HandHeld 8570 User Guide

3200

™

User’s Guide

Linear Imager

Disclaimer

Hand Held Products, Inc. (“Hand Held Products”) reserves the right to make
changes in specifications and other information contained in this document
without prior notice, and the reader should in all cases consult Hand Held
Products to determine whether any such changes have been made. The
information in this publication does not represent a commitment on the part of
Hand Held Products.

Hand Held Products shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages
resulting from the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All
rights are reserved. No part of this document may be photocopied, reproduced,
or translated into another language without the prior written consent of Hand
Held Products.

©2008 Hand Held Products, Inc. All rights reserved.
Web Address: www.handheld.com

Table of Contents

Chapter 1 - Getting Started

About This Manual ............................................................... 1-1

Unpacking the Imager........................................................... 1-1

3200 Models ......................................................................... 1-1

Connecting the Imager with USB ........................................ 1-2

USB PC or Macintosh Keyboard ................................... 1-2

Plug and Play ........................................................................ 1-3

Connecting the Imager When Powered by Host

(Keyboard Wedge)............................................................. 1-3

Keyboard Wedge Connection ........................................ 1-4

Laptop Direct Connect ................................................... 1-4

Connecting the Imager with RS-232 Serial Port............ 1-4

Reading Techniques ............................................................. 1-6

Resetting the Standard Product Defaults .............................. 1-6

Chapter 2 - Terminal Interfaces

Terminal ID .......................................................................... 2-1

Supported Terminals............................................................. 2-2

Keyboard Country ................................................................ 2-3

Keyboard Style ..................................................................... 2-4

Keyboard Modifiers.............................................................. 2-4

RS-232 Baud Rate.......................................................... 2-6

RS-232 Word Length: Data Bits, Stop Bits, and Parity. 2-7

RS-232 Handshaking ..................................................... 2-8

Chapter 3 - Output

Good Read Indicators ........................................................... 3-1

Beeper – Good Read ...................................................... 3-1

Beeper Pitch – Good Read ............................................. 3-1

Trigger Modes ...................................................................... 3-1

Manual/Serial Trigger .................................................... 3-1

Trigger .................................................................................. 3-1

Automatic Trigger.......................................................... 3-2

1

Reread Delay ........................................................................ 3-2

Chapter 4 - Data Editing

Prefix/Suffix Overview......................................................... 4-1

To Clear One or All Prefixes or Suffixes:...................... 4-3

To Add a Carriage Return Suffix to all Symbologies .... 4-3

Prefix Selections............................................................. 4-3

Suffix Selections ............................................................ 4-4

Function Code Transmit................................................. 4-4

Intercharacter, Interfunction, and Intermessage Delays ....... 4-4

Intercharacter Delay ....................................................... 4-5

Interfunction Delay ........................................................ 4-5

Intermessage Delay ........................................................ 4-6

Chapter 5 - Data Formatting

Data Format Editor Introduction .......................................... 5-1

To Add a Data Format.................................................... 5-1

Other Programming Selections ...................................... 5-2

Data Format Editor Commands ..................................... 5-2

Data Format Editor......................................................... 5-3

Data Formatter ............................................................... 5-4

Chapter 6 - Symbologies

Introduction........................................................................... 6-1

Message Length .................................................................... 6-1

Codabar................................................................................. 6-2

Codabar Start/Stop Characters ...................................... 6-2

Codabar Check Character .............................................. 6-2

Codabar Message Length............................................... 6-3

Code 39................................................................................. 6-4

Code 39 Start/Stop Characters....................................... 6-4

Code 39 Check Character............................................... 6-5

Code 39 Message Length ............................................... 6-5

Full ASCII...................................................................... 6-6

Code 39 Code Page ........................................................ 6-7

2

Interleaved 2 of 5 .................................................................. 6-7

Check Digit..................................................................... 6-7

Interleaved 2 of 5 Message Length ................................ 6-8

Code 93 ................................................................................. 6-9

Code 93 Message Length ............................................... 6-9

Code 93 Code Page ........................................................ 6-9

Straight 2 of 5 Industrial ..................................................... 6-10

Straight 2 of 5 Industrial Message Length ................... 6-10

Straight 2 of 5 IATA Message Length ......................... 6-11

Matrix 2 of 5 ....................................................................... 6-11

Matrix 2 of 5 Message Length ..................................... 6-12

Code 11 ............................................................................... 6-12

Check Digits Required ................................................. 6-12

Code 11 Message Length ............................................. 6-13

Code 128 ............................................................................. 6-13

ISBT 128 Concatenation .............................................. 6-13

Code 128 Message Length ........................................... 6-14

Code 128 Code Page .................................................... 6-14

Code 128 Function Code Transmit .............................. 6-14

Telepen................................................................................ 6-15

Telepen Output ............................................................. 6-15

Telepen Message Length.............................................. 6-15

UPC A................................................................................. 6-16

UPC A Check Digit...................................................... 6-16

UPC A Number System ............................................... 6-16

UPC A Addenda........................................................... 6-16

UPC A Addenda Required ........................................... 6-17

UPC E0 and UPC E1 .......................................................... 6-18

UPC E0 and UPC E1 Expand....................................... 6-18

UPC E0 and UPC E1 Addenda Required..................... 6-19

UPC E0 Check Digit .................................................... 6-19

UPC E0 Number System.............................................. 6-19

UPC E0 Addenda ......................................................... 6-20

3

EAN/JAN 13....................................................................... 6-20

EAN/JAN 13 Check Digit............................................ 6-20

EAN/JAN 13 Addenda................................................. 6-20

EAN/JAN 13 Addenda Required ................................. 6-21

EAN/JAN 13 Addenda Separator ................................ 6-21

ISBN Translate............................................................. 6-22

EAN/JAN 8......................................................................... 6-22

EAN/JAN 8 Check Digit.............................................. 6-22

EAN/JAN 8 Addenda................................................... 6-22

EAN/JAN 8 Addenda Required ................................... 6-23

EAN/JAN 8 Addenda Separator .................................. 6-23

MSI ..................................................................................... 6-24

MSI Check Character................................................... 6-24

MSI Message Length ................................................... 6-25

Plessey Code....................................................................... 6-25

Plessey Message Length .............................................. 6-25

RSS Limited ....................................................................... 6-26

RSS Expanded .................................................................... 6-27

RSS Expanded Message Length .................................. 6-27

China Post Code ................................................................. 6-28

Chapter 7 - Interface Keys

Keyboard Function Relationships......................................... 7-1

Supported Interface Keys .................................................... 7-3

Chapter 8 - Utilities

To Add a Test Code I.D. Prefix to All Symbologies............ 8-1

Show Software Revision....................................................... 8-1

Show Data Format ................................................................ 8-1

Resetting the Standard Product Defaults .............................. 8-1

Chapter 9 - Default Chart

Resetting the Standard Product Defaults .............................. 9-1

Menu Commands.................................................................. 9-1

4

Chapter 10 - Product Specifications

3200 Product Specifications ............................................... 10-1

Chapter 11 - Maintenance

Repairs ................................................................................ 11-1

Maintenance........................................................................ 11-1

Cleaning the Device ..................................................... 11-1

Inspecting Cords and Connectors................................. 11-1

Replacing the Interface Cable ...................................... 11-2

Troubleshooting .................................................................. 11-2

Chapter 12 - Customer Support

Technical Assistance........................................................... 12-1

Online Technical Assistance ........................................ 12-2

For Further Information................................................ 12-2

Product Service and Repair................................................. 12-2

Online Product Service and Repair Assistance ............ 12-3

Limited Warranty................................................................ 12-3

Appendix A

Symbology Chart ................................................................. A-1

ASCII Conversion Chart (Code Page 1252)........................ A-2

Code Page Mapping of Printed barcodes............................. A-4

Sample Symbols

5

6

3200 Imager Identification

Item Number,

Serial Number and

Compliance

Information

location

1

Getting Started

About This Manual

This User’s Guide provides installation and programming instructions for the

3200. Product specifications, dimensions, warranty, and customer support
information are also included.

Hand Held Products barcode imagers are factory programmed for the most
common terminal and communications settings. If you need to change these
settings, programming is accomplished by scanning the barcodes in this guide.

An asterisk (*) next to an option indicates the default setting.

Unpacking the Imager

After you open the shipping carton containing the 3200, take the following steps:

• Check to make sure everything you ordered is present.

• Save the shipping container for later storage or shipping.

• Check for damage during shipment. Report damage immediately to the
carrier who delivered the carton.

3200 Models

Note: The Hand Held Products 3200 imager may be used with two interfaces,

which are described in this User’s Guide. Refer to the chart below to
determine the models that can be used with your interface.

The chart below lists the 3200 imager models. “04” designates ivory and “14”
designates black

Models Primary Interfaces

3200-04USBE (ivory)
3200-14USBE (black)

3200-04KBWE (ivory)
3200-14KBWE (black)

3200 User’s Guide 1 - 1

.

USB

Keyboard wedge

Connecting the Imager with USB

USB Keyboard (PC)

USB Keyboard (Mac)

Note: Hand Held Products recommends connecting the imager end of the cable

first and the host end second.

An imager can be connected to the USB port of a computer.

1. Connect the appropriate interface cable to the imager and to the computer.

2. The imager beeps.

3. Verify the imager operation by scanning a barcode from the Sample Symbols
in the back of this manual.

For additional USB programming and technical information, refer to the Hand
Held Products “USB Application Note,” available at www.handheld.com.

USB PC or Macintosh Keyboard

The 3200 imagers are factory programmed for a USB interface. If this is your
interface and you do not need to modify the settings, skip to Chapter 3.

If you programmed the imager for a different terminal interface and you want to
change to a USB Keyboard (PC) or USB Keyboard (Mac), scan one of the
following codes to program the 3200. Scanning these codes adds a CR and
selects the terminal ID (USB PC Keyboard - 124, USB Macintosh Keyboard -

125).

1 - 2 3200 User’s Guide

Plug and Play

Plug and Play barcodes provide instant imager set up for commonly used
interfaces.

Note: After you scan one of the codes, power cycle the host terminal to have the

interface in effect.

Connecting the Imager When Powered by Host (Keyboard Wedge)

An imager can be connected between the keyboard and PC as a “keyboard
wedge,” plugged into the serial port or connected to a portable data terminal.
The following is an example of a keyboard wedge connection:

1. Turn off power to the terminal/computer.

2. Disconnect the keyboard cable from the back of the terminal/computer.

3. Connect the appropriate interface cable to the imager and to the terminal/
computer.

4. Turn the terminal/computer power back on.

Note: You will not hear a power-up beep because the 3200 is factory defaulted

to a USB connection. You must scan the IBM PC AT and Compatibles

with CR suffix barcode on page 1-4 to enable keyboard wedge ability.

Verify the imager operation by scanning a barcode from the Sample Symbols in
the back of this manual. The imager beeps once.

