FUNAI MGD134 User Manual

COLOR TV/DVD

MGD134 (13 inch)

OWNER’S MANUAL

As an ENERGY STAR

Partner, our company has determined that this product meets the E

NERGY STAR guidelines for

energy efficiency. E

NERGY STAR

is a U.S. registered mark.

If you need additional assistance for set-up or operating after

reading owner’s manual, please call TOLL FREE : 1-800-605-8610.

Or visit our WEB SITE at

http://www.funai-corp.com

Please read before using this equipment

–2–

0C28

1.Read instructions-All the safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions should be followed.

5.Cleaning-Unplug TV/DVD from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by the TV/DVD manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/DVD near waterfor example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this TV/DVD on an unstable cart, stand, tripod, bracket, or table. The TV/DVD may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/DVD. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

9. Ventilation-Slots and openings in the cabinet and the back or bottom are provided for ventilation and to ensure reliable operation of the TV/DVD and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/DVD on a bed, sofa, rug, or other similar surface. This TV/DVD should never be placed near or over a radiator or heat register. This TV/DVD should not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This TV/DVD should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/DVDs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This TV/DVD is equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

The caution marking is located on the rear of the cabinet.

IMPORTANT SAFEGUARDS

PORTABLE CART WARNING

AVERTISSEMENT POUR UNE

TABLE ROULANTE PORTATIVE

S3126A

–3–

0C28

EXAMPLE OF ANTENNA GROUNDING AS PER

12.Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the TV/DVD, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/DVD receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/DVD due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind into this TV/DVD through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/DVD.

18.Servicing-Do not attempt to service this TV/DVD yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/DVD from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the

TV/DVD.

c. If the TV/DVD has been exposed to rain or water. d. If the TV/DVD does not operate normally by following the

operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV/DVD to its normal operation.

e. If the TV/DVD has been dropped or damaged in any way. f. When the TV/DVD exhibits a distinct change in perfor-

mance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other hazards.

21.Safety Check-Upon completion of any service or repairs to this TV/DVD, ask the service technician to perform routine safety checks to determine that the TV/DVD is in proper operating condition.

22.Heat-This TV/DVD product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

NATIONAL ELECTRICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELE CTRICAL CODE

GROUND

CLAMP

ANTENNA

L EAD I N WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDI NG ELECTRODE SYSTEM (NEC ART 250, PART H)

–4–

0C28

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

PRECAUTIONS

The serial number of this product may be found on the back of the unit. No other TV/DVD has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

SUPPLIED ACCESSORIES

Rod Antenna

–5–

0C28

AV OID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

LOCATION

For safe operation and satisfactory performance of your TV/DVD, keep the following in mind when selecting a place for its installation:

•

Shield it from direct sunlight and keep it away from sources of intense heat.

•

Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top or bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

•

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the TV/DVD near strong magnetic fields.

•

Avoid moving TV/DVD to locations where temperature differences are extreme.

•

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.

•

If by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.

•

Do not put your fingers or objects into the TV/DVD disc loading tray.

•

Do not place anything directly on top of the unit.

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place or after heating a cold room or under conditions of high humidity. If a DVD is played in a TV/DVD which has moisture, it may damage the DVD and TV/DVD. Therefore when the condensation occurs inside the unit, turn POWER on and allow at least 2 hours for the unit to dry out.

The following symbols below appear in some headings and notes in this manual, with the following meanings

: Description refers to TV operation (in the TV mode).

: Description refers to playback of DVD video discs

(in the DVD mode).

: Description refers to playback of audio CDs

(in the DVD mode).

: Description refers to playback of MP3 discs

(in the DVD mode).

: Description refers to the items to be set by the

QUICK mode (in the DVD mode).

QUICK

MP3

DVD-V

SYMBOLS USED IN THIS MANUAL

•

If you need to replace these accessories, please refer to the PART NO. under the illustrations and call 1-800605-8610.

•

Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators (Splitter). Contact your local electronics store for these items.

•

We do not recommend the use of universal remote controls. Not all of the functions may be controlled with a universal remote control. If you decide to use a universal remote control with this unit, please be aware that the code number given may not operate this unit. In this case, please call the manufacturer of the universal remote control.

BatteriesRemote Control Unit

2 AA BatteriesNE224UD

Owner’s Manual

1EMN20008

0EMN01755 or 0EMN00673 or 0EMN01599

Owner's Manual

–6–

0C28

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . . . . . . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL

SHOCK AND FIRE . . . . . . . . . . . . . . . . . . . . . .5

SYMBOLS USED IN THIS MANUAL . . . . . . .5

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

C SUPPLIED ACCESSORIES . . . . . . . . . . . . . . .5

C TABLE OF CONTENTS . . . . . . . . . . . . . . . . . .6

C FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

OPERATING CONTROLS AND FUNCTIONS

. . .8

INSTALLING THE BATTERIES . . . . . . . . . . .9

C PREPARATION FOR USE . . . . . . . . . . . . . . .10

ANTENNA/CABLE CONNECTIONS . . . . . . .10

CONNECTING TO EXTERNAL INPUT JACKS

CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS, MD DECK OR DAT DECK (for DVD only) . .11

