Honeywell 3310G User Manual

Vuquest™ 3310g

Area-Imaging Scanner

User’s Guide

Disclaimer

Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.

HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material. HII disclaims all responsibility for the selection and use of software and/or hardware to achieve intended results.

This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of HII.

and are the property of their respective owners. Web Address: Microsoft® Windows®, Windows NT®, Windows 2000, Windows ME, Windows XP, and the Windows logo are trademarks or

registered trademarks of Microsoft Corporation. Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies

and are the property of their respective owners.

www.honeywellaidc.com

Product Agency Compliance - Vuquest 3310

USA

FCC Part 15 Subpart B Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio or television technician for help. If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions.

The user may find the following booklet helpful: “Something About Interference.” This is available at FCC local regional offices. Honeywell is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Honeywell. The correction is the responsibility of the user.

Use only shielded data cables with this system. This unit has been tested with cables less than 3 meters. Cables greater than 3 meters may not meet class B performance.

Caution: Any changes or modifications made to this equipment not expressly approved by Honeywell may void the FCC authorization to operate this equipment.

UL Statement

UL listed: UL60950-1, 2nd Edition.

Canada

Industry Canada ICES-003

This Class B digital apparatus complies with Canadian ICES-003. Operation is subject to the following conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

Conformité à la règlementation canadienne

Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada. Son fonctionnement est assujetti aux conditions suivantes :

1. Cet appareil ne doit pas causer de brouillage préjudiciable.

2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le brouillage pouvant causer un fonctionnement indésirable.

C-UL Statement

C-UL listed: CSA C22.2 No.60950-1-07, 2nd Edition.

Europe

The CE marking indicates compliance to 2004/108/EC EMC Directive with Standards EN55022 CLASS B, EN55024, EN61000-3-2, EN61000-3-3. In addition, complies to 2006/95/EC Low Voltage Directive, when shipped with recommended power supply.

European Contact:

Hand Held Products Europe B.V. Nijverheidsweg 9-13 5627 BT Eindhoven The Netherlands

Honeywell International Inc. shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.

Honeywell Scanning & Mobility Product Environmental Information

Refer to www.honeywellaidc.com/environmental for the RoHS / REACH / WEEE information.

South Korea

This product meets Korean agency approval.

Taiwan

If the following label is attached to your product, the product meets Taiwan agency approval:

BSMI Standard: CNS13438, CNS14336-1 依據標準 : CNS13438, CNS14336-1

International

LED Safety Statement

LEDs have been tested and classified as “EXEMPT RISK GROUP” to the standard: IEC 62471:2006.

CB Scheme

Certified to CB Scheme IEC 60950-1, Second Edition.

Patents

For patent information, please refer to www.hsmpats.com.

Solids and Water Protection

The Vuquest 3310 has a rating of IP53, immunity of foreign particles and dripping water.

Warning

To reduce the possibility of heat-related injuries, avoid touching sections of the scanner that feel warm.

Caution

To maintain compliance with standards when not powering the imager with the optional power supply, the power source should be listed and meet applicable requirements for a limited power source or a Class 2 power supply with

rating: 5 - 5.2 Vdc, 1.0 A minimum.

Required Safety Labels

Scanner

Compliance Label location

Part Number, Serial Number and Revision Information location

Illumination output

Chapter 1 - Getting Started

About This Manual ...............................................................................................................1-1

Unpacking Your Device .......................................................................................................1-1

Connecting the Device.........................................................................................................1-1

Connecting with USB .....................................................................................................1-1

Connecting with Keyboard Wedge.................................................................................1-1

Connecting with RS232 Serial Port................................................................................1-2

Reading Techniques ............................................................................................................1-3

Menu Bar Code Security Settings........................................................................................1-3

Setting Custom Defaults ......................................................................................................1-3

Resetting the Custom Defaults ............................................................................................1-4

Chapter 2 - Programming the Interface

Introduction ..........................................................................................................................2-1

Programming the Interface - Plug and Play .........................................................................2-1

Keyboard Wedge ...........................................................................................................2-1

Laptop Direct Connect ...................................................................................................2-1

RS232 Serial Port ..........................................................................................................2-1

USB IBM SurePos..........................................................................................................2-2

USB PC or Macintosh Keyboard....................................................................................2-2

USB HID.........................................................................................................................2-2

USB Serial......................................................................................................................2-3

Remote MasterMind™ for USB......................................................................................2-3

Verifone

Gilbarco

Honeywell Bioptic Aux Port Configuration......................................................................2-4

Datalogic™ Magellan

NCR Bioptic Aux Port Configuration ..............................................................................2-5

Wincor Nixdorf Terminal Default Settings ......................................................................2-5

Wincor Nixdorf Beetle™ Terminal Default Settings .......................................................2-6

Keyboard Country Layout ....................................................................................................2-6

Keyboard Style...................................................................................................................2-14

Keyboard Conversion ........................................................................................................2-15

Control Character Output...................................................................................................2-15

Keyboard Modifiers ............................................................................................................2-15

RS232 Modifiers ................................................................................................................2-18

RS232 Baud Rate ........................................................................................................2-18

RS232 Word Length: Data Bits, Stop Bits, and Parity .................................................2-19

RS232 Receiver Time-Out...........................................................................................2-21

RS232 Handshaking ....................................................................................................2-21

RS232 Timeout ............................................................................................................2-21

XON/XOFF...................................................................................................................2-22

ACK/NAK .....................................................................................................................2-22

Ruby Terminal Default Settings.....................................................................2-4

Terminal Default Settings ..............................................................................2-4

Aux Port Configuration..............................................................2-5

Scanner to Bioptic Communication ................................................................................... 2-22

Scanner-Bioptic Packet Mode .....................................................................................2-22

Scanner-Bioptic ACK/NAK Mode.................................................................................2-23

Scanner-Bioptic ACK/NAK Timeout.............................................................................2-23

Chapter 3 - Input/Output Settings

Power Up Beeper ................................................................................................................ 3-1

Beep on BEL Character.......................................................................................................3-1

Trigger Click ........................................................................................................................3-1

Good Read and Error Indicators..........................................................................................3-2

Beeper – Good Read.....................................................................................................3-2

Beeper Volume – Good Read........................................................................................3-2

Beeper Pitch – Good Read............................................................................................ 3-2

Beeper Pitch – Error ......................................................................................................3-3

Beeper Duration – Good Read ......................................................................................3-3

LED – Good Read .........................................................................................................3-3

Number of Beeps – Good Read ....................................................................................3-4

Number of Beeps – Error............................................................................................... 3-4

Good Read Delay ..........................................................................................................3-4

User-Specified Good Read Delay..................................................................................3-4

Manual Trigger Modes.........................................................................................................3-5

LED Illumination - Manual Trigger .................................................................................3-5

Serial Trigger Mode.............................................................................................................3-5

Read Time-Out ..............................................................................................................3-6

Presentation Mode ..............................................................................................................3-6

LED Illumination - Presentation Mode ...........................................................................3-6

Presentation LED Behavior after Decode......................................................................3-7

Presentation Sensitivity .................................................................................................3-7

Presentation Centering.................................................................................................. 3-7

CodeGate

Streaming Presentation™ Mode .........................................................................................3-9

Mobile Phone Read Mode.................................................................................................3-10

Hands-Free Time-Out........................................................................................................3-10

Character Activation Mode ................................................................................................3-10

Activation Character .................................................................................................... 3-11

Character Activation Laser Timeout ............................................................................ 3-11

Character Deactivation Mode ............................................................................................3-11

End Character Activation After Good Read................................................................. 3-11

Character Activation Timeout ......................................................................................3-12

Deactivation Character ................................................................................................3-12

Reread Delay.....................................................................................................................3-12

User-Specified Reread Delay ............................................................................................3-13

2D Reread Delay ...............................................................................................................3-13

Illumination Lights..............................................................................................................3-13

Aimer Delay .......................................................................................................................3-14

User-Specified Aimer Delay.........................................................................................3-14

Aimer Mode ....................................................................................................................... 3-14

Centering........................................................................................................................... 3-14

..........................................................................................................................3-9

Preferred Symbology.........................................................................................................3-16

High Priority Symbology ..............................................................................................3-16

Low Priority Symbology ...............................................................................................3-16

Preferred Symbology Time-out.................................................................................... 3-17

Preferred Symbology Default.......................................................................................3-17

Output Sequence Overview...............................................................................................3-17

Output Sequence Editor ..............................................................................................3-17

To Add an Output Sequence .......................................................................................3-17

Other Programming Selections....................................................................................3-18

Output Sequence Editor ..............................................................................................3-19

Partial Sequence .........................................................................................................3-19

Require Output Sequence ...........................................................................................3-19

Multiple Symbols ...............................................................................................................3-20

No Read ............................................................................................................................3-20

Video Reverse ...................................................................................................................3-21

Working Orientation...........................................................................................................3-21

Chapter 4 - Data Editing

Prefix/Suffix Overview .........................................................................................................4-1

To Add a Prefix or Suffix:............................................................................................... 4-1

Example: Add a Tab Suffix to All Symbologies..............................................................4-2

To Clear One or All Prefixes or Suffixes........................................................................ 4-2

To Add a Carriage Return Suffix to All Symbologies..................................................... 4-2

Prefix Selections..................................................................................................................4-2

Suffix Selections..................................................................................................................4-2

Function Code Transmit ...................................................................................................... 4-3

Communication Check Character........................................................................................ 4-3

Intercharacter, Interfunction, and

Intermessage Delays .......................................................................................................4-4

Intercharacter Delay ......................................................................................................4-4

User Specified Intercharacter Delay.............................................................................. 4-4

Interfunction Delay.........................................................................................................4-5

Intermessage Delay....................................................................................................... 4-5

Chapter 5 - Data Formatting

Data Format Editor Introduction .......................................................................................... 5-1

Add a Data Format .............................................................................................................. 5-1

Other Programming Selections......................................................................................5-2

Terminal ID Table................................................................................................................5-3

Data Format Editor Commands...........................................................................................5-3

Move Commands...........................................................................................................5-6

Search Commands........................................................................................................ 5-7

Miscellaneous Commands.............................................................................................5-9

Data Formatter ..................................................................................................................5-11

Data Format Non-Match Error Tone............................................................................ 5-12

Primary/Alternate Data Formats........................................................................................5-12

Single Scan Data Format Change............................................................................... 5-13

iii

Chapter 6 - External Input / Output

External Input ...................................................................................................................... 6-1

External Trigger Control.................................................................................................6-1

External Trigger Polarity ................................................................................................6-1

External Trigger Parameters..........................................................................................6-2

External Trigger Schematic ...........................................................................................6-2

External Output....................................................................................................................6-3

External Illumination Control..........................................................................................6-3

External Illumination Parameters...................................................................................6-3

External Illumination Schematic.....................................................................................6-4

Chapter 7 - Symbologies

All Symbologies...................................................................................................................7-1

Message Length Description...............................................................................................7-1

Codabar...............................................................................................................................7-2

Codabar Concatenation................................................................................................. 7-3

Code 39 ............................................................................................................................... 7-4

Code 32 Pharmaceutical (PARAF)................................................................................ 7-5

Full ASCII....................................................................................................................... 7-6

Code 39 Code Page ......................................................................................................7-6

Interleaved 2 of 5.................................................................................................................7-7

NEC 2 of 5........................................................................................................................... 7-8

Code 93 ............................................................................................................................... 7-9

Code 93 Code Page ....................................................................................................7-10

Straight 2 of 5 Industrial (three-bar start/stop)...................................................................7-11

Straight 2 of 5 IATA (two-bar start/stop)............................................................................7-12

Matrix 2 of 5.......................................................................................................................7-13

Code 11 ............................................................................................................................. 7-14

Code 128........................................................................................................................... 7-15

ISBT 128 Concatenation..............................................................................................7-15

Code 128 Code Page ..................................................................................................7-16

GS1-128 ............................................................................................................................ 7-17

Telepen..............................................................................................................................7-18

UPC-A ...............................................................................................................................7-19

UPC-A/EAN-13

with Extended Coupon Code .......................................................................................... 7-21

Coupon GS1 DataBar Output............................................................................................7-21

UPC-E0 .............................................................................................................................7-22

UPC-E1 .............................................................................................................................7-24

EAN/JAN-13 ......................................................................................................................7-24

Convert UPC-A to EAN-13 ..........................................................................................7-24

ISBN Translate ............................................................................................................7-26

EAN/JAN-8 ........................................................................................................................ 7-27

MSI .................................................................................................................................... 7-29

GS1 DataBar Omnidirectional ........................................................................................... 7-31

GS1 DataBar Limited.........................................................................................................7-31

GS1 DataBar Expanded....................................................................................................7-32

Trioptic Code ..................................................................................................................... 7-32

Codablock A ......................................................................................................................7-33

Codablock F ...................................................................................................................... 7-34

PDF417 .............................................................................................................................7-35

MacroPDF417 ................................................................................................................... 7-35

MicroPDF417.....................................................................................................................7-36

GS1 Composite Codes......................................................................................................7-36

UPC/EAN Version........................................................................................................7-37

GS1 Emulation ..................................................................................................................7-37

TCIF Linked Code 39 (TLC39) ..........................................................................................7-38

QR Code............................................................................................................................7-38

QR Code Page ............................................................................................................7-39

Data Matrix ........................................................................................................................ 7-40

Data Matrix Code Page ...............................................................................................7-40

MaxiCode ..........................................................................................................................7-41

Aztec Code ........................................................................................................................7-42

Aztec Code Page.........................................................................................................7-42

Chinese Sensible (Han Xin) Code.....................................................................................7-43

Postal Codes - 2D .............................................................................................................7-44

Single 2D Postal Codes:..............................................................................................7-44

Combination 2D Postal Codes:....................................................................................7-45

Postal Codes - Linear........................................................................................................7-48

China Post (Hong Kong 2 of 5).................................................................................... 7-48