3200 User’s Guide 1 - 3

Keyboard Wedge Connection

IBM PC AT and Compatibles

with CR suffix

Laptop Direct Connect

with CR suffix

Scanning the barcode below allows operation of the 3200 as a keyboard wedge
interface to an IBM PC AT with a U. S. keyboard.

If you programmed the imager for a different terminal interface and you want to
change to an IBM PC AT and compatibles keyboard wedge interface, scan the
barcode below.

Note: The following barcode also programs a carriage return (CR) suffix.

Laptop Direct Connect

For most laptops, scanning the Laptop Direct Connect barcode allows
operation of the imager in parallel with the integral keyboard. The following
Laptop Direct Connect barcode selects terminal ID 03, programs a carriage
return (CR) suffix and turns on Emulate External Keyboard (page 2-4).

Connecting the Imager with RS-232 Serial Port

1. Turn off power to the terminal/computer.

2. Connect the appropriate interface cable to the imager.

1 - 4 3200 User’s Guide

Note: For the imager to work properly, you must have the correct cable for your

RS-232 Interface

type of terminal/computer.

3. Plug the serial connector into the serial port on your computer. Tighten the
two screws to secure the connector to the port.

4. Connect the power supply and plug into an outlet.

5. Turn the terminal/computer power back on.

Note: You will not hear a power-up beep because the 3200 is factory defaulted

to a USB connection. You must scan the RS-232 Interface barcode below
to enable RS-232 ability.

All communication parameters between the imager and terminal must match for
correct data transfer through the serial port using RS-232 protocol. Scanning the
RS-232 interface barcode, programs the imager for an RS-232 interface at
38,400 baud, parity–none, 8 data bits, 1 stop bit, and adds a suffix of a CR LF.

Refer to page 2-6 for additional RS-232 configuration settings.

3200 User’s Guide 1 - 5

Reading Techniques

Good Technique

Bad Technique

Bad Technique

Standard Product Default Settings

The imager has a bright red aiming beam that corresponds to its horizontal field
of view. The aiming beam should be centered horizontally over the barcode; it
will not read if the aiming beam is in any other direction.

The best focus point for reading most code densities is about 5 inches (12.7 cm)
from the unit. To read a single barcode or multiple barcodes (on a page or on an
object), hold the imager at an appropriate distance from the target, pull the
trigger, and center the aiming beam on the barcode.

Resetting the Standard Product Defaults

If you aren’t sure what programming options are in your imager, or you’ve
changed some options and want the factory settings restored, scan the

Standard Product Default Settings

barcode below.

The Menu Commands starting on page 9-1 lists the factory default settings for
each of the commands (indicated by an asterisk (*) on the programming pages).

1 - 6 3200 User’s Guide

2

Terminal ID

Save

Terminal Interfaces

Terminal ID

If your interface is not a standard PC AT, refer to Terminal ID, beginning on page
2-1 and locate the Terminal ID number for your PC. Scan the Terminal ID
barcode below, then scan the numeric barcode(s) from the Programming Chart
inside the back cover of this manual to program the imager for your terminal ID.
Scan Save to save your selection.

For example, an IBM AT terminal has a Terminal ID of 003. You would scan the
Terminal ID barcode, then 0, 0, 3 from the Programming Chart inside the back
cover of this manual, then Save. If you make an error while scanning the digits
(before scanning Save), scan the Discard code on the Programming Chart, scan
the Terminal ID barcode, scan the digits, and the Save code again.

Note: After scanning one of these codes, you must power cycle your computer.

3200 User’s Guide 2 - 1

Supported Terminals

Ter minal Model(s) Terminal ID

RS-232 TTL
USB PC Keyboard
USB Mac Keyboard

* Factory default

000
124 *
125

2 - 2 3200 User’s Guide

Keyboard Country

* United States

Denmark

France

Germany/Austria

Great Britain

Italy

Norway

Spain

Switzerland

Belgium

Finland

Scan the appropriate country code below to program the keyboard for your
country. As a general rule, the following characters are supported, but need
special care for countries other than the United States:
@ | $ # { } [ ] = / ‘ \ < > ~

3200 User’s Guide 2 - 3

Please refer to Hand Held Products website ( www.handheld.com) for complete

Program Keyboard Country

* Regular

Caps Lock

Autocaps via NumLock

Emulate External Keyboard

keyboard country support information and applicable interfaces. If you need to
program a keyboard for a country other than one listed above, scan the Program
Keyboard Country barcode below, then scan the numeric barcode(s) for the
appropriate country from the inside back cover, then the Save barcode.

Keyboard Style

This programs keyboard styles, such as Caps Lock and Shift Lock.

Regular.

Regular

Caps Lock

Autocaps via NumLock

Germany, France) where the Caps Lock key cannot be used to toggle Caps
Lock. The NumLock option works similarly to the regular Auotcaps, but uses the
NumLock key to retrieve the current state of the Caps Lock.

Emulate External Keyboard

keyboard (IBM AT or equivalent).

Note: After scanning the Emulate External Keyboard barcode, you must power

is used when you normally have the Caps Lock key off.

is used when you normally have the Caps Lock key on.

barcode should be scanned in countries (e.g.,

should be scanned if you do not have an external

cycle your computer.

Default =

Keyboard Modifiers

This modifies special keyboard features, such as CTRL+ ASCII codes and Turbo
Mode.

2 - 4 3200 User’s Guide

Control + ASCII Mode On:

Control + ASCII Mode On

* Control + ASCII Mode Off

Numeric Keypad Mode On

* Numeric Keypad Mode Off

Automatic Direct

Connect Mode On

* Automatic Direct Connect

Mode Off

control characters for values 00-1F. Refer to Keyboard Function

Relationships, page 7-1 for CTRL+ ASCII Values.

The imager sends key combinations for ASCII

Default = Off

Numeric Keypad Mode:

numeric keypad.

Default = Off

Automatic Direct Connect Mode:

IBM AT style terminal and the system is dropping characters.

Sends numeric characters as if entered from a

This selection can be used if you have an

Default = Off

3200 User’s Guide 2 - 5

RS-232 Baud Rate

300

2400

600

1200

4800

* 38400

9600

19200

57,600

Baud Rate sends the data from the imager to the terminal at the specified rate.
The host terminal must be set for the same baud rate as the imager.

Default = 38,400

.

2 - 6 3200 User’s Guide

RS-232 Word Length: Data Bits, Stop Bits, and Parity

7 Data, 1 Stop, Parity Even

7 Data, 1 Stop, Parity None

7 Data, 1 Stop, Parity Odd

7 Data, 2 Stop, Parity Odd

7 Data, 2 Stop, Parity Even

7 Data, 2 Stop Parity None

* 8 Data, 1 Stop, Parity None

8 Data, 1 Stop, Parity Even

8 Data, 1 Stop, Parity Odd

Data Bits

application requires only ASCII Hex characters 0 through 7F decimal (text, digits,
and punctuation), select 7 data bits. For applications which require use of the full
ASCII set, select 8 data bits per character.

Stop Bits
Parity

Default = None.

sets the word length at 7 or 8 bits of data per character. If an

Default = 8.

sets the stop bits at 1 or 2.

provides a means of checking character bit patterns for validity.

Default = 1.

3200 User’s Guide 2 - 7

RS-232 Handshaking

RTS/CTS On

* XON/OFF Off

* RTS/CTS Off

XON/XOFF On

ACK/NAK On

* ACK/NAK Off

RS-232 handshaking is a set of rules concerning the exchange of data between
serially communicating devices.

NAK Off

.

Default = RTS/CTS, XON/XOFF and ACK/

2 - 8 3200 User’s Guide

3

* On

Off

Low (1600 Hz)

* Medium (2550 Hz)

High (4200 Hz)

* Manual/Serial Trigger

Output

Good Read Indicators

Beeper – Good Read

The beeper may be programmed On or Off in response to a good read. Turning
this option off, only turns off the beeper response to a good read indication. All
error and menu beeps are still audible.

Beeper Pitch – Good Read

The beeper pitch codes modify the pitch (frequency) of the beep the imager
emits on a good read.

Default = Medium.

Default = On.

Trigger Modes

Manual/Serial Trigger

Trigger

The following barcodes will allow you to use the reader in Manual Trigger mode
(need to press the trigger to read) or Automatic Trigger mode (the beam is
always on).

3200 User’s Guide 3 - 1

Automatic Trigger

Automatic Trigger

Short (500 ms)

* Medium (750 ms)

Long (1000 ms)

Extra Long (2000 ms)

The imager scans continuously at full power with illumination fully on.

Reread Delay

This sets the time period before the imager can read the
time. Setting a reread delay protects against accidental rereads of the same
barcode. Longer delays are effective in minimizing accidental rereads at POS
(point of sale). Use shorter delays in applications where repetitive barcode
scanning is required.

Reread Delay only works when in automatic trigger mode or presentation mode
(see page 3-2).

Default = Medium.

same

barcode a second

3 - 2 3200 User’s Guide

4

Data Editing

Prefix/Suffix Overview

When a barcode is scanned, additional information is sent to the host computer
along with the barcode data. This group of barcode data and additional,
user-defined data is called a “message string.” The selections in this section are
used to build the user-defined data into the message string.

Prefix and Suffix characters are data characters that can be sent before and after
scanned data. You can specify if they should be sent with all symbologies, or
only with specific symbologies. The following illustration shows the breakdown
of a message string:

Prefix

alpha numeric
characters

Scanned Data

variable length 1-11

Suffix

1-11
alpha numeric
characters

Points to Keep In Mind

• It is not necessary to build a message string. The selections in this chapter
are only used if you wish to alter the default settings.

Default suffix = None

• A prefix or suffix may be added or cleared from one symbology or all
symbologies.

• You can add any prefix or suffix from the ASCII Conversion Chart (Code Page

1252) on page A-2, plus Code I.D. and AIM I.D.

• You can string together several entries for several symbologies at one time.

• Enter prefixes and suffixes in the order in which you want them to appear on
the output.

.

Default prefix = None.

3200 User’s Guide 4 - 1

To Add a Prefix or Suffix:

Step 1. Scan the Add Prefix or Add Suffix symbol (page 4-3).

Step 2. Determine the 2 digit Hex value from the Symbology Chart (included in

the Appendix A) for the symbology to which you want to apply the prefix
or suffix. For example, for Code 128, Code ID is “j” and Hex ID is “6A”.

Step 3. Scan the 2 hex digits from the Programming Chart inside the back

cover of this manual or scan 9, 9 for all symbologies.

Step 4. Determine the hex value from the ASCII Conversion Chart (Code Page

1252) on page A-2, for the prefix or suffix you wish to enter.

Step 5. Scan the 2 digit hex value from the Programming Chart inside the back

cover of this manual.

Step 6. Repeat Steps 4 and 5 for every prefix or suffix character.

Step 7. To add the Code I.D., scan 5, C, 8, 0.

To add AIM I.D., scan 5, C, 8, 1.
To add a backslash (\), scan 5, C, 5, C.

