer Size

64 MB

NAND Flash

8 GB

Seek Time

12 ms (Average)

Height

0.267 in/6.8 mm (nominal)

Width

2.75 in/70 mm (nominal)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows

10) of system disk is reserved for the system recovery software.

HP 1 TB SATA 6G 2.5" 8GB Solid State Hybrid Drive (SSHD)

Capacity

1 TB

Rotational Speed

5,400 rpm

Drive Type

Solid State Hybrid Drive (SSHD) technology with NAND Flash

Interface

SATA 6 Gb/s

Buffer Size

64 MB

NAND Flash

8 GB

Seek Time

12 ms (Average)

Height

0.374 in/9.5 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows

10) of system disk is reserved for the system recovery software.

HP 2 TB SATA 6G 2.5" 8 GB Solid State Hybrid Drive (SSHD)

Capacity

2 TB

Rotational Speed

5,400 rpm

Drive Type

Solid State Hybrid Drive (SSHD) technology with NAND Flash

Interface

SATA 6 Gb/s

Buffer Size

128 MB

NAND Flash

8 GB

Seek Time

12 ms (Average)

Height

0.374 in/9.5 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Storage

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 37

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows

10) of system disk is reserved for the system recovery software.

HP 2 TB 5.4K SATA 6.0Gb/s 2.5” Hard Disk Drive

Capacity

2 TB

Rotational Speed

5,400 rpm

Interface

SATA 6 Gb/s

Buffer Size

128 MB

Logical Blocks

3,907,050,336

Seek Time

12 ms (Average)

Height

0.374 in/9.5 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows

10) of system disk is reserved for the system recovery software.

500 GB 2.5” FIPS 140-2 SED Solid State Drive

Capacity

500 GB

Architecture

Self-Encrypting (SED) Solid State Drive with SATA interface

Interface

SATA 6 Gb/s

Buffer Size

32 MB

Logical Blocks

976,773,168

Seek Time

12 ms (Average)

Height

0.267 in/6.8 mm (nominal)

Width

2.75 in/70 mm (nominal)

Operating Temperature

41° to 131° F (5° to 55° C)

NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows

10) of system disk is reserved for the system recovery software.

HP 9.5mm Slim DVD-ROM Drive

Height

9.5 mm height

Orientation

Either horizontal or vertical

Interface type

SATA/ATAPI

Dimensions (W x H x D)

5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel

Weight (max)

Up to 0.31 lb (140g) without bezel

Read Speeds

DVD+R/-R/+RW/

-RW/+R DL /-R DL Up to 8X
DVD-ROM Up to 8X
CD-ROM, CD-R Up to 24X
CD-RW Up to 24X

Access time
(typical reads, including
settling)

Random: DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full stroke: DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)

Power

Source Slimline SATA DC power receptacle

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Storage

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 38

DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)

Environmental conditions
(operating - non-condensing)

Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)

HP 9.5mm Slim DVD Writer Drive

Height

9.5 mm height

Orientation

Either horizontal or vertical

Interface type

SATA/ATAPI

Disc recording capacity

Up to 8.5 GB DL or 4.7 GB standard

Dimensions (W x H x D)

5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel

Weight (max)

0.31 lb (140 g)

Read Speeds

DVD-R DL - Up to 6X
DVD+R - Up to 8X
DVD+RW - Up to 8X
DVD+R DL - Up to 6X
DVD-R - Up to 8X
DVD-RW - Up to 6X
CD-R - Up to 24X
CD-RW - Up to 10X
DVD-RW, DVD+RW - Up to 8X
DVD-R DL, DVD+R DL - Up to 8X
DVD+R, DVD-R - Up to 8X
DVD-ROM DL, DVD-ROM - Up to 8X
CD-ROM, CD-R - Up to 24X
CD-RW - Up to 24X

Write Speeds

DVD-R DL Up to 6X
DVD+R Up to 8X
DVD+RW Up to 8X
DVD+R DL Up to 6X
DVD-R Up to 8X
DVD-RW Up to 6X
CD-R Up to 24X
CD-RW Up to 24X

Access time
(typical reads, including
settling)

Random DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full Stroke DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)
Stop Time 6 seconds (typical)

Power

Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)

Environmental conditions
(operating - non-condensing)

Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications - Storage

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 39

HP 9.5mm Slim Blu-Ray Writer Drive

Height

9.5 mm height

Orientation

Either horizontal or vertical

Interface type

SATA/ATAPI

Disc recording capacity

Up to 128 GB QL, 100 GB TL, 50 GB DL or 25 GB standard SL

Dimensions (W x H x D)

5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel

Weight (max)

0.29 lb (132 g)

Write Speeds

BD-R Up to 4X
BD-RE Up to 2X
BD-R Up to 6X
BD-RE Up to 2X
DVD-R Up to 8X
DVD-RW Up to 6X
DVD+R Up to 8X
DVD+RW Up to 8X
DVD-RAM Up to 5X
CD-R Up to 24X
CD-RW Up to 10X

Read Speeds

BD-R Up to 6X
BD-RE Up to 4X
BD-ROM Up to 6X
BD-R Up to 6X
BD-RE Up to 6X
DVD-ROM Up to 8X
DVD-R Up to 8X
DVD-RW Up to 8X
DVD+R Up to 8X
DVD+RW Up to 8X
BDMV (AACS Compliant
Disc)
Up to 6x/2x (Read/Play)
DVD-RAM Up to 5x
DVD-Video (CSS
Compliant Disc)
Up to 8x/4x (Read/Play)
CD-R/RW/ROM Up to 24x
CD-DA (DAE) Up to 24X/10X (Read/Play)

Access time
(typical reads, including
settling)

Random BD-ROM: 205 ms (typical), DVD-ROM: 185 ms (typical),
CD-ROM: 165 ms (typical)
Full Stroke BD-ROM: 350 ms (typical), DVD-ROM: 345 ms (typical),
CD-ROM: 340 ms (typical)

Power

Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC -1200 mA typical, 2000 mA maximum

Environmental conditions
(operating - non-condensing)

Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 40

NETWORKING AND COMMUNICATIONS

HP EliteDesk 705 G4 Microtower

Realtek RTL8111EPH 10/100/1000 Integrated NIC

Connector

RJ-45

System Interface

PCIe + SMBus

Controller

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s

Data rates supported

IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)

IEEE Compliance

TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K

Performance

Cable Disconnetion: 25mW
100Mbps Full Run: 450mW
1000bp Full Run: 1000mW
WoL Enable(S3/S4/S5): 50mW
WoL Disable(S3/S4/S5): 25mW

Power

ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption

MAC/PHY Interconnect

Auto MDI/MDIX Crossover cable detection

Management Interface

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status

Intel® Ethernet I210-T1 Gigabit Network Adapter

Connector

RJ-45

System Interface

PCIe Express x1

Data rates supported

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s

IEEE Compliance

IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)

Performance

TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 41

Power consumption

Cable Disconnection: 25mW
100Mbps Full Run: 450mW
1000bp Full Run: 1000mW
WoL Enable(S3/S4/S5): 50mW
WoL Disable(S3/S4/S5): 25mW

