Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
Security Lock (Lock sold separately)

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
HDMI port (Cable not included)

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
AT A GLANCE
• Preinstalled Windows 10 or FreeDOS 2.0 versions
• Choice of 8th Generation Intel® Core™ i7, i5 and i3 processors
• Display include your choice of 35.56 cm (14") diagonal narrow bezel, anti-glare, ultra-wide or standard view angle, HD
or FHD
• Graphics include your choice of integrated Intel® UHD Graphics 620, Intel® HD Graphics 620, or switchable discrete
graphics AMD Radeon™ 530
• Enhanced security features including TPM and mini security lock
• Integrated with 2 stereo speakers and dual array microphone for better audio experience
• Support dual storage, Solid State Drives up to 512 GB, and/or Hard Drives up to 1 TB
2
• Up to 32 GB total system memory
• Optional 720p HD webcam or no webcam available Full-size island-style spill resistant keyboard and Clickpad with
multi-touch gestures enabled, taps enabled as default.802.11b/g/n (1x1) and Bluetooth® 4.2 Combo
• Passed MIL-STD test
3
• Up to 12 hours and 15 minutes (UMA, WHL-U processor, HD display, 4 GB*1 memory, SSD)
1. Lock sold separately.
2. Dual storage needs to be configured before purchase.
3. MIL-STD-810G testing is not intended to demonstrate fitness of U.S. Department of Defense (DoD) contract
requirements or for military use. Test results are not a guarantee of future performance under these test
conditions. Accidental damage requires an optional HP Accidental Damage Protection Care Pack.
NOTE: See important legal disclosures for all listed specs in their respective features sections.

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
Windows 10 Pro 64
1
Windows 10 Home Single Language 64
1
Windows 10 Pro 64 (National Academic only)
2
Windows 10 Home 64
1
FreeDOS 2.0
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately
purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is
automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for
updates. See http://www.windows.com.
2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10
Anniversary Update. Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.
Intel® Core™ i7-8565U with Intel® UHD Graphics 620 (1.8 GHz base frequency, up to 4.6 GHz with Intel® Turbo Boost
Technology, 8 MB L3 cache, 4 cores)
3,4,5,6
Intel® Core™ i5-8265U with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost
Technology, 6 MB L3 cache, 4 cores)
3,4,5,6
Intel® Core™ i3-8145U with Intel® UHD Graphics 620 (2.1 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost
Technology, 4 MB L3 cache, 2 cores)
3,4,5,6
Intel® Core™ i3-7020U with Intel® HD Graphics 620 (2.3 GHz, 3 MB cache, 2 cores)
3,4,6
8th Generation Intel® Core™ i7 processor (i7-8565U)6
8th Generation Intel® Core™ i5 processor (i5-8265U)6
8th Generation Intel® Core™ i3 processor (i3-8145U)6
7th Generation Intel® Core™ i3 processor (i3-7020U)6
3. Multicore is designed to improve performance of certain software products. Not all customers or software applications
will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application
workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement
of higher performance.
4. Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization
mode.
5. Intel® Turbo Boost performance varies depending on hardware, software and overall system configuration. See
www.intel.com/technology/turboboost for more information.
6. In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on
products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7
drivers on http://www.support.hp.com.
Chipset is integrated with processor

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
Intel® UHD Graphics 620 (i7-8565U, i5-8265U and i3-8145U)7
Intel® HD Graphics 620 (i3-7020U)
7
Discrete
AMD Radeon™ 530 (2 GB GDDR5 dedicated)
8
Supports
Support HD decode, DX12, HDMI 1.4b
7. HD content required to view HD images.
8. AMD Dynamic Switchable Graphics technology requires an Intel processor, plus an AMD Radeon™ discrete graphics
configuration and is not available on FreeDOS and Linux OS. With AMD Dynamic Switchable Graphics technology, full
enablement of all discrete graphics video and display features may not be supported on all systems (e.g. OpenGL
applications will run on the integrated GPU or the APU as the case may be).
35.56 cm (14") diagonal HD SVA eDP anti-glare WLED-backlit slim-flat, 220 cd/m², 45% NTSC one WLAN antenna
(1366 x 768)
7,9
35.56 cm (14") diagonal HD SVA eDP anti-glare WLED-backlit slim-flat, 220 cd/m², 45% NTSC two WLAN antennas
(1366 x 768)
7,9
35.56 cm (14") diagonal FHD IPS eDP anti-glare WLED-backlit slim-flat, 250 cd/m², 45% NTSC one WLAN antenna
(1920 x 1080)
7,9
35.56 cm (14") diagonal FHD IPS eDP anti-glare WLED-backlit slim-flat, 250 cd/m², 45% NTSC two WLAN antennas
(1920 x 1080)
7,9
7. HD content required to view HD images.
9. Resolutions are dependent upon monitor capability, and resolution and color depth settings.
500 GB 7200 rpm SATA10
1 TB 5400 rpm SATA
10
16 GB memory cache Intel® Optane® (Only available with HDD) to optimize HDD performance
10
Primary M.2 Storage
128 GB SATA TLC Solid State Drive
10
256 GB SATA TLC Solid State Drive
10
256 GB PCIe® NVMe™ Value Solid State Drive 10
256 GB PCIe® NVMe™ TLC Solid State Drive 10
512 GB PCIe® NVMe™ Value Solid State Drive1 10
10. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB
(for Windows 10) is reserved for system recovery software.
32 GB DDR4-2400 SDRAM (only available for 8th Generation Intel® processors)
32 GB DDR4-2133 SDRAM
11

