This chapter introduces you to the basic features of your
notebook. Read this chapter to learn:
■ How to identify the features of your Gateway
notebook
■ How to locate your notebook’s model and serial
number
■ How to locate the Microsoft Certificate of
Authenticity
■ How to locate the specifications for your notebook
■ What accessories are available for your notebook
Tips & TricksTo access the contents of this guide while you
are traveling, download an electronic copy
from www.gateway.com/support/manlib/
.
1
Chapter 1: Checking Out Your Gateway Solo 1450
Front
LCD panel
release
latch
Speaker
Battery
charge
indicator
Speaker
Power
indicator
ComponentIconDescription
LCD panel release latchOpen the LCD panel by sliding the release latch to the right.
SpeakersProvide audio output. Speakers are turned off while
headphones are connected.
Battery charge indicatorThe LED shows the battery activity and status.
■
LED green – battery is fully charged.
■
LED orange – battery is charging.
■
LED red – battery is low.
■
LED blinking and red – battery is very low.
This LED only lights up when your notebook is plugged in.
Power indicatorLights up when your notebook is turned on and shows the
notebook power status.
■
LED on – power is on.
■
LED blinking – notebook is in Standby mode.
■
LED off – power is off or notebook is in Hibernate mode.
2
www.gateway.com
Left side
Left side
Modem jack
Ethernet jack
Microphone jack
PC Card
eject button
Headphone jack
PC Card
slot
Diskette
drive
Diskette drive
eject button
ComponentIconDescription
Modem jackPlug a modem cable into this jack. For more information, see “Connecting
the modem” on page 31.
Ethernet jackPlug a 10/100 Ethernet network cable into this jack. For more information,
see “Connecting to a wired Ethernet network” on page 32.
Microphone
jack
Headphone
jack
PC Card
eject button
PC Card slotInsert one Type II or Type III PC Card into this slot. For more information,
Diskette driveInsert a standard 3.5-inch diskette into this drive. For more information,
Plug a microphone into this jack.
Plug amplified speakers or headphones into this jack. The built-in
speakers are turned off when a device is plugged into this jack.
Press this eject button to remove the PC Card from the PC Card slot. For
more information, see “Adding and removing a PC Card” on page 252.
see “Adding and removing a PC Card” on page 252.
see “Using the diskette drive” on page 78.
Diskette drive
eject button
Press the eject button to remove a diskette from the drive. For more
information, see “Using the diskette drive” on page 78.
www.gateway.com
3
Chapter 1: Checking Out Your Gateway Solo 1450
Right side
BatteryManual eject hole
Recordable drive
CD/DVD/
Activity
indicator
Eject button
ComponentIconDescription
BatteryThe battery is located here. For more information, see
“Changing batteries” on page 133.
CD/DVD/Recordable driveInsert CDs, CD-R/RWs, or DVDs into this drive. For
more information, see “Using the CD or DVD drive” on
page 79.
This drive may be a CD, DVD, CD-RW, or combination
DVD/CD-RW drive. To determine the type of drive in
your notebook, examine the drive tray’s plastic cover
and compare the logo to those listed in “Identifying drive
types” on page 79.
Activity indicatorLights up when your computer is accessing the CD,
DVD, or recordable drive. For more information, see
“Using the CD or DVD drive” on page 79.
Eject buttonPress the eject button to open the disc tray. For more
information, see “Using the CD or DVD drive” on
page 79.
Manual eject holeInsert a straightened paperclip into this hole to open the
drive tray if pressing the drive eject button fails to open
the tray.
4
www.gateway.com
Back
Back
Kensington
lock slot
Power
connector
USB
ports
Monitor
port
Parallel
port
Ventilation
fan
ComponentIconDescription
Kensington™ lock slotSecure your computer to an object by connecting a
Kensington cable lock to this slot.
Power connectorPlug the AC adapter cable into this connector.
USB portsPlug USB (Universal Serial Bus) devices (such as a USB
Iomega™ Zip™ drive, printer, scanner, camera, keyboard,
or mouse) into these ports.
Monitor portPlug an analog VGA monitor into this port.
Parallel portPlug a parallel device (such as a printer) into this port.
Ventilation fanHelps cool internal components. Do not block or insert
objects into these slots.
www.gateway.com
5
Chapter 1: Checking Out Your Gateway Solo 1450
Bottom
Hard drive
Memory
bay
Reset
hole
Ventilation
fan
Battery
Battery
latch
System
label
ComponentIconDescription
Hard driveThe hard drive is located here. For more information, see “Replacing
the hard drive” on page 259.
BatteryThe battery is located here. For more information, see “Changing
batteries” on page 133.
Battery latchSlide to release the battery.
System labelIncludes the product model number. For more information, see
“Identifying your model” on page 10.
Ventilation fanHelps cool internal components. Do not block or insert objects into
these slots.
6
www.gateway.com
ComponentIconDescription
Reset holeInsert a straightened paper clip into this hole to manually restart your
notebook.
Memory bayInstall as many as two memory modules into this bay. For more
information, see “Adding or replacing memory” on page 255.
Bottom
www.gateway.com
7
Chapter 1: Checking Out Your Gateway Solo 1450
Keyboard area
Multi-function buttons
Power button
Keyboard
Touchpad
Status
indicators
ComponentIconDescription
Power buttonPress to turn your notebook on or off. You can also configure the
power button for Standby/Resume mode. For more information on
configuring the power button mode, see “Changing the power
scheme” on page 137.
Multi-function
buttons
Status indicatorsInform you when a drive is in use or when a button has been
8
Press these buttons to open programs you assign to them. By
default, these buttons are set to open your e-mail application, your
Web browser, online help, and another program that you assign.
For more information, see “Multi-function buttons” on page 27 and
“Programming the multi-function buttons” on page 165.
pressed that affects how the keyboard is used. For more
information, see “Status indicators” on page 22.
www.gateway.com
Keyboard area
ComponentIconDescription
TouchpadProvides all the functionality of a mouse. For more information,
see “Using the EZ Pad touchpad” on page 28 and “Changing the
touchpad settings” on page 163.
KeyboardA full-sized 86-key keyboard. For more information, see “Using the
keyboard” on page 23.
www.gateway.com
9
Chapter 1: Checking Out Your Gateway Solo 1450
Identifying your model
ImportantThe labels shown in this section are for informational
purposes only. Label information varies by model, features
ordered, and location.
Gateway model number
The label on the bottom of your notebook contains information that identifies
your notebook model and its features. Gateway Technical Support will need
this information if you call for assistance.
Gateway model number
Internal wireless devices
Gateway serial number
You can locate the Gateway serial number:
■ Printed on a white sticker on the bottom or back of your notebook.
■ Printed on the customer invoice that came with your notebook. The
invoice will also contain your customer ID number.
■ Displayed in HelpSpot in Windows XP. Click Start, then click Help and
Support
10
. Click View product serial number.
www.gateway.com
Microsoft Certificate of Authenticity
The Microsoft Certificate of Authenticity label found on the bottom of your
notebook includes the product key code for your operating system.
Identifying your model
www.gateway.com
11
Chapter 1: Checking Out Your Gateway Solo 1450
Finding your specifications
For more information about your computer, such as memory size, memory
type, and hard drive size, go to the
Gateway’s eSupport page at www.gateway.com/support
has links to additional Gateway documentation and detailed specifications.
In Windows XP, view your computer’s serial number or check your
specifications by clicking
My Computer Info.
Start, Help and Support, then clicking
My Computer Info link in HelpSpot or visit
. The eSupport page also
12
www.gateway.com
Finding your specifications
You can also find out more about your computer at the Gateway eSupport site.
Visit www.gateway.com/support
.
www.gateway.com
13
Chapter 1: Checking Out Your Gateway Solo 1450
Accessories
Gateway offers accessories that can help you make the most of using your
notebook.
Batteries and automobile/airplane power adapters
If you run your notebook on battery power for extended periods, you may
want to buy an additional battery so that you can swap batteries when
necessary. See “Changing batteries” on page 133 for more information about
using an additional battery in your notebook.