CONNECTING TO A DOLBY DIGITAL

DECODER (for DVD) . . . . . . . . . . . . . . . . . . .12

TV SECTION

C SET UP FOR USE . . . . . . . . . . . . . . . . . . . . .13

SELECTING THE LANGUAGE . . . . . . . . . . .13

CHANNEL SET UP . . . . . . . . . . . . . . . . . . . . .13

DELETING (OR ADDING) CHANNEL(S) . . .14

C TV OPERATION . . . . . . . . . . . . . . . . . . . . . . .15

WATCHING A TV PROGRAM . . . . . . . . . . . .15

DEGAUSSING . . . . . . . . . . . . . . . . . . . . . . . .15

PICTURE CONTROL . . . . . . . . . . . . . . . . . . .15

SLEEP TIMER . . . . . . . . . . . . . . . . . . . . . . . . .16

CLOSED CAPTION SYSTEM . . . . . . . . . . . .16

V-CHIP SET UP . . . . . . . . . . . . . . . . . . . . . . . .17

VD SECTION

C ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . .19

PLAYABLE DISCS . . . . . . . . . . . . . . . . . . . . .19

DISC TYPES . . . . . . . . . . . . . . . . . . . . . . . . . .19

C PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . .20

BASIC PLAYBACK . . . . . . . . . . . . . . . . . . . .20

GENERAL FEATURES . . . . . . . . . . . . . . . . . .20

DISC MENU . . . . . . . . . . . . . . . . . . . . . . . . . .20

TITLE MENU . . . . . . . . . . . . . . . . . . . . . . . . .20

RESUME . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

PAUSE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

STEP BY STEP PLAYBACK . . . . . . . . . . . . .21

FAST FORWARD/REVERSE SEARCH . . . . .21

SLOW FORWARD / SLOW REVERSE . . . . .21

C SEARCH FUNCTION . . . . . . . . . . . . . . . . . .22

TRACK SEARCH . . . . . . . . . . . . . . . . . . . . . .22

TITLE / CHAPTER SEARCH . . . . . . . . . . . . .22

TIME SEARCH . . . . . . . . . . . . . . . . . . . . . . . .22

MARKER SETUP SCREEN . . . . . . . . . . . . . .22

C SPECIAL PLAYBACK FUNCTION . . . . . . . .23

REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

PROGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . .23

RANDOM PLAYBACK . . . . . . . . . . . . . . . . .23

C PLAYING A MP3 DISC . . . . . . . . . . . . . . . . . .24

MP3 PLAYBACK . . . . . . . . . . . . . . . . . . . . . .24

REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

PROGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . .24

RANDOM PLAYBACK . . . . . . . . . . . . . . . . .24

C CHANGING THE SETTINGS . . . . . . . . . . . .25

SUBTITLE LANGUAGE . . . . . . . . . . . . . . . .25

AUDIO LANGUAGE . . . . . . . . . . . . . . . . . . .25

STEREO SOUND MODE . . . . . . . . . . . . . . . .25

CAMERA ANGLE . . . . . . . . . . . . . . . . . . . . . .25

BLACK LEVEL SETTING . . . . . . . . . . . . . . .25

VIRTUAL SURROUND . . . . . . . . . . . . . . . . .25

C THE ON-SCREEN INFORMATION . . . . . . .26

C CHANGING THE DVD SETUP ITEMS . . . .27

LANGUAGE SETTING . . . . . . . . . . . . . . . . .27

DISPLAY SETTING . . . . . . . . . . . . . . . . . . . .28

AUDIO SETTINGS . . . . . . . . . . . . . . . . . . . . .28

PARENTAL CONTROL . . . . . . . . . . . . . . . . .29

INITIALIZE . . . . . . . . . . . . . . . . . . . . . . . . . . .29

C TROUBLESHOOTING GUIDE . . . . . . . . . . .30

C MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . .32

DISC HANDLING . . . . . . . . . . . . . . . . . . . . . .32

C SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .33

C WARRANTY . . . . . . . . . . . . . . . . . . .Back Cover

–7–

0C28

TV Mode

DVD Mode

¡Dolby Digital sound

This TV/DVD can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for audio CD and MP3

This TV/DVD can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD and MP3

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the TV/DVD for five minutes in the stop mode. When the screen saver program is activated for 15 minutes, the power is automatically turned off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This TV/DVD automatically detects if the loaded disc is DVD, audio CD or MP3 on disc.

¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / Group / All / A-B

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which the play was stopped.

¡Virtual Surround ¡Bit rate indication ¡DRC (Dynamic range control)

You can control the range of sound volume.

•

181 channel capability PLL frequency synthesizer tuner with direct station call

(A converter may be necessary to view scrambled cable channels.)

•

Infrared remote control

•

Trilingual on screen menu display selectable in English, Spanish, or French

¡Sleep Timer

The Sleep Timer function enables you to shut off the power without pressing POWER after a desired time period.

¡Closed Caption Decoder

You may view specially labeled (cc) TV programs, movies, news, etc. with either a dialogue caption or text display added to the program.

¡Auto Shut Off Function

If there is no air signal input from the antenna terminal and no operation for 15 minutes, the TV/DVD will turn itself off automatically.

¡V-CHIP

Enables parents to prevent their children from watching inappropriate material on TV.

FEATURES

–8–

0C28

7. Remote Sensor Window

8. STOP Button

[page 20]

Stops operation of the disc.

