DATA SHEET

ARUBA 2530 SWITCH SERIES

PRODUCT OVERVIEW

The Aruba 2530 Switch Series provides security, reliability,

and ease of use for enterprises, branch oces, and SMBs.

This series of fully managed switches delivers full Layer 2

capabilities with enhanced access security, ACLs, trac

prioritization, sFlow, and IPv6 host support. Right size

deployment is simple with choice of 8-, 24-, and 48-port

models available with Gigabit or Fast Ethernet ports, and

optional PoE+. The 2530 delivers power savings with fanless

models, Energy Ecient Ethernet, ability to disable LEDs and

enable port low power mode.

The Aruba 2530 Switch Series is easy to use and deploy,

and delivers consistent wired/wireless user experience with

unied management tools such as Aruba ClearPass Policy

Manager, Aruba AirWave and cloud-based Aruba Central.

KEY FEATURES

• Cost-eective, reliable and secure Aruba Layer 2

switch series.

• ACLs, EEE, trac prioritization.

• 8-, 24-, and 48-port Gigabit or Fast Ethernet models.

• PoE+ models for voice, video and wireless.

• Security and network management with Aruba

ClearPass Policy Manager, AirWave and cloud-

based Central

The Aruba 2530 Switch Series oers uplink exibility with

four Gigabit Ethernet uplinks on 24- and 48-port models. The

Gigabit 24- and 48-port models have four small form-factor

pluggable (SFP) slots for ber connectivity. The Fast Ethernet

24- and 48-port models have two SFPs and two RJ-45 Gigabit

uplinks. The compact and fan-less 8-port switches oer

additional exibility with two dual-personality ports that can be

used as either RJ-45 Gigabit Ethernet or SFP ports. The PoE+

switch models are IEEE 802.3af- and IEEE 802.3at-compliant

with up to 30 W per port, making them suitable for voice, video,

or wireless deployments with PoE+.

FEATURES AND BENEFITS

Unied Wired and Wireless

• ClearPass Policy Manager supports unied wired and

wireless policies using Aruba ClearPass Policy Manager

• Switch auto-conguration automatically congures switch

for dierent settings such as VLAN, CoS, PoE max power,

and PoE priority when Aruba AP is detected

• User Role denes a set of switch-based policies in areas

such as security, authentication, and QoS. A User Role

can be assigned to a group of users or devices, using local

switch conguration (YA only)

Quality of Service (QoS)

• Trac prioritization (IEEE 802.1p) allows real-time trac

classication with support for eight priority levels mapped

to either two or four queues, and uses weighted decit

round robin (WDRR) or strict priority

• Simplied quality of service (QoS) conguration

 - Port-based prioritizes trac by specifying a port and

priority level

 - VLAN-based prioritizes trac by specifying a VLAN and

priority level

• Class of Service (CoS) sets the IEEE 802.1p priority tag

based on IP address, IP Type of Service (ToS), Layer 3

protocol, TCP/UDP port number, source port, and DiServ

• Rate limiting establishes per-port ingress-enforced

maximums for all ingressed trac or for broadcast,

multicast, or unknown destination trac

• Layer 4 prioritization enables prioritization based on

TCP/UDP port numbers

• Flow control helps deliver reliable communication during

full-duplex operation

DATA SHEET

ARUBA 2530 SWITCH SERIES

Management

• Aruba Central support—Cloud-based management platform

complies with RFC 7030 for encryption key enrollment

• Zero-Touch ProVisioning (ZTP) uses settings in DHCP to

enable ZTP with Aruba AirWave

• Flexible management with same hardware – Supports both

cloud-based Central and on-premise AirWave with the same

hardware ensuring change management platform without

ripping and replacing switching infrastructure

• Choice of management interfaces

 - HTML-based easy-to-use Web GUI allows conguration

of the switch from any Web browser

 - Robust CLI provides advanced conguration and diagnostics

 - Simple network management protocol (SNMPv1/v2c/v3)

allows the switch to be managed with a variety of third-

party network management applications

• Virtual stacking provides single IP address management for

up to 16 switches

®

• sFlow

(RFC 3176) delivers wire-speed trac accounting and

monitoring, congured by SNMP and CLI with three terminal

encrypted receivers

• IEEE 802.1AB Link-Layer Discovery Protocol (LLDP)

automates device discovery protocol for easy mapping by

network management applications

• Logging provides local and remote logging of events via

SNMP (v2c and v3) and syslog; provides log throttling and

log ltering to reduce the number of log events generated

• Port mirroring allows trac to be mirrored on any port or

a network analyzer to assist with diagnostics or detecting

network attacks

• Remote monitoring (RMON) provides advanced monitoring

and reporting capabilities for statistics, history, alarms,

and events

• Friendly port names allows assignment of descriptive

names to ports

• Dual ash images provides independent primary and

secondary operating system les for backup while upgrading

• Multiple conguration les are easily stored with a

ash image

• Front-panel LEDs

 - Locator LEDs allows users to set the locator LED on a

specic switch to turn on, blink, or turn o; and simplies

troubleshooting by making it easy to locate a particular

switch within a rack of similar switches

 - Per-port LEDs provides an at-a-glance view of the status,

activity, speed, and full-duplex operation

 - Power and fault LEDs display issues, if any

• Download Software via DHCP adds the option to specify

the location of switch software via DHCP

• TR-069 support enables zero-touch conguration for switches

Connectivity

• IPv6

 - IPv6 host allows the switch to be deployed and

managed at the edge of an IPv6 network

 - Dual stack (IPv4/IPv6) supports connectivity for both

protocols; provides a transition mechanism from IPv4

to IPv6

 - MLD snooping forwards IPv6 multicast trac to

appropriate interface; prevents IPv6 multicast trac

from ooding the network

 - IPv6 ACL/QoS supports ACL and QoS for IPv6 network

trac on Gigabit and 48 port 10/100 models

 - Security RA Guard, DHCPv6 Protection, Dynamic IPv6

Lockdown (YA only)