Power
Management

ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption

Management Interface

Auto MDI/MDIX Crossover cable detection

IT Manageability

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status

Intel 9260 802.11a/b/g/n/ac (2x2) WiFi® and Bluetooth® 5.0 Combo1 Non-vPro

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz & 160MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security1

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 42

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

• 802.11ac VHT160(5GHz) : +11.5dBm minimum

Power Consumption

• Transmit mode2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps: -93.5dBm maximum

802.11b, 11Mbps: -84dBm maximum

802.11a/g, 6Mbps: -86dBm maximum

802.11a/g, 54Mbps: -72dBm maximum

802.11n, MCS07: -67dBm maximum

802.11n, MCS15: -64dBm maximum

802.11ac, MCS0: -84dBm maximum

802.11ac, MCS9: -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230: 2.3 x 22.0 x 30.0 mm

Weight

Type 2230: 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%

for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2/5.0 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps

BLE: 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 43

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

Power Management Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Realtek 802.11a/b/g/n/ac (2x2) WiFi® and Bluetooth® 4.2 Combo

1

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security3

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 44

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b: +14dBm minimum

• 802.11g: +12dBm minimum

• 802.11a: +12dBm minimum

• 802.11n HT20(2.4GHz): +12dBm minimum

• 802.11n HT40(2.4GHz): +12dBm minimum

• 802.11n HT20(5GHz): +10dBm minimum

• 802.11n HT40(5GHz): +10dBm minimum

• 802.11ac VHT80(5GHz): +10dBm minimum

Power Consumption

• Transmit mode2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps: -93.5dBm maximum

802.11b, 11Mbps: -84dBm maximum

802.11a/g, 6Mbps: -86dBm maximum

802.11a/g, 54Mbps: -72dBm maximum

802.11n, MCS07: -67dBm maximum

802.11n, MCS15: -64dBm maximum

802.11ac, MCS0: -84dBm maximum

802.11ac, MCS9: -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%

for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 45

BLE: 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps

BLE: 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of + 4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

Power Management Certifications

ETS 300 328, ETS 300 826

Low Voltage Directive IEC950

UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 46

HP EliteDesk 705 G4 Small Form Factor Business PC

Realtek RTL8111EPH 10/100/1000 Integrated NIC

Connector

RJ-45

System Interface

PCIe + SMBus

Controller

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s

Data rates supported

IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)

IEEE Compliance

TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K

Performance

Cable Disconnetion: 25mW
100Mbps Full Run: 450mW
1000bp Full Run: 1000mW
WoL Enable(S3/S4/S5): 50mW
WoL Disable(S3/S4/S5): 25mW

Power

ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption

MAC/PHY Interconnect

Auto MDI/MDIX Crossover cable detection

Management Interface

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status

Intel® 8260 2x2 Dual Band 802.11ac WLAN/ Bluetooth® Combo*

Wireless LAN Standards

IEEE 802.11 ac/a/b/g/n

System Interface

PCIe + SMBus

Interoperability

Wi-Fi® certification

WLAN + Bluetooth® Combo M.2 Card device shall meet all of the requirements to
support Bluetooth® 4.1 and backwards compatible with 2.1 with EDR

Frequency Band

802.11b/g/n

2.402-2.482 GHz

802.11a/n/ac

4.9 – 4.95 GHz (Japan)

5.15 – 5.25 GHz

5.25 – 5.35 GHz

5.47 – 5.725 GHz

5.825 – 5.850 GHz (Note: Indonesia does not
support this
band)

Antenna Interface

With antennas installed in the system, the antenna peak gain is less than +3dBi in the

2.4GHz band and less than +4dBi in the 5GHz band to allow the device to meet
regulatory limits.

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 47

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: card will support rates for NSS=1 and NSS=2 for RX and TX for 20

and 40 MHz channels. Short and long guard interval shall be supported.

• 802.11ac: card will support rates for NSS=1 and NSS=2 for RX and TX for 80
MHz channels. 433Mbps for 1x1 and 867Mbps for 2x2.

Security

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through V5

• WAPI

Note: Check latest software/driver release for updates on supported security
features.

Roaming

802.11r Fast Roaming

Output Power (Transmitting)

• 802.11b: +16dBm minimum

• 802.11g: +14dBm minimum

• 802.11a: +14dBm minimum

• 802.11n HT20 (2.4GHz) : +14dBm minimum

• 802.11n HT40 (2.4GHz) : +12dBm minimum

• 802.11n HT20 (5GHz) : +14dBm minimum

• 802.11n HT40 (5GHz) : +12dBm minimum

• 802.11ac 80MHz (5GHz) : +12dBm minimum

Notes:

1. RF Tx power have to meet minimum criteria and with +1.5dBm tolerance but -

1.5dBm.

2. RF Parameter will be verified by R&S CMW500 via link mode. .

Power Consumption

Transmit: 2.0 Watts

Receive: 1.6 Watts

Idle mode (PSP): 180 mW (WLAN associated)

Idle mode: 50 mW (WLAN unassociated)

Connect Standby 10mW (WLAN+BT)

Radio off: 5 mW

Bluetooth® Power Consumption

Peak operating: 330 mW

Receive: 230 mW

USB selective suspend: 17 mW

Power Management

The product conforms to the ACPI and PCI Express M.2 bus methods to manage power
of the WLAN components.
Supports all 802.11 compliant power-save modes. These include the basic Power
Save Polling (PSP) in 802.11 and Automatic Power Save Delivery (APSD) defined in

802.11e.

Receiver Sensitivity for FER
<10%

802.11b, 1Mbps: -94dBm maximum

802.11b, 11Mbps: -86dBm maximum

802.11a/g, 6Mbps: -88dBm maximum

802.11a/g, 54Mbps : -74dBm maximum

802.11n, MCS07 : -69dBm maximum

802.11n, MCS15 : -66dBm maximum

802.11ac, 1SS, MCS-0 : -86dBm maximum

802.11ac, 1SS, MCS-9 : -61dBm maximum

802.11ac, 2SS, MCS-0 : -83dBm maximum

802.11ac, 2SS, MCS-9 : -58dBm maximum

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 48

Note:

1. Rx sensitivity have to meet maximum criteria and with -1.5dBm tolerance but
+1.5dBm.

2. Note: RF Parameter will be verified by R&S CMW500 via link mode.

Form Factors

PCI Express M.2 form factor

Operating Voltage

The card will be powered by a 3.3V, ± 9% supply from the host system.

Temperature

Operating:
Non-operating:

14° to 158° F (-10° to 70° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating:
Non-operating:

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating:
Non-operating:

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

* Wireless access point and Internet service required and not included. Availability of public wireless access points limited. The specifications for
the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the
ability of the notebook to communicate with other 802.11ac WLAN devices.