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
32 GB DDR4-2400 SDRAM (2 X 16 GB) (Only available for 8th Generation Intel® processors)11
16 GB DDR4-2400 SDRAM (1 X 16 GB) (Only available for 8th Generation Intel® processors)11
8 GB DDR4-2400 SDRAM (1 x 8 GB) (Only available for 8th Generation Intel® processors)11
4 GB DDR4-2400 SDRAM (1 x 4 GB) (Only available for 8th Generation Intel® processors)11
32 GB DDR4-2133 SDRAM (2 X 16 GB)11
16 GB DDR4-2133 SDRAM (1 X 16 GB)11
8 GB DDR4-2133 SDRAM (1 x 8 GB)
11
4 GB DDR4-2133 SDRAM (1 x 4 GB)11
Memory Slots
2 SODIMM
Both slots are customer accessible / upgradeable
DDR4 PC4 SODIMMS, system runs at 2400 (Intel 7th Gen (KBL) runs at 2133)
Supports Dual Channel Memory
11. Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to
ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
NETWORKING/COMMUNICATIONS
Intel® Dual Band Wireless-AC 9560 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 5 Combo, non-vPro™ 12
Realtek 802.11a/b/g/n/ac (1x1) and Bluetooth® 4.2 Combo 12
Realtek 802.11b/g/n (1x1) and Bluetooth® 4.2 Combo
12
Ethernet
Integrated 10/100/1000 GbE
Realtek RTL8111HSH-CG 10/100/1000 GbE NIC
13
12. Wireless access point and Internet service required and sold separately. Availability of public wireless access points
limited.
13. The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet,
and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet
server and network infrastructure is required.
2 Integrated stereo speakers
Integrated dual array microphone
Camera
7. HD content required to view HD images.
14. Sold separately or as an optional feature.

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Full-size island-style spill resistant keyboard
Clickpad with multi-touch gesture support
ESC: System Information
F1: Windows Help
F2: Brightness Down
F3: Brightness Up
F4: Display Switching
F5: Blank
F6: Speaker Mute
F7: Volume Down
F8: Volume Up
F9: Previous track/section
F10: Starts, Pauses, or resumes playback
F11: Next track/section
F12: Airplane mode (Wireless feature on or off).
HP ePrint
25
HP Support Assistant15
HP Recovery Manager
Native Miracast Support16
sMedio True DVD for HP
Security Management
Firmware TPM
Mini security lock (Lock sold separately)
Windows Defender
17
15. HP Support Assistant requires Windows and Internet access.
16. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming.
17. Windows Defender Opt In, Windows 10, and internet connection required for updates.
25. HP ePrint Driver requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of
eligible printers, supported documents and image types and other HP ePrint details, see
http://www.hp.com/go/eprintcenter). Print times and connection speeds may vary.
HP Smart 65 W EM External AC power adapter
18
HP Smart 65 W External AC power adapter18
HP Smart 45 W External AC power adapter
18

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
HP Long Life 3-cell, 41 Wh Li-ion
19
Battery Life
Up to 12 hours and 15 minutes (UMA, WHL-U processor, HD display, 4 GB*1 memory, SSD)20
Power Cord
3-wire plug - 1m
18
3-wire plug – 1.8m
18
Battery Weight
18. Availability may vary by country.
19. Battery is internal and not replaceable by customer. Serviceable by warranty.
20. Windows 10 MM14 battery life will vary depending on various factors including product model, configuration, loaded
applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery
will naturally decrease with time and usage. See http://www.bapco.com for additional details.
Starting at 3.26 lbs21
Starting at 1.48 kg
21
Product Dimensions (w x d x h)
8.89 x 12.76 x 7.83 in
22.59 x 32.4 x 19.9 cm
21. Weight will vary by configuration.
1 USB 3.1 Type-C™ Gen 1
2 USB 3.1 Gen 1
1 HDMI 1.422
1 RJ-45
1 AC power
1 Headphone/Microphone Combo Jack
Expansion Slots
1 multi-format digital media reader
Supports SD, SDHC, SDXC
22. HDMI cable sold separately.