• IEEE 802.3at Power over Ethernet (PoE+) provides up

to 30 W per port that allows support of the latest PoE+

capable devices such as IP phones, wireless access

points, and security cameras, as well as any IEEE 802.3af

compliant end device; eliminates the cost of additional

electrical cabling and circuits that would otherwise be

necessary in IP phone and WLAN deployments

• Auto-MDIX adjusts automatically for straight-through or

crossover cables on all ports

• Pre-standard PoE support detects and provides power to

pre-standard PoE devices

• SFP slots provides ber connectivity such as Gigabit-SX,

LX, LH, and BX with four SFP slots on all 24- and 48-port

Gigabit Ethernet models. Fast Ethernet 24- and 48-port

models have two SFP slots and two RJ-45 Gigabit uplinks;

8-port models have two dual-personality ports supporting

either SFP or RJ-45 Gigabit uplinks

• Dual-personality (RJ-45 or USB micro-B) serial console

port gives easy access to switch CLI with front-of-switch

location and the exibility of using either an RJ-45 or USB

micro-B serial console port

Layer 2 switching

• VLANs provides support for 512 VLANs and 4,094

VLAN IDs

• Jumbo packet support supports up to 9,220-byte frame

size to improve the performance of large data transfers;

8- and 24-port Fast Ethernet models automatically support

up to 2,000-byte frames with no conguration needed

DATA SHEET

ARUBA 2530 SWITCH SERIES

• 16K MAC address table provides access to many

Layer 2 devices

• GARP VLAN Registration Protocol allows automatic learning

and dynamic assignment of VLANs

• Rapid Per-VLAN Spanning Tree (RPVST+) allows each

VLAN to build a separate spanning tree to improve link

bandwidth usage; is compatible with PVST+

Security

• ACLs accommodates IPv4/IPv6 port and VLAN-based ACLs

(IPv6 ACL is supported only on Gigabit Ethernet and 48-

port models.)

• Source-port ltering allows only specied ports to

communicate with each other

• RADIUS/TACACS+ eases switch management security

administration by using a password authentication server

• Secure Sockets Layer (SSL) encrypts all HTTP trac,

allowing secure access to the browser-based

management GUI in the switch

• Port security allows access only to specied MAC addresses,

which can be learned or specied by the administrator

• MAC address lockout prevents particular congured MAC

addresses from connecting to the network

• Multiple user authentication methods

 - IEEE 802.1X uses an IEEE 802.1X supplicant on the client

in conjunction with a RADIUS server to authenticate in

accordance with industry standards

 - Web-based authentication provides a browser-based

environment, similar to IEEE 802.1X, to authenticate

clients that do not support the IEEE 802.1X supplicant

 - MAC-based authentication authenticates the client with

the RADIUS server based on the client’s MAC address

• Secure shell (SSH) v2 encrypts all transmitted data for

secure remote CLI access over IP networks

• Secure shell encrypts all transmitted data for secure

remote CLI access over IP networks

• STP BPDU port protection blocks Bridge Protocol Data

Units (BPDUs) on ports that do not require BPDUs,

preventing forged BPDU attacks

• STP root guard protects the root bridge from malicious

attacks or conguration mistakes

• Secure management access delivers protected encryption

of all access methods (CLI, GUI, or MIB) through SSHv2

and SNMPv3

• Custom banner displays security policy when users log in

to the switch

• Secure FTP allows secure le transfer to and from the

switch; protects against unwanted le downloads or

unauthorized copying of a switch conguration le

• Protected ports CLI oers intuitive CLI to congure the

source-port lter feature, by allowing specied ports to be

isolated from all other ports on the switch; the protected

port or ports can communicate only with the uplink or

shared resources

• Authentication exibility

 - Multiple IEEE 802.1X users per port provides

authentication for up to 32 IEEE 802.1X users per port;

prevents a user from “piggybacking” on another user’s

IEEE 802.1X authentication

 - Concurrent IEEE 802.1X and Web or MAC authentication

schemes per port allows a switch port to accept any

IEEE 802.1X and either Web or MAC authentications

• Switch management logon security helps secure switch

CLI logon by optionally requiring either RADIUS or

TACACS+ authentication

• DHCP protection blocks DHCP packets from unauthorized

DHCP servers, preventing denial-of-service attacks

• Dynamic ARP protection blocks ARP broadcasts from

unauthorized hosts, preventing eavesdropping or theft of

network data

• Dynamic IP lockdown works with DHCP protection to block

trac from unauthorized hosts, preventing IP source

address spoong

• MAC Pinning allows non-chatty legacy devices to stay

authenticated by pinning client MAC addresses to the port

until the clients logo or get disconnected

Convergence

• IEEE 802.1AB Link Layer Discovery Protocol (LLDP) facilitates

easy mapping using network management applications with

LLDP automated device discovery protocol

• LLDP-MED (Media Endpoint Discovery) denes a standard

extension of LLDP that stores values for parameters such

as QoS and VLAN to automatically congure network

devices such as IP phones

• IP multicast (data-driven IGMP) prevents ooding of IP

multicast trac

• PoE and PoE+ allocations support multiple methods—

automatic, IEEE 802.3at dynamic, LLDP-MED ne grain,

IEEE 802.3af device class, or user specied—to allocate and

manage PoE/PoE+ power for more ecient energy use

• Voice VLAN uses LLDP-MED to automatically congure a

VLAN for IP phones

DATA SHEET

ARUBA 2530 SWITCH SERIES

• IP multicast (data-driven IGMPv3) prevents ooding of IP

multicast trac

• LLDP-CDP compatibility receives and recognizes CDP

packets from Cisco’s IP phones for seamless interoperation

• Local MAC Authentication assigns attributes such as VLAN

and QoS using locally congured prole that can be a list

of MAC prexes Unied Wired and Wireless

• HTTP redirect function supports HPE Intelligent

Management Center (IMC) bring your own device

(BYOD) solution

Resiliency and high availability

• Port trunking and link aggregation

 - Trunking supports up to eight links per trunk to increase

bandwidth and create redundant connections; and

supports L2, L3, and L4 trunk load-balancing algorithm

(L4 trunk load balancing is supported only on Gigabit

Ethernet and 48-port models.)