Intel® Ethernet I210-T1 Gigabit Network Adapter

Connector

RJ-45

System Interface

PCI (Intel® proprietary) + SMBus

Data rates supported

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s

IEEE Compliance

IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)

Performance

TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K

Power consumption

Cable Disconnection: 25mW
100Mbps Full Run: 450mW
1000bp Full Run: 1000mW
WoL Enable(S3/S4/S5): 50mW
WoL Disable(S3/S4/S5): 25mW

Power
Management

ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption

Management Interface

Auto MDI/MDIX Crossover cable detection

IT Manageability

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status

Security & Manageability

Intel® vPro™ support with appropriate Intel® chipset components

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 49

Intel® 9260 802.11a/b/g/n/ac (2x2) WiFi® and Bluetooth® 5.0 Combo1 Non-vPro

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz & 160MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security1

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

• 802.11ac VHT160(5GHz) : +11.5dBm minimum

Power Consumption

• Transmit mode2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 50

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of

10% for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2/5.0 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps

BLE: 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

Power Management Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 51

Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Intel® 3168 802.11a/b/g/n/ac (1x1) WiFi® and Bluetooth® 4.2 Combo1

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security3

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

Power Consumption

• Transmit mode2.0 W

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 52

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%

for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps

BLE : 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 53

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826
Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Intel® 2 7265 802.11a/b/g/n/ac (2x2) WiFi® and Bluetooth® 4.2 Combo1 Non-vPro™

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security3

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 54

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

Power Consumption

• Transmit mode2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%

for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps

BLE : 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 55

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826
Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Realtek 802.11a/b/g/n/ac (1x1) WiFi® and Bluetooth® 4.2 Combo1

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 56

Security1

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +14dBm minimum

• 802.11g : +12dBm minimum

• 802.11a : +12dBm minimum

• 802.11n HT20(2.4GHz) : +12dBm minimum

• 802.11n HT40(2.4GHz) : +12dBm minimum

• 802.11n HT20(5GHz) : +10dBm minimum

• 802.11n HT40(5GHz) : +10dBm minimum

• 802.11ac VHT80(5GHz) : +10dBm minimum

Power Consumption

• Transmit mode2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna.
One embedded dual band 2.4/5 GHz antenna is provided to the card to support WLAN
communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%

for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2 Compliant

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 57

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps

BLE : 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications
Power Management Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Intel® 9260 802.11a/b/g/n/ac (2x2) WiFi® and Bluetooth® 5.0 Combo1 Non-vPro™

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 58

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz & 160MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security1

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

• 802.11ac VHT160(5GHz) : +11.5dBm minimum

Power Consumption

• Transmit mode2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 59

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%

for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2/5.0 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps

BLE: 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

Power Management Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 60

HP EliteDesk 705 G4 Desktop Mini Business PC

Realtek RTL8111EPH 10/100/1000 Integrated NIC

Connector

RJ-45

System Interface

PCIe + SMBus

Controller

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s

Data rates supported

IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)

IEEE Compliance

TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K

Performance

Cable Disconnetion: 25mW
100Mbps Full Run: 450mW
1000bp Full Run: 1000mW
WoL Enable(S3/S4/S5): 50mW
WoL Disable(S3/S4/S5): 25mW

Power

ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption

MAC/PHY Interconnect

Auto MDI/MDIX Crossover cable detection

Management Interface

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status

Intel® 8260 2x2 Dual Band 802.11ac WLAN/ Bluetooth® Combo*

Wireless LAN Standards

IEEE 802.11 ac/a/b/g/n

System Interface

PCIe + SMBus

Interoperability

Wi-Fi® certification

WLAN + Bluetooth® Combo M.2 Card device shall meet all of the requirements to
support Bluetooth® 4.1 and backwards compatible with 2.1 with EDR

Frequency Band

802.11b/g/n

2.402-2.482 GHz

802.11a/n/ac

4.9 – 4.95 GHz (Japan)

5.15 – 5.25 GHz

5.25 – 5.35 GHz

5.47 – 5.725 GHz

5.825 – 5.850 GHz (Note: Indonesia does not
support this
band)

Antenna Interface

With antennas installed in the system, the antenna peak gain is less than +3dBi in the

2.4GHz band and less than +4dBi in the 5GHz band to allow the device to meet
regulatory limits.

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 61

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: card will support rates for NSS=1 and NSS=2 for RX and TX for 20

and 40 MHz channels. Short and long guard interval shall be supported.

• 802.11ac: card will support rates for NSS=1 and NSS=2 for RX and TX for 80
MHz channels. 433Mbps for 1x1 and 867Mbps for 2x2.

Security

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through V5

• WAPI

Note: Check latest software/driver release for updates on supported security
features.

Roaming

802.11r Fast Roaming

Output Power (Transmitting)

• 802.11b: +16dBm minimum

• 802.11g: +14dBm minimum

• 802.11a: +14dBm minimum

• 802.11n HT20 (2.4GHz) : +14dBm minimum

• 802.11n HT40 (2.4GHz) : +12dBm minimum

• 802.11n HT20 (5GHz) : +14dBm minimum

• 802.11n HT40 (5GHz) : +12dBm minimum

• 802.11ac 80MHz (5GHz) : +12dBm minimum

Notes:

1. RF Tx power have to meet minimum criteria and with +1.5dBm tolerance but -

1.5dBm.

2. RF Parameter will be verified by R&S CMW500 via link mode. .

Power Consumption

Transmit: 2.0 Watts

Receive: 1.6 Watts

Idle mode (PSP): 180 mW (WLAN associated)

Idle mode: 50 mW (WLAN unassociated)

Connect Standby 10mW (WLAN+BT)

Radio off: 5 mW

Bluetooth® Power Consumption

Peak operating: 330 mW

Receive: 230 mW

USB selective suspend: 17 mW

Power Management

The product conforms to the ACPI and PCI Express M.2 bus methods to manage power
of the WLAN components.
Supports all 802.11 compliant power-save modes. These include the basic Power
Save Polling (PSP) in 802.11 and Automatic Power Save Delivery (APSD) defined in

802.11e.

Receiver Sensitivity for FER
<10%

802.11b, 1Mbps: -94dBm maximum

802.11b, 11Mbps: -86dBm maximum

802.11a/g, 6Mbps: -88dBm maximum

802.11a/g, 54Mbps : -74dBm maximum

802.11n, MCS07 : -69dBm maximum

802.11n, MCS15 : -66dBm maximum

802.11ac, 1SS, MCS-0 : -86dBm maximum

802.11ac, 1SS, MCS-9 : -61dBm maximum

802.11ac, 2SS, MCS-0 : -83dBm maximum

802.11ac, 2SS, MCS-9 : -58dBm maximum

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 62

Note:

1. Rx sensitivity have to meet maximum criteria and with -1.5dBm tolerance but
+1.5dBm.

2. Note: RF Parameter will be verified by R&S CMW500 via link mode.

Form Factors

PCI Express M.2 form factor

Operating Voltage

The card will be powered by a 3.3V, ± 9% supply from the host system.

Temperature

Operating:
Non-operating:

14° to 158° F (-10° to 70° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating:
Non-operating:

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating:
Non-operating:

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

* Wireless access point and Internet service required and not included. Availability of public wireless access points limited. The specifications for
the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the
ability of the notebook to communicate with other 802.11ac WLAN devices.