Note: To add a backslash (\) as in Step 7, you must scan 5C twice – once to

create the leading backslash and then to create the backslash itself.

Step 8. Scan Save to exit and save, or scan Discard to exit without saving.
Repeat Steps 1-6 to add a prefix or suffix for another symbology.

Example: Add a Suffix to a specific symbology

To send a CR (carriage return)Suffix for UPC only:

Step 1. Scan Add Suffix.

Step 2. Determine the 2 digit hex value from the Symbology Chart (included in

the Appendix A) for UPC.

Step 3. Scan 6, 3 from the Programming Chart inside the back cover of this

manual.

Step 4. Determine the hex value from the ASCII Conversion Chart (Code Page

1252) on page A-2, for the CR (carriage return).

Step 5. Scan 0, D from the Programming Chart inside the back cover of this

manual.

Step 6. Scan Save, or scan Discard to exit without saving.

4 - 2 3200 User’s Guide

To Clear One or All Prefixes or Suffixes:

Add CR Suffix

All Symbologies

Add Prefix

Clear One Prefix

Clear All Prefixes

You can clear a single prefix or suffix, or clear all prefixes/suffixes for a
symbology. When you Clear One Prefix (Suffix), the specific character you
select is deleted from the symbology you want. When you Clear All Prefixes
(Suffixes), all the prefixes or suffixes for a symbology are deleted.

Step 1. Scan the Clear One Prefix or Clear One Suffix symbol.

Step 2. Determine the 2 digit Hex value from the Symbology Chart (included in

the Appendix A) for the symbology from which you want to clear the pre­fix or suffix.

Step 3. Scan the 2 digit hex value from the Programming Chart inside the back

cover of this manual or scan 9, 9 for all symbologies.

Your change is automatically saved.

To Add a Carriage Return Suffix to all Symbologies

Scan the following barcode if you wish to add a carriage return suffix to all
symbologies at once. This action first clears all current suffixes, then programs
a carriage return suffix for all symbologies.

Prefix Selections

3200 User’s Guide 4 - 3

Suffix Selections

Add Suffix

Clear One Suffix

Clear All Suffixes

* Enable

Disable

Function Code Transmit

When this selection is enabled and function codes are contained within the
scanned data, the imager transmits the function code to the terminal. Charts of
these function codes are provided in Supported Interface Keys starting on

page 7-3. When the imager is in keyboard wedge mode, the scan code is

converted to a key code before it is transmitted.

Default = Enable.

Intercharacter, Interfunction, and Intermessage Delays

Some terminals drop information (characters) if data comes through too quickly.
Intercharacter, interfunction, and intermessage delays slow the transmission of
data, increasing data integrity.

Each delay is composed of a 5 millisecond step. You can program up to 99 steps
(of 5 ms each) for a range of 0-495 ms.

4 - 4 3200 User’s Guide

Intercharacter Delay

1 2345

Intercharacter Delay

Prefix Scanned Data Suffix

Intercharacter Delay

Interfunction Delays

Prefix Scanned Data Suffix

1 2345STX HT CR LF

Interfunction Delay

An intercharacter delay of up to 495 milliseconds may be placed between the
transmission of each character of scanned data. Scan the Intercharacter Delay
barcode below, then scan the number of milliseconds and the SAVE barcode
using the Programming Chart inside the back cover of this manual.

To remove this delay, scan the Intercharacter Delay barcode, then set the
number of steps to 0. Scan the SAVE barcode using the Programming Chart
inside the back cover of this manual.

Note: Intercharacter delays are not supported in USB serial emulation.

Interfunction Delay

An interfunction delay of up to 495 milliseconds may be placed between the
transmission of each segment of the message string. Scan the Interfunction
Delay barcode below, then scan the number of milliseconds and the SAVE
barcode using the Programming Chart inside the back cover of this manual.

To remove this delay, scan the Interfunction Delay barcode, then set the
number of steps to 0. Scan the SAVE barcode using the Programming Chart
inside the back cover of this manual.

3200 User’s Guide 4 - 5

Intermessage Delay

2nd Scan Transmission1st Scan Transmission

Intermessage Delay

Intermessage Delay

An intermessage delay of up to 495 milliseconds may be placed between each
scan transmission. Scan the Intermessage Delay barcode below, then scan the
number of milliseconds and the SAVE barcode using the Programming Chart
inside the back cover of this manual.

To remove this delay, scan the Intermessage Delay barcode, then set the
number of steps to 0. Scan the SAVE barcode using the Programming Chart
inside the back cover of this manual.

4 - 6 3200 User’s Guide

5

Data Formatting

Data Format Editor Introduction

You may use the Data Format Editor to change the imager’s output. For
example, you can use the Data Format Editor to insert characters at certain
points in barcode data as it is scanned. The selections in the following pages are
used only if you wish to alter the output.

Normally, when you scan a barcode, it gets outputted automatically; however
when you do a format, you must use a “send” command (see Send Commands
on page 5-2) within the format program to output data.

Multiple formats may be programmed into the imager. They are stacked in the
order in which they are entered. However, the following list presents the order
in which formats are applied:

1. Specific Term ID, Actual Code ID, Actual Length

2. Specific Term ID, Actual Code ID, Universal Length

3. Specific Term ID, Universal Code ID, Actual Length

4. Specific Term ID, Universal Code ID, Universal Length

5. Universal Term ID, Actual Code ID, Actual Length

6. Universal Term ID, Actual Code ID, Universal Length

7. Universal Term ID, Universal Code ID, Actual Length

8. Universal Term ID, Universal Code ID, Universal Length

Default Data Format setting = None.

If you have changed data format settings, and wish to clear all formats and return
to the factory defaults, scan the Default Data Format code on page 5-3.

To Add a Data Format

Step 1. Scan the Enter Data Format symbol (page 5-3).

Step 2. Terminal Type

Refer to the Supported Terminals Chart (page 2-2) and locate the Ter­minal ID number for your PC. Scan three numeric barcodes on the
inside back cover to program the imager for your terminal ID (you must
enter 3 digits). For example, scan 0 0 0 for an RS-232 TTL.

Note: The wildcard for all terminal types is 0099.

Step 3. Code I.D.

In the Appendix A, find the symbology to which you want to apply the
data format. Locate the Hex value for that symbology and scan the 2
digit hex value from the Programming Chart inside the back cover of
this manual.

3200 User’s Guide 5 - 1

Step 4. Length

Specify what length (up to 9999 characters) of data will be acceptable
for this symbology. Scan the four digit data length from the Program-

ming Chart inside the back cover of this manual. (Note: 50 characters is

entered as 0050. 9999 is a universal number, indicating all lengths.)

Step 5. Editor Commands

Refer to the Format Editor Commands Chart (page 5-2). Scan the sym-
bols that represent the command you want to enter. 94 alphanumeric
characters may be entered for each symbology data format.

Step 6. Scan Save from the Programming Chart inside the back cover of this

manual to save your entries.

Other Programming Selections

• Clear One Data Format
This deletes one data format for one symbology. If you are clearing the
primary format, scan 0 from the Programming Chart inside the back cover of
this manual. If you are clearing an alternate format, scan 1, 2, or 3, depending
on the alternate format you are clearing. Scan the Terminal Type (refer to the
Supported Terminals Chart on page 2-2), Code I.D. (refer to the Symbology

Chart on page A-1), and the barcode data length for the specific data format

that you want to delete. All other formats remain unaffected.

• Save from the Programming Chart inside the back cover of this manual
This exits, saving any Data Format changes.

• Discard from the Programming Chart inside the back cover of this manual
This exits without saving any Data Format changes.

Data Format Editor Commands

Send Commands

F1 Send all characters followed by “xx” key or function code, starting from cur-

rent cursor position.
ASCII code, see ASCII Conversion Chart (Code Page 1252) on page A-2.)

F2 Send “nn” characters followed by “xx” key or function code, starting from

current cursor position.
(00-99) for the number of characters and xx stands for the hex value for an
ASCII code. See ASCII Conversion Chart (Code Page 1252) on page A-2.)

F3 Send up to but not including “ss” character (Search and Send) starting from

current cursor position, leaving cursor pointing to “ss” character followed by
“xx” key or function code.
hex values for ASCII codes, see ASCII Conversion Chart (Code Page

1252) on page A-2.)

F4 Send “xx” character “nn” times (Insert) leaving cursor in current cursor posi-

Syntax = F4xxnn

tion.

ASCII Conversion Chart (Code Page 1252) on page A-2, and nn is the

numeric value (00-99) for the number of times it should be sent.)

5 - 2 3200 User’s Guide

Syntax = F1xx

Syntax = F2nnxx

Syntax = F3ssxx

(xx stands for the hex value for an ASCII code, see

(xx stands for the hex value for an

(nn stands for the numeric value

(ss and xx both stand for the

Move Commands

Enter Data Format

* Default Data Format

Clear One Data Format

Save

Discard

Clear All Data Formats

F5 Move the cursor ahead “nn” characters from current cursor position.

Syntax = F5nn

characters the cursor should be moved ahead.)

F7 Move the cursor to the beginning of the data string.

(nn stands for the numeric value (00-99) for the number of

Syntax = F7.

Miscellaneous Commands

FE Compare character in current cursor position to the character “xx.” If char-

acters are equal, increment cursor. If characters are not equal, no format
match.

ASCII Conversion Chart (Code Page 1252) on page A-2.)

Syntax = FExx

(xx stands for the hex value for an ASCII code, see

Data Format Editor

3200 User’s Guide 5 - 3

Data Formatter

Data Formatter Off

* Data Formatter On,

but Not Required

Data Format On, Format Required

When Data Formatter is turned off, the barcode data is output to the host as read
(including prefixes and suffixes). Choose one of the following options.

Data Formatter On.

When Data Formatter is required, all input data must conform to an edited format
or the imager does not transmit the input data to the host device.

Default =

5 - 4 3200 User’s Guide

6

All Symbologies On

All Symbologies Off

Symbologies

Introduction

This programming section contains the following menu selections. Refer to

Chapter 9 for settings and defaults.

• All Symbologies • Interleaved 2 of 5

• China Post Code • Matrix 2 of 5

• Codabar • MSI

• Code 11 • Plessey Code

• Code 39 • RSS-14

• Code 32 Pharmaceutical (PARAF)

• Code 93

• Code 128 • Telepen

• UPC-A/EAN-13 with Extended

Coupon Code

• EAN/JAN 8 • UPC E

• Straight 2 of 5 IATA

(two-bar start/stop)

• Straight 2 of 5

Industrial (three-bar
start/stop)

• UPC A

All Symbologies

If you want to decode all the symbologies allowable for your imager, scan the

Symbologies On

particular symbology, scan All Symbologies Off followed by the On symbol for
that particular symbology.

code. If on the other hand, you want to decode only a

All

Message Length

You are able to set the valid reading length of some of the barcode symbologies.
If the data length of the scanned barcode doesn’t match the valid reading length,
the imager will issue an error beep. You may wish to set the same value for
minimum and maximum length to force the imager to read fixed length barcode
data. This helps reduce the chances of a misread.