 - IEEE 802.3ad Link Aggregation Control Protocol

(LACP) eases conguration of trunks through

automatic conguration

• IEEE 802.1s Multiple Spanning Tree provides high link

availability in multiple VLAN environments by allowing

multiple spanning trees; provides legacy support for IEEE

802.1d and IEEE 802.1w

• SmartLink provides easy-to-congure link redundancy of

active and standby links

Flexibility

• Flexible mounting

 - Rack mountable allows the switch to be mounted on a

standard 19-inch rack, with the hardware included

 - Wall mountable allows the switch to be mounted on a

wall, using the hardware included

 - Surface mountable allows the switch to be mounted

above or below a surface (such as a desk or table), using

the hardware included

• Quiet operation lowers noise, making it suitable for

deployments in acoustically sensitive environments such

as conference rooms and oce spaces

• Compact size reduces space requirements (refer to the

product specications for the exact dimensions)

Warranty and support

• Limited Lifetime Warranty

See www.hpe.com/networking/warrantysummary for

warranty and support information included with your

product purchase.

Software releases

• To nd software for your product, refer to www.hpe.com/

networking/support; for details on the software releases

available with your product purchase, refer to www.hpe.

com/networking/warrantysummary

Product architecture

• Energy-ecient design

 - IEEE 802.3az reduces power consumption during

periods of low data activity on Gigabit Ethernet switches

 - Port low-power mode enables the port to automatically

go into low-power mode to conserve energy when no

link is detected

 - Fan-less and variable-speed fans decreases power

consumption in fan-less (all 8-port, 2530-24, and 2530-

48 PoE+ switches) as well as variable-speed fan switches

 - Port LEDs conserves energy by optionally turning o

port link and activity LEDs

• Switch on a chip provides a highly integrated, high-

performance switch design with a nonblocking architecture

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48G-PoE+ Switch
(J9772A)

I/O ports and slots

48 RJ-45 autosensing 10/100/1000
PoE+ ports (IEEE 802.3 Type
10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type
1000BASE-T, IEEE 802.3at PoE+);
Media Type: Auto-MDIX; Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

4 xed Gigabit Ethernet SFP ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

Physical characteristics

Dimensions 17.44 (w) x 13.00 (d) x 1.75 (h) in

(44.3 x 32.26 x 4.45 cm)
(1U height)

Weight 10.4 lb (4.72 kg) 8.7 lb (3.95 kg) 2.2 lb (1 kg)

Memory and processor

Processor ARM9E @ 800 MHz, 128 MB ash,

256 MB DDR3 DIMM; packet buer
size: 3 MB dynamically allocated

Mounting and enclosure

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

Performance

IPv6 Ready Certied IPv6 Ready Certied IPv6 Ready Certied

100 Mb Latency < 7.4 µs (LIFO 64-byte packets) < 7.4 µs (LIFO 64-byte packets) < 7.4 µs (LIFO 64-byte packets)

1000 Mb Latency < 2.3 µs (LIFO 64-byte packets) < 2.3 µs (LIFO 64-byte packets) < 2.6 µs (LIFO 64-byte packets)

Throughput up to 77.3 Mpps (64-byte packets) up to 41.6 Mpps (64-byte packets) up to 14.8 Mpps (64-byte packets)

Switching capacity 104 Gbps 56 Gbps 20 Gbps

MAC address table size 16000 entries 16000 entries 16000 entries

Aruba 2530-24G-PoE+ Switch
(J9773A)

24 RJ-45 autosensing 10/100/1000
PoE+ ports (IEEE 802.3 Type
10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type
1000BASE-T, IEEE 802.3at PoE+);
Media Type: Auto-MDIX; Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

4 xed Gigabit Ethernet SFP ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

17.44 (w) x 13.00 (d) x 1.75 (h) in
(44.3 x 33.02 x 4.45 cm)
(1U height)

ARM9E @ 800 MHz, 128 MB ash,
256 MB DDR3 DIMM; packet buer
size: 1.5 MB dynamically allocated

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

Aruba 2530-8G-PoE+ Switch
(J9774A)

8 RJ-45 autosensing 10/100/1000
PoE+ ports (IEEE 802.3 Type
10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type
1000BASE-T, IEEE 802.3at PoE+);
Media Type: Auto-MDIX; Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

2 dual-personality ports; each port
can be used as either an RJ-45
10/100/1000 port (IEEE 802.3 Type
10Base-T; IEEE 802.3u Type 100Base­TX; IEEE 802.3ab1000Base-T Gigabit

Ethernet) or as a SFP slot (for use with
SFP transceivers)

1 dual-personality (RJ-45 or USB
micro-B) serial console port

10.00(w) x 6.28(d) x 1.75(h) in
(25.4 x 15.95 x 4.45 cm)
(1U height)

ARM9E @ 800 MHz, 128 MB ash,
256 MB DDR3 DIMM; packet buer
size: 1.5 MB dynamically allocated

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48G-PoE+ Switch
(J9772A)

Environment

Operating temperature 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C)

Operating relative

humidity

Nonoperating/Storage

temperature

Nonoperating/Storage

relative humidity

Altitude up to 10,000 ft (3 km) up to 10,000 ft (3 km) up to 10,000 ft (3 km)

Acoustic Power: 43.6 dB, Pressure: 33.6 dB Power: 43.9 dB, Pressure: 39.6 dB Power: 0 dB, Pressure: 0 dB

Electrical characteristics

Frequency 50/60 Hz 50/60 Hz 50/60 Hz

Maximum heat dissipation 236 BTU/hr (248.98 kJ/hr), (switch

AC voltage 100 - 127/200 - 240 VAC 100 - 127/200 - 240 VAC 100 - 127/200 - 240 VAC

Current 5.8/2.9 A 3.2/1.6 A 1.4 A

Maximum power rating 476 W 247 W 86 W

Idle power 40.1 W 25.2 W 13.4 W

PoE power 382 W 195 W 67 W

Notes Idle power is the actual power

Safety

Emissions

15% to 95% @ 104°F (40°C),
noncondensing

-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C)

15% to 90% @ 149°F (65°C),

noncondensing

only: 236 BTU/hr; combined switch
+ max. PoE devices: 1624 BTU/hr)

consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

PoE power is the total power

budget available to all PoE ports.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

Aruba 2530-24G-PoE+ Switch
(J9773A)

15% to 95% @ 104°F (40°C),
noncondensing

15% to 90% @ 149°F (65°C),
noncondensing

135 BTU/hr (142.42 kJ/hr), (switch
only: 135 BTU/hr; combined switch
+ max. PoE devices: 843 BTU/hr)

Idle power is the actual power
consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