Korea Post...................................................................................................................7-49

Chapter 8 - Imaging Commands

Single-Use Basis ................................................................................................................. 8-1

Command Syntax................................................................................................................8-1

Image Snap - IMGSNP........................................................................................................8-1

IMGSNP Modifiers......................................................................................................... 8-1

Image Ship - IMGSHP .........................................................................................................8-3

IMGSHP Modifiers......................................................................................................... 8-4

Intelligent Signature Capture - IMGBOX ...........................................................................8-10

Signature Capture Optimize ........................................................................................8-10

IMGBOX Modifiers.......................................................................................................8-11

Chapter 9 - Interface Keys

Keyboard Function Relationships........................................................................................9-1

Supported Interface Keys ....................................................................................................9-3

Chapter 10 - Utilities

To Add a Test Code I.D. Prefix to All Symbologies...........................................................10-1

Show Decoder Revision ....................................................................................................10-1

Show Scan Driver Revision ...............................................................................................10-1

Show Software Revision.................................................................................................... 10-1

Show Data Format.............................................................................................................10-1

Test Menu..........................................................................................................................10-2

TotalFreedom ....................................................................................................................10-2

Application Plug-Ins (Apps) ...............................................................................................10-2

EZConfig-Scanning Introduction........................................................................................10-3

Installing EZConfig-Scanning from the Web................................................................ 10-3

Resetting the Factory Defaults .......................................................................................... 10-4

Chapter 11 - Serial Programming Commands

Conventions.......................................................................................................................11-1

Menu Command Syntax....................................................................................................11-1

Query Commands .............................................................................................................11-1

Responses................................................................................................................... 11-2

Trigger Commands............................................................................................................11-3

Resetting the Custom Defaults..........................................................................................11-3

Menu Commands .............................................................................................................. 11-4

Chapter 12 - Product Specifications

3310 Scanner Product Specifications................................................................................12-1

Depth of Field ....................................................................................................................12-2

Typical Performance....................................................................................................12-2

Guaranteed Performance ............................................................................................12-2

Mounting General Guidelines............................................................................................12-3

Standard Cable Pinouts.....................................................................................................12-4

Keyboard Wedge.........................................................................................................12-4

Serial Output ............................................................................................................... 12-5

USB ............................................................................................................................12-5

Chapter 13 - Maintenance

Repairs ..............................................................................................................................13-1

Maintenance......................................................................................................................13-1

Cleaning the Scanner ..................................................................................................13-1

Cleaning the Window................................................................................................... 13-1

Inspecting Cords and Connectors ...............................................................................13-1

Replacing Cables ..............................................................................................................13-1

Replacing an Interface Cable ......................................................................................13-2

Troubleshooting a Corded Scanner...................................................................................13-2

Chapter 14 - Customer Support

Technical Assistance.........................................................................................................14-1

Product Service and Repair...............................................................................................14-1

Appendix A - Reference Charts

Symbology Charts ...............................................................................................................A-1

Linear Symbologies .......................................................................................................A-1

2D Symbologies.............................................................................................................A-3

Postal Symbologies .......................................................................................................A-3

ASCII Conversion Chart (Code Page 1252)........................................................................A-3

Lower ASCII Reference Table.............................................................................................A-4

ISO 2022/ISO 646 Character Replacements ......................................................................A-8

Unicode Key Maps ............................................................................................................A-10

Sample Symbols

Programming Chart

vii

viii

Scanner USB Connection:

Getting Started

About This Manual

This User’s Guide provides installation and programming instructions for the Vuquest™ 3310 area-imaging scanner. Product specifications, dimensions, warranty, and customer support information are also included.

Honeywell bar code scanners are factory programmed for the most common terminal and communications settings. If you need to change these settings, programming is accomplished by scanning the bar codes in this guide.

An asterisk (*) next to an option indicates the default setting.

Unpacking Your Device

After you open the shipping carton containing the product, take the following steps:

• Check for damage during shipment. Report damage immediately to the carrier who delivered the carton.

• Make sure the items in the carton match your order.

• Save the shipping container for later storage or shipping.

Connecting the Device

Connecting with USB

A scanner can be connected to the USB port of a computer.

1. Connect the appropriate interface cable to the device first, then to the computer.

2. The scanner beeps.

3. Verify the scanner operation by scanning a bar code from the Sample Symbols in the back of this manual.

The unit defaults to a USB PC Keyboard. Refer to page 2-2 for other USB terminal settings. For additional USB programming and technical information, refer to “USB Application Note,” available at www.honey-

wellaidc.com.

Connecting with Keyboard Wedge

A scanner can be connected between the keyboard and PC as a “keyboard wedge,” where the scanner provides data output that is similar to keyboard entries. The following is an example of a keyboard wedge connection:

1. Turn off power and disconnect the keyboard cable from the back of the terminal/computer.

1 - 1

2. Connect the appropriate interface cable to the device and to the terminal/computer.

Scanner Keyboard Wedge Connection:

Scanner RS232 Serial Port Connection:

3. Turn the terminal/computer power back on. The scanner beeps.

4. Verify the scanner operation by scanning a bar code from the Sample Symbols in the back of this manual. The scanner beeps once.

The unit defaults to an IBM PC AT and compatibles keyboard wedge interface with a USA keyboard. A carriage return (CR) suffix is added to bar code data.

Connecting with RS232 Serial Port

1. Turn off power to the terminal/computer.

2. Connect the appropriate interface cable to the scanner.

Note: For the scanner to work properly, you must have the correct cable for your type of terminal/computer.

3. Plug the serial connector into the serial port on your computer. Tighten the two screws to secure the connector to the port.

4. Once the scanner has been fully connected, power up the computer.

This interface programs 115,200 baud, 8 data bits, no parity, and 1 stop bit.

Note: Please note, the end of the cable with the ferrite plugs into the scanner. The end of the cable with the label “DO NOT

connect this end to the bar code scanner” plugs into the computer.

1 - 2

Reading Techniques

Linear bar code 2D Matrix symbol

Set Custom Defaults

Save Custom Defaults

The scanner has a view finder that projects a bright green aiming beam that corresponds to the scanner’s horizontal field of view. The aiming beam should be centered over the bar code, but it can be positioned in any direction for a good read.

The aiming beam is smaller when the scanner is closer to the code and larger when it is farther from the code. Symbologies with smaller bars or elements (mil size) should be read closer to the unit. Symbologies with larger bars or elements (mil size) should be read farther from the unit. To read single or multiple symbols (on a page or on an object), hold the scanner at an appropriate distance from the target, press the button, and center the aiming beam on the symbol. If the code being scanned is highly reflective (e.g., laminated), it may be necessary to tilt the code up 15° to 18° to prevent unwanted reflection.

Menu Bar Code Security Settings

Honeywell scanners are programmed by scanning menu bar codes or by sending serial commands to the scanner. If you want to restrict the ability to scan menu codes, you can use the Menu Bar Code Security settings. Please contact the nearest technical support office (see Technical Assistance on page 14-1) for further information.

Setting Custom Defaults

You have the ability to create a set of menu commands as your own, custom defaults. To do so, scan the Set Custom Defaults bar code below before scanning the menu commands for your custom defaults. If a menu command requires scanning numeric codes from the back cover, then a Save code, that entire sequence will be saved to your custom defaults. When you have entered all the commands you want to save for your custom defaults, scan the Set Custom Defaults bar code.

1 - 3

You may have a series of custom settings and want to correct a single setting. To do so, just scan the new setting to overwrite

Activate Custom Defaults

the old one. For example, if you had previously saved the setting for Beeper Volume at Low to your custom defaults, and decide you want the beeper volume set to High, just scan the Set Custom Defaults bar code, then scan the Beeper Volume High menu code, and then Save Custom Defaults. The rest of the custom defaults will remain, but the beeper volume setting will be updated.

Resetting the Custom Defaults

If you want the custom default settings restored to your scanner, scan the Activate Custom Defaults bar code below. This is the recommended default bar code for most users. It resets the scanner to the custom default settings. If there are no custom defaults, it will reset the scanner to the factory default settings. Any settings that have not been specified through the custom defaults will be defaulted to the factory default settings.

1 - 4

IBM PC AT and Compatibles with

CR suffix

Laptop Direct Connect

with CR suffix

RS232 Interface

Programming the Interface

Introduction

This chapter describes how to program your system for the desired interface.

Programming the Interface - Plug and Play

Plug and Play bar codes provide instant scanner set up for commonly used interfaces.

Note: After you scan one of the codes, power cycle the host terminal to have the interface in effect.

Keyboard Wedge

If you want your system programmed for an IBM PC AT and compatibles keyboard wedge interface with a USA keyboard, scan the bar code below. Keyboard wedge is the default interface.

Note: The following bar code also programs a carriage return (CR) suffix.

Laptop Direct Connect

For most laptops, scanning the Laptop Direct Connect bar code allows operation of the scanner in parallel with the integral keyboard. The following Laptop Direct Connect bar code also programs a carriage return (CR) suffix and turns on Emulate External Keyboard (page 2-14).

RS232 Serial Port

The RS232 Interface bar code is used when connecting to the serial port of a PC or terminal. The following RS232 Interface bar code also programs a carriage return (CR) and a line feed (LF) suffix, baud rate, and data format as indicated

below. It also changes the trigger mode to manual.

Option Setting

Baud Rate 115,200 bps Data Format 8 data bits, no parity bit, 1 stop bit

2 - 1

USB IBM SurePos

(USB Handheld Scanner)

Interface

USB IBM SurePos

(USB Tabletop Scanner)

Interface

(

)

USB Keyboard (Mac)

USB Japanese Keyboard (PC)

USB HID Bar Code Scanner

Scan one of the following “Plug and Play” codes to program the scanner for an IBM SurePos (USB handheld scanner) or IBM SurePos (USB tabletop scanner) interface.

Note: After scanning one of these codes, you must power cycle the cash register.

Each bar code above also programs the following suffixes for each symbology:

Symbology Suffix Symbology Suffix

EAN 8 0C Code 39 00 0A 0B EAN 13 16 Interleaved 2 of 5 00 0D 0B UPC A 0D Code 128 00 18 0B UPC E 0A Code 39 00 0A 0B

USB PC or Macintosh Keyboard

Scan one of the following codes to program the scanner for USB PC Keyboard or USB Macintosh Keyboard. Scanning these codes also adds a CR and LF.

USB HID

Scan the following code to program the scanner for USB HID bar code scanners.

2 - 2

USB Serial

CTS/RTS Emulation On

* CTS/RTS Emulation Off

ACK/NAK Mode On

* ACK/NAK Mode Off

ReM Off

* ReM On

Scan the following code to program the scanner to emulate a regular RS232-based COM Port. If you are using a Microsoft® Windows® PC, you will need to download a driver from the Honeywell website (www.honeywellaidc.com). The driver will use the next available COM Port number. Apple® Macintosh computers recognize the scanner as a USB CDC class device and automatically use a class driver.

Note: No extra configuration (e.g., baud rate) is necessary.

CTS/RTS Emulation

ACK/NAK Mode

Remote MasterMind™ for USB

When using a USB interface, you may wish to configure your scanner to communicate with Remote MasterMind Scanner Management Software (ReM). Scan the ReM On bar code to communicate with ReM. To disable this capability, scan ReM

Off. Default = ReM On.

2 - 3

Verifone® Ruby Terminal Default Settings

Verifone Ruby Settings

Gilbarco Settings

Honeywell Bioptic Settings

Scan the following Plug and Play code to program the scanner for a Verifone Ruby terminal. This bar code sets the baud rate to 1200 bps and the data format to 8 data bits, Mark parity bit, 1 stop bit. It also adds a line feed (LF) suffix an programs the following prefixes for each symbology:

Symbology Prefix

UPC-A A UPC-E A EAN-8 FF EAN-13 F

Note: If you are having unexpected results with this programming code, scan the Activate Defaults bar code on page 1-4

first, then scan the programming code above.

Gilbarco® Terminal Default Settings

Scan the following Plug and Play code to program the scanner for a Gilbarco terminal. This bar code sets the baud rate to 2400 bps and the data format to 7 data bits, even parity, 2 stop bits. It also adds a carriage return (CR) suffix and programs the following prefixes for each symbology:

Symbology Prefix

UPC-A A UPC-E E0 EAN-8 FF EAN-13 F

Note: If you are having unexpected results with this programming code, scan the Activate Defaults bar code on page 1-4

first, then scan the programming code above.

Honeywell Bioptic Aux Port Configuration

Scan the following Plug and Play code to program the scanner for a Honeywell bioptic scanner auxiliary port configuration. This bar code sets the baud rate to 38400 bps and the data format to 8 data bits, no parity, 1 stop bit.

Note: If you are having unexpected results with this programming code, scan the Activate Defaults bar code on page 1-4

first, then scan the programming code above.

2 - 4

Datalogic™ Magellan© Aux Port Configuration

Datalogic Magellan Bioptic Settings

NCR Bioptic Settings

Wincor Nixdorf Terminal Settings

Scan the following Plug and Play code to program the scanner for a Datalogic Magellan auxiliary port configuration. This bar code sets the baud rate to 9600 bps and the data format to 8 data bits, no parity, 1 stop bit.

Note: If you are having unexpected results with this programming code, scan the Activate Defaults bar code on page 1-4

first, then scan the programming code above.

NCR Bioptic Aux Port Configuration

Scan the following Plug and Play code to program the scanner for an NCR bioptic scanner auxiliary port configuration. The communication should be set at 9600bps baud rate, 7 data bit data format, even parity and 1 stop bit. The following prefixes are programmed for each symbology:

Symbology Prefix Symbology Prefix

UPC-A A Interleaved 2 of 5 b UPC-E E0 Code 128 f

GS1 DataBar Omnidirecitonal

EAN-8 FF GS1 DataBar

Expanded EAN-13 F Codabar N Code 39 a Code 32

Pharmaceutical

(PARAF)

Note: If you are having unexpected results with this programming code, scan the Activate Defaults bar code on page 1-4

first, then scan the programming code above.