Intel® 3168 802.11a/b/g/n/ac (1x1) WiFi® and Bluetooth® 4.2 Combo [1]

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security3

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 63

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

Power Consumption

• Transmit mode2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm

Weight

Type 2230 : 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%

for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps

BLE : 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 64

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826
Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Intel® Ethernet I210-T1 Gigabit Network Adapter

Connector

RJ-45

System Interface

PCI (Intel® proprietary) + SMBus

Data rates supported

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s

IEEE Compliance

IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)

Performance

TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K

Power consumption

Cable Disconnetion: 25mW
100Mbps Full Run: 450mW
1000bp Full Run: 1000mW
WoL Enable(S3/S4/S5): 50mW
WoL Disable(S3/S4/S5): 25mW

Power
Management

ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption

Management Interface

Auto MDI/MDIX Crossover cable detection

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 65

IT Manageability

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status

Security & Manageability

Intel® vPro™ support with appropriate Intel® chipset components

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 66

Intel® 9260 802.11a/b/g/n/ac (2x2) WiFi® and Bluetooth® 5.0 Combo1 Non-vPro™

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz & 160MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security1

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

• 802.11ac VHT160(5GHz) : +11.5dBm minimum

Power Consumption

• Transmit mode2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 67

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230: 2.3 x 22.0 x 30.0 mm

Weight

Type 2230: 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of

10% for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2/5.0 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps

BLE: 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

Power Management Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 68

Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Intel® 2 7265 802.11a/b/g/n/ac (2x2) WiFi® and Bluetooth® 4.2 Combo [1] Non-vPro™

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security3

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

Power Consumption

• Transmit mode2.0 W

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 69

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -93.5dBm maximum

802.11b, 11Mbps : -84dBm maximum

802.11a/g, 6Mbps : -86dBm maximum

802.11a/g, 54Mbps : -72dBm maximum

802.11n, MCS07 : -67dBm maximum

802.11n, MCS15 : -64dBm maximum

802.11ac, MCS0 : -84dBm maximum

802.11ac, MCS9 : -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230: 2.3 x 22.0 x 30.0 mm

Weight

Type 2230: 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%

for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps

BLE: 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 70

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826
Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Intel® 3168 802.11a/b/g/n/ac (1x1) WiFi® and Bluetooth® 4.2 Combo1

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi® certified

Frequency Band

802.11b/g/n

• 2.402 – 2.482 GHz

802.11a/n

• 4.9 – 4.95 GHz (Japan)

• 5.15 – 5.25 GHz

• 5.25 – 5.35 GHz

• 5.47 – 5.725 GHz

• 5.825 – 5.850 GHz

Data Rates

• 802.11b: 1, 2, 5.5, 11 Mbps

• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security3

• IEEE and WiFi® compliant 64 / 128 bit WEP encryption for a/b/g mode only

• AES-CCMP: 128 bit in hardware

• 802.1x authentication

• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

• WPA2 certification

• IEEE 802.11i

• Cisco Certified Extensions, all versions through CCX4 and CCX Lite

• WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 71

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

• 802.11b : +18.5dBm minimum

• 802.11g : +17.5dBm minimum

• 802.11a : +18.5dBm minimum

• 802.11n HT20(2.4GHz) : +15.5dBm minimum

• 802.11n HT40(2.4GHz) : +14.5dBm minimum

• 802.11n HT20(5GHz) : +15.5dBm minimum

• 802.11n HT40(5GHz) : +14.5dBm minimum

• 802.11ac VHT80(5GHz) : +11.5dBm minimum

Power Consumption

• Transmit mode2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps: -93.5dBm maximum

802.11b, 11Mbps: -84dBm maximum

802.11a/g, 6Mbps: -86dBm maximum

802.11a/g, 54Mbps: -72dBm maximum

802.11n, MCS07: -67dBm maximum

802.11n, MCS15: -64dBm maximum

802.11ac, MCS0: -84dBm maximum

802.11ac, MCS9: -59dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230: 2.3 x 22.0 x 30.0 mm

Weight

Type 2230: 2.8g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10%

for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology

Bluetooth Specification

4.0/4.1/4.2 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)

Data Rates and Throughput

Legacy: 3 Mbps data rate; throughput up to 2.17 Mbps

BLE: 1 Mbps data rate; throughput up to 0.2 Mbps

Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Networking and Communications

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 72

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software
Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826
Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Input/Output Devices

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 73

I/O DEVICES

HP EliteDesk 705 G4 Microtower

HP Conferencing Keyboard

1.

Function Keys

6.

End/Decline a Call

2.

F11 Lync or Skype for Business Contact list

1

7.

Answer a Call

3.

F12 Lync or Skype for Business Calendar

2

8.

Microphone Mute

4.

Share Screen

9.

Volume Up/Down

5.

Stop Webcam

10.

Audio Mute

1. Microsoft Lync 2013, or Skype for Business, or Microsoft Outlook 2013 Contact list

2. Microsoft Lync 2013, or Skype for Business, or Microsoft Outlook 2013 Calendar

HP USB Premium Keyboard

Physical Characteristics

Keys

104, 105 layout (depending upon country)

Dimensions (L x W x H)

17.04 x 5.55 x 0.52 in (433 x 141 x13.2 mm)

Weight

1.54 lb (698g)

Electrical

Operating voltage

5 VDC, +/-5%

Power consumption

35mA (All LED on)

System interface

USB Type A plug connector

ESD

Contact Discharge: 8 KV Air Discharge: 15 KV

EMI - RFI

Conforms to FCC rules for a Class B computing device

Mechanical

Keycaps

Low-profile design

Switch actuation

60±10g nominal peak force with tactile feedback

Switch life

10 million keystrokes (Life tester)

Switch type

Contamination-resistant switch membrane

Key-leveling mechanisms

For all double-wide and greater-length keys

Cable length

6 ft (1.8 m)

Environmental

Acoustics

43-dBA maximum sound pressure level

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Input/Output Devices

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 74

Operating temperature

50° to 122° F (10° to 50° C)

Non-operating temperature

-22° to 140° F (-30° to 60° C)

Operating humidity

10% to 90% (non-condensing at ambient)

Non-operating humidity

20% to 80% (non-condensing at ambient)

Operating shock

40 g, six surfaces

Non-operating shock

80 g, six surfaces

Operating vibration

2-g peak acceleration

Non-operating vibration

4-g peak acceleration

Drop (out of box)

26 in (66 cm) on carpet, six-drop sequence

Drop (in box)

30 in (76.2 cm) on concrete, 16-drop sequence

Approvals

UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC

Ergonomic Compliance

TUVGS

Kit Contents

Keyboard, QSP

Warranty Card

Product Notice

Skylab USB Wired Keyboard

Physical Characteristics

Keys

104, 105, 106, 107, 109 layout (depending upon country)

Dimensions (L x W x H)

171.97 x 68.35 x 8.27 in (436.8± 1.5 x 137.6± 1.0 x 21.0±

1.0 cm)

Weight

1.32 lb (0.6± 0.08 kg)