3200 User’s Guide 6 - 1

EXAMPLE: Decode only those barcodes with a count of 9-20 characters.

* On

Off

Transmit

* Don’t Transmit

EXAMPLE: Decode only those barcodes with a count of 15 characters.

For a value other than the minimum and maximum message length defaults,
scan the barcodes included in the explanation of the symbology, then scan the
digit value of the message length and Save barcodes on the Programming Chart
inside the back cover of this manual. The minimum and maximum lengths and
the defaults are included with the respective symbologies.

Min. length = 09 Max. length = 20

Min. length = 15 Max. length = 15

Codabar

<Default All Codabar Settings>

Codabar

Codabar Start/Stop Characters

Start/Stop characters identify the leading and trailing ends of the barcode. You
may either transmit, or not transmit Start/Stop characters.

Default = Don’t Transmit

.

Codabar Check Character

Codabar check characters are created using different “modulos.” You can
program the imager to read only Codabar barcodes with Modulo 16 check
characters.

6 - 2 3200 User’s Guide

Default = No Check Character.

No Check Character

* No Check Character

Validate Modulo 16 and Transmit

Validate Modulo 16, but

Don’t Transmit

Minimum Message Length

Maximum Message Length

with or without a check character.
When Check Character is set to

Codabar barcodes printed with a check character, and will transmit this character
at the end of the scanned data.

When Check Character is set to
read Codabar barcodes printed
check character with the scanned data.

indicates that the imager reads and transmits barcode data

Validate and Transmit

Validate, but Don’t Transmit

with

a check character, but will not transmit the

, the imager will only read

, the unit will only

Codabar Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 2-60. Minimum Default = 4, Maximum Default = 60.

3200 User’s Guide 6 - 3

Code 39

* On

Off

Transmit

* Don’t Transmit

< Default All Code 39 Settings >

Code 39

Code 39 Start/Stop Characters

Start/Stop characters identify the leading and trailing ends of the barcode. You
may either transmit, or not transmit Start/Stop characters.

Transmit.

Default = Don’t

6 - 4 3200 User’s Guide

Code 39 Check Character

Validate, but Don’t Transmit

* No Check Character

Validate and Transmit

Minimum Message Length

Maximum Message Length

* Off

On

No Check Character indicates that the imager reads and transmits barcode data
with or without a check character.

When Check Character is set to Validate, but Don’t Transmit, the unit only
reads Code 39 barcodes printed with a check character, but will not transmit the
check character with the scanned data.

When Check Character is set to Validate and Transmit, the imager only reads
Code 39 barcodes printed with a check character, and will transmit this character
at the end of the scanned data.

Default = No Check Character.

Code 39 Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 0-48. Minimum Default = 0, Maximum Default = 48.

Code 32 Pharmaceutical (PARAF)

Code 32 Pharmaceutical is a form of the Code 39 symbology used by Italian
pharmacies. This symbology is also known as PARAF.

3200 User’s Guide 6 - 5

Full ASCII

* Full ASCII Off

Full ASCII On

If Full ASCII Code 39 decoding is enabled, certain character pairs within the
barcode symbol will be interpreted as a single character. For example: $V will
be decoded as the ASCII character SYN, and /C will be decoded as the ASCII
character #.

Default = Off

.

NUL %U DLE $P
SOH $A DC1 $Q !/A 11AAQQ a+Aq+Q
STX $B
ETX $C DC3 $S #/C 33CC SSc+Cs+S
EOT $D DC4 $T $/D 44DDTTd+Dt+T
ENQ $E
ACK $F SYN $V &/F 66 FFVV f+Fv+V
BEL $G ETB $W ‘/G77GGWW g+Gw+W
BS $H CAN $X (/H 88HHXX h+Hx+X
HT $I
LF $J
VT $K ESC %A +/K ;%FKK[%Kk+K{%P
FF $L
CR $M GS %C -- =%HMM ]%Mm+M}%R
SO $N RS %D .. >%INN^%Nn+N~%S
SI $O

DC2 $R “/B 22 BBRRb+Br+R

NAK $U %/E 55EEUU e+Eu+U

EM $Y )/I 99 IIYYi+Iy+Y
SUB $Z */J :/ZJJ ZZj+Jz+Z

FS %B ,/L <%GLL\%Ll+L|%Q

US %E //O ?%JOO_%Oo+ODEL %T

SP SPACE

00@%VPP‘%Wp+P

Character pairs /M and /N decode as a minus sign and period respectively.
Character pairs /P through /Y decode as 0 through 9.

6 - 6 3200 User’s Guide

Code 39 Code Page

Code 39 Code Page

* On

Off

Code pages define the mapping of character codes to characters. If the data
received does not display with the proper characters, it may be because the
barcode being scanned was created using a code page that is different from the
one the host program is expecting. If this is the case, scan the barcode below,
select the code page with which the barcodes were created from the chart, Code

Page Mapping of Printed barcodes on page A-4, and scan the value and the

SAVE barcode from the Programming Chart inside the back cover of this manual.
The data characters should then appear properly.

Interleaved 2 of 5

< Default All Interleaved 2 of 5 Settings >

Interleaved 2 of 5

Check Digit

No Check Digit indicates that the imager reads and transmits barcode data with
or without a check digit.

3200 User’s Guide 6 - 7

When Check Digit is set to Validate, but Don’t Transmit, the unit only reads

Validate, but Don’t Transmit

* No Check Digit

Validate and Transmit

Minimum Message Length

Maximum Message Length

Interleaved 2 of 5 barcodes printed with a check digit, but will not transmit the
check digit with the scanned data.

When Check Digit is set to Validate and Transmit, the imager only reads
Interleaved 2 of 5 barcodes printed with a check digit, and will transmit this digit
at the end of the scanned data.

Default = No Check Digit.

Interleaved 2 of 5 Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 2-80. Minimum Default = 4, Maximum Default = 80.

6 - 8 3200 User’s Guide

Code 93

* On

Off

Minimum Message Length

Maximum Message Length

Code 93 Code Page

< Default All Code 93 Settings >

Code 93

Code 93 Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 0-80. Minimum Default = 0, Maximum Default = 80.

Code 93 Code Page

Code pages define the mapping of character codes to characters. If the data
received does not display with the proper characters, it may be because the
barcode being scanned was created using a code page that is different from the
one the host program is expecting. If this is the case, scan the barcode below,
select the code page with which the barcodes were created from the chart, Code

Page Mapping of Printed barcodes on page A-4, and scan the value and the

SAVE barcode from the Programming Chart inside the back cover of this manual.
The data characters should then appear properly.

3200 User’s Guide 6 - 9

Straight 2 of 5 Industrial (three-bar start/stop)

On

* Off

Minimum Message Length

Maximum Message Length

<Default All Straight 2 of 5 Settings>

Straight 2 of 5 Industrial

Straight 2 of 5 Industrial Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 1-48. Minimum Default = 4, Maximum Default = 48.

Straight 2 of 5 IATA (two-bar start/stop)

<Default All Code IATA 2 of 5 Settings>

6 - 10 3200 User’s Guide

Straight 2 of 5 IATA

On

* Off

Minimum Message Length

Maximum Message Length

On

* Off

Straight 2 of 5 IATA Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 1-48. Minimum Default = 4, Maximum Default = 48.

Matrix 2 of 5

<Default All Matrix 2 of 5 Settings>

Matrix 2 of 5

3200 User’s Guide 6 - 11

Matrix 2 of 5 Message Length

Minimum Message Length

Maximum Message Length

On

* Off

One Check Digit

* Two Check Digits

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 1-80. Minimum Default = 4, Maximum Default = 80.

Code 11

<Default All Code 11 Settings>

Code 11

Check Digits Required

This option sets whether 1 or 2 check digits are required with Code 11 barcodes.

Default = Two Check Digits.

6 - 12 3200 User’s Guide

Code 11 Message Length

Minimum Message Length

Maximum Message Length

* On

Off

* Off

On

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 1-80. Minimum Default = 4, Maximum Default = 80.

Code 128

<Default All Code 128 Settings>

Code 128

ISBT 128 Concatenation

In 1994 the International Society of Blood Transfusion (ISBT) ratified a standard
for communicating critical blood information in a uniform manner. The use of
ISBT formats requires a paid license. The ISBT 128 Application Specification
describes 1) the critical data elements for labeling blood products, 2) the current
recommendation to use Code 128 due to its high degree of security and its
space-efficient design, 3) a variation of Code 128 that supports concatenation of
neighboring symbols, and 4) the standard layout for barcodes on a blood product
label. Use the barcodes below to turn concatenation on or off.

3200 User’s Guide 6 - 13

Default =Off.

Code 128 Message Length

Minimum Message Length

Maximum Message Length

Code 128 Code Page

* Function Codes Off

Function Codes On

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 0-80. Minimum Default = 0, Maximum Default = 80.

Code 128 Code Page

Code pages define the mapping of character codes to characters. If the data
received does not display with the proper characters, it may be because the
barcode being scanned was created using a code page that is different from the
one the host program is expecting. If this is the case, scan the barcode below,
select the code page with which the barcodes were created from the chart, Code

Page Mapping of Printed barcodes on page A-4, and scan the value and the

SAVE barcode from the Programming Chart inside the back cover of this manual.
The data characters should then appear properly.

Code 128 Function Code Transmit

By default, Code 128 function codes are not transmitted with Code 128 barcode
data. However, if you wish to transmit Code 128 function codes with the barcode
data, scan the Function Codes On barcode, below.

Telepen

6 - 14 3200 User’s Guide

<Default All Telepen Settings>

Telepen

On

* Off

Original Telepen Output

* AIM Telepen Output

Minimum Message Length

Maximum Message Length

Telepen Output

Using AIM Telepen Output, the imager reads symbols with start/stop pattern 1
and decodes them as standard full ASCII (start/stop pattern 1). When Original
Telepen Output is selected, the imager reads symbols with start/stop pattern 1
and decodes them as compressed numeric with optional full ASCII (start/stop
pattern 2).

Telepen Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 1-60. Minimum Default = 1, Maximum Default = 60.

Default = AIM Telepen Output.

3200 User’s Guide 6 - 15

UPC A

* On

Off

* On

Off

Off

* On

<Default All UPC A Settings>

UPC A

UPC A Check Digit

This selection allows you to specify whether the check digit should be transmitted
at the end of the scanned data or not. Default = On.

UPC A Number System

The numeric system digit of a U.P.C. symbol is normally transmitted at the
beginning of the scanned data, but the unit can be programmed so it will not
transmit it.

Default = On.

UPC A Addenda

6 - 16 3200 User’s Guide

This selection adds 2 or 5 digits to the end of all scanned UPC A data.

* 5 Digit Addenda Off

5 Digit Addenda On

* 2 Digit Addenda Off

2 Digit Addenda On

* Not Required

Required

* On

Off

Default = Off for both 2 Digit and 5 Digit Addenda.

