QuickSpecs
Input/Output Devices - Notebooks
Overview
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 1
Input/Output Devices - Notebooks
Models
HP Pro x2 612 Replacement Wacom Pen
K0G16AA
HP Executive Tablet Pen G2
F3G73AA
HP Ultrathin Bluetooth Mouse
L9V78AA
HP Ultrathin Bluetooth Mouse SE
L9V77AA
HP Wireless Optical Mouse
K7S53AA
HP 2.4 GHz Wireless Mouse
L0Z84AA
HP Slim Bluetooth Mouse
F3J92AA
HP Ultra Mobile Wireless Mouse
H6F25AA
HP Touch to Pair Mouse
H6E52AA
HP X4000b Bluetooth Mouse
H3T50AA
HP Comfort Grip Wireless Mouse
H2L63AA
HP USB Travel Mouse
G1K28AA
HP 3-Button USB Laser Mouse
H4B81AA
HP Pro x2 612 G1 Travel Keyboard
G8X14AA
HP Pro x2 612 G1 Backlit Power Keyboard
K3T47AA
HP Elite x2 1011 Power Keyboard
L0U13AA
HP Elite x2 1011 G1 Travel Keyboard
K6B54AA
HP Bluetooth Keyboard
F3J73AA
HP Slim Bluetooth Keyboard
H4Q44AA
HP USB Essential Keyboard/Mouse (APJ & Americas only)
H6L29AA
HP Stylish USB Keyboard and Mouse
H4B80AA
HP Stylish Wireless Keyboard and Mouse
H4B79AA
HP 2.4 GHz Wireless Keyboard and Mouse Bundle
G1K29AA
HP Input/Output devices provide additional desktop functionality for HP Business Notebooks.
Introduction
QuickSpecs
Input/Output Devices - Notebooks
Overview
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 2
HP's Input/Output devices with USB connections are compatible with all HP Business Notebook and docking products.
HP Executive Tablet Pen Gen 2 is compatible only with the HP EliteBook Revolve 810 G2 , the HP ElitePad 1000 G2 and
HP Pro Tablet 610 G1. Refer to your notebook's QuickSpecs for specific compatibility.
The HP Wacom Replacement Pen and the HP Pro x2 612 G1Keyboards are compatible only with the HP Pro x2 612 G1.
The Elite X2 1011 G1 Soft Keyboard Jacket is only compatible with the HP Elite X2 1011 G1 only.
The HP Elite x2 1011 Power and Travel Keyboards are only compatible with the HP Elite x2 1011.
NOTE: Not all localizations and models are available in all regions.
HP's Input/Output devices have a one-year limited warranty. Technical support is available seven days a week, 24 hours a day, as
well as in online support forums. Certain restrictions and exclusions apply.
Compatibility
Service and Support
QuickSpecs
Input/Output Devices - Notebooks
Technical Specifications
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 3
HP Pro x2 612 Replacement
Wacom Pen
Dimensions ( L x W)
4.33 x .22 in (110 x 5.5 mm)
Weight
.10 oz (2.8 g)
Color and materials
Black plastic
Connecting technology
Electro-Magnetic Resonance (EMR)
Kit contents
HP Wacom Digitizer Pen and documentation
Hovering
15 mm
Pressure sensing
1024 levels
Battery
Not required
Compatibility
HP Pro x2 612 G1
HP Executive
Tablet Pen G2
Dimensions ( L x W)
5.65 x 0.47 in (143.5 x 11.8 mm)
Weight
1.06 oz (30 g)
Color
Black
Power
One AAA battery
System requirements
Windows 8, Windows 8.1
Compatibility
HP ElitePad 1000 G2 Tablet, and HP EliteBook
Revolve 810 G2 only
Kit contents
HP Executive Tablet Pen G2, AAA battery and
documentation
Functionality
Right-click, draw, type, and navigate better than
ever with a capacitive tip that offers pin-point
accuracy to help improve productivity.