Electrical

Operating voltage

4.4-5.25VDC

Power consumption

50-mA maximum (with 5 VDC power supplied and three
LEDs ON)

System interface

USB

ESD

Contact Discharge: 2, 4,6,8KV
Air Discharge: 2, 4, 8,10,12.5KV

EMI - RFI

Conforms to FCC rules for a Class B computing device

Mechanical

Keycaps

Low-profile design

Switch actuation

60±10g nominal peak force with tactile feedback

Switch life

10 million keystrokes (Life tester)

Switch type

Contamination-resistant switch membrane

Key-leveling mechanisms

For all double-wide and greater-length keys

Cable length

6 ft (1.8 m)

Microsoft PC 99 - 2001

Mechanically compliant

Environmental

Acoustics

43-dBA maximum sound pressure level

Operating temperature

50° to 122° F (10° to 50° C)

Non-operating temperature

Minus 30 degress to 60 degress Celsius

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Input/Output Devices

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 75

Operating humidity

10% to 90% (non-condensing at ambient)

Non-operating humidity

20% to 80% (non-condensing at ambient)

Operating shock

40 g, six surfaces

Non-operating shock

80 g, six surfaces

Operating vibration

2-g peak acceleration

Non-operating vibration

4-g peak acceleration

Drop (out of box)

26 in (66 cm) on carpet, six-drop sequence

Drop (in box)

30 in (76.2 cm) on concrete, 16-drop sequence

Approvals

UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC

Ergonomic compliance

ANSI HFS 100, ISO 9241-4, and TUVGS

Kit contents

Keyboard, Installation Guide, Warranty card, Safety and Comfort Guide

HP USB Premium Mouse

Dimensions (H x L x W)

4.21 x 2.64 x 1.52 in (107 x 67 x 38.7 mmm)

Weight

0.19lb (90g)

Environmental

Operating temperature

50° to 122°F (10° to 50° C)

Non-operating temperature

-22° to 140°F (-30° to 60° C)

Operating humidity

10% to 90% (non-condensing at ambient)

Non-operating humidity

20% to 80% (non condensing at ambient)

Operating shock

50 g, 6 surfaces

Non-operating shock

80 g, 6 surfaces

Operating vibration

2 g peak acceleration

Non-operating vibration

4 g peak acceleration

Electrical

Operating voltage

5 VDC, +/-5%

Power consumption

12mA

Mechanical

Connector

USB 2.0

Type

3D mouse (3 keys and wheel)

Resolution

800, 1200, 1600 DPI

Sensor

Pixart PAN3606DL

Tracking speed

Tracking acceleration

8G(max), 1G=9.8m/s2

Cable length

6 ft (1.8 m)

Color

Jack Black

Regulatory approvals

Compliant

UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Input/Output Devices

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 76

HP USB Mouse

Dimensions (H x L x W)

37mm*115mm*62.9mm

Weight

90 +10g/- 5 g

Color

Black

Connector

USB

Mechanical

Resolution

800 DPI sensitivity

Buttons

Two primary buttons and clickable scroll wheel

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Audio

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 77

AUDIO/MULTIMEDIA

HP EliteDesk 705 G4 Microtower

Type

Integrated

HD Stereo Codec

Synaptics CX20632

Audio I/O Ports

Front: 1 - Headset connector supports a CTIA style headset and is re-taskable as a Line-in, Line­out, Microphone-in or Headphone-out port
1 - Headphone port
Rear: Line-out
Line-in which is retaskable as a Microphone Input
All ports are 3.5mm and support stereo

Internal Speaker Amplifier

2W class D mono amplifier for the internal speaker only. External speakers must be powered
externally

Multi-streaming Capable

Playback multi-streaming can be enabled in the audio control panel to allow independent audio
streams to be sent to/from the front and rear jacks or integrated speaker.

Sampling

Independent sampling rates for DAC’s and ADC’s; supports resolutions from 16 to 24-bit; 44.1 kHz
to 192 kHz for DAC and 44.1 kHz to 96 kHz for ADC

Wavetable Syntheses

Yes - Uses OS soft wavetable

Analog Audio

Yes

# of Channels on Line-Out

Stereo (Left & Right channels)

Internal Speaker

Yes

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Audio

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 78

HP EliteDesk 705 G4 Small Form Factor Business PC

Type

Integrated

HD Stereo Codec

Conexant CX20632

Audio I/O Ports

Front: 1 - Headset connector supports a CTIA style headset and is re-taskable as a Line-in, Line­out, Microphone-in or Headphone-out port
1 - Headphone port
Rear: Line-out
Line-in which is retaskable as a Microphone Input
All ports are 3.5mm and support stereo

Internal Speaker Amplifier

2W class D mono amplifier for the internal speaker only. External speakers must be powered
externally

Multi-streaming Capable

Playback multi-streaming can be enabled in the audio control panel to allow independent audio
streams to be sent to/from the front and rear jacks or integrated speaker.

Sampling

Independent sampling rates for DAC’s and ADC’s; supports resolutions from 16 to 24-bit; 44.1 kHz
to 192 kHz for DAC and 44.1 kHz to 96 kHz for ADC

Wavetable Syntheses

Yes - Uses OS soft wavetable

Analog Audio

Yes

# of Channels on Line-Out

Stereo (Left & Right channels)

Internal Speaker

Yes

HP EliteDesk 705 G4 Desktop Mini Business PC

Type

Integrated

HD Stereo Codec

Conexant CX20632

Audio I/O Ports

Front: 1 - Headset connector supports a CTIA style headset and is re-taskable as a Line-in, Line­out, Microphone-in or Headphone-out port
1 - Headphone port
All ports are 3.5mm and support stereo

Internal Speaker Amplifier

2W class D mono amplifier for the internal speaker only. External speakers must be powered

Multi-streaming Capable

Playback multi-streaming can be enabled in the audio control panel to allow independent audio
streams to be sent to/from the front and rear jacks or integrated speaker.

Sampling

Independent sampling rates for DAC’s and ADC’s; supports resolutions from 16 to 24-bit; 44.1 kHz
to 192 kHz for DAC and 44.1 kHz to 96 kHz for ADC

Wavetable Syntheses

Yes - Uses OS soft wavetable

Analog Audio

Yes

# of Channels on Line-Out

Stereo (Left & Right channels)

Internal Speaker

Yes

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Power

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 79

POWER

HP EliteDesk 705 G4 Microtower

UNIT ENVIRONMENT AND OPERATING CONDITIONS

Temperature Range

Operating : 5°C ~45°C
Non-Operating : -40°C ~66°C

Relative Humidity

Operating: 5% to 90% relative humidity at max inlet temperature
Non Operating: 5% to 90% relative humidity at max inlet temperature

Maximum Altitude
(unpressurized)

Operating: 5000m
Non-operating: 50000ft (15240 m)

HP EliteDesk 705 G4 Small Form Factor Business PC

UNIT ENVIRONMENT AND OPERATING CONDITIONS

Temperature Range

Operating : 5°C ~50°C
Non-Operating : -40°C ~66°C

Relative Humidity

Operating 5% to 90% relative humidity at max inlet temperature
Non-Operating 5% to 90% relative humidity at max inlet temperature