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
HP Services offers 1-year limited warranties and 90 day software limited warranty options depending on country. Batteries have
a default one year limited warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the
platform. Refer to http://www.hp.com/support/batterywarranty/ for additional battery information. On-site service and
extended coverage is also available. HP Care Pack Services are optional extended service contracts that go beyond the standard
limited warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at:
http://www.hp.com/go/cpc.
23
23. HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your
geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit
http://www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or indicated
to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such
rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP
Product.

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
Stand-Alone Power
Requirements (AC Power)
Nominal Operating Voltage
N/A (Switchable graphics design)
32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
-4° to 140° F (-20° to 60° C)
10% to 90%, non-condensing
40 G, 2 ms duration, half-sine
240 G, 2 ms duration, half-sine
Planned Industry Standard
Certifications
No, but compliant with Energy Star
Australia /
NZ A-Tick Compliance
Saudi Arabian Compliance
(ICCP)
24. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit http://www.epeat.net
for more information.

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
DISPLAYS
Note: All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may
vary either higher or lower.
14.0" diagonal HD WLED AntiGlare (1366x768) slim-flat
(3.0mm) SVA, eDP, Narrow
Bezel
Outline Dimensions (W x H)
Format of LCD Pixel Arrangement
14" diagonal FHD WLED AntiGlare (1920x1080) slim-flat
(3.0mm), UWVA, eDP, Narrow
Bezel
Outline Dimensions (W x H)

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
Format of LCD Pixel Arrangement

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
500 GB 7200 rpm SATA Hard
Drive
32° to 140° F (0° to 60° C) [case temp]
S.M.A.R.T., NCQ, Ultra DMA
1 TB 5400 rpm SATA
Hard Drive
Single Track
Average
Maximum
2 ms
12 ~ 13 ms
18 ~ 22 ms
32° to 140° F (0° to 60° C) [case temp]
S.M.A.R.T., NCQ, Ultra DMA
128 GB 2280 M2 SATA-3 TLC
Solid State Drive

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
0.01 lb (6 g) ~ 0.02 lb (10 g)
32° to 158°F (0° to 70°C) [ambient temp]
256 GB PCIe NVMe TLC Solid
State Drive
32° to 158°F (0° to 70°C) [ambient temp]
256 GB 2280 M2 PCIe NVMe
Value Solid State Drive
32° to 158°F (0° to 70°C) [ambient temp]

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
512 GB 2280 M2 PCIe NVMe
Value Solid State Drive
256 GB 2280 M2 SATA-3 TLC
Solid State Drive
32° to 158°F (0° to 70°C) [ambient temp]
16 GB Intel® Optane™
Solution PCIe Gen3x2
M.2 SSD

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
NOTE: For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10)
is reserved for system recovery software.
NETWORKING/COMMUNICATIONS
Realtek 802.11b/g/n
(1x1) Wi-Fi® and
Bluetooth® 4.2 Combo
1
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
802.11b/g/n
2.402 – 2.482 GHz
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: MCS 0 ~ MCS 7, (20MHz, and 40MHz)
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM
IEEE and Wi-Fi® compliant 64 / 128 bit WEP encryption for b/g mode only
AES-CCMP: 128 bit in hardware
802.1x authentication
WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
IEEE 802.11 compliant roaming between access points
802.11b: +14dBm minimum
802.11g: +12dBm minimum
802.11n HT20(2.4GHz): +12dBm minimum
802.11n HT40(2.4GHz): +12dBm minimum
Transmit mode 2.0 W
Receive mode 1.6 W
Idle mode (PSP) 180 mW (WLAN Associated)
Idle mode 50 mW (WLAN unassociated)
Connected Standby 10mW
Radio disabled 8mW
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
802.11b, 1Mbps: -93.5dBm maximum
802.11b, 11Mbps: -84dBm maximum
802.11g, 6Mbps: -86dBm maximum