With an automobile/airplane power adapter, you can save battery power by
plugging your notebook into an automobile cigarette lighter or an airplane
in-flight power receptacle.
Carrying cases
Gateway has large-capacity carrying cases if you need additional space for
accessories or supplies.
Peripheral devices
You can attach devices such as a keyboard, mouse, printer, or monitor to your
notebook.
14
Memory
Large programs, such as multimedia games or graphics programs, use a lot of
memory. If your programs are running more slowly than you think they
should, try adding more memory.
Printers
You can attach many types of printers to your notebook. The most common
types are inkjet and laser printers, which print in color or black and white.
See “Installing a printer, scanner, or other peripheral device” on page 33 for
more information about attaching a printer to your notebook.
Inkjet printers and cartridges are relatively inexpensive, but usually they are
slower than laser printers. Using an inkjet color printer, you can print pictures,
banners, and greeting cards, as well as documents.
Laser printers and cartridges are more expensive, but usually they print much
faster than inkjet printers. Laser printers are better than inkjet printers when
you are printing large documents.
www.gateway.com
Getting Started
This chapter provides basic information about your
Gateway notebook. Read this chapter to find out how to:
■ Connect the AC adapter
■ Start and turn off your notebook
■ Identify the status indicators
■ Use the keyboard
■ Use the EZ Pad touchpad
■ Connect the modem
■ Connect to an Ethernet network
■ Install peripheral devices
2
Chapter 2: Getting Started
Connecting the AC adapter
You can run your notebook using an AC adapter or the notebook battery. The
battery was shipped to you partially charged. You should use the AC adapter
right away to fully charge the battery. Allow 24 hours for the battery to fully
charge.
ImportantIf the battery is not fully charged before you use your
notebook on battery power for the first time, the battery life
may be much shorter than you expect. If the battery life
seems short even after being charged for 24 hours, the
battery may need to be recalibrated. For information on
recalibrating the battery, see “Recalibrating the battery” on
page 132.
To connect the AC adapter:
1 Connect the power cord to the AC adapter.
16
WarningReplace the power cord if it becomes damaged. The
replacement cord must be of the same type and voltage
rating as the original cord or your notebook may be
damaged.
www.gateway.com
Connecting the AC adapter
2 Connect the AC adapter to your notebook’s power connector.
3 Plug the power cord into a wall outlet.
The battery charge indicator turns on (see “Front” on page 2 for the
location of the battery charge indicator). If the battery charge indicator
does not turn on, unplug the adapter from your notebook, then plug it
back in.
4 When you finish using your notebook for the first time, turn your
notebook off and leave your notebook connected to AC power for at least
24 hours. The battery charge indicator may not show a charge for several
hours. For more information about the battery charge indicator on your
model, see “Monitoring the battery charge” on page 130.
5 If the battery charge indicator does not show a full charge after 24 hours,
contact Gateway Technical Support at
www.gateway.com/support/contact.
WarningDo not attempt to disassemble the AC adapter. The
AC adapter has no user-replaceable or user-serviceable
parts inside. The AC adapter has dangerous voltages that
can cause serious injury or death. Contact Gateway about
returning defective AC adapters.
www.gateway.com
17
Chapter 2: Getting Started
Protecting from power source problems
During a power surge, the voltage level of electricity coming into your
computer can increase to far above normal levels and cause data loss or system
damage. Protect your computer and peripheral devices by connecting them
to a surge protector, which absorbs voltage surges and prevents them from
reaching your computer.
WarningHigh voltages can enter your computer through both the
power cord and the modem connection. Protect your
computer by using a surge protector. If you have a
telephone modem, use a surge protector that has a
modem jack. If you have a cable modem, use a surge
protector that has an antenna/cable TV jack. During an
electrical storm, unplug both the surge protector and the
modem.
18
www.gateway.com
Starting your notebook
To st art your notebook:
1 Open your notebook by sliding the latch on the front of your notebook
to the right and lifting the LCD panel.
2 Press the power button located above the keyboard.
Power button
Starting your notebook
The power button is preset to On/Off mode. However, you can also set
it to function in Standby/Resume mode. For instructions on changing
the power button mode, see “Changing power settings” on page 137.
3 If you are starting your notebook for the first time, follow the on-screen
instructions to set up your notebook.
Waking up your notebook
When you have not used your notebook for several minutes, it may enter a
power-saving mode called Standby. While in Standby, the power indicator
flashes.
If your notebook is in Standby mode, “wake” it up by pressing the power
button. For more information on changing power-saving settings, see
“Changing power settings” on page 137.
www.gateway.com
19
Chapter 2: Getting Started
Turning off your notebook
To turn off your notebook in W indows XP:
1 Click Start, then click Turn Off Computer. The Turn Off Computer dialog box
opens.
2 Click Tu r n Of f. Windows shuts down and turns off your notebook.
ImportantIf for some reason you cannot use the Turn Off Computer
option in Windows to turn off your notebook, press and
hold the power button for about five seconds, then release
it.
To turn off your notebook in Windows 2000:
1 Click Start, then click Shut Down. The Shut Down Windows dialog box
opens.
20
2 Click the arrow button to open the What do you want your computer to do
list
, then click Shut down.
3 Click OK. Windows shuts down and turns off your notebook.
ImportantIf for some reason you cannot use the Shut Down option
in Windows to turn off your notebook, press and hold the
power button for about five seconds, then release it.
www.gateway.com
Restarting (rebooting) your notebook
Restarting (rebooting) your
notebook
If your notebook does not respond to keyboard or touchpad input, you may
have to close programs that are not responding. If closing unresponsive
programs does not restore your notebook to normal operation, you may have
to restart (reboot) your notebook.
To cl ose unresponsive programs and restart your notebook:
1 Press CTRL+ALT+DEL. A window opens that lets you close a program that
is not responding.
2 Click the program that is not responding.
3 Close the program by clicking End Task.
4 If your notebook does not respond, turn it off, wait ten seconds and turn
it on again.
ImportantIf your notebook does not turn off immediately, complete
the following steps until the notebook turns off:
■
Press and hold the power button for about five seconds,
then release it
■
Insert a straightened paper clip into the reset hole on the
bottom of your notebook
■
Remove AC power and the battery for more than 10
seconds
As a part of the regular startup process, a program to check the disk status
runs automatically. When the checks are finished, Windows starts.
www.gateway.com
21
Chapter 2: Getting Started
Status indicators
Status indicators inform you when a drive is being used or when a button
has been pressed that affects how the keyboard is used.
Pad lock
Caps lock
Scroll lock
Diskette drive
Hard drive
Disc drive
IndicatorIconDescription
Caps LockCaps Lock is turned on.
Pad LockThe embedded numeric keypad is turned on.
1
Scroll LockScroll Lock is turned on.
Diskette driveThe standard 1.44 MB diskette drive is in use.
Hard driveThe hard drive is in use.
Disc driveThe CD, DVD, or recordable drive is in use.
22
www.gateway.com
Using the keyboard
Navigati
Your notebook features a full-size keyboard that functions the same as a
desktop computer keyboard. Many of the keys have been assigned alternate
functions, including shortcut keys for Windows, function keys for specific
system operations, and the Pad Lock keys for the numeric keypad.
You can attach an external keyboard to your notebook using a USB port. You
do not need to shut down your notebook to connect a keyboard.
Using the keyboard
FN key
Application key
Windows key
Function keys/
System keys
Numeric
keypad
Windows
key
Volume key s
on keys/
Arrow keys
FN key
www.gateway.com
23
Chapter 2: Getting Started
Key types
The keyboard has several different types of keys. Some keys perform specific
actions when pressed alone and other actions when pressed in combination
with another key.
Key typeIconDescription
Function keysPress these keys labeled F1 to F12 to perform actions in
programs. For example, pressing
Each program uses different function keys for different purposes.
Refer to the program documentation to find out more about the
function key actions.