Maximum Altitude
(unpressurized)

Operating: 5000m
Non-operating: 50,000 ft (15240 m)

HP EliteDesk 705 G4 Desktop Mini Business PC

UNIT ENVIRONMENT AND OPERATING CONDITIONS

Temperature Range

Operating : 5°C ~35°C
Non-Operating : -40°C ~66°C

Relative Humidity

Operating 5% to 90% relative humidity at max inlet temperature
Non-Operating 5% to 90% relative humidity at max inlet temperature

Maximum Altitude
(unpressurized)

Operating: 5000m
Non-operating: 50,000 ft (15240 m)

DM

SFF

MT

80 PLUS Platinum

180W active PFC
90/92/89% efficient at
20/50/100% load (115V)
91/93/90% efficient at
20/50/100% load (230V

250W active PFC / 80 PLUS Platinum
400W active PFC / 80 PLUS Platinum
90/92/89% efficient at 20/50/100%
load (115V)
91/93/90% efficient at 20/50/100%
load (230V)

Operating Voltage Range

90Vac~264Vac

90Vac~264Vac

90Vac~264Vac

Rated Voltage Range

100Vac~240Vac

100Vac~240Vac

100Vac~240Vac

Rated Line Frequency

50HZ~60HZ

50HZ~60HZ

50HZ~60HZ

Operating Line
Frequency

47HZ~63HZ

47HZ~63HZ

47HZ~63HZ

Rated Input Current

65W≦1.6A
90W≦1.2A
150WW≦2.2A

250W≦3A
400W≦5.2A

250W≦3A
400W≦5.2A

Rated Input Current with
Energy Efficient* Power
Supply

65W≦1.6A
90W≦1.2A
150WW≦2.2A

250W≦3A
400W≦5.2A

250W≦3A
400W≦5.2A

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Power

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 80

DC Output

+19.5V

+12V

+12V

Current Leakage (NFPA
99: 2102)

Less than 500 microamps of
leakage current at 120 Vac with
the ground wire disconnected,
as required for Non-patient
Electrical Appliances and
Equipment used in a patient
care facility or that contact
patients in normal use. Per
section 10.3.5.1.
Less than 100 microamps of
leakage current at 120 Vac with
the ground wire intact with
normal polarity, as required for
Non-patient Electrical
Appliances and Equipment used
in a patient care facility or that
contact patients in normal use.
Per section 10.3.5.1.

Less than 500 microamps of
leakage current at 120 Vac with
the ground wire disconnected,
as required for Non-patient
Electrical Appliances and
Equipment used in a patient
care facility or that contact
patients in normal use. Per
section 10.3.5.1.
Less than 100 microamps of
leakage current at 120 Vac with
the ground wire intact with
normal polarity, as required for
Non-patient Electrical
Appliances and Equipment used
in a patient care facility or that
contact patients in normal use.
Per section 10.3.5.1.

Less than 500 microamps of leakage
current at 120 Vac with the ground
wire disconnected, as required for
Non-patient Electrical Appliances
and Equipment used in a patient care
facility or that contact patients in
normal use. Per section 10.3.5.1.
Less than 100 microamps of leakage
current at 120 Vac with the ground
wire intact with normal polarity, as
required for Non-patient Electrical
Appliances and Equipment used in a
patient care facility or that contact
patients in normal use. Per section

10.3.5.1.

Power Supply Fan

N/A

50mm variable speed

70mm variable speed

Power cord length

6.0 ft. (1.83 m)

6.0 ft. (1.83 m)

6.0 ft. (1.83 m)

External Power Adapter

External power supply
65W EPS, 89% average
efficiency at 115V & 230Vac
90W EPS, 89% average
efficiency at 115V & 230Vac
150W EPS, 89% average
efficiency at 115V & 230Vac

Internal power supply

Internal power supply

Dimensions

65W : 113.5mm x 55mm x
30mm
90W : 132.5mm x 57mm x

30.3mm
150W : 167.5mm x 80mm x

40.5mm

200mm x 85mm x 53mm

165mm x 95mm x 73mm
The harmonic input current requirements must be met under the following operating conditions:
Load Requirements: 50% and 100%
Input Voltage: 230Vac/50Hz.
For active power factor correction the power factor at 50% &100% loads shall be greater than 0.9 over the entire nominal input
voltage range (100-127VAC and 200-240VAC).

Condition

Standard Efficiency

82/85/82%

85/88/85%

87/90/87%

90/92/89%

Input Voltage

10% of Rated Load

-

75%

81%

84%

84%

115Vac/60HZ

20% of Rated Load

-

82%

85%

87%

90%

115Vac/60HZ

50% of Rated Load

-

85%

88%

90%

92%

115Vac/60HZ

PF>0.9

PF>0.9

PF>0.9

PF>0.9

PF>0.95

100% of Rated Load

70%

82%

85%

87%

89%

115Vac/60HZ

PF>0.9

PF>0.9

PF>0.9

PF>0.9

PF>0.9

230Vac/50HZ

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Weights and Dimensions

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 81

WEIGHTS & DIMENSIONS

DM

SFF

MT

Chassis (W x D x H) Not
including bezel

6.97 x 6.89 x 1.35 in
177 x 175 x 34.2 mm

3.7 x 10.6 x 11.7 in
95 x 270 x 296 mm

6.69 x10.79 x 13.3 in
170 x 274 x 338 mm

System Volume

64 cu in

1.05 L

463 cu in

7.6 L

960 cu in

15.74 L

Max System Weight

1.265 kg

5.88 kg

7.14 kg

Max Supported Weight
(desktop orientation)

N/A

77 lb
35 kg

77 lb
35 kg

Stand Dimensions

160 x 117 x 18.5 mm

Packaging (W x D x H)

19.57 x 5.04 x 8.78 in
497 x 128 x 223 mm

15.71 x 9.06 x 19.65 in
399 x 230 x 499 mm

15.35 x 11.73 x 19.65 in
390 x 298 x 499 mm

Shipping Weight

2.95 kg

6.49 lb

16.12 lb

7.32 kg

22.64 lb

10.28 kg

Shipping Weight (Molded Pulp)

16.62 lb

7.54kg

23.15 lb

10.5kg

Multipack
Packaging (10 units)

20.28x16.54x25 in
515x420x636 mm

Palletization Profile

18-units per layer
5 or 6 layers max
depending on details of
air freight
90 or 108 units per pallet
depending on details of
air freight

45.354 x 39.13 x 57.80
in, 1152 x 994 x 1468 mm
(include pallet)

6-units per layer 60 per pallet

47.24 x 39.37 x 94.49 in
(including pallet)
10 layer max

6-units per layer 42 per pallet

47.24 x 39.37 x 86.85 in
(including pallet)
7 layer max

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Technical Specifications – Miscellaneous Features

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 82

MISCELLANEOUS FEATURES

Management Features

• Advanced Configuration and Power Management Interface (ACPI). Allows the system to wake from a low power mode.