Wincor Nixdorf Terminal Default Settings

Scan the following Plug and Play code to program the scanner for a Wincor Nixdorf terminal. This bar code sets the baud rate to 9600 bps and the data format to 8 data bits, no parity, 1 stop bit.

Note: If you are having unexpected results with this programming code, scan the Activate Defaults bar code on page 1-4

first, then scan the programming code above.

2 - 5

Wincor Nixdorf Beetle™ Terminal Default Settings

Wincor Nixdorf Beetle Settings

* United States

Albania

Azeri (Cyrillic)

Azeri (Latin)

Belarus

Belgium

Scan the following Plug and Play code to program the scanner for a Wincor Nixdorf Beetle terminal. Communication using 115200bps, no parity bit, 8 data bits and 1 stop bit. The following prefixes are programmed for each symbology:

Symbology Prefix Symbology Prefix

Code 128 K EAN-13 A Code 93 L GS1-128 P Codabar N Interleaved 2 of 5 I UPC-A A0 Straight 2 of 5 IATA H UPC-E C All other bar codes M EAN-8 B

Note: If you are having unexpected results with this programming code, scan the Activate Defaults bar code on page 1-4

first, then scan the programming code above.

Keyboard Country Layout

Scan the appropriate country code below to program the keyboard layout for your country or language. As a general rule, the following characters are supported, but need special care for countries other than the United States: @ | $ # { } [ ] = / ‘ \ < > ~

Keyboard Countries

2 - 6

Keyboard Countries (Continued)

Bosnia

Brazil

Brazil (MS)

Bulgaria (Cyrillic)

Bulgaria (Latin)

Canada (French legacy)

Canada (French)

Canada (Multilingual)

Croatia

Czech

Czech (Programmers)

2 - 7

Keyboard Countries (Continued)

Czech (QWERTY)

Czech (QWERTZ)

Denmark

Dutch (Netherlands)

Estonia

Faroese

Finland

France

Gaelic

Germany

Greek

2 - 8

Keyboard Countries (Continued)

Greek (220 Latin)

Greek (220)

Greek (319 Latin)

Greek (319)

Greek (Latin)

Greek (MS)

Greek (Polytonic)

Hebrew

Hungarian (101 key)

Hungary

Iceland

2 - 9

Keyboard Countries (Continued)

Irish

Italian (142)

Italy

Japan ASCII

Kazakh

Kyrgyz (Cyrillic)

Latin America

Latvia

Latvia (QWERTY)

Lithuania

Lithuania (IBM)

2 - 10

Keyboard Countries (Continued)

Macedonia

Malta

Mongolian (Cyrillic)

Norway

Poland

Polish (214)

Polish (Programmers)

Portugal

Romania

Russia

Russian (MS)

2 - 11

Keyboard Countries (Continued)

Russian (Typewriter)

SCS

Serbia (Cyrillic)

Serbia (Latin)

Slovakia

Slovakia (QWERTY)

Slovakia (QWERTZ)

Slovenia

Spain

Spanish variation

Sweden

2 - 12

Keyboard Countries (Continued)

Switzerland (French)

Switzerland (German)

Tatar

Turkey F

Turkey Q

Ukrainian

United Kingdom

United States (Dvorak)

United States (Dvorak left)

United Stated (Dvorak right)

United States (International)

2 - 13

Keyboard Countries (Continued)

Uzbek (Cyrillic)

* Regular

Caps Lock

Shift Lock

Automatic Caps Lock

Autocaps via NumLock

Emulate External Keyboard

Keyboard Style

This programs keyboard styles, such as Caps Lock and Shift Lock. If you have used Keyboard Conversion settings, they will override any of the following Keyboard Style settings. Default = Regular.

Regular is used when you normally have the Caps Lock key off.

Caps Lock is used when you normally have the Caps Lock key on.

Shift Lock is used when you normally have the Shift Lock key on (not common to U.S. keyboards).

Automatic Caps Lock is used if you change the Caps Lock key on and off. The software tracks and reflects if you have Caps

Lock on or off . This selection can only be used with systems that have an LED that notes the Caps Lock status (AT keyboards).

Autocaps via NumLock bar code should be scanned in countries (e.g., Germany, France) where the Caps Lock key cannot be used to toggle Caps Lock. The NumLock option works similarly to the regular Autocaps, but uses the NumLock key to retrieve the current state of the Caps Lock.

Emulate External Keyboard should be scanned if you do not have an external keyboard (IBM AT or equivalent).

Note: After scanning the Emulate External Keyboard bar code, you must power cycle your computer.

2 - 14

Keyboard Conversion

* Keyboard Conversion Off

Convert All Characters

to Upper Case

Convert All Characters

to Lower Case

Control Character Output On

* Control Character Output Off

Alphabetic keyboard characters can be forced to be all upper case or all lowercase. So if you have the following bar code: “abc569GK,” you can make the output “ABC569GK” by scanning Convert All Characters to Upper Case, or to “abc569gk” by scanning Convert All Characters to Lower Case.

These settings override Keyboard Style selections.

Note: If your interface is a keyboard wedge, first scan the menu code for Automatic Caps Lock (page 2-14). Otherwise, your

output may not be as expected.

Default = Keyboard Conversion Off.

Control Character Output

This selection sends a text string instead of a control character. For example, when the control character for a carriage return is expected, the output would display [CR] instead of the ASCII code of 0D. Refer to ASCII Conversion Chart (Code Page

1252) on page A-3. Only codes 00 through 1F are converted (the first column of the chart).

Note: Control + X (Control + ASCII) Mode overrides this mode.

Default = Off.

Keyboard Modifiers

This modifies special keyboard features, such as CTRL+ ASCII codes and Turbo Mode.

Control + X (Control + ASCII) Mode On: The scanner sends key combinations for ASCII control characters for values 00-1F. Windows is the preferred mode. All keyboard country codes are supported. DOS mode is a legacy mode, and it does not support all keyboard country codes. New users should use the Windows mode. Refer to Keyboard Function Relationships, page 91 for CTRL+ X Values.

2 - 15

Windows Mode Prefix/Suffix Off: The scanner sends key combinations for ASCII control characters for values 00-1F, but it

Windows Mode Control + X

Mode On

* Control + X Mode Off

DOS Mode Control + X Mode On

Windows Mode Prefix/Suffix Off

Turbo Mode On

* Turbo Mode Off

Numeric Keypad Mode On

* Numeric Keypad Mode Off

does not translate any prefix or suffix information.

Default = Control + X Mode Off.

Turbo M o d e: The scanner sends characters to a terminal faster. If the terminal drops characters, do not use Turbo Mode. Default = Off

Numeric Keypad Mode: Sends numeric characters as if entered from a numeric keypad. Default = Off.

2 - 16

Automatic Direct Connect Mode: This selection can be used if you have an IBM AT style terminal and the system is dropping

Automatic Direct Connect Mode

* Automatic Direct Connect

Mode Off

characters. Default = Off.

2 - 17

RS232 Modifiers

300

600

1200

2400

4800

9600

19200

38400

57600

* 115,200

RS232 Baud Rate

Baud Rate sends the data from the scanner to the terminal at the specified rate. The host terminal must be set for the same baud rate as the scanner. Default = 115,200.

2 - 18

RS232 Word Length: Data Bits, Stop Bits, and Parity

300

600

1200

2400

4800

9600

19200

38400

57,600

* 115,200

Data Bits sets the word length at 7 or 8 bits of data per character. If an application requires only ASCII Hex characters 0

through 7F decimal (text, digits, and punctuation), select 7 data bits. For applications that require use of the full ASCII set, select 8 data bits per character. Default = 8.

Stop Bits sets the stop bits at 1 or 2. Default = 1.

2 - 19

Parity provides a means of checking character bit patterns for validity.

7 Data, 1 Stop, Parity Even

7 Data, 1 Stop, Parity None

7 Data, 1 Stop, Parity Odd

7 Data, 2 Stop, Parity Even

7 Data, 2 Stop Parity None

7 Data, 2 Stop, Parity Odd

8 Data, 1 Stop, Parity Even

* 8 Data, 1 Stop, Parity None

8 Data, 1 Stop, Parity Odd

8 Data, 1 Stop, Parity Mark

Default = None.

2 - 20

RS232 Receiver Time-Out

Flow Control, No Timeout

Two-Direction Flow Control

Flow Control with Timeout

* RTS/CTS Off

RS232 Timeout

The unit stays awake to receive data until the RS232 Receiver Time-Out expires. A manual or serial trigger resets the timeout. When an RS232 receiver is sleeping, a character may be sent to wake up the receiver and reset the time-out. A transaction on the CTS line will also wake up the receiver. The receiver takes 300 milliseconds to completely come up. Change the RS232 receiver time-out by scanning the bar code below, then scanning digits from the inside back cover of this manual, then scanning Save. The range is 0 to 300 seconds. Default = 0 seconds (no time-out - always on).

RS232 Handshaking

RS232 Handshaking allows control of data transmission from the scanner using software commands from the host device. When RTS/CTS is turned Off, no data flow control is used.

Flow Control, No Timeout: The scanner asserts RTS when it has data to send, and will wait indefinitely for CTS to be asserted by the host.

Two-Direction Flow Control: The scanner asserts RTS when it is OK for the host to transmit. The host asserts CTS when it is OK for the device to transmit.

Flow Control with Timeout: The scanner asserts RTS when it has data to send and waits for a delay (see RS232

Timeout on page 2-21) for CTS to be asserted by the host. If the delay time expires and CTS is not asserted, the device

transmit buffer is cleared and scanning may resume.

Default = RTS/CTS Off.

RS232 Timeout

When using Flow Control with Timeout, you must program the length of the delay you want to wait for CTS from the host. Set the length (in milliseconds) for a timeout by scanning the bar code below, then setting the timeout (from 1-5100 milliseconds) by scanning digits from the inside back cover, then scanning Save.

2 - 21

XON/XOFF

XON/XOFF On

* XON/XOFF Off

ACK/NAK On

* ACK/NAK Off

* Packet Mode Off

Packet Mode On

Standard ASCII control characters can be used to tell the scanner to start sending data (XON/XOFF On) or to stop sending data (XON/XOFF Off). When the host sends the XOFF character (DC3, hex 13) to the scanner, data transmission stops. To resume transmission, the host sends the XON character (DC1, hex 11). Data transmission continues where it left off

when XOFF was sent. Default = XON/XOFF Off.

ACK/NAK

After transmitting data, the scanner waits for an ACK character (hex 06) or a NAK character (hex 15) response from the host. If ACK is received, the communications cycle is completed and the scanner looks for more bar codes. If NAK is received, the last set of bar code data is retransmitted and the scanner waits for ACK/NAK again. Turn on the ACK/NAK protocol by scanning the ACK/NAK On bar code below. To turn off the protocol, scan ACK/NAK Off. Default = ACK/NAK

Off.

Scanner to Bioptic Communication

The following settings are used to set up communication between Honeywell scanners and bioptic scanners.

Note: The scanner’s baud rate must be set to 38400 and the RS232 timeout must be set to 3000 in order to communicate with

a bioptic scanner. See "RS232 Modifiers" on page 2-18, and RS232 Timeout on page 2-21 for further information.

Scanner-Bioptic Packet Mode

Packet Mode On must be scanned to set the scanner’s format so it is compatible with a bioptic scanner. Default = Packet Mode Off.

2 - 22

Scanner-Bioptic ACK/NAK Mode

* Bioptic ACK/NAK Off

Bioptic ACK/NAK On

ACK/NAK Timeout

Bioptic ACK/NAK On must be scanned so the scanner will wait for an ACK or NAK from a bioptic scanner after each

packet is sent. The Scanner-Bioptic ACK/NAK Timeout (below) controls how long the scanner will wait for a response. Default = Bioptic ACK/NAK Off.

Scanner-Bioptic ACK/NAK Timeout

This allows you to set the length (in milliseconds) for a timeout for a bioptic scanner’s ACK/NAK response. Scan the bar code below, then set the timeout (from 1-30,000 milliseconds) by scanning digits from the inside back cover, then scanning

Save. Default = 5100.

2 - 23

2 - 24

Power Up Beeper Off -

Scanner

* Power Up Beeper On -

Scanner

*Beep on BEL Off

Beep on BEL On

*Trigger Click Off

Trigger Click On

Input/Output Settings

Power Up Beeper

The scanner can be programmed to beep when it’s powered up. Scan the Off bar code(s) if you don’t want a power up beep.

Default = Power Up Beeper On - Scanner.

Beep on BEL Character

You may wish to force the scanner to beep upon a command sent from the host. If you scan the Beep on BEL On bar code below, the scanner will beep every time a BEL character is received from the host. Default = Beep on BEL Off.

Trigger Click

To hear an audible click every time the scanner button is pressed, scan the Trigger Click On bar code below. Scan the Trigger Click Off code if you don’t wish to hear the click. (This feature has no effect on serial or automatic triggering.) Default = Trigger

Click Off.

[

3 - 1

Good Read and Error Indicators

Beeper - Good Read Off

* Beeper - Good Read On

Low

Medium

* High

Off

Low (1600 Hz)

* Medium (2700 Hz)

Beeper – Good Read

The beeper may be programmed On or Off in response to a good read. Turning this option off only turns off the beeper response to a good read indication. All error and menu beeps are still audible. Default = Beeper - Good Read On.

Beeper Volume – Good Read

The beeper volume codes modify the volume of the beep the scanner emits on a good read. Default = High.

Beeper Pitch – Good Read

The beeper pitch codes modify the pitch (frequency) of the beep the scanner emits on a good read. Default = Medium.

3 - 2

Beeper Pitch – Error

High (4200 Hz)

* Razz (250 Hz)

Medium (3250 Hz)

High (4200 Hz)

* Normal Beep

Short BeepShort Beep

* LED - Good Read On

LED - Good Read Off

The beeper pitch codes modify the pitch (frequency) of the sound the scanner emits when there is a bad read or error.