Pen supports hover feature and pressure sensitivity
levels up to 256
Windows 8 Certified
Soft tip for quiet performance and more precise
writing capabilities
HP Ultrathin
Bluetooth Mouse
Dots per inch (PDI)
1200
Connectivity
Bluetooth® 3.0
Dimensions (H x L x W)
1.02 x 2.48 x3.98 in (2.60 x 6.12 x 10.88 cm)
Weight
3.60 oz (102 g)
Color
Black
System requirements
Windows 7, Windows 8 and Windows 10
Functionality
4-Way Scroll
Vertically : 1 or 2 fingers UP or 1 or 2 fingers Down
Horizontally : 1 or 2 fingers Left or 1 or 2 fingers
Right
Kit contents
HP Ultrathin Bluetooth Mouse, two AA batteries and
documentation
NOTE: The Wacom Pen is available as a configurable option at the time of order and available on models ordered with a digitizer
screen. Models without a built-in digitizer are incompatible with the Pen and cannot be added as aftermarket option.
QuickSpecs
Input/Output Devices - Notebooks
Technical Specifications
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 4
HP Ultrathin Bluetooth
Mouse SE
Dots per inch (PDI)
1200
Connectivity
Bluetooth® 3.0
Dimensions (H x L x W)
1.02 x 2.48 x3.98 in (2.60 x 6.12 x 10.88 cm)
Weight
3.60 oz (102 g)
Color
Red
System requirements
Windows 7, Windows 8 and Windows 10
Functionality
4-Way Scroll
Vertically : 1 or 2 fingers UP or 1 or 2 fingers Down
Horizontally : 1 or 2 fingers Left or 1 or 2 fingers
Right
Kit contents
HP Ultrathin Bluetooth Mouse SE, two AA batteries
and documentation
HP Wireless Optical Mouse
Dots per inch (PDI)
1200
Connectivity
2.4 GHz
Tracking type
Optical
Dimensions (H x L x W)
1.40 x 2.26 x 3.70 in (3.58 x 5.75 x 9.40 cm)
Weight
2.09 oz (59.5 g)
System requirements
Windows 7, Windows 8 and Windows 10
Available USB port
Functionality
3 Buttons (Left, Right and Scroll)
Kit contents
HP Wireless Optical Mouse, nano USB receiver, one
AA battery and documentation
HP 2.4 GHz Wireless Mouse
Dots per inch (PDI)
1600
Connectivity
2.4 GHz
Tracking type
Optical
Dimensions (H x L x W)
1.53 x 2.24 x 3.73 in (3.91 x 5.70 x 9.48 cm)
Weight
2.82 oz (80 g)
System requirements
Windows 7, Windows 8 and Windows 10
Available USB port
Functionality
3 Buttons (Left, Right and Scroll)
Kit contents
HP 2.4 GHz Wireless Mouse, nano USB receiver, one
AA battery and documentation
HP Slim Bluetooth
Mouse
Dots per inch (PDI)
1200
Connectivity
Bluetooth 3.0
Dimensions (H x L x W)
0.98 x 4.00 x 2.54 in (2.50 x 10.17 x 6.46 cm)
Weight
1.55 oz (44 g)
System requirements
Windows XP ,Vista ,Windows 7 , Windows 8 ,
Windows 10, Mac OSX , Chrome , and Android
Kit contents
HP Slim Bluetooth Mouse , one AA battery and
documentation
QuickSpecs
Input/Output Devices - Notebooks
Technical Specifications
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 5
HP Ultra Mobile Wireless
Mouse
Dots per inch (PDI)
1200
Connectivity
2.4 GHz, Link 5
Dimensions (H x L x W)
0.98 x 4.00 x 2.54 in (2.50 x 10.17 x 6.46 cm)