PoE power is the total power

budget available to all PoE ports.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

Aruba 2530-8G-PoE+ Switch
(J9774A)

15% to 95% @ 104°F (40°C),
noncondensing

15% to 90% @ 149°F (65°C),
noncondensing

65 BTU/hr (68.58 kJ/hr), (switch only:
65 BTU/hr; combined switch + max.
PoE devices: 293 BTU/hr)

Idle power is the actual power
consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

PoE power is the total power

budget available to all PoE ports.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48G-PoE+ Switch
(J9772A)

Immunity

Generic EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24

EN EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24

ESD IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2

Radiated IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3

EFT/Burst IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4

Surge IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5

Conducted IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6

Power frequency

magnetic eld

Voltage dips and

interruptions

Harmonics EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2

Flicker EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3

Management

Notes

Services

IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8

IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

Aruba 2530-24G-PoE+ Switch
(J9773A)

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

Aruba 2530-8G-PoE+ Switch
(J9774A)

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48-PoE+ Switch
(J9778A)

I/O ports and slots

48 RJ-45 autosensing 10/100 PoE+
ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX,
IEEE 802.3at PoE+); Media Type:
Auto-MDIX; Duplex: half or full

2 autosensing 10/100/1000 ports
(IEEE 802.3 Type 10BASE-T, IEEE

802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

2 xed Gigabit Ethernet SFP ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

Physical characteristics

Dimensions 17.40 (w) x 12.70 (d) x 1.75 (h) in

(44.2 x 32.26 x 4.45 cm)
(1U height)

Weight 10.1 lb (4.58 kg) 8.4 lb (3.81 kg) 2.0 lb (0.91 kg)

Memory and processor

Processor ARM9E @ 800 MHz, 128 MB ash,

256 MB DDR3 DIMM; packet buer
size: 3 MB dynamically allocated

Mounting and enclosure

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

Performance

IPv6 Ready Certied IPv6 Ready Certied IPv6 Ready Certied

100 Mb Latency < 6.6 µs (LIFO 64-byte packets) < 1.7 µs (LIFO 64-byte packets) < 1.3 µs (LIFO 64-byte packets)

1000 Mb Latency < 2.2 µs (LIFO 64-byte packets) < 1.1 µs (LIFO 64-byte packets) < 1.3 µs (LIFO 64-byte packets)

Throughput up to 13 Mpps (64-byte packets) up to 9.5 Mpps (64-byte packets) up to 4.1 Mpps (64-byte packets)

Switching capacity 17.6 Gbps 12.8 Gbps 5.6 Gbps

MAC address table size 16000 entries 16000 entries 16000 entries

Aruba 2530-24-PoE+ Switch
(J9779A)

24 RJ-45 autosensing 10/100 PoE+
ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX,
IEEE 802.3at PoE+); Media Type:
Auto-MDIX; Duplex: half or full

2 autosensing 10/100/1000 ports
(IEEE 802.3 Type 10BASE-T, IEEE

802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

2 xed Gigabit Ethernet SFP ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

17.40 (w) x 12.70 (d) x 1.75 (h) in
(44.2 x 32.26 x 4.45 cm)
(1U height)

ARM9E @ 800 MHz, 128 MB ash,
256 MB DDR3 DIMM; packet buer
size: 1.5 MB dynamically allocated

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

Aruba 2530-8-PoE+ Switch
(J9780A)

8 RJ-45 autosensing 10/100 PoE+
ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX,
IEEE 802.3at PoE+); Media Type:
Auto-MDIX; Duplex: half or full

2 dual-personality ports; each

port can be used as either an

RJ-45 10/100/1000 port (IEEE

802.3 Type 10Base-T; IEEE 802.3u
Type 100Base-TX; IEEE 802.3ab
1000Base-T Gigabit Ethernet) or as

a SFP slot (for use with SFP
transceivers) ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

10.00 (w) x 6.28 (d) x 1.75 (h) in
(25.4 x 15.95 x 4.45 cm)
(1U height)

ARM9E @ 800 MHz, 128 MB ash,
256 MB DDR3 DIMM; packet buer
size: 1.5 MB dynamically allocated

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48-PoE+ Switch
(J9778A)

Environment

Operating temperature 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C)

Operating relative

humidity

Nonoperating/Storage

temperature

Nonoperating/Storage

relative humidity

Altitude up to 10,000 ft (3 km) up to 10,000 ft (3 km) up to 10,000 ft (3 km)

Acoustic Power: 37.9 dB, Pressure: 31.8 dB Power: 40.4 dB, Pressure: 31.7 dB Power: 0 dB, Pressure: 0 dB

Electrical characteristics

Frequency 50/60 Hz 50/60 Hz 50/60 Hz

Maximum heat dissipation 170 BTU/hr (179.35 kJ/hr), (switch

AC voltage 100 - 127/200 - 240 VAC 100 - 127/200 - 240 VAC 100 - 127/200 - 240 VAC

Current 5.2/2.6 A 2.8/1.4 A 1.4 A

Maximum power rating 441 W 237 W 76.7 W

Idle power 37.5 W 21.8 W 5.8 W

PoE power 382 W 195 W 67 W

Notes Idle power is the actual power

Safety

Emissions

15% to 95% @ 104°F (40°C),
noncondensing

-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C)

15% to 90% @ 149°F (65°C),

noncondensing

only: 170 BTU/hr; combined switch
+ max. PoE devices: 1505 BTU/hr)

consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

PoE power is the total power

budget available to all PoE ports.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

Aruba 2530-24-PoE+ Switch
(J9779A)

15% to 95% @ 104°F (40°C),
noncondensing

15% to 90% @ 149°F (65°C),
noncondensing

99 BTU/hr (104.45 kJ/hr), (switch
only: 99 BTU/hr; combined switch +
max. PoE devices: 809 BTU/hr)

Idle power is the actual power
consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

PoE power is the total power

budget available to all PoE ports.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

Aruba 2530-8-PoE+ Switch
(J9780A)

15% to 95% @ 104°F (40°C),
noncondensing

15% to 90% @ 149°F (65°C),
noncondensing

29 BTU/hr (30.6 kJ/hr), (switch only:
29 BTU/hr; combined switch + max.
PoE devices: 262 BTU/hr)

Idle power is the actual power
consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

