nüvi® 2575R/ 2575
quick start manual
Connecting the Device to Vehicle Power
WARNING
This product contains a lithium-ion battery. To prevent the possibility of personal injury or product damage caused by battery exposure to extreme heat, remove the device from the vehicle when exiting or store it out of direct sunlight.
Charge your device before using it on battery power.
1.Fit the bottom of your device into the mount.
2.Tilt your device back until it snaps into place.
3.Plug the vehicle power cable into the mini-USB connector on the mount.
4.Plug the other end of the vehicle power cable into a power outlet in your vehicle.
2 |
nüvi 2575R/ 2575 Quick Start Manual |
5.If you are using a traffic receiver
, connect the external antenna to the traffic receiver and secure it to the windshield using the suction cups.
6.There is an optional choice for video in connector , connecting rear view camera and driving recorder connector .
After the device has been connected to vehicle power, the following occurs.
•The device turns on.
•The device acquires satellite signals. When at least one of the
bars is green, your device has acquired satellite signals.
•NOTE: The device may need a clear view of the sky to acquire satellite signals.
•The device charges as you drive. in the status bar indicates the status of the internal battery.
Mounting Your Device
1.Remove the clear plastic from the suction cup.
2.Clean and dry your windshield and the suction cup with a lintfree cloth.
3.Press the suction cup to the windshield.
4.While pressing, flip the lever back toward the windshield.
5.Snap the mount onto the suction cup arm .
nüvi 2575R/ 2575 Quick Start Manual |
3 |
Device Overview |
• To turn off your device, touch |
|
Off. |
• To reset the device, hold the Power key for 10 seconds.
•To exit the menu, press and
|
|
|
|
release the Power key. |
||
|
|
About Points of Interest |
||||
|
|
|
|
|||
|
|
Power key |
|
The detailed maps loaded in your |
||
|
|
microSD™ card slot |
|
device contain points of interest, |
||
|
|
|
|
such as restaurants, hotels, and auto |
||
|
|
Analogue television |
|
|||
|
|
services. |
||||
|
|
receiver |
|
|||
|
|
External TV |
|
Finding a Point of Interest by |
||
|
|
antenna connector |
|
|||
|
|
|
Category |
|||
|
|
|
|
|||
Using the Power Key |
1. |
From the Main menu, touch |
||||
1. Press and quickly release the |
|
Where To? > Points of Interest. |
||||
|
Power key to view additional |
2. |
Select a category. |
|||
|
options. |
3. |
If necessary, select a subcategory. |
|||
2. |
Select an option: |
|||||
4. |
Select a destination. |
|||||
|
• To adjust screen brightness, |
|||||
|
5. |
Touch Go!. |
||||
|
|
touch and drag the scroll bar. |
||||
|
|
|
|
4 |
nüvi 2575R/ 2575 Quick Start Manual |