UPC A Addenda Required

When Addenda Required is set to on, the imager will only read UPC A barcodes
that have addenda.

Default = Not Required.

UPC-A/EAN-13
with Extended Coupon Code

Use the following codes to enable or disable UPC-A and EAN-13 with Extended
Coupon Code.

Default = On.

3200 User’s Guide 6 - 17

UPC E

* UPC E0 On

UPC E0 Off

UPC E1 On

* UPC E1 Off

* Off

On

<Default All UPC E Settings>

UPC E0 and UPC E1

Most U.P.C. barcodes lead with the 0 number system. For these codes, use the
UPC E0 selection. If you need to read codes that lead with the 1 number system,
use the UPC E1 selection.

UPC E0 and UPC E1 Expand

Default = On (UPC E0) and Off (UPC E1).

UPC E Expand expands the UPC E code to the 12 digit, UPC A format.

Default = Off.

6 - 18 3200 User’s Guide

UPC E0 and UPC E1 Addenda Required

* Not Required

Required

Off

* On

Off

* On

When Addenda Required is set to on, the imager will only read UPC E barcodes
that have addenda.

Default = Not Required.

UPC E0 Check Digit

Check Digit specifies whether the check digit should be transmitted at the end of
the scanned data or not.

Default = On.

UPC E0 Number System

The numeric system digit of a U.P.C. symbol is normally transmitted at the
beginning of the scanned data, but the unit can be programmed so it will not
transmit it.

Default = On.

3200 User’s Guide 6 - 19

UPC E0 Addenda

* 5 Digit Addenda Off

5 Digit Addenda On

* 2 Digit Addenda Off

2 Digit Addenda On

* On

Off

Off

* On

This selection adds 2 or 5 digits to the end of all scanned UPC E data.

Default = Off for both 2 Digit and 5 Digit Addenda.

EAN/JAN 13

<Default All EAN/JAN Settings>

EAN/JAN 13

EAN/JAN 13 Check Digit

This selection allows you to specify whether the check digit should be transmitted
at the end of the scanned data or not.

EAN/JAN 13 Addenda

6 - 20 3200 User’s Guide

Default = On.

This selection adds 2 or 5 digits to the end of all scanned EAN/JAN 13 data.

* 5 Digit Addenda Off

5 Digit Addenda On

* 2 Digit Addenda Off

2 Digit Addenda On

* Not Required

Required

Off

* On

Default = Off for both 2 Digit and 5 Digit Addenda.

EAN/JAN 13 Addenda Required

When Addenda Required is set to on, the imager will only read EAN/JAN 13
barcodes that have addenda.

Default = Not Required.

EAN/JAN 13 Addenda Separator

When this feature is on, there is a space between the data from the barcode and
the data from the addenda. When turned off, there is no space.

Default = On.

3200 User’s Guide 6 - 21

Note: If you want to enable or disable EAN13 with Extended Coupon Code,

* Off

On

* On

Off

Off

* On

refer to UPC-A/EAN-13 with Extended Coupon Code on page 6-17.

ISBN Translate

This selection causes EAN-13 Bookland symbols to be translated into their
equivalent ISBN number format.

Default = Off.

EAN/JAN 8

<Default All EAN/JAN 8 Settings>

EAN/JAN 8

EAN/JAN 8 Check Digit

This selection allows you to specify whether the check digit should be transmitted
at the end of the scanned data or not.

Default = On.

EAN/JAN 8 Addenda

6 - 22 3200 User’s Guide

This selection adds 2 or 5 digits to the end of all scanned EAN/JAN 8 data.

* 5 Digit Addenda Off

5 Digit Addenda On

* 2 Digit Addenda Off

2 Digit Addenda On

* Not Required

Required

Off

* On

Default = Off for both 2 Digit and 5 Digit Addenda.

EAN/JAN 8 Addenda Required

When Addenda Required is set to on, the imager will only read EAN/JAN 8
barcodes that have addenda.

Default = Not Required.

EAN/JAN 8 Addenda Separator

When this feature is on, there is a space between the data from the barcode and
the data from the addenda. When turned off, there is no space.

Default = On.

3200 User’s Guide 6 - 23

MSI

On

* Off

Validate Type 10 and Transmit

* Validate Type 10, but Don’t

Transmit

<Default All MSI Settings>

MSI

MSI Check Character

Different types of check characters are used with MSI barcodes. You can
program the imager to read MSI barcodes with Type 10 check characters.

Default = Validate Type 10, but Don’t Transmit.

When Check Character is set to
MSI barcodes printed with the specified type check character, and will transmit
this character at the end of the scanned data.

When Check Character is set to
read MSI barcodes printed with the specified type check character, but will not
transmit the check character with the scanned data.

Validate and Transmit

Validate, but Don’t Transmit

, the imager will only read

, the unit will only

6 - 24 3200 User’s Guide

MSI Message Length

Minimum Message Length

Maximum Message Length

On

* Off

Minimum Message Length

Maximum Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 4-48. Minimum Default = 4, Maximum Default = 48.

Plessey Code

<Default All Plessey Code Settings>

Plessey Code

Plessey Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 4-48. Minimum Default = 4, Maximum Default = 48.

3200 User’s Guide 6 - 25

RSS-14

* On

Off

* On

Off

RSS-14

RSS Limited

RSS Limited

< Default All RSS-14 Settings >

< Default All RSS Limited Settings >

RSS Expanded

< Default All RSS Expanded Settings >

6 - 26 3200 User’s Guide

RSS Expanded

* On

Off

Minimum Message Length

Maximum Message Length

RSS Emulation

128 Emulation

* EAN•UCC Emulation Off

RSS Expanded Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 4-74. Minimum Default = 4, Maximum Default = 74.

EAN•UCC Emulation

The imager can automatically format the output from any EAN•UCC data carrier
to emulate what would be encoded in an equivalent UCC/EAN-128 or
RSS+Composite symbol. EAN•UCC data carriers include UPC-A and UPC-E,
EAN-13 and EAN-8, ITF-14, UCC/EAN-128, and EAN•UCC RSS and
Composites. If UCC/EAN-128 Emulation is selected, the AIM Symbology
Identifier will be reported as “]C1”. If RSS Emulation is selected, the AIM
Symbology Identifier will be reported as “]e0.” Any application that accepts
EAN•UCC data can be simplified since it only needs to recognize one data carrier

Default = EAN•UCC Emulation Off

type.

.

3200 User’s Guide 6 - 27

China Post Code

On

* Off

Minimum Message Length

Maximum Message Length

<Default All China Post Code Settings>

China Post Code

China Post Message Length

Scan the barcodes below to change the message length. Refer to Message

Length on page 6-1 for additional information. Minimum and Maximum

lengths = 2-80. Minimum Default = 4, Maximum Default = 80.

6 - 28 3200 User’s Guide

7

Interface Keys

Keyboard Function Relationships

The following Keyboard Function Code, Hex/ASCII Value, and Full ASCII
“CTRL”+ relationships apply to all terminals that can be used with the imager.
Refer to page 2-5 enable Control + ASCII mode.

Function Code HEX/ASCII Value Full ASCII “CTRL” +

NUL 00 2

SOH 01 A

STX 02 B
ETX 03 C

EOT 04 D

ENQ 05 E

ACK 06 F

BEL 07 G

BS 08 H
HT 09 I

LF 0A J

VT 0B K

FF 0C L
CR 0D M
SO 0E N

SI 0F O

DLE 10 P
DC1 11 Q
DC2 12 R
DC3 13 S
DC4 14 T
NAK 15 U
SYN 16 V

ETB 17 W
CAN 18 X

EM 19 Y
SUB 1A Z
ESC 1B [

FS 1C \

GS 1D ]

RS 1E 6

US 1F -

3200 User’s Guide 7 - 1

The last five characters in the Full ASCII “CTRL”+ column ( [ \ ] 6 - ), apply to US
only. The following chart indicates the equivalents of these five characters for
different countries.

Country Codes

United States [ \ ] 6 ­Belgium [ < ] 6 ­Scandinavia 8 < 9 6 ­France ^ 8 $ 6 =
Germany à + 6 ­Italy \ + 6 ­Switzerland < . . 6 ­United Kingdom [ ¢ ] 6 ­Denmark 8 \ 9 6 ­Norway 8 \ 9 6 ­Spain [ \ ] 6 -

7 - 2 3200 User’s Guide

Supported Interface Keys

IBM AT/XT and
PS/2 Compatibles,
WYSE PC/AT

ASCII HEX

NUL 00 Reserved Reserved
SOH 01 Enter (KP) CR/Enter
STX 02 Cap Lock Caps Lock
ETX 03 ALT make Reserved
EOT 04 ALT break Reserved
ENQ 05 CTRL make Reserved
ACK 06 CTRL break Reserved
BEL 07 CR/Enter CR/Enter
BS 08 Reserved Reserved
HT 09 Tab Tab
LF 0A Reserved Reserved
VT 0B Tab Tab
FF 0C Delete Delete
CR 0D CR/Enter CR/Enter
SO 0E Insert Insert
SI 0F Escape Escape
DLE 10 F11 Reserved
DC1 11 Home Home
DC2 12 Print Print
DC3 13 Back Space Back Space
DC4 14 Back Tab Back Tab
NAK 15 F12 Reserved
SYN 16 F1 F1
ETB 17 F2 F2
CAN 18 F3 F3
EM 19 F4 F4
SUB 1A F5 F5
ESC 1B F6 F6
FS 1C F7 F7
GS 1D F8 F8
RS 1E F9 F9
US 1F F10 F10

* IBM 3191/92, 3471/72, 3196/97, 3476/77, Telex (all models)

Supported Keys

IBM XTs and
Compatibles
Supported Keys

3200 User’s Guide 7 - 3

7 - 4 3200 User’s Guide

8

Add Code I.D. Prefix to

All Symbologies (Temporary)

Show Revision

Data Format Settings

Standard Product Default Settings

Utilities

To Add a Test Code I.D. Prefix to All Symbologies

This selection allows you to turn on transmission of a Code I.D. before the
decoded symbology. (See the Symbology Chart, included in the Appendix

A, page A-1) for the single character code that identifies each symbology.) This

action first clears all current prefixes, then programs a Code I.D. prefix for all
symbologies. This is a temporary setting that will be removed when the unit is
power cycled.

Show Software Revision

Scan the barcode below to output the current software revision, unit serial
number, and other product information.

Show Data Format

Scan the barcode below to show current data format settings.

Resetting the Standard Product Defaults

If you aren’t sure what programming options are in your imager, or you’ve
changed some options and want the standard product default settings restored,
scan the

The Menu Commands starting on page 9-1 lists the standard product default
settings for each of the commands (indicated by an asterisk (*) on the
programming pages).

3200 User’s Guide 8 - 1

Standard Product Default Settings

barcode below.