9. PREV (SKIP) H Button [page 21]

Plays back from the beginning of the current chapter or track.

SEARCH (REV) E Button (Front Panel) [page 21]

During playback or in the pause mode, press and hold button down

for a few seconds to change

reverse playback speed.

10. PLAY Button [page 20]

Starts playback of the disc contents. Press to change to DVD mode when TV mode.

11. NEXT (SKIP) G Button [page 21]

Plays back from the beginning of the next chapter or track.

SEARCH (FWD) D Button (Front Panel) [page 21]

During playback or in the pause mode, press and hold button down

for a few seconds to change for-

ward playback speed.

12. PAUSE Button [page 21]

Pauses the current disc operation.

13. OPEN/CLOSE Button

[page 20]

Press to insert discs into or remove them from the tray.

14. HEADPHONE Jack

To connect headphone (not supplied) for personal listening.

15. MODE Button

[pages 23-25]

Activates program playback or random playback mode when playing CDs or MP3.

16. Number Buttons TV Mode:

[page 15]

Press two digits to directly access the desired channel. Remember to press 0 before a single digit channel.

+100 Button

Press to select cable channels which are higher than 99.

DVD Mode:

[page 22]

Press to enter the desired number.

+10 Button

Press to enter the desired numbers which are greater than 9.

23 20

13 34

19 18

REV

SLOW

PLAY

STOP

FWD

ENTER

PAUSE

DISC

RETURNTITLESETUP

REPEATSEARCH MODE

CLEAR

MODE

ANGLESUBTITLEAUDIO

DISPLAY

SKIP

SELECT

POWER PICTURE

OPEN/ CLOSE

CH.

VOL.

MUTEV.SURR

SLEEP

123

456

789

0 +10

+100

OPERATING CONTROLS AND FUNCTIONS

TV/DVD FRONT PANEL

REMOTE CONTROL

1. Disc loading tray

2. VIDEO input Jack

[page 11]

Connect to the video output jack of a video camera or VCR.

3. AUDIO L/R input Jacks

[page 11]

Connect to the audio output jacks of a video camera or VCR.

4. POWER Button

[page 13]

Press to turn the power on and off.

5. VOLUME K/L (VOL.m/n) Buttons

Press to control the volume level for the DVD and TV.

6. CHANNEL K/L (CH. K/L) Buttons [page 14]

Press to select memorized channel. Press to change to TV mode when DVD mode.

VIDEO

AUDIO

VOLUME

CHANNEL

STOP PAUSE

OPEN/CLOSE

PLAY

HEADPHONE

PREV NEXT

POWER

742 891011 12 13 146531

–9–

0C28

COAXIAL

ANT.

3938

32. Arrow Buttons TV Mode:

[page 13]

Press to select a setting mode from the menu on the TV screen. Press to select or adjust from a particular menu.

DVD Mode:

[page 20]

Use when making settings while watching the display on a TV screen.

33. DISC MENU Button

[page 20]

Displays the menus in the DVD.

34. SELECT Button

[page 20]

Press to change to TV mode, external input mode or DVD mode.

35. MUTE Button

Press MUTE to turn off the sound portion of the TV program. (Volume level display turns LIGHT RED from LIGHT BLUE.) Press MUTE again or press VOL. m or n to restore sound.

36. PICTURE Button

[page 15]

Press to enter picture adjustment mode.

37. Power cord

Connect to a standard AC outlet (120V/60Hz). NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect to a standard AC outlet.

38. COAXIAL digital audio out Jack (DVD Audio Only)

[pages 11, 12]

Connect to the digital input of an external amplifier or decoder.

39. ANT. in Jack

Connect to an antenna, cable system, or satellite system.

NOTE: When you select the DVD mode by this

button, press PLAY or OPEN/CLOSE first. Otherwise, the DVD features are not operated.

17. SLEEP Button [page 16]

Press SLEEP to display the sleep timer and start the function. The shut off time can be determined by the number of times you press this button. (0, 30, 60, 90, or 120 minutes)

18. REV h Button

[page 21]

Press to view the DVD picture in fast reverse motion. Press PAUSE, then press this button to begin slow motion playback. Press this button repeatedly to change the reverse speed of slow motion.

FWD g Button

[page 21]

Press to fast forward the Disc. Press PAUSE, then press this button to begin slow motion playback. Press this button repeatedly to change the forward speed of slow motion.

19. V.SURR (VIRTUAL SURROUND) Button

[page 25]

Press to set virtual surround on/off.

20. SETUP Button

[pages 13,27-29]

Press to enter or exit the TV menu or DVD setup mode.

21. TITLE Button

[page 20]

Displays the title menu.

22. CLEAR Button

[pages 22-24]

Resets a setting.

23. DISPLAY Button TV Mode:

Press to display the channel number on the screen. If you press it again, the channel number will disappear.

DVD Mode:

[page 26]

Displays the current status on the TV screen for checking purposes.

24. SEARCH MODE Button

[page 22]

Press to locate a desired point.

25. AUDIO Button

[page 25]

Press to select a desired audio language or sound mode.

26. SUBTITLE Button

[page 25]

Press to select a desired subtitle language.

27. REPEAT Button

[page 23]

Repeats playback of the current disc, title, chapter or track.

