QuickSpecs

Overview

HP ProBook 4425s Notebook PC HP ProBook 4525s

Notebook PC

WLAN antennas

Integrated microphone

Webcam LED (works with optional webcam)

Optional 2 MP webcam

Power button with LED indicator

Stereo speakers

Wireless switch with LED indicator

Optical drive (select models)

Optional RJ-11/modem port

10.

(2) USB 2.0 ports

11.

Optional HP Fingerprint Sensor

Kensington Lock slot

Power connector

Battery charging LED indicator

VGA connector (external monitor/projector)

RJ-45/Ethernet port

12.

ClickPad with left and right ClickPad buttons

13.

Stereo microphone in

14.

Stereo headphone/line out

15.

Media Card Reader

16.

Hard drive activity LED indicator

17.

HP QuickLook 3 button with LED indicator

18.

HP QuickWeb button with LED indicator

19.

Volume mute button

20.

Volume down button

21.

Volume up button

HDMI port

Combo eSATA/USB port

ExpressCard/34 slot

USB 2.0 port

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 1

QuickSpecs

Overview

HP ProBook 4425s Notebook PC HP ProBook

4525s Notebook PC

Battery release latches

HP ProBook 4525s Notebook PC

Battery bay

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 2

QuickSpecs

Overview

HP ProBook 4425s Notebook PC HP ProBook

4525s Notebook PC

WWAN antennas (select models)

WLAN antennas

Integrated microphone

Webcam LED (works with optional webcam)

Optional 2 MP webcam

Power button with LED indicator

Stereo speakers

Wireless switch with LED indicator

Battery charging LED indicator

10.

Power connector

11.

Optical drive (select models)

12.

Optional RJ-11/modem port

Kensington Lock slot

13.

(2) USB 2.0 ports

14.

Optional HP Fingerprint Sensor

15.

ClickPad with left and right ClickPad buttons

16.

Stereo microphone in

17.

Stereo headphone/line out

18.

Media Card Reader

19.

Hard drive activity LED indicator

20.

HP QuickLook 3 button with LED indicator

21.

HP QuickWeb button with LED indicator

22.

Volume mute button

23.

Volume down button

24.

Volume up button

Combo eSATA/USB port

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 3

QuickSpecs

Overview

VGA connector (external monitor/projector)

RJ-45/Ethernet port

HDMI port

HP ProBook 4425s Notebook PC HP ProBook

4525s Notebook PC

ExpressCard/34 slot

USB 2.0 port

Battery release latches

Battery bay

SIM card slot (select units, located inside battery bay)

At A Glance

Genuine Windows 7 versions, Genuine Windows Vista versions, Genuine Windows XP Professional available through downgrade rights from Windows 7 Professional, SUSE Linux, Red Flag Linux (PRC only), or FreeDOS Thin, lightweight design with brushed aluminum finish for durability and style Color choice of caviar or bordeaux Full-sized spill-resistant keyboard with full separate numeric keypad on the HP ProBook 4525s New AMD VISION Pro architecture AMD Phenom™ II Quad-Core or Triple-Core Mobile Processor, AMD Turion™ II Dual-Core Mobile Processor, AMD Athlon™ II Dual-Core Processor for Notebook PCs, or AMD V-Series Single-Core Processor for Notebook PCs Integrated ATI Mobility Radeon HD 4250 graphics; or HP ProBook 4525s also offers ATI Mobility Radeon HD 503v discrete graphics with 512 MB dedicated video memory Optional HP Fingerprint Sensor for single sign-on HP Face Recognition for HP ProtectTools for easy logins using the optional integrated 2 MP webcam Choice of 9-cell or 6-cell battery to customize weight and run-time to your needs Corel Home Office productivity suite for word processing, spreadsheets, and presentations ArcSoft TotalMedia Suite for playing, creating, and editing video and audio files New keyboard function keys for play, rewind, and fast-forward of video and audio files HP DayStarter (calendar display while Windows starts), HP QuickLook 3 (quick access to e-mail, calendar, contacts and tasks), HP QuickWeb HP Power Assistant to conserve power, increase battery run-time, monitor power needs, report workforce power consumption HP Connection Manager 3.1

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 4

HP ProBook 4425s Notebook PC HP ProBook

QuickSpecs

4525s Notebook PC

Overview

Flexible wireless connectivity options:

Integrated HP un2420 EV-DO/HSDPA Mobile Broadband Module* provides worldwide Gobi mobile Internet technology with GPS Integrated Broadcom 802.11 b/g/n or b/g wireless LAN module

Bluetooth® v2.1 Widescreen LED-backlit HD display with 16:9 aspect ratio, BrightView optional HP ProBook 4425s: 14.0-inch diagonal HP ProBook 4525s: 15.6-inch diagonal Enhanced security features including HP ProtectTools with Central Management, optional HP Fingerprint Sensor, HP Face Recognition, Computrace LoJack Pro ready, HP SpareKey, HP Disk Sanitizer, optional HP Privacy Filter HDMI port for connecting to high-resolution displays; combo eSATA/USB port

* Only available in HP ProBook 4525s with integrated graphics.

