Honeywell Security User Manual
User guide
evohome Security
Home
INDEX
4
7
8
9
4
10
12
11
12
Controlling your system
evohome Security hub LED indications
Types of alerts and alarms generated
Battery maintenance
Troubleshooting
Contactless tag reader (SPRS8EZS)
Wireless remote control key fob (TCC800MS)
Wireless panic button (TCPA1BS)
Honeywell Total Connect Comfort International iOS/Android app
3Introduction
3
This document is intended to help you with the operation of your evohome hub based security system
following the installation procedure as described in the online “Installation Guide”.
The evohome security system is an alarm system that can be accessed and controlled locally or
remotely. A contactless tag reader (SPRS8EZS), wireless remote control key fob (TCC800MS) or
wireless panic button (TCPA1BS) are used for the local operation. A free iOS or Android app is available
for the remote control security operation as well as capturing and playing back photo images (only for
optional wireless motion sensor with camera accessory (CAMIR8EZS)
There are 2 modes of arming available for the system:
• Total arm – All sensors in the home are activated to protect all covered areas in the home whilst
you are away
• Partial arm – Only selected motion sensors or door window sensors in the home are protected
when “Partial mode” is activated. Typically this is used to activate only those sensors installed
downstairs in your home whilst you are asleep at night upstairs or in another area of the home.
(The partial mode setup for those sensors can be done in your security account within the TCC web
portal (See URL link above)
In the event of an intrusion detected by any of the sensors, the system will alert up to 3 contacts via
email by default and SMS text message provided this option has been setup in your TCC security web
account. Also an SOS or panic (personal attack) alert can be triggered by any connected contactless
tag reader (SPRS8EZS), wireless remote control key fob (TCC800MS) or wireless panic button
(TCPA1BS).
In addition if your system consist of a contactless tag reader, a wireless battery siren or a wireless
battery internal siren, then an alarm sound will be heard until the system is disarmed or reaches the
end of the alarm duration.
The system comprises three types of components:
• evohome security hub which is the core of the system: it communicates with all the other
components of the system and transmits the alarms in case of a problem.
• Control & Indication Equipment to operate the system (arming and disarming for example).
• Sensors are installed in the premises and communicate with the hub in case of problems (intrusion,
fire, etc). Sirens are used to sound locally when an alarm is triggered.
Note that the Total Comfort Connect (TCC) security web portal
https://international.mytotalconnectcomfort.com/ cannot be used to perform remote control of
the system and is only intended for setting up your accounts and system
INTRODUCTION
4
Your evohome security system can be controlled via the following interfaces listed below:
• Contactless tag reader (SPRS8EZ)
• Wireless Remote control key fob (TCC800MS)
• Wireless Panic button (TCPA1BS)
• iOS/Android “Honeywell Total Connect Comfort International” app
Contactless tag reader (SPRS8EZ)
The tag reader is an accessory typically installed near the entry/exit point in your home and is used to
do the following:
• control the security status of the evohome security hub
• activate an SOS/panic (personal attack) email/SMS alert
• indicate events from the security hub
The tag reader comprises an integrated siren that will sound in case of alarm for a fixed 180 second
duration unless disarmed by the user
Note there is no ability to control the system via your Total Comfort Connect (TCC)
security web account
CONTROLLING YOUR SYSTEM
5
How to use the tag reader
The security system can be set in two different arming modes:
• Total arm / total set: this mode is used when you leave your premises.
• Partial arm / partial set: this mode is used when you want to use your system while in your home
(at night for example). Only all sensors that you have set to “Partial mode” in your TCC security web
account)
As well as arming the tag reader can also be used to initiate a silent SOS/panic (personal attack) alert.
To arm the system when you leave your premises: Total arm
To arm the system when you are still in your premises: Partial arm
1. Press this button.
1. Press this button.
2. Present your tag in front of this area on the tag reader.
2. Present your tag in front of this area on the tag reader.
3. The green light flashes during the 30 second exit delay.
3. The green light flashes during the 30 second exit delayand
remains flashing. There are no beeps produced.
4. Exit the premises before the end of the beeps. The beeps will begin slow
and increase faster near the end of the exit delay period).
CONTROLLING YOUR SYSTEM