PoE power is the total power

budget available to all PoE ports.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48-PoE+ Switch
(J9778A)

Immunity

Generic EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24

EN EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24

ESD IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2

Radiated IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3

EFT/Burst IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4

Surge IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5

Conducted IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6

Power frequency

magnetic eld

Voltage dips and

interruptions

Harmonics EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2

Flicker EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3

Management

Notes

Services

IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8

IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

Aruba 2530-24-PoE+ Switch
(J9779A)

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

Aruba 2530-8-PoE+ Switch
(J9780A)

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48G Switch
(J9775A)

I/O ports and slots

48 RJ-45 autosensing 10/100/1000
ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

4 xed Gigabit Ethernet SFP ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

Physical characteristics

Dimensions 17.44 (w) x 10.00 (d) x 1.75 (h) in

(44.3 x 25.4 x 4.45 cm)
(1U height)

Weight 6.8 lb (3.08 kg) 6.1 lb (2.77 kg) 2.0 lb (0.91 kg)

Memory and processor

Processor ARM9E @ 800 MHz, 128 MB ash,

256 MB DDR3 DIMM; packet buer
size: 3 MB dynamically allocated

Mounting and enclosure

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

Performance

IPv6 Ready Certied IPv6 Ready Certied IPv6 Ready Certied

100 Mb Latency < 7.4 µs (LIFO 64-byte packets) < 7.4 µs (LIFO 64-byte packets) < 7.4 µs (LIFO 64-byte packets)

1000 Mb Latency < 2.3 µs (LIFO 64-byte packets) < 2.3 µs (LIFO 64-byte packets) < 2.6 µs (LIFO 64-byte packets)

Throughput up to 77.3 Mpps (64-byte packets) up to 41.6 Mpps (64-byte packets) up to 14.8 Mpps (64-byte packets)

Switching capacity 104 Gbps 56 Gbps 20 Gbps

MAC address table size 16000 entries 16000 entries 16000 entries

Aruba 2530-24G Switch
(J9776A)

24 RJ-45 autosensing 10/100/1000
ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

4 xed Gigabit Ethernet SFP ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

17.44 (w) x 10.00 (d) x 1.75 (h) in
(44.3 x 25.4 x 4.45 cm)
(1U height)

ARM9E @ 800 MHz, 128 MB ash,
256 MB DDR3 DIMM; packet buer
size: 1.5 MB dynamically allocated

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

Aruba 2530-8G Switch
(J9777A)

8 RJ-45 autosensing 10/100/1000
ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX,
IEEE 802.3ab Type 1000BASE-T);
Media Type: Auto-MDIX; Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

2 dual-personality ports; each

port can be used as either an

RJ-45 10/100/1000 port (IEEE

802.3 Type 10Base-T; IEEE 802.3u
Type 100Base-TX; IEEE 802.3ab
1000Base-T Gigabit Ethernet) or as

a SFP slot (for use with SFP
transceivers) ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

10.00 (w) x 6.28 (d) x 1.75 (h) in
(25.4 x 15.95 x 4.45 cm)
(1U height)

ARM9E @ 800 MHz, 128 MB ash,
256 MB DDR3 DIMM; packet buer
size: 1.5 MB dynamically allocated

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48G Switch
(J9775A)

Environment

Operating temperature 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C)

Operating relative

humidity

Nonoperating/Storage

temperature

Nonoperating/Storage

relative humidity

Altitude up to 10,000 ft (3 km) up to 10,000 ft (3 km) up to 10,000 ft (3 km)

Acoustic Power: 34.5 dB, Pressure: 31.0 dB Power: 34.0 dB, Pressure: 26.4 dB Power: 0 dB, Pressure: 0 dB

Electrical characteristics

Frequency 50/60 Hz 50/60 Hz 50/60 Hz

Maximum heat dissipation 203 BTU/hr (214.17 kJ/hr) 164 BTU/hr (173.02 kJ/hr) 63 BTU/hr (66.46 kJ/hr), (switch only:

AC voltage 100 - 127/200 - 240 VAC 100 - 127/200 - 240 VAC 100 - 127/200 - 240 VAC

Current 1.2/0.7 A .6/.4 A 0.5 A

Maximum power rating 59.5 W 48.0 W 18.6 W

Idle power 29.5 W 28.8 W 13.6 W

Notes Idle power is the actual power

Safety

Emissions

15% to 95% @ 104°F (40°C),
noncondensing

-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C)

15% to 90% @ 149°F (65°C),

noncondensing

Achieved Miercom Certied
Green Award

consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

Aruba 2530-24G Switch
(J9776A)

15% to 95% @ 104°F (40°C),
noncondensing

15% to 90% @ 149°F (65°C),
noncondensing

Idle power is the actual power
consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

Aruba 2530-8G Switch
(J9777A)

15% to 95% @ 104°F (40°C),
noncondensing

15% to 90% @ 149°F (65°C),
noncondensing

63 BTU/hr)

Idle power is the actual power
consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48G Switch
(J9775A)

Immunity

Generic EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24

EN EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24

ESD IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2

Radiated IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3

EFT/Burst IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4

Surge IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5

Conducted IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6

Power frequency

magnetic eld

Voltage dips and

interruptions

Harmonics EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2

Flicker EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3

Management

Notes

Services

IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8

IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

Aruba 2530-24G Switch
(J9776A)

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

Aruba 2530-8G Switch
(J9777A)

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48 Switch
(J9781A)

I/O ports and slots

48 RJ-45 autosensing 10/100 ports
(IEEE 802.3 Type 10BASE-T, IEEE

802.3u Type 100BASE-TX); Duplex:

half or full

2 autosensing 10/100/1000 ports
(IEEE 802.3 Type 10BASE-T, IEEE

802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

2 xed Gigabit Ethernet SFP ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

Physical characteristics

Dimensions 17.40 (w) x 9.70 (d) x 1.75 (h) in

(44.2 x 24.64 x 4.45 cm)
(1U height)

Weight 6.3 lb (2.86 kg) 5.7 lb (2.59 kg) 1.8 lb (0.82 kg)

