Gateway 18-inch LCD TV

Specifications

Specifications are subject to change without notice or obligation.

Display Panel

Screen size

Diagonal 18-inch





Aspect ratio

4:3 wide





Number of pixels

1024 (Horizontal, RGB Trio) × 768 (Vertical) pixels





Pixel pitch

0.3585 × 0.3585 mm





Luminance

450 cd/m2, at APL13% typical

Contrast ratio

350:1 typical





Response time

25 ms typical





Colors

16.7 M colors / 8 bits





Viewing angle

80° Horizontal / +50,-60° Vertical









Power Source

Input voltage

90 ~ 240 Vac, 47.5 Hz -63 Hz





Input current

2.0 A





Power consumption

60 ± 10% Watts typical





Stand-by and Power Save

8 Watts max.





www.gateway.com

Gateway 18-inch LCD TV Specifications

Connector Types

1

RCA jacks for audio, video, and YPBPR

1

6-pin Din S-terminal for S-Video





1

15-pin D-SUB for RGB





1

F-terminal coax









Video Signal

Type

Analog







Polarity

Positive







Amplitude

0.7 Vp-p







Sync

0.3 V below video







Frequency

H: 15.734 KHz V: 60 Hz (NTSC)



H: 15.625 KHz V: 50 Hz (PAL)







Input impedance

75 ohms













YPBPR Signal (Component)

Type

Analog













Polarity

Positive









Amplitude

Y: 1 Vp-p, C: 0.286 Vp-p







Sync

0.3 V below video











Frequency Y/PB/PR

H: 15.734

KHz V: 60

Hz (NTSC)



H: 15.625

KHz V: 50

Hz (PAL)









2