F1 may open help.
System keysPress these colored keys in combination with the
perform specific actions. For more information, see “System key
combinations” on page 25.
Navigation keysPress these keys to move the cursor to the beginning of a line,
to the end of a line, up the page, down the page, to the beginning
of a document, or to the end of a document.
Volume keysPress these colored keys in combination with the
increase or decrease the volume or to turn off all sound. For more
information, see “System key combinations” on page 25,
“Adjusting the volume” on page 81, and “Adjusting the volume
in Windows 2000” on page 84.
FN key to
FN key to
FN keyPress the FN key in combination with a colored system key (such
STATUS, STANDBY, or PAUSE) to perform a specific action.
as
Application keyPress this key for quick access to shortcut menus and help
assistants in Windows.
Windows keyPress this key to open the Windows Start menu. This key can
also be used in combination with other keys to open utilities like
F (Search utility), R (Run utility), and E (Explorer utility).
Numeric keypadUse these keys to type numbers when the numeric keypad is
turned on. Press
Arrow keysPress these keys to move the cursor up, down, right, or left.
FN+PAD LOCKto turn on the numeric keypad.
24
www.gateway.com
System key combinations
When you press an FN key and a system key at the same time, your notebook
performs the action identified by the colored text or icon on the key.
Using the keyboard
Press and hold F
N while
pressing this system key...
To...
Display the power status box in the upper-left corner of your
display. The box shows the battery charge level, the BIOS version,
and whether the AC adapter is being used. Press the key
combination again to close this box.
Toggle the notebook display between the LCD, an external
monitor, or both displays at the same time. A monitor must be
plugged into the monitor port on your notebook.
Enter Standby mode. Press the power button to leave Standby
mode. For more information, see “Changing power modes” on
page 136.
Turn on Pad Lock so you can use the numeric keypad. Press this
key combination again to turn off Pad Lock. The Pad Lock status
indicator appears when this function is turned on.
Pause the text scrolling in a DOS screen. The Scroll Lock status
indicator appears when this function is turned on. Press the key
combination again to continue scrolling. (This function is only
available in some programs.)
Pause execution of a DOS program. (This function is only available
in some programs.)
Stop the currently running DOS program. (This function is only
available in some programs.)
Mute the sound. Press the key combination again to restore the
sound. For more information, see “Adjusting the volume” on
page 81, and “Adjusting the volume in Windows 2000” on
page 84.
www.gateway.com
25
Chapter 2: Getting Started
Press and hold FN while
pressing this system key...
To...
Increase volume. For more information, see “Adjusting the
volume” on page 81, and “Adjusting the volume in Windows 2000”
on page 84.
Decrease volume. For more information, see “Adjusting the
volume” on page 81, and “Adjusting the volume in Windows 2000”
on page 84.
26
www.gateway.com
Multi-function buttons
Press the multi-function buttons to open programs you assign to them. These
buttons can be assigned different functions than those listed. For more
information, see “Programming the multi-function buttons” on page 165.
User-defined
shortcut
Help
Internet
E-mail
Multi-function buttons
ButtonIconPress to...
E-mailOpen your e-mail program.
InternetOpen your Web browser.
HelpOpen online help.
User-defined shortcutOpen the program you assign to this key.
www.gateway.com
27
Chapter 2: Getting Started
Using the EZ Pad touchpad
The EZ Pad™ consists of a touchpad, two buttons, and a rocker switch.
28
Left
touchpad
button
When you move your finger on the touchpad, the pointer (arrow) on the screen
moves in the same direction.
Rocker
switch
www.gateway.com
Right
touchpad
button
Touchpad
You can use the EZ-Pad left and right buttons below the touchpad to select
objects.
You can assign a function to the rocker switch between the touchpad buttons.
This function can be to scroll up or down, maximize or minimize the active
window, or open and close the Start menu. For more information about
programming the rocker switch, see “Changing the touchpad settings” on
page 163.
Using the touchpad
To . . .D o t h is...
Using the EZ Pad touchpad
Move the pointer
on the screen.
Select an object
on the screen.
Start a program
or open a file or
folder.
Move your finger around on the
touchpad. If you run out of space
and need to move the pointer
farther, lift your finger, move it to the
middle of the touchpad, then
continue moving your finger.
Position the pointer over the object.
Press the left button below the
touchpad once. This action is
called clicking.
Position the pointer over the object.
Press the left button below the
touchpad twice in rapid
succession. This action is called
double-clicking.
www.gateway.com
29
Chapter 2: Getting Started
To...Do this...
Access a shortcut
menu or find
more information
about an object
on the screen.
Move an object
on the screen.
Position the pointer over the object.
Quickly press and release the right
button once. This action is called
right-clicking.
Position the pointer over the object.
Press the left button and hold it
down, then use the touchpad to
move (drag) the object to the
appropriate part of the screen.
Release the button to drop the
object where you want it.
30
www.gateway.com
Connecting the modem
Your notebook has a built-in 56K modem that you can use to connect it to
a standard telephone line.
CautionTo reduce the risk of fire, use only No. 26 AWG or larger
telecommunications line cord.
To connect the modem:
1 Insert one end of the modem cable into the modem jackon the left
side of your notebook.
Connecting the modem
2 Insert the other end of the modem cable into a telephone wall jack. The
modem will not work with digital or PBX telephone lines.
3 Start your notebook, then start your communications program.
www.gateway.com
31
Chapter 2: Getting Started
Connecting to a wired Ethernet
network
Your notebook has a network jack that you can use to connect it to a 10/100
wired Ethernet network.
ImportantYour notebook may be equipped with built-in wireless
Ethernet or you may have a wireless Ethernet PC Card for
networking. For information about connecting to a wireless
Ethernet network, see “Using a Wireless Ethernet
Network” on page 169. For information about installing a
wireless Ethernet PC Card, see “Adding and removing a
PC Card” on page 252.
To connect to a wired Ethernet network:
1 Insert one end of the network cable into the network jackon the
left side of your notebook.
32
2 Insert the other end of the network cable into a network jack. Ask your
network administrator to help you select the correct network jack.
Your notebook is now physically connected to the network. Your network
administrator can help you log onto your network.
www.gateway.com
Installing a printer, scanner, or other peripheral device
Broadband Internet connections
You can use your notebook’s Ethernet jack for more than just networking.
Many broadband Internet connections, such as cable modems and DSL
modems, connect to your notebook’s Ethernet jack. For more information,
see “Using the Internet” on page 67.
Installing a printer, scanner, or
other peripheral device
Your computer has one or more of the following ports: Universal Serial Bus
(USB) and parallel. These ports are used for connecting peripheral devices such
as printers, scanners, and digital cameras to your computer. For more
information about port locations, see “Checking Out Your Gateway Solo
1450” on page 1.
USB ports support plug-and-play and hot swapping, which means that your
computer will usually recognize such a device whenever you plug it into the
appropriate port. When you use a USB device for the first time, your computer
will prompt you to install any software the device needs. After doing this,
you can disconnect and reconnect the device at any time.
Parallel port devices are not plug-and-play. Refer to the device documentation
for detailed information and installation instructions.
Help and
Support
For more information about installing peripheral devices in
Windows XP, click Start, then click Help and Support.
Type the keyword installing devices in the HelpSpot Search box , then click the arrow.
www.gateway.com
33
Chapter 2: Getting Started
34
www.gateway.com
Getting Help
This chapter tells you about additional information
resources available to help you use your computer. Read
this chapter to learn how to access:
■ HelpSpot
■
Online help
■ Gateway Web site
™
3
Chapter 3: Getting Help
HelpSpot
Your computer may include HelpSpot, an easily accessible collection of help
information, troubleshooters, instructional videos, and automated support.
Use HelpSpot to answer questions about Windows and to help you quickly
discover and use the many features of your Gateway computer. HelpSpot also
has an area called Contact Gateway that helps you find the right resource at
Gateway to answer your questions or help solve your problems.