Memory and processor

Processor ARM9E @ 800 MHz, 128 MB ash,

256 MB DDR3 DIMM; packet buer
size: 3 MB dynamically allocated

Mounting and enclosure

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

Performance

IPv6 Ready Certied IPv6 Ready Certied IPv6 Ready Certied

100 Mb Latency < 6.6 µs (LIFO 64-byte packets) < 1.7 µs (LIFO 64-byte packets) < 1.3 µs (LIFO 64-byte packets)

1000 Mb Latency < 2.2 µs (LIFO 64-byte packets) < 1.1 µs (LIFO 64-byte packets) < 1.3 µs (LIFO 64-byte packets)

Throughput up to 13 Mpps (64-byte packets) up to 9.5 Mpps (64-byte packets) up to 4.1 Mpps (64-byte packets)

Switching capacity 17.6 Gbps 12.8 Gbps 5.6 Gbps

MAC address table size 16000 entries 16000 entries 16000 entries

Aruba 2530-24 Switch
(J9782A)

24 RJ-45 autosensing 10/100 ports
(IEEE 802.3 Type 10BASE-T, IEEE

802.3u Type 100BASE-TX); Duplex:

half or full

2 autosensing 10/100/1000 ports
(IEEE 802.3 Type 10BASE-T, IEEE

802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

2 xed Gigabit Ethernet SFP ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

17.40 (w) x 9.70 (d) x 1.75 (h) in
(44.2 x 24.64 x 4.45 cm)
(1U height)

ARM9E @ 800 MHz, 128 MB ash,
256 MB DDR3 DIMM; packet buer
size: 1.5 MB dynamically allocated

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

Aruba 2530-8 Switch
(J9783A)

8 RJ-45 autosensing 10/100 ports
(IEEE 802.3 Type 10BASE-T, IEEE

802.3u Type 100BASE-TX); Media
Type: Auto-MDIX; Duplex: half or full

2 dual-personality ports; each

port can be used as either an

RJ-45 10/100/1000 port (IEEE

802.3 Type 10Base-T; IEEE 802.3u
Type 100Base-TX; IEEE 802.3ab
1000Base-T Gigabit Ethernet) or as

a SFP slot (for use with SFP
transceivers) ports

1 dual-personality (RJ-45 or USB
micro-B) serial console port

10.00 (w) x 6.28 (d) x 1.75 (h) in
(25.4 x 15.95 x 4.45 cm)
(1U height)

ARM9E @ 800 MHz, 128 MB ash,
256 MB DDR3 DIMM; packet buer
size: 1.5 MB dynamically allocated

Mounts in an EIA-standard 19-inch
telco rack or equipment cabinet
(rack-mounting kit available);
Horizontal surface mounting;
Wall mounting

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48 Switch
(J9781A)

Environment

Operating temperature 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C) 32°F to 113°F (0°C to 45°C)

Operating relative

humidity

Nonoperating/Storage

temperature

Nonoperating/Storage

relative humidity

Altitude up to 10,000 ft (3 km) up to 10,000 ft (3 km) up to 10,000 ft (3 km)

Acoustic Power: 0 dB, Pressure: 0 dB Power: 0 dB, Pressure: 0 dB Power: 0 dB, Pressure: 0 dB

Electrical characteristics

Frequency 50/60 Hz 50/60 Hz 50/60 Hz

Maximum heat dissipation 102 BTU/hr (107.61 kJ/hr) 50 BTU/hr (52.75 kJ/hr) 25 BTU/hr (26.38 kJ/hr)

AC voltage 100 - 127/200 - 240 VAC 100 - 127/200 - 240 VAC 100 - 127/200 - 240 VAC

Current 0.7/0.4 A 0.3/0.2 A 0.5 A

Maximum power rating 29.9 W 14.7 W 7.2 W

Idle power 17.1 W 8.4 W 4.5 W

Notes Idle power is the actual power

Safety

Emissions

15% to 95% @ 104°F (40°C),
noncondensing

-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C)

15% to 90% @ 149°F (65°C),

noncondensing

consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

Aruba 2530-24 Switch
(J9782A)

15% to 95% @ 104°F (40°C),
noncondensing

15% to 90% @ 149°F (65°C),
noncondensing

Idle power is the actual power
consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

Aruba 2530-8 Switch
(J9783A)

15% to 95% @ 104°F (40°C),
noncondensing

15% to 90% @ 149°F (65°C),
noncondensing

Idle power is the actual power
consumption of the device with no

ports connected.

Maximum power rating and

maximum heat dissipation are the
worst-case theoretical maximum
numbers provided for planning
the infrastructure with fully loaded

PoE (if equipped), 100% trac, all

ports plugged in, and all modules

populated.

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

FCC Class A; EN 55022/CISPR-22
Class A; VCCI Class A

SPECIFICATIONS

DATA SHEET

ARUBA 2530 SWITCH SERIES

Aruba 2530-48 Switch
(J9781A)

Immunity

Generic EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24

EN EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24

ESD IEC 61000-4-2 IEC 61000-4-2 IEC 61000-4-2

Radiated IEC 61000-4-3 IEC 61000-4-3 IEC 61000-4-3

EFT/Burst IEC 61000-4-4 IEC 61000-4-4 IEC 61000-4-4

Surge IEC 61000-4-5 IEC 61000-4-5 IEC 61000-4-5

Conducted IEC 61000-4-6 IEC 61000-4-6 IEC 61000-4-6

Power frequency

magnetic eld

Voltage dips and

interruptions

Harmonics EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2

Flicker EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3

Management

Notes

Services

IEC 61000-4-8 IEC 61000-4-8 IEC 61000-4-8

IEC 61000-4-11 IEC 61000-4-11 IEC 61000-4-11

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

Aruba 2530-24 Switch
(J9782A)

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

Aruba 2530-8 Switch
(J9783A)

Aruba Central and Aruba AirWave
Network Management;
IMC—Intelligent Management
Center; command-line interface;
Web browser; conguration menu;

out-of-band management (serial

RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB;
Ethernet Interface MIB AirWave
Network Management

IEEE 802.3az applies to Gigabit
models only; IEEE 802.3at and IEEE

802.3af apply to PoE+ models only.
When using SFPs with this product,
SFPs with revision “B” or later

(product number ends with the

letter “B” or later, e.g., J4858B,
J4859C) are required.