28. ANGLE Button

[page 25]

Press to change the camera angle to see the sequence being played back from a different angle.

29. REPEAT A-B Button [page 23]

Repeats playback of a selected section.

30. RETURN Button

[page 25]

Returns to the previous operation in the DVD setup mode.

31. ENTER Button

[pages 13, 20]

Press to accept a setting.

TV/DVD REAR VIEW

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

NOTES

¡Do not mix alkaline and manganese batteries. ¡Do not mix old and new batteries.

–10–

0C28

NOTE:

Before plugging the antenna into the ANT. IN jack of the TV/DVD, check that the pin is not bent. If it is bent, straighten the pin as illustrated, then plug the pin into the ANT. IN jack of the TV/DVD.

PREPARATION FOR USE

ANTENNA/CABLE CONNECTIONS

CABLE WITH CONVERTER/DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown here.

Channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/ DVD Remote Control.

TO VIEW A SCRAMBLED/UNSCRAMBLED CHANNEL

1.Set the TV/DVD channel selector to the output channel of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to view on your Cable Converter Box or Satellite Box.

Bent pin

Cable

Plug

(Needs to be straightened)

(Straight pin)

VHF/UHF Antenna (Not supplied)

VHF/UHF Combiner (Not supplied)

Flat twin-lead cable

UHF Antenna (Not supplied)

VHF Antenna (Not supplied)

From Cable System

75-ohm Coaxial Cable (Not supplied)

Satellite Box or Cable Box (Not supplied)

From Cable System or Satellite Dish

VHF/UHF COMBINED ANTENNA

The VHF/UHF Rod Antenna (supplied) is detachable. Insert the stem of the antenna into the hole on the upper-back portion of the TV/DVD. Connect the VHF/UHF Rod Antenna or VHF/UHF Combination Antenna to the ANT. terminal of the TV/DVD as shown in the diagram above. For the best reception, fully extend the VHF/UHF Rod Antenna and make the necessary adjustments. (Avoid touching the top section when adjusting.)

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/DVD without a converter box. Use the TV/ DVD Remote Control to select channels.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

Rod Antenna (Supplied)

OUT

COAXIAL

ANT.

–11–

0C28

CONNECTING TO EXTERNAL INPUT JACKS

When you watch a program recorded on an another source (VCR or video camera), use the audio/video input jacks on the front of the TV/DVD.

Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this TV/DVD. Then press SELECT until "AUX" appears on the screen.

NOTE:

•

When you connect a monaural VCR (another source) to this TV/DVD, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this TV/DVD. The audio will output in both L and R channel equally.

[Another source]

To the audio output jacks

Audio/Video cables (not supplied)

etc.

To the video output jack

[Front of the TV/DVD]

AUX

CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGITAL

INPUT JACKS, MD DECK OR DAT DECK (for DVD only)

Use an audio coaxial digital cable available at retail for the audio connections.

NOTES:

•

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital sound by an MD or DAT deck.

•

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the TV/DVD.

•

Set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a TV/DVD using incorrect settings may generate noise distortion and may also damage the speakers. (See page 28 to set DOLBY DIGITAL to OFF.)

COAXIAL

ANT.

Amplifier equipped with digital

input jacks, MD deck,

DAT deck, etc.

To COAXIAL DIGITAL AUDIO INPUT jack

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack (only DVD AUDIO OUT)

VIDEO

AUDIO

POWER

AUDIO

–12–

CONNECTING TO A DOLBY DIGITAL DECODER (for DVD)

If using this TV/DVD to play a DVD disc in a 5.1 channel Dolby Digital surround format, the TV/DVD outputs a DOLBY DIGITAL Data stream from its COAXIAL digital audio out jack. By hooking the TV/DVD up to a Dolby Digital decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound as enjoyed in movie theaters.

Use audio coaxial digital cables available at retail for the audio connections.

NOTES:

•

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the TV/DVD.

•

If connected to a Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in the setup mode. (See page 28 to set DOLBY DIGITAL to ON.)

•

Unless connected to a Dolby Digital decoder, set DOLBY DIGITAL to OFF for audio output in the setup mode. Playing a TV/DVD using incorrect settings may generate noise distortion and may also damage the speakers.

COAXIAL

ANT.

Front speaker

(left)

Center

speaker

Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack

To COAXIAL DIGITAL AUDIO INPUT jack

Dolby Digital decoder

Manufactured under license from Dolby Laboratories.“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

0C28

–13–

0C28

SELECTING THE LANGUAGE

1 Plug in the TV/DVD power cord

Plug the TV/DVD power cord into a standard AC outlet.

NOTE:

•

If any digits appear in the corner of the screen, press POWER without unplugging the power cord.

Make sure ...

•

Press POWER to turn on the TV/DVD.

NOTE: This function effects only the language on the screen menu and not the audio source.

2 Select “LANGUAGE”

Press SETUP on the remote control. Press Arrow (K/L) to point to

“LANGUAGE”.

3 Select “ENGLISH”, “ESPAÑOL” or “FRANÇAIS”

Select “ENGLISH”, “ESPAÑOL”= Spanish or “FRANÇAIS”= French using ENTER.