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 5

QuickSpecs

Standard Features (availability may vary by country)

HP ProBook 4425s Notebook PC HP ProBook

4525s Notebook PC

Processors

Operating System

AMD Phenom II Quad-Core Mobile Processor P920 (1.6 GHz, 2MB L2 cache) AMD Phenom II Triple-Core Mobile Processor P820 (1.8 GHz, 1.5 MB L2 cache) AMD Turion II Dual-Core Mobile Processor P520 (2.3 GHz, 2MB L2 cache) AMD Athlon II Dual-Core Processor P320 (2.1 GHz, 1MB L2 cache) AMD V Series Processor V120 (2.2 GHz, 512 KB L2 cache)

NOTE: battery optimization mode.

* Intel's numbering is not a measurement of higher performance.

Preinstalled

Supported Certified

* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality. See:

Processor speed denotes maximum performance mode; processors will run at lower speeds in

Genuine Windows 7 Professional Edition 32 Genuine Windows XP Professional available through downgrade rights from Windows 7 Professional Genuine Windows 7 Home Premium Edition 32 Genuine Windows 7 Home Basic Edition 32 Genuine Windows 7 Starter 32 Genuine Windows Vista Business 32 Genuine Windows Vista Home Basic 32 SUSE Linux Enterprise Desktop 11 Red Flag Linux (PRC only) FreeDOS

Genuine Windows 7 Professional 64 SUSE Linux Enterprise Desktop 11

http://www.microsoft.com/windows/windows-7/

*†

for details.

Chipset

** Certain Windows Vista product features require advanced or additional hardware. See:

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx http://www.microsoft.com/windowsvista/getready/capable.mspx

Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit:

† Windows XP Professional is preinstalled on this system and includes end user rights and media for Windows 7 Professional. You may only use one version at a time. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data.

Integrated graphics: AMD RS880M chipset

Discrete graphics (available in HP ProBook 4525s only): AMD RS880MD chipset

http://www.windowsvista.com/upgradeadvisor

and

for details. Windows Vista Upgrade

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 6

QuickSpecs

Standard Features (availability may vary by country)

HP ProBook 4425s Notebook PC HP ProBook

4525s Notebook PC

Graphics

Display

Integrated graphics: ATI Mobility Radeon HD 4250 graphics controller with shared video memory

Discrete graphics (available in HP ProBook 4525s only): ATI Mobility Radeon HD 530v graphics controller with 512 MB dedicated video memory

Microsoft DirectX 10.1 (discrete),10 (integrated) capable

Internal

External

HP ProBook 4425s:

14.0-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)

14.0-inch diagonal LED-backlit HD BrightView (1366 x 768 resolution)

HP ProBook 4525s:

15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)

15.6-inch diagonal LED-backlit HD BrightView (1366 x 768 resolution)

Optional HP Privacy Filter Up to 32-bit per pixel color depth

VGA

port supports resolutions up to 1600 x 1200 at 75 Hz, and lower resolutions at up to 100 Hz. HDMI

port supports direct connection to high-definition displays with up to 1920 x 1080 resolution and 7-channel audio with one convenient cable (not included).

NOTE: and color depth settings.

Resolutions are dependent upon monitor capability, and resolution

Memory

Standard

Maximum

Dual-channel

* Memory speed is processor dependent. NOTE: branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. Full availability of 4 GB or more of memory requires a Windows 64-bit operating system or Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available due to system resource requirements.

Due to the non-industry standard nature of some third-party memory modules, we recommend HP

DDR3 PC3-10600 SDRAM (1333 MHz) Two SODIMM slots supporting dual-channel memory 1024 MB and 2048 MB SODIMMs Standard memory up to 4096 MB

Upgradeable to 8192 MB with optional 4096 MB SODIMMs in slots 1 and 2

Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 7

QuickSpecs

Standard Features (availability may vary by country)

HP ProBook 4425s Notebook PC HP ProBook

4525s Notebook PC

Communications

Wireless Devices

Realtek Ethernet (10/100/1000 NIC) Optional 56K V.92 modem

* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.

** Designed for downloads from 56K modem compliant sources. Maximum achievable download transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is subject to country regulatory approval.

Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry standards. Mobile Broadband (WWAN) requires a Windows operating system and is available in select countries as a factory configurable feature for the HP ProBook 4525s only. Integrated Bluetooth is also available (factory configurable only) and can be combined with any of the supported wireless LAN and wireless WAN options.