Weight
3.25 oz (92 g)
System requirements
Windows XP, Vista, Windows 7, Windows 8, Windows
10, Mac OSX, and Android
Kit contents
HP Ultra Mobile Wireless Mouse, two AA batteries
and documentation
HP Touch to Pair Mouse
Dots per inch (PDI)
1600
Connectivity
Bluetooth 3.0 + NFC
Dimensions (H x L x W)
1.52 x 4.21 x 2.88 in (3.86 x 10.70 x 7.31 cm)
Weight
2.65 oz (75 g) (w/o batteries)
System requirements
Windows Vista, Windows 7, Windows 8 and Windows
10 (NFC pairing only works on system with NFC
enabled and Windows 8 and higher)
Kit contents
HP Touch to Pair Mouse, two AA batteries, and
documentation
HP X4000b Bluetooth Mouse
Dots per inch (PDI)
1200-1600
Connectivity
Bluetooth 3.0
Dimensions (H x L x W)
1.52 x 4.21 x 2.64 in (3.86 x 10.69 x 6.71 cm)
Weight
4.3 oz (122.5 g)
System requirements
Windows Vista, Windows 7, Windows 8, and
Windows 10
Kit contents
HP X4000b Bluetooth mouse, two AA batteries and
documentation
HP Comfort Grip Wireless Mouse
Dots per inch (PDI)
800
Connectivity
2.4 GHz, Link 5
Dimensions (H x L x W)
1.52 x 4.21 x 2.64 in (3.86 x 10.69 x 6.71 cm)
Weight
4.3 oz (122.5 g)
System requirements
Windows Vista, Windows 7, Windows 8, and
Windows 10;
Available USB port
Kit contents
HP Comfort Grip Wireless Mouse, USB Wireless
micro-receiver, two AA batteries, and
documentation
QuickSpecs
Input/Output Devices - Notebooks
Technical Specifications
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 6
HP USB Travel Mouse
Dots per inch (PDI)
1000
Dimensions (H x L x W)
1.45 x 3.85 x 2.32 in (3.7 x 9.8 x 5.9 cm)
Weight
2.15 oz (61 g)
Cable length
3 ft (95 cm)
System requirements
Windows 7, Windows 8 and Windows 10
Available USB port
Approvals
EMC
Standards
EN55022:1998, EN55024:1998
Safety
Standards
UL(60950), CSA(60950-1-03),
(EN60950-1:2006)
Laser
Standards
Mouse in compliance with EN 608251:1994 Class 1 LED
Kit contents
HP USB Travel Mouse and documentation
HP 3-Button USB Laser Mouse
Dots per inch (PDI)
1000
Dimensions (H x L x W)
1.47 x 4.53 x 2.47 in (3.73 x 11.5 x 6.29 cm)
Weight
3.36 oz (102 g)
Cable length
6 ft (180 cm)
System requirements
Windows Vista, Windows 7; Available USB port
Kit contents
HP 3-Button USB Laser Mouse and documentation
HP Pro x2 612 G1Travel
Keyboard
Dimensions
8.89 x 12.38 x 0.23 inch (22.6 x 31.4 x 0.6 cm)
Weight
1.57 lbs (715 g)
Kit contents
HP Pro x2 612 G1 Travel Keyboard and
documentation
Key Features
- Thin keyboard folio with retaining flap
- ClickPad (87 x 49 mm) with image sensor,
multi-touch gestures enabled, on/off
function and LED indicator
- Foldable kickstand; 120° viewing angle
- Docking connector to tablet
- USB 3.0 port
- Combo audio jack, DC-in (4.5mm)
- Full size 81/82-key island-style backlit
keyboard with full row of function keys and
LED indicators
HP Pro x2 612 G1Backlit
Power Keyboard
Dimensions
9.43 x 12.44 x 0.39 inch (23.9 x 31.6 x 0.10 cm)
Weight