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
802.11g, 54Mbps: -72dBm maximum
802.11n, MCS07: -67dBm maximum
High efficiency antenna.
One embedded dual band 2.4/5 GHz antenna is provided to the card to
support WLAN communications and Bluetooth communications
Type 2230: 2.3 x 22.0 x 30.0 mm
Operating: 14° to 158° F (–10° to 70° C)
Non-operating: –40° to 176° F (–40° to 80° C)
Operating: 10% to 90% (non-condensing)
Non-operating: 5% to 95% (non-condensing)
Operating: 0 to 10,000 ft (3,048 m)
Non-operating: 0 to 50,000 ft (15,240 m)
LED Amber – Radio OFF
LED OFF – Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Number of Available
Channels
Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)
Legacy: 3 Mbps Signaling Data Rate1 2.17 Mbps
BLE: 1 Mbps Signaling Data Rate1 0.2 Mbps
1. Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
Bluetooth Software
Supported
Link Topology
Microsoft Windows Bluetooth Software
Microsoft Windows ACPI, and USB Bus Support
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles
Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Realtek
802.11a/b/g/n/ac (1x1)
Wi-Fi® and Bluetooth®
4.2 Combo
1
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
• 802.11b/g/n
2.402 – 2.482 GHz

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
• 802.11a/n/ac
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
IEEE and Wi-Fi® compliant 64 / 128 bit WEP encryption for b/g mode only
AES-CCMP: 128 bit in hardware
802.1x authentication
WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
IEEE 802.11 compliant roaming between access points
802.11b: +14dBm minimum
802.11g: +12dBm minimum
802.11a: +12dBm minimum
802.11n HT20(2.4GHz): +12dBm minimum
802.11n HT40(2.4GHz): +12dBm minimum
802.11n HT20(5GHz): +10dBm minimum
802.11n HT40(5GHz): +10dBm minimum
802.11ac VHT80(5GHz): +10dBm minimum
Transmit mode 2.0 W
Receive mode 1.6 W
Idle mode (PSP) 180 mW (WLAN Associated)
Idle mode 50 mW (WLAN unassociated)
Connected Standby 10mW
Radio disabled 8mW
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
802.11b, 1Mbps: -93.5dBm maximum
802.11b, 11Mbps: -84dBm maximum
802.11a/g, 6Mbps: -86dBm maximum
802.11a/g, 54Mbps: -72dBm maximum
802.11n, MCS07: -67dBm maximum

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
802.11n, MCS15: -64dBm maximum
802.11ac, MCS0: -84dBm maximum
802.11ac, MCS9: -59dBm maximum
High efficiency antenna.
One embedded dual band 2.4/5 GHz antenna is provided to the card to
support WLAN communications and Bluetooth communications
Type 2230: 2.3 x 22.0 x 30.0 mm
Operating: 14° to 158° F (–10° to 70° C)
Non-operating: –40° to 176° F (–40° to 80° C)
Operating: 10% to 90% (non-condensing)
Non-operating: 5% to 95% (non-condensing)
Operating: 0 to 10,000 ft (3,048 m)
Non-operating: 0 to 50,000 ft (15,240 m)
LED Amber – Radio OFF
LED OFF – Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Number of Available
Channels
Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)
Legacy: 3 Mbps Signaling Data Rate1 2.17 Mbps
BLE: 1 Mbps Signaling Data Rate1 0.2 Mbps
1. Actual throughput may vary.
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Bluetooth Software
Supported Link Topology
Microsoft Windows Bluetooth Software
Microsoft Windows ACPI, and USB Bus Support
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles
Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Intel® 9560
802.11a/b/g/n/ac (2x2)
Wi-Fi® and Bluetooth®
5.0 Combo1
non-vPro
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
802.11b/g/n
2.402 – 2.482 GHz
802.11a/n
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &
160MHz)
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
IEEE and Wi-Fi® compliant 64 / 128 bit WEP encryption for b/g mode only
AES-CCMP: 128 bit in hardware
802.1x authentication
WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
IEEE 802.11 compliant roaming between access points
802.11b: +18.5dBm minimum
802.11g: +17.5dBm minimum
802.11a: +18.5dBm minimum
802.11n HT20(2.4GHz): +15.5dBm minimum
802.11n HT40(2.4GHz): +14.5dBm minimum
802.11n HT20(5GHz): +15.5dBm minimum
802.11n HT40(5GHz): +14.5dBm minimum
802.11ac VHT80(5GHz): +11.5dBm minimum
802.11ac VHT160(5GHz): +11.5dBm minimum
Transmit mode: 2.0 W
Receive mode: 1.6 W
Idle mode (PSP) 180 mW (WLAN Associated)
Idle mode:50 mW(WLAN unassociated)
Connected Standby/Modern Standby: 10mW
Radio disabled: 8 mW
ACPI and PCI Express compliant power management
802.11 compliant power saving mode