To start HelpSpot:
■ Click Start, then click Help and Support. HelpSpot opens.
36
If this is the first time you have started HelpSpot on your computer, you
may experience a brief wait while HelpSpot builds the help database, then
HelpSpot will display an introductory video.
www.gateway.com
You can find help information by clicking a link, performing a search, or
browsing the index. To learn about using your Gateway computer, your
touchpad, and other tasks, click the
Using your computer link on the HelpSpot
main page.
HelpSpot
www.gateway.com
37
Chapter 3: Getting Help
Searching for a topic
To search for a topic in HelpSpot, type a word or phrase (keyword) in the
Search box located at the top of any HelpSpot screen, then click the
arrowbutton.
Search box
Search results
header
Search results
headers
For each search, you receive the following search result types:
■ Suggested Topics - These topics are located in HelpSpot and are relevant
to your search topic
■ Full-text Search Matches - These topics are located in HelpSpot and
contain the words you entered in the
■ Microsoft Knowledge Base - These topics are located on the Microsoft.com
Search box
Web site (you must be connected to the Internet to search for and access
these topics) and contain the words you entered in the
■ Gateway.com Search - These topics are located on the Gateway.com Web
Search box
site (you must be connected to the Internet to search for and access these
topics) and contain the words you entered in the
Search box
38
To view a list of your search results, click the results header for the type of
results you want to view.
To view a topic, click the topic name in the
www.gateway.com
Search Results list.
HelpSpot Videos
HelpSpot contains several short videos to help introduce you to new concepts
or show you how to perform various tasks.
To play a HelpSpot video:
■ To watch a video in HelpSpot, click Video Tutorials on the HelpSpot home
page, then click a video title. The video plays.
HelpSpot
www.gateway.com
39
Chapter 3: Getting Help
Online help
Many programs provide information online so you can research a topic or
learn how to perform a task while you are using the program. Most online
help information can be accessed by selecting a topic from a
by clicking a
You can search for information by viewing the help contents, checking the
index, searching for a topic or keyword, or browsing through the online help.
Help menu or
Help button.
40
www.gateway.com
Gateway Web site
Gateway provides a variety of information on its Web site to help you use
your computer.
Gateway Web site
Visit the Gateway Web site at www.gateway.com for:
■ Technical documentation and product guides
■ Technical tips and support, including online chat services
■ Hardware drivers
■ Order status
■ Frequently asked questions (FAQs)
For more information about connecting to the Internet, see “Using the
Internet” on page 67.
www.gateway.com
41
Chapter 3: Getting Help
42
www.gateway.com
Windows Basics
Read this chapter to learn on how to:
■ Use the Windows desktop
■ Manage files and folders
■ Work wi t h d ocument s
■ Use shortcuts
4
Chapter 4: Windows Basics
About the Windows environment
After your computer starts, the first screen you see is the Windows desktop.
The desktop is like the top of a real desk. Think of the desktop as your
personalized work space where you open programs and perform other tasks.
Your desktop may be different from the example shown below, depending on
how your computer is set up.
Help and
Support
For more information about the Windows XP desktop, click
Start, then click Help and Support.
Type the keyword Windows desktop in the HelpSpot
Search box , then click the arrow.
44
www.gateway.com
Using the desktop
The desktop contains the taskbar, the Start button, and the Recycle Bin icon.
Desktop elementsDescription
The taskbar is the bar at the bottom of the screen containing the Start button
on the left and a clock on the right. Other buttons on the taskbar represent
programs that are running.
Click a program’s button on the taskbar to open the program’s window.
The Start button provides access to programs, files, help for Windows and
other programs, and computer tools and utilities.
Click the Start button, then open a file or program by clicking an item on
the menu that opens.
The Recycle Bin is where files, folders, and programs that you discarded
are stored. You must empty the Recycle Bin to permanently delete them
from your computer. For instructions on how to use the Recycle Bin, see
“Deleting files and folders” on page 54.
About the Windows environment
Using the Start menu
You can start programs, open files, customize your system, get help, search
for files and folders, and more using the Start menu.
To use the Start menu:
1 Click the Start button on the lower left of the Windows desktop. The Start
menu opens showing you the first level of menu items.
2 To see all programs and files in the Start menu, click All Programs.
When you move the mouse pointer over any menu item that has an
arrow next to it, another menu, or submenu, opens and reveals related
files, programs, or commands.
www.gateway.com
45
Chapter 4: Windows Basics
3 Click a file or program to open it.
46
Help and
Support
For more information about the Windows XP Start menu,
click Start, then click Help and Support.
Type the keyword Windows Start menu in the HelpSpot
Search box , then click the arrow.
www.gateway.com
Identifying Window items
When you double-click the icon for a drive, folder, file, or program, a window
opens on the desktop. This example shows the Local Disk (C:) window, which
opens after double-clicking the
window.
Local Disk (C:) icon in the My Computer
About the Windows environment
Title bar
Menu bar
Every program window looks a little different because each has its own menus,
icons, and controls. Most windows include these items:
Window itemDescription
The title bar is the horizontal bar at the top
of a window that shows the window title.
Close
Maximize
Minimize
Clicking the minimize button reduces the
active window to a button on the taskbar.
Clicking the program button in the taskbar
opens the window again.
Clicking the maximize button expands the
active window to fit the entire screen. Clicking
the maximize button again restores the
window to its former size.
www.gateway.com
47
Chapter 4: Windows Basics
Window itemDescription
Clicking the close button closes the active
window or program.
Clicking an item on the menu bar starts an
action such as Print or Save.
Help and
Support
For more information about windows in Windows XP, click
Start, then click Help and Support.
Type the keyword window in the HelpSpot Search box
, then click the arrow.
48
www.gateway.com
Working with files and folders
Working with files and folders
You can organize your files and programs to suit your preferences much like
you would store information in a file cabinet. You can store these files in
folders and copy, move, and delete the information just as you would
reorganize and throw away information in a file cabinet.
Viewing drives
Drives are like file cabinets because they hold files and folders. A computer
almost always has more than one drive. Each drive has a letter, usually Local
Disk (C:) for the hard drive and 3½ Floppy (A:) for the diskette drive. You also
have a CD, CD-RW, DVD, or combination DVD/CD-RW drive.
To vi ew the drives on your computer:
■ In Windows XP, click Start, then click My Computer on the Start menu.
- OR -
In Windows 2000, double-click the
Drives
My Computer icon on the desktop.
www.gateway.com
49
Chapter 4: Windows Basics
To see the files and folders on a drive:
■ Double-click the drive icon. If you do not see the contents of a drive after
you double-click its icon, click
Show the contents of this drive.
Help and
Support
For more information about files and folders in
Windows XP, click Start, then click Help and Support.
Type the keyword files and folders in the HelpSpot
Search box , then click the arrow.
50
www.gateway.com
Creating folders
Folders are much like the folders in a file cabinet. They can contain files and
other folders.
Files are much like paper documents—letters, spreadsheets, and pictures—that
you keep on your computer. In fact, all information on a computer is stored
in files.
Folders
Files
Working with files and folders
To create a folder:
1 In Windows XP, click Start, then click My Computer on the Start menu.
- OR -
In Windows 2000, double-click the
My Computer icon on the desktop.
2 Double-click the drive where you want to put the new folder. Typically,
Local Disk (C:) is your hard drive and 3½ Floppy (A:) is your diskette
drive. If you do not see the contents of the drive, click
of this drive
.
Show the contents
3 If you want to create a new folder inside an existing folder, double-click
the existing folder. If you do not see the contents of the drive or folder,
click
Show the contents of this drive or Show the contents of this folder.
www.gateway.com
51
Chapter 4: Windows Basics
4 Click File, New, then click Folder. The new folder is created.
5 Type a name for the folder, then press ENTER. The new folder name
appears by the folder icon.
Help and
Support
For information on renaming folders, see “Shortcuts” on page 66.
For more information about creating files and folders in
Windows XP, click Start, then click Help and Support.