8 - 2 3200 User’s Guide

9

Standard Product Default Settings

Default Chart

Resetting the Standard Product Defaults

If you aren’t sure what programming options are in your imager, or you’ve
changed some options and want the factory settings restored, scan the

Standard Product Default Settings

The chart on the following pages lists the factory default settings for each of the
menu commands (indicated by an asterisk (*) on the programming pages).

Menu Commands

The following chart lists all of the menu commands and the defaults and ranges
for each entry.

barcode below.

Selection

Factory Default Settings Default

Setting

* Indicates default

Page

Terminal Interfaces

Terminal ID USB PC Keyboard 2-2

*USA 2-3
Belgium 2-3
Denmark 2-3
Finland 2-3
France 2-3

Program Keyboard Country

Keyboard Style

3200 User’s Guide 9 - 1

Germany/Austria 2-3
Great Britain 2-3
Italy 2-3
Norway 2-3
Spain 2-3
Switzerland 2-3
*Regular 2-4
Emulate External

Keyboard

2-4

Selection

Keyboard Modifiers

Serial Port Connection RS-232 1-5

Baud Rate

Word Length: Data Bits,
Stop Bits, and Parity

RS-232 Handshaking

Setting

* Indicates default

*Control + ASCII Off 2-5
Control + ASCII On 2-5
*Numeric Keypad Off 2-5
Numeric Keypad On 2-5
*Auto Direct Conn. Off 2-5
Auto Direct Conn. On 2-5

300 BPS 2-6
600 BPS 2-6
1200 BPS 2-6
2400 BPS 2-6
4800 BPS 2-6
9600 BPS 2-6
19200 BPS 2-6
*38400 BPS 2-6
57600 BPS 2-6
7 Data, 1 Stop, Parity Even 2-7
7 Data, 1 Stop, Parity None 2-7
7 Data, 1 Stop, Parity Odd 2-7
7 Data, 2 Stop, Parity Even 2-7
7 Data, 2 Stop, Parity None 2-7
7 Data, 2 Stop, Parity Odd 2-7
8 Data, 1 Stop, Parity Even 2-7
*8 Data, 1 Stop, Parity None 2-7
8 Data, 1 Stop, Parity Odd 2-7
*RTS/CTS Off 2-8
RTS/CTS On 2-8
*XON/XOFF Off 2-8
XON/XOFF On 2-8
*ACK/NAK Off 2-8
ACK/NAK On 2-8

Page

Output Selections

Beeper - Good Read

Off 3-1
*On 3-1

9 - 2 3200 User’s Guide

Selection

Beeper Volume - Good
Read

Beeper Pitch - Good Read
(Frequency)

Trigger Mode

Reread Delay

Setting

* Indicates default

Off 3-1
Low 3-1
Medium 3-1
*High 3-1
Low (1600) (min 400Hz) 3-1
*Medium (2550) 3-1
High (4200) (max 9000Hz) 3-1
*Manual/Serial Trigger 3-1
Automatic Trigger 3-2
Short (500 ms) 3-2
*Medium (750 ms) 3-2
Long (1000 ms) 3-2
Extra Long (2000 ms) 3-2

Page

Prefix/Suffix Selections

Add CR Suffix to All Symbologies 4-3

Add Prefix 4-3

Prefix

Suffix

Function Code Transmit

Intercharacter Delay 4-5
Interfunction Delay 4-5
Intermessage Delay 4-6

Clear One Prefix 4-3
Clear All Prefixes 4-3
Add Suffix 4-4
Clear One Suffix 4-4
Clear All Suffixes 4-4
*Enable 4-4
Disable 4-4

Data Formatter Selections

*Default Data Format (None) 5-3

Data Format Editor

Data Formatter

Enter Data Format 5-3
Clear One Data Format 5-3
Clear All Data Formats 5-3
Off 5-4
*On, but Not Required 5-4
On, Required 5-4

3200 User’s Guide 9 - 3

Selection

Symbologies

All Symbologies

Codabar

Codabar

Codabar Start/Stop Char.

Codabar Check Char.

Codabar Message Length

Code 39

Code 39

Code 39 Start/Stop Char.

Code 39 Check Char.

Code 39 Message Length

Code 32 Pharmaceutical
(PARAF)

Code 39 Full ASCII

Interleaved 2 of 5

Interleaved 2 of 5

Setting

* Indicates default

All Symbologies Off 6-1
All Symbologies On 6-1
Default All Codabar

Settings
Off 6-2

*On 6-2
*Don’t Transmit 6-2

Transmit 6-2
*No Check Char. 6-3
Validate, But Don’t Transmit 6-3
Validate, and Transmit 6-3
Minimum (2 - 60) *4 6-3
Maximum (2 - 60) *60 6-3
Default All Code 39

Settings
Off 6-4
*On 6-4
*Don’t Transmit 6-4
Transmit 6-4
*No Check Char. 6-5
Validate, But Don’t

Transmit
Validate,

and Transmit
Minimum (0 - 48) *0 6-5
Maximum (0 - 48) *48 6-5
*Off 6-5
On 6-5
*Off 6-6
On 6-6
Default All Interleaved

2 of 5 Settings
Off 6-7
*On 6-7

Page

6-2

6-4

6-5

6-5

6-7

9 - 4 3200 User’s Guide

Selection

Interleaved 2 of 5 Check
Digit

Interleaved 2 of 5 Message
Length

Code 93

Code 93

Code 93 Message Length

Straight 2 of 5 Industrial

Straight 2 of 5 Industrial

Straight 2 of 5 Industrial
Message Length

Straight 2 of 5 IATA

Straight 2 of 5 IATA

Straight 2 of 5 IATA Mes­sage Length

Matrix 2 of 5

Matrix 2 of 5

Matrix 2 of 5 Message
Length

Code 11

Code 11

Code 11 Check Digits
Required

Setting

* Indicates default

*No Check Char. 6-8

Validate, But Don’t
Transmit

Validate, and Transmit 6-8
Minimum (2 - 80) *4 6-8
Maximum (2 - 80) *80 6-8
Default All Code 93

Settings
Off 6-9
*On 6-9
Minimum (0 - 80) *0 6-9
Maximum (0 - 80) *80 6-9
Default All Straight 2 of 5

Settings
*Off 6-10
On 6-10
Minimum (1 - 48) *4 6-10
Maximum (1 - 48) *48 6-10
Default All Straight 2 of 5 IATA

Settings
*Off 6-11
On 6-11
Minimum (1 - 48) *4 6-11
Maximum (1 - 48) *48 6-11
Default All Matrix 2 of 5

Settings
*Off 6-11
On 6-11
Minimum (1 - 80) *4 6-12
Maximum (1 - 80) *80 6-12
Default All Code 11

Settings
*Off 6-12
On 6-12
1 Check Digit 6-12
*2 Check Digits 6-12

Page

6-8

6-9

6-10

6-11

6-11

6-12

3200 User’s Guide 9 - 5

Selection

Code 11 Message Length

Code 128

Code 128

ISBT Concatenation

Code 128 Message Length

Code 128 Code Page Code 128 Code Page 6-14

Code 128 Function Code
Transmit

ISBT Concatenation

Telepen

Telepen

Telepen Output

Telepen Message Length

UPC A

UPC A

UPC A Check Digit

UPC A Number System

UPC A 2 Digit Addenda

UPC A 5 Digit Addenda

Setting

* Indicates default

Minimum (1 - 80) *4 6-13
Maximum (1 - 80) *80 6-13
Default All Code 128

Settings
Off 6-13
*On 6-13
On 6-13
*Off 6-13
Minimum (0 - 80) *0 6-14
Maximum (0 - 80) *80 6-14

*Off 6-14
On 6-14
*Off 6-13
On 6-13
Default All Telepen

Settings
*Off 6-15
On 6-15
*AIM Telepen Output 6-15
Original Telepen Output 6-15
Minimum (1 - 60) *1 6-15
Maximum (1 - 60) *60 6-15
Default All

UPC A Settings
Off 6-16
*On 6-16
Off 6-16
*On 6-16
Off 6-16
*On 6-16
*Off 6-17
On 6-17
*Off 6-17
On 6-17

Page

6-13

6-15

6-16

9 - 6 3200 User’s Guide

Selection

UPC A Addenda Required

UPC E

UPC E0

UPC E1

UPC E Expand

UPC E Check Digit

UPC E Number System

UPC E 2 Digit Addenda

UPC E 5 Digit Addenda

UPC E Addenda Required

EAN/JAN 13

EAN/JAN 13

EAN/JAN 13 Check Digit

EAN/JAN 13 2 Digit
Addenda

EAN/JAN 13 5 Digit
Addenda

EAN/JAN 13 Addenda
Required

EAN/JAN 13 Addenda
Separator

ISBN Translate

Setting

* Indicates default

*Not Required 6-17
Required 6-17
Default All UPC E

Settings
Off 6-18
*On 6-18
*Off 6-18
On 6-18
*Off 6-18
On 6-18
Off 6-19
*On 6-19
Off 6-19
*On 6-19
*Off 6-20
On 6-20
*Off 6-20
On 6-20
*Not Required 6-19
Required 6-19
Default All EAN/

JAN 13 Settings
Off 6-20
*On 6-20
Off 6-20
*On 6-20
*Off 6-21
On 6-21
*Off 6-21
On 6-21
*Not Required 6-21
Required 6-21
Off 6-21
*On 6-21
*Off 6-22
On 6-22

Page

6-18

6-20

3200 User’s Guide 9 - 7

Selection

EAN/JAN 8

EAN/JAN 8

EAN/JAN 8 Check Digit

EAN/JAN 8 2 Digit
Addenda

EAN/JAN 8 5 Digit
Addenda

EAN/JAN 8 Addenda
Required

EAN/JAN 8 Addenda
Separator

Coupon Code

MSI Default All MSI Settings 6-24

MSI

MSI Check Character

MSI Message Length

Plessey Code Default All Plessey Settings 6-25

Plessey Code

Plessey Message Length

RSS-14

RSS-14

RSS Limited

Setting

* Indicates default

Default All EAN/
JAN 8 Settings

Off 6-22
*On 6-22
Off 6-22
*On 6-22
*Off 6-23
On 6-23
*Off 6-23
On 6-23
*Not Required 6-23
Required 6-23
Off 6-23
*On 6-23
Off 6-23
*On 6-17

*Off 6-24
On 6-24
*Validate Type 10, but Don’t

Transmit
Validate Type 10 and

Transmit
Minimum (4 - 48) *4 6-25
Maximum (4 - 48) *48 6-25

*Off 6-25
On 6-25
Minimum (4 - 48) *4 6-25
Maximum (4 - 48) *48 6-25
Default All

RSS-14 Settings
Off 6-26
*On 6-26
Default All RSS-14

Limited Settings

Page

6-22

6-24

6-24

6-26

6-26

9 - 8 3200 User’s Guide

Selection

RSS Limited

RSS Expanded

RSS Expanded

RSS Expanded Msg.
Length

EAN•UCC Emulation

China Post Code

China Post Code

China Post Code Msg.
Length

Setting

* Indicates default

Off 6-26
*On 6-26
Default All RSS-14

Expanded Settings
Off 6-27
*On 6-27
Minimum (4 - 74) *4 6-27
Maximum (4 - 74) *74 6-27
RSS Emulation 6-27
128 Emulation 6-27
*EAN•UCC Emulation Off 6-27
Default All China Post Code