HP un2420 EV-DO/HSPA Mobile Broadband Module (only available in HP ProBook 4525s with integrated graphics)

All 802.11 integrated wireless LAN options

Broadcom 4313GN

802.11 b/g/n WiFi Adapter

Broadcom 4312G

802.11b/g WiFi Adapter

HP Integrated Module with Bluetooth Wireless Technology

Integrated mobile broadband module with Gobi global mobile Internet technology that provides connectivity to both CDMA (EVDO) and UMTS (HSPA) networks. It also provides GPS functionality for various mapping applications and security applications.

NOTE:

Two 850/900/1575/1800/1900/2100 MHz antennas integrated in the top of the display panel support current and future WWAN technologies.

Wi-Fi certified Wired Equivalent Privacy (WEP) support up to 128-bit keys Wi-Fi Protected Access (WPA) and WPA2 support

802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, and LEAP Advanced Encryption Standard (AES) support Dual antennas integrated in the display enclosure

Integrated support for 802.11 b, g, and n Cisco Compatible Extensions support Up to 300 mbps data rate

Integrated support for 802.11 b and g Cisco Compatible Extensions support Up to 54 mbps data rate

Bluetooth Specification v2.1 compliant Works with a wide range of Bluetooth devices

Separately purchased mobile network operator service is required.

Keyboard

The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage to sensitive components underneath. The 101/102-key compatible keyboard features a full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, full separate numeric keypad, and 12 function keys. US and International key layouts are available. Other features include hotkeys for instant access to power conservation and brightness, and 19.05 x 19.05 mm key pitch (center-to-center spacing).

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 8

QuickSpecs

Standard Features (availability may vary by country)

HP ProBook 4425s Notebook PC HP ProBook

4525s Notebook PC

Pointing device

Expansion card slots

Storage

ClickPad with gestures support: Two-finger scroll, zoom, pinch and pivot rotate, and three finger flick

NOTE:

ExpressCard/34 slot Media Card Reader

* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo Card directly into your notebook could damage the memory card and/or notebook.

Internal Storage Device

NOTE:

HP 3D DriveGuard (Windows models only)

Fixed optical drives

Gestures not available for Linux and FreeDOS.

Supports ExpressCard/34 (34 mm x 75 mm x 5 mm) card sizes Supports SD (Secure Digital), MMC (MultiMedia Card), Memory Stick,

Memory Stick Pro, Memory Stick Duo*, xD-Picture card

250/320/500 GB 7200 rpm SMART SATA II Hard Drive

Up to 15 GB is reserved for the system recovery software.

The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive. Uses three-axis digital motion detection with intelligent sensitivity to help protect the hard drive during normal use from shock and vibration. The digital accelerometer temporarily halts all data transfer and parks the hard drive when abrupt motion is detected.

Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive DVD+/-RW SuperMulti DL LightScribe Drive DVD-ROM Drive

* Support for the Blu-ray DVD drive on configurations with integrated graphics requires Windows7 or Windows Vista; configurations with discrete graphics support it with any offered Windows operating system.

Interfaces

VGA HDMI Stereo microphone in Stereo headphone/line

out Power connector RJ-11/modem (optional) RJ-45/Ethernet Combo eSATA/USB 2.0 USB 2.0 LED status indicators

One One One One

One One One One Three Eight

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 9

QuickSpecs

Standard Features (availability may vary by country)

HP ProBook 4425s Notebook PC HP ProBook

4525s Notebook PC

Audio/Visual

Software

High Definition Audio support Integrated stereo speakers Integrated digital microphone Stereo headphone/line out Stereo microphone in

Optional 2 MP webcam

Supports videoconferencing and still image capture Improved quality for video streaming and still image capture (1600x1200 resolution) Up to 30 frames/sec Fixed focus lens 16-bit true color (camera sensor up to UXGA resolution)

Preinstalled software with Windows operating system

Additional software available from the web

* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to receive updates. First update included. Subscription required for updates thereafter.

HP Recovery Manager (available with Windows 7 or Vista only) HP Support Assistant (available with Windows 7 or Vista only) HP ProtectTools Security Manager HP Face Recognition HP QuickLaunch Buttons Software HP QuickLook 3 HP QuickWeb HP Power Assistant HP Connection Manager 3.1 HP Wireless Assistant HP Day Starter Corel Home Office productivity suite 60-day trial Roxio Creator Business (select models) ArcSoft Total Media Suite Microsoft Office Professional 2007 60-day Convertible Trial McAfee Total Protection HP Webcam Software (select models) Skype WinZip 12 trial

HP SoftPaq Download Manager

HP Recovery Manager

Models shipped with Windows 7 or Windows Vista include HP Recovery Manager. HP Recovery Manager enables fast recovery of the factory preinstalled image if the system becomes corrupted or if important system files are accidentally deleted. Up to 15 GB of the hard drive is reserved for the system recovery software.

DA - 13610 Worldwide QuickSpecs — Version 1 — 5.5.2010

Page 10