Default = Razz.

Beeper Duration – Good Read

The beeper duration codes modify the length of the beep the scanner emits on a good read. Default = Normal.

LED – Good Read

The LED indicator can be programmed On or Off in response to a good read. Default = On.

3 - 3

Number of Beeps – Good Read

Number of Good Read Beeps/LED Flashes

Number of Error Beeps/LED Flashes

* No Delay

Short Delay (500 ms)

Medium Delay (1,000 ms)

Long Delay (1,500 ms)

User-Specified Good Read Delay

The number of beeps of a good read can be programmed from 1 - 9. The same number of beeps will be applied to the beeper and LED in response to a good read. For example, if you program this option to have five beeps, there will be five beeps and five LED flashes in response to a good read. The beeps and LED flashes are in sync with one another. To change the number of beeps, scan the bar code below and then scan a digit (1-9) bar code and the Save bar code on the

Programming Chart inside the back cover of this manual. Default = 1.

Number of Beeps – Error

The number of beeps and LED flashes emitted by the scanner for a bad read or error can be programmed from 1 - 9. For example, if you program this option to have five error beeps, there will be five error beeps and five LED flashes in response to an error. To change the number of error beeps, scan the bar code below and then scan a digit (1-9) bar code and the Save bar code on the Programming Chart inside the back cover of this manual. Default = 1.

Good Read Delay

This sets the minimum amount of time before the scanner can read another bar code. Default = 0 ms (No Delay).

User-Specified Good Read Delay

If you want to set your own length for the good read delay, scan the bar code below, then set the delay (from 0 - 30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save.

3 - 4

Manual Trigger Modes

* Manual Trigger - Normal

Manual Trigger - Enhanced

Off

Low

Medium

* High

When in manual trigger mode, the scanner scans until a bar code is read, or until the button is released. Two modes are available, Normal and Enhanced. Normal mode offers good scan speed and the longest working ranges (depth of field). Enhanced mode will give you the highest possible scan speed but slightly less range than Normal mode. Enhanced mode is

best used when you require a very fast scan speed and don’t require a long working range. Default = Manual Trigger-Normal.

LED Illumination - Manual Trigger

If you wish to set the illumination LED brightness, scan one of the bar codes below. This sets the LED illumination for the scanner when the button is pressed. Default = High.

Note: The LEDs are like a flash on a camera. The lower the ambient light in the room, the brighter the LEDs need to be so

the scanner can “see” the bar codes.

Serial Trigger Mode

You can activate the scanner either by pressing the button, or using a serial trigger command (see Trigger Commands on page 11-3). When in serial mode, the scanner scans until a bar code has been read or until the deactivate command is sent. The scanner can also be set to turn itself off after a specified time has elapsed (see Read Time-Out, which follows).

3 - 5

Read Time-Out

Presentation Mode

Off

Low

* High

Use this selection to set a time-out (in milliseconds) of the scanner’s button when using serial commands to trigger the scanner. Once the scanner has timed out, you can activate the scanner either by pressing the button or using a serial trigger command. After scanning the Read Time-Out bar code, set the time-out duration (from 0-300,000 milliseconds) by scanning digits on the Programming Chart inside the back cover, then scanning Save. Default = 30,000 ms.

Presentation Mode

Presentation Mode uses ambient light and scanner illumination to detect bar codes. When in Presentation Mode, the LEDs remain dim until a bar code is presented to the scanner, then the aimer turns on and the LEDs turn up to read the code. If the light level in the room is not high enough, Presentation Mode may not work properly

Scan the following bar code to program your scanner for Presentation Mode.

LED Illumination - Presentation Mode

If you wish to set the illumination LED brightness, scan one of the bar codes below. This sets the LED illumination for the scanner when it is in Presentation Mode. (If the scanner is triggered manually, the LED illumination will switch to the setting for a manual trigger. (See LED Illumination - Manual Trigger on page 3-5.) Default = High.

Note: The LEDs are like a flash on a camera. The lower the ambient light in the room, the brighter the LEDs need to be so

the scanner can “see” the bar codes.

Note: LED Illumination - Presentation Mode does not apply to Streaming Presentation™ Mode or Mobile Phone Read

3 - 6

Mode.

Presentation LED Behavior after Decode

* LEDs On

LEDs Off

Sensitivity

When a scanner is in presentation mode, the LEDs dim 30 seconds after a bar code is decoded. If you wish to dim the LEDs immediately after a bar code is decoded, scan the LEDs Off bar code, below. Default = LEDs On.

Presentation Sensitivity

Presentation Sensitivity is a numeric range that increases or decreases the scanner's reaction time to bar code presentation. To set the sensitivity, scan the Sensitivity bar code, then scan the degree of sensitivity (from 0-20) from the inside back cover, and Save. 0 is the most sensitive setting, and 20 is the least sensitive. Default = 1.

Presentation Centering

Use Presentation Centering to narrow the scanner’s field of view when it is in Presentation Mode to make sure the scanner reads only those bar codes intended by the user. For instance, if multiple codes are placed closely together, Presentation Centering will insure that only the desired codes are read.

Note: To adjust centering when the scanner is hand-held, see Centering (page 3-14).

If a bar code is not touched by a predefined window, it will not be decoded or output by the scanner. If Presentation Centering is turned on by scanning Presentation Centering On, the scanner only reads codes that pass through the centering window you specify using the Top of Presentation Centering Window, Bottom of Presentation Centering Window, Left, and Right of Presentation Centering Window bar codes.

3 - 7

In the example below, the white box is the centering window. The centering window has been set to 20% left, 30% right,

Bar Code 1

Bar Code 2

10 20 30 40 50 60 70 80 90 100%

100

Presentation Centering On

* Presentation Centering Off

Streaming Presentation™ Mode

When in Streaming Presentation mode, the scanner’s aimer goes out after a short time, but the scan illumination remains on all the time to continuously search for bar codes. Two modes are available, Normal and Enhanced. Normal mode offers good scan speed and the longest working ranges (depth of field). Enhanced mode will give you the highest possible scan speed but slightly less range than Normal mode. Enhanced mode is best used when you require a very fast scan speed and don’t require

a long working range.

When using Preferred Symbology (page 3-16), a lower priority symbol must be centered on the aiming pattern to be read in Streaming Presentation Mode.

3 - 9

Mobile Phone Read Mode

Hand Held Scanning - Mobile

Phone

Streaming Presentation -

Mobile Phone

Hands-Free Time-Out

* Off

When this mode is selected, your scanner is optimized to read bar codes from mobile phone or other LED displays. However, the speed of scanning printed bar codes may be slightly lower when this mode is enabled. You can enable Mobile Phone Read-

ing for either a hand held device, or for a hands-free (presentation) application.

Note: To turn off Mobile Phone Read Mode, scan a Manual or Serial Trigger Mode bar code (see page 3-5).

Hands-Free Time-Out

The Presentation Mode is referred to as “hands-free” mode. If the scanner’s button is pressed when using a hands-free mode, the scanner changes to manual trigger mode. You can set the time the scanner should remain in manual trigger mode by setting the Hands-Free Time-Out. Once the time-out value is reached, (if there have been no further button presses) the scanner reverts to the original hands-free mode.

Scan the Hands-Free Time-Out bar code, then scan the time-out duration (from 0-300,000 milliseconds) from the inside back cover, and Save. Default = 5,000 ms.

Character Activation Mode

You may use a character sent from the host to trigger the scanner to begin scanning. When the activation character is received, the scanner continues scanning until either the Character Activation Laser Timeout (page 3-11), the deactivation character is received (see Deactivation Character on page 3-12), or a bar code is transmitted. Scan the following On bar code to use char- acter activation, then use Activation Character (following) to select the character you will send from the host to start scanning.

Default = Off.

3 - 10

Activation Character

Character Activation Laser

Timeout

* Off

Do Not End Character Activation

After Good Read

* End Character Activation After

Good Read

This sets the character used to trigger scanning when using Character Activation Mode. On the ASCII Conversion Chart

(Code Page 1252), page A-3, find the hex value that represents the character you want to use to trigger scanning. Scan

the following bar code, then use the Programming Chart to read the alphanumeric combination that represents that ASCII character. Scan Save to finish.

Character Activation Laser Timeout

You can set a timeout for the length of time the laser remains on and attempting to decode bar codes when using Character Activation Mode. Set the length (in milliseconds) for a timeout by scanning the following bar code, then setting the timeout (from 1-65535 milliseconds) by scanning digits from the Programming Chart, then scanning Save. Default = 5000 ms.

Character Deactivation Mode

If you have sent a character from the host to trigger the scanner to begin scanning, you can also send a deactivation character to stop scanning. Scan the following On bar code to use character deactivation, then use Deactivation Character (following) to

select the character you will send from the host to terminate scanning. Default = Off.

End Character Activation After Good Read

After a bar code is successfully detected and read from the scanner, the illumination can be programmed either to remain on and scanning, or to turn off. When End Character Activation After Good Read is enabled, the illumination turns off and stops scanning after a good read. If you scan Do Not End Character Activation After Good Read, the illumination

remains on after a good read. Default = End Character Activation After Good Read.

3 - 11

Character Activation Timeout

Deactivation Character

Short (500 ms)

* Medium (750 ms)

Long (1000 ms)

Extra Long (2000 ms)

You can set a timeout for the length of time the illumination remains on and attempting to decode bar codes when using Character Activation Mode. Set the length (in milliseconds) for a timeout by scanning the following bar code, then setting the timeout (from 1-300,000 milliseconds) by scanning digits from the Programming Chart inside the back cover of this manual, then scanning Save. Default = 30,000 ms.

Deactivation Character

This sets the character used to terminate scanning when using Character Deactivation Mode. On the ASCII Conversion

Chart (Code Page 1252), page A-3, find the hex value that represents the character you want to use to terminate scanning.

Scan the following bar code, then use the Programming Chart to read the alphanumeric combination that represents that ASCII character. Scan Save to finish.

Reread Delay

This sets the time period before the scanner can read the same bar code a second time. Setting a reread delay protects against accidental rereads of the same bar code. Longer delays are effective in minimizing accidental rereads. Use shorter delays in applications where repetitive bar code scanning is required. Reread Delay only works when in a Presentation Mode (see page

3-6). Default = Medium.

3 - 12

User-Specified Reread Delay

* 2D Reread Delay Off

Short (1000ms)

Medium (2000ms)

Long (3000ms)

Extra Long (4000ms)

* Lights On

Lights Off

If you want to set your own length for the reread delay, scan the bar code below, then set the delay (from 0-65,535 milliseconds) by scanning digits from the inside back cover, then scanning Save.

2D Reread Delay

Sometimes 2D bar codes can take longer to read than other bar codes. If you wish to set a separate Reread Delay for 2D bar codes, scan one of the programming codes that follows. 2D Reread Delay Off indicates that the time set for Reread Delay is

used for both 1D and 2D bar codes. Default = 2D Reread Delay Off.

Illumination Lights

If you want the illumination lights on while reading a bar code, scan the Lights On bar code, below. However, if you want to turn just the lights off, scan the Lights Off bar code. Default = Lights On.

Note: This setting does not affect the aimer light. The aiming light can be set using Aimer Mode (page 3-14).

3 - 13

Aimer Delay

200 milliseconds

400 milliseconds

* Off (no delay)

Delay Duration

Off

* Interlaced

The aimer delay allows a delay time for the operator to aim the scanner before the picture is taken. Use these codes to set the time between when the button is pushed and when the picture is taken. During the delay time, the aiming light will appear, but

the LEDs won’t turn on until the delay time is over. Default = Off.

User-Specified Aimer Delay

If you want to set your own length for the duration of the delay, scan the bar code below, then set the time-out by scanning digits (0 - 4,000 ms) from the Programming Chart inside the back cover of this manual, then scan Save.

Aimer Mode

This feature allows you to turn the aimer on and off. When the Interlaced bar code is scanned, the aimer is interlaced with the illumination LEDs. Default = Interlaced.

Centering

Use Centering to narrow the scanner’s field of view to make sure that when the scanner is hand-held, it reads only those bar codes intended by the user. For instance, if multiple codes are placed closely together, centering will insure that only the desired codes are read. (Centering can be used in conjunction with Aimer Delay, page 3-14, for the most error-free operation in applications where multiple codes are spaced closely together. Using the Aimer Delay and Centering features, the scanner can emulate the operation of older systems, such as linear laser bar code scanners.)

Note: To adjust centering when the scanner is in Presentation Mode, see Presentation Centering (page 3-7).

3 - 14

If a bar code is not touched by a predefined window, it will not be decoded or output by the scanner. If Centering On is

Bar Code 1

Bar Code 2

10 20 30 40 50 60 70 80 90 100%

100

Centering On

* Centering Off

Top of Centering Window

Bottom of Centering Window

checked, the scanner only reads codes that pass through the centering window you specify using the Top of Centering Window, Bottom of Centering Window, Left, and Right of Centering Window selections.

In the example below, the white box is the centering window. The centering window has been set to 20% left, 30% right, 8% top, and 25% bottom. Since Bar Code 1 passes through the centering window, it will be read. Bar Code 2 does not pass through the centering window, so it will not be read.

Note: A bar code needs only to be touched by the centering window in order to be read. It does not need to pass completely

through the centering window.

Scan Centering On, then scan one of the following bar codes to change the top, bottom, left, or right of the centering window. Then scan the percent you want to shift the centering window using digits on the inside back cover of this manual. Scan Save.

Default Centering = 40% for Top and Left, 60% for Bottom and Right.

3 - 15

Preferred Symbology

Left of Centering Window

Right of Centering Window

Preferred Symbology On

* Preferred Symbology Off

High Priority Symbology

The scanner can be programmed to specify one symbology as a higher priority over other symbologies in situations where both bar code symbologies appear on the same label, but the lower priority symbology cannot be disabled.