Type the keyword creating files and folders in the
HelpSpot Search box , then click
the arrow.
Copying and moving files and folders
The skills you need to copy and move files are called copying, cutting, and
pasting.
When you copy and paste a file or folder, you place a copy of the file or folder
on the Windows clipboard, which temporarily stores it. Then, when you decide
what folder you want the copy to go in (the destination folder), you paste it
there.
When you cut and paste a file or folder, you remove the file or folder from
its original location and place the file or folder on the Windows clipboard.
When you decide where you want the file or folder to go, you paste it there.
ImportantThe clipboard stores whatever you cut or copy until you cut
or copy again. Then the clipboard contains the new
information only. Therefore, you can paste copies of a file
or folder into more than one place, but as soon as you copy
or cut a different file or folder, the original file or folder is
deleted from the clipboard.
52
www.gateway.com
Working with files and folders
To copy a file or folder to another folder:
1 Locate the file or folder you want to copy. For more information, see
“Viewing drives” on page 49 and “Searching for files” on page 57.
2 Right-click (press the right mouse or touchpad button) the file or folder
that you want to copy. A pop-up menu opens on the desktop.
3 Click Copy on the pop-up menu.
4 Open the destination folder.
5 With the pointer inside the destination folder, right-click.
6 Click Paste. A copy of the file or folder appears in the new location.
To move a file or folder to another folder:
1 Locate the file or folder you want to move. For more information, see
“Viewing drives” on page 49 and “Searching for files” on page 57.
2 Right-click (press the right mouse or touchpad button) the file or folder
that you want to move. A pop-up menu opens on the desktop.
3 Click Cut on the pop-up menu.
4 Open the destination folder.
5 With the pointer inside the destination folder, right-click.
6 Click Paste. The file or folder you moved appears in its new location and
is removed from its old location.
Help and
Support
For more information about moving files and folders in
Windows XP, click Start, then click Help and Support.
Type the keyword copying files and folders or moving files and folders in the HelpSpot Search box
, then click the arrow.
www.gateway.com
53
Chapter 4: Windows Basics
Deleting files and folders
When you throw away paper files and folders, you take them from the file
cabinet and put them in a trash can. Eventually the trash can is emptied.
In Windows, you throw away files and folders by first moving them to the
Windows trash can, called the Recycle Bin, where they remain until you decide
to empty the bin.
You can recover any file in the Recycle Bin as long as the bin has not been
emptied.
To delete files or folders:
1 In My Computer or Windows Explorer, click the files or folders that you
want to delete. For instructions on how to select multiple files and folders,
see “Shortcuts” on page 66.
If you cannot find the file you want to delete, see “Searching for files”
on page 57.
2 Click File, then click Delete. Windows moves the files and folders to the
Recycle Bin.
54
Help and
Support
For more information about deleting files and folders in
Windows XP, click Start, then click Help and Support.
Type the keyword deleting files and folders in the
HelpSpot Search box , then click
the arrow.
To re cover files or folders from the Recycle Bin:
1 Double-click the Recycle Bin icon. The Recycle Bin window opens and lists
the files and folders you have thrown away since you last emptied it.
2 Click the files or folders that you want to restore. For instructions on how
to select multiple files and folders, see “Shortcuts” on page 66.
3 Click File, then click Restore. Windows returns the deleted files or folders
to their original locations.
www.gateway.com
Working with files and folders
Help and
Support
For more information about recovering files and folders
from the Recycle Bin in Windows XP, click Start, then click
Help and Support.
Type the keyword Recycle Bin in the HelpSpot Search
box , then click the arrow.
To empty the R ecycle Bin:
CautionEmptying the Recycle Bin permanently erases any files or
folders in the bin. These files cannot be restored.
1 Double-click the Recycle Bin icon on the desktop. The Recycle Bin window
opens.
2 Click File, then click Empty Recycle Bin. Windows asks you if you are sure
that you want to empty the bin.
3 Click Ye s. Windows permanently deletes all files in the Recycle Bin.
Help and
Support
For more information about emptying the Recycle Bin in
Windows XP, click Start, then click Help and Support.
Type the keyword emptying Recycle Bin in the HelpSpot
Search box , then click the arrow.
Browsing for files and folders
A file or folder that you need is rarely right on top of your Windows desktop.
It is usually on a drive inside a folder that may be inside yet another folder,
and so on.
Windows drives, folders, and files are organized in the same way as a real file
cabinet in that they may have many levels (usually many more levels than
a file cabinet, in fact). So you usually will have to search through levels of
folders to find the file or folder that you need. This is called browsing.
www.gateway.com
55
Chapter 4: Windows Basics
To browse for a file:
1 In Windows XP, click Start, then click My Computer. The My Computer
window opens.
- OR -
In Windows 2000, double-click the
My Computer window opens.
My Computer icon on the desktop. The
2 Double-click the drive or folder that you think contains the file or folder
that you want to find. If you do not see the contents of the drive or folder,
click
Show the contents of this drive or Show the contents of this folder.
56
www.gateway.com
Searching for files
3 Continue double-clicking folders and their subfolders until you find the
file or folder you want.
Help and
Support
For more information about browsing for files and folders
in Windows XP, click Start, then click Help and Support.
Type the keyword files and folders in the HelpSpot
Search box , then click the arrow.
Searching for files
If you are looking for a particular file or folder or a set of files or folders that
have characteristics in common, but you do not remember where they are
stored on your hard drive, you can use the Search utility to search by:
■ Name or part of a name
■ Creation date
■ Modification date
■ File type
■ Text contained in the file
■ Time period in which it was created or modified
You can also combine search criteria to refine searches.
Files and folders found using this utility can be opened, copied, cut, renamed,
or deleted directly from the list in the results window.
www.gateway.com
57
Chapter 4: Windows Basics
Using the Search utility
To find files and folders using the Search utility:
1 In Windows XP, click Start, then click Search. The Search Results window
opens. Click
- OR -
All files and folders.
In Windows 2000, click
Search Results window opens.
Start, Search, then click For Files or Folders. The
2 If you want to search by file or folder name, type in all or part of the
file or folder name in the name box in the left pane of the window.
■ If you type all of the name, Search will list all files and folders of
that name.
58
■ If you type part of the name, Search will list all of the file and folder
names containing the letters you typed.
www.gateway.com
Searching for files
3 Click Search or Search Now. When the search is completed, Windows lists
the files and folders whose names contain the text that you searched for.
4 Open a file, folder, or program by double-clicking the name in the list.
Help and
Support
For more information about searching for files and folders
in Windows XP, click Start, then click Help and Support.
Type the keyword searching in the HelpSpot Search box
Using advanced search options
Search can find files meeting more criteria than file name. You can narrow
your search by selecting the search options that you want. You can search by
the:
■ Date the file was created or modified.
■ Size of the file.
■ Type of file, such as a program or a text document.
www.gateway.com
, then click the arrow.
59
Chapter 4: Windows Basics
Adding icons to the desktop
You may want to add an icon (shortcut) to the desktop for a program that
you use frequently.
To add icons to the desktop:
1 Click Start, then click All Programs.
2 Right-click (click the right mouse or touchpad button) the program that
you want to add to the desktop.
3 Click Send To, then click Desktop (create shortcut). A shortcut icon for that
program appears on the desktop.
Help and
Support
For more information about desktop icons in Windows XP,
click Start, then click Help and Support.
Type the keyword desktop icons in the HelpSpot Search
box , then click the arrow.
60
www.gateway.com
Working with documents
Computer documents include word processing files, spreadsheet files, or other
similar files. The basic methods of creating, saving, opening, and printing a
document apply to most of these types of files.
Working with documents
The following examples show how to create, save, open, and print a document
using Microsoft
Microsoft Excel, Microsoft WordPad, and Microsoft Publisher.
For more information about using a program, click
®
Word. Similar procedures apply to other programs such as
Creating a new document
To create a new document:
1 Click Start, All Programs, then click Microsoft Word. Microsoft Word starts
and a blank document opens.