4 Exit the Language mode

Press SETUP to return to TV mode. NOTE: If for some reason the menu is in Spanish or

French, press SETUP, press Arrow (K/L) to point to “IDIOMA [ESPAÑOL]” or “LANGAGE [FRANÇAIS]”, then press ENTER, then press SETUP on the remote control.

CHANNEL SET UP

You can program the tuner to scan all the channels you receive in your area.

NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the TV/DVD channel selector to the output channel of the cable box or satellite box (Ex CH3), then select the channel to be viewed on the Cable Box or Satellite Box.

Make sure ...

•

Press POWER to turn on the TV/DVD.

1 Select “CHANNEL SET UP”

Press SETUP on the remote control. Press Arrow (K/L) to point to

“CHANNEL SET UP”. Then press ENTER.

2 Begin auto ch programming

Press Arrow (K/L) to point to “AUTO CH PROGRAMMING”.

Then press ENTER. The tuner scans and memorizes all

the active channels in your area.

3 After scanning

The tuner stops on the lowest memorized channel.

•

When AUTO CH PROGRAMMING is activated where there is no TV signal input, “NO TV SIGNALS” will appear on the display after the completion of the channel scanning.

•

The TV/DVD may recognize TV channels to be CATV channels by the receiving conditions. In this case, try auto ch programming again in the fine receiving conditions.

SET UP FOR USE

TV SECTION

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP

B LANGUAGE [ENGLISH]

CAPTION [OFF]

- TV SETUP -

B CHANNEL SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

– CHANNEL SET UP –

ADD / DELETE CH (CATV)

B AUTO CH PROGRAMMING

–14–

0C28

DELETING (OR ADDING)

CHANNEL(S)

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Press SETUP on the remote control. Press Arrow (K/L) to point to

“CHANNEL SET UP”. Then press ENTER.

2 Select “ADD/DELETE CH”

Press Arrow (K/L) to point to “ADD/DELETE CH”.

Press ENTER.

3 Enter the desired channel number

Press Arrow (K/L) until your desired channel number appears. (You can also use the number buttons or CHANNEL(CH.) K/L to enter it) (Example: CH8)

•

You must precede single-digit channel numbers with a zero (Example: 02 ... 09).

•

When selecting cable channels which are higher than 99, press +100 first, then press the last two digits. (Example: to select channel 125, first press +100, then press 2 and 5).

4 Delete (or add) it from (into) memory

Press ENTER. The channel number changes to light red. The channel is deleted from memory.

•

To delete another channel, repeat steps [3] and [4].

•

If you press ENTER again, the channel is memorized again.

5 Exit the channel setup mode

Press SETUP to return to TV mode. NOTE: To confirm that channel(s) has been deleted

or added, press CHANNEL(CH.) K/L.

- TV SETUP -

B CHANNEL SET UP

V-CHIP SET UP LANGUAGE [ENGLISH] CAPTION [OFF]

Added channel: Light blue. Deleted channel: Light red.

ADD / DELETE

– CHANNEL SET UP –

B ADD / DELETE CH (CATV)

AUTO CH PROGRAMMING

–15–

0C28

DEGAUSSING

Magnetism from nearby appliances and speakers might affect the color of the TV picture.

If this happens, move this unit away from the appliance. If the color is still not correct, disconnect power cord from AC outlet then reconnect it after 30 minutes.

WATCHING A TV PROGRAM

1 Turn on the TV/DVD

Press POWER to turn on the TV/DVD.

2 Select the channel number

Press CHANNEL(CH.) K/L to select your desired channel number, or press the number buttons.

Notes for using the number buttons on the remote control:

•

You must precede single-digit channel numbers with a zero (Example: 02 ... 09).

•

When selecting cable channels which are higher than 99, press +100 first, then press the last two digits. (Example: to select channel 125, first press +100, then press 2 and 5).

Remember:

¡If the TV/DVD is connected to a cable box or

satellite box, the TV/DVD must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press VOLUME(VOL.) XX/YYto adjust the volume.

NOTE:

•

If you press CHANNEL(CH.) K/L in the DVD mode, you can change the TV channels.

Even if you turn off the TV/DVD in the DVD mode, when you turn it on again, it will go into the TV mode.

PICTURE CONTROL

The TV/DVD’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS – are

preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a more natural looking image.

Make sure ...

•

TV/DVD power must be turned on.

1 Select “PICTURE CONTROL”

Press PICTURE on the remote control.

2 Select item you want to adjust

Press Arrow (K/L) until desired control is displayed.

BRIGHT CONTRAST COLOR TINT SHARPNESS

3 Adjust the picture control

Press Arrow (s / B) to adjust to your desired level within 5 seconds.

NOTE:

•

At step [3], the picture adjustment display will disappear from the TV screen after about 5 seconds unless you press any buttons, even though you may not be finished. In this case, repeat from step [1].

•

If there is a power failure of any kind, the unit will retain its memory for this feature.

VOLUME 20

C C C C C C C C C C C C C C C C

BRIGHT

–

PPPP PP PP PP PPPP CC PP PP PP PP PP PP PP

TV OPERATION

to decrease brightness

to decrease contrast

to pale to brilliant

to green

to clear

to purple

to soft

to increase brightness

to increase contrast

BRIGHT

CONTRAST

COLOR

TINT

SHAPNESS

Arrow Button { Arrow Button B

–16–

0C28

CLOSED CAPTION SYSTEM

You can view specially labeled (cc) TV programs, movies, news, etc. with either a dialogue caption or text display.

