Item # ________________________________
Quantity_______________________________
C.S.I. Section 11400
HR2 SERIES
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
STANDARD FEATURES
■ Modular panel construction
■ Cam lock attachment
■ Stainless steel interior and exterior
■ Hydraulic door closure
■ Self-contained pre-charged refrigeration system
OPTIONS
❑ Remote refrigeration
❑ Side trim
❑ One side
❑ Both sides
❑ Rear trim
❑ Stainless steel floor
❑ Pass thru
TWO WIDE RETARDER
MODEL CONFIGURATIONS
❑ 30" Interior Depth Two Door – Two Single
Side or End Load Racks or One Double Rack
❑ 50" Interior Depth Two Door – Three Single
Side or End Load Racks or One Double Rack
❑ 63" Interior Depth Two Door – Four Single
End or Five Side Load Racks or Two Double
Racks
❑ 83" Interior Depth Two Door – Six Single End
or Side Load Racks or Two Double Racks
❑ 96" Interior Depth Two Door – Seven Single
End or Eight Side Load Racks or Two Double
Racks
❑ 116" Interior Depth Two Door – Nine Single
End or Side Load Racks or Three Double Racks
Specifications, Details and Dimensions on Inside and Back.
S
T
U
R
D
Y
N
I
G
N
I
E
K
E
A
B
T
T
I
S
A
R
C
US
N
M
M
O
C
I
T
S
A
D
T
R
I
O
A
N
D
N
S
A
T
HR2 SERIES TWO WIDE RETARDER
LISTED
F-40018 – HR2 Series Two Wide Retarder Page 1 of 4
HR2 SERIES
TWO WIDE RETARDER
FRONT VIEW SIDE VIEW PLAN VIEW
30" INTERIOR DEPTH
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
50" INTERIOR DEPTH
63" INTERIOR DEPTH
Page 2 of 4 F-40018 – HR2 Series Two Wide Retarder
HR2 SERIES
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
FRONT VIEW SIDE VIEW PLAN VIEW
83" INTERIOR DEPTH
TWO WIDE RETARDER
96" INTERIOR DEPTH
1Electrical 2 Drain
F-40018 – HR2 Series Two Wide Retarder Page 3 of 4
116" INTERIOR DEPTH
HR2 SERIES
TWO WIDE RETARDER
SPECIFICATIONS
GENERAL:
30" Interior Depth Two Door – Two Single Side or
End Load Racks or One Double Rack
50" Interior Depth Two Door – Three Single Side
or End Load Racks or One Double Rack
63" Interior Depth Two Door – Four Single End or
Five Side Load Racks or Two Double Racks
83" Interior Depth Two Door – Six Single End or
Side Load Racks or Two Double Racks
96" Interior Depth Two Door – Seven Single End
or Eight Side Load Racks or Two Double Racks
116" Interior Depth Two Door – Nine Single End or
Side Load Racks or Three Double Racks
DETAILS AND DIMENSIONS
701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
CONSTRUCTION: Stainless steel interior and
exterior is standard. The interior perimeter is
supplied with bumpers on all sides to protect the
finish.
CAPACITY: Door opening will accommodate
75" high racks.
INSULATION: The proofer cabinet is rigid and
formed of stainless steel panels with polyurethane
foam insulation and sealed with gaskets to form a
strong, energy efficient, tight and sanitary enclosure.
HARDWARE AND FITTINGS: Heavy-duty, plasticcoated door handle positioned horizontally. Positive
action door closure.
NOTE: This unit includes a self-contained refrigeration system with a 6450 BTU/Hr. condensing unit. The system
is charged with R22 refrigerant at the factory prior to shipping. Contact your Hobart sales representative for
information to use this unit with a remote refrigeration system.
PHYSICAL DATA 30" INTERIOR DEPTH 50" INTERIOR DEPTH 63" INTERIOR DEPTH
Interior Dimensions 75"H x 30"D x 51.5"W 75"H x 50"D x 51.5"W 75"H x 63.4"D x 51.5"W
Rack Capacity
Net Door Opening Height 75" 75" 75"
Net Door Opening Width 51.5" 51.5" 51.5"
Number of Doors 222
Exterior Dimensions 99.5"H x 36"D x 60.0"W 99.5"H x 55.5"D x 60.0"W 99.5"H x 69"D x 60.0"W
Power Input (w/neutral) 208-240V/60Hz/1/14A 208-240V/60Hz/1/14A 208-240V/60Hz/1/14A
PHYSICAL DATA 83" INTERIOR DEPTH 96" INTERIOR DEPTH 116" INTERIOR DEPTH
Interior Dimensions 75"H x 83"D x 51.5"W 75"H x 96.5"D x 51.5"W 75"H x 116"D x 51.5"W
Rack Capacity
Net Door Opening Height 75" 75" 75"
Net Door Opening Width 51.5" 51.5" 51.5"
Number of Doors 222
Exterior Dimensions 99.5"H x 88.1"D x 60.0"W 99.5"H x 102"D x 60.0"W 99.5"H x 120.1"D x 60.0"W
Power Input (w/neutral) 208-240V/60Hz/1/14A 208-240V/60Hz/1/14A 208-240V/60Hz/1/14A
2 single side or 2 end load 3 single side or 3 end load 4 single end or 5 side load
or 1 double or 1 double or 2 double
6 single end or 6 side load 7 single end or 8 side load 9 single end or 9 side load
or 2 double or 2 double or 3 double
As continued product improvement is a policy of Hobart, specifications are subject to change without notice.
Page 4 of 4 F-40018 – HR2 Series Two Wide Retarder
F-40018 (5/04) LITHO IN U.S.A. (H-01)
Printed On Recycled Paper