2 If you do not see the New Document pane, click File, then click New.
Help on its menu bar.
New
Document
pane
www.gateway.com
61
Chapter 4: Windows Basics
3 Click General Templates. The Templates dialog box opens.
4 Click a tab for the type of document you want to create, click a document
template style, then click
OK. The document template opens.
62
5 Begin composing your document. Use the menus and toolbar buttons at
the top of the window to format the document.
Help and
Support
For more information about working with documents in
Windows XP, click Start, then click Help and Support.
Type the keyword documents in the HelpSpot Search box
, then click the arrow.
www.gateway.com
Saving a document
After you create a document, you need to save it if you want to use it later.
To save a document in Microsoft Word:
1 Click File, then click Save. The Save As dialog box opens.
2 Click the arrow button to open the Save in list, then click the drive or
folder where you want to save the file. If you do not see the folder you
want, browse through the folders listed below the
3 Type a new file name in the File name box.
Save in
list
Working with documents
Save in list.
File
name
4 Click Save.
Help and
Support
For more information about saving documents in
Windows XP, click Start, then click Help and Support.
Type the keyword saving in the HelpSpot Search box
, then click the arrow.
www.gateway.com
63
Chapter 4: Windows Basics
Opening a document
To view, revise, or print an existing document, first you need to open it. Open
the document in the program that it was created in.
To open a document in Microsoft Word:
1 Click Start, All Programs, then click Microsoft Word. Microsoft Word starts
and a blank document opens.
2 Click File, then click Open.
3 Click the arrow button to open the Look in list, then click the drive or
folder that contains the file you want to open. If you do not see the folder
you want, browse through the folders listed below the
Look in
list
Look in list.
64
4 Double-click the document file name. The document opens.
Help and
Support
For more information about opening documents in
Windows XP, click Start, then click Help and Support.
Type the keyword opening files in the HelpSpot Search
box, then click the arrow.
www.gateway.com
Printing a document
To print a document, you must have a printer connected to your computer
or have access to a network printer. For more information about installing or
using your printer, refer to the printer documentation.
To print a document in Microsoft Word:
1 Make sure that the printer is turned on and loaded with paper.
2 Start Microsoft Word and open a document.
3 Click File, then click Print. The Print dialog box opens.
4 Set the print options, then click OK. The document prints.
Working with documents
Help and
Support
For more information about printing documents in
Windows XP, click Start, then click Help and Support.
Type the keyword printing in the HelpSpot Search box
, then click the arrow.
www.gateway.com
65
Chapter 4: Windows Basics
Shortcuts
The following table shows a few shortcuts that you can use in Windows and
almost all programs that run in Windows. For more information on Windows
shortcuts, see your Windows or program documentation.
To...Do this...
Copy a file, folder, text, or graphicClick the item, then press CTRL + C.
Cut a file, folder, text, or graphicClick the item, then press CTRL + X.
Paste a file, folder, text, or graphicClick inside the folder or window where you want to paste
the object, then press
CTRL + V.
Select multiple items in a list or in a
window
Select multiple adjacent items in a list
or window
Permanently delete a file or folderClick the file or folder, then press
Rename a file or folderClick the file or folder, press
Close the active window or programPress
Switch to a different file, folder, or
running program
Help and
Support
For more information about Windows keyboard shortcuts
in Windows XP, click Start, then click Help and Support.
Type the keyword Windows keyboard shortcuts in the
HelpSpot Search box, then click
the arrow.
Click the first item, press and hold down the CTRL key,
then click each of the remaining items.
Click the first item in the list, press and hold down the
SHIFT key, then click the last item in the list.
file is permanently deleted. The file or folder is not stored
in the Recycle Bin.
F2, type the new name, then
ENTER.
press
ALT + F4.
Press ALT +TAB.
SHIFT + DELETE. The
66
www.gateway.com
Using the Internet
This chapter provides information about the Internet and
the World Wide Web. Read this chapter to learn how to:
5
■ Set up and access an Internet account using America
Online
■
Connect to a Web site using a browser
■ Download files from the Internet
■ Send and receive e-mail using America Online
®
Chapter 5: Using the Internet
Learning about the Internet
The Internet is a worldwide network of computers linked together to provide
information to people everywhere. The two most popular services on the
Internet are e-mail and the World Wide Web. You can access this network by
connecting your computer to a telephone, DSL (Digital Subscriber Line), or
cable line and signing up with an Internet Service Provider (ISP).
Cable and DSL modems, a connection known as broadband, use your TV cable
or special telephone lines to connect to your ISP and access the Internet. Cable
and DSL modems connect to your computer through an Ethernet jack and
provide a faster connection speed than if you use a standard telephone
modem.
ImportantFor the location of your modem and Ethernet jacks, see
“Left side” on page 3.
Internet Servers
store information so other
computers can access it
from the Internet.
Your c o m pu ter
connects to the
Internet through
an ISP.
68
ISP Servers
let you connect to
the Internet and
access your e-mail
messages.
www.gateway.com
Learning about the Internet
If you want to access the Internet you need:
■ A modem – a device that connects your computer to other computers
or servers using a telephone, DSL, or cable line.
■ An Internet Service Provider – a company that provides access to the
Internet through an ISP server. When you connect to an ISP, the ISP server
lets you access the Internet and your e-mail messages.
■ A Web browser – a program that displays information from the World
Wide Web.
■ An e-mail program – a program that lets you create, send, and receive
e-mail messages over the Internet.
www.gateway.com
69
Chapter 5: Using the Internet
Setting up an Internet account
Before you can view the information on the World Wide Web, you need to
set up an Internet account with an Internet Service Provider (ISP). If you have
chosen America Online as an ISP, follow these instructions to set up and
connect to your account. To set up a different ISP service or to transfer an
existing account to this computer, contact the ISP directly.
If you set up an account with America Online, an Internet e-mail address is
created for you. After completing the setup, you are ready to access the
Internet.
To set up an Internet acc ount with America Online:
1 Click Start, All Programs, then click America Online.
2 Follow the on-screen instructions. After setting up your account, you can
connect to the Internet and access your e-mail services.
Accessing your Internet account
To connect to your America Online Internet account:
1 Click Start, All Programs, then click America Online.
2 Complete the member name and password information, then click
Connect. Your computer dials the Internet account telephone number.
After connecting, the We lco m e window opens.
If you are using a service other than America Online, check with your ISP for
the correct procedure for connecting.
70
www.gateway.com
Setting up an Internet account
To disconnect from your America Online Internet account:
■ Click X in the top-right corner of the America Online window. Your
computer disconnects from the Internet.
ImportantMake sure that your computer disconnects correctly from
your Internet account. If you do not have an “unlimited
hours” ISP account, you may have to pay for the time that
you are connected, even if you are not at your computer.
If you are using a service other than America Online, check with your ISP for
the correct procedure for disconnecting.
Help and
Support
For general information about using Internet accounts in
Windows XP, click Start, then click Help and Support.
Type the keyword ISP in the HelpSpot Search box
, then click the arrow.
www.gateway.com
71
Chapter 5: Using the Internet
Using the World Wide Web
The World Wide Web is a multimedia window to the Internet that gives you
access to millions of information sources.
Information on the Web comes to you on Web pa ges, which are electronic
documents that you view using a Web page display program called a browser.
You can use any of the commercially available Web browsers, like Microsoft
Internet Explorer (which comes installed on your new computer), Netscape
Navigator, or the browser built into America Online.
Web p a ges can contain text, animations, music, and other multimedia features.
A group of related Web pages is called a Web sit e . You can access Web sites
to shop, track investments, read the news, download programs, and much
more.
You can explore a Web site or visit other Web sites by clicking areas on a Web
page called links or hyperlinks. A link may be colored or underlined text, a
picture, or an animated image. You can identify a link by moving the mouse
pointer over it. If the pointer changes to a hand, the item is a link.
To learn more about using the Web browser features, click
bar.