CAPTION mode: By choosing the caption mode, you

can watch dramas, movies and news while captioning the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can

watch half screen text information if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is used, usually for a second language if available.

NOTE:

Not all programs are broadcast with closed captions. Your television is designed to provide error free closed captions from high quality antenna, cable and VCR signals. Conversely, poor quality signals are likely to result in caption errors or no captions at all. Common signal conditions which may cause captions errors are listed below:

•

Automobile ignition noise

•

Electric motor brush noise

•

Weak snowy reception on TV screen

•

Multiplex signal reception displaying picture ghosts or airplane flutter.

NOTE:

If the TV/DVD displays a black box on the TV screen, this means that the TV/DVD is set to the TEXT mode. To clear screen, select [CAPTION1], [CAPTION2] or [OFF].

Make sure ...

•

TV/DVD power must be turned on.

1 Select “CAPTION”

Press SETUP on the remote control. Press K or L to point to “CAP-

TION”.

2 Select your desired caption menu

Press ENTER until your desired caption menu appears.

([CAPTION1], [CAPTION2], [TEXT1] or [TEXT2])

3 Exit the caption setting mode

Press SETUP to return to TV mode.

TO CANCEL THE CLOSED CAPTION SYSTEM

Repeat steps [1] and [2], select [OFF] using ENTER. Press SETUP on the remote control to return to TV mode.

WHEN THE CLOSED CAPTION MODE IS ON

The On-Screen Display will disappear after 5 seconds.

•

This is also true when MUTE is pressed.

•

If there is a power failure of any kind, the unit will retain its memory for this feature.

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [OFF]

- TV SETUP -

CHANNEL SET UP V-CHIP SET UP LANGUAGE [ENGLISH]

B CAPTION [CAPTION1]

he Sleep Timer function enables you to shut off the power

without pressing POWER after a desired time period.

1 Set “SLEEP TIMER”

Press SLEEP on the remote control. You may change the sleep time with pressing SLEEP repeatedly. The timer is set up to 120 minutes, 30 minutes each time SLEEP is pressed.

NOTES:

•

When you disconnect the unit from the AC outlet, or if you have a power failure, the sleep time will be lost.

•

To view the time left for sleep timer press SLEEP once when SLEEP display disappears. After 10 seconds, display will disappear again.

To cancel the sleep timer:

Press SLEEP repeatedly until “SLEEP 0 MINUTE” is displayed.

SLEEP 120 MINUTE

SLEEP TIMER

–17–

0C28

V-CHIP SET UP

V-CHIP enables parents to prevent their children from watching inappropriate material on TV.

V-CHIP reads the ratings for programming (except for news and sports programs, unedited movies on premium cable channels, and Emergency Broadcast System signals), then denies access to programming if the program’s rating meets the limitations you select. In this case, “PROTECTED PROGRAM by ...” message appears on the TV screen.

To block ratings, follow the steps below.

•

Programming may be rated by the Motion Picture Association of America (MPAA) or according to the Television Parental Guidelines. In order to block any inappropriate programming, set your limits in both places (MPAA RATING and TV RATING).

TV RATING SET UP

Make sure ...

•

TV/DVD power must be turned on.

1 Select “V-CHIP SET UP”

Press SETUP on the remote control. Press Arrow (K/L) to point to “V-

CHIP SET UP”. Then press ENTER.

2 Input Access code

Press the number buttons to enter 4digit access code. The default code is 0000.

3 Select “TV RATING”

Press Arrow (K/L) to point to “TV RATING”.

Then press ENTER.

4 Select your desired item

Press Arrow (K/L) to point to your desired item.

Then press ENTER to select [BLOCK] or [VIEW].

Selection Rating Category Explanations

TV-Y Appropriate for all children TV-Y7 Appropriate for children seven and older TV-G General Audience TV-PG Parental Guidance suggested. TV-14 Unsuitable for children under 14

TV-MA Mature audience only

•

When you select a rating category and turn it [BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

•

When you turn “TV-Y” to [VIEW], all ratings will turn to [VIEW] automatically.

- TV SETUP -

CHANNEL SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF]

ACCESS CODE

_ _ _ _

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG ( ) [VIEW] TV–14 ( ) [VIEW] TV–MA( ) [VIEW]

– V-CHIP SET UP –

B TV RATING

MPAA RATING CHANGE CODE

When you select TV-Y7, TV-PG, TV-14 or TV-MA and you press ENTER, the sub-ratings will appear on the TV screen.

If you select the rating category (example: TV-PG) and turn it [BLOCK] or [VIEW], the sub-ratings (example: V for Violence) will turn [BLOCK] or [VIEW] automatically.

You can set the sub-ratings to [BLOCK] or [VIEW] individually when the rating category is set to [BLOCK].

To set the sub-ratings individually, follow the steps below.

•

When you select [TV-Y7]:

Press Arrow (K/L) to select “FV” (Fantasy Violence). Then press ENTER to select [BLOCK] or [VIEW].

•

When you select [TV-PG], [TV-14] or [TV-MA]:

Press Arrow (K/L) to select “D”(Suggestive Dialog), “L”(Coarse Language), “S”(Sexual Situation), or “V”(Violence). Then press ENTER to select [BLOCK] or [VIEW].