Controls system power consumption, making it possible to place individual cards and peripherals in a low-power or
powered-off state without affecting other elements of the system.

• Dual State Power Button; acts as both an on/off button and a suspend-to-sleep button

Serviceability Features

• Dual colored power LED on front of computer to indicate either normal or fault condition

• System/Emergency ROM

• Flash ROM

• CMOS Battery Holder for easy replacement

• Flash Recovery with Video Configuration Record Software

• 5 Aux Power LED on System PCA

• Processor ZIF Socket for easy Upgrade

• Over-Temp Warning on Screen (Requires IM Agents)

• Clear Password Jumper

• DIMM Connectors for easy Upgrade

• Clear CMOS Button

• NIC LEDs (integrated) (Green & Amber)

• Dual Color Power and HD LED - To Indicate Normal Operations and Fault Conditions

• Color coordinated cables and connectors

• Tool-less Hood Removal

• Front power switch

• System memory can be upgraded without removing the system board or any internal components

• Tool-less Hard Drive, CD & Diskette Removal

• Green Pull Tabs, and Quick Release Latches for easy Identification

Additional Features

• Product can be oriented as either a desktop (horizontal) or a tower (vertical)

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

After Market Options

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 83

AFTER MARKET OPTIONS

Graphics Solutions

DM

SFF

TWR

Part Number

AMD® Radeon™ R7 430 2GB 2DP Card

X

3TK71AA

AMD® Radeon™ RX550 4GB 2DP Card

X

3MQ82AA

HP DisplayPort™ To HDMI True 4k Adapter

X X X

2JA63AA

HP DVI Cable Kit

X X

DC198A

HP HDMI Standard Cable Kit

X X X

T6F94AA

HP DisplayPort™ Cable Kit

X X X

VN567AA

HP DisplayPort™ To DVI-D Adapter

X X X

FH973AA

HP DisplayPort™ To VGA Adapter

X X X

AS615AA

Desktop Mini Accessories

DM

SFF

TWR

Part Number

HP Desktop Mini G3 Port Cover Kit

X

1ZE52AA

HP G4 Mini 2.5-inch SATA Drive Bay Kit

X

3TK91AA

HP Desktop Mini LockBox V2

X

3EJ57AA

HP Desktop Mini 500GB HDD/I/O Expansion Module

X

K9Q82AA

HP Desktop Mini DVD-Writer ODD Expansion Module

X

K9Q83AA

HP Desktop Mini I/O Expansion Module

X

K9Q84AA

HP Desktop Mini Security/Dual VESA Sleeve v2

X

2JA32AA

HP Desktop Mini Vertical Chassis Stand

X

G1K23AA

HP DM VESA Power Supply Holder Kit

X

1RL87AA

Desktop Mini Accessories

DM

SFF

TWR

Part Number

Intel® 9260 802.11ac non-vPro PCIe x1 Card

X X

3TK89AA

Realtek 8822BE 802.11ac PCIe x1 Card

X X

3TK90AA

Data Storage Drives

DM

SFF

TWR

Part Number

HP 256GB SATA TLC Non-SED Solid State Drive

X X X

P1N68AA

HP PCIe NVME TLC 256GB SSD M.2 Drive

X X X

1CA51AA

HP PCIe NVME TLC 512GB SSD M.2 Drive

X X X

X8U75AA

HP PCIe NVME TLC 512GB SSD PCIe Drive

X X

Z4L70AA

HP 500GB 7200PRM SATA 6.0Gb/s 3.5” Hard Drive

X X

QK554AA

HP 1TB 7200rpm SATA 6Gb/s 3.5” Hard Drive

X X

QK555AA

HP SATA SuperMulti JB Drive

X

QS208AA

HP 9.5mm Slim Removable SATA 500GB

X X

T7G14AA

HP 9.5mm G3 8/6/4 SFF G4 400 SFF/MT DVD Writer

X

1CA53AA

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

After Market Options

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 84

Input Devices

DM

SFF

TWR

Part Number

HP USB (Grey) SmartCard CCID Keyboard

X X

J7H70AA

HP USB Antimicrobial Business Slim Keyboard and Mouse (China Only)

X X

Z9H50AA

HP USB Buisness Slim CCID SmartCard Keyboard

X X

Z9H48AA

HP USB Business Slim (Grey) Keyboard (EMEA Only)

X X

Z9H49AA

HP USB Business Slim Keyboard

X X X

N3R87AA

HP USB Business Slim Keyboard and Mouse and Mousepad

X X X

T4E63AA

HP USB Collaboration Keyboard

X X X

Z9N38AA

HP USB Conferencing Keyboard

X X

K8P74AA

HP USB Keyboard

X X X

QY776AA

HP USB Keyboard and Mouse Healthcare Edition

1VD81AA

HP USB Premium Keyboard

X X X

Z9N40AA

HP USB PS/2 Washable Keyboard & Mouse

X X X

BU207AA

HP Wireless Business Slim Keyboard and Mouse

X X X

N3R88AA

HP Wireless Collaboration Keyboard

X X X

Z9N39AA

HP Wireless Premium Keyboard

X X X

Z9N41AA

HP PS/2 Business Slim Keyboard

X X X

N3R86AA

HP USB Grey v2 Mouse (EMEA only)

X X

Z9H74AA

HP USB Premium Mouse

X X

1JR32AA

HP PS/2 Mouse

X X X

QY775AA

HP USB 1000dpi Laser Mouse

X X X

QY778AA

HP USB Hardened Mouse

X X

P1N77AA

HP USB Mouse

X X X

QY777AA

System Memory

DM

SFF

TWR

Part Number

HP 4GB DDR4-2666 DIMM

X X

3TK85AA

HP 8GB DDR4-2666 DIMM

X X

3TK87AA

HP 16GB DDR4-2666 DIMM

X X

3TK83AA

HP 4GB DDR4-2666 SODIMM

X

3TK86AA

HP 8GB DDR4-2666 SODIMM

X

3TK88AA

HP 16GB DDR4-2666 SODIMM

X

3TK84AA

Multimedia Devices

DM

SFF

TWR

Part Number

HP Business Headset v2

X X X

T4E61AA

HP USB Business Speakers v2

X X X

N3R89AA

Security Devices

DM

SFF

TWR

Part Number

HP Solenoid Lock & Hood Sensor (MT)

X

J6L42AA

HP Business PC Security Lock v3 Kit

X X

3XJ17AA

HP Dual Head Keyed Cable Lock

X X X

T1A64AA

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

After Market Options

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 85

HP Keyed Cable Lock 10mm

X X X

T1A62AA

HP Master Keyed Cable Lock 10mm

X X X

T1A63AA

Stands and Accessories

DM

SFF

TWR

Part Number

HP B300 PC Mounting Bracket

X

2DW53AA

HP B500 PC Mounting Bracket

X

2DW52AA

HP Single Monitor Arm

X

BT861AA

I/O Devices

DM

SFF

TWR

Part Number

HP DisplayPort™ Port Flex IO

X X X

3TK72AA

HP HDMI Port Flex IO (705)

X X X

3TK75AA

HP Type-C™ USB 3.1 Gen2 Port Flex IO

X X X

3TK78AA

HP VGA Port Flex IO

X X X

3TK80AA

HP Internal Serial Port Flex IO

X

3TK76AA

HP Serial Port Adapter (2nd Serial Port )

X X

PA716A

HP Internal Serial Port (600/705/800)

X X

3TK82AA

HP PCIe x1 Parallel Port Card

X X

N1M40AA

HP 800/600/400 G3 Serial/ PS/2 Adapter

X X

1VD82AA

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Change Log

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 86

© Copyright 2020 HP Development Company, L.P. All rights reserved.