For example, you may be using the scanner in a retail setting to read U.P.C. symbols, but have occasional need to read a code on a drivers license. Since some licenses have a Code 39 symbol as well as the PDF417 symbol, you can use Preferred Symbology to specify that the PDF417 symbol be read instead of the Code 39.

Preferred Symbology classifies each symbology as high priority, low priority, or as an unspecified type. When a low priority symbology is presented, the scanner ignores it for a set period of time (see Preferred Symbology Time-out on page 3-17) while it searches for the high priority symbology. If a high priority symbology is located during this period, then that data is read immediately.

If the time-out period expires before a high priority symbology is read, the scanner will read any bar code in its view (low priority or unspecified). If there is no bar code in the scanner’s view after the time-out period expires, then no data is reported.

Note: A low priority symbol must be centered on the aiming pattern to be read.

Scan a bar code below to enable or disable Preferred Symbology. Default = Preferred Symbology Off.

High Priority Symbology

To specify the high priority symbology, scan the High Priority Symbology bar code below. On the Symbology Charts on page A-1, find the symbology you want to set as high priority. Locate the Hex value for that symbology and scan the 2 digit hex value from the Programming Chart (inside back cover). Scan Save to save your selection. Default = None

Low Priority Symbology

To specify the low priority symbology, scan the Low Priority Symbology bar code below. On the Symbology Charts on page A-1, find the symbology you want to set as low priority. Locate the Hex value for that symbology and scan the 2 digit hex value from the Programming Chart (inside back cover).

3 - 16

If you want to set additional low priority symbologies, scan FF, then scan the 2 digit hex value from the Programming Chart

Low Priority Symbology

Preferred Symbology Time-out

Preferred Symbology Default

for the next symbology. You can program up to 5 low priority symbologies. Scan Save to save your selection. Default = None.

Preferred Symbology Time-out

Once you have enabled Preferred Symbology and entered the high and low priority symbologies, you must set the time-out period. This is the period of time the scanner will search for a high priority bar code after a low priority bar code has been encountered. Scan the bar code below, then set the delay (from 1-3,000 milliseconds) by scanning digits from the inside back cover, then scanning Save. Default = 500 ms.

Preferred Symbology Default

Scan the bar code below to set all Preferred Symbology entries to their default values.

Output Sequence Overview

Output Sequence Editor

This programming selection allows you to program the scanner to output data (when scanning more than one symbol) in whatever order your application requires, regardless of the order in which the bar codes are scanned. Reading the Default Sequence symbol programs the scanner to the Universal values, shown below. These are the defaults. Be certain you want to delete or clear all formats before you read the Default Sequence symbol.

Note: To make Output Sequence Editor selections, you’ll need to know the code I.D., code length, and character match(es)

your application requires. Use the Alphanumeric symbols (inside back cover) to read these options. You must hold the button while reading each bar code in the sequence.

To Add an Output Sequence

1. Scan the Enter Sequence symbol (see Require Output Sequence, page 3-19).

2. Code I.D. On the Symbology Charts on page A-1, find the symbology to which you want to apply the output sequence format. Locate the Hex value for that symbology and scan the 2 digit hex value from the Programming Chart (inside back cover).

3. Length Specify what length (up to 9999 characters) of data output will be acceptable for this symbology. Scan the four digit data length from the Programming Chart. (Note: 50 characters is entered as 0050. 9999 is a universal number, indicating all lengths.) When calculating the length, you must count any programmed prefixes, suffixes, or formatted characters as part of the length (unless using 9999).

4. Character Match Sequences On the ASCII Conversion Chart (Code Page 1252), page A-3, find the Hex value that represents the character(s) you want to match. Use the Programming Chart to read the alphanumeric combination that represents the ASCII characters. (99 is the Universal number, indicating all characters.)

3 - 17

5. End Output Sequence Editor

A - Code 39

B - Code 128

C - Code 93

Scan F F to enter an Output Sequence for an additional symbology, or Save to save your entries.

Other Programming Selections

• Discard

This exits without saving any Output Sequence changes.

Output Sequence Example

In this example, you are scanning Code 93, Code 128, and Code 39 bar codes, but you want the scanner to output Code 39 1st, Code 128 2nd, and Code 93 3rd, as shown below.

Note: Code 93 must be enabled to use this example.

You would set up the sequence editor with the following command line: SEQBLK62999941FF6A999942FF69999943FF The breakdown of the command line is shown below: SEQBLKsequence editor start command 62 code identifier for Code 39 9999 code length that must match for Code 39, 9999 = all lengths 41 start character match for Code 39, 41h = “A” FF termination string for first code 6A code identifier for Code 128 9999 code length that must match for Code 128, 9999 = all lengths 42 start character match for Code 128, 42h = “B” FF termination string for second code 69 code identifier for Code 93 9999 code length that must match for Code 93, 9999 = all lengths 43 start character match for Code 93, 43h = “C” FF termination string for third code To program the previous example using specific lengths, you would have to count any programmed prefixes, suffixes, or for-

matted characters as part of the length. If you use the example on page 3-18, but assume a <CR> suffix and specific code lengths, you would use the following command line:

SEQBLK62001241FF6A001342FF69001243FF

The breakdown of the command line is shown below: SEQBLKsequence editor start command 62 code identifier for Code 39 0012 A - Code 39 sample length (11) plus CR suffix (1) = 12

3 - 18

41 start character match for Code 39, 41h = “A”

Enter Sequence

Default Sequence

Transmit Partial Sequence

* Discard Partial Sequence

FF termination string for first code 6A code identifier for Code 128 0013 B - Code 128 sample length (12) plus CR suffix (1) = 13 42 start character match for Code 128, 42h = “B” FF termination string for second code 69 code identifier for Code 93 0012 C - Code 93 sample length (11) plus CR suffix (1) = 12 43 start character match for Code 93, 43h = “C” FF termination string for third code

Output Sequence Editor

Partial Sequence

If an output sequence operation is terminated before all your output sequence criteria are met, the bar code data acquired to that point is a “partial sequence.”

Scan Discard Partial Sequence to discard partial sequences when the output sequence operation is terminated before completion. Scan Transmit Partial Sequence to transmit partial sequences. (Any fields in the sequence where no data

match occurred will be skipped in the output.)

Require Output Sequence

When an output sequence is Required, all output data must conform to an edited sequence or the scanner will not transmit the output data to the host device. When it’s On/Not Required, the scanner will attempt to get the output data to conform to an edited sequence but, if it cannot, the scanner transmits all output data to the host device as is.

3 - 19

When the output sequence is Off, the bar code data is output to the host as the scanner decodes it. Default = Off.

Required

On/Not Required

*Off

* Off

Note: This selection is unavailable when the Multiple Symbols Selection is turned on.

Multiple Symbols

When this programming selection is turned On, it allows you to read multiple symbols with a single press of the scanner’s button. If you press and hold the button, aiming the scanner at a series of symbols, it reads unique symbols once, beeping (if turned on) for each read. The scanner attempts to find and decode new symbols as long as the button is pressed. When this

programming selection is turned Off, the scanner will only read the symbol closest to the aiming beam. Default = Off.

No Read

With No Read turned On, the scanner notifies you if a code cannot be read. If using an EZConfig Tool Scan Data Window (see page 10-3), an “NR” appears when a code cannot be read. If No Read is turned Off, the “NR” will not appear. Default = Off.

If you want a different notation than “NR,” for example, “Error,” or “Bad Code,” you can edit the output message (see Data

Formatting beginning on page 5-1). The hex code for the No Read symbol is 9C.

3 - 20

Video Reverse

Video Reverse Only

Video Reverse and Standard Bar

Codes

* Video Reverse Off

Upright:

Vertical, Top to Bottom:

(Rotate CW 90°)

Upside Down:

Vertical, Bottom to Top:

(Rotate CCW 90°)

Video Reverse is used to allow the scanner to read bar codes that are inverted. The Video Reverse Off bar code below is an example of this type of bar code. Scan Video Reverse Only to read only inverted bar codes. Scan Video Reverse and Stan- dard Bar Codes to read both types of codes.

Note: After scanning Video Reverse Only, menu bar codes cannot be read. You must scan Video Reverse Off or Video

Reverse and Standard Bar Codes in order to read menu bar codes.

Note: Images downloaded from the unit are not reversed. This is a setting for decoding only.

Working Orientation

Some bar codes are direction-sensitive. For example, KIX codes and OCR can misread when scanned sideways or upside down. Use the working orientation settings if your direction-sensitive codes will not usually be presented upright to the scanner.

Default = Upright.

3 - 21

3 - 22

* Upright

Vertical, Bottom to Top

Upside Down

Vertical, Top to Bottom

Data Editing

Prefix/Suffix Overview

When a bar code is scanned, additional information is sent to the host computer along with the bar code data. This group of bar code data and additional, user-defined data is called a “message string.” The selections in this section are used to build the user-defined data into the message string.

Prefix and Suffix characters are data characters that can be sent before and after scanned data. You can specify if they should be sent with all symbologies, or only with specific symbologies. The following illustration shows the breakdown of a message string:

Prefix

alpha numeric & control characters

Scanned Data

variable length1-11

Suffix

1-11 alpha numeric & control characters

Points to Keep In Mind

• It is not necessary to build a message string. The selections in this chapter are only used if you wish to alter the default settings. Default prefix = None. Default suffix = None.

• A prefix or suffix may be added or cleared from one symbology or all symbologies.

• You can add any prefix or suffix from the ASCII Conversion Chart (Code Page 1252), beginning on page A-3, plus Code I.D. and AIM I.D.

• You can string together several entries for several symbologies at one time.

• Enter prefixes and suffixes in the order in which you want them to appear on the output.

• When setting up for specific symbologies (as opposed to all symbologies), the specific symbology ID value counts as an added prefix or suffix character.

• The maximum size of a prefix or suffix configuration is 200 characters, which includes header information.

To Add a Prefix or Suffix:

Step 1. Scan the Add Prefix or Add Suffix symbol (page 4-2). Step 2. Determine the 2 digit Hex value from the Symbology Chart (included in the Symbology Charts beginning on page

A-1) for the symbology to which you want to apply the prefix or suffix. For example, for Code 128, Code ID is “j” and Hex ID is “6A”.

Step 3. Scan the 2 hex digits from the Programming Chart inside the back cover of this manual or scan 9, 9 for all

symbologies.

Step 4. Determine the hex value from the ASCII Conversion Chart (Code Page 1252), beginning on page A-3, for the prefix

or suffix you wish to enter.

Step 5. Scan the 2 digit hex value from the Programming Chart inside the back cover of this manual. Step 6. Repeat Steps 4 and 5 for every prefix or suffix character. Step 7. To add the Code I.D., scan 5, C, 8, 0.

To add AIM I.D., scan 5, C, 8, 1. To add a backslash (\), scan 5, C, 5, C.

Note: To add a backslash (\) as in Step 7, you must scan 5C twice – once to create the leading backslash and then to create

the backslash itself.

Step 8. Scan Save to exit and save, or scan Discard to exit without saving. Repeat Steps 1-6 to add a prefix or suffix for another symbology.

4 - 1

Example: Add a Tab Suffix to All Symbologies

Add CR Suffix

All Symbologies

Add Prefix

Clear One Prefix

Clear All Prefixes

Add Suffix

Step 1. Scan Add Suffix. Step 2. Scan 9, 9 from the Programming Chart inside the back cover of this manual to apply this suffix to all symbologies. Step 3. Scan 0, 9 from the Programming Chart inside the back cover of this manual. This corresponds with the hex value

for a horizontal tab, shown in the ASCII Conversion Chart (Code Page 1252), beginning on page A-3.

Scan Save, or scan Discard to exit without saving.

To Clear One or All Prefixes or Suffixes

You can clear a single prefix or suffix, or clear all prefixes/suffixes for a symbology. If you have been entering prefixes and suffixes for single symbologies, you can use Clear One Prefix (Suffix) to delete a specific character from a symbology. When you Clear All Prefixes (Suffixes), all the prefixes or suffixes for a symbology are deleted.

Step 1. Scan the Clear One Prefix or Clear One Suffix symbol. Step 2. Determine the 2 digit Hex value from the Symbology Chart (included in the Symbology Charts beginning on page

A-1) for the symbology from which you want to clear the prefix or suffix.

Step 3. Scan the 2 digit hex value from the Programming Chart inside the back cover of this manual or scan 9, 9 for all

symbologies.

Your change is automatically saved.

To Add a Carriage Return Suffix to All Symbologies

Scan the following bar code if you wish to add a carriage return suffix to all symbologies at once. This action first clears all current suffixes, then programs a carriage return suffix for all symbologies.

Prefix Selections

Suffix Selections

4 - 2

Function Code Transmit

Clear One Suffix

Clear All Suffixes

* Enable

Disable

* None

LRC Starts on 1st Character

LRC Starts on 2nd Character

CRC

When this selection is enabled and function codes are contained within the scanned data, the scanner transmits the function code to the terminal. Charts of these function codes are provided in Supported Interface Keys starting on page 9-3. When the

scanner is in keyboard wedge mode, the scan code is converted to a key code before it is transmitted. Default = Enable.

Communication Check Character

To enhance security, you can specify the transmission type of a check character; either LRC where the calculation starts on the first transmitted character, LRC where the calculation starts on the second transmitted character, or CRC.

Note: This option adds a check character to the bar code data for all symbologies. If you need to enable or disable check

characters for individual symbologies, see Symbologies beginning on page 7-1.

Scan the following bar code to set the communication check character type. Default = None.

4 - 3

Intercharacter, Interfunction, and

1 2345

Intercharacter Delay

Prefix Scanned Data Suffix

Intercharacter Delay

Delay Length

Character to Trigger Delay

Intermessage Delays

Some terminals drop information (characters) if data comes through too quickly. Intercharacter, interfunction, and intermessage delays slow the transmission of data, increasing data integrity.