Refer to the Hewlett Packard

Enterprise website at

www.hpe.com/networking/services

for details on the service-level

descriptions and product numbers.

For details about services and
response times in your area, please

contact your local Hewlett Packard
Enterprise sales oce.

DATA SHEET

ARUBA 2530 SWITCH SERIES

SPECIFICATIONS

Aruba 2530-8-PoE+ Internal PS Switch (JL070A)

I/O ports and slots

8 RJ-45 autosensing 10/100 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3at
PoE+); Media Type: Auto-MDIX; Duplex: half or full 2 dual-personality ports; each port can be used as either an
RJ-45 10/100/1000 port (IEEE 802.3 Type 10BASE-T; IEEE 802.3u Type 100BASE-TX; IEEE 802.3ab 1000BASE-T

Gigabit Ethernet) or as a SFP slot (for use with SFP transceivers) ports

1 dual-personality (RJ-45 or USB micro-B) serial console port

Physical characteristics

Dimensions 10(w) x 9.68(d) x 1.75(h) in

(25.4 x 24.59 x 4.45 cm)
(1U height)

Weight 4.65 lb (2.11 kg)

Memory and processor

ARM9E @ 800 MHz, 128 MB ash, 256 MB DDR3 DIMM; packet buer size: 1.5 MB dynamically allocated

Mounting and enclosure

Mounts in an EIA-standard 19-inch telco rack or equipment cabinet (rack-mounting kit available); Horizontal
surface mounting; Wall mounting

Performance

IPv6 Ready Certied

100 Mb Latency < 1.3 µs (LIFO 64-byte packets)

1000 Mb Latency < 1.3 µs (LIFO 64-byte packets)

Throughput up to 4.1 Mpps (64-byte packets)

Switching capacity 5.6 Gbps

MAC address table size 16000 entries

Environment

Operating temperature 32°F to 113°F (0°C to 45°C)

Operating relative

humidity

Nonoperating/Storage

temperature

Nonoperating/Storage

relative humidity

Altitude up to 10,000 ft (3 km)

Acoustic Power: 0 dB, Pressure: 0 dB

Electrical characteristics

Frequency 50/60 Hz

Maximum heat dissipation 29 BTU/hr (30.6 kJ/hr), (switch only: 29 BTU/hr; combined switch + max. PoE devices: 239 BTU/hr)

AC voltage 100 - 127/200 - 240 VAC

Current 0.9/0.5 A

Maximum power rating 70.2 W

Idle power 5.3 W

PoE power 67 W PoE

Notes Idle power is the actual power consumption of the device with no ports connected. Maximum power rating

15% to 95% @ 104°F (40°C),

noncondensing

-40°F to 158°F (-40°C to 70°C)

15% to 90% @ 149°F (65°C),

noncondensing

and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the

infrastructure with fully loaded PoE (if equipped), 100% trac, all ports plugged in, and all modules populated.
PoE power is the total power budget available to all PoE ports.

SPECIFICATIONS

Aruba 2530-8-PoE+ Internal PS Switch (JL070A)

Safety

UL 60950-1; CAN/CSA 22.2
No. 60950-1; EN 60825;
IEC 60950-1; EN 60950-1

Emissions

FCC Class A; EN 55022/CISPR-22 Class A; VCCI Class A

Immunity

Generic EN 55024, CISPR 24

EN EN 55024, CISPR 24

ESD IEC 61000-4-2

Radiated IEC 61000-4-3

EFT/Burst IEC 61000-4-4

Surge IEC 61000-4-5

Conducted IEC 61000-4-6

Power frequency

magnetic eld

Voltage dips and

interruptions

Harmonics EN 61000-3-2, IEC 61000-3-2

Flicker EN 61000-3-3, IEC 61000-3-3

Management

Notes

Services

IEC 61000-4-8

IEC 61000-4-11

Aruba Central and Aruba AirWave Network Management; IMC—Intelligent Management Center; command-line
interface; Web browser; conguration menu; out-of-band management (serial RS-232C or Micro USB); IEEE 802.3
Ethernet MIB; Repeater MIB; Ethernet Interface MIB AirWave Network Management

IEEE 802.3az applies to Gigabit models only; IEEE 802.3at and IEEE 802.3af apply to PoE+ models only. When
using SFPs with this product, SFPs with revision “B” or later (product number ends with the letter “B” or later, e.g.,
J4858B, J4859C) are required.

Refer to the Hewlett Packard Enterprise website at www.hpe.com/networking/services for details on the
service-level descriptions and product numbers. For details about services and response times in your area,
please contact your local Hewlett Packard Enterprise sales oce.

DATA SHEET

ARUBA 2530 SWITCH SERIES

DATA SHEET

ARUBA 2530 SWITCH SERIES

STANDARDS AND PROTOCOLS
(APPLIES TO ALL PRODUCTS IN SERIES)

Denial of service protection

• Network DoS Filter

Device management

• RFC 1591 DNS (client)

• SSHv1/SSHv2 Secure Shell

• RFC 2576 (Coexistence between SNMP V1, V2, V3)

• RFC 2579 (SMIv2 Text Conventions)

• RFC 2580 (SMIv2 Conformance)

• RFC 3416 (SNMP Protocol Operations v2)

• RFC 3417 (SNMP Transport Mappings)

General protocols

• IEEE 802.1D MAC Bridges

• IEEE 802.1p Priority

• IEEE 802.1Q VLANs

• IEEE 802.1s Multiple Spanning Trees

• IEEE 802.1w Rapid Reconguration of Spanning Tree

• IEEE 802.3 Type 10BASE-T

• IEEE 802.3ab 1000BASE-T

• IEEE 802.3ad Link Aggregation Control Protocol (LACP)

• IEEE 802.3af Power over Ethernet

• IEEE 802.3at Power over Ethernet Plus

• IEEE 802.3az Energy Ecient Ethernet

• IEEE 802.3x Flow Control

• RFC 768 UDP

• RFC 783 TFTP Protocol (revision 2)

• RFC 792 ICMP

• RFC 793 TCP

• RFC 826 ARP

• RFC 854 TELNET

• RFC 868 Time Protocol

• RFC 951 BOOTP

• RFC 1350 TFTP Protocol (revision 2)