Settings
*Off 6-28
On 6-28
Minimum (2 - 80) *4 6-28
Maximum (2 - 80) *80 6-28

Page

6-27

6-28

3200 User’s Guide 9 - 9

9 - 10 3200 User’s Guide

10

Product Specifications

3200 Product Specifications

Parameter Specification

Dimensions (Typical):

Height
Length
Width

Weight
Light Source 626 nm ± 30mn visible red LED
Scan Rate 270 scans per second in most usages
Skew Angle ±55 degrees
Pitch Angle ±55 degrees
Scan Contrast 20% minimum
Voltage Requirements 5VDC ±5% at imager
Current Draw (Max): Scanning

3200 @ 4.75 - 5.25Vdc 245mA 90mA

Temperature Ranges:

Operating

Storage
Humidity 0 to 95% non-condensing at 122° F (50° C)

Mechanical Drop

Vibration Withstands 5G peak from 22 to 300 Hz
ESD Sensitivity 8 kV Air discharge
Sealant Rating IP41

Product Agency Compliance

3.8 inches (9.52 cm)
6 inches (15.3 cm)

2.7 inches (6.8 cm)

5.1 ounces (145 g)

Standby

32° F to +122° F (0° C to +50° C)

-4° F to +140° F (-20° C to +60° C)

Operational after 25 drops from 4 feet
(1.2 m) to concrete

International: IEC60825-1 Eye Safety (Class 1 LED)
Japan: VCCI
Taiwan: BSMI
South Korea: MIC
Australia/NZ: C-Tick marked.
Europe:
CE 2004/108/EC EMC directive (Class B EMI)
USA: FCC (Class B)
Canada: ICES-003 (Class B)

3200 User’s Guide 10 - 1

Standard Cable Pinouts

10 Pin RJ41 Modular Plug

connects to the imager handle

1

2 Cord shield

3 Tied to supply power

4 Supply ground

5 Terminal clock

6 Terminal data

7 Supply power input (Refer to tables on page 10-1)

8 Keyboard data

9 Keyboard clock

10

Keyboard Wedge

10 - 2 3200 User’s Guide

Standard Cable Pinouts

10 Pin RJ41 Modular Plug

connects to the imager handle

1

2 Cord shield

3 Prog 1 (Tied to supply power for primary cable)

4 Supply ground

5 Receive data - Serial data to imager

6 Transmit data - Serial data from imager

7 Supply power input (Refer to tables on page 10-1)

8 Request to send data

9 Clear to send data

10

Serial Output

3200 User’s Guide 10 - 3

Standard Cable Pinouts

10 Pin Modular Plug

connects to the imager handle

1

2 Data +

3 Tied to supply power

4 Supply ground

567 5 volt supply power input

8910 Data -

USB

10 - 4 3200 User’s Guide

11

!

Caution:

Do not submerge the imager in water. Do not use

abrasive wipes or tissues on the imager’s window –

abrasive wipes may scratch the window.

Never use solvents (e.g., acetone, benzene, ether, or

phenol-based agents) on the housing or window –

solvents may damage the finish or the window.

Maintenance

Repairs

Repairs and/or upgrades are not to be performed on this product. These
services are to be performed only by an authorized service center. Please see

Customer Support on page 12-1 for further information.

Maintenance

The 3200 provides reliable and efficient operation with a minimum of care.
Although specific maintenance is not required, the following periodic checks
ensure dependable scanner operation:

Cleaning the Device

Reading performance may degrade if the scanner’s window is not clean. If the
window is visibly dirty, or if the scanner isn’t operating well, clean the window with
a soft cloth or lens tissue dampened with water (or a mild soapy water solution).
If a soapy water solution is used, rinse with a clean lens tissue dampened with
water only.

The scanner’s housing may also be cleaned the same way.

Inspecting Cords and Connectors

Inspect the scanner’s interface cable and connector for wear or other signs of
damage. A badly worn cable or damaged connector may interfere with scanner
operation. Contact your Hand Held Products distributor for information about
cable replacement. Cable replacement instructions are on page 11-2.

3200 User’s Guide 11 - 1

Replacing the Interface Cable

Cable
Release

The standard interface cable is attached to the scanner with an 10-pin modular
connector. When properly seated, the connector is held in the 3200 scanner’s
handle by a flexible retention tab. The interface cable is designed to be field
replaceable.

• Order replacement cables from Hand Held Products or from an authorized
distributor.

• When ordering a replacement cable, specify either the 6 ft. USB cable (p/n
AMCBC000800DAR0) or the 6 ft keyboard wedge cable (p/n
AMCBC000900DAR0).

To Replace the 3200 Interface Cable:

1. Turn the power to the host system

OFF.

2. Disconnect the scanner’s cable from

the terminal or computer.

3. Locate the small hole on the bottom of

the scanner’s handle. This is the
cable release.

4. Straighten one end of a paper clip.

5. Insert the end of the paper clip into the

small hole and press in. This
depresses the retention tab, releasing
the connector. Pull the connector out
while maintaining pressure on the
paper clip, then remove the paper clip.

6. Replace with the new cable.

Insert the connector into the opening
and press firmly. The connector is
keyed to go in only one way, and will click into place.

Troubleshooting

The scanner automatically performs self-tests whenever you turn it on. If your
scanner is not functioning properly, review the following Troubleshooting Guide
to try to isolate the problem.

Is the power on? Is the red aiming illumination line on?

If the red aiming illumination line isn’t illuminated, check that:

• The cable is connected properly.

• The host system power is on (if external power isn’t used).

• The trigger works.

11 - 2 3200 User’s Guide

Is the scanner having trouble reading your symbols?

If the scanner isn’t reading symbols well, check that the symbols:

• Aren’t smeared, rough, scratched, or exhibiting voids.

• Aren’t coated with frost or water droplets on the surface.

• Are enabled in the scanner or in the decoder to which the scanner connects.

Is the barcode displayed but not entered?

The barcode is displayed on the host device correctly, but you still have to press
a key to enter it (the Enter/Return key or the Tab key, for example).

You need to program a suffix. Programming a suffix enables the scanner to
output the barcode data plus the key you need (such as “CR”) to enter the data
into your application. Refer to Prefix/Suffix Overview on page 4-1 for further
information.

Does the scanner read the barcode incorrectly?

If the scanner reads a barcode, but the data is not displayed correctly on the host
screen:

• The scanner may not be programmed for the appropriate terminal interface.
For example, you scan “12345” and the host displays “@es%.”

Reprogram the scanner with the correct Plug and Play or Terminal selection
barcode. See Chapter 1 and Chapter 2.

• The scanner may not be programmed to output your barcode data properly.
For example, you scan “12345” and the host displays “A12345B.”

Reprogram the scanner with the proper symbology selections. See Chapter

6.

The scanner won’t read your barcode at all.

1. Scan the sample barcodes in the back of this manual. If the scanner reads

the sample barcodes, check that your barcode is readable.
Verify that your barcode symbology is enabled (see Chapter 6).

2. If the scanner still can’t read the sample barcodes, scan All Symbologies on

page 6-1.

If you aren’t sure what programming options have been set in the scanner, or if
you want the factory default settings restored, scan Resetting the Standard

Product Defaults on page 9-1.

3200 User’s Guide 11 - 3

11 - 4 3200 User’s Guide

12

Customer Support

Technical Assistance

If you need assistance installing or troubleshooting, please call your Distributor
or the nearest Hand Held Products technical support office:

North America/Canada

Telephone: [phone]
Fax number: [phone]

E-mail: [e-mail]

Latin America

Telephone: [phone]
Telephone: [phone]

E-mail: [e-mail]

Brazil

Telephone: [phone]
Fax: [phone]

E-mail: [e-mail]

Mexico

Telephone: [phone]

E-mail: [e-mail]

Europe, Middle East, and Africa

Telephone: [phone]
Fax: [phone]

E-mail: [e-mail]

Asia Pacific

Telephone - Hong Kong: [phone] or
Telephone - China: [phone]

E-mail: [e-mail]

Japan

Telephone: [phone]

E-mail: [e-mail]

Malaysia

Telephone: [phone]

E-mail: [e-mail]

2511-3050

3200 User’s Guide 12 - 1

Online Technical Assistance

You can also access technical assistance online at www.handheld.com.

For Further Information

To download the full User’s Guide for these products, visit our website at

www.handheld.com

.

Product Service and Repair

Hand Held Products provides service for all its products through service centers
throughout the world. To obtain warranty or non-warranty service, return the unit
to Hand Held Products (postage paid) with a copy of the dated purchase record
attached. Contact the appropriate location below to obtain a Return Material
Authorization number (RMA #) before returning the product.

North America

Telephone: [phone]
Fax: [phone]

E-mail: [e-mail]

Latin America

Telephone: [phone]
Telephone: [phone]
Fax: [phone]

E-mail: [e-mail]

Brazil

Telephone: [phone]
Fax: [phone]

E-mail: [e-mail]

Mexico

Telephone: [phone]
Fax: [phone]

E-mail: [e-mail]

Europe, Middle East, and Africa

Telephone: [phone]
Fax: [phone]

E-mail: [e-mail]

Asia Pacific

Telephone: [phone]
Fax: [phone]

E-mail: [e-mail]

12 - 2 3200 User’s Guide

Japan

Telephone: [phone]
Fax: [phone]

E-mail: [e-mail]

Online Product Service and Repair Assistance

You can also access product service and repair assistance online at

www.handheld.com.

Limited Warranty

Hand Held Products, Inc. ("Hand Held Products") warrants its products to be free
from defects in materials and workmanship and to conform to Hand Held
Products’ published specifications applicable to the products purchased at the
time of shipment. This warranty does not cover any Hand Held Products product
which is (i) improperly installed or used; (ii) damaged by accident or negligence,
including failure to follow the proper maintenance, service, and cleaning
schedule; or (iii) damaged as a result of (A) modification or alteration by the
purchaser or other party, (B) excessive voltage or current supplied to or drawn
from the interface connections, (C) static electricity or electro-static discharge,
(D) operation under conditions beyond the specified operating parameters, or (E)
repair or service of the product by anyone other than Hand Held Products or its
authorized representatives.

This warranty shall extend from the time of shipment for the duration published
by Hand Held Products for the product at the time of purchase ("Warranty
Period"). Any defective product must be returned (at purchaser’s expense)
during the Warranty Period to Hand Held Products’ factory or authorized service
center for inspection. No product will be accepted by Hand Held Products
without a Return Materials Authorization, which may be obtained by contacting
Hand Held Products. In the event that the product is returned to Hand Held
Products or its authorized service center within the Warranty Period and Hand
Held Products determines to its satisfaction that the product is defective due to
defects in materials or workmanship, Hand Held Products, at its sole option, will
either repair or replace the product without charge, except for return shipping to
Hand Held Products.