NOTE: When you select [TV-MA], “D” does not appear on the TV screen.

•

The sub-ratings which set to [BLOCK] appears next to the rating category in the TV RATING menu.

5 Exit the V-Chip setting mode

Press SETUP on the remote control to return to original mode.

TV–Y7 [BLOCK]

B FV [BLOCK]

TV–PG [BLOCK]

B D [BLOCK]

L [BLOCK] S [BLOCK] V [BLOCK]

B TV–Y [VIEW]

TV–Y7 ( ) [VIEW] TV–G [VIEW] TV–PG (DLSV) [BLOCK] TV–14 (DLSV ) [BLOCK] TV–MA ( LSV) [BLOCK]

–18–

0C28

4 Select your desired item

Press Arrow (K/L) to point to your desired item.

Then press ENTER to select [BLOCK] or [VIEW].

•

When you select the rating category and turn it [BLOCK], the higher rating will turn [BLOCK] automatically. Also, the lower rating will turn [VIEW] automatically.

•

When you turn “G” to [VIEW], all ratings will turn to [VIEW] automatically.

5 Exit the V-Chip setting mode

Press SETUP on the remote control to return to original mode.

MPAA RATING SET UP

Make sure ...

•

TV/DVD power must be turned on.

1 Select “V-CHIP SET UP”

Press SETUP on the remote control. Press Arrow (K/L) to point to “V-

CHIP SET UP”. Then press ENTER.

2 Enter 4-digit access code

Press the number buttons. The default code is 0000.

3 Select “MPAA RATING”

Press Arrow (K/L) to point to “MPAA RATING”.

Then press ENTER.

Selection Rating Category Explanations

G General Audience PG Parental Guidance suggested. PG-13 Unsuitable for children under 13 R Restricted; under 17 requires accompa-

nying parent or adult guardian

NC-17 No one under 17 admitted X Mature audience only

- TV SETUP -

CHANNEL SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF]

– V-CHIP SET UP –

TV RATING

B MPAA RATING

CHANGE CODE

G [VIEW] PG [VIEW] PG–13 [VIEW]

B R [BLOCK]

NC–17 [BLOCK] X [BLOCK]

ACCESS CODE

_ _ _ _

CHANGE ACCESS CODE

To change access code, follow the steps.

1 Select “V-CHIP SET UP”

Press SETUP on the remote control.

Press Arrow (K/L) to point to “VCHIP SET UP”.

Then press ENTER.

2 Enter 4-digit access code

Press the number buttons. The default code is 0000.

3 Select “CHANGE CODE”

Press Arrow (K/L) to point to “CHANGE CODE". Then press ENTER.

4 Enter 4-digit access code

Press the number buttons to enter your desired access code in the NEW CODE space. Then enter the same code in the CONFIRM CODE space. V-CHIP SET UP screen appear on the screen.

•

If you enter wrong code, repeat step 4, making sure you enter the same new code exactly in the confirm code space.

5 Exit the V-Chip setting mode

Press SETUP on the remote control to return to original mode.

NOTE:

•

If you unplug the power cord or power failure occurs, the changed access code will be lost and will return to default (0000). Change your access code again as necessary.

- TV SETUP -

CHANNEL SET UP

B V-CHIP SET UP

LANGUAGE [ENGLISH] CAPTION [OFF]

ACCESS CODE

_ _ _ _

– V-CHIP SET UP –

TV RATING MPAA RATING

B CHANGE CODE

NEW CODE

_ _ _ _

CONFIRM CODE

_ _ _ _

–19–

0C28

DVD SECTION

ABOUT THE DISCS

The following discs can be played back on this TV/DVD.

DVD video

DVD-R/RW*

DVD+R/RW*

Audio CD

CD-R/RW*

MP3*

* Depending on the types or the writing method of the

medium some discs can not be played.

• Some DVD-R/RW, DVD+R/RW, or CD-R/RW discs made on personal computers or on DVD recorders may not be played back properly due to the factors such as scratches, dirt or special properties of the disc.

• Discs made on personal computers may not be played back properly due to the different environment or the settings of the application you use. We recommend always to use the standardized, rightly formatted discs. (Please contact the sales agency for more detail).

This TV/DVD conforms to the NTSC color system. You cannot play discs recorded in other color systems such as PA L or SECAM.

¡Some discs include region codes as shown below.

¡The number inside the symbol refers to a region of the

world, and a disc encoded in a specific region format can only be played back on TV/DVD with the same region code.

The following discs cannot be played back on this TV/DVD.

DVD with region codes other than 1 or ALL

DVD-ROM

DVD-RAM (Never play back, otherwise malfunc-

tion may result.)

CD-ROM

VSD

CDV (Only plays back the audio part.)

CD-G (Only plays back the sound.)

CD-I (Never play back, otherwise malfunction

may result.)

SACD

Photo CD (Never play back, otherwise malfunc-

tion may result.)

Video CD (Never play back, otherwise malfunc-

tion may result.)

Any other discs without compatibility indications.

PLAYABLE DISCS

[

DVD

]

Data on a DVD is divided into sections called "titles" and then into subsections called "chapters", each of which is given a title or chapter number. Playback conditions are preset on some DVD video discs and these playback conditions take priority over user operations on this TV/DVD. If a function you selected does not run as desired, refer to the manual accompanying the disc.