The information contained herein is subject to change without notice. The only warranties for HP products are set forth in the
express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Microsoft and Windows
are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Intel, Celeron, Core, Pentium
are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a trademark of its
proprietor, used by HP, Inc. under license. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum. NVIDIA, GeForce
and NVS are trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and other countries. AMD and Radeon are
trademarks of Advanced Micro Devices, Inc. ENERGY STAR is a registered trademark owned by the U.S. Environmental Protection
Agency. DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in
the United States and other countries.

Date

Version History

Action

Description of Change

June 20, 2018

From v1 to v2

Update

Weights & Dimensions

June 28, 2018

From v2 to v3

Added

Environmental tab

July 19, 2018

From v3 to v4

Added

Note for SATA Drive Bracket added to Internal Slots and Ports
section

July 27, 2018

From v4 to v5

Remove

Checkmark off the SFF for the RX550 graphics card in the After
Market Options section

July 30, 2018

From v5 to v6

Change

Graphic cards info moved to processors section and graphic
removed off QS.

August 1, 2018

From v6 to v7

Add/remove

AMD Ryzer™ CPU added to processors
USB mentions formatted to last statement requirements

August 9, 2018

From v7 to v8

Update

Processors order re-arranged

August 20, 2018

From v8 to v9

Update

Shipping weight (Molded Pulp) added to to weight and
dimensions for SFF and MT
Palletization profile updated

August 21, 2018

From v9 to v10

Update

Windows Home removed

August 27, 2018

From v10 to v11

Update

Windows Home re-attached

August 30, 2018

From v11 to v12

Update

Optional Discrete Graphics Solutions table section added
GTX1060 and GT730 graphic cards specs added
After market options corrected

September 6, 2018

From v12 to v13

Add

System Integrated Graphics and its specs added on both
Graphics sections

September 13, 2018

From v13 to v14

Add

2700X CPU*, 2700 CPU* and 2600 CPU* processors information
updated.

September 18, 2018

From v14 to v15

Removal

Duplicated AMD Ryzen™ 7 PRO 2700X CPU* removed from

processors

September 19, 2018

From v15 to v16

Add

NVIDIA GeForce GT730 2GB DP DVI PCIe x8 GFX added to Graphics
section for MT and SFF

September 27, 2018

From v16 to v17

Update

AMD Radeon RX 560 graphic card added
Last bullet added to “At a Glance” section

October 5,2018

From v17 to v18

Update

Memory footnote change from 2400 to 2133

October 9, 2018

From v18 to v19

Update

Max boost and base frequency added to AMD Ryzen and PRO
processors

October 11, 2018

From v19 to v20

Update

Footnote 33 updated to Raid 1 configuration

October 17, 2018

From v20 to v21

Update

AMD® Athlon™ PRO 200GE APU with AMD®Radeon added to

processors

October 18, 2018

From v21 to v22

Update

VESA Plate Intergrated added to not shown call outs for Desktop
Mini
Athlon PRO" Processo added to “At a glance” second bullet

QuickSpecs

HP EliteDesk 705 G4 Business Desktops PCs

Change Log

Not all configuration components are available in all regions/countries.

c06040429 — DA16287 — Worldwide — Version 46 — July 30, 2020

Page 87

Foot note no. 4 removed from third bullet at “At a glance”section

AMD Athlon™ PRO 200GE Processor put in AMD® Ryzen™ with

AMD®Radeon processors section

November 14, 2018

From v22 to v23

Update

Max. Resolution added to AMD Radeon™ 560

November 21, 2018

From v23 to v24

Update

SSD Intel Optane 118GB 2280 PCIe NVME (Optane) removed from
storage

November 28, 2018

From v24 to v25

Update

Active Mode Row added to SFF Environmental data table

December 17, 2018

From v25 to v26

Update

AMD Radeon™ R7 430 Graphics 2GB GDDR5 64bit 2DP, AMD
Radeon™ R7 430 Graphics 2GB GDDR5 64bit DP+VGA and AMD

Radeon™ RX 580 Graphics 8GB GDDR5 Added to graphics

January 2, 2019

From v26 to v27

Update

Max System Weight set for MT and SFF

January 23, 2019

From v27 to v28

Update

AMD® PRO A6-9500 APU Graphics processor added for SFF

February 1, 2019

From v28 to v29

Update

HP PhoneWise, HP WorkWise and HP ePrinter + Jet advantage
removed.

February 11, 2019

From v29 to v30

Update

Support for VESA 100 mounting system on bottom of PC chassis”
added to mounting in the call outs section for DM

March 11, 2019

From v30 to v31

Update

Type C port USB port (2.0 or 3.0) and PORTS information
charging capability statement update and PORTS information, on
USB type C port (15W) added.

April 1, 2019

From v31 to v32

Update

DVD and Blue-ray ROM´s added to Storage specs section

April 15, 2019

From v32 to v33

Update

AMO updated

April 16, 2019

From v33 to v34

Update

HP 9.5mm Slim DVD Writer Drive Write speeds updated

May 15, 2019

From v34 to v35

Update

AMD® PRO A12-8870, AMD® PRO A10-8770 APU, AMD® PRO A6­8570 APU and Intel® 8260 802.11AC 2x2 DualBand PCIe x1
Combo added.

May 28, 2019

From v35 to v36

Update

Web-supported only added

June 27, 2019

From v36 to v37

Update

EPEAT references updated
RTL8111EPH NIC added on 705 G4 DM section
HP Cloud Recovery and footnote added at software section

July 10, 2019

From v37 to v38

Update

Duplicated environmental tables removed
Typo corrected in environmental table for SFF

July 29, 2019

From v38 to v39

Update

NVIDIA® GeForce® RTX 2060 6 GB and AMD® Radeon™ 520 1GB
added to Graphics
AMD® Radeon™ RX550 4GB made able for SFF

August 20, 2019

From v39 to v40

Update

Bays specs, and references updated
Disclaimer added to SFF call outs back image
Cable lock slot upgraded to Standard

September 10, 2019

From v40 to v41

Update

Windows 10 Enterprise 64 added to web supported only section

September 17, 2019

From v41 to v42

Update

Note added to Graphics

November 5, 2019

From v42 to v43

Update

EPEAT references updated / Power Factor table added to Power
Supply

December 11, 2019

From v43 to v44

Update

Weights and dimensions typos corrected

February 18, 2020

From v44 to v45

Update

Drivelock note and disclaimer added

July 30, 2020

From v45 to v46

Update

DM rear image call out #4 corrected