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
802.11b, 1Mbps: -93.5dBm maximum
802.11b, 11Mbps: -84dBm maximum
802.11a/g, 6Mbps: -86dBm maximum
802.11a/g, 54Mbps: -72dBm maximum
802.11n, MCS07: -67dBm maximum
802.11n, MCS15: -64dBm maximum
802.11ac, MCS0: -84dBm maximum
802.11ac, MCS9: -59dBm maximum
High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to
support WLAN MIMO communications and Bluetooth communications
PCI-Express M.2 MiniCard with CNVi Interface
1. Type 2230: 2.3 x 22.0 x 30.0 mm
2. Type 1216: 1.67 x 12.0 x 16.0 mm
1. Type 2230: 2.8 g
2. Type 126: 1.3 g
Operating: 14° to 158° F (–10° to 70° C)
Non-operating: –40° to 176° F (–40° to 80° C)
Operating: 10% to 90% (non-condensing)
Non-operating: 5% to 95% (non-condensing)
Operating: 0 to 10,000 ft (3,048 m)
Non-operating: 0 to 50,000 ft (15,240 m)
LED Amber – Radio OFF
LED OFF – Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology
4.0/4.1/4.2/5.0 Compliant
Number of Available
Channels
Legacy: 0~79 (1 MHz/CH)
BLE: 0~39 (2 MHz/CH)
Legacy: 3 Mbps Signaling Data Rate1 2.17 Mbps
BLE: 1 Mbps Signaling Data Rate1 0.2 Mbps
1. Actual throughput may vary.

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
The Bluetooth component shall operate as a Class II Bluetooth device with
a maximum transmit power of + 4 dBm for BR and EDR.
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Bluetooth Software
Supported Link Topology
Microsoft Windows Bluetooth Software
Microsoft Windows ACPI, and USB Bus Support
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles
Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
87.74 % at 115 Vac and 88.4 % at 230Vac

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
32°F to 95°F (0° to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20° to 85°C)
0 to 16,400 ft (0 to 5000m)
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
87.74 % at 115 Vac and 88.4 % at 230Vac
32°F to 95°F (0° to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20° to 85°C)
0 to 16,400 ft (0 to 5000m)

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
HP EM 65 W Smart
AC adapter
87.74 % at 115 Vac and 88.4 % at 230Vac
32°F to 95°F (0° to 35°C)
Non-operating (storage)
temperature
-4°F to 185°F (-20° to 85°C)
0 to 16,400 ft (0 to 5000m)
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives
Worldwide safety standards - IEC60950, EN60950, UL60950, Class1,
SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B,
FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE.
MTBF - over 200,000 hours at 25°C ambient condition.
HP 3-cell Long Life
Li-Ion (41 WHr)
6.0 x 186.35 x 90.2 mm (0.236 x 7.33 x 3.55 inch)
3cell Lithium-Ion Polymer cell / 515974 Prismatic cell 496080

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
32˚ to 113˚ F (0˚ to 45˚ C)
14˚ to 122˚ F (-10˚ to 60˚ C)
Optional Travel Battery
Available

Options and Accessories
Sold separately and availability may vary by country.
Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
HP 3005pr USB3 Port Replicator
HP USB-C Universal Dock NF (non-flash)
HP USB Essential Keyboard and Mouse
HP Ultra Mobile Wireless Mouse
HP Comfort Grip Wireless Mouse
HP 3-Button USB Laser Mouse
HP ProDisplay P203 20-inch Monitor
HP ProDisplay P223 21.5-inch Monitor
HP ProDisplay P240va 23.8-inch Monitor

Not all configuration components are available in all regions/countries.
c06271499 – DA16462 – Worldwide – Version 7 – April 22, 2020
Networking / Communications section
© Copyright 2020 HP Development Company, L.P. The information contained herein is subject to change without notice. The only
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein.
Bluetooth is a trademark of its proprietor and used by HP Inc. under license. Intel, Core, Thunderbolt and Intel vPro are trademarks
of Intel Corporation or its subsidiaries in the U.S. and/or other countries. USB Type-C™ and USB-C™ are trademarks of USB
Implementers Forum. SD, SDHC and SDXC are registered trademarks of SD-3C in the United States, other countries or both.
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the
United States and other countries. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. Microsoft
and Windows are either trademarks or registered trademarks of Microsoft Corporation in the U.S. and/or other countries.