EXCEPT AS MAY BE OTHERWISE PROVIDED BY APPLICABLE LAW, THE
FOREGOING WARRANTY IS IN LIEU OF ALL OTHER COVENANTS OR
WARRANTIES, EITHER EXPRESSED OR IMPLIED, ORAL OR WRITTEN,
INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

HAND HELD PRODUCTS’ RESPONSIBILITY AND PURCHASER’S
EXCLUSIVE REMEDY UNDER THIS WARRANTY IS LIMITED TO THE
REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT. IN NO EVENT
SHALL HAND HELD PRODUCTS BE LIABLE FOR INDIRECT, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES, AND, IN NO EVENT, SHALL ANY
LIABILITY OF HAND HELD PRODUCTS ARISING IN CONNECTION WITH

3200 User’s Guide 12 - 3

ANY PRODUCT SOLD HEREUNDER (WHETHER SUCH LIABILITY ARISES
FROM A CLAIM BASED ON CONTRACT, WARRANTY, TORT, OR
OTHERWISE) EXCEED THE ACTUAL AMOUNT PAID TO HAND HELD
PRODUCTS FOR THE PRODUCT. THESE LIMITATIONS ON LIABILITY
SHALL REMAIN IN FULL FORCE AND EFFECT EVEN WHEN HAND HELD
PRODUCTS MAY HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH
INJURIES, LOSSES, OR DAMAGES. SOME STATES, PROVINCES, OR
COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATIONS OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

All provisions of this Limited Warranty are separate and severable, which means
that if any provision is held invalid and unenforceable, such determination shall
not affect the validity of enforceability of the other provisions hereof. Use of any
peripherals not manufactured/sold by Hand Held Products voids the warranty.
This includes but is not limited to: cables, power supplies, cradles, and docking
stations. Hand Held Products, Inc. extends these warranties only to the first end­users of the products. These warranties are nontransferable.

The limited duration of the warranty for the 3200 is for two (2) years and six (6)
months for the cables.

12 - 4 3200 User’s Guide

Appendix A

Symbology Chart

Symbology

China Post

Codabar

Codablock F

Code 2 of 5

Code 11
Code 16K o ]K
Code 39
Code 32 Pharma-

ceutical (PARAF)

Code 49

Code 93

Code 128

UCC/EAN-128

EAN/JAN-8

EAN/JAN-13
EAN-13 with

Extended
Coupon Code

CodeIDAIMIDHex

Q]X051

a

q

f

h

b

<]X03C

l

i

j

I]C149

D ]E4 44 UPC-A with

d

d]E364

ID

61

m

]F

71

m

]O

66

m

]R

68

m

]H

m

6F No Read 9C
62

m

]A

6C Reduced Space

m

]T

69

m

]G

6A

m

]C

64

]E

0

Symbology

IATA 2 of 5

Interleaved 2 of 5

Korea Post

Matrix 2 of 5

MSI

Plessey Code

PosiCode

Symbology (RSS­14, RSS Limited,
RSS Expanded)

Telepen

Trioptic Code

UPC-A

Extended Coupon
Code

UPC-E

CodeIDAIMIDHex

f

e

?]X03F

m]X06D

g

n]P06E

W

y

t

=]X03D

c

c]E363

E

All Symbologies

]R

]l

]M

]p

]e

]B

]E

]E

ID

66

m

65

m

67

m

57

m

79

m

74

m

63

0

45

0

99

Note: “m” represents the AIM modifier character. Refer to International

Technical Specification, Symbology Identifiers, for AIM modifier character
details.

Note: Prefix/Suffix entries for specific symbologies override the universal (All

Symbologies, 99) entry.

Refer to

Data Editing

beginning on page 4-1 and

Data Formatting

beginning on

page 5-1 for information about using Code ID and AIM ID.

3200 User’s Guide A - 1

ASCII Conversion Chart (Code Page 1252)

Note:

This table applies to U.S. style keyboards. Certain characters may differ depending on your
Country Code/PC regional settings.

Dec Hex Char Dec Hex Char Dec Hex Char Dec Hex Char

0 00 NUL 32 20 64 40 @ 96 60 ‘
1 01 SOH 33 21 ! 65 41 A 97 61 a
2 02 STX 34 22 “ 66 42 B 98 62 b
3 03 ETX 35 23 # 67 43 C 99 63 c
4 04 EOT 36 24 $ 68 44 D 100 64 d
5 05 ENQ 37 25 % 69 45 E 101 65 e
6 06 ACK 38 26 & 70 46 F 102 66 f
7 07 BEL 39 27 ‘ 71 47 G 103 67 g
8 08 BS 40 28 ( 72 48 H 104 68 h
9 09 HT 41 29 ) 73 49 l 105 69 i
10 0A LF 42 2A * 74 4A J 106 6A j
11 0B VT 43 2B + 75 4B K 107 6B k
12 0C FF 44 2C , 76 4C L 108 6C l
13 0D CR 45 2D - 77 4D M 109 6D m
14 0E SO 46 2E . 78 4E N 110 6E n
15 0F SI 47 2F / 79 4F O 111 6F o
16 10 DLE 48 30 0 80 50 P 112 70 p
17 11 DC1 49 31 1 81 51 Q 11 3 71 q
18 12 DC2 50 32 2 82 52 R 114 72 r
19 13 DC3 51 33 3 83 53 S 11 5 73 s
20 14 DC4 52 34 4 84 54 T 116 74 t
21 15 NAK 53 35 5 85 55 U 117 75 u
22 16 SYN 54 36 6 86 56 V 11 8 76 v
23 17 ETB 55 37 7 87 57 W 119 77 w
24 18 CAN 56 38 8 88 58 X 120 78 x
25 19 EM 57 39 9 89 59 Y 121 79 y
26 1A SUB 58 3A : 90 5A Z 122 7A z
27 1B ESC 59 3B ; 91 5B [ 123 7B {
28 1C FS 60 3C < 92 5C \ 124 7C |
29 1D GS 61 3D = 93 5D ] 125 7D }
30 1E RS 62 3E > 94 5E ^ 126 7E ~
31 1F US 63 3F ? 95 5F _ 127 7F

A - 2 3200 User’s Guide

Dec Hex Char Dec Hex Char Dec Hex Char Dec Hex Char

128 80
129 81 161 A1 ¡ 193 C1 Á 225 E1 á
130 82 ‚ 162 A2 ¢ 194 C2 Â 226 E2 â
131 83 ƒ 163 A3 £ 195 C3 Ã 227 E3 ã
132 84 „ 164 A4 ¤ 196 C4 Ä 228 E4 ä
133 85 … 165 A5 ¥ 197 C5 Å 229 E5 å
134 86 † 166 A6 ¦ 198 C6 Æ 230 E6 æ
135 87 ‡ 167 A7 § 199 C7 Ç 231 E7 ç
136 88 ˆ 168 A8 ¨ 200 C8 È 232 E8 è
137 89 ‰ 169 A9 © 201 C9 É 233 E9 é
138 8A Š 170 AA 202 CA Ê 234 EA ê

139 8B ‹ 171 AB « 203 CB Ë 235 EB ë
140 8C Œ 172 AC ¬ 204 CC Ì 236 EC ì
141 8D 173 AD - 205 CD Í 237 ED í
142 8E Ž 174 AE ® 206 CE Î 238 EE î
143 8F 175 AF ¯ 207 CF Ï 239 EF ï
144 90 176 B0 ° 208 D0 Ð 240 F0 ð
145 91 ‘ 177 B1 ± 209 D1 Ñ 241 F1 ñ
146 92 ’ 178 B2 ² 210 D2 Ò 242 F2 ò
147 93 “ 179 B3 ³ 211 D3 Ó 243 F3 ó
148 94 ” 180 B4 ´ 212 D4 Ô 244 F4 ô
149 95 • 181 B5 µ 213 D5 Õ 245 F5 õ
150 96 – 182 B6 ¶ 214 D6 Ö 246 F6 ö
151 97 — 183 B7 · 215 D7 × 247 F7 ÷
152 98 ˜ 184 B8 ¸ 216 D8 Ø 248 F8 ø
153 99 ™ 185 B9 ¹ 217 D9 Ù 249 F9 ù
154 9A š 186 BA 218 DA Ú 250 FA ú

155 9B › 187 BB » 219 DB Û 251 FB û
156 9C œ 188 BC ¼ 220 DC Ü 252 FC ü
157 9D 189 BD ½ 221 DD Ý 253 FD ý
158 9E ž 190 BE ¾ 222 DE Þ 254 FE þ
159 9F Ÿ 191 BF ¿ 223 DF ß 255 FF ÿ

€

€

160 A0 192 C0 À 224 E0 à

3200 User’s Guide A - 3

Code Page Mapping of Printed barcodes

Code pages define the mapping of character codes to characters. If the data
received does not display with the proper characters, it may be because the
barcode being scanned was created using a code page that is different from the
one the host program is expecting. If this is the case, select the code page with
which the barcodes were created. The data characters should then appear
properly.

Note: The Code Page option is available for Code 39, Code 93, and Code 128.

Code Page Standard Description
1CP ISO646
2 (Default) ISO 2022 Automatic National Replacement

Characters
3CP Binary
82 ISO 2022 11 Swe Swedish Replacement Characters
83 ISO 2022 69 Fra French/Belgium Replacement Charac-

ters
81 ISO 2022 25 Fra French/Belgium Replacement Charac-

ters
84 ISO 2022 11 Ger German Replacement Characters
85 ISO 2022 11 Ita Italian Replacement Characters
86 ISO 2022 11 Swi Swiss Replacement Characters
87 ISO 2022 11 UK British Replacement Characters
88 ISO 2022 11 Dan Danish Replacement Characters
89 ISO 2022 11 Nor Norwegian Replacement Characters
90 ISO 2022 11 Spa Spanish Replacement Characters

A - 4 3200 User’s Guide

UPC A

0 123456 7890

Interleaved 2 of 5

Code 128

EAN 13

1234567890

Code 128

9 780330 290951

654

EAN 8

3210 5

456123

80

UPC-E

Sample Symbols

Code 93

123456-9$

Straight 2 of 5 Industrial

123456

Matrix 2 of 5

6543210

RSS-14

(01)00123456789012

Code 39

Codabar

BC321

A13579B

Sample Symbols

Programming Chart

A

C

Save

B

Discard

F

E

D

Note:

If you make an error while scanning the letters or digits (before scanning
Save), scan Discard, scan the correct letters or digits, and Save.

0

2

6

1

7

5

4

3

8

9

Hand Held Products, Inc.

700 Visions Drive
P.O. Box 208
Skaneateles Falls, NY 13153-0208

3200-UG Rev A

2/08