Web
page
Linked Web page
Help in the menu
Link
72
www.gateway.com
Connecting to a Web site
After you set up an account with an Internet Service Provider (ISP) such as
America Online, you can access the many information sources on the World
Wide Web.
To connect to a Web site:
1 Connect to your Internet account. After your computer connects, a
default opening page or welcome screen opens.
2 To go to a different Web site, type the address (called a URL for “Universal
Resource Locator”) in the browser address bar (for example
www.gateway.com
- OR -
On the current Web page, click a link to a Web site.
The Web browser locates the server computer on the Internet, downloads
(transfers) data to your computer, and displays the page on the site that
you requested.
), then click GO on the browser address bar.
Using the World Wide Web
Help and
Support
Sometimes Web pages display slowly. The speed that a Web page displays on
your screen depends on the complexity of the Web page and other Internet
conditions. Additionally, the speed of your connection will determine how
fast Web pages display.
For more information about connecting to a Web site in
Windows XP, click Start, then click Help and Support.
Type the keyword connecting to Web site in the
HelpSpot Search box , then click
the arrow.
www.gateway.com
73
Chapter 5: Using the Internet
Downloading files
Downloading is the process of transferring files from a computer on the
Internet to your computer.
To protect your computer against viruses, make sure that you scan the files
you download. For more information, see “Protecting your computer from
viruses” on page 226.
To download files or programs from a Web site:
1 Connect to your Internet account.
2 In the address bar, type the address of the Web site that contains the file
or program you want to download, then click
bar.
- OR -
Click a link on a Web page to navigate to the Web site containing the
file that you want to download.
3 Create or locate the folder where you want to store the file on your
computer.
GO on the browser address
74
4 Click the link on the Web page for the file that you want to download.
5 Follow the on-screen instructions for saving the file in the folder that
you want. A copy of the file is downloaded to your computer. The time
that it takes to transfer the file to your computer depends on file size
and Internet conditions.
6 Open the folder that you created.
7 Install or view the downloaded file by double-clicking it. If applicable,
follow the instructions provided on the Web site to run or install the
program.
Help and
Support
For more information about downloading files in
Windows XP, click Start, then click Help and Support.
Type the keyword downloading files in the HelpSpot Search box , then click the arrow.
www.gateway.com
Using e-mail
E-mail (electronic mail) lets you send messages to anyone who has an Internet
connection and e-mail address. E-mail is usually a free service of your Internet
account.
The Internet never closes, so you can send e-mail messages at any time. Your
e-mail messages arrive at most e-mail addresses in minutes.
An e-mail address consists of a user name, the @ symbol, and the Internet
domain name of the Internet Service Provider (ISP) or company that “hosts”
that user. Your e-mail address is assigned when you sign up for an account
with an ISP. For example, a person with an account with America Online
might have an e-mail address that is similar to this one:
jdoe@aol.com
User nameInternet domain name
Using e-mail
Sending e-mail
To send e-mail using America Online:
1 Connect to your America Online account.
2 Click Write.
3 Type the e-mail address of the recipient you want to send e-mail to in
the
Send To box.
4 Type the subject of your e-mail in the Subject box.
5 Type the e-mail message.
6 When finished, click Send Now. Your e-mail is sent over the Internet to
the e-mail address you specified.
www.gateway.com
75
Chapter 5: Using the Internet
Checking your e-mail
To check your e-mail using America Online:
1 Connect to your America Online account.
2 Click Read.
3 Double-click the message you want to read.
For more information about managing and organizing your e-mail messages,
see the online help in your e-mail program.
Help and
Support
For general information about using e-mail in Windows XP,
click Start, then click Help and Support.
Type the keyword e-mail in the HelpSpot Search box
, then click the arrow.
76
www.gateway.com
Using Multimedia
This chapter provides information on using the
multimedia capabilities of your notebook. Read this
chapter to learn how to:
■ Use the diskette drive
■ Use a CD or DVD drive
■ Adjust the volume
■ Play CDs and DVDs
■ Record and play audio files
■ Use Windows Media Player
■ Use MusicMatch
■ Use a recordable drive to create CDs
6
Chapter 6: Using Multimedia
Using the diskette drive
The diskette drive uses 3.5-inch diskettes (sometimes called floppy disks).
Diskettes are useful for storing files or transferring files to another computer.
WarningDo not expose diskettes to water or magnetic fields.
Exposure could damage the data on the diskette.
78
Diskette
slot
Eject
button
To use a disk ette:
1 Insert the diskette into the diskette slot with the label facing up.
2 To access a file on the diskette in Windows XP, click Start, then click My
Computer
double-click the file name.
- OR -
To access a file on the diskette in Windows 2000, double-click the
Computer
double-click the file name.
. Double-click the drive letter (for example, the A: drive), then
icon, the drive letter (for example, the A: drive), then
3 To remove the diskette, make sure that the diskette drive status indicator
is off (see “Status indicators” on page 22), then press the diskette eject
button.
www.gateway.com
My
Using the CD or DVD drive
You can use your computer to enjoy a wide variety of multimedia features,
such as making recordings, listening to audio CDs, and watching DVD movies.
Identifying drive types
Your Gateway notebook contains one of the following drive types. Look on
the front of the drive for one of the following logos:
Using the CD or DVD drive
CD drive
CD-RW drive
DVD drive
Combination
DVD/CD-RW drive
Use a CD drive for installing programs,
playing audio CDs, and accessing data.
You cannot use this drive to create CDs.
Use a CD-RW drive for installing programs,
playing audio CDs, and accessing data.
Use this drive for recording music and data
to CD-R or CD-RW discs. You can only write
to a CD-R disc once. You can write to and
erase CD-RW discs multiple times. For more
information, see “Using a recordable drive”
on page 103.
Use a DVD drive for installing programs,
playing audio CDs and DVDs, and
accessing data.
You cannot use this drive to create CDs.
Use a combination DVD/CD-RW drive for
installing programs, playing audio CDs and
DVDs, and accessing data.
Use this drive for recording music and data
to CD-R or CD-RW discs. You can only write
to a CD-R disc once. You can write to and
erase CD-RW discs multiple times. For more
information, see “Using a recordable drive”
on page 103.
www.gateway.com
79
Chapter 6: Using Multimedia
Inserting a CD or DVD
To insert a CD or DVD:
1 Press the eject button on the CD or DVD drive. After the tray opens
slightly, pull the disc tray completely open.
Activity indicatorManual eject hole
Eject button
80
2 Place the disc in the tray with the label facing up, then press down
carefully on the disc until it snaps into place.
ImportantWhen you place a single-sided disc in the tray, make sure
that the label side is facing up. If the disc has two playable
sides, place the disc so that the name of the side you want
to play is facing up.
3 Push the tray in until it is closed.
www.gateway.com
Adjusting the volume
Adjusting the volume in Windows XP
You can use the volume controls to adjust the overall volume and the volume
of specific sound devices in your computer.
To adjust the overall volume level using har dware controls:
■ On the keyboard, press the volume system key combination (FN+ or
F
N+) to change the volume, or press the mute system key combination
(F
N+) to turn off all sound.
To adjust the overall volume level from Windows:
1 Click Start, then click Control Panel. The Control Panel window opens. If
your Control Panel is in Category View, click
Devices
.
Sounds, Speech, and Audio
Adjusting the volume
2 Click/Double-click the Adjust the system volume or Sounds and Audio
Devices
. The Sounds and Audio Devices Properties dialog box opens.
www.gateway.com
81
Chapter 6: Using Multimedia
3 Click the Vol um e tab.
4 Drag the Device Volume slider to change the volume or click to select the
Mute check box, then click OK.
82
Help and
Support
For more information about adjusting volume in
Windows XP, click Start, then click Help and Support.
Type the keyword adjusting volume in the HelpSpot Search box , then click the arrow.
To adjust specific volume levels:
1 Click Start, then click Control Panel. The Control Panel window opens. If
your Control Panel is in Category View, click
Devices
.