Intercharacter Delay

An intercharacter delay of up to 5000 milliseconds (in 5ms increments) may be placed between the transmission of each character of scanned data. Scan the Intercharacter Delay bar code below, then scan the number of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.

To remove this delay, scan the Intercharacter Delay bar code, then set the number of delays to 0. Scan the Save bar code using the Programming Chart inside the back cover of this manual.

Note: Intercharacter delays are not supported in USB serial.

User Specified Intercharacter Delay

An intercharacter delay of up to 5000 milliseconds (in 5ms increments) may be placed after the transmission of a particular character of scanned data. Scan the Delay Length bar code below, then scan the number of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.

Next, scan the Character to Trigger Delay bar code, then the 2-digit hex value for the ASCII character that will trigger the delay ASCII Conversion Chart (Code Page 1252), beginning on page A-3.

To remove this delay, scan the Delay Length bar code, and set the number of delays to 0. Scan the Save bar code using the Programming Chart inside the back cover of this manual.

4 - 4

Interfunction Delay

Interfunction Delays

Prefix Scanned Data Suffix

1 2345STX HT CR LF

Interfunction Delay

2nd Scan Transmission1st Scan Transmission

Intermessage Delay

An interfunction delay of up to 5000 milliseconds (in 5ms increments) may be placed between the transmission of each control character in the message string. Scan the Interfunction Delay bar code below, then scan the number of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.

To remove this delay, scan the Interfunction Delay bar code, then set the number of delays to 0. Scan the Save bar code using the Programming Chart inside the back cover of this manual.

Intermessage Delay

An intermessage delay of up to 5000 milliseconds (in 5ms increments) may be placed between each scan transmission. Scan the Intermessage Delay bar code below, then scan the number of 5ms delays, and the Save bar code using the

Programming Chart inside the back cover of this manual.

To remove this delay, scan the Intermessage Delay bar code, then set the number of delays to 0. Scan the Save bar code using the Programming Chart inside the back cover of this manual.

4 - 5

4 - 6

* Default Data Format

Data Formatting

Data Format Editor Introduction

You may use the Data Format Editor to change the scanner’s output. For example, you can use the Data Format Editor to insert characters at certain points in bar code data as it is scanned. The selections in the following pages are used only if you wish to alter the output. Default Data Format setting = None.

Normally, when you scan a bar code, it is output automatically. However, when you create a format, you must use a “send” command (see Send Commands on page 5-3) within the format program to output data.

Multiple formats may be programmed into the scanner. They are stacked in the order in which they are entered. However, the following list presents the order in which formats are applied:

1. Specific Terminal ID, Actual Code ID, Actual Length

2. Specific Terminal ID, Actual Code ID, Universal Length

3. Specific Terminal ID, Universal Code ID, Actual Length

4. Specific Terminal ID, Universal Code ID, Universal Length

5. Universal Terminal ID, Actual Code ID, Actual Length

6. Universal Terminal ID, Actual Code ID, Universal Length

7. Universal Terminal ID, Universal Code ID, Actual Length

8. Universal Terminal ID, Universal Code ID, Universal Length

The maximum size of a data format configuration is 2000 bytes, which includes header information. If a bar code is read that fails the first data format, the next data format, if there is one, will be used on the bar code data. If there

is no other data format, the raw data is output. If you have changed data format settings, and wish to clear all formats and return to the factory defaults, scan the Default Data

Format code below.

Add a Data Format

Step 1. Scan the Enter Data Format symbol (page 5-2). Step 2. Select Primary/Alternate Format

Determine if this will be your primary data format, or one of 3 alternate formats. This allows you to save a total of 4 different data formats. To program your primary format, scan 0 using the Programming Chart inside the back cover of this manual. If you are programming an alternate format, scan 1, 2, or 3, depending on which alternate format you are programming. (See "Primary/Alternate Data Formats" on page 5-12 for further information.)

Step 3. Terminal Type

Refer to Terminal ID Table (page 5-3) and locate the Terminal ID number for your PC. Scan three numeric bar codes on the inside back cover to program the scanner for your terminal ID (you must enter 3 digits). For example, scan 0 0 3 for an AT wedge.

Note: 099 indicates all terminal types.

Step 4. Code I.D.

In the Symbology Charts beginning on page A-1, find the symbology to which you want to apply the data format. Locate the Hex value for that symbology and scan the 2 digit hex value from the Programming Chart inside the back cover of this manual.

If you wish to create a data format for all symbologies, with the exception of some specific symbologies, refer to B8 (page 5-11).

If you are creating a data format for Batch Mode Quantity, use 35 for the Code I.D.

Note: 99 indicates all symbologies.

5 - 1

Step 5. Length

Enter Data Format

Save

Discard

Clear One Data Format

Clear All Data Formats

Save

Discard

Specify what length (up to 9999 characters) of data will be acceptable for this symbology. Scan the four digit data length from the Programming Chart inside the back cover of this manual. For example, 50 characters is entered as 0050.

Note: 9999 indicates all lengths.

Step 6. Editor Commands

Refer to Data Format Editor Commands (page 5-3). Scan the symbols that represent the command you want to enter.

Step 7. Scan Save to save your data format, or Discard to exit without saving your changes.

Other Programming Selections

Clear One Data Format

This deletes one data format for one symbology. If you are clearing the primary format, scan 0 from the Programming

Chart inside the back cover of this manual. If you are clearing an alternate format, scan 1, 2, or 3, depending on the

format you are clearing. Scan the Terminal Type and Code I.D. (see Symbology Charts on page A-1), and the bar code data length for the specific data format that you want to delete. All other formats remain unaffected.

Clear all Data Formats

This clears all data formats.

Save to exit and save your data format changes. Discard to exit without saving any data format changes.

5 - 2

Terminal ID Table

Ter minal Model(s) Terminal ID

USB PC keyboard (HID)

Mac Keyboard PC Keyboard (Japanese) Serial (COM driver required) HID POS USB SurePOS Handheld USB SurePOS Tabletop

Serial RS232 TTL

RS232 True RS485 (IBM-HHBCR 1+2, 46xx)

Keyboard PS2 compatibles

AT compatibles

124 125 134 130 131 128 129 000 000 051 003 002

Data Format Editor Commands

When working with the Data Format Editor, a virtual cursor is moved along your input data string. The following commands are used to both move this cursor to different positions, and to select, replace, and insert data into the final output.

Send Commands

Send all characters

F1 Include in the output message all of the characters from the input message, starting from current cursor position,

followed by an insert character. Syntax = F1xx where xx stands for the insert character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

Send a number of characters

F2 Include in the output message a number of characters followed by an insert character. Start from the current cursor

position and continue for “nn” characters or through the last character in the input message, followed by character “xx.” Syntax = F2nnxx where nn stands for the numeric value (00-99) for the number of characters, and xx stands for the insert character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

F2 Example: Send a number of characters

Send the first 10 characters from the bar code above, followed by a carriage return. Command string: F2100D F2 is the “Send a number of characters” command 10 is the number of characters to send 0D is the hex value for a CR The data is output as: 1234567890

F2 and F1 Example: Split characters into 2 lines

Send the first 10 characters from the bar code above, followed by a carriage return, followed by the rest of the characters.

Command string: F2100DF10D F2 is the “Send a number of characters” command 10 is the number of characters to send for the first line 0D is the hex value for a CR

5 - 3

F1 is the “Send all characters” command 0D is the hex value for a CR The data is output as: 1234567890

ABCDEFGHIJ <CR>

Send all characters up to a particular character

F3 Include in the output message all characters from the input message, starting with the character at the current cursor

position and continuing to, but not including, the search character “ss,” followed by an insert character. The cursor is moved forward to the “ss” character. Syntax = F3ssxx where ss stands for the search character’s hex value for its ASCII code, and xx stands for the insert character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

F3 Example: Send all characters up to a particular character

Using the bar code above, send all characters up to but not including “D,” followed by a carriage return. Command string: F3440D F3 is the “Send all characters up to a particular character” command 44 is the hex value for a 'D” 0D is the hex value for a CR The data is output as: 1234567890ABC

<CR>

Send all characters up to a string

B9 Include in the output message all characters from the input message, starting with the character at the current cursor

position and continuing to, but not including, the search string “s...s.” The cursor is moved forward to the beginning of the “s...s” string. Syntax = B9nnnns...s where nnnn stands for the length of the string, and s...s stands for the string to be matched. The string is made up of hex values for the characters in the string. Refer to the ASCII Conversion Chart

(Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

B9 Example: Send all characters up to a defined string

Using the bar code above, send all characters up to but not including “AB.” Command string: B900024142 B9 is the “Send all characters up to a string” command 0002 is the length of the string (2 characters) 41 is the hex value for A 42 is the hex value for B The data is output as: 1234567890

Send all but the last characters

E9 Include in the output message all but the last “nn” characters, starting from the current cursor position. The cursor is

moved forward to one position past the last input message character included. Syntax = E9nn where nn stands for the numeric value (00-99) for the number of characters that will not be sent at the end of the message.

Insert a character multiple times

F4 Send “xx” character “nn” times in the output message, leaving the cursor in the current position. Syntax = F4xxnn where

xx stands for the insert character’s hex value for its ASCII code, and nn is the numeric value (00-99) for the number of times it should be sent. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

5 - 4

E9 and F4 Example: Send all but the last characters, followed by 2 tabs

Send all characters except for the last 8 from the bar code above, followed by 2 tabs. Command string: E908F40902 E9 is the “Send all but the last characters” command 08 is the number of characters at the end to ignore F4 is the “Insert a character multiple times” command 09 is the hex value for a horizontal tab 02 is the number of times the tab character is sent The data is output as: 1234567890AB <tab><tab>

Insert a string

BA Send “ss” string of “nn” length in the output message, leaving the cursor in the current position. Syntax = BAnnnns...s

where nnnn stands for the length of the string, and s...s stands for the string. The string is made up of hex values for the characters in the string. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

B9 and BA Example: Look for the string “AB” and insert 2 asterisks (**)

Using the bar code above, send all characters up to but not including “AB.” Insert 2 asterisks at that point, and send the rest of the data with a carriage return after.

Command string: B900024142BA00022A2AF10D B9 is the “Send all characters up to a string” command 0002 is the length of the string (2 characters) 41 is the hex value for A 42 is the hex value for B BA is the “Insert a string” command 0002 is the length of the string to be added (2 characters) 2A is the hex value for an asterisk (*) 2A is the hex value for an asterisk (*) F1 is the “Send all characters” command 0D is the hex value for a CR The data is output as: 1234567890**ABCDEFGHIJ

<CR>

Insert symbology name

B3 Insert the name of the bar code’s symbology in the output message, without moving the cursor. Only symbologies with

a Honeywell ID are included (see Symbology Charts on page A-1). Refer to the ASCII Conversion Chart (Code Page

1252), beginning on page A-3 for decimal, hex and character codes.

Insert bar code length

B4 Insert the bar code’s length in the output message, without moving the cursor. The length is expressed as a numeric

string and does not include leading zeroes.

5 - 5

B3 and B4 Example: Insert the symbology name and length

Send the symbology name and length before the bar code data from the bar code above. Break up these insertions with spaces. End with a carriage return.

Command string: B3F42001B4F42001F10D B3 is the “Insert symbology name” command F4 is the “Insert a character multiple times” command 20 is the hex value for a space 01 is the number of times the space character is sent B4 is the “Insert bar code length” command F4 is the “Insert a character multiple times” command 20 is the hex value for a space 01 is the number of times the space character is sent F1 is the “Send all characters” command 0D is the hex value for a CR The data is output as: Code128 20 1234567890ABCDEFGHIJ

<CR>

Insert key strokes

B5 Insert a key stroke or combination of key strokes. Key strokes are dependent on your keyboard (see Unicode Key Maps

on page A-10). Any key can be inserted, including arrows and functions. Syntax = B5xxssnn where xx is the number of keys pressed (without key modifiers), ss is the key modifier from the table below, and nn is the key number from the

Unicode Key Maps, page A-10.

Key Modifiers

No Key Modifier 00 Shift Left 01 Shift Right 02 Alt Left 04 Alt Right 08 Control Left 10 Control Right 20

For example, B501021F inserts an “A” on a 104 key, U.S. style keyboard. B5 = the command, 01 = number of keys pressed (without the key modifier), 02 is the key modifier for Shift Right, and 1F is the “a” key. If a lower case “a” were to be inserted, B501001F would be entered.

If there are three keystrokes, the syntax would change from B5xxssnn for one keystroke to B5xxssnnssnnssnn. An example that would insert "abc" is as follows: B503001F00320030F833.

Note: Key modifiers can be added together when needed. Example: Control Left+Shift Left = 11.

Move Commands

Move the cursor forward a number of characters

F5 Move the cursor ahead “nn” characters from current cursor position.

Syntax = F5nn where nn is the numeric value (00-99) for the number of characters the cursor should be moved ahead.

F5 Example: Move the cursor forward and send the data

5 - 6

Move the cursor forward 3 characters, then send the rest of the bar code data from the bar code above. End with a carriage return.

Command string: F503F10D F5 is the “Move the cursor forward a number of characters” command 03 is the number of characters to move the cursor F1 is the “Send all characters” command 0D is the hex value for a CR The data is output as: 4567890ABCDEFGHIJ

<CR>

Move the cursor backward a number of characters

F6 Move the cursor back “nn” characters from current cursor position.

Syntax = F6nn where nn is the numeric value (00-99) for the number of characters the cursor should be moved back.

Move the cursor to the beginning

F7 Move the cursor to the first character in the input message. Syntax = F7.

FE and F7 Example: Manipulate bar codes that begin with a 1

Search for bar codes that begin with a 1. If a bar code matches, move the cursor back to the beginning of the data and send 6 characters followed by a carriage return. Using the bar code above:

Command string: FE31F7F2060D FE is the “Compare characters” command 31 is the hex value for 1 F7 is the “Move the cursor to the beginning” command F2 is the “Send a number of characters” command 06 is the number of characters to send 0D is the hex value for a CR The data is output as: 123456

<CR>

Move the cursor to the end

EA Move the cursor to the last character in the input message. Syntax = EA.