• RFC 1542 BOOTP Extensions

• RFC 1918 Address Allocation for Private Internet

• RFC 2030 Simple Network Time Protocol (SNTP) v4

• RFC 2131 DHCP

• RFC 3411 An Architecture for Describing Simple Network

Management Protocol (SNMP) Management Frameworks

• RFC 3412 Message Processing and Dispatching for the

Simple Network Management Protocol (SNMP)

• RFC 3413 Simple Network Management Protocol (SNMP)

Applications

• RFC 3414 User-based Security Model (USM) for version 3

of the Simple Network Management Protocol (SNMPv3)

• RFC 3415 View-based Access Control Model (VACM) for

the Simple Network Management Protocol (SNMP)

• RFC 3575 IANA Considerations for RADIUS

• RFC 5905 NTP Client

IP multicast

• RFC 3376 IGMPv3

IPv6

• RFC 1981 IPv6 Path MTU Discovery

• RFC 2460 IPv6 Specication

• RFC 2464 Transmission of IPv6 over Ethernet Networks

• RFC 2925 Remote Operations MIB (Ping only)

• RFC 3315 DHCPv6 (client only)

• RFC 3484 Default Address Selection for IPv6

• RFC 3513 IPv6 Addressing Architecture

• RFC 3596 DNS Extension for IPv6

• RFC 3810 Multicast Listener Discovery Version 2 (MLDv2)

for IPv6

• RFC 4022 MIB for TCP

• RFC 4113 MIB for UDP

• RFC 4251 SSHv6 Architecture

• RFC 4252 SSHv6 Authentication

• RFC 4252 SSHv6 Transport Layer

• RFC 4254 SSHv6 Connection

• RFC 4291 IP Version 6 Addressing Architecture

• RFC 4293 MIB for IP

• RFC 4419 Key Exchange for SSH

• RFC 4443 ICMPv6

• RFC 4861 IPv6 Neighbor Discovery

• RFC 4862 IPv6 Stateless Address Auto-conguration

• RFC 5095 Deprecation of Type 0 Routing Headers in IPv6

MIBs

• RFC 1155 Structure and Identication of Management

Information for TCP/IP Internets

• RFC 1212 Concise MIB Denitions

• RFC 1213 MIB II

• RFC 1493 Bridge MIB

• RFC 2021 RMONv2 MIB

• RFC 2578 Structure of Management Information

Version 2 (SMIv2)

• RFC 2579 Textual Conventions for SMIv2

• RFC 2613 SMON MIB

• RFC 2618 RADIUS Client MIB

• RFC 2620 RADIUS Accounting Client MIB

• RFC 2665 Ethernet-Like-MIB 2

• RFC 2668 802.3 MAU MIB

• RFC 2674 802.1p and IEEE 802.1Q Bridge MIB

DATA SHEET

ARUBA 2530 SWITCH SERIES

• RFC 2737 Entity MIB (Version 2)

• RFC 2863 The Interfaces Group MIB

• RFC 4836 Managed Objects for 802.3 Medium Attachment

Units (MAU)

Network management

• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

• RFC 1098 A Simple Network Management Protocol (SNMP)

• RFC 1155 Structure of Management Information

• RFC 2819 Four groups of RMON: 1 (statistics), 2 (history) 3

(alarm) and 9 (events)

• RFC 3411 SNMP Management Frameworks

• RFC 3412 Message Processing and Dispatching for the

Simple Network Management Protocol (SNMP)

• RFC 3413 Simple Network Management Protocol

(SNMP) Applications

• RFC 3414 User-based Security Model (USM) for version 3

of the Simple Network Management Protocol (SNMPv3)

• RFC 3415 View-based Access Control Model (VACM) for

the Simple Network Management Protocol (SNMP)

• RFC 3418 Management Information Base (MIB) for the

Simple Network Management Protocol (SNMP)

• RFC 5424 Syslog Protocol

• ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED)

• SNMPv1/v2c/v3

QoS/CoS

• RFC 2474 DiServ precedence, with 4 queues per port

• RFC 2475 DiServ Architecture

• RFC 2597 DiServ Assured Forwarding (AF)

• RFC 2598 DiServ Expedited Forwarding (EF)

ARUBA 2530 SWITCH SERIES ACCESSORIES

Transceivers

• Aruba 100M SFP LC FX 2km MMF XCVR (J9054D)

• Aruba 1G SFP RJ45 T 100m Cat5e XCVR (J8177D)

• Aruba 1G SFP LC SX 500m MMF XCVR (J4858D)

• Aruba 1G SFP LC LX 10km SMF XCVR (J4859D)

• Aruba 1G SFP LC LH 70km SMF XCVR (J4860D)

Cables

• Aruba X2C2 RJ45 to DB9 Console Cable (JL448A)

Mounting Kit

• HPE X410 1U Universal 4-post Rack Mounting Kit (J9583A)

Aruba 2530-8-PoE+ Internal PS Switch ( JL070A)

• HPE X510 1U Cable Guard (J9700A)

Aruba 2530-8G-PoE+ Switch ( J9774A)

• Aruba 2530 8-port Switch Power Adapter Shelf (J9820A)

• Aruba X510 1U Cable Guard (J9700A)

Aruba 2530-8-PoE+ Switch ( J9780A)

• Aruba 2530 8-port Switch Power Adapter Shelf (J9820A)

• Aruba X510 1U Cable Guard (J9700A)

Aruba 2530-8G Switch (J9777A)

• Aruba 2530 8-port Switch Power Adapter Shelf (J9820A)

• Aruba X510 1U Cable Guard (J9700A)

Aruba 2530-8 Switch (J9783A)

• Aruba 2530 8-port Switch Power Adapter Shelf (J9820A)

• HPE X510 1U Cable Guard (J9700A)

Security

• IEEE 802.1X Port Based Network Access Control

• RFC 1492 TACACS+

• RFC 2138 RADIUS Authentication

• RFC 2866 RADIUS Accounting

• RFC 7030 Enrollment over Secure Transport

• Secure Sockets Layer (SSL)

3333 SCOTT BLVD | SANTA CLARA, CA 95054

1.844.473.2782 | T: 1.408.227.4500 | FAX: [phone] | [e-mail]

www.arubanetworks.com DS_2530SwitchSeries_120617