Sounds, Speech, and Audio
2 Click/Double-click the Adjust the system volume or Sounds and Audio
Devices
. The Sounds and Audio Devices Properties dialog box opens.
www.gateway.com
3 Click the Vol um e tab.
4 Click Advanced in the Device volume area.
Adjusting the volume
If the device you want to adjust does not appear in the window, click
Options, Properties, the check box next to the audio device you want to
adjust, then click
OK.
5 Drag the volume level and balance sliders for the device you want to
adjust. For more information about the volume controls, click
window.
Help in the
6 Click X in the top-right corner of the window to close it.
www.gateway.com
83
Chapter 6: Using Multimedia
Adjusting the volume in Windows 2000
You can use the volume controls to adjust the overall volume and the volume
of specific sound devices in your computer.
To adjust the overall volume level using har dware controls:
■ On the keyboard, press the volume system key combination (FN+ or
F
N+) to change the volume, or press the mute system key combination
(F
N+) to turn off all sound.
To adjust the overall volume level from Windows:
■ Click the speaker iconon the taskbar, then drag the slider to change
the volume or click to select the
Mute check box.
84
www.gateway.com
Adjusting the volume
To adjust specific volume levels:
1 Double-click thespeakericonon the taskbar. The Volum e Co ntro l
window opens.
If the device you want to adjust does not appear in the Volume Control
window, click
then click
Options, Properties, the audio device you want to adjust,
OK.
2 Drag the volume level and balance sliders for the device you want to
adjust, then close the window. For more information about the volume
controls, click
Help in the Volume Control window.
www.gateway.com
85
Chapter 6: Using Multimedia
Listening to CDs
You can use the CD or DVD drive on your notebook to listen to music CDs.
Listening to CDs in Windows XP
Use the Windows Media Player to listen to CDs in Windows XP. For more
information about using the Windows Media Player, click
use MusicMatch to listen to CDs. See “Using MusicMatch” on page 94 for
more information.
To play a CD:
1 Insert a CD into the CD or DVD drive.
2 If a dialog box opens with a list of CD players, click Windows Media Player.
The Windows Media Player opens.
- OR -
Help. You can also
If a dialog box does not open with a list of CD players, click
click
Windows Media Player. The Windows Media Player opens.
Start, then
86
www.gateway.com
3 When the media player opens, click(play).
Listening to CDs
Play
Stop
PreviousMute
Next
Volume
If you do not hear audio or you want to change the volume, see
“Adjusting the volume” on page 81.
Help and
Support
For more information about playing CDs in Windows XP,
click Start, then click Help and Support.
Type the keyword playing CDs in the HelpSpot Search
box , then click the arrow.
www.gateway.com
87
Chapter 6: Using Multimedia
Listening to CDs in Windows 2000
Use the Windows CD Player to play an audio CD. You can also use
MusicMatch to listen to CDs. See “Using MusicMatch” on page 94 for more
information.
To play a CD:
■ Insert a CD into the CD or DVD drive. The CD Player opens and the CD
plays.
- OR -
If the CD does not start playing automatically, click
Accessories, Entertainment, then click CD Player. When the CD Player
Start, Programs,
opens, click(play).
Pause
Previous
Play
Rewind
Skip
Forward
Stop
Next
Eject
CD
If you do not hear audio or you want to change the volume, see
“Adjusting the volume in Windows 2000” on page 84.
88
www.gateway.com
Recording and playing audio
Recording and playing audio
To play a CD:
1 Plug a microphone into the Microphone jack on your computer. See “Left
side” on page 3 for the location of the Microphone jack.
2 Click Start, All Programs, Accessories, Entertainment, then click Sound
Recorder
. The Sound Recorder opens.
RewindFast Forward Play
Stop
Record
3 Click(record), then speak into the microphone.
4 When you finish recording, click(stop).
5 Click File, then click Save As. The Save As dialog box opens.
6 Name the recording, specify the location where you want to save the
recording, then click
Help and
Support
For more information about recording audio in
Windows XP, click Start, then click Help and Support.
Type the keyword recording audio in the HelpSpot
Search box , then click the arrow.
Save. The recording is saved.
www.gateway.com
89
Chapter 6: Using Multimedia
To play an audio recording in Sound Recorder:
1 Open the Sound Recorder.
2 Click File, then click Open. The Open dialog box opens.
3 Click the file you want to play, then click Open.
4 Play the file by clicking(play), then stop playing the file by
clicking(stop).
Help and
Support
For more information about playing an audio recording in
Windows XP, click Start, then click Help and Support.
Type the keyword playing audio in the HelpSpot Search
box , then click the arrow.
90
www.gateway.com
Playing audio and video files with the Windows Media Player
Playing audio and video files with
the Windows Media Player
The Windows Media Player can play several types of audio and video files,
including WAV, MIDI, MP3, AU, AVI, and MPEG formats. For more
information about using the Windows Media Player, click
To play a file using the Windows Media Player:
1 In Windows XP, click Start, All Programs, then click Windows Media Player.
- OR -
Help.
In Windows 2000, click
click
Windows Media Player.
The Windows Media Player opens.
Play
Stop
Start, Programs, Accessories, Entertainment, then
Video file
information
Video
screen
www.gateway.com
91
Chapter 6: Using Multimedia
2 Click File, then click Open. The Open dialog box opens.
ImportantIf the menu bar does not appear, click the show menu
3 Click the file you want to play, then click Open.
4 Play the file by clicking(play), then stop playing the file by
clicking(stop).
barbutton.
Help and
Support
For more information about playing audio and video using
the Windows Media Player in Windows XP, click Start, then
click Help and Support.
Type the keyword Media Player in the HelpSpot Search
box , then click the arrow.
Playing a DVD
A Digital Versatile Disc (DVD) is similar to a standard CD but has greater data
capacity. Because of this increased capacity, full-length movies, several albums
of music, or several gigabytes of data can fit on a single disc. If your computer
has a DVD drive or a combination DVD/CD-RW drive, you can play DVDs
with the InterVideo DVD Player program or Windows Media Player. For more
information about playing DVDs, click
To play a DVD:
1 Make sure that the speakers are turned on or headphones are plugged in
and that the volume is turned up.
2 Turn off your screen saver and standby timers.
Help in the DVD player program.
92
www.gateway.com
Playing a DVD
3 To play a DVD using InterVideo DVD, click Start, All Programs, DVD, then
click
DVD Player. The InterVideo DVD Player video screen and control
panel open.
-OR-
To play a DVD using Windows Media Player in Windows XP, click
All Programs, then click Windows Media Player. The Windows Media Player
Start,
opens.
- OR -
To play a DVD using Windows Media Player in Windows 2000, click
Programs, Accessories, Entertainment, then click Windows Media Player. The
Start,
Windows Media Player opens.
ImportantIf the Intervideo DVD player is not on your Start menu, or
if Windows Media Player cannot play a DVD, you will need
to install the InterVideo DVD program. To install the
InterVideo program, insert the InterVideo DVD Software
disc into your DVD drive and follow the instructions printed
on the disc.
4 Insert a DVD into the DVD drive, then click(play). The DVD plays.
5 To specifically control the DVD or adjust the volume, use the controls
in the DVD player. For more information on using the DVD player, see
its online help.
Help and
Support
For more information about playing DVDs in Windows XP,
click Start, then click Help and Support.
Type the keyword playing DVDs in the HelpSpot Search
box , then click the arrow.
www.gateway.com
93
Chapter 6: Using Multimedia
Using MusicMatch
Using MusicMatch™, you can:
■ Play music CDs
■ Create MP3 music files from your music CDs
■ Edit music track information
■ Use your music files to build a music library
■ Listen to Internet Radio
For more information on using MusicMatch, see its online Help.
Playing CDs
You can use the MusicMatch program to play music CDs.
To play a music CD in Windows XP:
94
1 Insert the music CD into the CD or DVD drive on your computer. The
first time you insert an audio CD, the Audio CD dialog box opens.
www.gateway.com
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