Search Commands

Search forward for a character

F8 Search the input message forward for “xx” character from the current cursor position, leaving the cursor pointing to the

“xx” character. Syntax = F8xx where xx stands for the search character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

F8 Example: Send bar code data that starts after a particular character

Search for the letter “D” in bar codes and send all the data that follows, including the “D.” Using the bar code above: Command string: F844F10D F8 is the “Search forward for a character” command 44 is the hex value for “D”

5 - 7

F1 is the “Send all characters” command 0D is the hex value for a CR The data is output as: DEFGHIJ

<CR>

Search backward for a character

F9 Search the input message backward for “xx” character from the current cursor position, leaving the cursor pointing to

the “xx” character. Syntax = F9xx where xx stands for the search character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

Search forward for a string

B0 Search forward for “s” string from the current cursor position, leaving cursor pointing to “s” string. Syntax = B0nnnnS

where nnnn is the string length (up to 9999), and S consists of the ASCII hex value of each character in the match string. For example, B0000454657374 will search forward for the first occurrence of the 4 character string “Test.” Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

B0 Example: Send bar code data that starts after a string of characters

Search for the letters “FGH” in bar codes and send all the data that follows, including “FGH.” Using the bar code above:

Command string: B00003464748F10D B0 is the “Search forward for a string” command 0003 is the string length (3 characters) 46 is the hex value for “F” 47 is the hex value for “G” 48 is the hex value for “H” F1 is the “Send all characters” command 0D is the hex value for a CR The data is output as: FGHIJ

<CR>

Search backward for a string

B1 Search backward for “s” string from the current cursor position, leaving cursor pointing to “s” string. Syntax = B1nnnnS

where nnnn is the string length (up to 9999), and S consists of the ASCII hex value of each character in the match string. For example, B1000454657374 will search backward for the first occurrence of the 4 character string “Test.” Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

Search forward for a non-matching character

E6 Search the input message forward for the first non-“xx” character from the current cursor position, leaving the cursor

pointing to the non-“xx” character. Syntax = E6xx where xx stands for the search character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

E6 Example: Remove zeroes at the beginning of bar code data

5 - 8

This example shows a bar code that has been zero filled. You may want to ignore the zeroes and send all the data that follows. E6 searches forward for the first character that is not zero, then sends all the data after, followed by a carriage return. Using the bar code above:

Command string: E630F10D E6 is the “Search forward for a non-matching character” command

30 is the hex value for 0 F1 is the “Send all characters” command 0D is the hex value for a CR The data is output as: 37692

<CR>

Search backward for a non-matching character

E7 Search the input message backward for the first non-“xx” character from the current cursor position, leaving the cursor

pointing to the non-“xx” character. Syntax = E7xx where xx stands for the search character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

Miscellaneous Commands

Suppress characters

FB Suppress all occurrences of up to 15 different characters, starting at the current cursor position, as the cursor is

advanced by other commands. When the FC command is encountered, the suppress function is terminated. The cursor is not moved by the FB command. Syntax = FBnnxxyy . .zz where nn is a count of the number of suppressed characters in the list, and xxyy .. zz is the list of characters to be suppressed.

FB Example: Remove spaces in bar code data

This example shows a bar code that has spaces in the data. You may want to remove the spaces before sending the data. Using the bar code above:

Command string: FB0120F10D FB is the “Suppress characters” command 01 is the number of character types to be suppressed 20 is the hex value for a space F1 is the “Send all characters” command 0D is the hex value for a CR The data is output as: 34567890

<CR>

Stop suppressing characters

FC Disables suppress filter and clear all suppressed characters. Syntax = FC.

Replace characters

E4 Replaces up to 15 characters in the output message, without moving the cursor. Replacement continues until the E5

command is encountered. Syntax = E4nnxx1xx2yy1yy2...zz1zz2 where nn is the total count of the number of characters in the list (characters to be replaced plus replacement characters); xx replacement characters, continuing through zz

E4 Example: Replace zeroes with CRs in bar code data

and zz2.

defines characters to be replaced and xx2 defines

If the bar code has characters that the host application does not want included, you can use the E4 command to replace those characters with something else. In this example, you will replace the zeroes in the bar code above with carriage returns.

Command string: E402300DF10D E4 is the “Replace characters” command

5 - 9

02 is the total count of characters to be replaced, plus the replacement characters (0 is replaced by CR, so total characters = 2)

30 is the hex value for 0 0D is the hex value for a CR (the character that will replace the 0) F1 is the “Send all characters” command 0D is the hex value for a CR The data is output as: 1234

5678 ABC <CR>

Stop replacing characters

E5 Terminates character replacement. Syntax = E5.

Compare characters

FE Compare the character in the current cursor position to the character “xx.” If characters are equal, move the cursor

forward one position. Syntax = FExx where xx stands for the comparison character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

Compare string

B2 Compare the string in the input message to the string “s.” If the strings are equal, move the cursor forward past the end

of the string. Syntax = B2nnnnS where nnnn is the string length (up to 9999), and S consists of the ASCII hex value of each character in the match string. For example, B2000454657374 will compare the string at the current cursor position with the 4 character string “Test.” Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page A-3 for decimal, hex and character codes.

Check for a number

EC Check to make sure there is an ASCII number at the current cursor position. The format is aborted if the character is

not numeric.

EC Example: Only output the data if the bar code begins with a number

If you want only data from bar codes that begin with a number, you can use EC to check for the number. Command string: ECF10D EC is the “Check for a number” command F1 is the “Send all characters” command 0D is the hex value for a CR

If this bar code is read, the next data format, if there is one, will be used on the data. If there

is no other format, the format fails and the raw data is output as AB1234.

If this bar code is read: the data is output as:

1234AB <CR>

Check for non-numeric character

ED Check to make sure there is a non-numeric ASCII character at the current cursor position. The format is aborted if the

character is numeric.

ED Example: Only output the data if the bar code begins with a letter

If you want only data from bar codes that begin with a letter, you can use ED to check for the letter. Command string: EDF10D ED is the “Check for a non-numeric character” command

5 - 10

F1 is the “Send all characters” command

Data Formatter Off

0D is the hex value for a CR

If this bar code is read, the next data format, if there is one, will be used on this data. If there

is no other format, the format fails and the raw data is output as 1234AB.

If this bar code is read: the data is output as: AB1234

<CR>

Insert a delay

EF Inserts a delay of up to 49,995 milliseconds (in multiples of 5), starting from the current cursor position. Syntax = EFnnnn

where nnnn stands for the delay in 5ms increments, up to 9999. This command can only be used with keyboard emulations.

Discard Data

B8 Discards types of data. For example, you may want to discard Code 128 bar codes that begin with the letter A. In step

4 (page 5-1), select 6A (for Code 128), and in step 5, select 9999 (for all lengths). Enter FE41B8 to compare and discard Code 128 bar codes that begin with the letter A. Syntax = B8.

Note: The B8 command must be entered after all other commands.

The Data Format must be Required (see page 5-11) in order for the B8 command to work. If Data Format is On, but Not Required (page 5-12), bar code data that meets the B8 format is scanned and output as usual. Because the data format needs to be On and Required (page 5-12) for the B8 command, you must input data formats for all bar codes you wish to discard as well as all bar codes you wish to output. Other data format settings impact the B8 command. If Data Format Non-Match Error Tone is On (page 5-12), the scanner emits an error tone. If Data format Non-Match Error Tone is Off, the code is disabled for reading and no tone is sounded.

Data Formatter

When Data Formatter is turned Off, the bar code data is output to the host as read, including prefixes and suffixes.

You may wish to require the data to conform to a data format you have created and saved. The following settings can be applied to your data format:

Data Formatter On, Not Required, Keep Prefix/Suffix

Scanned data is modified according to your data format, and prefixes and suffixes are transmitted.

Data Formatter On, Not Required, Drop Prefix/Suffix

Scanned data is modified according to your data format. If a data format is found for a particular symbol, those prefixes and suffixes are not transmitted. If a data format is not found for that symbol, the prefixes and suffixes are transmitted.

Data Format Required, Keep Prefix/Suffix

Scanned data is modified according to your data format, and prefixes and suffixes are transmitted. Any data that does not match your data format requirements generates an error tone and the data in that bar code is not transmitted. If you wish to process this type of bar code without generating an error tone, see Data Format Non-Match Error Tone.

Data Format Required, Drop Prefix/Suffix

Scanned data is modified according to your data format. If a data format is found for a particular symbol, those prefixes and suffixes are not transmitted. Any data that does not match your data format requirements generates an error tone. If you wish to process this type of bar code without generating an error tone, see Data Format Non-Match Error Tone.

5 - 11

Choose one of the following options. Default = Data Formatter On, Not Required, Keep Prefix/Suffix.

* Data Formatter On,

Not Required,

Keep Prefix/Suffix

Data Formatter On,

Not Required,

Drop Prefix/Suffix

Data Format Required,

Keep Prefix/Suffix

Data Format Required,

Drop Prefix/Suffix

* Data Format Non-Match Error

Tone On

Data Format Non-Match

Error Tone Off

Primary Data Format

Data Format Non-Match Error Tone

When a bar code is encountered that doesn’t match your required data format, the scanner normally generates an error tone. However, you may want to continue scanning bar codes without hearing the error tone. If you scan the Data Format Non-Match Error Tone Off bar code, data that doesn’t conform to your data format is not transmitted, and no error tone will sound. If you wish to hear the error tone when a non-matching bar code is found, scan the Data Format Non-Match Error

Tone On bar code. Default = Data Format Non-Match Error Tone On.

Primary/Alternate Data Formats

You can save up to four data formats, and switch between these formats. Your primary data format is saved under 0. Your other three formats are saved under 1, 2, and 3. To set your device to use one of these formats, scan one of the bar codes below.

5 - 12

Single Scan Data Format Change

Data Format 1

Data Format 2

Data Format 3

Single Scan-Primary

Data Format

Single Scan-Data Format 1

Single Scan-Data Format 2

Single Scan-Data Format 3

You can also switch between data formats for a single scan. The next bar code is scanned using an alternate data format, then reverts to the format you have selected above (either Primary, 1, 2, or 3).

For example, you may have set your device to the data format you saved as Data Format 3. You can switch to Data Format 1 for a single button press by scanning the Single Scan-Data Format 1 bar code below. The next bar code that is scanned

uses Data Format 1, then reverts back to Data Format 3.

5 - 13

5 - 14

* External Trigger Control Off

External Trigger Control On

* External Trigger Polarity High

External Trigger Polarity Low

External Input / Output

The Vuquest 3310 scanner can be integrated with a variety of third party devices. The External Trigger and Illumination Controls can be configured using the bar codes in this chapter. These controls offer simple trigger signals. An External I/O license and cable are required; contact the nearest technical support office for further information (see Technical Assistance beginning on page 14-1).

External Input

External Trigger Control

The External Trigger Control allows object detection from the third party device to trigger the scanner. If you want to use the third party device object detection, scan the External Trigger Control On bar code. If you want to use the 3310 scan-

ner object detection, scan the External Trigger Control Off bar code. Default = External Trigger Control Off.

External Trigger Polarity

External Trigger Polarity has two states, High and Low. A digital high polarity is 1 and a digital low polarity is 0. If the third party device triggers on low polarity, 0, scan the External Trigger Polarity Low bar code. Default = External Trigger Polar-

ity High.

6 - 1

External Trigger Parameters

Fairchild

NC7SZ12 5L6X

Tri-State Buffer

CMOS Input Level

10K

Resistor

+3.3V Scanner

Scanner

Controller

Please see External

Trigger Parameters

for voltage levels

Pin 14

3310 Scanner

Host/Register

Data Connector

Pin 6

Customer Device

Power Link

(Not on al l cables)

+3.3V to +5.0V

Controller

Standard Trigger Input Connection

Fairchild

NC7SZ12 5L6X

Tri-State Buffer

CMOS Input Level

10K

Resistor

+3.3V Scanner

Scanner

Controller

Please see External

Trigger Parameters

for voltage levels

Pin 14

3310 Scanner

Host/Register

Data Connector

Pin 6

Customer Device

Power Link

(Not on al l cables)

Customer

VCC

Controller

Example of Trigger Input Connection Using an Opto-Isolator

+5.2V

Adapter

N.C.

+5.2V Scanner P ower

+5.2V

Push-pull

logic gate

or similar

type driver .

Push-pull

logic gate

or similar

type driver.

Opto-Isolator

Scanner Cable with

External Trigger and

Lamp Signals

Scanner Cable with

External Trigger and

Lamp Signals

Note: All connections for power and ground and communication not

shown for clarity. Additional details of the user connector can be

found in the 3310 Vuquest User’s Guide.

Green

Black

Green

Black

Customer

Ground

Customer

Ground

Customer

Ground

+5.2V

Adapter

+5.2V Scanner P ower

Pin 10

+5.2V

GND

User Connector (15 pin

HD-22 pin size).

User Connector (15 pin

HD-22 pin size).

Note: All connections for power and ground and communication not

shown for clarity. Additional details of the user connector can be

found in the 3310 Vuquest User’s Guide.

Absolute Maximum

The input is protected by an input protection diode on the ground side. The input voltage can be below ground provided it is current limited below the value shown on the next line of this table.

Input protection diode current. The limiting factor on current is the dissipation in the 1K, 0402 resistor (not the gate diode limit).

Maximum Input Voltage

Maximum Input Current

Low Value: -0.5 Volts High Value: +5.5 Volts

Low Value: -6 Milliamperes

Parameter Values

Input Resistance to Ground

Maximum Input Low Voltage Logical Low Level High Value: 0.8 Volts Value does not include harness drops or margin for noise. Input High Voltage Threshold Low Value: 2.6 Volts Value does not include harness drops or margin for noise.