2.16 lbs (980 g)
Kit contents
HP Pro x2 612 G1 Backlit Power Keyboard and
documentation
Key Features
- Power keyboard base
- ClickPad (87 x 49 mm) with image sensor,
multi-touch gestures enabled, on/off
function and LED indicator
QuickSpecs
Input/Output Devices - Notebooks
Technical Specifications
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 7
- Docking connector, DisplayPort 1.2, VGA,
SD card reader, 2 USB 3.0 port (1 charging),
RJ45, Combo audio jack, DC-in (4.5mm)
- Full size 81/82-key island-style backlit
keyboard with full row of function keys and
LED indicators
HP Elite x2 1011
Power Keyboard
Dimensions
11.73 x 8.12 x 0.82 in (29.8 x 20.61 x 2.08 cm)*
*Tablet with power keyboard
Weight
Starting at 1.72 lbs ( 780 g)
Kit contents
HP Elite x2 1011 Power Keyboard , documentation
Ports and slots
Ports
1 docking connector to tablet
1 headphone/microphone combo
1 DisplayPort 1.2
1 USB 3.0
1 USB 3.0 charging
1 docking connector for dongle support
1 4.5 mm multi-pin AC port
Slots
1 smart card reader
HP Elite x2 1011
Travel Keyboard
Dimensions
11.6 x 8.26x 0.24 inch (29.56 x 21.0 x 0.6 cm)
Weight
1.18 lbs (530 g)
Kit contents
HP Elite x2 1011 G1 Travel Keyboard and
documentation
Key features
-Thin keyboard folio with retaining flap
-ClickPad (87 x 49 mm) with image sensor,
multi-touch gestures enabled, on/off function and
LED indicator
-Foldable kickstand; 130° viewing angle
-Docking connector to tablet
-USB 3.0 port
-Combo audio jack, DC-in (4.5mm)
-Full size 81/82-key island-style backlit keyboard
with full row of function keys and LED indicators
HP Bluetooth Keyboard
Dimensions (H x L x W)
0.59 x 10.43 x 4.60 in (1.50 x 26.50 x 11.70
cm)
Weight
8.85oz (251 g)
Connectivity
Bluetooth 3.0
System requirements
Windows Vista, Windows 7, Windows 8,
Windows 10 and Android
Kit contents
HP Bluetooth Keyboard, two AAA batteries
and documentation
QuickSpecs
Input/Output Devices - Notebooks
Technical Specifications
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 8
HP Slim Bluetooth Keyboard
Dimensions (H x L x W)
0.6 x 10.3 x 4.6 in (1.7 x 26.4 x 11.7 cm)
Weight
9.5 oz (270 g)
Connectivity
Bluetooth 3.0
System requirements
Windows Vista, Windows 7, Windows 8
Kit contents
HP Slim Bluetooth Keyboard, two AAA batteries, and
documentation
HP USB Essential Keyboard/Mouse
(APJ & Americas only)
HP USB Essential Keyboard
Dimensions (H x L x W)
1.08 x 18.15 x 6.02 in (2.74 x 46.1 x 15.3 cm)
Weight
20.6 oz (585 g)
Cable length
5 ft (1.5 m)
System requirements
Windows Vista, Windows 7,Windows 8, and Windows
10
Available USB port
Approvals
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick,
MIC
HP USB Essential Mouse
Dots per inch (PDI)
1000
Dimensions (H x L x W)
1.37 x 4.53 x 2.48 inch (3.50 x 11.50 x 6.30 cm)
Weight
3.74 oz (106 g)
Cable length
5.9 ft (1.8 m)
System requirements
Windows Vista, Windows 7, Windows 8, and Windows
10.
