Goalzero BOULDER 100BC User Manual
TM
100BC
GET TO KNOW YOUR GEAR
Front View
Kickstand
2
HOW IT WORKS
Plug the 8mm blue-ringed cable into the INPUT port on the Goal Zero Yeti or Sherpa and angle
the Boulder 100 Briefcase toward the sun with the attached kickstand. You’ll get the best
solar charging experience if you continue to reposition the solar panel throughout the day.
Back View
8mm Output
(for charging & chaining)
3
HOW TO CHAIN
To chain multiple Boulder 100 Briefcases together, and for Boulder configurations
over 150W, you’ll need to purchase a combiner cable from Goal Zero. Give our
customer solutions center a call for help picking the right cable for your setup.
Boulder 100 Briefcase Solar Panel
Charges the following Approx. Charge time
GOAL ZERO Sherpa 50 3 hrs
GOAL ZERO Sherpa 100 3-4 hrs
GOAL ZERO Yeti 150 3-6 hrs
GOAL ZERO Yeti 400 8-16 hrs
GOAL ZERO Yeti 1400 29-57 hrs
Solar Panel
Rated Power 100W
Open Circuit Voltage 18-22V
Cell Type Monocrystalline
Ports
Solar port (blue, 8mm male/female) 14-22V, up to 7A (100W max)
General
Weight 25.9 lbs (11.7 kg)
Dimensions 21.75 x 26.75 x 3.5 in (55.2 x 70.0 x 8.9 cm)
Certs
Warranty 12 months
4
FREQUENTLY ASKED QUESTIONS
Q: Are the Boulder Solar Panels waterproof?
A: Yes. The Boulders are designed to withstand the elements, so they’re great for
permanent and semi-permanent installations. What you’re recharging from the Boulders
is what needs your help to stay dry, so keep those power packs and power stations
covered up and protected from the dust, rain, and snow.
Q: Can I chain a Boulder 100 Briefcase with other Boulders?
A: Depends on the panels. Yes, you can chain the Boulder 100 Briefcase with other
Boulders that have an 8mm input or input connector, like the Boulder 50 or the older
Boulder 30, by inserting the 8mm blue-ringed connector of the Boulder 100 Briefcase
into the 8mm input of the other Boulder Solar Panel. When chaining Boulder Solar
Panels in configurations over 150W, you’ll need to purchase a combiner cable from Goal
Zero. Give our customer solutions center call to determine the right cable for your setup.
Q: What can I charge directly from the Boulder Solar Panels?
A: All of our Boulder Solar Panels are designed to charge Sherpa Power Packs and Goal
Zero Yeti Portable Power Stations. If you’re looking to recharge things like headlamps,
phones, and other USB devices, check out our foldable Nomad Solar Panels.
Q: How long will it take to charge my Goal Zero Yeti from a Boulder Solar Panel?
A: That depends on a few factors – how big the Yeti it is, how big the Boulder it is, how
cloudy it is, how hot it is, just to name a few. We’ve created a handy calculator that takes
all of these factors into consideration. Also, great news, all the Yetis allow for something
called “pass-through power”, this means you can be trickle charging your Yeti and using it
to power your gear, all at the same time.
Q: Can I mount the Boulder Solar Panels to my roof?
A: The Boulder 100 Briefcase is not designed to be mounted permanently to a fixture;
this briefcase fold-and-go style allows you to be more portable. For mountable panels,
take a look at the Boulder 50 and 100 Solar Panels.
5
CONOZCA SUS DISPOSITIVOS
Vista frontal
Soporte
6
CÓMO FUNCIONA
Conecte el cable con el anillo azul de 8 mm al puerto de ENTRADA (INPUT) del Goal Zero
Yeti o Sherpa y oriente el maletín del Boulder 100 hacia el sol con el soporte al que va unido.
Conseguirá una mejor carga solar si continúa recolocando el panel solar a lo largo del día.
Vista posterior
Salida de 8 mm
(para la carga y
encadenamiento)
7