Low Value: 9.7 K Nominal Value: 10.0 K High Value: 10.3 K

Pull down resistor loading.

External Trigger Schematic

6 - 2

External Output

* External Illumination Control Off

External Illumination Control On

External Illumination Control

The External Illumination Control allows the third party device to use external illumination, supplemental to the illumination from the scanner. If the illumination will be provided by the third party device, scan the External Illumination Control On

bar code. Default = External Illumination Control Off.

External Illumination Parameters

Absolute Maximum

Maximum voltage on output pin with scanner powered down.

Maximum current driven into pin from external source.

Parameter Values

Output Low Voltage Iout = 500uA

Output Low Voltage Iout = 1mA

Output Low Voltage Iout = 4mA

Output Low Voltage Iout = 6mA

Output High Voltage Iout = -500uA

Output High Voltage Iout = -1mA

Output High Voltage Iout = -4mA

Output High Voltage Iout = -6mA

High Value: 6 Volts

High Value: 5mA Maximum current limited by series resistor dissipation.

High Value: 0.6 Volts

High Value: 0.7 Volts

High Value: 1.0 Volts

High Value: 1.2 Volts

Low Value: 3.6 Volts

Low Value: 3.5 Volts

Low Value: 3.3 Volts

Low Value: 3.1 Volts

This allows a pull-up to be connected to this line provided it does not exceed the current on the next line of this table while operating.

Internal one-hundred ohm series resistor drop included.

6 - 3

External Illumination Schematic

Standard Lamp Connection

On-Semic onductor

MC74VHC1GT125DF1G

Tri-state buf fer or equivalent.

10K

Resistor

100 Ohm

0603 Resistor

+4.9V to

+5.2V

Scanner

Controller

Pin 15

3310 Scanner

Pin 6

Customer Device

Power Link

(Not on all cables)

Lamp Connection Using Opto-Isolation Example

Adapter

Customer

Ground

+5.2V

Scanner

Power

+5.2V

Opto-Isolator

Scanner Cable wit h

External Trigger and

Lamp Signals

Note: All connections for power, ground and scanner signals not shown for clarity.

Yellow Wire

Pin 11

To Customer

PC/Register

data connector

Custom er

Power Supply

Black Wire

Lamp

Driver/Switch

Customer

Ground

On-Semic onductor

MC74VHC1GT125DF1G

Tri-state buf fer or equivalent.

10K

Resistor

100 Ohm

0603 Resistor

+4.9V to

+5.2V

Scanner

Controller

Pin 15

3310 Scanner

Pin 6

Customer Device

Power Link

(Not on all cables)

Adapter

Customer

Ground

+5.2V

Scanner

Power

+5.2V

Scanner Cable wit h

External Trigger and

Lamp Signals

Yellow Wire

Pin 11

To Customer

PC/Register

data connector

Black Wire

Lamp

Driver/Switch

Customer

Ground

Please see External Illumination Parameters

for signal level informati on.

Note: All c onnections for power and

ground and communication not s hown for

clarity. Additi onal details of the us er

connector can be found in the

3310 User’s Guide.

User Con nect or (15 pin HD-2 2

pin size).

Please see External Illumination Parameters

for signal level informati on.

Note: All connections for power and

ground and communication not s hown for

clarity. Additi onal details of the us er

connector can be found in the

3310 User’s Guide.

6 - 4

All Symbologies On

All Symbologies Off

Symbologies

This programming section contains the following menu selections. Refer to Chapter 11 for settings and defaults.

• All Symbologies • Interleaved 2 of 5

• Aztec Code • Korea Post

• China Post (Hong Kong 2 of 5) • Matrix 2 of 5

• Chinese Sensible (Han Xin) Code • MaxiCode

• Codabar • MicroPDF417

• Codablock A • MSI

• Codablock F • NEC 2 of 5

• Code 11 • Postal Codes - 2D

• Code 128 • Postal Codes - Linear

• Code 32 Pharmaceutical (PARAF) • PDF417

• Code 39 • GS1 DataBar Omnidirectional

• Code 93 • QR Code

• Data Matrix • Straight 2 of 5 IATA (two-bar start/stop)

• EAN/JAN-13 • Straight 2 of 5 Industrial (three-bar start/stop)

• EAN/JAN-8 • TCIF Linked Code 39 (TLC39)

• GS1 Composite Codes • Telepen

• GS1 DataBar Expanded • Trioptic Code

• GS1 DataBar Limited • UPC-A

• GS1 DataBar Omnidirectional • UPC-A/EAN-13 with Extended Coupon Code

• GS1 Emulation • UPC-E0

•GS1-128 •UPC-E1

All Symbologies

If you want to decode all the symbologies allowable for your scanner, scan the All Symbologies On code. If on the other hand, you want to decode only a particular symbology, scan All Symbologies Off followed by the On symbol for that particular sym-

bology.

Note: When All Symbologies On is scanned, 2D Postal Codes are not enabled. 2D Postal Codes must be enabled separately.

Message Length Description

You are able to set the valid reading length of some of the bar code symbologies. If the data length of the scanned bar code doesn’t match the valid reading length, the scanner will issue an error tone. You may wish to set the same value for minimum and maximum length to force the scanner to read fixed length bar code data. This helps reduce the chances of a misread.

EXAMPLE: Decode only those bar codes with a count of 9-20 characters.

Min. length = 09Max. length = 20

7 - 1

EXAMPLE: Decode only those bar codes with a count of 15 characters.

* On

Off

Transmit

* Don’t Transmit

* No Check Character

For a value other than the minimum and maximum message length defaults, scan the bar codes included in the explanation of the symbology, then scan the digit value of the message length and Save bar codes on the Programming Chart inside the back cover of this manual. The minimum and maximum lengths and the defaults are included with the respective symbologies.

Min. length = 15Max. length = 15

Codabar

Codabar On/Off

Codabar Start/ Stop Characters

Start/Stop characters identify the leading and trailing ends of the bar code. You may either transmit, or not transmit Start/ Stop characters. Default = Don’t Transmit.

Codabar Check Character

Codabar check characters are created using different “modulos.” You can program the scanner to read only Codabar bar codes with Modulo 16 check characters. Default = No Check Character.

No Check Character indicates that the scanner reads and transmits bar code data with or without a check character. When Check Character is set to Validate and Transmit, the scanner will only read Codabar bar codes printed with a check

character, and will transmit this character at the end of the scanned data. When Check Character is set to Validate, but Don’t Transmit, the unit will only read Codabar bar codes printed with a

check character, but will not transmit the check character with the scanned data.

7 - 2

Codabar Concatenation

Validate Modulo 16, but

Don’t Transmit

Validate Modulo 16

and Transmit

* Off

Require

Minimum Message Length

Maximum Message Length

Codabar supports symbol concatenation. When you enable concatenation, the scanner looks for a Codabar symbol having a “D” start character, adjacent to a symbol having a “D” stop character. In this case the two messages are concatenated into one with the “D” characters omitted.

A12 3 4D

D5 6 7 8A

Select Require to prevent the scanner from decoding a single “D” Codabar symbol without its companion. This selection has no effect on Codabar symbols without Stop/Start D characters.

Codabar Message Length

Scan the bar codes below to change the message length. Refer to Message Length Description (page 7-1) for additional information. Minimum and Maximum lengths = 2-60. Minimum Default = 4, Maximum Default = 60.

7 - 3

Code 39

* On

Off

Transmit

* Don’t Transmit

* No Check Character

Validate, but Don’t Transmit

Validate and Transmit

< Default All Code 39 Settings >

Code 39 On/Off

Code 39 Start/ Stop Characters

Start/Stop characters identify the leading and trailing ends of the bar code. You may either transmit, or not transmit Start/ Stop characters. Default = Don’t Transmit.

Code 39 Check Character

No Check Character indicates that the scanner reads and transmits bar code data with or without a check character. When Check Character is set to Validate, but Don’t Transmit, the unit only reads Code 39 bar codes printed with a check

character, but will not transmit the check character with the scanned data. When Check Character is set to Validate and Transmit, the scanner only reads Code 39 bar codes printed with a check

character, and will transmit this character at the end of the scanned data. Default = No Check Character.

7 - 4

Code 39 Message Length

Minimum Message Length

Maximum Message Length

* Off

Scan the bar codes below to change the message length. Refer to Message Length Description (page 7-1) for additional information. Minimum and Maximum lengths = 0-48. Minimum Default = 0, Maximum Default = 48.

Code 39 Append

This function allows the scanner to append the data from several Code 39 bar codes together before transmitting them to the host computer. When the scanner encounters a Code 39 bar code with the append trigger character(s), it buffers Code 39 bar codes until it reads a Code 39 bar code that does not have the append trigger. The data is then transmitted in the

order in which the bar codes were read (FIFO). Default = Off.

Code 32 Pharmaceutical (PARAF)

Code 32 Pharmaceutical is a form of the Code 39 symbology used by Italian pharmacies. This symbology is also known as PA RA F.

Note: Trioptic Code (page 7-32) must be turned off while scanning Code 32 Pharmaceutical codes.

7 - 5

Full ASCII

Full ASCII On

* Full ASCII Off

Code 39 Code Page

If Full ASCII Code 39 decoding is enabled, certain character pairs within the bar code symbol will be interpreted as a single character. For example: $V will be decoded as the ASCII character SYN, and /C will be decoded as the ASCII character #. Default = Off.

NUL %U DLE $P SOH $A STX $B ETX $C EOT $D ENQ $E ACK $F BEL $G BS $H HT $I LF $J VT $K FF $L CR $M SO $N SI $O

DC1 $Q !/A 11 AA QQ a+Aq+Q DC2 $R “/B 22BBRRb+Br+R DC3 $S #/C 33CCSSc+Cs+S DC4 $T $/D 44 DD TT d+Dt+T NAK $U %/E 55 EE UU e+Eu+U SYN $V &/F 66 FF VV f+Fv+V ETB $W ‘/G77GGWWg+Gw+W CAN $X (/H 88HHXXh+Hx+X EM $Y )/I 99IIYYi+Iy+Y SUB $Z */J :/ZJJZZ j+Jz+Z ESC %A +/K ;%FKK[%Kk+K{%P FS %B ,/L <%GLL\%Ll+L|%Q GS %C -- =%HMM ]%Mm+M}%R RS %D .. >%INN^%Nn+N~%S US %E //O ?%JOO_%Oo+ODEL %T

SP SPACE

00@%VPP‘%Wp+P

Character pairs /M and /N decode as a minus sign and period respectively. Character pairs /P through /Y decode as 0 through 9.

Code 39 Code Page

Code pages define the mapping of character codes to characters. If the data received does not display with the proper characters, it may be because the bar code being scanned was created using a code page that is different from the one the host program is expecting. If this is the case, scan the bar code below, select the code page with which the bar codes were created (see ISO 2022/ISO 646 Character Replacements on page A-7), and scan the value and the Save bar code from the Programming Chart on the inside the back cover of this manual. The data characters should then appear properly.

7 - 6

Interleaved 2 of 5

* On

Off

* No Check Digit

Validate, but Don’t Transmit

Validate and Transmit

Minimum Message Length

< Default All Interleaved 2 of 5 Settings >

Interleaved 2 of 5 On/Off

Check Digit

No Check Digit indicates that the scanner reads and transmits bar code data with or without a check digit. When Check Digit is set to Validate, but Don’t Transmit, the unit only reads Interleaved 2 of 5 bar codes printed with a

check digit, but will not transmit the check digit with the scanned data. When Check Digit is set to Validate and Transmit, the scanner only reads Interleaved 2 of 5 bar codes printed with a

check digit, and will transmit this digit at the end of the scanned data. Default = No Check Digit.

Interleaved 2 of 5 Message Length

Scan the bar codes below to change the message length. Refer to Message Length Description (page 7-1) for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 80.

7 - 7

NEC 2 of 5

Maximum Message Length

* On

Off

* No Check Digit

Validate, but Don’t Transmit

Validate and Transmit

< Default All NEC 2 of 5 Settings >

NEC 2 of 5 On/Off

Check Digit

digit, but will not transmit the check digit with the scanned data. When Check Digit is set to Validate and Transmit, the scanner only reads NEC 2 of 5 bar codes printed with a check digit,

and will transmit this digit at the end of the scanned data. Default = No Check Digit.

7 - 8

NEC 2 of 5 Message Length

Minimum Message Length

Maximum Message Length

* On

Off

Minimum Message Length

Maximum Message Length

Code 93

< Default All Code 93 Settings >

Code 93 On/Off

Code 93 Message Length

Scan the bar codes below to change the message length. Refer to Message Length Description (page 7-1) for additional information. Minimum and Maximum lengths = 0-80. Minimum Default = 0, Maximum Default = 80.

7 - 9

Code 93 Append

* Off

Code 93 Code Page

This function allows the scanner to append the data from several Code 93 bar codes together before transmitting them to the host computer. When this function is enabled, the scanner stores those Code 93 bar codes that start with a space (excluding the start and stop symbols), and does not immediately transmit the data. The scanner stores the data in the order in which the bar codes are read, deleting the first space from each. The scanner transmits the appended data when

it reads a Code 93 bar code that starts with a character other than a space. Default = Off.

Code 93 Code Page

7 - 10

Straight 2 of 5 Industrial (three-bar start/stop)

* Off

Minimum Message Length

Maximum Message Length

Straight 2 of 5 Industrial On/Off

Straight 2 of 5 Industrial Message Length

Scan the bar codes below to change the message length. Refer to Message Length Description (page 7-1) for additional information. Minimum and Maximum lengths = 1-48. Minimum Default = 4, Maximum Default = 48.

7 - 11

Straight 2 of 5 IATA (two-bar start/stop)

* Off

Minimum Message Length

Maximum Message Length

Straight 2 of 5 IATA On/Off

Straight 2 of 5 IATA Message Length

7 - 12