Available USB port
Approvals
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick,
MIC
Kit contents
Keyboard, mouse, and documentation
HP Stylish USB Keyboard and Mouse
HP Stylish USB Keyboard
Dimensions (H x L x W)
0.98 x 18.0 x 6.4 in (2. 5 x 45.8 x 16.3 cm)
Weight
31.7 oz (900 g) minimum
Cable length
6 ft (1.8 m)
System requirements
Windows Vista, Windows7; Available USB port
HP Stylish USB Mouse
Dots per inch (PDI)
1000
Dimensions (H x L x W)
1.47 x 4.53 x 2.47 in (3.73 x 11.5 x 6.29 cm)
Weight
3.36 oz (102 g)
Cable length
Cable length 6 ft (180 cm)
System requirements
Windows Vista, Windows 7; Available USB port
Approvals
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick,
MIC
Kit contents
Keyboard, Mouse, and documentation
QuickSpecs
Input/Output Devices - Notebooks
Technical Specifications
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 9
HP Stylish Wireless Keyboard and Mouse
HP Stylish Wireless Keyboard
Dimensions (H x L x W)
1.09 x 18.1 x 6.47 in (2.79 x 46.03 x 16.43 cm)
Weight
Wireless Connection Encryption
31.04 oz (880 g) (w/o batteries)
Secure 128-bit (AES) encryption between device and
receiver
System requirements
Windows Vista, Windows 7; Available USB port for the
receiver; CD-ROM Drive
HP Stylish Wireless Mouse
Dots per inch (PDI)
1000
Dimensions (H x L x W)
1.46 x 4.53 x 2.47 in (37 x 115 x 62.9 mm)
Weight
2.4 oz (67 g)
System requirements
Windows Vista, Windows 7; Available USB port for the
receiver; CD-ROM Drive
Kit contents
Keyboard, Mouse, USB Receiver, Software and
Documentation CD-ROM, product and warranty
documentation, four AA Alkaline batteries (installed)
HP 2.4 GHz Wireless Keyboard
and Mouse Bundle
Keyboard
Dimensions (H x L x W)
1.08 x 16.6 x 5.66 in ( 2.74 x 42.15 x 14.38 cm)
Weight
Wireless Connection Encryption
16.27 oz (460 g) With battery
Secure 128-bit (AES) encryption between device and
receiver
System requirements
Windows Vista, Windows 7; Windows 8, Windows 8.1,
Windows 10 and Android. USB to connect the receiver.
Mouse
Dots per inch (PDI)
1000
Dimensions (H x L x W)
1.46 x 4.53 x 2.48 inch (3.7 x 11.5 x 6.29 cm)
Weight
4.06 oz (115 g) With battery
System requirements
Windows Vista, Windows 7; Windows 8, Windows 8.1,
and Android. USB to connect the receiver.
Kit contents
Keyboard, Mouse, USB Receiver, AA batteries and
documentation
QuickSpecs
Input/Output Devices - Notebooks
Summary of Changes
c04168420 – DA 11862 – Worldwide – Version 39 – July 27, 2015
Page 10
Date of change:
Version History:
Description of change:
June 16, 2014
From v25 to v26
Changed
Version to match PB
June 21, 2014
V26 to v27
Added
HP Executive Tablet Pen
November 6, 2014
V27 to V28
Added
HP Wacom Digitizer Pen and HP Pro x2 612 G1Travel
Keyboard
November 7, 2014
V28 to V29
Added
The HP Wireless Optical Mouse and the
HP 2.4 GHz Wireless Mouse
November 26, 2014
V29 to V30
Changed
HP 2.4 GHz Wireless Mouse resolution
December 16, 2014
V30 to V31
Added
HP Elite x2 1011 G1 Travel Keyboard and specs
The disclaimer for the Wacom Replacement Pen.
January 12, 2015
V31 to V32
Updated
Name of HP Elite x2 612 Replacement Wacom Pen
February 17, 2015
V32 to V33
Added
HP Pro x2 1011 Power Keyboard
February 18, 2015
V33 to V34
Added
HP Pro x2 1011 Travel Keyboard
February 19, 2015
V34 to V35
Added
HP Ultrathin Wireless Mouse
April 1, 2015
V35 to V36
Changed
HP Ultrathin Wireless Mouse to HP Ultrathin Bluetooth
Mouse
Added
HP Ultrathin Bluetooth Mouse SE
May 20, 2015
V36 to V37
Added
Wireless Connection Encryption
July 17, 2015
V37 to V38
Updated
Products that are Windows 10 compatible
July 27, 2015
V38 to V39
Removed
Products that are end of life
HP Optical USB Travel Mouse RH304AA
HP USB Essential Keyboard and Mouse Bundle
H2S75AA
© Copyright 2015 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. Microsoft and Windows are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries. Bluetooth is a trademark of its proprietor and
used by Hewlett-Packard Company under license. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Loading...