DISC TYPES

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2Chapter 3 Chapter 4

[

AUDIO CD

]

Data on an audio CD is divided into sections called “tracks”, each of which is given a track number.

Example

Track 1 Track 2 Track 3 Track 4 Track 5 Track 6

[

MP3

]

Data on an MP3 is divided into sections called "groups", and then into subsections called "tracks", each of which is given a group or track number.

Example

Group 1 Group 2

Track 1 Track 2 Track 5 Track 6Track 3 Track 4

–20–

0C28

BASIC PLAYBACK

Getting started

¡Turn on the power of amplifier and any other com-

ponents, if necessary.

1 Press POWER.

The power will turn on.

2 Press OPEN/CLOSE to open disc loading

tray.

3 Place the chosen disc in the tray, with the

label facing up.

MP3CD

DVD-V

PLAYING A DISC

4 Press PLAY.

The tray will close automatically and playback will then start from the first chapter or track of the disc. If the playback does not start automatically, press PLAY.

¡When you playback a DVD which features a title

menu, it may appear on the screen. In this case, refer to “TITLE MENU”.

5 Press STOP to stop playback.

NOTES

¡When the DVD mode has been switched to the TV

mode, the DVD mode shuts down first and then TV picture and sound appears in about 4 seconds. Similarly, when POWER is pressed to turn off in the DVD mode, this mode shuts down first and then the TV/DVD’s power is turned off.

¡A “prohibited icon” may appear at

the top-right on the TV screen during operation, warning that a prohibited operation has been encountered by the DVD or the disc.

¡With DVDs that use titles for playback program sig-

nals, playback may start from the second title, or it may skip these titles.

¡During the playback of a two layered disc, pictures

may stop for a moment. This happens when the 1st layer switches to the 2nd layer. This is not a malfunction.

GENERAL FEATURES

DVD may contain menus to navigate the disc and access special features. Press appropriate number buttons or use Arrow (K/L/s/B) to highlight your selection in the DVD main menu and press ENTER to confirm.

NOTES

¡Select DVD mode by pressing SELECT on the

remote control. Then press PLAY or OPEN/CLOSE before you operate the DVD functions.

¡Unless stated, all operations described are based on

remote control use. Some operations can be carried out using the menu bar on the TV screen.

DVD-V

TITLE MENU

1 Press TITLE on the remote control.

The title menu will appear.

2 If the feature is not available, symbol

may appear on the TV screen.

3 Press Arrow (K/L/s/B) to select an item

and ENTER to confirm selection.

DVD-V

DISC MENU

1 Press DISC MENU on the remote control.

The DVD main menu will appear.

2 If the feature is not available, symbol

may appear on the TV screen.

3 If disc menu is available on the disc, audio

language, subtitle options, chapters for the title and other options will appear for selection.

4 Press Arrow (K/L/s/B) to select an item

and ENTER to confirm selection.

DVD-V

CALLING UP A MENU SCREEN DURING PLAYBACK

For DVD-Vs

¡Press DISC MENU to call up the DVD menu. ¡Press TITLE to call up the title menu.

NOTE

¡Contents of menus and corresponding menu opera-

tions may vary between discs. Refer to the manual accompanying the disc for details.

–21–

0C28

STEP BY STEP PLAYBACK

1 During playback, press PAUSE.

Playback will pause and sound will be muted.

2 The disc goes forward by one frame each

time PAUSE is pressed.

3 To exit step by step playback, press PLAY.

DVD-V

RESUME

1 During playback, press STOP.

Resume message will appear on the TV screen.

2 Press PLAY, playback will resume from the

point at which playback was stopped.

To cancel resume, press STOP twice.

¡If TV/DVD is turned off, resume function will be

cancelled.

¡For MP3, playback will resume from the beginning

of the track at which playback was stopped.

MP3CD

DVD-V

1 During playback, press FWD g or REV

h .

“ g 1” or “h 1” appears on the screen.

2 To select another speed, repeat step1 until

your required speed appears on the screen.

For DVDs, fast forward/reverse search speed is different depending on the disc. Approximate speed is 1(×2), 2(×8), 3(×50) and 4(×100).

¡For audio CDs, approximate speed is ×16. ¡For MP3, approximate speed is ×8 ¡When you use buttons on the TV/DVD front panel,

press and hold NEXT G / SEARCH g or PREV H / SEARCH h for a few seconds.

3 To return to normal playback, press PLAY.

MP3CD

DVD-V

FAST FORWARD/REVERSE

SLOW FORWARD /

SLOW REVERSE

1 During playback, press PAUSE.

2 Press FWD g or REV h .

“ 1” or “ 1” appears on the screen.

3 To select another speed, repeat step2 until

your required speed appears on the screen.

Slow forward or reverse speed varies with the disc. Approximate speed is 1(1/16), 2(1/8) and 3(1/2).

¡When you use buttons on the TV/DVD front panel,

press and hold NEXT G / SEARCH g or PREV H / SEARCH h for a few seconds.

4 To return to normal playback, press PLAY.

DVD-V

PAUSE

1 During playback, press PAUSE.

Playback will pause and sound will be muted.

2 To continue playback, press PLAY.

MP3CD

DVD-V

+ 47 hidden pages
